Alpine Cde 143Bt Users Manual SXM145BT/CDE 143BT/UTE 42BT

2014-12-12

: Alpine Alpine-Cde-143Bt-Users-Manual-118856 alpine-cde-143bt-users-manual-118856 alpine pdf

Open the PDF directly: View PDF PDF.
Page Count: 47

Designed by ALPINE Japan
68-21627Z76-A
•OWNER’S MANUAL
Please read before using this equipment.
•MODE D’EMPLOI
Veuillez lire avant d’utiliser cet appareil.
•MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
777 Supertest Road, Toronto,
Ontario M3J 2M9, Canada
Phone 1-800-ALPINE-1 (1-800-257-4631)
EN
FR
ES
RR
Thank you for purchasing this Alpine product. Please take a moment to protect your purchase by
registering your product now at the following address: www.alpine-usa.com/registration.
You will be informed of product and software updates (if applicable), special promotions, news
about Alpine, and entered for a chance to win prizes.
Merci d’avoir acheté ce produit Alpine. Nous vous invitons à consacrer un moment à la protection
de votre achat en enregistrant votre produit dès maintenant à l’adresse suivante :
www.alpine-usa.com/registration.
Vous serez tenu informé des mises à jour des produits et des logiciels (le cas échéant), des
promotions spéciales, de l’actualité d’Alpine, et vous aurez une chance de remporter des prix.
Gracias por adquirir este producto Alpine. Con solo unos pocos pasos podrá proteger su producto,
registrándolo a través de la siguiente dirección: www.alpine-usa.com/registration.
Recibirá información sobre nuevos productos y software, promociones especiales, novedades sobre
Alpine y participará en el sorteo de premios.
CD/USB/ADVANCED BLUETOOTH WITH SiriusXM Tuner
CDE-SXM145BT
CD/USB RECEIVER WITH ADVANCED BLUETOOTH
CDE-143BT
USB RECEIVER WITH ADVANCED BLUETOOTH
UTE-42BT
(CDE-SXM145BT only)
ALPINE ELECTRONICS MARKETING, INC.
1-7, Yukigaya-Otsukamachi, Ota-ku,
Tokyo 145-0067, JAPAN
Phone: 03-5499-4531
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue de la Belle Etoile, Z.I. Paris Nord Il,
B.P. 50016, 95945 Roissy Charles de Gaulle
Cedex, France
Phone 01-48638989
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
161-165 Princes Highway, Hallam
Victoria 3803, Australia
Phone 03-8787-1200
ALPINE ELECTRONICS GmbH
Wilhelm-Wagenfeld-Str. 1-3, 80807 München, Germany
Phone 089-32 42 640
ALPINE ELECTRONICS OF U.K. LTD.
Alpine House
Fletchamstead Highway, Coventry CV4 9TW, U.K.
Phone 0870-33 33 763
ALPINE ITALIA S.p.A.
Viale C. Colombo 8, 20090 Trezzano
Sul Naviglio (MI), Italy
Phone 02-484781
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava)-APDO 133, Spain
Phone 945-283588
3-EN
Contents ENGLISH
Operating Instructions
WARNING
WARNING....................................................... 6
CAUTION ........................................................ 6
PRECAUTIONS ............................................... 6
Getting Started
Accessory List ...............................................................9
Turning Power On and Off.......................................9
Source Selection..........................................................9
Detaching and Attaching the Front Panel .........9
Detaching ..................................................................9
Attaching ...................................................................9
Initial System Start-Up............................................ 10
Adjusting Volume .................................................... 10
Setting Time............................................................... 10
Radio
Listening to Radio.................................................... 11
Presetting Stations Manually............................... 11
Presetting Stations Automatically...................... 11
Tuning to Preset Stations ...................................... 11
Frequency Search Function.................................. 11
CD/MP3/WMA
(CDE-SXM145BT/CDE-143BT only)
Playback ...................................................................... 12
Repeat Play................................................................. 12
M.I.X. (Random Play) ............................................... 12
Searching for CD Text ............................................. 12
Folder/File Name Search
(concerning MP3/WMA) ........................................ 13
Folder Name Search mode............................... 13
File Name Search mode..................................... 13
Search Position Memory ....................................... 13
About MP3/WMA ..................................................... 13
Terminology........................................................... 14
Sound Setting
Adjusting Subwoofer Level/Bass Level/Mid
Level/Treble Level/Balance (Between Left and
Right)/Fader (Between Front and Rear)/
Defeat............................................................................15
Audio Setup................................................................15
Equalizer Presets (F-EQ)......................................15
Adjusting the Parametric Equalizer Curve
(3BAND EQ).............................................................16
Setting the Bass Control ..........................................16
Setting the Mid Control ...........................................16
Setting the Treble Control.......................................16
Setting the Source Volume Level....................17
Adjusting the High Pass Filter ..........................17
Turning Subwoofer ON/OFF.............................17
Adjusting the Low Pass Filter ...........................17
Setting the Subwoofer Phase...........................17
Setting the Subwoofer System........................17
External Device......................................................17
Connecting to an External Amplifier
(POWER IC)....................................................................17
Setting the MX Level ...........................................18
Other Functions
Displaying the Text...................................................18
About “Text” ...........................................................19
Using the Front AUX Input Terminal..................19
Option Menu Setting ..............................................19
SETUP
Setting ..........................................................................20
General Setting .....................................................21
Setting the AUX SETUP mode................................21
Setting the AUX NAME mode ................................21
Playing MP3/WMA Data (PLAY MODE)
(CDE-SXM145BT/CDE-143BT only).......................21
Demonstration ............................................................21
Display Setting ......................................................21
Dimmer Control ..........................................................21
Scroll Setting (TEXTSCROLL) ..................................21
Scroll Type Setting .....................................................21
Tuner Setting..........................................................22
Setting the TUNER (FM) tone quality ..................22
iPod/iPhone Setting ............................................22
iPod/iPhone Search Mode Setting.......................22
4-EN
Contents ENGLISH
BLUETOOTH Operation
Setup Before Using.................................................. 22
About BLUETOOTH.............................................. 22
Before Using BLUETOOTH Function .............. 22
How to connect to a BLUETOOTH
compatible device (Pairing) ............................. 23
Pairing a BLUETOOTH compatible device with
SSP (Secure Simple Pairing)....................................23
Pairing a BLUETOOTH compatible device
without SSP (Secure Simple Pairing)...................23
BLUETOOTH SETUP.................................................. 23
Setting the BLUETOOTH Connection
(BT IN) ....................................................................... 23
Setting the BLUETOOTH Device ..................... 23
Setting the Visible Mode................................... 24
Setting the BLUETOOTH sound quality........ 24
Adjusting the volume (VOL LV ADJ)....................24
Sound Auto setting (TYPE SET).............................24
Setting the caller information display
ON/OFF.................................................................... 24
Setting the Phone Book Update..................... 24
Setting the Phone Book Auto Update ON/OFF
(AUTO) ............................................................................24
Setting the Phone Book Manual Update ON/OFF
(MANUAL)......................................................................24
Changing the Phone book List Order........... 24
Setting the Received Calls automatically
(Auto Answer)........................................................ 25
Selecting the output speaker .......................... 25
Displaying the firmware version..................... 25
Updating the firmware ...................................... 25
Hands-Free Phone Control ................................... 25
About the Hands-Free Phone.......................... 25
Answering a Call................................................... 25
Hanging up the Telephone .............................. 25
Voice Control Operation.................................... 25
Calling ...................................................................... 26
Redialing a Number In Outgoing History..........26
Dialing a Number In Incoming History...............26
Dialing a Number In Incoming Missed Call
History ............................................................................26
Dialing a Number In The Phone Book ................26
Phone book alphabet search function ...............26
Call waiting function........................................... 27
Preset a number in the Phone Book
(Shortcut dial)........................................................ 27
Dialing the preset number ............................... 27
Adjusting the volume when receiving a
Call............................................................................. 27
Muting the microphone input quickly
(Voice Mute)........................................................... 27
Call Switching Operation .................................. 27
BLUETOOTH Audio Operation..............................28
Recalling the BLUETOOTH Audio Mode .......28
Selecting the desired Song ..............................28
Selecting the Desired Group (Folder)............28
Pausing.....................................................................28
Displaying the Text ..............................................28
Flash Memory (optional)
Playing MP3/WMA Files from Flash Memory
(optional) .....................................................................28
Flash Memory Connection (optional) ...............29
Connect Flash Memory ......................................29
Remove Flash Memory.......................................29
About MP3/WMA File of Flash Memory ...........29
iPod/iPhone (optional)
Connecting an iPod/iPhone..................................29
Setting the iPod Control.........................................30
Playback .......................................................................30
Searching for a desired Song ...............................30
Alphabet search function ......................................31
Direct Search Function ...........................................31
Change Playlist/Artist/Album/Genre/
Composer ....................................................................31
Random Play Shuffle (M.I.X.).................................31
Repeat Play .................................................................32
SiriusXM Satellite Radio Operation
(CDE-SXM145BT only)
Receiving Channels with the SiriusXM
Tuner .............................................................................32
SiriusXM Setting (CDE-SXM145BT Only) ..........32
Managing Artist and Song Alerts ...................33
Setting the Favorite Sports Team Alerts.......33
Setting the Parental Control.............................33
Confirming the strength of the SiriusXM
signal.........................................................................34
Setting Tune Start.................................................34
Checking the SiriusXM Radio ID Number ........34
Storing Channel Presets .........................................34
Tuning Channels using Presets............................34
Storing the desired Artist and Song Alerts......34
Tune Scan Function .................................................35
Tune Start Function .................................................35
Receiving and Tuning to an Alert .......................35
5-EN
Contents ENGLISH
Note
• The description related with Disc on this Owner’s Manual is only
applicable to CDE-SXM145BT/CDE-143BT.
Search Function........................................................ 35
Searching by Channel ........................................ 35
Searching by My Music ...................................... 35
Searching by My Games .................................... 36
Searching by Featured Favorites .................... 36
Using Jump Memory and Jump Recall
function ....................................................................... 36
Replay Function........................................................ 36
Parental Lock Function........................................... 36
Storing iTunes Tagging information ................. 37
Changing the Display............................................. 37
Information
In Case of Difficulty.................................................. 37
Basic.......................................................................... 37
Radio......................................................................... 37
CD (CDE-SXM145BT/CDE-143BT only) ......... 37
MP3/WMA............................................................... 38
Audio........................................................................ 38
iPod ........................................................................... 38
Indication for CD Player
(CDE-SXM145BT/CDE-143BT only) ................ 38
Indication for Flash Memory............................ 38
Indication for iPod Mode................................... 39
BLUETOOTH mode............................................... 39
SiriusXM Advisory Messages
(CDE-SXM145BT only) ........................................ 39
Specifications ............................................................ 41
Installation and Connections
WARNING..................................................... 42
CAUTION ...................................................... 42
PRECAUTIONS ............................................. 42
Installation.................................................................. 43
Removal................................................................... 43
Mounting the Microphone................................... 43
Connections............................................................... 44
LIMITED WARRANTY
6-EN
Operating Instructions
WARNING
This symbol means important instructions. Failure
to heed them can result in serious injury or death.
DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR ATTENTION AWAY
FROM SAFELY DRIVING YOUR VEHICLE.
Any function that requires your prolonged attention should only be
performed after coming to a complete stop. Always stop the vehicle
in a safe location before performing these functions. Failure to do so
may result in an accident.
KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL HEAR OUTSIDE
NOISES WHILE DRIVING.
Excessive volume levels that obscure sounds such as emergency
vehicle sirens or road warning signals (train crossings, etc.) can be
dangerous and may result in an accident. LISTENING AT LOUD
VOLUME LEVELS IN A CAR MAY ALSO CAUSE HEARING
DAMAGE.
DO NOT DISASSEMBLE OR ALTER.
Doing so may result in an accident, fire or electric shock.
USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.
(Check with your dealer if you are not sure.) Failure to do so may
result in fire, etc.
KEEP SMALL OBJECTS SUCH AS BATTERIES OUT OF THE REACH OF
CHILDREN.
Swallowing them may result in serious injury. If swallowed, consult
a physician immediately.
USE THE CORRECT AMPERE RATING WHEN REPLACING FUSES.
Failure to do so may result in fire or electric shock.
DO NOT BLOCK VENTS OR RADIATOR PANELS.
Doing so may cause heat to build up inside and may result in fire.
USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.
Use for other than its designed application may result in fire,
electric shock or other injury.
DO NOT PLACE HANDS, FINGERS OR FOREIGN OBJECTS IN INSERTION
SLOTS OR GAPS.
Doing so may result in personal injury or damage to the product.
CAUTION
This symbol means important instructions. Failure
to heed them can result in injury or material
property damage.
HALT USE IMMEDIATELY IF A PROBLEM APPEARS.
Failure to do so may cause personal injury or damage to the
product. Return it to your authorized Alpine dealer or the nearest
Alpine Service Center for repairing.
PRECAUTIONS
Product Cleaning
Use a soft dry cloth for periodic cleaning of the product. For more
severe stains, please dampen the cloth with water only. Anything
else has the chance of dissolving the paint or damaging the plastic.
Temperature
Be sure the temperature inside the vehicle is between +60°C
(+140°F) and −10°C (+14°F) before turning your unit on.
Moisture Condensation
You may notice the CD playback sound wavering due to
condensation. If this happens, remove the disc from the player and
wait about an hour for the moisture to evaporate.
Damaged Disc
Do not attempt to play cracked, warped, or damaged discs. Playing
a bad disc could severely damage the playback mechanism.
Maintenance
If you have problems, do not attempt to repair the unit yourself.
Return it to your Alpine dealer or the nearest Alpine Service Station
for servicing.
Never Attempt the Following
Do not grip or pull out the disc while it is being pulled back into the
player by the automatic reloading mechanism.
Do not attempt to insert a disc into the unit when the unit power is
off.
WARNING
7-EN
Inserting Discs
Your player accepts only one disc at a time for playback. Do not
attempt to load more than one disc.
Make sure the label side is facing up when you insert the disc.
“ERROR” will be displayed on your player if you insert a disc
incorrectly. If “ERROR” continues to be displayed even though the
disc has been inserted correctly, push the RESET button with a
pointed object such as a ballpoint pen.
Playing a disc while driving on a very bumpy road may result in
skips, but this will not scratch the disc or damage the player.
New Discs
To prevent the CD from jamming, “ERROR” is displayed if discs
with irregular surfaces are inserted or if discs are inserted
incorrectly. When a new disc is ejected immediately after initial
loading, use your finger to feel around the inside of the center hole
and outside edge of the disc. If you feel any small bumps or
irregularities, this could inhibit proper loading of the disc. To
remove the bumps, rub the inside edge of the hole and outside edge
of the disc with a ballpoint pen or other such instrument, then
insert the disc again.
Irregular Shaped Discs
Be sure to use round discs only for this unit and never use any
special shaped discs.
Use of anything but round discs may cause damage to the
mechanism.
Installation Location
Make sure this unit will not be installed in a location subjected to:
•Direct sun and heat
• High humidity and water
• Excessive dust
•Excessive vibrations
Correct Handling
Do not drop the disc while handling. Hold the disc so you will not
leave fingerprints on the surface. Do not affix tape, paper, or
gummed labels to the disc. Do not write on the disc.
Disc Cleaning
Fingerprints, dust, or soil on the surface of the disc could cause the
CD player to skip. For routine cleaning, wipe the playing surface
with a clean, soft cloth from the center of the disc to the outer edge.
If the surface is heavily soiled, dampen a clean, soft cloth in a
solution of mild neutral detergent before cleaning the disc.
Disc Accessories
There are various accessories available on the market for protecting
the disc surface and improving sound quality. However, most of
them will influence the thickness and/or diameter of the disc. Using
such accessories can cause the disc to be out of standard
specifications and may create operational problems. We
recommend not using these accessories on discs played in Alpine
CD players.
On handling Compact Discs (CD/CD-R/CD-RW)
• Do not touch the surface.
• Do not expose the disc to direct sunlight.
• Do not affix stickers or labels.
• Clean the disc when it is dusty.
• Make sure that there are no bumps around the disc.
• Do not use commercially available disc accessories.
Do not leave the disc in the car or the unit for a long time. Never
expose the disc to direct sunlight. Heat and humidity may damage
the CD and you may not be able to play it again.
To cu st om ers u sing CD -R/CD - RW
• If a CD-R/CD-RW cannot be played back, make sure the last
recording session was closed (finalised).
• Finalise the CD-R/CD-RW if necessary, and attempt playback again.
About media that can be played
Use only compact discs with the label side showing the CD logo
marks below.
If you use unspecified compact discs, correct performance cannot
be guaranteed.
You can play CD-Rs (CD-Recordables)/CD-RWs
(CD-ReWritables) which have been recorded only on audio devices.
You can also play CD-Rs/CD-RWs containing MP3 formatted
audio files.
• Some of the following CDs may not play on this unit:
Flawed CDs, CDs with fingerprints, CDs exposed to extreme
temperatures or sunlight (e.g., left in the car or this unit), CDs
recorded under unstable conditions, CDs on which a recording failed
or a re-recording was attempted, copy-protected CDs which do not
conform to the audio CD industry standard.
Center Hole
Center Hole New Disc
Outside
(Bumps)
Bumps
CORRECT
INCORRECT CORRECT
Transparent Sheet Disc Stabilizer
8-EN
• Use discs with MP3/WMA files written in a format compatible with
this unit. For details, refer to “About MP3/WMA” on page 13.
• ROM data other than audio files contained in a disc will not produce
sound when played back.
Protecting the USB Port
• Only a USB Flash Memory devices can be connected to the USB port
on this unit. Correct performance using other USB products cannot
be guaranteed. A USB hub is not supported.
• Depending on the shape or size of a Flash Memory device, it may not
be connected to the USB terminal of this unit-a USB extension (sold
separately) is recommended for this connection.
Also, avoid connecting Flash Memory and Front Aux at the same
time.
• If a USB device is inserted in the unit, it projects out and may be a
danger while driving.
Use a commercially available USB extension cable, and connect it in a
safe way.
• Depending on the connected Flash Memory device, the unit may not
function or some functions may not be performed.
• The audio file format that can be played back on the unit is MP3/
WMA.
• Artist/song name, etc., can be displayed, however some special
characters may not be correctly displayed.
On Handling Flash Memory
CAUTION
Alpine accepts no responsibility for lost data, etc., even if data,
etc., is lost while using this product.
• To prevent malfunction or damage, note the following points.
Read the Flash Memory Owner’s Manual thoroughly.
Do not touch the terminals by hand or metal.
Do not subject Flash Memory to excessive shock.
Do not bend, drop, disassemble, modify or soak in the water.
• Fix the Flash Memory in a location where driver operation will not be
hindered.
• Flash Memory may not function correctly at high or low temperature.
• Use only certified Flash Memory. Please pay attention that even
certified Flash Memory, may not function correctly depending on its
type or state.
• Flash Memory function is not guaranteed. Use Flash Memory
according to the terms of agreement.
• Depending on the settings of the Flash Memory type, memory state
or encoding software, the unit may not play back or display properly.
• A file that is copy-protected (copyright protection) cannot be played
back.
• Flash Memory may take time to start playback. If there is a particular
file other than audio in the Flash Memory, it may take considerable
time before the file is played back or searched.
• The unit can play back “mp3” or “wma” file extensions.
• Do not add the above extensions to a file other than audio data. This
non-audio data will not be recognised. The resulting playback may
contain noise that can damage speakers and/or amplifiers.
• It is recommended to back up important data on a personal
computer.
• Do not remove the USB device while playback is in progress. Change
SOURCE to something other than USB, then remove the USB device
to prevent possible damage to its memory.
• iPhone, iPod, iPod classic, iPod nano, and iPod touch are
trademarks of Apple Inc., registered in the U.S. and other countries.
• “Made for iPod,” and “Made for iPhone,” mean that an electronic
accessory has been designed to connect specifically to iPod, or
iPhone, respectively, and has been certified by the developer to meet
Apple performance standards. Apple is not responsible for the
operation of this device or its compliance with safety and regulatory
standards. Please note that the use of this accessory with iPod, or
iPhone may affect wireless performance.
•The BLUETOOTH
® word mark and logos are registered
trademarks owned by the Bluetooth SIG, Inc. and any use of such
marks by Alpine Electronics, Inc. is under licence.
• Sirius, XM and all related marks and logos are trademarks of Sirius
XM Radio Inc. All rights reserved.
• Windows Media and the Windows logo are trademarks, or
registered trademarks of Microsoft Corporation in the United States
and/or other countries.
• MPEG Layer-3 audio coding technology licensed from Fraunhofer
IIS and Thomson. Supply of this product only conveys a licence for
private, non-commercial use and does not convey a licence nor
imply any right to use this product in any commercial (i.e.
revenue-generation) real time broadcasting (terrestrial, satellite,
cable and/or any other media), broadcasting/streaming via internet,
intranets and/or other networks or in other electronic content
distribution systems, such as pay-audio or audio-on-demand
applications. An independent licence for such use is required. For
details, please visit http://www.mp3licensing.com
• © 2012 Nokia. All rights reserved. Nokia and Works with Nokia are
trademarks or registered trademarks of Nokia Corporation.
9-EN
*The illustration is for CDE-SXM145BT/CDE-143BT.
Accessory List
• Head Unit ..................................................................................1
• Power Cable ..............................................................................1
• Microphone ..............................................................................1
• Mounting Sleeve ......................................................................1
• Carrying Case*..........................................................................1
• Bracket Key ...............................................................................2
• Screw (M5 × 8) ..........................................................................4
• Owner’s Manual..................................................................1 set
*It is for CDE-SXM145BT/CDE-143BT.
Turning Power On and Off
Press SOURCE to turn on the unit.
Note
• The unit can be turned on by pressing any other button except and
e (Release).
Press and hold SOURCE for at least 2 seconds to turn
off the unit.
Note
• The first time power is turned on, the volume will start from level 12.
Source Selection
Press SOURCE to change the source.
TUNER SIRIUSXM*1 DISC*2 USB AUDIO/iPod*3
BT AUDIO*4 AUXILIARY*5 TUNER
*1 Displayed only when a siriusXM Tuner is
connected.(CDE-SXM145BT only).
*2 Only for CDE-SXM145BT/CDE-143BT.
*3 Only when the iPod/iPhone is connected.
*4 Only when BT IN is set to ON. Refer to “Setting the
BLUETOOTH Connection (BT IN)” on page 23.
*5 Only when AUX SETUP is set to ON. Refer to “Setting the AUX
SETUP mode” on page 21.
Detaching and Attaching the Front Panel
1
Turn off the unit power.
2
Press e (Release) at the lower left side until the front
panel pops out.
3
Grasp the left side of the front panel and pull it out.
Notes
• The front panel may become hot in normal usage (especially the
connector terminals on the back of the front panel). This is not a
malfunction.
• To protect the front panel, place it in the supplied carrying case
(CDE-SXM145BT/CDE-143BT only).
• When detaching the front panel, do not apply excessive force as it may
result in malfunction.
1
Insert the right side of the front panel into the main unit.
Align the groove on the front panel with the projections
on the main unit.
2
Push the left side of the front panel until it locks firmly into
the main unit.
Notes
• Before attaching the front panel, make sure that there is no dirt or dust
on the connector terminals and no foreign object between the front
panel and the main unit.
• Attach the front panel carefully, holding the sides of the front panel to
avoid pushing buttons by mistake.
Getting Started
AUDIO/SETUP
e
/ENTER
SOURCE/Rotary encoder
Detaching
Attaching
10-EN
Initial System Start-Up
Be sure to press the RESET button when using the unit for the first time,
after changing the car battery, etc.
1
Turn off the unit power.
2
Remove the detachable front panel.
3
Press RESET with a ballpoint pen or similar pointed object.
Adjusting Volume
Turn the Rotary encoder until the desired sound is
obtained.
Setting Time
1
Press and hold AUDIOSETUP for at least 2 seconds to
activate the SETUP selection mode.
2
Turn the Rotary encoder to select GENERAL, and then
press ENTER.
AUDIO GENERAL DISPLAY TUNER SIRIUSXM* iPod
BLUETOOTH
*Displayed only when a siriusXM Tuner is
connected.(CDE-SXM145BT only).
3
Turn the Rotary encoder to select the CLOCK ADJ mode,
and then press ENTER.
The time indication will blink.
4
Turn the Rotary encoder to adjust the hours while the
time indication is blinking.
5
When the hour has been adjusted, press ENTER.
6
Turn the Rotary encoder to adjust the minutes while the
time indication is blinking.
7
Press and hold AUDIOSETUP for at least 2 seconds to
return to normal mode.
Notes
• To synchronize the clock to another clock/watch or radio time
announcement, press and hold ENTER for at least 2 seconds after
setting the “hour”. Minutes will reset to “00”. If the display shows over
“30” minutes when you do this, the time will advance one hour.
• Pressing r will return to the previous mode.
• Pressing and holding r for at least 2 seconds will return to normal
mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
RESET button
Controllable with Remote Control
This unit can be controlled with an optional Alpine remote control.
For details, consult your Alpine dealer. Point the optional remote
control transmitter at the remote-control sensor.
*The illustration is for CDE-SXM145BT/CDE-143BT.
Connectable to Remote Control Interface Box
With an optional Alpine Steering Wheel Remote Control Interface
Box (not included), this unit is controllable from the vehicles
steering wheel controls. For details, contact your Alpine dealer.
Remote control sensor
11-EN
*The illustration is for CDE-SXM145BT/CDE-143BT.
Listening to Radio
1
Press SOURCE to select TUNER mode.
2
Press BAND repeatedly until the desired radio band is
displayed.
F1 (FM1) F2 (FM2) AM F1 (FM1)
3
Press TUNEA.ME to select the tuning mode.
SEEK DX (Distance mode) SEEK LOCAL (Local mode)
MANUAL (Manual mode) SEEK DX
Note
• The initial mode is Distance mode.
Distance mode:
Both strong and weak stations will be automatically tuned in
(Automatic Seek Tuning).
Local mode:
Only strong stations will be automatically tuned in (Automatic
Seek Tuning).
Manual mode:
The frequency is manually tuned in steps (Manual tuning).
4
Press or to tune in the desired station.
In Manual mode, holding down or will change the
frequency continuously.
Presetting Stations Manually
1
Select the radio band and tune in a desired radio station
you wish to store in the preset memory.
2
Press and hold, for at least 2 seconds, any one of the
preset buttons (1 through 6) into which you wish to store
the station.
The selected station is stored.
The display shows the band, preset number and station
frequency memorized.
Notes
• A total of 18 stations can be stored in the preset memory (6 stations for
each band; FM1, FM2 and AM).
• If you store a station in a preset memory which already has a station,
the current station will be cleared and replaced with the new station.
Presetting Stations Automatically
1
Press BAND repeatedly until the desired radio band is
displayed.
2
Press and hold TUNEA.ME for at least 2 seconds.
The frequency on the display continues to change while the
automatic memory is in progress. The tuner will automatically
seek and store 6 strong stations in the selected band. They will
be stored into preset buttons 1 to 6 in order of signal strength.
When the automatic memory has been completed, the tuner
goes to the station stored in preset location No.1.
Note
• If no stations are stored, the tuner will return to the original station you
were listening to before the auto memory procedure began.
Tuning to Preset Stations
1
Press BAND repeatedly until the desired band is
displayed.
2
Press any one of the station preset buttons (1 through 6)
that has your desired radio station in memory.
The display shows the band, preset number and frequency of
the station selected.
Frequency Search Function
You can search for a radio station by its frequency.
1
Press ENTER in Radio mode to activate Frequency
search mode.
The “” indicator lights up.
2
Turn the Rotary encoder to select the desired frequency.
3
Press ENTER to receive the selected frequency.
Note
•Press r in the search mode to cancel. Or, the search mode will be
canceled if no operation is performed for 60 seconds.
Radio
BAND
/ENTER
SOURCE/
TUNE/A.ME
Rotary encoder
Preset buttons
(1 through 6)
12-EN
*The illustration is for CDE-SXM145BT/CDE-143BT.
Playback
1
Insert a disc with the label side facing up.
The disc will be pulled into the unit automatically.
Note
• When a disc is already inserted, press SOURCE to switch to the
DISC mode.
2
While playing back MP3/WMA, press or to select the
desired folder.
Pressing and holding or will change folders continuously.
3
Press or to select the desired track (file).
Pressing and holding or will fast backward/fast
forward track continuously.
4
To pause playback, press .
Pressing again will resume playback.
5
To eject the disc, press .
Notes
• Do not remove a CD during its eject cycle. Do not load more than one
disc at a time. A malfunction may result from doing either.
•The “” indicator lights up when a disc is inserted.
• Three-inch (8 cm) CDs cannot be used.
• Any file protected by DRM (Digital Rights Management) copy
protection, cannot be played back on this unit.
• The track display for MP3/WMA data playback is the file numbers
recorded on the disc.
• The playback time may not be correctly displayed when a VBR
(Variable Bit Rate) recorded file is played back.
• During CD/MP3/WMA playback, press r, and then you can quickly
return to the hierarchy level selected last time in the search mode.
Repeat Play
1
Press z 4.
The song is played back repeatedly.
RPT ONE*1 RPT FOLDER*2 RPT OFF RPT ONE
*1 Only a track/file is repeatedly played back.
*2 Only files in a folder are repeatedly played back. (MP3/WMA
mode only)
2
To cancel repeat play, select RPT OFF with the above
procedure.
M.I.X. (Random Play)
1
Press 5 x.
The songs are played back in random sequence.
MIX FOLDER*1 MIX ALL*2/*3 MIX OFF MIX FOLDER
*1 Only files in a folder are played back in random sequence.
(MP3/WMA mode)
*2 The tracks/files in the disc are played back in random sequence.
*3 In the USB mode, all files stored in the Flash Memory are played
back in random sequence.
2
To cancel M.I.X. play, select MIX OFF with the above
procedure.
Searching for CD Text
On discs utilizing CD Text, songs can be searched and played by using
their recorded titles. For discs without CD Text, searches are made using
the track numbers associated with each song.
1
Press ENTER during play.
This will set the search mode, and the “” indicator lights up.
2
Turn the Rotary encoder to select the desired track, and
then press ENTER.
This will play the selected track.
Notes
•Press r in the search mode to cancel. Or, the search mode is canceled
if no operation is performed for 60 seconds.
• When CD Text Search is made during M.I.X. play, the M.I.X. play
mode will be canceled.
• If any one of the preset buttons (1 through 6) is pressed in the
search mode, a search can be made quickly by skipping to the specified
location. For details, refer to “Direct Search Function” on page 31.
CD/MP3/WMA
(CDE-SXM145BT/
CDE-143BT only)
4
5
/ENTER
SOURCE/
/ II
Rotary encoder
Preset buttons
(1 through 6)
13-EN
Folder/File Name Search
(concerning MP3/WMA)
Folder and file names may be searched and displayed during playback.
1
During MP3/WMA playback, press ENTER to activate
the search mode.
The “” indicator lights up.
2
Turn the Rotary encoder to select Folder Name Search
mode, and then press ENTER.
3
Turn the Rotary encoder to select the desired folder.
4
Press and hold ENTER for at least 2 seconds to play
back the first file in the selected folder.
Notes
• If any one of the preset buttons (1 through 6) is pressed in the
Folder Name search mode, a search can be made quickly by skipping to
the specified location. For details, refer to “Direct Search Function” on
page 31.
•Press and hold r for at least 2 seconds in the search mode to cancel.
Or, the search mode is canceled if no operation is performed for 60
seconds.
• To search for files in the Folder Name Search mode, press ENTER.
Files in the folder may be searched.
•Press r to exit Folder Name Search mode in step 3 in order to select
File Name Search mode.
• The root folder is displayed as “\ROOT”.
• When Folder Name Search is made during M.I.X. play, the M.I.X. play
mode will be canceled.
1
During MP3/WMA playback, press ENTER to activate
the search mode.
The “” indicator lights up.
2
Turn the Rotary encoder to select File Name Search mode,
and then press ENTER.
3
Select the desired file by turning the Rotary encoder.
4
Press ENTER to play back the selected file.
Notes
• If any one of the preset buttons (1 through 6) is pressed in the File
Name search mode, a search can be made quickly by skipping to the
specified location. For details, refer to “Direct Search Function” on
page 31.
•Press and hold r for at least 2 seconds in the search mode to cancel.
Or, the search mode is canceled if no operation is performed for 60
seconds.
•Press r in the search mode to return to the previous mode.
• When File Name Search is made during M.I.X. play, the M.I.X. play
mode will be canceled.
Search Position Memory
During playback, you can quickly return to the last-selected hierarchy
level in the search mode.
Press r.
The hierarchy you selected last in the search mode is displayed.
About MP3/WMA
CAUTION
Except for private use, duplicating audio data (including MP3/
WMA data) or distributing, transferring, or copying it, whether
for free or for a fee, without permission of the copyright holder is
strictly prohibited by the Copyright Act and by international
treaty.
What is MP3?
MP3, whose official name is “MPEG Audio Layer 3,” is a compression
standard prescribed by the ISO, the International Standardization
Organization and MPEG which is a joint activity institution of the IEC.
MP3 files contain compressed audio data. MP3 encoding is capable of
compressing audio data at extremely high ratios, reducing the size of
music files to as much as one-tenth their original size. This is achieved
while still maintaining near CD quality. The MP3 format realizes such
high compression ratios by eliminating the sounds that are either
inaudible to the human ear or masked by other sounds.
What is WMA?
WMA, or “Windows Media™ Audio,” is compressed audio data.
WMA is similar to MP3 audio data.
Method for creating MP3/WMA files
Audio data is compressed using software with MP3/WMA codecs. For
details on creating MP3/WMA files, refer to the user’s manual for that
software.
MP3/WMA files that are playable on this device have the file extensions
“mp3” / “wma”. Files with no extension cannot be played back (WMA
ver. 7.1, 8 and 9 are supported).
Supported playback sampling rates and bit rates
MP3
WMA
This device may not play back correctly depending on sampling rates.
ID3 tags/WMA tags
This device supports ID3 tag v1 and v2, and WMA tag.
If tag data is in an MP3/WMA file, this device can display the title (track
title), artist name, and album name ID3 tag/WMA tag data.
This device can only display single-byte alphanumeric characters (up to
30 for ID3 tags and up to 15 for WMA tags) and the underscore. For
non-supported characters, “NO SUPPORT” is displayed.
If information contains characters other than ID3 tag information, the
audio file may not be played back.
The tag information may not be correctly displayed, depending on the
contents.
Producing MP3/WMA discs
MP3/WMA files are prepared, then written to a CD-R or CD-RW using
CD-R writing software. A disc can hold up to 255 files/folders (including
Root Folders), and the maximum number of folders is 255.
Playback may not be performed if a disc exceeds the limitations
described above.
Folder Name Search mode
File Name Search mode
Sampling rates: 48 kHz, 44.1 kHz, 32 kHz, 24 kHz, 22.05 kHz, 16 kHz,
12 kHz, 11.025 kHz, 8 kHz
Bit rates: 8 - 320 kbps
Sampling rates: 48 kHz, 44.1 kHz, 32 kHz
Bit rates: 32 - 192 kbps
14-EN
Media supported
The media that this device can play back are CD-ROMs, CD-Rs, and
CD-RWs.
Corresponding File Systems
This device supports discs formatted with ISO9660 Level 1 or Level 2.
Under the ISO9660 standard, there are some restrictions to remember.
The maximum nested folder depth is 8 (including the root directory).
The number of characters for a folder/file name is limited.
Valid characters for folder/file names are letters A-Z (all caps), numbers
0-9, and ‘_’ (underscore).
This device also can play back discs in Joliet, Romeo, etc., and other
standards that conform to ISO9660. However, sometimes the file
names, folder names, etc., are not displayed correctly.
Formats supported
This device supports CD-ROM XA, Mixed Mode CD, Enhanced CD
(CD-Extra) and Multi-Session.
This device cannot correctly play back discs recorded with Track At
Once or packet writing.
Order of files
Files are played back in the order that the writing software writes them
to the disc. Therefore, the playback order may not be what is expected.
Verify the writing order in the software’s documentation. The playback
order of the folders and files is as follows.
*The folder No./ folder Name will not be displayed if no readable file is
contained in the folder.
Bit rate
This is the “sound” compression rate specified for encoding. The higher
the bit rate, the higher the sound quality, but also the larger the files.
Sampling rate
This value shows how many times per second the data is sampled
(recorded). For example, music CDs use a sampling rate of 44.1 kHz, so
the sound is sampled (recorded) 44,100 times per second. The higher
the sampling rate, the higher the sound quality, but also the larger the
volume of data.
Encoding
Converting music CDs, WAVE (AIFF) files, and other sound files into the
specified audio compression format.
Tag
Song information such as track titles, artist names, album names, etc.,
written into MP3/WMA files.
Root folder
The root folder (or root directory) is found at the top of the file system.
The root folder contains all folders and files. It is created automatically
for all burned discs.
Root folder
Folder MP3/WMA File
Terminology
15-EN
*The illustration is for CDE-SXM145BT/CDE-143BT.
Adjusting Subwoofer Level/Bass Level/Mid
Level/Treble Level/Balance (Between Left
and Right)/Fader (Between Front and Rear)/
Defeat
1
Press AUDIOSETUP repeatedly to choose the desired
mode.
Each press changes the mode as follows:
SUBWOOFER*1 BASS LEVEL*2 MID LEVEL*2 TRE LEVEL*2
BALANCE FADER DEFEAT VOLUME SUBWOOFER
*1 When the SUBWOOFER mode is set to SUBW OFF, its level
cannot be adjusted.
*2 Adjustable only when DEFEAT is DEFEAT OFF.
Note
• If no operation is performed for 5 seconds, the unit automatically
returns to normal mode.
2
Turn the Rotary encoder until the desired sound is
obtained in each mode.
By setting DEFEAT ON, previously adjusted settings of BASS, MID
and TRE LEVEL will return to the factory defaults.
Audio Setup
You can flexibly customize the unit to suit your own preference and
usage. From the AUDIO SETUP menu, Audio Setting can be modified.
1
Press and hold AUDIOSETUP for at least 2 seconds to
activate the SETUP mode.
2
Turn the Rotary encoder to select AUDIO, and then press
ENTER.
AUDIO GENERAL DISPLAY TUNER SIRIUSXM*1 iPod
BLUETOOTH
*1 Displayed only when a siriusXM Tuner is
connected.(CDE-SXM145BT only).
3
Turn the Rotary encoder to select the desired sound
setting menu, and then press ENTER.
FACTORY EQ*2/*3 3BAND EQ*2/*4 VOL LV ADJ HPF*2
SUBWOOFER SUBW LPF*2/*5 SUBW PHASE*5
SUBW SYS*5 POWER IC MX SETTING*2
(e.g. Select SUBWOOFER)
*2 Adjustment cannot be performed when DEFEAT is set to ON.
*3 Any changes made to either FACTORY EQ or 3BAND EQ are
reflected in the others’ settings.
*4 In step 3, three sound adjustment items (Bass, Mid and Treble)
can be selected in 3BAND EQ mode. Turn the Rotary encoder
to select the desired item, and then press ENTER to continue
to step 4.
*5 These functions are inoperable when SUBWOOFER is set to
SUBW OFF.
4
Turn the Rotary encoder to change the setting, and then
press ENTER.
(e.g. Select SUBW ON or SUBW OFF)
5
Press and hold AUDIOSETUP for at least 2 seconds to
return to normal mode.
Notes
•Pressing r returns to the previous Sound menu mode.
• Pressing and holding r for at least 2 seconds will return to normal
mode.
• If no operation is performed for 60 seconds, Sound menu mode is
canceled.
10 typical equalizer settings are preset at the factory for a variety of
musical source material. USER settings are created in the 3BAND EQ
mode.
Setting item: FACTORY EQ
Setting contents:
USER / FLAT (Initial setting) / POPS / ROCK / NEWS / JAZZ /
ELEC DANCE / HIP HOP / EASY LIS / COUNTRY / CLASSICAL
Sound Setting
Subwoofer +0 ~ +15
Bass level -7 ~ +7
Mid level -7 ~ +7
Treble level -7 ~ +7
Balance L15 ~ R15
Fader R15 ~ F15
Defeat ON/OFF
Volume 0 ~ 35
AUDIO/SETUP
/ENTER
Rotary encoder
Use steps 1 to 5 to select one of the setting modes to modify.
See the applicable section below for details about the
selected setting item.
Equalizer Presets (F-EQ)
16-EN
You can modify the Equalizer settings to create a response curve more
appealing to your personal taste. The setting of Bass, Mid and Treble can
be adjusted in this mode.
Setting item: 3BAND EQ
Further setting items: BASS / MID / TREBLE
Setting the Bass Control
1
After selecting BASS from the 3BAND EQ adjustment
mode, turn the Rotary encoder to select the desired Bass
setting item, and then press ENTER.
WIDTH (Q) CENTER FRQ LEVEL
2
Turn the Rotary encoder to select the desired setting
value, and then press ENTER.
3
Press r to return to the previous step.
Setting the Bass Bandwidth (WIDTH (Q))
Turn the Rotary encoder to select the desired bass
bandwidth.
WIDE 0.50 MEDIUM 1.00 MEDIUM 1.50 NARROW 2.00
Changes the boosted bass bandwidth to wide or narrow. A wider setting
will boost a wide range of frequencies above and below the center
frequency. A narrower setting will boost only frequencies near the
center frequency.
Setting the Bass Center Frequency (CENTER FRQ)
Turn the Rotary encoder to select the desired bass center
frequency.
60 (Hz) 80 (Hz) 100 (Hz) 120 (Hz)
Emphasises the displayed bass frequency ranges.
Setting the Bass Level
Turn the Rotary encoder to select the desired bass level
(-7 ~ +7)*.
You can emphasise or weaken the bass level.
*The adjustment can also be made by pressing AUDIO. Refer to
“Adjusting Subwoofer Level/Bass Level/Mid Level/Treble Level/
Balance (Between Left and Right)/Fader (Between Front and
Rear)/Defeat” on page 15.
Setting the Mid Control
1
After selecting MID from the 3BAND EQ adjustment mode,
turn the Rotary encoder to select the desired setting item,
and then press ENTER.
WIDTH (Q) CENTER FRQ LEVEL
2
Turn the Rotary encoder to select the desired setting
value, and then press ENTER.
3
Press r to return to the previous step.
Setting the Mid Bandwidth (WIDTH (Q))
Turn the Rotary encoder to select the desired Mid
bandwidth.
WIDE 0.75 MEDIUM 1.00 MEDIUM 1.25 NARROW 1.50
Setting the Mid Center Frequency (CENTER FRQ)
Turn the Rotary encoder to select the desired Mid center
frequency.
500 (Hz) 1.0K (Hz) 1.5K (Hz) 2.5K (Hz)
Setting the Mid Level
Turn the Rotary encoder to select the desired Mid level
(-7 ~ +7)*.
You can emphasise or weaken the Mid level.
*The adjustment can also be made by pressing AUDIO. Refer to
“Adjusting Subwoofer Level/Bass Level/Mid Level/Treble Level/
Balance (Between Left and Right)/Fader (Between Front and
Rear)/Defeat” on page 15.
Setting the Treble Control
1
After selecting TREBLE from the 3BAND EQ adjustment
mode, turn the Rotary encoder to select the desired
Treble setting item, and then press ENTER.
WIDTH (Q) CENTER FRQ LEVEL
2
Turn the Rotary encoder to select the desired setting
value, and then press ENTER.
3
Press r to return to the previous step.
Setting the Treble Bandwidth (WIDTH (Q))
Turn the Rotary encoder to select the desired treble
bandwidth.
WIDE 0.75 NARROW 1.25
Setting the Treble Center Frequency (CENTER FRQ)
Turn the Rotary encoder to select the desired treble
center frequency.
7.5K (Hz) 10.0K (Hz) 12.5K (Hz) 15.0K (Hz)
Setting the Treble Level
Turn the Rotary encoder to select the desired treble level
(-7 ~ +7)*.
You can emphasise or weaken the treble level.
*The adjustment can also be made by pressing AUDIO. Refer to
“Adjusting Subwoofer Level/Bass Level/Mid Level/Treble Level/
Balance (Between Left and Right)/Fader (Between Front and
Rear)/Defeat” on page 15.
Adjusting the Parametric Equalizer Curve
(3BAND EQ)
17-EN
The output level of each source is individually adjustable. For example, if
the TUNER level sounds lower than CD, its output can be adjusted
without affecting the other sources.
Setting item: VOL LV ADJ
Further setting items: TUNER / SIRIUSXM*1 / DISC*2 / USB /
iPod / BT AUDIO / AUX
Setting contents:
-14 dB ~ +14 dB
*1 Only for CDE-SXM145BT.
*2 Only for CDE-SXM145BT/CDE-143BT.
The High Pass Filter on this unit can be adjusted to suit your personal
taste.
Setting item: HPF
Setting contents:
HPF OFF (Initial setting) / HPF 60 (Hz) / HPF 80 (Hz) /
HPF 120 (Hz) / HPF 160 (Hz)
All frequencies above the selected cutoff are output.
When the subwoofer is on, you can adjust the subwoofer output level
(refer to “Adjusting Subwoofer Level/Bass Level/Mid Level/Treble Level/
Balance (Between Left and Right)/Fader (Between Front and Rear)/
Defeat” on page 15).
Setting item: SUBWOOFER
Setting contents:
SUBW OFF / SUBW ON (Initial setting)
OFF:
No subwoofer signal is output from the Subwoofer RCA
Connectors (refer to “Connections” on page 44).
ON:
The subwoofer signal is output from the Subwoofer RCA
Connectors (refer to “Connections” on page 44).
The Low Pass Filter on this unit can be adjusted to suit your personal
taste.
Setting item: SUBW LPF
Setting contents:
LPF OFF (Initial setting) / LPF 60 (Hz) / LPF 80 (Hz) /
LPF 120 (Hz) / LPF 160 (Hz)
All frequencies lower than the selected cutoff are output.
The subwoofer output phase is toggled SUBWOOFER NORMAL (0°) or
SUBWOOFER REVERSE (180°). To adjust the level, turn the Rotary
encoder.
Setting item: SUBW PHASE
Setting contents:
NORMAL (Initial setting) / REVERSE
When the subwoofer is on, you can select either SYS 1 or SYS 2 for the
desired subwoofer effect.
Setting item: SUBW SYS
Setting contents:
SUBW SYS 1 / SUBW SYS 2 (Initial setting)
SUBW SYS 1:
Subwoofer level changes according to the main volume setting.
SUBW SYS 2:
Subwoofer level change is different from the main volume setting.
For example, even at low volume settings, the subwoofer is still
audible.
Connecting to an External Amplifier (POWER IC)
When an external amplifier is connected, sound quality can be
improved by stopping the power supply of the built-in amplifier.
Setting item: POWER IC
Setting contents:
OFF / ON (Initial setting)
OFF:
Use this mode when the line output of this unit is used to drive an
external amplifier. In this setting, the head unit’s internal amplifier
is turned OFF and cannot drive speakers.
ON:
The speakers are driven by the built-in amplifier.
OFF:
ON:
Setting the Source Volume Level
Adjusting the High Pass Filter
Turning Subwoofer ON/OFF
Adjusting the Low Pass Filter
Setting the Subwoofer Phase
Setting the Subwoofer System
External Device
Front
Left
Amplier Front
Right
Rear
Left
Amplier Rear
Right
Speakers
SPEAKER
RIGHT FRONT Front
Right
SPEAKER
RIGHT REAR Rear
Right
SPEAKER
LEFT REAR Rear
Left
SPEAKER
LEFT FRONT Front
Left
18-EN
Note
• No sound is produced by the system when the power output is set to
OFF.
MX (Media Xpander) makes vocals or instruments sound distinct
regardless of the music source. The CD, iPod, etc. will be able to
reproduce the music clearly even in cars with a lot of road noise.
Setting item: MX SETTING
Setting contents:
SIRIUSXM*1 / FM / CD*2 / CMPM*2 / USB / iPod / BT AUDIO /
AUX
FM (LEVEL 1 to 3):
The medium to high frequencies become clearer, and produces
well balanced sound at all frequencies.
CD*2 (LEVEL 1 to 3):
CD mode processes a large amount of data during playback. MX
takes advantage of this large data quantity to reproduce a clearer,
cleaner output.
SIRIUSXM*1 / CMPM*2 / USB / iPod / BT AUDIO (LEVEL 1 to 3):
This corrects information that was lost at the time of compression.
This reproduces a well-balanced sound close to the original.
AUX (LEVEL 1 to 3):
Choose the MX mode that corresponds to the media connected.
*1 CDE-SXM145BT only.
*2 CDE-SXM145BT/CDE-143BT only.
Notes
• Each music source, such as CD and MP3/WMA can have its own MX
setting.
• On disks with both MP3/WMA and CD-DA, when the source changes
from “MP3/WMA to CD-DA” or “CD-DA to MP3/WMA”, MX-mode
switching may delay playback slightly.
• Setting to LEVEL OFF sets MX mode of each music source to OFF.
• The function is inoperable when DEFEAT is set to ON.
• There is no MX mode for AM radio.
*The illustration is for CDE-SXM145BT/CDE-143BT.
Displaying the Text
Text information, such as the disc name and the track name, will be
displayed if playing a CD text compatible disc. It is also possible to
display the folder name, the file name and the tag, etc., while playing
MP3/WMA files.
Press k.
The display will change every time the button is pressed.
Note
• When the TEXTSCROLL is set to SCR MANUAL on page 21, press
and hold k for at least 2 seconds, the current text will be scrolled one
time (except Radio mode).
The display in Radio mode:
FREQUENCY CLOCK FREQUENCY
The display in CD mode (CDE-SXM145BT/CDE-143BT only):
TRACK NO./ELAPSED TIME TEXT (DISC NAME)*1
TEXT (TRACK NAME)*1 TRACK NO./CLOCK
TRACK NO./ELAPSED TIME
The display in MP3/WMA mode:
FILE NO./ELAPSED TIME FOLDER NO./FILE NO. FOLDER
NAME*2 FILE NAME*2 ARTIST NAME*3 ALBUM NAME*3
SONG NAME*3 FILE NO./CLOCK FILE NO./ELAPSED TIME
The display in iPod mode:
TRACK NO./ELAPSED TIME ARTIST NAME*3 ALBUM NAME*3
SONG NAME*3 TRACK NO./CLOCK TRACK NO./ELAPSED
TIME
The display in BLUETOOTH Audio mode:
BT A/ELAPSED TIME*4 ARTIST NAME*3 ALBUM NAME*3
SONG NAME*3 BT A/CLOCK BT A/ELAPSED TIME
*1 Displayed during playback of a disc with CD text.
If there is no text (Disc Name or Track Name), “DISC
TEXT”/“TRACK TEXT” is displayed.
*2 If there is no text (Folder Name or File Name), “FOLDER”/
“FILE” is displayed.
*3 If an MP3/WMA file contains ID3 tag/WMA tag
information, the ID3 tag/WMA tag information is displayed
(e.g., song name, artist name, and album name). All other
tag data is ignored.
If there is no tag information, “ARTIST”/“ALBUM”/“SONG”
is displayed.
*4 Depending on the connected mobile phone, the elapsed time
may not be displayed.
Setting the MX Level
Other Functions
BAND
/ENTER/OPTION
SOURCE/
/ II
Rotary encoder
19-EN
Text compatible CDs contain text information such as the disc name and
track name. Such text information is referred to as “text”.
Notes
• Some characters may not be displayed correctly with this device,
depending on the character type.
• “NO SUPPORT” is displayed if text information is not supported by the
unit.
• The text or tag information may not be correctly displayed, depending
on the contents.
Using the Front AUX Input Terminal
Connect a portable music player, etc. by simply connecting it to the
input on the front panel. An optional adapter cable is required (standard
RCA to 3.5ø mini-phono plug or 3.5ø to 3.5ø mini phono plug).
Press SOURCE, and select the AUXILIARY mode to
listen to the portable device.
Notes
• This function is available only when AUX SETUP is set to ON. For
details, refer to “Setting the AUX SETUP mode” on page 21.
• If a Flash Memory device is directly connected to the Front USB port,
the size or shape may interfere with driving operations. Avoid making
connections to the AUX Input and the USB Port at the same time.
Option Menu Setting
You can quickly adjust the setting items relevant to the current SOURCE
by using Option Menu.
1
Press and hold ENTER/OPTION for at least 2 seconds
to activate the Option menu of the current source.
Note
• The option menu varies depending on the source.
2
Turn the Rotary encoder to select the desired setting
item, and then press ENTER.
3
Turn the Rotary encoder to change the setting, and then
press ENTER.
After the setting, the display will return to the current source
automatically.
Setting item:
TUNER mode:
TUNER SET*1 VOL LV ADJ*2 MX SETTING*3
SiriusXM mode (CDE-SXM145BT Only):
TUNE SCAN*4 ALERT MEMO*5 SXM SET*6 VOL LV ADJ*2
MX SETTING*3
CD mode (CDE-SXM145BT/CDE-143BT only):
CD SET*7 VOL LV ADJ*2 MX SETTING*3
MP3/WMA (Disc) (CDE-SXM145BT/CDE-143BT only) mode:
CD SET*7 VOL LV ADJ*2 MX SETTING*3
MP3/WMA (USB) mode:
VOL LV ADJ*2 MX SETTING*3
iPod mode:
APP DIRECT*8 iPod SET*9 VOL LV ADJ*2 MX SETTING*3
BT AUDIO mode:
BT SET*10 VOL LV ADJ*2 MX SETTING*3
AUX mode:
AUX SET*11 VOL LV ADJ*2 MX SETTING*3
Phone mode (Non-calling mode):
PHONE SET*12 VOL LV ADJ*13
Phone mode (Calling mode):
MIC GAIN*14 CALL SOUND*14 SPK SWITCH*15 VOICE
MUTE*16 CALL WAIT*17 END CALL*18 VOL LV ADJ*13
*1 The setting items are the same as TUNER setting in SETUP
mode. For details, refer to “SETUP” on page 20.
*2 You can individually emphasise or weaken the volume level
of the current source to create your own tonal preference. The
setting values in Option mode and in SETUP mode are
linkage. Refer to “Setting the Source Volume Level” on
page 17.
*3 Refer to “Setting the MX Level” on page 18.
*4 Refer to “Tune Scan Function” on page 35.
*5 Refer to “Storing the desired Artist and Song Alerts” on
page 34.
*6 ALERTSETUP, GAME ALERT, P-LOCK, SIGNAL IND and
TUNE START can be selected in this mode. For details about
these settings, refer to “SiriusXM Setting (CDE-SXM145BT
Only)” on page 32.
*7 PLAY MODE can be selected in this mode. For details, refer
to “Playing MP3/WMA Data (PLAY MODE)
(CDE-SXM145BT/CDE-143BT only)” on page 21.
*8 Refer to “Setting the iPod Control” on page 30.
*9 The setting items are the same as iPod setting in SETUP
mode. For details, refer to “iPod/iPhone Setting” on page 22.
About “Text”
Portable player, etc. Main unit
or
Optional adapter cable (RCA pin
plugs [red, white] 3.5ø miniplugs)
or (3.5ø miniplugs).
20-EN
*10 FW VERSION can be selected in this mode. You can see the
current firmware version about BLUETOOTH by using this
setting.
*11 AUX NAME can be selected in this mode. For details, refer to
“Setting the AUX NAME mode” on page 21.
*12 CALL SOUND, CALLER ID, PB UPDATE, PB ORDER,
AUTO ANS, SPEAKER SL and FW VERSION can be
selected in this mode. For details about these settings, refer to
“BLUETOOTH SETUP” on page 23.
*13 The Hands free phone talk level, ring tone level and
microphone gain level can be adjusted by using this setting.
Changing the settings in the Option mode will also affect the
same settings in the SETUP menu. Refer to “Adjusting the
volume (VOL LV ADJ)” on page 24.
*14 Refer to “Setting the BLUETOOTH sound quality” on
page 24.
*15 While calling, the call sound can be switched between the
unit and mobile phone by using this setting.
This operation can also be done by pressing BAND. Refer to
“Call Switching Operation” on page 27.
*16 While calling, and the Voice Mute is activated, the
microphone input will mute instantly and “VOICE MUTE”
will blink. This operation can also be done by pressing .
Refer to “Muting the microphone input quickly (Voice Mute)”
on page 27.
*17 If there is a waiting call, select this item to display the caller’s
Name and waiting number (1 or 2). Press k and the
display will switch.
*18 Select this item to hang up the call.
Notes
•Press r to return to the previous mode.
• Pressing and holding r for at least 2 seconds will return to normal
mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
*The illustration is for CDE-SXM145BT/CDE-143BT.
Setting
You can flexibly customize the unit to suit your own preferences and
usage. From the SETUP menu, GENERAL Setting, DISPLAY Setting,
etc., can be modified.
1
Press and hold AUDIOSETUP for at least 2 seconds to
activate the SETUP mode.
2
Turn the Rotary encoder to select the desired item, and
then press ENTER.
(e.g. Select GENERAL)
AUDIO*1 GENERAL DISPLAY TUNER SIRIUSXM*2
iPod BLUETOOTH*3
GENERAL:
CLOCK ADJ*4 AUX SETUP*5 AUX NAME*6 PLAY MODE*7
DEMO
DISPLAY:
DIMMER TEXTSCROLL SCROLLTYPE
TUNER:
FM SET
iPod:
iPod LIST
*1 Refer to “Audio Setup” on page 15.
*2 Displayed only when a SiriusXM Tuner is connected. For
details, refer to “SiriusXM Setting (CDE-SXM145BT Only)” on
page 32. (CDE-SXM145BT Only)
*3 Refer to “BLUETOOTH SETUP” on page 23.
*4 Refer to “Setting Time” on page 10.
*5 Not displayed when the current source is AUXILIARY.
*6 Displayed only when AUX SETUP is set to ON.
*7 CDE-SXM145BT/CDE-143BT only.
3
Turn the Rotary encoder to select a setting item, and then
press ENTER.
(e.g. Select AUX SETUP)
4
Turn the Rotary encoder to change the setting, and then
press ENTER.
(e.g. Select AUX ON or AUX OFF.)
SETUP
Use steps 1 to 5 to select one of the SETUP modes to modify.
See the applicable section below for details about the
selected SETUP item.
AUDIO/SETUP
/ENTER
SOURCE/Rotary encoder
21-EN
5
Press and hold AUDIOSETUP for at least 2 seconds to
return to normal mode.
Notes
•Press r to return to the previous mode.
• Pressing and holding r for at least 2 seconds will return to normal
mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
GENERAL is selected on the setup main menu in step 2.
Setting the AUX SETUP mode
You can input the audio of an external device, (such as a Portable audio
player) to the AUX connector of this unit.
Setting item: AUX SETUP
Setting contents:
AUX OFF / AUX ON (Initial setting)
AUX OFF:
When set to OFF, AUX source cannot be selected.
AUX ON:
Set to ON when a portable device is connected. If SOURCE is
pressed and AUX is selected, the sound of the portable device is
input to the unit.
Setting the AUX NAME mode
You can change the AUX NAME display in the SETUP mode.
Setting item: AUX NAME
Setting contents:
AUXILIARY (Initial setting) / TV / DVD / PORTABLE / GAME
Note
• PORTABLE is abbreviated as PMD in the display.
Playing MP3/WMA Data (PLAY MODE)
(CDE-SXM145BT/CDE-143BT only)
This unit can play back CDs containing both CD and MP3/WMA data
(created in Enhanced CD (CD Extra) format). However, in some
situations, playback of an enhanced CD may be difficult. In this case,
you can select playback of a single session only, containing the CD data.
When a disc contains both CD and MP3/WMA data, playback starts
from the CD data portion of the disc.
Setting item: PLAY MODE
Setting contents:
CD-DA / CDDA/MP3 (Initial setting)
CD-DA:
Only the CD data in Session 1 can be played back.
CDDA/MP3:
CD data, MP3/WMA files in mixed mode, and multi-session discs
can be played back.
Note
• Perform this setting before inserting a disc. If a disc has already been
inserted, remove it first.
Demonstration
This unit has a demonstration feature for the display.
Setting item: DEMO
Setting contents:
DEMO OFF (Initial setting) / DEMO ON
Note
• To quit Demo mode, set to DEMO OFF.
DISPLAY is selected on the setup main menu in step 2.
Dimmer Control
Set the Dimmer control to AUTO to decrease the illumination
brightness of the unit with the head lights of the vehicle ON. This mode
decreases the unit’s backlighting at a certain extent at night.
Setting item: DIMMER
Setting contents:
DIM MANUAL / DIM AUTO (Initial setting)
Scroll Setting (TEXTSCROLL)
This CD player can scroll the disc and track names recorded on
CD-TEXT discs, as well as the text information of MP3/WMA files,
folder names, and tags.
Setting item: TEXTSCROLL
Setting contents:
SCR MANUAL (Initial setting) / SCR AUTO
SCR MANUAL:
The above information is scrolled only when a disc is loaded, a
channel or track is changed, etc.
SCR AUTO:
CD text information, folder and file names, and the tag
information are scrolled continuously.
Note
• In parts of the display, scrolling may not occur, or scroll content may
differ.
Scroll Type Setting
Choose from two scrolling methods.
Select the type you prefer.
Setting item: SCROLLTYPE
Setting contents:
SCR TYPE 1 / SCR TYPE 2 (Initial setting)
SCR TYPE 1 :
The characters scroll from right to left, one character at a time,
until the entire title has scrolled.
SCR TYPE 2 :
Words are built up from left to right, a single character at a time.
When the display is full, it is cleared and the subsequent words are
displayed the same way until all words of the title have been
shown.
General Setting Display Setting
22-EN
TUNER is selected on the setup main menu in step 2.
Setting the TUNER (FM) tone quality
This unit can set your preferred tone quality for FM radio source.
Setting item: FM SET
Setting contents:
HI-FI / NORMAL (Initial setting) / STABLE
HI-FI:
High-quality setting
NORMAL:
Standard setting
STABLE:
Control noise
Note
• Noise may be more noticeable when HI-FI is set, depending on the
reception status. In this case, the NORMAL setting is recommended.
“iPod” is selected on the setup main menu in step 2.
iPod/iPhone Search Mode Setting
The unit allows you to search for the iPod/iPhone using nine different
search modes.
Setting item: iPod LIST
Further setting items: PLAYLISTS / ARTISTS /ALBUMS /
AUDIOBOOKS / PODCASTS / GENRES / COMPOSERS / SONGS /
GENIUS MIX
Setting contents:
OFF / ON
Notes
• When the search mode is in Playlists/Artists/Albums/Podcasts/Genres/
Songs/Genius Mix, the initial setting is On, and when the search mode
is in Audiobooks/Composers, the initial setting is Off.
• For search mode details, refer to “Searching for a desired Song” on
page 30.
*The illustration is for CDE-SXM145BT/CDE-143BT.
Setup Before Using
BLUETOOTH is a wireless technology allowing communication
between a mobile device or personal computer over short distances.
This enables a hands-free call or data transmission between
BLUETOOTH compatible devices. BLUETOOTH transmission is
available in the unlicensed 2.4 GHz spectrum if the distance between
devices is within 10 meters. For details, refer to the BLUETOOTH
Home page (http://www.bluetooth.com).
Notes
• Depending on the BLUETOOTH version, a BLUETOOTH compatible
device may not be able to communicate with this unit.
• Proper function of this unit with all BLUETOOTH compatible devices
is not guaranteed. For handling of the BT compatible device, consult
your ALPINE dealer or ALPINE website.
• Depending on the surroundings, BLUETOOTH wireless connection
may be unstable.
• When you place a call, or perform setup operations, be sure to stop your
car in a safe place.
• Depending on the connected BLUETOOTH compatible device(s), the
function may differ. Also refer to the Owner’s Manual of the connected
device(s).
• When you search this unit using the BLUETOOTH compatible phone,
the unit name is displayed as “Alpine CD Receiver” (CDE-SXM145BT/
CDE-143BT only)/“Alpine Digital Media Receiver” (UTE-42BT only)
model name.
Before using the BLUETOOTH function, the following settings need to
be made.
Set “BT IN” to ON when you want to use Hands-Free phone
or BT Audio function. Refer to “Setting the BLUETOOTH
Connection (BT IN)” on page 23.
Note
• Before using BLUETOOTH function, it must be paired with this unit.
Refer to “How to connect to a BLUETOOTH compatible device
(Pairing)” on page 23.
Tuner Setting
iPod/iPhone Setting
BLUETOOTH Operation
About BLUETOOTH
Before Using BLUETOOTH Function
BAND/ABC SEARCH
AUDIO/SETUP
1
2
/ENTER
SOURCE/
/ II
/VOICE CTRL
Rotary encoder
Preset buttons
(1 through 6)
23-EN
For details on the control from a BLUETOOTH compatible device, refer
to the Owner’s Manual of the BLUETOOTH compatible device.
Pairing a BLUETOOTH compatible device with
SSP (Secure Simple Pairing)
1
Using your BLUETOOTH compatible device, select the
“Alpine CD Receiver” (CDE-SXM145BT/CDE-143BT only)/
“Alpine Digital Media Receiver” (UTE-42BT only) for
pairing.
2
Turn the Rotary encoder to change the head unit display
from “PAIR NO” to “PAIR YES”, and then press /ENTER.
If “PAIR NO” is selected, the connection will be canceled.
3
If the pairing was successful, “CONNECTED” is displayed
for a few seconds. The head unit then returns to its
previous state.
Pairing a BLUETOOTH compatible device without
SSP (Secure Simple Pairing)
1
Using your BLUETOOTH compatible device, select the
“Alpine CD Receiver” (CDE-SXM145BT/CDE-143BT only)/
“Alpine Digital Media Receiver” (UTE-42BT only) for
pairing.
2
Input the PIN code (“0000”) in a BLUETOOTH compatible
device.
Note
• The PIN code is fixed as “0000”.
3
If the pairing was successful, “CONNECTED” is displayed
for a few seconds. The head unit then returns to its
previous state.
Notes
• If the connection is unsuccessful, “FAILED” is displayed.
• After a successful pairing, the two devices should connect automatically
whenever the vehicle’s ignition is turned ON. However, should the
automatic connection fail, try reconnecting manually.
• Set “VISIBLE M” to VISI M ON to enable this unit to be recognised by a
BLUETOOTH compatible device, refer to “Setting the Visible Mode” on
page 24.
BLUETOOTH SETUP
The following steps 1 to 5 are common to the various BLUETOOTH
functions. For details, refer to each individual function.
Note
• Set “BT IN” to ON, and then perform BLUETOOTH SETUP operation.
Refer to “Setting the BLUETOOTH Connection (BT IN)” on page 23.
1
Press and hold AUDIOSETUP for at least 2 seconds to
activate the SETUP mode.
2
Turn the Rotary encoder to select “BLUETOOTH”, and then
press ENTER.
The BLUETOOTH setup mode is activated.
3
Turn the Rotary encoder to select the desired items and
then press ENTER.
BLUETOOTH:
BT IN*1 PAIRED DE V*2 VISIBLE M*2 CALL SOUND*2
CALLER ID*2 PB UPDATE*1/*2 PB ORDER*2 AUTO ANS*2
SPEAKER SL*2 FW VERSION*2 FW UPDATE*1
*1 The items are not displayed during a phone call.
*2 The items are not displayed if “BT IN” is set to OFF. Refer to
“Setting the BLUETOOTH Connection (BT IN)” on page 23.
4
Turn the Rotary encoder to change the settings.
5
Press and hold AUDIOSETUP for at least 2 seconds.
The SETUP mode is canceled.
Notes
•Press r to return to the previous mode.
• Pressing and holding r for at least 2 seconds will return to normal
mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
With BLUETOOTH technology, you can place a hands-free call by a
BLUETOOTH-equipped mobile phone.
Audio information of a BLUETOOTH compatible mobile phone, a
portable audio player, etc., is controllable/playable wirelessly from this
unit.
Setting item: BT IN
Setting contents:
OFF / ON (Initial setting)
ON:
Select when you want to pair your BLUETOOTH compatible phone
with this unit or/and use BLUETOOTH Audio function.
OFF:
Hands-Free Phone function and BLUETOOTH Audio are not used.
Note
• When “BT IN” is set to OFF, the indicators related to Hands-free phone
(c battery quantity and i signal strength (CDE-143BT/
UTE-42BT only)) will not be displayed.
Select one of 5 connected BLUETOOTH compatible devices that you
previously registered.
Setting item: PAIRED DE V
1
Turn the Rotary encoder to select a BLUETOOTH
compatible device you want to use (you want to change
connection) and then press ENTER.
2
Turn the Rotary encoder to select “CONNECT” then press
ENTER to connect the selected device.
The connected device is marked with “l”. Select “DISCONNECT”
to disconnect this device. Select “CLEAR” when you want to clear
the device from the device list.
How to connect to a BLUETOOTH
compatible device (Pairing)
Setting the BLUETOOTH Connection
(BT IN)
Setting the BLUETOOTH Device
24-EN
Notes
• If the connection is successfully changed, “CONNECTED” is displayed
for 2 seconds and the indicator lights up, then the display returns to
the SETUP screen.
• If a mobile phone is connected to this unit successfully, the c
indicator lights up to show the battery quantity of the connected mobile
phone. The j indicator lights up when the battery quantity is in
mid level, and it blinks in low level.
•Indicator i (Signal Strength) (CDE-143BT/UTE-42BT only):
The indicator will display the current signal strength of mobile phone.
The indicator blinks when the signal of the connected mobile phone is
weak.
• Depending on the connected mobile phone, the c (battery
quantity) and i (signal strength) (CDE-143BT/UTE-42BT only)
indicators may not be displayed.
• If all the 5 positions have been registered, you cannot register the 6th
device. To register another device, you need to delete one of the devices
from position 1 to 5 first.
You can set whether this unit can be recognised or not from a
BLUETOOTH compatible device. Normally set this to VISI M ON.
Setting item: VISIBLE M
Setting contents:
VISI M OFF / VISI M ON (Initial setting)
VISI M OFF:
Disable recognition of this unit from the BLUETOOTH compatible
device.
VISI M ON:
Enable recognition of this unit from the BLUETOOTH compatible
device.
You can flexibly customize the sound of a call to fit your own
preferences.
Setting item: CALL SOUND
Further setting items: VOL LV ADJ / TYPE SET
Adjusting the volume (VOL LV ADJ)
You can emphasise or weaken the volume level of the Phone call, the
ring tone and the microphone input to fit your own preferences.
Setting contents:
PHONE TALK:
-5 dB ~ +5 dB
RING TONE:
-5 dB ~ +5 dB
MIC GAIN:
-5 dB ~ +5 dB
Sound Auto setting (TYPE SET)
This unit provides 5 methods to improve the sound quality of calling.
You can choose the type according to your own preference.
Setting contents:
TYPE1 (Initial setting) / TYPE2 / TYPE3 / TYPE4 / TYPE5
TYPE1:
Standard Mode (recommended)
TYPE2:
Enhances the noise reduction
TYPE3:
Enhances the echo-cancel
TYPE4:
Enhances both noise reduction and echo-cancel
TYPE5:
Weakens both noise reduction and echo-cancel
Notes
• The functions below are designed to improve the sound quality of the
caller to driver.
Noise reduction: This function can reduce the road noise, but excessive
enhancement may affect the sound quality of calling.
Echo-cancel: This function can reduce echo, but excessive enhancement
may affect the sound quality of calling.
• Improvement effect differs depending on the actual calling environment,
so please choose a suitable type accordingly.
If you want to keep the ID information of the caller from others, set this
item to OFF. Telephone number will be displayed while you are dialing;
“NO NAME” will be displayed during a call.
Setting item: CALLER ID
Setting contents:
OFF / ON (Initial setting)
You can update the phone book automatically or manually.
Setting item: PB UPDATE
Further Setting contents: AUTO/MANUAL
Setting the Phone Book Auto Update ON/OFF
(AUTO)
When you select AUTO ON in this step, whenever the vehicle’s ignition
is turned ON or after the phone is re-paired with this unit, the phone
book will be updated automatically.
Setting contents:
AUTO OFF / AUTO ON (Initial setting)
Note
• “UPDATING” will be displayed during the phone book update.
Setting the Phone Book Manual Update ON/OFF
(MANUAL)
When you select UPDATE YES in this step, the phone book will be
updated immediately regardless if the Auto update function is on or off.
Setting contents:
UPDATE NO (Initial setting) / UPDATE YES
Note
• “UPDATING” will be displayed during the phone book update.
The phone book is listed alphabetically according to the initial letter of
name.
You can choose to arrange the phone book list order according to the
initial letters of the FIRST NAME or LAST NAME.
Setting item: PB ORDER
Setting contents:
FIRST NAME (Initial setting) / LAST NAME
Setting the Visible Mode
Setting the BLUETOOTH sound quality
Setting the caller information display ON/
OFF
Setting the Phone Book Update
Changing the Phone book List Order
25-EN
Note
• “WAITING” will be displayed while the Phone book order is switching.
You can cancel the “WAITING” screen to perform other operations by
pressing r when the ordering is still in progress. The phone book is
not accessible during this time. In addition, the ordering may affect the
playback of BT AUDIO.
When a call is received, you can set whether to receive it automatically
or not.
Setting item: AUTO ANS
Setting contents:
AT ANS OFF (Initial setting) / AT ANS ON
AT ANS OFF:
When a call is received, it is not answered automatically. Press f
to receive the call.
AT ANS ON:
When a call is received, it is answered automatically after about 5
seconds.
Note
• If the received call setting on the mobile phone is on, the call will be
answered automatically even though this setting is set to OFF.
You can select the connected speaker in car to output the sound signal of
telephone.
Setting item: SPEAKER SL
Setting contents:
ALL (Initial setting) / FRONT-L / FRONT-R / FRONT-LR
ALL:
The sound be output from all of speakers in car.
FRONT-L:
The sound only be output from the front left speaker.
FRONT-R:
The sound only be output from the front right speaker.
FRONT-LR:
The sound be output from the front left and front right speaker.
The current firmware version will be displayed.
Setting item: FW VERSION
Future BLUETOOTH firmware updates may become available for
phone interoperability.
For information to update your BLUETOOTH firmware, please visit
Alpine home page (http://www.alpine-usa.com).
Setting item: FW UPDATE
Setting contents:
UPDATE NO (Initial setting) / UPDATE YES
Hands-Free Phone Control
Hands-free calls are possible when using a HSP (Head Set Profile) and
HFP (Hands-Free Profile) compatible mobile phone with this unit.
Notes
• Avoid performing a hands-free call in heavy traffic or on narrow or
winding streets.
• Close the windows while calling to reduce background noise.
• If both calling parties are using hands-free devices, or the call is made in
a noisy location, difficulty hearing the other person’s voice is normal.
• Depending on telephone line conditions or certain mobile devices used,
voices may sound unnatural.
• When using a microphone, speak as directly as you can into the
microphone to pick up the best sound quality.
• Certain mobile phone features are dependent on the capabilities and
settings of your service provider’s network. Additionally, certain features
may not be activated by your service provider, and/or the provider’s
network settings may limit the feature’s functionality.
Always contact your service provider about feature availability and
functionality.
All features, functionality, and other product specifications, as well as
the information contained in the Owner’s Manual are based upon the
latest available information and are believed to be accurate at the time
of printing.
Alpine reserves the right to change or modify any information or
specifications without notice or obligation.
Incoming calls are announced by the received call ring tone and a
displayed message (PHONE).
Press f or ENTER.
The call starts.
Notes
• When “AUTO ANS” is set to AT ANS ON, you can receive a call
automatically. Refer to “Setting the Received Calls automatically (Auto
Answer)” on page 25.
• While calling, the source sound on the unit is muted. After calling,
playback will resume.
• The caller name will not be displayed during phonebook updating.
Press f.
The call finishes.
Note
• You can also hang up the call by pressing and holding r for at least 2
seconds.
When a Smartphone equipped with voice recognition function is paired
with this unit, the Smartphone can be controlled by Voice Control via
this unit.
Press and hold VOICE CTRL for at least 2 seconds to
activate the Voice Recognition mode.
After the Voice Recognition mode is activated and “SPEAK” is
displayed, you can make a phone call, play a song, etc., via this
unit by inputting voice control commands*.
*Please refer to your smartphone manual for other voice control
commands.
Setting the Received Calls automatically
(Auto Answer)
Selecting the output speaker
Displaying the firmware version
Updating the firmware
About the Hands-Free Phone
Answering a Call
Hanging up the Telephone
Voice Control Operation
26-EN
Notes
• You can perform this operation only when a Voice recognition
compatible mobile phone is connected. If the mobile phone is not
compatible with the Voice recognition, “NO SUPPORT” is displayed for
2 seconds.
• The Voice recognition function performance depends on the recognition
range of the mobile phone and mounting location of the microphone.
Please pay attention when the microphone is mounted.
• Voice recognition operation depends on the function of the mobile
phone. For details, refer to the Owner’s Manual of the mobile phone.
• If a called person that you say is not found, “NO CALL” is displayed for
2 seconds.
• Please obey all local traffic laws while using this function.
Call History is recorded for the last dialed/received/missed calls. There
are various ways of making calls based on the “Calling”. The following
steps 1 to 5 are common to the various ways of making these calls. For
details, refer to each individual category for making calls.
1
Press f.
The outgoing method list is displayed.
2
Turn the Rotary encoder to select the outgoing mode.
Setting contents:
DIALED / RECEIVED / MISSED / PHONE BOOK
DIALED:
Dialed history
RECEIVED:
Received history
MISSED:
Missed incoming history
PHONE BOOK:
Mobile phone book
3
Press ENTER.
The outgoing mode is activated, and each mode list is displayed.
Note
• It may take some time for the list to be displayed, and also directly after
connection, the list may not be brought up to date.
4
Turn the Rotary encoder to select a name or a telephone
number from the list.
Note
• You can use Phone book alphabet search function to search a name or
number from Phone Book. For details, refer to “Phone book alphabet
search function” on page 26.
5
Press ENTER.
The selected telephone will be called.
If one name has several numbers registered in the telephone
book, press ENTER after selecting the name*, then turn the
Rotary encoder to choose the desired number and press
ENTER, the telephone will be called. Depending on the
connected mobile phone, this function may not be performed.
*If the name cannot be recognised, default number will be
displayed.
Notes
•Press r to return to the previous mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
• If there is no content in DIALED/RECEIVED/MISSED/PHONE BOOK
list, “----------” will be displayed for 2 seconds.
• If you place a call directly from the paired mobile phone, the phone
number is not displayed, you cannot redial from the unit in this case.
Redialing a Number In Outgoing History
Previously dialed telephone numbers (Maximum 20 items) are stored in
dialed calls history. You can redial a number by searching from dialed
calls history.
Setting item: DIALED
Dialing a Number In Incoming History
Telephone numbers from received calls (Maximum 20 items) are stored
in the Received List. You can redial these numbers by searching here.
Setting item: RECEIVED
Dialing a Number In Incoming Missed Call
History
Telephone numbers for received calls that are missed (Maximum 20
items), are stored in the Missed List. You can redial these numbers by
searching here.
Setting item: MISSED
Dialing a Number In The Phone Book
Up to 1,000 names (at most 3 telephone numbers for each name) are
downloadable from a mobile phone. Dial a call by selecting a person
from the phone book list.
Setting item: PHONE BOOK
Notes
• The order of the list display depends on the setting of “PB ORDER”
(refer to “Changing the Phone book List Order” on page 24).
• If the call history or phone book of the mobile phone is added or deleted
while it is connected to the unit, the list displayed on the unit may not
be brought up to date. If it is not updated, you cannot correctly place a
call.
• You can display the information of a number stored in phone book by
pressing k. Each press changes the display as Name Tel eph one
NO. Telephone label* Name
If the information cannot be obtained, “NO NAME”, “NO NUMBER”
or “NO LABEL” will display.
*The telephone label of a number depends on the number information
stored in Phone book of the mobile phone, which includes 4
types-MOBILE, HOME, OFFICE, and OTHER.
Phone book alphabet search function
You can select the first three letters to search for a desired name in
phone book list by using the Phone book alphabet search function.
For example:
Searching a name “Michael James”
The following example explains how the search is performed.
Depending on the setting in PB ORDER (refer to “Changing the Phone
book List Order” on page 24), the phone book is listed in first name or
last name order. Please search for the first name or last name according
to the setting.
1
Press BAND/ABC SEARCH while in the phone book list, the
phone book alphabet search mode is activated.
The letter selection list is displayed.
2
Turn the Rotary encoder to select the first letter (e.g. M),
and then press .
The letter selection list is displayed.
Calling
27-EN
3
Turn the Rotary encoder to select the second letter (e.g. I),
and then press .
The letter selection list is displayed.
4
Turn the Rotary encoder to select the third letter (e.g. C),
and then press ENTER.
The names stored in phone book which begin with “MIC” are
searched.
5
Turn the Rotary encoder to select the desired name (e.g.
Michael James), and then press ENTER to make the
call.
Notes
• If the selected name has several numbers registered in phone book, you
need to turn the Rotary encoder to select the desired number, and
then press ENTER.
•Press in step 3 or 4 to delete the current entry and return to the
previous step.
• You can search for a name by its first letter, first two letters or first three
letters. Press ENTER after entering the desired number of letters. A
list displays the names beginning with the entered letter(s).
• If there is no First or Last name, you may not be able to search for a
contact using the Alphabet Search function.
If a second call is received during a current call, you can have the first
caller wait momentarily while you take the second call. When you are
finished with one call, you can switch to the other one.
If a second call is received during the current call (call1),
the information of second caller (call2) is displayed
instead of the current caller's name. Press 2, the call
waiting mode is activated.
In this case, call1 is on hold, while you take call2.
Notes
• In the call waiting mode, press 1 or 2 to switch between the calling
person and the person on hold.
• In the call waiting mode, press and hold 1 or 2 for at least 2 seconds
to hang up call1 or call2, and the other call will be answered
automatically.
• In the call waiting mode, you can press k to change the display
between waiting number (1or 2) and caller name.
Assign numbers that you dial frequently to presets for quick recall. You
can assign up to six frequently called phone numbers to number presets.
Select a number you want to preset from the Phone Book
list. Press and hold any one of the preset buttons (1
through 6) as the one that you wish to store the number
for at least 2 seconds.
The phone number you selected is stored in presets.
Notes
• If the name has several numbers registered in the phone book, press
ENTER after selecting the name. Turn the Rotary encoder to
choose the desired number. Press and hold any one of the preset
buttons (1 through 6) for at least 2 seconds. The selected number is
stored as a preset number.
• A total of 30 phone numbers can be stored in the preset memory ( 6
numbers for each mobile phone in the paired device list). If a mobile
phone is deleted from the paired device list, the stored preset numbers of
this mobile phone are deleted, even when it is paired again.
• If you store a phone number in a preset with a previously stored
number, the current number will be cleared and replaced by the new
one.
1
Press any one of the preset buttons (1 through 6) that has
had a number stored in the phone mode.
The information (name/number) stored in the preset station is
displayed.
2
Press ENTER or f.
The stored preset number is dialed directly.
While calling, you can adjust the volume.
Turn the Rotary encoder to adjust the volume.
Note
• You may need to increase volume from your regular audio listening
source level. However, increasing the volume excessively may result in
feedback. Feedback is directly related to the volume. Turning down the
volume as low as acceptable, will reduce it. Positioning the microphone
in a direction away from the main car speakers (e.g. clipped on sun
visor) may also reduce feedback at high volume.
While calling, activating the Voice Mute function will instantly mute the
microphone input. Your voice will not be heard by the caller.
While calling, press to mute the microphone input.
Press again will bring the microphone input back to its
previous volume level.
Note
• The operation can also be performed in the option menu of phone mode
(calling mode). Refer to “Option Menu Setting” on page 19.
While making a call, this function allows you to initiate the transfer of
the audio between the mobile phone and the speakers in the car.
While calling, press BAND or press and hold to switch
the call sound between the unit and mobile phone.
Notes
• Depending on the mobile phone, this operation may not be performed.
• The operation can also be performed in the option menu of phone mode
(calling mode). Refer to “Option Menu Setting” on page 19.
Call waiting function
Preset a number in the Phone Book
(Shortcut dial)
Dialing the preset number
Adjusting the volume when receiving a
Call
Muting the microphone input quickly
(Voice Mute)
Call Switching Operation
28-EN
BLUETOOTH Audio Operation
Audio information of a BLUETOOTH compatible mobile phone, a
portable player, etc., is controllable/playable wirelessly* from this unit.
*To play back audio, a mobile phone or a portable player conforming to
A2DP (Advanced Audio Distribution Profile) and AVRCP (Audio/
Video Remote Control Profile) is required.
Not all functions work with all devices.
Notes
• Set “BT IN” to ON when you want to use BLUETOOTH Audio
function. Refer to “Setting the BLUETOOTH Connection (BT IN)” on
page 23.
• During a call, sound on the BLUETOOTH audio source is muted.
• If you operate the Hands-free phone (e.g. searching in the phonebook)
while using the BLUETOOTH Audio function, BLUETOOTH Audio
playback may be affected.
Press SOURCE/ to select the BT AUDIO mode.
Press .
Returns the beginning of the song being played back.
Press .
Forwards the next song.
Press and hold or .
Fast backward/fast forward track continuously.
Press 1 or 2 to select the desired Group (Folder).
Pressing and holding 1 or 2 will change folders
continuously.
Note
• The action depends on the connected device.
Press .
A playback stops. Touching again will resume a playback.
Tag information can be displayed.
Press k during a song playing and pausing.
Each press changes the display.
For details, refer to “Displaying the Text” on page 18.
*The illustration is for CDE-SXM145BT/CDE-143BT.
Note
• You can connect Nokia (Symbian™) phone via USB port to play back
the music stored on your phone.
Playing MP3/WMA Files from Flash Memory
(optional)
If you connect a Flash device containing MP3/WMA, MP3/WMA files
can be played back.
1
Press SOURCE to switch to the USB AUDIO mode.
2
To pause playback, press .
Pressing again will resume the playback.
Notes
• The root folder is displayed as “\ROOT” in the Folder Name Search
mode.
• This unit plays back files in Flash Memory with the same controls and
modes used for playback of CDs containing MP3/WMA. For details,
refer to “CD/MP3/WMA (CDE-SXM145BT/CDE-143BT only)” on
page 12.
• Before disconnecting Flash Memory, be sure to change to another source
or set to pause.
• The playback time may not be correctly displayed when a VBR
(Variable Bit Rate) recorded file is played back.
Recalling the BLUETOOTH Audio Mode
Selecting the desired Song
Selecting the Desired Group (Folder)
Pausing
Displaying the Text
Flash Memory (optional)
SOURCE/
/ II
29-EN
Flash Memory Connection (optional)
1
Open the cover of the USB Port.
2
Connection the Flash Memory directly to the USB Port, or
via the USB cable.
1
Carefully, pull out the Flash Memory Device from the USB
cable or the USB Port.
2
Close the cover of the USB Port.
Notes
• Change to a source other than the Flash Memory mode, then remove
the Flash Memory Device. If Flash Memory is removed in the Flash
Memory mode, data may be damaged.
• When removing Flash Memory, pull it out straight.
• If sound is not output or Flash Memory is not recognized even when
connected, remove the Flash Memory Device once, and then connect it
again.
• Route the USB cable away from other cables, etc.
• After removing the Flash Memory, close the cover of the USB Port to
prevent dust or foreign objects from entering and causing a
malfunction.
About MP3/WMA File of Flash Memory
Playing back MP3/WMA
MP3/WMA files are prepared, then stored to a Flash Memory Device.
This unit can recognise at most 255 folders and 255 files per folder
stored in Flash Memory. Playback may not be performed if a Flash
Memory Device exceeds the limitations described above.
Do not make a file’s playback time more than 1 hour.
Media supported
This device can play back files stored on Flash Memory devices
designed for USB connection.
Corresponding File Systems
This device supports FAT 12/16/32 for Flash Memory devices.
*The illustration is for CDE-SXM145BT/CDE-143BT.
Connecting an iPod/iPhone
An iPod/iPhone can be connected to this unit by using the Interface
cable for iPod (included with iPod). When an iPod/iPhone is connected
to this unit, you can choose to control the iPod/iPhone using its own
controls or by the head unit controls. For details, refer to “Setting the
iPod Control” on page 30.
These instructions refer to controlling the iPod/iPhone from this Head
Unit (HU) only. Make sure iPod Control is set to HU MODE (HEAD
UNIT). Refer to “Setting the iPod Control” on page 30. Refer to the
iPod/iPhone manual for operations using the iPod/iPhone.
Notes
• An iPhone connected to this unit operates as an iPod. The iPhone can
be used as a hands-free device using the integrated BLUETOOTH
module.
• Internet and telephone functions of iPod touch or iPhone, etc., can also
be used when connecting to the unit. However, using these functions
will stop or pause the playing songs. Stop using any applications or the
phone functions before going back to music playback on your device .
About iPod/iPhone models usable with this unit
• Confirmed devices regarding Made for iPod. Correct function of
earlier versions cannot be guaranteed.
iPod touch (4th generation): Ver.5.1.1
iPod nano (6th generation): Ver.1.2
iPod touch (3rd generation): Ver.5.1.1
iPod nano (5th generation): Ver.1.0.2
iPod classic (160 GB) (Late 2009): Ver.2.0.4
Connect Flash Memory
Remove Flash Memory
USB Connection TerminalThis unit
Flash Memory
(sold separately)
or
Flash Memory
(sold separately)
Cable (sold
separately)
iPod/iPhone (optional)
BAND/ABC SEARCH
1
2
4
5
/ENTER/OPTION
SOURCE/
/ II
Rotary encoder
Preset buttons
(1 through 6)
USB Connection Terminal
This unit
iPod/iPhone
(sold separately)
Included with iPod/iPhone
30-EN
iPod touch (2nd generation): Ver.4.2.1
iPod nano (4th generation): Ver.1.0.4
iPod classic (120 GB): Ver.2.0.1
iPod touch (1st generation): Ver.3.1.3
iPod nano (3rd generation): Ver.1.1.3
iPod classic (80 GB, 160 GB): Ver.1.1.2
• Confirmed devices regarding Made for iPhone. Correct function of
earlier versions cannot be guaranteed.
iPhone 4S: Ver.5.1.1
iPhone 4: Ver.5.1.1
iPhone 3GS: Ver.5.1.1
iPhone 3G: Ver.4.2.1
iPhone: Ver.3.1.3
• For clarity in identifying your model of iPod, please see Apple’s own
document “Identifying iPod models” at
http://support.apple.com/kb/HT1353
• This unit does not support video playback from iPod/iPhone, even
using a video-compatible cable.
Setting the iPod Control
When an iPod/iPhone is connected, operate it from its own controls or
from the head unit.
1
Press and hold ENTEROPTION for at least 2 seconds
in the iPod mode.
The Option menu for iPod mode is activated.
2
Turn the Rotary encoder to select APP DIRECT, and then
press ENTER.
The iPod control mode will switch between iPod MODE and HU
MODE.
HU MODE (HEAD UNIT):
Operate the iPod/iPhone via this unit.
iPod MODE:
Operate the iPod/iPhone using its own controls. When iPod is
selected, some functions will not be operable via the head unit.
Notes
• During HU MODE, you can switch to iPod MODE directly by pressing
BAND.
•The “P” indicator lights up when the iPod MODE is activated.
• Once the control mode is changed, this will set pause status, press
to continue.
• Depending upon the iPod used, iPod control may not be selectable. Or,
if iPod is selected, operation must still be from the head unit.
Playback
1
Press SOURCE to switch to the iPod mode.
2
Press or to select the desired song.
Pressing and holding or will fast backward/fast
forward the current track.
3
To pause playback, press .
Pressing again will resume playback.
Notes
• A song playing on the iPod/iPhone while it is connected to this unit will
continue to play from where it was paused after disconnection.
• If you listen to an episode from a selected Podcast or Audiobook, the
episode can be changed by pressing 1 or 2.
• An episode may have several chapters. The chapter can be changed by
pressing or .
• During iPod/iPhone playback, press r, and then you can quickly
return to the hierarchy level selected last time in the search mode.
Searching for a desired Song
An iPod/iPhone can contain thousands of songs. This unit utilizes
various methods to make searches for desired content as simple as
possible.
Each music category has its own individual hierarchy as shown below.
Choose a music category from the list below to narrow searches quickly.
Note
• You can select your preferred search mode. Refer to “iPod/iPhone
Search Mode Setting” on page 22.
For example:
Searching by Artist name
The following example explains how an ARTIST search is performed.
Another search mode can be used for the same operation, although the
hierarchy differs.
1
Press ENTER to activate the search selection mode.
The “” indicator lights up.
2
Turn the Rotary encoder to select the ARTIST search
mode, and then press ENTER.
SHUFFLEALL*1 PLAYLIST ARTIST ALBUM SONG
PODCAST GENRE COMPOSER AUDIOBOOK GENIUS
MIX*2/*3 SHUFFLEALL
*1 Refer to “Random Play Shuffle (M.I.X.)” on page 31.
*2 Depending on the connected iPod/iPhone, Genius Mix function
may not be supported.
*3 When an iPod/iPhone with Genius Mix list created by iTunes is
connected to this unit, GENIUS MIX search mode can be used
to search a Genius Mix list.
Note
• The display of search mode list varies depending on the setting of iPod
LIST. For details, refer to “iPod/iPhone Search Mode Setting” on
page 22.
3
Turn the Rotary encoder to select the desired Artist, and
then press ENTER.
4
Turn the Rotary encoder to select the desired Album, and
then press ENTER.
5
Turn the Rotary encoder to select the desired Song, and
then press ENTER.
Notes
• After pressing and holding ENTER for at least 2 seconds while in
each hierarchy (except Song, Audiobook and Genius Mix list hierarchy),
all songs of the selected hierarchy are played back.
Hierarchy 1 Hierarchy 2 Hierarchy 3 Hierarchy 4
Playlist Song — —
Artist*Album*Song —
Album*Song — —
Song———
Podcast Episode — —
Genre*Artist*Album*Song
Composer*Album*Song —
Audiobook — — —
Genius Mix list———
31-EN
• After selecting [ALL] in the search mode with“*”, (refer to the table on
the previous page) press and hold ENTER for at least 2 seconds to
play back all songs in the iPod/iPhone or selected search mode.
• While in the search mode, if you press and hold r for 2 seconds, or no
operation is performed for 60 seconds, the search mode is canceled.
• In the search mode, pressing r will return to the previous mode.
• When search is made during M.I.X. play, the M.I.X. play mode will be
canceled.
• “NO SONG” will be displayed if there are no songs in the selected
playlist in the PLAYLIST search mode.
• “NO PODCAST” will be displayed if there is no podcast data in the
iPod/iPhone in the PODCAST search mode.
• “NOAUDIOBOK” will be displayed if there is no audiobook data in the
iPod/iPhone in AUDIOBOOK search mode.
• “NO GENIUS” will be displayed if there is no genius mix list data in the
GENIUS MIX search mode.
• If “iPod name” stored in the iPod/iPhone is selected in the desired
Playlist search mode, and ENTER is pressed, you can search for all
songs in the iPod/iPhone. Also, if you press and hold ENTER for at
least 2 seconds, all songs in the iPod/iPhone are played back.
• Depending on the iPod/iPhone, podcast search is not supported.
• If any one of the preset buttons (1 through 6) is pressed in the
search mode, a search can be made quickly by skipping to the specified
location. For details, refer to “Direct Search Function” on page 31.
• During search mode, a search can be made quickly by Alphabet search
function to find the desired artist or song, etc. For details, refer to
“Alphabet search function” on page 31.
Alphabet search function
Use the alphabet search function to search for an album, song, etc., by its
first letter. Select the first letter of the desired title (album, song, etc.),
and the titles beginning with this letter are listed.
1
After selecting a search mode, press ABC SEARCH.
The letter selection list is displayed.
2
Turn the Rotary encoder to select a desired letter (e.g. M),
and then press ENTER.
The titles beginning with “M” are listed.
3
Turn the Rotary encoder to select the desired title.
Notes
• While in Alphabet search mode, pressing r will return to the previous
mode.
• If the PLAYLIST search mode is used to search for a song, the Alphabet
search function is inactive in the song search hierarchy.
• This function is unavailable when Genius Mix list is selected.
Direct Search Function
Direct search can be used to jump a fixed percentage of titles within the
current search category (album, song, etc.).
In the search mode, press any one of the preset buttons (1
through 6) to quickly skip over a designated percent of
your song content.
Song search example:
If there are 100 songs in your iPod/iPhone, they are divided into 6
groups using percentages (shown below). These groups are
assigned to the preset buttons (1 through 6).
Example 1:
Suppose the song you are searching for is located at around the
middle (50%) of your library: press button 4 to jump to the 50th
song and turn the Rotary encoder to find the desired song.
Example 2:
Suppose the song you are searching for is located near the end
(83%) of your library: press button 6 to jump to the 83rd song
and turn the Rotary encoder to find the desired song.
Notes
• This function is also applicable to CD/MP3/WMA search.
• This function is unavailable when Genius Mix list is selected.
• This function is inactive during Alphabet Search mode.
Change Playlist/Artist/Album/Genre/
Composer
Playlist/Artist/Album/Genre/Composer can be easily changed.
For example, if you listen to a song from a selected album, the next or
previous album can be selected.
Press 1 or 2 to change to the previous or next Playlist/
Artist/Album/Genre/Composer.
Notes
• If the song search mode was used to select a song, this function is
inactive.
• If an album is selected during an artist search, other albums by that
artist are searchable.
• This function is inactive during shuffle (x) playback.
Random Play Shuffle (M.I.X.)
The Shuffle function of the iPod/iPhone is displayed as x on this unit.
Shuffle Albums:
The songs on each album are played back in proper order. Upon
completion of all the songs on the album, the next album is selected
randomly. This continues until all albums have been played.
Shuffle Songs:
Song shuffle randomly plays back songs within a selected category
(playlist, album, etc.). The songs within the category are played just
once until all songs have been played.
1
Press 5 x.
The songs are played back in random sequence.
MIX ALBUM*1 MIX SONG*2 MIX OFF MIX ALBUM
*1 Shuffle Albums.
*2 Shuffle Songs.
2
To cancel M.I.X. play, select MIX OFF with the above
procedure.
Note
• If a song is selected in the album search mode before selecting M.I.X.
play, the songs will not play back randomly even when Shuffle Albums
is selected.
All 100 songs (100%)
0% 17% 33% 50% 67% 83%
Preset
buttons 123456
Songs 1st
song
17th
song
33rd
song
50th
song
67th
song
83rd
song
32-EN
Shuffle ALL:
Shuffle ALL plays all songs in the iPod/iPhone randomly. Any one
song does not play back again until all songs have been played back.
1
Press ENTER to activate the search selection mode.
2
Turn the Rotary encoder to select SHUFFLEALL, and then
press ENTER.
To cancel M.I.X. play, press 5 x to select OFF.
Note
• If Shuffle ALL is selected, the selected songs being played back in the
search mode are canceled.
Repeat Play
Only Repeat One is available for the iPod/iPhone.
Repeat One:
A single song is repeatedly played back.
1
Press z 4.
The song is played back repeatedly.
RPT ONE* RPT OFF RPT ONE
*Repeat One.
2
To cancel repeat play, select RPT OFF with the above
procedure.
Note
• During repeat playback, no other songs are selectable by pressing
or .
*The illustration is for CDE-SXM145BT/CDE-143BT.
SiriusXM Tuner operation:
When a SiriusXM Tuner is connected to this unit, the following
operations may be performed.
Receiving Channels with the SiriusXM Tuner
About SiriusXM Satellite Radio
Everything worth listening to is on SiriusXM. Get over 130 channels,
including the most commercial-free music, plus the best sports, news,
talk and entertainment. A SiriusXM Tuner and Subscription are required.
For more information, visit www.siriusxm.com/activatenow, or call
1-866-635-2349.
To activate SiriusXM Canada service go www.xmradio.ca and click on
“ACTIVATE RADIO” in the top right corner, or call 1-877-438-9677.
Note
• The SiriusXM Satellite Radio controls on this unit are available only
when a SiriusXM Tuner is connected.
1
Press SOURCE to activate the Satellite Radio
(SIRIUSXM) mode.
2
Press or to select the desired channel.
Holding down or will rapidly browse through the
channels.
Alternatively, you can enter the number of the desired channel
using the numeric keypad on an optional remote control.
SiriusXM Setting (CDE-SXM145BT Only)
The following steps 1 to 5 are common to the various SiriusXM
functions. For details, refer to each individual function.
Note
• Connect a SiriusXM Tuner, and then perform SiriusXM SETUP
operation.
1
Press and hold AUDIOSETUP for at least 2 seconds to
activate the SETUP mode.
SiriusXM Satellite Radio
Operation (CDE-SXM145BT
only)
BAND
/ENTER/OPTION
SOURCE/
/ II
1
2
Rotary encoder
Preset buttons
(1 through 6)
33-EN
2
Turn the Rotary encoder to select “SiriusXM”, and then
press ENTER.
The SiriusXM setup mode is activated.
3
Turn the Rotary encoder to select the desired items and
then press ENTER.
SiriusXM:
ALERTSETUP GAME ALERT P-LOCK SIGNAL IND
TUNE START
4
Turn the Rotary encoder to change the settings.
5
Press and hold AUDIOSETUP for at least 2 seconds.
The SETUP mode is canceled.
Notes
•Press r to return to the previous mode.
• Pressing and holding r for at least 2 seconds will return to normal
mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
The following operations can be performed to change the Alert settings.
The Artist and Song Alerts feature allows you to mark Artists and Songs
from the current channel and then the unit alerts you later when the
marked Artists or Songs are playing on other channels.
Setting item: ALERTSETUP
Setting contents:
ALERT LIST / ALERT / A S ALERT / DELETE ALL
ALERT LIST
This menu option allows you to enable the Artist/Song alert for
individual Artist/Songs (ALERT ON or OFF) or to delete individual
stored Artist/Song alerts (DELETE).
1Turn the Rotary encoder to select ALERT LIST, and then press
ENTER.
2Turn the Rotary encoder to select a stored Artist or Song,
and then press ENTER.
3Turn the Rotary encoder to ALERT to enable (ALERT ON) or
disable (ALERT OFF) the alert for the selected Artist/Song or
turn the Rotary encoder to select DELETE to delete the
selected Artist/Song from memory.
ALERT
This menu option allows you to temporarily disable the Artist/
Song Alerts for all Artists/Songs. When the Alerts are re-enabled,
individual Artist/Song Alert disabled in the ALERT LIST menu
setting remain disabled.
Turn the Rotary encoder to select ALERT ON or OFF, and
then press ENTER.
If ON is set, the alert for all stored Artists/Songs is enabled.
If OFF is set, the alerts for all stored Artists/Songs are disabled.
A S ALERT
This menu option allows you to enable the alerts of all sources.
Turn the Rotary encoder to select ON or OFF, and then press
ENTER.
If ON is set, the alert of all source is enabled.
If OFF is set, the alert of all source is disabled.
DELETE ALL
This operation will delete all alerts (artists, songs and team) stored
in memory.
After selecting this item,
Turn the Rotary encoder to select DELETE YES, and then
press ENTER.
This menu option allows you to select your favorite teams, organized by
leagues, so that you will be alerted later when your favorite teams are
playing on other channels.
Setting item: GAME ALERT
After selecting GAME ALERT, a sports league list will be displayed.
1Turn the Rotary encoder to select the desired league, and
then press ENTER.
2Turn the Rotary encoder to select a team you want to store,
and then press ENTER.
A “TEAM SAVED” pop-up screen is followed by an “XX U(sed)/YY
E(mpty)”.
XX is the total number of Artist/Song/Game alert items stored
in memory, and YY is the total number of memory slots still
available for storage.
Note
• Select “NONE” on the team list if you do not want to store in
memory.
You can lock out channels with passcode protection. Channels that are
locked cannot be accessed without entering the passcode. You can
unlock a channel or change the passcode using this menu option.
Setting item: P-LOCK
Setting contents:
CLEAR ALL / LOCKED CH / EDIT CODE
How to input passcode?
1
After select P-LOCK, a passcode input screen will be
displayed.
2
Input the passcode using the Rotary encoder.
The initial default 4-digit passcode is set to 0000.
The passcode is entered one digit at a time with the Rotary
encoder.
For example, by turning to clockwise 2 steps, the number 1 is
selected.
After entering the digit, it is displayed as “l” (asterisk).
3
Press , and then input the next digit of the passcode
as described in step 2.
4
Repeat steps 2 to 3 until the 4 digits of the passcode are
entered, and then press ENTER.
After the correct passcode is entered, the LOCKED CH/CLEAR
ALL/EDIT CODE items can be adjusted.
CLEAR ALL:
Unlock all locked channels.
Turn the Rotary encoder to select CLEAR YES, and then press
ENTER.
LOCKED CH:
After selecting this item, turn the Rotary encoder to select a
channel from channel list, press ENTER to select to lock or
unlock the channel. Locked channels cannot be tuned without
entering the passcode.
The locked channel will be displayed with “L” before channel No.
EDIT CODE:
Change the passcode.
1 Input the old passcode as steps 1 to 4 in “How to input
passcode?”.
After the old passcode is entered, the new passcode input
screen will be displayed.
Managing Artist and Song Alerts
Setting the Favorite Sports Team Alerts
Setting the Parental Control
34-EN
2 Input the new passcode as steps 1 to 4 in “How to input
passcode?”.
A confirm screen (CNFIRM) will be displayed and the new
passcode must be entered again for confirmation.
When the passcode is changed successfully, the unit will
display CODE SAVED.
Note
• Keep a note of the numbers somewhere safe in case you should
forget it.
You can check the signal strength through this setting item.
Setting item: SIGNAL IND
Setting content:
SIGNAL IND
SIGNAL IND:
This menu item displays the SiriusXM signal strength as STRONG,
GOOD, WEAK or NO SIGNAL.
Note
• If the Signal Indicator reports Weak or No Signal and your vehicle is
parked outside with no obstructions to the southern sky, then your
SiriusXM antenna may not be properly installed or may have become
damaged.
Tuning to a Preset that is a music channel will start a song from the
beginning.
Setting item: TUNE START
Setting contents:
OFF / ON (Initial setting)
OFF:
When set to OFF, Tune Start mode is unavailable.
ON:
When ON, selecting a preset station will automatically reset the
currently playing song from its beginning. Pressing r will return
to live satellite radio.
Note
• Displayed only when SiriusXM SXV200 Tuner is connected.
Checking the SiriusXM Radio ID Number
To subscribe to the SiriusXM Satellite Radio service, it is necessary to
locate and identify the Radio ID of your SiriusXM Tuner. The Radio ID
contains 8 characters and can be found on the bottom of your SiriusXM
Tuner or can be displayed on when selecting Channel 0 by following the
steps below:
1
While in the Satellite Radio Mode, press or to
select channel “0”.
The unit displays “RADIO ID” and ID number alternately.
Note
• The Radio ID does not include the letters I, O, S or F.
2
To cancel the ID number display, select a channel other
than “0”.
Storing Channel Presets
1
Press BAND to select the desired band you want to store
the preset in.
There are 3 Satellite Radio Preset bands.
Each press of BAND changes the band: SXM1 SXM2 SXM3
SXM1
2
Tune to the desired channel, and then press and hold (for
at least 2 seconds) one of the preset buttons (1 through 6)
to store the channel.
The display then shows the stored Band and preset number (for
example, SXM1-3 is shown when preset 3 of BAND1 is selected).
3
Repeat the procedure to store up to 5 other channels onto
the same band.
Notes
• A total of 18 channels can be stored in the preset memory, 6 Channels
for each band (SXM1, SXM2 and SXM3).
• If you store a new channel into a preset which already has a channel
assigned, the current channel will be cleared and replaced with the new
one.
Tuning Channels using Presets
1
Press BAND to select the desired band of Presets you wish
to access.
2
Press the preset buttons (1 through 6) that has your
desired Satellite Radio channel stored in memory.
Storing the desired Artist and Song Alerts
While listening to SiriusXM Satellite Radio, you can be alerted when
your favorite songs or artists are playing on other channels. An
interruption ALERT will be displayed when a matching artist or song is
found on another channel. For receiving interruption ALERT
information, refer to “Receiving and Tuning to an Alert” on page 35.
1
Press and hold ENTER/OPTION for at least 2 seconds
when a Song or the song of an Artist you want to store is
playing.
The Option mode is activated.
2
Turn the Rotary encoder to select ALERT MEMO, and then
press ENTER.
3
Turn the Rotary encoder to choose SAVE ART? or SAVE
SNG? (when available), and then press ENTER.
Note
• If both the artist name and song title are not available to save,
UNAVAILABL will be displayed.
4
The new alert was stored in memory.
An “ART/SONG SAVED” pop-up screen is followed by an “XX
U(sed)/YY E(mpty)”.
XX is the total number of song titles or artist names stored in
memory, and YY is the total number of memory locations still
available for storage.
Confirming the strength of the SiriusXM
signal
Setting Tune Start
35-EN
Notes
• If you try to store when the memory is full, “MEM FULL” is displayed
followed by “REPLACE/CANCEL”. If you want to replace an existing
alert item, select “REPLACE” by turning Rotary encoder, and then
press ENTER, the existing alert list stored in memory is displayed.
Select one of the stored alerts using the Rotary encoder. To replace the
selected alert, press ENTER and an “ART/SONG SAVED” pop-up
screen is followed by an “XX U(sed)/YY E(mpty)”.
• You can manage the stored Alert memory setting on Setup mode, for
details, refer to “Managing Artist and Song Alerts” on page 33.
• If no operation is performed for 60 seconds, the setting mode is
canceled.
Tune Scan Function
While listening to SiriusXM Satellite Radio, you can scan through all the
songs you have not yet listened to from your current band of preset
channels.
1
Press and hold /ENTER/OPTION for at least 2 seconds
when you want to scan the preset music.
The Option mode is activated.
2
Turn the Rotary encoder to select TUNE SCAN, and then
press /ENTER.
The TUNE SCAN mode is activated, and the “R” indicator will
blink.
Press /ENTER during scan playback, tune scan mode will be
canceled and the selected track will be played back normally, at
the same time the “R” indicator disappears.
Press r during scan playback to cancel Tune Scan mode. The
tuner returns to the channel before Tune Scan was initiated and
“SCAN STOP” will be displayed.
Notes
• This function is available when SiriusXM SXV200 Vehicle Tuner is
connected.
• If no operation is performed during the scanning process, when
scanning finishes, the next mode depends on the SiriusXM Tuner.
• During Tune Scan mode, the artist name song name will be displayed in
the first 3 seconds.
• The SiriusXM Tune scans through the songs from the preset music
channels on the current band only, scanning from oldest to newest.
Tune Start Function
When the user tunes to a preset station that plays music-type content,
the SiriusXM tuner plays the currently playing track for that channel
from the track start. Therefore, the user can enjoy the full track (i.e.,
song) rather than playing the channel from the current live play point.
To cover the case when the user prefers non-Tune Start Function, you
can set TUNE START to OFF, for details, refer to “Setting Tune Start” on
page 34.
Note
• Preset stations that play other than music-type content will start playing
the channel from the current live play point when selected.
Receiving and Tuning to an Alert
Whenever a stored sports team, artist, or song is playing on another
channel, an interruption ALERT appears on the unit display. To tune to
the game, artist or song identified by the alert, follow the steps below:
1
Turn the Rotary encoder to select the desired game, artist
or song from the list of active alerts.
2
Press ENTER.
Notes
• If no operation is performed for 5 seconds, the unit returns to normal
mode.
• Sports teams/Artist name and Song title which you have stored and
which are currently playing will be displayed in a category called “MY
GAMES”/“MY MUSIC” in search mode. For details, refer to “Search
Function” on page 35.
Search Function
You can search for SiriusXM programming content by Category or by
Channel.
1
Press ENTER in the SiriusXM mode.
2
Turn the Rotary encoder to select the desired Category,
and then press ENTER.
3
Turn the Rotary encoder to select the desired Channel
Name, and then press ENTER.
1
Turn the Rotary encoder to select ALL CHANS after step 1,
and then press ENTER.
All Channels will be displayed in a list.
2
Turn the Rotary encoder to select the desired channel,
and then press ENTER to confirm.
Note
•Press k, the information of the broadcasting channels will be
displayed. You can choose the desired channel from the artist name list
or song name list.
Each time you press k, the display changes as below.
Channel number Channel name Artist name
Song name Channel number
1
Turn the Rotary encoder to select MY MUSIC* after step 1,
and then press ENTER.
The artist names and song names that you have stored and are
currently playing will be displayed in a list.
*Displayed only when the stored song or artist is broadcasting.
2
Turn the Rotary encoder to select the desired artist/song,
and then press ENTER to confirm.
The channel of the selected artist/song being broadcast is
received.
Searching by Channel
Searching by My Music
36-EN
Note
•Press k, the information of the broadcasting channels will be
displayed. You can choose the desired channel from the artist name list
or song name list.
Each time you press k, the display changes as below.
Artist name Song name Artist name
1
Turn the Rotary encoder to select MY GAMES* after step 1,
and then press ENTER.
The sport teams that you have stored and the game is currently
broadcasting will be displayed in a list.
*Displayed only when the game of stored team is broadcasting.
2
Turn the Rotary encoder to select the desired team, and
then press ENTER to confirm.
The channel of the selected game being broadcast is received.
Notes
• During channel search, pressing 1 or 2 to select another Category.
• The Search mode is canceled if you press and hold r for at least
2 seconds, or no operation is performed for 60 seconds in Search mode.
•Press r in the search mode to return to the previous mode.
Featured Favorites are a collection of channels that are created by the
SiriusXM programming team that are updated several times throughout
the year.
1
Turn the Rotary encoder to select FEATURED after step 1,
and then press /ENTER.
The Category that SXM recommends will be displayed in a list.
2
Turn the Rotary encoder to select the desired Category,
and then press /ENTER.
3
Turn the Rotary encoder to select the desired channel,
and then press /ENTER to confirm.
Notes
•Press k, the information of the selected channels will be displayed.
You can choose the desired channel from the artist name list or song
name list.
Each time you press k, the display changes as below.
Channel No Channel Name Artist Name Song Title
• When the selected Featured Favorites station is not broadcasting, the
channel will tune to channel 000 automatically.
• When an unsubscribed Channel is selected, the channel number is
marked with “*”.
Using Jump Memory and Jump Recall
function
1
While in SiriusXM mode, select your favorite SiriusXM
Channel.
2
Press and hold for at least 2 seconds.
The channel you selected is stored as the Jump Source.
3
Press and hold BAND for at least 2 seconds to recall, and
then tune to the saved Jump Source channel.
Note
• Pressing and holding BAND again for at least 2 seconds will jump back
to the previous mode or SiriusXM channel.
Replay Function
In SiriusXM mode, you can pause, rewind and replay up to 60 minutes
of live SiriusXM Satellite Radio.
1
While listening to a SiriusXM channel, press to enter
the Replay mode, which mutes the audio.
The display will show “PAUSED” while in this mode.
2
Press again to resume playback of the stored audio
from the point at which it was paused.
During playback, the SiriusXM Tuner will continue to store the
channel audio until you exit the Replay mode (up to 30 minutes).
During REPLAY playback:
•Fast rewind:
Press and hold .
• Fast forward:
Press and hold .
• Returning to the beginning of the current song:
Press . (If you press in the first 2 seconds of a song,
you return to the beginning of the previous song.)
• Advancing to the beginning of the next song:
Press .
Notes
• If you continue to press Fast forward until the end, the Replay mode is
canceled, and the unit will change to live SiriusXM radio mode.
• If you change channels while in Replay mode, the unit will exit Replay
mode to live Satellite Radio mode and clear the Replay memory.
3
Press r to cancel the REPLAY mode.
The unit returns to live SiriusXM radio mode.
Parental Lock Function
This function can help restrict the listening of channels to children of
appropriate age levels only. For information on setting the Parental
Control passcode, refer to “Setting the Parental Control” on page 33.
When a locked channel is selected, a “CH LOCKED” pop-up screen is
followed by a “LOCK CODE?”.
Input the 4-digit passcode you set in, and then press
ENTER, refer to “Setting the Parental Control” on
page 33.
Turn the Rotary encoder to select the number from 0-9, and
then use or to adjust the digit.
The initial number is 0000.
Notes
• If you input a wrong passcode, “WRONG CODE” is displayed.
• After entering the correct passcode, you can access all locked channels
without entering the passcode again until the unit is powered off and
then back on.
Searching by My Games
Searching by Featured Favorites
37-EN
Storing iTunes Tagging information
iTunes Tagging lets you tag songs heard on SiriusXM channels. Use this
unit in conjunction with an optional SiriusXM Tuner and a Tagging
compatible iPod/iPhone to tag the music that you listen to. This tag
information is automatically transferred to your iPod/iPhone. Later,
when your iPod/iPhone is connected to iTunes, you can preview, buy
and download your tagged songs. For details, refer to the Owner’s
Manual of the Tagging compatible iPod/iPhone.
The m indicator will light when a song playing on a SiriusXM
channel has tag information available.
Press and hold k for at least 2 seconds to save its tag
information.
If no iPod/iPhone is connected, “TAG COUNT X” is displayed (X is
the total amount of the tag information stored in this unit).
Notes
• During tagging, the iPod/iPhone takes priority to save the tag
information. If no iPod/iPhone is connected, the tag information is
saved to this unit.
• When the memory of iPod/iPhone is full, “iPod FULL” and “TAG
COUNT X” are displayed. The tag information will be stored to the
unit.
• If the operation is failed, “CANNOT TAG” is displayed.
• This unit can store up to 50 tagged songs. When the memory of the unit
is full, “TAGCOUNT50” and “MEMO FULL” are displayed.
• When an iPod that doesn’t support the tagging function is connected,
“NON-TAGGING IPOD” is displayed.
• When the iPod/iPhone is disconnected from the unit during tagging, its
tag information will be stored in the unit.
• If there is stored tag information on the unit, when an iPod/iPhone
supporting the tag function is connected, the stored tag information will
be transferred to the iPod/iPhone automatically. When the iPod/iPhone
memory becomes full, “iPod FULL” will be displayed, and any
remaining tag information on the unit will not be transferred to the
iPod/iPhone.
• If tag information already exists, “ALREADY TAGGED” will be
displayed when you try to tag information again.
Changing the Display
Text information, such as the channel name, artist name/feature and
song/program title, is available with each SiriusXM channel. The unit
can display this text information as explained below.
In SiriusXM mode, press k.
Each time you press this button, the display changes as shown
below.
Band/Channel Number Channel Name* Artist Name*
Song Title* Content info.* Category Name* Clock
Band/Channel Number
*If there is no text information, nothing will be displayed.
In Case of Difficulty
If you encounter a problem, please turn the power off, then on again. If
the unit is still not functioning normally, please review the items in the
following checklist. This guide will help you isolate the problem if the
unit is at fault. Otherwise, make sure the rest of your system is properly
connected or consult your authorized Alpine dealer.
No function or display.
• Vehicle’s ignition is off.
– If connected following instructions, the unit will not operate with
the vehicle’s ignition off.
• Improper power lead (Red) and battery lead (Yellow) connections.
– Check power lead and battery lead connections.
•Blown fuse.
– Check the fuse of the unit; replace with the proper value if
necessary.
• Internal micro-computer malfunctioned due to interference noise
etc.
–Press the RESET button with a ballpoint pen or other pointed
article.
Unable to receive stations.
• No antenna or open connection in cable.
– Make sure the antenna is properly connected;
replace the antenna or cable if necessary.
Unable to tune stations in the seek mode.
• You are in a weak signal area.
– Make sure the tuner is in the DX mode.
• If the area you are in is a primary signal area, the antenna may not be
grounded and connected properly.
– Check your antenna connections; make sure the antenna is
properly grounded at its mounting location.
• The antenna may not be the proper length.
– Make sure the antenna is fully extended; if broken, replace the
antenna with a new one.
Broadcast is noisy.
• The antenna is not the proper length.
– Extend the antenna fully; replace it if it is broken.
• The antenna is poorly grounded.
– Make sure the antenna is grounded properly at its mounting
location.
CD Player not functioning.
• Out of operating temperature range +50°C (+120°F) for CD.
– Allow the vehicle’s interior (or trunk) temperature to cool.
CD playback sound is wavering.
• Moisture condensation in the CD Module.
– Allow enough time for the condensation to evaporate (about
1 hour).
CD insertion not possible.
• A CD is already in the CD player.
– Eject the CD and remove it.
Information
Basic
Radio
CD (CDE-SXM145BT/CDE-143BT only)
38-EN
• The CD is being improperly inserted.
– Make sure the CD is being inserted following instructions in the
CD Player Operation section.
Unable to fast forward or backward the CD.
• The CD has been damaged.
– Eject the CD and discard it; using a damaged CD in your unit can
cause damage to the mechanism.
CD playback sound skips due to vibration.
• Improper mounting of the unit.
– Securely re-mount the unit.
• The disc is very dirty.
–Clean the disc.
• The disc has scratches.
– Change the disc.
• The pick-up lens is dirty.
– Do not use a commercially available lens cleaner disc. Consult
your nearest Alpine dealer.
CD playback sound skips without vibration.
• The disc is dirty or scratched.
– Clean the disc; damaged disc should be replaced.
Error displays (built-in CD player only).
• Mechanical error
– Press . After the error indication disappears, insert the disc
again. If the above-mentioned solution does not solve the problem,
consult your nearest Alpine dealer.
CD-R/CD-RW playback not possible.
• Close session (finalisation) has not been performed.
– Perform finalisation and attempt playback again.
MP3/WMA is not played back.
• Writing error occurred. The MP3/WMA format is not compatible.
– Make sure the MP3/WMA has been written in a supported format.
Refer to “About MP3/WMA” on page 13, then rewrite in the
format supported by this device.
The sound is not output from the speakers.
• Unit has no output signal of the internal amplifier.
– POWER IC is switched to “ON”, refer to “Connecting to an
External Amplifier (POWER IC)” on page 17.
iPod does not play and no sound is output.
• The iPod has not been recognised.
– Reset this unit and the iPod. Refer to “Initial System Start-Up” on
page 10. To reset the iPod, refer to the Owner’s Manual of the iPod.
•No CD is inserted.
–Insert a CD.
• Although a disc is inserted, “NO DISC” is displayed and the unit does
not start to play or eject the disc.
– Remove the disc by following these steps:
Press the button again for at least 2 seconds.
If the disc still does not eject, consult your Alpine dealer.
• Mechanism error.
1 Press the button and eject the CD.
If not ejecting, consult your Alpine dealer.
2 When the error indication remains after ejecting, press the
button again.
If the error indication still does not turn off after pressing the
button for a few times, consult your Alpine dealer.
• When “ERROR” is displayed:
If the disc cannot be ejected by pressing , press the RESET button
(Refer to “Initial System Start-Up” on page 10) and press again.
If the disc still cannot be ejected, consult your Alpine dealer.
• A copy-protected WMA file was played back.
– You can only play back non-copy-protected files.
• A sampling rate/bit rate not supported by the unit is used.
– Use a sampling rate/bit rate that is supported by the unit.
• A USB device that is not supported by the unit is connected.
– Connect a USB device that is supported by the unit.
• A Flash Memory Device is not connected.
– Make sure the Flash Memory device is correctly connected and the
cable is not excessively bent.
• No MP3/WMA (file) is stored in the Flash Memory.
– Connect the Flash Memory device after storing songs (files).
• A copy-protected WMA file was played back.
– You can only play back non-copy-protected files.
• A sampling rate/bit rate not supported by the unit is used.
– Use a sampling rate/bit rate that is supported by the unit.
• Text information that is not recognizable by the unit has been input.
– Use a Flash Memory device with input text information that is
supported by the unit.
MP3/WMA
Audio
iPod
Indication for CD Player (CDE-SXM145BT/
CDE-143BT only)
Indication for Flash Memory
NO DEVICE
NO SUPPORT
39-EN
• Communication error or others
– Change to other source.
–Turn the power off.
– Turn the ignition key off, and then set to ON again.
• Communication error
– Turn the ignition key off, and then set to ON again.
– Check the display by reconnecting between the Flash Memory and
this unit.
• Power surge error
Excessive voltage/current is supplied to the Flash Memory.
– Try another Flash Memory, if available.
• The iPod/iPhone is not connected.
– Make sure the iPod/iPhone is correctly connected (Refer to
“Connecting an iPod/iPhone” on page 29).
Make sure the cable is not bent excessively.
• There are no songs in the iPod/iPhone.
– Download songs to the iPod/iPhone and connect to this unit.
• Communication error
– Turn the ignition key off, and then set to ON again.
– Check the display by reconnecting between the iPod/iPhone and
this unit, using the iPod/iPhone cable.
• Caused by the iPod/iPhone Software Version not being compatible
with this unit.
– Update the iPod/iPhone Software Version to be compatible with
this unit.
• The iPod/iPhone is not verified.
– Reset the iPod.
– Try another iPod/iPhone, if available.
• Power surge error
Excessive voltage/current is supplied to the iPod/iPhone.
– Try another iPod/iPhone, if available.
– Turn the power off.
– Turn the ignition key off, and then set to ON again.
• The BLUETOOTH device is not connected.
– Connect the BLUETOOTH device.
The following messages may be displayed while operating the unit in
SiriusXM mode.
• The SiriusXM Tuner is disconnected or the unit is having trouble
communicating with the Tuner.
– Connect the Tuner or check the Tuner connection to the back of
the unit.
• The SiriusXM Satellite Radio antenna or cable is either damaged or
not connected correctly to the SiriusXM Tuner.
– Check that the SiriusXM antenna cable is connected to the
SiriusXM Tuner and check that the antenna cable is not kinked or
otherwise damaged. Replace the antenna if necessary.
• The SiriusXM satellite signal is too weak at the current location.
– Move the vehicle to a location with a clear view of the southern
sky.
– Make sure the Satellite Radio antenna is properly mounted and not
obstructed by metal objects.
• The active channel has become unsubscribed or the requested
channel is not available in your subscription package.
Note
• The unit will revert to the previous selected channel or to channel 1
automatically.
– Visit www.siriusxm.com for information on subscribing to this
channel.
Indication for iPod Mode
BLUETOOTH mode
SiriusXM Advisory Messages
(CDE-SXM145BT only)
40-EN
• The active channel is no longer in the SiriusXM channel lineup or the
user has entered an invalid channel number.
Note
• The unit will revert to the previous channel or to channel 1
automatically.
– Visit www.siriusxm.com for information on the current channel
lineup.
• Your subscription has been updated.
– Press any button to clear this message.
• A locked channel is selected.
– Input the passcode. On how to input passcode, refer to “Setting the
Parental Control” on page 33.
Note
• If wrong passcode is input, “WRONG CODE” will be displayed and the
unit will revert to the previous selected channel.
• Buffer for Replay will full within 11 seconds.
• Buffer for Replay is full.

41-EN
Specifications
FM TUNER SECTION
AM TUNER SECTION
CD PLAYER SECTION
PICKUP
USB SECTION
BLUETOOTH SECTION
GENERAL
*Primary amplifier ratings per CEA-2006 Standard
• Power output: measured at 4 Ohms and ≤ 1% THD+N
• S/N: 80 dBA (reference: 1 W into 4 Ohms)
CHASSIS SIZE
NOSEPIECE SIZE
Note
• Due to continuous product improvement, specifications and design are
subject to change without notice.
Tuning Range 87.7~107.9 MHz
Mono Usable Sensitivity 9.3 dBf (0.8 µV/75 ohms)
50 dB Quieting Sensitivity 13.5 dBf (1.3 µV/75 ohms)
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
Tuning Range 530~1,710 kHz
Sensitivity (IEC Standard) 22.5 V/27 dB
Frequency Response 5~20,000 Hz (±1 dB)
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
Wave length 795 nm
Laser power CLASS I
USB requirements USB 1.1/2.0
Max. Power Consumption 1,000 mA
USB Class Mass Storage
File System FAT 12/16/32
MP3 Decoding MPEG AUDIO Layer-3
WMA Decoding Windows Media™ Audio
BLUETOOTH Specification BLUETOOTH V 3.0
Output Power +4 dBm Max. (Power class 2)
Profile HFP (Hands-Free Profile)
HSP (Head Set Profile)
A2DP (Advanced Audio
Distribution Profile)
AVRCP (Audio/Video Remote
Control Profile)
Power Requirement 14.4 V DC
(11~16 V allowable)
Power Output 18 W RMS × 4*
Maximum Pre-Output Voltage 2 V/10 k ohms
Bass ±14 dB at 100 Hz
Mid ±14 dB at 1 kHz
Treble ±14 dB at 10 kHz
Loudness 10 dB at 100 Hz
Weight 1.194 kg (2 lbs. 10 oz)
(CDE-SXM145BT/
CDE-143BT)
0.854 kg (1 lbs. 14 oz)
(UTE-42BT)
Width 178 mm (7")
Height 50 mm (2")
Depth 161.5 mm (6–3/8")
Width 169 mm (6–3/4")
Height 45 mm (1–3/4")
Depth 25 mm (1")
42-EN
Installation and Connections
Before installing or connecting the unit, please read the following
and refer to “Operating Instructions” on page 6 for proper use.
WARNING
MAKE THE CORRECT CONNECTIONS.
Failure to make the proper connections may result in fire or
product damage.
USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.
(Check with your dealer if you are not sure.) Failure to do so may
result in fire, etc.
BEFORE WIRING, DISCONNECT THE CABLE FROM THE NEGATIVE BATTERY
TERMINAL.
Failure to do so may result in electric shock or injury due to
electrical shorts.
DO NOT SPLICE INTO ELECTRICAL CABLES.
Never cut away cable insulation to supply power to other
equipment. Doing so will exceed the current carrying capacity of
the wire and result in fire or electric shock.
DO NOT DAMAGE PIPE OR WIRING WHEN DRILLING HOLES.
When drilling holes in the chassis for installation, take precautions
so as not to contact, damage or obstruct pipes, fuel lines, tanks or
electrical wiring. Failure to take such precautions may result in fire.
DO NOT USE BOLTS OR NUTS IN THE BRAKE OR STEERING SYSTEMS TO
MAKE GROUND CONNECTIONS.
Bolts or nuts used for the brake or steering systems (or any other
safety-related system), or tanks should NEVER be used for
installations or ground connections. Using such parts could disable
control of the vehicle and cause fire etc.
KEEP SMALL OBJECTS SUCH AS BATTERIES OUT OF THE REACH OF
CHILDREN.
Swallowing them may result in serious injury. If swallowed, consult
a physician immediately.
DO NOT INSTALL IN LOCATIONS WHICH MIGHT HINDER VEHICLE
OPERATION, SUCH AS THE STEERING WHEEL OR GEARSHIFT.
Doing so may obstruct forward vision or hamper movement etc.
and results in serious accident.
DO NOT ALLOW CABLES TO BECOME ENTANGLED IN SURROUNDING
OBJECTS.
Arrange wiring and cables in compliance with the manual to
prevent obstructions when driving. Cables or wiring that obstruct
or hang up on places such as the steering wheel, gear lever, brake
pedals, etc. can be extremely hazardous.
CAUTION
HAVE THE WIRING AND INSTALLATION DONE BY EXPERTS.
The wiring and installation of this unit requires special technical
skill and experience. To ensure safety, always contact the dealer
where you purchased this product to have the work done.
USE SPECIFIED ACCESSORY PARTS AND INSTALL THEM SECURELY.
Be sure to use only the specified accessory parts. Use of other than
designated parts may damage this unit internally or may not
securely install the unit in place. This may cause parts to become
loose resulting in hazards or product failure.
ARRANGE THE WIRING SO IT IS NOT CRIMPED OR PINCHED BY A SHARP
METAL EDGE.
Route the cables and wiring away from moving parts (like the seat
rails) or sharp or pointed edges. This will prevent crimping and
damage to the wiring. If wiring passes through a hole in metal, use a
rubber grommet to prevent the wire’s insulation from being cut by
the metal edge of the hole.
DO NOT INSTALL IN LOCATIONS WITH HIGH MOISTURE OR DUST.
Avoid installing the unit in locations with high incidence of
moisture or dust. Moisture or dust that penetrates into this unit may
result in product failure.
PRECAUTIONS
• Be sure to disconnect the cable from the (−) battery post before
installing your CDE-SXM145BT/CDE-143BT/UTE-42BT. This will
reduce any chance of damage to the unit in case of a short-circuit.
• Be sure to connect the color coded leads according to the diagram.
Incorrect connections may cause the unit to malfunction or damage
to the vehicle’s electrical system.
• When making connections to the vehicle’s electrical system, be aware
of the factory installed components (e.g. on-board computer). Do not
tap into these leads to provide power for this unit. When connecting
the CDE-SXM145BT/CDE-143BT/UTE-42BT to the fuse box, make
sure the fuse for the intended circuit of the CDE-SXM145BT/
CDE-143BT/UTE-42BT has the appropriate amperage. Failure to do
so may result in damage to the unit and/or the vehicle. When in
doubt, consult your Alpine dealer.
• The CDE-SXM145BT/CDE-143BT/UTE-42BT uses female
RCA-type jacks for connection to other units (e.g. amplifier) having
RCA connectors. You may need an adaptor to connect other units. If
so, please contact your authorized Alpine dealer for assistance.
• Be sure to connect the speaker (−) leads to the speaker (−) terminal.
Never connect left and right channel speaker cables to each other or
to the vehicle body.
IMPORTANT
Please record the serial number of your unit in the space provided
below and keep it as a permanent record. The serial number or the
engraved serial number is located on the bottom of the unit.
SERIAL NUMBER: [ ]
INSTALLATION DATE: [ ]
INSTALLATION TECHNICIAN: [ ]
PLACE OF PURCHASE: [ ]
43-EN
Installation
CAUTION
When you install this unit in your car, do not remove the
detachable front panel.
If the detachable front panel is removed during installation, you
might press too hard and warp the metal plate that holds it in
place.
The main unit must be mounted within 35 degrees of the
horizontal plane, back to front.
1
Remove the mounting sleeve from the main unit (Refer to
“Removal” on page 43).
*If the installed mounting sleeve is loose in the dashboard, the
pressure plates may be bent slightly to remedy the problem.
2
Reinforce the head unit with the metal mounting strap
(not supplied). Secure the ground lead of the unit to a
clean metal spot.
Connect each input lead coming from an amplifier to the
corresponding output lead coming from the left rear of the
CDE-SXM145BT/CDE-143BT/UTE-42BT. Connect all other leads
of the CDE-SXM145BT/CDE-143BT/UTE-42BT according to
details described in the CONNECTIONS section.
Note
• For the screw marked “*”, use an appropriate screw for the chosen
mounting location.
3
Slide the CDE-SXM145BT/CDE-143BT/UTE-42BT into the
dashboard until it clicks. This ensures that the unit is
properly locked and will not accidentally come out from
the dashboard. Install the detachable front panel.
1
Remove the detachable front panel.
2
Insert the bracket keys into the unit, along the guides on
either side. The unit can now be removed from the
mounting sleeve.
3
Pull the unit out, keeping it unlocked as you do so.
JAPANESE CAR
Mounting the Microphone
For the sake of safety, mount the microphone in the following location.
• In a stable and secure location.
• In a location that does not inhibit safely driving the vehicle.
• Mount the microphone in a location where the driver’s voice can
easily be picked up.
Choose a location for the microphone that can easily pick up the drivers
voice. Requiring the driver to move towards the microphone for
audibility causes a distraction that could be dangerous.
Detachable Front
Panel
Less than 35°
Dashboard
Mounting Sleeve (Included)
Pressure Plates*
This unit
*
Bolt Stud
Hex Nut (M5)
Metal
Mounting
Strap
Screw
This unit
Removal
Bracket keys
(Included)
This unit
Front Frame
Screws (M5 × 8)
(Included)
This unit
Mounting Bracket
44-EN
Connections
*When Subwoofer is OFF: Output is for Rear speakers. When Subwoofer is ON: Output is for Subwoofer.
For details on how to set the Subwoofer to ON/OFF, refer to “Turning Subwoofer ON/OFF” on page 17.
POWER ANT
REMOTE TURN-ON
ILLUMINATION
IGNITION
BATTERY
GND
SPEAKER
RIGHT FRONT
SPEAKER
RIGHT REAR
SPEAKER
LEFT REAR
SPEAKER
LEFT FRONT
Microphone
To amplier
To power antenna
To the instrument cluster illumination lead
Ignition Key
(Blue/White)
(Red)
(Black)
(Blue)
Amplier
Amplier
Battery
Speakers
Rear Left
Front Left
Front Right
Rear Right
Speakers
Front
Rear or Subwoofers*
The illustration is for CDE-SXM145BT/CDE-143BT.
(Green)
(Green/Black)
(White)
(White/Black)
(Gray/Black)
(Gray)
(Violet/Black)
(Violet)
(Orange)
(Yellow)
45-EN
Microphone (Supplied)
Power Antenna Lead (Blue)
Connect this lead to the +B terminal of your power antenna, if
applicable.
Note
• This lead should be used only for controlling the vehicle’s power
antenna. Do not use this lead to turn on an amplifier or a signal
processor, etc.
Remote Turn-On Lead (Blue/White)
Connect this lead to the remote turn-on lead of your amplifier or
signal processor.
Illumination Lead (Orange)
This lead may be connected to the vehicle’s instrument cluster
illumination lead. This will allow the backlighting of this unit to dim
whenever the vehicle’s lights are turned on.
Switched Power Lead (Ignition) (Red)
Connect this lead to an open terminal on the vehicle’s fuse box or
another unused power source which provides (+) 12V only when the
ignition is turned on or in the accessory position.
Battery Lead (Yellow)
Connect this lead to the positive (+) post of the vehicle’s battery.
Ground Lead (Black)
Connect this lead to a good chassis ground on the vehicle. Make sure
the connection is made to bare metal and is securely fastened using
the sheet metal screw provided.
Right Front (+) Speaker Output Lead (Gray)
Right Front (−) Speaker Output Lead (Gray/Black)
Right Rear (−) Speaker Output Lead (Violet/Black)
Right Rear (+) Speaker Output Lead (Violet)
-Left Rear (+) Speaker Output Lead (Green)
Left Rear (−) Speaker Output Lead (Green/Black)
Left Front (−) Speaker Output Lead (White/Black)
Left Front (+) Speaker Output Lead (White)
Antenna Receptacle
Front Output RCA Connectors
RED is down and WHITE is up.
Rear/Subwoofer Output RCA Connectors
Steering Remote Control Interface Connector
To steering remote control interface box.
You can operate this unit from the vehicle’s control unit when an
Alpine Steering Remote Control Interface Box (optional) is
connected. For details, contact your Alpine dealer.
MIC Input Connector
To Microphone.
Fuse Holder (10A)
Power Supply Connector
RCA Extension Cable (sold separately)
Front AUX Input Terminal
This terminal allows for input of audio from an external device (such
as a portable player), using a commercially-available converter cable.
USB Terminal
Connect this to a Flash Memory or an iPod/iPhone (sold separately).
SiriusXM Tuner connector (CDE-SXM145BT only)
Connect to a SiriusXM Tuner.
To prevent external noise from entering the audio system.
•Locate the unit and route the leads at least 10 cm away from the
car harness.
•Keep the battery power leads as far away from other leads as
possible.
•Connect the ground lead securely to a bare metal spot (remove
any paint, dirt or grease if necessary) of the car chassis.
•If you add an optional noise suppressor, connect it as far away
from the unit as possible. Your Alpine dealer carries various
noise suppressors, contact them for further information.
•Your Alpine dealer knows best about noise prevention
measures so consult your dealer for further information.
LIMITED WARRANTY
ALPINE ELECTRONICS OF AMERICA, INC. AND ALPINE OF CANADA INC. (“Alpine”), are dedicated to quality craftsmanship and are pleased to offer
this Warranty. We suggest that you read it thoroughly. Should you have any questions, please contact your Dealer or contact Alpine at one of the
telephone numbers listed below.
PRODUCTS COVERED:
This Warranty covers Car Audio Products and Related Accessories (“the
product”). Products purchased in the Canada are covered only in the
Canada. Products purchased in the U.S.A. are covered only in the U.S.A.
LENGTH OF WARRANTY:
This Warranty is in effect for one year from the date of the first
consumer purchase.
WHO IS COVERED:
This Warranty only covers the original purchaser of the product, who
must reside in the United States, Puerto Rico or Canada.
WHAT IS COVERED:
This Warranty covers defects in materials or workmanship (parts and
labor) in the product.
WHAT IS NOT COVERED:
This Warranty does not cover the following:
Damage occurring during shipment of the product to Alpine for
repair (claims must be presented to the carrier).
Damage caused by accident or abuse, including burned voice coils
caused by over-driving the speaker (amplifier level is turned up
and driven into distortion or clipping). Speaker mechanical failure
(e.g. punctures, tears or rips). Cracked or damaged LCD panels.
Dropped or damaged hard drives.
Damage caused by negligence, misuse, improper operation or
failure to follow instructions contained in the Owner’s manual.
Damage caused by act of God, including without limitation,
earthquake, fire, flood, storms or other acts of nature.
Any cost or expense related to the removal or reinstallation of the
product.
Service performed by an unauthorized person, company or
association.
Any product which has the serial number defaced, altered or
removed.
Any product which has been adjusted, altered or modified without
Alpine’s consent.
Any product not distributed by Alpine within the United States,
Puerto Rico or Canada.
Any product not purchased from an Authorized Alpine Dealer.
HOW TO OBTAIN WARRANTY SERVICE:
You are responsible for delivery of the product to an Authorized
Alpine Service Center or Alpine for repair and for payment of any
initial shipping charges. Alpine will, at its option, repair or replace
the product with a new or reconditioned product without charge.
If the repairs are covered by the warranty, and if the product was
shipped to an Authorized Alpine Service Center or Alpine, Alpine
will pay the return shipping charges.
You should provide a detailed description of the problem(s) for
which service is required.
You must supply proof of your purchase of the product.
You must package the product securely to avoid damage during
shipment. To prevent lost packages it is recommended to use a
carrier that provides a tracking service.
HOW WE LIMIT IMPLIED WARRANTIES:
ANY IMPLIED WARRANTIES INCLUDING FITNESS FOR USE AND
MERCHANTABILITY ARE LIMITED IN DURATION TO THE PERIOD OF THE
EXPRESS WARRANTY SET FORTH ABOVE AND NO PERSON IS
AUTHORIZED TO ASSUME FOR ALPINE ANY OTHER LIABILITY IN
CONNECTION WITH THE SALE OF THE PRODUCT.
HOW WE EXCLUDE CERTAIN DAMAGES:
ALPINE EXPRESSLY DISCLAIMS LIABILITY FOR INCIDENTAL AND
CONSEQUENTIAL DAMAGES CAUSED BY THE PRODUCT. THE TERM
“INCIDENTAL DAMAGES” REFERS TO EXPENSES OF TRANSPORTING
THE PRODUCT TO THE ALPINE SERVICE CENTER, LOSS OF THE
ORIGINAL PURCHASER’S TIME, LOSS OF THE USE OF THE PRODUCT,
BUS FARES, CAR RENTALS OR OTHERS COSTS RELATING TO THE CARE
AND CUSTODY OF THE PRODUCT. THE TERM “CONSEQUENTIAL
DAMAGES” REFERS TO THE COST OF REPAIRING OR REPLACING OTHER
PROPERTY WHICH IS DAMAGED WHEN THIS PRODUCT DOES NOT
WORK PROPERLY. THE REMEDIES PROVIDED UNDER THIS WARRANTY
ARE EXCLUSIVE AND IN LIEU OF ALL OTHERS.
HOW STATE/PROVINCIAL LAW RELATES TO THE
WARRANTY:
This Warranty gives you specific legal rights, and you may also have
other rights which vary from state to state and province to province. In
addition, some states/provinces do not allow limitations on how long
an implied warranty lasts, and some do not allow the exclusion or
limitation of incidental or consequential damages. Accordingly,
limitations as to these matters contained herein may not apply to you.
IN CANADA ONLY:
This Warranty is not valid unless your Alpine car audio product has
been installed in your vehicle by an Authorized Installation Center, and
this warranty stamped upon installation by the installation center.
HOW TO CONTACT CUSTOMER SERVICE:
Should the product require service, please call the following number
for your nearest Authorized Alpine Service Center.
Or visit our website at; http://www.alpine-usa.com
CAR AUDIO 1-800-ALPINE-1 (1-800-257-4631)
NAVIGATION 1-888-NAV-HELP (1-888-628-4357)
ALPINE ELECTRONICS OF AMERICA, INC., 19145 Gramercy Place, Torrance, California 90501, U.S.A.
ALPINE ELECTRONICS OF CANADA, INC., 777 Supertest Road, Toronto, Ontario M3J 2M9, Canada
Do not send products to these addresses.
Call the toll free telephone number or visit the website to locate a service center.
About the Rules of Bluetooth Electromagnetic Radiation Regulation
USA/Canada FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of FCC Rules and Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired operation of this device.
Le présent appareil est conforme aux la partie 15 des règles de la FCC et CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit
pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d'en compromettre le fonctionnement.
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and
meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio
frequency (RF) Exposure rules. This equipment has very low levels of RF energy that it deemed to comply without
maximum permissive exposure evaluation (MPE). But it is desirable that it should be installed and operated keeping
the radiator at least 20cm or more away from person’s body (excluding extremities: hands, wrists, feet and ankles).
Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non
contrôlé et respecte les règles les radioélectriques (RF) de la FCC lignes directrices d'exposition dans le Supplément
C à OET65 et d’exposition aux fréquences radioélectriques (RF) CNR-102 de l’IC. Cet équipement émet une énergie
RF très faible qui est considérée conforme sans évaluation de l’exposition maximale autorisée. Cependant, cet
équipement doit être installé et utilisé en gardant une distance de 20 cm ou plus entre le dispositif rayonnant et le
corps (à l’exception des extrémités : mains, poignets, pieds et chevilles).
México La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo
no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la
que pueda causar su operación no deseada.
Don’t forget to take a moment to protect your purchase by registering your product now at the following
address: www.alpine-usa.com/registration.
N’oubliez pas de consacrer un moment à la protection de votre achat en enregistrant votre produit dès
maintenant à l’adresse suivante : www.alpine-usa.com/registration.
Recuerde que con solo unos pocos pasos podrá proteger su producto, registrándolo a través de la siguiente
dirección: www.alpine-usa.com/registration.

Navigation menu
