Dear, Sir
We always appreciate your kind cooperations on our FCC applications.
According to your requests, I revised the files.
FCC ID: S3FAP-200
1) Please submit the probe calibration report for the probe used during the 6/9/05 SAR tests.
====> Please find the attached file. (filename : ATT. R (PROBE CAL. DATA))
2) With respect to my previous question #5 (cdma2000), please address each point in the document sent with the previous email (and attached
here for your convenience) entitled “CDMA-2000 SAR Testing Guidance List.doc”. Regarding point #3 in this list, you may perform power meter
measurements and provide the information in a table similar to the one attached (“CDMA-2000 RC Output Power Table.doc”. Please note that the
values shown in the attached table are for reference only. The table does not have to be exactly like the attached, but should provide all of the
requested information).
====> The choice of Radio Configuration and Service Option tested for SAR compliance was based upon
power measurements
of all available combinations. The worst case combination was chosen.
Please find the attached file. (filename : CDMA-2000 RC Outpower Table.doc)
If you have questions or comments on this application, please do not hesitate to conatct us.
Thanks and Best Regards,
Keun- Ho Park - HCT
----- Original Message -----
From: Gregory Czumak
To: '??? (HCT)'
Cc: 'KiSoo Kim (HCT)' ; 'PCTEST - Al Cirwithian' ; 'PCTEST - Randy Ortanez' ; 'Courtenay Geraghty'
Sent: Tuesday, June 14, 2005 1:14 AM
Subject: RE: FCC Part 24 Application. (FCC ID: S3FAP-200): AIJI SYSTEM CO., LTD. -3/3-
Dear Mr. Park,
This is in response to your email dated 6/13/05, responding to our previous request for additional information.
1. Please submit the probe calibration report for the probe used during the 6/9/05 SAR tests.
2. With respect to my previous question #5 (cdma2000), please address each point in the document sent with the
previous email (and attached here for your convenience) entitled “CDMA-2000 SAR Testing Guidance List.doc”.
Regarding point #3 in this list, you may perform power meter measurements and provide the information in a table
similar to the one attached (“CDMA-2000 RC Output Power Table.doc”. Please note that the values shown in the
attached table are for reference only. The table does not have to be exactly like the attached, but should provide all
of the requested information).
Sincerely,
Gregory Czumak
Quality Manager
Senior Certification Engineer
PCTEST Engineering Laboratory, Inc.
6660-B Dobbin Road
Columbia, MD 21045
410-290-6652
410-290-6654 (Fax)
gregory@pctestlab.com
This communication and its attachments contain information from PCTEST Engineering Laboratory, Inc., and is intended
for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally
privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited.
Please notify the sender immediately if you receive this communication in error, and delete it from your computer
system. Usage of PCTEST email addresses for non-business related activities is strictly prohibited. No warranty is made
that the e-mail or attachment(s) are free from computer virus or other defect. Thank you.
From: Courtenay Geraghty [mailto:courtenay@pctestlab.com]
Sent: Monday, June 13, 2005 9:55 AM
To: 'Gregory Czumak'
Subject: FW: FCC Part 24 Application. (FCC ID: S3FAP-200): AIJI SYSTEM CO., LTD. -3/3-
From: ??? (HCT) [mailto:khpark@hct.co.kr]
Sent: Monday, June 13, 2005 9:06 AM
To: Courtenay Geraghty
Cc: ??? ?? (HCT); ??? (HCT); ??? (HCT); ??? (HCT); ??? ?? (HCT); ??? (HCT); kisookim@hctec.co.kr; 'PCTEST Accounting'; randy@pctestlab.com;
PCTEST - Al Cirwithian
Subject: Re: FCC Part 24 Application. (FCC ID: S3FAP-200): AIJI SYSTEM CO., LTD. -3/3-
Dear Sir,
Page
2
of
6
6/16/2005
According to your requests on the below questions, we'd like to send the answers on each questions
under each question as belows;
If you have questions or comments on this application, please do not hesitate to conatct us.
Thanks and Best Regards,
Keun- Ho Park - HCT
----- Original Message -----
From: Courtenay Geraghty
To: khpark@hct.co.kr ; kisookim@hctec.co.kr
Cc: PCTEST - Al Cirwithian ; randy@pctestlab.com ; 'PCTEST Accounting'
Sent: Wednesday, May 25, 2005 7:23 AM
Subject: RT: FCC Part 24 Application. (FCC ID: S3FAP-200): AIJI SYSTEM CO., LTD.
To: Mr. Kim/ HCT
From: Gregory Czumak/ PCTEST TCB
Re: FCC ID: S3FAP -200
Applicant: AIJI SYSTEM CO., LTD.
Application Received: 05/11/2005
Correspondence Reference Number: 150524A.HCT
Confirmation Number: 1505110250
Date of Original Email: 05/24/2005
Subject: Request for additional information
In regards to your recent TCB application referenced above, we kindly request that you provide the following additional
information.
1. At the recent FCC/TCBC Training Workshop (May 2005), the FCC instituted new requirements with respect to SAR testing
for phones that employ the cdma2000 chipset. Any device utilizing cdma2000 must address if and how the various
combinations of Radio Configurations, Service Options, data rates, channel combinations and modulations affect the
output power level, and, in turn, the measured SAR levels. Please see the attached documents.
The document entitled “CDMA-2000 SAR Testing Guidance.doc” is from the FCC, and, while still in draft form, outlines
the FCC’s concerns. The second attachment, entitled “CDMA-2000 SAR Testing Guidance List.doc” is PCTEST’s attempt
to make the FCC’s document more understandable. Please address the issues in the “List” document. The various
combinations listed above must be examined (e.g., through the use of power meter measurements) in order to determine
which produces the highest level of sustained output power, and determines the combination that must be used for SAR
Page
3
of
6
6/16/2005
testing.
If your investigations show that a particular combination, that was not used for your SAR measurements, produces the
highest sustained output power, then you must remeasure SAR using that combination, and submit new data. Please also
submit the results of your investigation of the various combinations, as well as a table describing all of these combinations
in which the EUT is capable of operating. Please contact PCTEST, or the FCC directly, with any questions.
====> We've retested and revised theSAR Test report, plot and System Verifications data added measurement.
Please find the attached test plot.
(filename: ATT. N (SAR REPORT)-new / ATT. O (SAR TEST DATA)-new / ATT. Q (DIPOLE VALIDATION PLOTS)-new)
The items indicated above must be submitted before processing can continue on the above referenced application. Failure to
provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of
the filing fees.
If you have any questions, please do not hesitate to contact us.
Sincerely,
Gregory Czumak
Quality Manager
Senior Certification Engineer
PCTEST Engineering Laboratory, Inc.
6660-B Dobbin Road
Columbia, MD 21045
410-290-6652
410-290-6654 (Fax)
gregory@pctestlab.com
This communication and its attachments contain information from PCTEST Engineering Laboratory, Inc., and is intended for the
exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any
unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notify the sender
immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email
addresses for non-business related activities is strictly prohibited. No warranty is made that the e -mail or attachment(s) are free
from computer virus or other defect. Thank you.
