products with watertight reputation
6500-915
WATERPROOF MEDIA PLAYER
for Bluetooth MP3 devices
OWNER'S MANUAL
PLEASE READ THIS INSTRUCTION MANUAL BEFORE
INSTLAATION AND OPERATION
! !
is a trademark of Jacuzzi Products Co
Bluetooth
1 Getting Started
1.1 Contents
1.2 Connections
1.3 12-pin Harness Connection
1.4 Mounting the BlueCube Media Player
1.5 Power On
1.6 Handheld Remote Control Charging
1.7 Handheld Remote Control Synchronizing
2 Location of Controls
2.1 Wireless Handheld Remote Control
2.2 Using Audio Menu on Handheld Remote Control
2.3 Wired Remote Control
3. Listening to Devices
3.1 Listening via Bluetooth
3.1.1 Pairing with Bluetooth Device
3.1.2 Listening via Bluetooth Device
3.2 Listening via Auxillary Input
3.3 Adjusting Volume Level
4. Other Features
4.1 Using VBass
4.2 External Trigger
4.3 Pump Control
5. Specifications and Dimensions
4.1 Specifications
4.2 Dimensions
6. Warranty Information
7. FCC Statements
3
3
3
4
4
5
5
5
6
6
6
6
7
7
7
7
7
7
7
7
7
7
8
8
8
9
10
Table of Contents Bluecube Media Player 6500-915
www.aquaticav.com 2
Getting Started Bluecube Media Player 6500-915
www.aquaticav.com 3
1.1 Contents
6500-915 BlueCube Media Player
Wiring Harness (AQ-UNH-2)
Owner's Manual
1.2 Connections
1: 12-pin Watertight Harness
The 12-pin harness supplies power and ground connection to the BlueCube Media Player and four (4)
speaker channel output connections from the BlueCube Media Player.
2: Spa Controller
This must be connected to the spa controller.
3: Subwoofer Output
Connect to a subwoofer amplifier.
4: 3.5mm Auxiliary Input
Connect to an audio source, such as MP3 player or other audio line out.
5: 8-pin DIN Cable for remotes
Connect to optional wireless or wired Remote Control (sold separately).
6: EXT Trigger
Provide 12Vdc when EXT trigger is pressed on remote control (sold separately).
7: Power On LED
When the BlueCube is powered On, the LED will lit.
8: Bluetooth Antenna Connection
Connect to the Male SMA connector of the Bluetooth antenna. Do not apply excess torque to the SMA
connector (no more than 0.5N-m). Use hands to tighten the connection. (No wrench is used)
12-pin Watertight Harness1
4
5
6
8
2
3
6
Connect SPA controller (Black)
Connect To Subwoofer (brown)
3.5mm Female Auxiliary Input
8-pin DIN cable for Remote (black)
External Trigger (brown)
Power On LED
Getting Started Bluecube Media Player 6500-915
www.aquaticav.com 4
1.3 12-pin Harness Connection
The AQ-BC-6BT includes the universal harness AQ-UHN-2 in order to connect the BlueCube to power and
speakers.
All open wire connections should be soldered and protected against water and dust for best long term
performance.
Power Antenna (7)
DC Ground (10)
LR-(2) No connection
LR+(3)
LF-(5)
LF+(6)
RF-(8)
RF+(9)
RR-(11)
RR+(12)
FUS E BOX
Left Rear Speaker
+
-
Left Front Speaker
+
-
+
-
+
-
Right Front Speaker
Right Rear Speaker
Please put a
fuse into the box
(Blue color)
(Green/strip)
(Green color)
(White/strip)
(White color)
(Gray/strip)
(Gray color)
(Purple color)
(Purple/strip)
(Black color)
No lower than 2 Ohm load should be used
or damage may occur to the BlueCube Media
Player.
Make sure the polarity of speakrs are
connected correctly.
(Yellow color)
+12VDC(1)
1.4 Mounting the BlueCube Media Player
1. Make sure the outside surface is clean and clear of
debris
2. The BlueCube Media Player has four (4) front
screws. Drive the screws using a screw driver.
Make sure screws are snug and do not over tighten.
Getting Started Bluecube Media Player 6500-915
www.aquaticav.com 5
1.5 Power On
The stereo (6500-915) requires +12V dc to both the red and yellow wires. When both of these wires have
power, the stereo is always powered on and is indicated by a red LED coming out of the heatsink of the
stereo. Ground is connected to the Black wire.
If the stereo is not connected to the same power supply, please make sure to switch ON the stereo (6500-
915) before the spa controller is turned on.
For detailed instructions, you can check out our online video:
"How to wire your Aquatic AV stereo system"
http://www.aquaticav.com/support/videos
1.6 Handheld Remote Control Charging (AQ-DM-6UBT-T sold separately)
The remote has a built-in Polymer Lithium rechargeable battery. It comes with a custom made charging
cable. Connect one end to the blades of the remote control and another the other end to any USB female
device (5V dc) for charging.
Make sure the remote has been charged before used.
1.7 Handheld Remote Control Synchronizing (AQ-DM-6UBT-T sold separately)
The remote has a receiver dongle (AQ-DM-6UBT-R) with a built-in male DIN connector. Connect the dongle
to the female DIN connector of BlueCube Media Player (AQ-BC-6BT).
The remote should already be paired from the factory, but if you need to synchronize the remote, follow
below steps.
1. Make sure BlueCube Media Player (AQ-BC-6BT) is powered ON (red LED lit)
2. Put the remote close to the dongle (AQ-DM-6UBT-R) (ideally within 0.5 meter)
2. Press and hold MODE until the LCD shows "Pairing in Progress". Release the button.
3. WIthin 2 seconds, the LCD will show "Paired". If it fails to pair, the LCD will show "Retry again". If this
happens, wait 5 seconds and repeat the above procedures.
For any additional remote controls, you will also need to synchroize those remote controls to the BlueCube
Media Player (AQ-BC-6BT).
If the pairing process is not successful, try again to put your remote close to the dongle.
Depending on the frequency of usage, the remote might drain its battery. Please charge the remote before
use. If the LCD shows nothing, it means that the battery has been drained.
If you have lost your remote control and buy a new remote control, please follow the above steps to pair the
remote control
Location of Controls Bluecube Media Player 6500-915
www.aquaticav.com 6
2.1 Wireless Handheld Remote Control AQ-RF6UBT-T (sold separately)
23
1
AUDIO AUDIO
MODEMODE
PAIRPAIR
AUDIO AUDIO
MODEMODE
PAIRPAIR
Buttons AUX IN Mode Bluetooth Mode
Power
Mode/Pair
Volume
Up
Volume
Down
2
3
EXT
Trigger
Audio
VBass
Fast
Forward
Fast
Rewind
Play/
Pause
11
2
3
Press once: Toggle Operational mode to Standby mode or vice versa
Press once: Change the source
Press and hold: Pair
Press once: Volume up
Press and hold: Fast volume up
Press once: Volume down
Press and hold: Fast volume down
Press once: no function
Press and hold: no function
Press once: Next track
Press and hold: Fast Forward
Press once: no function
Press and hold: no function
Press once: Previous track
Press and hold: Fast backward
Press once: Toggle mute
Press and hold: no function
Press once: Play/Pause
Press and hold: no function
Press once: Toggle Pump 1 on or off
Press and hold: no function
Press once: Toggle Pump 2 on or off
Press and hold: no function
Press once: Toggle Pump 3 on or off
Press and hold: no function
Press once: Toggle EXT trigger ON (12V dc) or OFF
Press and hold: no function
Press once: no function
Press and hold: no function
Press once: Toggle VBass ON or OFF
Press and hold: no function
2.2 Wired Remote Control AQ-WR6 (sold separately)
Coming Soon!
AUDIO MENU
Short press AUDIO
BALANCE Use +/- to adjust
FADER
ROCK
BASS
TREBLE
Short press AUDIO
Use +/- to adjust
Use +/- to adjust
CLASSIC
POP
Use +/- to adjust
Short press AUDIO
Short press AUDIO
Short press AUDIO
Short press AUDIO
Short press AUDIO
Long press AUDIO
to save and exit
Short press AUDIO
Long press AUDIO
to save and exit
Long press AUDIO
to save and exit
Long press AUDIO
to save and exit
Long press AUDIO
to save and exit
Long press AUDIO
to save and exit
2.2 Using Audio Menu on Handheld Remote
Control (purchased separately)
BlueCube+ Media Player (AQ-BC-6UBT) has equiped with
a audio DSP to meet different listening experiences.
1. To enter audio menu, press once AUDIO button.
2. Each press of AUDIO button will advance to the next
audio setting as described on the right.
3. In the audio menu, press and hold will save and exit the
audio menu to the original mode.
If you have chosen preset equalizer (Rock, Classic, or
Pop), the previously set Bass, Treble will be overrided.
Listening to Devices Bluecube Media Player 6500-915
www.aquaticav.com 7
3.1 Listening via Bluetooth
3.1.1 Pair with Bluetooth Device
1. Switch on your Bluetooth device.
2. Select 'AQUATIC AV' from the list of available devices to pair (no password is needed).
3.1.2 Listening via Bluetooth Device
1. Bluetooth mode will be activated once a Bluetooth device is paired.
2. Play the song from device and the sound will play through the Bluecube Media Player.
3. Press Play/Pause to play/pause the song.
4. Press Fast Rewind or Fast Forward buttons to play previous or next song
5. Track and volume can be controlled directly from your Bluetooth device or remote control.
3.1.3 Multi-link Feature
A second Bluetooth device can always pair to the BlueCube Media Player even when it has been
paired to another Bluetoot device.
3.2 Listening via Auxiliary Input
1. Connect your MP3 device to the 3.5mm stereo jack.
2. Press Mode on the remote control to select 'AUX IN' mode.
3.3 Adjust Volume Level
1. Press Volume Up once to increase the volume.
2. Press Volume Down once to reduce the volume.
3. Press and hold either Volume Up or Volume Down to increase or decrease audio volume
continuously.
Other Features
4.1 Using VBass
1. VBass is a features to boost up the bass of the audio using latest DSP technology.
2. Press VBass once to toggle it ON or OFF.
4.2 12V External Trigger
Press EXT on the remote to toggle the External Trigger ON/OFF. When Ext Trigger is turned on,
+12Vdc will be from EXT wire. This can be used for turning ON/OFF other devices.
4.3 Pump Control
Press 1, 2, or 3 to toggle the pump 1, 2, or 3 On/Off.
Specifications & Dimensions Bluecube Media Player 6500-915
www.aquaticav.com 8
4.1 Specifications
Media
Supported media
Device control
Inputs
Auxiliary
Subwoofer
Sub-out
Power
Output voltage @2 Ohm
Output voltage @4 Ohm
Operation voltage
Max current draw
Standby current draw
Multi-Environment Certifications
Waterproof / Dustproof
Conformal PCB coating
UV Protection
Salt/Frog protection
Stainless steel mountings
Bluetooth/MP3
via Bluetooth / MP3 device
via Jacuzzi Spa Top Side Panel, RF Handheld Remote
Control or Wired Remote Control (sold separately)
1x stereo pair 3.5mm stereo input
1x connector
4x 72W
4x 45W
9.6V - 14.4V
7A
6mA
Yes IP64
Yes
500 hours stable. ASTM D4329 compliant
500 hours stable. ASTM B117 compliant
Yes
Warranty Information Bluecube Media Player 6500-915
www.aquaticav.com 9
Aquatic AV offers a limited warranty of our products on the following terms:
Length of Warranty
2 years on audio systems, electronics, speakers, and accessories (receipt required).
Coverage
This warranty covers only the original purchaser of a Aquatic AV product purchased from an authorized Aquatic
AV dealer in the United States. In order to receive service, the purchaser must provide Aquatic AV with a copy
of the receipt stating the customer name, dealer name, product pruchased and date of purchase.
Defective products
Products found to be defective during the warranty period will be repaired or replaced (with a product deemed
to be equivalent) at Aquatic AV's discretion.
What is not covered
Damage caused by accident, abuse, improper operation, theft. Any cost or expernse related to the removal or
reinstallation of the product. Service performed by another other than an authorized Aquatic AV service center.
Any product with the serial number or tamper labels defaced, altered or removed. Subsequent damage to other
components. Any product not purchased from an authorized Aquatic AV dealer.
Limit on implied warranties
Any implied warranties including warranties of fitness for use and merchantability are limited in duration to the
period of the express warranty set forth above. Some states do not allow limitation on the length of an implied
warranty, so this limitation may not apply. No person is authorized to assume for Aquatic AV any other liability in
connection with the sale of the product.
How to obtain service
You must obtain a return material authorization number (RMA) to return any product to Aquatic AV. You are
responsible for shipping charges of returned products to Aquatic AV.
Please record the model and serial number[s] of your equipment in the spaced provided below as your
permanent record and will assist us with your factory warranty coverage. These numbers can be found on the
rear of the BlueCube Media Player.
Model number[s]: Serial number[s]:
FCC Statements Bluecube Media Player 6500-915
www.aquaticav.com 10
FCC ID:
MADE IN CHINA
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NOTE:
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Consult the dealer or an experienced radio/TV technician for help.
The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such
modifications could void the user authority to operate the equipment.
WBQAQRFDM6B
products with watertight reputation
Aquatic AV
282 Kinney Drive
San Jose, CA65112, USA
E-mail: info@aquaticav.com
US & Canada: 1 877 579 2782
International: +1 408 559 1668
Fax: +1 408 559 0125
www.aquaticav.com

Navigation menu
