fact sheet
anticimex.com/smart
Version 1 - 24.01.2018
Anticimex Smart
Smart Connect is the gateway for the Smart system.
Smart devices are linked wireless with each other
creating an uninterrupted grid network.
The product consists of a single master control box,
which connects and controls up to 50 Smart devices.
The system creates its own wireless network without
interfering other existing networks at the site. It forwards
information from traps and sensors to WisePlan over the
mobile network.
Smart Connect is wall mounted indoors and connected
directly to the main 230V electric circuit. In the case of a
power failure, the unit has a built-in rechargeable backup
battery.
It’s ideal for use in food processing and manufacturing
plants, pharmaceutical and packaging industries, as well
as in and around apartment blocks, hospitals, schools,
government properties and many other areas. At any site,
that has a need to monitoring pest activities and protect
against them entering the building. 2 – And forward the
information over the
mobile network to
WisePlan.
1 – Smart Connect
collects information
from Smart devices.
Anticimex
Smart Connect
Anticimex Smart
Anticimex Smart is an intelligent system that
keeps an eye on things you do not want to see.
By constantly monitoring and instantly reacting, it
prevents costly infestations in an environmentally-
friendly way. Add the services traditionally
provided by us, and you will get a solution that
gives you the best of two worlds –automation
and expertise.
anticimex.com/smart
Version 1 - 24.01.2018
Smart Connect
Controls
Power supply
IP classification
Dimensions
Weight
Electronic control with GPRS data transfer to sms, email and WisePlan. Wireless data
transmission with 920 MHz to Smart Catch and Smart Eye.
Standard 230 V socket, and back-up battery
IP 44
L 175 / W 40 / H 179
0,4 kg
Accessories
Article no.
Equipment
Installation Mounted on a wall indoors, where a connection to the main 230V electric circuit
is possible. Preferably, located in the middle of the work area or in the technical room.
Plastic material PP, Pmma
Standard Phillips screwdriver and a drill with (concrete) drill Ø 5 mm.
300 101
300 201 Smart Eye
300 301 Smart Catch
SIM card
Installation equipment
See FCC compliance statement and manuals on One.anticimex.com
