CARDO SYSTEMS, INC. QUICK GUIDE
Cardo S-800™
Bluetooth® Headset
2
Cardo S-800™
Congratulations and thank you for choosing the Cardo S-800
Bluetooth® headset. This Quick Guide will help you learn about
the Cardo S-800’s many features, allowing you to make the best
use of your headset.
Cardo S-800 Overview
1 Microphone
2 Multi-Function Wheel (MFW)
3 LED Status Indicator
4 Power and Hot Dial
Button
5 Charging Jack
6 Control Button
(CTRL)
7 Speaker
8 Earloop
1 4 7
5
27
3
8
3
Cardo S-800™
Getting Started
To use your Cardo S-800 (“the headset”), please follow these
initial steps:
• Charge your headset
• Pair your headset with a Bluetooth®-enabled mobile phone.
1. Charging your Headset
The headset comes with a built-in rechargeable battery. Prior to
using the headset, make sure to charge the headset for at least 4
hours. Normally it takes approximately 2 hours to fully charge the
headset.
1. Connect the charger to an AC wall outlet and the charger plug to
the headset’s Charging Jack. The headset’s LED status indica--
tor will be red during charging.
2. When the battery is fully charged, the red LED will turn off.
3. Disconnect the charger from AC wall outlet and the headset.
NOTE: Charging indication may be delayed for a few seconds if the
headset has not been used for a long time or the battery is drained.
4
Cardo S-800™
The fully charged battery offers up to 8 hours talk time and up to
one week standby time.
2. Pairing your Headset
Before you can use your headset you must pair the headset to your
Bluetooth-enabled mobile phone. If you do not have a Bluetooth-enabled
mobile phone, please visit http://cardosystems.com/adapter2.php for
information on the Cardo BTA II Bluetooth Adapter.
1. Turn on your phone and turn ON its Bluetooth function.
2. Make sure the headset is turned OFF, then press and hold the
Power Button for approximately 8 seconds until the LED status
indicator begins alternating blue and red, indicating that the
headset is in Pairing Mode.
3. Set the phone to search for Bluetooth devices by following the
instructions in the phone’s user guide. This is usually found in the
phone’s Bluetooth menu and may referred to as “discover” or
“add” a device.
4. After a few seconds, the phone will list the “Cardo S-800” as a
discovered device. Select it from the list and press “OK” or “Yes”.
5
Cardo S-800™
5. When prompted, enter the passkey “0000” (4 zeros) and press
“OK” to complete the pairing.
6. When the pairing is complete, your phone will conrm that the
pairing was successful and the headset’s LED status indicator
will begin ashing slowly in blue.
You should now be able to make and receive calls using your
headset. To initially connect the headset to your phone, you may
need to tap the CTRL Button once on the headset.
IMPORTANT: If the pairing is not completed within 2 minutes while
the Pairing Mode is activated, the headset will return to Standby
mode, ashing blue once every three seconds and you must start
the Pairing process again from Step 2 above.
NOTE: Your headset can pair with up to 8 phones, and will
automatically connect to the last phone connected to the headset. To
connect to a different paired phone, go to the Bluetooth menu of the
active phone and disconnect the headset. Then go to the Bluetooth
menu of the phone you wish to connect and connect the headset by
selecting it from the list of Paired Devices.
6
Cardo S-800™
3. Wearing your Headset
The S-800 headset can be worn on either your left or right ear.
There are two ways in which you can wear the S-800 headset.
1. Without the earloop: Gently insert the headset without an earloop
into your ear, and it will hold itself in place securely.
2. With the earloop: Insert the straight portion of the pin of the ear--
loop to a suitable depth so that the speaker ts snugly in your ear.
The earloop is exible, and may be adjusted for
maximum comfort.
The lanyard for the S-800 provides an easy and
convenient way of carrying your headset while it is
not in use.
1. To attach the headset to the lanyard, insert
the speaker into the upper loop of the lanyard.
Then pull the headset downwards into the lower
loop, until it is held securely in place.
2. To release the headset from the lan--
yard, simply pull the headset upward.
Upper
loop
Lower
loop
7
Cardo S-800™
4. Using your Headset – Basic Functions
Function Required Action
Turn ON/OFF the
headset
Press and hold the Power Button for at
least 4 seconds
Answer a call Tap the CTRL Button*
End a call Tap the CTRL Button
Make a call from
your phone
Dial normally from your phone and the
call will be transferred to the headset
(subject to phone settings).
Make a call using
Voice Dial
During Standby, tap the CTRL Button,
wait for the tone and say the name
of the person you wish to call. (Your
mobile phone must support the Voice
Dial feature.)
Increase the volume Move the MFW up by steps. When you
hear a beep, it is at maximum.
Decrease the volume Move the MFW down by steps.When
you hear a beep, it is at minimum.
Mute the microphone During a call, tap the MFW inwards to
turn on/off mute.
* NOTE: Wait until you hear the incoming call on the headset (not
only on the phone)
8
Cardo S-800™
5. Using your Headset – Advanced Functions
1. Redial the last dialed number*
During Standby, press the MFW inwards to redial the last dialed number.
2. Reject an incoming call*
During an incoming call, press and hold the CTRL Button for 3 seconds.
3. Call waiting / Toggling between calls*
During an incoming call and one call on hold or waiting, tap the MFW
inwards to answer the incoming call or toggle between calls.
4. Conference call*
During an active call and one call on hold or waiting, tap the MFW
inwards for 3 seconds to combine both calls into a Conference call.
5. Transfer calls to/from headset*
During a call, press and hold the CTRL Button for 3 seconds to
transfer the call between the headset and the mobile phone.
NOTE: On some phones, transferring a call to the headset
requires just a tap of the CTRL Button.
* These features are only supported by mobile phones that include the Bluetooth
Handsfree prole.
9
Cardo S-800™
6. Hot Dial Function
The S-800 allows you easily call any of three different phone
numbers at the press of a button.
In order to use the Hot Dial function, you must rst congure
your mobile phone’s Speed Dial settings. Please refer to your
mobile phone’s user guide or our website (www.cardosystems.com)
for instructions on saving Speed Dial numbers.
To Hot Dial:
• Speed dial #2: Tap the Hot Dial Button once.
• Speed dial #3: Tap the Hot Dial Button twice rapidly.
• Speed dial #4: Tap the Hot Dial Button three times rapidly.
7. SWAP (Swapping connection between two active mobile
phones)
The S-800 allows you to swap, i.e. to alternately use one among
the last two phones to which it has been connected.
To SWAP between phones:
• While both phones are turned on and the headset is in
Standby mode, double-press the MFW inwards.
10
Cardo S-800™
• The headset will switch to the second phone.
• Each time you double-press the MFW, the alternate phone
connects to the headset.
NOTE: This feature may only be used when the headset
and both phones are in Standby mode.
8. Battery Status Indicator
To check the status of the headset’s battery, press and hold the CTRL
Button for at least four seconds while the headset is in Standby mode.
The LED Status Indicator will ash for two seconds as follows:
    • Blue Full charged
    • Red and Blue Medium charge
    • Red Weak charge
9. Locating the Headset (Buzzer Function)
The S-800 allows you to locate the headset by activating an
audible buzzer.
To activate the Buzzer:
• Dial a number with the mobile phone and press Send/Talk.
• While the call is in progress (or even while still ringing), turn
11
Cardo S-800™
the mobile phone’s volume buttons up, then down, repeating
the up/down sequence ve or more times.
• The headset will start buzzing.
10. Call back the last incoming caller (Callback Function)
The S-800 allows you to place a call to the phone number of the
last incoming call. The headset will store the phone number of the
last answered, missed or rejected call.
To use the Callback function:
• While in Standby mode, rapidly move the MFW down twice
and release (double down-click).
NOTE: The Callback number memory will be cleared if:
1. The headset is disconnected from the current phone and
connected to a different phone.
2. The headset is turned off or has been charged.
3. The last incoming caller had a blocked or restricted number.
NOTE: This feature is not supported by some mobile phones.
11. Auto-Answer Function
The S-800 allows you to automatically answer all incoming calls
12
Cardo S-800™
using the Auto-Answer function. Please note that once this feature
is activated you are subject to unintended eavesdropping. Use of
this feature is at your own risk!
Learn more at www.cardosystems.com/faq/autoanswer
When Auto-Answer mode is enabled on an incoming call, the Headset
will ring for a few seconds and then automatically answer the call without
the need to press the CTRL Button. Auto-Answer is disabled by default.
To enable/disable Auto-Answer:
• While in Standby mode, press and hold the MFW upwards
for seven seconds.
• When the Auto-Answer function is enabled, the blue Status
Indicator will begin ashing rapidly.
NOTE:
• Auto-Answer will not answer an incoming call if you are
currently on a call (Call Waiting).
• Turning off the headset will disable the Auto-Answer
function.
• Auto-answer can be enabled again after turning on the
headset by following the instructions above.
13
Cardo S-800™
12. Button Lock
The S-800 allows you to lock its buttons, preventing the buttons
from being accidentally pressed.
To lock/unlock the buttons on the Headset:
• While in Standby mode, simultaneously press the MFW and
the CTRL Button for at least four seconds.
13. Disabling / enabling the LED Status Indicator
The S-800 allows you to turn off the ashing LED Status
Indicator. • While in Standby mode, move the MFW down and hold
for at least four seconds.
• The Status Indicator will stop/begin ashing, depending on
whether you are disabling/enabling the Status Indicator.
14. Changing the Wheel orientation
The default conguration of the headset is designed for use on
your right ear. This means that clicking up on the MFW towards
the small ‘+’ sign on the headset increases the volume one step
at a time, while clicking down towards the ‘-’ sign on the headset
decreases the volume one step at a time.
14
Cardo S-800™
If you wear the Headset on your left ear, the S-800 allows you to
change the MFW orientation from right to left ear, so that pressing
the MFW up still increases the volume, and pressing down
decreases the volume. Only volume orientation is affected.
To set the Headset for left ear orientation:
• Make sure the headset is turned off.
• Now turn it on by pressing the CTRL Button and the Power
Button simultaneously for 4 seconds.
• Once you see 3 blue ashes followed by a single simultane--
ous ash of the red and blue lights, the headset is powered
on and you may release the buttons.
NOTE: The headset will revert to its default right ear
conguration once it is turned off. In order to regularly use
the headset in left ear conguration, always turn on the
headset using the CTRL + Power Button procedure above.
15
Cardo S-800™
ADVANCED FUNCTIONS REFERENCE
Function Required Action
Redial the last dialed
number
During Standby, tap the MFW inwards.
Reject an incoming
call
During an incoming call, press and hold
the CTRL Button for 3 seconds.
Call waiting / Toggling
between calls
During an incoming call and one call on
hold or waiting, tap the MFW inwards.
Conference Call During an active call and one call on hold
or waiting, tap the MFW inwards.
Transfer calls to / from
headset
During a call, press and hold the CTRL
Button for 3 seconds.
Hot Dial Tap the Hot Dial Button 1, 2, or 3 times
rapidly to call Speed Dial #2, #3, or #4
respectively.
SWAP between active
phones
During Standby, double-press the MFW
inwards.
Battery Status
Indicator
Press and hold the CTRL Button for 4
seconds; Blue=Full, Red/Blue=Medium,
Red=Weak.
Locating the headset
(Buzzer)
Dial a call, then press VolUp/VolDn on the
phone 5 times.
Call back the last
incoming caller
(Callback)
During Standby mode, rapidly move the
MFW down twice and release (double
down-click).
16
Cardo S-800™
Function Required Action
Auto-Answer On/Off During Standby mode, press and hold the
MFW upwards for 7 seconds.
Button Lock On/Off During Standby mode, simultaneously
press the MFW and the CTRL Button for
at least 4 seconds.
Disabling / enabling the
LED Status Indicator
During Standby mode, move the MFW
down and hold for at least four seconds.
Changing the Wheel
orientation
Turn on the headset by pressing and
holding the CTRL Button and the Power
Button simultaneously for 4 seconds.
6. Status Lights
Missed Call Indicator
Whenever a call is missed or rejected, the red and blue Status
Indicator will begin ashing simultaneously, notifying you of the
missed call.
To clear this Missed Call Indicator, press any button on the
headset.
NOTE: This feature is not supported by some mobile
phones.
17
Cardo S-800™
The headset uses the following Status Indicators to display its
status:
Status Light Auto-
Answer Status
Single blue ashing
slowly (every 3 sec) Disabled Standby mode
Double blue ashing
slowly (every 3 sec) Disabled During a call
Red and blue
simultaneously ashing
slowly
Disabled Missed call
Red ashing slowly
(every 3 sec) Disabled Low battery
Single blue ashing
rapidly Enabled Standby mode
Double blue ashing
rapidly Enabled During a call
Red and blue
simultaneously ashing
rapidly
Enabled Missed call
Red ashing rapidly Enabled Low battery
Alternating red/blue
ashing Pairing mode
3 blue ashes Power ON
18
Cardo S-800™
Status Light Auto-
Answer Status
3 red ashes Power OFF
None
Headset is off or
Status Indicator is
disabled
7. Audio Tones
With the exception of the actions described in the following table,
all actions are followed by a single tone to conrm that the
headset has accepted the action. A double tone means that the
action has failed.
Action Tone
Mute On/off tone and mute reminder tone
every 20 seconds
Volume up Tone on maximum volume
Volume down Tone on minimum volume
Locate the headset Buzzing
Call back list is empty Two short beeps
19
Cardo S-800™
8. Troubleshooting
NOTE: For most problems, it is recommended as a rst step that
you turn the headset off for one minute and then on again. If that
fails, try pairing the headset and phone again.
Problem Action
Pairing fails 1. Delete S-800 from your paired device list in your phone
(if it is listed).
2. Turn off the mobile phone and Headset.
3. Take the battery out of the phone and put it back.
4. Repeat the pairing process as described in
Pairing your Headset section above.
Can’t
answer
phone calls
or perform
voice
dialing
(Assuming your mobile phone supports Voice Dialing) :
1. Make sure your Headset is turned ON and in Standby
mode while the blue light indicatorashes slowly.
2. Verify that the Bluetooth function on your phone is set
to ON.
3. Verify that the S-800 is the correctly paired Headset to
your mobile phone (refer to the phone manual).
4. Connect the headset to the phone as described above.
5. Check “Denitions” or “Settings” on your mobile phone
for Voice Dial Enablings.
6. Perform the pairing process as described in Pairing
your Headset section and check again.
20
Cardo S-800™
Problem Action
Battery does
not provide
at least six
hours of talk
time
Make sure your headset is fully charged.
Charging time is up to 2 hours for an empty battery.
When fully charged and charger is connected to
headset, the red light indicator turns off.
NOTE: You may have compromised the battery’s
capacity if you did not fully charge it prior to initial use.
Red Status
Light does not
light steady
when charger is
connected.
1. Make sure the wall charger is rmly plugged into
the Charging Jack.
2. Disconnect the charger from the Charging Jack,
wait a few seconds and plug it back in.
3. When the headset is fully charged, the
red light turns off.
Bad sound
quality
1. Possibly caused by nearby interference.
2. If you have a GSM phone and your
headset is too close to the phone, interference may occur.
3. Headset and mobile phone are more than 30 ft.
(10m) apart. Range will be shortened if there are major
obstacles between the Headset and mobile phone.
I press the
buttons and
nothing happens
Your headset is probably in key lock mode. Unlock the
Headset as described above.
21
Cardo S-800™
Problem Action
I am unable to
connect the
headset with the
mobile phone
or Bluetooth
enabled device
1. Ensure your headset is turned on and is properly
charged.
2. Ensure the headset is paired with your mobile
phone.
3. Ensure your mobile phone’s Bluetooth feature is
activated. Please refer to your mobile phone’s user
guide for specic instructions.
4. Ensure the headset is within a maximum of 33 feet
(10 meters) of your mobile phone(s) and there are no
obstructions, such as walls or other electronic devices
in between.
The person
with whom I am
speaking with is
not able to hear
me clearly
Ensure the headset is connected with your mobile
phone by verifying that the audio of your call is playing
through the headset, and not your phone’s speaker.
22
Cardo S-800™
9. Support
For additional information visit our website at
www.cardosystems.com or contact us at:
Phone: Toll-free USA 1-800 488-0363
Europe +1 412 788 4533
Email: support@cardosystems.com
FAQ: www.cardosystems.com/faq
The Cardo S-800™ Headset is compliant with and adopts the Bluetooth®
Specication 2.0. However, interoperability between the device and other
Bluetooth®
-enabled products is not guaranteed. For more information on
the compatibility between the device, please visit our website at:
www.cardosystems.com/declaration
10. Accessories
Accessories for your Cardo S-800™ headset may be ordered online at
www.cardosystems.com/S800/Accessories.
23
Cardo S-800™
Copyright © 2007 The Cardo S-800™
is developed and
manufactured by
Cardo Systems, Inc.
All rights reserved.
The Bluetooth® word
mark and logos
are owned by the
Bluetooth SIG, Inc.
Other trademarks
and trade names are
those of their respec--
tive owners.
24
Cardo S-800™
IMPORTANT SAFETY INSTRUCTIONS
1. Make sure the voltage specs of your Wall Charger fit your power grid (110 V or 220 V).
2. Don’t touch the Wall Charger while your hands are wet.
3. Never try to open the wall charger.
4. Do not expose the Wall Charger to high temperatures or very humid conditions.
5. In the event of overheating, disconnect the Wall Charger and forward it to any CARDO authorized Service Center.
6. Please read carefully the safety instructions regarding your headset, located in the enclosed Manual.
Please maintain basic safety precautions when using your Cardo Product (“Product”). This will reduce the risks of
fire, electric shock and injury to users. Among others, you should comply with the following:
1. Use a damp cloth to clean the Product. DO NOT use liquid or aerosol cleaners.
2. Use caution when using your Product near water such as bathtubs, kitchen sinks or swimming pools.
3. Do not expose your Product to extreme temperature, moisture or high voltage.
4. Your Product is rugged, but can be damaged or broken if not handled with care.
5. Do not expose the Product to liquids, nor place heavy objects on it.
6. Do not disassemble the Product or any of its components for any reason.
7. Do not open the Product’s casing, as this will void the warranty and may damage the electronic circuits. If
assistance is needed, contact the store from which you have purchased the Product or contact us via e-mail
at: support@cardosystems.com
To reach us via phone, please call: In the USA and Canada toll-free 1-800-488-0363 or 412-788-4533. In Europe,
call: +4989 450 36819
For additional Service Centers near you, please visit our website at http://www.cardosystems.com/
Note: Prior to contacting us, make sure you have a valid registration number available.
8. Discontinue the use of your Product if:
a. Your Product is damaged.
b. Liquid has been spilled on or into the Product.
c. Your Product has been dropped and the case has been damaged.
d. Your Product exhibits a distinct change in performance.
25
Cardo S-800™
e. Your Product does not operate normally and adjusting the controls does not resolve the issue.
9. Unplug your wall charger from the Product if:
a. Liquid has been spilled into the charger, Product or mobile phone.
c. The Wall Charger does not operate normally after following the operating instructions.
d. Your Wall Charger has been dropped and the case has been damaged.
e. The Wall Charger exhibits a change in performance.
Automobile Travel Please be mindful that certain activities such as automobile travel require your complete
attention and concentration. Check the rules and regulations regarding the use of wireless devices in the area
where you drive and obey the laws at all times. Pull over to the side of the road and park before making or
answering a call if driving conditions require it. Do not initiate calls, perform pairing, linking or similar operations
while driving. Most electronic equipment is shielded from RF signals. However, certain electronic equipment may
not be shielded against the RF signals emanating from your wireless equipment.
Pacemakers The Health Industry Manufacturers Association recommends that a minimum separation of about
six inches (or 16 cm) to be maintained between a mobile phone or wireless device and a pacemaker to avoid
potential interference with the pacemaker. Be sure not to interfere with the functionality of personal medical
devices.
Hearing Aids Some devices may interfere with certain hearing aids. In the event of such interference, you should
consult your hearing aid manufacturer to discuss alternatives.
Other Medical Devices If you use any other personal medical device, consult the manufacturer of your device
and/or your physician to determine if it is adequately shielded from interference caused by external RF energy.
Your physician may be able to assist you in obtaining this information.
LIMITED WARRANTY
Your Product is covered with a One-Year Limited product warranty from the date of original purchase. Please
retain the retail sales receipt and your registration data for proof of purchase.
What this limited warranty covers and for how long: Cardo Systems, Inc. (the “Company” or “Cardo“) warrants the
Product and Wall Charger against defects in material and workmanship under normal use and service for a period of
26
Cardo S-800™
one (1) year from date of purchase (proof of purchase and registration required). The Company at its sole discretion,
will at no charge either repair, replace or refund the purchase price of the Product to the original purchaser during the
warranty period, provided the Product has not been damaged or tampered with and has been returned in accordance
with the terms of this warranty to an authorized Company Repair Center. Repair, at the Company’s option, may include the
replacement of parts, boards or batteries with functionally equivalent reconditioned or new parts.
Warranty Conditions This express limited warranty is extended by Cardo Systems, Inc. solely to the original purchaser
and is not assignable or transferable to others. This is the complete warranty for your Product. The Company assumes no
obligation or liability for additions or modifications to this warranty unless made in writing and signed by an officer of the
Company. Batteries are warranted only if the battery capacity falls below 70% of rated capacity or if the battery develops
leakage. This warranty becomes void if: a. any of the seals on the case or battery are broken or Product or battery
show signs of tampering, b. The battery is used in equipment other than the equipment for which it was intended. The
Company disclaims all responsibility for any equipment not furnished by Cardo Systems Inc., which is attached to or used
in connection with the Product. Furthermore, the Company is not responsible for any damage to any part of the Product
resulting from the use of ancillary equipment not furnished by Cardo for use with the Product.
What this warranty does not cover:
1. Defects or damage resulting from the use of this Product in other than its normal and customary manner.
2. Defects or damage from misuse, accident or neglect.
3. Defects caused by improper operation, maintenance, installation, adjustment or modification of any kind.
4. Products opened, disassembled or repaired by non-authorized parties.
5. Defects or damage due to exposure to excessive temperatures, adverse weather conditions, external impacts
or spills of food or liquid.
6. All plastic surfaces and all other externally exposed parts that are scratched or damaged after purchase.
Warranty Service To receive warranty service, your Product must be registered. Fax either the attached
registration card or register online at: www.cardosystems.com/registration.php. Please present the Product,
along with your registration number, bill of sale (receipt) at any authorized Service Center or at the store from
which you have purchased the Product. Returns to the Company pursuant to the limited warranty can only be
accepted with a Return Authorization number obtained from Cardo’s customer service department.
General Provisions This warranty is given in lieu of all other express or implied warranties, including without
limitation, implied warranties of merchantability and fitness for a particular purpose.
27
Cardo S-800™
1. Cardo is not liable for any incidental or consequential damages arising from the use or misuse of any of the
Company’s Products.
2. The user should never attempt to perform service, adjustments or repairs of the Product by him/herself. Doing
so will void all warranties. During the term of the warranty, all Products must be returned to the point of
purchase or the authorized service center for all necessary work.
3. The Company is not responsible for any loss or damage incurred during shipping. All repair work on the
Product by parties not explicitly authorized by the Company will void any and all warranties.
4. The information in this Manual is furnished strictly for informational purposes and is subject to change
without notice. Cardo assumes no liability or responsibility for any errors or inaccuracies that may appear in
the Manual or Quick Start Guide.
NOTE: Look for appropriate displays to verify that you are being serviced by an Authorized Cardo Dealer or Service
Center. Cardo retains the right to amend and change its Products, manuals and specifications at any time without
notice.
IMPORTANT: Cardo assumes no responsibility for direct and consequential damages, harm, merchantability or
loss of any kind, including those resulting from the use of non-Cardo components or products in conjunction with
its Products, and specifically the use of third party Bluetooth headsets or chargers. Using non-Cardo products in
connection with the BTA II is at your own risk.
WARRANTIES
FCC Notice This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this Product may not cause harmful interference, and (2) this Product must accept any interference
received, including interference that may cause undesired operation. Warning: Changes or modifications to this
unit not expressly approved by the party responsible for compliance could void the User’s authority to operate the
equipment. Use only approved batteries and chargers. This equipment has been tested and found to comply with
Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates and can radiate radio frequency energy, and if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. Your Product is designed to
operate at the maximum strength allowed by the FCC. This means that your Product can communicate only over
28
Cardo S-800™
a certain distance subject on the location of the cell phone, base unit and Headset, your vehicle, the construction
and layout of your home or office. Weather conditions can also affect performance.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED
BATTERIES ACCORDING TO THE INSTRUCTIONS.
ALERTE : Risque d’explosion si la batterie est remplacée par un model qui ne convient pas. Il faut traiter les
batteries usées selon les instructions.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for help.
European CE Notice - Certification and Safety Approvals/ General Information
This Product is CE marked according to the provisions of the R & TTE Directive (99/5/EC). Hereby Cardo Systems,
Inc. declares that this Product is in compliance with the essential requirements and other relevant provisions
of Directive 1999/5/EC. For further information please visit http://www.cardosystems.com. Please note that
this Product uses radio frequency bands not harmonized within the European Union (“EU”). Within the EU this
Product is intended to be used in Austria, Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Italy,
Luxembourg, The Netherlands, Portugal, Spain, Sweden, The United Kingdom and within EFTA in Iceland,
Norway and Switzerland. Users are not permitted to make changes or modify the Product in any way. Changes or
modifications not expressly approved by Cardo will void the user’s authority to operate the equipment.
29
Cardo S-800™
Service
In the USA and Canada, call toll-free: 1 800 488-0363 or 412 788-4533;
In Europe, call: +49 (89) 450 368 19.
Service is provided under limited warranty. Cardo Systems, Inc. will only accept Products returned in compliance with
our Warranty Provisions and submitted with a Return Authorization Number issued by a Cardo authorized service
department. The Company retains the right to return all shipments not in compliance with our Warranty Provisions.
Patent, Copyright, Trademark Information
U.S. and Worldwide Patent Pending; ©2003 Cardo Systems Inc.; Assembled in China. Bluetooth® is a trademark owned
by Bluetooth® SIG, Inc., scala™ is a trademark owned by Cardo Systems, Inc. All rights reserved by Cardo Systems, Inc.
State Law Rights
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on
how long an implied warranty lasts. Therefore depending on where you use the Product, certain of the above
limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may be
entitled to other rights, which vary from state to state.
Contact Information
Cardo Systems, Inc.,
100 High Tower Blvd.,
Pittsburgh, PA 15205 (USA)
www.cardosystems.com.
In the US and Canada call toll-free: 1 800 488-0363 or 412 788-4533, Fax: 412 788-0270;
In Europe, call: +49 (89) 450 368 19, Fax: +49 (89) 404-817
Need more help? Please visit www. cardosystems.com
30
Cardo S-800™
C A R D O S Y S T E M S , I N C .
QG800_004/04-7_J
Developed and Manufactured by:
All rights reserved

Navigation menu
