VEEDER - ROOT
SERIAL INTERFACE MANUAL
for
TLS-300 and TLS-350
UST Monitoring Systems
and
TLS-350R
Environmental & Inventory
Management System
through Software Versions 020/133/333/433/520
Manual Number 576013-635
Revision AA
NOTICE
Veeder-Root makes no warranty of any kind with regard to this publication, including but not
limited to, the implied warranties of merchantability and fitness for a particular purpose.
Veeder-Root shall not be liable for errors contained herein or for incidental or consequential
damages in connection with the furnishing, performance, or use of this publication.
The information contained in this publication may be subject to change without notice.
This publication contains proprietary information which is protected by copyright. All rights
reserved. No part of this publication may be photocopied, reproduced, or translated to another
language without the prior written consent of Veeder-Root.
©Veeder-Root 2014. All rights reserved.
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA iii
NOTICE ............................................................................................................................................................................... ii
1.0 INTRODUCTION ................................................................................................................................................... 1
2.0 HARDWARE CONNECTIONS .............................................................................................................................. 1
2.1 RS-232 ............................................................................................................................................................... 1
2.2 EIA RS-232 INTERFACE ................................................................................................................................... 1
2.3 INTERNAL MODEM ........................................................................................................................................... 2
3.0 CHARACTER FORMAT AND BAUD RATE .......................................................................................................... 2
4.0 SWITCH SETTINGS .............................................................................................................................................. 2
4.1 DIP SWITCH ...................................................................................................................................................... 2
5.0 COMMAND MESSAGE FORMAT ......................................................................................................................... 3
6.0 RESPONSE MESSAGE FORMAT ........................................................................................................................ 4
6.1 COMPUTER FORMAT ...................................................................................................................................... 4
6.2 DISPLAY FORMAT ............................................................................................................................................ 4
6.3 ASCII FLOATING POINT FORMAT .................................................................................................................. 5
6.3.1 NOTES ....................................................................................................................................................... 5
6.3.2 EXAMPLES ................................................................................................................................................ 6
7.0 FUNCTION CODES AND RESPONSE MESSAGES ............................................................................................ 7
7.1 CONTROL FUNCTIONS ........................................................................................................................................ 9
7.2 OPERATIONAL REPORTS .................................................................................................................................. 37
7.2.1 SYSTEM REPORTS ..................................................................................................................................... 37
7.2.2 IN-TANK REPORTS ...................................................................................................................................... 58
7.2.3 SENSOR REPORTS ................................................................................................................................... 101
7.2.4 LINE LEAK REPORTS ................................................................................................................................ 123
7.2.5 MISCELLANEOUS REPORTS ................................................................................................................... 142
7.2.6 I/O DEVICE REPORTS ............................................................................................................................... 145
7.3 SETUP FUNCTIONS & REPORTS .................................................................................................................... 152
7.3.1 SYSTEM SETUP ......................................................................................................................................... 152
7.3.2 COMMUNICATIONS SETUP ...................................................................................................................... 181
7.3.3 WARNING, ALARM, & AUTO-PRINT SETUP ............................................................................................ 202
7.3.4 IN-TANK SETUP ......................................................................................................................................... 244
7.3.5 SENSOR SETUP ........................................................................................................................................ 314
7.3.6 VOLUMETRIC LINE LEAK SETUP ............................................................................................................. 347
7.3.7 PUMP SENSOR SETUP ............................................................................................................................. 366
7.3.8 PRESSURE LINE LEAK SETUP ................................................................................................................. 372
7.3.9 RECONCILIATION SETUP ......................................................................................................................... 403
7.3.10 WIRELESS PLLD SETUP ......................................................................................................................... 419
7.3.11 METER MAP & DELIVERY TICKET SETUP ............................................................................................ 435
7.3.12 PUMP MONITOR RELAY SETUP ............................................................................................................ 442
7.3.13 I/O DEVICE SETUP .................................................................................................................................. 448
7.3.14 EEPROM SETUP ...................................................................................................................................... 462
7.3.15 MISCELLANEOUS SETUP ....................................................................................................................... 465
7.4 DIAGNOSTIC REPORTS ................................................................................................................................... 483
7.4.1 SYSTEM DIAGNOSTIC REPORTS ............................................................................................................ 483
7.4.2 IN-TANK DIAGNOSTIC REPORTS ............................................................................................................ 489
7.4.3 SENSOR DIAGNOSTIC REPORTS ........................................................................................................... 519
7.4.4 LINE LEAK DIAGNOSTIC REPORTS ........................................................................................................ 537
7.4.5 RECONCILIATION DIAGNOSTIC REPORTS ............................................................................................ 564
7.5 RECONCILIATION REPORTS ........................................................................................................................... 570
7.6 VARIANCE ANALYSIS REPORTS..................................................................................................................... 585
7.7 IN-STATION DIAGNOSTICS (ISD) .................................................................................................................... 598
7.7.1 ISD REPORTS ............................................................................................................................................ 598
7.7.2 ISD SETUP.................................................................................................................................................. 635
7.7.3 ISD DIAGNOSTIC REPORTS ..................................................................................................................... 653
8.0 IFSF DATABASE SUPPORT .................................................................................................................................. 675
8.1 TANK LEVEL GAUGE DATABASE .................................................................................................................... 675
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA iv
8.2 TANK LEVEL GAUGE ERROR CODE DATABASE .......................................................................................... 676
8.3 TANK PROBE DATABASE ................................................................................................................................ 676
8.4 TANK CONTENTS TABLE DATABASE ............................................................................................................. 678
8.5 TANK TEMPERATURE TABLE DATABASE ..................................................................................................... 678
8.6 TANK PROBE ERROR CODE DATABASE ....................................................................................................... 678
8.7 DATA DOWNLOAD DATABASE ........................................................................................................................ 679
8.8 COMMUNICATION SERVICE DATABASE ........................................................................................................ 679
9.0 FUNCTION CODE SUMMARY ............................................................................................................................... 680
CONTROL FUNCTIONS (7.1) ................................................................................................................................... 680
OPERATIONAL REPORTS (7.2) .............................................................................................................................. 681
SYSTEM REPORTS (7.2.1) .................................................................................................................................. 681
IN-TANK REPORTS (7.2.2) .................................................................................................................................. 681
SENSOR REPORTS (7.2.3) ................................................................................................................................. 682
LINE LEAK REPORTS (7.2.4) .............................................................................................................................. 683
MISCELLANEOUS REPORTS (7.2.5) .................................................................................................................. 683
I/O DEVICE REPORTS (7.2.6) ............................................................................................................................. 684
SETUP FUNCTIONS & REPORTS (7.3) .................................................................................................................. 684
SYSTEM SETUP (7.3.1) ....................................................................................................................................... 684
COMMUNICATIONS SETUP (7.3.2) .................................................................................................................... 685
WARNING, ALARM, & AUTO-PRINT SETUP (7.3.3) .......................................................................................... 685
IN-TANK SETUP (7.3.4) ........................................................................................................................................ 687
SENSOR SETUP (7.3.5) ....................................................................................................................................... 689
VOLUMETRIC LINE LEAK SETUP (7.3.6) ........................................................................................................... 690
PUMP SENSOR SETUP (7.3.7) ........................................................................................................................... 690
PRESSURE LINE LEAK SETUP (7.3.8) ............................................................................................................... 691
RECONCILIATION SETUP (7.3.9) ....................................................................................................................... 691
WIRELESS PLLD SETUP (7.3.10) ....................................................................................................................... 692
METER MAP & DELIVERY TICKET SETUP (7.3.11) ........................................................................................... 692
LINE/PLLD/WPLLD SETUP .................................................................................................................................. 693
PUMP MONITOR RELAY SETUP (7.3.12) ........................................................................................................... 693
PRESSURE LINE LEAK SETUP (refer to 7.3.8) ................................................................................................... 693
PUMP SENSOR SETUP (refer to 7.3.7) ............................................................................................................... 693
I/O DEVICE SETUP (7.3.13) ................................................................................................................................. 693
EEPROM SETUP (7.3.14) .................................................................................................................................... 694
MISCELLANEOUS SETUP (7.3.15) ..................................................................................................................... 694
DIAGNOSTIC REPORTS (7.4) ................................................................................................................................. 695
SYSTEM DIAGNOSTIC REPORTS (7.4.1) .......................................................................................................... 695
IN-TANK DIAGNOSTIC REPORTS (7.4.2) ........................................................................................................... 695
SENSOR DIAGNOSTIC REPORTS (7.4.3) .......................................................................................................... 696
LINE LEAK DIAGNOSTIC REPORTS (7.4.4) ....................................................................................................... 696
RECONCILIATION DIAGNOSTIC REPORTS (7.4.5) .......................................................................................... 697
VARIANCE ANALYSIS REPORTS (7.6) ................................................................................................................... 698
IN-STATION DIAGNOSTICS (ISD) (7.7) ................................................................................................................... 698
ISD REPORTS (7.7.1) ........................................................................................................................................... 698
ISD SETUP (7.7.2) ................................................................................................................................................ 698
ISD DIAGNOSTIC REPORTS (7.7.3) ................................................................................................................... 699
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 1
1.0 INTRODUCTION
The serial RS-232 interface is used to connect the system to a controlling computer, a display terminal
(CRT) or a printing terminal. A modem can be connected directly to the system to provide telephone
line access.
NOTE: The software versions for these systems vary depending on when they were purchased and if
software upgrades have been installed. The version in which each function code first appeared is
indicated in a box next to its description in Section 7. Commands appearing in software versions greater
than 100 are only active in systems equipped with an ECPU.
2.0 HARDWARE CONNECTIONS
The RS-232 interface is a module accessed via a 25-pin D-connector located on the bottom-left of the
console.
2.1 RS-232
The RS-232 D-connector is a panel mount, 25-pin female type, wired in a Data Terminal Equipment
(DTE) configuration. A modem (DCE) may be connected directly to the interface using a straight-
through cable. A CRT or printing terminal (DTE) may be connected to the interface by using a null
cable which reverses the sense of the transmit/receive signals. The system does not require or activate
any handshake signals.
RS-232 signals are wired to the female D-connector as follows:
PIN
2 Transmitted Data
3 Received Data
7 Signal Ground (common return) and Chassis
2.2 EIA RS-232 INTERFACE
The EIA RS-232 interface is designed to connect to modems for transmission of data over telephone
lines. It can be used for direct local attachment of terminals if the cable run is no more than 50 feet. In
practice, cable runs longer than 50 feet have performed satisfactorily; however, since the RS-232
specification is designed for operation up to 50 feet, direct connect cable runs greater than 50 feet are not
warranted for proper operation.
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 2
2.3 INTERNAL MODEM
The optional internal modem operates at up to 2400 Baud. The modem module contains two RJ11 jacks
for phone line connections, and is accessible at the bottom left of the console.
3.0 CHARACTER FORMAT AND BAUD RATE
The system receives and sends characters via the RS-232 interface in an ASCII format that is configured
via the system front panel keypads. Selections consist of: 1 start bit; 7 or 8 data bits; odd, even or no
parity; and 1 or 2 stop bits. Communications rate is selectable: 300, 1200, 2400, 4800 or 9600 baud.
The system operates in a full duplex mode. Characters are not echoed when received, and transmitted
characters must not be echoed back to the system. Transmit and receive can occur simultaneously, and
commands can be stacked in the system buffer (up to 128 characters).
4.0 SWITCH SETTINGS
4.1 DIP SWITCH
A four-position DIP switch is located on the CPU board, which is mounted in the right-back of the
console printer compartment. The DIP switch is next to the battery switch. The DIP switch positions
are assigned as follows:
Switch
1 Front Panel Setup Security Enable
2 RS-232 Security Enable
3 Unused
4 Fiscal Height Security
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 3
5.0 COMMAND MESSAGE FORMAT
All command and response messages are configured in a format which includes a surrounding envelope
of control characters and a function code and data field message. The control characters are described in
this section while the function codes and data field messages are described in subsequent sections.
The system responds to a command message that has the following configuration:
SOH
Security Code
Function Code
Data Field
SOH is a control-A character (ASCII 01).
The RS-232 security code is an optional six-digit code used to limit external serial access to the system
for security purposes. It can be set to any unique set of characters using either the front panel switches
or the external communication interface setup commands. The system will not respond to a command
without the proper security code, if the DIP switch is set to enable RS-232 security.
The function code is a six character command code which the system interprets to determine the type of
action to take and response to return. System function codes and response messages are defined in
subsequent sections.
The data field is optional and contains information necessary to perform the selected function (such as
setup information).
If the system receives a command message string containing a function code that it does not recognize, it
will respond with a <SOH>9999FF1B<ETX>. The "9999" indicates that the system has not understood
the command, while the "FF1B" is the appropriate checksum for the preceding <SOH>9999 string.
There is one command which does not follow the above format. The escape command is performed by
sending an ESC (escape character, ASCII 27), to the system. It is a means to halt a response message at
any time before its completion.
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 4
6.0 RESPONSE MESSAGE FORMAT
There are two types of response message formats: computer (or packed data format) and display format.
Each format uses a different surrounding envelope of control characters.
6.1 COMPUTER FORMAT
The computer format is a stream of numbers without any formatting characters; i.e., carriage return, line
feed, spaces, labels, etc. The message format is as follows:
SOH
Function Code
Data Field
&&
Checksum
The function code is identical to the received command message function code.
The data field contains the response message which is described in subsequent sections.
The "&&" is a fixed tag character which indicates that the checksum immediately follows.
The Checksum is a series of four ASCII-hexadecimal characters which provide a check on the integrity
of all the characters preceding it, including the control characters. The four characters represent a 16-bit
binary count which is the 2's complemented sum of the 8-bit binary representation of the message
characters after the parity bit (if enabled) has been cleared. Overflows are ignored. The data integrity
check can be done by converting the four checksum characters to the 16-bit binary number and adding
the 8-bit binary representation of the message characters to it. The binary result should be zero.
ETX is programmable if enabled via the S53100f command. If it is disabled, the ETX is a fixed
Control-C character (ASCII 03). Caution should be taken before changing the ETX character, because it
affects the transmitted messages on ALL communications ports of the system, and additional host
devices may be connected to other ports which expect the ETX to be a Control-C.
6.2 DISPLAY FORMAT
The display format is intended for display on a CRT or printer. It includes all the necessary formatting
characters such as carriage returns, line feeds, nulls, spaces, labels, etc. The message format is as
follows:
SOH
Function Code
Data Field
ETX
See subsequent sections for a description of the data field response messages.
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 5
6.3 ASCII FLOATING POINT FORMAT
6.3.1 NOTES
6.3.1.1 HHHHHHHH (H = 0-9 or A-F) indicates the 8 "nibble" ASCII-Hexadecimal representation of
a 4-Byte Floating Point number. Many data parameters are transmitted in this format.
6.3.1.2 The 32-bits are arranged as follows:
Byte
1
2
3
4
S EEE
EEEE
E MMM
MMMM
MMMM
MMMM
MMMM
MMMM
Nibble
1
2
3
4
5
6
7
8
S is the sign bit (0 if positive, 1 if negative).
EEE EEEE E represents the 2's exponent. It is a 2's complement value biased by 127 (7F
Hex). The exponent can be determined by subtracting 127 from the value of the E field and
raising 2 to the resulting power.
MMM MMMM MMMM MMMM MMMM MMMM represents the 23-bit mantissa. Since
the mantissa describes a value which is greater than or equal to 1.0 and less than 2.0, the 24th
bit is always assumed to be equal to 1 and is not transmitted or stored. The value of the
mantissa can be determined by dividing the value of the M field by 8,388,608 (223) and adding
1.0.
6.3.1.3 The complete value of the floating point number can then be determined by multiplying the
exponent by the mantissa and attaching the appropriate positive or negative sign.
6.3.1.4 By convention, 00 00 00 00 represents the value 0.0 even though it actually converts to 5.8775
x 10-39.
6.3.1.5 The eight "nibbles" are transmitted in sequence from 1 through 8 as shown in section 6.3.1.2.
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 6
6.3.2 EXAMPLES
6.3.2.1 3F800000 hex = 0011 1111 1000 0000 0000 0000 0000 0000 bin
S = 0 = + (positive)
E = 011 1111 1 bin = 7F hex = 127 dec
M = 000 0000 0000 0000 0000 0000 bin = 0 hex = 0 dec
Exponent = 2(127-127) = 1.0
Mantissa = 1.0 + (0/8,388,608) = 1.0
Decimal Value = +1.0 x 1.0 = 1.0
6.3.2.2 B8D1B717 hex = 1011 1000 1101 0001 1011 0111 0001 0111 bin
S = 1 = - (negative)
E = 011 1000 1 bin = 71 hex = 113 dec
M = 101 0001 1011 0111 0001 0111 bin = 51 B7 17 hex = 5,355,287 dec
Exponent = 2(113-127) = 0.0000610352
Mantissa = 1.0 + (5,355,287/8,388,608) = 1.63840
Decimal Value = -0.0000610352 x 1.63840 = -0.0001
6.3.2.3 C2C7FAE1 hex = 1100 0010 1100 0111 1111 1010 1110 0001 bin
S = 1 = - (negative)
E = 100 0010 1 bin = 85 hex = 133 dec
M = 100 0111 1111 1010 1110 0001 bin = 47 FA E1 hex = 4,717,281 dec
Exponent = 2(133-127) = 64
Mantissa = 1.0 + (4,717,281/8,388,608) = 1.56234
Decimal Value = -64 x 1.56234 = -99.99
6.3.2.4 461C4000 hex = 0100 0110 0001 1100 0100 0000 0000 0000 bin
S = 0 = + (positive)
E = 100 0110 0 bin = 8C hex = 140 dec
M = 001 1100 0100 0000 0000 0000 bin = 1C 40 00 hex = 1,851,392 dec
Exponent = 2(140-127) = 8,192
Mantissa = 1.0 + (1,851,392/8,388,608) = 1.22070
Decimal Value = +8,192 x 1.22070 = 10,000
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 7
7.0 FUNCTION CODES AND RESPONSE MESSAGES
All response messages are sent in a format described in previous sections. The function codes and data
fields of these message formats are described in this section. The data field response messages are
divided into the following major groupings:
Function Codes ................................................................................................................. Response Types
001 to 09B .........................................................................................................................Control Functions
101 to 132 ...................................................................................................... Operational Reports (System)
201 to 2E2 ...................................................................................................... Operational Reports (In-tank)
301 to 34C ....................................................................................................... Operational Reports (Sensor)
351 to 389 ................................................................................................. Operational Reports (Line Leak)
391 to 392 ...........................................................................................Operational Reports (Miscellaneous)
401 to 412 ................................................................................................ Operational Reports (I/O Device)
501 to 51E ........................................................................................... Setup Functions & Reports (System)
520 to 531 ........................................................................... Setup Functions & Reports (Communications)
532 to 5E2 ..................................................... Setup Functions & Reports (Warning, Alarm, & Auto-print)
601 to 683 ........................................................................................... Setup Functions & Reports (In-tank)
701 to 74E ............................................................................................ Setup Functions & Reports (Sensor)
751 to 7BC .................................................................. Setup Functions & Reports (Volumetric Line Leak)
771 to 7DC ................................................................................ Setup Functions & Reports (Pump Sensor)
774 to 7D9........................................................................ Setup Functions & Reports (Pressure Line Leak)
790 to 79F ............................................................................... Setup Functions & Reports (Reconciliation)
7A0 to 7BE ............................................................................ Setup Functions & Reports (Wireless PLLD)
7B1 to 7B6 ......................................................Setup Functions & Reports (Meter Map & Delivery Ticket)
7C4 to 7C9 .................................................................... Setup Functions & Reports (Pump Monitor Relay)
801 to 813 ..................................................................................... Setup Functions & Reports (I/O Device)
851 to 853 ...................................................................................... Setup Functions & Reports (EEPROM)
881 to 8C4 ............................................................................... Setup Functions & Reports (Miscellaneous)
901 to 908 ....................................................................................................... Diagnostic Reports (System)
A01 to A91 ....................................................................................................... Diagnostic Reports (In-tank)
B01 to B4B ...................................................................................................... Diagnostic Reports (Sensor)
B50 to B8E .................................................................................................. Diagnostic Reports (Line Leak)
B91 to BB1 .......................................................................................... Diagnostic Reports (Reconciliation)
C01 to C09 ................................................................................................................ Reconciliation Reports
C10 to C25 .......................................................................................................... Variance Analysis Reports
V00 to V12 ................................................................................................. In-Station Diagnostics (Reports)
V40 to V52 .................................................................................................... In-Station Diagnostics (Setup)
V80 to XE0 ......................................................................................... In-Station Diagnostics (Diagnostics)
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 8
Most response messages can be requested for either a single device (tank, sensor, line, etc.) or all
devices. A "TT" in the function code signifies single device number 01 through 16. When "TT" is 00, it
signifies all devices.
Typically, response messages include information on the active devices only. That is, those devices that
are connected and working. However, the system can be forced to send data on inactive devices by
using an inactive device number. In this case, if no valid data is available on a device, the message is
filled out with question marks (?) in the place of numbers.
Computer format response messages do not include any formatting characters such as carriage returns,
line feeds, spaces, nulls, labels, etc. Only those characters shown are actually included in the response
message. For convenience, the messages are shown in segments and do not actually include any line
feeds, carriage returns, etc. Also, the notes to the right and between the message lines are not included
in the messages. All number values contained in the response messages retain leading zeroes.
Display format response messages include the formatting characters shown. All message lines end with
a carriage return, line feed and six nulls. All response messages start and end with at least one blank
line.
The system function codes and response messages are described in detail in the following sections under
the major headings given above. A summary list of all function codes is given at the end of this
document.
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 9
7.1 CONTROL FUNCTIONS
Function Code: 001 Version 1
Function Type: System Reset
Command Format:
Display: <SOH>S00100
Computer: <SOH>s00100
Typical Response Message, Display Format:
<SOH>
S00100
MAR 27, 1996 4:47 PM
<ETX>
Typical Response Message, Computer Format:
<SOH>s00100YYMMDDHHmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. && - Data Termination Flag
3. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 10
Function Code: 002 Version 1
Function Type: Clear Power Reset Flag
Command Format:
Display: <SOH>S00200
Computer: <SOH>s00200
Typical Response Message, Display Format:
<SOH>
S00200
MAR 27, 1996 8:06 PM
<ETX>
Typical Response Message, Computer Format:
<SOH>s00200YYMMDDHHmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. && - Data Termination Flag
3. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 11
Function Code: 003 Version 1
Function Type: Remote Alarm Reset
Command Format:
Display: <SOH>S00300
Computer: <SOH>s00300
Typical Response Message, Display Format:
<SOH>
S00300
MAR 27, 1996 8:04 PM
<ETX>
Typical Response Message, Computer Format:
<SOH>s00300YYMMDDHHmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. && - Data Termination Flag
3. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 12
Function Code: 010 Version 14
Function Type: Cancel Autodial Computer Mode Session
Command Format:
Display: <SOH>S01000
Computer: <SOH>s01000
Typical Response Message, Display Format:
<SOH>
S01000
MAR 27, 1996 8:04 PM
<ETX>
Typical Response Message, Computer Format:
<SOH>s00300YYMMDDHHmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. && - Data Termination Flag
3. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 13
Function Code: 031 Version 10
Function Type: Confirm Clear Function
Command Format:
Display: <SOH>S03100832382
Computer: <SOH>s03100832382
Typical Response Message, Display Format:
<SOH>
S03100
MAR 29, 1996 6:27 PM
CONFIRM CLEAR COMPLETE
<ETX>
Typical Response Message, Computer Format:
<SOH>s03100YYMMDDHHmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. && - Data Termination Flag
3. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 14
Function Code: 051 Version 1
Function Type: Clear In-Tank Delivery Reports
Command Format:
Display: <SOH>S051TT
Computer: <SOH>s051TT
Typical Response Message, Display Format:
<SOH>
S051TT
MAR 29, 1996 6:27 PM
DELIVERY REPORTS ERASED
<ETX>
Typical Response Message, Computer Format:
<SOH>s051TTYYMMDDHHmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. && - Data Termination Flag
4. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 15
Function Code: 052 Version 1
Function Type: Start In-Tank Leak Detect Test
Command Format:
Display: <SOH>S052TT
Computer: <SOH>s052TT
Typical Response Message, Display Format:
<SOH>
S052TT
MAR 27, 1996 6:28 PM
TANK PRODUCT LABEL
1 UNLEADED REGULAR LEAK TEST START
TEST BY EXTERN INTERFACE
<ETX>
Typical Response Message, Computer Format:
<SOH>s052TTYYMMDDHHmmTTk&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. k - Status Flag
0=OFF
1=ON
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 16
Function Code: 053 Version 1
Function Type: Stop In-Tank Leak Detect Test
Command Format:
Display: <SOH>S053TT
Computer: <SOH>s053TT
Typical Response Message, Display Format:
<SOH>
S053TT
MAR 29, 1996 6:27 PM
TANK PRODUCT LABEL
1 REGULAR UNLEADED LEAK TEST STOP
<ETX>
Typical Response Message, Computer Format:
<SOH>s053TTYYMMDDHHmmTTk&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. k - Status Flag
0=OFF
1=ON
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 17
Function Code: 054 Version 5
Function Type: Delete CSLD Rate Table
Command Format:
Display: <SOH>S054TT149
Computer: <SOH>s054TT149
Notes:
1. TT - Tank Number (command valid for single tank only)
2. 149 - This verification code must be sent to confirm the command
Typical Response Message, Display Format:
<SOH>
S054TT
MAR 29, 1996 6:27 PM
T 1:REGULAR UNLEADED CSLD RECORDS DELETED
<ETX>
Typical Response Message, Computer Format:
<SOH>s054TTYYMMDDHHmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number
3. && - Data Termination Flag
4. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 18
Function Code: 081 Version 7
Function Type: Start Pressure Line Leak Test (3.00 GPH only in V18)
Command Format:
Display: <SOH>S081QQ149
Computer: <SOH>s081QQ149
Notes:
1. 149 - This verification code must be sent to confirm the command
Typical Response Message, Display Format:
<SOH>
S081QQ
MAR 29, 1996 6:27 PM
Q 1:REGULAR UNLEADED
STATUS: TEST COMPLETE
<ETX>
Typical Response Message, Computer Format:
<SOH>s081QQYYMMDDHHmmQQtt&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. QQ - Pressure Line Leak sensor number (Decimal, 00=All)
3. tt - Test status
00=test complete
01=dispensing
02=testing at 3.00 gal/hr
03=testing at 0.10 gal/hr
04=test aborted
05=running pump (manual test starting)
06=line lockout
07=disable alarm
08=test pending
09=testing delay
0A=pressure check
0B=testing at 0.20 gal/hr
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 19
Function Code: 082 Version 7
Function Type: Stop Pressure Line Leak Test
Command Format:
Display: <SOH>S082QQ149
Computer: <SOH>s082QQ149
Notes:
1. 149 - This verification code must be sent to confirm the command
Typical Response Message, Display Format:
<SOH>
S082QQ
MAR 29, 1996 6:27 PM
Q 1:REGULAR UNLEADED
STATUS: TEST COMPLETE
<ETX>
Typical Response Message, Computer Format:
<SOH>s082QQYYMMDDHHmmQQtt&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. QQ - Pressure Line Leak sensor number (Decimal, 00=All)
3. tt - Test status
00=test complete
01=dispensing
02=testing at 3.00 gal/hr
03=testing at 0.10 gal/hr
04=test aborted
05=running pump (manual test starting)
06=line lockout
07=disable alarm
08=test pending
09=testing delay
10=pressure check
11=testing at 0.20 gal/hr
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 20
Function Code: 083 Version 10
Function Type: Start WPLLD Line Leak Test (3.00 GPH only in V18)
Command Format:
Display: <SOH>S083WW149
Computer: <SOH>s083WW149
Notes:
1. 149 - This verification code must be sent to confirm the command
Typical Response Message, Display Format:
<SOH>
S083WW
MAR 27, 1996 3:47 PM
W 1:UNLEADED REGULAR
STATUS: TEST PENDING
<ETX>
Typical Response Message, Computer Format:
<SOH>s083WWYYMMDDHHmmWWtt&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. WW - WPLLD Line Leak sensor number (Decimal, 00=All)
3. tt - Test status
00=test complete
01=dispensing
02=testing at 3.00 gal/hr
03=testing at 0.20 gal/hr
04=test aborted
05=line lockout
06=disable alarm
07=test pending
08=test delay
09=testing at 0.10 gal/hr
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 21
Function Code: 084 Version 10
Function Type: Stop WPLLD Line Leak Test
Command Format:
Display: <SOH>S084WW149
Computer: <SOH>s084WW149
Notes:
1. 149 - This verification code must be sent to confirm the command
Typical Response Message, Display Format:
<SOH>
S084WW
MAR 27, 1996 3:48 PM
W 1:UNLEADED REGULAR
STATUS: TEST ABORTED
<ETX>
Typical Response Message, Computer Format:
<SOH>s084WWYYMMDDHHmmWWtt&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. WW - WPLLD Line Leak sensor number (Decimal, 00=All)
3. tt - Test status
00=test complete
01=dispensing
02=testing at 3.00 gal/hr
03=testing at 0.20 gal/hr
04=test aborted
05=line lockout
06=disable alarm
07=test pending
08=test delay
09=testing at 0.10 gal/hr
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 22
Function Code: 087 Version 18
Function Type: Start Pressure Line Leak Test by Type
Command Format:
Display: <SOH>S087QQ149rr
Computer: <SOH>s087QQ149rr
Notes:
1. 149 - This verification code must be sent to confirm the command
Typical Response Message, Display Format:
<SOH>
S087QQ
MAR 29, 1999 6:27 PM
Q 1:REGULAR UNLEADED
0.2 GPH SCHEDULED
STATUS: TEST COMPLETE
<ETX>
Typical Response Message, Computer Format:
<SOH>s087QQYYMMDDHHmmQQrrtt&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. QQ - Pressure Line Leak sensor number (Decimal, 00=All)
3. rr - Test Type
01=0.10 GPH
02=0.20 GPH
03=3.00 GPH
4. tt - Test status
00=test complete
01=dispensing
02=testing at 3.00 gal/hr
03=testing at 0.10 gal/hr
04=test aborted
05=running pump (manual test starting)
06=line lockout
07=disable alarm
08=test pending
09=testing delay
0A=pressure check
0B=testing at 0.20 gal/hr
5. && - Data Termination Flag
6. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 23
Function Code: 088 Version 18
Function Type: Start WPLLD Line Leak Test by Type
Command Format:
Display: <SOH>S088WW149rr
Computer: <SOH>s088WW149rr
Notes:
1. 149 - This verification code must be sent to confirm the command
Typical Response Message, Display Format:
<SOH>
S088WW
MAR 29, 1999 6:27 PM
W 1:REGULAR UNLEADED
0.2 GPH SCHEDULED
STATUS: TEST COMPLETE
<ETX>
Typical Response Message, Computer Format:
<SOH>s088WWYYMMDDHHmmWWrrtt&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. WW - WPLLD Line Leak sensor number (Decimal, 00=All)
3. rr - Test Type
01=0.10 GPH
02=0.20 GPH
03=3.00 GPH
4. tt - Test status
00=test complete
01=dispensing
02=testing at 3.00 gal/hr
03=testing at 0.20 gal/hr
04=test aborted
05=line lockout
06=disable alarm
07=test pending
08=test delay
09=testing at 0.10 gal/hr
5. && - Data Termination Flag
6. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 24
Function Code: 089 Version 19
Function Type: Pressure Line Leak Pressure Offset Reset
Command Format:
Display: <SOH>S089QQ149
Computer: <SOH>s089QQ149
Notes:
1. 149 - This verification code must be sent to confirm the command
Typical Response Message, Display Format:
<SOH>
S089QQ
JAN 1, 2000 6:27 PM
Q 1:REGULAR UNLEADED
PRESSURE OFFSET RESET
<ETX>
Typical Response Message, Computer Format:
<SOH>s089QQYYMMDDHHmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. QQ - Pressure Line Leak sensor number (Decimal, 00=All)
3. && - Data Termination Flag
4. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 25
Function Code: 090 Version 19
Function Type: WPLLD Line Leak Pressure Offset Reset
Command Format:
Display: <SOH>S090WW149
Computer: <SOH>s090WW149
Notes:
1. 149 - This verification code must be sent to confirm the command
Typical Response Message, Display Format:
<SOH>
S090WW
JAN 1, 2000 6:27 PM
W 1:REGULAR UNLEADED
PRESSURE OFFSET RESET
<ETX>
Typical Response Message, Computer Format:
<SOH>s090WWYYMMDDHHmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. WW - WPLLD Line Leak sensor number (Decimal, 00=All)
3. && - Data Termination Flag
4. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 26
Function Code: 091 Version 15
Function Type: Close Current Shift
Command Format:
Display: <SOH>S09100
Computer: <SOH>s09100
Typical Response Message, Display Format:
<SOH>
S09100
MAR 27, 1996 8:04 PM
CLOSE CURRENT SHIFT: YES
<ETX>
Typical Response Message, Computer Format:
<SOH>s09100YYMMDDHHmmff&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. ff - Close Current Shift Flag
01=If close accepted
3. && - Data Termination Flag
4. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 27
Function Code: 092 Version 23
Function Type: Start Pressure Line Leak Profile Line Test
Command Format:
Display: <SOH>S092QQ149
Computer: <SOH>s092QQ149
Notes:
1. 149 - This verification code must be sent to confirm the comand
Typical Response Message, Display Format:
<SOH>
I092QQ
NOV 14, 2001 10:15 PM
START PRESSURE LINE LEAK PROFILE LINE TEST
Q 1:UNLEADED REGULAR
STATUS: RUNNING PUMP
<ETX>
Typical Response Message, Computer Format:
<SOH>s092QQYYMMDDHHmmQQtt
QQtt&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. QQ - Pressure Line Leak Sensor Number (Decimal, 00 = all)
3. tt - Test Status
00 = TEST COMPLETE (DONE: BULK MOD 10000)
01 = TURN PUMP ON (RUNNING PUMP)
02 = PUMP ON WAIT (RUNNING PUMP)
03 = PRESSURE 1 WAIT (PUMP OFF)
04 = PRESSURE 2 WAIT (MEASURING Pxx 19.123 PSI)
05 = CALC WAIT TIME (MEASURING Pxx 19.123 PSI)
06 = PRESSURE N WAIT (MEASURING Pxx 19.123 PSI)
07 = EVALUATE PERIOD (MEASURING Pxx 19.123 PSI)
08 = TEST ABORT (ABORTED)
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 28
Function Code: 093 Version 23
Function Type: Stop Pressure Line Leak Profile Line Test
Command Format:
Display: <SOH>S093QQ149
Computer: <SOH>s093QQ149
Notes:
1. 149 - This verification code must be sent to confirm the comand
Typical Response Message, Display Format:
<SOH>
I093QQ
NOV 14, 2001 10:15 PM
STOP PRESSURE LINE LEAK PROFILE LINE TEST
Q 1:UNLEADED REGULAR
STATUS: ABORTED
<ETX>
Typical Response Message, Computer Format:
<SOH>s093QQYYMMDDHHmmQQtt
QQtt&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. QQ - Pressure Line Leak Sensor Number (Decimal, 00 = all)
3. tt - Test Status
00 = TEST COMPLETE (DONE: BULK MOD 10000)
01 = TURN PUMP ON (RUNNING PUMP)
02 = PUMP ON WAIT (RUNNING PUMP)
03 = PRESSURE 1 WAIT (PUMP OFF)
04 = PRESSURE 2 WAIT (MEASURING Pxx 19.123 PSI)
05 = CALC WAIT TIME (MEASURING Pxx 19.123 PSI)
06 = PRESSURE N WAIT (MEASURING Pxx 19.123 PSI)
07 = EVALUATE PERIOD (MEASURING Pxx 19.123 PSI)
08 = TEST ABORT (ABORTED)
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 29
Function Code: 094 Version 23
Function Type: Recalculate Pressure Line Leak Profile Bulk Modulus
Command Format:
Display: <SOH>S094QQ149
Computer: <SOH>s094QQ149
Notes:
1. 149 - This verification code must be sent to confirm the comand
Typical Response Message, Display Format:
<SOH>
I094QQ
NOV 14, 2001 10:15 PM
RECALCULATE PRESSURE LINE LEAK PROFILE LINE TEST BULK MODULUS
Q 1:UNLEADED REGULAR
STATUS: DONE: BULK MOD 10000
<ETX>
Typical Response Message, Computer Format:
<SOH>s094QQYYMMDDHHmmQQtt
QQtt&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. QQ - Pressure Line Leak Sensor Number (Decimal, 00 = all)
3. tt - Test Status
00 = TEST COMPLETE (DONE: BULK MOD 10000)
01 = TURN PUMP ON (RUNNING PUMP)
02 = PUMP ON WAIT (RUNNING PUMP)
03 = PRESSURE 1 WAIT (PUMP OFF)
04 = PRESSURE 2 WAIT (MEASURING Pxx 19.123 PSI)
05 = CALC WAIT TIME (MEASURING Pxx 19.123 PSI)
06 = PRESSURE N WAIT (MEASURING Pxx 19.123 PSI)
07 = EVALUATE PERIOD (MEASURING Pxx 19.123 PSI)
08 = TEST ABORT (ABORTED)
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 30
Function Code: 095 Version 24
Function Type: Start Vacuum Sensor Manual Test
Command Format:
Display: <SOH>S095SS149
Computer: <SOH>s095SS149
Notes:
1. 149 - This verification code must be sent to confirm the command
Typical Response Message, Display Format:
<SOH>
S095SS
FEB 14, 2004 10:15 AM
START VACUUM SENSOR MANUAL TEST
s 1:VACUUM SENSOR #1
MANUAL TEST STARTED
<ETX>
Typical Response Message, Computer Format:
<SOH>s095SSYYMMDDHHmmSStt...
SStt&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Smart Sensor Number (Decimal, 00=all)
3. tt - Manual Test Status
00=ABORTED
01=STARTED
02=PENDING
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 31
Function Code: 096 Version 24
Function Type: Stop Vacuum Sensor Manual Evacuation Test
Command Format:
Display: <SOH>S096SS149
Computer: <SOH>s096SS149
Notes:
1. 149 - This verification code must be sent to confirm the command
Typical Response Message, Display Format:
<SOH>
S096SS
FEB 14, 2004 10:15 AM
STOP VACUUM SENSOR MANUAL EVACUATION TEST
s 1:VACUUM SENSOR #1
MANUAL TEST ABORTED
<ETX>
Typical Response Message, Computer Format:
<SOH>s096SSYYMMDDHHmmSStt...
SStt&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Smart Sensor Number (Decimal, 00=all)
3. tt - Manual Test Status
00=ABORTED
01=STARTED
02=PENDING
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 32
Function Code: 097 Version 24
Function Type: Start Vacuum Sensor Evacuation Hold
Command Format:
Display: <SOH>S097SS149
Computer: <SOH>s097SS149
Notes:
1. 149 - This verification code must be sent to confirm the command
Typical Response Message, Display Format:
<SOH>
S097SS
FEB 14, 2004 10:15 AM
START VACUUM SENSOR EVACUATION HOLD
s 1:VACUUM SENSOR #1
EVAC HOLD STARTED
EVACUATION STATE: EVAC_HOLD
<ETX>
Typical Response Message, Computer Format:
<SOH>s097SSYYMMDDHHmmSSEE...
SSEE&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Smart Sensor Number (Decimal, 00=all)
3. EE - Evacuation State (Hex)
00=Vacuum Ok
01=Evacuation Pending
02=Evacuation Active
03=Evacuation Pending Manual
04=Evacuation Active Manual
05=No Vacuum
06=Evacuation Hold
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 33
Function Code: 098 Version 24
Function Type: Stop Vacuum Sensor Evacuation Hold
Command Format:
Display: <SOH>S098SS149
Computer: <SOH>s098SS149
Notes:
1. 149 - This verification code must be sent to confirm the command
Typical Response Message, Display Format:
<SOH>
S098SS
FEB 14, 2004 10:15 AM
STOP VACUUM SENSOR EVACUATION HOLD
s 1:VACUUM SENSOR #1
EVAC HOLD ABORTED
EVACUATION STATE: VACUUM OK
<ETX>
Typical Response Message, Computer Format:
<SOH>s098SSYYMMDDHHmmSSEE...
SSEE&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Smart Sensor Number (Decimal, 00=all)
3. EE - Evacuation State (Hex)
00=Vacuum Ok
01=Evacuation Pending
02=Evacuation Active
03=Evacuation Pending Manual
04=Evacuation Active Manual
05=No Vacuum
06=Evacuation Hold
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 34
Function Code: 099 Version 26
Function Type: Start Mag Sump Leak Test
Command Format:
Display: <SOH>S099ss149
Computer: <SOH>s099ss149
Notes:
1. 149 - This verification code must be sent to confirm the command
Typical Response Message, Display Format:
<SOH>
S099ss
FEB 14, 2004 10:15 AM
START MAG SUMP LEAK TEST
s 1:SUMP 1
LEAK TEST STARTED
<ETX>
Typical Response Message, Computer Format:
<SOH>s099ssYYMMDDHHmmsstt...
sstt&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. ss - Smart Sensor Number (Decimal, 00=all)
3. tt - Mag Sump Leak Test Status
00=NO TEST DATA AVAILABLE
01=LEAK TEST ABORTED
02=FILL SUMP
03=MEASURING HEIGHT
04=LEAK TEST PASSED
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 35
Function Code: 09A Version 26
Function Type: Start Mag Sump Leak Test Measuring Height Phase
Command Format:
Display: <SOH>S09Ass149
Computer: <SOH>s09Ass149
Notes:
1. 149 - This verification code must be sent to confirm the command
Typical Response Message, Display Format:
<SOH>
S09Ass
FEB 14, 2004 10:15 AM
START MAG SUMP LEAK TEST MEASURING HEIGHT PHASE
s 1:SUMP 1
STABLILITY PHASE STARTED
<ETX>
Typical Response Message, Computer Format:
<SOH>s09AssYYMMDDHHmmsstt...
sstt&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. ss - Smart Sensor Number (Decimal, 00=all)
3. tt - Mag Sump Leak Test Status
00=NO TEST DATA AVAILABLE
01=LEAK TEST ABORTED
02=FILL SUMP
03=MEASURING HEIGHT
04=LEAK TEST PASSED
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 36
Function Code: 09B Version 26
Function Type: Stop Mag Sump Leak Test
Command Format:
Display: <SOH>S09Bss149
Computer: <SOH>s09Bss149
Notes:
1. 149 - This verification code must be sent to confirm the command
Typical Response Message, Display Format:
<SOH>
S09Bss
FEB 14, 2004 10:15 AM
STOP MAG SUMP LEAK TEST
s 1:SUMP 1
LEAK TEST ABORTED
<ETX>
Typical Response Message, Computer Format:
<SOH>s09BssYYMMDDHHmmsstt...
sstt&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. ss - Smart Sensor Number (Decimal, 00=all)
3. tt - Mag Sump Leak Test Status
00=NO TEST DATA AVAILABLE
01=LEAK TEST ABORTED
02=FILL SUMP
03=MEASURING HEIGHT
04=LEAK TEST PASSED
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 37
7.2 OPERATIONAL REPORTS
7.2.1 SYSTEM REPORTS
Function Code: 101 Version 1
Function Type: System Status Report
Command Format:
Display: <SOH>I10100
Computer: <SOH>i10100
Notes:
1. This command will report all active OR unacknowledged alarms
and warnings up to the limit of 25 alarms in display format,
and 150 alarms in computer format
Typical Response Message, Display Format:
<SOH>
I10100
JUL 29, 1997 9:02 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
SYSTEM STATUS REPORT
ALL FUNCTIONS NORMAL
<ETX>
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 38
Function Code 101 Notes: (Continued)
Typical Response Message, Computer Format:
<SOH>i10100YYMMDDHHmmAANNTT...
AANNTT&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. AA - Alarm/Warning Category:
00=All Functions Normal
01=System Alarm
02=Tank Alarm
03=Liquid Sensor Alarm
04=Vapor Sensor Alarm
05=Input Alarm
06=Volumetric Line Leak Alarm
07=Groundwater Sensor Alarm
08=Type A Sensor Alarm
12=Type B Sensor Alarm
13=Universal Sensor Alarm
14=Auto-Dial Fax Alarm
18=Mechanical Dispenser Interface Alarm
19=Electronic Dispenser Interface Alarm
20=Product Alarm
21=Pressure Line Leak Alarm
26=Wireless PLLD Alarm
28=Smart Sensor Alarm
29=Modbus Alarm
30=ISD Site Alarm
31=ISD Hose Alarm
32=ISD Vapor Flow Meter Alarm
33=PMC Alarm
34=Pump Relay Monitor Alarm
35=VMCI Dispenser Interface Alarm (Version 28)
36=VMC Alarm (Version 28)
37=APM Alarm (Version 31)
99=Externally Detected Alarm (not reported by Console)
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 39
Function Code 101 Notes: (Continued)
3. NN - Alarm Type Number:
- If AA is 01 and NN is:
01=Printer out of Paper
02=Printer Error
03=EEPROM Configuration Error
04=Battery Off
05=Too Many Tanks
06=System Security Warning
07=ROM Revision Warning
08=Remote Display Communications Error
09=Autodial Error
10=Software Module Warning
11=Tank Test Shutdown Warning
12=Protective Cover Alarm
13=BIR Shift Close Pending
14=BIR Daily Close Pending
15=PC(H8) Revision Warning
16=System Self Test Error
17=System Clock Incorrect Warning
18=System Device Poll Timeout
19=Maintenance Tracker NVMem Removed
20=Maintenance Tracker Communication Module Removed
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 40
Function Code 101 Notes: (Continued)
- If AA is 02 and NN is:
01=Tank Setup Data Warning
02=Tank Leak Alarm
03=Tank High Water Alarm
04=Tank Overfill Alarm
05=Tank Low Product Alarm
06=Tank Sudden Loss Alarm
07=Tank High Product Alarm
08=Tank Invalid Fuel Level Alarm
09=Tank Probe Out Alarm
10=Tank High Water Warning
11=Tank Delivery Needed Warning
12=Tank Maximum Product Alarm
13=Tank Gross Leak Test Fail Alarm
14=Tank Periodic Leak Test Fail Alarm
15=Tank Annual Leak Test Fail Alarm
16=Tank Periodic Test Needed Warning
17=Tank Annual Test Needed Warning
18=Tank Periodic Test Needed Alarm
19=Tank Annual Test Needed Alarm
20=Tank Leak Test Active
21=Tank No CSLD Idle Time Warning
22=Tank Siphon Break Active Warning
23=Tank CSLD Rate Increase Warning
24=Tank AccuChart Calibration Warning
25=Tank HRM Reconciliation Warning
26=Tank HRM Reconciliation Alarm
27=Tank Cold Temperature Warning
28=Tank Missing Delivery Ticket Warning
29=Tank/Line Gross Leak Alarm
30=Delivery Density Warning
31=Density Warning
32=Fuel Quality Alarm
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 41
Function Code 101 Notes: (Continued)
- If AA is 03, 04, 07, 08, 12, or 13 and NN is:
02=Sensor Setup Data Warning
03=Sensor Fuel Alarm
04=Sensor Out Alarm
05=Sensor Short Alarm
06=Sensor Water Alarm
07=Sensor Water Out Alarm
08=Sensor High Liquid Alarm
09=Sensor Low Liquid Alarm
10=Sensor Liquid Warning
- If AA is 05 and NN is:
01=Input Setup Data Warning
02=Input Normal
03=Input Alarm
- If AA is 06 and NN is:
01=VLLD Setup Data Warning
02=VLLD Self Test Alarm
03=VLLD Shutdown Alarm
04=VLLD Leak Test Fail Alarm
05=VLLD Selftest Invalid Warning
06=VLLD Continuous Handle On Warning
07=VLLD Gross Line Test Fail Alarm
08=VLLD Gross Line Selftest Fail Alarm
09=VLLD Gross Pump Test Fail Alarm
10=VLLD Gross Pump Selftest Fail Alarm
11=VLLD Periodic Test Needed Warning
12=VLLD Annual Test Needed Warning
13=VLLD Periodic Test Needed Alarm
14=VLLD Annual Test Needed Alarm
15=VLLD Periodic Line Test Fail Alarm
16=VLLD Periodic Line Selftest Fail Alarm
17=VLLD Periodic Pump Test Fail Alarm
18=VLLD Periodic Pump Selftest Fail Alarm
19=VLLD Annual Line Test Fail Alarm
20=VLLD Annual Line Selftest Fail Alarm
21=VLLD Annual Pump Test Fail Alarm
22=VLLD Annual Pump Selftest Fail Alarm
23=VLLD Pressure Warning
24=VLLD Pressure Alarm
25=VLLD Gross Test Fault Alarm
26=VLLD Periodic Test Fault Alarm
27=VLLD Annual Test Fault Alarm
28=VLLD Fuel Out Alarm
- If AA is 14 and NN is:
01=Autodial Setup Data Warning
02=Autodial Failed Alarm
03=Autodial Service Report Warning (Added in V19)
04=Autodial Alarm Clear Warning (Added in V19)
05=Autodial Delivery Report Warning (Added in V19)
- If AA is 18, 19 and NN is:
02=DIM Disabled Alarm
03=DIM Communication Failure Alarm
04=DIM Transaction Alarm
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 42
Function Code 101 Notes: (Continued)
- If AA is 20 and NN is:
01=BIR Setup Data Warning
02=BIR Threshold Alarm
03=BIR Close Shift Warning
04=BIR Close Daily Warning
- If AA is 21 and NN is:
01=PLLD Setup Data Warning
02=PLLD Gross Test Fail Alarm
03=PLLD Annual Test Fail Alarm
04=PLLD Periodic Test Needed Warning
05=PLLD Periodic Test Needed Alarm
06=PLLD Sensor Open Alarm
07=PLLD High Pressure Alarm (Obsolete V19)
08=PLLD Shutdown Alarm
09=PLLD High Pressure Warning (Obsolete V19)
10=PLLD Continuous Handle On Warning (Obsolete V19)
11=PLLD Periodic Test Fail Alarm
12=PLLD Annual Test Needed Warning
13=PLLD Annual Test Needed Alarm
14=PLLD Low Pressure Alarm
15=PLLD Sensor Short Alarm (Obsolete V19)
16=PLLD Continuous Handle On Alarm
17=PLLD Fuel Out Alarm
18=PLLD Line Equipment Alarm
- If AA is 26 and NN is:
01=WPLLD Setup Data Warning
02=WPLLD Gross Test Fail Alarm
03=WPLLD Periodic Test Fail Alarm
04=WPLLD Periodic Test Needed Warning
05=WPLLD Periodic Test Needed Alarm
06=WPLLD Sensor Open Alarm
07=WPLLD Communications Alarm
08=WPLLD Shutdown Alarm
09=WPLLD Continuous Handle On Warning (Obsolete V19)
10=WPLLD Annual Test Fail Alarm
11=WPLLD Annual Test Needed Warning
12=WPLLD Annual Test Needed Alarm
13=WPLLD High Pressure Warning (Obsolete V19)
14=WPLLD High Pressure Alarm (Obsolete V19)
15=WPLLD Sensor Short Alarm (Obsolete V19)
16=WPLLD Continuous Handle On Alarm
17=WPLLD Fuel Out Alarm
18=WPLLD Line Equipment Alarm
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 43
Function Code 101 Notes: (Continued)
- If AA is 28 and NN is:
01=Smart Sensor Setup Data Warning
02=Smart Sensor Communication Alarm
03=Smart Sensor Fault Alarm
04=Smart Sensor Fuel Warning
05=Smart Sensor Fuel Alarm
06=Smart Sensor Water Warning
07=Smart Sensor Water Alarm
08=Smart Sensor High Liquid Warning
09=Smart Sensor High Liquid Alarm
10=Smart Sensor Low Liquid Warning
11=Smart Sensor Low Liquid Alarm
12=Smart Sensor Temperature Warning
13=Smart Sensor Relay Active
14=Smart Sensor Install Alarm
15=Smart Sensor Sensor Fault Warning
16=Smart Sensor Vacuum Warning
17=Smart Sensor No Vacuum Warning
- If AA is 29 and NN is:
01=Improper Setup alarm
02=Communication Loss alarm
- If AA is 30 and NN is:
01=Stage 1 Transfer Monitoring Failure warning
(ISD only)
02=Containment Monitoring Gross Failure warning
(ISD)
03=Containment Monitoring Gross Failure alarm
(ISD)
04=Containment Monitoring Degradation Failure warning
(ISD only)
05=Containment Monitoring Degradation Failure alarm
(ISD only)
06=Containment Monitoring CVLD Failure warning
(ISD)
07=Containment Monitoring CVLD Failure alarm
(ISD)
08=Vapor Processor Over Pressure Failure warning
(ISD only)
09=Vapor Processor Over Pressure Failure alarm
(ISD only)
10=Vapor Processor Status Test warning
(ISD only)
11=Vapor Processor Status Test alarm
(ISD only)
12=Missing Relay Setup alarm
(ISD only)
13=Missing Hose Setup alarm
(ISD only)
14=Missing Tank Setup alarm
(ISD)
15=Missing Vapor Flow Meter alarm
(ISD only)
16=Missing Vapor Pressure Sensor alarm
(ISD)
17=Missing Vapor Pressure Input alarm
(ISD)
18=Setup Fail warning
(ISD)
19=Setup Fail alarm
(ISD)
20=Sensor Out warning
(ISD)
21=Sensor Out alarm
(ISD)
22=PC-ISD Offline
(ISD)
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 44
Function Code 101 Notes: (Continued)
- If AA is 31 and NN is:
01=Collection Monitoring Gross Failure warning
02=Collection Monitoring Gross Failure alarm
03=Collection Monitoring Degradation Failure warning
04=Collection Monitoring Degradation Failure alarm
05=Flow Performance Hose Blockage Failure warning
06=Flow Performance Hose Blockage Failure alarm
07=Vapor Flow Meter Setup alarm
- If AA is 32 and NN is:
01=Locked rotor alarm
- If AA is 33 and NN is:
01=Vapor Processor Run Time Fault warning
02=Processor Monitoring Effluent Emissions Failure
warning
03=Processor Monitoring Effluent Emissions Failure alarm
04=Processor Monitoring Over Pressure Failure warning
05=Processor Monitoring Over Pressure Failure alarm
06=Processor Monitoring Duty Cycle Failure warning
07=Processor Monitoring Duty Cycle Failure alarm
08=PMC (stand alone mode only) Setup warning
- If AA is 34 and NN is:
01=Setup Data Warning
02=Pump Relay Alarm
- If AA is 35 and NN is:
01=Setup Data Warning
02=Disabled VMCI Alarm
03=VMC Comm Timeout Alarm (Added in V31)
- If AA is 36 and NN is:
01=VMC Comm timeout (Obsolete V31)
02=Meter Not Connected
03=FP Shutdown Warning
04=FP Shutdown Alarm
- If AA is 37 and NN is:
01=Gross Over-Pressure Test Warning
02=APM Gross Over-Pressure Test Failure warning
03=APM Gross Over-Pressure Test Failure alarm
04=APM Degradation Over-Pressure Test Failure warning
05=APM Degradation Over-Pressure Test Failure alarm
06=APM Sensor Test Failure warning
07=APM Sensor Test Failure alarm
08=APM Setup Failure warning
09=APM Sensor Out Failure warning
10=APM Sensor Out Failure alarm
- If AA is 99 and NN is:
01=Externally Dectected Communication Alarm
02=Communications - Data Reception Timeout
03=Communications - Failed Checksum
04=Communications - Parity Error
05=Modem - Line Busy
06=Modem - No Answer
07=Modem - No Carrier
08=Modem - No Dial Tone
09=Modem - Modem Error
10=Modem - Modem Not Responding
11=Modem - Port Not Available
12=Polling - Could Not Update Queue
13=Polling - Invalid Data Type Requested
4. TT - Tank/Sensor Number
5. && - Data Termination Flag
6. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 45
Function Code: 102 Version 1
Function Type: System Configuration Report
Command Format:
Display: <SOH>I10200
Computer: <SOH>i10200
Typical Response Message, Display Format:
<SOH>
I10200
JAN 22, 1996 3:05 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
SYSTEM CONFIGURATION
SLOT BOARD TYPE POWER ON RESET CURRENT
1 4 PROBE / G.T. 164040 166912
2 UNUSED 10191362 10329900
3 UNUSED 10122894 10209602
4 UNUSED 10107912 10186864
5 UNUSED 10115504 10165331
6 UNUSED 10105807 10165451
7 UNUSED 10097749 10164467
8 UNUSED 10102487 10152837
9 4 INPUT BOARD 40158 40158
10 UNUSED 15000000 15000000
11 UNUSED 15000000 15000000
12 UNUSED 15000000 15000000
13 UNUSED 15000000 15000000
14 UNUSED 15000000 15000000
15 UNUSED 15000000 15000000
16 UNUSED 15000000 15000000
COMM 1 FAXMODEM BOARD 47008 47006
COMM 2 RS232 SERIAL BD 14764 14753
COMM 3 ELEC DISP INT. 100725 100748
COMM 4 UNUSED 15000000 15000000
COMM 5 UNUSED 15000000 15000000
COMM 6 UNUSED 15000000 15000000
<ETX>
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 46
Function Code 102 Notes: (Continued)
Typical Response Message, Computer Format:
<SOH>i10200YYMMDDHHmmNNSSTTFFFFFFFFCCCCCCCC...
SSTTFFFFFFFFCCCCCCCC&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. NN - Number of Modules to Follow (Hex)
3. SS - Slot Number (Hex)
4. TT - Type of Module (Hex):
00=Not used
01=Four Probe Module
02=Vapor Sensor Module
03=Liquid Sensor Module
04=Four Relay Module
05=I/O Combo Module
06=Printer Module
07=RS-232 Module
08=Modem Module
09=Volumetric Line Leak Module
0A=Four Probe w/ Ground Temp Module
0B=Groundwater Sensor Module
0C=Type A Sensor Module
0D=Remote Display Module
10=Type B Sensor Module
11=Universal Sensor Module
12=Fax/Modem (1785) Module
13=Remote/Local Printer Module
14=Pump Sensor Module
15=European RS-232 Module
17=Eight Probe Module
18=Mechanical Dispenser Interface Module
19=Electronic Dispenser Interface Module
1A=Pressure Line Leak Sensor Module
1B=Pressure Line Leak Controller Module
1D=Remote Printer Module
1E=External Fax/Modem Module
1F=RS-485 Module
20=Wireless PLLD AC Interface Module
21=Wireless PLLD Communications Module
22=Wireless PLLD Controller Module
23=Hughes Satellite J-Box Module
24=Fax/Modem (1786) Module
25=Serial Satellite Module
26=Four Probe / Four Liquid Sensor Module
27=Four PLLD Sensor Module
28=SmartSensor(8) Module
29=RS-485 Modbus Module
2B=SmartSensor(7) Module
2C=Four Input Module (Version 26)
2D=MT Comm Module (Version 27)
2E=Pump Relay Monitor Module (Version 27)
2F=VMCI Dispenser Interface Module (Version 28)
5. FFFFFFFF - Power On Reset (ASCII Hex IEEE float)
6. CCCCCCCC - Current I/O Reading (ASCII Hex IEEE float)
7. && - Data Termination Flag
8. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 47
Function Code: 111 Version 2
Function Type: Priority Alarm History Report
Command Format:
Display: <SOH>I11100
Computer: <SOH>i11100
Typical Response Message, Display Format:
<SOH>
I11100
JUL 29, 1997 9:02 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
PRIORITY ALARM HISTORY
ID CATEGORY DESCRIPTION ALARM TYPE STATE DATE TIME
W 3 OTHER SPECIAL WPLLD SHUTDOWN ALM CLEAR 1-01-96 8:07AM
W 3 OTHER SPECIAL WPLLD SHUTDOWN ALM ALARM 1-01-96 8:06AM
SYSTEM BATTERY IS OFF CLEAR 1-01-96 8:00AM
SYSTEM BATTERY IS OFF ALARM 1-01-96 8:00AM
<ETX>
Typical Response Message, Computer Format:
<SOH>i11100YYMMDDHHmmAAccNNTTSSYYMMDDHHmm...
AAccNNTTSSYYMMDDHHmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. AA - Alarm/Warning Category:
See explanation for "AA" in Function i10100
3. cc - Sensor Category
00=Other
01=Annular
02=Dispenser Pan
03=Monitoring Well
04=STP Sump
05=Piping Sump
4. NN - Alarm Type Number:
See explanation for "NN" in Function i10100
5. TT - Tank/Sensor Number
6. SS - Alarm State
01=Alarm cleared
02=Alarm occurred
7. YYMMDDHHmm - Date/Time Alarm state occurred
8. && - Data Termination Flag
9. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 48
Function Code: 112 Version 2
Function Type: Non-Priority Alarm History Report
Command Format:
Display: <SOH>I11200
Computer: <SOH>i11200
Typical Response Message, Display Format:
<SOH>
I11200
JAN 22, 1996 3:05 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
NON-PRIORITY ALARM HISTORY
ID CATEGORY DESCRIPTION ALARM TYPE STATE DATE TIME
SYSTEM PAPER OUT CLEAR 12-20-95 12:01PM
SYSTEM PAPER OUT ALARM 12-20-95 12:00PM
T 2 TANK SPECIAL INVALID FUEL LEVEL CLEAR 12-20-95 11:59AM
T 2 TANK SPECIAL INVALID FUEL LEVEL ALARM 12-20-95 11:59AM
<ETX>
Typical Response Message, Computer Format:
<SOH>i11200YYMMDDHHmmAAccNNTTSSYYMMDDHHmm...
AAccNNTTSSYYMMDDHHmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. AA - Alarm/Warning Category:
See explanation for "AA" in Function i10100
3. cc - Sensor Category
00=Other
01=Annular
02=Dispenser Pan
03=Monitoring Well
04=STP Sump
05=Piping Sump
4. NN - Alarm Type Number:
See explanation for "NN" in Function i10100
5. TT - Tank/Sensor Number
6. SS - Alarm State
01=Alarm cleared
02=Alarm occurred
7. YYMMDDHHmm - Date/Time Alarm state occurred
8. && - Data Termination Flag
9. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 49
Function Code: 113 Version 14
Function Type: Active Alarm Report
Command Format:
Display: <SOH>I11300
Computer: <SOH>i11300
Notes:
1. This command will report ALL active alarms and warnings
regardless of their acknowledgement state. If there are
more than can be contained in the non-priority and priority
history storage areas, they will be reported here without
time and date stamps
Typical Response Message, Display Format:
<SOH>
I11300
JAN 28, 1996 10:09 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
ACTIVE ALARMS REPORT
ID CATEGORY DESCRIPTION ALARM TYPE DATE TIME
SYSTEM PAPER OUT 12-20-95 12:00PM
T 2 TANK SPECIAL INVALID FUEL LEVEL 12-20-95 11:59AM
<ETX>
Typical Response Message, Computer Format:
<SOH>i11300YYMMDDHHmma..ab..bc..cd..dAAccNNTTYYMMDDHHmm...
AAccNNTTYYMMDDHHmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. a..a - Station Header 1: 20 ASCII characters
3. b..b - Station Header 2: 20 ASCII characters
4. c..c - Station Header 3: 20 ASCII characters
5. d..d - Station Header 4: 20 ASCII characters
6. AA - Alarm/Warning Category:
See explanation for "AA" in Function i10100
7. cc - Sensor Category
00=Other
01=Annular
02=Dispenser Pan
03=Monitoring Well
04=STP Sump
05=Piping Sump
8. NN - Alarm Type Number:
See explanation for "NN" in Function i10100
9. TT - Tank/Sensor Number
10. YYMMDDHHmm - Alarm Date and Time
11. && - Data Termination Flag
12. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 50
Function Code: 114 Version 19
Function Type: Cleared Alarm Report
Command Format:
Display: <SOH>I11400
Computer: <SOH>i11400
Typical Response Message, Display Format:
<SOH>
I11400
JAN 28, 1996 10:09 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
CLEARED ALARMS REPORT
ID CATEGORY DESCRIPTION ALARM TYPE STATE DATE TIME
T 4 TANK PRODUCT 4 PROBE OUT CLEAR 1-02-96 4:10AM
T 1 TANK PRODUCT 1 INVALID FUEL LEVEL CLEAR 1-02-96 1:12AM
SYSTEM PAPER OUT CLEAR 1-02-96 1:09AM
<ETX>
Typical Response Message, Computer Format:
<SOH>i11400YYMMDDHHmma..ab..bc..cd..dAAccNNTTSSYYMMDDHHmm...
AAccNNTTSSYYMMDDHHmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. a..a - Station Header 1: 20 ASCII characters
3. b..b - Station Header 2: 20 ASCII characters
4. c..c - Station Header 3: 20 ASCII characters
5. d..d - Station Header 4: 20 ASCII characters
6. AA - Alarm/Warning Category:
See explanation for "AA" in Function i10100
7. cc - Sensor Category
00=Other
01=Annular
02=Dispenser Pan
03=Monitoring Well
04=STP Sump
05=Piping Sump
8. NN - Alarm Type Number:
See explanation for "NN" in Function i10100
9. TT - Tank/Sensor Number
10. SS - Alarm State
01=Alarm cleared
02=Alarm occurred
11. YYMMDDHHmm - Clear Alarm Date and Time
12. && - Data Termination Flag
13. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 51
Function Code: 115 Version 27
Function Type: Maintenance Tracker Unacknowledged Alarm Report
Command Format:
Display: <SOH>I11500
Computer: <SOH>i11500
Typical Response Message, Display Format:
<SOH>
I11500
JUL 29, 2006 3:05 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
MAINTENANCE TRACKER UNACKNOWLEDGED ALARM REPORT
ID CATEGORY DESCRIPTION ALARM TYPE DATE TIME
L12 OTHER LIQUID SENS 12 SENSOR OUT 7-08-06 11:12AM
L 1 OTHER LIQUID SENS 1 SENSOR OUT 7-08-06 10:10AM
<ETX>
Typical Response Message, Computer Format:
<SOH>i11500YYMMDDHHmma..ab..bc..cd..dAAccNNTTYYMMDDHHmm...
AaccNNTTYYMMDDHHmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. a..a - Station Header 1: 20 ASCII characters
3. b..b - Station Header 2: 20 ASCII characters
4. c..c - Station Header 3: 20 ASCII characters
5. d..d - Station Header 4: 20 ASCII characters
6. AA - Alarm/Warning Category:
See explanation for "AA" in Function i10100
7. cc - Sensor Category
00=Other
01=Annular
02=Dispenser Pan
03=Monitoring Well
04=STP Sump
05=Piping Sump
8. NN - Alarm Type Number:
See explanation for "NN" in Function i10100
9. TT - Tank/Sensor Number
10. YYMMDDHHmm - Maintenance Tracker Alarm Active Date and Time
11. && - Data Termination Flag
12. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 52
Function Code: 116 Version 19 (Obsolete V27)
Function Type: Service Report History
Command Format:
Display: <SOH>I11600
Computer: <SOH>i11600
Typical Response Message, Display Format:
<SOH>
I11600
MAR 26, 1996 1:47 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
SERVICE REPORT
DATE/TIME ID CODE
MAR 29, 1996 8:50 AM 1234567890 12345
MAR 28, 1996 8:50 AM 3482221100 EABC2
FEB 26, 1996 8:15 AM 3482221100 12345
JAN 25, 1996 2:20 PM 3482221100 Z1234
JAN 23, 1996 1:48 PM 3482221100 12345
<ETX>
Typical Response Message, Computer Format:
<SOH>i11600YYMMDDHHmma..ab..bc..cd..dNNYYMMDDHHmmiiiiiiiiiiccccc...
YYMMDDHHmmiiiiiiiiiiccccc&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. a..a - Station Header 1: 20 ASCII characters
3. b..b - Station Header 2: 20 ASCII characters
4. c..c - Station Header 3: 20 ASCII characters
5. d..d - Station Header 4: 20 ASCII characters
6. NN - Number of Records to follow (Decimal)
7. YYMMDDHHmm - Date and Time of entry
8. iiiiiiiiii - Service ID entered by Service Contractor (10 alpha/numeric)
9. ccccc - Service Code entered by Service Contractor (5 alpha/numeric)
10. && - Data Termination Flag
11. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 53
Function Code: 119 Version 27
Function Type: Maintenance History Report
Command Format:
Display: <SOH>I11900YYMMDDYYMMDD OR <SOH>I11900
Computer: <SOH>i11900YYMMDDYYMMDD OR <SOH>i11900
Notes:
1. YYMMDD - Requested Start Date (year, month, day).
2. YYMMDD - Requested End Date (year, month, day).
3. - If the dates are not specified, the most recent 20 records
are returned.
Typical Response Message, Display Format:
<SOH>
I11900
MAR 26, 2006 1:47 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
MAINTENANCE HISTORY
TYPE DATE/TIME DESCRIPTION
LOGOUT JAN 09, 2006 11:50 AM J SMITH A12345
SERVICE CODE JAN 09, 2006 10:27 AM COLD BOOT SYSTEM 1203
SERVICE CODE JAN 09, 2006 9:55 AM INSTALLED PAPER 1211
ALARM ACKNOWLEDGED JAN 09, 2006 8:52 AM L12:SENSOR OUT ALARM
ALARM ACKNOWLEDGED JAN 09, 2006 8:52 AM L 1:SENSOR OUT ALARM
LOGIN JAN 09, 2006 8:50 AM J SMITH A12345
ALARM CLEAR JAN 08, 2006 7:31 AM L12:SENSOR OUT ALARM
ALARM CLEAR JAN 08, 2006 7:30 AM L 1:SENSOR OUT ALARM
ALARM ACTIVE JAN 08, 2006 6:52 AM L12:SENSOR OUT ALARM
ALARM ACTIVE JAN 08, 2006 6:50 AM L 1:SENSOR OUT ALARM
MTC ERR JAN 05, 2006 8:30 PM
ALARM CLEAR JAN 03, 2006 8:30 AM L 1:SENSOR OUT ALARM
ALARM ACTIVE JAN 03, 2006 6:25 AM L 1:SENSOR OUT ALARM
HISTORY DISABLED JAN 02, 2006 7:25 PM
VLLD TEST JAN 02, 2006 6:25 PM P 1 0.2 GPH TEST PASS
WPLLD TEST JAN 02, 2006 3:45 PM W 1 0.2 GPH TEST PASS
PLLD TEST JAN 02, 2006 1:45 PM Q 1 0.2 GPH TEST PASS
TANK TEST JAN 02, 2006 10:28 AM T 1 PERIODIC TEST PASS
HISTORY ENABLED JAN 01, 2006 6:25 AM
<ETX>
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 54
Function Code 119 Notes: (Continued)
Typical Response Message, Computer Format:
<SOH>i11900YYMMDDHHmmNNNNNYYMMDDHHmmttXXXXXXYYMMDDHHmmttXXXXXX...
YYMMDDHHmmttXXXXXX&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. NNNNN - Number of records to Follow (Decimal)
3. YYMMDDHHmm - Date/time of record
4. tt - Record type (Hex)
01=Maintenance History Enabled
02=Maintenance History Disabled
03=Maintenance Tracker Login
04=Maintenance Tracker Logout
05=Maintenance Tracker Remote Login
06=Maintenance Tracker Remote Logout
07=Maintenance Alarm Active
08=Maintenance Alarm Inactive
09=Maintenance Alarm Acknowledge
0A=Maintenance Alarm Remote Acknowledge
0B=Service Code
0C=Tank Test, 0.20 Gal/Hr Fullest Monthly
0D=PLLD Test, 0.20 Gal/Hr Latest Monthly
0E=WPLLD Test, 0.20 Gal/Hr Latest Monthly
0F=MT Comm Card Removed
10=VLLD Test, 0.20 Gal/Hr Latest Monthly
5. XXXXXX - Six digit data field:
000000= place filler (unused) for types 01, 02
iiiiii= login ID code for types 03, 04, 05, 06 (ASCII,
padded with leading zeros)
ddttnn= Alarm device #, type, and alarm number for types
07, 08, 09, 0A (Decimal)
00cccc= Four digit service code for type 0B (Decimal,
padded with leading zeros)
0000tt= Device # for types 0C, 0D, 0E (Decimal, padded
with leading zeros)
000000= Place filler (unused) for type 0F
6. && - Data Termination Flag
7. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 55
Function Code: 11A Version 27
Function Type: Service Report History
Command Format:
Display: <SOH>I11A00
Computer: <SOH>i11A00
Typical Response Message, Display Format:
<SOH>
I11A00
MAR 26, 2006 1:47 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
SERVICE REPORT
DATE/TIME LABEL ID LABEL CODE
MAR 29, 2006 8:50 AM J DOE A12345 INSTALLED PAPER 1211
MAR 28, 2006 8:50 AM D SMITH A34822 CLEARED PAPER JAM 0204
FEB 26, 2006 8:15 AM D SMITH A34822 RECONNECT PHONE LN 0503
JAN 25, 2006 2:20 PM D SMITH A34822 REPLACED PROBE 0304
JAN 23, 2006 1:48 PM D SMITH A34822 FIX STUCK FLOAT 0305
<ETX>
Typical Response Message, Computer Format:
<SOH>i11A00YYMMDDHHmmNNYYMMDDHHmmiiiiiicccc...
YYMMDDHHmmiiiiiicccc&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. NN - Number of Records to follow (Decimal)
3. YYMMDDHHmm - Date and Time of entry
4. iiiiii - Service ID entered by Service Contractor (6 alpha/numeric)
5. cccc - Service Code entered by Service Contractor (4 numeric)
6. && - Data Termination Flag
7. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 56
Function Code: 11B Version 28
Function Type: Service Notice Session Report
Command Format:
Display: <SOH>I11B00
Computer: <SOH>i11B00
Typical Response Message, Display Format:
<SOH>
I11B00
APR 10, 2007 3:05 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
SERVICE NOTICE SESSION REPORT
START TIME END TIME
APR 10, 2007 8:00 AM IN PROGRESS
APR 9, 2007 8:10 AM APR 9, 2007 9:10 AM
APR 8, 2007 8:05 AM APR 8, 2007 8:45 AM
<ETX>
Typical Response Message, Computer Format:
<SOH>i11B00YYMMDDHHmmfYYMMDDHHmmNNYYMMDDHHmmYYMMDDHHmm...
YYMMDDHHmmYYMMDDHHmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. f - Service Notice Session Enable
0 = Disabled
1 = Enabled
3. YYMMDDHHmm - Start Date and Time
- if Service Notice Session Enable = 0 (Disabled) then
Start Date/Time is invalid
- if Service Notice Session Enable = 1 (Enabled) then Start
Date/Time is valid
4. NN - Number of Service Notice Session Start/End records to follow
(Hex)
5. YYMMDDHHmm - Start Date and Time
6. YYMMDDHHmm - End Date and Time
7. && - Data Termination Flag
8. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 57
Function Code: 132 Version 32
Function Type: Fiscal Height Security Report
Command Format:
Display: <SOH>I13200
Computer: <SOH>i13200
Typical Response Message, Display Format:
<SOH>
I13200
APR 1, 2011 8:03 AM
FISCALLY SEALED : NO
FISCAL HEIGHT SECURITY : DISABLED
FISCAL HEIGHT SECURITY SWITCH : OFF
<ETX>
Typical Response Message, Computer Format:
<SOH>i13200YYMMDDHHmmsfp&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. s - Is Fiscally Sealed
0=No
1=Yes
3. f - Fiscal Height Security Enable/Disable Flag
0=Disabled
1=Enabled
4. p - Fiscal Height Security Switch Position
0=Off
1=On
5. && - Data Termination Flag
6. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 58
7.2.2 IN-TANK REPORTS
Function Code: 201 Version 1
Function Type: In-Tank Inventory Report
Command Format:
Display: <SOH>I201TT
Computer: <SOH>i201TT
Typical Response Message, Display Format:
<SOH>
I201TT
JAN 22, 1996 3:06 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
TANK PRODUCT VOLUME TC VOLUME ULLAGE HEIGHT WATER TEMP
1 REGULAR UNLEADED 5329 5413 4699 48.97 0.00 37.39
<ETX>
Typical Response Message, Computer Format:
<SOH>i201TTYYMMDDHHmmTTpssssNNFFFFFFFF...
TTpssssNNFFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. p - Product Code (one ASCII character [20h-7Eh])
4. ssss - Tank Status Bits:
Bit 1 - (LSB) Delivery in Progress
Bit 2 - Leak Test in Progress
Bit 3 - Invalid Fuel Height Alarm (MAG Probes Only)
Bit 4-16 - Unused
5. NN - Number of eight character Data Fields to follow (Hex)
6. FFFFFFFF - ASCII Hex IEEE floats:
1. Volume
2. TC Volume
3. Ullage
4. Height
5. Water
6. Temperature
7. Water Volume
7. && - Data Termination Flag
8. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 59
Function Code: 202 Version 1
Function Type: In-Tank Delivery Report
Command Format:
Display: <SOH>I202TT
Computer: <SOH>i202TT
Typical Response Message, Display Format:
<SOH>
I202TT
JUL 29, 1997 9:02 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
DELIVERY REPORT
T 1:REGULAR UNLEADED
INCREASE DATE / TIME GALLONS TC GALLONS WATER TEMP DEG F HEIGHT
END: JUL 28, 1997 3:14 PM 3231 3194 0.00 76.14 48.27
START: JUL 28, 1997 3:05 PM 1244 1231 0.00 73.89 24.40
AMOUNT: 1987 1963
END: JUL 25, 1997 2:48 PM 4460 4414 0.00 74.56 63.06
START: JUL 25, 1997 2:37 PM 1157 1146 0.00 72.85 23.22
AMOUNT: 3303 3268
<ETX>
Typical Response Message, Computer Format:
<SOH>i202TTYYMMDDHHmmTTpddYYMMDDHHmmYYMMDDHHmmNNFFFFFFFF...
TTpddYYMMDDHHmmYYMMDDHHmmNNFFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. p - Product Code (one ASCII character [20h-7Eh])
4. dd - Number of Deliveries to follow (Decimal, 00 if no data
available for this tank)
5. YYMMDDHHmm - Starting Date/Time
6. YYMMDDHHmm - Ending Date/Time
7. NN - Number of eight character Data Fields to follow (Hex)
8. FFFFFFFF - ASCII Hex IEEE floats:
1. Starting Volume
2. Starting TC Volume
3. Starting Water
4. Starting Temp
5. Ending Volume
6. Ending TC Volume
7. Ending Water
8. Ending Temp
9. Starting Height
10. Ending Height
9. && - Data Termination Flag
10. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 60
Function Code: 203 Version 1
Function Type: In-Tank Leak Detect Report
Command Format:
Display: <SOH>I203TT
Computer: <SOH>i203TT
Typical Response Message, Display Format:
<SOH>
I203TT
JAN 22, 1996 3:06 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
TANK 1 REGULAR UNLEADED
TEST STATUS: OFF 0.2 GAL/HR TEST PASS
TEST START TIME: OCT 22, 1991 10:30 PM DURATION: 7 HOURS
START TEMP: 58.7 DEG F START VOLUME: 2123 GALLONS
ENDING TEMP: 58.1 DEG F LEAK RATE: -0.01 GALLONS/HR
CUMULATIVE PERIODIC VOLUME CHANGE (GALLONS):
-0.01 -0.02 -0.01 -0.03 -0.05 -0.04
<ETX>
Typical Response Message, Computer Format:
<SOH>i203TTYYMMDDHHmmTTpYYMMDDHHmmHHNNFFFFFFFF...
TTpYYMMDDHHmmHHNNFFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. p - Product Code (one ASCII character [20h-7Eh])
4. YYMMDDHHmm - Starting Date/Time
5. HH - Test Duration (hours)
6. NN - Number of eight character Data Fields to follow (Hex)
7. FFFFFFFF - ASCII Hex IEEE floats:
1. Starting Temp
2. Ending Temp
3. Starting Volume
4. Ending Rate
5. Hourly changes up to the number of fields
8. && - Data Termination Flag
9. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 61
Function Code: 204 Version 1
Function Type: In-Tank Shift Inventory Report
Command Format:
Display: <SOH>I204TT
Computer: <SOH>i204TT
Typical Response Message, Display Format:
<SOH>
I204TT
JAN 22, 1996 3:06 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
TANK PRODUCT
1 REGULAR UNLEADED VOLUME TC VOLUME ULLAGE HEIGHT WATER TEMP
SHIFT 1 STARTING VALUES 8518 8492 1482 76.26 0.00 64.57
ENDING VALUES 8518 8492 1482 76.26 0.00 64.57
DELIVERY VALUE 0
TOTALS 0
SHIFT 2 STARTING VALUES 8518 8492 1482 76.26 0.00 64.57
ENDING VALUES 8518 8492 1482 76.26 0.00 64.57
DELIVERY VALUE 0
TOTALS 0
<ETX>
Typical Response Message, Computer Format:
<SOH>i204TTYYMMDDHHmmTTpssNNFFFFFFFF...
TTpssNNFFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. p - Product Code (one ASCII character [20h-7Eh])
4. ss - Shift Number 01, 02, 03
5. NN - Number of eight character Data Fields to follow (Hex)
6. FFFFFFFF - ASCII Hex IEEE floats:
1. Start Volume
2. Start Ullage
3. Start TC Volume
4. Start Height
5. Start Water
6. Start Temperature
7. End Volume
8. End Ullage
9. End TC Volume
A. End Height
B. End Water
C. End Temperature
D. Total Value
7. && - Data Termination Flag
8. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 62
Function Code: 205 Version 1
Function Type: In-Tank Status Report
Command Format:
Display: <SOH>I205TT
Computer: <SOH>i205TT
Typical Response Message, Display Format:
<SOH>
I205TT
JAN 22, 1996 3:07 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
TANK PRODUCT STATUS
1 REGULAR UNLEADED NORMAL
<ETX>
Typical Response Message, Computer Format:
<SOH>i205TTYYMMDDHHmmTTnnNN...
TTnnNN&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. nn - Number of alarms active for tank (Hex, 00=none)
4. NN - Alarm Type Number:
See explanation for "NN" when "AA" is 02 in Function i10100
5. && - Data Termination Flag
6. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 63
Function Code: 206 Version 1
Function Type: In-Tank Alarm History Report
Command Format:
Display: <SOH>I206TT
Computer: <SOH>i206TT
Typical Response Message, Display Format:
<SOH>
I206TT
JAN 22, 1996 3:07 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
TANK ALARM HISTORY
TANK 1 REGULAR UNLEADED
LOW PRODUCT ALARM DEC 22, 1995 3:31 PM
DEC 19, 1995 10:05 AM
INVALID FUEL LEVEL DEC 20, 1995 11:59 AM
DEC 20, 1995 11:58 AM
DEC 20, 1995 11:57 AM
<ETX>
Typical Response Message, Computer Format:
<SOH>i206TTYYMMDDHHmmTTnnYYMMDDHHmmaaaa...
TTnnYYMMDDHHmmaaaa&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. nn - Number of alarms in history for tank (Decimal, 00=none)
4. YYMMDDHHmm - Date and time alarm occurred
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 64
Function Code 206 Notes: (Continued)
5. aaaa - Type of alarm:
0001=Tank Setup Data Warning
0002=Tank Leak Alarm
0003=Tank High Water Alarm
0004=Tank Overfill Alarm
0005=Tank Low Product Alarm
0006=Tank Sudden Loss Alarm
0007=Tank High Product Alarm
0008=Tank Invalid Fuel Level Alarm
0009=Tank Probe Out Alarm
000A=Tank High Water Warning
000B=Tank Delivery Needed Warning
000C=Tank Maximum Product Alarm
000D=Tank Gross Leak Test Fail Alarm
000E=Tank Periodic Leak Test Fail Alarm
000F=Tank Annual Leak Test Fail Alarm
0010=Tank Periodic Test Needed Warning
0011=Tank Annual Test Needed Warning
0012=Tank Periodic Test Needed Alarm
0013=Tank Annual Test Needed Alarm
0014=Tank Leak Test Active
0015=Tank No CSLD Idle Time Warning
0016=Tank Siphon Break Active Warning
0017=Tank CSLD Rate Increase Warning
0018=Tank AccuChart Calibration Warning
0019=Tank HRM Reconciliation Warning
001A=Tank HRM Reconciliation Alarm
001B=Tank Cold Temperature Warning
001C=Tank Missing Delivery Ticket Warning
001D=Tank/Line Gross Leak Alarm
6. && - Data Termination Flag
7. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 65
Function Code: 207 Version 2
Function Type: In-Tank Leak Test History Report
Command Format:
Display: <SOH>I207TT
Computer: <SOH>i207TT
Typical Response Message, Display Format:
<SOH>
I207TT
JUL 29, 1997 9:02 AM
TANK LEAK TEST HISTORY
T 1:REGULAR UNLEADED
LAST GROSS TEST PASSED:
TEST START TIME HOURS VOLUME % VOLUME TEST TYPE
JUL 29, 1997 6:02 AM 2821 48.9 STANDARD
LAST ANNUAL TEST PASSED:
NO TEST PASSED
FULLEST ANNUAL TEST PASS
NO TEST PASSED
LAST PERIODIC TEST PASS:
TEST START TIME HOURS VOLUME % VOLUME TEST TYPE
JUL 29, 1997 4:15 AM 27 2680 46.4 CSLD
FULLEST PERIODIC TEST
PASSED EACH MONTH:
TEST START TIME HOURS VOLUME % VOLUME TEST TYPE
JUL 20, 1997 1:52 AM 25 2916 50.5 CSLD
<ETX>
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 66
Function Code 207 Notes: (Continued)
Typical Response Message, Computer Format:
<SOH>i207TTYYMMDDHHmmTTNNRRnnttYYMMDDHHmmhhhhhhhhVVVVVVVVpppppppp...
TTNNRRnnttYYMMDDHHmmhhhhhhhhVVVVVVVVpppppppp&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. NN - Number of Leak History Reports to Follow (Hex)
4. RR - Leak Report Type:
00=Last Test Passed
01=Fullest Test Passed
02=Fullest Periodic Monthly Test Passed
5. nn - Leak History Number (1-12) for first Monthly Tests Passed
6. tt - In-Tank Leak Test Type:
00=0.20 gal/hr test
01=0.10 gal/hr test
02=Gross (3 gal/hr)test
7. YYMMDDHHmm - In-Tank Leak Test Start Time
8. hhhhhhhh - Leak Test Duration in Hours (ASCII Hex IEEE float)
9. VVVVVVVV - Leak Test Volume (ASCII Hex IEEE float)
10. pppppppp - Leak Test Percentage of Full Volume (ASCII Hex IEEE float)
11. && - Data Termination Flag
12. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 67
Function Code: 208 Version 2
Function Type: In-Tank Leak Test Results Report
Command Format:
Display: <SOH>I208TT
Computer: <SOH>i208TT
Typical Response Message, Display Format:
<SOH>
I208TT
JAN 22, 1996 3:07 PM
PREVIOUS IN TANK LEAK TEST RESULTS
TANK 1 REGULAR UNLEADED
TEST TYPE START TIME RESULT RATE HOURS VOLUME
ANNUAL NOV 21, 1995 8:34 AM PASSED 0.00 12 9088
PERIODIC NOV 21, 1995 8:34 AM PASSED 0.00 12 9088
GROSS NOV 24, 1995 8:04 AM PASSED 0.00 9088
<ETX>
Typical Response Message, Computer Format:
<SOH>i208TTYYMMDDHHmmTTNNttmmYYMMDDHHmmRRrrrrrrrrhhhhhhhhVVVVVVVV...
TTNNttmmYYMMDDHHmmRRrrrrrrrrhhhhhhhhVVVVVVVV&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. NN - Number of Results to Follow (Hex)
4. tt - In-Tank Leak Test Result Type:
00=0.20 gal/hr Test
01=0.10 gal/hr Test
02=Gross (3 gal/hr) Test
5. mm - In-Tank Leak Manifold Status:
00=Tank Not Manifolded During Leak Test
01=Tank Manifolded During Leak Test
6. YYMMDDHHmm - Previous In-Tank Leak Test Start Time
7. RR - Previous In-Tank Leak Test Result:
00=Test Invalid
01=Test Passed
02=Test Failed
8. rrrrrrrr - Test Rate (ASCII Hex IEEE float)
9. hhhhhhhh - Leak Test Duration in Hours (ASCII Hex IEEE float)
10. VVVVVVVV - Leak Test Volume (ASCII Hex IEEE float)
11. && - Data Termination Flag
12. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 68
Function Code: 20A Version 110
Function Type: HRM Adjusted Delivery Report
Command Format:
Display: <SOH>I20ATT
Computer: <SOH>i20ATT
Typical Response Message, Display Format:
<SOH>
I20ATT
JAN 22, 1996 3:08 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
ADJUSTED DELIVERY REPORT
T 1:REGULAR UNLEADED
INCREASE INCREASE DELIVERY DELIVERY
INCREASE DATE/TIME VOLUME TC VOLUME ADJUSTMENT VOLUME TC VOLUME
JAN 13, 1996 2:06 AM 3795 3859 8 3803 3868
JAN 15, 1996 1:07 PM 5383 5458 30 5413 5487
JAN 17, 1996 3:13 AM 6012 6114 -1 6010 6113
JAN 19, 1996 3:22 AM 4413 4480 -3 4409 4473
JAN 21, 1996 2:52 AM 6005 6112 6 6011 6119
<ETX>
Typical Response Message, Computer Format:
<SOH>i20A00YYMMDDHHmmTTpPPrrYYMMDDHHmmNNFFFFFFFF...
TTpPPrrYYMMDDHHmmNNFFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. p - Product Code (one ASCII character [20h-7Eh])
4. PP - Probe Type
5. rr - Number of Records to follow (Decimal)
6. YYMMDDHHmm - Date/Time of Delivery Start
7. NN - Number of eight character Data Fields to follow (Hex)
8. FFFFFFFF - ASCII Hex IEEE floats:
1. Increase Volume
2. Increase Temp Comp Volume
3. Adjustment factor
4. Adjusted Increase Value
5. Adjusted Temp Comp Volume
9. && - Data Termination Flag
10. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 69
Function Code: 20B Version 110
Function Type: BIR Adjusted Delivery Report
Command Format:
Display: <SOH>I20BTT
Computer: <SOH>i20BTT
Typical Response Message, Display Format:
<SOH>
I20BTT
JAN 22, 1996 3:08 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
BIR ADJUSTED DELIVERY REPORT
T 1:REGULAR UNLEADED
START END ADJ ADJ TC
DELIVERY START DATE DELIVERY END DATE VOLUME VOLUME DELIV DELIV
JAN 21, 1996 2:52 AM JAN 21, 1996 3:12 AM 3193 9197 6011 6119
JAN 19, 1996 3:22 AM JAN 19, 1996 3:40 AM 4193 8602 4409 4473
JAN 17, 1996 3:13 AM JAN 17, 1996 3:40 AM 2739 8749 6010 6113
<ETX>
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 70
Function Code 20B Notes: (Continued)
Typical Response Message, Computer Format:
<SOH>i20BTTYYMMDDHHmmTTddYYMMDDHHmmYYMMDDHHmmNNFFFFFFFF...
TTddYYMMDDHHmmYYMMDDHHmmNNFFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=All)
3. dd - Number of Deliveries to follow
4. YYMMDDHHmm - Starting Date/Time
5. YYMMDDHHmm - Ending Date/Time
6. NN - Number of eight character Data Fields to follow (Hex)
7. FFFFFFFF - ASCII Hex IEEE floats:
1. Starting Volume
2. Ending Volume
3. Adjusted Delivery Volume
4. Adjusted Temperature Compensated Delivery Volume
5. Starting Fuel Height
6. Starting Fuel Temperature 1
7. Starting Fuel Temperature 2
8. Starting Fuel Temperature 3
9. Starting Fuel Temperature 4
10. Starting Fuel Temperature 5
11. Starting Fuel Temperature 6
12. Ending Fuel Height
13. Ending Fuel Temperature 1
14. Ending Fuel Temperature 2
15. Ending Fuel Temperature 3
16. Ending Fuel Temperature 4
17. Ending Fuel Temperature 5
18. Ending Fuel Temperature 6
19. Total Dispensed During Delivery
20. Starting Fuel Temperature Average
21. Ending Fuel Temperature Average
8. && - Data Termination Flag
9. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 71
Function Code: 20C Version 15
Function Type: In-Tank Most Recent Delivery Report
Command Format:
Display: <SOH>I20CTT
Computer: <SOH>i20CTT
Typical Response Message, Display Format:
<SOH>
I20CTT
JUL 29, 1997 9:03 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
LAST DELIVERY REPORT
T 1:REGULAR UNLEADED
INCREASE DATE / TIME GALLONS TC GALLONS WATER TEMP DEG F HEIGHT
END: JUL 28, 1997 3:14 PM 3231 3194 0.00 76.14 48.27
START: JUL 28, 1997 3:05 PM 1244 1231 0.00 73.89 24.40
AMOUNT: 1987 1963
<ETX>
Typical Response Message, Computer Format:
<SOH>i20CTTYYMMDDHHmmTTpddYYMMDDHHmmYYMMDDHHmmNNFFFFFFFF...
TTpddYYMMDDHHmmYYMMDDHHmmNNFFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. p - Product Code (one ASCII character [20h-7Eh])
4. dd - Number of Deliveries to follow (Decimal, 00 if no data
available for this tank)
5. YYMMDDHHmm - Starting Date/Time
6. YYMMDDHHmm - Ending Date/Time
7. NN - Number of eight character Data Fields to follow (Hex)
8. FFFFFFFF - ASCII Hex IEEE floats:
1. Starting Volume
2. Starting TC Volume
3. Starting Water
4. Starting Temp
5. Ending Volume
6. Ending TC Volume
7. Ending Water
8. Ending Temp
9. Starting Height
10. Ending Height
9. && - Data Termination Flag
10. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 72
Function Code: 20D Version 15
Function Type: In-Tank Stick Height Report
Command Format:
Display: <SOH>I20DTT
Computer: <SOH>i20DTT
Notes:
1. This command will respond only if stick height is enabled.
Tank stick height is fuel height (without tilt) + stick
offset. If the stick height is less then zero, it will be
set to zero. If the stick height is greater than tank
diameter, it will be set to tank diameter.
Typical Response Message, Display Format:
<SOH>
I20DTT
OCT 15, 1996 4:29 PM
TANK STICK HEIGHT
TANK PRODUCT LABEL INCHES
1 REGULAR 25.0
2 MIDGRADE 67.5
3 SUPER 66.1
<ETX>
Typical Response Message, Computer Format:
<SOH>i20DTTYYMMDDHHmmTTFFFFFFFF...
TTFFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. FFFFFFFF - Stick Height (ASCII Hex IEEE float)
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 73
Function Code: 211 Version 14
Function Type: Tank Chart Report
Command Format:
Display: <SOH>I211TThhhhhh
Computer: <SOH>i211TTFFFFFFFF
Notes:
1. TT - Tank number, 00=All tanks
2. hhhhh - height step size (inches or millimeters). Up to 6 decimal
digits. If less then 6 digits are entered, use carriage
return to terminate the command.
3. FFFFFFFF - height step size (ASCII Hex IEEE float)
Minimum Step Size:0.010 inches or 0.397 millimeter
Minimum Resolution: 3 decimal places
Typical Response Message, Display Format:
<SOH>
I21101
OCT 15, 1996 4:29 PM
STATION HEADER 1.... TANK 1
STATION HEADER 2.... TANK CALIBRATION CHART REGULAR UNLEADED
STATION HEADER 3.... 10028 GALLONS
STATION HEADER 4.... 96.00 INCHES
DEPTH CAPACITY DEPTH CAPACITY DEPTH CAPACITY DEPTH CAPACITY
INCHES GALLONS INCHES GALLONS INCHES GALLONS INCHES GALLONS
-----------------------------------------------------------------------------
0.000 0 26.000 2413 52.000 5827 78.100 9021
0.500 69 26.500 2474 52.500 5894 78.500 9073
1.000 90 27.000 2535 53.000 5961 79.000 9123
1.500 114 27.500 2596 53.500 6028 79.500 9173
:
:
<ETX>
Typical Response Message, Computer Format:
<SOH>i211TTYYMMDDHHmmTTnnnnaaaaaaaaAAAAAAAAbbbbbbbbBBBBBBBB...
TTnnnnaaaaaaaaAAAAAAAAbbbbbbbbBBBBBBBB&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. nnnn - Number of eight character Data Fields to follow (Hex)
4. aaaaaaaa - Height 1 (ASCII Hex IEEE float)
5. AAAAAAAA - Volume 1 (ASCII Hex IEEE float)
6. bbbbbbbb - Height 2 (ASCII Hex IEEE float)
7. BBBBBBBB - Volume 2 (ASCII Hex IEEE float)
8. && - Data Termination Flag
9. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 74
Function Code: 212 Version 24
Function Type: In-Tank Leak Test History Report 2
Command Format:
Display: <SOH>I212TT
Computer: <SOH>i212TT
Typical Response Message, Display Format:
<SOH>
I212TT
JUL 29, 1997 9:02 AM
TANK LEAK TEST HISTORY
T 1:REGULAR UNLEADED
LAST GROSS TEST PASSED:
TEST START TIME HOURS VOLUME % VOLUME TEST TYPE
JUL 29, 1997 6:02 AM 2821 48.9 STANDARD
LAST ANNUAL TEST PASSED:
NO TEST PASSED
FULLEST ANNUAL TEST PASS
NO TEST PASSED
LAST PERIODIC TEST PASS:
TEST START TIME HOURS VOLUME % VOLUME TEST TYPE
JUL 29, 1997 4:15 AM 27 2680 46.4 CSLD
FULLEST PERIODIC TEST
PASSED EACH MONTH:
TEST START TIME HOURS VOLUME % VOLUME TEST TYPE
JUL 20, 1997 1:52 AM 25 2916 50.5 CSLD
<ETX>
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 75
Function Code 212 Notes: (Continued)
Typical Response Message, Computer Format:
<SOH>i212TTYYMMDDHHmmTTNNRRnnttYYMMDDHHmm
hhhhhhhhVVVVVVVVppppppppzzmmmmmmmm...
TTNNRRnnttYYMMDDHHmm
hhhhhhhhVVVVVVVVppppppppzzmmmmmmmmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. NN - Number of Leak History Reports to Follow (Hex)
4. RR - Leak Report Type:
00=Last Test Passed
01=Fullest Test Passed
02=Fullest Periodic Monthly Test Passed
5. nn - Leak History Number (1-12) for first Monthly Tests Passed
6. tt - In-Tank Leak Test Type:
00=0.20 gal/hr test
01=0.10 gal/hr test
02=Gross (3 gal/hr) test
7. YYMMDDHHmm - In-Tank Leak Test Start Time
8. hhhhhhhh - Leak Test Duration in Hours (ASCII Hex IEEE float)
9. VVVVVVVV - Leak Test Volume (ASCII Hex IEEE float)
10. pppppppp - Leak Test Percentage of Full Volume (ASCII Hex IEEE float)
11. zz - Number of 8 Byte Fields to Follow (Hex)
12. mmmmmmmm - In-Tank Leak Test Method (Hex)
00000000=Standard
00000001=CSLD
13. && - Data Termination Flag
14. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 76
Function Code: 213 Version 26
Function Type: In-Tank Extended Standard Delivery Report
Command Format:
Display: <SOH>I213TTnn
Computer: <SOH>i213TTnn
Notes:
1. TT - Tank Number (Decimal, 00=all)
2. nn - Number of most recent deliveries (Decimal)
Typical Response Message, Display Format:
<SOH>
I213TTnn
JUL 29, 1997 9:02 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
DELIVERY REPORT
T 1:REGULAR UNLEADED
INCREASE DATE / TIME GALLONS TC GALLONS WATER TEMP DEG F HEIGHT
END: JUL 28, 1997 3:14 PM 3231 3194 0.00 76.14 48.27
START: JUL 28, 1997 3:05 PM 1244 1231 0.00 73.89 24.40
AMOUNT: 1987 1963
END: JUL 25, 1997 2:48 PM 4460 4414 0.00 74.56 63.06
START: JUL 25, 1997 2:37 PM 1157 1146 0.00 72.85 23.22
AMOUNT: 3303 3268
<ETX>
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 77
Function Code 213 Notes: (Continued)
Typical Response Message, Computer Format:
<SOH>i213TTYYMMDDHHmmTTpddYYMMDDHHmmYYMMDDHHmmNNFFFFFFFF...
TTpddYYMMDDHHmmYYMMDDHHmmNNFFFFFFFF...&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. p - Product Code (single ASCII character [20h-7Eh])
4. dd - Number of Deliveries to follow (Decimal, 00 if no data
available for this tank)
5. YYMMDDHHmm - Starting Date/Time
6. YYMMDDHHmm - Ending Date/Time
7. NN - Number of eight character Data Fields to follow (Hex)
8. FFFFFFFF - ASCII Hex IEEE float:
1. Starting Volume
2. Starting TC Volume
3. Starting Water
4. Starting Temp
5. Ending Volume
6. Ending TC Volume
7. Ending Water
8. Ending Temp
9. Starting Height
10. Ending Height
9. && - Data Termination Flag
10. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 78
Function Code: 214 Version 26
Function Type: In-Tank Mass/Density Inventory Report
Command Format:
Display: <SOH>I214TT
Computer: <SOH>i214TT
Typical Response Message, Display Format:
<SOH>
I214TT
JUL 22, 1996 3:06 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
IN-TANK MASS/DENSITY INVENTORY
TANK PRODUCT VOLUME MASS DENSITY HEIGHT WATER TEMP
1 REGULAR UNLEADED 5329 20357 5.9987 48.97 0.00 37.39
<ETX>
Typical Response Message, Computer Format:
<SOH>i214TTYYMMDDHHmmTTpssssNNFFFFFFFF...
TTpssssNNFFFFFFFF...&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. p - Product Code (single ASCII character [20h-7Eh])
4. ssss - Tank Status Bits:
Bit 1=(LSB) Delivery in Progress
Bit 2=Leak Test in Progress
Bit 3=Invalid Fuel Height Alarm (MAG Probes Only)
Bit 4-16 - Unused
5. NN - Number of eight character Data Fields to follow (Hex)
6. FFFFFFFF - ASCII Hex IEEE float:
1. Volume
2. Mass
3. Density
4. Height
5. Water
6. Temperature
7. && - Data Termination Flag
8. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 79
Function Code: 215 Version 26
Function Type: In-Tank Mass/Density Delivery Report
Command Format:
Display: <SOH>I215TT
Computer: <SOH>i215TT
Typical Response Message, Display Format:
<SOH>
I215TT
JUL 29, 1997 9:02 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
MASS/DENSITY DELIVERY REPORT
T 1:REGULAR UNLEADED
INCREASE DATE / TIME GALLONS MASS DENSITY WATER TEMP HEIGHT
END: JUL 28, 1997 3:14 PM 3231 19380 5.9983 0.00 76.14 48.27
START: JUL 28, 1997 3:05 PM 1244 7461 5.9983 0.00 73.89 24.40
AMOUNT: 1987 11918
END: JUL 25, 1997 2:48 PM 4460 26754 5.9987 0.00 74.56 63.06
START: JUL 25, 1997 2:37 PM 1157 6940 5.9987 0.00 72.85 23.22
AMOUNT: 3303 19813*
<ETX>
Note: asterisk (*) indicates default density.
Typical Response Message, Computer Format:
<SOH>i215TTYYMMDDHHmmTTpddYYMMDDHHmmYYMMDDHHmmNNFFFFFFFFf...
TTpddYYMMDDHHmmYYMMDDHHmmNNFFFFFFFFf...&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. p - Product Code (single ASCII character [20h-7Eh])
4. dd - Number of Deliveries to follow (Decimal, 00=no data)
5. YYMMDDHHmm - Starting Date/Time
6. YYMMDDHHmm - Ending Date/Time
7. NN - Number of eight character Data Fields to follow (Hex)
8. FFFFFFFF - ASCII Hex IEEE float:
1. Starting Volume
2. Starting Mass
3. Starting Density
4. Starting Water
5. Starting Temp
6. Ending Volume
7. Ending Mass
8. Ending Density
9. Ending Water
10. Ending Temp
11. Starting Height
12. Ending Height
9. f - Default Density Flag (0=new value, 1=default)
10. && - Data Termination Flag
11. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 80
Function Code: 216 Version 26
Function Type: Tank 50 Point Heights, Volumes and Slope Report
Command Format:
Display: <SOH>I216TT
Computer: <SOH>i216TT
Typical Response Message, Display Format:
<SOH>
I216TT
SEP 16, 2004 3:15 PM
TANK 50 POINT HEIGHTS, VOLUMES AND SLOPES
T 1: REGULAR UNLEADED
DIAMETER FULL VOLUME SLOPE
96.00 10000 104.17
PAIR HEIGHT VOLUME SLOPE
1 94.08 9800 104.17
2 92.16 9600 104.17
3 90.24 9400 104.17
4 88.32 9200 104.17
5 86.44 9000 104.17
:
:
45 9.60 1000 104.17
46 7.68 800 104.17
47 5.76 600 104.17
48 3.84 400 104.17
49 1.92 200 104.17
<ETX>
Typical Response Message, Computer Format:
<SOH>i216TTYYMMDDHHmmTTddddddddffffffffssssssssnn
HHHHHHHHVVVVVVVVSSSSSSSS...
HHHHHHHHVVVVVVVVSSSSSSSS...
TTddddddddffffffffssssssssnn
HHHHHHHHVVVVVVVVSSSSSSSS...
HHHHHHHHVVVVVVVVSSSSSSSS&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. dddddddd - Tank Diameter, Inches (ASCII Hex IEEE float)
4. ffffffff - Full Volume, Gallons (ASCII Hex IEEE float)
5. ssssssss - Slope, Gallons per Inch (ASCII Hex IEEE float)
6. nn - Number of Height/Volume Pairs to Follow (Hex).
7. HHHHHHHH - Height, Inches (ASCII Hex IEEE float)
8. VVVVVVVV - Volume, Gallons (ASCII Hex IEEE float)
9. SSSSSSSS - Slope, Gallons per Inch (ASCII Hex IEEE float)
10. && - Data Termination Flag
11. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 81
Function Code: 217 Version 26
Function Type: Tank Profile
Command Format:
Display: <SOH>I217TT
Computer: <SOH>i217TT
Typical Response Message, Display Format:
<SOH>
I217TT
SEP 16, 2004 3:15 PM
TANK PROFILE
T 1: REGULAR UNLEADED
TANK PRODUCT LABEL PROFILE
1 REGULAR UNLEADED 1 PT
<ETX>
Typical Response Message, Computer Format:
<SOH>i217TTYYMMDDHHmmTTpp...TTpp&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. pp - Tank Profile Selected (Hex)
00= 1 Pt
01= 4 Pts
02=20 Pts
03=Linear
04=50 Pts
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 82
Function Code: 218 Version 26
Function Type: Tank Chart Audit Trail
Command Format:
Display: <SOH>I218TT
Computer: <SOH>i218TT
Notes:
1. Returns the times of the last 10 tank chart modifications, most recent first
Typical Response Message, Display Format:
<SOH>
I218TT
JUL 29, 1997 9:02 AM
TANK CHART AUDIT TRAIL
T 1: REGULAR UNLEADED
TANK CAPACITY : 1000
CONSOLE SERIAL NUMBER:
xxxxxxxxxxxxxxxxxxxx
PROBE S/N : yyyyyy
WEIGHTS AND MEASURES:
zzzzzzzzzzzzzzzzzzzz
DATE/TIME
SEP 10, 2004 4:33 PM
SEP 09, 2004 3:25 PM
SEP 08, 2004 11:10 AM
SEP 02, 2004 5:30 PM
SEP 01, 2004 3:28 PM
<ETX>
Typical Response Message, Computer Format:
<SOH>i218TTYYMMDDHHmmTTccccccccxxxxxxxxxxxxxxxxxxxxyyyyyyzzzzzzzzzzzzzzzzzzzz
nnyymmddhhmm...yymmddhhmm...
TTccccccccxxxxxxxxxxxxxxxxxxxxyyyyyyzzzzzzzzzzzzzzzzzzzz
nnyymmddhhmm...yymmddhhmm&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. cccccccc - Tank Capacity, Gallons (ASCII Hex IEEE float)
4. x..x - Console Serial Number (20 ASCII characters [20h-7Eh])
5. yyyyyy - Probe Serial Number (Decimal)
6. z..z - Weights and Measures Office (20 ASCII characters [20h-7Eh])
7. nn - Number of Date/Time fields to follow (Decimal)
8. yymmddhhmm - Date and Time of Tank Chart Modification
9. && - Data Termination Flag
10. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 83
Function Code: 219 Version 26
Function Type: Tank Chart Security Status
Command Format:
Display: <SOH>I219TT
Computer: <SOH>i219TT
Typical Response Message, Display Format:
<SOH>
I21900
JUN 22, 2001 3:15 PM
TANK CHART SECURITY
ENABLED
<ETX>
Typical Response Message, Computer Format:
<SOH>i21900YYMMDDHHmmf&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. f - Tank Chart Security Flag
0=Disabled
1=Enabled
3. && - Data Termination Flag
4. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 84
Function Code: 21A (like 201) Version 27
Function Type: In-Tank Inventory Report With 90/95% Ullage
Command Format:
Display: <SOH>I21ATT
Computer: <SOH>i21ATT
Typical Response Message, Display Format:
<SOH>
I21ATT
JAN 22, 2006 3:06 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
TANK PRODUCT VOLUME TC VOLUME 95% ULLAGE HEIGHT WATER TEMP
1 REGULAR UNLEADED 8904 8904 596 80.00 0.00 60.00
<ETX>
Typical Response Message, Computer Format:
<SOH>i21ATTYYMMDDHHmmTTpssssNNFFFFFFFF...
TTpssssNNFFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. p - Product Code (one ASCII character [20h-7Eh])
4. ssss - Tank Status Bits:
Bit 1 - (LSB) Delivery in Progress
Bit 2 - Leak Test in Progress
Bit 3 - Invalid Fuel Height Alarm (MAG Probes Only)
Bit 4 - 16 - Unused
5. NN - Number of eight character Data Fields to follow (Hex)
6. FFFFFFFF - ASCII Hex IEEE floats:
1. Volume
2. TC Volume
3. 90/95% Ullage
4. Height
5. Water
6. Temperature
7. Water Volume
7. && - Data Termination Flag
8. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 85
Function Code: 21B Version 26
Function Type: BIR Extended Adjusted Delivery Report
Command Format:
Display: <SOH>I21BTTnn
Computer: <SOH>i21BTTnn
Notes:
1. TT - Tank Number (Decimal, 00=All)
2. nn - Number of most recent deliveries (Decimal)
Typical Response Message, Display Format:
<SOH>
I21BTTnn
JAN 22, 1996 3:08 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
BIR ADJUSTED DELIVERY REPORT
T 1:REGULAR UNLEADED
START END ADJ ADJ TC
DELIVERY START DATE DELIVERY END DATE VOLUME VOLUME DELIV DELIV
JAN 21, 1996 2:52 AM JAN 21, 1996 3:12 AM 3193 9197 6011 6119
JAN 19, 1996 3:22 AM JAN 19, 1996 3:40 AM 4193 8602 4409 4473
JAN 17, 1996 3:13 AM JAN 17, 1996 3:40 AM 2739 8749 6010 6113
<ETX>
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 86
Function Code 21B Notes: (Continued)
Typical Response Message, Computer Format:
<SOH>i21BTTYYMMDDHHmmTTddYYMMDDHHmmYYMMDDHHmmNNFFFFFFFF...
TTddYYMMDDHHmmYYMMDDHHmmNNFFFFFFFF...&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=All)
3. dd - Number of Deliveries to follow
4. YYMMDDHHmm - Starting Date/Time
5. YYMMDDHHmm - Ending Date/Time
6. NN - Number of eight character Data Fields to follow (Hex)
7. FFFFFFFF - ASCII Hex IEEE floats:
1. Starting Volume
2. Ending Volume
3. Adjusted Delivery Volume
4. Adjusted Temperature Compensated Delivery Volume
5. Starting Fuel Height
6. Starting Fuel Temperature 1
7. Starting Fuel Temperature 2
8. Starting Fuel Temperature 3
9. Starting Fuel Temperature 4
10. Starting Fuel Temperature 5
11. Starting Fuel Temperature 6
12. Ending Fuel Height
13. Ending Fuel Temperature 1
14. Ending Fuel Temperature 2
15. Ending Fuel Temperature 3
16. Ending Fuel Temperature 4
17. Ending Fuel Temperature 5
18. Ending Fuel Temperature 6
19. Total Dispensed During Delivery
20. Starting Fuel Temperature Average
21. Ending Fuel Temperature Average
8. && - Data Termination Flag
9. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 87
Function Code: 221 Version 116
Function Type: Ticketed Delivery Report
Command Format:
Display: <SOH>I221TTtt
Computer: <SOH>i221TTtt
Notes:
1. TT - Tank Number (Decimal, 00=all)
2. tt - Report Type (if not entered will default to current)
01=current
02=previous
Typical Response Message, Display Format:
<SOH>
I221TT
MAR 20, 1998 3:25 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
CURRENT PERIOD TICKETED DELIVERY REPORT
VOLUMES ARE STANDARD
T 1:REGULAR UNLEADED
TICKET GAUGE DLVY BEFORE AFTER EST DLVY
DELIVERY END DATE VOLUME VOLUME VAR TMP TMP TMP
MAR 7, 1998 8:26 AM 5901.0 5905.0 -4.0 44.8 42.4 41.0
MAR 9, 1998 11:37 AM 5901.0 5905.0 -4.0 44.6 43.2 42.4
MAR 10, 1998 11:34 PM 4099.0 4094.0 5.0 44.6 42.6 40.5
<ETX>
Typical Response Message, Computer Format:
<SOH>i221TTYYMMDDHHmmTTpPPdddYYMMDDHHmmNNFFFFFFFF...
TTpPPdddYYMMDDHHmmNNFFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. p - Product Code (one ASCII character [20h-7Eh])
4. PP - Probe type (Decimal)
5. ddd - Number of deliveries to follow (decimal) if 0, no more data
for this tank will follow
6. YYMMDDHHmm - Ending date/ time
7. NN - Number of eight character Data Fields to follow (Hex)
8. FFFFFFFF - ASCII Hex IEEE floats:
1. ticket volume
2. gauged volume
3. delivery variance
4. start fuel temperature
5. end fuel temperature
6. estimated delivery temperature
9. && - Data Termination Flag
10. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 88
Function Code: 222 Version 23
Function Type: Bill of Lading Report
Command Format: Inquire:
Display: <SOH>S222TTtt <SOH>I222TT
Computer: <SOH>s222TTtt <SOH>i222TT
Notes:
1. TT - Tank Number (Decimal, 00=all)
2. tt - Report Type (if tt is not entered current is default)
01=current
02=previous
Typical Response Message, Display Format:
<SOH>
2220101
JAN 1, 1996 8:00 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
CURRENT PERIOD TICKETED AND BOL DELIVERY REPORT
PROD 1: UNLEADED GASOLINE
BOL TICKET GAUGE TC GAUGE
DELIVERY END DATE NUMBER VOLUME VOLUME VOLUME
DEC 2, 1993 2:00 AM 123456 0.0 502.0 0.0
DEC 6, 1993 2:00 AM 123983 7375.0 7369.0 7375.0
DEC 10, 1993 2:00 AM 123902 2799.0 2790.0 2799.0
Typical Response Message, Computer Format:
<SOH>222TTYYMMDDHHmmTTpPPdddYYMMDDHHmmAAaa..aaNNFFFFFFFF....FFFFFFFF...
TTpPPdddYYMMDDHHmmAAaa..aaNNFFFFFFFF....FFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 0=all)
3. p - Product Code (Decimal)
4. PP - Probe type (Decimal)
5. ddd - Number of deliveries to follow (Decimal) if 0, no more data
for this tank will follow
6. YYMMDDHHmm - Ending date/ time
7. AA - Number of ASCII characters to follow (Hex)
8. aa..aa - Bill of Lading Number (ASCII characters [20h-7Eh])
9. NN - Number of eight character Data Fields to follow (Hex)
10. FFFFFFFF - ASCII Hex IEEE floats:
1. Ticketed volume
2. Gauged volume
3. Gauged TC volume
11. && - Data Termination Flag
12. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 89
Function Code: 225 Version 116
Function Type: Periodic Delivery Variance Report
Command Format:
Display: <SOH>I225TTtt
Computer: <SOH>i225TTtt
Notes:
1. TT - Tank Number (Decimal, 00=all)
2. tt - Report Type (if not entered will default to current)
01=current
02=previous
Typical Response Message, Display Format:
<SOH>
I225TT
MAR 20, 1998 3:25 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
CURRENT PERIOD DELIVERY VARIANCE REPORT
VOLUMES ARE STANDARD
T 1:REGULAR UNLEADED
TICKET GAUGE VARIANCE
VOLUME VOLUME
MAR 7, 1998 8:26 AM 5901.0 5905.0 -4.0
MAR 9, 1998 11:37 AM 5901.0 5905.0 -4.0
MAR 10, 1998 11:34 PM 4099.0 4094.0 5.0
MAR 12, 1998 8:27 PM 3800.0 3797.0 3.0
MAR 14, 1998 8:28 AM 5900.0 5899.0 1.0
MAR 16, 1998 11:39 AM 5902.0 5916.0 -14.0
MAR 18, 1998 2:02 PM 5901.0 5900.0 1.0
TOTALS 37404.0 37417.0 -13.0
PERCENT VARIANCE OF SALES -13.0=-0.0%
<ETX>
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 90
Function Code 225 Notes: (Continued)
Typical Response Message, Computer Format:
<SOH>i225TTYYMMDDHHmmTTpPPdddYYMMDDHHmmNNFFFFFFFF...
TTpPPdddYYMMDDHHmmNNFFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Numbers (Decimal, 00=all tanks)
3. p - Product Number (Decimal)
4. PP - Probe type (Decimal)
5. ddd - Number of deliveries to follow (decimal) if 000, no more
data for this tank will follow
6. YYMMDDHHmm - Delivery Time
7. NN - Number of eight character Data Fields to follow (Hex)
8. FFFFFFFF - ASCII Hex IEEE floats:
1. Ticketed volume
2. Gauged volume
3. Delivery variance
9. && - Data Termination Flag
10. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 91
Function Code: 226 Version 116
Function Type: Weekly Delivery Variance Report
Command Format:
Display: <SOH>I226TTtt
Computer: <SOH>i226TTtt
Notes:
1. TT - Tank Number (Decimal, 00=all)
2. tt - Report Type (if not entered will default to current)
01=current
02=previous
Typical Response Message, Display Format:
<SOH>
I226TT
MAR 20, 1998 3:25 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
CURRENT WEEK DELIVERY VARIANCE REPORT
VOLUMES ARE STANDARD
T 1:REGULAR UNLEADED
TICKET GAUGE VARIANCE
VOLUME VOLUME
MAR 16, 1998 11:39 AM 5902.0 5916.0 -14.0
MAR 18, 1998 2:02 PM 5901.0 5900.0 1.0
TOTALS 11803.0 11816.0 -13.0
PERCENT VARIANCE OF SALES -13.0=-0.1%
<ETX>
Typical Response Message, Computer Format:
<SOH>i226TTYYMMDDHHmmTTpPPdddYYMMDDHHmmNNFFFFFFFF...
TTpPPdddYYMMDDHHmmNNFFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Numbers (Decimal, 00=all tanks)
3. p - Product Number (Decimal)
4. PP - Probe type (Decimal)
5. ddd - Number of deliveries to follow (decimal) if 0, no more data
for this tank will follow
6. YYMMDDHHmm - Delivery Time
7. NN - Number of eight character Data Fields to follow (Hex)
8. FFFFFFFF - ASCII Hex IEEE float:
1. Ticketed volume
2. Gauged volume
3. Delivery variance
9. && - Data Termination Flag
10. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 92
Function Code: 227 Version 116
Function Type: Daily Delivery Variance Report
Command Format:
Display: <SOH>I227TTMMDD
Computer: <SOH>i227TTMMDD
Notes:
1. TT - Tank number
2. MMDD - Month and day for Daily Report, if left blank will report
current date
Typical Response Message, Display Format:
<SOH>
I227TT
MAR 20, 1998 3:26 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
DAILY DELIVERY VARIANCE REPORT
VOLUMES ARE STANDARD
T 1:REGULAR UNLEADED
TICKET GAUGE VARIANCE
VOLUME VOLUME
MAR 16, 1998 11:39 AM 5902.0 5916.0 -14.0
<ETX>
Typical Response Message, Computer Format:
<SOH>i227TTYYMMDDHHmmTTpPPdddYYMMDDHHmmNNFFFFFFFF...
TTpPPdddYYMMDDHHmmNNFFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. p - Product Code (one ASCII character [20h-7Eh])
4. PP - Probe Type (Decimal)
5. ddd - Number of deliveries to follow (decimal) if 000, no more
data for this tank will follow
6. YYMMDDHHmm - Delivery Time
7. NN - Number of eight character Data Fields to follow (Hex)
8. FFFFFFFF - ASCII Hex IEEE float:
1. Ticketed volume
2. Gauged volume
3. Delivery variance
9. && - Data Termination Flag
10. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 93
Function Code: 237 Version 33
Function Type: In-Tank Product Inventory Report
Command Format:
Display: <SOH>I237TT
Computer: <SOH>i237TT
Typical Response Message, Display Format:
<SOH>
I237TT
JAN 22, 2012 3:06 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
PRODUCT INVENTORY REPORT
TANK PRODUCT LABEL VOLUME TC VOLUME
1 REGULAR 1 5265 5224
2 REGULAR 2 5265 5220
3 REGULAR 3 5265 5217
4 REGULAR 4 5265 5231
TOTAL: 21060 20892
5 DIESEL 3287 3276
TOTAL: 3287 3276
<ETX>
Typical Response Message, Computer Format:
<SOH>i237TTYYMMDDHHmmNNTTpnnaaaaaaaaAAAAAAAA...
TTpnnaaaaaaaaAAAAAAAAbbccccccccCCCCCCCC&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. NN - Number of tanks to follow (Hex)
3. TT - Tank Number (Decimal, 00=all)
4. p - Product Code (one ASCII character [20h-7Eh])
5. nn - Number of eight byte ASCII Hex floats to follow
6. aaaaaaaa - Tank Volume
7. AAAAAAAA - Tank TC Volume
8. bb - Number of eight byte ASCII Hex floats to follow
9. cccccccc - Product Volume
10. CCCCCCCC - Product TC Volume
11. && - Data Termination Flag
12. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 94
Function Code: 238 Version 33
Function Type: In-Tank Siphon Manifolded Inventory Report
Command Format:
Display: <SOH>I238TT
Computer: <SOH>i238TT
Typical Response Message, Display Format:
<SOH>
I238TT
JAN 22, 2012 3:06 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
SIPHON MANIFOLDED INVENTORY REPORT
TANK PRODUCT LABEL VOLUME TC VOLUME
1 REGULAR 1 5265 5224
2 REGULAR 2 5265 5220
TOTAL: 10530 10448
3 PREMIUM 1 5265 5217
4 PREMIUM 2 5265 5231
TOTAL: 10530 10448
5 DIESEL 3287 3276
TOTAL: 3287 3276
<ETX>
Typical Response Message, Computer Format:
<SOH>i238TTYYMMDDHHmmNNTTpnnaaaaaaaaAAAAAAAA...
TTpnnaaaaaaaaAAAAAAAAbbccccccccCCCCCCCC&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. NN - Number of tanks to follow (Hex)
3. TT - Tank Number (Decimal, 00=all)
4. p - Product Code (one ASCII character [20h-7Eh])
5. nn - Number of eight byte ASCII Hex floats to follow
6. aaaaaaaa - Tank Volume
7. AAAAAAAA - Tank TC Volume
8. bb - Number of eight byte ASCII Hex floats to follow
9. cccccccc - Product Volume
10. CCCCCCCC - Product TC Volume
11. && - Data Termination Flag
12. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 95
Function Code: 239 Version 33
Function Type: In-Tank Manifolded Delivery Report
With Sales Adjustment if BIR available
Command Format:
Display: <SOH>I239TT
Computer: <SOH>i239TT
Typical Response Message, Display Format:
<SOH>
I239TT
JUL 29, 2012 9:02 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
MANIFOLDED DELIVERY REPORT
TANK PRODUCT LABEL
1 REGULAR A
2 REGULAR B
3 REGULAR C
DATE / TIME GALLONS TC GALLONS
OCT 10, 2012 1:01 AM 25857 25857
OCT 9, 2012 1:01 AM 25854 25854
OCT 8, 2012 1:01 AM 25851 25851
OCT 7, 2012 1:01 AM 25848 25848
OCT 6, 2012 1:01 AM 25845 25845
OCT 5, 2012 1:01 AM 25842 25842
<ETX>
Typical Response Message, Computer Format:
<SOH>i239TTYYMMDDHHmmnnTTp...TTpddYYMMDDHHmmNNFFFFFFFF...
nnTTp...TTpddYYMMDDHHmmNNFFFFFFFF...&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. nn - Number of Tanks to follow (???)
3. TT - Tank Number (Decimal, 00=all)
4. p - Product Code (single ASCII character [20h-7Eh])
5. dd - Number of Deliveries to follow (Decimal, 00 if no data
available)
6. YYMMDDHHmm - Starting Date/Time
7. NN - Number of eight character Data Fields to follow (Hex)
8. FFFFFFFF - ASCII Hex IEEE float:
1. Unadjusted Delivery Volume, IEEE float
2. Unadjusted TC Delivery Volume, IEEE float
3. Estimated Sales, IEEE float
4. Manifolded tanks bit mask, unsigned long
5. Probe Out bit mask, unsigned long
9. && - Data Termination Flag
10. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 96
Function Code: 23A Version 33
Function Type: In-Tank Manifolded Delivery Report
With Sales Adjustment if BIR available
Command Format:
Display: <SOH>I23ATT
Computer: <SOH>i23ATT
Typical Response Message, Display Format:
<SOH>
I23ATT
JUL 29, 2012 9:02 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
MANIFOLDED DELIVERY REPORT
TANK PRODUCT LABEL
1 REGULAR A
2 REGULAR B
3 REGULAR C
START DATE / TIME END DATE / TIME GALLONS TC GALLONS
OCT 10, 2012 1:01 AM OCT 10, 2012 1:21 AM 25857 25857
OCT 9, 2012 1:01 AM OCT 9, 2012 1:21 AM 25854 25854
OCT 8, 2012 1:01 AM OCT 8, 2012 1:21 AM 25851 25851
OCT 7, 2012 1:01 AM OCT 7, 2012 1:21 AM 25848 25848
OCT 6, 2012 1:01 AM OCT 6, 2012 1:21 AM 25845 25845
OCT 5, 2012 1:01 AM OCT 5, 2012 1:21 AM 25842 25842
<ETX>
Typical Response Message, Computer Format:
<SOH>i239TTYYMMDDHHmmnnTTp...TTpddYYMMDDHHmmYYMMDDHHmmNNFFFFFFFF...
nnTTp...TTpddYYMMDDHHmmYYMMDDHHmmNNFFFFFFFF...&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. nn - Number of Tanks to follow
3. TT - Tank Number (Decimal, 00=all)
4. p - Product Code (single ASCII character [20h-7Eh])
5. dd - Number of Deliveries to follow (Decimal, 00 if no data
available)
6. YYMMDDHHmm - Start Date/Time
7. YYMMDDHHmm - End Date/Time
8. NN - Number of eight character Data Fields to follow (Hex)
9. FFFFFFFF - ASCII Hex IEEE float:
1. Unadjusted Delivery Volume, IEEE float
2. Unadjusted TC Delivery Volume, IEEE float
3. Estimated Sales, IEEE float
4. Manifolded tanks bit mask, unsigned long
5. Probe Out bit mask, unsigned long
10. && - Data Termination Flag
11. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 97
Function Code: 251 Version 3
Function Type: CSLD Results Report
Command Format:
Display: <SOH>I251TT
Computer: <SOH>i251TT
Typical Response Message, Display Format:
<SOH>
I251TT
JAN 22, 1996 3:09 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
CSLD TEST RESULTS
TANK PRODUCT RESULT
1 REGULAR UNLEADED PER: JAN 22, 1996 PASS
<ETX>
Typical Response Message, Computer Format:
<SOH>i251TTYYMMDDHHmmTTrr...
TTrr&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=all)
3. rr - Tank CSLD Results:
01=PASS
02=FAIL
03=NO RESULTS AVAILABLE
04=INVALID (software versions 3 and 4 only)
08=INCR (software versions 5 and above)
09=WARN (software versions 5 and above)
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 98
Function Code: 281 Version 3
Function Type: Fuel Management Report
Command Format:
Display: <SOH>I281TT
Computer: <SOH>i281TT
Typical Response Message, Display Format:
<SOH>
I281TT
JAN 22, 1996 3:09 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
FUEL MANAGEMENT REPORT
REGULAR UNLEADED ( TANK 1 )
DAYS FUEL REMAINING: 1.8 AVERAGE SALES (GALLONS)
INVENTORY : 5308 GAL SUN MON TUE WED THR FRI SAT
95% ULLAGE: 4218 GAL 2696 2075 2602 2046 2471 2805 2824
<ETX>
Typical Response Message, Computer Format:
<SOH>i281TTYYMMDDHHmmPPTTpttp...NNFFFFFFFF...
PPTTpttp...NNFFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. PP - Number of tank product code pairs to follow (Hex)
3. TTp,ttp - Tank Number (decimal) and Product Code (ASCII character)
4. NN - Number of eight character Data Fields to follow (Hex)
5. FFFFFFFF - ASCII Hex IEEE floats:
1. Days Supply of Fuel Remaining
2. Present Inventory
3. Present 95% Ullage
4. Average Sales on Sundays
5. Average Sales on Mondays
6. Average Sales on Tuesdays
7. Average Sales on Wednesdays
8. Average Sales on Thursdays
9. Average Sales on Fridays
10. Average Sales on Saturdays
6. && - Data Termination Flag
7. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 99
Function Code: 282 Version 19
Function Type: FLS Diagnostic: Volume History Table
Command Format:
Display: <SOH>I282TT
Computer: <SOH>i282TT
Typical Response Message, Display Format:
<SOH>
I282TT
JAN 3, 1996 10:07 PM
FLS DIAGNOSTICS: VOLUME TABLE
T 1:UNLEADED GASOLINE
CURRENT INVENTORY VOLUME: 5345
CURRENT INVENTORY TIME: JAN 3, 1996 10:07:22 PM
MOST RECENT STORED: JAN 3, 1996 10:00:22 PM
1141 1297 1476 1625 1742 1932 2085 2156 2218 2242 2242 2242 2242
2248 2265 2281 2307 2339 2405 2456 2573 2701 2854 3022 3141 3297
3476 3625 3742 3932 4085 4156 0 0 4242 4242 4242 4248 4265
4281 4307 4339 4405 4456 4573 4701 4854 5022 5160 5276 5345 5450
<ETX>
Typical Response Message, Computer Format:
<SOH>iXXXTTYYMMDDHHmmTTFFFFFFFFYYMMDDHHmmNNFFFFFFFF...
TTFFFFFFFFYYMMDDHHmmNNFFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. TT - Tank Number (Decimal, 00=All Tanks)
3. FFFFFFFF - Current Inventory Volume (ASCII Hex IEEE float)
4. YYMMDDHHmm - Date and Time of the most recent stored hourly history
volume
5. NN - Number of eight character Data Fields to follow (Hex)
6. FFFFFFFF - ASCII Hex IEEE floats:
1. Latest recorded hourly volume
2. Intermediate hourly recorded volumes
3. Oldest recorded hourly volume
7. && - Data Termination Flag
8. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 100
Function Code: 2E2 Version 14
Function Type: In-Tank Stored Inventory Report
Command Format:
Display: <SOH>I2E2TTII
Computer: <SOH>i2E2TTII
Typical Response Message, Display Format:
<SOH>
I2E2TT
JAN 22, 1996 3:06 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
JAN 22, 1996 8:00 AM
TANK PRODUCT VOLUME TC VOLUME ULLAGE HEIGHT WATER TEMP
1 REGULAR UNLEADED 5329 5413 4699 48.97 0.00 37.39
<ETX>
Typical Response Message, Computer Format:
<SOH>i2E2TTYYMMDDHHmmIIYYMMDDHHmmTTpssssNNFFFFFFFF...
TTpssssNNFFFFFFFF&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. II - Inventory Record Number (Decimal 01, 02, 03, 04)
3. YYMMDDHHmm - Date and Time of Recorded Inventory
4. TT - Tank Number (Decimal, 00=all)
5. p - Product Code (one ASCII character [20h-7Eh])
6. ssss - Tank Status Bits:
Bit 1 - (LSB) Delivery in Progress
Bit 2 - Leak Test in Progress
Bit 3 - Invalid Fuel Height Alarm (MAG Probes Only)
Bit 4-16 - Unused
7. NN - Number of eight character Data Fields to follow (Hex)
8. FFFFFFFF - ASCII Hex IEEE floats:
1. Volume
2. TC Volume
3. Ullage
4. Height
5. Water
6. Temperature
7. Water Volume
9. && - Data Termination Flag
10. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 101
7.2.3 SENSOR REPORTS
Function Code: 301 Version 1
Function Type: Liquid Sensor Status Report
Command Format:
Display: <SOH>I301SS
Computer: <SOH>i301SS
Typical Response Message, Display Format:
<SOH>
I301SS
JAN 28, 1995 10:10 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
LIQUID STATUS REPORT
SENSOR LOCATION STATUS
1 LIQUID # 1 SENSOR NORMAL
<ETX>
Typical Response Message, Computer Format:
<SOH>i301SSYYMMDDHHmmSSssss...
SSssss&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Sensor Number (Decimal, 00=all)
3. ssss - Sensor Status Value:
0000=Sensor Normal
0001=Sensor Setup Data Warning
0002=Sensor Fuel Alarm
0003=Sensor Out Alarm
0004=Sensor Short Alarm
0005=Sensor Water Alarm
0006=Sensor Water Out Alarm
0007=Sensor High Liquid Alarm
0008=Sensor Low Liquid Alarm
0009=Sensor Liquid Warning
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 102
Function Code: 302 Version 1
Function Type: Liquid Sensor Alarm History Report
Command Format:
Display: <SOH>I302SS
Computer: <SOH>i302SS
Typical Response Message, Display Format:
<SOH>
I302SS
JAN 28, 1995 10:10 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
LIQUID ALARM HISTORY REPORT
SENSOR LOCATION
1 LIQUID # 1
JAN 6, 1995 8:02 AM FUEL ALARM
<ETX>
Typical Response Message, Computer Format:
<SOH>i302SSYYMMDDHHmmSSNNYYMMDDHHmmaaaa...
SSNNYYMMDDHHmmaaaa&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Sensor Number (Decimal, 00=all)
3. NN - Number of Alarm Incidents to follow
4. YYMMDDHHmm - Date and Time of Alarm
5. aaaa - Alarm type number:
0001=Sensor Setup Data Warning
0002=Sensor Fuel Alarm
0003=Sensor Out Alarm
0004=Sensor Short Alarm
0005=Sensor Water Alarm
0006=Sensor Water Out Alarm
0007=Sensor High Liquid Alarm
0008=Sensor Low Liquid Alarm
0009=Sensor Liquid Warning
6. && - Data Termination Flag
7. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 103
Function Code: 306 Version 1
Function Type: Vapor Sensor Status Report
Command Format:
Display: <SOH>I306SS
Computer: <SOH>i306SS
Typical Response Message, Display Format:
<SOH>
I306SS
JAN 28, 1995 10:11 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
VAPOR STATUS REPORT
SENSOR LOCATION STATUS
1 VAPOR # 1 SENSOR NORMAL
<ETX>
Typical Response Message, Computer Format:
<SOH>i306SSYYMMDDHHmmSSssss...
SSssss&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Sensor Number (Decimal, 00=all)
3. ssss - Sensor Status Value:
0000=Sensor Normal
0001=Sensor Setup Data Warning
0002=Sensor Fuel Alarm
0003=Sensor Out Alarm
0004=Sensor Short Alarm
0005=Sensor Water Alarm
0006=Sensor Water Out Alarm
0007=Sensor High Liquid Alarm
0008=Sensor Low Liquid Alarm
0009=Sensor Liquid Warning
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 104
Function Code: 307 Version 1
Function Type: Vapor Sensor Alarm History Report
Command Format:
Display: <SOH>I307SS
Computer: <SOH>i307SS
Typical Response Message, Display Format:
<SOH>
I307SS
JAN 28, 1995 10:11 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
VAPOR ALARM HISTORY REPORT
SENSOR LOCATION
1 VAPOR # 1
JAN 6, 1995 8:02 AM WATER ALARM
<ETX>
Typical Response Message, Computer Format:
<SOH>i307SSYYMMDDHHmmSSNNYYMMDDHHmmaaaa...
SSNNYYMMDDHHmmaaaa&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Sensor Number (Decimal, 00=all)
3. NN - Number of Alarm Incidents to follow
4. YYMMDDHHmm - Date and Time of Alarm
5. aaaa - Alarm type number:
0001=Sensor Setup Data Warning
0002=Sensor Fuel Alarm
0003=Sensor Out Alarm
0004=Sensor Short Alarm
0005=Sensor Water Alarm
0006=Sensor Water Out Alarm
0007=Sensor High Liquid Alarm
0008=Sensor Low Liquid Alarm
0009=Sensor Liquid Warning
6. && - Data Termination Flag
7. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 105
Function Code: 311 Version 1
Function Type: Groundwater Sensor Status Report
Command Format:
Display: <SOH>I311SS
Computer: <SOH>i311SS
Typical Response Message, Display Format:
<SOH>
I311SS
JAN 28, 1995 10:11 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
GROUNDWATER STATUS REPORT
SENSOR LOCATION STATUS
1 GROUND WATER # 1 SENSOR NORMAL
<ETX>
Typical Response Message, Computer Format:
<SOH>i311SSYYMMDDHHmmSSssss...
SSssss&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Sensor Number (Decimal, 00=all)
3. ssss - Sensor Status Value:
0000=Sensor Normal
0001=Sensor Setup Data Warning
0002=Sensor Fuel Alarm
0003=Sensor Out Alarm
0004=Sensor Short Alarm
0005=Sensor Water Alarm
0006=Sensor Water Out Alarm
0007=Sensor High Liquid Alarm
0008=Sensor Low Liquid Alarm
0009=Sensor Liquid Warning
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 106
Function Code: 312 Version 1
Function Type: Groundwater Sensor Alarm History Report
Command Format:
Display: <SOH>I312SS
Computer: <SOH>i312SS
Typical Response Message, Display Format:
<SOH>
I312SS
JAN 28, 1995 10:11 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
GROUNDWATER ALARM HISTORY REPORT
SENSOR LOCATION
1 GROUND WATER # 1
JAN 6, 1995 8:02 AM OPEN ALARM
<ETX>
Typical Response Message, Computer Format:
<SOH>i312SSYYMMDDHHmmSSNNYYMMDDHHmmaaaa...
SSNNYYMMDDHHmmaaaa&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Sensor Number (Decimal, 00=all)
3. NN - Number of Alarm Incidents to follow
4. YYMMDDHHmm - Date and Time of Alarm
5. aaaa - Alarm type number:
0001=Sensor Setup Data Warning
0002=Sensor Fuel Alarm
0003=Sensor Out Alarm
0004=Sensor Short Alarm
0005=Sensor Water Alarm
0006=Sensor Water Out Alarm
0007=Sensor High Liquid Alarm
0008=Sensor Low Liquid Alarm
0009=Sensor Liquid Warning
6. && - Data Termination Flag
7. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 107
Function Code: 315 Version 24
Function Type: Smart Sensor Status Report
Command Format:
Display: <SOH>I315SS
Computer: <SOH>i315SS
Typical Response Message, Display Format:
<SOH>
I315SS
JAN 22, 2003 3:07 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
SMART SENSOR STATUS REPORT
SENSOR LOCATION STATUS
1 SUMP 1 SENSOR NORMAL
<ETX>
Typical Response Message, Computer Format:
<SOH>i315SSYYMMDDHHmmSSssss...
SSssss&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Smart Sensor Number (Decimal, 00=all)
3. ssss - Sensor status value:
0000=Smart Sensor Normal
0001=Smart Sensor Setup Data Warning
0002=Smart Sensor Communication Alarm
0003=Smart Sensor Fault Alarm
0004=Smart Sensor Fuel Warning
0005=Smart Sensor Fuel Alarm
0006=Smart Sensor Water Warning
0007=Smart Sensor Water Alarm
0008=Smart Sensor High Liquid Warning
0009=Smart Sensor High Liquid Alarm
0010=Smart Sensor Low Liquid Warning
0011=Smart Sensor Low Liquid Alarm
0012=Smart Sensor Temperature Warning
0013=Smart Sensor Relay Active
0014=Smart Sensor Install Alarm
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 108
Function Code: 316 Version 24
Function Type: Smart Sensor Alarm History Report
Command Format:
Display: <SOH>I316SS
Computer: <SOH>i316SS
Typical Response Message, Display Format:
<SOH>
I316SS
JAN 22, 2003 3:07 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
SMART SENSOR ALARM HISTORY REPORT
SENSOR LOCATION
1 T1 SUMP
JUN 23, 2003 2:12 PM WATER WARNING
JUN 23, 2003 2:12 PM WATER ALARM
JUN 23, 2003 2:12 PM FUEL ALARM
<ETX>
Typical Response Message, Computer Format:
<SOH>i316SSYYMMDDHHmmSSnnYYMMDDHHmmaaaa...
SSnnYYMMDDHHmmaaaa&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Smart Sensor Number (Decimal, 00=all)
3. nn - Number of alarms incidents to follow (Decimal, 00=none)
4. YYMMDDHHmm - Date and time alarm occurred
5. aaaa - Alarm type number:
0001=Smart Sensor Setup Data Warning
0002=Smart Sensor Communication Alarm
0003=Smart Sensor Fault Alarm
0004=Smart Sensor Fuel Warning
0005=Smart Sensor Fuel Alarm
0006=Smart Sensor Water Warning
0007=Smart Sensor Water Alarm
0008=Smart Sensor High Liquid Warning
0009=Smart Sensor High Liquid Alarm
0010=Smart Sensor Low Liquid Warning
0011=Smart Sensor Low Liquid Alarm
0012=Smart Sensor Temperature Warning
0013=Smart Sensor Relay Active
0014=Smart Sensor Install Alarm
6. && - Data Termination Flag
7. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 109
Function Code: 317 Version 26
Function Type: Mag Sump Leak Test In Progress/Last Test Report
Command Format:
Display: <SOH>I317ss
Computer: <SOH>i317ss
Typical Response Message, Display Format:
<SOH>
I317ss
FEB 19, 2005 9:55 AM
MAG SUMP LEAK TEST
IN PROGRESS
s 1:SUMP NUMBER 1
STATUS:MEASURING HEIGHT
START TIME:
FEB 19, 2005 9:43 AM
START HT: 20.971 IN.
START TEMP: 76.1 F
CURRENT HT: 20.971 IN.
CURRENT TEMP: 76.1 F
DURATION: 12 MINS
TEMP RATE: 6.0 F/HR
LEAK RATE: 0.0000 IN./HR
<ETX>
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 110
Function Code 317 Notes: (Continued)
Typical Response Message, Computer Format:
<SOH>i317ssYYMMDDHHmmssttccYYMMDDHHmmNNHHHHHHHHTTTTTTTThhhhhhhhttttttttdddddddd
RRrrrrrrrrmmmmmmmmLLllllllll...
ssttccYYMMDDHHmmNNHHHHHHHHTTTTTTTThhhhhhhhttttttttdddddddd
RRrrrrrrrrmmmmmmmmLLllllllll&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. ss - Smart Sensor Number (Decimal, 00=all)
3. tt - Mag Sump Leak Test Status
00=NO TEST DATA AVAILABLE
01=LEAK TEST ABORTED
02=FILL SUMP
03=MEASURING HEIGHT
04=LEAK TEST PASSED
4. cc - Abort Reason Code
00=NOT ABORTED
01=MAG SENS ALM/WARN
02=WATER TOO LOW
03=WATER TOO HIGH
04=TEMP TOO LOW
05=TEMP TOO HIGH
06=WATER INCREASED
07=WATER DECREASED
08=INSUFFICIENT DATA
09=LEAK RATE TOO HIGH
10=TEST PHASE TIMEOUT
11=TEMP STABLE TIMEOUT
5. YYMMDDHHmm - Start Date/Time
6. NN - Number of 8 bytes data fields to follow (Decimal)
7. HHHHHHHH - Starting Height, Inches (ASCII Hex IEEE float)
8. TTTTTTTT - Starting Temperature, Degrees F (ASCII Hex IEEE float)
9. hhhhhhhh - Ending Height (ASCII Hex IEEE float)
10. tttttttt - Ending Temperature (ASCII Hex IEEE float)
11. dddddddd - Duration in minutes (ASCII Hex IEEE float)
12. RR - Temperature Change Rate Status Flag
00=UNKNOWN
01=VALID
02=COMPUTING
03=STABLE
13. rrrrrrrr - Temperature Rate Change, Degrees F/Hr (ASCII Hex IEEE float)
14. mmmmmmmm - Temperature Stable Time in minutes (ASCII Hex IEEE float)
15. LL - Leak Rate Status Flag
00=UNKNOWN
01=VALID
02=COMPUTING
16. llllllll - Leak Rate, Inches/Hr (ASCII Hex IEEE float)
17. && - Data Termination Flag
18. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 111
Function Code: 318 Version 26
Function Type: Mag Sump Leak Test Last Passed Test Report
Command Format:
Display: <SOH>I318ss
Computer: <SOH>i318ss
Typical Response Message, Display Format:
<SOH>
I318ss
FEB 21, 2005 10:50 AM
MAG SUMP LEAK TEST
LAST PASSED TEST
s 1:SUMP NUMBER 1
RESULT: TEST PASSED
START TIME:
FEB 19, 2005 9:43 AM
START HT: 20.971 IN.
START TEMP: 76.1 F
END HT: 20.971 IN.
END TEMP: 76.1 F
DURATION: 120 MINS
<ETX>
Typical Response Message, Computer Format:
<SOH>i318ssYYMMDDHHmmssttYYMMDDHHmmNNHHHHHHHHTTTTTTTT
hhhhhhhhttttttttdddddddd...
ssttYYMMDDHHmmNNHHHHHHHHTTTTTTTT
hhhhhhhhttttttttdddddddd&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. ss - Smart Sensor Number (Decimal, 00=all)
3. tt - Mag Sump Leak Test Status
00=NO TEST DATA AVAILABLE
01=LEAK TEST ABORTED
02=FILL SUMP
03=MEASURING HEIGHT
04=LEAK TEST PASSED
4. YYMMDDHHmm - Start Date/Time
5. NN - Number of 8 bytes data fields to follow (Decimal)
6. HHHHHHHH - Starting Height, Inches (ASCII Hex IEEE float)
7. TTTTTTTT - Starting Temperature, Degrees F (ASCII Hex IEEE float)
8. hhhhhhhh - Ending Height (ASCII Hex IEEE float)
9. tttttttt - Ending Temperature (ASCII Hex IEEE float)
10. dddddddd - Duration in minutes (ASCII Hex IEEE float)
11. && - Data Termination Flag
12. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 112
Function Code: 319 Version 26
Function Type: Mag Sump Leak Test Last 10 Test Passed Report
Command Format:
Display: <SOH>I319ss
Computer: <SOH>i319ss
Typical Response Message, Display Format:
<SOH>
I319ss
NOV 15, 2004 8:26 AM
MAG SUMP LEAK TEST
LAST 10 TEST PASSED
s 1:SUMP NUMBER 1
START START END END DURATION
START DATE/TIME HEIGHT TEMP HEIGHT TEMP MINUTES
JAN 19, 2005 9:43 AM 22.971 76.1 22.971 76.1 120
DEC 12, 2004 10:24 AM 22.344 75.4 22.338 75.3 120
MAY 3, 2004 1:18 PM 21.972 72.0 21.970 72.2 120
FEB 23, 2004 3:12 PM 21.065 76.2 21.061 76.2 120
<ETX>
Typical Response Message, Computer Format:
<SOH>i319ssYYMMDDHHmmssttYYMMDDHHmmNNHHHHHHHHTTTTTTTT
hhhhhhhhttttttttdddddddd...
YYMMDDHHmmNNHHHHHHHHTTTTTTTT
hhhhhhhhttttttttdddddddd...
ssttYYMMDDHHmmNNHHHHHHHHTTTTTTTT
hhhhhhhhttttttttdddddddd...
YYMMDDHHmmNNHHHHHHHHTTTTTTTT
hhhhhhhhttttttttdddddddd&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. ss - Smart Sensor Number (Decimal, 00=All)
3. tt - Number of Tests to follow (Max=10)
4. YYMMDDHHmm - Date/Time Test
5. NN - Number of 8 bytes data fields to follow
6. HHHHHHHH - Starting Height, Inches (ASCII Hex IEEE float)
7. TTTTTTTT - Starting Temperature, Degrees F (ASCII Hex IEEE float)
8. hhhhhhhh - Ending Height (ASCII Hex IEEE float)
9. tttttttt - Ending Temperature (ASCII Hex IEEE float)
10. dddddddd - Duration in minutes (ASCII Hex IEEE float)
11. && - Data Termination Flag
12. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 113
Function Code: 31A Version 26
Function Type: Mag Sump Leak Test Last Passed Each Year Report
Command Format:
Display: <SOH>I31Ass
Computer: <SOH>i31Ass
Typical Response Message, Display Format:
<SOH>
I31Ass
NOV 15, 2004 8:26 AM
MAG SUMP LEAK TEST
LAST PASSED EACH YEAR
s 1:SUMP NUMBER 1
START START END END DURATION
START DATE/TIME HEIGHT TEMP HEIGHT TEMP MINUTES
JAN 19, 2005 9:43 AM 22.971 76.1 22.971 76.1 120
FEB 12, 2004 10:24 AM 22.344 75.4 22.338 75.3 120
MAR 3, 2003 1:18 PM 21.972 72.0 21.970 72.2 120
JAN 23, 2002 3:12 PM 21.065 76.2 21.061 76.2 120
<ETX>
Typical Response Message, Computer Format:
<SOH>i31AssYYMMDDHHmmssttYYMMDDHHmmNNHHHHHHHHTTTTTTTT
hhhhhhhhttttttttdddddddd...
YYMMDDHHmmNNHHHHHHHHTTTTTTTT
hhhhhhhhttttttttdddddddd...
ssttYYMMDDHHmmNNHHHHHHHHTTTTTTTT
hhhhhhhhttttttttdddddddd...
YYMMDDHHmmNNHHHHHHHHTTTTTTTT
hhhhhhhhttttttttdddddddd&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. ss - Smart Sensor Number (Decimal, 00=All)
3. tt - Total Tests to follow (Max=3)
4. YYMMDDHHmm - Date/Time Test
5. NN - Number of 8 bytes data fields to follow
6. HHHHHHHH - Starting Height, Inches (ASCII Hex IEEE float)
7. TTTTTTTT - Starting Temperature, Degrees F (ASCII Hex IEEE float)
8. hhhhhhhh - Ending Height (ASCII Hex IEEE float)
9. tttttttt - Ending Temperature (ASCII Hex IEEE float)
10. dddddddd - Duration in minutes (ASCII Hex IEEE float)
11. && - Data Termination Flag
12. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 114
Function Code: 322 Version 27
Function Type: Pump Relay Monitor Status Report
Command Format:
Display: <SOH>I322rr
Computer: <SOH>i322rr
Typical Response Message, Display Format:
<SOH>
I322rr
JUN 22, 2006 3:12 PM
PUMP RELAY MONITOR STATUS REPORT
PUMP PUMP RELAY
DEVICE LABEL (OUT) (IN) STATUS
1 PUMP RELAY UNLEADED OFF Q 1: OFF NORMAL
<ETX>
Typical Response Message, Computer Format:
<SOH>i322rrYYMMDDHHmmrrabssss...
rrabssss&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. rr - Pump Relay Monitor Number (Decimal, 00=all)
3. a - Pump Status (ASCII Hex)
0=Off
1=On
4. b - Relay Status (ASCII Hex)
0=Off (or N/A B no Pump Relay assigned)
1=On
5. ssss - Number of 8-character data fields to follow (ASCII Hex)
0000=Normal
0001=Setup Data Warning
0002=Pump Relay Alarm
6. && - Data Termination Flag
7. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 115
Function Code: 323 Version 27
Function Type: Pump Relay Monitor Alarm History Report
Command Format:
Display: <SOH>I323rr
Computer: <SOH>i323rr
Typical Response Message, Display Format:
<SOH>
I323rr
JUN 22, 2006 3:12 PM
PUMP RELAY MONITOR ALARM HISTORY REPORT
DEVICE LABEL
PUMP RELAY UNLEADED
JUN 1, 2006 8:02 AM PUMP RELAY ALARM
<ETX>
Typical Response Message, Computer Format:
<SOH>i323rrYYMMDDHHmmrrNNYYMMDDHHmmaaaa...
rrNNYYMMDDHHmmaaaa&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. rr - Pump Relay Monitor Number (Decimal, 00=all)
3. NN - Number of Alarm Incidents to follow (ASCII Hex)
4. YYMMDDHHmm - Date and Time of Alarm
5. aaaa - Alarm Type number (ASCII Hex):
0001=Setup Data Warning
0002=Pump Relay Alarm
6. && - Data Termination Flag
7. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 116
Function Code: 333 Version 24
Function Type: Smart Sensor Install Log
Command Format:
Display: <SOH>I333SS
Computer: <SOH>i333SS
Typical Response Message, Display Format:
<SOH>
I333SS
JAN 22, 2003 3:25 PM
SMART SENSOR INSTALL LOG
DATE SENSOR SERIAL NUMBER TYPE
01-01-03 6:00:00 1 123456 MAG SENSOR
01-01-03 6:00:00 2 123457 FLOWMETER
<ETX>
Typical Response Message, Computer Format:
<SOH>i333SSYYMMDDHHmmnnnYYMMDDHHmmSSNNNNNNNNffff...
YYMMDDHHmmSSNNNNNNNNffff&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. nnn - Number of Events to Follow (Decimal)
3. YYMMDDHHmm - Date and Time of Install Event
4. SS - Smart Sensor Number (Decimal)
5. NNNNNNNN - Sensor Serial Number (ASCII Hex IEEE float)
6. ffff - Smart Sensor Model Number (ASCII Hex IEEE float)
7. && - Data Termination Flag
8. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 117
Function Code: 341 Version 2
Function Type: Type A (2 Wire CL) Sensor Status Report
Command Format:
Display: <SOH>I341SS
Computer: <SOH>i341SS
Typical Response Message, Display Format:
<SOH>
I341SS
FEB 18, 1990 10:53 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
2 WIRE CL STATUS REPORT
SENSOR LOCATION STATUS
1 2 WIRE CL SENSOR #1 FUEL ALARM
<ETX>
Typical Response Message, Computer Format:
<SOH>i341SSYYMMDDHHmmSSssss...
SSssss&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Sensor Number (Decimal, 00=all)
3. ssss - Sensor Status Value:
0000=Sensor Normal
0001=Sensor Setup Data Warning
0002=Sensor Fuel Alarm
0003=Sensor Out Alarm
0004=Sensor Short Alarm
0005=Sensor Water Alarm
0006=Sensor Water Out Alarm
0007=Sensor High Liquid Alarm
0008=Sensor Low Liquid Alarm
0009=Sensor Liquid Warning
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 118
Function Code: 342 Version 2
Function Type: Type A (2 Wire CL) Sensor Alarm History Report
Command Format:
Display: <SOH>I342SS
Computer: <SOH>i342SS
Typical Response Message, Display Format:
<SOH>
I342SS
FEB 18, 1990 10:53 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
2 WIRE CL ALARM HISTORY REPORT
SENSOR LOCATION
1 2 WIRE CL SENSOR #1
FEB 12, 1990 11:32 AM FUEL ALARM
FEB 10, 1990 10:09 AM OPEN ALARM
<ETX>
Typical Response Message, Computer Format:
<SOH>i342SSYYMMDDHHmmSSNNYYMMDDHHmmaaaa...
SSNNYYMMDDHHmmaaaa&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Sensor Number (Decimal, 00=all)
3. NN - Number of Alarm Incidents to follow
4. YYMMDDHHmm - Date and Time of Alarm
5. aaaa - Alarm type number:
0001=Sensor Setup Data Warning
0002=Sensor Fuel Alarm
0003=Sensor Out Alarm
0004=Sensor Short Alarm
0005=Sensor Water Alarm
0006=Sensor Water Out Alarm
0007=Sensor High Liquid Alarm
0008=Sensor Low Liquid Alarm
0009=Sensor Liquid Warning
6. && - Data Termination Flag
7. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 119
Function Code: 346 Version 2
Function Type: Type B (3 Wire CL) Sensor Status Report
Command Format:
Display: <SOH>I346SS
Computer: <SOH>i346SS
Typical Response Message, Display Format:
<SOH>
I346SS
FEB 18, 1990 10:53 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
3 WIRE CL STATUS REPORT
SENSOR LOCATION STATUS
1 3 WIRE CL SENSOR #1 FUEL ALARM
<ETX>
Typical Response Message, Computer Format:
<SOH>i346SSYYMMDDHHmmSSssss...
SSssss&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Sensor Number (Decimal, 00=all)
3. ssss - Sensor Status Value:
0000=Sensor Normal
0001=Sensor Setup Data Warning
0002=Sensor Fuel Alarm
0003=Sensor Out Alarm
0004=Sensor Short Alarm
0005=Sensor Water Alarm
0006=Sensor Water Out Alarm
0007=Sensor High Liquid Alarm
0008=Sensor Low Liquid Alarm
0009=Sensor Liquid Warning
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 120
Function Code: 347 Version 2
Function Type: Type B (3 Wire CL) Sensor Alarm History Report
Command Format:
Display: <SOH>I347SS
Computer: <SOH>i347SS
Typical Response Message, Display Format:
<SOH>
I347SS
FEB 18, 1990 10:53 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
3 WIRE CL ALARM HISTORY REPORT
SENSOR LOCATION
1 3 WIRE CL SENSOR #1
FEB 12, 1990 11:32 AM FUEL ALARM
FEB 10, 1990 10:09 AM OPEN ALARM
<ETX>
Typical Response Message, Computer Format:
<SOH>i347SSYYMMDDHHmmSSNNYYMMDDHHmmaaaa...
SSNNYYMMDDHHmmaaaa&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Sensor Number (Decimal, 00=all)
3. NN - Number of Alarm Incidents to follow
4. YYMMDDHHmm - Date and Time of Alarm
5. aaaa - Alarm type number:
0001=Sensor Setup Data Warning
0002=Sensor Fuel Alarm
0003=Sensor Out Alarm
0004=Sensor Short Alarm
0005=Sensor Water Alarm
0006=Sensor Water Out Alarm
0007=Sensor High Liquid Alarm
0008=Sensor Low Liquid Alarm
0009=Sensor Liquid Warning
6. && - Data Termination Flag
7. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 121
Function Code: 34B Version 4
Function Type: Universal Sensor Status Report
Command Format:
Display: <SOH>I34BSS
Computer: <SOH>i34BSS
Typical Response Message, Display Format:
<SOH>
I34BSS
FEB 18, 1990 10:53 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
UNIVERSAL STATUS REPORT
SENSOR LOCATION STATUS
1 UNIVERSAL SENSOR #1 FUEL ALARM
<ETX>
Typical Response Message, Computer Format:
<SOH>i34BSSYYMMDDHHmmSSssss...
SSssss&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Sensor Number (Decimal, 00=all)
3. ssss - Sensor Status Value:
0000=Sensor Normal
0001=Sensor Setup Data Warning
0002=Sensor Fuel Alarm
0003=Sensor Out Alarm
0004=Sensor Short Alarm
0005=Sensor Water Alarm
0006=Sensor Water Out Alarm
0007=Sensor High Liquid Alarm
0008=Sensor Low Liquid Alarm
0009=Sensor Liquid Warning
4. && - Data Termination Flag
5. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 122
Function Code: 34C Version 4
Function Type: Universal Sensor Alarm History Report
Command Format:
Display: <SOH>I34CSS
Computer: <SOH>i34CSS
Typical Response Message, Display Format:
<SOH>
I34CSS
FEB 18, 1990 10:53 AM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
UNIVERSAL ALARM HISTORY REPORT
SENSOR LOCATION
1 UNIVERSAL SENSOR 1
FEB 12 1990 11:32 AM FUEL ALARM
FEB 10 1990 10:09 PM OPEN ALARM
<ETX>
Typical Response Message, Computer Format:
<SOH>i34CSSYYMMDDHHmmSSNNYYMMDDHHmmaaaa...
SSNNYYMMDDHHmmaaaa&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. SS - Sensor Number (Decimal, 00=all)
3. NN - Number of Alarm Incidents to follow
4. YYMMDDHHmm - Date and Time of Alarm
5. aaaa - Alarm type number:
0001=Sensor Setup Data Warning
0002=Sensor Fuel Alarm
0003=Sensor Out Alarm
0004=Sensor Short Alarm
0005=Sensor Water Alarm
0006=Sensor Water Out Alarm
0007=Sensor High Liquid Alarm
0008=Sensor Low Liquid Alarm
0009=Sensor Liquid Warning
6. && - Data Termination Flag
7. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 123
7.2.4 LINE LEAK REPORTS
Function Code: 351 Version 1
Function Type: Volumetric Line Leak Result Report
Command Format:
Display: <SOH>I351PP
Computer: <SOH>i351PP
Typical Response Message, Display Format:
<SOH>
I351PP
MAR 26, 1996 1:55 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
P 1:REGULAR UNLEADED
3.0 GAL/HR TEST LINE SELF PUMP
PREV 24 HOURS 104 104 111
SINCE MIDNIGHT 53 53 56
0.2 GAL/HR TEST
MAR 25, 1996 8:14 PM PASSED
MAR 25, 1996 2:02 AM PASSED
MAR 24, 1996 2:20 AM PASSED
0.1 GAL/HR TEST
MAR 26, 1996 1:48 AM PASSED
MAR 25, 1996 4:11 AM PASSED
MAR 24, 1996 3:25 AM PASSED
<ETX>
Typical Response Message, Computer Format:
<SOH>i351PPYYMMDDHHmmPPLLSSBBllssbbNNYYMMDDHHmmRR...nnYYMMDDHHmmRR...
PPLLSSBBllssbbNNYYMMDDHHmmRR...nnYYMMDDHHmmRR&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. PP - Pipeline Number (Decimal, 00=all)
3. LL - 3.00 GPH Line tests passed in previous 24 hours (Hex)
4. SS - 3.00 GPH Self tests passed in previous 24 hours (Hex)
5. BB - 3.00 GPH Pumpside tests passed in previous 24 hours (Hex)
6. ll - 3.00 GPH Line tests passed since midnight (Hex)
7. ss - 3.00 GPH Self tests passed since midnight (Hex)
8. bb - 3.00 GPH Pumpside tests passed since midnight (Hex)
9. NN - Number of 0.20 GPH test date entries to follow (Decimal)
10. YYMMDDHHmm - Date and Time of test
11. RR - Test result (00=fail, 01=pass)
12. nn - Number of 0.10 GPH test date entries to follow (Decimal)
13. YYMMDDHHmm - Date and Time of test
14. RR - Test result (00=fail, 01=pass)
15. && - Data Termination Flag
16. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 124
Function Code: 352 Version 1
Function Type: Volumetric Line Leak Alarm History Report
Command Format:
Display: <SOH>I352PP
Computer: <SOH>i352PP
Typical Response Message, Display Format:
<SOH>
I352PP
MAR 26, 1996 1:55 PM
STATION HEADER 1....
STATION HEADER 2....
STATION HEADER 3....
STATION HEADER 4....
P 1:REGULAR UNLEADED
DEC 24, 1991 9:51 PM LINE LEAK SHUTDOWN
DEC 23, 1991 9:46 PM LLD SELF TEST FAIL
DEC 22, 1991 9:31 PM LINE LEAK TEST FAIL
<ETX>
Typical Response Message, Computer Format:
<SOH>i352PPYYMMDDHHmmPPNNYYMMDDHHmmaaaa...
PPNNYYMMDDHHmmaaaa&&CCCC<ETX>
Notes:
1. YYMMDDHHmm - Current Date and Time
2. PP - Pipeline Number (Decimal, 00=all)
3. NN - Number of Alarm entries to follow (Decimal)
4. YYMMDDHHmm - Date and Time of Alarm
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 125
Function Code 352 Notes: (Continued)
5. aaaa - Alarm type code:
0001=VLLD Setup Data Warning
0002=VLLD Self Test Alarm
0003=VLLD Shutdown Alarm
0004=VLLD Leak Test Fail Alarm
0005=VLLD Selftest Invalid Warning
0006=VLLD Continuous Handle On Warning
0007=VLLD Gross Line Test Fail Alarm
0008=VLLD Gross Line Selftest Fail Alarm
0009=VLLD Gross Pump Test Fail Alarm
000A=VLLD Gross Pump Selftest Fail Alarm
000B=VLLD Periodic Test Needed Warning
000C=VLLD Annual Test Needed Warning
000D=VLLD Periodic Test Needed Alarm
000E=VLLD Annual Test Needed Alarm
000F=VLLD Periodic Line Test Fail Alarm
0010=VLLD Periodic Line Selftest Fail Alarm
0011=VLLD Periodic Pump Test Fail Alarm
0012=VLLD Periodic Pump Selftest Fail Alarm
0013=VLLD Annual Line Test Fail Alarm
0014=VLLD Annual Line Selftest Fail Alarm
0015=VLLD Annual Pump Test Fail Alarm
0016=VLLD Annual Pump Selftest Fail Alarm
0017=VLLD Pressure Warning
0018=VLLD Pressure Alarm
0019=VLLD Gross Test Fault Alarm
001A=VLLD Periodic Test Fault Alarm
001B=VLLD Annual Test Fault Alarm
001C=VLLD Fuel Out Alarm
6. && - Data Termination Flag
7. CCCC - Message Checksum
Serial Interface Manual
TLS-300/350/350R Monitoring Systems
Part No. 576013-635, Revision AA 126
Function Code: 353 Version 2
Function Type: Volumetric Line Leak Pump Status
Command Format:
