titanium
The sound of innovation.
GENERALMUSIC spa via delle Rose, 12 S. Giovanni M. (RN) 47842, Italy tel. +39 0541.959511 fax + 39 0541.957404 www.lemaudio.com
ENG Generalmusic reserves the right to make any aesthetic, functional or design modification to any of its products without any prior notice.
marco morosini
TECHNICAL SPECIFICATIONS
T3A/T4A/T5A/T6A preset list
LEM INDOOR
LEM OUTDOOR
FLAT
ENTERTAIN
MAX LOUD
CD PLAYER
WALL MOUNT
STAGE MONITOR
LEM INDOOR SW
LEM OUTDOOR SW
FLAT SW
ENTERTAIN SW
MAX LOUD SW
CD PLAYER SW
WALL MOUNT SW
MIC PLUG&PLAY
T5SA preset list
d400
d400 HOUSE
2xT3A + 2 x T5SA
2xT3A + 1 x T5SA
T4A
T4A HOUSE
T5A/T6A
T5A/T6A HOUSE
T4MA
T5MA
80Hz
100Hz
120Hz
140Hz
160Hz
180Hz
T4MA/T5MA preset list
FULL RANGE
VOCAL 1
VOCAL 2
DRUMFILL+SW
GUITAR
PIANO
PAIR
ONSTAGE
The same presets
are also available
with plug-in
ANTI-FEEDBACK
activated.
loudspeaker specifications
T200 / T3A T300 / T4A T400 / T5A T500 / T6A T4MA T5MA T5SA
power handling
(EIA RS-426A)
impedance
passive crossover
connections (passive version)
construction
dimension
weight (passive / active)
processor/amplifier specifications T3A T4A T5A T6A T4MA T5MA T5SA
output power EIA
(1kHz, max THD 1%)
input sensitivity
input impedance
A/D converters
active crossover
alignment delay
plug-in
distortion
controls
connections
power supply
system specifications T200 / T3A T300 / T4A T400 / T5A T500 / T6A T4MA T5MA T5SA
SPL MAX continuous
frequency response (-10 dB)
dispersion (OxV)
D/A converters
components
protections
eq
-
8" midrange
10" woofer 12" neodymium woofer 15" neodymium woofer 15" neodymium woofer 12" woofer 15" woofer 15" neodymium woofer
200W continuous
400W peak
300W continuous
600W peak
400W continuous
800W peak
500W continuous
1000W peak
8 Ohm 4 / 8 Ohm 4 / 8 Ohm 4 / 8 Ohm
LP: 12dB/ott. @ 3kHz
HP: 18dB/ott. @ 3kHz
LP: 12dB/ott. @ 2.5kHz
HP: 18dB/ott. @ 2.5kHz
LP: 12dB/ott. @ 2kHz
HP: 18dB/ott. @ 2kHz
LP: 12dB/ott. @ 5.8kHz
HP: 6dB/ott. @ 5.8kHz
LP: 18dB/ott. @ 800Hz
HP: 12dB/ott. @ 800Hz
357x490x355 400x608x390 452x690x430 452x804x430 506x326x422 586x356x495 466x600x600
14,5 / 22 17,5 / 25 22,5 / 32 28 / 37 26 33,5 43,5
100W high
200W low
100W high
300W low
100W high
400W low
200W high
400W low
50W high
250W low
100W high
350W low 500W
2 x XLR-F + 2 x XLR-M
120 dB 123 dB 124 dB 126 dB 122 dB 124 dB 125 dB
60Hz - 20kHz 55Hz - 20kHz 50Hz - 20kHz 45Hz - 20kHz 55Hz - 20kHz 50Hz - 20kHz 40Hz - 160Hz
90˚ x 65˚ 100˚ x 60˚ 100˚ x 60˚ 90˚ x 65˚ 80˚ x 80˚ 80˚ x 80˚ -
-
-
25 parametric bands
peak, 6dB lo-shelf, 12dB lo-shelf, 6dB hi-shelf, 12dB lo-shelf, notch
gain+/-15dB, variable with 0.5dB step
bandwidth from 0.05 to 3.00 octave, variable with 0.05 step
frequency from 15.6 Hz to 16 kHz
Independent peak limiter on each output
Long term power protection on each output
LFC - Low Frequency Control
24 bit
dynamic range 100 dB
sampling rate 48kHz
-
-
-
0 dB (0.775V)
30 kOhm (balanced) - 15 kOhm (unbalanced)
1" compression driver with titanium diaphragm 1" coaxial driver
-
Laminated beech plywood with black scratch-resistant paint - Metal grid - Metal handles and speaker stand adapter
1/2 x SPEAKON
max delay 200 mm
noise gate, anti-feedback, multiband compressor
24 bit
1 x COMBO + 1 x XLR-M
see label
type Bessel, Butterworth or Linkwitz-Riley
variable from 15.6 Hz to 16 kHz
6, 12, 18 o 24 dB per otcave
<0.02 %
volume - PRESET select - shield on/off
titanium
the sound of innovation.
Titanium series by LEM is a loudspeaker system line in beech plywood cabinets that combines
professional features and state-of-the-art performance with the most advanced technology.
Each part of the project, from custom made loudspeakers, to oversized amplifiers and cabinet construction
has been carefully designed for the optimum performance and maximum sound quality in every situation.
Beyond this, the active versions of titanium speakers are equipped with one of the most innovative
digital control systems for loudspeakers. Thanks to 40bit resolution and 24bit low-noise conversion,
the titanium digital processor is able to perform, with very high precision, all the processing features
needed for the best acoustic performance. The titanium series consists of 11 models, which include
4 passives, 4 actives, a sub-woofer and two active stage monitors. These have been designed to be used
either as mobile systems in LIVE and DJ applications or as a fixed systems in small and medium sized
public venues, clubs, conference rooms and theatres.
T4MA and T5MA stage monitors
Titanium series includes two stage monitors, T4MA and T5MA,
which use coaxial speakers and are housed in small-size,
low-profile cabinets that can be ‘invisible’ on any stage.
Both models have the choice of two different set-ups when placed
on stage (35° or 55°), according to the distance of the listener
from the monitor. Even T4MA and T5MA, thanks to the integrated
digital processor, offer the choice of 16 different presets prepared
to provide the monitors with diverse acoustic and dynamic
responses according to the instruments used. The monitors can
be coupled also to the T5SA sub-woofer to obtain full-range,
high-efficiency drum-fill systems.
speakers
The HF section uses a 1” compression driver with titanium diaphragm, which provides higher reliability and greater sound
brilliance than those made in traditional materials. The wide dispersion horns provide the maximum coverage without distortion.
All woofers are custom made to LEM’s specifications and they offer greater power handling and efficiency. Neodymium, used on
the woofer’s magnet, guarantees high quality acoustic performance whilst, at the same time, reduces the total weight of the cabinet.
passive versions
The titanium passive versions (T200, T300, T400 and T500) are equipped with crossover filters made with selected components,
for an optimal frequency distribution, and with a sophisticated electronic protection circuit to prevent the overload of the HF driver.
All models, T200 excluded, are available with 4 or 8 Ohm impedance.
T3A / T200
Two way system
1” compression driver
with titanium diaphragm
10” woofer
Amplifier 100+200W (T3A)
Power handling 200W (T200)
T4A / T300
Two way system
1” compression driver
with titanium diaphragm
12” neodymium woofer
amplifier 100+300W (T4A)
power handling 300W (T300)
T5A / T400
Two way system
1” compression driver
with titanium diaphragm
15” neodymium woofer
amplifier 100+400W (T5A)
power handling 400W (T400)
T5SA
Sub-woofer
15” neodymium woofer
amplifier 500W
T4MA
Two way stage monitor
coaxial loudspeaker
1” compression driver
12” woofer
amplifier 50+250W
T6A / T500
Three way system
1” compression driver
with titanium diaphragm
8” midrange
15” neodymium woofer
amplifier 200+400W (T6A)
power handling 500W (T500)
T5MA
Two way stage monitor
coaxial loudspeaker
1” compression driver
15” woofer
amplifier 100+350W
cabinets
Titanium cabinets are made with 13-layer beech plywood,
which combines light weight with strength and high durability.
They are finished with black scratch-resistant paint and are
protected with 1,5 mm metal grid with an exclusive design
and double folding for an improved stiffness. Each model includes
one or two metal handles and a metal speaker stand adaptor.
In the 10” and 12” models also included are 4 M8 flying points
for wall or ceiling mounting using simple chains or steel cables
or the more suitable LEM accessories SC41 (T4A and T300)
and SC42 (T3A and T200).
SC41 SC42
T5SA sub-woofer
T5SA sub-woofer uses a special 15” neodymium woofer with
a 4” moving coil, able to give the greatest excursion, efficiency
and power handling. T5SA includes a series of PRESETS with
crossover and EQ settings for the perfect match with each model
of titanium, including stage monitors. Moreover, there is a series
of generic PRESETS with crossovers at different frequencies,
which allow T5SA to be used with other brands of satellites.
To make transportation easier the T5SA has two metal handles
and 4 wheels on the rear panel.
The titanium active versions are equipped with bi-amplified modules
(class H for low section and class AB for high section), able to deliver
to the transducers continuous power with a very high dynamic reserve
and efficiency. Each amplification module includes a dedicated digital
processor based on LEM’s RED208 proprietary DSP, one of the most
advanced DSPs in the world especially designed for digital audio
applications. With high fidelity sound and a huge processing power, the
processor offers an impressive set of functions, including high-precision
EQ and CROSSOVER filters, delay lines for a perfect loudspeaker
alignment and a multi-function protection system for maximum durability
and reliability. In addition, thanks to digital processing, all titanium active
models offer the possibility to choose between 16 different PRESETS,
prepared by LEM’s technicians and sound engineers to provide the speakers with diverse acoustic and dynamic responses for all
kinds of usage and personal requirements. Unlike usual active speakers, thanks to the available presets, the titanium speakers give
you whatever kind of sound you need in any situation. The presets can be selected from the control panel and consist of
diverse equalizations and DSP settings, which also allows the different titanium models to be used with the active sub-woofer T5SA.
technology
red 208
Stage monitor a due vie
Altoparlante coassiale
Driver a compressione da 1”
Woofer da 15”
Amplificatore 100+350W
