Huawei Technologies M636 CDMA 1X Mobile Phone User Manual M636

Huawei Technologies Co.,Ltd CDMA 1X Mobile Phone M636

Contents

(M636)User Manual

Copyright © Huawei Technologies Co., Ltd. 2012.
All rights reserved.
No part of this document may be reproduced or
transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
The product described in this manual may include
copyrighted software of Huawei Technologies Co., Ltd.
and possible licensors. Customers shall not in any manner
reproduce, distribute, modify, decompile, disassemble,
decrypt, extract, reverse engineer, lease, assign, or
sublicense the said software, unless such restrictions are
prohibited by applicable laws or such actions are
approved by respective copyright holders under licenses.
Trademarks and Permissions
, , and are trademarks or
registered trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names
mentioned are the property of their respective owners.
Notice
Some features of the product and its accessories
described herein rely on the software installed, capacities
and settings of local network, and may not be activated
or may be limited by local network operators or network
service providers. Thus the descriptions herein may not
exactly match the product or its accessories you purchase.
Huawei Technologies Co., Ltd. reserves the right to
change or modify any information or specifications
contained in this manual without prior notice or
obligation.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED "AS IS".
EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO
WARRANTIES OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE
ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE
LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO.,
LTD. BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT,
OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS,
BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED
SAVINGS.
Import and Export Regulations
Customers shall comply with all applicable export or
import laws and regulations and will obtain all necessary
governmental permits and licenses in order to export, re-
export or import the product mentioned in this manual
including the software and technical data therein.
Safety Precautions
Please read the safety precautions carefully to ensure the
correct use of your mobile phone.
Do not crash, throw, or puncture your mobile
phone. Avoid the falling, squeezing, and
bending of your mobile phone.
Do not use your mobile phone in a moist
environment, such as the bathroom. Prevent
your mobile phone from being soaked or
washed in liquid.
Do not switch on your mobile phone when it
is prohibited to use phones or when the
phone may cause interference or danger.
Do not use your mobile phone while driving.
Follow any rules or regulations in hospitals
and health care facilities. Switch off your
mobile phone near medical apparatus.
Switch off your mobile phone in aircraft. The
phone may cause interference to control
equipment of the aircraft.
Switch off your mobile phone near high-
precision electronic devices. The phone may
affect the performance of these devices.
Do not attempt to disassemble your mobile
phone or its accessories. Only qualified
personnel are allowed to service or repair the
phone.
Do not place your mobile phone or its
accessories in containers with a strong
electromagnetic field.
Do not place magnetic storage media near
your mobile phone. Radiation from the phone
may erase the information stored on them.
Do not put your mobile phone in a high-
temperature place or use it in a place with
flammable gas such as a gas station.
Keep your mobile phone and its accessories
away from children. Do not allow children to
use your mobile phone without guidance.
Use only approved batteries and chargers to
avoid the risk of explosions.
Observe any laws or regulations on the use of
wireless devices. Respect others' privacy and
legal rights when using your wireless device.
Strictly follow the relevant instructions of this
manual while using the USB cable. Otherwise
your mobile phone or PC may be damaged.
i
Contents
1 Getting Started ............................................................. 1
Installing the microSD Card and the Battery ................. 1
Charging the Battery .................................................... 1
Your Phone ................................................................... 2
Keys and Functions ....................................................... 3
Screen Icons ................................................................. 6
2 Call Functions ................................................................ 8
Making a Call................................................................ 8
Answering a Call ........................................................... 9
3 Text Input ..................................................................... 9
Changing the Text Input Mode ..................................... 9
Entering English and Spanish ...................................... 10
Entering a Number or a Symbol .................................. 10
4 Contacts ...................................................................... 10
Adding a Contact ........................................................ 10
Searching for a Contact .............................................. 11
5 Messaging .................................................................. 11
6 @metro App Store ....................................................... 11
Accessing @metro App Store ...................................... 12
Changing Your @metro App Store Settings ................. 12
Using On-line Help ...................................................... 13
7 Media Applications ..................................................... 13
Taking a Picture .......................................................... 13
Recording a Video ...................................................... 13
Playing a Video ........................................................... 14
Playing Music ............................................................. 14
Recording an Audio clip .............................................. 15
8 Bluetooth® ................................................................... 15
ii
9 Security ....................................................................... 16
Keypad Lock ............................................................... 16
Phone Lock ................................................................. 16
10 TTY Operation ........................................................... 17
Using the TTY Device .................................................. 17
Setting the TTY Mode ................................................. 17
11 Troubleshooting ........................................................ 18
12 Warnings and Precautions ........................................ 19
1
1 Getting Started
Installing the microSD Card and the Battery
All the pictures in this guide are provided for your reference
only.
Please read the section "Warnings and Precautions" before
using your phone for safety tips and precautions.
Charging the Battery
When the battery icon changes to or the charging
animation becomes static, the battery is fully charged.
If the battery charge is fully depleted, it may take several
minutes for the phone to display the charging icon after the
charger is plugged in.
2
Your Phone
1
Earpiece
2
3
Volume key
4
5
Data/Charger
connector
6
3
7
Camera
8
Keys and Functions
1
2
3
4
6 7
8
9
1415
10
11
12
1316
5
In this guide, the navigation keys of the phone are indicated by
, , and . The left soft key is indicated by
, and the right soft key is indicated by .
4
No.
Press...
To...
1
Dial a number or answer a call.
Access Call Logs in standby mode.
2
Turn the speaker on or off (press and
hold the key for about 3 seconds).
3
Press the key and another key to
enter the upper character on the
other key in editing mode.
Press the key for consecutive times
to switch between text input
methods in editing mode.
4
Switch between "abc/en" mode (lower
case), "Abc/En" mode (capitalization of
the first letter), and "ABC/EN" mode
(upper case) in editing mode.
5
Lock the keypad in standby mode
(press and hold the key for about 3
seconds).
Enter the number 0.
5
No.
Press...
To...
6
Switch between Vibration mode and
the current profile mode in standby
mode (press and hold the key for
about 3 seconds).
Enter a space in editing mode.
7
Access the camera in standby mode
(press and hold the key for about 3
seconds).
Access the symbol list in editing
mode.
8
Access the application assigned to the
key in standby mode.
To assign the application, select
Menu > Settings > Phone > Smart Key.
9
Start a new line in editing mode.
10
Delete characters in editing mode or
delete selected items in an application.
11
Go back to the previous screen.
6
No.
Press...
To...
12
Power the phone on or off (press
and hold the key for about 3
seconds).
End or reject a call.
Return to standby mode.
13
Select the option displayed in the lower
right corner of the screen.
14
Confirm a selection.
15
Access the functions assigned to the
navigation keys in standby mode.
Scroll through a menu.
16
Select the option displayed in the lower
left corner of the screen.
Screen Icons
Screen icons listed in the following table indicate the
current status of your phone. They are provided for your
reference only.
For more icon information, select Menu > Settings >
Phone > Phone Info > Icon Glossary.
7
Icon
Indicates...
Signal strength of the code division multiple
access (CDMA) 1X network.
Airplane Mode activated.
Roaming state.
Music player playing in the background.
New text message received.
The memory for text messages is full.
New multimedia message received.
The memory for multimedia messages is full.
The microSD card installed.
Location on.
Headset connected.
Speaker on.
Alarm clock enabled.
Bluetooth on.
8
Icon
Indicates...
Ringing mode activated.
Silence mode activated.
Vibration mode activated.
Ringing and Vibration mode activated.
Battery level.
2 Call Functions
Making a Call
1. In standby mode, press the number keys to enter a
phone number.
To make an international call, press to enter the
plus sign (+). Then enter the country or region code,
area code, and phone number.
To call an extension number, enter the switchboard
number, press to enter P or press to enter T,
and enter the extension number.
2. Press to dial the number.
3. Press to end the call or cancel the dialing.
If P is entered between the switchboard number and the
extension number, the phone will prompt you to call the
9
extension number after the call to the switchboard number is
connected.
If T is entered between the switchboard number and the
extension number, the phone automatically dials the
extension number after the call to the switchboard number is
connected.
Answering a Call
When you receive an incoming call, press to answer
it or to reject it.
If the Any Key answer function is enabled, you can press
any key except and to answer a call. To set
this function, select Menu > Settings > Call > Answer
Mode > Any Key.
3 Text Input
Changing the Text Input Mode
The current text input mode indicator is displayed in the
upper right corner of the text input screen. To switch
between the text input modes, repeatedly press .
You can select Menu > Settings > Phone > Text Input
Settings to change the input language or predictive input
mode.
When entering text, press to delete the character to the left
of the cursor, press and hold to delete all the characters to
the left of the cursor.
10
Entering English and Spanish
In multi-tap text input mode, press the key labeled with
the desired letter to enter the letter on the key.
In predictive input mode:
1. Press each key according to the spelling sequence of
the desired word. The phone displays candidate words
that may be spelt by the keystroke sequence.
2. Press or to scroll to the desired word.
3. Press to enter the desired word, or to
enter the word followed by a space.
Entering a Number or a Symbol
In number input mode, press the key labeled with the
desired number or symbol to enter it.
In any text input mode other than the number input
mode, press and then press the number or symbol
key, or press and hold the number or symbol key until
the number or symbol appears on the screen.
In any text input mode, press to display the symbol
list. Press to scroll to the desired symbol. Then
press or to enter the symbol.
4 Contacts
Adding a Contact
1. Select Menu > Contacts > Create Contact.
2. Edit the contact information.
3. Press or to save the contact.
11
Searching for a Contact
1. Select Menu > Contacts.
2. Enter the contact name, or the first several letters of a
contact name.
3. Press and to scroll to the contact.
5 Messaging
1. Select Menu > Messages > Create Message.
2. Add recipients by entering the phone numbers, or press
and then select the recipients from Contacts.
3. Edit the message.
You can select Options > Insert Object to add picture, audio,
video or other attachments to the message, and the message will
be converted to MMS (Multimedia Message Service) mode
automatically.
4. Select Options > Send to send the message.
6 @metro App Store
With @metro App Store, you can download full featured
applications over the air including games, personalized
ring tones, pictures, and more. You can send and receive
instant messages and email, or browse the web to catch
up on all the latest news.
This section outlines how to obtain games and other
applications for your phone. For more information about
this function, consult your service provider.
12
Accessing @metro App Store
Download games, ring tones, email, and more using the
@metro App Store. For information on airtime charges,
consult your service provider.
To access the @metro App Store, select Menu > @metro >
@metro App Store.
Your phone takes a moment to connect, then the Catalog
menu appears in the display. You can follow the
instructions in your phone's display.
The first time you access the @metro App Store, an "airtime
warning" message appears in the display along with
instructions on how to remove this message.
Please check with your Wireless Carrier for availability of
applications.
Changing Your @metro App Store Settings
Use the Settings menu in @metro App Store to manage,
move, order applications, and much more.
1. Select Menu > @metro > Settings. The following
options appear in the display:
Order Apps: Download applications over the network.
Move Apps: Move previously downloaded
applications between available folders.
Manage Apps: View used and available memory.
Main Menu View: Select whether you wish to view
the @metro App Store menu in a list or icon format.
13
View Log: View the @metro App Store log, which
displays information about recent activity using
@metro App Store.
2. Press and to select the desired option.
3. Press to enter the option's sub-menu and view or
change settings.
Using On-line Help
The Help sub-menu within @metro App Store is a short
tutorial on several @metro App Store features. View
information about charges, cancelling subscriptions,
buying apps, disabling apps, and more.
1. Select Menu > @metro > Help. The help subjects appear
in the display.
2. Press and to select the desired help subject.
3. Press to view the selected help information.
7 Media Applications
Taking a Picture
1. Press and hold for about 3 seconds in standby
mode.
2. Press to configure the camera settings.
3. Press to take a picture.
You can select Options > Shooting Mode to switch between
camera mode and video camera mode.
Recording a Video
1. Select Menu > Camcorder.
14
2. Press to configure the relevant settings.
3. Press to start recording. While recording, you can
press to pause, and again to resume recording.
4. Press to stop recording.
Playing a Video
Select Menu > File Mgmt > My Videos, then select a video
file and press to play it.
While the video is playing:
Press to pause or continue playing.
Press to play the next video. Press and hold
for about 3 seconds to fast-forward the video.
Press to play the previous video. Press and hold
for about 3 seconds to rewind the video.
Press the volume key to adjust the volume.
Press to exit the video player.
Playing Music
A microSD card must be installed in the phone before using the
music player.
1. Select Menu > Music Player > Options > Media
Library > Playlist.
2. Select Options > Create to create a new playlist.
3. Open the playlist and select Add to add songs to the
playlist.
4. Select a music file and press to play it.
While the music is playing:
15
Press to pause or continue playing.
Press to play the next song. Press and hold
for about 3 seconds to fast-forward the song.
Press to play the previous song. Press and hold
for about 3 seconds to rewind the song.
Press the volume key to adjust the volume.
Press to exit the music player screen and play
music in the background.
Select Options > Exit to exit the music player.
Recording an Audio clip
1. Select Menu > Organizer > Recorder.
2. Press to start recording. While recording, you can
press to pause, and again to resume recording.
3. Press to stop recording.
4. Press to play the recording.
To ensure an optimal audio effect, keep your phone's
microphone close to the sound source when recording.
8 Bluetooth®
Your phone supports Bluetooth. You can transfer data
between your phone and other Bluetooth devices and talk
on the phone using a Bluetooth headset.
1. Select Menu > Organizer > Bluetooth.
2. Select Bluetooth > On to enable the Bluetooth function.
3. Select Search for Devices to search for available
Bluetooth devices, then pair your phone with the
16
desired device.
When a Bluetooth device is found for the first time,
authentication is required.
A Bluetooth headset is not included in the product package
and must be purchased separately. Before using a Bluetooth
headset, refer to the user manuals of the relevant devices.
4. After the authentication, you can exchange data
between your phone and the other Bluetooth device.
9 Security
Keypad Lock
When the keypad is locked, you can still press to answer a
call or make an emergency call.
To lock the keypad, press and hold for about 3
seconds in standby mode. To unlock the keypad, press
, then .
If the Auto Keypad Lock function is enabled, the phone's
keypad will automatically lock after being idle in standby
mode for a pre-defined period. To set this function, select
Menu > Settings > Phone > Auto Keypad Lock.
Phone Lock
The phone lock protects your phone from unauthorized
use.
By default, the phone lock is disabled. To enable or
17
disable the phone lock, select Menu > Settings >
Security > Phone Lock.
Once you enable the phone lock, you must enter the
password. The default password to unlock your phone is
0000, and it can be changed to any numeric string of four
to eight digits in length. To change the password, select
Menu > Settings > Security > Change Phone Lock Code.
10 TTY Operation
Using the TTY Device
The Teletypewriter (TTY) is a typewriting device. By
connecting the phone to the TTY device, you can use the
TTY functions to send/receive messages.
When you use the TTY function, do as follows:
1. Set the phone to the TTY mode and connect the TTY
device to the headset jack of the phone.
2. Make or answer calls as normal.
3. When the call is put through, use the TTY device to
send or receive the letters.
4. Press to end the call.
Setting the TTY Mode
Select Menu > Settings > Phone > TTY Settings to set the
TTY mode as follows:
TTY OFF: The standard voice speaking mode and the
listening mode.
TTY FULL: Transmit and receive the TTY characters.
TTY VCO: Receive TTY characters but transmit by
18
speaking into the microphone.
TTY HCO: Transmit TTY characters but receive by
listening to the earpiece.
11 Troubleshooting
If you encounter any problem when using your phone, try
to rectify the problem according to the following table. If
the problem persists, contact the service provider or the
dealer.
Problem
Ensure that...
The battery
cannot be
charged.
The charger is properly connected to
your phone and the power socket.
The phone
cannot be
powered on.
The battery power is sufficient.
The battery is properly installed.
Press and hold .
You cannot
make a call
except an
emergency call.
The phone number is correct.
You are in the network service
area.
You have not enabled the call
restriction function.
Bad call quality.
The signal strength is strong
enough.
If you are staying indoors, move
close to a window.
19
Problem
Ensure that...
During a call,
the other side
cannot hear
your voice.
The microphone is not covered.
If you use a wired headset, make
sure connector is fully plugged in.
The signal
strength is not
strong enough
or your phone is
often off line.
The antenna is in a good condition.
Move close to a place with strong
signal strength.
Your phone
displays "No
service found",
"Service
unavailable" or
"Network
problem".
You are in an area with very weak
signal or outside your service
provider's network coverage (in a
tunnel or surrounded by buildings).
If so, move to another area and try
again.
Do not utilize the service option
without obtaining authorization
from your service provider.
12 Warnings and Precautions
This section contains important information pertaining to
the operating instructions of your device. It also contains
information about how to use the device safely. Read this
information carefully before using your device.
20
Electronic Device
Power off your device if using the device is prohibited. Do
not use the device when using the device causes danger
or interference with electronic devices.
Medical Device
Follow rules and regulations set forth by hospitals and
health care facilities. Do not use your device when
using the device is prohibited.
Pacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and
a pacemaker to prevent potential interference with the
pacemaker. If you are using a pacemaker, use the
device on the opposite side of the pacemaker and do
not carry the device in your front pocket.
Some wireless devices may affect the performance of
hearing aids. For any such problems, consult your
service provider.
To ensure that the Hearing Aid Compatibility rating for
your device is maintained, secondary transmitters such
as Bluetooth components must be disabled during a
call.
Potentially Explosive Atmosphere
Power off your device in any area with a potentially
explosive atmosphere, and comply with all signs and
instructions. Areas that may have potentially explosive
atmospheres include the areas where you would normally
be advised to turn off your vehicle engine. Triggering of
sparks in such areas could cause an explosion or a fire,
21
resulting in bodily injuries or even deaths. Do not power
on your device at refueling points such as service stations.
Comply with restrictions on the use of radio equipment in
fuel depots, storage, and distribution areas, and chemical
plants. In addition, adhere to restrictions in areas where
blasting operations are in progress. Before using the
device, watch out for areas that have potentially explosive
atmospheres that are often, but not always, clearly
marked. Such locations include areas below the deck on
boats, chemical transfer or storage facilities, and areas
where the air contains chemicals or particles such as grain,
dust, or metal powders. Ask the manufacturers of vehicles
using liquefied petroleum gas (such as propane or butane)
whether this device can be safely used in their vicinity.
Traffic Security
Observe local laws and regulations while using the device.
In addition, if using the device while driving a vehicle,
comply with the following guidelines:
Concentrate on driving. Your first responsibility is to
drive safely.
Do not talk on the device while driving. Use hands-free
accessories.
When you have to make or answer a call, park the
vehicle at the road side before using your device.
RF signals may affect electronic systems of motor
vehicles. For more information, consult the vehicle
manufacturer.
In a motor vehicle, do not place the device over the air
22
bag or in the air bag deployment area. Otherwise, the
device may hurt you owing to the strong force when
the air bag inflates.
Do not use your device while flying in an aircraft.
Power off your device before boarding an aircraft.
Using wireless devices in an aircraft may cause danger
to the operation of the aircraft and disrupt the wireless
telephone network. It may also be considered illegal.
Operating Environment
Do not use or charge the device in dusty, damp, and
dirty places or places with magnetic fields. Otherwise,
it may result in a malfunction of the circuit.
The device complies with the RF specifications when
the device is used near your ear or at a distance of 1.5
cm from your body. Ensure that the device accessories
such as a device case and a device holster are not
composed of metal components. Keep your device 1.5
cm away from your body to meet the requirement
earlier mentioned.
On a stormy day with thunder, do not use your device
when it is being charged, to prevent any danger caused
by lightning.
When you are on a call, do not touch the antenna.
Touching the antenna affects the call quality and
results in increase in power consumption. As a result,
the talk time and the standby time are reduced.
While using the device, observe the local laws and
regulations, and respect others' privacy and legal rights.
23
Keep the ambient temperature between 0°C and 40°C
while the device is being charged. Keep the ambient
temperature between 0°C to 40°C for using the device
powered by a battery.
Prevention of Hearing Damage
Using a headset at high volume can damage your hearing.
To reduce the risk of damage to hearing, lower the
headset volume to a safe and comfortable level.
Safety of Children
Comply with all precautions with regard to children's
safety. Letting the child play with your device or its
accessories, which may include parts that can be detached
from the device, may be dangerous, as it may present a
choking hazard. Ensure that small children are kept away
from the device and accessories.
Accessories
Choose only batteries, chargers, and accessories approved
for use with this model by the device manufacturer. The
use of any other type of battery, charger, or accessory
may invalidate any warranty for the device, may be in
violation of local rules or laws, and may be dangerous.
Please contact your dealer for information about the
availability of approved batteries, chargers, and
accessories in your area.
Battery and Charger
Unplug the charger from the electrical plug and the
device when not in use.
The battery can be charged and discharged hundreds
24
of times before it eventually wears out. When the
standby time and the talk time are shorter than the
normal time, replace the battery.
Use the AC power supply defined in the specifications
of the charger. An improper power voltage may cause a
fire or a malfunction of the charger.
Do not connect two poles of the battery with
conductors, such as metal materials, keys, or jewelries.
Otherwise, the battery may be short-circuited and may
cause injuries and burns on your body.
Do not disassemble the battery or solder the battery
poles. Otherwise, it may lead to electrolyte leakage,
overheating, fire, or explosion.
If battery electrolyte leaks out, ensure that the
electrolyte does not touch your skin and eyes. When
the electrolyte touches your skin or splashes into your
eyes, wash your eyes with clean water immediately and
consult a doctor.
If there is a case of battery deformation, color change,
or abnormal heating while you charge or store the
battery, remove the battery immediately and stop using
it. Otherwise, it may lead to battery leakage,
overheating, explosion, or fire.
If the power cable is damaged (for example, the cord is
exposed or broken), or the plug loosens, stop using the
cable at once. Otherwise, it may lead to an electric
shock, a short circuit of the charger, or a fire.
Do not dispose of batteries in fire as they may explode.
25
Batteries may also explode if damaged.
Danger of explosion if battery is incorrectly replaced.
Recycle or dispose of used batteries according to the
local regulations or reference instruction supplied with
your device.
Cleaning and Maintenance
The device, battery, and charger are not water-resistant.
Keep them dry. Protect the device, battery, and charger
from water or vapor. Do not touch the device or the
charger with a wet hand. Otherwise, it may lead to a
short circuit, a malfunction of the device, and an
electric shock to the user.
Do not place your device, battery, and charger in places
where they can get damaged because of collision.
Otherwise, it may lead to battery leakage, device
malfunction, overheating, fire, or explosion.
Do not place magnetic storage media such as magnetic
cards and floppy disks near the device. Radiation from
the device may erase the information stored on them.
Do not leave your device, battery, and charger in a
place with an extreme high or low temperature.
Otherwise, they may not function properly and may
lead to a fire or an explosion. When the temperature is
lower than 0°C, performance of the battery is affected.
Do not place sharp metal objects such as pins near the
earpiece. The earpiece may attract these objects and
hurt you when you are using the device.
Before you clean or maintain the device, power off the
26
device and disconnect it from the charger.
Do not use any chemical detergent, powder, or other
chemical agents (such as alcohol and benzene) to clean
the device and the charger. Otherwise, parts of the
device may be damaged or a fire can be caused. You
can clean the device and the charger with a piece of
damp and soft antistatic cloth.
Do not dismantle the device or accessories. Otherwise,
the warranty on the device and accessories is invalid
and the manufacturer is not liable to pay for the
damage.
Emergency Call
You can use your device for emergency calls in the service
area. The connection, however, cannot be guaranteed in
all conditions. You should not rely solely on the device for
essential communications.
Certification Information (SAR)
This device meets guidelines for exposure to radio waves.
Your device is a low-power radio transmitter and receiver.
As recommended by international guidelines, the device is
designed not to exceed the limits for exposure to radio
waves. These guidelines were developed by the
independent scientific organization International
Commission on Non-Ionizing Radiation Protection (ICNIRP)
and include safety measures designed to ensure safety for
all users, regardless of age and health.
The Specific Absorption Rate (SAR) is the unit of
measurement for the amount of radio frequency energy
27
absorbed by the body when using a device. The SAR value
is determined at the highest certified power level in
laboratory conditions, but the actual SAR level of the
device when being operated can be well below the value.
This is because the device is designed to use the minimum
power required to reach the network.
The SAR limit adopted by USA and Canada is 1.6
watts/kilogram (W/kg) averaged over one gram of tissue.
The highest SAR value reported to the FCC and IC for this
device type when tested for use at the ear is 0.878 W/kg,
and when properly worn on the body is 0.875 W/kg.
FCC Statement
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
28
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications made to this device not expressly
approved by Huawei Technologies Co., Ltd. may void the FCC
authorization to operate this device.
Hearing Aid Compatibility (HAC) regulations for
Mobile phones
In 2003, the FCC adopted rules to make digital wireless
telephones compatible with hearing aids and cochlear
implants. Although analog wireless phones do not usually
cause interference with hearing aids or cochlear implants,
digital wireless phones sometimes do because of
electromagnetic energy emitted by the phone's antenna,
backlight, or other components.
Your phone is compliant with FCC HAC regulations (ANSI
C63.19).
While some wireless phones are used near some hearing
29
devices (hearing aids and cochlear implants), users may
detect a buzzing, humming, or whining noise.
Some hearing devices are more immune than others to
this interference noise, and phones also vary in the
amount of interference they generate.
The wireless telephone industry has developed a rating
system for wireless phones, to assist hearing device users
find phones that may be compatible with their hearing
devices. Not all phones have been rated. Phones that are
rated have the rating on their box or a label located on
the box. The ratings are not guarantees. Results will vary
depending on the user's hearing device and hearing loss.
If your hearing device happens to be vulnerable to
interference, you may not be able to use a rated phone
successfully. Trying out the phone with your hearing
device is the best way to evaluate it for your personal
needs.
M-Ratings: Phones rated M3 or M4 meet FCC
requirements and are likely to generate less interference
to hearing devices than phones that are not labeled.
M4 is the better/higher of the two ratings.
T-Ratings: Phones rated T3 or T4 meet FCC requirements
and are likely to be more usable with a hearing device's
telecoil ("T Switch" or "Telephone Switch") than unrated
phones. T4 is the better/higher of the two ratings. (Note
that not all hearing devices have telecoils in them.)
Hearing devices may also be measured.
Your phone meets the M4/T4 level rating. Hearing devices
30
may also be rated. Your hearing device manufacturer or
hearing health professional may help you find this rating.
For more information about the FCC Hearing Aid
Compatibility please go to http://www.fcc.gov/cgb/dro.
Version: 01 Part Number: 9672xxxx

Navigation menu
