Users Manual

BLUETOOTH STEREO HEADSETBLUETOOTH STEREO HEADSETBLUETOOTH STEREO HEADSETHA-W700BT -J/CINSTRUCTIONSMANUEL D’INSTRUCTIONSMANUAL DE INSTRUCCIONES1. To reduce the risk of electrical shocks, fire, etc.:● Do not remove screws, cover or cabinet.● Do not expose this appliance to rain or moisture.2. For your safety…● Never use the unit when driving a car, motorcycle, or bicycle. This could result in an accident. ● Pay special attention to traffic around you when using the headphones outside. Failure to do so could result in an accident.● Be careful not to turn up the sound volume too high. Your hearing can be damaged from listening to sounds at excessive volume for long periods.● Do not disassemble or modify the unit.● Do not allow flammable, water or metallic objects to enter the unit.● If you find skin problems where the headphones are in contact with the skin, stop using the headphones; otherwise, it may cause inflammation or irritation to the skin.● In dry air such as in winter, you may feel a static shock when using the headphones.3. Avoid using the headphones…● in places subject to excessive humidity or dust● in places subject to extremely high (over 40°C or 104°F) or low (under 0°C or 32°F) temperatures4. DO NOT leave the unit…● exposed to direct sunlight● near a heater5. To protect the unit, DO NOT…● allow them to get wet● shake them or drop them against hard objectsThank you for purchasing this JVC product. Before you begin operating this unit, please read the operating instructions carefully to be sure you get the best possible performance. If you have any questions, consult your JVC dealer.6. For using the headphones…● Attach the ear pieces firmly when replacing them; otherwise, the ear pieces may be left in your ears when taking the headphones off. If the ear piece is left in your ear, be careful not to push it deep into the ear canal. Be careful not to apply the power that exceeds the headphones’ input capacity. This may result in sound distortion and could damage the oscillation board. Grasp and pull the plug itself to disconnect the headphones. Do not pull on the cord. When the ear pieces get dirty, detach the ear pieces and wash them in water-diluted detergent. After washing, dry the ear pieces and attach to the headphones. Replace the ear pieces when: they lose its elasticity; they are stained badly; they are broken or deformed. The ear pieces will deteriorate with age even in normal use and maintenance. Store the ear pieces in a place where children cannot reach to avoid the risk of the accident such as swallowing them.● When using canal type headphones, you may hear the sound of cord rubbing together or the sound of vibrations which travels through your body when walking.7. For safe use of battery…● Use only the supplied charging unit to charge the battery.● Be sure to use the supplied AC adaptor.● There are no serviceable parts inside. Consult your dealer to replace the built-in battery.● When discarding batteries, environmental problems must be considered and the local rules or laws governing the disposal of these batteries must be followed strictly.EnglishListening to MusicPreparation: • Make sure that the Bluetooth device can transmit music through the Bluetooth connection (compatible with the A2DP profile of Bluetooth)• Finish pairing between the unit and the Bluetooth device.• Turn on the Bluetooth device.1 Turn on the unit.2 Execute the Bluetooth (A2DP) connection on the Bluetooth device.• Refer also to the instruction manual supplied for the target device.• If the connection is not completed within five minutes, this unit goes to power saving mode. In this case, repeat the procedure from step 1.3 Start playback on the Bluetooth device.• Set the connected Bluetooth device so that the device emits the sound through the Bluetooth stereo headphones.4 Adjust the volume by tilting the control switch up or down.Basic controls available for the device:Button Press Press and hold6Play/pause Stop*¢Skip (to the next) Search (to forward)*4Skip (to the previous) Search (to backward)** Not available for some devices.• You can perform some of the Bluetooth device operations with the control switch of the unit if the device is compatible with the AVRCP profile. The operations you can do may vary depending on the device you use. Refer also to the instruction manual supplied for the target device to see the available operations.To stop using the unit Disconnect the Bluetooth connection on the Bluetooth device and turn off the unit.For the better sound and comfort fit of the headphonesThe medium-size ear pieces are attached to the supplied headphones when purchased.You may not enjoy the bass sound fully if the ear pieces are not fit to your ears. To enjoy better sound while reducing sound leakage and getting full noise canceling effect, choose the ear pieces from the supplied three sizes (Small, Medium, or Large) and adjust their positions to fit them to your ears.TroubleshootingWhat appears to be trouble is not always serious. Check the following points before consult your JVC dealer.Cannot pair the devices.☞ You cannot pair the Bluetooth device having receiving function only.☞ Bring the devices as closer as possible.Cannot connect the devices.☞ Pairing is incomplete. Perform the pairing again.☞ Check that the Bluetooth communication function is activated in the Bluetooth device.The sound is intermittent/The communication range is small.☞ Although Bluetooth wireless technology can transmit the contents within the range of approx. 10 m, obstacles (human bodies, metallic objects, wall, etc.) or radiowave condition may affect the sound and decrease its range.☞ The sound may be intermittent in the following cases. Avoid the following conditions when you use this unit.– Places where the wireless local area network is applied.– Near the microwave oven.– Near the other Bluetooth devices.– Places where the radiowave is used.No sound.☞ The connection between the Bluetooth device and this unit is incomplete. Connect the devices again.☞ The setting of the Bluetooth device is incorrect. Set the connected Bluetooth device so that the device emits the sound through the Bluetooth stereo headphones.Printed in ChinaLNT0091-001A© 2007 Victor Company of Japan, LimitedBattery disposalWhen disposing the unit, take off the built-in lithium-ion battery and dispose appropriately for environmental protection.1. Take off the screws with the Phillips-head screwdriver.2. Open the case and take off the battery. • Do not take off the battery from its case when you dispose of the battery.Calling through the unitPreparation: • Activate the Bluetooth communication function on your cellular phone.• Finish pairing between the unit and your cellular phone.1 Turn on the unit.2 Execute the Bluetooth connection on the cellular phone.• Refer also to the instruction manual supplied for the cellular phone.• When using a cellular phone supports both HFP and HSP Bluetooth Profile, use HFP for this unit.• When the connection is completed, the blue lamp flashes repeatedly.Basic controls available for the cellular phone connected with HFP:Status CALL buttonPress Press and holdWaiting Start voice dialing RedialDialing by voice dialingCancel voice dialing —Calling Cancel calling —Incoming Answer the call Reject the callAnswering Finish the call Switch the device (between cellular phone and audio device)Basic controls available for the cellular phone connected with HSP:Status CALL buttonPress Press and holdWaiting — Start calling*1Calling Cancel calling*1Cancel calling or activate the audio player*2Incoming Answer the call —Answering Finish the call*3Activate the audio device*1 Not available on some cellular phones.*2 Varies depending on the model of the cellular phone.*3 When answering a call on cellular phone, the function may not work.To make a call while playing back musicWhen connecting the cellular phone by using HFP or HSP Bluetooth Profile, you can make a call by using the cellular phone.To answer a call while playing back musicWhen a call comes in, the playback sound turns to ring tone. Press the CALL button to answer the call.To finish the callPress the CALL button. The playback sound comes back. (The playback sound may not come back in some cellular phone.)You can register up to 8 Bluetooth devices to the unit.• The device that has the oldest connection date will be overwritten when you register a 9th Bluetooth device.Before pairing...• Make sure that the unit is turned off.• Turn on the target Bluetooth device and place it within 1 m from the unit.1 Turn on the unit with pressing and holding the CALL button to make it in the pairing mode.The blue lamp and the red lamp will start flashing continuously as the unit finds the target Bluetooth device (pairing mode). Release the CALL button after the flashing starts.• Finish the steps below within about 3 minutes after the flashing starts (the pairing mode is automatically cancelled after the period). Turn off the unit and start from step 1 again when you cannot finish the operation.2 Execute pairing operation on the target Bluetooth device to find the unit.The device shows the list of Bluetooth devices found. The unit is recognized as “JVC HA-W700BT”. Repeat from Step 1 again when “JVC HA-W700BT” is not found.• Refer also to the instruction manual supplied for the target device.Registering a Bluetooth device – Pairing3 Select “JVC HA-W700BT” on the target Bluetooth device.4 Enter “0000” when the Pass code* is requested on the target Bluetooth device.Pairing is finished when the red lamp goes out and the blue lamp flashes three times repeatedly.* also called as “pass key”, “PIN code”, “PIN number”, etc.5 Execute Bluetooth connection to the unit on the target Bluetooth device.The unit saves the target as the last connected Bluetooth device.• Refer also to the instruction manual supplied for the target device.• Some Bluetooth device will automatically connect with the unit after pairing is finished.• When the connection is completed, the blue lamp flashes repeatedly.To pair with devices which cannot show the Bluetooth device list...On some Bluetooth devices, pairing may automatically be established by making both the unit and the target device in the pairing mode. Refer also to the instruction manual supplied for the target device to make it in the pairing mode.CAUTIONFCC INFORMATIONThis device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference(2) This device must accept any interference received, including interference that may cause undesired operation.CAUTION: Changes or modifications not approved by JVC could void user’s authority to operate the equipment.ContactAddress: JVC AMERICAS CORP. JVC COMPANY OF AMERICA 1700 Valley Road, Wayne, N.J. 07470Telephone: 1 (800) 252-5722Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:• Reorient or relocate the receiving antenna.• Increase the separation between the equipment and receiver.• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.• Consult the dealer or an experienced radio/TV technician for help.IC INFORMATIONThis device complies with RSS-210 of the IC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference(2) This device must accept any interference received, including interference that may cause undesired operation of the device.CAUTION: Changes or modifications not approved by JVC could void user’s authority to operate the equipment.ContactAddress: JVC CANADA INC. 21 Finchdene Square, Toronto, ON M1X 1A7Telephone: (416) 293-1311e-mail: info@jvc.caNote: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Industry Canada’s RSS-210. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:• Reorient or relocate the receiving antenna.• Increase the separation between the equipment and receiver.• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.• Consult the dealer or an experienced radio/TV technician for help.INFORMATION SUR ICCet appareil est conforme à la RSS-210 du réglement de la IC. Le fonctionnement est sujet aux deux conditions suivantes:(1) Cet appareil ne peut causer d’interférences nuisi-bles(2) Cet appareil reçoit toute interférence même les interférences qui peuvent occasioner un mauvais fonctionnement.ATTENTION: Les changements ou les modifications non approuvés par JVC risquent de retirer à l’utilisateur le droit d’utiliser l’appareil.ContactAdresse: JVC CANADA INC. 21 Finchdene Square, Toronto, ON M1X 1A7Téléphone: (416) 293-1311e-mail: info@jvc.caRemarque: L’appareil a été testé et jugé conforme aux limites des appareils numériques de classe B, aux termes de la réglementation RSS-210 de l’industrie du Canada. Ces limites ont pour but d’assurer une protection raisonnable contre les interférences parasites lorsque l’appareil est utilisé dans une installation résidentielle. Cet appareil engendre, utilise et peut émettre une énergie radioélectrique et, s’il n’est pas installé et utilisé en stricte conformité avec ces instructions, il peut provoquer des interférences parasites dans les liaisons radiophoniques. Ceci ne garantit pas pour autant qu’une installation particulière n’émettra aucune interférence. Si l’appareil engendre des interférences parasites avec la réception radio ou télévision, ce qui pourra être déterminé en éteignant puis en rallumant l’appareil, il est conseillé à l’utilisateur d’essayer de corriger les interférences en prenant l’une des mesures ci-dessous:• Modifier l’orientation ou changer l’emplacement de l’antenne de réception.• Eloigner davantage l’appareil du récepteur.• Brancher l’appareil dans une prise d’un circuit différent de celui auquel le récepteur est raccordé.• Demander l’aide de son agent ou d’un technicien radio/télévision qualifié.IMPORTANTCAUTION:TO PREVENT ELECTRIC SHOCK DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.ATTENTION:POUR PREVENIR LES CHOCS ELECTRIQES NE PAS UTILISER CETTER FICHE AVEC UN PROLONGATEUR, UNE PRISE DE COURANT OU UNE AUTRE SORTIE DE COURANT, SAUF SI LES LAMES PEUVENT ETRE INSEREES A FOND SANS EN LAISSER AUCUNE PARTIE A DECOUVERT.(1) This device may not cause interference.(2) This device must accept any interference, including interference that may cause undesired operation of the device.(1) Ce produit ne cause pas d’interférence.(2) Ce produit doit accepte toute interférence, incluant interférence qui peut causé opération non désiré.ENGLISHThis product’s performance would be degraded under a strong electro-static environment. And the function would be self-recoverable after the above case.This product’s performance would be degraded since the disturbance from the mains cord. And the function would be self-recoverable after the above case.FRANÇAISLes performances de ce produit se détérioreront dans un environnement fortement électro-statique. Par ailleurs, le fonctionnement se restaurera de lui-même dans le cas ci-dessus.Les performances de ce produit se détérioreront en cas de perturbations du cordon d’alimentation. Par ailleurs, le fonctionnement se restaurera de lui-même dans le cas ci-dessus.ESPAÑOLEl rendimiento de este producto puede deteriorarse en un entorno con campos electrostáticos fuertes. El funcionamiento se repondrá a la normalidad después del caso arriba mencionado.El rendimiento de este producto puede deteriorarse debido a las perturbaciones del cable de la red eléctrica. El funcionamiento se repondrá a la normalidad después del caso arriba mencionado.Hearing Comfort and Well-Being• Do not play your personal audio at a high volume. Hearing experts advice against continuous extended play.• If you experience a ringing in your ears, reduce volume or discontinue use.Traffic safety• Do not use while operating a motorized vehicle. It may create a traffic hazard and is illegal in many area.• You should use extreme caution or temporarily discontinue use in potentially hazardous situations.• Even though your earphones are of the open-air type designed to let you hear outside sounds, don’t turn up the volume so high that you can’t hear what’s around you.SpecificationsGeneralBluetooth version: Bluetooth 2.0 certifiedOutput power: Bluetooth power class 2Service area: max. 10 m (10.9 yd.) (approx.)* * Communication range may vary depending on the environmental conditions.Frequency band: 2.4 GHz (2,4000 GHz – 2,4835 GHz) Bluetooth profile:A2DP (Advanced Audio Distribution Profile), AVRCP (Audio/Video Remote Control Profile), HFP (Hands-free Profile), HSP (Headset Profile)Supported Codec: SBCPower supply: Built-in lithium-ion rechargeable battery (DC 3.7 V)Battery life*: Music play time: max. XXX hours Standby time: max. XXX hours* Depends on use.Mass: 35 g (1.23 oz.) (including headphones)Headphones (J48139-001)Frequency response: 10 Hz – 23,000 HzSensitivity: 93 dB/1 mWAccessoriesAC adaptor x 1 (S004CU0500050), Ear pieces (3 pairs, L, M, S), Charging unit (J48140-001) x 1Designs and specifications are subject to change without notice.The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Victor Company of Japan, Limited (JVC) is under license. Other trademarks and trade names are those of their respective owners.Parts name18234 5679pq1 (CALL) button Controls the cellular phone calling through this unit.2 Control switch* Controls the music player connected with this unit.3 Red lamp Indicates the battery status of this unit.4 Blue lamp Indicates the communication status between this unit and Bluetooth equipment.5 Microphone Picks up your voice when calling through this unit.6 Strap hole 7 Stereo mini jack 8 Headphones 9 Battery charge terminal p Clip q POWER switch Slides to turn on or off this unit.* The volume level of the connected device cannot be changed from this unit.BatteryFeaturesThis unit is a wireless stereo headset using Bluetooth® wireless technology.Call CallControl ControliPod with Bluetooth TransmitterBluetooth cell phoneAs Bluetooth Stereo Headset As Bluetooth ReceiverControlMusic & CallBluetooth cell phone with music player Bluetooth audio sourceMusic• Checking the battery chargePress the PLAY/PAUSE button while holding the CALL button. (Press the PLAY/PAUSE button within two seconds after pressing CALL button.) The red lamp lights or flashes to show the battery remains.• The red lamp starts slow flashing automatically when the battery become nearly empty. Battery chargingCharge the built-in rechargeable lithium-ion battery first to use this unit.1 Connect the AC adaptor to the charging unit.• Do not use any AC adaptor other than the supplied one.2 Connect the AC adaptor to the AC outlet.3 Put the unit on the charging stand.The red lamp lights up when the battery charge terminals contact.The blue lamp will light up when the charging is finished (the red lamp will turn off).• It takes about three hours to charge the battery to full when it is empty.• You can use the unit while charging.• Disconnect the AC adaptor from the AC outlet when you do not use the charging unit for a extended period of time.• Do not pull the cord when disconnecting the AC adaptor.• Do not handle the power cord with wet hands!• Do not bend the power cord sharply.Battery charge terminalRed lamp Battery levelRemain lit FullFlash continuously HalfwayTwo short flashes twice LowOne short flash twice Need to chargeAbout BluetoothBluetooth is a short-range wireless radio communication technology for the mobile device such as cellular phones, portable PCs, and other devices. The Bluetooth devices can be connected without cables and communicate each other.About Bluetooth ProfileBluetooth Profile designates the way of communication between Bluetooth devices. The system supports the following Bluetooth Profiles.A2DP: Advanced Audio Distribution ProfileThe profile controls sending/receiving the high-quality audio contents.AVRCP: Audio/Video Remote Control ProfileThe profile controls the functions of audio/video devices such as playing, stopping, pausing and volume control.HSP: Headset ProfileThe profile controlling the cell phone, and controlling the connection between the devices.HFP: Hands-Free ProfileThe profile controls the hands-free call with cell phone.About pairingPairing creates a unique and encrypted link between two Bluetooth devices and lets them communicate with each other. Bluetooth devices will not work if the devices have not been paired.Cautions on Bluetooth communication• Microwaves emitted from Bluetooth devices may affect the operation of electronic medical devices. Turn off this unit and other Bluetooth devices in hospitals, airplanes, trains, or crowding places.• Bluetooth devices use 2.4 GHz band, which is the same as that used by wireless LAN devices and microwave oven. Interference may occur near these devices and cause noise, disconnectivity, or a decrease of communication speed.• Connection with all Bluetooth devices cannot be guaranteed. Connectivity, operation, display indication or function may differ depending on the characteristics and specification of the devices.• Some Bluetooth devices take more time to establish connection.• To use the Bluetooth functions, the Bluetooth devices are required to be compatible with the same Bluetooth profiles as this unit is. However, the functions may differ depending on the specifications of the Bluetooth device even when it is compatible with the same profiles.LED flashing patternsStatus LED Flashing patternWhile pairing Blue ●-●-●-●-●-●-●-●-●-●-●-●-●-Red ●-●-●-●-●-●-●-●-●-●-●-●-●-Connecting Blue ●-●-●--------------●-●-●----------Red ------------------------------------------Communicating Blue ●---------------------●-----------------Red ------------------------------------------HA-W700BT_J.indd 1HA-W700BT_J.indd 1 07.8.1 2:38:54 PM07.8.1 2:38:54 PM
1. To reduce the risk of electrical shocks, fire, etc.:● Do not remove screws, cover or cabinet.● Do not expose this appliance to rain or moisture.2. For your safety…● Never use the unit when driving a car, motorcycle, or bicycle. This could result in an accident. ● Pay special attention to traffic around you when using the headphones outside. Failure to do so could result in an accident.● Be careful not to turn up the sound volume too high. Your hearing can be damaged from listening to sounds at excessive volume for long periods.● Do not disassemble or modify the unit.● Do not allow flammable, water or metallic objects to enter the unit.● If you find skin problems where the headphones are in contact with the skin, stop using the headphones; otherwise, it may cause inflammation or irritation to the skin.● In dry air such as in winter, you may feel a static shock when using the headphones.3. Avoid using the headphones…● in places subject to excessive humidity or dust● in places subject to extremely high (over 40°C or 104°F) or low (under 0°C or 32°F) temperatures4. DO NOT leave the unit…● exposed to direct sunlight● near a heater5. To protect the unit, DO NOT…● allow them to get wet● shake them or drop them against hard objectsThank you for purchasing this JVC product. Before you begin operating this unit, please read the operating instructions carefully to be sure you get the best possible performance. If you have any questions, consult your JVC dealer.6. For using the headphones…● Attach the ear pieces firmly when replacing them; otherwise, the ear pieces may be left in your ears when taking the headphones off. If the ear piece is left in your ear, be careful not to push it deep into the ear canal. Be careful not to apply the power that exceeds the headphones’ input capacity. This may result in sound distortion and could damage the oscillation board. Grasp and pull the plug itself to disconnect the headphones. Do not pull on the cord. When the ear pieces get dirty, detach the ear pieces and wash them in water-diluted detergent. After washing, dry the ear pieces and attach to the headphones. Replace the ear pieces when: they lose its elasticity; they are stained badly; they are broken or deformed. The ear pieces will deteriorate with age even in normal use and maintenance. Store the ear pieces in a place where children cannot reach to avoid the risk of the accident such as swallowing them.● When using canal type headphones, you may hear the sound of cord rubbing together or the sound of vibrations which travels through your body when walking.7. For safe use of battery…● Use only the supplied charging unit to charge the battery.● Be sure to use the supplied AC adaptor.● There are no serviceable parts inside. Consult your dealer to replace the built-in battery.● When discarding batteries, environmental problems must be considered and the local rules or laws governing the disposal of these batteries must be followed strictly.FrenchListening to MusicPreparation: • Make sure that the Bluetooth device can transmit music through the Bluetooth connection (compatible with the A2DP profile of Bluetooth)• Finish pairing between the unit and the Bluetooth device.• Turn on the Bluetooth device.1 Turn on the unit.2 Execute the Bluetooth (A2DP) connection on the Bluetooth device.• Refer also to the instruction manual supplied for the target device.• If the connection is not completed within five minutes, this unit goes to power saving mode. In this case, repeat the procedure from step 1.3 Start playback on the Bluetooth device.• Set the connected Bluetooth device so that the device emits the sound through the Bluetooth stereo headphones.4 Adjust the volume by tilting the control switch up or down.Basic controls available for the device:Button Press Press and hold6Play/pause Stop*¢Skip (to the next) Search (to forward)*4Skip (to the previous) Search (to backward)** Not available for some devices.• You can perform some of the Bluetooth device operations with the control switch of the unit if the device is compatible with the AVRCP profile. The operations you can do may vary depending on the device you use. Refer also to the instruction manual supplied for the target device to see the available operations.To stop using the unit Disconnect the Bluetooth connection on the Bluetooth device and turn off the unit.For the better sound and comfort fit of the headphonesThe medium-size ear pieces are attached to the supplied headphones when purchased.You may not enjoy the bass sound fully if the ear pieces are not fit to your ears. To enjoy better sound while reducing sound leakage and getting full noise canceling effect, choose the ear pieces from the supplied three sizes (Small, Medium, or Large) and adjust their positions to fit them to your ears.TroubleshootingWhat appears to be trouble is not always serious. Check the following points before consult your JVC dealer.Cannot pair the devices.☞ You cannot pair the Bluetooth device having receiving function only.☞ Bring the devices as closer as possible.Cannot connect the devices.☞ Pairing is incomplete. Perform the pairing again.☞ Check that the Bluetooth communication function is activated in the Bluetooth device.The sound is intermittent/The communication range is small.☞ Although Bluetooth wireless technology can transmit the contents within the range of approx. 10 m, obstacles (human bodies, metallic objects, wall, etc.) or radiowave condition may affect the sound and decrease its range.☞ The sound may be intermittent in the following cases. Avoid the following conditions when you use this unit.– Places where the wireless local area network is applied.– Near the microwave oven.– Near the other Bluetooth devices.– Places where the radiowave is used.No sound.☞ The connection between the Bluetooth device and this unit is incomplete. Connect the devices again.☞ The setting of the Bluetooth device is incorrect. Set the connected Bluetooth device so that the device emits the sound through the Bluetooth stereo headphones.Battery disposalWhen disposing the unit, take off the built-in lithium-ion battery and dispose appropriately for environmental protection.1. Take off the screws with the Phillips-head screwdriver.2. Open the case and take off the battery. • Do not take off the battery from its case when you dispose of the battery.Calling through the unitPreparation: • Activate the Bluetooth communication function on your cellular phone.• Finish pairing between the unit and your cellular phone.1 Turn on the unit.2 Execute the Bluetooth connection on the cellular phone.• Refer also to the instruction manual supplied for the cellular phone.• When using a cellular phone supports both HFP and HSP Bluetooth Profile, use HFP for this unit.• When the connection is completed, the blue lamp flashes repeatedly.Basic controls available for the cellular phone connected with HFP:Status CALL buttonPress Press and holdWaiting Start voice dialing RedialDialing by voice dialingCancel voice dialing —Calling Cancel calling —Incoming Answer the call Reject the callAnswering Finish the call Switch the device (between cellular phone and audio device)Basic controls available for the cellular phone connected with HSP:Status CALL buttonPress Press and holdWaiting — Start calling*1Calling Cancel calling*1Cancel calling or activate the audio player*2Incoming Answer the call —Answering Finish the call*3Activate the audio device*1 Not available on some cellular phones.*2 Varies depending on the model of the cellular phone.*3 When answering a call on cellular phone, the function may not work.To make a call while playing back musicWhen connecting the cellular phone by using HFP or HSP Bluetooth Profile, you can make a call by using the cellular phone.To answer a call while playing back musicWhen a call comes in, the playback sound turns to ring tone. Press the CALL button to answer the call.To finish the callPress the CALL button. The playback sound comes back. (The playback sound may not come back in some cellular phone.)You can register up to 8 Bluetooth devices to the unit.• The device that has the oldest connection date will be overwritten when you register a 9th Bluetooth device.Before pairing...• Make sure that the unit is turned off.• Turn on the target Bluetooth device and place it within 1 m from the unit.1 Turn on the unit with pressing and holding the CALL button to make it in the pairing mode.The blue lamp and the red lamp will start flashing continuously as the unit finds the target Bluetooth device (pairing mode). Release the CALL button after the flashing starts.• Finish the steps below within about 3 minutes after the flashing starts (the pairing mode is automatically cancelled after the period). Turn off the unit and start from step 1 again when you cannot finish the operation.2 Execute pairing operation on the target Bluetooth device to find the unit.The device shows the list of Bluetooth devices found. The unit is recognized as “JVC HA-W700BT”. Repeat from Step 1 again when “JVC HA-W700BT” is not found.• Refer also to the instruction manual supplied for the target device.Registering a Bluetooth device – Pairing3 Select “JVC HA-W700BT” on the target Bluetooth device.4 Enter “0000” when the Pass code* is requested on the target Bluetooth device.Pairing is finished when the red lamp goes out and the blue lamp flashes three times repeatedly.* also called as “pass key”, “PIN code”, “PIN number”, etc.5 Execute Bluetooth connection to the unit on the target Bluetooth device.The unit saves the target as the last connected Bluetooth device.• Refer also to the instruction manual supplied for the target device.• Some Bluetooth device will automatically connect with the unit after pairing is finished.• When the connection is completed, the blue lamp flashes repeatedly.To pair with devices which cannot show the Bluetooth device list...On some Bluetooth devices, pairing may automatically be established by making both the unit and the target device in the pairing mode. Refer also to the instruction manual supplied for the target device to make it in the pairing mode.CAUTIONSpecificationsGeneralBluetooth version: Bluetooth 2.0 certifiedOutput power: Bluetooth power class 2Service area: max. 10 m (10.9 yd.) (approx.)* * Communication range may vary depending on the environmental conditions.Frequency band: 2.4 GHz (2,4000 GHz – 2,4835 GHz) Bluetooth profile:A2DP (Advanced Audio Distribution Profile), AVRCP (Audio/Video Remote Control Profile), HFP (Hands-free Profile), HSP (Headset Profile)Supported Codec: SBCPower supply: Built-in lithium-ion rechargeable battery (DC 3.7 V)Battery life*: Music play time: max. XXX hours Standby time: max. XXX hours* Depends on use.Mass: 35 g (1.23 oz.) (including headphones)Headphones (J48139-001)Frequency response: 10 Hz – 23,000 HzSensitivity: 93 dB/1 mWAccessoriesAC adaptor x 1 (S004CU0500050), Ear pieces (3 pairs, L, M, S), Charging unit (J48140-001) x 1Designs and specifications are subject to change without notice.The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Victor Company of Japan, Limited (JVC) is under license. Other trademarks and trade names are those of their respective owners.Parts name18234 5679pq1 (CALL) button Controls the cellular phone calling through this unit.2 Control switch* Controls the music player connected with this unit.3 Red lamp Indicates the battery status of this unit.4 Blue lamp Indicates the communication status between this unit and Bluetooth equipment.5 Microphone Picks up your voice when calling through this unit.6 Strap hole 7 Stereo mini jack 8 Headphones 9 Battery charge terminal p Clip q POWER switch Slides to turn on or off this unit.* The volume level of the connected device cannot be changed from this unit.BatteryFeaturesThis unit is a wireless stereo headset using Bluetooth® wireless technology.Call CallControl ControliPod with Bluetooth TransmitterBluetooth cell phoneAs Bluetooth Stereo Headset As Bluetooth ReceiverControlMusic & CallBluetooth cell phone with music player Bluetooth audio sourceMusic• Checking the battery chargePress the PLAY/PAUSE button while holding the CALL button. (Press the PLAY/PAUSE button within two seconds after pressing CALL button.) The red lamp lights or flashes to show the battery remains.• The red lamp starts slow flashing automatically when the battery become nearly empty. Battery chargingCharge the built-in rechargeable lithium-ion battery first to use this unit.1 Connect the AC adaptor to the charging unit.• Do not use any AC adaptor other than the supplied one.2 Connect the AC adaptor to the AC outlet.3 Put the unit on the charging stand.The red lamp lights up when the battery charge terminals contact.The blue lamp will light up when the charging is finished (the red lamp will turn off).• It takes about three hours to charge the battery to full when it is empty.• You can use the unit while charging.• Disconnect the AC adaptor from the AC outlet when you do not use the charging unit for a extended period of time.• Do not pull the cord when disconnecting the AC adaptor.• Do not handle the power cord with wet hands!• Do not bend the power cord sharply.Battery charge terminalRed lamp Battery levelRemain lit FullFlash continuously HalfwayTwo short flashes twice LowOne short flash twice Need to chargeAbout BluetoothBluetooth is a short-range wireless radio communication technology for the mobile device such as cellular phones, portable PCs, and other devices. The Bluetooth devices can be connected without cables and communicate each other.About Bluetooth ProfileBluetooth Profile designates the way of communication between Bluetooth devices. The system supports the following Bluetooth Profiles.A2DP: Advanced Audio Distribution ProfileThe profile controls sending/receiving the high-quality audio contents.AVRCP: Audio/Video Remote Control ProfileThe profile controls the functions of audio/video devices such as playing, stopping, pausing and volume control.HSP: Headset ProfileThe profile controlling the cell phone, and controlling the connection between the devices.HFP: Hands-Free ProfileThe profile controls the hands-free call with cell phone.About pairingPairing creates a unique and encrypted link between two Bluetooth devices and lets them communicate with each other. Bluetooth devices will not work if the devices have not been paired.Cautions on Bluetooth communication• Microwaves emitted from Bluetooth devices may affect the operation of electronic medical devices. Turn off this unit and other Bluetooth devices in hospitals, airplanes, trains, or crowding places.• Bluetooth devices use 2.4 GHz band, which is the same as that used by wireless LAN devices and microwave oven. Interference may occur near these devices and cause noise, disconnectivity, or a decrease of communication speed.• Connection with all Bluetooth devices cannot be guaranteed. Connectivity, operation, display indication or function may differ depending on the characteristics and specification of the devices.• Some Bluetooth devices take more time to establish connection.• To use the Bluetooth functions, the Bluetooth devices are required to be compatible with the same Bluetooth profiles as this unit is. However, the functions may differ depending on the specifications of the Bluetooth device even when it is compatible with the same profiles.LED flashing patternsStatus LED Flashing patternWhile pairing Blue ●-●-●-●-●-●-●-●-●-●-●-●-●-Red ●-●-●-●-●-●-●-●-●-●-●-●-●-Connecting Blue ●-●-●--------------●-●-●----------Red ------------------------------------------Communicating Blue ●---------------------●-----------------Red ------------------------------------------1. To reduce the risk of electrical shocks, fire, etc.:● Do not remove screws, cover or cabinet.● Do not expose this appliance to rain or moisture.2. For your safety…● Never use the unit when driving a car, motorcycle, or bicycle. This could result in an accident. ● Pay special attention to traffic around you when using the headphones outside. Failure to do so could result in an accident.● Be careful not to turn up the sound volume too high. Your hearing can be damaged from listening to sounds at excessive volume for long periods.● Do not disassemble or modify the unit.● Do not allow flammable, water or metallic objects to enter the unit.● If you find skin problems where the headphones are in contact with the skin, stop using the headphones; otherwise, it may cause inflammation or irritation to the skin.● In dry air such as in winter, you may feel a static shock when using the headphones.3. Avoid using the headphones…● in places subject to excessive humidity or dust● in places subject to extremely high (over 40°C or 104°F) or low (under 0°C or 32°F) temperatures4. DO NOT leave the unit…● exposed to direct sunlight● near a heater5. To protect the unit, DO NOT…● allow them to get wet● shake them or drop them against hard objectsThank you for purchasing this JVC product. Before you begin operating this unit, please read the operating instructions carefully to be sure you get the best possible performance. If you have any questions, consult your JVC dealer.6. For using the headphones…● Attach the ear pieces firmly when replacing them; otherwise, the ear pieces may be left in your ears when taking the headphones off. If the ear piece is left in your ear, be careful not to push it deep into the ear canal. Be careful not to apply the power that exceeds the headphones’ input capacity. This may result in sound distortion and could damage the oscillation board. Grasp and pull the plug itself to disconnect the headphones. Do not pull on the cord. When the ear pieces get dirty, detach the ear pieces and wash them in water-diluted detergent. After washing, dry the ear pieces and attach to the headphones. Replace the ear pieces when: they lose its elasticity; they are stained badly; they are broken or deformed. The ear pieces will deteriorate with age even in normal use and maintenance. Store the ear pieces in a place where children cannot reach to avoid the risk of the accident such as swallowing them.● When using canal type headphones, you may hear the sound of cord rubbing together or the sound of vibrations which travels through your body when walking.7. For safe use of battery…● Use only the supplied charging unit to charge the battery.● Be sure to use the supplied AC adaptor.● There are no serviceable parts inside. Consult your dealer to replace the built-in battery.● When discarding batteries, environmental problems must be considered and the local rules or laws governing the disposal of these batteries must be followed strictly.SpanishListening to MusicPreparation: • Make sure that the Bluetooth device can transmit music through the Bluetooth connection (compatible with the A2DP profile of Bluetooth)• Finish pairing between the unit and the Bluetooth device.• Turn on the Bluetooth device.1 Turn on the unit.2 Execute the Bluetooth (A2DP) connection on the Bluetooth device.• Refer also to the instruction manual supplied for the target device.• If the connection is not completed within five minutes, this unit goes to power saving mode. In this case, repeat the procedure from step 1.3 Start playback on the Bluetooth device.• Set the connected Bluetooth device so that the device emits the sound through the Bluetooth stereo headphones.4 Adjust the volume by tilting the control switch up or down.Basic controls available for the device:Button Press Press and hold6Play/pause Stop*¢Skip (to the next) Search (to forward)*4Skip (to the previous) Search (to backward)** Not available for some devices.• You can perform some of the Bluetooth device operations with the control switch of the unit if the device is compatible with the AVRCP profile. The operations you can do may vary depending on the device you use. Refer also to the instruction manual supplied for the target device to see the available operations.To stop using the unit Disconnect the Bluetooth connection on the Bluetooth device and turn off the unit.For the better sound and comfort fit of the headphonesThe medium-size ear pieces are attached to the supplied headphones when purchased.You may not enjoy the bass sound fully if the ear pieces are not fit to your ears. To enjoy better sound while reducing sound leakage and getting full noise canceling effect, choose the ear pieces from the supplied three sizes (Small, Medium, or Large) and adjust their positions to fit them to your ears.TroubleshootingWhat appears to be trouble is not always serious. Check the following points before consult your JVC dealer.Cannot pair the devices.☞ You cannot pair the Bluetooth device having receiving function only.☞ Bring the devices as closer as possible.Cannot connect the devices.☞ Pairing is incomplete. Perform the pairing again.☞ Check that the Bluetooth communication function is activated in the Bluetooth device.The sound is intermittent/The communication range is small.☞ Although Bluetooth wireless technology can transmit the contents within the range of approx. 10 m, obstacles (human bodies, metallic objects, wall, etc.) or radiowave condition may affect the sound and decrease its range.☞ The sound may be intermittent in the following cases. Avoid the following conditions when you use this unit.– Places where the wireless local area network is applied.– Near the microwave oven.– Near the other Bluetooth devices.– Places where the radiowave is used.No sound.☞ The connection between the Bluetooth device and this unit is incomplete. Connect the devices again.☞ The setting of the Bluetooth device is incorrect. Set the connected Bluetooth device so that the device emits the sound through the Bluetooth stereo headphones.Battery disposalWhen disposing the unit, take off the built-in lithium-ion battery and dispose appropriately for environmental protection.1. Take off the screws with the Phillips-head screwdriver.2. Open the case and take off the battery. • Do not take off the battery from its case when you dispose of the battery.Calling through the unitPreparation: • Activate the Bluetooth communication function on your cellular phone.• Finish pairing between the unit and your cellular phone.1 Turn on the unit.2 Execute the Bluetooth connection on the cellular phone.• Refer also to the instruction manual supplied for the cellular phone.• When using a cellular phone supports both HFP and HSP Bluetooth Profile, use HFP for this unit.• When the connection is completed, the blue lamp flashes repeatedly.Basic controls available for the cellular phone connected with HFP:Status CALL buttonPress Press and holdWaiting Start voice dialing RedialDialing by voice dialingCancel voice dialing —Calling Cancel calling —Incoming Answer the call Reject the callAnswering Finish the call Switch the device (between cellular phone and audio device)Basic controls available for the cellular phone connected with HSP:Status CALL buttonPress Press and holdWaiting — Start calling*1Calling Cancel calling*1Cancel calling or activate the audio player*2Incoming Answer the call —Answering Finish the call*3Activate the audio device*1 Not available on some cellular phones.*2 Varies depending on the model of the cellular phone.*3 When answering a call on cellular phone, the function may not work.To make a call while playing back musicWhen connecting the cellular phone by using HFP or HSP Bluetooth Profile, you can make a call by using the cellular phone.To answer a call while playing back musicWhen a call comes in, the playback sound turns to ring tone. Press the CALL button to answer the call.To finish the callPress the CALL button. The playback sound comes back. (The playback sound may not come back in some cellular phone.)You can register up to 8 Bluetooth devices to the unit.• The device that has the oldest connection date will be overwritten when you register a 9th Bluetooth device.Before pairing...• Make sure that the unit is turned off.• Turn on the target Bluetooth device and place it within 1 m from the unit.1 Turn on the unit with pressing and holding the CALL button to make it in the pairing mode.The blue lamp and the red lamp will start flashing continuously as the unit finds the target Bluetooth device (pairing mode). Release the CALL button after the flashing starts.• Finish the steps below within about 3 minutes after the flashing starts (the pairing mode is automatically cancelled after the period). Turn off the unit and start from step 1 again when you cannot finish the operation.2 Execute pairing operation on the target Bluetooth device to find the unit.The device shows the list of Bluetooth devices found. The unit is recognized as “JVC HA-W700BT”. Repeat from Step 1 again when “JVC HA-W700BT” is not found.• Refer also to the instruction manual supplied for the target device.Registering a Bluetooth device – Pairing3 Select “JVC HA-W700BT” on the target Bluetooth device.4 Enter “0000” when the Pass code* is requested on the target Bluetooth device.Pairing is finished when the red lamp goes out and the blue lamp flashes three times repeatedly.* also called as “pass key”, “PIN code”, “PIN number”, etc.5 Execute Bluetooth connection to the unit on the target Bluetooth device.The unit saves the target as the last connected Bluetooth device.• Refer also to the instruction manual supplied for the target device.• Some Bluetooth device will automatically connect with the unit after pairing is finished.• When the connection is completed, the blue lamp flashes repeatedly.To pair with devices which cannot show the Bluetooth device list...On some Bluetooth devices, pairing may automatically be established by making both the unit and the target device in the pairing mode. Refer also to the instruction manual supplied for the target device to make it in the pairing mode.CAUTIONSpecificationsGeneralBluetooth version: Bluetooth 2.0 certifiedOutput power: Bluetooth power class 2Service area: max. 10 m (10.9 yd.) (approx.)* * Communication range may vary depending on the environmental conditions.Frequency band: 2.4 GHz (2,4000 GHz – 2,4835 GHz) Bluetooth profile:A2DP (Advanced Audio Distribution Profile), AVRCP (Audio/Video Remote Control Profile), HFP (Hands-free Profile), HSP (Headset Profile)Supported Codec: SBCPower supply: Built-in lithium-ion rechargeable battery (DC 3.7 V)Battery life*: Music play time: max. XXX hours Standby time: max. XXX hours* Depends on use.Mass: 35 g (1.23 oz.) (including headphones)Headphones (J48139-001)Frequency response: 10 Hz – 23,000 HzSensitivity: 93 dB/1 mWAccessoriesAC adaptor x 1 (S004CU0500050), Ear pieces (3 pairs, L, M, S), Charging unit (J48140-001) x 1Designs and specifications are subject to change without notice.The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Victor Company of Japan, Limited (JVC) is under license. Other trademarks and trade names are those of their respective owners.Parts name18234 5679pq1 (CALL) button Controls the cellular phone calling through this unit.2 Control switch* Controls the music player connected with this unit.3 Red lamp Indicates the battery status of this unit.4 Blue lamp Indicates the communication status between this unit and Bluetooth equipment.5 Microphone Picks up your voice when calling through this unit.6 Strap hole 7 Stereo mini jack 8 Headphones 9 Battery charge terminal p Clip q POWER switch Slides to turn on or off this unit.* The volume level of the connected device cannot be changed from this unit.BatteryFeaturesThis unit is a wireless stereo headset using Bluetooth® wireless technology.Call CallControl ControliPod with Bluetooth TransmitterBluetooth cell phoneAs Bluetooth Stereo Headset As Bluetooth ReceiverControlMusic & CallBluetooth cell phone with music player Bluetooth audio sourceMusic• Checking the battery chargePress the PLAY/PAUSE button while holding the CALL button. (Press the PLAY/PAUSE button within two seconds after pressing CALL button.) The red lamp lights or flashes to show the battery remains.• The red lamp starts slow flashing automatically when the battery become nearly empty. Battery chargingCharge the built-in rechargeable lithium-ion battery first to use this unit.1 Connect the AC adaptor to the charging unit.• Do not use any AC adaptor other than the supplied one.2 Connect the AC adaptor to the AC outlet.3 Put the unit on the charging stand.The red lamp lights up when the battery charge terminals contact.The blue lamp will light up when the charging is finished (the red lamp will turn off).• It takes about three hours to charge the battery to full when it is empty.• You can use the unit while charging.• Disconnect the AC adaptor from the AC outlet when you do not use the charging unit for a extended period of time.• Do not pull the cord when disconnecting the AC adaptor.• Do not handle the power cord with wet hands!• Do not bend the power cord sharply.Battery charge terminalRed lamp Battery levelRemain lit FullFlash continuously HalfwayTwo short flashes twice LowOne short flash twice Need to chargeAbout BluetoothBluetooth is a short-range wireless radio communication technology for the mobile device such as cellular phones, portable PCs, and other devices. The Bluetooth devices can be connected without cables and communicate each other.About Bluetooth ProfileBluetooth Profile designates the way of communication between Bluetooth devices. The system supports the following Bluetooth Profiles.A2DP: Advanced Audio Distribution ProfileThe profile controls sending/receiving the high-quality audio contents.AVRCP: Audio/Video Remote Control ProfileThe profile controls the functions of audio/video devices such as playing, stopping, pausing and volume control.HSP: Headset ProfileThe profile controlling the cell phone, and controlling the connection between the devices.HFP: Hands-Free ProfileThe profile controls the hands-free call with cell phone.About pairingPairing creates a unique and encrypted link between two Bluetooth devices and lets them communicate with each other. Bluetooth devices will not work if the devices have not been paired.Cautions on Bluetooth communication• Microwaves emitted from Bluetooth devices may affect the operation of electronic medical devices. Turn off this unit and other Bluetooth devices in hospitals, airplanes, trains, or crowding places.• Bluetooth devices use 2.4 GHz band, which is the same as that used by wireless LAN devices and microwave oven. Interference may occur near these devices and cause noise, disconnectivity, or a decrease of communication speed.• Connection with all Bluetooth devices cannot be guaranteed. Connectivity, operation, display indication or function may differ depending on the characteristics and specification of the devices.• Some Bluetooth devices take more time to establish connection.• To use the Bluetooth functions, the Bluetooth devices are required to be compatible with the same Bluetooth profiles as this unit is. However, the functions may differ depending on the specifications of the Bluetooth device even when it is compatible with the same profiles.LED flashing patternsStatus LED Flashing patternWhile pairing Blue ●-●-●-●-●-●-●-●-●-●-●-●-●-Red ●-●-●-●-●-●-●-●-●-●-●-●-●-Connecting Blue ●-●-●--------------●-●-●----------Red ------------------------------------------Communicating Blue ●---------------------●-----------------Red ------------------------------------------HA-W700BT_J.indd 2HA-W700BT_J.indd 2 07.8.1 2:39:16 PM07.8.1 2:39:16 PM
