User manual
![](/img.php?id=1420471&img=bg1.png)
English
www.lg.com
All rights reserved.
LG Electronics Inc., 2010
Note : For the best performance and to
prevent any damage to, or misuse of the
HBM-905, please read all of the information
carefully prior to using the HBM-905.
Any modifi cations or changes to this manual
due to typographical errors or inaccuracies
of stated information shall only be made by
LG Electronics Inc.
LG Electronics
BLUETOOTH
®
Mono Headset
HBM-905 User Manual
![](/img.php?id=1420471&img=bg2.png)
2 3
ENG
ENG
Table of Contents
Included in Package
Introduction
The LG Bluetooth
®
Headset HBM- 905 is a lightweight wireless Headset utilizing
Bluetooth
®
technology. This product can be used as an audio accessory for
devices supporting either the Headset,Handsfree or A2DP Bluetooth
®
Profi les.
LG HBM-905
Bluetooth
®
Headset
Ear-loops (2) Ear rubber (2)
Introduction 3
- Included in Package 3
Part Description 4
How to use 4
- Change direction 4
- Charging 5
- Low battery 5
- Power on 5
- Power off 5
- Pairing 6
• Easy Pairing 6
• Manual Pairing 7
- Auto Reconnect 7
• Out of range 7
- Volume control 8
- Calling 8
• Answering a call 8
• Making a call 8
• Voice dialing 8
• Last number redial 9
• Ending a call 9
• Transferring a call 9
• Call waiting 9
• Call Reject 9
- Multipoint 9
• Multipoint Connect 10
• Calling Functions 10
- Name Alert
TM
10
• Enable/Disable ‘Name Alert
TM
’ 10
• Language Selection 11
- Battery Status Alert 11
- Audio Streaming (A2DP) 11
Summary of button functions 12
LED indication 13
Troubleshooting 13
Specification 14
Precautions 14
Declaration of confirmation 15
Additional information 15
Limited warranty 18
Important safety information 18
User manual Quick Start Guide Warranty Card
![](/img.php?id=1420471&img=bg3.png)
4 5
ENG
ENG
Part Description
Charging
- Remove the cover on the charging port and connect the charger.
- When the charger is connected, with power on or off, the Headset will turn off.
- While charging, the LED indicator will show a solid white light.
- The buttons will not function while the device is charging.
- It takes 2 hours to fully charge the Headset.
- When charging is complete, the LED indicator will turn off.
Front
How to use
Change direction
Call Button/
LED Indicator
Volume Control
(Circulation)
PWR Switch
Charging Port
MIC
Back
Low battery
- An announcement will be made once every 2 minutes.
(Speech: Battery very low, please charge now)
- If the battery is not charged, the headset will turn off.
Power on
- Move the power switch to the ‘ON’ position.
• The power will turn on. (Speech: Ready,[“battery status”])
Power off
- Move the power switch to the ‘OFF’ position.
• The Bluetooth link will disconnect, and the power will turn off.
(Speech: Powering Down)
- Before using the headset for the fi rst time, you must pair it with a Bluetooth
enabled handset.
- There are 2 Pairing Methods with the HBM-905.
Pairing
How to use
![](/img.php?id=1420471&img=bg4.png)
6 7
ENG
ENG
Auto Reconnect
- When the HBM-905 turns off (accidentally or intentionally) while connected to a
handset, the Headset and handset will disconnect.
The Headset and handset will automatically reconnect when the HBM-905 is
turned back on.(as long as both devices are within the required range of 33ft.
or 10m).
Out of range
- When the HBM-905 and your handset are separated by a distance of 33 feet (10
meters) or more, the Headset and handset will disconnect. When the handset
and HBM-905 are brought back within the required distance, the HBM-905 will
automatically reconnect with the handset.
- If the Headset and handset do not automatically reconnect when they are back
within the required range, briefl y press the CALL button on the HBM-905 to
reconnect manually.
NOTE: If The Headset does not connect with handset within 63 minutes, the
Headset will automatically turn off.
1) Easy Pairing
A. With the Power off, move the power switch to the ‘ON’ position
B. The headset will enter Auto-Reconnect mode for 10 seconds. (If your
headset has been previously paired to the handset, the headset will
automatically reconnect to the handset)
C. If the HBM-905 fails to reconnect to the phone (Speech: Failed to connect to
phone) after 10 seconds, the HBM-905 will automatically enter pairing mode.
D. When the headset enters Pairing Mode, the LED indicator will show a solid
white light. (Speech: Please pair phone now)
E. Using your handset, fi nd the Bluetooth Menu and “search for” or “add” new
devices.
F. Select “LG HBM-905” from the list of devices and pair it with your handset.
G. If you are asked for the Pass/PIN code during the pairing procedure, please
enter “0000” (4 Zeros).
H. Once pairing has completed successfully, you will hear a beep.
(Speech: Paired to phone successfully)
I. After pairing successfully, be sure to “Connect” to the LG HBM-905 using
your handsets controls.
(Speech: Connected to Phone) You will hear a short beep.
J. Some handsets will ask for permission to access the phones contact list.
If you would like to use Name Alert Function, please select OK or Allow
Access.
K. If you want to pair with a different device in the future, the headset must be
placed in Pairing Mode.
L. If the headset is in Pairing mode for three minutes without being connected
to a handset, the HBM-905 will automatically turn off.
2) Manual Pairing
A. With the Power off, press and hold the CALL button and move the power
switch to the ‘ON’ position at the same time.
B. When the headset enters Pairing Mode, the LED indicator will show a white
light. (Speech: Please pair phone now)
C. Continue from letter E above.
Volume control
- Briefl y press the VOLUME button to adjust HBM-905 speaker volume
- There are eight levels of speaker volume.
- There are 14 levels while streaming audio via A2DP.
- The volume will increase one level, each time the volume button is pressed.
When the headset reaches the maximum volume level, the next press of the
button will return the headset to the lowest volume level.
NOTE: The HBM-905 has the Automatic Volume Control that can
automatically adjust HBM-905 volume according to the environmental
noise level.
How to useHow to use
![](/img.php?id=1420471&img=bg5.png)
8 9
ENG
ENG
Multipoint
The LG HBM-905 is capable of having two handsets connected to the Headset
at the same time. This will give you the freedom of having only one Headset to
operate both your handsets.
Multipoint Connect
- Pair the Headset with one of your Bluetooth-enabled handsets.(per the pairing
instructions on pages 6-7).
- Turn off the Headset.
- With the power off hold the CALL button and move the PWR switch to ON
position, to enter Manual Pairing mode.
- Now, pair and connect the Headset with your other Bluetooth-enabled handset.
(This will be your Primary handset).
- Once this handset is paired and connected, go back and connect the fi rst paired
handset to Headset. (This will be your Secondary handset).
NOTE: When the HBM-905 is connected to two handsets at the same time
(Multipoint), the Headset calling functions will work with the most
recently used handset.
Calling
Answering a call
- With an incoming call, briefl y press the CALL button to answer. When the call is
connected, you will hear a beep.
- With name alert active, the headset will ring once and then announce who is calling.
- If name alert is not active, Headset will only ring.
Making a call
- If you make a call from the handset, the call will (subject to phone settings)
automatically transfer to the Headset. If the call is not automatically transferred, you
can manually transfer the call by briefl y pressing the CALL button on the HBM-905
(Headset and handset must be paired).
Voice dialing*
- Briefl y press the CALL button to activate “Voice Command”. You will get the best
results if you record the voice dialing tag through your Headset.
NOTE: If the handset does not support Voice Dialing, it is possible that
performing this action will activate Last Number redial.
Last number redial*
- Press and hold the CALL button for 1second to activate “Last Number Redial”.
The Headset will beep, and call the last number dialed.
Ending a call
- Briefl y press the CALL button.
Transferring a call*
- While on a call on your handset, briefl y press the CALL button to transfer the audio
to the Headset.(Headset and handset must be paired).
- And to transfer a call from the Headset to handset, press and hold VOLUME button
for 3 seconds.
Call waiting*
- Answer a second call without hanging up the fi rst call by pressing the CALL button
for 1second. Press the CALL button for 1second to return to the original call.
- Briefl y press the CALL button to terminate the active call or both calls at once.
(subject to handset’s support)
Call Reject*
- Activate Call Reject by pressing the CALL button for 1second when the handset rings.
* It is possible to use these functions only when your handset supports them.
For further information about using these features, please consult your handset’s
user manual.
How to useHow to use
![](/img.php?id=1420471&img=bg6.png)
10 11
ENG
ENG
Name Alert
TM
The LG HBM-905 is capable of announcing the caller’s name.
NOTE: The Name Alert
TM
function is not supported by all handsets.
Phones operating on Andriod can download HBM-905 extender to
access this feature.In “Android Marketplace” search for HBM-905
Extender and install on your handset.
Enable/Disable ‘Name Alert
TM
’
- Press and hold the VOLUME button on the HBM-905 for 5 seconds to enable/
disable ‘Name Alert
TM
’. You will hear, “Enabled Name Alert
TM
” or “Disabled Name
Alert
TM
”.
Language Selection
- The Name Alert
TM
function allows you to choose from 2 different language options.
They are English and Spanish.
- To enter Language Selection Mode, With the Power off, press and hold the
VOLUME button and move the power switch to the ‘ON’ position at the same time.
You will hear “Please select language”.
- To browse language type, press the VOLUME button to scroll through the
language options.
- To select a language, press the CALL button once after hearing your language.
You will hear “English Selected”
- If no language is selected for 5 seconds, the current language will remain.
(Speech: Cancelled).
Calling Function
- Voice Dial and Last Number Redial features work with the Primary handset.
(most recently used handset).
- The fi rst connected device is set as primary handset and the next connected
device is set as secondary handset.
- The device which made the last outgoing call will always be set as the primary
handset.
Battery Status Alert
- To check the battery status, press and hold the VOLUME button on the HBM-905
for 2 seconds.
- There are 5 levels of battery status: “Battery full”, “Battery high”, “Battery medium”,
“Battery low”, and “Battery very low”
Audio Streaming (A2DP)
The HBM-905 supports music streaming (A2DP).
When you play music from your Bluetooth Enabled Device, it will automatically
transfer to your headset. Music will automatically pause when you have an incoming
call. When the call is ended the music will start playing again.
A2DP allows streaming of all audio from your handset and running applications
Including Music and GPS Navigation.
SMS Reader
The HBM-905 Bluetooth headset supports the “BT Reader” Android application that
reads text messages into your headset.
Using SMS reader with the Android Operating system requires a free download of “BT
Reader” in the Android marketplace.
Free BT Reader App now available at Android Market.
How to useHow to use
![](/img.php?id=1420471&img=bg7.png)
12 13
ENG
ENG
Summary of button functions
Function
HBM-905 Status
Action
Power on Power off Move the PWR switch from OFF position to
ON position.
Power off Power on Move the PWR switch from ON position to
OFF position.
Volume adjustment On Call
Briefl y press the VOLUME button to increase
the volume.
(After reaching maximum volume, it will circulate
to the lowest level)
Transferring a call On Call
- Handset to headset
Briefl y press the CALL button on the HBM-905
(Headset and handset must be paired)
- Headset to handset
Press and hold the VOLUME button on HBM-905
for 3 seconds
Answering a call Ringing Briefl y press the CALL button.
Ending a call On Call Briefl y press the CALL button.
Call waiting On Call Press the CALL button for 1 second.
Last number redial Idle Press the CALL button for 1 second.
Voice dialing
(Handset must support)
Idle Briefl y press the CALL button.
Manual pairing Power off
With the Power off, press the CALL button and
move the Power Switch to the on side at the
same time.
Call reject Ringing Press the CALL button for 1 second.
(Name Alert
TM
)
Activate/ Deactivate
Idle
Press and hold the VOLUME button for 5 seconds.
Enter language
selection mode Power Off
With the Power off, press the VOLUME button
and move the Power Switch to the on side at
the same time.
Browse language
type
Language
Selection Mode
Press VOLUME button once.
Select language Language
Selection Mode Press CALL button once.
Check battery status
Power off
Press and hold the VOLUME button for 2 seconds.
Function HBM-905 Status Action
Operating
Power on The white LED light fl ickers 4 times.
Power off
The white LED light fl ickers 4 times and then turns off.
Pairing mode The white LED light stays on.
Headset/handsfree
Profi le connected The white LED light fl ickers once every 5 seconds.
Call connected The white LED light fl ickers once every 5 seconds.
Charging
Charging The white LED light stays on.
Charging complete
LED is turned off.
Troubleshooting
Issue Possible problem Resolution
Does not turn on Check whether the battery of the
HBM-905 is fully charged. Charge the battery.
Unable to
communicate with
the LG Bluetooth
®
Headset HBM-905
Check whether the handset
supports the headset or
handsfree Bluetooth profi les.
Determine whether your
handset supports the Headset or
Handsfree Bluetooth profi les.
Check whether the battery of the
HBM-905 is low.
Charge the battery.
Unable to pair the
HBM-905 with
Bluetooth® device
Check and make sure the
Headset is on.
Move the PWR switch to ON
position.
Check and make sure the
Headset is placed in pairing
mode.
With the power off, move the
PWR switch to ON position
during hold the CALL button
to place the Headset in pairing
mode.
Low sound Check the speaker volume. lncrease the volume level.
LED indication
![](/img.php?id=1420471&img=bg8.png)
14 15
Declaration of Confi rmation
ENG
ENG
Precautions
FCC NOTICE TO USERS:
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
IMPORTANT NOTE:
To comply with the FCC RF exposure compliance requirements, no change to
the antenna or the device is permitted. Any change to the antenna or the device
could result in the device exceeding the RF exposure requirements and void user’s
authority to operate the device.
Do not drop the unit from high places.
Do not modify, repair, or take apart.
Do not expose directly to water, alcohol, benzene, etc. for cleaning.
Do not expose directly to fl ammables.
Do not place or keep the unit near a heat source.
Keep unit away from humidity & dust.
Do not place heavy objects on the unit.
Please only use the Headset with an LG original charger (Travel Adaptor, Vehicle
Power Charger). Otherwise the Headset might be damaged.
Changes or modifi cations not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
There is a risk of explosion if the battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
The ear loop is made of a durable plastic. However, bending the ear loop
repeatedly is not recommended.
Additional Information
1. Radio frequency exposure
This Bluetooth® Headset, HBM-905, is a radio transmitter and receiver. When in
operation, it communicates with a Bluetooth
®
equipped mobile device by receiving and
transmitting radio frequency (RF) electromagnetic fi elds (microwaves) in the frequency
range 2.4 to 2.4835 GHz. The output power of the radio transmitter is low
Your Bluetooth® Headset is designed to operate in compliance with the RF exposure
guidelines and limits set by national authorities and international health agencies when
used any compatible LG Electronics mobile phone.
2. Potentially explosive atmosphere
Turn off your electronic device when in any area with a potentially explosive
atmosphere. It is rare, but your electronic device could generate sparks. Sparks in such
areas could cause an explosion or fi re resulting in bodily injury or even death. Areas
with a potentially explosive atmosphere are often, but not always, clearly marked.
Specifi cation
ITEM Description
Bluetooth
®
specifi cation
V3.0 (HFP/HSP/A2DP/PBAP)
Battery
Battery 3.7V / 105mAh Li-Polymer
Stand by time Up to 140Hrs
Talk Time Up to 4Hrs
Charging time < 2Hrs
Operation temperature -10°C ~ 60°C
Dimension / weight 16.0mm(W) X 83.3mm(L) X 10.2mm(H) / 11g
![](/img.php?id=1420471&img=bg9.png)
16 17
ENG
ENG
- If LG Electronics repairs or replaces the product, the repaired or replaced
product shall be warranted for the remaining time of the original warranty period
or for ninety (90) days from the date of repair, whichever is longer. Repair or
replacement may involve the use of functionally equivalent reconditioned units.
Replaced parts or components will become the property of LG Electronics.
- This Warranty does not cover any failure of the product due to normal wear and
tear, or due to misuse, including but not limited to use in other than the normal
and customary manner, in accordance with instructions for use and maintenance
of the product. Nor does this warranty cover any failure of the product due to
accident, modifi cation or adjustment, acts of God or damage resulting from liquid.
- This warranty does not cover product failures due to improper repair installations,
modifi cations or service performed by a non- LG Electronics authorized person.
Tampering with any of the seals on the product will void the warranty.
- THERE ARE NO EXPRESS WARRANTIES, WHETHER WRITTEN OR
ORAL, OTHER THAN THIS PRINTED INCLUDING WITHOUT LIMITATION
THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS LIMITED
WARRANTY. IN NO EVENT SHALL LG ELECTRONICS OR ITS VENDORS
BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY
NATURE WHATSOEVER, INCLUDING BUT NOT LIMITED TO LOST PROFITS
OR COMMERCIAL LOSS, TO THE FULL EXTENT THOSE DAMAGES CAN BE
DISCLAIMED BY LAW.
• Some countries/states do not allow the exclusion or limitation of incidental or
consequential damages, or limitation of the duration of implied warranties, so
the preceding limitations or exclusions may not apply to you. The warranty
provided does not affect the consumer’s statutory rights under applicable national
legislation in force, nor the consumer’s rights against the dealer arising from their
sales/purchase contract.
3.Emergency calls
IMPORTANT!
This Bluetooth
®
Headset and the electronic device connected to the Headset
operate using radio signals, cellular and landline networks as well as user -
programmed functions, which cannot guarantee connection under all conditions.
Therefore you should never rely solely upon any electronic device for essential
communications (e.g. medical emergencies). Remember, in order to make or
receive calls, the Headset and the electronic device connected to the Headset
must be switched on and in a service area with adequate cellular signal strength.
Emergency calls may not be possible on all cellular phone networks or when
certain network services and/or phone features are in use. Check with your local
service provider.
4. Battery information
A rechargeable battery has a long service life if treated properly. A new battery
or one that has not been used for a long period of time could have reduced
capacity the fi rst few times it is used.
Do not expose the battery to extreme temperatures, never above +60°(+140°F)
or under -20°(-4°F). For maximum battery capacity, use the battery in room
temperature. If the battery is used in low temperatures, the battery capacity
will be reduced. The battery can only be charged in temperatures between
+10°(+50°F) and +45°(+113°F). For your safety, do not remove the battery
incorperated in the product. If you need to replace the battery, take it to the
nearest authorised LG Electronics service point or dealer for assistance.
5. Recycling the battery in your Bluetooth
®
Headset
The battery in your Bluetooth
®
Headset must be disposed of properly and
should never be placed in municipal waste. The LG Electronics service partner
removing battery will dispose of it according to local regulations.
6. Conditions
- The warranty is valid only if the original receipt issued to the original purchaser
by the dealer, specifying the date of purchase and serial number, is presented
with the product to be repaired or replaced. LG Electronics reserves the right to
refuse warranty service if this information has been removed or changed after
the original purchase of the product from the dealer.
Additional InformationAdditional Information
![](/img.php?id=1420471&img=bga.png)
ENG
Subject to the conditions of this Limited Warranty, LG Electronics warrants this
product to be free from defects in design, material and workmanship at the time
of its original purchase by a consumer, and for a subsequent period of one (1)
year. Should your product need warranty service, please return it to the dealer
from whom it was purchased or contact your local LG Electronics contact center
to get further information.
Limited Warranty
Avoiding hearing damage
Permanent hearing loss may occur if you use your Headset at a high volume.
Set the volume to a safe level.
You can adapt over time to a higher volume of sound that may sound normal
but can be damaging to your hearing. If you experience ringing in your ears or
muffl ed speech, stop listening and have your hearing checked. The louder the
volume, the less time is required before your hearing could be affected. Hearing
experts suggest that to protect your hearing:
• Limit the amount of time you use Headset at high volume.
• Avoid turning up the volume to block out noisy surroundings.
• Turn the volume down if you can’t hear people speaking near you.
For information about how to set a maximum volume limit on your handset,
please refer to the features guide for your handset.
Using Headsets safely
Use of Headsets to listen to music while operating a vehicle is not recommended
and is illegal in some areas.
Be careful and attentive while driving. Stop using this device if you fi nd it
disruptive or distracting while operating any type of vehicle or performing any
other activity that requires your full attention.
Important safety information
18
