Nokia Wireless Charging Plate DT-900 User Guide
Issue 1
About your wireless charger
With the Nokia Wireless Charging Plate DT-900, you can charge your phone or other
compatible device without the hassle of untangling charger cables. Just pop your
phone on the charging plate, and your phone starts charging.
Parts of the product are magnetic. Metallic materials may be attracted to the product.
Do not place credit cards or other magnetic storage media near the product, because
info stored on them may be erased.
The surface of this product is nickel-free.
Read this user guide carefully before using the product. Also, read the user guide for
the device that you connect to the product.
About Qi
Qi is a global standard that makes wireless charging possible for your device. With a
Qi-compatible device, you don't need to connect any cables. You just place your
device on the charging surface.
Qi works using magnetic induction, and is currently designed for devices that use 5
watts of power or less, such as mobile phones. Qi chargers and devices use the same
frequency, so as long as their active areas are touching, all Qi products are
compatible, regardless of manufacturer or brand. For more details, see the user
guides of both devices.
2 About your wireless charger
© 2012 Nokia. All rights reserved.
Keys and parts
1Power supply
2Charger cable
3Indicator light
4Power supply connector
5Charging plate
Switch the charging plate on or off
Keys and parts 3
© 2012 Nokia. All rights reserved.
Use the charging plate only with the supplied power supply.
Switch on
1 Connect one end of the charger cable to the power supply.
2 Plug the power supply into a wall outlet.
3 Connect the other end of the cable to the charging plate.
You can keep the plate plugged into the wall outlet even when you're not charging
your phone. The plate uses hardly any power when not charging.
Switch off
Disconnect the power supply from the plate, then unplug from the wall outlet.
Charge your device
1 Make sure that there's nothing on the charging plate.
2 Place your phone or other compatible device on the charging plate. When the
white indicator light goes off, the battery is fully charged.
It's normal for the plate and phone to get warm, and they may get even warmer if you
use your phone to, for example, stream music while charging.
4 Charge your device
© 2012 Nokia. All rights reserved.
Keep the area around the plate free. If there is something on the plate besides your
phone, the phone doesn't charge, and the white indicator light blinks quickly.
Indicator lights
Wonder what the different lights on your charging plate mean?
Continuous light Charging
One long blink The battery of your phone is already full
Blinking quickly Charging problem
If there is a problem with charging:
•Check that no other object is on the plate.
•Make sure the plate doesn't get too hot. If the plate is too warm, take your phone
off the plate, and switch the plate off. The plate may switch off automatically if
it is too hot. When the plate has cooled down, try charging again.
Find support
When you want to learn more about how to use your device, or if you're unsure how
your device should work, read the user guide thoroughly.
If your issue remains unsolved, contact Nokia for repair options.
Product and safety information
Take care of your device
Handle your device, charger and accessories with care. The following suggestions help you protect your warranty coverage.
•Keep the device dry. Precipitation, humidity, and all types of liquids or moisture can contain minerals that corrode
electronic circuits. If your device gets wet, allow the device to dry.
Indicator lights 5
© 2012 Nokia. All rights reserved.
•Use the charger for intended purposes only. Improper use, or use of incompatible chargers may present a risk of fire,
explosion, or other hazard. Never use a damaged charger. Only use the charger indoors.
•Do not attempt to charge a device having a damaged, cracked or open battery case or a device that is not compatible
with Qi.
•Do not use or store the device in dusty or dirty areas. Moving parts and electronic components can be damaged.
•Do not store the device in high temperatures. High temperatures can shorten the life of the device, and warp or melt
plastics.
•Do not store the device in cold temperatures. When the device warms to its normal temperature, moisture can form
inside the device and damage electronic circuits.
•Do not attempt to open the device.
•Unauthorised modifications may damage the device and violate regulations governing radio devices.
•Do not drop, knock, or shake the device. Rough handling can break internal circuit boards and mechanics.
•Only use a soft, clean, dry cloth to clean the surface of the device.
Recycle
Always return your used electronic products, batteries, and packaging materials to dedicated collection points. This way
you help prevent uncontrolled waste disposal and promote the recycling of materials.
Implanted medical devices
Manufacturers of medical devices recommend a minimum separation of 15.3 centimetres (6 inches) between a wireless
device and an implanted medical device, such as a pacemaker or implanted cardioverter defibrillator, to avoid potential
interference with the medical device. Persons who have such devices should:
•Always keep the wireless device more than 15.3 centimetres (6 inches) from the medical device.
•Not carry the wireless device in a breast pocket.
•Switch the wireless device off if there is any reason to suspect that interference is taking place.
•Follow the manufacturer directions for the implanted medical device.
If you have any questions about using your wireless device with an implanted medical device, consult your health care
provider.
Copyright and other notices
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this DT-900 product is in compliance with the essential requirements and other
relevant provisions of Directive 2004/108/EC. A copy of the Declaration of Conformity can be found at http://
www.nokia.com/global/declaration.
© 2012 Nokia. All rights reserved.
Nokia, Nokia Connecting People, and the Nokia Original Accessories logo are trademarks or registered trademarks of Nokia
Corporation.
6 Copyright and other notices
© 2012 Nokia. All rights reserved.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior
written permission of Nokia is prohibited. Nokia operates a policy of continuous development. Nokia reserves the right to
make changes and improvements to any of the products described in this document without prior notice.
The ‘Qi’ symbol is a trademark of the Wireless Power Consortium
To the maximum extent permitted by applicable law, under no circumstances shall Nokia or any of its licensors be responsible
for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no warranties of any kind, either
express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular
purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise
this document or withdraw it at any time without prior notice.
The availability of some features may vary by region. Please contact your operator for more details.
The availability of products may vary by region. For more info, contact your Nokia dealer. This device may contain
commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion
contrary to law is prohibited.
FCC/INDUSTRY CANADA/MEXICO NOTICE
This device complies with part 15 of the FCC rules and Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. Your device may cause TV or radio
interference (for example, when using a device in close proximity to receiving equipment). If you require assistance, contact
your local service facility. Any changes or modifications not expressly approved by Nokia could void the user's authority to
operate this equipment.
