Motorola Solutions 89FT5866 Portable 2-Way Radio User Manual MOTOTRBO Professional Digital Two Way Radio System
Motorola Solutions, Inc. Portable 2-Way Radio MOTOTRBO Professional Digital Two Way Radio System
Contents
- 1. Users Guide
- 2. RF Safety Manual
Users Guide
PROFESSIONAL DIGITAL TWO-WAY RADIO
MOTOTRBO™
SL Series
PORTABLES
USER GUIDE
Contents
Declaration of Conformity....................... 13
Notes...............................................15
Important Safety Information........16
Software Version............................17
Computer Software Copyrights....18
Handling Precautions.................... 19
RF Energy Exposure and
Product Safety Guidelines
and Instructions......................... 20
Notes...............................................21
Getting Started............................... 22
How to Use This Guide..................................22
What Your Dealer/System Administrator
Can Tell You.............................................22
Preparing Your Radio for Use.......23
Charging the Battery......................................23
Attaching the Battery..................................... 24
Attaching the Earpiece/Audio Accessory.......24
Powering Up the Radio..................................25
Adjusting the Volume.....................................25
Identifying Radio Controls............ 26
Contents
3
English
Radio Controls...............................................26
Using the 4-Way Navigation Disc.................. 27
Using the Keypad.......................................... 28
Additional Radio Controls in
Non-Connect Plus Mode............30
Push-To-Talk (PTT) Button............................30
Programmable Buttons..................................30
Assignable Radio Functions............... 31
Assignable Settings or Utility
Functions....................................... 33
Accessing the Programmed Functions..........33
Identifying Status Indicators...........................34
Display Icons.......................................34
Call Icons............................................ 37
Utilities Icons.......................................37
Mini Notice Icons.................................38
Sent Item Icons ..................................38
Job Tickets Icons................................ 39
LED Indicator...................................... 39
Audio Tones........................................40
Indicator Tones................................... 41
Switching Between Connect Plus and
Non-Connect Plus Modes.........................41
IP Site Connect..............................................41
Capacity Plus.................................................42
Linked Capacity Plus..................................... 42
Making and Receiving Calls..........44
Selecting a Site..............................................44
Roam Request....................................44
Site Restriction....................................44
Selecting a Zone............................................44
Selecting a Channel.......................................45
Receiving and Responding to a Radio Call... 46
Receiving and Responding to a
Group Call......................................46
Receiving and Responding to a
Private Call.................................... 47
Receiving an All Call...........................48
Receiving and Responding to a
Phone Call..................................... 48
Making a Radio Call.......................................49
Making a Group Call........................... 50
Making a Private Call .........................51
Making an All Call............................... 52
Making a Phone Call with the One
Touch Access Button.....................52
Making a Private Call with a One
Touch Call Button.......................... 54
Contents
4
English
Making a Group, Private or All Call
with the Programmable Number
Key ................................................55
Making a Phone Call with the
Programmable Phone Button........ 56
Stopping a Radio Call....................................57
Talkaround.....................................................58
Monitoring Features.......................................59
Monitoring a Channel..........................59
Permanent Monitor............................. 59
Advanced Features in Non-
Connect Plus Mode.................... 60
Radio Check.................................................. 60
Sending a Radio Check...................... 60
Remote Monitor............................................. 61
Initiating Remote Monitor....................62
Scan Lists...................................................... 63
Viewing an Entry in the Scan List....... 63
Viewing an Entry in the Scan List
by Alias Search..............................64
Editing the Scan List........................... 64
Scan...............................................................68
Setting an Active Scan List................. 68
Starting and Stopping Scan................ 69
Responding to a Transmission
During a Scan................................ 69
Deleting a Nuisance Channel............. 70
Restoring a Nuisance Channel........... 70
Contact Settings............................................ 70
Making a Group Call from Contacts....71
Making a Private Call from
Contacts ........................................72
Making a Phone Call from Contacts... 73
Making a Call Alias Search ................75
Making a Group, Private, Phone or
All Call by Alias Search .................77
Assigning an Entry to a
Programmable Number Key ......... 78
Removing the Association between
Entry and Programmable
Number Key ..................................79
Adding a New Contact........................ 80
Sending a Message to a Contact........80
Call Indicator Settings....................................81
Activating and Deactivating Call
Ringers for Call Alert .....................81
Activating and Deactivating Call
Ringers for Private Calls ............... 81
Activating and Deactivating Call
Ringers for Text Message..............82
Contents
5
English
Activating and Deactivating Call
Ringers for Telemetry Status
with Text........................................ 83
Assigning Ring Styles......................... 83
All Tones.............................................84
Ring Alert Type Selection................... 84
Escalating Alarm Tone Volume...........85
Call Log Features.......................................... 85
Viewing Recent Calls..........................86
Missed Call Screen.............................86
Storing an Alias from a Call List..........86
Deleting a Call from a Call List............86
Viewing Details from a Call List.......... 87
Call Alert Operation....................................... 87
Receiving and Responding to a
Call Alert........................................ 88
Making a Call Alert from the
Contact List....................................88
Making a Call Alert with the One
Touch Access Button.....................89
Emergency Operation....................................89
Receiving an Emergency Alarm..........90
Responding to an Emergency
Alarm............................................. 90
Sending an Emergency Alarm............ 91
Sending an Emergency Alarm with
Call.................................................92
Sending an Emergency Alarm with
Voice to Follow ............................. 93
Reinitiating an Emergency Mode........94
Exiting Emergency Mode....................94
Text Message Features.................................94
Writing and Sending a Text
Message........................................ 95
Sending a Quick Text Message..........96
Sending a Quick Text Message..........97
Accessing the Drafts Folder................98
Managing Fail-to-Send Text
Messages.................................... 100
Managing Sent Text Messages........ 102
Receiving a Text Message................105
Managing Received Text Messages.105
Job Tickets...................................................109
Accessing the Job Ticket Folder.......109
Responding to the Job Ticket........... 110
Deleting a Job Ticket........................ 111
Privacy.........................................................111
Covert Mode................................................ 113
Entering Covert Mode.......................113
Exiting Covert Mode..........................113
Dual Tone Multi Frequency (DTMF)............ 113
Multi-Site Controls....................................... 113
Starting an Automatic Site Search....114
Stopping an Automatic Site Search.. 115
Contents
6
English
Starting a Manual Site Search.......... 115
Security........................................................116
Radio Disable....................................116
Radio Enable.................................... 118
Lone Worker................................................ 119
Password Lock Features............................. 120
Accessing the Radio from
Password..................................... 120
Unlocking the Radio from Locked
State............................................ 121
Turning the Password Lock On or
Off................................................ 121
Changing the Password....................122
Bluetooth Operation.....................................123
Turning Bluetooth On and Off...........123
Finding and Connecting to a
Bluetooth Device..........................124
Finding and Connecting from a
Bluetooth Device (Discoverable
Mode)...........................................125
Disconnecting from a Bluetooth
Device..........................................125
Switching Audio Route......................126
Viewing Device Details..................... 126
Editing Device Name........................ 126
Deleting Device Name...................... 127
Bluetooth Mic Gain............................127
Notification List............................................ 127
Accessing the Notification List.......... 128
Over-the-Air-Programming (OTAP)............. 128
Utilities......................................................... 129
Locking and Unlocking the Keypad.. 129
Turning Keypad Tones On or Off......129
Turning the Option Board
Feature(s) On or Off.................... 130
Identifying Cable Type...................... 130
Turning the Voice Operating
Transmission (VOX) Feature
On or Off...................................... 130
Controlling the Display Backlight...... 131
Turning the Radio Tones/Alerts On
or Off............................................132
Setting the Tone Alert Volume
Offset Level..................................132
Turning the Talk Permit Tone On
or Off............................................133
Setting the Text Message Alert
Tone.............................................134
Changing the Display Mode..............134
Adjusting the Display Brightness...... 135
Wallpaper Mode................................136
Screen Saver Mode.......................... 136
Audio Accessory............................... 137
Auto Keypad Lock.............................137
Contents
7
English
Language..........................................138
Turning the LED Indicator On or Off. 138
Voice Announcement........................138
Digital Mic AGC (Mic AGC-D)........... 139
Intelligent Audio................................ 140
Turning the Acoustic Feedback
Suppressor Feature On or Off..... 141
Text Entry Configuration................... 142
Flexible Receive List.........................147
Accessing General Radio
Information...................................150
RSSI Values......................................153
Additional Radio Controls in
Connect Plus Mode.................. 154
Push-To-Talk (PTT) Button..........................154
Programmable Buttons................................154
Assignable Radio Functions............. 155
Assignable Settings or Utility
Functions..................................... 155
Identifying Status Indicators in Connect
Plus Mode...............................................156
Display Icons.....................................156
Call Icons.......................................... 158
Sent Item Icons ................................158
LED Indicator.................................... 159
Indicator Tones................................. 160
Audio Tones......................................160
Making and Receiving Calls in
Connect Plus Mode.................. 161
Selecting a Site............................................161
Roam Request..................................161
Site Lock On/Off................................161
Site Restriction..................................161
Selecting a Zone..........................................162
Using Multiple Networks.............................. 162
Selecting a Call Type...................................163
Receiving and Responding to a Radio Call. 163
Receiving and Responding to a
Group Call....................................163
Receiving and Responding to a
Private Call.................................. 164
Receiving an All Call.........................165
Making a Radio Call.....................................165
Making a Call with the Channel
Selector Knob.............................. 166
Making a Private Call with a One
Touch Call Button........................ 168
Contents
8
English
Making a Call with the
Programmable Manual Dial
Button.......................................... 168
Advanced Features in Connect
Plus Mode................................. 170
Auto Fallback...............................................170
Indications of Auto Fallback Mode....170
Making/Receiving Calls in Fallback
Mode............................................170
Returning to Normal Operation.........171
Radio Check................................................ 171
Sending a Radio Check.................... 171
Remote Monitor........................................... 172
Initiating Remote Monitor..................172
Scan.............................................................173
Starting and Stopping Scan.............. 173
Responding to a Transmission
During a Scan.............................. 174
User Configurable Scan...............................174
Turning Scan On or Off.....................175
Editing the Scan List......................... 175
Understanding Scan Operation.........176
Contacts Settings.........................................177
Making a Private Call from Contacts.177
Making a Call Alias Search...............178
Adding a New Contact...................... 179
Call Indicator Settings..................................179
Activating and Deactivating Call
Ringers for Call Alert ...................179
Activating and Deactivating Call
Ringers for Private Calls.............. 180
Activating and Deactivating Call
Ringers for Text Message............181
Assigning Ring Styles....................... 181
Escalating Alarm Tone Volume.........182
Call Log Features........................................ 182
Viewing Recent Calls........................183
Deleting a Call from a Call List..........183
Viewing Details from a Call List........ 184
Call Alert Operation..................................... 184
Receiving and Responding to a
Call Alert...................................... 184
Making a Call Alert from the
Contact List..................................184
Making a Call Alert with the One
Touch Access Button...................185
Emergency Operation..................................185
Receiving an Incoming Emergency.. 187
Saving the Emergency Details to
the Alarm List...............................188
Deleting the Emergency Details........188
Contents
9
English
Responding to an Emergency Call... 188
Responding to an Emergency Alert.. 189
Initiating an Emergency Call............. 189
Initiating an Emergency Call with
Voice to Follow............................ 190
Initiating an Emergency Alert............190
Exiting Emergency Mode..................191
Text Message Features...............................191
Writing and Sending a Text
Message...................................... 192
Sending a Quick Text Message........193
Sending a Quick Text Message
with the One Touch Access
Button.......................................... 194
Accessing the Drafts Folder..............195
Managing Fail-to-Send Text
Messages.................................... 197
Managing Sent Text Messages........ 199
Receiving a Text Message................202
Reading a Text Message..................202
Managing Received Text Messages.202
Privacy.........................................................206
Making a Privacy-Enabled
(Scrambled) Call.......................... 207
Security........................................................207
Radio Disable....................................207
Radio Enable.................................... 209
Password Lock Features............................. 210
Accessing the Radio from
Password..................................... 210
Unlocking the Radio from Locked
State............................................ 211
Turning the Password Lock On or
Off................................................ 211
Changing the Password....................212
Bluetooth Operation.....................................213
Turning Bluetooth On and Off...........213
Finding and Connecting to a
Bluetooth Device..........................214
Finding and Connecting from a
Bluetooth Device (Discoverable
Mode)...........................................215
Disconnecting from a Bluetooth
Device..........................................215
Switching Audio Route......................216
Viewing Device Details..................... 216
Editing Device Name........................ 216
Deleting Device Name...................... 217
Bluetooth Mic Gain............................217
Notification List............................................ 217
Accessing the Notification List.......... 218
Utilities......................................................... 218
Turning the Radio Tones/Alerts On
or Off............................................218
Contents
10
English
Turning Keypad Tones On or Off......219
Setting the Tone Alert Volume
Offset Level..................................219
Turning the Talk Permit Tone On
or Off............................................220
Changing the Display Mode..............220
Adjusting the Display Brightness...... 221
Controlling the Display Backlight...... 222
Locking and Unlocking the Keypad.. 222
Language..........................................223
Turning the LED Indicator On or Off. 223
Identifying Cable Type...................... 224
Voice Announcement........................224
Wallpaper Mode................................225
Screen Saver Mode.......................... 225
Audio Accessory............................... 226
Auto Keypad Lock.............................226
Digital Mic AGC (Mic AGC-D)........... 226
Intelligent Audio................................ 227
Turning the Acoustic Feedback
Suppressor Feature On or Off..... 228
Text Entry Configuration................... 229
Accessing General Radio
Information...................................234
Accessories..................................245
Antennas......................................................245
Audio Accessories....................................... 245
Batteries.......................................................245
Bluetooth......................................................245
Cables..........................................................245
Carry Devices.............................................. 245
Chargers......................................................246
Miscellaneous Accessories..........................246
Batteries and Chargers Warranty......... 247
The Workmanship Warranty........................247
The Capacity Warranty................................247
Limited Warranty....................................248
MOTOROLA COMMUNICATION
PRODUCTS........................................... 248
I. WHAT THIS WARRANTY COVERS
AND FOR HOW LONG:......................... 248
II. GENERAL PROVISIONS:....................... 249
III. STATE LAW RIGHTS:............................249
IV. HOW TO GET WARRANTY SERVICE:.249
V. WHAT THIS WARRANTY DOES NOT
COVER:..................................................250
VI. PATENT AND SOFTWARE
PROVISIONS:........................................ 250
Contents
11
English
Declaration of Conformity
This declaration is applicable to your radio only if your radio is labeled with the FCC logo shown below.
Declaration of Conformity
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party
Name: Motorola Solutions, Inc.
Address: 1303 East Algonquin Road, Schaumburg, IL 60196-1078, U.S.A.
Phone Number: 1-800-927-2744
Hereby declares that the product:
Model Name: SL7550/ SL7590/ SL7580
conforms to the following regulations:
FCC Part 15, subpart B, section 15.107(a), 15.107(d) and section 15.109(a)
Declaration of Conformity
13
English
Class B Digital Device
As a personal computer peripheral, this device complies with Part 15 of the FCC Rules. This device complies with
Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
1This device may not cause harmful interference, and
2This device must accept any interference received, including interference that may cause undesired operation.
Note:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
Declaration of Conformity
14
English
Notes
Notes
15
English
Important Safety Information
RF Energy Exposure and Product Safety Guide
for Portable Two-Way Radios
ATTENTION!
This radio is restricted to Occupational use only.
Before using the radio, read the RF Energy Exposure
and Product Safety Guide for Portable Two-Way
Radios which contains important operating
instructions for safe usage and RF energy awareness
and control for Compliance with applicable standards
and Regulations.
For a list of Motorola-approved antennas, batteries,
and other accessories, visit the following website:
http://www.motorolasolutions.com
Any modification to this device, not expressly
authorized by Motorola, may void the user’s authority
to operate this device.
Under Industry Canada regulations, this radio
transmitter may only operate using an antenna of a
type and maximum (or lesser) gain approved for the
transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent
isotropically radiated power (e.i.r.p.) is not more than
that necessary for successful communication.
This radio transmitter has been approved by Industry
Canada to operate with Motorola-approved antenna
with the maximum permissible gain and required
antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain
greater than the maximum gain indicated for that
type, are strictly prohibited for use with this device.
Important Safety Information
16
English
Informations importantes sur la sécurité
vi
Français Canadien
Informations importantes sur la
sécurité
Exposition aux radiofréquences et sécurité du produit pour
radios bidirectionnelles portatives
ATTENTION!
Cette radio ne doit être utilisée qu'à des fins professionnelles.
Avant d'utiliser la radio, lisez le guide Exposition aux
radiofréquences et sécurité du produit pour radios
bidirectionnelles portatives, qui contient d'importantes
instructions de fonctionnement pour une utilisation sécuritaire et
des informations sur l'exposition aux fréquences
radioélectriques afin d'assurer la conformité aux normes et
règlements applicables.
Pour obtenir une liste d'antennes et d'autres accessoires
approuvés par Motorola, consultez le site Web:
http://www.motorolasolutions.com
Selon la règlementation d'Industrie Canada, cet émetteur radio
ne peut être utilisé qu'avec une antenne dont le type et le gain
maximal (ou minimal) sont approuvés par Industrie Canada
pour cet émetteur. Afin de limiter les interférences radio pour les
autres utilisateurs, le type et le gain de l'antenne doivent être
choisis de façon à ce que la puissance isotrope rayonnée
équivalente (P.I.R.E.) ne soit pas plus forte qu'il ne le faut pour
établir la communication.
Le présent émetteur a été approuvé par Industrie Canada pour
fonctionner avec les types d'antenne agréés par Motorola et
ayant un gain admissible maximal ainsi que l'impédance
requise pour chaque type d'antenne indiqué.
Les types d'antenne non inclus, dont le gain est supérieur au
gain maximal indiqué, sont strictement interdits pour
l'exploitation de l'émetteur.
FRC_Safety_PCR_ASTRO_New.fm Page vi Tuesday, June 18, 2013 10:55 AM
Software Version
All the features described in the following sections are
supported by the radio's software version R02.30.00
or later.
See Checking the Firmware Version and Codeplug
Version on page 151 to determine your radio's
software version.
Check with your dealer or system administrator for
more details of all the features supported.
Software Version
17
English
Computer Software Copyrights
The Motorola products described in this manual may
include copyrighted Motorola computer programs
stored in semiconductor memories or other media.
Laws in the United States and other countries
preserve for Motorola certain exclusive rights for
copyrighted computer programs including, but not
limited to, the exclusive right to copy or reproduce in
any form the copyrighted computer program.
Accordingly, any copyrighted Motorola computer
programs contained in the Motorola products
described in this manual may not be copied,
reproduced, modified, reverse-engineered, or
distributed in any manner without the express written
permission of Motorola. Furthermore, the purchase of
Motorola products shall not be deemed to grant either
directly or by implication, estoppel, or otherwise, any
license under the copyrights, patents or patent
applications of Motorola, except for the normal non-
exclusive license to use that arises by operation of
law in the sale of a product.
The AMBE+2™ voice coding Technology embodied in
this product is protected by intellectual property rights
including patent rights, copyrights and trade secrets
of Digital Voice Systems, Inc.
This voice coding Technology is licensed solely for
use within this Communications Equipment. The user
of this Technology is explicitly prohibited from
attempting to decompile, reverse engineer, or
disassemble the Object Code, or in any other way
convert the Object Code into a human-readable form.
U.S. Pat. Nos. #5,870,405, #5,826,222, #5,754,974,
#5,701,390, #5,715,365, #5,649,050, #5,630,011,
#5,581,656, #5,517,511, #5,491,772, #5,247,579,
#5,226,084 and #5,195,166.
Computer Software Copyrights
18
English
Handling Precautions
The MOTOTRBO Series Digital Portable radio meets
IP54 specifications, allowing the radio to withstand
adverse field conditions such as being exposed to
water or dust.
— Keep your radio clean and exposure to water
should be avoided to help ensure proper
functionality and performance.
— To clean the exterior surfaces of the radio, use a
diluted solution of mild dishwashing detergent and
fresh water (i.e. one teaspoon of detergent to one
gallon of water).
— These surfaces should be cleaned whenever a
periodic visual inspection reveals the presence of
smudges, grease, and/or grime.
Caution: The effects of certain chemicals and
their vapors can have harmful results on
certain plastics. Avoid using aerosol sprays,
tuner cleaners and other chemicals.
Handling Precautions
19
English
RF Energy Exposure and Product
Safety Guidelines and Instructions
For more detailed proper usage instructions,
warnings and cautions, refer to the RF Energy
Exposure and Product Safety Guide for Portable
Two-Way Radios booklet.
— To ensure a comfortable audio level and
compliance with RF energy exposure limits, do not
hold the radio against the ear or alongside the
head.
— Use only in front of the face or with Motorola
Solutions approved audio accessories and carry
cases to ensure compliance with RF energy
exposure limits.
RF Energy Exposure and Product...
20
English
Notes
Notes
21
English
Getting Started
How to Use This Guide
This User Guide covers the basic operation of the
MOTOTRBO Portables.
However, your dealer or system administrator may
have customized your radio for your specific needs.
Check with your dealer or system administrator for
more information.
For features that are available in both conventional
Analog and Digital modes, no icon is shown.
Conventional Analog Mode-Only features are not
available in Connect Plus mode of operation. See
Additional Radio Controls in Connect Plus Mode on
page 154 for more information.
For features that are available in a conventional multi-
site mode, see IP Site Connect on page 41 for more
information.
Selected features are also available on the single-site
trunking mode, Capacity Plus. See Capacity Plus on
page 42 for more information.
Selected features are also available in the multi-site
trunking mode, Linked Capacity Plus. See Linked
Capacity Plus on page 42 for more information.
What Your Dealer/System Administrator Can
Tell You
You can consult your dealer or system administrator
about the following:
— Is your radio programmed with any preset
conventional channels?
— Which buttons have been programmed to access
other features?
— What optional accessories may suit your needs?
— What are the best radio usage practices for
effective communication?
— What maintenance procedures will help promote
longer radio life?
Getting Started
22
English
Preparing Your Radio for Use
Charging the Battery
Your radio is powered by a Lithium-Ion (Li-lon)
battery. To avoid damage and comply with warranty
terms, charge the battery using a Motorola charger
exactly as described in the charger user guide. All
chargers can charge only Motorola authorized
batteries. Other batteries may not charge. It is
recommended your radio remains powered off while
charging.
Charge a new battery 14 to 16 hours before initial
use for best performance. Prior to charging a
battery with the radio, it is recommended to turn
the radio off. Batteries charge best at room
temperature. The battery charging icon will be displayed until
the user unplugs the USB cable or takes the radio
out of the charger.
Preparing Your Radio for Use
23
English
Attaching the Battery
1Align the battery contacts with the contacts inside
the battery compartment. Insert the contact side of
the battery first. Gently push the battery into place.
1
2
2To attach battery cover, align it in place and slide
the battery latch ( ) until it snaps into place. Slide
battery latch into lock position.
1
2
A
3
Attaching the Earpiece/Audio Accessory
The audio jack ( ) is located on the antenna side of
the radio. It is used to connect accessories to the
radio.
A
1Lift up the flap of the Audio Jack cover. Align the
indicators ( ) on both the connector and housing,
then push until it fits in properly.
2Rotate connector clockwise or counterclockwise to
lock.
3To unlock, rotate until the indicators on both the
connector and housing are aligned. Pull out the
connector gently to disconnect from radio.
Preparing Your Radio for Use
24
English
A
Powering Up the Radio
Press the On/Off button ( ) on the front keypad. You
see a welcome message or welcome image.
The LED blinks green( ).
A
B
Adjusting the Volume
To increase the volume, push the Volume Button
( ) up.
To decrease the volume, push the volume button
down.
Note: Your radio can be programmed to have a
minimum volume offset where the volume level
cannot be lowered past the programmed minimum
volume. Check with your dealer or system
administrator for more information.
A
Preparing Your Radio for Use
25
English
Identifying Radio Controls
Radio Controls
5
9
4
3
7
8
2
1
15
11
12
10
6
14
13
1LED Indicator
2Push-to-Talk (PTT) Button
3Display
4Microphone
5Volume Button
6Front Button P1[1]
7On/Off Button
8Emergency Button[1]
94–way Navigation Disc
10 Antenna
11 Speaker
12 Front Button P2[1]
13 Back/Home Button
14 Menu/OK Button
15 Keypad
1These buttons are programmable.
Identifying Radio Controls
26
English
Using the 4-Way Navigation Disc
You can use the 4-way navigation disc,
, to scroll through options,
increase/decrease values, and navigate vertically.
Category Direction
or or
Menu Vertical
Navigation
-
Lists Vertical
Navigation
-
View Details Vertical
Navigation
Previous/Next
Item
Numeric
Values
Increase/
Decrease
-
You can use the 4-way navigation disc, , as a
number, alias, or free form text editor.
The button can be used to change the channels in
the home screen.
Press to select your desired channel.
Editor
Category
Direction
or or
Number - -
Alias - Move cursor one
character left/right.
Free
Form Text
Move cursor up/
down
Move cursor one
character left/right.
Identifying Radio Controls
27
English
Using the Keypad
You can use the 3 x 4 alphanumeric keypad to access your radio’s features. You can use the keypad to enter
subscriber aliases or IDs, and text messages. Many characters require that you press a key multiple times. The next
table shows the number of times a key needs to be pressed to generate the required character.
Key Number of Times Key is Pressed
1 2 3 4 5 6 7 8 9 10 11 12 13
1 . , ? ! @ & ' % — : * #
A B C 2
D E F 3
G H I 4
J K L 5
M N O 6
P Q R S 7
T U V 8
Identifying Radio Controls
28
English
Key Number of Times Key is Pressed
1 2 3 4 5 6 7 8 9 10 11 12 13
W X Y 8
0Note: Press to enter “0” and long press to activate the CAPS lock. Another long press to turn off
the CAPS lock.
* or
del Note: Press during text entry to delete the character. Press during numeric entry to enter a “*”.
# or
space Note: Press during text entry to insert a space. Press during numeric entry to enter a “#”. Long
press to change text entry method.
Identifying Radio Controls
29
English
Additional Radio Controls in Non-
Connect Plus Mode
Push-To-Talk (PTT) Button
The PTT button on the side of the radio ( ) serves
two basic purposes:
A
— While a call is in progress, the PTT button allows
the radio to transmit to other radios in the call.
Press and hold down PTT button to talk. Release
the PTT button to listen.
The microphone is activated when the PTT button
is pressed.
— While a call is not in progress, the PTT button is
used to make a new call (see Making a Radio Call
on page 49).
If the Talk Permit Tone (see Turning the Talk Permit
Tone On or Off on page 133) is enabled, wait until
the short alert tone ends before talking.
During a call, if the Channel Free Indication feature is
enabled on your radio (programmed by your dealer),
you will hear a short alert tone the moment the target
radio (the radio that is receiving your call) releases
the PTT button, indicating the channel is free for you
to respond.
You will also hear a continuous talk prohibit tone, if
your call is interrupted, indicating that you should
release the PTT button, for example when the radio
receives an Emergency Call.
Programmable Buttons
Your dealer can program the programmable buttons
as shortcuts to radio functions depending on the
duration of a button press:
— Short press – Pressing and releasing rapidly.
Additional Radio Controls in Non-Connect...
30
English
— Long press – Pressing and holding for the
programmed duration.
— Hold down – Keeping the button pressed.
Note: The programmed duration of a button press is
applicable for all assignable radio/utility functions or
settings. See Emergency Operation on page 185 for
more information on the programmed duration of the
Emergency button.
Assignable Radio Functions
Actions — A programmable button to access a CPS
programmable action list.
Audio Routing — Toggles audio routing between
internal and external speakers.
Bluetooth® Audio Switch — Toggles audio routing
between internal radio speaker and external
Bluetooth-enabled accessory.
Contacts — Provides direct access to the Contacts
list.
Call Alert — Provides direct access to the contacts
list for you to select a contact to whom a Call Alert
can be sent.
Call Log — Selects the call log list.
Channel Announcement — Plays zone and channel
announcement voice messages for the current
channel.
Display Radio Alias — Shows radio display name.
Emergency — Depending on the programming,
initiates or cancels an emergency.
Intelligent Audio — Toggles intelligent audio on or
off.
Job Tickets — Allows the user to view and act upon
job tickets.
Manual Dial — Depending on the programming,
initiates a Private or Phone Call by keying in any
subscriber ID or phone number.
Manual Site Roam[2] — Starts the manual site
search.
2Not applicable in Capacity Plus and Linked Capacity Plus
Additional Radio Controls in Non-Connect...
31
English
Mic AGC On/Off — Toggles the internal microphone
automatic gain control (AGC) on or off.
Monitor — Monitors a selected channel for activity.
Notifications — Provides direct access to the
Notifications list.
Nuisance Channel Delete[2] — Temporarily removes
an unwanted channel, except for the Selected
Channel, from the scan list. The Selected Channel
refers to the user’s selected zone/channel
combination from which scan is initiated.
One Touch Access — Directly initiates a predefined
Private, Phone or Group Call, a Call Alert or a Quick
Text message.
Option Board Feature — Toggles option board
feature(s) on or off for option board-enabled
channels.
Permanent Monitor[2] — Monitors a selected
channel for all radio traffic until function is disabled.
Phone— Provides direct access to the Phone
Contacts list
Power Battery Indicator — Displays the current
status of the battery level.
Privacy — Toggles privacy on or off.
Radio Alias and ID — Provides radio alias and ID.
Radio Check — Determines if a radio is active in a
system.
Radio Enable — Allows a target radio to be remotely
enabled.
Radio Disable — Allows a target radio to be remotely
disabled.
Remote Monitor — Turns on the microphone of a
target radio without it giving any indicators.
Repeater/Talkaround[2] — Toggles between using a
repeater and communicating directly with another
radio.
Ring Alert Type — Provides direct access to the
Ring Alert Type Setting.
Scan[2] — Toggles scan on or off.
Site Info — Displays current Linked Capacity Plus
site name and ID. Plays site announcement voice
messages for the current site (this function is
unavailable when Voice Announcement is disabled).
Site Lock On/Off[2] — When toggled on, the radio
searches the current site only. When toggled off, the
Additional Radio Controls in Non-Connect...
32
English
radio searches other sites in addition to the current
site.
Telemetry Control — Controls the Output Pin on a
local or remote radio.
Text Message — Selects the text message menu.
Transmit Interrupt Remote Dekey — Stops the
transmission of a remote monitored radio without
giving any indicators, or an ongoing interruptible call
to free the channel.
Unassigned — Unassigned programmable button.
Voice Announcement On/Off — Toggles voice
announcement on or off.
Voice Operating Transmission (VOX) — Toggles
VOX on or off.
Zone — Allows selection from a list of zones.
Assignable Settings or Utility Functions
All Tones/Alerts — Toggles all tones and alerts on
or off.
Brightness — Allows brightness to be set via the
manual brightness mode or auto brightness control
via the radio’s photo sensor.
Display Mode — Toggles the day/night display mode
on or off.
Wallpaper — Displayed on home screen.
Accessing the Programmed Functions
You can access various radio functions through one
of the following ways:
— A short or long press of the relevant
programmable buttons.
— Use the 4-Way Navigation Disc as follows:
1Press to access the menu. Press the
appropriate Menu Scroll button ( or ) to
access the menu functions.
2To select a function or enter a sub-menu, press
the button.
3To go back one menu level, or to return to the
previous screen, press the button. Long
Additional Radio Controls in Non-Connect...
33
English
press the button to return to the Home
screen.
Note: Your radio automatically exits the menu
after a period of inactivity and returns to your
Home screen.
Identifying Status Indicators
Display Icons
Your radio has a 2 inch landscape display with QVGA
(Quarter Video Graphics Array) 16-bit color
resolution.
The following are icons that appear on the radio’s
display. Icons are displayed arranged left-most in
order of appearance/usage.
Received Signal Strength Indicator
(RSSI)
The number of bars displayed
represents the radio signal strength.
Four bars indicate the strongest signal.
This icon is only displayed while
receiving.
Monitor
Selected channel is being monitored.
Bluetooth Not Connected
The Bluetooth feature is enabled but
there is no remote Bluetooth device
connected.
Bluetooth Connected
The Bluetooth feature is enabled. The
icon stays lit when a remote Bluetooth
device is connected.
Bluetooth Discoverable
The Bluetooth feature is enabled and
radio is in discoverable mode.
High Volume Data
Radio is receiving high volume data and
channel is busy.
Job Ticket Notification
Additional Radio Controls in Non-Connect...
34
English
Notification List has items to review.
Option Board
The Option Board is enabled. (Option
board enabled models only)
Option Board Non-Function
The Option Board is disabled.
Over-the-Air Programming Delay
Timer
Indicates time left before automatic
restart of radio.
Scan[3][4]
Scan feature is enabled.
Scan- Priority 1[3][4]
Radio detects activity on channel/group
designated as Priority 1.
Scan- Priority 2[3][4]
Radio detects activity on channel/group
designated as Priority 2.
Flexible Receive List
Flexible receive list is enabled.
Emergency
Radio is in Emergency mode.
Secure
The Privacy feature is enabled.
Unsecure
The Privacy feature is disabled.
Site Roaming[3]
The site roaming feature is enabled.
Talkaround[3][4]
In the absence of a repeater, radio is
currently configured for direct radio to
radio communication.
Additional Radio Controls in Non-Connect...
35
English
Battery
The number of bars (0 – 4) shown
indicates the charge remaining in the
battery. Blinks when the battery is low.
Battery Discharging Status
Shows battery discharging status.
All Tones Disabled
No ring tones available.
Call Log
Radio call log.
Contact
Radio contact is available.
Message
Incoming message.
Silent Ring
Silent ring mode is enabled.
Ring Only
Ringing mode is enabled.
Vibrate
Vibrate mode is enabled.
Vibrate and Ring
Vibrate and Ring mode is enabled.
Keypad
Keypad locked.
3Not applicable in Capacity Plus
4Not applicable in Linked Capacity Plus
Additional Radio Controls in Non-Connect...
36
English
Call Icons
The following icons appear on the radio’s display
during a call. These icons also appear in the Contacts
list to indicate ID type.
Private Call
Indicates a Private Call in progress.
Group Call/All Call
Indicates a Group Call or All Call in
progress.
Phone Call as Private Call
Indicates a Phone Call as Private Call
in progress. In the Contacts list, it
indicates a phone alias (name) or ID
(number).
Phone Call as Group/All Call
Indicates a Phone Call as Group/All
Call in progress. In the Contacts list, it
indicates a group alias (name) or ID
(number).
Bluetooth PC Call
Indicates a Bluetooth PC Call in
progress. In the Contacts list, it
indicates a Bluetooth PC Call alias
(name) or ID (number).
Private Call Alert
In the Contacts list, it indicates a
subscriber alias (name) or ID
(number).
Utilities Icons
The following icons appear beside menu items on the
radio’s display that offer the following options.
Checkbox (Empty)
Indicates the option is not selected.
Checkbox (Checked)
Indicates the option is selected.
Brightness
Additional Radio Controls in Non-Connect...
37
English
Indicates the brightness level.
Brightness Highlighted
Highlights the brightness level.
Mini Notice Icons
The following icons appear momentarily on the
radio’s display after an action to perform task is
taken.
Successful Transmission
(Positive)
Successful action taken.
Failed Transmission (Negative)
Failed action taken.
Transmission in Progress
(Transitional)
Transmitting. This is seen before
indication for Successful
Transmission or Failed Transmission.
Sent Item Icons
The following icons appear at the top right corner of
the radio’s display in the Sent Items folder.
OR
Sent Successfully
The text message is sent successfully.
OR
Individual or Group Message Read
The text message has been read.
OR
Individual or Group Message Unread
The text message has not been read.
OR
Send Failed
The text message has not been sent.
Additional Radio Controls in Non-Connect...
38
English
OR
In-Progress
— The text message to a group alias or ID
is pending transmission.
— The text message to a subscriber alias
or ID is pending transmission, followed
by waiting for acknowledgement.
Job Tickets Icons
All Jobs
Indicates all jobs listed.
New Jobs
Indicates new jobs.
LED Indicator
The LED indicator ( ) shows the operational status of
your radio.
A
Blinking red Radio is transmitting at low battery
condition, receiving an emergency
transmission or has failed the self-
test upon powering up.
Solid yellow Radio is monitoring a digital
conventional channel or in Bluetooth
Discoverable Mode. Also indicates
fair battery charge when
programmable button is pressed.
Blinking
yellow
Radio is scanning for activity or
receiving a Call Alert, flexible receive
Additional Radio Controls in Non-Connect...
39
English
list is enabled or all local Linked
Capacity Plus channels are busy.
Double
blinking
yellow
Radio is no longer connected to the
repeater while in Capacity Plus or
Linked Capacity Plus; all Capacity
Plus or Linked Capacity Plus
channels are currently busy . Auto
Roaming is enabled, radio is actively
searching for a new site, or radio has
yet to respond to a group call alert.
Also indicates that radio has yet to
respond to a group call alert, or radio
is locked.
Solid green Radio is powering up or transmitting.
Also indicates full charge of the
battery when the programmable
button is pressed.
Blinking
green
Radio is powering up, receiving a
non-privacy- enabled call or data,
detecting activity, or retrieving Over-
the-Air Programming transmissions
over the air.
Rapidly
blinking
green
Radio is receiving a privacy-enabled
call or data.
Note:
While in conventional mode, when the LED blinks
green, it indicates the radio detects activity over the
air. Due to the nature of the digital protocol, this
activity may or may not affect the radio's programmed
channel.
For Capacity Plus and Linked Capacity Plus, there is
no LED indication when the radio is detecting activity
over the air.
Audio Tones
Alert tones provide you with audible indications of the
radio’s status or the radio’s response to data
received.
High pitched tone Low pitched tone
Continuous Tone A monotone sound.
Sounds continuously
until termination.
Additional Radio Controls in Non-Connect...
40
English
High pitched tone Low pitched tone
Periodic Tone Sounds periodically
depending on the
duration set by the radio.
Tone starts, stops, and
repeats itself.
Repetitive Tone A single tone that
repeats itself until it is
terminated by the user.
Momentary Tone Sounds only once for a
short period of time
defined by the radio.
Indicator Tones
High pitched tone Low pitched tone
Positive Indicator Tone
Negative Indicator Tone
Switching Between Connect Plus and Non-
Connect Plus Modes
To switch to a non-Connect Plus mode, you must
change to another zone, if programmed by your
dealer or system administrator. Check with your
dealer or system administrator to see if your radio has
been programmed with non-Connect Plus zones, and
what features are available while operating in non-
Connect Plus zones.
IP Site Connect
This feature allows your radio to extend conventional
communication beyond the reach of a single site, by
connecting to different available sites which are
connected via an Internet Protocol (IP) network.
When the radio moves out of range from one site and
into the range of another, it connects to the new site's
repeater to send or receive calls/data transmissions.
Depending on your settings, this is done
automatically or manually.
If the radio is set to do this automatically, it scans
through all available sites when the signal from the
current site is weak or when the radio is unable to
Additional Radio Controls in Non-Connect...
41
English
detect any signal from the current site. It then locks
on to the repeater with the strongest Received Signal
Strength Indicator (RSSI) value.
In a manual site search, the radio searches for the
next site in the roam list that is currently in range (but
which may not have the strongest signal) and locks
on to it.
Note: Each channel can only have either Scan or
Roam enabled, not both at the same time.
Channels with this feature enabled can be added to a
particular roam list. The radio searches the channel(s)
in the roam list during the automatic roam operation
to locate the best site.
A roam list supports a maximum of 16 channels
(including the Selected Channel).
Note: You cannot manually add or delete an entry to
the roam list. Check with your dealer or system
administrator for more information.
Capacity Plus
Capacity Plus is a single-site trunking configuration of
the MOTOTRBO radio system, which uses a pool of
channels to support hundreds of users and up to 254
Groups. This feature allows your radio to efficiently
utilize the available number of programmed channels
while in Repeater Mode.
You hear a negative indicator tone if you try to access
a feature not applicable to Capacity Plus via a
programmable button press.
Your radio also has features that are available in
conventional digital mode, IP Site Connect, Capacity
Plus and Linked Capacity Plus. However, the minor
differences in the way each feature works does NOT
affect the performance of your radio.
Check with your dealer or system administrator for
more information on this configuration.
Linked Capacity Plus
Linked Capacity Plus is a multi-site multi-channel
trunking configuration of the MOTOTRBO radio
system, combining the best of both Capacity Plus and
IP Site Connect configurations.
Linked Capacity Plus allows your radio to extend
trunking communication beyond the reach of a single
site, by connecting to different available sites which
are connected via an Internet Protocol (IP) network. It
also provides an increase in capacity by efficiently
Additional Radio Controls in Non-Connect...
42
English
utilizing the combined available number of
programmed channels supported by each of the
available sites.
When the radio moves out of range from one site and
into the range of another, it connects to the new site's
repeater to send or receive calls/data transmissions.
Depending on your settings, this is done
automatically or manually.
If the radio is set to do this automatically, it scans
through all available sites when the signal from the
current site is weak or when the radio is unable to
detect any signal from the current site. It then locks
on to the repeater with the strongest Received Signal
Strength Indicator (RSSI) value.
In a manual site search, the radio searches for the
next site in the roam list that is currently in range (but
which may not have the strongest signal) and locks
on to it.
Any channel with Linked Capacity Plus enabled can
be added to a particular roam list. The radio searches
these channels during the automatic roam operation
to locate the best site.
Note: You cannot manually add or delete an entry to
the roam list. Check with your dealer or system
administrator for more information.
Similar to Capacity Plus, icons of features not
applicable to Linked Capacity Plus are not available
in the menu. You hear a negative indicator tone if you
try to access a feature not applicable to Linked
Capacity Plus via a programmable button press.
Check with your dealer or system administrator for
more information on this configuration.
Additional Radio Controls in Non-Connect...
43
English
Making and Receiving Calls
Selecting a Site
A site provides coverage for a specific area. A
Connect Plus site has a site controller and a
maximum of 15 repeaters. In a multi-site network, the
Connect Plus radio will automatically search for a new
site when the signal level from the current site drops
to an unacceptable level.
Roam Request
A Roam Request tells the radio to search for a
different site, even if the signal from the current site is
acceptable.
Note: This is programmed by your dealer.
Press the programmed Roam Request button.
You hear a tone, indicating the radio has switched
to a new site. The display shows Site ID <Site
Number>.
Site Restriction
Your Connect Plus radio system administrator has the
ability to decide which network sites your radio is and
is not allowed to use. Your radio does not need to be
reprogrammed to change the list of allowed and
disallowed sites. If your radio attempts to register at a
disallowed site, you see a brief message stating:
Site <number given> Not Allowed. The radio
then searches for a different network site.
Selecting a Zone
A zone is a group of channels. Your radio supports up
to 250 zones, with a maximum of 160 channels per
zone.
1Access the Zone feature.
Radio Controls Steps
Programmed
Zone button
Press the programmed Zone
button.
Radio menu 1 to access the menu.
2 or to Zone and
press to select.
The current zone is displayed and indicated by a
.
Making and Receiving Calls
44
English
2Select the required zone.
Radio
Control
Steps
or or and scroll to the required
zone.
Keypad 1Enter the first character of the
required zone.
2A blinking cursor appears allowing
you to continue entering the
subsequent characters of the
required zone.
Note: Press to move one space to
the left. Press to move one space
to the right. Press the key to
delete any unwanted characters.
Note: The first line of the display
shows the characters you keyed in.
The second line shows a zone that
matches what you have already
keyed in. The alias search is case-
insensitive. If there are two or more
Radio
Control
Steps
zones matches the keyed in
characters, the radio displays the
zone that is listed first in the zone list.
3Press to select.
The display shows <Zone> Selected
momentarily and returns to the selected zone
screen.
Selecting a Channel
Transmissions are sent and received on a channel.
Depending on your radio’s configuration, each
channel may have been programmed differently to
support different groups of users or supplied with
different features. After selecting the relevant Zone,
select the relevant channel you require to transmit or
receive on.
Making and Receiving Calls
45
English
—On the navigation disc, press to access the
Channel List (while on the Home Screen). The
active channel is displayed and indicated by a .
Receiving and Responding to a Radio Call
Once the channel, subscriber ID or group ID is
displayed, you can proceed to receive and respond to
calls.
The LED lights up solid green while the radio is
transmitting and blinks green when the radio is
receiving.
Note: The LED lights up solid green while the radio is
transmitting and blinks green rapidly when the radio is
receiving a privacy-enabled call . To unscramble a
privacy-enabled call, your radio must have the same
Privacy Key, OR the same Key Value and Key ID
(programmed by your dealer), as the transmitting
radio (the radio you are receiving the call from).
Note: See Privacy on page 111 for more information.
Receiving and Responding to a Group Call
To receive a call from a group of users, your radio
must be configured as part of that group.
When you receive a Group Call (while on the Home
screen), the LED blinks green. The first line of the
display shows the caller alias, and the RSSI icon. The
second line displays the group alias and the Group
Call icon (in Digital mode only). Your radio unmutes
and the incoming call sounds through the radio's
speaker.
1Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
— If the Channel Free Indication feature is
enabled, you hear a short alert tone the
moment the transmitting radio releases the
PTT button, indicating the channel is free for
you to respond. Press the PTT button to
respond.
— If the Voice Interrupt feature is enabled, press
the PTT button to stop the current call from the
transmitting radio and free the channel for you
to talk/respond.
The LED lights up solid green.
2Wait for one of the following tones to finish (if
enabled), and speak clearly into the microphone.
— the Talk Permit Tone
Making and Receiving Calls
46
English
— the PTT Sidetone
3Release the PTT button to listen.
If there is no voice activity for a predetermined period
of time, the call ends.
Note: See Making a Group Call on page 50 for
details on making a Group Call.
Note: If the radio receives a Group Call while not on
the Home screen, it remains on its current screen
prior to answering the call.
Note: Long press the button to go to the Home
screen to view the caller alias before replying.
Receiving and Responding to a Private Call
A Private Call is a call from an individual radio to
another individual radio.
When you receive a Private Call, the LED blinks
green. The first line of the display shows the
subscriber alias or ID, and the RSSI icon. The second
line displays Private Call and the Private Call icon.
Your radio unmutes and the incoming call sounds
through the radio's speaker.
1Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
— If the Channel Free Indication feature is
enabled, you hear a short alert tone the
moment the transmitting radio releases the
PTT button, indicating the channel is free for
you to respond. Press the PTT button to
respond.
— If the Voice Interrupt feature is enabled, press
the PTT button to stop the current call from the
transmitting radio and free the channel for you
to talk/respond.
The LED lights up solid green.
2Wait for the Talk Permit Tone to finish (if enabled),
and speak clearly into the microphone.
3Release the PTT button to listen.
If there is no voice activity for a predetermined period
of time, the call ends.
The display shows Call Ended.
See Making a Private Call on page 51 for details on
making a Private Call.
Making and Receiving Calls
47
English
Receiving an All Call
An All Call is a call from an individual radio to every
radio on the channel. It is used to make important
announcements requiring the user’s full attention.
When you receive an All Call, a tone sounds and the
LED blinks green.
The first line of the display shows the caller alias, and
the RSSI icon. The second line displays All Call
and the All Call icon. Your radio unmutes and the
incoming call sounds through the radio speaker.
Once the All Call ends, the radio returns to the
previous screen before receiving the call. An All Call
does not wait for a predetermined period of time
before ending.
If the Channel Free Indication feature is enabled, you
will hear a short alert tone the moment the
transmitting radio releases the PTT button, indicating
the channel is now available for use.
You cannot respond to an All Call.
Note: See Making an All Call on page 52 for details
on making an All Call.
Note: The radio stops receiving the All Call if you
switch to a different channel while receiving the call.
During an All Call, you will not be able to use any
programmed button functions until the call ends.
Receiving and Responding to a Phone Call
Phone Call as Private Call
When you receive a Phone Call as a Private Call, the
Phone Call icon appears in the top right corner; the
display shows the caller alias or Phone Call.
If Phone Call capability is not enabled in your radio,
the first line of the display shows Unavailable and
your radio mutes the call. Your radio returns to the
previous screen when the call ends.
1Press the PTT button to talk and release it to
listen.
2Press to end the call.
The display shows Ending Phone Call.
If successful, a tone sounds and the display shows
All Call and Call Ended.
Making and Receiving Calls
48
English
If unsuccessful, your radio returns to the Phone
Call screen. Repeat Step 2 on page 48 to end the
call.
Phone Call as Group Call
When you receive a Phone Call as a Group Call,
1Press the PTT button to talk and release it to
listen.
2Press to end the call.
The display shows Ending Phone Call.
If successful, a tone sounds and the display shows
All Call and Call Ended.
If unsuccessful, your radio returns to the Phone
Call screen. Repeat Step 2 on page 49 to end the
call.
Phone Call as All Call
When you receive a Phone Call as an All Call, the
Phone Call icon appears in the top right corner; the
display shows All Call and Phone Call.
If Phone Call capability is not enabled in your radio,
the first line of the display shows Unavailable and
your radio mutes the call.
Note: When you receive a Phone Call as an All Call,
you can respond to the call or end the call, only if an
All Call type is assigned to the channel.
1Press the PTT button to talk and release it to
listen.
2Press to end the call.
The display shows Ending Phone Call.
If successful, a tone sounds and the display shows
All Call and Call Ended.
If unsuccessful, your radio returns to the Phone
Call screen. Repeat Step 3 to end the call.
Making a Radio Call
After selecting your channel, you can select a
subscriber alias or ID, or group alias or ID by using:
— The PTT button.
— A programmed One Touch Access button – The
One Touch Access feature allows you to make a
Making and Receiving Calls
49
English
Group or Private Call to a predefined ID easily.
This feature can be assigned to a short or long
programmable button press. You can ONLY have
one ID assigned to a One Touch Access button.
Your radio can have multiple One Touch Access
buttons programmed.
— The programmed number keys – This method is
for Group, Private and All Calls only and is used
with the keypad (see Making a Group, Private or
All Call with the Programmable Number Key on
page 55).
— A programmable button – This method is for
Phone Calls only (see Making a Phone Call with
the Programmable Phone Button on page 56).
— The Contacts list (see Contact Settings on page
70).
— Manual Dial – This method is for Private and
Phone Calls only and is dialed using the keypad
(see Making a Private Call from Contacts on page
72, and ).
Note: Your radio must have the Privacy feature
enabled on the channel to send a privacy-enabled
transmission. Only target radios with the same
Privacy Key OR the same Key Value and Key ID as
your radio will be able to unscramble the
transmission.
Note: See Privacy on page 111 for more information.
Making a Group Call
To make a call to a group of users, your radio must
be configured as part of that group.
1Do one of the following.
— Select the channel with the active group alias
or ID. See Selecting a Channel on page 45
— Press the programmed One Touch Access
button.
2Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
3Press the PTT button to make the call.
The LED lights up solid green. The Group Call
icon appears in the top right corner. The first text
line shows the group call alias.
4Wait for the Talk Permit Tone to finish (if enabled),
and speak clearly into the microphone.
5Release the PTT button to listen.
When the target radio responds, the LED blinks
green, the radio unmutes and the response
sounds through the radio’s speaker. You see the
Making and Receiving Calls
50
English
Group Call icon, the group alias or ID, and
transmitting radio alias or ID on your display.
6If the Channel Free Indication feature is enabled,
you hear a short alert tone the moment the
transmitting radio releases the PTT button,
indicating the channel is free for you to respond.
Press the PTT button to respond.
If there is no voice activity for a predetermined
period of time, the call ends. Radio returns to the
screen you were on prior to initiating the call.
Making a Private Call
While you can receive and/or respond to a Private
Call initiated by an authorized individual radio, your
radio must be programmed for you to initiate a Private
Call.
There are two types of Private Calls. The first type,
where a radio presence check is performed prior to
setting up the call, while the other sets up the call
immediately.
Only one of these call types can be programmed to
your radio by your dealer.
You will hear a negative indicator tone, when you
make a Private Call via the Contacts list, Call Log,
One Touch Access button, the programmed number
keys, or the Channel Selector Knob, if this feature is
not enabled.
Use the Text Message or Call Alert features to
contact an individual radio. See Text Message
Features on page 94 or Call Alert Operation on
page 87 for more information.
1Do one of the following.
— Select the channel with the active subscriber
alias or ID. See Selecting a Channel on page
45
— Press the programmed One Touch Access
button.
2Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
3Press the PTT button to make the call.
If you release the PTT button while the radio is
setting up the call, it exits without any indication
and returns to the previous screen.
The LED lights up solid green, the radio unmutes
and the response sounds through the radio’s
speaker. The Private Call icon appears on the top
Making and Receiving Calls
51
English
right corner. The first text line shows the
subscriber alias. The second text line displays the
call status..
4Wait for the Talk Permit Tone to finish (if enabled),
and speak clearly into the microphone.
5Release the PTT button to listen.
When the target radio responds, the LED blinks
green, the radio unmutes and the response
sounds through the radio's speaker.
6If the Channel Free Indication feature is enabled,
you hear a short alert tone the moment the
transmitting radio releases the PTT button,
indicating the channel is free for you to respond.
Press the PTT button to respond.
If there is no voice activity for a predetermined
period of time, the call ends. You hear a short
tone. The display shows Call Ended.
Your radio may be programmed to perform a radio
presence check prior to setting up the Private Call. If
the target radio is not available, you hear a short tone
and see negative mini notice on the display.
Making an All Call
This feature allows you to transmit to all users on the
channel. Your radio must be programmed to allow
you to use this feature.
Users on the channel cannot respond to an All Call.
1Select the channel with the active All Call group
alias or ID. See Selecting a Channel on page 45
2Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
3Press the PTT button to make the call.
The LED lights up solid green.The Group Call icon
appears in the top right corner. The first text line
shows All Call.
4Wait for the Talk Permit Tone to finish (if enabled),
and speak clearly into the microphone.
Making a Phone Call with the One Touch Access
Button
1Press the programmed One Touch Access
button to make a Phone Call to the predefined
alias or ID.
Making and Receiving Calls
52
English
If the entry for the One Touch Access button is
empty, a negative indicator tone sounds. If the
access code was not preconfigured in the
Contacts list, the display shows Access Code:.
Enter the access code and press to proceed.
The LED lights up solid green. The Phone Call
icon appears in the top right corner. The first text
line shows the subscriber alias. The second text
line displays the call status.
If the call-setup is successful, the DTMF tone
sounds. You hear the dialing tone of the telephone
user. The first text line shows the subscriber alias.
The Phone Call icon remains in the top right
corner.
If the call-setup is unsuccessful, a tone sounds
and the display shows Phone Call Failed. Your
radio returns to the Access Code input screen. If
the access code was preconfigured in the
Contacts list, the radio returns to the screen you
were on prior to initiating the call.
2Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
3Press the PTT button to talk and release it to
listen.
To enter extra digits, if requested by the Phone
Call, enter the extra digits using the keypad and
press to proceed.
The DTMF tone sounds with each keypad press,
and the radio returns to the previous screen.
4Press to end the call.
If de-access code was not preconfigured in the
Contacts list, the display shows De-Access
Code:. Press the One Touch Access button, if it
is programmed with the de-access code. If the
entry for the One Touch Access button is empty,
a negative indicator tone sounds.
The DTMF tone sounds with each keypad press,
and the display shows Ending Phone Call.
If the end-call-setup is successful, a tone sounds
and the display shows Call Ended.
If the end-call-setup is unsuccessful, your radio
returns to the Phone Call screen. Repeat Step 4
on page 53 or wait for the telephone user to end
the call.
Making and Receiving Calls
53
English
Note:
When the telephone user ends the call, a tone
sounds and the display shows Call Ended.
If the call ends while you are entering the extra
digits requested by the Phone Call, your radio
returns to the screen you were on prior to initiating
the call.
During channel access, press to dismiss the
call attempt. A tone sounds to indicate success.
During the call, if you press the One Touch
Access button with the deaccess code
preconfigured or enter the deaccess code as the
input for extra digits, your radio attempts to end
the call.
The access or deaccess code cannot be more
than 10 characters.
Making a Private Call with a One Touch Call Button
Note: Programmable buttons press must be initiated
from the Home screen.
The One Touch Call feature allows you to easily
make a Private Call to a pre-defined Private Call alias
or ID. This feature can be assigned to a short or long
programmable button press.
You can ONLY have one alias or ID assigned to a
One Touch Call button. Your radio can have multiple
One Touch Call buttons programmed.
1Press the programmed One Touch Call button to
make a Private Call to the pre-defined Private Call
alias or ID.
2Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
3Press the PTT button to make the call.
The LED lights up solid green.
The display shows the Private Call alias or ID.
4Wait for the Talk Permit Tone to finish (if enabled)
and speak clearly into the microphone.
5Release the PTT button to listen.
When the target radio responds, the LED blinks
green.
6If the Channel Free Indication feature is enabled,
you will hear a short alert tone the moment the
Making and Receiving Calls
54
English
target radio releases the PTT button, indicating the
channel is free for you to respond. Press the PTT
button to respond.
If there is no voice activity for a predetermined
period of time, the call ends.
Making a Group, Private or All Call with the
Programmable Number Key
The Programmable Number Key feature allows you to
make a Group, Private or All Call to a predefined alias
or ID easily. This feature can be assigned to all the
available number keys on a keypad.
You can ONLY have one alias or ID assigned to a
number key, but you can have more than one number
key associated to an alias or ID.
1Long press the programmed number key, when
you are on the Home screen, to make a Group,
Private or All Call to the predefined alias or ID.
If the number key is not associated to an entry, a
negative indicator tone sounds.
2Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
3Press the PTT button to make the call.
The LED lights up solid green, the radio unmutes
and the response sounds through the radio’s
speaker. The Group/Private Call icon appears in
the top right corner. The first text line shows the
caller alias. The second text line displays either
the call status for a Private Call or All Call for
All Call.
4Wait for the Talk Permit Tone to finish (if enabled),
and speak clearly into the microphone.
5Release the PTT button to listen.
When the target radio responds, the LED blinks
green, the radio unmutes and the response
sounds through the radio's speaker..
6If the Channel Free Indication feature is enabled,
you hear a short alert tone the moment the
transmitting radio releases the PTT button,
indicating the channel is free for you to respond.
Press the PTT button to respond.
If there is no voice activity for a predetermined
period of time, the call ends. Radio returns to the
screen you were on prior to initiating the call.
For a Private Call, you hear a short tone when the
call ends.
Making and Receiving Calls
55
English
See Assigning an Entry to a Programmable
Number Key on page 78 for details on assigning
an entry to a number key on the keypad.
Making a Phone Call with the Programmable Phone
Button
1Press the programmed Phone button to enter into
the Phone Entry list.
2 or to the required subscriber alias or ID,
and press to select.
If the access code was not preconfigured in the
Contacts list, the display shows Access Code:.
Enter the access code and press the button to
proceed.
The LED lights up solid green. The Phone Call
icon appears in the top right corner. The first text
line shows the subscriber alias. The second text
line displays the call status.
If the call-setup is successful, the DTMF tone
sounds. You hear the dialing tone of the telephone
user. The first text line shows the subscriber alias.
The Phone Call icon remains in the top right
corner.
If call-setup is unsuccessful, a tone sounds and
the display shows Phone Call Failed. Your
radio returns to the Access Code input screen. If
the access code was preconfigured in the
Contacts list, the radio returns to the screen you
were on prior to initiating the call.
3Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
4Press the PTT button to talk and release it to
listen.
5To enter extra digits, if requested by the Phone
Call, do one of the following.
— Press any keypad key to begin the input of the
extra digits. The first line of the display shows
Extra Digits:. The second line of the display
shows a blinking cursor. Enter the extra digits
and press the button to proceed. The
DTMF tone sounds and the radio returns to the
previous screen.
Making and Receiving Calls
56
English
— Press One Touch Access button. The DTMF
tone sounds. If the entry for the One Touch
Access button is empty, a negative indicator
tone sounds.
6Press to end the call.
If deaccess code was not preconfigured in the
Contacts list, the first line of the display shows De-
Access Code:. The second line of the display
shows a blinking cursor. Enter the deaccess code
and press the button to proceed. The radio
returns to the previous screen.
The DTMF tone sounds and the display shows
Ending Phone Call.
If the end-call-setup is successful, a tone sounds
and the display shows Call Ended.
If the end-call-setup is unsuccessful, your radio
returns to the Phone Call screen. Repeat Steps 4
on page 56 and 5 on page 56 or wait for the
telephone user to end the call.
When you press PTT button while in the Phone
Contacts screen, a tone sounds and the display
shows Press OK to Place Phone Call.
When the telephone user ends the call, a tone
sounds and the display shows Phone Call
Ended.
If the call ends while you are entering the extra
digits requested by the Phone Call, your radio
returns to the screen you were on prior to initiating
the call.
Note: During channel access, press to
dismiss the call attempt and a tone sounds.
Note: During the call, when you press One Touch
Access button with the deaccess code
preconfigured or enter the deaccess code as the
input for extra digits, your radio attempts to end
the call.
Note: The access or deaccess code cannot be
more than 10 characters.
Stopping a Radio Call
This feature allows you to stop an ongoing Group or
Private Call to free the channel for transmission. For
example, when a radio experiences a “stuck
microphone” condition where the PTT button is
inadvertently pressed by the user.
Making and Receiving Calls
57
English
Your radio must be programmed to allow you to use
this feature.
1Press the programmed Transmit Interrupt
Remote Dekey button, while on the relevant
channel.
2Wait for acknowledgment.
The radio sounds a positive indicator tone and the
display shows Remote Dekey Success, indicating
that the channel is now free. The display shows
Call Interrupted, and the radio sounds a
negative indicator tone until the PTT button is
released, if it is transmitting an interruptible call
that is stopped via this feature.
OR
The radio sounds a negative indicator tone and
the display shows Remote Dekey Failed.
Talkaround
You can continue to communicate when your
repeater is not operating, or when your radio is out of
the repeater’s range but within talking range of other
radios.
This is called “talkaround”.
Note: This feature is not applicable in Capacity Plus
and Linked Capacity Plus.
The Talkaround setting is retained even after
powering down.
You can toggle between talkaround and repeater
modes by pressing the programmed Repeater/
Talkaround button OR using the radio menu as
described next.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Talkaround and press to select.
You can also use or to change the selected
option.
5Press to enable/disable the Talkaround.
Making and Receiving Calls
58
English
The display shows beside Enabled.
The disappears from beside Enabled.
Monitoring Features
Monitoring a Channel
Use the Monitor feature to make sure a channel is
clear before transmitting.
This feature is not applicable in Capacity Plus and
Linked Capacity Plus.
1Press and hold the programmed Monitor button
and listen for activity.
The Monitor icon appears on the display and the
LED lights up solid yellow. You hear radio activity
or total silence, depending on how your radio is
programmed. This indicates that the channel is in
use.
2Press the PTT button to talk and release it to
listen.
Permanent Monitor
Use the Permanent Monitor feature to continuously
monitor a selected channel for activity.
Note: This feature is not applicable in Capacity Plus
and Linked Capacity Plus.
1Press the programmed Permanent Monitor
button to activate permanent monitoring of the
channel.
Radio sounds an alert tone, the LED lights up solid
yellow, and the display shows Permanent
Monitor On. The Monitor icon appears on the
display.
2Press the programmed Permanent Monitor
button to exit Permanent Monitor mode.
Radio sounds an alert tone, the LED turns off, and
display shows Radio sounds an alert tone, the
LED turns off.
Making and Receiving Calls
59
English
Advanced Features in Non-Connect
Plus Mode
Radio Check
If enabled, this feature allows you to determine if
another radio is active in a system without disturbing
the user of that radio. No audible or visual notification
is shown on the target radio.
Sending a Radio Check
1Access the Radio Check feature.
Radio
Control
Steps
Programmed
Radio Check
button
1Press the programmed Radio
Check button.
2 or to the required
subscriber alias or ID and
press to select.
Menu 1 to access the menu
Radio
Control
Steps
2 or to Contacts and
press to select
3Use one of the steps
described next to select the
required subscriber alias or
ID
— select the subscriber alias
or ID directly
— or to the
required subscriber
alias or ID and press
to select.
—use the Manual Dial
menu
— or to Manual
Dial and press to
select.
Advanced Features in Non-Connect...
60
English
Radio
Control
Steps
— or to Radio
Number and press
to select.
— If there was previously
dialed ID, the ID
appears along with a
blinking cursor. Else,
the first line of the
display shows Radio
Number:; the second
line of the display
shows a blinking
cursor. Use the keypad
to edit/enter the ID,
and press to
select.
4 or to Radio Check
and press to select.
The display shows transitional mini notice,
indicating the request is in progress. The LED
lights up solid green.
2Wait for acknowledgement.
If the button is pressed when the radio is
waiting for acknowledgement, a tone sounds, and
the radio terminates all retries and exits Radio
Check mode.
If Radio Check is successful, a positive indicator
tone sounds and the display shows positive mini
notice.
If Radio Check is unsuccessful, a negative
indicator tone sounds and the display shows
negative mini notice.
Radio returns to the subscriber alias or ID screen.
Remote Monitor
Use the Remote Monitor feature to turn on the
microphone of a target radio (subscriber alias or IDs
only). No audible or visual indication is given to the
target radio. You can use this feature to monitor,
Advanced Features in Non-Connect...
61
English
remotely, any audible activity surrounding the target
radio.
Your radio must be programmed to allow you to use
this feature.
Initiating Remote Monitor
1Access the Remote Monitor feature.
Radio
Control
Steps
Program
med
Remote
Monitor
Button
1Press the programmed Remote
Monitor button.
2 or to the required
subscriber alias or ID and press
to select.
Menu 1 to access the menu
2 or to Contacts and
press to select
3Use one of the steps described
next to select the required
subscriber alias or ID
Radio
Control
Steps
— select the subscriber alias or
ID directly
— or to the required
subscriber alias or ID and
press to select.
—use the Manual Dial menu
— or to Manual
Dial and press to
select.
— or to Radio
Number and press to
select.
— If there was previously
dialed ID, the ID appears
along with a blinking
cursor. Else, the first line
of the display shows
Advanced Features in Non-Connect...
62
English
Radio
Control
Steps
Radio Number:; the
second line of the display
shows a blinking cursor.
Key in the subscriber alias
or ID and press to
select.
4 or to Remote Mon. and
press to select.
The display shows transitional mini notice,
indicating the request is in progress. The LED
lights up solid green.
2Wait for acknowledgement.
If successful, a positive indicator tone sounds and
the display shows positive mini notice. Your radio
starts playing audio from the monitored radio for a
programmed duration and display shows Rem.
Monitor. Once the timer expires, the radio sounds
an alert tone and the LED turns off.
If unsuccessful, the radio sounds a negative
indicator tone the display shows negative mini
notice.
Scan Lists
Scan lists are created and assigned to individual
channels/ groups. Your radio cycles through the
programmed scan list for the current channel looking
for voice activity. At each channel in the cycle the
radio also cycles through the group list for that
channel.
Your radio can support up to 250 scan lists, with a
maximum of 16 members in a list.
You can add, delete, or prioritize channels by editing
a scan list.
You can attach a new scan list to your radio via Front
Panel Programming.
Note: This feature is not applicable in Capacity Plus
and Linked Capacity Plus.
Viewing an Entry in the Scan List
1 to access the menu.
Advanced Features in Non-Connect...
63
English
2 or to Scan and press to select.
3 or to View/Edit List and press to
select.
4Use or to view each member on the list.
The Priority icon appears left of the member’s
alias, if set, to indicate whether the member is on
a Priority 1 or Priority 2 channel list. You cannot
have multiple Priority 1 or Priority 2 channels in a
scan list.
There is no Priority icon if priority is set to None.
Viewing an Entry in the Scan List by Alias Search
1 to access the menu.
2 or to Scan and press to select.
3 or to View/Edit List and press to
select.
4Key in the first character of the required alias.
A blinking cursor appears.
5Use the keypad to type the required alias.
Press to move one space to the left. Press to
move one space to the right. Press the key
to delete any unwanted characters.
The first line of the display shows the characters
you keyed in. The second line of the display
shows an alias that matches what you have keyed
in.
The alias search is case-insensitive. If there are
two or more entries with the same name, the radio
displays the entry that is listed first in the scan list.
Editing the Scan List
Adding a New Entry to the Scan List
1 to access the menu.
2 or to Scan and press to select.
Advanced Features in Non-Connect...
64
English
3 or to View/Edit List and press to
select.
4 or to Add Member and press to select.
5Select the required alias or ID by
Radio
Control
Steps
Radio
Navigation
Buttons
or to the required alias or
ID.
Keypad Key in the first character of the
required alias.
A blinking cursor appears.
Press to move one space to the
left. Press to move one space to
the right. Press the key to
delete any unwanted characters.
Long press to change the
text entry method.
Radio
Control
Steps
The first line of the display shows
the characters you keyed in. The
next lines of the display show the
short listed search results. The
alias search is case-insensitive. If
there are two or more aliases with
the same name, the radio displays
the alias that is listed first in the
list.
6Press to select.
7 or to the required priority level and press
to select.
The display shows Entry Saved, followed
immediately by Add Another?.
8Do one of the following:
— or to Yes and press to select, and
repeat Steps 5 on page 65 to 7 on page 65.
Advanced Features in Non-Connect...
65
English
— or to No and press to save the
current list.
Deleting an Entry from the Scan List
1 to access the menu.
2 or to Scan and press to select.
3 or to View/Edit List and press to
select.
4Select the required alias or ID by
Radio
Control
Steps
Radio
Navigation
Buttons
or to the required alias or
ID.
Keypad Key in the first character of the
required alias.
A blinking cursor appears.
Radio
Control
Steps
Press to move one space to the
left. Press to move one space to
the right. Press the key to
delete any unwanted characters.
Long press to change the
text entry method.
The first line of the display shows
the characters you keyed in. The
next lines of the display show the
short listed search results. The
alias search is case-insensitive. If
there are two or more aliases with
the same name, the radio displays
the alias that is listed first in the
list.
5Press to select.
6 or to Delete and press to select.
Advanced Features in Non-Connect...
66
English
7Do one of the following:
—At Delete Entry?, or to Yes and press
to delete entry. The display shows Entry
Deleted.
— or to No and press to return to the
previous screen.
8Repeat Steps 4 on page 66 to 7 on page 67 to
delete other entries.
After deleting all required aliases or IDs, long
press to return to the Home screen.
Setting and Editing Priority for an Entry in the
Scan List
1 to access the menu.
2 or to Scan and press to select.
3 or to View/Edit List and press to
select.
4Select the required alias or ID by
Radio
Control
Steps
Radio
Navigation
Buttons
or to the required alias or
ID.
Keypad Key in the first character of the
required alias.
A blinking cursor appears.
Press to move one space to the
left. Press to move one space to
the right. Press the key to
delete any unwanted characters.
Long press to change the
text entry method.
The first line of the display shows
the characters you keyed in. The
next lines of the display show the
short listed search results. The
alias search is case-insensitive. If
there are two or more aliases with
Advanced Features in Non-Connect...
67
English
Radio
Control
Steps
the same name, the radio displays
the alias that is listed first in the
list.
5Press to select.
6 or to Edit Priority and press to
select.
7 or to the required priority level and press
to select.
The display shows Entry Saved before returning
to the previous screen.
Note:
The Priority icon appears left of the member’s
name.
There is no Priority icon if priority is set to None.
Scan
When you start a scan, your radio cycles through the
programmed scan list for the current channel looking
for voice activity.
The LED blinks yellow and you see the Scan icon on
the display.
There are two ways of initiating scan:
—Main Channel Scan (Manual): Your radio scans
all the channels/groups in your scan list. On
entering scan, your radio may – depending on the
settings – automatically start on the last scanned
“active” channel/group or on the channel where
scan was initiated.
—Auto Scan (Automatic): Your radio automatically
starts scanning when you select a channel/group
that has Auto Scan enabled.
Note: This feature is not applicable in Capacity Plus
and Linked Capacity Plus.
Setting an Active Scan List
1 to access the menu.
Advanced Features in Non-Connect...
68
English
2 or to Scan and press to select.
3 or to Set Active List and press to
select.
4 or to the required list and press to
select.
The list selected will be your active scan list.
Starting and Stopping Scan
While scanning, the radio will only accept data (e.g.
text message, location, telemetry, or PC data) if
received on its Selected Channel.
You can start and stop scanning by pressing the
programmed Scan button OR follow the procedure
described next.
1Use the Channel Selector Knob to select a
channel programmed with a scan list.
2 to access the menu.
3 or to Scan and press to select.
—The display shows Turn On if scan is disabled.
—The display shows Turn Off if scan is
enabled.
4Press to select.
— The LED blinks yellow and the Scan icon is
displayed, when Scan is enabled.
— The LED turns off and the Scan icon is not
displayed, when Scan is disabled.
Responding to a Transmission During a Scan
During scanning, your radio stops on a channel/group
where activity is detected. Your radio unmutes and
the incoming call sounds through the radio's
speaker.The radio stays on that channel while the
activity is present and for a programmed time period
known as “hang time”.
1Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
If the Channel Free Indication feature is enabled,
you hear a short alert tone the moment the
transmitting radio releases the PTT button,
indicating the channel is free for you to respond.
Advanced Features in Non-Connect...
69
English
2Press the PTT button during hang time.
The LED lights up solid green.
3Wait for the Talk Permit Tone to finish (if enabled)
and speak clearly into the microphone.
4Release the PTT button to listen.
If you do not respond within the hang time, the
radio returns to scanning other channels/groups.
Deleting a Nuisance Channel
If a channel continually generates unwanted calls or
noise (termed a “nuisance” channel), you can
temporarily remove the unwanted channel from the
scan list.
This capability does not apply to the channel
designated as the Selected Channel.
Deleting a “nuisance” channel is only possible
through the programmed Nuisance Channel Delete
button. This feature is not accessible through the
menu.
1When your radio “locks on to” an unwanted or
nuisance channel, press the programmed
Nuisance Channel Delete button until you hear a
tone.
2Release the Nuisance Channel Delete button.
The nuisance channel is deleted.
Restoring a Nuisance Channel
To restore the deleted nuisance channel, do one of
the following:
— Turn the radio off and then power it on again.
— Stop and restart a scan via the programmed Scan
button or menu.
— Change channel or zone.
Contact Settings
Contacts provides “address-book” capabilities on your
radio. Each entry corresponds to an alias or ID that
you use to initiate a call.
Each entry, depending on context, associates with
one of five types of calls: Group Call, Private Call, All
Call, PC Call or Dispatch Call.
PC Call and Dispatch Call are data-related. They are
only available with the applications. Refer to the data
applications documentation for more information.
Advanced Features in Non-Connect...
70
English
Note:
If the Privacy feature is enabled on a channel, you
can make privacy-enabled Group Call, Private Call,
and All Call on that channel. Only target radios with
the same Privacy Key OR the same Key Value and
Key ID as your radio will be able to unscramble the
transmission.
See Privacy on page 111 for more information.
Additionally, Contacts menu allows you to assign
each entry to a programmable number key or more
on a keypad. If an entry is assigned to a number key,
your radio can perform a quick dial on the entry.
Your radio supports maximum of 1000 Contact list
entries.
Each entry within Contacts displays the following
information:
— Call Type
— Call Alias
— Call ID
Note:
You can add or edit subscriber IDs for the Digital
Contacts list.
Making a Group Call from Contacts
1 to access the menu.
2 or to Contacts and press to select.
The entries are alphabetically sorted.
3 or to the required group alias or ID.
4Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
5Press the PTT button to make the call.
The LED lights up solid green. The first line
displays the subscriber alias or ID. The second
line displays Private Call and the Private Call
icon
6Wait for the Talk Permit Tone to finish (if enabled),
and speak clearly into the microphone.
7Release the PTT button to listen.
When any user in the group responds, the LED
blinks green, the display shows the transmitting
user's ID, the radio unmutes and the response
sounds through the radio's speaker.
Advanced Features in Non-Connect...
71
English
8If the Channel Free Indication feature is enabled,
you hear a short alert tone the moment the
transmitting radio releases the PTT button,
indicating the channel is free for you to respond.
Press the PTT button to respond.
If there is no voice activity for a predetermined
period of time, the call ends.
9You hear a short tone. The display shows Call
Ended.
Making a Private Call from Contacts
1 to access the menu.
2 or to Contacts and press to select.
The entries are alphabetically sorted.
3Use one of the steps described next to select the
required subscriber alias or ID:
— select the subscriber alias or ID directly
— or to the required subscriber alias or
ID and press to select.
—use the Manual Dial menu
— or to Manual Dial and press to
select.
— or to Radio Number and press
to select.
— If there was previously dialed ID, the ID
appears along with a blinking cursor. Else,
the first line of the display shows Radio
Number:; the second line of the display
shows a blinking cursor. Use the keypad to
edit/enter the ID. Press to select.
4Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
5Press the PTT button to make the call.
The LED lights up solid green. The first line
displays the subscriber alias or ID. The second
line displays Private Call and the Private Call
icon.
6Wait for the Talk Permit Tone to finish (if enabled),
and speak clearly into the microphone.
Advanced Features in Non-Connect...
72
English
7Release the PTT button to listen.
When the target radio responds, the LED blinks
green and the display shows the transmitting
user's ID. the radio unmutes and the response
sounds through the radio's speaker.
8If the Channel Free Indication feature is enabled,
you hear a short alert tone the moment the
transmitting radio releases the PTT button,
indicating the channel is free for you to respond.
Press the PTT button to respond.
If there is no voice activity for a predetermined
period of time, the call ends.
The display shows Call Ended.
Making a Phone Call from Contacts
1 to access the menu.
2 or to Contacts and press to select.
The entries are alphabetically sorted.
3Use one of the steps described next to select the
required subscriber alias or ID:
— select the subscriber alias or ID directly
— or to the required subscriber alias or
ID and press to select.
—use the Manual Dial menu
— or to Manual Dial and press to
select.
— or to Phone Number and press
to select.
—The first line of the display shows Phone
Number: , the second line of the display
shows a blinking cursor. Use the keypad to
enter a telephone number, and press to
select the entered number.
If the entry selected is empty, a negative indicator
tone sounds and the display shows Phone Call
Invalid # .
When you press PTT button while in the Phone
Contacts screen, a negative indicator tone sounds
and the display shows Press OK to Place
Phone Call.
Advanced Features in Non-Connect...
73
English
4 or to Call Phone and press to select.
5If the access code was not preconfigured in the
Contacts list, the first line of the display shows
Access Code: . The second line of the display
shows a blinking cursor. Enter the access code
and press to proceed.
During channel access, press to dismiss the
call attempt and a negative indicator tone sounds.
Your radio returns to the Call Phone screen.
The access code cannot be more than 10
characters.
The first line of the display shows Calling. The
second line of the display shows the subscriber
alias or ID, and the Phone Call icon.
If successful, the DTMF tone sounds. You hear
the dialing tone of the telephone user. The first line
of the display shows the subscriber alias or ID,
and the RSSI icon. The second line of the display
shows Phone Call and the Phone Call icon.
If unsuccessful, a tone sounds and the display
shows Phone Call Failed. Your radio returns to
the Access Code input screen. If the access code
was preconfigured in the Contacts list, the radio
returns to the screen you were on prior to initiating
the call.
6Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
7Do one of the following:
— Press the PTT button to talk and release it to
listen.
Note:
The RSSI icon disappears during transmission.
To enter extra digits, if requested by the Phone
Call, press any keypad key to begin the input of
extra digits. The first line of the display shows
Extra Digits: . The second line of the
display shows a blinking cursor. Enter the extra
digits and press to proceed. The DTMF
tone sounds and the radio returns to the
previous screen.
If the call ends while you are entering the extra
digits requested by the Phone Call, your radio
Advanced Features in Non-Connect...
74
English
returns to the screen you were on prior to
initiating the call.
— Press One Touch Access button.
Note:
The DTMF tone sounds.
If the entry for the One Touch Access button
is empty, a negative indicator tone sounds.
During the call, when you press One Touch
Access button with the deaccess code
preconfigured or enter the deaccess code as the
input for extra digits, your radio attempts to end
the call.
During channel access and access/deaccess code
or extra digits transmission, your radio responds to
On/ Off/Volume Control Knob and Channel
Selector Knob only. A tone sounds for every
invalid input.
8Press to end the call.
9If deaccess code was not preconfigured in the
Contacts list, the first line of the display shows De-
Access Code:. The second line of the display
shows a blinking cursor. Enter the deaccess code
and press to proceed.
The deaccess code cannot be more than 10
characters.
The DTMF tone sounds and the display shows
Ending Phone Call.
If successful, a tone sounds and the display shows
Phone Call Ended. Your radio returns to the Call
Phone screen.
If unsuccessful, your radio returns to the Phone
Call screen. Repeat Steps 8 on page 75 and 9 on
page 75 or wait for the telephone user to end the
call.
When the telephone user ends the call, a tone
sounds and the display shows Phone Call
Ended.
Making a Call Alias Search
You can also use alias or alphanumeric search to
retrieve the required subscriber alias.
This feature is only applicable while in Contacts.
Note:
Advanced Features in Non-Connect...
75
English
Press button or to exit alias search.
If you release the PTT button while the radio is setting
up the call, it exits without any indication and returns
to the previous screen.
Your radio may be programmed to perform a radio
presence check prior to setting up the Private Call. If
the target radio is not available, you hear a short tone
and see negative mini notice on the display.
1 to access the menu.
2 or to Contacts and press to select.
The entries are alphabetically sorted.
3Key in the first character of the required alias.
A blinking cursor appears.
4Use the keypad to type the required alias.
Press to move one space to the left. Press to
move one space to the right. Press the key
to delete any unwanted characters. Long press
to change text entry method.
The first line of the display shows the characters
you keyed in. The next lines of the display show
the short listed search results. The alias search is
case-insensitive. If there are two or more entries
with the same name, the radio displays the entry
that is listed first in the Contacts list.
5Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
6Press the PTT button to make the call.
The LED lights up solid green. The display shows
the destination alias.
7Wait for the Talk Permit Tone to finish (if enabled),
and speak clearly into the microphone.
8Release the PTT button to listen.
When the target radio responds, the LED blinks
green, the radio unmutes and the response
sounds through the radio’s speaker.
9If the Channel Free Indication feature is enabled,
you hear a short alert tone the moment the
transmitting radio releases the PTT button,
indicating the channel is free for you to respond.
Press the PTT button to respond.
Advanced Features in Non-Connect...
76
English
If there is no voice activity for a predetermined
period of time, the call ends.
The display shows Call Ended.
Making a Group, Private, Phone or All Call by Alias
Search
You can also use alias or alphanumeric search to
retrieve the required subscriber alias.
This feature is only applicable while in Contacts.
Note:
Press button or to exit alias search.
If you release the PTT button while the radio is setting
up the call, it exits without any indication and returns
to the previous screen.
Your radio may be programmed to perform a radio
presence check prior to setting up the Private Call. If
the target radio is not available, you hear a short tone
and see Party Not Available on the display; the
radio returns to the menu prior to initiating the radio
presence check.
1 to access the menu.
2 or to Contacts and press to select.
The entries are alphabetically sorted.
3Key in the first character of the required alias.
A blinking cursor appears.
4Use the keypad to type the required alias.
Press to move one space to the left. Press to
move one space to the right. Press the key
to delete any unwanted characters.
The first line of the display shows the characters
you keyed in. The second line of the display
shows an alias that matches what you have keyed
in. The alias search is case-insensitive. If there are
two or more entries with the same name, the radio
displays the entry that is listed first in the Contacts
list.
5 or to scroll to desired entry, if necessary.
6Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
7Press the PTT button to make the call.
Advanced Features in Non-Connect...
77
English
The LED lights up solid green. The first line
displays the target radio’s ID. The second line
displays the call type and the Call icon.
8Wait for the Talk Permit Tone to finish (if enabled)
and speak clearly into the microphone.
9Release the PTT button to listen.
When the target radio responds, the LED blinks
green.
10 If the Channel Free Indication feature is enabled,
you will hear a short alert tone the moment the
target radio releases the PTT button, indicating the
channel is free for you to respond. Press the PTT
button to respond.
If there is no voice activity for a programmed
period of time, the call ends.
You hear a short tone. The display shows Call
Ended.
Assigning an Entry to a Programmable Number Key
Note: See Making a Group, Private or All Call with
the Programmable Number Key on page 55 for
details on making a Group, Private or All Call with the
programmed number key(s).
1 to access the menu.
2 or to Contacts and press to select.
The entries are alphabetically sorted.
3 or to the required alias or ID and press
to select.
4 or to Program Key and press to
select.
5 or to the desired number key and press
to select.
If the number key is currently assigned to another
entry, the display shows The Key is Already
Assigned and then, the first line of the display
shows Overwrite?. Do one of the following.
— or to Yes and press to overwrite
the number key assignment.
— or to No and press to return to the
previous step.
Advanced Features in Non-Connect...
78
English
Each entry can be associated to different number
keys. You see a before each number key that is
assigned to an entry. If the is before Empty, that
number key is not assigned.
If a number key is assigned to an entry in a
particular mode, this feature is not supported when
you long press the number key in another mode.
The radio sounds a positive indicator tone and the
display shows Contact Saved.
The screen automatically returns to the previous
menu.
Removing the Association between Entry and
Programmable Number Key
1Access the required alias or ID via:
Radio Control Steps
Programmed
number key
Long press the programmed
number key to the required
alias or ID; press to select.
Menu 1 to access the menu
Radio Control Steps
2 or to Contacts and
press to select. The
entries are alphabetically
sorted.
3 or to the required
subscriber alias or ID and
press to select.
2 or to Program Key and press to
select.
3 or to Empty and press to select.
The first line of the display shows Clear from
all keys? .
4 or to Yes and press to select.
Note: When an entry is deleted, the association
between the entry and its programmed number
key(s) is removed.
Advanced Features in Non-Connect...
79
English
The radio sounds a positive indicator tone and the
display shows Contact Saved.
The screen automatically returns to the previous
menu.
Adding a New Contact
1 to access the menu.
2 or to Contacts and press to select.
3 or to New Contact and press to
select.
4 or to the required contact type, either
Radio Contact or Phone Contact, and press
to select.
5Use the keypad to enter the contact number and
press to confirm.
6Use the keypad to enter the contact name and
press to confirm.
7If adding a Radio Contact, or to the
required ringer type and press to select.
The radio sounds a positive indicator tone and the
display shows positive mini notice.
Sending a Message to a Contact
1 to access the menu.
2 or to Contacts and press to select.
3 or to New Contact and press to
select.
4 or to the required contact type, either
Radio Contact or Phone Contact, and press
to select.
5 or to the required alias and press to
select.
Advanced Features in Non-Connect...
80
English
6 or to Send Message and press to
select.
7Press to send the message.
Call Indicator Settings
Activating and Deactivating Call Ringers for Call Alert
You can select, or turn on or off ringing tones for a
received Call Alert.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Tones/Alert and press to
select.
5 or to Call Ringers and press to
select.
6 or to Call Alert and press to select.
The current tone is indicated by a .
7 or to the required tone and press to
select.
You can also use or to change the selected
option.
appears beside selected tone.
Activating and Deactivating Call Ringers for Private
Calls
You can turn on or off the ringing tones for a received
Private Call.
1 to access the menu.
2 or to Utilities and press to select.
Advanced Features in Non-Connect...
81
English
3 or to Radio Settings and press to
select.
4 or to Tones/Alerts and press to
select.
5 or to Call Ringers and press to
select.
6 or to Private Call and press to
select.
You can also use or to change the selected
option.
7Press to enable/disable the Private Call
ringing tones.
The display shows beside Enabled, if Private
Call ringing tones are enabled.
The disappears from beside Enabled, if Private
Call ringing tones are disabled.
Activating and Deactivating Call Ringers for Text
Message
You can turn on or off the ringing tones for a received
Text Message.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Tones/Alerts and press to
select.
5 or to Call Ringers and press to
select.
6 or to Text Message and press to
select.
The current tone is indicated by a .
Advanced Features in Non-Connect...
82
English
7 or to the required tone and press to
select.
appears beside selected tone.
Activating and Deactivating Call Ringers for Telemetry
Status with Text
You can turn on or off the ringing tones for a received
Telemetry Status with Text.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Tones/Alerts and press to
select.
5 or to Call Ringers and press to
select.
6 or to Telemetry and press to select.
The current tone is indicated by a .
7Do one of the following:
— or to the preferred tone and press
to select. The display shows Tone <Number>
Selected and a appears left of the selected
tone.
— or to Turn Off and press to
select. The display shows Telemetry Ringer
Off and a appears left of Turn Off.
Assigning Ring Styles
You can program your radio to sound one of ten
predefined ringing tones when receiving a Call Alert
or a Text Message from a particular contact.
The radio sounds out each ring style as you navigate
through the list.
1 to access the menu.
2 or to Contacts and press to select.
The entries are alphabetically sorted.
Advanced Features in Non-Connect...
83
English
3 or to the required alias or ID and press
to select.
4 or to View/Edit and press to select.
5 or to Ringer and press to select.
6 or to required ring style and press to
select.
A indicates the current selected tone.
7 or to the required tone and press to
select. appears beside selected tone.
The display shows Contact Saved.
All Tones
1 to access the menu.
2 or to Utilities and press to select.
3Go to Radio Settings. SelectTones/Alerts.
Select All Tones. Toggle All Tones to be
enabled or disabled.
Ring Alert Type Selection
You can program your the radio calls to one
predeternined vibrate call. If All Tones status is
disabled, the radio displays the All Tone Mute icon.
If All Tones status is enabled, the related ring alert
type is displayed.
The radio sounds one vibration if it is a momentary
ring style. The radio will vibrate repetitively if it is a
repetitive ring style. When set to Ring & Vibrate, the
radio sounds a specific ring tone if there is any
incoming radio transaction (i.e. Call Alert, Message or
Job Ticket). It sounds like a good key tone or missed
call. If the notification list is not empty, the radio
repeats a vibration every 5 minutes.
1 to access the menu.
2 or to Utilities and press to select.
Advanced Features in Non-Connect...
84
English
3Go to Radio Settings. Select Tones/Alerts.
Select Ring Alert Type.
4Choose from one of the following:
—Ring
—Vibrate
—Vibrate & Ring
—Silent
Escalating Alarm Tone Volume
You can program your radio to continually alert you
when a radio call remains unanswered. This is done
by automatically increasing the alarm tone volume
over time. This feature is known as Escalert.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Tones/Alerts and press to
select.
5 or to Escalert and press to select.
You can also use or to change the selected
option.
6Press to enable/disable the Escalert.
The display shows beside Enabled.
The disappears from beside Enabled.
Call Log Features
Your radio keeps track of all recent outgoing,
answered, and missed Private Calls. Use the call log
feature to view and manage recent calls.
You can perform the following tasks in each of your
call lists:
— Store ID to Contacts
— Delete
— View Details
Advanced Features in Non-Connect...
85
English
Viewing Recent Calls
The lists are Missed, Answered, and Outgoing.
1 to access the menu.
2 or to Call Log and press to select.
3 or to preferred list and press to select.
The display shows the most recent entry at the top
of the list.
4 or to view the list.
Press the PTT button to start a Private Call with
the current selected alias or ID.
Missed Call Screen
Whenever a call is missed, your radio displays a
missed call message in the notification list. The
display shows Missed Calls.
Do one of the following:
—Press to view the missed call ID. The
missed call log list appears on display.
—Press to store or delete the entry.
Storing an Alias from a Call List
You can also store an ID without an alias.
1 to access the menu.
2 or to Call Log and press to select.
3 or to the required list and press to
select.
4 or to Store and press to select.
A blinking cursor appears. If needed, key in the
alias for that ID and press . The display shows
positive mini notice.
Deleting a Call from a Call List
1 to access the menu.
2 or to Call Log and press to select.
Advanced Features in Non-Connect...
86
English
3 or to the required list and press to
select.
When you select a call list and it contains no
entries, the display shows List Empty, and
sounds a low tone if Keypad Tones are turned on
(see Turning Keypad Tones On or Off on page
129).
4 or to the required alias or ID and press
to select.
5 or to Delete Entry? and press to
select.
6Do one of the following:
—Press to select Yes to delete the entry. The
display shows Entry Deleted.
— or to No, and press the button to
return to the previous screen.
Viewing Details from a Call List
1 to access the menu.
2 or to Call Log and press to select.
3 or to the required list and press to
select.
4 or to the required alias or ID and press
to select.
5 or to View Details and press to
select.
Display shows details.
Call Alert Operation
Call Alert paging enables you to alert a specific radio
user to call you back when they are able to do so.
This feature is applicable for subscriber aliases or IDs
only and is accessible through the menu via Contacts
or manual dial.
Advanced Features in Non-Connect...
87
English
Receiving and Responding to a Call Alert
When you receive a Call Alert page, you see the
notification list listing a Call Alert with the alias or ID of
the calling radio on the display.
When you hear a repetitive tone and the LED
blinks yellow, do one of the following:
— Press the PTT button while the display still
shows the Call Alert in the Notification List to
respond with a Private Call.
—Press to exit the Notification List. The
alert is moved to the Missed Call Log.
See Notification List on page 127 for details
about the Notification List.
See Call Log Features on page 85 for details
about the Missed Call List.
Making a Call Alert from the Contact List
1 to access the menu.
2 or to Contacts and press to select.
3Use one of the steps described next to select the
required subscriber alias or ID:
— select the subscriber alias or ID directly
— or to the required subscriber alias or
ID and press to select.
—use the Manual Dial menu
— or to Manual Dial and press to
select.
— or to Radio Contact and press
to select.
—The first line of the display shows Radio
Number: , the second line of the display
shows a blinking cursor. Enter the
subscriber ID you want to page and press
.
4 or to Call Alert and press to select.
The display shows Call Alert and the
subscriber alias or ID, indicating that the Call Alert
has been sent.
Advanced Features in Non-Connect...
88
English
The LED lights up solid green when your radio is
sending the Call Alert.
If the Call Alert acknowledgement is received, the
display shows positive mini notice.
If the Call Alert acknowledgement is not received,
the display shows negative mini notice.
Making a Call Alert with the One Touch Access Button
— Press the programmed One Touch Access
button to make a Call Alert to the predefined alias
or ID.
The display shows Call Alert and the
subscriber alias or ID, indicating that the Call Alert
has been sent.
The LED lights up solid green when your radio is
sending the Call Alert.
If the Call Alert acknowledgement is received, the
display shows positive mini notice.
If the Call Alert acknowledgement is not received,
the display shows negative mini notice.
Emergency Operation
An Emergency Alarm is used to indicate a critical
situation. You are able to initiate an Emergency at
any time on any screen display even when there is
activity on the current channel.
Your dealer can set the duration of a button press for
the programmed Emergency button, except for long
press, which is similar with all other buttons:
The Emergency button is assigned with the
Emergency On/Off feature. Check with your dealer for
the assigned operation of the Emergency button.
Note:
If the short press for the Emergency button is
assigned to turn on the Emergency mode, then the
long press for the Emergency button is assigned to
exit the Emergency mode.
If the long press for the Emergency button is
assigned to turn on the Emergency mode, then the
short press for the Emergency button is assigned to
exit the Emergency mode.
Your radio supports three Emergency Alarms:
— Emergency Alarm
Advanced Features in Non-Connect...
89
English
— Emergency Alarm with Call
— Emergency Alarm with Voice to Follow
Note: Only ONE of the Emergency Alarms above can
be assigned to the programmed Emergency button.
In addition, each alarm has the following types:
—Regular – Radio transmits an alarm signal and
shows audio and/or visual indicators.
—Silent – Radio transmits an alarm signal without
any audio or visual indicators. Radio receives calls
without any sound through the radio’s speaker,
until you press the PTT button to initiate the call.
—Silent with Voice – Radio transmits an alarm
signal without any audio or visual indicators, but
allow incoming calls to sound through the radio’s
speaker.
Receiving an Emergency Alarm
On receiving an emergency alarm the emergency
icon appears, a tone sounds, the LED blinks red and
the radio displays the emergency caller alias. If more
than one alarm has occurred all emergency caller
aliases are displayed in an Alarm List.
1When receiving an emergency alarm, do one of
the following:
— If a single emergency call alias is displayed,
press to view more details. press again
to view your action details.
— If the multiple emergency caller aliases are
displayed in the Alarm List, or to the
required alias and press to view more
details. Press again to view your action
items.
2Press and select Yes to exit the Alarm List.
To revisit the Alarm List, press to access the
menu and select Alarm List.
Responding to an Emergency Alarm
1In the Alarm List, or to the required alias.
2Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
If the Channel Free Indication feature is enabled,
you will hear a short alert tone the moment the
Advanced Features in Non-Connect...
90
English
transmitting radio releases the PTT button,
indicating the channel is now available for use.
3Press PTT button to transmit non-emergency
voice to the same group that the Emergency
Alarm was targeted to.
Emergency voice can only be transmitted by the
emergency initiating radio. All other radios
(including the emergency receiving radio) transmit
non-emergency voice.
The LED lights up solid green. Your radio remains
in the Emergency mode.
4Wait for the Talk Permit Tone to finish (if enabled)
and speak clearly into the microphone.
5Release the PTT button to listen.
When the emergency initiating radio responds, the
LED blinks green, the LED blinks green, the radio
unmutes and the response sounds through the
radio's speaker.You see the Group Call icon, the
group ID, and transmitting radio ID on your
display.
6Your radio displays the Alarm List.
Sending an Emergency Alarm
This feature allows you to send an Emergency Alarm,
a non-voice signal, which triggers an alert indication
on a group of radios.
If your radio is set to Silent, it will not display any
audio or visual indicators during Emergency mode.
Press the programmed Emergency On button.
The display shows Tx Alarm and the destination
alias. The LED lights up solid green and the
Emergency icon appears on the Home screen
display.
When an Emergency Alarm acknowledgement is
received, the Emergency tone sounds and the
LED blinks green. The display shows Alarm Sent.
If your radio does not receive an Emergency
Alarm acknowledgement, and after all retries have
been exhausted, a tone sounds and the display
shows Alarm Failed.
Radio exits the Emergency Alarm mode and
returns to the Home screen.
Advanced Features in Non-Connect...
91
English
Sending an Emergency Alarm with Call
This feature allows you to send an Emergency Alarm
to a group of radios. Upon acknowledgement by a
radio within the group, the group of radios can
communicate over a programmed Emergency
channel.
If your radio is set to Silent, it will not display any
audio or visual indicators during Emergency mode, or
allow any received calls to sound through the radio’s
speaker, until you press the PTT button to initiate the
call.
If your radio is set to Silent with Voice, it will not
display any audio or visual indicators during
Emergency mode, but allow incoming calls to sound
through the radio’s speaker. The indicators will only
appear once you press the PTT button to initiate, or
respond to, the call.
1Press the programmed Emergency On button.
The display shows Tx Alarm and the destination
alias. The LED lights up solid green and the
Emergency icon appears on the Home screen
display.
When an Emergency Alarm acknowledgment is
received, the Emergency tone sounds and the
LED blinks green. The display shows Alarm Sent.
2Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
3Press PTT button to make the call.
The LED lights up solid green and the Group icon
appears on the display.
4Wait for the Talk Permit Tone to finish (if enabled)
and speak clearly into the microphone.
5Release the PTT button to listen.
If the Channel Free Indication feature is enabled,
you hear a short alert tone the moment the
transmitting radio releases the PTT button,
indicating the channel is free for you to respond.
6Press the PTT button to respond.
7Once your call ends, press Emergency Off button
to exit the Emergency mode.
The radio returns to the Home screen.
Advanced Features in Non-Connect...
92
English
Sending an Emergency Alarm with Voice to Follow
This feature allows you to send an Emergency Alarm
to a group of radios. Your radio’s microphone is
automatically activated, allowing you to communicate
with the group of radios without pressing the PTT
button.
This activated microphone state is also known as “hot
mic”.
If your radio has Emergency Cycle Mode enabled,
repetitions of hot mic and receiving period are made
for a programmed duration.
Note: During Emergency Cycle Mode, received calls
sound through the radio’s speaker.
If you press the PTT button during the programmed
programmed receiving period, you will hear a prohibit
tone, indicating that you should release the PTT
button. The radio ignores the PTT press and remains
in Emergency mode.
Note: If you press the PTT button during hot mic, and
continue to press it after the hot mic duration expires,
the radio continues to transmit until you release the
PTT button.
If your radio is set to Silent, it will not display any
audio or visual indicators during Emergency mode, or
allow any received calls to sound through the radio’s
speaker, until the programmed hot mic transmission
period is over, and you press the PTT button.
If your radio is set to Silent with Voice, it will not
display any audio or visual indicators during
Emergency mode when you are making the call with
hot mic, but allow sound through the radio’s speaker
when the target radio responds after the programmed
hot mic transmission period is over. The indicators will
only appear when you press the PTT button.
Note: If the Emergency Alarm request fails, the radio
does not retry to send the request, and enters the hot
mic state directly.
1Press the programmed Emergency On button.
The display shows Tx Alarm and the destination
alias. The LED lights up solid green and the
Emergency icon is displayed.
2Once the display shows Alarm Sent, speak
clearly into the microphone.
When hot mic has been enabled, the radio
automatically transmits without a PTT press until
the hot mic duration expires. While transmitting,
Advanced Features in Non-Connect...
93
English
the LED lights up solid green and the Emergency
icon appears on the display.
3The radio automatically stops transmitting when
the cycling duration between hot mic and receiving
calls expires, if Emergency Cycle Mode is
enabled.
4Once the hot mic duration expires, the radio
automatically stops transmitting. To transmit
again, press the PTT button.
Reinitiating an Emergency Mode
Note: This feature is only applicable to the radio
sending the Emergency Alarm.
There are two instances where this can happen:
— You change the channel while the radio is in
Emergency mode. This exits the Emergency
mode. If Emergency Alarm is enabled on this new
channel, the radio reinitiates Emergency.
— You press the programmed Emergency On
button during an Emergency initiation/transmission
state. This causes the radio to exit this state, and
to reinitiate Emergency.
Exiting Emergency Mode
Note: This feature is only applicable to the radio
sending the Emergency Alarm.
Your radio exits Emergency mode when one of the
following occurs:
— Emergency Alarm acknowledgement is received
(for Emergency Alarm only)
— All retries to send the alarm have been exhausted
— The Emergency Off button is pressed.
Note:
If your radio is powered off, it exits the Emergency
mode. The radio will not reinitiate the Emergency
mode automatically when it is turned on again.
If you change channels when your radio is in
Emergency mode to a channel that has no
emergency system configured, No Emergency is
shown on your display.
Text Message Features
Your radio is able to receive data, for example a text
message, from another radio or an e-mail application.
Advanced Features in Non-Connect...
94
English
The maximum length of characters for a text
message, including the subject line (seen when
receiving message from an e-mail application), is 140
whereas for receiving this is 280 characters.
Note: Long press at any time to return to the
Home screen.
Writing and Sending a Text Message
1Access the Text Message feature.
Radio Controls Steps
Programmed
Text Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
2 or to Messages
and press to select.
2 or to Compose and press to select.
A blinking cursor appears.
3Use the keypad to type your message.
Press to move one space to the left. Press or
the key to move one space to the right.
Press the key to delete any unwanted
characters. Long press to change text entry
method.
4Press once message is composed.
5Depending on whether you want to send, save, re-
edit, or delete the newly composed message, do
one of the following.
— or to Send, and press to send the
message.
— or to Save, and press to save the
message to the Drafts folder.
— to edit the message.
— again to choose between deleting the
message or saving it to the Drafts folder.
The display shows transitional mini notice,
confirming your message is being sent.
Advanced Features in Non-Connect...
95
English
If the message is sent successfully, a tone sounds
and the display shows positive mini notice.
If the message cannot be sent, a low tone sounds
and the display shows negative mini notice.
If the text message fails to send, the radio returns
you to the Resend option screen (see Managing
Fail-to-Send Text Messages on page 100
Sending a Quick Text Message
Your radio supports a maximum of 50 Quick Text
messages as programmed by your dealer.
While Quick Text messages are predefined, you can
edit each message before sending it.
1Access the Text Message feature.
Radio Controls Steps
Programmed
Text Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
Radio Controls Steps
2 or to Messages
and press to select.
2 or to Quick Text and press to select.
3 or to the required Quick Text and press
to select.
4Use the keypad to edit the message, if required.
Press to move one space to the left. Press or
the key to move one space to the right.
Press the key to delete any unwanted
characters. Long press to change text entry
method.
5Press once message is composed.
Advanced Features in Non-Connect...
96
English
6Depending on whether you want to send, save, re-
edit, or delete the newly composed message, do
one of the following.
— or to Send, and press to send the
message.
— or to Save, and press to save the
message to the Drafts folder.
— to edit the message.
— again to choose between deleting the
message or saving it to the Drafts folder.
7If you are sending the message, select the
recipient by
— or to the required alias or ID and press
to select.
— or to Manual Dial, and press to
select. The first line of the display shows Radio
Number:. The second line of the display shows
a blinking cursor. Key in the subscriber alias or
ID and press .
The display shows , transitional mini notice,
confirming your message is being sent.
If the message is sent successfully, a tone sounds
and the display shows positive mini notice.
If the message cannot be sent, a low tone sounds
and the display shows negative mini notice.
If the text message fails to send, the radio returns
you to the Resend option screen (see Managing
Fail-to-Send Text Messages on page 100).
Sending a Quick Text Message
— Press the programmed One Touch Access
button to send a predefined Quick Text message
to a predefined alias or ID.
The display shows transitional mini notice,
confirming your message is being sent.
If the message is sent, a tone sounds and the
display shows positive mini notice.
If the message cannot be sent, a low tone sounds
and the display shows negative mini notice.
If the text message fails to send, the radio returns
you to the Resend option screen (see Managing
Fail-to-Send Text Messages on page 100).
Advanced Features in Non-Connect...
97
English
Accessing the Drafts Folder
You can save a text message to send it at a later
time.
If a PTT button press or a mode change causes the
radio to exit the text message writing/editing screen
while you are in the process of writing or editing a text
message, your current text message is automatically
saved to the Drafts folder.
The most recent saved text message is always added
to the top of the Drafts list.
The Drafts folder stores a maximum of ten (10) last
saved messages. When the folder is full, the next
saved text message automatically replaces the oldest
text message in the folder.
Note:
Long press at any time to return to the Home
screen.
Viewing a Saved Text Message
1Access the Text Message feature.
Radio Controls Steps
Programmed
Text Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
2 or to Messages
and press to select.
2 or to Drafts and press to select.
3 or to the required message and press
to select.
Editing and Sending a Saved Text Message
1Press again while viewing the message.
2 or to Edit and press to select.
A blinking cursor appears.
3Use the keypad to type your message.
Advanced Features in Non-Connect...
98
English
Press to move one space to the left. Press or
the key to move one space to the right.
Press the key to delete any unwanted
characters. Long press to change text entry
method.
4Press once message is composed.
5Select the message recipient by
— or to the required alias or ID and press
to select.
— or to Manual Dial, and press to
select. The first line of the display shows Radio
Number:. The second line of the display shows
a blinking cursor. Key in the subscriber alias or
ID and press .
The display shows transitional mini notice,
confirming your message is being sent.
If the message is sent successfully, a tone sounds
and the display shows positive mini notice.
If the message cannot be sent, a low tone sounds
and the display shows negative mini notice.
If the text message cannot be sent, it is moved to
the Sent Items folder and marked with a Send
Failed icon.
Deleting a Saved Text Message from Drafts
1Access the Text Message feature.
Radio Controls Steps
Programmed
Text Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
2 or to Messages
and press to select.
2 or to Drafts and press to select.
3 or to the required message and press
to select.
Advanced Features in Non-Connect...
99
English
4Press again while viewing the message.
5 or to Delete and press to delete the
text message.
Managing Fail-to-Send Text Messages
You can select one of the following options while at
the Resend option screen:
— Resend
— Forward
— Edit
Note: If the channel type (i.e. conventional digital or
Capacity Plus or Linked Capacity Plus) is not a
match, you can only edit and forward a Fail-to-Send
message.
Resending a Text Message
—Press to resend the same message to the
same subscriber/group alias or ID.
If the message is sent successfully, a tone sounds
and the display shows positive mini notice.
If the message cannot be sent, the display shows
negative mini notice.
Forwarding a Text Message
Select Forward to send the message to another
subscriber/ group alias or ID.
1 or to Forward and press to select.
2Select the message recipient by
— or to the required alias or ID and press
to select.
— or to Manual Dial, and press to
select. The first line of the display shows Radio
Number:. The second line of the display shows
a blinking cursor. Key in the subscriber alias or
ID and press .
The display shows Text Message:
<Subscriber/Group Alias or ID>, confirming
your message is being sent.
If the message is sent successfully, a tone sounds
and the display shows positive mini notice.
Advanced Features in Non-Connect...
100
English
If the message cannot be sent, a low tone sounds
and the display shows negative mini notice.
Editing a Text Message
Select Edit to edit the message before sending it.
Note: If a subject line is present (for messages
received from an e-mail application), you cannot edit
it.
1 or to Edit and press to select.
A blinking cursor appears.
2Use the keypad to edit your message.
Press to move one space to the left. Press or
the key to move one space to the right.
Press the key to delete any unwanted
characters. Long press to change text entry
method.
3Press once message is composed.
4Depending on whether you want to send, save, re-
edit, or delete the newly composed message, do
one of the following.
— or to Send, and press to send the
message.
— or to Save, and press to save the
message to the Drafts folder.
— to edit the message.
— again to choose between deleting the
message or saving it to the Drafts folder.
5If you are sending the message, select the
recipient by
— or to the required alias or ID and press
to select.
— or to Manual Dial, and press to
select. The first line of the display shows Radio
Number:. The second line of the display shows
a blinking cursor. Key in the subscriber alias or
ID and press .
Advanced Features in Non-Connect...
101
English
The display shows Text Message:
<Subscriber/Group Alias or ID>, confirming
your message is being sent.
If the message is sent successfully, a tone sounds
and the display shows positive mini notice.
If the message cannot be sent, a low tone sounds
and the display shows negative mini notice.
Managing Sent Text Messages
Once a message is sent to another radio, it is saved
in Sent Items. The most recent sent text message is
always added to the top of the Sent Items list.
The Sent Items folder is capable of storing a
maximum of thirty (30) last sent messages. When the
folder is full, the next sent text message automatically
replaces the oldest text message in the folder.
Note: Long press at any time to return to the
Home screen.
Viewing a Sent Text Message
1Access the Text Message feature.
Radio Controls Steps
Programmed
Text Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
2 or to Messages
and press to select.
2 or to Sent Items and press to select.
3 or to the required message and press
to select.
A subject line may be shown if the message is
from an e-mail application.
The icon at the top right corner of the screen
indicates the status of the message (see Sent Item
Icons on page 38).
Sending a Sent Text Message
You can select one of the following options while
viewing a sent text message:
Advanced Features in Non-Connect...
102
English
— Resend
— Forward
— Edit
— Delete
Note: If the channel type (i.e. conventional digital or
Capacity Plus or Linked Capacity Plus) is not a
match, you can only edit, forward, or delete a Sent
message.
1Press again while viewing the message.
2 or to one of the options described next
and press to select.
Option Steps
Forward Select Forward to send the selected
text message to another subscriber/
group alias or ID (see Forwarding a
Text Message on page 100).
Edit Select Edit to edit the selected text
message before sending it (see Editing
a Text Message on page 101).
Option Steps
Delete Select Delete to delete the text
message.
Resend Select Resend to resend the selected
text message to the same subscriber/
group alias or ID.
The display shows transitional mini
notice, confirming that the same
message is being sent to the same
target radio.
If the message is sent successfully, a
tone sounds and the display shows
positive mini notice.
If the message cannot be sent, a low
tone sounds and the display shows
negative mini notice.
If the message fails to send, the radio
returns you to the Resend option
screen. Press to resend the
message to the same subscriber/group
alias or ID.
Advanced Features in Non-Connect...
103
English
Option Steps
Note: Changing the volume, and
pressing any button, except for ,
, or , returns you to the
message.
Note: The radio exits the Resend
option screen if you press the PTT
button to initiate a Private or Group
Call, or to respond to a Group Call.
The radio also exits the screen when it
receives a text or telemetry message,
an emergency call or alarm, or a call
alert.
Note: The display returns to the
Resend option screen if you press the
PTT button to respond to a Private Call
(except when the radio is displaying
the Missed Call screen), and at the
end of an All Call.
If you exit the message sending screen while the
message is being sent, the radio updates the
status of the message in the Sent Items folder
without providing any indication in the display or
via sound.
If the radio changes mode or powers down before
the status of the message in Sent Items is
updated, the radio cannot complete any In-
Progress messages and automatically marks it
with a Send Failed icon.
The radio supports a maximum of five (5) In-
Progress messages at one time. During this
period, the radio cannot send any new message
and automatically marks it with a Send Failed icon.
Deleting All Sent Text Messages from Sent Items
1Access the Text Message feature.
Radio Controls Steps
Programmed
Text Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
2 or to Messages
and press to select.
Advanced Features in Non-Connect...
104
English
2 or to Sent Items and press to select.
When you select Sent Items and it contains no
text messages, the display shows List Empty,
and sounds a low tone if Keypad Tones are turned
on (see Turning Keypad Tones On or Off on page
129).
3 or to Delete All and press to select.
4Choose one of the following.
— or to Yes and ppress to select. The
display shows positive mini notice.
— or to No and press to return to the
previous screen.
Receiving a Text Message
When your radio receives a message, the display
shows the alias or ID of the sender and the Message
icon at the far left of the screen.
You can select Read when receiving a text message.
Note:
The radio exits the Text Message alert screen and
sets up a Private or Group Call to the sender of the
messageif the PTT button is pressed when the radio
is displaying the alert screen.
Reading a Text Message
1 or to Read? and press to select.
Selected message in the Inbox opens.
A subject line may be shown if the message is
from an e-mail application.
2Do one of the following:
—Press to return to the Inbox.
—Press a second time to reply, forward, or
delete the text message.
Managing Received Text Messages
Use the Inbox to manage your text messages. The
Inbox is capable of storing a maximum of 30
messages.
Text messages in the Inbox are sorted according to
the most recently received.
Advanced Features in Non-Connect...
105
English
Your radio supports the following options for text
messages:
— Reply
— Forward
— Delete
— Delete All
Note: If the channel type (i.e. conventional digital or
Capacity Plus or Linked Capacity Plus) is not a
match, you can only forward, delete, or delete all
Received messages.
Note: Long press at any time to return to the
Home screen.
Viewing a Text Message from the Inbox
1 to access the menu.
2 or to Messages and press to select.
3 or to Inbox and press to select.
4 or toview the messages.
A subject line may be shown if the message is
from an e-mail application.
5Do one of the following:
—Press to select the current message, and
press again to reply, quick reply, forward,
or delete that message.
—Long press to return to the Home
screen.
Viewing a Telemetry Status Text Message from
the Inbox
1 to access the menu.
2 or to Messages and press to select.
3 or to Inbox and press to select.
4 or to the required message and press
to select.
Advanced Features in Non-Connect...
106
English
You cannot reply to a Telemetry Status text
message.
The display shows Telemetry: <Status Text
Message>.
5Long press to return to the Home screen.
Replying to a Text Message from the Inbox
1Access the Text Message feature.
Radio Controls Steps
Programmed
Text Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
2 or to Messages
and press to select.
2 or to Inbox and press to select.
3 or to the required message and press
to select.
A subject line may be shown if the message is
from an e-mail application.
4Press once more to access the sub-menu.
5Do one of the following:
— or to Reply and press to select.
— or to Quick Reply and press to
select.
A blinking cursor appears.
6Use your keypad to write/edit your message.
7Press once message is composed.
The display shows transitional mini notice,
confirming your message is being sent.
If the message is sent successfully, a tone sounds
and the display shows positive mini notice,
If the message cannot be sent,a low tone sounds
and the display shows negative mini notice,
Advanced Features in Non-Connect...
107
English
If the message cannot be sent, the radio returns
you to the Resend option screen (see Managing
Fail-to-Send Text Messages on page 100).
Deleting a Text Message from the Inbox
1Access the Text Message feature.
Radio Controls Steps
Programmed
Text Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
2 or to Messages
and press to select.
2 or to Inbox and press to select.
3 or to the required message and press
to select.
A subject line may be shown if the message is
from an e-mail application.
4Press once more to access the sub-menu.
5 or to Delete and press to select.
6 or to Yes and press to select.
The display shows positive mini notice and the
screen returns to the Inbox.
Deleting All Text Messages from the Inbox
1Access the Text Message feature.
Radio Controls Steps
Programmed
Text Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
2 or to Messages
and press to select.
2 or to Inbox and press to select.
Advanced Features in Non-Connect...
108
English
When you select Inbox and it contains no text
messages, the display shows List Empty, and
sounds a low tone if Keypad Tones are turned on
(see Turning Keypad Tones On or Off on page
129).
3 or to Delete All and press to select.
4 or to Yes and press to select.
The display shows positive mini notice.
Job Tickets
Your radio is able to receive Job Tickets, which are
messages from the dispatcher listing out tasks that
need to be performed.
You can respond to Job Tickets in order to sort them
into Job Ticket Folders. By default, the folders are
“All", "New", "Started", and "Completed". Check with
your dealer or system administrator for an additional
10 folders.
Your radio supports a maximum of 100 Job Tickets,
all of which can be seen in the "All" folder. New Job
Tickets and Job Tickets with recent change in state
are listed first. Upon reaching the maximum number
of Job Tickets, the next Job Ticket automatically
replaces the last Job Ticket in your radio.
Note:
Job Tickets are retained even after radio is powered
down and powered up again.
Your radio will automatically detect and discard the
duplicated Job Tickets with the same subject line.
Accessing the Job Ticket Folder
Access the Job Ticket folder.
Radio Control Steps
Programmed
Job Ticket
button
1Press the programmed Job
Ticket button.
2 or to the required
folder and press to
select.
Note: You can also press
and the corresponding
number key (1–9) to access
the required folder.
Advanced Features in Non-Connect...
109
English
Radio Control Steps
Menu 1 to access the menu.
2 or to Job Tickets
and press to select.
3 or to the required
folder and press to
select.
Note: You can also press
and the corresponding
number key (1–9) to access
the required folder.
4 or to the required Job
Ticket and press to
select.
Responding to the Job Ticket
1 to access the menu
2 or to Job Tickets and press to select
3 or to the required folder and press to
select.
You can also press the corresponding number key
(1–9) to access the required folder.
4 or to the required Job Ticket and press
to select.
5Press once more to access the sub-menu.
You can also press the corresponding number key
(1–9) to Quick Reply.
6 or to the required Job Ticket and press
to select.
You can also press the corresponding number key
(1–9) to respond to the job ticket.
The display shows transitional mini notice, confirming
your message being sent.
If the message is sent, a tone sounds and the display
shows positive mini notice.
Advanced Features in Non-Connect...
110
English
If the message is not sent, a low tone sounds and the
display shows negative mini notice.
Deleting a Job Ticket
Delete a Job Ticket.
Radio Control Steps
Programmed
Job Ticket
button
1Press the programmed Job
Ticket button.
2 or to All and press
to select
Menu 1 to access the menu
2 or to Job Tickets
and press to select
3 or to All and press
to select
4 or to the required
Job Ticket and press to
select.
Radio Control Steps
Note: At Step 4, while
viewing the Job Ticket, press
to delete.
5Press again while
viewing the Job Ticket.
6 or to Delete and
press to select
Note: You can also press
to delete.
Privacy
If enabled, this feature helps to prevent
eavesdropping by unauthorized users on a channel
by the use of a software-based scrambling solution.
The signaling and user identification portions of a
transmission are not scrambled.
Your radio must have privacy enabled on the channel
to send a privacy-enabled transmission, although this
is not a necessary requirement for receiving a
Advanced Features in Non-Connect...
111
English
transmission. While on a privacy-enabled channel,
the radio is still able to receive clear (unscrambled)
transmissions.
Your radio supports two types of privacy:
— Basic Privacy
— Enhanced Privacy.
Only ONE of the privacy types above can be
assigned to the radio.
To unscramble a privacy-enabled call or data
transmission, your radio must be programmed to
have the same Privacy Key (for Basic Privacy), OR
the same Key Value and Key ID (for Enhanced
Privacy) as the transmitting radio.
If your radio receives a scrambled call that is of a
different Privacy Key, OR a different Key Value and
Key ID, you will either hear a garbled transmission
(Basic Privacy) or nothing at all (Enhanced Privacy).
If the radio has a privacy type assigned, the Home
screen shows the Secure or Unsecure icon, except
when the radio is sending or receiving an Emergency
call or alarm.
The LED lights up solid green while the radio is
transmitting and blinks green rapidly when the radio is
receiving an ongoing privacy-enabled transmission.
You can access this feature by
— Pressing the programmed Privacy button to
toggle privacy on or off.
— Using the Radio Menu as described by the steps
described next.
Note: Some radio models may not offer this Privacy
feature. Check with your dealer or system
administrator for more information.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Privacy and press to select.
You can also use or to change selected
option.
Advanced Features in Non-Connect...
112
English
5Press to enable/disable Privacy.
The display shows beside Enabled.
The disappears from beside Enabled.
Covert Mode
Your radio is capable of Covert Mode. During covert
mode, all keypad and programmed button access are
blocked. When enabled, all visual indications (display,
LED's and backlight) are enabled.
This feature allows audio or tone only via a wired
accessory or a Bluetooth accessory.
Entering Covert Mode
Press the button and the 2, 5, and 8 numeric
keys in tandem in home screen.
Exiting Covert Mode
To exit Covert Mode, do one of the following:
—Press the button and the 2, 5, and 8
numeric keys in tandem. Radio will go back to
normal mode.
— Power cycle the radio via the On/Off button.
Dual Tone Multi Frequency (DTMF)
The Dual Tone Multi Frequency (DTMF) feature
allows the radio to operate in a radio system with an
interface to telephone systems.
1Press and hold the PTT button to initiate a DTMF
call.
2Enter the desired number, * or #.
You can turn off the DTMF tone by disabling all
radio tones and alerts (see Turning the Radio
Tones/Alerts On or Off on page 132).
Multi-Site Controls
These features are applicable when your current
radio channel is part of an IP Site Connect or Linked
Capacity Plus configuration.
Advanced Features in Non-Connect...
113
English
See IP Site Connect on page 41 and Linked Capacity
Plus on page 42 for more details about these
configurations.
Starting an Automatic Site Search
Note: The radio only scans for a new site if the
current signal is weak or when the radio is unable to
detect any signal from the current site. If the RSSI
value is strong, the radio remains on the current site.
Start Automatic Site search by
Radio
Control
Description
Site Lock
On/Off
button
Press the programmed Site Lock
On/Off button to toggle the start/stop
automatic site search.
Radio
menu 1 to access the menu.
2 or to Utilities and
press to select.
3 or to Radio Settings
and press to select.
Radio
Control
Description
4 or to Site Roaming and
press to select.
5 or to Site Lock and
press to select.
If the current channel is
— a multi-site channel with an attached roam list
AND
— is out of range,
the radio also performs an automatic site search
(that is the site is unlocked) during
— a PTT button press or
— data transmission.
A tone sounds and the display shows Site
Unlocked.
The radio then returns to the Home screen. The
display shows the Site Roaming icon and channel
alias.
Advanced Features in Non-Connect...
114
English
The LED blinks yellow rapidly when the radio is
actively searching for a new site, and turns off
once the radio locks on to a site.
Stopping an Automatic Site Search
When your radio is actively searching for a new
site, you can stop the search by
Radio
Control
Description
Site Lock
On/Off
button
Press the programmed Site Lock
On/Off button to toggle the start/stop
automatic site search.
Radio
menu 1 to access the menu.
2 or to Utilities and
press to select.
3 or to Radio Settings
and press to select.
4 or to Site Roaming and
press to select.
Radio
Control
Description
5 or to Site Lock and
press to select.
A tone sounds and the display shows Site
Locked.
The radio then returns to the Home screen. The
LED turns off and the display shows the channel
alias.
Starting a Manual Site Search
Start a Manual Site Search by
Radio
Control
Description
Manual
Site
Roam
button
Press the programmed Manual Site
Roam button to start the manual site
search.
Radio
menu 1 to access the menu.
Advanced Features in Non-Connect...
115
English
Radio
Control
Description
2 or to Utilities and
press to select.
3 or to Radio Settings
and press to select.
4 or to Site Roaming and
press to select.
5 or to Active Search
and press to select.
A tone sounds, the display shows Finding Site,
and the LED blinks green.
If a new site is found, a tone sounds and the LED
turns off. The display shows Site <Alias>
Found.
If there is no available site within range, a tone
sounds and the LED turns off. The display shows
Out of Range.
If a new site is within range, but the radio is unable
to connect to it, a tone sounds and the LED turns
off. The display shows Channel Busy.
The radio returns to the Home screen.
Security
You can enable or disable any radio in the system.
For example, you might want to disable a stolen
radio, to prevent the thief from using it, and enable
that radio, when it is recovered.
Note: Performing Radio Disable and Enable is limited
to radios with these functions enabled. Check with
your dealer or system administrator for more
information.
Radio Disable
1Access this feature by
Radio
Controls
Steps
Radio
Disable
button
1Press the programmed Radio
Disable button.
Advanced Features in Non-Connect...
116
English
Radio
Controls
Steps
2 or to the required alias or
ID and press to select.
Radio
menu 1 to access the menu.
2 or to Contacts and press
to select. The entries are
alphabetically sorted.
3Use one of the steps described
next to select the required
subscriber alias or ID
— select the required alias or ID
directly
— or to the required
alias or ID and press to
select.
—use the Manual Dial menu
Radio
Controls
Steps
— or to Manual Dial
and press to select.
— or to Radio
Number and press to
select.
— The first line of the display
shows Radio Number: .
the second line of the
display shows a blinking
cursor. Use the keypad to
enter the subscriber alias
or ID and press .
4 or to Radio Disable
and press to select.
The display shows Radio Disable:
<Subscriber Alias or ID> and the LED lights
up solid green.
2Wait for acknowledgment.
Advanced Features in Non-Connect...
117
English
If successful, the radio sounds a positive indicator
tone and the display shows positive mini notice.
If not successful, the radio sounds a negative
indicator tone and the display shows negative mini
notice.
Do not press during the Radio Disable
operation as you will not get an acknowledgement
message.
Radio Enable
1Access this feature by
Radio
Controls
Steps
Radio
Enable
button
1Press the programmed Radio
Enable button.
2 or to the required alias or
ID and press to select.
Radio
menu 1 to access the menu.
Radio
Controls
Steps
2 or to Contacts and press
to select. The entries are
alphabetically sorted.
3Use one of the steps described
next to select the required
subscriber alias or ID
— select the required alias or ID
directly
— or to the required
alias or ID and press to
select.
—use the Manual Dial menu
— or to Manual Dial
and press to select.
— or to Radio
Number and press to
select.
Advanced Features in Non-Connect...
118
English
Radio
Controls
Steps
— The first line of the display
shows Radio Number: .
the second line of the
display shows a blinking
cursor. Use the keypad to
enter the subscriber alias
or ID and press .
4 or to Radio Enable and
press to select.
The display shows Radio Enable: <Subscriber
Alias or ID> and the LED lights up solid green.
2Wait for acknowledgment.
If successful, the radio sounds a positive indicator
tone and the display shows positive mini notice.
If not successful,the radio sounds a negative
indicator tone and the display shows negative mini
notice.
Do not press during the Radio Enable
operation as you will not get an acknowledgement
message.
Lone Worker
This feature raises an emergency if there is no user
activity, such as any radio button press or activation
of the channel selector, for a predefined time.
Before raising the emergency, when the inactivity
timer expires, the radio warns the user via an audio
indicator.
If there is still no acknowledgment by the user before
the predefined reminder timer expires, the radio
initiates an Emergency Alarm.
Only one of the following Emergency Alarms can be
assigned to this feature:
— Emergency Alarm
— Emergency Alarm with Call
— Emergency Alarm with Voice to Follow
The radio remains in the emergency state allowing
voice messages to proceed until action is taken. See
Advanced Features in Non-Connect...
119
English
Emergency Operation on page 89 on ways to exit
Emergency.
Note: This feature is limited to radios with this
function enabled. Check with your dealer or system
administrator for more information.
Password Lock Features
If enabled, this feature only allows you access your
radio if the correct password is entered upon
powering up.
Accessing the Radio from Password
1Power up your radio.
You hear a continuous tone.
2Do one of the following:
— Enter your current four-digit password with the
radio’s keypad. The second line of the display
shows . Press to proceed.
—Enter your current four-digit password. Press
or to edit each digit’s numeric value. Each
digit changes to . Press to move to next
digit. Press to confirm your selection.
You hear a positive indicator tone for every digit
entered. Press to remove the last on the
display. You hear a negative indicator tone, if you
press when the second line of the display is
empty, or if you press more than four digits.
If the password is correct, your radio proceeds to
power up. See Powering Up the Radio on page
25.
If the password is incorrect, the display shows
Wrong Password. Repeat Steps 1 on page 120
and 2 on page 120. Password less than four digits
is incorrect.
After the third incorrect password, the display
shows Wrong Password and then, shows Radio
Locked. A tone sounds and the LED double blinks
yellow.
Your radio enters into locked state for 15 minutes,
and responds to inputs from On/Off Button and
programmed Backlight button only.
Advanced Features in Non-Connect...
120
English
Note:
The radio is unable to receive any call, including
emergency calls, in locked state.
Unlocking the Radio from Locked State
1If your radio was powered down after being in the
locked state, power up the radio.
A tone sounds and the LED double blinks yellow.
The display shows Radio Locked.
2Wait for 15 minutes.
Your radio restarts the 15 minutes timer for locked
state when you power up.
3Repeat Steps 1 on page 210 and 2 on page 210
in Accessing the Radio from Password on page
210.
Turning the Password Lock On or Off
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Passwd Lock and press to
select.
5Enter the four-digit password.
See Step 2 on page 210 in Accessing the Radio
from Password on page 210.
6Press to proceed.
If the password is incorrect, the display shows
Wrong Password, and automatically returns to the
previous menu.
7If the password entered in the previous step is
correct, press to enable/disable password
lock.
The display shows beside Enabled.
The disappears from beside Enabled.
Advanced Features in Non-Connect...
121
English
Changing the Password
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Passwd Lock and press to
select.
5Enter the four-digit password.
See Step 2 on page 210 in Accessing the Radio
from Password on page 210.
6Press to proceed.
If the password is incorrect, the display shows
Wrong Password, and automatically returns to the
previous menu.
7If the password entered in the previous step is
correct, or to Change Pwd and press
to select.
8Enter a new four-digit password.
See Step 2 on page 210 in Accessing the Radio
from Password on page 210.
9Reenter the previously entered four-digit
password. See Step 2 on page 210 in Accessing
the Radio from Password on page 210.
10 Press to proceed.
If the reentered password matches the new
password entered earlier, the display shows
Password Changed.
If the reentered password does NOT match the
new password entered earlier, the display shows
Passwords Do Not Match.
The screen automatically returns to the previous
menu.
Advanced Features in Non-Connect...
122
English
Bluetooth Operation
This feature allows you to use your radio with a
Bluetooth enabled device (accessory) via a wireless
Bluetooth connection. Your radio supports both
Motorola and COTS (Commercially available Off-The-
Shelf) Bluetooth-enabled devices.
Bluetooth operates within a range of 10 meters (32
feet) line of sight.This is an unobstructed path
between your radio and your Bluetooth-enabled
device.
It is not recommended that you leave your radio
behind and expect your Bluetooth-enabled device to
work with a high degree of reliability when they are
separated.
At the fringe areas of reception, both voice and tone
quality will start to sound “garbled” or “broken”. To
correct this problem, simply position your radio and
Bluetooth-enabled device closer to each other (within
the 10-meter/32 feet defined range) to reestablish
clear audio reception. Your radio’s Bluetooth function
has a maximum power of 2.5 mW (4 dBm) at the 10-
meter/32 feet range.
Your radio can support up to 3 simultaneous
Bluetooth connections with Bluetooth-enabled
devices of unique types. For example, a headset, a
scanner, and a PTT-Only Device (POD). Multiple
connections with Bluetooth-enabled devices of the
same type are not supported.
Refer to your respective Bluetooth-enabled device’s
user manual for more details on your Bluetooth-
enabled device’s full capabilities.
Turning Bluetooth On and Off
1 to access the menu.
2 or to Bluetooth and press to select.
3 or to My Status and press to select.
The display shows On and Off. The current status
is indicated by a .
4Do one of the following:
— or to On and press to select. The
display shows On and a appears left of the
selected status.
Advanced Features in Non-Connect...
123
English
— or to Off and press to select. The
display shows Off and a appears left of the
selected status.
Finding and Connecting to a Bluetooth Device
Do not turn off your Bluetooth-enabled device or
press during the finding and connecting
operation as this cancels the operation.
1Turn on your Bluetooth-enabled device and place
it in pairing mode. Refer to respective Bluetooth-
enabled device’s user manual.
2On your radio, press to access the menu.
3 or to Bluetooth and press to select.
4 or to Devices and press to select.
5Do one of the following:
— or to the required device and press
to select.
— or to Find Devices to locate available
devices. or to the required device and
press to select.
6 or to Connect and press to select.
Display shows Connecting to <Device>. Your
Bluetooth-enabled device may require additional
steps to complete the pairing. Refer to respective
Bluetooth-enabled device’s user manual.
If successful, the radio display shows <Device>
Connected. A tone sounds and appears besides
the connected device. The Bluetooth Connected icon
appears on the status bar.
If unsuccessful, the radio display shows Connecting
Failed .
Note: If pin code is required, use the same entry
method as Step 2 on page 210 in Accessing the
Radio from Password on page 210.
Advanced Features in Non-Connect...
124
English
Finding and Connecting from a Bluetooth Device
(Discoverable Mode)
Do not turn off your Bluetooth or your radio during the
finding and connecting operation as this may cancel
the operation.
1Turn Bluetooth On.
See Turning Bluetooth On and Off on page 123.
2 to access the menu.
3 or to Bluetooth and press to select.
4 or to Find Me and press to select.
Your radio can now be found by other Bluetooth-
enabled devices for a programmed duration. This
is called Discoverable Mode.
5Turn on your Bluetooth-enabled device and pair it
with your radio.
Refer to respective Bluetooth-enabled device’s
user manual.
Disconnecting from a Bluetooth Device
1On your radio, press to access the menu.
2 or to Bluetooth and press to select.
3 or to Devices and press to select.
4 or to the required device and press to
select.
5 or to Disconnect and press to select.
Display shows Disconnecting from <Device>.
Your Bluetooth-enabled device may require
additional steps to disconnect. Refer to respective
Bluetooth-enabled device’s user manual.
The radio display shows <Device> Disconnected. A
positive indicator tone sounds and disappears
beside the connected device. The Bluetooth
Connected icon disappears on the status bar.
Advanced Features in Non-Connect...
125
English
Switching Audio Route
You can toggle audio routing between internal radio
speaker and external Bluetooth-enabled accessory.
Press the programmed Bluetooth Audio Switch
button.
—A tone sounds and display shows Route Audio
to Radio.
—A tone sounds and display shows Route Audio
to Bluetooth.
Viewing Device Details
1 to access the menu.
2 or to Bluetooth and press to select.
3 or to Devices and press to select.
4 or to the required device and press to
select.
5 or to View Details and press to
select.
Editing Device Name
You can edit the name of available Bluetooth-enabled
devices.
1 to access the menu.
2 or to Bluetooth and press to select.
3 or to Devices and press to select.
4 or to the required device and press to
select.
5 or to Edit Name and press to select.
6Press to move one space to the left. Press to
move one space to the right. Press to delete
Advanced Features in Non-Connect...
126
English
any unwanted characters. Long press to
change text entry method.
A blinking cursor appears. Use the keypad to type
the required zone.
7The display shows Device Name Saved.
Deleting Device Name
You can remove a disconnected device from the list
of Bluetooth-enabled devices.
1 to access the menu.
2 or to Bluetooth and press to select.
3 or to Devices and press to select.
4 or to the required device and press to
select.
5 or to Delete and press to select.
The display shows Device Deleted.
Bluetooth Mic Gain
Allows control of the connected Bluetooth-enabled
device’s microphone gain value.
1 to access the menu.
2 or to Bluetooth and press to select.
3 or to BT Mic Gain and press to
select.
4 or to the BT Mic Gain type and the current
values.
To edit values, press to select.
5 or to increase or to decrease values and
press to select.
Notification List
Your radio has a Notification List that collects all your
“unread” events on the channel, such as unread text
messagestelemetry messages and missed calls.
Advanced Features in Non-Connect...
127
English
Unread Job Tickets are also stored in the notification
list.
The Notification icon appears on the status bar when
the Notification List has one or more events.
For TMS and missed call/call alert notification events,
the maximum number are 30 TMS and 10 missed
calls/call alerts. This maximum number depends on
individual feature (job tickets or TMS or missed calls/
call alerts) list capability.
Note: After the events are read, they are removed
from the Notification List.
Accessing the Notification List
1 to access the menu.
2 or to Notification and press to
select.
3 or to the required event and press to
select.
Long press to return to the Home Screen.
Over-the-Air-Programming (OTAP)
Your radio can be updated by your dealer remotely,
via OTAP, without needing to be physically
connected. Additionally, some settings can also be
configured via OTAP.
While undergoing OTAP, the LED blinks green.
Note: When the radio is receiving high volume data,
the High Volume Data icon appears and channel is
busy. A PTT button press at this time may cause a
negative tone to sound.
Once the programming is complete, depending on
your radio’s configuration:
—A tone sounds, the display shows Updating
Restarting, and your radio restarts (powers off
and on again).
—Select between Restart Now or Postpone.
Selecting Postpone allows your radio to return to
the previous display, with an OTAP Timer icon
visible, for a period of time before the automatic
restart occurs.
Upon power up after the automatic restart occurs, the
display shows Sw Update Completed if the OTAP
Advanced Features in Non-Connect...
128
English
update is successful or Sw Update Failed if the
OTAP update is unsuccessful.
See Software Update on page 152 for your updated
software version.
Utilities
Locking and Unlocking the Keypad
You can lock your radio’s keypad to avoid inadvertent
key entry.
To lock/unlock your radio’s keypad.
Option Steps
Locking the
Keypad 1 to access the menu.
2 or to Utilities and
press to select.
3 or to Radio Settings
and press to select.
4 or to Keypad Lock and
press to select.
Option Steps
You can also use or to
change the selected option.
Unlocking
the Keypad Press followed by .
After the keypad is locked, the display shows
Keypad Locked and returns to the Home screen.
After the keypad is unlocked, the display shows
Keypad Unlocked and returns to the Home
screen.
Turning Keypad Tones On or Off
You can enable and disable keypad tones if needed.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
Advanced Features in Non-Connect...
129
English
4 or to Tones/Alerts and press to
select.
5 or to Keypad Tones and press to
select.
You can also use or to change the selected
option.
6Press to enable/disable keypad tones.
The display shows beside Enabled.
The disappears from beside Enabled.
Turning the Option Board Feature(s) On or Off
A channel can support up to 6 option board features.
Refer to your dealer or system administrator for more
information.
— Press the programmed Option Board Feature
button to toggle the feature on or off.
Identifying Cable Type
You can select the type of cable your radio uses.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Cable Type and press to select.
At Step 4, you can also use or to change the
selected option.
5The current cable type is indicated by a
Turning the Voice Operating Transmission (VOX)
Feature On or Off
This feature allows you to initiate a hands-free voice
activated call on a programmed channel. The radio
automatically transmits, for a programmed period,
whenever the microphone on the VOX-capable
accessory detects voice.
Pressing the PTT button during radio operation will
disable VOX. To re-enable VOX, do one of the
following:
Advanced Features in Non-Connect...
130
English
— Turn the radio off and power it on again
— Press the programmed VOX button to toggle the
feature on or off
or follow the steps described next to access this
feature via the radio menu.
Note: Turning this feature on or off is limited to radios
with this function enabled. Check with your dealer or
system administrator for more information.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to VOX and press to select.
5Press to disable/enable VOX.
The display shows beside Enabled.
The disappears from beside Enabled.
Controlling the Display Backlight
You can enable or disable the radio’s display
backlight as needed. The setting also affects the
Menu Navigation Buttons and keypad backlighting
accordingly.
Press the programmed Backlight button to toggle the
backlight settings, or follow the procedure described
next to access this feature via the radio menu.
The display backlight and keypad backlighting are
automatically turned off if the LED indicator is
disabled (see Turning the LED Indicator On or Off on
page 138).
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Backlight and press to select.
Advanced Features in Non-Connect...
131
English
You can also use or to change the selected
option.
5Press to enable/disable the display backlight.
The display shows beside Enabled.
The disappears from beside Enabled.
Turning the Radio Tones/Alerts On or Off
You can enable and disable all radio tones and alerts
(except for the incoming Emergency alert tone) if
needed.
Press the programmed All Tones/Alerts button to
toggle all tones on or off, or follow the procedure
described next to access this feature via the radio
menu.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Tones/Alerts and press to
select.
5 or to All Tones and press to select.
6Press to enable/disable all tones and alerts.
The display shows beside Enabled.
The disappears from beside Enabled.
Setting the Tone Alert Volume Offset Level
You can adjust the Tone Alert Volume Offset level if
needed. This feature adjusts the volume of the tones/
alerts, allowing it to be higher or lower than the voice
volume.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
Advanced Features in Non-Connect...
132
English
4 or to Tones/Alerts and press to
select.
5 or to Vol. Offset and press to
select.
6 or to the required volume value.
The radio sounds a feedback tone with each
corresponding volume value.
7Do one of the following:
—Press to keep the required displayed
volume value.
—Press to exit without changing the
current volume offset settings.
— Repeat Step 6 on page 133 to select another
volume value.
Turning the Talk Permit Tone On or Off
You can enable and disable the Talk Permit Tone if
needed.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Tones/Alerts and press to
select.
5 or to Talk Permit and press to
select.
You can also use or to change the selected
option.
6Press to enable/disable the Talk Permit Tone.
The display shows beside Enabled.
The disappears from beside Enabled.
Advanced Features in Non-Connect...
133
English
Setting the Text Message Alert Tone
You can customize your radio’s text message alert
tone to Momentary or Repetitive for each entry in the
Contacts list.
1 to access the menu.
2 or to Contacts and press to select.
3 or to the required subscriber alias or ID
and press to select.
4 or to Message Alert and press to
select.
The display shows Momentary and Repetitive.
You can also use or to change the selected
option.
5 or to the required setting and press to
enable
appears besides selected setting.
Changing the Display Mode
You can change radio’s display mode between Day
or Night, as needed. This affects the color palette of
the display.
Change the Display Mode
Radio Control Steps
Programmed
Display Mode
Button
Press the programmed Display
Mode button.
Menu 1 to access the menu.
2 or to Utilities and
press to select.
3 or to Radio
Settings and press to
select.
4 or to Display and
press to select.
Advanced Features in Non-Connect...
134
English
Radio Control Steps
The display shows Day
Mode and Night Mode.
Note: You can also use or
to change the selected
option.
5 or to the required
setting and press to
enable. appears besides
selected setting.
Adjusting the Display Brightness
You can adjust radio’s display brightness as needed.
Note: Display brightness cannot be adjusted when
“Auto Brightness” is enabled.
Adjust the Display Brightness
Radio Control Steps
Programmed
Display 1Press the programmed
Brightness button.
Radio Control Steps
Brightness
Button 2Decrease display brightness
by pressing or increase
the display brightness by
pressing . Select from
setting of 1 to 8. Press to
confirm your entry.
Menu 1 to access the menu.
2 or to Utilities and
press to select.
3 or to Radio
Settings and press to
select.
4 or to Brightness
and press to select.
The display shows a
progress bar.
Advanced Features in Non-Connect...
135
English
Radio Control Steps
5Decrease display brightness
by pressing or increase
the display brightness by
pressing . Select from
setting of 1 to 8. Press to
confirm your entry.
Wallpaper Mode
Your radio displays the Wallpaper background on
home screen. The user can select from 5 default
wallpapers.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Display and press to select.
5 or to Wallpaper and press to select.
You can also use or to change the selected
option.
Screen Saver Mode
The screen saver feature allows the radio to save
radio battery time. A Screen Saver Pre Duration
is used to track the radio activities before entering
screen saver mode.
Radio starts Screen Saver Pre Duration upon
power up. Radio enters into screen saver mode when
Screen Saver Pre Duration timer expires, the
radio exits screen saver mode and responds to
related transaction normally upon any user input and
over the air transaction.
Radio restarts Screen Saver Pre Duration upon
any user input and over the air transaction. After
being in Screen Saver mode for 5 seconds, radio
enters keypad lock state automatically. When any
audio or Bluetooth accessory is connected, battery
saver mode is enabled, radio enters screen saver
mode.
Advanced Features in Non-Connect...
136
English
If there is any user input or over the air transaction,
the radio exits screen saver mode and responds to
user interaction. The Screen Saver Pre Duration
is restarted and the radio goes back to screen saver
mode when it expires.
Note: The screen saver mode is to help improve
battery life.
Audio Accessory
The audio accessory has two modes: Normal and
Battery Saver mode. When audio accessory is
plugged in and the setting is in Battery Saver Mode,
the radio restarts the timer and goes into screen
saver mode. In this scenario, when there is any user
input (including user input on radio and accessory
attachment/detachment) or when receiving
emergency alarm/call, the radio exits screen saver
mode and responds to user event as normal. The
Screen Saver timer restarts and the radio goes back
to screen saver mode when the time allocated
expires.
Note: This battery saver mode is to improve battery
life. See Screen Saver box SRS for more details in
this mode.
Auto Keypad Lock
You can enable/disable your radio’s auto keypad lock
to avoid inadvertent key entry.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Auto Keypad Lock and press to
select.
5Do one of the following:
—Press to enable Auto Keypad Lock. The
display shows beside Enabled.
—Press to disable Auto Keypad Lock. The
disappears from beside Enabled.
Advanced Features in Non-Connect...
137
English
Language
You can set your radio display to be in your required
language.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Languages and press to select.
5 or to the required language and press
to enable. appears beside selected language.
Turning the LED Indicator On or Off
You can enable and disable the LED Indicator if
needed.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to LED Indicator and press to
select.
5Press to enable/disable the LED Indicator.
The display shows beside Enabled.
The disappears from beside Enabled.
Voice Announcement
This feature enables the radio to audibly indicate the
current Zone or Channel the user has just assigned,
or programmable button press. This audio indicator
can be customized per customer requirements. This
is typically useful when the user is in a difficult
condition to read the content shown on the display.
Toggle Voice Announcement On or Off.
Advanced Features in Non-Connect...
138
English
Radio Control Steps
Programmed
Voice
Announcement
Button
Press the programmed Voice
Announcement button.
Menu 1 to access the menu.
2 or to Utilities
and press to select.
3 or to Radio
Settings and press to
select.
4 or to Voice
Announcement and press
to select.
Note: You can also use
or to change the
selected option.
5Do one of the following:
Radio Control Steps
—Press to enable
Voice Announcement.
The display shows
beside Enabled.
—Press to disable
Voice Announcement.
The disappears from
beside Enabled.
Digital Mic AGC (Mic AGC-D)
This feature controls the your radio's microphone gain
automatically while transmitting on a digital system. It
suppresses loud audio or boosts soft audio to a
preset value in order to provide a consistent level of
audio.
1 to access the menu.
2 or to Utilities and press to select.
Advanced Features in Non-Connect...
139
English
3 or to Radio Settings and press to
select.
You can also use or to change the selected
option.
4 or to Mic AGC-D and press to select.
5Do one of the following:
—Press to enable Mic AGC-D. The display
shows beside Enabled.
—Press to disable Mic AGC-D. The
disappears from beside Enabled.
Intelligent Audio
Your radio can automatically adjust its audio volume
to overcome background noise in the environment,
inclusive of all stationary and non-stationary noise
sources. This feature is a Receive-only feature and
does not affect Transmit audio.
Note: This feature is not applicable during a
Bluetooth session.
Toggle Intelligent Audio On or Off.
Radio Control Steps
Programmed
Intelligent
Audio Button
Press the programmed
Intelligent Audio button.
Menu 1 to access the menu.
2 or to Radio
Settings and press to
select.
3 or to Radio
Settings and press to
select.
4 or to Intelligent
Audio and press to
select.
Note: You can also use or
to change the selected
option.
5Do one of the following:
Advanced Features in Non-Connect...
140
English
Radio Control Steps
—Press to enable
Intelligent Audio. The
display shows beside
Enabled.
—Press to disable
Intelligent Audio. The
disappears from beside
Enabled.
See Accessories on page 245 for recommended
Bluetooth-enabled audio accessories with in-built
Automatic Volume Control for similar performance.
Turning the Acoustic Feedback Suppressor Feature On
or Off
This feature allows you to minimize acoustic feedback
in received calls.
Toggle Acoustic Feedback Suppressor Features
On or Off
Radio Control Steps
Programmed
Acoustic
Feedback
Suppressor
Button
Press the programmed
Acoustic Feedback
Suppressor button.
Menu 1 to access the menu.
2 or to Utilities and
press to select.
3 or to Radio
Settings and press to
select.
4 or to AF
Suppressor and press
to select.
Note: You can also use or
to change the selected
option.
5Do one of the following:
Advanced Features in Non-Connect...
141
English
Radio Control Steps
—Press to enable
Acoustic Feedback
Suppressor. The display
shows beside Enabled.
—Press to disable
Acoustic Feedback
Suppressor. The
disappears from beside
Enabled.
Text Entry Configuration
You can configure the following settings for entering
text on your radio:
— Word Predict
— Word Correct
— Sentence Cap
— My Words
Your radio supports the following text entry methods:
— Numbers
— Symbols
— Predictive or Multi-Tap
— Language (If programmed)
Note: Press at any time to return to the
previous screen or long press to return to the
Home Screen. The radio exits the current screen
once the inactivity timer expires.
Word Predict
Your radio can learn common word sequences that
you often enter. It then predicts the next word you
may want to use after you enter the first word of a
common word sequence into the text editor.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Text Entry and press to select.
Advanced Features in Non-Connect...
142
English
5 or to Word Predict and press to
select.
You can also use or to change the selected
option.
6Do one of the following:
—Press to enable Word Predict. The display
shows beside Enabled.
—Press to disable Word Predict. The
disappears from beside Enabled.
Word Correct
Supplies alternative word choices when the word
entered into the text editor is not recognized by the in-
built dictionary.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Text Entry and press to select.
5 or to Word Correct and press to
select.
You can also use or to change the selected
option.
6Do one of the following:
—Press to enable Word Correct. The display
shows beside Enabled.
—Press to disable Word Correct. The
disappears from beside Enabled.
Sentence Cap
Automatically enables capitalization for the first letter
in the first word for every new sentence.
1 to access the menu.
Advanced Features in Non-Connect...
143
English
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Text Entry and press to select.
5 or to Sentence Cap and press to
select.
6Do one of the following:
—Press to enable Sentence Cap. The display
shows beside Enabled.
—Press to disable Sentence Cap. The
disappears from beside Enabled.
Viewing Custom Words
You can add your own custom words into your radio’s
in-built dictionary. Your radio maintains a list to
contain these words.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Text Entry and press to select.
5 or to My Words and press to select.
6 or to List of Words and press to
select.
Display shows the list of custom words.
Editing Custom Word
You can edit the custom words saved in your radio.
1 to access the menu.
2 or to Utilities and press to select.
Advanced Features in Non-Connect...
144
English
3 or to Radio Settings and press to
select.
4 or to Text Entry and press to select.
5 or to My Words and press to select.
6 or to List of Words and press to
select.
Display shows the list of custom words.
7 or to the required word and press to
select.
8 or to Edit and press to select.
9Use the keypad to edit your custom word.
Press to move one space to the left. Press or
the key to move one space to the right.
Press the key to delete any unwanted
characters. Long press to change text entry
method. Press once your custom word is
completed.
The display shows transitional mini notice, confirming
your custom word is being saved.
If the custom word is saved, a tone sounds and the
display shows positive mini notice.
If the custom word is not saved, a low tone sounds
and the display shows negative mini notice.
Adding Custom Word
You can add your own custom words into your radio’s
in-built dictionary.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Text Entry and press to select.
Advanced Features in Non-Connect...
145
English
5 or to My Words and press to select.
6 or to Add New Word and press to
select.
Display shows the list of custom words.
7Use the keypad to edit your custom word.
Press to move one space to the left. Press or
the key to move one space to the right.
Press the key to delete any unwanted
characters. Long press to change text entry
method. Press once your custom word is
completed.
The display shows transitional mini notice, confirming
your custom word is being saved.
If the custom word is saved, a tone sounds and the
display shows positive mini notice.
If the custom word is not saved, a low tone sounds
and the display shows negative mini notice.
Deleting a Custom Word
You can delete the custom words saved in your radio.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Text Entry and press to select.
5 or to My Words and press to select.
6 or to the required word and press to
select.
7 or to Delete and press to select.
8Choose one of the following.
—At Delete Entry?, press to select Yes.
The display shows Entry Deleted.
Advanced Features in Non-Connect...
146
English
— or to No and press to return to the
previous screen.
Deleting All Custom Words
You can delete all custom words from your radio’s in-
built.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Text Entry and press to select.
5 or to My Words and press to select.
6 or to Delete All and press to select.
7Choose one of the following.
—At Delete Entry?, press to select Yes.
The display shows Entry Deleted.
— or to No and press to return to the
previous screen.
Flexible Receive List
Flexible Receive List is a digital-only (currently
supported in Capacity Plus and Linked Capacity Plus)
feature that allows you to add, delete or edit members
on the receive talkgroup list. Your radio can support a
maximum of 16 members in the list.
Turning the Flexible Receive List On or Off
You can enable and disable the Flexible Receive List
if needed.
Enable the Flexible Receive List
Radio Control Steps
Programmed
Flexible
Receive List
Button
Press the programmed
Flexible Receive List button.
Advanced Features in Non-Connect...
147
English
Radio Control Steps
Menu 1 to access the menu.
2 or to Utilities
and press to select.
3 or to Radio
Settings and press to
select.
4 or to Flexible Rx
List and press to
select.
5Press to enable/disable
the Flexible Rx List.
Previous
display
Current display
Turn On Flexible Rx List On
Turn Off Flexible Rx List Off
Adding a New Entry to the Flexible Receive List
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Flexible Rx List and press to
select.
5 or to View/Edit List and press to
select.
6 or to Add Member and press to select.
7Select the required alias or ID by
Radio
Control
Steps
Radio
Navigation
Buttons
or to the required alias or
ID.
Advanced Features in Non-Connect...
148
English
Radio
Control
Steps
Keypad Key in the first character of the
required alias.
A blinking cursor appears.
Press to move one space to the
left. Press to move one space to
the right. Press the key to
delete any unwanted characters.
Long press to change the
text entry method.
The first line of the display shows
the characters you keyed in. The
next lines of the display show the
short listed search results. The
alias search is case-insensitive. If
there are two or more aliases with
the same name, the radio displays
the alias that is listed first in the
list.
8Press to select.
The display shows Add Another?.
9 or to No and press to select
The display shows .
Deleting an Entry from the Flexible Receive List
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Flexible Rx List and press to
select.
5 or to View/Edit List and press to
select.
6Select the required alias or ID by
Advanced Features in Non-Connect...
149
English
Radio
Control
Steps
Radio
Navigation
Buttons
or to the required alias or
ID.
Keypad Key in the first character of the
required alias.
A blinking cursor appears.
Press to move one space to the
left. Press to move one space to
the right. Press the key to
delete any unwanted characters.
Long press to change the
text entry method.
The first line of the display shows
the characters you keyed in. The
next lines of the display show the
short listed search results. The
alias search is case-insensitive. If
there are two or more aliases with
Radio
Control
Steps
the same name, the radio displays
the alias that is listed first in the
list.
7Press to select.
8 or to Delete and press to select.
9 or to Yes and press to select.
The display shows .
Accessing General Radio Information
Your radio contains information on the following:
— Battery
— Radio Alias and ID
— Firmware and Codeplug Versions
— Open-Source Software Information
— Software Update
— Site Information
Advanced Features in Non-Connect...
150
English
Press at any time to return to the previous
screen or long press to return to the Home
screen. The radio exits the current screen once the
inactivity timer expires.
Accessing the Battery Information
Displays information on your radio battery.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Battery Info and press to
select.
The display shows the battery information.
For IMPRES batteries ONLY: The display reads
Recondition Battery if the battery requires
reconditioning in an IMPRES charger. After the
reconditioning process, the display then shows the
battery information.
Checking the Radio Alias and ID
This feature displays the ID of your radio.
Press the programmed Radio Alias and ID button to
check your radio alias and ID. You hear a positive
indicator tone.
Follow the procedure described next to access this
feature via the radio screen.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to My ID and press to select.
The first line of the display shows the radio alias.
The second line of the display shows the radio ID.
Checking the Firmware Version and Codeplug
Version
Displays the firmware version on your radio.
Advanced Features in Non-Connect...
151
English
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Versions and press to select.
The display shows the current firmware and
codeplug versions.
Checking the Open-Source Software Information
Displays the open-source software (OSS) information
on your radio.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Versions and press to select.
The display shows the Firmware Version
information.
Software Update
Displays the date and time of the latest software
update carried out via Over-the-Air Programming.
Note: Software Update menu is only available after at
least one successful OTAP session.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to SW Update and press to select.
The display shows the date and time of the latest
software update.
See Over-the-Air-Programming (OTAP) on page 128
for details on OTAP session.
Advanced Features in Non-Connect...
152
English
Site Information
Displays the current Linked Capacity Plus site name
your radio is on.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Site Info and press to select.
The display shows the current Linked Capacity
Plus site name.
See Linked Capacity Plus on page 42 for details on
Linked Capacity Plus.
RSSI Values
Your radio shows the Received Signal Strength
Indicator (RSSI) icon at the top of your display. This
feature allows you to view the RSSI values.
On the home screen, press three times and
immediately press , all within 5 seconds.
The display shows current RSSI values. Long
press the to return to the Home Screen.
See Display Icons on page 34 for details on RSSI
icon.
Advanced Features in Non-Connect...
153
English
Additional Radio Controls in Connect
Plus Mode
Push-To-Talk (PTT) Button
The PTT button on the side of the radio ( ) serves
two basic purposes:
A
— While a call is in progress, the PTT button allows
the radio to transmit to other radios in the call.
Press and hold down PTT button to talk. Release
the PTT button to listen.
The microphone is activated when the PTT button
is pressed.
— While a call is not in progress, the PTT button is
used to make a new call (see Making a Radio Call
on page 165).
If the Talk Permit Tone (see Turning the Talk Permit
Tone On or Off on page 133) is enabled, wait until the
short alert tone ends before talking.
Programmable Buttons
Your dealer can program the programmable buttons
as shortcuts to radio functions depending on the
duration of a button press:
— Short press – Pressing and releasing rapidly.
— Long press – Pressing and holding for the
programmed duration.
— Hold down – Keeping the button pressed.
Note: The programmed duration of a button press is
applicable for all assignable radio/utility functions or
settings. See Emergency Operation on page 185 for
more information on the programmed duration of the
Emergency button.
Additional Radio Controls in Connect...
154
English
Assignable Radio Functions
Actions — A programmable button to access a CPS
programmable action list.
Bluetooth® Audio Switch — Toggles audio routing
between internal radio speaker and external
Bluetooth-enabled accessory.
Busy Queue Cancellation – Exits the busy mode
when a non-Emergency call in the Busy Queue was
initiated. Emergency calls, once accepted into the
Busy Queue, cannot be cancelled.
Contacts — Provides direct access to the Contacts
list.
Voice Announcement for Channel — Plays zone
and channel announcement voice messages for the
current channel. This function is unavailable when
Voice Announcement is disabled.
Emergency On/Off — Depending on the
programming, initiates or cancels an emergency.
Manual Dial — Depending on the programming,
initiates a Private Call by keying in any subscriber ID.
One Touch Access — Directly initiates a predefined
Private Call, a Call Alert or a Quick Text message.
Privacy — Toggles privacy on or off.
Radio Check — Determines if a radio is active in a
system.
Radio Enable — Allows a target radio to be remotely
enabled.
Radio Disable — Allows a target radio to be remotely
disabled.
Remote Monitor — Turns on the microphone of a
target radio without it giving any indicators.
Roam Request – Requests to search for a different
site.
Scan — Toggles scan on or off.
Site Lock On/Off — When toggled on, the radio
searches the current site only. When toggled off, the
radio searches other sites in addition to the current
site.
Text Message — Selects the text message menu.
Zone — Allows selection from a list of zones.
Assignable Settings or Utility Functions
All Tones/Alerts — Toggles all tones and alerts on
or off.
Additional Radio Controls in Connect...
155
English
Backlight — Toggles display backlight on or off.
Brightness — Allows brightness to be set via the
manual brightness mode or auto brightness control
via the radio’s photo sensor.
Display Mode — Toggles the day/night display mode
on or off.
Keypad Lock — Toggles keypad between locked
and unlocked.
Power Level — Toggles transmit power level
between high and low.
Wallpaper — Displayed on home screen.
Identifying Status Indicators in Connect Plus
Mode
Display Icons
Your radio has a 2 inch landscape display with QVGA
(Quarter Video Graphics Array) 16-bit color
resolution.
The following are icons that appear on the radio’s
display. Icons are displayed arranged left-most in
order of appearance/usage.
Received Signal Strength Indicator
(RSSI)
The number of bars displayed
represents the radio signal strength.
Four bars indicate the strongest signal.
This icon is only displayed while
receiving.
Bluetooth Not Connected
The Bluetooth feature is enabled but
there is no remote Bluetooth device
connected.
Bluetooth Connected
The Bluetooth feature is enabled. The
icon stays lit when a remote Bluetooth
device is connected.
Bluetooth Discoverable
The Bluetooth feature is enabled and
radio is in discoverable mode.
Notification List has items to review.
Additional Radio Controls in Connect...
156
English
Option Board
The Option Board is enabled. (Option
board enabled models only)
Option Board Non-Function
The Option Board is disabled.
Scan
Scan feature is enabled.
Emergency
Radio is in Emergency mode.
Secure
The Privacy feature is enabled.
Unsecure
The Privacy feature is disabled.
Site Roaming
The site roaming feature is enabled.
Battery
The number of bars (0 – 4) shown
indicates the charge remaining in the
battery. Blinks when the battery is low.
Battery Discharging Status
Shows battery discharging status.
All Tones Disabled
No ring tones available.
Call Log
Radio call log.
Contact
Radio contact is available.
Message
Incoming message.
Silent Ring
Silent ring mode is enabled.
Additional Radio Controls in Connect...
157
English
Ring Only
Ringing mode is enabled.
Vibrate
Vibrate mode is enabled.
Vibrate and Ring
Vibrate and Ring mode is enabled.
Keypad
Keypad locked.
Call Icons
The following icons appear on the radio’s display
during a call. These icons also appear in the Contacts
list to indicate ID type.
Private Call
Indicates a Private Call in progress.
Group Call/All Call
Indicates a Group Call or All Call in
progress.
Sent Item Icons
The following icons appear at the top right corner of
the radio’s display in the Sent Items folder.
OR
Sent Successfully
The text message is sent successfully.
OR
Individual or Group Message Read
The text message has been read.
OR
Individual or Group Message Unread
The text message has not been read.
Additional Radio Controls in Connect...
158
English
OR
Send Failed
The text message has not been sent.
LED Indicator
The LED indicator ( ) shows the operational status of
your radio.
A
Blinking red Radio is transmitting at low battery
condition, receiving an emergency
transmission or has failed the self-
test upon powering up.
Rapidly
blinking red
Radio is receiving over-the-air file
transfer (Option Board firmware file,
Network Frequency file or Option
Board Codeplug file) or upgrading to
a new Option Board firmware file.
Blinking
green and
yellow
Radio is receiving a Call Alert,
received a text message or Scan is
enabled and is receiving activity.
Solid yellow Radio is in Bluetooth Discoverable
Mode. Also indicates fair battery
charge when programmable button
is pressed.
Double
blinking
yellow
Radio is actively searching for a new
site.
Blinking
yellow
Radio is receiving a Call Alert or
Scan is enabled and is idle (not
unmuted to any activity)
Solid green Radio is powering up or transmitting.
Also indicates full charge of the
battery when the programmable
button is pressed.
Blinking
green
Radio is powering up, receiving a
non-privacy- enabled call or data.
Additional Radio Controls in Connect...
159
English
Rapidly
blinking
green
Radio is receiving a privacy-enabled
call.
Note:
Indicator Tones
High pitched tone Low pitched tone
Positive Indicator Tone
Negative Indicator Tone
Audio Tones
Alert tones provide you with audible indications of the
radio’s status or the radio’s response to data
received.
High pitched tone Low pitched tone
Continuous Tone A monotone sound.
Sounds continuously
until termination.
High pitched tone Low pitched tone
Periodic Tone Sounds periodically
depending on the
duration set by the radio.
Tone starts, stops, and
repeats itself.
Repetitive Tone A single tone that
repeats itself until it is
terminated by the user.
Momentary Tone Sounds only once for a
short period of time
defined by the radio.
Additional Radio Controls in Connect...
160
English
Making and Receiving Calls in Connect
Plus Mode
Selecting a Site
A site provides coverage for a specific area. A
Connect Plus site has a site controller and a
maximum of 15 repeaters. In a multi-site network, the
Connect Plus radio will automatically search for a new
site when the signal level from the current site drops
to an unacceptable level.
Roam Request
A Roam Request tells the radio to search for a
different site, even if the signal from the current site is
acceptable.
Note: This is programmed by your dealer.
Press the programmed Roam Request button.
You hear a tone, indicating the radio has switched
to a new site. The display shows Site ID <Site
Number>.
Site Lock On/Off
When toggled on, the radio searches the current site
only. When toggled off, the radio searches other sites
in addition to the current site.
Press the programmed Site Lock button.
— You hear a positive indicator tone, indicating
the radio has locked to the current site. The
display shows Site Locked.
— You hear a negative indicator tone, indicating
the radio is unlocked. The display shows Site
Unlocked.
Site Restriction
Your Connect Plus radio system administrator has the
ability to decide which network sites your radio is and
is not allowed to use. Your radio does not need to be
reprogrammed to change the list of allowed and
disallowed sites. If your radio attempts to register at a
disallowed site, you see a brief message stating:
Site <number given> Not Allowed. The radio
then searches for a different network site.
Making and Receiving Calls in Connect...
161
English
Selecting a Zone
The radio can be programmed with a maximum of 16
Connect Plus Zones and each Connect Plus zone
contains a maximum of 16 assignable positions on
the Channel Selector Knob.
Each assignable knob position can be used to start
one of the following voice call types:
— Group Call
— Multigroup Call
— All Call
— Private Call
1Access the Zone feature.
Radio Controls Steps
Programmed
Zone button
Press the programmed Zone
button.
Radio menu 1 to access the menu.
2 or to Zone and
press to select.
The current zone is displayed and indicated by a
.
2Select the required zone.
Radio Control Steps
or or and scroll to the
required zone.
3Press to select.
The display shows <Zone> Selected
momentarily and returns to the selected zone
screen.
Using Multiple Networks
If your radio has been programmed to use multiple
Connect Plus networks, you can select a different
network by switching to the Connect Plus zone that is
assigned to the desired network. These network-to-
zone assignments are configured by your dealer
through radio programming.
Making and Receiving Calls in Connect...
162
English
Selecting a Call Type
Use the 4–Way Navigation Disc to select a call type.
This can be a Group Call, Multi-group Call, All Call or
Private Call, depending on how your radio is
programmed. If you navigate with the 4–Way
Navigation Disc to a different Call Type this causes
the radio to re-register with the Connect Plus site.
The radio registers with the Registration Group ID
that has been programmed for the newChannel
Selector Knob position call type.
If you select a position that has no call type assigned
to it, your radio sounds a continuous tone and the
display shows Unprogrammed. Your radio does not
operate when selected to an unprogrammed channel,
use the 4–Way Navigation Disc to select a
programmed channel instead.
Once the required zone is displayed (if you have
multiple zones in your radio), use the 4–Way
Navigation Disc to select the call type.
Receiving and Responding to a Radio Call
Once the channel, subscriber ID or call type is
displayed, you can proceed to receive and respond to
calls.
The LED lights up solid green while the radio is
transmitting and blinks green when the radio is
receiving.
Note: The LED lights up solid green while the radio is
transmitting and blinks green rapidly when the radio is
receiving a privacy-enabled call . To unscramble a
privacy-enabled call, your radio must have the same
Privacy Key, OR the same Key Value and Key ID
(programmed by your dealer), as the transmitting
radio (the radio you are receiving the call from).
Note: See Privacy on page 206 for more information.
Receiving and Responding to a Group Call
To receive a call from a group of users, your radio
must be configured as part of that group.
When you receive a Group Call (while on the Home
screen), the LED blinks green. The first line of the
display shows the caller alias, and the RSSI icon. The
second line displays the group alias and the Group
Making and Receiving Calls in Connect...
163
English
Call icon (in Digital mode only). Your radio unmutes
and the incoming call sounds through the radio's
speaker.
1Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
If the Voice Interrupt feature is enabled, press the
PTT button to stop the current call from the
transmitting radio and free the channel for you to
talk/respond.
The LED lights up solid green.
2Wait for one of the Talk Permit Tone to finish (if
enabled), and speak clearly into the microphone.
3Release the PTT button to listen.
If there is no voice activity for a predetermined period
of time, the call ends.
Note: See Making a Group Call on page 166 for
details on making a Group Call.
Note: If the radio receives a Group Call while not on
the Home screen, it remains on its current screen
prior to answering the call.
Note: Long press the button to go to the Home
screen to view the caller alias before replying.
Receiving and Responding to a Private Call
A Private Call is a call from an individual radio to
another individual radio.
When you receive a Private Call, the LED blinks
green. The first line of the display shows the
subscriber alias or ID, and the RSSI icon. The second
line displays Private Call and the Private Call icon.
Your radio unmutes and the incoming call sounds
through the radio's speaker.
1Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
2Press the PTT button to respond to the call.
The LED lights up solid green.
3Wait for the Talk Permit Tone to finish (if enabled),
and speak clearly into the microphone.
4Release the PTT button to listen.
If there is no voice activity for a predetermined period
of time, the call ends.
Making and Receiving Calls in Connect...
164
English
The display shows Call Ended.
See Making a Private Call on page 166 for details on
making a Private Call.
Receiving an All Call
An All Call is a call from an individual radio to every
radio on the site. It is used to make important
announcements requiring the user’s full attention.
When you receive an All Call, a tone sounds and the
LED blinks green.
The first line of the display shows the caller alias, and
the RSSI icon. The second line displays All Call
and the All Call icon. Your radio unmutes and the
incoming call sounds through the radio speaker.
Once the All Call ends, the radio returns to the
previous screen before receiving the call. An All Call
does not wait for a predetermined period of time
before ending.
You cannot respond to an All Call.
Note: See Making an All Call on page 167 for details
on making an All Call.
Note: The radio stops receiving the All Call if you
switch to a different channel while receiving the call.
During an All Call, you will not be able to use any
programmed button functions until the call ends.
Making a Radio Call
After selecting your channel, you can select a
subscriber alias or ID, or group alias or ID by using:
— The PTT button.
— A programmed One Touch Access button – The
One Touch Access feature allows you to make a
Private Call to a predefined ID easily. This feature
can be assigned to a short or long programmable
button press. You can ONLY have one ID
assigned to a One Touch Access button. Your
radio can have multiple One Touch Access
buttons programmed.
— The Contacts list (see Contacts Settings on page
177).
Note: Your radio must have the Privacy feature
enabled on the channel to send a privacy-enabled
transmission. Only target radios with the same Key
Value and Key ID as your radio will be able to
unscramble the transmission.
Note: See Privacy on page 206 for more information.
Making and Receiving Calls in Connect...
165
English
Making a Call with the Channel Selector Knob
Making a Group Call
To make a call to a group of users, your radio must
be configured as part of that group.
1Select the channel with the active group alias or
ID. See Selecting a Call Type on page 163.
2Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
3Press the PTT button to make the call.
The LED lights up solid green. The Group Call
icon appears in the top right corner. The first text
line shows the group call alias.
4Wait for the Talk Permit Tone to finish (if enabled),
and speak clearly into the microphone.
5Release the PTT button to listen.
When the target radio responds, the LED blinks
green, the radio unmutes and the response
sounds through the radio’s speaker. You see the
Group Call icon, the group alias or ID, and
transmitting radio alias or ID on your display.
If there is no voice activity for a predetermined
period of time, the call ends. Radio returns to the
screen you were on prior to initiating the call.
Making a Private Call
While you can receive and/or respond to a Private
Call initiated by an authorized individual radio, your
radio must be programmed for you to initiate a Private
Call.
You will hear a negative indicator tone, when you
make a Private Call via the Contacts list, Call Log,
One Touch Access button, or the Channel Selector
Knob, if this feature is not enabled.
Use the Text Message or Call Alert features to
contact an individual radio. See Text Message
Features on page 191 or Call Alert Operation on
page 87 for more information.
1Do one of the following.
— Select the channel with the active subscriber
alias or ID. See Selecting a Call Type on page
163.
— Press the programmed One Touch Access
button.
Making and Receiving Calls in Connect...
166
English
2Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
3Press the PTT button to make the call.
If you release the PTT button while the radio is
setting up the call, it exits without any indication
and returns to the previous screen.
The LED lights up solid green, the radio unmutes
and the response sounds through the radio’s
speaker. The Private Call icon appears on the top
right corner. The first text line shows the
subscriber alias. The second text line displays the
call status..
4Wait for the Talk Permit Tone to finish (if enabled),
and speak clearly into the microphone.
5Release the PTT button to listen.
When the target radio responds, the LED blinks
green, the radio unmutes and the response
sounds through the radio's speaker.
If there is no voice activity for a predetermined
period of time, the call ends. You hear a short
tone. The display shows Call Ended.
Your radio may be programmed to perform a radio
presence check prior to setting up the Private Call. If
the target radio is not available, you hear a short tone
and see negative mini notice on the display.
Making an All Call
This feature allows you to transmit to all users on the
site that are currently not engaged in another call.
Your radio must be programmed to allow you to use
this feature.
Users on the channel/site cannot respond to an All
Call.
1Select the channel with the active All Call group
alias. See Selecting a Call Type on page 163.
2Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
3Press the PTT button to make the call.
The LED lights up solid green.The Group Call icon
appears in the top right corner. The first text line
shows All Call.
4Wait for the Talk Permit Tone to finish (if enabled),
and speak clearly into the microphone.
Making and Receiving Calls in Connect...
167
English
Making a Multi-group Call
This feature allows you to transmit to all users on
multiple groups. Your radio must be programmed to
allow you to use this feature.
Note: Users on the groups cannot respond to a Multi-
group Call.
1Turn the Channel Selector Knob to select the
Multi-group alias or ID.
2Press the PTT button to make the call.
The LED lights up solid green. The display shows
the Multi-group alias or ID.
Wait for the Talk Permit Tone to finish (if enabled)
and speak clearly into the microphone.
Making a Private Call with a One Touch Call Button
Note: Programmable buttons press must be initiated
from the Home screen.
The One Touch Call feature allows you to easily
make a Private Call to a pre-defined Private Call alias
or ID. This feature can be assigned to a short or long
programmable button press.
You can ONLY have one alias or ID assigned to a
One Touch Call button. Your radio can have multiple
One Touch Call buttons programmed.
1Press the programmed One Touch Call button to
make a Private Call to the pre-defined Private Call
alias or ID.
2Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
3Press the PTT button to make the call.
The LED lights up solid green.
The display shows the Private Call alias or ID.
4Wait for the Talk Permit Tone to finish (if enabled)
and speak clearly into the microphone.
5Release the PTT button to listen.
When the target radio responds, the LED blinks
green.
If there is no voice activity for a predetermined
period of time, the call ends.
Making a Call with the Programmable Manual Dial
Button
Making and Receiving Calls in Connect...
168
English
Making a Private Call
1Press the programmed Manual Dial button to
enter into the Manual Dial screen.
The display shows Number:.
2Use the keypad to enter a subscriber alias or
Private ID.
3Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
4Press the PTT button to make the call.
The LED lights up solid green. The Private Call
icon appears in the top right corner. The first text
line shows the subscriber alias. The second text
line displays the call status.
5Wait for the Talk Permit Tone to finish (if enabled)
and speak clearly into the microphone.
6Release the PTT button to listen.
When the target radio responds, the LED blinks
green.
If there is no voice activity for a predetermined
period of time, the call ends. You hear a short
tone. The display shows Call Ended.
Making and Receiving Calls in Connect...
169
English
Advanced Features in Connect Plus
Mode
Auto Fallback
Auto Fallback is a system feature that allows you to
continue to make and receive non-emergency calls
on the selected Group Contact in the event of certain
types of Connect Plus system failures.
If one of these failures occurs, your radio attempts to
roam to a different Connect Plus site. This search
process may result in your radio finding an operable
Connect Plus site, or it may result in your radio finding
a “Fallback Channel” (if your radio is enabled for Auto
Fallback). A Fallback Channel is a repeater that is
normally part of an operable Connect Plus site, but is
currently unable to communicate with either its site
controller or the Connect Plus network. In Fallback
mode, the repeater operates as a “stand-alone” digital
repeater. Auto Fallback Mode supports non-
emergency Group Calls only. No other call types are
supported in Fallback Mode.
Indications of Auto Fallback Mode
When your radio is using a Fallback channel, you
hear the intermittent “Fallback Tone” approximately
once every 15 seconds (except while transmitting).
The display periodically shows a brief message,
“Fallback Channel”. Your radio only permits PTT on
the selected Group Contact (Group Call, Multigroup
Call, or Site All Call). It does not allow you to make
other types of calls.
Making/Receiving Calls in Fallback Mode
Note:
Calls are heard only by radios that are monitoring the
same Fallback channel and selected to the same
Group. Calls are not networked to other sites or other
repeaters.
Emergency voice calls or Emergency Alerts are not
available in Fallback mode. If you press the
emergency button in Fallback mode, the radio
provides an invalid key press tone. Display-equipped
radios also show the message, “Feature not
available”.
Private (radio to radio) calls are not available in
Fallback mode. If you attempt a call to a private
contact, you will receive a denial tone. At this point
Advanced Features in Connect Plus...
170
English
you should select a desired group contact. Other non-
supported calls include Remote Monitor, Call Alert,
Radio Check, Radio Enable, Radio Disable, Text
messaging, Location Updates, and packet data calls.
Enhanced Traffic Channel Access (ETCA) is not
supported in Auto Fallback mode. If two or more radio
users press PTT at the same time (or at almost the
same time), it is possible that both radios transmit
until PTT is released. In this event, it is possible that
none of the transmissions will be understood by
receiving radios.
Making calls in Fallback mode is similar to normal
functioning. Simply select the group contact you wish
to use (using the radio’s normal channel selection
method), and then press the PTT to start your call. It
is possible that the channel may be in use already by
another group. If the channel is in use, you receive a
busy tone and the display will say “Channel Busy”.
You may select Group, Multi-group or Site All Call
contacts using your radio’s normal channel selection
method. While the radio is operating on the Fallback
Channel, the Multigroup operates just like other
Groups. It is only heard by radios that are currently
selected to the same Multi-group. Enhanced Privacy
is supported in Fallback mode.
Returning to Normal Operation
If the site returns to normal trunking operation while
you are in range of your Fallback repeater, your radio
automatically exits Auto Fallback mode. You hear a
registration “beep” when the radio successfully
registers. If you are in the range of an operable site
(that is not in Fallback mode), you may press the
Roam Request button (if programmed for your radio)
to force your radio to search for and register on an
available site. If no other site is available, your radio
returns to Auto Fallback mode after searching is
complete. If you drive out of coverage of your
Fallback repeater, your radio enters Search mode
(display indicates “Searching”).
Radio Check
If enabled, this feature allows you to determine if
another radio is active in a system without disturbing
the user of that radio. No audible or visual notification
is shown on the target radio.
Sending a Radio Check
1Access the Radio Check feature.
Advanced Features in Connect Plus...
171
English
Radio Control Steps
Programmed
Radio Check
button
1Press the programmed
Radio Check button.
2 or to the required
subscriber alias or ID and
press to select.
Menu 1 to access the menu.
2 or to Contacts and
press to select.
3 or to the required
subscriber alias or ID and
press to select.
4 or to Radio Check
and press to select.
The display shows the Target Alias, indicating the
request is in progress. The LED lights up solid
green.
2Wait for acknowledgement.
If the target radio is active in the system, a tone
sounds and the display briefly shows Target
Radio Available.
If the target radio is not active in the system, a
tone sounds and the display briefly shows Target
Radio Not Available.
Radio returns to the subscriber alias or ID screen.
Remote Monitor
Use the Remote Monitor feature to turn on the
microphone of a target radio (subscriber alias or IDs
only). No audible or visual indication is given to the
target radio. You can use this feature to monitor,
remotely, any audible activity surrounding the target
radio.
Your radio must be programmed to allow you to use
this feature.
Initiating Remote Monitor
Note: Remote Monitor automatically stops after a
programmed duration or when there is any user
operation on the target radio.
1Access the Remote Monitor feature.
Advanced Features in Connect Plus...
172
English
Radio Control Steps
Programmed
Remote
Monitor
Button
1Press the programmed
Remote Monitor button.
2 or to the required
subscriber alias or ID and
press to select.
Menu 1 to access the menu.
2 or to Contacts and
press to select.
3 or to the required
subscriber alias or ID and
press to select.
4 or to Manual Dial
and press to select.
5 or to Remote Mon.
and press to select.
The display shows the Target Alias, indicating the
request is in progress. The LED lights up solid
green.
2Wait for acknowledgement.
If successful, a positive indicator tone sounds and
the display shows Rem. Monitor Successful.
Your radio starts playing audio from the monitored
radio for a programmed duration and display
shows Rem. Monitor. Once the timer expires, the
radio sounds an alert tone and the LED turns off.
If unsuccessful, the radio sounds a negative
indicator tone the display shows Rem. Monitor
Failed.
Scan
This feature allows your radio to monitor and join calls
for groups/channels defined in a pre-programmed
scan list. When scan is enabled, the scan icon
appears on the status bar and the LED blinks green
and yellow.
Starting and Stopping Scan
Note: This procedure turns the Scan feature On or
Off for all Connect Plus zones with the same Network
Advanced Features in Connect Plus...
173
English
ID as your currently selected zone. It is important to
note that even when the Scan feature is turned on via
this procedure, scan may still be disabled for some
(or all) groups on your scan list. See Editing the Scan
List on page 175 for more information.
You can start and stop scanning by pressing the
programmed Scan button OR follow the procedure
described next.
1 to access the menu.
2 or to Scan and press to select.
3 or to Turn On or Turn Off and press
to select.
—The display shows Scan On if scan is disabled.
—The display shows Scan Off if scan is
enabled.
Responding to a Transmission During a Scan
During scanning, your radio stops on a channel/group
where activity is detected. The radio stays on that
channel for a programmed time period known as
“hang time”.
1Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
2Press the PTT button during hang time.
The LED lights up solid green.
3Wait for the Talk Permit Tone to finish (if enabled),
and speak clearly into the microphone.
4Release the PTT button to listen.
If you do not respond within the hang time, the
radio returns to scanning other groups.
User Configurable Scan
If the Edit List menu is enabled, a user is able to Add
and Remove the scan members from the Add
Member menu. A Scan List member must be a
regular Group Contact (i.e. not Multi-group or Site All
Call/Network Wide All Call) that is currently assigned
to a Channel Selector position in a Connect Plus
Zone with the same Network ID as the currently
selected Zone. The Talkgroup's Alias must also not
match any Talkgroup that is already included in the
current Zone's Scan List.
Advanced Features in Connect Plus...
174
English
Scan can be turned on or off from the menu or by
pressing a programmed Scan On/Off button.
This feature functions only when the radio is not
currently involved in a call. If you are presently
listening to a call, your radio cannot scan for other
group calls, and is therefore unaware they are in
progress. Once your call is finished, your radio
returns to the control channel time slot and is able to
scan for groups that are in the scan list.
Turning Scan On or Off
Note: This procedure turns the Scan feature On or
Off for all zones with the same Network ID as your
currently selected zone. It is important to note that
even when the Scan feature is turned on via this
procedure, scan may still be disabled for some (or all)
groups on your scan list. See the next section for
more information.
If Scan is turned on, the Scan icon appears on your
display. When Scan is on and you are not
participating in a call, the LED blinks green and
yellow.
The procedure for turning Scan on or off depends on
how your radio is programmed. If programmed with a
Scan On/Off button, use the button to toggle the
feature on or off. If your radio has been programmed
so that Scan can be turned on or off via the menu,
follow the procedure described next.
1 to access the menu.
2 or to Scan and press to select.
3 or to Turn On or Turn Off and press
to select.
—The display shows Scan On momentarily if
scan is disabled.
—The display shows Scan Off momentarily if
scan is enabled.
Editing the Scan List
Note: If the scan list entry happens to be the radio’s
currently selected group, the radio listens for activity
on this group regardless of whether the list entry
currently shows a check mark or not. Whenever a
radio is not in a call, the radio listens for activity on its
Selected Group, Multigroup, the Site All Call, and its
Default Emergency Revert Group (if configured for
one). This operation cannot be disabled.
Advanced Features in Connect Plus...
175
English
Your scan list determines which groups can be
scanned. The list is created when your radio is
programmed. If your radio has been programmed to
allow you to edit the scan list, you can selectively
enable/disable scan for individual groups on the list.
However, you cannot delete groups from the list or
add groups to the list. This can only be done through
radio programming.
1 to access the menu.
2 or to View/Edit List and press to
select.
3 or to the desired Group name.
If a check mark precedes the Group name, then
scan is currently enabled for this Group.
If there is no check mark preceding the Group
name, then scan is currently disabled for this
Group.
4 to select the desired Group.
The display shows Enable if scan is currently
disabled for the Group.
The display shows Disable if scan is currently
enabled for the Group.
5Select the displayed option (Enable or Disable)
and press to select.
Depending on which option was selected, the
radio momentarily displays Scan Enabled or Scan
Disabled as confirmation.
The radio displays the Zone scan list again. If scan
was enabled for the Group, the check mark displays
before the Group name. If scan was disabled for the
Group, the check mark is removed before the Group
name.
Understanding Scan Operation
Note: If you scan into a call for a group that is not
assigned to a channel position in your currently
selected zone and you miss the call’s Hang Time, you
have to switch to the proper zone and then select the
group’s channel position to talk back to that group.
There are some circumstances in which you can miss
calls for groups that are in your scan list. When you
miss a call for one of the following reasons, this does
not indicate a problem with your radio. This is a
normal scan operation for Connect Plus.
Advanced Features in Connect Plus...
176
English
— Scan feature is not turned on (check for the scan
icon on the display).
— Scan list member has been disabled via the menu
(see Editing the Scan List on page 175).
— You are participating in a call already.
— No member of the scanned group is registered at
your site (Multisite systems only).
Contacts Settings
Note:
You can add, or edit subscriber IDs for Digital
Contacts. Deleting subscriber IDs can only be
performed by your dealer.
If the Privacy feature is enabled on a channel, you
can make a privacy-enabled voice call on that
channel. Only target radios with the same Privacy
Key OR the same Key Value and Key ID as your
radio are able to unscramble the transmission.
Contacts provide “address-book” capabilities on your
radio. Each entry corresponds to an alias or ID that
you use to initiate a call.
Each zone provides a Contact List with up to 100
contacts. The following contact types are available:
— Private Call
— Group Call
— Multigroup Call
— All Call Voice
— All Call Text†
— Dispatch Call
The Dispatch Call contact type is used to send a text
message to a dispatcher PC through a third-party
Text Message Server.
Making a Private Call from Contacts
1 to access the menu.
2 or to Contacts and press to select.
The entries are alphabetically sorted.
3Use one of the steps described next to select the
required subscriber alias or ID:
— select the subscriber alias or ID directly
— or to the required subscriber alias or
ID and press to select.
—use the Manual Dial menu
Advanced Features in Connect Plus...
177
English
— or to Manual Dial and press to
select.
— If there was previously dialed ID, the ID
appears along with a blinking cursor. Use
the keypad to edit/enter the ID. Press to
select.
4Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
5Press the PTT button to make the call.
The LED lights up solid green. .
6Wait for the Talk Permit Tone to finish (if enabled),
and speak clearly into the microphone.
7Release the PTT button to listen.
When the target radio responds, the LED blinks
green and the display shows the transmitting
user's ID.
If there is no voice activity for a predetermined
period of time, the call ends.
You hear a short tone. The display shows Call
Ended.
Making a Call Alias Search
You can also use alias or alphanumeric search to
retrieve the required subscriber alias.
This feature is only applicable while in Contacts.
1 to access the menu.
2 or to Contacts and press to select.
The entries are alphabetically sorted.
3Key in the first character of the required alias, and
then press or to locate the required alias.
4Use the keypad to type the required alias.
Press to move one space to the left. Press to
move one space to the right. Press the key
to delete any unwanted characters. Long press
to change text entry method.
5Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
6Press the PTT button to make the call.
Advanced Features in Connect Plus...
178
English
The LED lights up solid green. The display shows
the destination alias.
7Wait for the Talk Permit Tone to finish (if enabled),
and speak clearly into the microphone.
8Release the PTT button to listen.
When the target radio responds, the LED blinks
green.
9If the Channel Free Indication feature is enabled,
you hear a short alert tone the moment the
transmitting radio releases the PTT button,
indicating the channel is free for you to respond.
Press the PTT button to respond.
If there is no voice activity for a predetermined
period of time, the call ends.
The display shows Call Ended.
Adding a New Contact
1 to access the menu.
2 or to Contacts and press to select.
3 or to New Contact and press to
select.
4Use the keypad to enter the contact number and
press to confirm.
5Use the keypad to enter the contact name and
press to confirm.
6If adding a Radio Contact, or to the
required ringer type and press to select.
The radio sounds a positive indicator tone and the
display shows Contact Saved.
Call Indicator Settings
Activating and Deactivating Call Ringers for Call Alert
You can select, or turn on or off ringing tones for a
received Call Alert.
1 to access the menu.
Advanced Features in Connect Plus...
179
English
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Tones/Alert and press to
select.
5 or to Call Ringers and press to
select.
6 or to Call Alert and press to select.
The current tone is indicated by a .
7 or to the required tone and press to
select.
You can also use or to change the selected
option.
appears beside selected tone.
Activating and Deactivating Call Ringers for Private
Calls
You can turn on or off the ringing tones for a received
Private Call.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Tones/Alerts and press to
select.
5 or to Call Ringers and press to
select.
6 or to Private Call and press to
select.
You can also use or to change the selected
option.
Advanced Features in Connect Plus...
180
English
7Press to enable/disable the Private Call
ringing tones.
The display shows beside Enabled, if Private
Call ringing tones are enabled.
The disappears from beside Enabled, if Private
Call ringing tones are disabled.
Activating and Deactivating Call Ringers for Text
Message
You can turn on or off the ringing tones for a received
Text Message.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Tones/Alerts and press to
select.
5 or to Call Ringers and press to
select.
6 or to Text Message and press to
select.
The current tone is indicated by a .
7 or to the required tone and press to
select.
appears beside selected tone.
Assigning Ring Styles
You can program your radio to sound one of ten
predefined ringing tones when receiving a Call Alert
or a Text Message from a particular contact.
The radio sounds out each ring style as you navigate
through the list.
1 to access the menu.
2 or to Contacts and press to select.
The entries are alphabetically sorted.
Advanced Features in Connect Plus...
181
English
3 or to the required alias or ID and press
to select.
4 or to View/Edit and press to select.
5 or to Ringer and press to select.
6 or to required ring style and press to
select.
A indicates the current selected tone.
7 or to the required tone and press to
select. appears beside selected tone.
The display shows Contact Saved.
Escalating Alarm Tone Volume
You can program your radio to continually alert you
when a radio call remains unanswered. This is done
by automatically increasing the alarm tone volume
over time. This feature is known as Escalert.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Tones/Alerts and press to
select.
5 or to Escalert and press to select.
You can also use or to change the selected
option.
6Press to enable/disable the Escalert.
The display shows beside Enabled.
The disappears from beside Enabled.
Call Log Features
Your radio keeps track of all recent outgoing,
answered, and missed Private Calls. Use the call log
feature to view and manage recent calls.
Advanced Features in Connect Plus...
182
English
You can perform the following tasks in each of your
call lists:
— Delete
— View Details
Viewing Recent Calls
The lists are Missed, Answered, and Outgoing.
1 to access the menu.
2 or to Call Log and press to select.
3 or to preferred list and press to select.
The display shows the most recent entry at the top
of the list.
4 or to view the list.
Press the PTT button to start a Private Call with
the current selected alias or ID.
Deleting a Call from a Call List
1 to access the menu.
2 or to Call Log and press to select.
3 or to the required list and press to
select.
When you select a call list and it contains no
entries, the display shows List Empty, and
sounds a low tone if Keypad Tones are turned on
(see Turning Keypad Tones On or Off on page
129).
4 or to the required alias or ID and press
to select.
5 or to Delete Entry? and press to
select.
6Do one of the following:
—Press to select Yes to delete the entry. The
display shows Entry Deleted.
— or to No, and press the button to
return to the previous screen.
Advanced Features in Connect Plus...
183
English
Viewing Details from a Call List
1 to access the menu.
2 or to Call Log and press to select.
3 or to the required list and press to
select.
4 or to the required alias or ID and press
to select.
5 or to View Details and press to
select.
Display shows details.
Call Alert Operation
Call Alert paging enables you to alert a specific radio
user to call you back when they are able to do so.
This feature is applicable for subscriber aliases or IDs
only and is accessible through the menu via Contacts
or manual dial.
Receiving and Responding to a Call Alert
When you receive a Call Alert page, you see the
notification list listing a Call Alert with the alias or ID of
the calling radio on the display.
When you hear a repetitive tone and the LED
blinks yellow and green, do one of the following:
— Press the PTT button while the display still
shows the Call Alert in the Notification List to
respond with a Private Call.
—Press to exit the Notification List. The
alert is moved to the Missed Call Log.
See Notification List on page 217 for details
about the Notification List.
See Call Log Features on page 182 for details
about the Missed Call List.
Making a Call Alert from the Contact List
1 to access the menu.
2 or to Contacts and press to select.
Advanced Features in Connect Plus...
184
English
3Use one of the steps described next to select the
required subscriber alias or ID:
— select the subscriber alias or ID directly
— or to the required subscriber alias or
ID and press to select.
—use the Manual Dial menu
— or to Manual Dial and press to
select.
—The first line of the display shows Radio
Number: , the second line of the display
shows a blinking cursor. Enter the
subscriber ID you want to page and press
.
4 or to Call Alert and press to select.
The display shows Call Alert: <Subscriber
Alias or ID>Call Alert and the subscriber
alias or ID, indicating that the Call Alert has been
sent.
The LED lights up solid green when your radio is
sending the Call Alert.
If the Call Alert acknowledgement is received, the
display shows Call Alert Successful.
If the Call Alert acknowledgement is not received,
the display shows Call Alert Failed.
Making a Call Alert with the One Touch Access Button
— Press the programmed One Touch Access
button to make a Call Alert to the predefined alias
or ID.
The display shows Call Alert and the
subscriber alias or ID, indicating that the Call Alert
has been sent.
The LED lights up solid green when your radio is
sending the Call Alert.
If the Call Alert acknowledgement is received, the
display shows Call Alert Successful.
If the Call Alert acknowledgement is not received,
the display shows Call Alert Failed.
Emergency Operation
Note:
If your radio is programmed for “Silent” or “Silent with
voice” emergency initiation, in most cases it
Advanced Features in Connect Plus...
185
English
automatically exits silent operation after the
Emergency Call or Emergency Alert is finished. The
exception to this rule is when “Emergency Alert” is the
configured Emergency Mode and “Silent” is the
configured Emergency Type. If your radio is
programmed in this manner, the silent operation
continues until you cancel silent operation by
pressing PTT or the button configured for
“Emergency Off”.
Emergency voice calls and Emergency Alerts are not
supported when operating in Connect Plus Auto
Fallback mode. For more information see the Auto
Fallback on page 170.
An Emergency Alert is used to indicate a critical
situation. You can initiate an Emergency at any time
on any screen display, even when there is activity on
the current channel. Pressing the Emergency button
initiates the programmed Emergency mode. The
programmed Emergency mode may also be initiated
by triggering the optional Man Down feature. The
Emergency feature may be disabled in your radio.
Your dealer can set the duration of a button press for
the programmed Emergency button, except for long
press, which is similar with all other buttons:
— Short press – Between 0.05 seconds and 0.75
seconds.
— Long press – Between 1.00 second and 3.75
seconds.
The Emergency button is assigned with the
Emergency On/Off feature. Check with your dealer for
the assigned operation of the Emergency button.
— If short Emergency button short press is assigned
to Emergency On, then Emergency button long
press is assigned to Emergency Off.
— If Emergency button short press is assigned to
Emergency On, then Emergency button short
press is assigned to Emergency Off.
When your radio is selected to a Connect Plus zone,
it supports three Emergency modes:
—Emergency Call – You must press the PTT button
to talk on the assigned emergency time slot.
—Emergency Call with Voice to Follow – For the
first transmission on the assigned emergency time
slot, the microphone is automatically unmuted and
you may talk without pressing the PTT button. The
microphone stays “hot” in this fashion for a time
period programmed into the radio. For subsequent
Advanced Features in Connect Plus...
186
English
transmissions in the same Emergency call, you
must press the PTT button.
—Emergency Alert – An Emergency Alert is not a
voice call. It is an emergency notification that is
sent to radios that are configured to receive these
alerts. The radio sends an emergency alert via the
control channel of the currently registered site.
The Emergency Alert is received by radios in the
Connect Plus network that are programmed to
receive them (no matter which network site they
are registered to).
Only ONE of the Emergency Modes can be assigned
to the Emergency button per zone. In addition, each
Emergency mode has the following types:
— Regular – Radio initiates an Emergency and
shows audio and/or visual indicators.
— Silent – Radio initiates an Emergency without any
audio or visual indicators. The radio will suppress
all audio or visual indications of the Emergency
until you press the PTT button to start a voice
transmission.
— Silent with Voice – The same as Silent operation,
except that the radio will also unmute for some
voice transmissions.
Receiving an Incoming Emergency
Your radio may be programmed to sound an alert
tone and also display information about the incoming
Emergency. If so programmed, upon receiving the
incoming Emergency, the display shows the
Emergency Details screen with the emergency icon,
the Alias or ID of the radio that requested the
Emergency, the Group Contact being used for the
Emergency, and one additional line of information.
The additional information is the name of the zone
that contains the Group Contact.
At the present time, the radio displays only the most
recently decoded Emergency. If a new Emergency is
received before the prior Emergency is cleared, the
details for the new Emergency replace the details of
the previous Emergency.
Depending on how your radio has been programmed,
the Emergency Details screen (or Alarm List screen)
will stay on your radio’s display even after the
Emergency ends. You can save the emergency
details to the Alarm List, or you can delete the
emergency details as described in the following
sections.
Advanced Features in Connect Plus...
187
English
Saving the Emergency Details to the Alarm List
Saving the emergency details to the Alarm List allows
you to view the details again at a later time by
selecting Alarm List from the Main Menu.
While the Emergency Details (or Alarm List)
screen is displayed, press .
The Exit Alarm List screen displays.
Do one of the following.
—Select Yes and press to save the
emergency details to the Alarm List, and to exit
the Emergency Details (or Alarm List) screen.
—Select No and press to return to the
Emergency Details (or Alarm List) screen.
Deleting the Emergency Details
While the Emergency Details screen is displayed,
press .
The Delete screen displays.
Do one of the following.
—Select Yes and press to delete the
emergency details.
—Select No and press to return to the
Emergency Details screen.
Responding to an Emergency Call
Note: If you do not respond to the Emergency Call
within the time allotted for the Emergency Call Hang
Time, the Emergency call will end. If you want to
speak to the group after the Emergency Call Hang
Time expires, you must first select the channel
position assigned to the group (if not already
selected). Then, press PTT to start a non-Emergency
Call to the group.
1When receiving an Emergency Call, press any
button to stop all Emergency Call received
indications.
2Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
3Press the PTT button to initiate a voice
transmission on the Emergency group.
Advanced Features in Connect Plus...
188
English
All radios that are monitoring this group hear your
transmission.
4Wait for the Talk Permit Tone to finish (if enabled)
and speak clearly into the microphone.
The LED lights up green.
5Release the PTT button to listen.
When the emergency initiating radio responds, the
LED blinks green, the LED blinks green, the radio
unmutes and the response sounds through the
radio's speaker.You see the Group Call icon, the
group ID, and transmitting radio ID on your
display.
Responding to an Emergency Alert
Note: The Group contact used for the Emergency
Alert should not be used for voice communication.
This could prevent other radios from sending and
receiving Emergency Alerts on the same group.
An Emergency Alert from a radio indicates that the
user is in an urgent situation. You may respond to the
alert by initiating a private call to the radio who
declared the emergency, initiating a group call to a
designated talk group, sending the radio a Call Alert,
initiating a Remote Monitor of that radio, etc. The
proper response is determined by your organization
and the individual situation.
Initiating an Emergency Call
Note:
If your radio is set to Silent, it does not display any
audio or visual indicators during Emergency mode
until you press the PTT button to initiate a voice
transmission.
If your radio is set to Silent with Voice, it does not
initially display any audio or visual indicators that the
radio is in Emergency mode. However, your radio un-
mutes for the transmissions of radios responding to
your emergency. The emergency indicators only
appear once you press the PTT button to initiate a
voice transmission from your radio.
For both “Silent” and “Silent with Voice” operation, the
radio automatically exits silent operation after the
Emergency Call is finished.
1Press the programmed Emergency button.
2Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
Advanced Features in Connect Plus...
189
English
3Press the PTT button to initiate a voice
transmission on the Emergency group.
When you release the PTT button, the Emergency
call continues for the time allotted for the
Emergency Call Hang Time.
If you press the PTT button during this time, the
Emergency call continues.
Initiating an Emergency Call with Voice to Follow
Your radio must be programmed for this type of
operation.
When enabled for this operation, when you press the
programmed Emergency button, and when your
radio receives the time slot assignment, the
microphone is automatically activated without
pressing the PTT button. This activated microphone
state is also known as “hot mic”. The “hot mic” applies
to the first voice transmission from your radio during
the Emergency call. For subsequent transmissions in
the same Emergency call, you must press the PTT
button.
1Press the programmed Emergency button.
2Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
3The microphone remains active for the “hot mic”
time specified in your radio's codeplug
programming.
During this time, the LED lights up green.
4Press and hold the PTT button to talk longer than
the programmed duration.
Initiating an Emergency Alert
Note: If your radio is programmed for “Silent” or
“Silent with Voice”, it will not provide any audio or
visual indications that it is sending an Emergency
Alert. If programmed for “Silent”, the silent operation
continues indefinitely until you press PTT or the
button configured for “Emergency Off”. If programmed
for “Silent with Voice”, the radio automatically cancels
silent operation when the site controller broadcasts
the Emergency Alert.
Press the orange Emergency button.
Upon transmitting the Emergency Alert to the site
controller, the radio’s display shows the
Advanced Features in Connect Plus...
190
English
Emergency icon, the Group contact used for the
Emergency Alert, and TX Alarm.
Once the Emergency Alert is successfully sent
and is being broadcast for other radios to hear, a
positive indicator tone sounds and the radio’s
display shows Alarm Sent. If the Emergency Alert
is unsuccessful, a negative indicator tone sounds
and the radio displays Alarm Failed.
Exiting Emergency Mode
Note: If the Emergency call ends due to the
expiration of the Emergency Hang Time, but the
emergency condition is not over, press the
Emergency button again to restart the process.
If you initiate an Emergency Alert by pressing the
programmed Emergency button, your radio
automatically exits Emergency mode after receiving a
response from the Connect Plus system.
If you initiate an Emergency call by pressing the
programmed Emergency button, your radio will be
assigned a channel automatically when one becomes
available. Once your radio has transmitted a
message indicating the emergency, you cannot
cancel your Emergency call. However, if you pressed
the button by accident or the emergency no longer
exists, you may wish to say this over the assigned
channel. When you release the PTT button, the
Emergency call is discontinued after the Emergency
Call Hang Time expires.
If your radio was configured for Emergency with Voice
to Follow, use the “hot mic” period to explain your
error, then press and release the PTT button to
discontinue the transmission. The Emergency call is
discontinued after the Emergency Call Hang Time
expires.
Text Message Features
Your radio is able to receive data, for example a text
message, from another radio or a text message
application.
The maximum length of characters for a text
message, including the subject line (seen when
receiving message from a text message application),
is 140.
The radio exits the current screen once the inactivity
timer expires. Any text message in the writing/editing
screen will automatically be saved to the Drafts folder.
Advanced Features in Connect Plus...
191
English
Note: Long press at any time to return to the
Home screen.
Writing and Sending a Text Message
1Access the Text Message feature.
Radio
Controls
Steps
Program
med Text
Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
2 or to Messages and
press to select.
2 or to Compose and press to select.
A blinking cursor appears.
3Use the keypad to type your message.
Press to move one space to the left. Press or
the key to move one space to the right.
Press the key to delete any unwanted
characters. Long press to change text entry
method.
4Press once message is composed.
5If you are sending the message, select the
recipient by
— or to the required alias or ID and press
to select.
— or to Manual Dial, and press to
select. The first line of the display shows
Number:. The second line of the display shows
a blinking cursor. Key in the subscriber alias or
ID and press .
The display shows Sending Message, confirming
your message is being sent.
Advanced Features in Connect Plus...
192
English
If the message is sent successfully, a tone sounds
and the display shows Message Sent.
If the message cannot be sent, a low tone sounds
and the display shows Message Send Failed.
If the text message fails to send, the radio returns
you to the Resend option screen (see Managing
Fail-to-Send Text Messages on page 197).
Sending a Quick Text Message
Your radio supports a maximum of 10 Quick Text
messages as programmed by your dealer.
While Quick Text messages are predefined, you can
edit each message before sending it.
1Access the Text Message feature.
Radio
Controls
Steps
Program
med Text
Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
Radio
Controls
Steps
2 or to Messages and
press to select.
2 or to Quick Text and press to select.
3 or to the required Quick Text and press
to select.
A blinking cursor appears.
4Use the keypad to edit the message, if required.
Press to move one space to the left. Press or
the key to move one space to the right.
Press the key to delete any unwanted
characters. Long press to change text entry
method.
5Press once message is composed.
Advanced Features in Connect Plus...
193
English
6Depending on whether you want to send, save, re-
edit, or delete the newly composed message, do
one of the following.
— or to Send, and press to send the
message.
— or to Save, and press to save the
message to the Drafts folder.
— to edit the message.
— again to choose between deleting the
message or saving it to the Drafts folder.
7If you are sending the message, select the
recipient by
— or to the required alias or ID and press
to select.
— or to Manual Dial, and press to
select. The first line of the display shows
Number:. The second line of the display shows
a blinking cursor. Key in the subscriber alias or
ID and press .
The display shows Sending Message, confirming
your message is being sent.
If the message is sent successfully, a tone sounds
and the display shows Message Sent.
If the message cannot be sent, a low tone sounds
and the display shows Message Send Failed.
If the text message fails to send, the radio returns
you to the Resend option screen (see Managing
Fail-to-Send Text Messages on page 197).
Sending a Quick Text Message with the One Touch
Access Button
— Press the programmed One Touch Access
button to send a predefined Quick Text message
to a predefined alias or ID.
The display shows Sending Message, confirming
your message is being sent.
If the message is sent, a tone sounds and the
display shows Message Sent.
If the message cannot be sent, a low tone sounds
and the display shows Message Send Failed.
Advanced Features in Connect Plus...
194
English
If the text message fails to send, the radio returns
you to the Resend option screen (see Managing
Fail-to-Send Text Messages on page 197).
Accessing the Drafts Folder
You can save a text message to send it at a later
time.
If a PTT button press or a mode change causes the
radio to exit the text message writing/editing screen
while you are in the process of writing or editing a text
message, your current text message is automatically
saved to the Drafts folder.
The most recent saved text message is always added
to the top of the Drafts list.
The Drafts folder stores a maximum of ten (10) last
saved messages. When the folder is full, the next
saved text message automatically replaces the oldest
text message in the folder.
Note:
Long press at any time to return to the Home
screen.
Viewing a Saved Text Message
1Access the Text Message feature.
Radio Controls Steps
Programmed
Text Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
2 or to Messages
and press to select.
2 or to Drafts and press to select.
3 or to the required message and press
to select.
Editing and Sending a Saved Text Message
1Press again while viewing the message.
2 or to Edit and press to select.
Advanced Features in Connect Plus...
195
English
A blinking cursor appears.
3Use the keypad to type your message.
Press to move one space to the left. Press or
the key to move one space to the right.
Press the key to delete any unwanted
characters. Long press to change text entry
method.
4Press once message is composed.
5Select the message recipient by
— or to the required alias or ID and press
to select.
— or to Manual Dial, and press to
select. The first line of the display shows
Number:. The second line of the display shows
a blinking cursor. Key in the subscriber alias or
ID and press .
The display shows Sending Message, confirming
your message is being sent.
If the message is sent successfully, a tone sounds
and the display shows Message Sent.
If the message cannot be sent, a low tone sounds
and the display shows Message Send Failed.
If the text message cannot be sent, it is moved to
the Sent Items folder and marked with a Send
Failed icon.
Deleting a Saved Text Message from Drafts
1Access the Text Message feature.
Radio Controls Steps
Programmed
Text Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
2 or to Messages
and press to select.
2 or to Drafts and press to select.
Advanced Features in Connect Plus...
196
English
3 or to the required message and press
to select.
4Press again while viewing the message.
5 or to Delete and press to delete the
text message.
Managing Fail-to-Send Text Messages
You can select one of the following options while at
the Resend option screen:
— Resend
— Forward
— Edit
Resending a Text Message
—Press to resend the same message to the
same subscriber/group alias or ID.
If the message is sent successfully, a tone sounds
and the display shows positive mini notice.
If the message cannot be sent, the display shows
negative mini notice.
Forwarding a Text Message
Select Forward to send the message to another
subscriber/ group alias or ID.
1 or to Forward and press to select.
2— or to the required alias or ID and press
to select.
— or to Manual Dial, and press to
select. The first line of the display shows
Number:. The second line of the display shows
a blinking cursor. Key in the subscriber alias or
ID and press .
The display shows Sending Msssage, confirming
your message is being sent.
If the message is sent successfully, a tone sounds
and the display shows Message Sent.
If the message cannot be sent, a low tone sounds
and the display shows Message Send Failed.
Advanced Features in Connect Plus...
197
English
Editing a Text Message
Select Edit to edit the message before sending it.
Note: If a subject line is present (for messages
received from a text message application), you
cannot edit it.
1 or to Edit and press to select.
A blinking cursor appears.
2Use the keypad to edit your message.
Press to move one space to the left. Press or
the key to move one space to the right.
Press the key to delete any unwanted
characters. Long press to change text entry
method.
3Press once message is composed.
4Depending on whether you want to send, save, re-
edit, or delete the newly composed message, do
one of the following.
— or to Send, and press to send the
message.
— or to Save, and press to save the
message to the Drafts folder.
— to edit the message.
— again to choose between deleting the
message or saving it to the Drafts folder.
5If you are sending the message, select the
recipient by
— or to the required alias or ID and press
to select.
— or to Manual Dial, and press to
select. The first line of the display shows
Number:. The second line of the display shows
a blinking cursor. Key in the subscriber alias or
ID and press .
The display shows Sending Message, confirming
your message is being sent.
Advanced Features in Connect Plus...
198
English
If the message is sent successfully, a tone sounds
and the display shows Message Sent.
If the message cannot be sent, a low tone sounds
and the display shows Message Send Failed.
Managing Sent Text Messages
Once a message is sent to another radio, it is saved
in Sent Items. The most recent sent text message is
always added to the top of the Sent Items list.
The Sent Items folder is capable of storing a
maximum of thirty (30) last sent messages. When the
folder is full, the next sent text message automatically
replaces the oldest text message in the folder.
Note: Long press at any time to return to the
Home screen.
Viewing a Sent Text Message
1Access the Text Message feature.
Radio
Controls
Steps
Program
med Text
Press the programmed Text
Message button.
Radio
Controls
Steps
Message
button
Menu 1 to access the menu.
2 or to Messages and
press to select.
2 or to Sent Items and press to select.
3 or to the required message and press
to select.
A subject line may be shown if the message is
from a text message application.
The icon at the top right corner of the screen
indicates the status of the message (see Sent Item
Icons on page 158).
Sending a Sent Text Message
You can select one of the following options while
viewing a sent text message:
Advanced Features in Connect Plus...
199
English
— Resend
— Forward
— Edit
— Delete
1Press again while viewing the message.
2 or to one of the options described next
and press to select.
Option Steps
Forward Select Forward to send the selected
text message to another subscriber/
group alias or ID (see Forwarding a
Text Message on page 197).
Edit Select Edit to edit the selected text
message before sending it (see
Editing a Text Message on page
198).
Delete Select Delete to delete the text
message.
Option Steps
Resend Select Resend to resend the
selected text message to the same
subscriber/group alias or ID.
The display shows Sending
Message, confirming that the same
message is being sent to the same
target radio.
If the message is sent successfully,
a tone sounds and the display
shows Message Sent.
If the message cannot be sent, a
low tone sounds and the display
shows Message Send Failed.
If the message fails to send, the
radio returns you to the Resend
option screen. Press to resend
the message to the same
subscriber/group alias or ID.
Note: If you exit the message
sending screen while the message
Advanced Features in Connect Plus...
200
English
Option Steps
is being sent, the radio updates the
status of the message in the Sent
Items folder without providing any
indication in the display or via
sound.
Note: If the radio changes mode or
powers down before the status of
the message in Sent Items is
updated, the radio cannot complete
any In- Progress messages and
automatically marks it with a Send
Failed icon.
Note: The radio supports a
maximum of five (5) In-Progress
messages at one time. During this
period, the radio cannot send any
new message and automatically
marks it with a Send Failed icon.
If you exit the message sending screen while the
message is being sent, the radio updates the
status of the message in the Sent Items folder
without providing any indication in the display or
via sound.
If the radio changes mode or powers down before
the status of the message in Sent Items is
updated, the radio cannot complete any In-
Progress messages and automatically marks it
with a Send Failed icon.
The radio supports a maximum of five (5) In-
Progress messages at one time. During this
period, the radio cannot send any new message
and automatically marks it with a Send Failed icon.
Deleting All Sent Text Messages from Sent Items
1Access the Text Message feature.
Radio Controls Steps
Programmed
Text Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
2 or to Messages
and press to select.
Advanced Features in Connect Plus...
201
English
2 or to Sent Items and press to select.
When you select Sent Items and it contains no
text messages, the display shows List Empty,
and sounds a low tone if Keypad Tones are turned
on (see Turning Keypad Tones On or Off on page
129).
3 or to Delete All and press to select.
4Choose one of the following.
— or to Yes and ppress to select. The
display shows positive mini notice.
— or to No and press to return to the
previous screen.
Receiving a Text Message
When your radio receives a message, the display
shows the Notification List with the alias or ID of the
sender and the Message icon.
You can select one of the following options when
receiving a text message:
— Read
— Read Later
— Delete
Reading a Text Message
1 or to Read? and press to select.
Selected message in the Inbox opens.
A subject line may be shown if the message is
from a text message application.
2Do one of the following:
—Press to return to the Inbox.
—Press a second time to reply, forward, or
delete the text message.
Managing Received Text Messages
Use the Inbox to manage your text messages. The
Inbox is capable of storing a maximum of 30
messages.
Text messages in the Inbox are sorted according to
the most recently received.
Advanced Features in Connect Plus...
202
English
Your radio supports the following options for text
messages:
— Reply
— Forward
— Delete
— Delete All
Note: If the channel type (i.e. conventional digital or
Capacity Plus or Linked Capacity Plus) is not a
match, you can only forward, delete, or delete all
Received messages.
Note: Long press at any time to return to the
Home screen.
Viewing a Text Message from the Inbox
1 to access the menu.
2 or to Messages and press to select.
3 or to Inbox and press to select.
4 or toview the messages.
A subject line may be shown if the message is
from a text message application.
5Do one of the following:
—Press to select the current message, and
press again to reply, quick reply, forward,
or delete that message.
—Long press to return to the Home
screen.
Replying to a Text Message from the Inbox
1Access the Text Message feature.
Radio
Controls
Steps
Program
med Text
Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
Advanced Features in Connect Plus...
203
English
Radio
Controls
Steps
2 or to Messages and
press to select.
2 or to Inbox and press to select.
3 or to the required message and press
to select.
A subject line may be shown if the message is
from a text message application.
4Press once more to access the sub-menu.
5Do one of the following:
— or to Reply and press to select.
— or to Quick Reply and press to
select.
A blinking cursor appears.
6Use your keypad to write/edit your message.
7Press once message is composed.
The display shows Sending Message, confirming
your message is being sent.
If the message is sent successfully, a tone sounds
and the display shows Message Sent.
If the message cannot be sent,a low tone sounds
and the display shows Message Send Failed.
If the message cannot be sent, the radio returns
you to the Resend option screen (see Managing
Fail-to-Send Text Messages on page 197).
Deleting a Text Message from the Inbox
1Access the Text Message feature.
Radio Controls Steps
Programmed
Text Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
Advanced Features in Connect Plus...
204
English
Radio Controls Steps
2 or to Messages
and press to select.
2 or to Inbox and press to select.
3 or to the required message and press
to select.
A subject line may be shown if the message is
from a text message application.
4Press once more to access the sub-menu.
5 or to Delete and press to select.
6 or to Yes and press to select.
The display shows Message Deleted, and the
screen returns to the Inbox.
Deleting All Text Messages from the Inbox
1Access the Text Message feature.
Radio Controls Steps
Programmed
Text Message
button
Press the programmed Text
Message button.
Menu 1 to access the menu.
2 or to Messages
and press to select.
2 or to Inbox and press to select.
When you select Inbox and it contains no text
messages, the display shows List Empty, and
sounds a low tone if Keypad Tones are turned on
(see Turning Keypad Tones On or Off on page
129).
3 or to Delete All and press to select.
4 or to Yes and press to select.
The display shows Inbox Cleared.
Advanced Features in Connect Plus...
205
English
Privacy
If enabled, this feature helps to prevent
eavesdropping by unauthorized users on a channel
by the use of a software-based scrambling solution.
The signaling and user identification portions of a
transmission are not scrambled.
Your radio must have privacy enabled on the current
channel selector position to send a privacy-enabled
transmission, although this is not a necessary
requirement for receiving a transmission. While on a
privacy-enabled channel selector position, the radio is
still able to receive clear (unscrambled)
transmissions.
Your radio supports Enhanced Privacy.
To unscramble a privacy-enabled call transmission,
your radio must be programmed to have the same
Key Value and Key ID (for Enhanced Privacy) as the
transmitting radio.
If your radio receives a scrambled call that is of a
different Key Value and Key ID, you hear nothing at
all (Enhanced Privacy).
If the radio has a privacy type assigned, the Home
screen shows the Secure or Unsecure icon, except
when the radio is sending or receiving an Emergency
call or alarm.
The LED lights up solid green while the radio is
transmitting and blinks green rapidly when the radio is
receiving an ongoing privacy-enabled transmission.
You can access this feature by
— Pressing the programmed Privacy button to
toggle privacy on or off.
— Using the Radio Menu as described by the steps
described next.
Note: Some radio models may not offer this Privacy
feature. Check with your dealer or system
administrator for more information.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings or or to
Connect Plus and press to select.
4 or to Enhanced Privacy.
Advanced Features in Connect Plus...
206
English
If the display shows Turn On, press
to enable Privacy. The radio displays a
message confirming your selection.
OR
If the display shows Turn Off, press
to disable Privacy. The radio displays a
message confirming your selection.
If the radio has a privacy type assigned, the
secure or unsecure icon appears on the status
bar, except when the radio is sending or receiving
an Emergency Alert.
Making a Privacy-Enabled (Scrambled) Call
Toggle privacy on using the programmed privacy
button or by using the menu. Your radio must have
the Privacy feature enabled for the currently selected
channel position to send a privacy-enabled
transmission. When privacy is enabled for the
currently selected channel position, all voice
transmissions made by your radio will be scrambled.
This includes Group Call, Multigroup Call, talk-back
during scanned calls, Site All Call, Emergency Call,
and Private Call. Only receiving radios with the same
Key Value and Key ID as your radio will be able to
unscramble the transmission.
Security
You can enable or disable any radio in the system.
For example, you might want to disable a stolen
radio, to prevent the thief from using it, and enable
that radio, when it is recovered.
Note: Performing Radio Disable and Enable is limited
to radios with these functions enabled. Check with
your dealer or system administrator for more
information.
Radio Disable
1Access this feature by
Radio
Controls
Steps
Radio
Disable
button
1Press the programmed Radio
Disable button.
2 or to the required alias or
ID and press to select.
Advanced Features in Connect Plus...
207
English
Radio
Controls
Steps
Radio
menu 1 to access the menu.
2 or to Contacts and
press to select. The entries
are alphabetically sorted.
3Use one of the steps described
next to select the required
subscriber alias or ID
— select the required alias or ID
directly
— or to the required
alias or ID and press
to select.
—use the Manual Dial menu
— or to Manual
Dial and press to
select.
Radio
Controls
Steps
— or to Radio
Number and press to
select.
— The first line of the display
shows Radio Number:.
the second line of the
display shows a blinking
cursor. Use the keypad to
enter the subscriber alias
or ID and press .
4 or to Radio Disable
and press to select.
The display shows Radio Disable: <Target
Alias or ID> and the LED blinks green.
2Wait for acknowledgment.
If successful, a positive indicator tone sounds and
the display shows Radio Disable Successful.
Advanced Features in Connect Plus...
208
English
If not successful, a negative indicator tone sounds
and the display shows Radio Disable Failed.
Radio Enable
1Access this feature by
Radio
Controls
Steps
Radio
Enable
button
1Press the programmed Radio
Enable button.
2 or to the required alias or
ID and press to select.
Radio
menu 1 to access the menu.
2 or to Contacts and press
to select. The entries are
alphabetically sorted.
3Use one of the steps described
next to select the required
subscriber alias or ID
Radio
Controls
Steps
— select the required alias or ID
directly
— or to the required
alias or ID and press to
select.
—use the Manual Dial menu
— or to Manual Dial
and press to select.
— or to Radio
Number and press to
select.
— The first line of the display
shows Radio Number: .
the second line of the
display shows a blinking
cursor. Use the keypad to
enter the subscriber alias
or ID and press .
Advanced Features in Connect Plus...
209
English
Radio
Controls
Steps
4 or to Radio Enable and
press to select.
The display shows Radio Enable: <Subscriber
Alias or ID> and the LED lights up solid green.
2Wait for acknowledgment.
If successful, a positive indicator tone sounds and
the display shows Radio Enable Successful.
If not successful, a negative indicator tone sounds
and the display shows Radio Enable Failed.
Password Lock Features
If enabled, this feature only allows you access your
radio if the correct password is entered upon
powering up.
Accessing the Radio from Password
1Power up your radio.
You hear a continuous tone.
2Do one of the following:
— Enter your current four-digit password with the
radio’s keypad. The display shows . Press
to proceed.
— Enter your current four-digit password. Press
or to edit each digit’s numeric value.
Each digit changes to . Press to move to
next digit. Press to confirm your selection.
You hear a positive indicator tone for every digit
entered. Press to remove the each on the
display. You hear a negative indicator tone, if you
press when the line is empty, or if you press
more than four digits.
If the password is correct, your radio proceeds to
power up. See Powering Up the Radio on page
25.
If the password is incorrect, the display shows
Wrong Password. Repeat Step 2 on page 210.
After the third incorrect password, the display
shows Wrong Password and then, shows Radio
Advanced Features in Connect Plus...
210
English
Locked. A tone sounds and the LED double blinks
yellow.
Note: The radio is unable to receive any call,
including emergency calls, in locked state.
Unlocking the Radio from Locked State
1If your radio was powered down after being in the
locked state, power up the radio.
A tone sounds and the LED double blinks yellow.
The display shows Radio Locked.
2Wait for 15 minutes.
Your radio restarts the 15 minutes timer for locked
state when you power up.
3Repeat Steps 1 on page 210 and 2 on page 210 in
Accessing the Radio from Password on page 210.
Turning the Password Lock On or Off
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Passwd Lock and press to
select.
5Enter the four-digit password.
See Step 2 on page 210 in Accessing the Radio
from Password on page 210.
6Press to proceed.
If the password is incorrect, the display shows
Wrong Password, and automatically returns to the
previous menu.
7If the password entered in the previous step is
correct, press to enable/disable password
lock.
The display shows beside Enabled.
The disappears from beside Enabled.
Advanced Features in Connect Plus...
211
English
Changing the Password
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Passwd Lock and press to
select.
5Enter the four-digit password.
See Step 2 on page 210 in Accessing the Radio
from Password on page 210.
6Press to proceed.
If the password is incorrect, the display shows
Wrong Password, and automatically returns to the
previous menu.
7If the password entered in the previous step is
correct, or to Change Pwd and press
to select.
8Enter a new four-digit password.
See Step 2 on page 210 in Accessing the Radio
from Password on page 210.
9Reenter the previously entered four-digit
password. See Step 2 on page 210 in Accessing
the Radio from Password on page 210.
10 Press to proceed.
If the reentered password matches the new
password entered earlier, the display shows
Password Changed.
If the reentered password does NOT match the
new password entered earlier, the display shows
Passwords Do Not Match.
The screen automatically returns to the previous
menu.
Advanced Features in Connect Plus...
212
English
Bluetooth Operation
This feature allows you to use your radio with a
Bluetooth enabled device (accessory) via a wireless
Bluetooth connection. Your radio supports both
Motorola and COTS (Commercially available Off-The-
Shelf) Bluetooth-enabled devices.
Bluetooth operates within a range of 10 meters (32
feet) line of sight.This is an unobstructed path
between your radio and your Bluetooth-enabled
device.
It is not recommended that you leave your radio
behind and expect your Bluetooth-enabled device to
work with a high degree of reliability when they are
separated.
At the fringe areas of reception, both voice and tone
quality will start to sound “garbled” or “broken”. To
correct this problem, simply position your radio and
Bluetooth-enabled device closer to each other (within
the 10-meter/32 feet defined range) to reestablish
clear audio reception. Your radio’s Bluetooth function
has a maximum power of 2.5 mW (4 dBm) at the 10-
meter/32 feet range.
Your radio can support up to 4 simultaneous
Bluetooth connections with Bluetooth-enabled
devices of unique types. For example, a headset, and
a PTT-Only Device (POD). Multiple connections with
Bluetooth-enabled devices of the same type are not
supported.
Refer to your respective Bluetooth-enabled device’s
user manual for more details on your Bluetooth-
enabled device’s full capabilities.
Turning Bluetooth On and Off
1 to access the menu.
2 or to Bluetooth and press to select.
3 or to My Status and press to select.
The display shows On and Off. The current status
is indicated by a .
4Do one of the following:
— or to On and press to select. The
display shows On and a appears left of the
selected status.
Advanced Features in Connect Plus...
213
English
— or to Off and press to select. The
display shows Off and a appears left of the
selected status.
Finding and Connecting to a Bluetooth Device
Do not turn off your Bluetooth-enabled device or
press during the finding and connecting
operation as this cancels the operation.
1Turn on your Bluetooth-enabled device and place
it in pairing mode. Refer to respective Bluetooth-
enabled device’s user manual.
2On your radio, press to access the menu.
3 or to Bluetooth and press to select.
4 or to Devices and press to select.
5Do one of the following:
— or to the required device and press
to select.
— or to Find Devices to locate available
devices. or to the required device and
press to select.
6 or to Connect and press to select.
Display shows Connecting to <Device>. Your
Bluetooth-enabled device may require additional
steps to complete the pairing. Refer to respective
Bluetooth-enabled device’s user manual.
If successful, the radio display shows <Device>
Connected. A tone sounds and appears besides
the connected device. The Bluetooth Connected icon
appears on the status bar.
If unsuccessful, the radio display shows Connecting
Failed .
Note: If pin code is required, use the same entry
method as Step 2 on page 210 in Accessing the
Radio from Password on page 210.
Advanced Features in Connect Plus...
214
English
Finding and Connecting from a Bluetooth Device
(Discoverable Mode)
Do not turn off your Bluetooth or your radio during the
finding and connecting operation as this may cancel
the operation.
1Turn Bluetooth On.
See Turning Bluetooth On and Off on page 123.
2 to access the menu.
3 or to Bluetooth and press to select.
4 or to Find Me and press to select.
Your radio can now be found by other Bluetooth-
enabled devices for a programmed duration. This
is called Discoverable Mode.
5Turn on your Bluetooth-enabled device and pair it
with your radio.
Refer to respective Bluetooth-enabled device’s
user manual.
Disconnecting from a Bluetooth Device
1On your radio, press to access the menu.
2 or to Bluetooth and press to select.
3 or to Devices and press to select.
4 or to the required device and press to
select.
5 or to Disconnect and press to select.
Display shows Disconnecting from <Device>.
Your Bluetooth-enabled device may require
additional steps to disconnect. Refer to respective
Bluetooth-enabled device’s user manual.
The radio display shows <Device> Disconnected. A
positive indicator tone sounds and disappears
beside the connected device. The Bluetooth
Connected icon disappears on the status bar.
Advanced Features in Connect Plus...
215
English
Switching Audio Route
You can toggle audio routing between internal radio
speaker and external Bluetooth-enabled accessory.
Press the programmed Bluetooth Audio Switch
button.
—A tone sounds and display shows Route Audio
to Radio.
—A tone sounds and display shows Route Audio
to Bluetooth.
Viewing Device Details
1 to access the menu.
2 or to Bluetooth and press to select.
3 or to Devices and press to select.
4 or to the required device and press to
select.
5 or to View Details and press to
select.
Editing Device Name
You can edit the name of available Bluetooth-enabled
devices.
1 to access the menu.
2 or to Bluetooth and press to select.
3 or to Devices and press to select.
4 or to the required device and press to
select.
5 or to Edit Name and press to select.
6Press to move one space to the left. Press to
move one space to the right. Press to delete
Advanced Features in Connect Plus...
216
English
any unwanted characters. Long press to
change text entry method.
A blinking cursor appears. Use the keypad to type
the required zone.
7The display shows Device Name Saved.
Deleting Device Name
You can remove a disconnected device from the list
of Bluetooth-enabled devices.
1 to access the menu.
2 or to Bluetooth and press to select.
3 or to Devices and press to select.
4 or to the required device and press to
select.
5 or to Delete and press to select.
The display shows Device Deleted.
Bluetooth Mic Gain
Allows control of the connected Bluetooth-enabled
device’s microphone gain value.
1 to access the menu.
2 or to Bluetooth and press to select.
3 or to BT Mic Gain and press to
select.
4 or to the BT Mic Gain type and the current
values.
To edit values, press to select.
5 or to increase or to decrease values and
press to select.
Notification List
Your radio has a Notification List that collects all your
“unread” events on the channel, such as unread text
messages, missed calls, and call alerts.
Advanced Features in Connect Plus...
217
English
The Notification icon appears on the status bar when
the Notification List has one or more events.
The list supports a maximum of forty (40) unread
events. When it is full, the next event automatically
replaces the oldest event.
Note: After the events are read, they are removed
from the Notification List.
Accessing the Notification List
1 to access the menu.
2 or to Notification and press to
select.
3 or to the required event and press to
select.
Long press to return to the Home Screen.
Utilities
Turning the Radio Tones/Alerts On or Off
You can enable and disable all radio tones and alerts
(except for the incoming Emergency alert tone) if
needed.
Press the programmed All Tones/Alerts button to
toggle all tones on or off, or follow the procedure
described next to access this feature via the radio
menu.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Tones/Alerts and press to
select.
5 or to All Tones and press to select.
6Press to enable/disable all tones and alerts.
Advanced Features in Connect Plus...
218
English
The display shows beside Enabled.
The disappears from beside Enabled.
Turning Keypad Tones On or Off
You can enable and disable keypad tones if needed.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Tones/Alerts and press to
select.
5 or to Keypad Tones and press to
select.
You can also use or to change the selected
option.
6Press to enable/disable keypad tones.
The display shows beside Enabled.
The disappears from beside Enabled.
Setting the Tone Alert Volume Offset Level
You can adjust the Tone Alert Volume Offset level if
needed. This feature adjusts the volume of the tones/
alerts, allowing it to be higher or lower than the voice
volume.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Tones/Alerts and press to
select.
5 or to Vol. Offset and press to
select.
6 or to the required volume value.
Advanced Features in Connect Plus...
219
English
The radio sounds a feedback tone with each
corresponding volume value.
7Do one of the following:
—Press to keep the required displayed
volume value.
—Press to exit without changing the
current volume offset settings.
— Repeat Step 6 on page 219 to select another
volume value.
Turning the Talk Permit Tone On or Off
You can enable and disable the Talk Permit Tone if
needed.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Tones/Alerts and press to
select.
5 or to Talk Permit and press to
select.
You can also use or to change the selected
option.
6Press to enable/disable the Talk Permit Tone.
The display shows beside Enabled.
The disappears from beside Enabled.
Changing the Display Mode
You can change radio’s display mode between Day
or Night, as needed. This affects the color palette of
the display.
Change the Display Mode
Radio Control Steps
Programmed
Display Mode
Button
Press the programmed Display
Mode button.
Advanced Features in Connect Plus...
220
English
Radio Control Steps
Menu 1 to access the menu.
2 or to Utilities and
press to select.
3 or to Radio
Settings and press to
select.
4 or to Display and
press to select.
The display shows Day
Mode and Night Mode.
Note: You can also use or
to change the selected
option.
5 or to the required
setting and press to
enable. appears besides
selected setting.
Adjusting the Display Brightness
You can adjust radio’s display brightness as needed.
Note: Display brightness cannot be adjusted when
“Auto Brightness” is enabled.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Display and press to select.
5 or to Brightness and press to select.
The display shows a progress bar.
6Decrease display brightness by pressing or
increase the display brightness by pressing .
Select from setting of 1 to 8. Press to confirm
your entry.
Advanced Features in Connect Plus...
221
English
Controlling the Display Backlight
You can enable or disable the radio’s display
backlight as needed. The setting also affects the
Menu Navigation Buttons and keypad backlighting
accordingly.
Press the programmed Backlight button to toggle the
backlight settings, or follow the procedure described
next to access this feature via the radio menu.
The display backlight and keypad backlighting are
automatically turned off if the LED indicator is
disabled (see Turning the LED Indicator On or Off on
page 138).
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Backlight and press to select.
You can also use or to change the selected
option.
5Press to enable/disable the display backlight.
The display shows beside Enabled.
The disappears from beside Enabled.
Locking and Unlocking the Keypad
You can lock your radio’s keypad to avoid inadvertent
key entry.
To lock/unlock your radio’s keypad.
Option Steps
Locking the
Keypad 1 to access the menu.
2 or to Utilities and
press to select.
3 or to Radio Settings
and press to select.
Advanced Features in Connect Plus...
222
English
Option Steps
4 or to Keypad Lock and
press to select.
You can also use or to
change the selected option.
Unlocking
the Keypad Press followed by .
After the keypad is locked, the display shows
Keypad Locked and returns to the Home screen.
After the keypad is unlocked, the display shows
Keypad Unlocked and returns to the Home
screen.
Language
You can set your radio display to be in your required
language.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Languages and press to select.
5 or to the required language and press
to enable. appears beside selected language.
Turning the LED Indicator On or Off
You can enable and disable the LED Indicator if
needed.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to LED Indicator and press to
select.
Advanced Features in Connect Plus...
223
English
5Press to enable/disable the LED Indicator.
The display shows beside Enabled.
The disappears from beside Enabled.
Identifying Cable Type
You can select the type of cable your radio uses.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Cable Type and press to select.
At Step 4, you can also use or to change the
selected option.
5The current cable type is indicated by a
Voice Announcement
This feature enables the radio to audibly indicate the
current Zone or Channel the user has just assigned,
or programmable button press. This audio indicator
can be customized per customer requirements. This
is typically useful when the user is in a difficult
condition to read the content shown on the display.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Voice Announcement and press
to select.
You can also use or to change the selected
option.
5Do one of the following:
Advanced Features in Connect Plus...
224
English
—Press to enable Voice Announcement. The
display shows beside Enabled.
—Press to disable Voice Announcement. The
disappears from beside Enabled.
Wallpaper Mode
Your radio displays the Wallpaper background on
home screen. The user can select from 5 default
wallpapers.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Display and press to select.
5 or to Wallpaper and press to select.
You can also use or to change the selected
option.
Screen Saver Mode
The screen saver feature allows the radio to save
radio battery time. A Screen Saver Pre Duration
is used to track the radio activities before entering
screen saver mode.
Radio starts Screen Saver Pre Duration upon
power up. Radio enters into screen saver mode when
Screen Saver Pre Duration timer expires, the
radio exits screen saver mode and responds to
related transaction normally upon any user input and
over the air transaction.
Radio restarts Screen Saver Pre Duration upon
any user input and over the air transaction. After
being in Screen Saver mode for 5 seconds, radio
enters keypad lock state automatically. When any
audio or Bluetooth accessory is connected, battery
saver mode is enabled, radio enters screen saver
mode.
If there is any user input or over the air transaction,
the radio exits screen saver mode and responds to
user interaction. The Screen Saver Pre Duration
Advanced Features in Connect Plus...
225
English
is restarted and the radio goes back to screen saver
mode when it expires.
Note: The screen saver mode is to help improve
battery life.
Audio Accessory
The audio accessory has two modes: Normal and
Battery Saver mode. When audio accessory is
plugged in and the setting is in Battery Saver Mode,
the radio restarts the timer and goes into screen
saver mode. In this scenario, when there is any user
input (including user input on radio and accessory
attachment/detachment) or when receiving
emergency alarm/call, the radio exits screen saver
mode and responds to user event as normal. The
Screen Saver timer restarts and the radio goes back
to screen saver mode when the time allocated
expires.
Note: This battery saver mode is to improve battery
life. See Screen Saver box SRS for more details in
this mode.
Auto Keypad Lock
You can enable/disable your radio’s auto keypad lock
to avoid inadvertent key entry.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Auto Keypad Lock and press to
select.
5Do one of the following:
—Press to enable Auto Keypad Lock. The
display shows beside Enabled.
—Press to disable Auto Keypad Lock. The
disappears from beside Enabled.
Digital Mic AGC (Mic AGC-D)
This feature controls the your radio's microphone gain
automatically while transmitting on a digital system. It
suppresses loud audio or boosts soft audio to a
preset value in order to provide a consistent level of
audio.
Advanced Features in Connect Plus...
226
English
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
You can also use or to change the selected
option.
4 or to Mic AGC-D and press to select.
5Do one of the following:
—Press to enable Mic AGC-D. The display
shows beside Enabled.
—Press to disable Mic AGC-D. The
disappears from beside Enabled.
Intelligent Audio
Your radio can automatically adjust its audio volume
to overcome background noise in the environment,
inclusive of all stationary and non-stationary noise
sources. This feature is a Receive-only feature and
does not affect Transmit audio.
Note: This feature is not applicable during a
Bluetooth session.
1 to access the menu.
Radio
Control
Steps
Menu 1 to access the menu.
2 or to Radio Settings and
press to select.
3 or to Radio Settings and
press to select.
4 or to Intelligent Audio
and press to select.
Note: You can also use or to
change the selected option.
5Do one of the following:
Advanced Features in Connect Plus...
227
English
Radio
Control
Steps
—Press to enable Intelligent
Audio. The display shows
beside Enabled.
—Press to disable Intelligent
Audio. The disappears from
beside Enabled.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Intelligent Audio and press
to select.
5Do one of the following:
—Press to enable Intelligent Audio. The
display shows beside Enabled.
—Press to disable Intelligent Audio. The
disappears from beside Enabled.
See Accessories on page 245 for recommended
Bluetooth-enabled audio accessories with in-built
Automatic Volume Control for similar performance.
Turning the Acoustic Feedback Suppressor Feature On
or Off
This feature allows you to minimize acoustic feedback
in received calls.
Toggle Acoustic Feedback Suppressor Features
On or Off
Radio Control Steps
Programmed
Acoustic
Feedback
Suppressor
Button
Press the programmed
Acoustic Feedback
Suppressor button.
Menu 1 to access the menu.
Advanced Features in Connect Plus...
228
English
Radio Control Steps
2 or to Utilities and
press to select.
3 or to Radio
Settings and press to
select.
4 or to AF
Suppressor and press
to select.
Note: You can also use or
to change the selected
option.
5Do one of the following:
—Press to enable
Acoustic Feedback
Suppressor. The display
shows beside Enabled.
Radio Control Steps
—Press to disable
Acoustic Feedback
Suppressor. The
disappears from beside
Enabled.
Text Entry Configuration
You can configure the following settings for entering
text on your radio:
— Word Predict
— Word Correct
— Sentence Cap
— My Words
Your radio supports the following text entry methods:
— Numbers
— Symbols
— Predictive or Multi-Tap
— Language (If programmed)
Advanced Features in Connect Plus...
229
English
Note: Press at any time to return to the
previous screen or long press to return to the
Home Screen. The radio exits the current screen
once the inactivity timer expires.
Word Predict
Your radio can learn common word sequences that
you often enter. It then predicts the next word you
may want to use after you enter the first word of a
common word sequence into the text editor.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Text Entry and press to select.
5 or to Word Predict and press to
select.
You can also use or to change the selected
option.
6Do one of the following:
—Press to enable Word Predict. The display
shows beside Enabled.
—Press to disable Word Predict. The
disappears from beside Enabled.
Word Correct
Supplies alternative word choices when the word
entered into the text editor is not recognized by the in-
built dictionary.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Text Entry and press to select.
Advanced Features in Connect Plus...
230
English
5 or to Word Correct and press to
select.
You can also use or to change the selected
option.
6Do one of the following:
—Press to enable Word Correct. The display
shows beside Enabled.
—Press to disable Word Correct. The
disappears from beside Enabled.
Sentence Cap
Automatically enables capitalization for the first letter
in the first word for every new sentence.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Text Entry and press to select.
5 or to Sentence Cap and press to
select.
6Do one of the following:
—Press to enable Sentence Cap. The display
shows beside Enabled.
—Press to disable Sentence Cap. The
disappears from beside Enabled.
Viewing Custom Words
You can add your own custom words into your radio’s
in-built dictionary. Your radio maintains a list to
contain these words.
1 to access the menu.
2 or to Utilities and press to select.
Advanced Features in Connect Plus...
231
English
3 or to Radio Settings and press to
select.
4 or to Text Entry and press to select.
5 or to My Words and press to select.
6 or to List of Words and press to
select.
Display shows the list of custom words.
Editing Custom Word
You can edit the custom words saved in your radio.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Text Entry and press to select.
5 or to My Words and press to select.
6 or to List of Words and press to
select.
Display shows the list of custom words.
7 or to the required word and press to
select.
8 or to Edit and press to select.
9Use the keypad to edit your custom word.
Press to move one space to the left. Press or
the key to move one space to the right.
Press the key to delete any unwanted
characters. Long press to change text entry
method. Press once your custom word is
completed.
The display shows transitional mini notice, confirming
your custom word is being saved.
Advanced Features in Connect Plus...
232
English
If the custom word is saved, a tone sounds and the
display shows positive mini notice.
If the custom word is not saved, a low tone sounds
and the display shows negative mini notice.
Adding Custom Word
You can add your own custom words into your radio’s
in-built dictionary.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Text Entry and press to select.
5 or to My Words and press to select.
6 or to Add New Word and press to
select.
Display shows the list of custom words.
7Use the keypad to edit your custom word.
Press to move one space to the left. Press or
the key to move one space to the right.
Press the key to delete any unwanted
characters. Long press to change text entry
method. Press once your custom word is
completed.
The display shows transitional mini notice, confirming
your custom word is being saved.
If the custom word is saved, a tone sounds and the
display shows positive mini notice.
If the custom word is not saved, a low tone sounds
and the display shows negative mini notice.
Deleting a Custom Word
You can delete the custom words saved in your radio.
1 to access the menu.
2 or to Utilities and press to select.
Advanced Features in Connect Plus...
233
English
3 or to Radio Settings and press to
select.
4 or to Text Entry and press to select.
5 or to My Words and press to select.
6 or to the required word and press to
select.
7 or to Delete and press to select.
8Choose one of the following.
—At Delete Entry?, press to select Yes.
The display shows Entry Deleted.
— or to No and press to return to the
previous screen.
Deleting All Custom Words
You can delete all custom words from your radio’s in-
built.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Settings and press to
select.
4 or to Text Entry and press to select.
5 or to My Words and press to select.
6 or to Delete All and press to select.
7Choose one of the following.
—At Delete Entry?, press to select Yes.
The display shows Entry Deleted.
— or to No and press to return to the
previous screen.
Accessing General Radio Information
Your radio contains information on the following:
Advanced Features in Connect Plus...
234
English
— Battery
— Degree of Tilt (Accelerometer)
— Radio Model Number Index
— Option Board Over-the-Air (OTA) Codeplug CRC
— Site Number
— Site Info
— Radio Alias and ID
— Firmware and Codeplug Versions
— Open-Source Software Information
Press at any time to return to the previous
screen or long press to return to the Home
screen. The radio exits the current screen once the
inactivity timer expires.
Accessing the Battery Information
Displays information on your radio battery.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Battery Info and press to
select.
The display shows the battery information.
For IMPRES batteries ONLY: The display reads
Recondition Battery if the battery requires
reconditioning in an IMPRES charger. After the
reconditioning process, the display then shows the
battery information.
Checking the Degree of Tilt (Accelerometer)
Note: The measurement on the display shows the
degree of tilt at the moment you press to accept
the Accelerometer option. If you change the angle
of the radio after pressing , the radio does not
change the measurement shown on its display. It
continues to display the measurement taken when
was pressed.
If the portable radio has been enabled for the Man
Down Alarms, there is a menu option to check how
the radio measures the degree of tilt. This is a helpful
feature when the dealer or Radio System
Administrator uses the MOTOTRBO Connect Plus
Advanced Features in Connect Plus...
235
English
Option Board CPS programming software to
configure the activation angle that will trigger the tilt
alarm.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4Tilt the radio at the angle that triggers the Tilt
Alarm.
5 or to Accelerometer and press to
select.
The display shows the radio’s angle of tilt
(deviation from perpendicular vertical position) in
degrees (example: 62 Deg.) Based on this, use
MOTOTRBO Connect Plus Option Board CPS to
configure the Activation Angle for 60 degrees
(which is the closest programmable value). The
Tilt Alarm timers are triggered when the Activation
Angle is 60 degrees, or greater.
Checking the Radio Model Number Index
This index number identifies your radio’s model-
specific hardware. Your radio system administrator
may ask for this number when preparing a new
Option Board codeplug for your radio.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Model Index and press to
select.
The display shows the Model Number Index.
Checking the CRC of the Option Board OTA
Codeplug File
Follow the instructions below if your radio system
administrator asks you to view the Option Board OTA
Codeplug File CRC (Cyclic Redundancy Check). This
menu option only appears if the Option Board
received its last codeplug update OTA.
Advanced Features in Connect Plus...
236
English
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to OB OTA CPcrc and press to
select.
The display shows some letters and numbers.
Communicate this information to your radio
system administrator exactly as shown.
Displaying the Site ID (Site Number)
Note: If you are not currently registered at a site, the
display shows Not Registered.
The radio briefly shows the Site ID as it registers with
a Connect Plus site. Following registration, the radio
does not generally indicate the Site number. To
display the registered Site number, do the following:
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Site Number and press to
select.
The display shows the Network ID and the Site
Number.
Checking the Site Info
Note: If you are not currently registered at a site, the
display shows Not Registered.
The Site Info feature provides information that can be
useful to a service technician. It consists of the
following information:
— Repeater number of current Control Channel
repeater.
— RSSI: Last signal strength value measured from
Control Channel repeater.
— Neighbor List sent by Control Channel repeater
(five numbers separated by commas).
Advanced Features in Connect Plus...
237
English
If you are requested to use this feature, please report
the displayed information exactly as it appears on the
screen.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Site Info and press to select.
The display shows the Site Info.
Checking the Radio ID
This feature displays the ID of your radio.
Follow the procedure described next to access this
feature via the radio screen.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to My ID and press to select.
The display shows the radio ID.
Checking the Firmware Version and Codeplug
Version
Displays the firmware version on your radio.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Versions and press to select.
The display a list with the following information:
— (Radio) Firmware Version
— (Radio) Codeplug Version
— Option Board Firmware Version
— Option Board Frequency Version
— Option Board Hardware Version
Advanced Features in Connect Plus...
238
English
— Option Board Codeplug Version
Checking for Updates
Connect Plus provides the ability to update certain
files (Option Board Codeplug, Network Frequency
File and Option Board Firmware File) over-the-air.
Note: Check with the dealer or network administrator
to determine whether this feature has been enabled
for your radio.
Any display Connect Plus radio has the ability to
show its current Option Board OTA Codeplug CRC,
Frequency File version or Option Board firmware file
version via a menu option. In addition, display radios
that have been enabled for over-the-air file transfer
can display the version of a "pending file". A "pending
file" is a Frequency File or Option Board firmware file
that the Connect Plus radio knows about via system
messaging, but the radio has not yet collected all of
the file’s packets. If a display Connect Plus radio has
a pending file, the menu provides options to:
— See the version number of the pending file
— See what percentage of packets has been
collected so far
— Request the Connect Plus radio to resume
collecting file packets
If the radio is enabled for Connect Plus over-the-air
file transfer, there may be times when the radio
automatically joins a file transfer without first notifying
the radio user. While the radio is collecting file
packets, the LED rapidly blinks red and the radio
displays the High Volume Data icon on the Home
Screen status bar.
Note: The Connect Plus radio cannot collect file
packets and receive calls at the same time. If you
wish to cancel the file transfer, press and release the
PTT button. This causes the radio to request a call on
the selected Contact Name, and it will also cancel the
file transfer for that radio until the process resumes at
a later time.
There are several things that can make the file
transfer process start again. The first example applies
to all over-the-air file types. The other examples apply
only to the Network Frequency File and Option Board
Firmware File:
— The radio system administrator re-initiates the
over-the-air file transfer.
Advanced Features in Connect Plus...
239
English
— The Option Board's pre-defined timer expires,
which causes the Option Board to automatically
resume the process of collecting packets.
— The timer has not yet expired, but the radio user
requests the file transfer to resume via the menu
option.
After the Connect Plus radio finishes downloading all
file packets, it must upgrade to the newly acquired
file. For the Network Frequency File, this is an
automatic process and does not require a radio reset.
For the Option Board Codeplug File, this is an
automatic process that will cause a brief interruption
to service as the Option Board loads the new
codeplug information and re-acquires a network site.
How quickly the radio upgrades to a new Option
Board firmware file depends on how the radio has
been configured by the dealer or system
administrator. The radio will either upgrade
immediately after collecting all file packets, or it will
wait until the next time that the user turns the radio
on.
Note: Check with your dealer or system administrator
to determine how your radio has been programmed.
The process of upgrading to a new Option Board
firmware file takes several seconds, and it requires
the Connect Plus Option Board to reset the radio.
Once the upgrade starts, the radio use will not be
able to make or receive calls until the process is
completed.
Firmware File
Firmware Up to Date
Note: If the Option Board firmware file is not Up to
Date (and if the radio has partially collected a more
recent Option Board firmware file version) the radio
displays a list with additional options; Version,
%Received, and Download.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Updates and press to select.
5 or to Firmware and press to select.
The display shows Firmware is Up to Date.
Advanced Features in Connect Plus...
240
English
Pending Firmware – Version
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Updates and press to select.
5 or to Firmware and press to select.
6 or to Version and press to select.
If there is a pending Option Board firmware file,
the display shows the pending firmware version
number.
If there is a pending Option Board firmware file,
the display shows Firmware is Up to Date
Pending Firmware – % Received
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Updates and press to select.
5 or to Firmware and press to select.
6 or to %Received and press to select.
The screen displays the percentage of firmware
file packets collected so far.
Note: When at 100%, the radio needs to be power
cycled Off and then On to initiate the firmware
upgrade.
Pending Firmware – Download
If the Connect Plus radio has previously left an OTA
Option Board Firmware File Transfer with a partial
file, the unit automatically rejoins the file transfer (if
still ongoing) when an internal timer expires. If you
want the unit to rejoin an ongoing Option Board
Firmware File transfer prior to expiration of this
Advanced Features in Connect Plus...
241
English
internal timer, use the Download option as described
below.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Updates and press to select.
5 or to Firmware and press to select.
6 or to Download and press to select.
The display shows the following:
Download Available Start Download
No Download
Available
Download not
available
7Do one of the following:
—Select Yes and press to start the download.
—Select No and press to return to the
previous menu.
Frequency File
Frequency File Up to Date
Note: If the Frequency File is not Up to Date (and if
the radio has partially collected a more recent
frequency file version) the radio displays a list with
additional options; Version, %Received, and
Download.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Frequency and press to select.
The display shows Freq. File is Up to Date.
Frequency File Pending – Version
1 to access the menu.
Advanced Features in Connect Plus...
242
English
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Updates and press to select.
5 or to Frequency and press to select.
6 or to Version and press to select.
If there is a pending Frequency File, the display
shows the pending Frequency File version
number.
Frequency File Pending — % Received
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Updates and press to select.
5 or to %Received and press to select.
The screen displays the percentage of frequency
file packets collected so far.
Frequency File Pending – Download
If the Connect Plus radio has previously left an OTA
Network Frequency File Transfer with a partial file,
the unit automatically rejoins the file transfer (if still
ongoing) when an internal timer expires. If you want
the unit to rejoin an ongoing Network Frequency File
transfer prior to expiration of this internal timer, use
the Download option as described below.
1 to access the menu.
2 or to Utilities and press to select.
3 or to Radio Info and press to select.
4 or to Updates and press to select.
5 or to Frequency and press to select.
Advanced Features in Connect Plus...
243
English
6 or to Download and press to select.
Download Currently
Unavailable
Download not
available
Download Currently
Available
Start Download
7Do one of the following:
—Select Yes and press to start the download.
—Select No and press to return to the previous
menu.
Advanced Features in Connect Plus...
244
English
Accessories
Antennas
— 420 – 445 MHz Stubby Antenna, (PMAE4076_)
— 438 – 470 MHz Stubby Antenna, (PMAE4077_)
— 403 – 425 MHz Stubby Antenna, (PMAE4078_)
— 450 – 490 MHz Stubby Antenna Kit, (PMAE4091_)
— 480 – 527 MHz Stubby Antenna Kit, (PMAE4092_)
— 806 – 870 MHz Stubby Antenna (PMAF4017_)
— 896 – 941 MHz Stubby Antenna (PMAF4018_)
Audio Accessories
— Surveillance Earpiece with in-line microphone and
PTT (PMLN5957_)
— Swivel Earpiece with in-line microphone and PTT
(PMLN5958_)
Batteries
— Lithium-Ion 1800 mAH Battery Pack (HKNN4013_)
— Lithium-Ion 1370 mAH Battery Pack
(PMNN4425_) [5]
Bluetooth
— HK200 Bluetooth Headset (US) (89409_)
— Operations Critical Wireless Earpiece with 12 inch
cable (US) (NNTN8125_)
— Operations Critical Wireless Earpiece with 9.5 inch
cable (US) (NNTN8126_)
— Operations Critical Wireless Push-To-Talk POD
(US) (NNTN8127_)
Cables
— Micro USB Programming Cable (25-124330-01R)
Carry Devices
— Carry Holder (PMLN5956_)
— Wrist Strap (PMLN6074_)
5Not applicable to the 800/900 band.
Accessories
245
English
Chargers
— Multi-Unit Charger, US Plug (PMLN5916_)
— Micro USB Charger, US Plug (PMPN4009_)
— Micro USB Single-Unit Plug-In Charger
(SPN5547_)
— SL Series Tri-Unit Charger (PMLN6358_)
Miscellaneous Accessories
— 1370 mAH Battery Cover (PMLN6000_)
— 1800 mAH Battery Cover (PMLN6001_)
Accessories
246
English
Batteries and Chargers Warranty
The Workmanship Warranty
The workmanship warranty guarantees against
defects in workmanship under normal use and
service.
All MOTOTRBO
Batteries
Two (2) Years
IMPRES Chargers
(Single-Unit and Multi-
Unit, Non-Display)
Two (2) Years
IMPRES Chargers (Multi-
Unit with Display)
One (1) Year
The Capacity Warranty
The capacity warranty guarantees 80% of the rated
capacity for the warranty duration.
Nickel Metal-Hydride
(NiMH) or Lithium-Ion (Li-
lon) Batteries
12 Months
IMPRES Batteries, When
Used Exclusively with
IMPRES Chargers
18 Months
Batteries and Chargers Warrant...
247
English
Limited Warranty
MOTOROLA COMMUNICATION PRODUCTS
I. WHAT THIS WARRANTY COVERS AND FOR
HOW LONG:
MOTOROLA SOLUTIONS, INC. (“MOTOROLA”)
warrants the MOTOROLA manufactured
Communication Products listed below (“Product”)
against defects in material and workmanship under
normal use and service for a period of time from the
date of purchase as scheduled below:
SL Series Digital
Portable Radios
Two (2) Years
Product Accessories
(Excluding Batteries and
Chargers)
One (1) Year
MOTOROLA, at its option, will at no charge either
repair the Product (with new or reconditioned parts),
replace it (with a new or reconditioned Product), or
refund the purchase price of the Product during the
warranty period provided it is returned in accordance
with the terms of this warranty. Replaced parts or
boards are warranted for the balance of the original
applicable warranty period. All replaced parts of
Product shall become the property of MOTOROLA.
This express limited warranty is extended by
MOTOROLA to the original end user purchaser only
and is not assignable or transferable to any other
party. This is the complete warranty for the Product
manufactured by MOTOROLA. MOTOROLA
assumes no obligations or liability for additions or
modifications to this warranty unless made in writing
and signed by an officer of MOTOROLA.
Unless made in a separate agreement between
MOTOROLA and the original end user purchaser,
MOTOROLA does not warrant the installation,
maintenance or service of the Product.
MOTOROLA cannot be responsible in any way for
any ancillary equipment not furnished by MOTOROLA
which is attached to or used in connection with the
Product, or for operation of the Product with any
ancillary equipment, and all such equipment is
expressly excluded from this warranty. Because each
system which may use the Product is unique,
MOTOROLA disclaims liability for range, coverage, or
Limited Warranty
248
English
operation of the system as a whole under this
warranty.
II. GENERAL PROVISIONS:
This warranty sets forth the full extent of
MOTOROLA'S responsibilities regarding the Product.
Repair, replacement or refund of the purchase price,
at MOTOROLA’s option, is the exclusive remedy.
THIS WARRANTY IS GIVEN IN LIEU OF ALL
OTHER EXPRESS WARRANTIES. IMPLIED
WARRANTIES, INCLUDING WITHOUT LIMITATION,
IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE,
ARE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY. IN NO EVENT SHALL
MOTOROLA BE LIABLE FOR DAMAGES IN
EXCESS OF THE PURCHASE PRICE OF THE
PRODUCT, FOR ANY LOSS OF USE, LOSS OF
TIME, INCONVENIENCE, COMMERCIAL LOSS,
LOST PROFITS OR SAVINGS OR OTHER
INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES ARISING OUT OF THE USE OR
INABILITY TO USE SUCH PRODUCT, TO THE
FULL EXTENT SUCH MAY BE DISCLAIMED BY
LAW.
III. STATE LAW RIGHTS:
SOME STATES DO NOT ALLOW THE EXCLUSION
OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES OR LIMITATION ON
HOW LONG AN IMPLIED WARRANTY LASTS, SO
THE ABOVE LIMITATION OR EXCLUSIONS MAY
NOT APPLY.
This warranty gives specific legal rights, and there
may be other rights which may vary from state to
state.
IV. HOW TO GET WARRANTY SERVICE:
You must provide proof of purchase (bearing the date
of purchase and Product item serial number) in order
to receive warranty service and, also, deliver or send
the Product item, transportation and insurance
prepaid, to an authorized warranty service location.
Warranty service will be provided by MOTOROLA
through one of its authorized warranty service
locations. If you first contact the company which sold
you the Product (e.g., dealer or communication
service provider), it can facilitate your obtaining
warranty service. You can also call MOTOROLA at
1-800-927-2744 US/Canada.
Limited Warranty
249
English
V. WHAT THIS WARRANTY DOES NOT
COVER:
1Defects or damage resulting from use of the
Product in other than its normal and customary
manner.
2Defects or damage from misuse, accident, water,
or neglect.
3Defects or damage from improper testing,
operation, maintenance, installation, alteration,
modification, or adjustment.
4Breakage or damage to antennas unless caused
directly by defects in material workmanship.
5A Product subjected to unauthorized Product
modifications, disassembles or repairs (including,
without limitation, the addition to the Product of
non-MOTOROLA supplied equipment) which
adversely affect performance of the Product or
interfere with MOTOROLA's normal warranty
inspection and testing of the Product to verify any
warranty claim.
6Product which has had the serial number removed
or made illegible.
7Rechargeable batteries if:
1any of the seals on the battery enclosure of
cells are broken or show evidence of
tampering.
2the damage or defect is caused by charging or
using the battery in equipment or service other
than the Product for which it is specified.
8Freight costs to the repair depot.
9A Product which, due to illegal or unauthorized
alteration of the software/firmware in the Product,
does not function in accordance with
MOTOROLA’s published specifications or the FCC
certification labeling in effect for the Product at the
time the Product was initially distributed from
MOTOROLA.
10 Scratches or other cosmetic damage to Product
surfaces that does not affect the operation of the
Product.
11 Normal and customary wear and tear.
VI. PATENT AND SOFTWARE PROVISIONS:
MOTOROLA will defend, at its own expense, any suit
brought against the end user purchaser to the extent
that it is based on a claim that the Product or parts
infringe a United States patent, and MOTOROLA will
pay those costs and damages finally awarded against
Limited Warranty
250
English
the end user purchaser in any such suit which are
attributable to any such claim, but such defense and
payments are conditioned on the following:
1that MOTOROLA will be notified promptly in
writing by such purchaser of any notice of such
claim,
2that MOTOROLA will have sole control of the
defense of such suit and all negotiations for its
settlement or compromise, and
3should the Product or parts become, or in
MOTOROLA’s opinion be likely to become, the
subject of a claim of infringement of a United
States patent, that such purchaser will permit
MOTOROLA, at its option and expense, either to
procure for such purchaser the right to continue
using the Product or parts or to replace or modify
