NEC of America MDD1075 Cellular WCDMA and PCS GSM Phone with RFID User Manual A98 MDD1075
NEC Corporation of America Cellular WCDMA and PCS GSM Phone with RFID A98 MDD1075
Contents
- 1. Users Manual
- 2. Users Manual RF Warning Page
Users Manual
![](/img.php?id=2091436&img=bg1.png)
1
Making a call/videophone call
As 0( is not equipped with the front camera, during a videophone call, you can send
only the substitute image (Chara-den) or image from the rear camera to the other party.
Making a call by entering the phone number
❶ Enter the phone number starting with the area code, then r (voice
call) / u (V.phone)
❷ After the call ends, y
Making a call from phonebook
Add the phone number of the other party to the phonebook in advance.
❶
f
(Search phonebook) to select a search condition and search the
phonebook
▶b
to select an entry, then
r
(voice call) /
u
(1 second or
longer)
(V.phone)
Making a call with redials
❶ i▶ "TEL function" ▶ "Dialed/Received call" ▶ "Redial" to select the
other party, then r (voice call) / u (V.phone)
■ To make a call with received calls
i▶ "TEL function" ▶ "Dialed/Received call" ▶ "Received calls" ▶"All calls" or "Missed
calls” to select the other party, then r (voice call)/u (V.phone)
Using Koe-no-Takuhaibin
This is a service to record a voice message and deliver it to the other party.
❶ Enter the other party's phone number, then o (Koetaku)
❷ Follow the operation guidance and record a message
The other party will be notified that a message is waiting.
Call Telephone
0
(
lh
![](/img.php?id=2091436&img=bg2.png)
2
■ To play a recorded message
On the Recording notification SMS detail screen, "再生 " (Play) ▶ "YES"
Also, it can be played from: i▶ "TEL function" ▶ "Koe-no-Takuhaibin" ▶ "Message confirm (voice)" ▶ "YES".
Making an international call
Use WORLD CALL to make international calls from Japan.
・ For WORLD CALL, please contact "General Inquiries" .
❶ 010▶Country code▶Area code (City code)▶The other party's
phone number▶r (voice call) / u (V.phone)
❷ After the call ends, y
・
Dial the other party's phone number excluding "0" at the beginning of the area code (city
code). However, to make a call to some countries/areas, such as in Italy, "0" is required.
・
You can make calls from overseas. (→p.5)
Receiving a call/videophone call
When you receive an incoming call, the ring tone sounds and the illumination flashes.
❶ When you receive an incoming call, r or d (Answer) / (Subst.)
You can only answer a videophone call with the substitute image.
❷ After the call ends, y
Adjusting earpiece volume
❶ i▶ "TEL function" ▶ "Dial/Receive setting" ▶ "In-call setting"
▶ "Volume" ▶Adjust with c▶d (Set)
・
During a call, you can adjust the volume with
a
/
Ss
.
![](/img.php?id=2091436&img=bg3.png)
3
When you can not answer a call
Setting record message
When you cannot answer a voice or videophone call, the FOMA terminal can record a
voice or videophone message.
❶ i
▶
"TEL function"
▶
"Rec. msg./Voice memo"
▶
"Record message
setting"
▶
"ON"
▶
"Phone" or "Videophone"
▶
Select an item
❷ Set ring time (3-digit number between 000 and 120 seconds)
■ If you receive a call with Record message setting ON
Record message activates if the set time ends. Press r to answer a voice/videophone
call while recording.
■ To play a recorded message
On the standby screen, d▶"Record message" icon or "Record VP message" icon▶
Select an item
Setting Public mode (Drive mode)
When Public mode (Drive mode) is set, a caller hears a message that you cannot answer
the call because you are driving or in a place where you have to refrain from using a
mobile phone (on a train or bus, in a theater, etc.), then the call ends automatically.
❶ On the standby screen, w (1 second or longer)
appears on the standby screen.
■ To release the setting
On the standby screen, w (1 second or longer)
Setting Public mode (Power OFF)
When Public mode (Power OFF) is set, a caller who made a call while the power is off hears a message
that you cannot answer the call because you are in a place where you have to turn off the mobile phone
(in a hospital, on an airplane, around a priority seat on a train, etc.), then the call ends automatically.
❶ w25251▶r
■ To release the setting
w25250▶r
![](/img.php?id=2091436&img=bg4.png)
4
Using various network services
■
Available network services
Useful DOCOMO network services are available.
・
The network services are not available when you are outside the service area or in a place where the signal is weak.
・
For details, refer to "Mobile Phone User's Guide [Network Services]".
・
For the application and inquiries, please contact "General Inquiries" .
Service name Application
Monthly charge
Voice Mail Service Required Charged
Missed call notice service Not required Free
Call Waiting Required Charged
Call Forwarding Service Required Free
Nuisance Call Blocking Not required Free
Caller ID Notification Not required Free
Caller ID Request Not required Free
English Guidance Not required Free
Multi Number Required Charged
2in1 Required Charged
Public mode (Drive mode) Not required Free
Public mode (Power OFF) Not required Free
Melody call Required Charged
Koe-no-Takuhaibin Not required Free
Setting voice mail service
❶
i▶
"TEL function"
▶
"Voice mail service"
▶
Select an item
Setting call waiting
❶
i▶
"TEL function" ▶ "Other network serv." ▶ "Call waiting" ▶Select
an item
Setting call forwarding
❶
i▶ "TEL function" ▶ "Other network serv." ▶ "Call forwarding" ▶
Select an item
![](/img.php?id=2091436&img=bg5.png)
5
Emergency call
Emergency call Phone number
Police emergency 110
Fire brigade/Ambulance emergency 119
Maritime distress call 118
・
Your FOMA terminal supports "Emergency Location Report". Calls made to emergency service organizations
(e.g. by dialing 110, 119 or 118) disclose information on the caller's location to the organization receiving
the call. The location information may not be correctly sent depending on the current location or signal
quality. When the location information is disclosed, the organization name appears on the standby screen.
The location information and phone number are not disclosed when, before each individual call made, "184"
or another blocking prefix is dialed first. If the information is deemed necessary for the protection of life, etc.,
this information may be acquired by the organization being called. Locations/timing planned for adoption of
this feature vary according to the status of the preparations by the relevant emergency service organizations.
・
When calling 110, 119 or 118 from the FOMA terminal, first say you are calling from a mobile phone, give
your number, and state your location clearly, because the police or fire department may call you back for
confirmation. Also, do not move around when making the call. Do not turn off the power immediately
after ending the call, but leave it turned on for ten minutes or so, so that you can receive a call.
・
Depending on the area you are calling from, you may not be connected with the nearest police
or fire department, etc.
・
When making a videophone call to 110, 119 or 118 from the FOMA terminal, the call automatically changes to a voice call.
Using overseas
To make calls overseas, use international roaming (WORLD WING).
■
International roaming (WORLD WING) is the service, which enables you to make calls and perform communication
over networks of affiliated overseas operators using the FOMA terminal, phone number and mail address of your own for
Japan, even when you are overseas. Voice calls, SMS and i-mode mail services are available without any special settings.
■
Supported area
This FOMA terminal is Class 4 and can be used in 3G or GSM/GPRS network service areas. Also it can
be used in countries/regions compatible with 3G850 MHz. Check available areas.
■
Before overseas use, refer to the following:
- "Mobile Phone User's Guide [International Services]"
- DOCOMO "International Services website"
- "
海外ご利用ガイド
" (Overseas use guide) (Japanese) in "My document" under Data box
■
Information
・
For a country code, international call access code, universal number international prefix, available countries and overseas
operators, refer to "Mobile Phone User's Guide [International Services]" or DOCOMO "International Services website".
・
Overseas usage fees (call charge, packet communications charge) differ from those in Japan.
![](/img.php?id=2091436&img=bg6.png)
6
Available services overseas
Main communication services 3G GSM/GPRS GSM
MyFACE *1 ○○×
Voice call *2 ○○○
Videophone call *2 ○××
SMS *3 ○○○
i-mode *4 ○○×
i-mode mail ○○×
i-channel *4 *5 ○○×
i-concier *6 ○○×
i-Widget *7 ○○×
Packet communications via a PC ○○×
Obtaining location information using GPS *8 ○○×
*1 : "Auto-upd set. roam" setting is required.
Packet communications charges will apply when you automatically update MyFACE content that
was registered at the time of purchase.
When traveling overseas from Japan, "MyFACE auto-update set" is set to "Don't auto-update".
When using auto-update for the first time, select whether or not to auto-update overseas.
*2 : When 2in1 is active, dialing using Number B is not available. Dialing using the additional number
of Multi number is not available.
*3 : When sending an SMS to FOMA terminal user, enter the other party's phone number as in Japan.
*4 : "i-mode overseas use" setting is required.
*5 : "i-channel overseas use" setting is required. Packet communications charges will apply when you
automatically update information on "Basic Channel". (Included in i-channel charges in Japan.)
*6 : Overseas use setting for i-concier is required. Packet communications charges will apply for each
reception of information.
*7 : "i-Widget overseas use" setting is required. When you open the i-Widget screen, multiple Widget
Appli may establish communications. In this case, packet communications charges will apply for
each communication.
*8 : GPS location service (Position location) is free of charge. However, packet communications
charges will apply, e.g. if you open a map from location information.
・ Some services are not available depending on the operator or network overseas.
![](/img.php?id=2091436&img=bg7.png)
7
Making a call to outside the country you stay in
❶ On the standby screen, 0 (1 second or longer) to enter +▶Country
code▶Area code (City code)▶The other party's phone number▶
r (voice call) / u (V.phone)
❷ After the call ends, y
・
To make an international call to Japan, dial "81" as country code.
・
Dial the other party's phone number excluding "0" at the beginning of the area
code (city code). However, to make a call to some countries/areas, such as in
Italy, "0" is required.
Making a call in the country of stay
❶ Area code (City code)▶The other party's phone number▶r (voice
call) / u (V.phone)
❷ After the call ends, y
Making a call to WORLD WING user overseas
When making a call to "WORLD WING" user overseas, make a call as an international
call to Japan (dial "81" (Japan) as the country code), irrespective whether the other
party is in or out of the country you stay.
❶ On the standby screen, 0 (1 second or longer) to enter + ▶
81▶The other party's mobile phone number excluding the
first "0"▶r (voice call) / u (V.phone)
❷ After the call ends, y
