ONTOP TECHNOLOGY BSP-002 BLUETOOTH SPEAKER User Manual BSP 002 Manual A4 170613
ONTOP TECHNOLOGY LTD BLUETOOTH SPEAKER BSP 002 Manual A4 170613
User Manual
Portable Bluetooth Speaker
BSP-002
1
Warning
• Never remove the casing of this apparatus.
• Never lubricate any part of this apparatus.
• Never place this apparatus on other electrical equipment.
Notice for the USA and Canada
This device complies with Part 15 of the FCC Rules and RSS standard
of Industry Canada. Operation is subject to the following two
conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules and ICES-003 of Industry Canada . These limits are designed
to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Relocate the receiving antenna.
• Increase the separation between equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
RF Radiation Exposure Statement: This equipment complies with
FCC’s and IC’s RF radiation exposure limits set forth for an
uncontrolled environment. The antenna(s) used for this transmitter
must be installed and operated to provide a separation distance of at
least 20 cm from all persons and must not be collocated or operating in
conjunction with any other antenna or transmitter. Installers must
ensure that 20cm separation distance will be maintained between the
device (excluding its handset) and users.
This product bears the selective sorting symbol for
waste electrical and electronic equipment(WEEE).
This means that this product must be handled
pursuant to European Directive 2002/96/EC in
order to be recycled or dismantled to minimize its
impact on the environment.
For further information, please contact your local or
regional authorities.
Electronic products not included in the selective
sorting process are potentially dangerous
for the environment and human health due to the
presence of hazardous substances.
2
• Place the unit on a level surface away from sources of direct
sunlight or excessive heat.
• Protect your furniture when placing your unit on a natural wood
and lacquered finish. A cloth or other protective material
should be placed between it and the furniture.
• Clean your unit with a soft cloth moistened only with mild soap
and water. Stronger cleaning agents, such as Benzene, thinner
or similar materials can damage the surface of the unit.
NOTE : This model is designed for use with Bluetooth
wireless devices compatible with the HFP, HSP, A2DP and
AVRCP streaming audio profiles. Refer to your Bluetooth
device’s user
manual or technical support to determine if your Bluetooth
Maintenance
3
WARNINGS & CAUTIONS
To reduce the risk of fire or electric shock, do not expose the BSP-002
to rain or moisture. The BSP-002 should not be exposed to dripping or
splashing, and objects filled with liquids, such as vases, should not be
placed on or near it. Do not use near bathtubs, washbowls, kitchen
sinks, laundry tubs, in a wet basement, near a swimming pool, or
anywhere else that water is present. As with any electronic products,
use care not to spill liquids into any part of the product. Liquids can
cause a failure and/or a fire hazard. The power supply must be used
indoors only. It is neither designed nor tested for charging outdoors, in
recreation vehicles, or on boats. Make no modifications to the product
or accessories. Unauthorized alterations may compromise safety,
regulatory compliance, and system performance, and will void the
warranty. Do not place any flame sources, such as lighted candles, on
or near the BSP-002. The BSP-002 contains small parts that may be a
choking hazard and is not suitable for children under age 3.
Before use, fully charge the battery by connecting the unit to computor
or universal USB mobile charger through the provided USB cable. Do
not continue charging the battery if it does not reach full charge within
the specified charging time. Overcharging may cause the battery to
become hot, rupture, or ignite. If you see any heat deformation or
leakage, properly dispose of the battery. Do not attempt to charge
the battery in temperatures outside the range of 32°-104°F (0°-40°C).
If the battery begins to leak, do not allow the liquid to come in contact
with your skin or eyes. If contact has been made, wash the affected
area with plenty of water and seek medical attention immediately. Do
not expose the product or battery to excessive heat, including direct
sunlight or fire and storage or use inside cars in hot weather, where it
can be exposed to temperatures in excess of 115°F (60°C). Doing so
may cause the battery and power supply to generate heat, rupture, or
ignite. Using the product in this manner also may result in a loss of
performance and a shortened life expectancy. Extended exposure to
direct sunlight may damage the external appearance and material
qualities.
WARNINGS & CAUTIONS
Do not step on, throw, or drop batteries or the power supply or device,
or expose them to a strong shock. Do not pierce, crush, dent, or
deform the batteries or power supply in any way. If either becomes
deformed, properly dispose of it. Do not short-circuit batteries. Refer
all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way: such as power supply
cord or plug is damaged; liquid has been spilled or objects have fallen
into the BSP-002; the BSP-002 has been exposed to rain or moisture,
does not operate normally, or has been dropped. Do not attempt to
service the BSP-002 yourself. Opening or removing covers may
expose you to dangerous voltages or other hazards and will void the
manufacturer’s warranty. To prevent risk of fire or electric shock,
avoid overloading wall outlets, extension cords, or integral
convenience receptacles. Do not place your BSP-002 on high
surfaces such as shelves. During music playback the BSP-002 may
vibrate and move which could cause the speaker to shift and fall off of
the edge. Your Bluetooth device (mobile phone, music player, tablet,
laptop, etc.) must support the A2DP Bluetooth profile in order to work
wirelessly with your BSP-002 speaker. The A2DP profile is supported
by most recent mobile products with built-in Bluetooth capability.
Please refer to your device’s user manual for details and instruction
regarding the Bluetooth profiles it supports.
4
Getting Start
Controls and Indicators
BSP-002 has a built-in rechargeable Li-Polymer battery.
The red CHR
indicator turns on while the battery is charging. The red indicator will
turn off when the battery has fully charged (around 2 hours).
To charge the unit, please use the USB cable provided and connect it
to a computer or a universal USB mobile charger.
1
2
3
5
4
6
1. module area 6. Charge/ Aux indicator
2. Function switch 7. Speaker Driver
3. Bluetooth indicator 8. Changeable Decoration ring
4. Charge/ Aux in socket
5. Wrist Strap hole
5
7
8
Listening to Bluetooth Music
NFC Bluetooth Pairing
6
In order to use this unit for music playback through Bluetooth,
the unit must first be paired with the Bluetooth device.
Pairing:
1. Slide the Function Switch to BT mode. The blue BT indicator
will flash for 20 seconds to search the last linked device. Then,
the unit will search for Bluetooth devices within range. While in
search mode, the Red and Blue BT indicator will flash
alternately. (searching will stop when no device is found to be in
range within two and a half minutes, the unit will go to sleep
mode)
2. Following the instructions on your device's user manual,
activate Bluetooth on your device and search for devices.
Once you have found "BSP-002”, pair to the speaker. A pass
code is not required.
3. Once connected, the Bluetooth indicator will flash slower than
before.
4. Every time you power on this unit, it will pair with the last
linked device when that device is in range.
NOTE: If no device is found in range or no device is paired or
connected for 5 minutes. The unit will go to sleep mode.
1. Slide the Function Switch to BT mode. Put your NFC device
near the bottom of this unit. This unit will automatic pair with
your device. Tap again to disconnect . (Make sure you have turn
on the NFC of your device)
2. Once connected, the Bluetooth indicator will flash slower than
before.
3. When the unit is in sleep mode. Put your NFC device near the
bottom of the unit can wake up the unit to connect with your
device.
Listening to other portable audio devices
Change the Decoration Ring
You can connect an MP3 player or other portable audio device
through this speaker via the Aux-in Jack.
1. Plug in the 3.5mm jack plug into the headphone or line-out
jack on your device and plug in the micro USB jack into the unit.
2. Slide the Function Switch on the unit to AUX mode so that
the green indicator for Aux-In mode turns on.
3. Turn on and play your device.
4. Adjust the volume level on your device.
To preserve power, remember to turn off the speaker when not in
use.
Turn the Decoration Ring anti-clockwise, you can release the
Decoration Ring. Turn it clockwise to lock the ring.
7
Playing Bluetooth Music
1. Once your device and this unit are paired you can start to play
music through this speaker using the Bluetooth function.
2. Press the Button on your device to play your music.
3. Press the Button again to pause play; press again to
resume playback.
4. Press the Skip Button on your device to Skip the track
forward / Backward.
5. Press the Volume Button on your device to adjust the volume
level up or down.
NOTE: This unit must be in Bluetooth mode to pair and use a
Bluetooth-enabled device.
Federal Communications
Commission (FCC) Statement
This device complies with part 15 of
the FCC Rules. Operation is subject
to the following two conditions: (1)
This device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may cause
undesired operation.
Note: This equipment has been tested
and found to comply with the limits
for a Class B digital device, pursuant
to part 15 of the FCC Rules. These
limits are designed to provide
reasonable protection against harmful
interference in a residential
installation. This equipment
generates, uses and can radiate radio
frequency energy and, if not installed
and used in accordance with the
instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a
particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment off and on,
the user is encouraged to try to
correct the interference by one or
more of the following measures:
Reorient or relocate the
receiving antenna.
Increase the separation between
the equipment and receiver.
Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
Consult the dealer or an
experienced radio/TV technician
for help.
Warning: Changes or modifications
made to this device not expressly
approved by
ONTOP TECHNOLOGY LTD may
void the FCC authorization to
operate this device.
Note: The manufacturer is not
responsible for any radio or tv
interference caused by unauthorized
modifications to this equipment.
Such modifications could void the
user’s authority to operate the
equipment.
