Panasonic of North America 9TAWJ-VR3004 Wireless LAN Module User Manual Short Term Confidential

Panasonic Corporation of North America Wireless LAN Module Short Term Confidential

Contents

(Short-Term Confidential) User Manual

1
For U.S.A
FCC CAUTION
Changes or modifications no expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
FCC Note:
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful interfer-
ence to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference
at his own expense.
For Canada
CAN ICES-3(A)/NMB-3(A)
Compliance statement and notification
This device complies with part 15 of the FCC Rules. Operation is subject to the
f
ollowing two conditions: (1) This device may not cause harmful interference, and (2)
t
his device must accept any interference received, including interference that may
cause undesired operation.
2
For U.S.A.
<FCC Information>
Information to to Be Supplied to the End User by the Installer or Integrator
If the FCC ID of this module is not visible from the outside of the end product, to satisfy FCC
exterior labeling requirements, the end product must be labeled in a visible area with the fol-
lowing: “Contains FCC ID: ACJ9TAWJ-VR3004”
The following regulatory and safety notices must be published in documentation supplied
to the end user of the product or system incorporating an adapter in compliance with local
regulations.
This transmitter must not be co-located or operated in conjunction with any other antenna or
transmitter.
Operating near 2.4 GHz electrical appliances may cause interference. Move away from the
electrical appliances.
Compliance with FCC requirement 15.407(c)
Data transmission is always initiated by software, which is the passed down through the MAC,
through the digital and analog baseband, and finally to the RF chip. Several special packets
are initiated by the MAC. These are the only ways the digital baseband portion will turn on
the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter
will be on only while one of the aforementioned packets is being transmitted. In other words,
this device automatically discontinue transmission in case of either absence of information to
transmit or operational failure.
This device is master equipment, 5.15-5.25GHz, 5.58-5.66GHz band is restricted to indoor
operations only.
Frequency Tolerance: ± 50 ppm (2.4GHz band), ± 20 ppm (5GHz band)
Radio Frequency (RF) Exposure Warning
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled en-
vironment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to
OET65. This equipment should be installed and operated keeping the radiator at least 20cm
or more away from person’s body (excluding extremities: hands, wrists, feet and ankles).
MEDICAL:
Consult the manufacturer of any personal medical devices, such as pacemakers, to determine
if they are adequately shielded from external RF (radio frequency) energy. The unit operates
in the frequency range of 2.412 GHz to 2.462 GHz and/or 5.180 GHz to 5.85 GHz.
Do not use the unit in health care facilities if any regulations posted in the area instruct you
not to do so. Hospitals or health care facilities may be using equipment that could be sensitive
to external RF (radio frequency) energy.
.
body.
3
For Canada
<IC Information>
Information to to Be Supplied to the End User by the Installer or Integrator
If the IC ID of this module is not visible from the outside of the end product, to satisfy IC exte-
rior labeling requirements, the end product must be labeled in a visible area with the following:
“Contains IC: 216A-WJVR3004”
The following regulatory and safety notices must be published in documentation supplied
to the end user of the product or system incorporating an adapter in compliance with local
regulations.
Informations à fournir à l’utilisateur final par l’installateur ou l’intégrateur
Afin de satisfaire les exigences en matière d’étiquetage externe IC, si l’identification IC de ce
module n’est pas visible sur le produit final, celui-ci doit être muni d’une étiquette apposée
dans une zone visible avec les indications suivantes : “Contient IC : 216A-WJVR3004”
Les consignes de contrôle et de sécurité suivantes doivent être publiées dans la documenta-
tion fournie à l’utilisateur final du produit ou du système intégrant un adaptateur conformé-
ment aux règlements locaux.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired opera-
tion of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1)
l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le
fonctionnement.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna
of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To
reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that neces-
sary for successful communication.
Conformément à la réglementation d’Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d’un type et d’un gain maximal (ou inférieur) approuvé pour
l’émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélec-
trique à l’intention des autres utilisateurs, il faut choisir le type d’antenne et son gain de sorte
que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l’intensité néces-
saire à l’établissement d’une communication satisfaisante.
Printed in Japan
© Panasonic System Networks Co., Ltd. 2014 PaF0514-0 PGQW1597ZA Imprime au Japon
For Canada
<IC Information>
5.15-5.25GHz band is restricted to indoor operations only.
La bande 5 150-5 250 MHz est restreints à une utilisation à l’intérieur.
Radio Frequency (RF) Exposure Warning
This equipment complies with IC radiation exposure limits set forth for an uncontrolled en-
vironment and meets RSS-102 of the IC radio frequency (RF) Exposure rules. This equip-
ment should be installed and operated keeping the radiator at least 20cm or more away from
person’s body (excluding extremities: hands, wrists, feet and ankles).
Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un
environnement non contrôlé et respecte les règles d’exposition aux fréquences radioélec-
triques (RF) CNR-102 de l’IC. Cet équipement doit être installé et utilisé en gardant une dis-
tance de 20 cm ou plus entre le dispositif rayonnant et le corps (à l’exception des extrémités :
mains, poignets, pieds et chevilles).
body.
corps.
