OPERATING INSTRUCTIONS
Tablet Computer
Model No. FZ-Q1 series
Please read these instructions carefully before using this product, and save this
manual for future use.
Contents
Read Me First
Safety Precautions .....................................1
Regulatory Information .............................9
Getting Started
First-time Operation ..................................19
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 1DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 1 2014/01/17 12:22:172014/01/17 12:22:17
1
Read Me First
Safety Precautions
To reduce the risk of injury, loss of life,
electric shock, re, malfunction, and
damage to equipment or property,
always observe the following safety
precautions.
Explanation of symbol word
panels
The following symbol word panels are
used to classify and describe the level
of hazard, injury, and property damage
caused when the denotation is disre-
garded and improper use is performed.
DANGER
Denotes a potential hazard that will
result in serious injury or death.
WARNING
Denotes a potential hazard that could
result in serious injury or death.
CAUTION
Denotes a hazard that could result in
minor injury.
NOTICE
Denotes a hazard that could result in
property damage.
The following symbols are used to clas-
sify and describe the type of instruc-
tions to be observed.
This symbol is used to alert
users to a specic operating
procedure that must not be
performed.
This symbol is used to alert us-
ers to a specic operating pro-
cedure that must be followed in
order to operate the unit safety.
01Read Me First.indd 2 2014/02/13 11:10:18
2
Read Me First
DANGER
Precautions on the Built-in
Battery (for disposal)
<Only for model with Built-in
Battery>
When disposing the battery, gen-
eration of heat, ignition or rupture
of the Built-in Battery may result.
Handling This Computer
Do Not Disassemble the
Computer Except When
Disposing
Handling the Built-in
Battery
Do Not Short the Positive
(+) and Negative (-) Con-
tacts
Do Not Throw the Battery
into a Fire or Expose It to
Excessive Heat
Do Not Apply Shocks to
the Built-in Battery by
Dropping It, Applying
Strong Pressure to It, etc.
Do Not Charge
Do Not Use
Do Not Deform, Disassem-
ble, or Modify the Battery
Avoid Extreme Heat (Near
the Fire, in Direct Sunlight,
for Example)
01Read Me First.indd 3 2014/02/13 11:10:18
3
Read Me First
Safety Precautions
WARNING
Generation of heat, ignition or rup-
ture of the Built-in Battery may
result.
Do Not Throw This Product
Into a Fire or Expose It to
Excessive Heat
Do Not Insert Sharp Ob-
jects Into This Product,
Disassemble, or Modify It
Do Not Apply Shocks to
the Product by Dropping It,
Applying Strong Pressure
to It, etc.
Do Not Charge the Battery
Using Methods Other Than
Those Specifi ed
Avoid Extreme Heat (Near
the Fire, In Direct Sunlight,
for Example)
When the Battery Has
Deteriorated, Contact Your
Technical Support Offi ce to
Replace the Battery
WARNING
Fire or electric shock may result.
Do Not Do Anything That
May Damage the AC Cord,
the AC Plug, or the AC
Adaptor
Do not damage or modify
the cord, place it near hot
tools, bend, twist, or pull
it forcefully, place heavy
objects on it, or bundle it
tightly.
Do not continue to use
a damaged AC cord, AC
plug and AC adaptor.
• Contact your technical
support offi ce for repair.
Do Not Connect the AC
Adaptor to a Power Source
Other Than a Standard
Household AC Outlet
Connecting to a DC/AC
converter (inverter) may
damage the AC adap-
tor. On an airplane, only
connect the AC adaptor/
charger to an AC outlet
specifi cally approved for
such use.
Do Not Pull or Insert the
AC Plug If Your Hands Are
Wet
Do Not Disassemble This
Product
Do Not Touch This Product
In a Thunderstorm If Con-
nected with the AC Cable
or Any Other Cables
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 4DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 4 2014/01/17 12:22:182014/01/17 12:22:18
4
Read Me First
WARNING
If a Malfunction or Trouble
Occurs, Immediately Stop
Use
If the Following Malfunc-
tion Occurs, Immediately
Unplug the AC Plug
• This product is damaged
• Foreign object inside this
product
• Smoke emitted
• Unusual smell emitted
• Unusually hot
After the above procedure,
contact your technical sup-
port offi ce for repair.
Clean Dust and Other Debris
of the AC Plug Regularly
• If dust or other debris ac-
cumulates on the plug,
humidity, etc. may cause a
defect in the insulation.
Insert the AC Plug Com-
pletely
Do not use a damaged
plug or loose AC outlet.
Close the Connector
Cover Tightly When Using
This Product Wherever
There is a Lot of Water,
Moisture, Steam, Dust,
Oily Vapors, etc.
If foreign matter has found
its way inside, immediate-
ly turn the power off and
unplug the AC cord. Then
contact your technical
support offi ce.
WARNING
Burns or low-temperature burns
may result.
Do Not Use This Product
in Close Contact With Your
Body For a Long Period of
Time
Do not use this product
with its heat-emitting parts
in close contact with your
body for long periods of
time.
• Low-temperature burns
may result.
Do Not Touch The Surface
of The AC Adaptor Contin-
uously While Using/Charg-
ing
• Burns may result.
Detrimental health effects on your
body may result.
Do Not Turn the Volume Up
To Loud When Using Head-
phones
• Listening at high volumes
that overstimulate the ear
for long periods of time
may result in loss of hear-
ing.
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 5DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 5 2014/01/17 12:22:182014/01/17 12:22:18
5
Read Me First
Safety Precautions
CAUTION
Fire or electric shock may result.
Do Not Move This Product
While the AC Plug Is Con-
nected
If the AC cord is damaged,
unplug the AC plug imme-
diately.
Do Not Subject the AC
Adaptor To Any Strong
Impact
Do not continue to use the
AC adaptor after a strong
impact such as being
dropped.
Contact your technical
support offi ce for repair.
<Only for model with LAN>
Do Not Connect a Tele-
phone Line, or a Network
Cable Other Than the One
Specified, Into the LAN
Port
Do not connect to a net-
work such as the ones
listed below.
• Networks other than
100BASE-TX or 10BASE-T
• Phone lines (IP phone
(Internet Protocol Tele-
phone), Telephone lines,
internal phone lines (on-
premise switches), digital
public phones, etc.)
Do Not Leave This Product
in High Temperature Envi-
ronment for a Long Period
of Time
• Leaving this product where
it will be exposed to ex-
tremely high temperatures
such as near fi re or in
direct sunlight may deform
the cabinet and/or cause
trouble in the internal parts.
Hold the Plug When Un-
plugging the AC Plug
Use Only the Specified AC
Adaptor With This Product
Do not use an AC adaptor
other than the one sup-
plied (supplied with the
unit or one sold separately
as an accessory).
This product may fall over or drop,
resulting in an injury.
Do Not Place This Product
on Unstable Surfaces
Avoid Stacking
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 6DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 6 2014/01/20 9:46:562014/01/20 9:46:56
6
Read Me First
CAUTION
Detrimental health effects on your
body may result.
Take a Break Of 10-15 Min-
utes Every Hour
• Using this product for long
periods of time may have
detrimental health effects
on the eyes or hands.
Burns, low-temperature burns, or
frostbite may result.
Do Not Expose the Skin To
This Product When Using
the Product In A Hot Or
Cold Environment
When it is necessary to
expose the skin to this
product such as to scan
a fi ngerprint, perform the
operation in the shortest
time possible.
NOTICE
Do not place the computer near a
television or radio receiver.
Keep the computer away from
magnets. Data stored on the fl ash
memory may be lost.
This computer is not intended for
the display of images for use in
medical diagnosis.
This computer is not intended for
a use with connection of medical
equipment for the purpose of medi-
cal diagnosis.
Panasonic shall not be liable for
loss of data or other incidental or
consequential damages resulting
from the use of this product.
If the battery will not be used
for a long period of time (a month
or more), charge or discharge
(use) the battery until the
remaining battery level becomes
30% to 40% and store it in a cool,
dry place.
This computer prevents overcharg-
ing of the battery by recharging only
when the remaining power is less
than approx. 95% of capacity.
The battery is not charged
when the computer is fi rst pur-
chased. Be sure to charge it before
using it for the fi rst time. When the
AC adaptor is connected to the
computer, charging begins automat-
ically.
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 7DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 7 2014/01/17 12:22:182014/01/17 12:22:18
7
Read Me First
Safety Precautions
Should the battery leak and the fl uid
get into your eyes, do not rub your
eyes. Immediately fl ush your eyes
with clear water and see a doctor
for medical treatment as soon as
possible.
NOTE
The battery may become
warm during recharging or normal
use. This is completely normal.
Recharging will not commence if
internal temperature of the battery
is outside of the allowable
temperature range (0 °C to 50 °C
{32 °F to 122 °F}). (Ä Refer-
ence Manual “Battery Power”) Once
the allowable range requirement is
satisfi ed, charging begins automati-
cally. Note that the recharging time
varies based on the usage condi-
tions. (Recharging takes longer
than usual when the temperature is
10 °C {50 °F} or below.)
If the temperature is low, the operat-
ing time is shortened. Only use the
computer within the allowable tem-
perature range.
This computer has a high tempera-
ture mode function that prevents
the degradation of the battery in
high temperature environments.
(Ä Reference Manual “Battery
Power”) A level corresponding to a
100% charge for high temperature
mode is approximately equivalent
to an 80% charge level for normal
temperature mode.
The battery is a consum-
able item. If the amount of time
the computer can be run by using
a particular battery becomes
dramatically shorter and repeated
recharging does not restore its
per-formance, the battery should
be replaced with a new one.
Always power off the computer
when it is not in use. Leaving the
computer on when the AC adaptor
is not connected will exhaust the
remaining battery capacity.
To minimize deterioration of the
built-in battery, connect the
computer to the AC adaptor and re-
charge it for approximately 2 hours
about once every year.
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 8DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 8 2014/01/17 12:22:182014/01/17 12:22:18
8
Read Me First
THIS PRODUCT IS NOT INTENDED
FOR USE AS, OR AS PART OF, NU-
CLEAR EQUIPMENT/SYSTEMS, AIR
TRAFFIC CONTROL EQUIPMENT/
SYSTEMS, AIRCRAFT COCKPIT
EQUIPMENT/SYSTEMS*1, MEDICAL
DEVICES OR ACCESSORIES*2, LIFE
SUPPORT SYSTEMS OR OTHER
EQUIPMENTS/DEVICES/SYSTEMS
THAT ARE INVOLVED WITH ENSUR-
ING HUMAN LIFE OR SAFETY. PAN-
ASONIC WILL NOT BE RESPONSI-
BLE FOR ANY LIABILITY RESULTING
FROM THE USE OF THIS PRODUCT
ARISING OUT OF THE FOREGOING
USES.
*1 AIRCRAFT COCKPIT EQUIPMENT/
SYSTEMS include Class2 Electronic
Flight Bag (EFB) Systems and Class1
EFB Systems when used during critical
phases of fl ight (e.g., during take-off and
landing) and/or mounted on to the aircraft.
Class1 EFB Systems and 2 EFB Systems
are defi ned by FAA: AC (Advisory Circu-
lar) 120-76A or JAA: JAA TGL (Temporary
Guidance Leafl ets) No.36.
*2 As defi ned by the European Medical
Device Directive (MDD) 93/42/EEC.
Panasonic cannot guarantee any
specifi cations, technologies, reliability,
safety (e.g. Flammability/Smoke/Tox-
icity/Radio Frequency Emission, etc)
requirements related to aviation stan-
dards that exceed the specifi cations of
our COTS (Commercial-Off-The-Shelf)
products.
This computer is not intended for use
in medical equipment including life-
support systems, air traffi c control sys-
tems, or other equipment, devices or
systems that are involved with ensuring
human life or safety. Panasonic cannot
be held responsible in any way for any
damages or loss resulting from the use
of this unit in these types of equipment,
devices or systems, etc.
This computer has been designed so
as to minimize shock to the LCD and
fl ash memory drive, etc., but no war-
ranty is provided against such trouble.
Therefore, as a precision instrument,
be extremely careful in the handling.
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 9DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 9 2014/01/17 12:22:182014/01/17 12:22:18
9
Read Me First
<Only for model with wireless LAN/Blue-
tooth/wireless WAN>
This product and your Health
This product, like other radio devices,
emits radio frequency electromagnetic
energy. The level of energy emitted by
this product however is far much less
than the electromagnetic energy emit-
ted by wireless devices like for exam-
ple mobile phones.
Because this product operates within
the guidelines found in radio frequency
safety standards and recommenda-
tions, we believe this product is safe for
use by consumers. These standards
and recommendations refl ect the con-
sensus of the scientifi c community and
result from deliberations of panels and
committees of scientists who continu-
ally review and interpret the extensive
research literature.
In some situations or environments, the
use of this product may be restricted by
the proprietor of the building or respon-
sible representatives of the organiza-
tion. These situations may for example
include:
Using this product on board of air-
planes, or
In any other environment where the
risk of interference to other devices
or services is perceived or identifi ed
as harmful.
If you are uncertain of the policy that
applies on the use of wireless devices
in a specifi c organization or environ-
ment (e.g. airports), you are encour-
aged to ask for authorization to use this
product prior to turning on the product.
Regulatory Information
We are not responsible for any radio or
television interference caused by un-
authorized modifi cation of this product.
The correction of interference caused
by such unauthorized modifi cation will
be the responsibility of the user. We
and its authorized resellers or distribu-
tors are not liable for damage or viola-
tion of government regulations that
may arise from failing to comply with
these guidelines. 26-M-1
<Uniquement pour les modèles avec
réseau local sans fi l et/ou Bluetooth>
Ce produit et votre santé
Ce produit, comme tout autre appareil
radio, émet de l’énergie radioélectrique.
Toutefois, la quantité d’énergie émise
par ce produit est beaucoup moins im-
portante que l’énergie radioélectrique
émise par des appareils sans fi l tels
que les téléphones portables. L’utilisa-
tion de ce produit ne comporte aucun
risque pour le consommateur du fait
que cet appareil opère dans les limites
des directives concernant les normes
et les recommendations de sécurité sur
les fréquences radio. Ces normes et
recommandations refl ètent le consen-
sus de la communauté scientifi que et
résultent de délibérations de jurys et
comités de scientifi ques qui examinent
et interprètent continuellement les nou-
veautés de la vaste littérature sur les
recherches effectuées. Dans certaines
situations ou environnements, l’utilisa-
tion de ce produit peut être restreinte
par le propriétaire du bâtiment ou par
les représentants responsables de l’or-
ganisation. Ces situations peuvent être
les suivantes par exemple :
A bord d’un avion, ou
Dans tout autre environnement
où les risques d’interférence sur
d’autres appareils ou services sont
perçus ou identifi ables comme dan-
gereux.
Si vous n’êtes pas sûr de la réglemen-
tation applicable à l’utilisation d’ap-
pareils sans fi l dans une organization
Information to the User / Informations destinées aux utilisateurs
Regulatory Information
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 10DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 10 2014/01/17 12:22:182014/01/17 12:22:18
10
Read Me First
ou un environnement spécifi que, (par
exemple dans un aéroport) nous vous
invitons à demander l’autorisation
d’utiliser ce produit avant sa mise en
marche.
Informations concernant la régle-
mentation
Nous déclinons toute responsabilité
pour toute interférence radio ou télévi-
sion causée par des modifi cations non
autorisées apportées à ce produit. La
correction d’interférences causées par
de telles modifi cations non autorisées
sera la seule responsabilité de son uti-
lisateur. Nousmêmes, les revendeurs
offi ciels et les distributeurs ne sommes
pas responsable de tout dégât ou de
toute violation des règlements de l’État
pouvant découler du non-respect de
ces directives. 26-F-1
Lithium Battery / Pile au lithium
Lithium Battery!
This computer contains a lithium battery
to enable the date, time, and other data
to be stored. The battery should only be
exchanged by authorized service per-
sonnel.
Warning!
A risk of explosion from incorrect instal-
lation or misapplication may possibly
occur. 15-E-1
Pile au lithium!
Le micro-ordinateur renferme une pile
au lithium qui permet de sauvegarder
certaines données, notamment la date
et l’heure. La pile ne doit être rempla-
cée que par un technicien qualifi é.
Danger !
Risque d’explosion en cas de non res-
pect de cette mise en garde! 15-F-1
Information for Users on Collection and Disposal of
Old Equipment and used Batteries
These symbols are only valid in the European Union.
If you wish to discard this product, please contact your local
authorities or dealer and ask for the correct method of dis-
posal. 53-M-1
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 11DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 11 2014/01/17 12:22:182014/01/17 12:22:18
11
Read Me First
Regulatory Information
<Only for model with wireless WAN>
The following safety precautions must be observed during all phases of the opera-
tion, usage, service or repair of any Personal Computer or Handheld Computer
incorporating wireless WAN modem. Manufacturers of the cellular terminal are
advised to convey the following safety information to users and operating person-
nel and to incorporate these guidelines into all manuals supplied with the prod-
uct. Failure to comply with these precautions violates safety standards of design,
manufacture and intended use of the product. Panasonic assumes no liability for
customer failure to comply with these precautions.
When in a hospital or other health care facility, observe the restrictions
on the use of mobiles. Switch Personal Computer or Handheld Computer
incorporating wireless WAN modem off, if instructed to do so by the guide-
lines posted in sensitive areas. Medical equipment may be sensitive to RF
energy.
The operation of cardiac pacemakers, other implanted medical equipment
and hearing aids can be affected by interference from Personal Computer
or Handheld Computer incorporating wireless WAN modem placed close
to the device. If in doubt about potential danger, contact the physician or
the manufacturer of the device to verify that the equipment is properly
shielded. Pacemaker patients are advised to keep their Personal Computer
or Handheld Computer incorporating wireless WAN modem away from the
pacemaker, while it is on.
Switch off Personal Computer or Handheld Computer incorporating wire-
less WAN modem before boarding an aircraft. Make sure it cannot be
switched on inadvertently. The operation of wireless appliances in an
aircraft is forbidden to prevent interference with communications systems.
Failure to observe these instructions may lead to the suspension or denial
of cellular services to the offender, legal action, or both.
For details on usage of this unit in aircrafts please consult and follow in-
struction provided by the airline.
Do not operate Personal Computer or Handheld Computer incorporat-
ing wireless WAN modem in the presence of fl ammable gases or fumes.
Switch off the cellular terminal when you are near petrol stations, fuel de-
pots, chemical plants or where blasting operations are in progress. Opera-
tion of any electrical equipment in potentially explosive atmospheres can
constitute a safety hazard.
Safety Precautions
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 12DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 12 2014/01/17 12:22:182014/01/17 12:22:18
12
Read Me First
Your Personal Computer or Handheld Computer incorporating wire-
less WAN modem receives and transmits radio frequency energy while
switched on. Remember that interference can occur if it is used close to
TV sets, radios, computers or inadequately shielded equipment. Follow
any special regulations and always switch off Personal Computer or Hand-
held Computer incorporating wireless WAN modem wherever forbidden,
or when you suspect that it may cause interference or danger.
Road safety comes fi rst! Do not use a Personal Computer or Handheld
Computer incorporating wireless WAN modem while driving a vehicle. Do
not place the computer with wireless WAN modem in an area where it
could cause personal injury to the driver or passengers. It is recommend-
ed to stow the unit in the boot or secure stowage area while driving.
Do not place the computer with wireless WAN modem in an area over an
air bag or in the vicinity where an air bag may deploy.
Air bags infl ate with great force and if the computer with wireless WAN
modem is placed in the air bag deployment area may be propelled with
great force and cause serious injury to occupants of the vehicle.
IMPORTANT!
Personal Computer or Handheld Computer incorporating wireless WAN
modem operate using radio signals and cellular networks cannot be guar-
anteed to connect in all conditions. Therefore, you should never rely solely
upon any wireless device for essential communications, for example
emergency calls.
Remember, in order to make or receive calls, Personal Computer or Hand-
held Computer incorporating wireless WAN modem must be switched on
and in a service area with adequate cellular signal strength.
Some networks do not allow for emergency calls if certain network ser-
vices or phone features are in use (e.g. lock functions, fi xed dialing etc.).
You may need to deactivate those features before you can make an emer-
gency call.
Some networks require that a valid SIM card be properly inserted in Per-
sonal Computer or Handheld Computer incorporating wireless WAN mo-
dem.
CAUTION:
Risk of Explosion if Battery is replaced by an Incorrect Type.
Dispose of Used Batteries According to the Instructions.
58-E-1
ATTENTION:
Il y a risque d’explosion si la batterie est remplacée par une batterie de type incorrect.
Mettre au rebut les batteries usagées conformément aux instructions.
58-F-1
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 13DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 13 2014/01/17 12:22:192014/01/17 12:22:19
13
Read Me First
Regulatory Information
For U.S.A.
Federal Communications Commis-
sion Radio Frequency Interference
Statement
Note: This equipment has been tested
and found to comply with the limits for
a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits
are designed to provide reasonable
protection against harmful interference
in a residential installation. This equip-
ment generates, uses and can radi-
ate radio frequency energy and, if not
installed and used in accordance with
the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particu-
lar installation. If this equipment does
cause harmful interference to radio or
television reception, which can be de-
termined by turning the equipment off
and on, the user is encouraged to try to
correct the interference by one or more
of the following measures:
Reorient or relocate the receiving
antenna.
Increase the separation between
the equipment and receiver.
Connect the equipment into an out-
let on a circuit different from that to
which the receiver is connected.
Consult the Panasonic Service
Center or an experienced radio/TV
technician for help.
Warning
To assure continued compliance, use
only shielded interface cables when
connecting to a computer or peripheral.
Also, any changes or modifi cations not
expressly approved by the party re-
sponsible for compliance could void the
user’s authority to operate this equip-
ment.
FCC RF Exposure Warning:
This equipment is provided with PC
Card slot that could be used with
wireless transmitters, which will be
specifi cally recommended when they
become available.
Other third-party wireless transmit-
ters have not been RF exposure
evaluated for use with this computer
and may not comply with FCC RF
exposure requirements.
<Only for model with wireless LAN/wire-
less WAN/Bluetooth>
This equipment complies with FCC
radiation exposure limits set forth
for an uncontrolled environment.
This equipment may not be co-
located or operated with any other
antenna or transmitter.
Camera Light
<For model with rear camera>
CAUTION
- The light from the LED is strong and can injure human eyes. Do not look directly
at the LEDs with naked eyes. 57-E-1
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 14DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 14 2014/01/17 12:22:192014/01/17 12:22:19
14
Read Me First
This device meets the government’s
requirements for exposure to radio
waves.
This device is designed and manu-
factured not to exceed the emission
limits for exposure to radio frequen-
cy (RF) energy set by the Federal
Communications Commission of the
U.S. Government.
The exposure standard for wireless
device employs a unit of measure-
ment known as the Specifi c Absorp-
tion Rate, or SAR. The SAR limit set
by the FCC is 1.6 W/kg.
* Tests for SAR are conducted us-
ing standard operating positions
accepted by the FCC with the
device transmitting at its highest
certifi ed power level in all tested
frequency bands.
Although the SAR is determined
at the highest certifi ed power
level, the actual SAR level of the
device while operating can be well
below the maximum value. This is
because the device is designed to
operate at multiple power levels
so as to use only the poser re-
quired to reach the network. In
general, the closer you are to a
wireless base station antenna, the
lower the power output.
<Only for model with wireless LAN>
This product is restricted to indoor
use due to its operation in the 5.15
to 5.25 GHz frequency range. FCC
requires this product to be used in-
doors for the frequency range 5.15 to
5.25 GHz to reduce the potential for
harmful interference to co-channel
Mobile Satellite systems. High power
radars are allocated as primary users
of the 5.25 to 5.35 GHz and 5.65 to
5.85 GHz bands. These radar stations
can cause interference with and/or
damage this product.
25-M-W-1
This device complies with Part 15 of
the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful
interference, and
(2)
This device must accept any interfer-
ence received, including interference
that may cause undesired operation.
Responsible Party:
Panasonic Corporation of North
America
Two Riverfront Plaza
Newark, NJ 07102
Support Contact:
http://www.panasonic.com/
contactinfo
6-M-1
FCC RF Exposure Warning:
This equipment is provided with
external antenna connector(s) for
connection to optional Car Mounter
or Port Replicator for mobile exter-
nal mounted antenna(s). External
antenna(s) must be professionally
installed and cannot exceed recom-
mended maximum antenna gain
as described in individual provided
supplement instructions for wireless
transmitters. The Car Mounter is
provided with Radiall/Larsen WLAN
whip antenna, type NMO5E2400B-
KTNC with 5dBi antenna gain.
The maximum allowable antenna
gain for the external WWAN base
whip antenna for the cellular band
is 4 dBi, PCS band is 3 dBi, LTE
Band 4 is 3 dBi, LTE Band 17 is
9 dBi and 10 dBi for LTE Band 13.
Also, user must maintain minimum
20 cm spacing between external
antenna(s) and all person’s body
(excluding extremities of hands,
wrist and feet) during wireless
modes of operation. 32-M-1
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 15DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 15 2014/01/17 12:22:192014/01/17 12:22:19
15
Read Me First
Regulatory Information
USA Only: Disposal may be regulated
in your community due to environmental
considerations. For disposal or recycling
information, please visit Panasonic web-
site: http://www.panasonic.com/environ-
mental or call 1-888-769-0149 65-M-2
<For USA-California Only>
This product contains a CR Coin Cell
Lithium Battery which contains Per-
chlorate Material - special handling may
apply.
See www.dtsc.ca.gov/hazardouswaste/
perchlorate/
38-M-1
<For USA and Canada>
A lithium ion battery
that is recyclable
powers the product
you have purchased.
Please call
1-800-8-BATTERY for
information on how to
recycle this battery.
L’appareil que vous
vous êtes procuré est
alimenté par une bat-
terie au lithium-ion.
Pour des renseigne-
ments sur le recy-
clage de la batterie,
veuillez composer le
1-800-8-BATTERY.
48-M-1
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 16DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 16 2014/01/17 12:22:192014/01/17 12:22:19
16
Read Me First
For Canada / Pour le Canada
Canadian ICES-003
CAN ICES-003(B) / NMB-003(B) 7-M-3
<Only for model with wireless LAN/
Bluetooth>
Industry Canada
This product complies with RSS247
Industry Canada.
Operation is subject to the following
two conditions;
(1) this device may not cause interfer-
ence, and
(2) this device must accept any inter-
ference, including interference that
may cause undesired operation of
the device.
<Ne s’applique qu’aux modèles avec
technologie Bluetooth/LAN sans fi l>
Industrie Canada
Cet équipement est conforme à la
norme CNR-247 d’Industrie Canada.
Son fonctionnement est soumis aux
deux conditions suivantes :
(1) ce dispositif ne peut produire de
brouillage, et
(2) ce dispositif doit accepter le brouilla-
ge, y compris le brouillage pouvant
entraîner le fonctionnement non
désiré de l’appareil. 30-Ca-1-1
<Only for model with wireless LAN>
This product (local network devices) for
the band 5150-5250 MHz is only indoor
usage to reduce potential for harmful
interference to co-channel Mobile Satel-
lite systems.
High power radars are allocated as
primary users (meaning they have
priority) of 5250-5350 MHz and 5650-
5850 MHz and these radars could
cause interference and/or damage to
LELAN devices.
<Ne s’applique qu’aux modèles avec
technologie LAN sans fi l>
Cet appareil (pour réseaux locaux
radioélectriques) dans les bandes de
fréquences 5150-5250 MHz est réser-
vé à une utilization à l’intérieur afi n de
réduire le risque d’interférence avec les
systèmes satellites mobiles bicanaux.
Les radars forte puissance sont dési-
gnés comme étant les premiers utili-
sateurs (c’est-à-dire qu’ils ont la prio-
rité) des bandes de fréquences 5250-
5350 MHz et 5650-5850 MHz. Ces
stations radars peuvent provoquer des
interférences et/ou des dommages à
ce périphérique. 30-Ca-2-1
<Only for model with wireless LAN/
wireless WAN/Bluetooth>
This computer complies with Indus-
try Canada radiation exposure limits
set forth for an uncontrolled environ-
ment.
This PC with WLAN and/or Blue-
tooth transmitters installed, has
been approved for portable opera-
tion and does not require any mini-
mum spacing be provided between
antennas and all person’s body.
<Ne s’applique qu’aux modèles avec
technologie Bluetooth/LAN sans fi l/
WAN sans fi l>
Cet équipement est conforme aux
limites d’exposition aux rayonne-
ments d’Industrie Canada établies
pour un environnement non contrô-
lé.
Ce PC avec émetteurs WLAN et/ou
Bluetooth a été approuvé à des fi ns
d’opération mobile; aucun espace
minimum entre les antennes et le
corps de l’utilisateur n’est requis.
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 17DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 17 2014/01/17 12:22:192014/01/17 12:22:19
17
Read Me First
Regulatory Information
This device has been designed to oper-
ate with the WWAN antenna having a
maximum gain of 4 dBi for the 850 MHz
band, 3 dBi for the 1700
MHz
band and
3 dBi for the 1900
MHz
band. WWAN
Antenna having a higher gain is strictly
prohibited per regulations of Industry
Canada. The Required antenna imped-
ance is 50 ohms.
To reduce potential radio interference
to other users, the antenna type and
its gain should be so chosen that the
equivalent isotropically radiated power
(EIRP) is not more than that required
for successful communication.
<Utilisation au Canada>
Ce dispositif a été conçu pour fonc-
tionner avec l’antenne de réseau
étendu sans fi l (WWAN) avec un gain
maximum de 4 dBi dans la bande
de 850 MHz, 3 dBi dans la bande de
1 700 MHz et 3 dBi dans la bande de
1 900 MHz. Les règlements d’Industrie
Canada interdisent l’utilisation d’une
antenne WWAN dont le gain serait
supérieur à cette limite. L’antenne doit
avoir une impédance de 50 ohms.
Afi n de réduire le risque d’interférence
radioélectrique aux autres utilisateurs
des bandes de fréquences, le type
d’antenne et son gain doivent être
tels que la puissance isotrope rayon-
née équivalente (PIRE) n’est pas plus
élevée que le niveau requis pour as-
surer la communication. 32-Ca-1-1
FOR USE WITH MODEL NO. :
CF-AA6373A
POUR UTILISER AVEC MODÈLE :
CF-AA6373A 20-Ca-1
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 18DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 18 2014/01/17 12:22:192014/01/17 12:22:19
18
Read Me First
For India
For the purpose of recycling to facilitate effective utilization of resources,
please return this product to a nearby authorized collection center, regis-
tered dismantler or recycler, or Panasonic service center when disposing
of this product.
Please see the Panasonic website for further information on collection
centers, etc.
http://www.panasonic.co.in/wps/portal/home 68-M-1
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 19DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 19 2014/01/17 12:22:192014/01/17 12:22:19
19
Getting Started
First-time Operation
Setup of Windows will take approximately
5 minutes / 20 minutes.
Go to the next step, confi rming each message on
the display.
Follow the steps below.
A When “Enable sensors” is displayed, touch [En-
able this sensor].
B When the [User Account Control] screen is dis-
played, touch [Yes].
C At the [Display Rotation Tool] confi rmation
screen, touch [Yes].
The computer restarts automatically, and the set-
ting is enabled.
You can set the Wireless Network after the setup of
Windows is complete.
If “Get online” is displayed, you can
select “Skip this step”.
“Join a wireless network” screen may
not appear.
CAUTION
You can change the user name, password, image and
security setting after setup of Windows.
Remember your password. If you forget the password,
you cannot use Windows. Creating a password reset
disk beforehand is recommended.
Do not use the following words for user name: CON,
PRN, AUX, CLOCK$, NUL, COM1 to COM9, LPT1 to
LPT9, @, &, space. In particular, if you create a user
name (account name) that includes the “@” mark, a
password will be requested at the log-on screen, even
if no password has been set. If you try to log on with-
out entering a password, “The user name or password
is incorrect.” may be displayed and you will not be
able to sign in / log on to
Windows .
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 28DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 28 2014/01/17 12:22:202014/01/17 12:22:20
20
5 Create the recovery disc.
A recovery disc allows you to install OS and restore
its factory default condition, in case, for example, the
recovery partition of the fl ash memory is damaged.
We recommend creating a recovery disc before you
begin using the computer.
Refer to Reference Manual “Recovery Disc
Creation Utility” about creating the disc.
DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 29DFQW5887ZAT_FZ-M1mk1-OI_8.1_M.indb 29 2014/01/17 12:22:202014/01/17 12:22:20
Panasonic Corporation
Osaka, Japan
Panasonic System Communications Company of North America
Two Riverfront Plaza,
Newark NJ 07102
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga,
Ontario L4W 2T3
Panasonic Australia Pty. Limited
ACN 001 592 187 ABN 83 001 592 187
1 Innovation Road, Macquarie Park NSW 2113
Web Site : http://panasonic.net/
© Panasonic Corporation 2015
Printed in Taiwan

Navigation menu
