OPERATING INSTRUCTIONS
Read Me First
Tablet Computer
Model No. FZ-G1 series
Getting Started
First-time Operation .....................................17
Read Me First
Safety Precautions .........................................2
Regulatory Information ...................................8
A2
A1
Please read these instructions carefully before using this product, and save this manual for future use.
Getting Started Read Me First
In these instructions, the names and terms are referred as follows.
: Conditions that may result in minor or moderate injury.
: Useful and helpful information.
“Windows® 8.1 Update Pro 64-bit” as “Windows” or “Windows 8.1”
“Windows® 7 Professional 32-bit Service Pack 1” and “Windows® 7 Professional 64-bit Ser-
vice Pack 1” as “Windows” or “Windows 7”
indicates Windows® 8.1 Operating System.
indicates Windows® 7 Operating System.
Refer to the OPERATING INSTRUCTIONS - Basic Guide by downloading from the following URL.
URL Ø
http://pc-dl.panasonic.co.jp/itn/manual/menu_en.html
n Terms and illustrations in these instructions
CAUTION
NOTE
2
Read Me First
Safety Precautions
To reduce the risk of injury, loss of life, elec-
tric shock, re, malfunction, and damage to
equipment or property, always observe the
following safety precautions.
Explanation of symbol word panels
The following symbol word panels are used
to classify and describe the level of hazard,
injury, and property damage caused when the
denotation is disregarded and improper use is
performed.
DANGER
Denotes a potential hazard that will result in
serious injury or death.
WARNING
Denotes a potential hazard that could result
in serious injury or death.
CAUTION
Denotes a hazard that could result in minor
injury.
NOTICE
Denotes a hazard that could result in prop-
erty damage.
The following symbols are used to classify
and describe the type of instructions to be
observed.
This symbol is used to alert users to
a specic operating procedure that
must not be performed.
This symbol is used to alert users to
a specic operating procedure that
must be followed in order to operate
the unit safety.
DANGER
Precautions on the Battery Pack
Electrolyte leakage, generation of heat,
ignition or rupture of the Battery Pack
may result.
nDo Not Throw the Battery Pack
into a Fire or Expose It to Exces-
sive Heat
nDo Not Deform, Disassemble, or
Modify the Battery Pack
nDo Not Short the Positive (+) and
Negative (-) Contacts
ÖDo not place the battery pack
together with articles such as
necklaces or hairpins when carry-
ing or storing.
nDo Not Apply Shocks to the
Product by Dropping It, Applying
Strong Pressure to It, etc.
ÖIf this product is subjected to
a strong impact, damaged or
deformed, stop using it immedi-
ately.
nDo Not Charge the Battery Using
Methods Other Than Those Spec-
ied
nDo Not Use the Battery Pack with
Any Other Product
• The battery pack is rechargeable
and was intended for the specied
product.
nDo Not Use This Product with a
Battery Pack Other Than the One
Specied
ÖUse only the specied battery
pack with your product.
nWhen the Battery Pack Has De-
teriorated, Replace It With a New
One
ÖDo not continue to use a dam-
aged battery pack.
nAvoid Extreme Heat (Near the
Fire, in Direct Sunlight, for Ex-
ample)
3
Read Me First
DANGER
Precautions on the Built-in Bridge
Battery (for disposal)
<Only for model with Built-in Bridge Bat-
tery>
When disposing the battery, generation
of heat, ignition or rupture of the Built-in
Bridge Battery may result.
Handling This Computer
nDo Not Disassemble the Com-
puter Except When Disposing
Handling the Built-in Bridge Battery
nDo Not Short the Positive (+) and
Negative (-) Contacts
nDo Not Throw the Battery into
a Fire or Expose It to Excessive
Heat
nDo Not Apply Shocks to the Built-
in Bridge Battery by Dropping It,
Applying Strong Pressure to It,
etc.
nDo Not Charge
nDo Not Use
nDo Not Deform, Disassemble, or
Modify the Built-in Bridge Battery
nAvoid Extreme Heat (Near the
Fire, in Direct Sunlight, for Ex-
ample)
WARNING
<Only for model with Built-in Bridge Bat-
tery>
Generation of heat, ignition or rupture of
the Built-in Bridge Battery may result.
nDo Not Throw This Product Into
a Fire or Expose It to Excessive
Heat
nDo Not Deform, Disassemble, or
Modify This Product
nDo Not Apply Shocks to the
Product by Dropping It, Applying
Strong Pressure to It, etc.
nDo Not Charge the Battery Using
Methods Other Than Those Spec-
ied
nAvoid Extreme Heat (Near the
Fire, In Direct Sunlight, for Ex-
ample)
nWhen the Battery Has Deteriorat-
ed, Contact Your Technical Sup-
port Ofce to Replace the Battery
4
Read Me First
Safety Precautions
WARNING
Fire or electric shock may result.
nDo Not Do Anything That May
Damage the AC Cord, the AC
Plug, or the AC Adaptor
Do not damage or modify the
cord, place it near hot tools,
bend, twist, or pull it forcefully,
place heavy objects on it, or
bundle it tightly.
ÖDo not continue to use a dam-
aged AC cord, AC plug and AC
adaptor.
• Contact your technical support
ofce for repair.
nDo Not Connect the AC Adaptor
to a Power Source Other Than a
Standard Household AC Outlet
ÖConnecting to a DC/AC converter
(inverter) may damage the AC
adaptor. On an airplane, only
connect the AC adaptor/charger
to an AC outlet specically ap-
proved for such use.
nDo Not Pull or Insert the AC Plug
If Your Hands Are Wet
nDo Not Disassemble This Prod-
uct
nDo Not Touch This Product In
a Thunderstorm If Connected
with the AC Cable or Any Other
Cables
nIf a Malfunction or Trouble Oc-
curs, Immediately Stop Use
If the Following Malfunction Oc-
curs, Immediately Unplug the
AC Plug and the Battery Pack
• This product is damaged
• Foreign object inside this prod-
uct
• Smoke emitted
• Unusual smell emitted
• Unusually hot
ÖAfter the above procedure, con-
tact your technical support ofce
for repair.
nClean Dust and Other Debris of the
AC Plug Regularly
• If dust or other debris accumu-
lates on the plug, humidity, etc.
may cause a defect in the insula-
tion.
nInsert the AC Plug Completely
ÖDo not use a damaged plug or
loose AC outlet.
nClose the Connector Cover
Tightly When Using This Product
Where is a Lot of Water, Mois-
ture, Steam, Dust, Oily Vapors,
etc.
ÖIf foreign matter has found its
way inside, immediately turn
the power off and unplug the
AC cord, and then remove the
battery pack. Then contact your
technical support ofce.
5
Read Me First
WARNING
Burns or low-temperature burns may
result.
nDo Not Use This Product in Close
Contact With Your Body For a
Long Period of Time
ÖDo not use this product with
its heat-emitting parts in close
contact with your body for long
periods of time.
• Low-temperature burns may re-
sult.
nDo Not Expose Yourself or Other
Persons to the Hot Wind from the
Ventilation Hole (Exhaust) For a
Long Period of Time
• Depending on the direction of the
computer or the way you hold the
computer, your hands and body
will be more exposed to the hot
wind.
• Covering the ventilation hole
(exhaust) with your hand or other
object can cause heat to build up
inside, possibly resulting in burns.
nDo Not Touch The Surface of The
AC Adaptor Continuously While
Using/Charging
• Burns may result.
• Do Not Place the Product in a Bag
or Case While It is Turned On
• Doing so may cause the product
to overheat and result in burns.
Detrimental health effects on your body
may result.
nDo Not Turn the Volume Up To
Loud When Using Headphones
• Listening at high volumes that
overstimulate the ear for long
periods of time may result in loss
of hearing.
CAUTION
Fire or electric shock may result.
nDo Not Move This Product While
the AC Plug Is Connected
ÖIf the AC cord is damaged, un-
plug the AC plug immediately.
nDo Not Subject the AC Adaptor
To Any Strong Impact
ÖDo not continue to use the AC
adaptor after a strong impact
such as being dropped.
ÖContact your technical support
ofce for repair.
<Only for model with LAN>
nDo Not Connect a Telephone
Line, or a Network Cable Other
Than the One Specified, Into the
LAN Port
ÖDo not connect to a network such
as the ones listed below.
• Networks other than
1000BASE-T, 100BASE-TX or
10BASE-T
• Phone lines (IP phone (Internet
Protocol Telephone), Telephone
lines, internal phone lines (on-
premise switches), digital public
phones, etc.)
nDo Not Leave This Product in
High Temperature Environment
for a Long Period of Time
• Leaving this product where it will
be exposed to extremely high
temperatures such as near re or
in direct sunlight may deform the
cabinet and/or cause trouble in
the internal parts.
nDo Not Block the Ventilation Hole
(Exhaust/Intake)
ÖDo not use this product wrapped
in cloth or on top of bedding or a
blanket.
6
Read Me First
Safety Precautions
CAUTION
Fire or electric shock may result.
nHold the Plug When Unplugging
the AC Plug
nUse Only the Specified AC Adap-
tor With This Product
ÖDo not use an AC adaptor other
than the one supplied (supplied
with the unit or one sold sepa-
rately as an accessory).
This product may fall over or drop, result-
ing in an injury.
nDo Not Place This Product on
Unstable Surfaces
nAvoid Stacking
Detrimental health effects on your body
may result.
nTake a Break Of 10-15 Minutes
Every Hour
• Using this product for long peri-
ods of time may have detrimen-
tal health effects on the eyes or
hands.
Burns, low-temperature burns, or frost-
bite may result.
nDo Not Expose the Skin To This
Product When Using the Product
In A Hot Or Cold Environment
ÖWhen it is necessary to expose
the skin to this product such as
to scan a ngerprint, perform the
operation in the shortest time
possible.
NOTICE
l Do not place the computer near a televi-
sion or radio receiver.
l Keep the computer away from magnets.
Data stored on the ash memory may be
lost.
l This computer is not intended for the dis-
play of images for use in medical diagno-
sis.
l This computer is not intended for a use
with connection of medical equipment for
the purpose of medical diagnosis.
l Panasonic shall not be liable for loss of
data or other incidental or consequential
damages resulting from the use of this
product.
l Do not touch the terminals on the battery
pack. The battery pack may no longer
function properly if the contacts are dirty or
damaged.
l Do not expose the battery pack to water,
or allow it to become wet.
l If the battery pack will not be used for a
long period of time (a month or more),
charge or discharge (use) the battery pack
until the remaining battery level becomes
30% to 40% and store it in a cool, dry
place.
l This computer prevents overcharging of
the battery by recharging only when the
remaining power is less than approx. 95%
of capacity.
l The battery pack is not charged when the
computer is rst purchased. Be sure to
charge it before using it for the rst time.
When the AC adaptor is connected to the
computer, charging begins automatically.
l Should the battery leak and the uid get
into your eyes, do not rub your eyes. Im-
mediately ush your eyes with clear water
and see a doctor for medical treatment as
soon as possible.
7
Read Me First
NOTE
l The battery pack may become warm dur-
ing recharging or normal use. This is com-
pletely normal.
l Recharging will not commence if internal
temperature of the battery pack is outside
of the allowable temperature range (0 °C to
50 °C {32 °F to 122 °F}). ( Reference
Manual “Battery Power”) Once the allow-
able range requirement is satised, charg-
ing begins automatically. Note that the
recharging time varies based on the usage
conditions. (Recharging takes longer than
usual when the temperature is 10 °C {50 °F}
or below.)
l If the temperature is low, the operating
time is shortened. Only use the computer
within the allowable temperature range.
l This computer has a high temperature
mode function that prevents the degra-
dation of the battery in high temperature
environments. ( Reference Manual
“Battery Power”) A level corresponding to
a 100% charge for high temperature mode
is approximately equivalent to an 80%
charge level for normal temperature mode.
l The battery pack is a consumable item.
If the amount of time the computer can
be run by using a particular battery pack
becomes dramatically shorter and re-
peated recharging does not restore its
performance, the battery pack should be
replaced with a new one.
l When transporting a spare battery inside a
package, briefcase, etc., it is recommend-
ed that it be placed in a plastic bag so that
its contacts are protected.
l Always power off the computer when it is
not in use. Leaving the computer on when
the AC adaptor is not connected will ex-
haust the remaining battery capacity.
l
<Only for model with Built-in Bridge Battery>
To minimize deterioration of the built-in
bridge battery, connect the computer to the
AC adaptor and recharge it for approxi-
mately 2 hours about once every year.
THIS PRODUCT IS NOT INTENDED FOR
USE AS, OR AS PART OF, NUCLEAR
EQUIPMENT/SYSTEMS, AIR TRAFFIC
CONTROL EQUIPMENT/SYSTEMS, AIR-
CRAFT COCKPIT EQUIPMENT/SYSTEMS*1,
MEDICAL DEVICES OR ACCESSORIES*2,
LIFE SUPPORT SYSTEMS OR OTHER
EQUIPMENTS/DEVICES/SYSTEMS THAT
ARE INVOLVED WITH ENSURING HUMAN
LIFE OR SAFETY. PANASONIC WILL NOT
BE RESPONSIBLE FOR ANY LIABILITY RE-
SULTING FROM THE USE OF THIS PROD-
UCT ARISING OUT OF THE FOREGOING
USES.
*1 AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS
include Class2 Electrical Flight Bag (EFB) Sys-
tems and Class1 EFB Systems when used dur-
ing critical phases of ight (e.g., during take-off
and landing) and/or mounted on to the aircraft.
Class1 EFB Systems and 2 EFB Systems are
dened by FAA: AC (Advisory Circular) 120-76A
or JAA: JAA TGL (Temporary Guidance Leaets)
No.36.
*2 As dened by the European Medical Device
Directive (MDD) 93/42/EEC.
Panasonic cannot guarantee any specica-
tions, technologies, reliability, safety (e.g.
Flammability/Smoke/Toxicity/Radio Fre-
quency Emission, etc.) requirements related
to aviation standards that exceed the speci-
cations of our COTS (Commercial-Off-The-
Shelf) products.
8
Read Me First
Information to the User / Informations destinées aux utilisateurs
<Only for model with wireless LAN/Bluetooth>
This product and your Health
This product, like other radio devices, emits
radio frequency electromagnetic energy. The
level of energy emitted by this product how-
ever is far much less than the electromagnetic
energy emitted by wireless devices like for
example mobile phones.
Because this product operates within the
guidelines found in radio frequency safety
standards and recommendations, we be-
lieve this product is safe for use by consum-
ers. These standards and recommendations
reect the consensus of the scientic com-
munity and result from deliberations of panels
and committees of scientists who continually
review and interpret the extensive research
literature.
In some situations or environments, the use
of this product may be restricted by the propri-
etor of the building or responsible represen-
tatives of the organization. These situations
may for example include:
l Using this product on board of airplanes,
or
l In any other environment where the risk of
interference to other devices or services is
perceived or identied as harmful.
If you are uncertain of the policy that applies
on the use of wireless devices in a specic or-
ganization or environment (e.g. airports), you
are encouraged to ask for authorization to use
this product prior to turning on the product.
Regulatory Information
We are not responsible for any radio or tele-
vision interference caused by unauthorized
modication of this product. The correction
of interference caused by such unauthorized
modication will be the responsibility of the
user. We and its authorized resellers or dis-
tributors are not liable for damage or violation
of government regulations that may arise from
failing to comply with these guidelines. 26-M-1
<Uniquement pour les modèles avec réseau
local sans l et/ou Bluetooth>
Ce produit et votre santé
Ce produit, comme tout autre appareil radio,
émet de
l’énergie radioélectrique. Toutefois, la quantité
d’énergie émise par ce produit est beaucoup
moins importante que l’énergie radioélec-
trique émise par des appareils sans l tels
que les téléphones portables. L’utilisation de
ce produit ne comporte aucun risque pour le
consommateur du fait que cet appareil opère
dans les limites des directives concernant
les normes et les recommendations de sécu-
rité sur les fréquences radio. Ces normes et
recommandations reètent le consensus de
la communauté scientique et résultent de
délibérations de jurys et comités de scienti-
ques qui examinent et interprètent continuel-
lement les nouveautés de la vaste littérature
sur les recherches effectuées. Dans certaines
situations ou environnements, l’utilisation de
ce produit peut être restreinte par le proprié-
taire du bâtiment ou par les représentants
responsables de l’organisation. Ces situations
peuvent être les suivantes par exemple :
l A bord d’un avion, ou
l Dans tout autre environnement où les
risques d’interférence sur d’autres appa-
reils ou services sont perçus ou identi-
ables comme dangereux.
Si vous n’êtes pas sûr de la réglementation
applicable à
l’utilisation d’appareils sans l dans une orga-
nization ou un environnement spécique, (par
exemple dans un aéroport) nous vous invitons
à demander l’autorisation
d’utiliser ce produit avant sa mise en marche.
Informations concernant la réglementation
Nous déclinons toute responsabilité pour
toute interférence radio ou télévision causée
par des modications non autorisées appor-
tées à ce produit. La correction
d’interférences causées par de telles modi-
cations non autorisées sera la seule respon-
sabilité de son utilisateur. Nousmêmes, les
revendeurs ofciels et les distributeurs ne
sommes pas responsable de tout dégât ou de
toute violation des règlements de l’État pou-
vant découler du non-respect de ces direc-
tives. 26-F-1
Regulatory Information
9
Read Me First
Lithium Battery / Pile au lithium
Lithium Battery!
This computer contains a lithium battery to
enable the date, time, and other data to be
stored. The battery should only be exchanged
by authorized service personnel.
Warning!
A risk of explosion from incorrect installation
or misapplication may possibly occur. 15-E-1
Pile au lithium!
Le micro-ordinateur renferme une pile au
lithium qui permet de sauvegarder certaines
données, notamment la date et l’heure. La
pile ne doit être remplacée que par un techni-
cien qualié.
Danger ! Risque d’explosion en cas de non
respect de cette mise en garde! 15-F-1
Information for Users on Collection and Disposal of Old Equip-
ment and used Batteries
These symbols are only valid in the European Union.
If you wish to discard this product, please contact your local authori-
ties or dealer and ask for the correct method of disposal. 53-M-1
Energy Star
As an ENERGY STAR® Partner, Panasonic Corporation has determined that this
product meets ENERGY STAR® guidelines for energy efciency. By enabling available
power management settings, Panasonic computers enter a low-power sleep mode
after a period of inactivity, saving the user energy.
<For U.S.A.>
To learn more about power management, please visit the web site:
www.energystar.gov/index.cfm?c=power_mgt.pr_power_management
Outline of the International ENERGY STAR® Ofce Equipment Program
The international ENERGY STAR® Ofce Equipment Program is an international
program that promotes energy saving through the use of computers and other ofce
equipment. The program backs the development and dissemination of products with
functions that effectively reduce energy consumption. It is an open system in which
business proprietors can participate voluntarily. The targeted products are ofce equip-
ment such as computers, displays, printers, facsimiles, and copiers. Their standards
and logos are uniform among participating nations.
<For U.S.A.>
For information about ENERGY STAR®, refer to the following web site:
Web Site: www.energystar.gov
22-M-1
10
Read Me First
Regulatory Information
Safety Precautions
<Only for model with wireless WAN>
The following safety precautions must be observed during all phases of the operation, usage, ser-
vice or repair of any Personal Computer or Tablet Computer incorporating wireless WAN modem.
Manufacturers of the cellular terminal are advised to convey the following safety information to
users and operating personnel and to incorporate these guidelines into all manuals supplied with
the product. Failure to comply with these precautions violates safety standards of design, manu-
facture and intended use of the product. Panasonic assumes no liability for customer failure to
comply with these precautions.
When in a hospital or other health care facility, observe the restrictions on the use of
mobiles. Switch Personal Computer or Tablet Computer incorporating wireless WAN
modem off, if instructed to do so by the guidelines posted in sensitive areas. Medical
equipment may be sensitive to RF energy.
The operation of cardiac pacemakers, other implanted medical equipment and hear-
ing aids can be affected by interference from Personal Computer or Tablet Computer
incorporating wireless WAN modem placed close to the device. If in doubt about po-
tential danger, contact the physician or the manufacturer of the device to verify that the
equipment is properly shielded. Pacemaker patients are advised to keep their Personal
Computer or Tablet Computer incorporating wireless WAN modem away from the pace-
maker, while it is on.
Switch off Personal Computer or Tablet Computer incorporating wireless WAN modem
before boarding an aircraft. Make sure it cannot be switched on inadvertently. The
operation of wireless appliances in an aircraft is forbidden to prevent interference with
communications systems. Failure to observe these instructions may lead to the suspen-
sion or denial of cellular services to the offender, legal action, or both.
For details on usage of this unit in aircrafts please consult and follow instruction pro-
vided by the airline.
Do not operate Personal Computer or Tablet Computer incorporating wireless WAN
modem in the presence of ammable gases or fumes. Switch off the cellular terminal
when you are near petrol stations, fuel depots, chemical plants or where blasting op-
erations are in progress. Operation of any electrical equipment in potentially explosive
atmospheres can constitute a safety hazard.
Your Personal Computer or Tablet Computer incorporating wireless WAN modem re-
ceives and transmits radio frequency energy while switched on. Remember that interfer-
ence can occur if it is used close to TV sets, radios, computers or inadequately shielded
equipment. Follow any special regulations and always switch off Personal Computer or
Tablet Computer incorporating wireless WAN modem wherever forbidden, or when you
suspect that it may cause interference or danger.
Road safety comes rst! Do not use a Personal Computer or Tablet Computer incor-
porating wireless WAN modem while driving a vehicle. Do not place the computer with
wireless WAN modem in an area where it could cause personal injury to the driver or
passengers. It is recommended to stow the unit in the boot or secure stowage area
while driving.
Do not place the computer with wireless WAN modem in an area over an air bag or in
the vicinity where an air bag may deploy.
Air bags inate with great force and if the computer with wireless WAN modem is placed
in the air bag deployment area may be propelled with great force and cause serious
injury to occupants of the vehicle.
11
Read Me First
IMPORTANT!
Personal Computer or Tablet Computer incorporating wireless WAN modem operate
using radio signals and cellular networks cannot be guaranteed to connect in all condi-
tions. Therefore, you should never rely solely upon any wireless device for essential
communications, for example emergency calls.
Remember, in order to make or receive calls, Personal Computer or Tablet Computer
incorporating wireless WAN modem must be switched on and in a service area with
adequate cellular signal strength.
Some networks do not allow for emergency calls if certain network services or phone
features are in use (e.g. lock functions, xed dialing etc.). You may need to deactivate
those features before you can make an emergency call.
Some networks require that a valid SIM card be properly inserted in Personal Computer
or Tablet Computer incorporating wireless WAN modem.
CAUTION:
Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries According to the
Instructions.
58-E-1
ATTENTION:
Il y a risque d’explosion si la batterie est remplacée par une batterie de type incorrect.
Mettre au rebut les batteries usagées conformément aux instructions.
58-F-1
Camera Light
<For model with rear camera>
CAUTION
- The light from the LED is strong and can injure human eyes. Do not look directly at the LEDs
with naked eyes.
57-E-1
12
Read Me First
Regulatory Information
Federal Communications Commission
Radio Frequency Interference Statement
Note: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful in-
terference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio com-
munications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television re-
ception, which can be determined by turning
the equipment off and on, the user is encour-
aged to try to correct the interference by one
or more of the following measures:
l Reorient or relocate the receiving antenna.
l Increase the separation between the
equipment and receiver.
l Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
l Consult the Panasonic Service Center or
an experienced radio/TV technician for
help.
Warning
To assure continued compliance, use only
shielded interface cables when connecting to
a computer or peripheral. Also, any changes
or modications not expressly approved by
the party responsible for compliance could
void the user’s authority to operate this equip-
ment.
FCC RF Exposure Warning:
l This equipment is provided with PC Card
slot that could be used with wireless trans-
mitters, which will be specically recom-
mended when they become available.
Other third-party wireless transmitters
have not been RF exposure evaluated for
use with this computer and may not com-
ply with FCC RF exposure requirements.
<Only for model with wireless LAN/wireless
WAN/Bluetooth>
l This equipment complies with FCC radia-
tion exposure limits set forth for an uncon-
trolled environment.
For U.S.A.
Laser Devices Caution / Précautions pour le Dispositifs Laser
<Only for model with the following label on the computer>
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
12-E-1
<Uniquement pour le modèle avec l’étiquette suivante sur l’ordinateur>
AVERTISSEMENT!
CET APPAREIL UTILISE UN LASER.
L’UTILISATION DE COMMANDES OU DE RÉGLAGES OU L’EXÉCUTION DE PROCÉDURES
AUTRES QUE CELLES SPÉCIFIÉES ICI PEUVENT PROVOQUER UNE EXPOSITION À DES
RADIATIONS DANGEREUSES.
NE PAS OUVRIR LES COUVERCLES NI ESSAYER DE RÉPARER SOI-MÊME.
CONFIER TOUT TRAVAIL D’ENTRETIEN À UN PERSONNEL QUALIFIÉ.
12-F-1
The following label is put on the computer.
L’étiquette suivant est mis sur de l’ordinateur.
13
Read Me First
l This equipment may not be co-located or
operated with any other antenna or trans-
mitter.
l This device meets the government’s re-
quirements for exposure to radio waves.
This device is designed and manufactured
not to exceed the emission limits for expo-
sure to radio frequency (RF) energy set by
the Federal Communications Commission
of the U.S. Government.
l The exposure standard for wireless device
employs a unit of measurement known as
the Specic Absorption Rate, or SAR. The
SAR limit set by the FCC is
1.6 W/kg.
* Tests for SAR are conducted using stan-
dard operating positions accepted by the
FCC with the device transmitting at its
highest certied power level in all tested
frequency bands.
Although the SAR is determined at the
highest certied power level, the actual
SAR level of the device while operating
can be well below the maximum value.
This is because the device is designed
to operate at multiple power levels so as
to use only the poser required to reach
the network. In general, the closer you
are to a wireless base station antenna,
the lower the power output.
<Only for model with wireless LAN>
This product is restricted to indoor use due
to its operation in the 5.15 to 5.25 GHz fre-
quency range. FCC requires this product to
be used indoors for the frequency range 5.15
to 5.25 GHz to reduce the potential for harm-
ful interference to co-channel Mobile Satellite
systems. High power radars are allocated
as primary users of the 5.25 to 5.35 GHz
and 5.65 to 5.85 GHz bands. These radar
stations can cause interference with and/or
damage this product. 25-M-W-1
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful inter-
ference, and
(2) This device must accept any interference
received, including interference that may
cause undesired operation.
Responsible Party:
Panasonic Corporation of North America
Two Riverfront Plaza
Newark, NJ 07102
Support Contact:
http://www.panasonic.com/contactinfo
6-M-1
FCC RF Exposure Warning:
l This equipment is provided with external
antenna connector(s) for connection to
optional Car Mounter or Port Replicator
for mobile external mounted antenna(s).
External antenna(s) must be professionally
installed and cannot exceed recommended
maximum antenna gain as described in
individual provided supplement instructions
for wireless transmitters. The Car Mounter
is provided with Radiall/Larsen WLAN whip
antenna, type NMO5E2400BKTNC with
5dBi antenna gain. The maximum allow-
able antenna gain for the external WWAN
base whip antenna for the cellular band
is 4 dBi, PCS band is 3 dBi, LTE Band 4
is 3 dBi, LTE Band 17 is 9 dBi and 10 dBi
for LTE Band 13. Also, user must maintain
minimum 20 cm spacing between external
antenna(s) and all person’s body (excluding
extremities of hands, wrist and feet) during
wireless modes of operation.
32-M-1
USA Only: Disposal may be regulated in your
community due to environmental consider-
ations. For disposal or recycling information,
please visit Panasonic website:
http://www.panasonic.com/environmental
or call 1-888-769-0149 65-M-2
<For USA-California Only>
This product contains a CR Coin Cell Lithium
Battery which contains Perchlorate Material -
special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/per-
chlorate/
38-M-1
A lithium ion battery that is
recyclable powers the prod-
uct you have purchased.
Please call
1-800-8-BATTERY
for information on how to
recycle this battery.
L’appareil que vous vous
êtes procuré est alimen-
té par une batterie au
lithium-ion.
Pour des renseignements
sur le recyclage de la batte-
rie, veuillez composer le
1-800-8-BATTERY.
48-M-1
14
Read Me First
Regulatory Information
For Canada
Canadian ICES-003
CAN ICES-3(B)/NMB-3(B) 7-M-2
<Only for model with wireless LAN/Bluetooth>
Industry Canada
This product complies with RSS210 Industry
Canada.
Operation is subject to the following two con-
ditions;
(1) this device may not cause interference,
and
(2) this device must accept any interference,
including interference that may cause un-
desired operation of the device.
<Ne s’applique qu’aux modèles avec techno-
logie Bluetooth/LAN sans l>
Industrie Canada
Cet équipement est conforme à la norme
CNR-210
d’Industrie Canada. Son fonctionnement est
soumis aux deux conditions suivantes :
(1) ce dispositif ne peut produire de brouillage,
et
(2) ce dispositif doit accepter le brouillage, y
compris le brouillage pouvant entraîner le
fonctionnement non désiré de l’appareil.
30-Ca-1-1
<Only for model with wireless LAN>
This product (local network devices) for the
band 5150-5250 MHz is only indoor usage
to reduce potential for harmful interference to
co-channel Mobile Satellite systems.
High power radars are allocated as primary
users (meaning they have priority) of 5250-
5350 MHz and 5650-5850 MHz and these
radars could cause interference and/or dam-
age to LELAN devices.
<Ne s’applique qu’aux modèles avec techno-
logie LAN sans l>
Cet appareil (pour réseaux locaux radioé-
lectriques) dans les bandes de fréquences
5150-5250 MHz est réservé à une utilization
à l’intérieur an de réduire le risque d’inter-
férence avec les systèmes satellites mobiles
bicanaux.
Les radars forte puissance sont désignés
comme étant les premiers utilisateurs (c’est-à-
dire qu’ils ont la priorité) des bandes de fré-
quences 5250-5350 MHz et 5650-5850 MHz.
Ces stations radars peuvent provoquer des
interférences et/ou des dommages à ce péri-
phérique. 30-Ca-2-1
<Only for model with wireless LAN/wireless
WAN/Bluetooth>
l This computer complies with Industry
Canada radiation exposure limits set forth
for an uncontrolled environment.
l This PC with WLAN and/or Bluetooth
transmitters installed, has been approved
for portable operation and does not require
any minimum spacing be provided be-
tween antennas and all person’s body.
<Ne s’applique qu’aux modèles avec techno-
logie Bluetooth/LAN sans l/WAN sans l>
l Cet équipement est conforme aux limites
d’exposition aux rayonnements d’Industrie
Canada établies pour un environnement
non contrôlé.
l Ce PC avec émetteurs WLAN et/ou
Bluetooth a été approuvé à des ns d’opé-
ration mobile; aucun espace minimum
entre les antennes et le corps de l’utilisa-
teur n’est requis.
For Used in Motor Vehicle /Pour L’utilisation Dans Un Véhi-cule Motorisé
Warning: Notebook Computer may be installed in a motor vehicle and visible to the driver only if used to
support vehicle related functions such as vehicle information, system control, rear or side observation and
navigation. If used for entertain-ment purpose, such as television reception or video play, it must be installed
to the rear of the driver’s seat where it will not be visible, directly or indirectly, to the operator of the motor
vehicle. Check with individual state/provincial laws to determine lawful use of this product while operating
within a motor vehicle.
Avertissement : L’ordinateur bloc-notes peut être installé dans un véhicule motorisé et dans le champ de
vision du conducteur uniquement en tant que dispositif d’aide aux fonctions du véhi-cule, comme par ex-
emple pour fournir des informations sur le véhicule, comme dispositif de contrôle de système, pour l’ob-
servation à l’arrière ou sur les côtés du véhicule, ainsi que pour fournir de l’information routière. Pour toute
utilisation à n dedivertissement, comme par exemple pour regarder la télévision ou jouer à des jeux vidéo,
il doit être installé à l’arrière du siège du conducteur, en un emplacement où il ne sera pas visible, ni directe-
ment ni indirectement, pour le conducteur du véhicule motorisé. Vériez les lois fédérales et nationales qui
régissentl’utilisation légale de cet appareil à l’intérieur d’un véhicule mo-torisé.
35-M-1
15
Read Me First
This device has been designed to operate
with the Radiall/Larsen whip antenna, type
NMO5E2400BKTNC WLAN antenna having
a maximum gain of 5dB. A WLAN Antenna
having a higher gain is strictly prohibited per
regulations of Industry Canada. The Required
antenna impedance is 50 ohms.
To reduce potential radio interference to other
users, the antenna type and its gain should
be so chosen that the equivalent isotropically
radiated power (EIRP) is not more than that
required for successful communication.
Cet appareil est conçu pour opérer avec
l’antenne-fouet Radiall/Larsen, type WLAN
NMO5E2400BKTNC, ayant un gain maximum
de 5 dB. Les règlements d’Industrie Canada
interdisent l’utilisation d’une antenne WLAN
dont le gain serait supérieur à cette limite.
L’antenne doit avoir une impédance de 50
ohms.
An de réduire le risque d’interférence ra-
dioélectrique aux autres utilisateurs des
bandes de fréquences, le type d’antenne et
son gain doivent être tels que la puissance
isotrope rayonnée équivalente (PIRE) n’est
pas plus élevée que le niveau requis pour as-
surer la communication. 25-Ca-1-1
<Only for model with wireless LAN/wireless
WAN/Bluetooth>
* This computer complies with Industry
Canada radiation exposure limits set forth
for an uncontrolled environment.
* This PC with WLAN and/or Bluetooth
transmitters installed, has been approved
for portable operation and does not require
any minimum spacing be provided between
antennas and all person’s body.
<Ne s’applique qu’aux modèles avec tech-
nologie Bluetooth/LAN sans l/WAN sans l>
* Cet équipement est conforme aux limites
d’exposition aux rayonnements d’Industrie
Canada établies pour un environnement non
contrôlé.
* Ce PC avec émetteurs WLAN et/ou
Bluetooth a été approuvé à des ns
d’opération mobile; aucun espace minimum
entre les antennes et le corps de l’utilisateur
n’est requis.
This device has been designed to operate
with the WWAN antenna having a maxi-
mum gain of 4 dBi for Cellular band, 3 dBi
for the PCS band and 5.5 dBi for LTE Band
4. WWAN Antenna having a higher gain is
strictly prohibited per regulations of Industry
Canada. The Required antenna impedance is
50 ohms.
To reduce potential radio interference to other
users, the antenna type and its gain should
be so chosen that the equivalent isotropically
radiated power (EIRP) is not more than that
required for successful communication.
<Utilisation au Canada>
Cet appareil est conçu pour opérer avec une
antenne WWAN (réseau étendu sans l)
dont le gain maximum est xé à [X1] pour la
bande cellulaire 4 dBi, 3 dBi pour la bande
PCS et 5.5 dBi pour la bande LTE Band 4.
Les règlements d’Industrie Canada interdisent
l’utilisation d’une antenne WWAN dont le gain
serait supérieur à cette limite. L’antenne doit
avoir une impédance de 50 ohms.
An de réduire le risque d’interférence ra-
dioélectrique aux autres utilisateurs des
bandes de fréquences, le type d’antenne et
son gain doivent être tels que la puissance
isotrope rayonnée équivalente (PIRE) n’est
pas plus élevée que le niveau requis pour as-
surer la communication. 32-Ca-1-1
FOR USE WITH MODEL NO. : CF-AA64B3C
POUR UTILISER AVEC MODÈLE : CF-AA64B3C
20-Ca-1
16
Read Me First
Regulatory Information
For Europe
<Only for model with a “CE” mark on the bottom of the computer>
Declaration of Conformity (DoC)
“Hereby, Panasonic declares that this Personal Computer is in compliance with the es-
sential requirements and other relevant provisions of the Directive 1999/5/EC.”
Hint:
If you want to get a copy of the original DoC of our above mentioned products, please contact our web ad-
dress:
http://www.ptc.panasonic.eu
Authorised Representative:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
18-E-0
For India
Declaration of Conformity with the requirements of the e-waste (Management and Handling) Rules, 2011.
(adopted by Notication S.O.1035(E) of Ministry of Environment and Forests)
The Product is in conformity with the requirements of Rule 13 of the e-waste Rules.
The content of hazardous substance with the exemption of the applications listed in SCHEDULE II of the
e-waste Rules:
1. Lead (Pb) - not over 0.1% by weight;
2. Cadmium (Cd) - not over 0.01% by weight;
3. Mercury (Hg) - not over 0.1% by weight;
4. Hexavalent chromium (Cr6+) - not over 0.1% by weight;
5. Polybrominated biphenyls (PBBs) - not over 0.1% by weight;
6. Polybrominated diphenyl ethers (PBDEs) - not over 0.1% by weight.
For the purpose of recycling to facilitate effective utilization of resources, please return this
product to a nearby authorized collection center, registered dismantler or recycler, or Panasonic
service center when disposing of this product.
Please see the Panasonic website for further information on collection centers, etc.
http://www.panasonic.com/in/corporate/sustainability/panasonic-india-i-recycle-program.html
68-M-2
17
Getting Started
n Preparation
A Check and identify the supplied accessories.
If you do not nd the described accessories, contact your support ofce.
• AC Adaptor .. 1
Model No:
CF-AA6413C
• AC Cord .... 1 • Battery Pack ..... 1
Model No: FZ-VZSU84U or
FZ-VZSU88U
• Digitizer pen ...... 1
è Reference Manual
“Screen Input Operation”
• Tether ...... 1 • Soft Cloth ... 1
è Reference Manual “Screen Input Operation”
• OPERATING INSTRUCTIONS - Read Me First (This book) .....1
We recommend that “OPERATING INSTRUCTIONS - Basic Guide” be downloaded.
(è cover) “OPERATING INSTRUCTIONS - Basic Guide” is described the basic operation
when using this computer.
To download above from this product, you need to setup connecting a network.
(è Connect to a network)
1 Inserting the Battery Pack.
Turn over the computer and insert the battery pack until it touch to
the secured position.
l Make sure no foreign objects are under the computer.
CAUTION
l Make sure the latch is securely locked. Otherwise the battery
pack may fall when you carry the computer.
l Do not touch the terminals of the battery pack and the computer.
Doing so can make the terminals dirty or damaged, and may
cause malfunction of the battery pack and the computer.
NOTE
l Note that the computer consumes electricity even when the com-
puter power is off. If the battery pack is fully charged, the battery
will fully discharge in the following period of time:*1
Status Discharge period
FZ-VZSU84U FZ-VZSU88U
When power is off
Approx. 6 weeks Approx. 12 weeks
In hibernation Approx. 10 days Approx. 20 days
In sleep*2 Approx. 7 days Approx. 14 days
*1 <Only for model with Built-in Bridge Battery>
The period of time is the value when the built-in bridge battery
is fully charged.
*2 <Only for model with LAN>
If “Wake Up from wired LAN” is enabled, the period of time will
be shorter.
1A
B
First-time Operation
18
Getting Started
First-time Operation
2 Attaching the pen (included) to the computer.
A Pass one of the loops
through the hole.
㪈㪉㪊 㪋
B Pass one of the loops
through another loop.
㪈㪉㪊 㪋
C Thread the second loop on
the tether through the hole
as illustrated.
㪊
D Pass the pen and tether
through the second loop.
㪋
CAUTION
l Do not pull the tether with excessive force. The pen (included)
may hit the computer, person’s body or other objects when re-
leased.
3 Connect your computer to a power outlet.
The battery charging starts automatically.
CAUTION
l Do not disconnect the AC adaptor until the rst-time operation
procedure is completed.
l When using the computer for the rst time, do not connect any
peripheral device (including wired LAN cable) except the battery
pack and AC adaptor.
l Handling the AC adaptor
Problems such as sudden voltage drops may arise during pe-
riods of thunder and lightning. Since this could adversely affect
your computer, an uninterruptible power source (UPS) is highly
recommended unless running from the battery pack alone.
4 Turn on the computer.
Press and hold the power switch (B) until the power indicator
(A) lights.
CAUTION
l Do not press the power switch repeatedly or do not hold the
power switch for four seconds or longer.
㻞
㻝
3
㻭㻮
4
19
Getting Started
5 Setup Windows.
Follow the on-screen instructions.
l The computer restarts several times. Do not touch the screen or
tablet buttons, and wait until the drive indicator has turned off.
l After the computer is turned on, the screen remains black or
unchanged for a while, but this is not a malfunction. Wait for a
moment until the Windows setup screen appears.
l Setup of Windows will take approximately
5 minutes / 20 minutes.
Go to the next step, conrming each message on the display.
l Follow the steps below.
A
When “Enable sensors” is displayed, touch [Enable this sensor].
B
When the [User Account Control] screen is displayed, touch [Yes].
C At the [Display Rotation Tool] conrmation screen, touch [Yes].
The computer restarts automatically, and the setting is enabled.
l You can set the Wireless Network after the setup of Windows is
complete.
If “Get online” is displayed, select “Skip this step”.
“Join a wireless network” screen may not appear.
CAUTION
l You can change the user name, password, image and security
setting after setup of Windows.
l Remember your password. If you forget the password, you can-
not use Windows. Creating a password reset disk beforehand is
recommended.
l Do not use the following words for user name: CON, PRN,
AUX, CLOCK$, NUL, COM1 to COM9, LPT1 to LPT9, @, &,
space. In particular, if you create a user name (account name)
that includes the “@” mark, a password will be requested at the
log-on screen, even if no password has been set. If you try to
log on without entering a password, “The user name or pass-
word is incorrect.” may be displayed and you will not be able to
sign in / log on to Windows
(è OPERATING INSTRUCTIONS - Basic Guide).
6 Update the on-screen manual
A Connect to the internet. Log on to Windows as an administrator.
For further information, refer to Connect to a network.
B Update the on-screen manual.
On the Start screen, click the [Manual Selector] tile.
Double-click [Manual Selector] on the desktop.
Follow the on-screen instructions.
7 Create a recovery disc.
A recovery disc allows you to install OS and restore its factory de-
fault condition, in case, the recovery partition of the ash memory
is damaged. We recommend creating a recovery disc before you
begin using the computer.
Refer to è
Reference Manual
“Recovery Disc Creation Utility”
about creating the disc.
Panasonic System Communications
Company of North America
Two Riverfront Plaza,
Newark NJ 07102
Panasonic Australia Pty. Limited
ACN 001 592 187 ABN 83 001 592 187
1 Innovation Road, Macquarie Park NSW 2113
Web Site : http://panasonic.net/
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga,
Ontario L4W 2T3
© Panasonic Corporation 2014
Printed in Taiwan
HS1214-0
DFQW5A84ZAT

Navigation menu
