Datasheet 523431 English

Wireless G Broadband VPN Router

54 Mbps Wireless 802.11g, VPN, QoS, 4-Port 10/100 Mbps LAN Switch

Part No.: 523431

Create a wireless network easily, in your home or office.

The INTELLINET NETWORK SOLUTIONS Wireless G Broadband Router, Model 523431,

lets you experience fast speeds as you surf the Web, download music or photos, and play

online games. This wireless router works with 802.11g as well as the older 802.11b

products, and also includes a 4-port 10/100 LAN switch so you can connect using network

Keeping intruders out of your network can be a challenge, and this feature-rich wireless router is designed to make that

challenge easier. It includes a true firewall that secures your network against hackers. With Network Address Translation

(NAT) to shield your networked devices from intruders, Denial of Service (DoS) attack prevention to avert potential threats

by scanning incoming traffic, and WEP and WPA encryption to conceal your information on the wireless LAN from

eavesdroppers, you can rest assured that you have taken the necessary precautions to protect the data on your network.

As if this were not enough, the built-in VPN server supports up to five connections simultaneously, giving you secure

access to your office or corporate network.

As you add more applications to your network, and as technology continues to advance, you need to be able to optimize

Up to 54 Mbps network data transfer rate

For more information on Intellinet products, consult your local dealer or visit www.intelllinet-network.com.

All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and

reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.

Compatible with all 802.11b & g wireless products

Easy wireless setup through integrated site survey function

Supports WEP and WPA (TKIP and AES) data encryption

Supports MAC filtering for wireless clients

Supports Access Point mode and WDS (Wireless Distribution System) mode

Supports VPN pass-through (IPSec, PPTP, L2TP)

94 Mbps WAN to LAN throughput for wired networks

Supports QoS (Quality of Service) bandwidth management

Integrated anti-DOS firewall

WOL (Wake-On LAN) function sends a wakeup signal to any computer in the LAN

Integrated scheduler to limit Internet access to client computers in the LAN

Content control through URL and domain filter

Remote management function (enable/disable and management port)

Easy installation through Web-based user interface

Firmware updates via Web-based user interface

• IEEE 802.3u (100Base-TX Fast Ethernet)

• LAN ports: 4 RJ-45 10/100 Mbps data ports

• LAN ports with Auto MDI/MDI-X

• LAN to WAN throughput: 94 Mbps

• Flash: 2 MB

• Memory: 16 MB SDRAM

• Certifications: FCC Class B, CE Mark, RoHS

• Chipset: KS8695PX (ARM9 CPU)

For more information on Intellinet products, consult your local dealer or visit www.intelllinet-network.com.

All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and

reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.

- CSMA/CD

- TCP/IP

- UDP

- ICMP

- PPPoE

- Special applications (port trigger)

- DMZ (demilitarized zone)

• Firewall:

- Access control based on MAC address

- Domain blocking

- URL filter

• Supports UPNP (Universal Plug and Play)

• Supports DHCP (client/server)

• Supports PPPoE (DSL), DHCP (cable) and static IP

• Supports VPN PPTP pass-through

• Wireless frequency range: 2.412 – 2.484 GHz

• Channels:

- USA & Canada: 11 channels

- Europe: 13 channels

- Japan: 14 channels

• Data rates:

- IEEE 802.11b (11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps)

- IEEE 802.11g (54 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 18 Mbps, 12 Mbps, 9 Mbps, 6

• Output power:

- OFDM: 17 dBm +/- 1 dBm (54 Mbps, 50 mW max.)

- CCK: 17 dBm +/- 1 dBm (11 Mbps, 50 mW max.)

• Receiver sensitivity: -65 dBm (54 Mbps); -78 dBm (11 Mbps)

For more information on Intellinet products, consult your local dealer or visit www.intelllinet-network.com.

All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and

reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.

• Power

• OP (operational status)

• Power Line Link/Act

• Weight: 1.25 kg (2.7 lbs.)

• Operating temperature: 0 – 55°C (32 – 122°F)

• Operating humidity: 10 – 95% RH, non-condensing

• Storage temperature: 0 – 60°C (0 – 149°F)

• External power adapter: 7.5 V DC, 1.5 A

Package Contents

• Wireless G Broadband Router

• Power cord

• Ethernet Cat5 RJ-45 cable, 0.8 m (2.6 ft.)
