Choose the best… Maytag hot water.

If you’re looking for the best water heater, you can’t go wrong with the

name millions of homeowners trust and depend on: Maytag. The Maytag®

Series 12 water heater is fully-loaded with energy-saving features and packed

with maximum water heating power, so you can count on all the hot water

you’ll ever need. And a 12-year warranty on the tank and parts delivers the

peace of mind you expect from every Maytag appliance!

Self-Cleaning Jetforce™cold water inlet virtually

eliminates harmful sediment buildup. Made of longer

lasting PEX (Cross-Linked Polyethylene) polymer.

In an ordinary electric water heater without self-cleaning

feature, sediment coats the surface of the heating

element, blocking effective heat transfer.

Electric Water Heaters

SERIES 12

Amodel®is a registered trademark of the Amoco Corporation.

Amodel®Drain Valve, cannot rust, covered to help prevent accidental damage.

3800-watt upper element operates when needed to give water in top of tank

a quick temperature boost.

Dual heavy-duty Anode Rods protect against corrosion, prolong tank life.

Lower fuel bills. 3-inches of thick energy-saving foam insulation keeps heat

in tank where it belongs.

Superglass™Plus porcelain lining with higher levels of zircon, for extra longer tank life.

Lower element easily converts from 3800 to 5500 watts of power,

to suit your wiring.

Energy-saving Silencer™fittings on cold inlet and hot outlet.

Temperature & Pressure Safety Valve installed at factory.

MAYTAG®SERIES 12 ELECTRIC WATER HEATERS

OUTPUT

MODEL TANK SIZE INPUT

(GALLONS, AT 90°F TEMP. RISE)

ENERGY HEIGHT DIAMETER CRATED

NUMBER GALLONS WATTS FIRST HOUR RECOVERY FACTOR (INCHES) (INCHES) WEIGHT

RATING PER HOUR (LBS)

HRE112 40S (Med.) 40 3800 50 17.3 .95 47 221⁄2124

5500 58 25.0

HRE112 50T (Tall) 50 3800 61 17.3 .95 57 221⁄2154

5500 68 25.0

HRE112 50S (Med.) 50 3800 60 17.3 .95 50 24 161

5500 66 25.0

HRE112 82T 80 3800 86 17.3 .94 62 26 222

5500 92 25.0

Selecting the right Maytag Water Heater

for you depends on the size of your

family, and your use of hot water.

These minimum recommendations are based on a typical home with 2 full bathrooms,

a clothes washer, and a dishwasher. If you have more than 2 bathrooms, teenagers in

the family, or if you just feel your family uses a lot of hot water, you should select the

next largest size. In warm climates, however, the next smallest size may be right for

you, because the cold water supply is probably warmer than the national average. If

you have a whirlpool bath, capacity should be at least 2⁄3of that tub. For example, for a

75-gallon tub, select a 50-gallon or larger Maytag Water Heater.

SELECTION

GUIDE

40 GALLON

3800 watt operation – family size up to two

5500 watt operation – family size up to three

50 GALLON

3800 watt operation – family size up to three

5500 watt operation – family size up to four

80 GALLON

3800 watt operation – family size up to five

5500 watt operation – family size up to seven

SERIES 12

WATER HEATER WARRANTY

12 YEARS Limited warranty against

tank leaks.

12 YEARS Limited warranty against

parts failure in materials

or workmanship.

1 YEAR Labor warranty.

Maytag Water Heater

Expansion Tanks protect

against the harmful effects of

thermal expansion.

Maytag Drain Pans help

protect your property from accidental

water damage.

EXPANSION TANKS

AND DRAIN PANS

*An additional 3" of clearance is required at the front of the water heater to accommodate the access panel.

Model numbers shown indicate 2-wire leads. For 3-wire leads, change “1” to “4” after “

HRE”

in model number (Example: HRE412 50T).

Electric models are shipped wired for 3800 watt operation, which requires 20-amp fusing, minimum 12-gauge wire. Conversion to higher-output 5500

watt operation is easily accomplished with a part that is supplied with heater. 5500 watt operation requires 30-amp fusing, minimum 10 gauge wire.

All models available in Canada, add “CAN” to end of model number (Example: HRE112 40S CAN).

Maytag®is a registered trademark of Maytag Corporation and is used under license to A.O. Smith Corporation

MRE-SS004-0405N ©2005 A.O. Smith Corporation Printed in U.S.A.

FOR MORE INFORMATION

If you have questions about Maytag Water Heater features,

performance, selection, warranties or available accessories,

call toll-free… 1- 800-360-8807
