User manual
1 | P a g e
FOBO ULTRA
User Manual
Draft
(For iOS7.1 and Android 4.30 & above)
2 | P a g e
Contents
1 Introduction
2 About FOBO Ultra
3 Importance of Tire Care
4 Product Description of FOBO Ultra
4.1 In-Car unit/Repeater
4.2 Tire Sensor unit
4.3 Sensor lock nuts & wrench
5 Using FOBO Ultra
5.1 Installing FOBO Ultra App
5.2 Installing FOBO Ultra In-Car unit and sensors
5.3 FOBO SHARE - Setting up multiple users
5.4 Sensor rotation
5.5 Disable sensor and Replace new sensor
5.6 Transfer FOBO Ultra to another user
5.7 How to change profile picture
5.8 Tire Inflation/Deflation
5.9 Hook & Drop
6 FOBO Ultra Alert Messages
7 In-Car unit audio & LED alerts
8 Replacing Battery
9 Trouble Shooting Guide
10 FOBO Ultra Specifications
11 Warning
12 Regulatory Information
13 Intellectual Properties
14 Limited Warranty and Disclaimer
3 | P a g e
1 Introduction
FOBO Ultra is the world‟s most advanced Tire Pressure Monitoring System
(TPMS) using Bluetooth Smart (Bluetooth 4.1 or later) technology to monitor your
Truck, RV, Caravan tire pressure and temperature. Bluetooth Smart is a very low
power wireless technology that could operate on a single coin cell battery for up to
Fifteen months (NOTE: Battery life may vary according to usage and climatic
temperature. Operating under extreme cold may drastically reduce battery
life.)
Please ensure that your smartphone has Bluetooth Smart Ready (Bluetooth 4.1 or
later) capability in order to use FOBO Ultra. Currently FOBO Ultra works best with
iOS 7.1 and Android 4.30 or above.
Before starting to use FOBO Ultra, please download the free FOBO Ultra App to
your smartphone from Google Play Store or Apple AppStore.
FOBO Ultra is a product designed and produced by Salutica Allied Solutions Sdn.
Bhd. (“Salutica”), a Malaysian company with its address at No. 3, Jalan Zarib 6,
Kawasan Perindustrian Zarib, 31500 Lahat, Ipoh, and Perak, Malaysia.
2 About FOBO Ultra
FOBO Ultra monitors your vehicle tires non-stop around the clock. Most drivers
have encountered situations where they need to rush for an urgent delivery only to
be stranded by a flat tire. Conventional Tire Pressure Monitoring Systems (TPMS)
could not alert you in advance because it stops operating as soon as the Vehicle
ignition is switched-off. With FOBO Ultra, you will get an alert as soon as the tire
pressure drops below a certain pre-set level, even when the Vehicle ignition is
switched off as long as you are within Bluetooth range(up to 30 meter with line of
sight; but the range may reduce by obstacles in between). This alert gives you time
to get the flat tire fixed before you need to use it.
FOBO Ultra can monitor up to 20 vehicle profiles on each smartphone. You can
receive data from the tire pressure sensors from all your vehicles without switching
on the ignition. FOBO Ultra allows you to monitor your Vehicle tires conveniently
at any time you want. NOTE: Under certain conditions the signals from FOBO
Ultra sensors may be blocked by surrounding objects or structures. If this
occurs, please move around the vehicle in order to capture signals from all the
tire sensors.
If you are sharing your vehicle with others, you (FOBO Sharer) can authorize
others (FOBO Sharee) to use your FOBO Ultra through the FoboShare function.
After adding them through FoboShare, FOBO Sharees who use your vehicle will
4 | P a g e
receive alerts and data from your FOBO Ultra on their respective smart phone
which is installed with FOBO Ultra App. Refer Details at Section 5.3
FOBO Ultra packaging consists of 4 wireless tire sensors, 1 wireless In-Car unit
and a 24V 10 feet power cable with connector to In-Car or Repeater. Replace your
vehicle tire valve caps with the sensors and place the In-Car unit inside the cab. The
sensors will measure tire pressure of each tire and transmit via Bluetooth to the In-
Car unit and your smartphone. In case of a breach of pre-set threshold of tire
pressure, the In-Car unit will produce an audible alert to notify you. An alert will
also pop up on your smartphone if it is within Bluetooth range.
FOBO Ultra system requires a qualified smartphone and FOBO Ultra App for
installation. In addition to being able to view information regarding your vehicle
tire pressure and temperature, the FOBO Ultra App will also produce an alert when
your tire has a problem.
DISCLAIMER: FOBO ULTRA IS NOT A DEVICE THAT PREVENTS
ACCIDENTS. IT IS ALSO NOT A DEVICE THAT PREVENTS TIRES
FROM BECOMING DEFLATED OR OVERINFLATED. FOBO ULTRA IS
NOT A SUBSTITUTE FOR SAFE TIRE MAINTENANCE PRACTICES.
PLEASE CONTINUE TO TAKE PRECAUTIONARY MEASURES WHILE
DRIVING AND TAKE FULL RESPONSIBILITY OF YOUR VEHICLE’S
TIRE CONDITION TO ENSURE SAFETY WHILE DRIVING. YOU
SHOULD CONTINUE TO PRACTICE PROPER TIRE CARE AND
SCHEDULED TIRE MAINTENANCE.
3 Importance of tire care
It is extremely important to ensure vehicle tires are properly inflated for safety
while driving. However, many drivers tend to neglect proper tire care and
maintenance. The vehicle tires are the only contact points between the vehicle and
the road. The weight of the vehicle and passengers are supported by the air pressure
inside the tires. Improperly inflated vehicle tires may cause serious accidents on the
road.
When tires are underinflated, the additional rolling resistance may cause buildup of
heat which may lead to the de-lamination of the tire materials as well as damage to
the tire‟s sidewall, which in turn increases the chances of a tire blow-out.
Underinflated tires will also cause accelerated wear on the tire shoulders thereby
causing uneven tire wear. Gas mileage will also be affected due to additional rolling
resistance when driving with underinflated tires. You would also experience a
significant loss of steering precision and cornering stability. Significantly under-
inflated tires will also be less effective in resisting hydroplaning.
5 | P a g e
On the other hand, an overinflated tire will cause accelerated wear on the center
portion of the tire resulting in uneven tire wear. It would also result in a harsher ride
and makes the tire more susceptible to damage when going over potholes or debris
on the road..
What is the optimum tire pressure? There are a lot of information about this subject
in internet forums and web articles. A quick guide for better understanding of tire
pressure below:-
1) Vehicle manufacturers recommend the optimum tire pressure for their
vehicle models. The information is usually available on a sticker at the door
jam (side of the driver‟s door) or in the owner‟s manual. For some vehicle
models, the information sticker may be on the trunk lid or on the fuel door.
Vehicle manufacturers usually recommend different tire pressure for front
and rear axles. This pressure is usually recommended for comfort driving
and optimum performance of the vehicle. It is not advisable to go below this
recommended pressure level.
2) The vehicle manufacturer recommended tire pressure is “cold pressure”.
When you drive your vehicle to the gas station, the friction on the road will
heat up your vehicle tires within a few minutes. Typically there will 1 psi
(~7kPa) increase in air pressure for every 10 deg F (5.6 deg C) rise in
temperature. It is advisable to inflate the tire pressure with this compensated
pressure above the recommended pressure.
3) Air pressure in tires is affected by changes in temperature. Check and adjust
your tire pressure whenever there is a drastic change in environment
temperature, e.g. Change of season.
4) A tire will normally lose its pressure through natural causes unless
accelerated by a puncture, faulty valve or damaged wheels. It is advisable to
change the tire valves or at least check the valves condition every time you
change a new set of tires. Under normal condition, a set of tires could
deflate at a rate of up to 2psi per month. It is good practice to check your tire
pressure regularly and top up to the optimum pressure.
5) Every vehicle tire has a maximum inflation pressure. It is not advisable to
inflate to the maximum inflation pressure of the tire. Follow the vehicle
manufacturer‟s recommended tire pressure instead.
6 | P a g e
4 Product Description of FOBO Ultra
4.1 In-Car Unit
The functions of three action buttons are to correspond with the instruction that
appears on the screen.
NOTE: Excessive frequent pressing on the buttons will drain the In-Car unit
battery.
Status indicator - LED will blink to show Bluetooth pairing mode or
battery low status
Alert buzzer - buzzer to alert when there is problem with tire
AA batteries - In-car unit/Repeater operates with 5AA size
batteries.
The FOBO Ultra In-Car unit/Repeater is a complex device that performs multiple
functions. Due to the shielding effect of the vehicle chassis, some drivers may face
difficulty in receiving the tire sensor signals on their smartphone when sitting inside
the cab. This problem may be further aggravated when the driver places the
smartphone in positions that are not optimal such as trouser pocket or waist pouch.
Antenna
Action Buttons
Battery cover
7 | P a g e
The In-Car unit is designed with an efficient antenna that can pick up sensor signals
better than a usual smartphone, enabling good signal reception from the tire sens-
ors. Keep the In-Car unit in the cab and fix the Repeater in the center of the Trailer
for optimal functioning of FOBO Ultra. You may remove it for other sensor
operation purposes, such as sensor position rotation and sensor disabling but place it
back once the sensor operation is completed. Note that In-Car unit is not water-
proof.
To conserve battery life, the In-Car unit/Repeater will go into „sleep‟ mode after it
detects that the vehicle has been stationary for more than 15 minutes. It will „wake
up‟ once it detects that the vehicle moves. You can still receive your tire pressure
and temperature data by accessing the FOBO Ultra App on the smartphone, even
when the In-Car unit is asleep. This is due to FOBO Ultra sensor‟s continuous
operation of 24 x 7 which allows you to receive an alert even when the vehicle‟s
ignition is switched off.
The In-Car unit/Repeater is also designed to be a secondary alert device in the
event of a deflated tire. This is to cover situations when you do not have your
smartphone with you while driving or if your smartphone‟s battery is dead. When
there is a tire pressure alert, the In-Car unit/Repeater will produce an audible and
visual LED alerts to inform you of a tire pressure problem.
8 | P a g e
4.2 Tire Sensor Unit
Knob cover
Single Internal Battery
Knob cover – waterproof cover. Please ensure the red silicon ring
is intact to prevent water from getting into
electronics compartment.
Single internal battery - CR2032 coin cell battery. When replacing battery,
please ensure the “+” sign of the battery is facing up,
away from PCB.
Internal PCB - internal electronics circuit (The pressure sensor chip
is mounted within this PCBA, and it senses the tire
pressure against a built-in vacuum, resulting in an
Absolute Pressure reading. The internal firmware
will then subtract the sea-level pressure of 101.3
Kpa (14.7 psi) from this reading. This final reading
which will be shown in the App can be termed as i)
Tire Absolute Pressure minus sea level pressure,
or ii) Gage Pressure reference to sea-level altitude.
With this formulation, Fobo Ultra sensor will read
the same pressure value for any given time,
irrespective of altitude (assuming a constant
temperature). This will ensure the correct tire
footprint per vehicle manufacturer‟s pressure
recommendation, for all altitude above sea-level,
given a constant temperature.
Rf4f4
f4f4f
44f4f
9 | P a g e
As a corollary, a tire with a Fobo reading of, say 40
psi at an altitude of 5000ft, will read the same 40
psi when driven to sea-level, given a constant
temperature. In reality, it will read higher due to the
warmer temperature at sea-level, and may need
some air release if the temperature difference is
great. Tire pressure generally will increase 1 psi
(~7kPa) for every 10 deg F (5.6 deg C) rise in
temperature.
FOBO wishes to highlight the above formulation is
for usage at sea-level and above, and will not be
accurate for use otherwise. In practice, this should
not be an issue as the lowest area on earth will
result in an insignificant error of 0.3 psi (~2 Kpa).
For users who wish to retain „Gage Pressure
Reading‟, the FOBO Ultra App has a Gage Pressure,
adjusted to local altitude using cell towers or
individual phone barometer if available. This Gage
Pressure button can be accessed from the App
(Kindly refers to Section 5.10 of this user manual).
FOBO Ultra sensor units are designed to be robust and operate reliably 24x7
to provide tire information around the clock. It is designed to be water proof
(IP57) and by our special use of custom engineering plastics, it will be able to
withstand road salts or other common automotive chemicals (petrol, engine
oil, wash shampoo, etc.).
Our designers have designed the sensors to ensure that there is no air leakage
as it replaces the tire‟s original valve cap. There is no need to screw on the
sensor extremely tight. Apply a reasonable hand twist force to ensure the
sensor is securely installed and should be able to be removed by hand with
ease.
When installing the sensors, please follow the on-screen prompt of the In-car
unit. After installation, in the event the tire sensors positions are mixed up,
usually after performing a tire rotation maintenance, you can easily re-
position the sensors to their correct position by selecting „sensor rotation‟ on
the in-car unit and follow the on-screen instructions. This eliminates the need
to remove the tire sensors physically.
10 | P a g e
A missing or damaged tire sensor can be replaced easily through the In-car
unit. You will need to purchase a replacement sensor which you can do so
online at www.my-fobo.com. To replace the sensor, first select „Disable
Sensor‟ on the In-car unit under sensor Management system and the pop-up
will prompt you to tap on the tire position that you want to disable. Then,
select „Replace sensor‟, upon selecting the app will blink at the first disabled
position and the App will prompt you to install the replacement sensor.
Follow the on-screen instruction and the replacement sensor will be paired
and be ready to use.
NOTE: Battery life span up to Fifteen months is an estimate based on
normal use at 23 °C. Battery life may vary according to usage and
climatic temperature.
Battery life span will change due to the following reasons:
1) Frequent change of pressure threshold setting in the App.
2) Disabling & enabling of sensors.
3) Release & pairing.
4) Removal & screw-on of sensors.
5) Operating under extreme cold/hot temperature.
6) Testing of product.
7) Rotation (refer section 5.4 of this user manual)
8) Trigger alert or let activated alerts unattended.
9) Multiple removal and screw-on of sensors for equalizing all tire
pressures.
All these activities will drain a battery very fast and affect the battery life
span.
11 | P a g e
4.3 Sensor Lock nuts and wrench
FOBO Ultra sensors and In-Car unit are tied to a FOBO account after
installation. They are not re-usable or transferable without the owner releasing
them from his/her FOBO account. This is a theft deterrent feature to
discourage theft.
As an additional anti-theft feature, all FOBO Ultra package comes with lock-
nuts and special wrench. FOBO Tire Plus‟s functionality is not affected if
you do not use the lock-nuts.
The lock nuts and wrench are made of custom engineering plastics that can
withstand road salts and common automotive chemicals (gasoline, engine oil,
wash shampoo, etc.).
In order to use the lock nuts, you must first install the lock nut to the tire valve
(with the bump facing tire rim). Screw in the lock nut all the way down and
ensure that there is still a minimum of 5 thread count on the tire valve for
the sensor unit to be screwed on. If there is insufficient thread for the tire
sensor, it may lead to air leakage. A solution for this would be to change the
tire valve to one with a longer thread. Next, screw in the tire sensor unit until
it is reasonably tight. Then use your finger to unscrew the lock nut outwards
(i.e. anti-clockwise) until it pushes against the bottom of the sensor unit. Use
the wrench to tighten the lock nut. The resultant friction force will make it
difficult to remove the sensor unit without loosening the lock nut. For rubber
valves, hold the valve stem with one hand and tighten the lock nut with the
wrench on another hand. This is to avoid the rubber valve from twisting
making it unable to tighten the lock nut.
12 | P a g e
WARNING: Do not apply too much force to tighten the lock-nut. You
may face difficulty to loosen the lock nut later on especially for rubber
valves that typically doesn’t stay firm on the tire rims.
NOTE: If your tire valve is too short, you shouldn’t use the lock nut as
this will block the sensors from being completely screwed on the tire
valve and causes air leak. Our sensors are designed to work on a tire
valve with a minimum of 5 thread counts.
13 | P a g e
Step by step diagram to use FOBO Ultra Lock Nut and wrench
14 | P a g e
5 Using FOBO Ultra
5.1 Installing FOBO Ultra App
You are required to have a smartphone with Bluetooth 4.0 (Bluetooth Smart)
capability in order to use FOBO Ultra. The smartphone must also be running
on iOS 7.1 or Android 4.3 and above. Follow the steps below to install your
FOBO Ultra:
Step 1: Download the FOBO Ultra App onto your smartphone
For iPhone users, download from Apple‟s AppStore. For Android
users, download from Google Play. Search for “FOBO Ultra”.
Step 2: Launch the FOBO Ultra App & key in your email address
For new users, key in your email address and click login.
You will receive an email from FOBO with an activation link.
Click on the activation link that you receive in your email.
Once activated, go back to the FOBO Ultra App and click on login
again.
You be brought to the App‟s Home screen.
Note:-
An activation e-mail message will be sent to your e-mail address when you
click on login as a first time user.
If you do not receive this activation e-mail from FOBO Admin, please
check your e-mail address entry to ensure it is valid without typo error.
This e-mail may also be filtered by some e-mail servers. Please check your
Spam mailbox.
If you still do not receive any message from FOBO Admin after 15
minutes (with a good internet connection), please write in to
fobo@salutica.com.my with your sign-in email.
IMPORTANT:
The email activation is to ensure that your account signup is done
securely. FOBO Ultra is locked to your FOBO account as an anti-theft
deterrent. Stolen sensors cannot be used by anyone else other than the
FOBO account owner.
Location service is required to be enabled for the FOBO Ultra App
(FOBO Ultra does not use the GPS function to track your location). The
location service on the iOS/Android system has other functionality that
15 | P a g e
the FOBO Ultra App uses to operate properly and to sync with the In-
Car unit. It will ensure FOBO Ultra functions as designed, mainly for
alert functions, and also the gauge pressure feature as required by users
living at high altitudes. FOBO Ultra is designed to be a low energy system
and does not drain your smartphone battery excessively.
By submitting your information to sign up a new user account, you
acknowledge your acceptance to the terms and conditions of our Software
Licensing Agreement and Privacy Policy.
5.2 Installing FOBO Ultra In-Car unit & sensors
TO REDUCE THE RISK OF AN ELECTROSTATIC DISCHARGE
(ESD) PLEASE TOUCH THE WHEEL WHEN SCREWING ON THE
TIRE SENSOR ON TO THE TIRE VALVE. THIS IS TO MINIMIZE
POTENTIAL ESD ATTACK WHICH MAY CAUSE DAMAGE TO
THE TIRE SENSOR AND ITS FUNCTION.
INSTALLING FOBO ULTRA SETS ON MORE THAN ONE VEHICLE
WHICH ARE PARKED CLOSELY TOGETHER MAY CAUSE CROSS
INTERFERENCE TO THE BLUETOOTH SIGNALS. PLEASE
INSTALL FOBO ULTRA ON ONE VEHICLE AT A TIME.
To begin using FOBO Ultra, firstly ensure that the FOBO Ultra App is
downloaded and you have already login to the App (see section 5.1 above for
installation and login).
Follow the steps below to pair FOBO Ultra to your smartphone:-
1) Turn on your smartphone‟s Bluetooth connection.
2) Set the FOBO Ultra‟s In-Car unit/Repeater into „pairing mode‟ by long
press “SELECT” to start pairing.
3) Open FOBO Ultra App.
4) Follow the on screen instruction on FOBO Ultra APP.
5) Key in the name you would like to identify your Vehicle.
6) Tap on the profile picture box and take a picture of your vehicle.
7) Select the vehicle manufacturer recommended tire pressure for all the
axles. The information is usually available on a sticker at the door jam
(side of the driver‟s door) or in the owner‟s manual. For certain vehicle
models, the information sticker may be on the trunk lid or on the fuel
16 | P a g e
door. You cannot proceed with the pairing without the input of this
information into the FOBO Ultra App.
8) Click “Done” on the top right hand corner of the screen.
9) Select “sensor installation” under Main Menu of In-Car unit and follow
the instructions on screen of the In-Car unit.
10) You will be prompted that installation is completed and you are now
ready to use FOBO Ultra.
CAUTION:
Motor vehicles of all kinds (caravan, trucks, RV and Trucks come with a very
wide array of rims, wheels, and tires, with an even larger choice of
aftermarket products. It is impossible for us to test every combination and
check the fitment of the FOBO Ultra sensor. In some instances, when the
FOBO sensor is screwed onto the valve stem, it might extend slightly beyond
the face of the rim/wheel. If the rim/wheel comes close to or strikes an object,
such as a curb, a pothole, the guide rail for an automatic vehicle wash, or a
component on the vehicle, the FOBO sensor or the valve stem itself might
become damaged. This can cause the FOBO to provide improper readings, or
might cause a loss of air pressure. We recommend that you carefully assess
the fitment of your rims, wheels, tires and the FOBO on your vehicle. If you
have any concerns, consult with your tire shop or auto mechanic. A shorter
valve stem might be considered to mitigate the situation.
17 | P a g e
5.3 FOBO SHARE- Setting up multiple users
FOBO Ultra is easy to share with your family members and friends. You can
share FOBO Ultra with up to 100 users by using the App‟s FoboShare
function. All that is required is for the other person to download the FOBO
Ultra App (they will also need an iOS/Android smartphone with Bluetooth 4.0
that is running on iOS7.1 or Android 4.3 and above). They need to activate
their App with their email and login to the App.
Follow these steps to share your FOBO Ultra with other users:-
1. Ensure that the user receiving the sharing (recipient) has downloaded the
FOBO Ultra App and has activated their App with their own email address.
2. Ensure that the recipient‟s smartphone has their Bluetooth connection
turned on.
3. On your Vehicle status screen, click on the settings icon and select
„FoboShare‟.
4. Click on the “+” sign at the top right corner of the App.
5. Type in the recipient‟s email that was used to activate their App.
6. Your vehicle profile will appear on the recipient‟s App with a “FoboShare”
logo.
7. The recipient clicks on your vehicle profile and he will start to receive all
the data from the FOBO Ultra sensors on his smartphone when he is
within Bluetooth range.
NOTE: Please ensure good internet connection for FOBO Ultra App to
connect to the cloud.
Note that shared users will not be able to change settings (name, user limits,
etc.) on your FOBO Ultra set. They can only view the readings and receive
alerts. At the FOBO Ultra‟s App HOME page, a shared vehicle will depict a
“FoboShare” logo at the bottom of vehicle profile image to distinguish a
shared vehicle from your own vehicle.
5.4 Sensor rotation
It is good practice to rotate your tire positions regularly to balance the thread
wear of your tires, usually swapping the front tires with the rear tires. FOBO
Ultra is designed to conveniently set the sensors to their correct tire position in
the in-car unit after you have swap your tires on your vehicle. You do not
18 | P a g e
need to physically remove the sensors. To correct the position of the sensors
in the in-car unit, please select “sensor Rotation” under Main Menu on in-car
unit. You will be prompted by the in-car unit to:
1) Select the sensor position to rotate. Move to the desired position to
select the sensor by using the arrow key which is in the middle of the in-
car unit/Repeater.
2) Upon selection, you will be prompted to touch the sensor to the in-car
unit /Repeater.
3) There will be an audible sound with a message to indicate successful
registration of new position.
4) Choose NEXT to go to another tire position to rotate.
5) Choose END to complete the rotation process.
You are now ready to use FOBO Ultra with the new tire positions. You can
perform tire rotation as often as you want.
5.5 Disable sensor and Replace new sensor
You may want to disable a sensor due to a missing sensor or damaged sensor
or to install a replacement sensor. Disabling a missing or damaged sensor will
remove future missing sensor alerts.
To disable a tire sensor:-
1. Go to Sensor Management in the Menu of In-Car/Repeater, select
“Disable sensor”.
2. Select the tire position in the screen to disable.
3. Once disabled You will see “Sensor Disabled” message will appear on the
screen. Take note that FOBO Ultra will stop monitoring the disabled
sensor position.
To install a replacement tire sensor:-
1. Select “Replace sensor” under Sensor Management in the Menu of In-
Car/Repeater.
2. The first disabled position will be blinking.
3. Move to the desired disabled position to assign a replacement sensor.
4. Select the tire position to replace.
5. You will be prompted to touch the sensor to the in-car unit.
19 | P a g e
6. Once replaced you will see “Sensor is successfully replaced..”. Please
mount the sensor to the physical tire position in accord with the screen
message.
NOTE: You can only install a replacement sensor after the tire position has
been “Disabled”. You can purchase replacement sensors online from
www.my-fobo.com.
5.6 Transfer FOBO Ultra to another user
Before passing on your FOBO Ultra set to another user, you will have to
release the Total system from your FOBO account. Select “Release (Total
sensor)” under Main Menu on in-car unit then “Release total system”.
Make sure your In-Car unit and smartphone are with you. You will be
prompted with a message to “Select PROCEED to continue and follow the
instruction on the phone App”, upon selecting PROCEED; the In-Car unit
will connect to the smartphone. You will hear an audible sound upon
successful release and “System released” message will appear on in-car unit
screen.
5.7 Tire Inflation/Deflation
To Inflate/Deflate the tire user just need to unscrew the sensor, inflate/deflate
the tire then screw back the sensor on tire valve. User do not need to release
or disable the sensor.
5.8 Hook & Drop
With its patent pending F.I.T (FOBO Intra Connect) technology, FOBO Ultra
System offers Hook & Drop for easy attachment and detachment of trailers to
prime mover. F.I.T. enables harvesting of sensor data by clusters of
individual sensors and then transmits the data amongst inter-connected
clusters to the In-Car unit. FOBO Ultra system can display up to 94 wheel
positions with a combination of 1 In-Car + 3 Repeater clusters. For example,
for a prime mover that hauls 3 trailers, FOBO Ultra allows 1 In-Car unit for
the prime mover and 3 repeater units for the 3 Trailers. 1 In-Car unit can
monitor up to a cluster of 22 sensors while each Repeater unit can monitor up
to a cluster of 24 sensors. Each Repeater unit can be independently controlled,
programmed and monitored.
20 | P a g e
To HOOK a trailer:
1. Select “Hook & Drop” in the Main Menu of In-Car unit.
2. Select “Hook a trailer”.
3. Upon selecting, the in-car unit will scan for available trailers nearby in
Bluetooth range.
4. List of available trailers will be displayed on the in-car unit screen.
5. Select the desired trailer from the list which you would like to Hook.
6. To confirm press “Yes”.
7. Once hooked you will see “Hook successful” message will appear on
the screen.
To DROP a trailer:
1. Select “Hook & Drop” in the Main Menu of In-Car unit..
2. Select “Drop a trailer”.
3. List of hooked trailers will be displayed on the screen.
4. Select the desired trailer from the list which you would like to Drop.
5. To confirm press “Yes”.
6. Once dropped you will see “Drop successful” message will appear on
the screen.
6 FOBO Ultra Alert Messages
You will get the following alert messages below on your smartphone during
the operation of FOBO Ultra under different conditions. The In-Car
unit/Repeater will also generate different alert tones to distinguish the severity
of the alert. When you get a continuous non-stop two-tone alert, please find a
safe location to stop your car and check the alert messages on the smartphone.
21 | P a g e
A. Soft Alert – In-Car unit will beep 5 tone alert every
5 minutes for 15 minutes –
6.1 Pressure below preset limit
You will receive this soft alert when the tire pressure drops below the pre-set
lower limit. The pre-set value for the low limit is 8% below the recommended
pressure that you have set or below 160kPa, whichever that is higher. You can
change this lower limit in the advance setting down to a minimum of 160kPa
(1.6 bar/23 psi). For fuel economy and optimum tire performance, it is
recommended to maintain this 8% range so that you can keep your tires
inflated optimally. If you find the reminder is too frequent, you may want to
check your tire for any leakage. Note that drastic temperature drop may also
cause tire pressure drop. Please check your tire pressure and re-inflate during
change of seasons.
Note: The hard limit for low pressure is fixed at 160kpa (1.6bar/23psi)
and cannot be change by the user.
6.2 Pressure above preset limit
You will receive this soft alert when the tire pressure increases above pre-set
upper limit. The pre-set value for upper limit is 25% above recommended
pressure or above 1296kPa (188psi), whichever that is lower. You can change
this upper limit in the advance settings up to a maximum of 1296KPa (188
psi). For optimum tire performance and grip, you should not overinflate your
vehicle tires. Note that the tire pressure will naturally increase as the vehicle
tires heat up due to friction while driving. However, you should check your
tire in the event of an abnormal rise in the tire pressure.
Note: The hard limit for high pressure is fixed at 1986kpa (188 psi) and
cannot be change by the user.
6.3 Sensor battery level low
You will receive this soft alert when the sensor battery level drops to certain
level. Please change the battery immediately after you receive this alert. You
will continue to receive this alert every time you start moving your vehicle
until the battery is changed.
22 | P a g e
6.4 In-Car unit/Repeater battery level low
You will receive this soft alert when the In-Car unit/Repeater reaches a
certain low level. Please change the battery immediately after you receive this
alert. You will continue to receive this alert every time you start moving your
vehicle until the battery is changed.
B. Emergency Alert – In-Car unit/Repeater it will beep
continuously non-stop with a two tone alert every 3
seconds for 15 minutes.
6.5 Pressure too low
You will receive this emergency alert when the tire pressure drops 15% below
the recommended pressure that you set or when the tire pressure is below
160kPa (1.6 bar/ 23psi), whichever that is higher. NOTE: IT IS
DANGEROUS TO DRIVE WITH LOW TIRE PRESSURE AND IT
MAY LEAD TO A BLOW-OUT. PLEASE STOP THE VEHICLE AND
HAVE THE TIRE CHECKED WHEN YOU RECEIVE THIS ALERT.
6.6 Pressure too high
You will receive this emergency alert when the tire pressure is 35% above the
vehicle tire recommended pressure that you set or when the tire pressure is
above 1296kPa (188psi), whichever that is lower. NOTE: THIS IS AN
ABNORMAL RISE IN THE TIRE PRESSURE. PLEASE STOP THE
VEHICLE AND HAVE THE TIRE CHECKED WHEN YOU RECEIVE
THIS ALERT.
6.7 Temperature too high
You will receive this emergency alert when the temperature detected exceeds
65oC/149oF. Note that the temperature inside the tire may be higher than the
temperature detected by FOBO Ultra sensors due to the air cooling effect on
the tire valve when the vehicle is moving. It is extremely dangerous to drive
when you get this alert message. WARNING: WHEN YOU RECEIVE
THIS ALERT, PLEASE STOP YOUR VEHICLE IMMEDIATELY
AND CHECK THE TIRE!
23 | P a g e
6.8 Signal low or sensor missing
You will receive this emergency alert when the In-Car unit/Repeater fails to
communicate with the tire sensor. It could be the sensor signal is blocked,
sensor unit damaged or missing from the tire. If confirmed the sensor is
damaged or missing, you could disable the sensor in order to continue using
FOBO Ultra with remaining working sensors. Please purchase the sensor
replacement immediately. It is not advisable to continue driving without
FOBO Ultra actively monitoring one or more of your vehicle tires.
6.9 Pressure Drop too fast
For fast air leak, FOBO Ultra smartly alerts the user when it matters the most.
FOBO sensors sense the pressure every 8 seconds, if the pressure changes
more than 15 Kpa OVER this time frame, the sensor will immediately send
an updated pressure signal to the phone which will trigger an alert on the
FOBO Ultra App in the event the pressure has breached the upper or lower
limit (Applicable to all 3 alert levels).
If there is a sudden drop in pressure (say from 200 Kpa to 0 Kpa) in LESS
than 8 seconds, the App will not alert you because the App will treat this as
though you have removed the sensor to inflate your tire. The system is
designed this way as we believe that if there is an instant drop to 0 pressure,
the user would have already felt it before getting any alert from the TPMS
(like getting a burst, or hitting a kerb/drain, etc.)
7 In-Car unit/Repeater audio & LED alerts
The In-Car unit/Repeater will produce different tones and LED flashes for different
situations. For repetitive alerts, you can stop the alerts by pressing the In-Car unit
side button once. In case you have forgotten the location of the problematic tire,
you can short press the side button another time to re-produce the alert one time.
Wake up – unit will produce “di da” tone once with LED blinking sequentially for
all four tire indicators. This shows that In-Car unit is awake and operational.
Sleep – unit will produce “daaa” tone once. No LED blink. This shows In-Car unit
is going to sleep and not operational. In-Car unit goes to sleep to conserve battery
when vehicle is not moving for a long time. However the sensors will still be
operational 24x7 and continue to monitor and alert to your smartphone in case of
flat tire.
24 | P a g e
Soft alert – unit will produce “di di di di di” tone once and repeat every 3 minutes.
LED will blink for 5 seconds on problematic tire. This alert is for non-emergency
situation such as:-
Tire pressure slightly exceed above or below user pre-set limits. It is not
dangerous to continue driving.
Sensor battery low. Once notified on low sensor battery, please remember to
change the battery as soon as possible. Do not leave the unit to continue
operating under low battery for a long time.
In-Car unit battery low. LED blink will be on the status LED, not on the tire
indicator LED. Once notified on low sensor battery, please remember to
change the battery as soon as possible. Do not leave the unit to continue
operating under low battery for a long time.
Signal low or sensor missing. For this situation, the tone will repeat every 5
seconds instead of 3 minutes to inform user of a possible missing sensor.
Emergency alert – unit will produce “di da di da di da” tone once and repeat every
5 seconds. LED will continue to blink on problematic tire. This alert is for
emergency situation such as:-
Tire pressure is too high or too low. It is not recommended to continue
driving without checking the condition of the tire. Please stop the vehicle at
a safe location to check the condition of the tire.
Tire temperature is too hot, exceeding 65oC or 149oF. It is not recommended
to continue driving without checking the condition of the tire. Please stop
the vehicle at a safe location to check the condition of the tire. Note that the
measured temperature may be lower by 10oC or 50oF compared to the actual
temperature of the air inside the tire when the vehicle is moving, due to the
cooling effect on the tire valve.
WARNING: FOBO ULTRA IS A MONITORING DEVICE TO
ALERTS THE USER WHEN IT DETECTS SIGNALS THAT IS OUT
OF PRE-SET CONDITIONS BASED ON THE SETTING BY THE
USER. THE USER OR DRIVER IS SOLELY RESPONSIBLE TO
FIND OUT THE ACTUAL CONDITION OF THE TIRE AND TO
ENSURE PROPER TIRE MAINTENANCE. FOBO ULTRA IS NOT
RESPONSIBLE FOR WRONG DIAGNOSTICS OR FALSE ALERTS
THAT MAY CAUSE INCONVENIENCE.
25 | P a g e
8 Replacing Battery
The coin cell battery (CR2032) used in the FOBO Ultra sensors could last up to
fifteen months based on normal operating condition. Operating in extreme cold or
hot temperatures may reduce battery operating life for both the tire sensors and the
In-Car unit.
You will receive an alert on the smartphone and In-Car unit/Repeater when the
sensor or In-Car unit/Repeater battery levels are low. You will be alerted every
time you start to drive your vehicle until the battery is replaced. It is advisable to
change the battery once you receive this battery alert to ensure proper performance
of FOBO Ultra. Do not wait until the battery is fully drained as it will cause FOBO
Ultra to stop working properly.
To replace the battery of sensor unit, unscrew the top cover. Be careful not to
damage the rubber gasket as it may affect water resistance of the sensor unit. Ensure
the battery (CR2032) is inserted with the “+” sign facing up, away from the PCB.
To replace battery for the In-Car unit, slide out the battery cover. Ensure the battery
(AA) is inserted in the correct orientation. It is advisable to use good quality AA
batteries (recommended Lithium or Alkaline) for longer lasting performance of In-
Car unit.
WARNING: RE-USING OLD BATTERIES OR MIXING OLD AND NEW
BATTERIES IN THE IN-CAR UNIT MAY DAMAGE THE ELECTRONICS.
9 Trouble Shooting Guide
Could not sign up a new FOBO account (did not receive activation e-
mail)
o Check the e-mail address entry is typed correctly
o Check the Spam mailbox, in case the e-mail was filtered by the e-
mail server
o Check the smartphone is connected to internet and able to receive
e-mail
Could not sign up a new FOBO account (received activation e-mail)
o Make sure to click on the “Activation” link of the latest e-mail, in
case there are multiple authentication e-mails
o You should be directed to web page that clearly displayed “FOBO
account is activated”.
26 | P a g e
Unable to Login after signing up to FOBO App
o Make sure your e-mail address is typed correctly
o A verification mail will be sent to your e-mail address
o Follow the instruction in the mail to activate your account before
you can Login
o Check if internet connection is available on your smartphone
Unable to pair FOBO Ultra In-Car unit/Repeater
o Make sure the battery is installed correctly and battery tab is
removed.
o Make sure your smartphone has Bluetooth 4.0 or later (Smart
Ready) capability. NOTE: BLUETOOTH 2.0 OR 3.0 WILL
NOT WORK WITH THIS DEVICE.
o Please check if the FOBO Ultra has been paired before to another
FOBO account. You‟ll need to “Release” the FOBO Ultra set from
the FOBO account that it is paired to, before using on your account.
The FOBO Ultra is designed to pair with one FOBO account only
for theft deterrent feature.
o Try to reset the Bluetooth manager of your smartphone (for iOS:
Settings-> Bluetooth-> OFF->ON). At times the Bluetooth manager
may be disrupted which may require manual reset.
o Try to do a hard reset on the phone.
Unable to pair FOBO Ultra sensors
o Make sure the sensor is screwed onto a tire valve with pressure
above 100kPa
o Try unscrew the sensor from tire valve, screw it back and try again
o Make sure the battery is installed correctly with battery “+” on top.
o Make sure your smartphone has Bluetooth 4.0 or later (Smart
Ready) capability. NOTE: BLUETOOTH 2.0 OR 3.0 WILL
NOT WORK WITH THIS DEVICE.
o Try to reset the Bluetooth manager of your smartphone (for iOS:
Settings-> Bluetooth-> OFF->ON). At times the Bluetooth manager
may be disrupted which may require manual reset.
o Try to do a hard reset on the phone.
27 | P a g e
10 FOBO Ultra Specifications
Sensor Specifications:
• Maximum Pressure 1296 Kpa (188 psi)
• Pressure Accuracy:
1 σ = +/- 0.79 psi (0 to + 50 °C)
1 σ = +/- 1.06 psi (-40 to + 85°C)
• Temperature Accuracy:
1 σ = +/- 1 °C (0 to + 50 °C)
1 σ = +1.33 / - 1°C (-40 to + 85°C)
• Operational temperature range: -40 to 85°C
• Up to 15 months battery life CR2032
• Dust protected & Waterproof : IP57
• Light weight sensors. Only 12.6 g each
• Certification: FCC, CE, BQB and RoHS
• Mechanical & Environmental Reliability Testing Standards: IEC 60068-2-2,
IEC 60068-2-1, IEC 60068-2-29, IEC 60068-2-5, IEC 60068-2-32, ISO
15184, ISO 2409, SAE J2848 , SAE J1455
• Bluetooth 4.1 (Compatible with Bluetooth 4.0 or later)
• Compatible with iOS 7.1 or Android 4.3 or later
In-Car / Repeater Specifications:
• Operational temperature range: -40 to 80°C
• Battery life: up to 12 months
• Power source: Battery AA x 5 pcs or 12V to 24V external supply
• Operating Temperature
- With vehicle power source: -40°C ~ +85°C
- With Alkaline batteries: -18°C ~ +50°C
• Storage Temperature:
Without Alkaline battery: -40°C ~ +85°C
With Alkaline battery: -30°C ~ +45°C
• Weight : 100g (without battery)
220g with 5x alkaline batteries
• Dust protected & Waterproof : IP57 (Repeater only)
• Certification: FCC, CE, BQB and RoHS
28 | P a g e
• Mechanical & Environmental Reliability Testing Standards: IEC 60068-2-2,
IEC 60068-2-1, IEC 60068-2-29, IEC 60068-2-5, IEC 60068-2-32, ISO
15184, ISO 2409, SAE J2848 , SAE J1455
• Bluetooth 4.1 (Compatible with Bluetooth 4.0 or later)
• Compatible with iOS 7.1 or Android 4.3 or later
• NFC
11 Warning
Take note that FOBO Ultra is not meant to function as anti-accident or
anti-injury device. FOBO Ultra is not a substitute for safe tire
maintenance practices. Please take full responsibility of your own safety
while driving. And continue to send your car for regular tire check and
maintenance.
Please take extra precaution to acoustics safety when operating the
FOBO Ultra In-Car unit. Note that placing the FOBO Ultra In-Car unit
beeper close to your ear may result in injury to the ear or permanent loss
of hearing.
You shall not use the FOBO Ultra in any unlawful way that violates any
laws.
Avoid exposing the FOBO Ultra In-Car unit and sensors to solvent, fire
or extreme temperatures.
FOBO Ultra may fail to function properly if the battery is below
optimum level. Replace the battery immediately to continue enjoying
full features of FOBO Ultra.
CAUTION
THERE MAY BE A RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE. DISPOSE ALL USED
BATTERIES PROPERLY.
29 | P a g e
12 Regulatory Information
Federal Communication Commission Interference
Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly Approved by the
party responsible for compliance could void the user's authority to operate this
equipment.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
30 | P a g e
Industry Canada statement:
This device complies with ISED‟s licence-exempt RSSs. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d‟ ISED applicables aux appareils
radio exempts de licence. L‟exploitation est autorisée aux deux conditions
suivantes : (1) le dispositif ne doit pas produire de brouillage préjudiciable, et
(2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage
susceptible de provoquer un fonctionnement indésirable.
Radiation Exposure Statement:
This equipment complies with ISED radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
Déclaration d’exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements
ISED établies pour un environnement non contrôlé. Cet équipement doit être
installé et utilisé avec un minimum de 20 cm de distance entre la source de
rayonnement et votre corps.
European Union Regulatory Conformance
This equipment is CE marked according to the provisions of the R&TTE
Directive (99/5/EC) and is in compliance with the essential requirements and
other relevant provisions of the Directive 1999/5/EC. This equipment meets
the following conformance standards:
EN 300 328, EN62479, EN 301 489-1&17, EN 60950-1
31 | P a g e
EU Declaration of Conformity
Hereby, Salutica Allied Solutions Sdn. Bhd. declares that this Bluetooth
device is in compliance with the essential requirements and other relevant
provision of Directive 1999/5/EC.
Caution: Changes or modifications to this FOBO device not expressly
Approved by the party responsible for compliance could void the user‟s
authority to operate it.
Bluetooth Wireless Compatibility:
This FOBO device supports the following Bluetooth wireless protocols and
profiles:
Bluetooth core technology v4.0
Battery Profile (BAS)
Proximity (PXP)
Device Information Service (DIS)
Bluetooth Wireless Interoperability:
This FOBO device is designed to be interoperating with all Bluetooth wireless
products that support compatible profiles and roles including:
Bluetooth core technology v4.0
Bluetooth master and slave roles
NCC Statement低功率電波輻射性電機管理辦法
第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使
用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。
第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發
現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前項合法
通信，指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信
或工業、科學及醫療用電波輻射性電機設備之干擾。
13 Intellectual Properties
FOBO™ is a trademark of Salutica Allied Solutions Sdn Bhd. All rights
reserved.
FOBO™ Ultra incorporates a few patent pending technologies solely
owned by Salutica Allied Solutions Sdn Bhd.
32 | P a g e
Bluetooth® is a registered trademark owned by Bluetooth SIG Inc.
IPhone® is a registered trademark of Apple Inc.
14 Limited Warranty & Disclaimer
14.1 Warranty
FOBO Ultra comes with a 12 months limited warranty. This Limited
Warranty does not cover: 1) products purchased from an unauthorized
reseller; 2) products purchased through online auctions; 3) products that are
operated in combination with software, peripheral or ancillary equipment such
as but not limited to batteries, chargers, adapters, headsets, connector cables,
and power supplies ("Ancillary Equipment") not furnished or otherwise
certified by Salutica for use with the FOBO products or any damage to the
FOBO products or ancillary equipment as a result of such use; 4) damage
caused by (a) accident, fire, misuse, neglect, unusual physical or electrical
stress, or modification; (b) improper or unauthorized installation, wiring,
repair, testing or (c) use of the product outside Salutica‟s published
guidelines; 5) instances in which someone other than Salutica (or its
authorized service centers) tests, alters, modifies or services the products in
any way; 6) products that have (a) serial numbers or date tags that have been
removed or altered, or (b) nonconforming or non-FOBO housings or parts;
and 7) consumable spare parts and accessories (unless they are found to be
non-functional or broken upon purchase of product).
In order to obtain any warranty service, you agree to bear all shipping charges
of the FOBO Ultra device to Salutica‟ s address.
14.2 Disclaimer
SALUTICA MAKES NO OTHER EXPRESS WARRANTY WHETHER
WRITTEN OR ORAL AND SALUTICA EXPRESSLY DISCLAIMS ALL
WARRANTIES AND CONDITIONS NOT STATED IN THIS LIMITED
WARRANTY. TO THE EXTENT ALLOWED BY THE LOCAL LAW OF
JURISDICTIONS OUTSIDE MALAYSIA, SALUTICA DISCLAIMS ALL
33 | P a g e
IMPLIED WARRANTIES OR CONDITIONS, INCLUDING ANY
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE. FOR ALL TRANSACTIONS OCCURRING
IN MALAYSIA, ANY IMPLIED WARRANTY OR CONDITION OF
MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR
A PARTICULAR PURPOSE IS LIMITED TO THE WARRANTY PERIOD
AS PROVIDED BY SALUTICA IN THE MATERIALS RECEIVED AT
THE TIME OF PURCHASE.
No warranty is made that the software provided by Salutica will meet your
requirements or will work in combination with any hardware or Applications
software products provided by third parties, that the operation of the software
products will be uninterrupted or error free, or that all defects in the software
products will be corrected.
14.3 Limitation of Liability
THE MAXIMUM LIABILITY OF SALUTICA UNDER THIS LIMITED
WARRANTY IS EXPRESSLY LIMITED TO THE LESSER OF THE
PRICE YOU HAVE PAID FOR THE PRODUCT OR THE COST OF
REPAIR OR REPLACEMENT OF THAT PRODUCT OR ANY
COMPONENT OR PART THAT MALFUNCTION IN CONDITIONS OF
NORMAL USE. EXCEPT AS INDICATED ABOVE, IN NO EVENT WILL
SALUTICA BE LIABLE FOR ANY DAMAGES CAUSED BY THE FOBO
ULTRA PRODUCT OR THE FAILURE OF THE PRODUCT TO
PERFORM, INCLUDING ANY LOST PROFITS OR SAVINGS OR
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
SALUTICA IS NOT LIABLE FOR ANY CLAIM MADE BY A THIRD
PARTY OR MADE BY YOU FOR A THIRD PARTY. THIS LIMITATION
OF LIABILITY APPLIES WHETHER DAMAGES ARE SOUGHT, OR A
CLAIM MADE, UNDER THIS LIMITED WARRANTY OR AS A TORT
CLAIM (INCLUDING NEGLIGENCE AND STRICT PRODUCT
LIABILITY), A CONTRACT CLAIM, OR ANY OTHER CLAIM. THIS
LIMITATION OF LIABILITY CANNOT BE WAIVED OR AMENDED BY
ANY PERSON. THIS LIMITATION OF LIABILITY WILL BE
EFFECTIVE EVEN IF YOU HAVE ADVISED SALUTICA OR AN
AUTHORIZED REPRESENTATIVE OF SALUTICA OF THE
POSSIBILITY OF ANY SUCH DAMAGES. THIS LIMITATION OF
LIABILITY, HOWEVER, WILL NOT APPLY TO CLAIMS FOR
PERSONAL INJURY.
14.4 What Law Governs This Warranty
THIS LIMITED WARRANTY IS GOVERNED BY AND CONSTRUED
UNDER THE LAWS OF MALAYSIA.
