USERS MANUAL 1

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598

Transmitter Certification

Test Report

FCC ID: SDBTGB001LP/SDBTGB001HP

FCC Rule Part: CFR 47 Part 24 Subpart D, Part 90 Subpart I, Part 101

Subpart C

ACS Report Number: 05-0169-LP/05-0169-HP

Manufacturer: Advanced Metering Data Systems, LLC

Equipment Type: Base Station Transceiver

Model(s): TGB001LP

TGB001HP

Users Manual

consent is prohibited.

AMDS CONFIDENTIAL

TGB 900MHz

Users Manual & Operators Guide

Prepared by:

AMDS

2021 Lakeshore Dr.

Suite 414

New Orleans, LA 70122

PH: (504)304-2502

consent is prohibited.

AMDS CONFIDENTIAL

1. DESCRIPTION

1.1. Purpose

The purpose of this document is to provide necessary information for use by

field personnel in the installation, operation, and troubleshooting of the

900MHz Cell Tower Gateway Basestation (TGB).

consent is prohibited.

AMDS CONFIDENTIAL

1.2. FCC Class B Statement

“NOTE: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modifications to this device not expressly approved by

AMDS could void the user’s authority to operate the equipment.

RF Exposure

In accordance with FCC requirements of human exposure to radiofrequency

fields, the radiating element shall be installed such that a minimum separation

distance of:

• For HP Models (i.e. FCC ID and IC ID’s end in “HP”) a distance of 2.5

meters.

• For LP Models (i.e. FCC ID and IC ID’s end in “LP”) a distance of 0.5

meters.

Note: These limits are for CFR 47 Part 90 and Par101 operation. CFR 47

Part 24 limits will be addressed at time of licensing according to Part 1.1307

of CFR 47. This information presented is correct for all three Rule Parts.

consent is prohibited.

AMDS CONFIDENTIAL

1.3. Industry Canada

This Class B digital apparatus meets all requirements of the Canadian

Interference Causing Equipment Regulations. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference,

and (2) this device must accept any interference received, including

interference that may cause undesired operation.

Cet appareillage numérique de la classe B répond à toutes les exigences de

l'interférence canadienne causant des règlements d'équipement. L'opération

est sujette aux deux conditions suivantes: (1) ce dispositif peut ne pas causer

l'interférence nocive, et (2) ce dispositif doit accepter n'importe quelle

interférence reçue, y compris l'interférence qui peut causer l'opération peu

désirée.

1.4. Specifications

1.4.1. Input Power

1.4.1.1. Voltage: 24VDC

1.4.1.2. Input Current

10A max (at low input voltage range)

Approximately 3A continuous

1.4.1.3. Alarms and Controls

Low-voltage alarm is asserted when output voltage drops below

22VDC.

Low-voltage disconnect is asserted when output voltage drops below

20VDC, re-connects when output voltage exceeds 22VDC.

1.4.2. Environmental

1.4.2.1. Operating temperature

-40˚C to +85˚C

1.4.2.2. Storage temperature

-40˚C to +85˚C

1.4.2.3. Humidity

0% to 95%, non-condensing

consent is prohibited.

AMDS CONFIDENTIAL

1.4.3 General Information

The TGB Transceiver is a high performance burst data radio system. The RF

receiver is configured to receive 3 distinct modulation schemes on 3 adjacent

frequencies in the 896 to 940 MHz frequency range.

The TGB RF Transmitter operates on a single configurable channel (12.5kHz,

13.6 KHz, or 25kHz authorized bandwidth depending on the channel and

FCC Rule section governing it’s operation) in the 935 to 960 MHz frequency

range. The transmitter utilizes yet another type of modulation scheme,

different from the three utilized by the receiver.

Transmitted and received data messages are short in nature, meaning that

the radio is intended for burst telemetry type of applications. Larger packets

may, however, be transmitted by sending successive packets.

The TGB operates as a multi-channel transceiver in a “cellular” type system.

The TGB assembles the received messages and forwards them to the TGB

Controller (one per city) via local phone lines. The TGB Controller eliminates

redundant messages (i.e., messages from endpoints that were received by

more than one TGB) before forwarding them to the NOC via a high-speed

connection (ISDN, T1, etc).

The TGB shall also notify the NOC of any alarm indications, such as

tamper/intrusion, temperature alarms, or power failure.

The TGB is installed inside an equipment enclosure containing a 24 VDC

power supply and battery charger (FCC Part 15 Class B Compliant), a cavity

duplexer/combiner allowing for single antenna operation, and all necessary

grounding and lightning protection hardware needed to protect the TGB under

normal operation.

consent is prohibited.

AMDS CONFIDENTIAL

1.5. Block Diagram

1.5.1. Power System

!!! Danger !!!

Hazardous AC voltages capable of producing severe electrical shock

are present at various locations in the TGB. Exercise caution when

working inside the enclosure, to assure that contact is not made with

and electrical termination.

!!! Warning !!!

The batteries are a source of energy and can be hazardous if

shorted. Exercise caution.

1.5.1.1. AC Power – Indoor

AC Power is supplied to the rectifier through a rack mounted power

strip with integral ON/OFF switch and surge protection.

1.5.1.2. AC Power – Outdoor

AC Power enters the outdoor enclosure through the bottom of the

cabinet. The rectifier plugs into the surge protected, GFI outlet located

in the bottom of the cabinet.

1.5.1.3. DC Power

An FCC, Part 15, Class B compliant rectifier (battery charger) converts

commercial power (120/220VAC) to 24VDC power to the equipment

chassis, heat exchanger, fans, intrusion alarm, and batteries. In the

event of commercial power failure, the rectifier provides uninterrupted

DC power by switching over to battery backup.

1.5.1.4. Fuses and Breakers

The TGB contains one 10A circuit breaker/disconnect to protect/control

power to the electronics chassis.

1.5.1.5. Grounding

The ground bus bar MUST be connected to the site’s HALO ground

using an insulated conductor of sufficient size. All transient voltage

protectors (antenna, commercial power, TELCO lines) are grounded to

this bus bar. Failure to properly ground the TGB equipment presents

a risk to not only the TGB electronics, but other customers’ equipment

at the site as well.

A qualified electrician must perform this connection. Consult a local

electrician, or site engineer, for size requirements.

consent is prohibited.

AMDS CONFIDENTIAL

1.5.2. Wiring

The TGB equipment enclosure wiring is supplied in another document and

is beyond the scope of this manual. All TGB connections to the wiring and

interconnect of the TGB equipment enclosure are provided below to assist

the operator in installing the TGB inside the equipment enclosure.

1.5.3. Alarms

1.5.3.1. Intrusion

The enclosure the TGB is mounted in is equipped with pin switches on

both the front and rear doors that activate and intrusion alarm when a

door is opened. A feature of the outdoor enclosures intrusion switch is

the ability to “pull out” the switch to cancel the alarm. The switch has a

30-minute mechanical delay, after which the intrusion alarm will again

be asserted.

1.5.3.2. Temperature

The TGB is equipped with high (120F) and low (41F) temperature

sensors. The TGB notifies the TGB controller of the type of alarm.

1.5.3.3. Power System

The rectifier has several alarm outputs to signal different types of faults

associated with the power system.

Low Voltage Alarm – Asserted upon loss of AC Commercial Power.

Rectifier Failure – Asserted when DC output voltage is out-of-range.

Load Fuse Failure – Asserted when one of the load fuses (Fan, Heat

Exchanger, Intrusion Alarm) opens.

Battery Failure – Asserted when output voltage drops below

threshold, Low voltage disconnect is activated, or Bypass switch is in

Bypass position.

1.5.4. RF Subsystem

1.5.4.1. Spark Gap

The antenna bulkhead connector is a Gas Discharge Tube Surge

Arrestor designed to shunt lightening induced transients to ground;

thereby protecting the TGB electronics from damage. The arrestor

contains a replaceable gas tube element that should be inspected

regularly are replaced as necessary.

1.5.4.2. Cavity Filter / Duplexer

The cavity filter is a frequency selective device designed to protect the

RF front end from overloading by out-of-band signals. The cavity filter

assembly is tuned and assembled as a unit by qualified AMDS

personnel. No cables or connectors should be changed or replaced,

consent is prohibited.

AMDS CONFIDENTIAL

nor should any adjustments be made to the tuning screws of the Cavity

Filter / Duplexer by the operator.

1.5.4.3. RF Cabling

The RF cabling and connectors inside the TGB enclosure are selected

due to their low-loss characteristics. No cables or connectors should

be changed or replaced by the operator.

1.5.5. Breakout Panel Assembly

The purpose of the Breakout Panel is to function as an interface

between the Fusion Processor and the “external world”. It provides a

termination point, and more importantly Transient Voltage

Suppression, of signals coming into the Fusion Processor. TVS

devices protect all Alarm Inputs, Modem Lines, and Ethernet Lines.

Signal I/O Function/Comments

POTS1

POTS2

Bi-directional POTS Modem Connections

Diagnostic

Port Bi-directional DB9 Female connector wired as a

DCE

Inputs 1-7 Inputs Contact Closure Alarm Inputs.

Ethernet Bi-directional 10/100Base T Ethernet Port

2. Installation

2.1. Ventilation

The outdoor enclosure is completely sealed from the outside environment

(NEMA 4). A heat exchanger is used to cool internal electronics.

The indoor enclosure is designed to circulate ambient air for cooling. Fans

inside the enclosure are designed to circulate air across the electronics and

power supply.

2.2. Electrical Connections

2.2.1. Grounding

Ensure that all connections to the Ground bus bar are secure. The bus

bar must also be connected to the site’s Halo Ground using the 8AWG

Green/Yellow cable provided with the TGB System.

consent is prohibited.

AMDS CONFIDENTIAL

2.2.2. Power/Battery

!!! Warning !!!

Do not make any connections with power applied to the system. The

batteries are a source of energy and can be hazardous if shorted.

Exercise caution.

Prior to connecting batteries, disconnect the battery cable from the right

hand side of the rectifier cabinet. Install batteries and connect jumpers to

battery terminals. Before reconnecting battery cable to right hand side of

rectifier cabinet, measure open circuit voltage between pins 1 & 2. The

voltage should be above 24VDC. If the voltage is below 22VDC, do not

proceed with connection—batteries must first be charged before

installation.

2.2.3. Antenna

The antenna connection is a Type-N female located on the top of the

indoor cabinet (bottom of the outdoor cabinet). The connector is a

bulkhead mounted surge arrestor rated at 90V.

The antennas (and their installations, including separation distances)

utilized by the TGB must follow the following FCC guidelines:

For Part 24:

The antenna(s) used for this transmitter (receiver) must be fixed-mounted

on outdoor permanent structures. RF exposure compliance is addressed

at the time of licensing, as required by the responsible FCC Bureau(s),

including antenna co-location requirements of §1.1307(b)(3).

For Part 90 and Part 101 Operation:

The antenna(s) used for this transmitter must be fixed-mounted on

outdoor permanent structures with a separation distance of 2.5 meters for

the HP model and 0.5 meters for the LP model (Note: Model numbers are

ascertained by either front panel labeling or by noting the IC or FCC ID

label placed on the rear panel of the TGB) from all persons during normal

operation. The peak conducted output power at each antenna terminal

must not exceed 1.24 Watts for the LP model and 32.21 Watts for the HP

Model. The peak radiated output power (EIRP) must not exceed 16.14

Watts for the LP model and 418.8 Watts for the HP model.

consent is prohibited.

AMDS CONFIDENTIAL

Antenna Co-Location At Multiple-Transmitter Sites:

According to § 1.1307(b)(3), the FCC requires the following (excerpted

from CFR 47):

(3) In general, when the guidelines

specified in § 1.1310 are exceeded in an

accessible area due to the emissions

from multiple fixed transmitters, actions

necessary to bring the area into

compliance are the shared responsibility

of all licensees whose transmitters

produce, at the area in question,

power density levels that exceed 5% of

the power density exposure limit applicable

to their particular transmitter or

field strength levels that, when

squared, exceed 5% of the square of the

electric or magnetic field strength

limit applicable to their particular

transmitter. Owners of transmitter

sites are expected to allow applicants

and licensees to take reasonable steps

to comply with the requirements contained

in § 1.1307(b) and, where feasible,

should encourage co-location of transmitters

and common solutions for controlling

access to areas where the RF

exposure limits contained in § 1.1310

might be exceeded.

2.3. Data Link

The TGB supports several different communications backbones—a

single/dual modem (56K) connection or a 10/100BaseT Ethernet connection.

The modems and Ethernet connections are made through the modular

connectors on the breakout panel.

2.4. Initial Startup

Prior to applying power, ensure that all fuses are in place, the antenna is

connected, the 24 VDC supply is connected to the TGB, and the data line

(POTS or Ethernet) is connected.

After approximately 30 seconds, the Fusion Processor will complete its boot

up procedure, and the TGB will connect to the TGB Controller.

After approximately 1 minute, the TGB boot-up sequence should be

completed. All LED’s indicating a green color on the front panel informs the

operator that the TGB is operating correctly and has passed all self tests.

consent is prohibited.

AMDS CONFIDENTIAL

IF ANY RED LIGHTS ARE DISPLAYED ON THE TGB FRONT PANEL,

POWER DOWN THE UNIT AND CALL THE OPERATIONS CENTER FOR

FURTHER INSTRUCTIONS.

3. Operation

3.1. General

The TGB is designed to operate with minimal user intervention—even in the

event of commercial AC power interruption.

Specialized software may be used (available ONLY to authorized AMDS

technical personnel pursuant to the requirements of CFR 47 Part 90.203) to

configure the control parameters of the TGB at the installation site for setup

and troubleshooting.

For all installation purposes other than those expressly listed above,

performed by authorized AMDS personnel, you, the operator, only have the

ability, and are authorized to:

• Connect power to the unit.

• Attach the interconnect cabling to the unit (i.e. RF cables, POTS

interconnect).

• Turn on and off the unit’s power.

• Connect a diagnostic cable to the unit to allow for monitoring of system

status.

• Run a monitoring and control program on an IBM PC compatible

computer that allows you to monitor several TGB status indicators and

to power up and down the unit.

• Visually ascertain certain system operational parameters by viewing

the LED indicators on the front panel of the TGB.

• Work with AMDS authorized personnel to ascertain if the TGB is

operating properly.

Pursuant to FCC regulations, you the operator are NOT allowed to perform the

following tasks by any means. Operators that do not adhere to these important

guidelines will face disciplinary action and may be prosecuted under the laws of

the United States Of America or Canada:

• You may not program new transmitter or receiver frequencies (these are

programmed by authorized AMDS personnel either at the site or at the

AMDS service depot using specialized software or via an internet

connection using a secure data link).

• You may not program any on-air related characteristics of the TGB.

NOTE: The items listed immediately above may not be invoked in any way due

to any control on the front panel of the TGB pursuant to CFR 47 Part 90.203 of

consent is prohibited.

AMDS CONFIDENTIAL

the FCC Rules. Highly controlled and specialized software, protected using

password login is utilized (either through a specialized diagnostic port or via a

secure internet link to the TGB) by ONLY AMDS authorized personnel, to

program any of the on-air operational parameters of the TGB.

3.2. Starting and Stopping

Prior to powering down the TGB Electronics, the Halt command should be

issued to the Fusion Processor via the internet link or by qualified AMDS

service personnel. After the Fusion Processor has completed shutdown, the

TGB Electronics can then be powered-down by switching the Chassis

breaker/disconnect to the OFF position. To start the TGB Electronics simply

switch the Chassis breaker/disconnect to the ON position.

If a qualified AMDS service professional is not present to execute the Halt

command to the Fusion Processor, the unit may be powered off (and then on

if desired) by the operator with no detriment to the system or it’s operation. If

this scenario is performed by the operator it is the operator’s responsibility to

inform the AMDS network operations center of this condition so that AMDS

personnel can perform the appropriate housekeeping for the TGB via the

secure internet link.

consent is prohibited.

AMDS CONFIDENTIAL

3.3. Indicators

Indicator Location Description

INPUT OK Power Supply GRN – Input voltage within normal

operating limits

FAULT Power Supply RED – Output Voltage Fault

GRN – Fusion Processor Power OKPOWER Fusion Processor

OFF – Fusion Processor Power Fail

RED – Alarm Input Active IN1 thru IN7 Fusion Processor OFF – Alarm Input not Active

TRIP CPC Flash RED – Trip Detected

MSG CPC Flash AMBER – Valid Message

Received

GRN – CPC Power OK OK CPC OFF – CPC Power Fail

RED – System RESET Asserted RESET A/D OFF – System OK

GRN – A/D Power OK POWER A/D OFF – A/D Power Fail

OTR A/D Flash AMBER – Input Over-range

GRN – Receiver Power OK POWER Receiver OFF – Receiver Power Fail

AMBER – Synthesizer Locked LOCK Receiver RED – Synthesizer Unlocked

GRN – AC Power OK AC POWER

OK Rectifier OFF – AC Power Fail

RED – DC Output Voltage Out of

Range

RECTIFIER

FAILURE Rectifier

OFF – Normal Operation

RED – Load Fuse Failed LOAD FUSE

FAILURE Rectifier OFF – Normal Operation

RED – Output Voltage Low, or

Low Voltage Disconnect

Activated, or

Switch in BYPASS

BATTERY

FAILURE Rectifier

OFF – Normal Operation

Shaded areas indicate Normal Operation.

3.4. Low Voltage Alarm and Disconnect

Upon Commercial AC Power Failure, the TGB will immediately notify the

network via the AC POWER Alarm; at which time the system will begin

operating on battery backup. After duration determined by capacity of

batteries, charge state, temperature, and current draw, the output voltage of

the batteries will decrease.

consent is prohibited.

AMDS CONFIDENTIAL

The system provides for local visual (BATTERY FAILURE) and remote

indication the system output voltage has fallen below a preset level. This

level is set at the factory at 24V. The alarm clears automatically when the

system output voltage increases above this level.

The Low Voltage Alarm is the final indication that the TGB system is about to

shut down. Once asserted the TGB will shutdown in approximately 8 hours

unless commercial AC power is restored..

4. Maintenance

4.1. General

The TGB is designed to require minimal maintenance. Care should be taken

to observe the appropriate precautions when working inside the TGB

enclosure.

!!! The circuit cards used in this equipment contain static sensitive

devices. Observe precautions for handling ESD sensitive items. A, ESD

wrist strap is located inside the front door of the TGB enclosure.

4.2. Preventative or Routine Maintenance

4.2.1. Surge arrestor

The antenna surge arrestor is of the gas discharge tube type. A gas tube

element may not always show outward signs of failure or degradation,

therefore routine maintenance and inspection is recommended. The gas

tube element can be replaced by simply removing the nut and replacing

the element. If the number of thunderstorms in an area is high, gas tubes

should be inspected more frequently. Gas tube degradation is dependant

on the number of strikes as well as the intensity of the strikes. As obvious

as it may seem, gas tube elements should never be inspected, or

replaced, when a thunderstorm is approaching or occurring.

4.2.2. Airflow

Without adequate airflow, TGB performance may degrade due to

increased temperature. At least once per year, the TGB enclosures

should be checked for proper airflow. This includes verifying operation of

all fans and ensuring that any air filters are free of dust and dirt.

4.3. Circuit Card Installation/Replacement

No operator or user serviceable equipment is provided in the TGB with the

exception of battery replacement and other housekeeping items.

IF ANY HARDWARE OR SOFTWARE FAILURE IS REPORTED OR

DETECTED SERVICING IS TO BE PERFORMED BY QUALIFIED AMDS

TECHNICAL SERVICE PERSONNEL ONLY!!

consent is prohibited.

AMDS CONFIDENTIAL

4.4. Battery Replacement

!!! Warning !!!

The batteries are a source of energy and can be hazardous if shorted.

Exercise caution.

The batteries are rated for a 5-yr life at 25˚C and 27.5VDC float voltage.

Extended periods of operation above 25˚C will reduce battery life (rule of

thumb: 50% life reduction per every 10˚C increase. After this time it is

appropriate to have a change-out program. In the event of frequent deep

discharges it is possible that the batteries may require earlier replacement.

Prior to disconnecting batteries, disconnect the battery cable from the right

hand side of the rectifier cabinet. Remove jumpers from the battery terminals

and remove old batteries. Install new batteries and reconnect jumpers.

Before reconnecting battery cable to right hand side of rectifier cabinet,

measure open circuit voltage between pins 1 & 2. The voltage should be

above 22VDC. If the voltage is below 22VDC, do not proceed with

connection—batteries must first be charged before installation.

4.5. Battery Recharging

!!! Warning !!!

The batteries are a source of energy and can be hazardous if shorted.

Exercise caution.

The shelf life of the batteries is 6 months from the date of charge. If the

battery has been stored for more than 6 months, it should be recharged prior

to installation.

consent is prohibited.

AMDS CONFIDENTIAL

5. Ordering Information and Parts List

5.1. Spares Kit

Description Manufacturer Part Number

Antenna Surge Arrestor Andrews APG-BNFNF-090

Gas Tube Andrews GASTUBE-090

Generator Plug Hubbell 2713

Bussmann GMT - 1 1/3 A 1 1/3A GMT Fuse Littlefuse HB481001.33

Bussmann GMT - 2 A 2A GMT Fuse Littlefuse HB481002

Bussmann GMT - 5 A 5A GMT Fuse Littlefuse H481005

Sensus Metering Systems TGB001HP BASE STATION TRANSCEIVER User Manual USERS MANUAL 1

Sensus Metering Systems Inc. BASE STATION TRANSCEIVER USERS MANUAL 1

Contents

USERS MANUAL 1

Navigation menu

Namespaces

Views

Navigation
