User Manual
SIMATIC NET
Industrial Wireless LAN
Approvals SCALANCE W700
802.11n
Reference Manual
01/2017
C79000-G8976-C392-05
W780 / W740 802.11n
W788C / W786C 802.11n
W770/W730 802.11n
W760/W720 802.11n
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Division Process Industries and Drives
Postfach 48 48
90026 NÜRNBERG
GERMANY
C79000-G8976-C392-05
Ⓟ01/2017 Subject to change
Copyright © Siemens AG 2014 - 2017.
All rights reserved
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
3
Table of contents
1
Approvals for SCALANCE W780 / W740 802.11n ................................................................................. 5
1.1
EC declaration of conformity ................................................................................................ 7
1.1.1
ATEX .................................................................................................................................. 8
1.1.2
RoHS .................................................................................................................................. 8
1.1.3
R&TTE / RED ...................................................................................................................... 8
1.1.3.1
Protection of health and safety ............................................................................................ 8
1.1.3.2
EMC.................................................................................................................................... 9
1.1.3.3
Efficient use of the radio spectrum ....................................................................................... 9
1.1.4
Products ............................................................................................................................ 10
1.2
General approvals ............................................................................................................. 12
1.3
National approvals ............................................................................................................. 21
2
Approvals for SCALANCE W788C / W786C 802.11n ...........................................................................39
2.1
EC declaration of conformity .............................................................................................. 40
2.1.1
ATEX ................................................................................................................................ 41
2.1.2
RoHS ................................................................................................................................ 41
2.1.3
R&TTE / RED .................................................................................................................... 41
2.1.3.1
Protection of health and safety .......................................................................................... 41
2.1.3.2
Efficient use of the radio spectrum ..................................................................................... 42
2.1.3.3
EMC.................................................................................................................................. 42
2.1.4
Products ............................................................................................................................ 43
2.2
General approvals ............................................................................................................. 44
2.3
National approvals ............................................................................................................. 52
3
Approvals for SCALANCE W770/W730 802.11n..................................................................................69
3.1
EC declaration of conformity .............................................................................................. 70
3.1.1
ATEX ................................................................................................................................ 71
3.1.2
RoHS ................................................................................................................................ 71
3.1.3
R&TTE / RED .................................................................................................................... 71
3.1.3.1
Protection of health and safety .......................................................................................... 71
3.1.3.2
EMC.................................................................................................................................. 72
3.1.3.3
Efficient use of the radio spectrum ..................................................................................... 72
3.1.4
Products W770/W730 ....................................................................................................... 73
3.2
General approvals ............................................................................................................. 74
3.3
SCALANCE W774/734 national approvals ......................................................................... 80
3.4
SCALANCE W778/738 national approvals ......................................................................... 95
4
Approvals for SCALANCE W760/W720 802.11n............................................................................... 103
4.1
EC declaration of conformity ............................................................................................ 104
4.1.1
ATEX .............................................................................................................................. 105
4.1.2
RoHS .............................................................................................................................. 105
4.1.3
R&TTE / RED .................................................................................................................. 105
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
4
Table of contents
4.1.3.1
Protection of health and safety ........................................................................................ 105
4.1.3.2 EMC ............................................................................................................................... 106
4.1.3.3 Efficient use of the radio spectrum ................................................................................... 106
4.1.4 Products...........................................................................................................................107
4.2
General approvals ............................................................................................................108
4.3
National approvals............................................................................................................114
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
5
Approvals for SCALANCE W780 / W740 802.11n 1
Note
Issued approvals on the type plate of the device
The specified approvals apply only when the corresponding mark is printed on the product.
You can check which of the following approvals have been granted for your product by the
markings on the type plate.
Range of validity
The approvals listed in this section apply to the following products:
Article number of the
RoW version:
Article number of the
US version:
Article number of the
Israel version:
Access point
SCALANCE W786-1 RJ-45 6GK5 786-1FC00-0AA0 6GK5 786-1FC00-0AB0 -
Dual access points
SCALANCE W786-2 RJ-45 6GK5 786-2FC00-0AA0 6GK5 786-2FC00-0AB0 6GK5786-2FC00-0AC0
SCALANCE W786-2IA RJ-45 6GK5 786-2HC00-0AA0 6GK5 786-2HC00-0AB0 -
SCALANCE W786-2 SFP 6GK5 786-2FE00-0AA0 6GK5 786-2FE00-0AB0 -
Article number of the
RoW version:
Article number of the
US version:
Article number of the
Israel version:
Access points
SCALANCE W788-1 RJ-45 6GK5788-1FC00-0AA0 6GK5788-1FC00-0AB0 -
SCALANCE W788-1 M12 6GK5788-1GD00-0AA0 6GK5788-1GD00-0AB0 -
Dual access points
SCALANCE W788-2 RJ-45 6GK5788-2FC00-0AA0 6GK5788-2FC00-0AB0 6GK5788-2FC00-0AC0
SCALANCE W788-2 M12 6GK5788-2GD00-0AA0 6GK5788-2GD00-0AB0 -
SCALANCE W788-2 M12 EEC 6GK5788-2GD00-0TA0 6GK5788-2GD00-0TB0 -
Ethernet client modules
SCALANCE W748-1 RJ-45 6GK5748-1FC00-0AA0 6GK5748-1FC00-0AB0 -
SCALANCE W748-1 M12 6GK5748-1GD00-0AA0 6GK5748-1GD00-0AB0 -
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
6
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.1 EC declaration of conformity
Abbreviations used
Some approvals apply only to certain devices or series. In such situations, the designations
of the products are shortened to avoid having to list all the type designations. The following
table shows how the abbreviations relate to the product variants.
Product group
The designation . . .
stands for . . .
Product name
Access points (IP30 and IP65) W788-x SCALANCE W788-1 M12
SCALANCE W788-2 M12
SCALANCE W788-2 M12 EEC
SCALANCE W788-1 RJ-45
SCALANCE W788-2 RJ-45
Access points (IP65) W786-x SCALANCE W786-1 RJ-45
SCALANCE W786-2 RJ-45
SCALANCE W786-2IA RJ-45
SCALANCE W786-2 SFP
SCALANCE W without W786-x W7x8 SCALANCE W788-1 RJ-45
SCALANCE W788-1 M12
SCALANCE W788-2 RJ-45
SCALANCE W788-2 M12
SCALANCE W788-2 M12 EEC
SCALANCE W748-1 RJ-45
SCALANCE W748-1 M12
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
7
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.1 EC declaration of conformity
1.1
EC declaration of conformity
The EC Declaration of Conformity is available for all responsible authorities at:
Siemens Aktiengesellschaft
Process Industries and Drives Division,
Process Automation
DE-76181 Karlsruhe
Germany
You will find the current EC declaration of conformity for these products on the Internet
pages of Siemens Industry Online Support
(hhttps://support.industry.siemens.com/cs/ww/en/ps/15853/cert).
The SIMATIC NET products described in these Operating Instructions meet the
requirements of the following EC directives:
●
94/9/EC
Directive of the European Parliament and the Council of 23 March 1994 on the
approximation of the laws of the Member States concerning equipment and protective
systems intended for use in potentially explosive atmospheres (until 19.04.2016).
●
2014/34/EU
Directive 2014/34/EU of the European Parliament and of the Council of 26 February 2014
on the harmonization of the laws of the Member States relating to equipment and
protective systems intended for use in potentially explosive atmospheres official journal of
the EU L96, 29/03/2014, pages. 309–356 (as of 20.04.2016)
●
1999/5/EC
Directive of the European Parliament and of the Council of 1999 March 1999 on Radio
Equipment and Telecommunications Terminal Equipment and the mutual recognition of
their conformity (until 12.06.2016).
●
2014/53/EU
Directive of the European Parliament and of the Council of April 16, 2014 on the
harmonization of the laws of the member states relating to placing radio equipment on the
market.; official journal of the EU L153, 22/05/2014, pages. 62–106 (as of 13.06.2016)
●2011/65/EU (RoHS)
RoHS directive of the European Parliament and of the Council of 8 June 2011 on the
restriction of the use of certain hazardous substances in electrical and electronic
equipment.
●
1999/519/EC
Council recommendation on the limitation of exposure of the general public to
electromagnetic fields (0 Hz to 300 GHz)
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
8
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.1 EC declaration of conformity
1.1.1
ATEX
ATEX directive (correct usage in potentially explosive atmospheres)
The SIMATIC NET product meets the requirements of the EC directive:94/9/EC (until
19.04.2016) and 2014/34/EU (as of 20.04.2016) "Equipment and Protective Devices for Use
in Potentially Explosive Atmospheres" according to the standards listed in the section
Products (Page 10):
Applied standard:
1 EN 60079-0 + A11
Hazardous areas - Part 0: Equipment - General requirements
2 EN 60079-15
Explosive atmospheres - Part 15: Equipment protection by type of protection "n"
1.1.2
RoHS
RoHS directive (restriction of the use of certain hazardous substances)
The SIMATIC NET products described in these operating instructions meet the requirements
of the EC directive 2011/65/EC for the restriction of the use of certain hazardous substances
in electrical and electronic equipment:
Applied standard:
3 EN 50581
Technical documentation for the assessment electrical and electronic products with
respect to restriction of hazardous substances
1.1.3
R&TTE / RED
1.1.3.1
Protection of health and safety
Article 3 (1) a) protection of health and safety
4 EN 60950-1+A1+A2+A11+A12
Information technology equipment - Safety - Part 1: General requirements
5 EN 62311
Assessment of electronic and electrical equipment related to human exposure re-
strictions for electromagnetic fields (0 Hz – 300 GHz)
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
9
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.1 EC declaration of conformity
1.1.3.2 EMC
Art. 3 (1) b - EMC
6 EN 50121-3-2+AC
Railway applications - Electromagnetic compatibility - part 3-2: Railway Vehicles -
Devices
7 EN 50121-4+AC
Railway applications - Electromagnetic compatibility - part 4: Interference emissions
and immunity of signal telecommunications equipment
8 ETSI EN 301 489-1
Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic
compatibility for radio equipment and services - Part 1 : Common technical re-
quirements
9 ETSI EN 301 489-17
Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic
compatibility for radio equipment and services - Part 17 :
10 EN 61000-6-1
Electromagnetic compatibility (EMC) - Part 6-1: Generic standards - Immunity for
residential, commercial and light-industrial environments
11 EN 61000-6-2+AC
Electromagnetic compatibility (EMC) - Part 6-2: Generic standards - Immunity for
industrial environments
12 EN 61000-6-3+A1+AC
Electromagnetic compatibility (EMC) - Part 6-3: Generic standards - Emission
standard for residential, commercial and light-industrial environments
13 EN 61000-6-4+A1
Electromagnetic compatibility (EMC) - Part 6-4: Generic standards - Emission
standard for industrial environments
1.1.3.3
Efficient use of the radio spectrum
Art. 3 (2) Efficient use of the radio spectrum
14
ETSI EN 301 328
Electromagnetic compatibility and radio spectrum matters (ERM) - wideband
transmission systems - data transmission equipment operating in the 2.4 GHz ISM
band and using wideband modulation techniques. Harmonized EN containing the
essential requirements according to Article 3.2 of the R&TTE directive.
15
ETSI EN 301 893
Broadband Radio Access Networks (BRAN) - 5 GHz high performance RLAN -
Harmonized EN covering essential requirements of article 3.2 of the R&TTE Di-
rective
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.1 EC declaration of conformity
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
10
1.1.4
Products
Product designation and standards
The standards that apply to the product are described in RoHS (Page 8), ATEX (Page 8) and
R&TTE / RED (Page 8).
Product name
Standards
W786-1 RJ45
W786-2 RJ45
W786-2IA RJ45
W786-2 SFP
W788-1 RJ45
W788-2 RJ45
W788-1 M12
W788-2 M12
W748-1 RJ45
W748-1 M12
1, 2 3, 4, 5, 8, 9, 10, 11, 12, 13, 14, 15,
W788-2 M12 EEC 1, 2 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.1 EC declaration of conformity
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
11
Certification ID
The following tables show the product names and the corresponding certification ID:
Type
Number and type of
the Ethernet interfaces
Number of inter-
nal antennas
Number of R-SMA
sockets for external
Certification ID
Article number
antennas
Article number US variant
W786-1 RJ-45 1 x RJ-45 - 3 EAPN-W1-RJ-E3
6GK5 786-1FC00-0AA0
6GK5 786-1FC00-0AB0
W786-2 RJ-45 1 x RJ-45 - 6 EAPN-W2-RJ-E3
6GK5 786-2FC00-0AA0
6GK5 786-2FC00-0AB0
W786-2IA RJ-45 1 x RJ-45 2 - EAPN-W2-RJ-I3
6GK5 786-2HC00-0AA0
6GK5 786-2HC00-0AB0
W786-2 SFP 2 x SFP - 6 EAPN-W2-SFP-E3
6GK5 786-2FE00-0AA0
6GK5 786-2FE00-0AB0
Type
Certification ID
Article number:
Article number US variant
W788-1 RJ-45 RAPN-W1-RJ-E3
6GK 5788-1FC00-0AA0
6GK 5788-1FC00-0AB0
W788-2 RJ-45 RAPN-W2-RJ-E3
6GK5 788-2FC00-0AA0
6GK5 788-2FC00-0AB0
W788-1 M12 RAPN-W1-M12-E3
6GK5 788-1GD00-0AA0
6GK5 788-1GD00-0AB0
W788-2 M12 RAPN-W2-M12-E3
6GK5 788-2GD00-0AA0
6GK5 788-2GD00-0AB0
W788-2 M12 EEC RAPN-W2-M12-E3
6GK5 788-2GD00-0TA0
6GK5 788-2GD00-0TB0
W748-1 RJ-45 RAPN-W1-RJ-E3
6GK5 748-1FC00-0AA0
6GK5 748-1FC00-0AB0
W748-1 M12 RAPN-W1-M12-E3
6GK5 748-1GD00-0AA0
6GK5 748-1GD00-0AB0
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.2 General approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
12
1.2
General approvals
ATEX (explosion protection directive)
The SIMATIC NET products meet the requirements of the EC directive 94/9/EC "Equipment
and Protective Devices for Use in Potentially Explosive Atmospheres”. and as of 20.04.2016
the EC directive 2014/34/EU.
ATEX classification:
II 3 G Ex nA IIC T4 Gc
KEMA 07ATEX0145 X
The products meet the requirements of the following standards:
●
EN 60079-15 (electrical apparatus for potentially explosive atmospheres; Type of
protection "n")
●
EN 60079-0 (Explosive atmospheres - Part 0: Equipment - General requirements)
You will find the current versions of the standards in the currently valid ATEX certificates.
IECEx
The SIMATIC NET products meet the requirements of explosion protection according to
IECEx.
IECEx classification:
Ex nA IIC T4 Gc
DEK 14.0025X
The products meet the requirements of the following standards:
●
IEC 60079-15 (Explosive atmospheres - Part 15: Equipment protection by type of
protection "n")
●
IEC 60079-0 (Explosive atmospheres - Part 0: Equipment - General requirements)
You will find the current versions of the standards in the currently valid IECEx certificates.
WARNING
When using SIMATIC NET products in hazardous area zone 2, make absolutely sure that
the associated conditions in the following document are adhered to:
"SIMATIC NET Product Information Use of subasseblies/modules in a Zone 2 Hazardous
Area".
You will find this document
on the data medium that ships with some devices.
on the Internet pages of Siemens Industry Online Support
(http://support.automation.siemens.com/ww).
Enter the document identification number C234 as the search term.
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.2 General approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
13
FM
The product meets the requirements of the standards:
●
Factory Mutual Approval Standard Class Number 3611
●
FM Hazardous (Classified) Location Electrical Equipment:
Non Incendive / Class I / Division 2 / Groups A,B,C,D / T4 and
Non Incendive / Class I / Zone 2 / Group IIC / T4
cULus Approval for Information Technology Equipment
cULus Listed I. T. E.
Underwriters Laboratories Inc. complying with
●
UL 60950-1 (Information Technology Equipment)
●CSA C22.2 No. 60950-1-03
Report no. E115352
Note
Only devices of the SCALANCE W786-x series have this approval.
cULus Approval Hazardous Location
cULus Listed I. T. E. FOR HAZ. LOC.
Underwriters Laboratories Inc. complying with
●
UL 60950-1 (Information Technology Equipment)
●ANSI/ISA 12.12.01-2007
●CSA C22.2 No. 213-M1987
Approved for use in
Cl. 1, Div. 2, GP A, B, C, D T4
Cl. 1, Zone 2, GP IIC T4
Report no. E240480
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.2 General approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
14
FCC approval
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1)
this device may not cause harmful interference, and
(2)
this device must accept any interference received, including interference that may cause
undesired operation.
Notice
Changes or modifications made to this equipment not expressly approved by SIEMENS may
void the FCC authorization to operate this equipment.
IEEE 802.11b or g operation of this product in the USA is firmware-limited to channels 1
through 11.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
●
Reorient or relocate the receiving antenna.
●
Increase the separation between the equipment and receiver.
●
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
●
Consult the dealer or an experienced radio/TV technician for help.
Notice
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20 cm
between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter. Professional Installation Notice:
To comply with FCC part 15 rules in the United States, the system must be professionally
installed to ensure compliance with the Part 15 certification. It is the responsibility of the
operator and professional installer to ensure that only certified systems are deployed in the
United States. The use of the system in any other combination (such as co-located antennas
transmitting the same information) is expressly forbidden.
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.2 General approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
15
Notice
For use of DFS channels
●
Use of the RCoax Cable Antenna 6XV1875-2D is not permitted in channels which
require dynamic frequency selection (DFS).
●
Any installation of either a master or a client device within 35 km of a TDWR (Terminal
Doppler Weather Radar) location shall be separated by at least 30 MHz (center-to-center)
from the TDWR operating frequency.
These devices shall be registered in the industry sponsored WISPA database,
http://udia.spectrumbridge.com/udia/home.aspx
(http://udia.spectrumbridge.com/udia/home.aspx)
When you open this link, you get the following choices:
–
"Search" opens a window with TDWR locations and frequencies.
–
"User Signup" allows you to register as user of the database.
–
After registering you can Logon and register your WLAN location. Please fill in all
required information.
For more information with respect to WISPA database and TWDR locations please consult
FCC publication KDB 443999 D01.
NEMA TS2
The product meets the requirements of the standard
NEMA TS2 (Traffic Controller Assemblies with NTCIP Requirements)
SCALANCE W788-2 M12 EEC
6GK5788-2GD00-0TA0
6GK5788-2GD00-0TB0
RSS-247 of Industry Canada for SCALANCE W786-x
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
This radio transmitter (IC: 267AA-MPCIE1V1) has been approved by Industry Canada to
operate with the antenna types listed in section 6.8 with the maximum permissible gain and
required antenna impedance for each antenna type indicated. Antenna types not included in
this list, having a gain greater than the maximum gain indicated for that type, are strictly
prohibited for use with this device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna
of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To
reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
necessary for successful communication.
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.2 General approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
16
To reduce potential radio interference to other users, the antenna type and its gain should be
so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
permitted for successful communication.
That the device for the band 5150-5250 MHz is only for indoor usage to reduce potential for
harmful interference to co-channel mobile satellite systems.
Users should also be cautioned to take note that high power radars are allocated as primary
users (meaning they have priority) of 5250-5350 MHz and 5650-5850 MHz and these radars
could cause interference and/or damage to LE-LAN devices.
This equipment complies with IC RSS-102 radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with minimum
distance 20cm between the radiator & your body.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
RSS-247 of Industry Canada for SCALANCE W7x8
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
This radio transmitter (IC: 267AA-MPCIE1V1) has been approved by Industry Canada to
operate with the antenna types listed in section 5.4 with the maximum permissible gain and
required antenna impedance for each antenna type indicated. Antenna types not included in
this list, having a gain greater than the maximum gain indicated for that type, are strictly
prohibited for use with this device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna
of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To
reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
necessary for successful communication.
To reduce potential radio interference to other users, the antenna type and its gain should be
so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
permitted for successful communication.
That the device for the band 5150-5250 MHz is only for indoor usage to reduce potential for
harmful interference to co-channel mobile satellite systems.
Users should also be cautioned to take note that high power radars are allocated as primary
users (meaning they have priority) of 5250-5350 MHz and 5650-5850 MHz and these radars
could cause interference and/or damage to LE-LAN devices.
This equipment complies with IC RSS-102 radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with minimum
distance 20cm between the radiator & your body.
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.2 General approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
17
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
Note for USA, Canada, Puerto Rico, Peru, Bahamas, Ecuador and Columbia
When operating the SCALANCE W700 with DFS (Dynamic Frequence Selection), the
IWLAN RCoax Cable 5 GHz (order number 6XV1875-2D) may not be used in the countries
listed above.
Approvals in Argentina
Devices of the SCALANCE W786-x series are approved in Argentina under the following
certification numbers:
Certification ID Certification number
EAPN-W1-RJ-E3 CNC: C-11549
EAPN-W2-RJ-E3 CNC: C-11536
EAPN-W2-RJ-I3 CNC: C-11564
EAPN-W2-SFP-E3 CNC: C-11547
Devices of the SCALANCE W788-x series are approved in Argentina under the following
certification numbers:
Certification ID Certification number
RAPN-W1-RJ-E3 CNC: C-11541
RAPN-W2-RJ-E3 CNC: C-11502
RAPN-W1-M12-E3 CNC: C-11546
RAPN-W2-M12-E3 CNC: C-11548
Approval in Brazil
From the SCALANCE W786-x series, the following devices are approved for Brazil:
Type
Order number EAPN number
W786-1 RJ-45 6GK5 786-1FC00-0AA0 EAPN-W1-RJ-E3
W786-2 RJ-45 6GK5 786-2FC00-0AA0 EAPN-W2-RJ-E3
W786C-2 RJ-45 6GK5 786-2FC00-1AA0 EAPN-W2-RJ-E3
W786-2IA RJ-45 6GK5 786-2HC00-0AA0 EAPN-W2-RJ-I3
W786C-2IA RJ-45 6GK5 786-2HC00-1AA0 EAPN-W2-RJ-I3
W786-2 SFP 6GK5 786-2FE00-0AA0 EAPN-W2-SFP-E3
The listed devices are approved in Brazil under the following certification numbers:
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.2 General approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
18
Este equipamento opera em caráter secundário, isto, ist é, não tem direito à proteção contra
interferência prejudicial, mesmo de estações do mesmo tipo e não pode causar interferência
a sistemas operando em caráter primário.
From the SCALANCE W7x8 series, the following devices are approved for Brazil:
Type
Order number RAPN number
W788-1 RJ-45 6GK 5788-1FC00-0AA0 RAPN-W1-RJ-E3
W788-2 RJ-45 6GK5 788-2FC00-0AA0 RAPN-W2-RJ-E3
W788-1 M12 6GK5 788-1GD00-0AA0 RAPN-W1-M12-E3
W788-2 M12 6GK5 788-2GD00-0AA0 RAPN-W2-M12-E3
W788-2 M12 EEC 6GK5 788-2GD00-0TA0 RAPN-W2-M12-E3
W748-1 RJ-45 6GK5 748-1FC00-0AA0 RAPN-W1-RJ-E3
W748-1 M12 6GK5 748-1GD00-0AA0 RAPN-W1-M12-E3
W788C-2 RJ-45 6GK 5788-2FC00-1AA0 RAPN-W2-RJ-E3
W788C-2 M12 6GK5 788-2GD00-1AA0 RAPN-W2-M12-E3
W788C-2 M12 EEC 6GK5788-2GD00-1TA0 RAPN-W2-M12-E3
The listed devices are approved in Brazil under the following certification numbers:
Este equipamento opera em caráter secundário, isto, ist é, não tem direito à proteção contra
interferência prejudicial, mesmo de estações do mesmo tipo e não pode causar interferência
a sistemas operando em caráter primário.
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.2 General approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
19
KCC Statement (Republic of Korea)
사용자안내문(제5조제1항제1호관련)
기 종 별 사 용 자 안 내 문
A급 기기급 기기 이 기기는 업무용(A 급)으로 전자파적합등록을 한(A 급)으로
(업무용 방송통신기기)
전자파적합등록을
한
기기이오니
판매자
또는
사용자는
이
점을
주의하시기 바라며,가정외의 지역에서 사용하는
것을 목적으로 합니다.
"당해 무선설비는 전파혼신 가능성이 있으므로 인명안전과 관련된 서비스는 할 수 없음"
Approval for Mexico
The WLAN modules included in the devices have the following certification number:
RCPSIMP12-0751
Approval for Oman
Devices of the SCALANCE W786-x series are approved in Oman under the following
certification numbers:
OMAN-TRA
R/1773/14
D090258
Devices of the SCALANCE W788-x series are approved in Oman under the following
certification numbers:
OMAN-TRA
R/1772/14
D090258
NCC Warning Statement (Taiwan)
Article 12
Without permission, any company, firm or user shall not alter the frequency, increase the
power, or change the characteristics and functions of the original design of the certified lower
power frequency electric machinery.
Article 14
The application of low power frequency electric machineries shall not affect the navigation
safety nor interfere a legal communication, if an interference is found, the service will be
suspended until improvement is made and the interference no longer exists.
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.2 General approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
20
Marking for the customs union
EAC (Eurasian Conformity)
Customs union of Russia, Belarus and Kazakhstan
Declaration of the conformity according to the technical regulations of the customs union
(TR CU)
Approvals SCALANCE W
700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
21
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
1.3
National approvals
The following table lists the countries in which the SCALANCE W700 product is approved.
The diamond symbol (♦) identifies all countries for which there was no approval at the time
these operating instructions were written.
The current status of the approvals can be found on the Internet at the following address:
http://www.siemens.com/funkzulassungen
Column Meaning
Country Country
Mode IEEE 802.11 standard and the TPC and / or DFS functionality, where required
CH Channel
MHz Frequency
PWR (EIRP) Maximum permitted effective isotropic radiated power
Use Permitted use indoors and / or outdoors
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
22
Country Mode CH MHz PWR
(EIRP)
Use
Andorra 11g 11n 1 2412 100 mW Indoor + outdoor
Belgium
-
-
Bosnia and Her- 13 2472
zegovina
Bulgaria
Denmark
Germany
Estonia
Finland
France
11a 11n
TPC
36
-
48
5180
-
5240
200 mW Indoor only
11a 11n
DFS + TPC
52
-
64
5260
-
5320
200 mW Indoor only
Greece
100
5500
1000 mW
Indoor + outdoor
Great Britain
-
-
Ireland
116
5580
Iceland
Italy
Croatia
Latvia
Liechtenstein
Lithuania
Luxembourg
132
-
140
5660
-
5700
1000 mW Indoor + outdoor
11a 11n 149
-
165
5745
-
5825
25 mW Indoor + outdoor
Malta
Macedonia
Monaco
Montenegro
Netherlands
Norway
Austria
Poland
Portugal
Romania
San Marino
Sweden
Switzerland
Slovakia
Slovenia
Spain
Czech Republic
Turkey
Hungary
Vatican
Cyprus
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
23
Country Mode CH MHz PWR
(EIRP)
Use
Egypt 11g 11n 1
-
13
2412
-
2472
100 mW Indoor + outdoor
11a 11n
TPC
36
-
64
5180
-
5320
200 mW Indoor only
Angola 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
Argentina 11g 11n 1 2412 1000 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 50 mW Indoor + outdoor
- -
48 5240
11a 11n 52 5260 250 mW Indoor + outdoor
TPC - -
64 5320
100 5500 250 mW Indoor + outdoor
- -
120 5600
132 5660 250 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 1000 mW Indoor + outdoor
- -
165 5825
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
24
Country Mode CH MHz PWR
(EIRP)
Use
Australia 11g 11n 1 2412 100 mW Indoor + outdoor
New Zealand - -
13 2472
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Bahrain 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 2000 mW Indoor + outdoor
- -
165 5825
Belarus 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 100 mW Indoor + outdoor
TCP - -
48 5240
11a 11n 52 5260 100 mW Indoor + outdoor
TCP + DFS - -
64 5320
132 5660 100 mW Indoor + outdoor
- -
140 5700
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
25
Country Mode CH MHz PWR
(EIRP)
Use
Brazil 11g 11n 1 2412 4000 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 200 mW Indoor only
TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 4000 mW Indoor + outdoor
- -
165 5825
Chile 11g 11n 1 2412 100 mW Indoor only
- -
13 2472
11a 11n 36 5180 100 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 100 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 100 mW Indoor only
DFS - -
165 5825
China 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 2000 mW Indoor + outdoor
- -
165 5825
Ivory Coast 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
26
Country Mode CH MHz PWR
(EIRP)
Use
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
Guatemala 11g 11n 1 2412 100 mW Indoor + outdoor
2 2417 200 mW Indoor + outdoor
- -
10 2457
11 2462 100 mW Indoor + outdoor
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 400 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 400 mW Indoor + outdoor
- -
116 5580
132 5660 400 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165
5825
Hong Kong 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
27
Country Mode CH MHz PWR
(EIRP)
Use
100
-
116
5500
-
5580
1000 mW Indoor + outdoor
132
-
140
5660
-
5700
1000 mW Indoor + outdoor
India 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 200 mW Indoor + outdoor
- -
165 5825
Israel 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
Indonesia ♦11g 11n 1 2412 100 mW Indoor + outdoor
2 2417 200 mW Indoor + outdoor
- -
10 2457
11 2462 100 mW Indoor + outdoor
- -
13 2472
11a 11n 149 5745 400 mW Indoor + outdoor
- -
161 5805
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
28
Country Mode CH MHz PWR
(EIRP)
Use
Japan 11g 11n 1 2412 200 mW Indoor + outdoor
- -
13 2472
11a 8 5040 200 mW Indoor + outdoor
- -
16
5080
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 200 mW Indoor + outdoor
- -
140 5700
11a 184 4920 200 mW Indoor + outdoor
-
-
196 4980
Kazakhstan 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 100 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 100 mW Indoor only
DFS + TPC - -
64 5320
132 5660 100 mW Indoor + outdoor
- -
140 5700
Qatar 11g 11n 1 2412 100 mW Indoor only
- -
13 2472
11a 11n 149 5745 100 mW Indoor only
-
-
165 5825
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
29
Country Mode CH MHz PWR
(EIRP)
Use
Colombia 11g 11n 1 2412 100 mW Indoor + outdoor
2 2417 200 mW Indoor + outdoor
- -
10 2457
11 2462 100 mW Indoor + outdoor
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 400 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 400 mW Indoor + outdoor
- -
116 5580
132 5660 400 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Korea 11g 11n 1 2412 400 mW Indoor + outdoor
- -
13 2472
11a 11n 149 5745 400 mW Indoor + outdoor
TPC - -
161 5805
Kuwait 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor + outdoor
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor + outdoor
DFS + TPC - -
64 5320
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
30
Country Mode CH MHz PWR
(EIRP)
Use
Macau 11g 11n 1
-
13
2412
-
2472
100 mW Indoor + outdoor
11a 11n 149
-
161
5745
-
5805
100 mW Indoor + outdoor
Madagascar 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC
-
48
-
5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC -
64
-
5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Malaysia 11g 11n 1 2412 200 mW Indoor + outdoor
- -
13 2472
11a 11n 56 5280 200 mW Indoor only
DFS - -
64 5320
11a 11n 149 5745 1000 mW Indoor + outdoor
- -
165 5825
Morocco ♦11g 11n 1 2412 100 mW Indoor only
(only with
SCALANCE
-
13
-
2472
W786
-
2IA RJ
-
45)
11a 11n 36 5180 200 mW Indoor only
TPC
-
48
-
5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC -
64
-
5320
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
31
Country Mode CH MHz PWR
(EIRP)
Use
Mexico 11g 11n 1
-
11
2412
-
2462
500 mW Indoor + outdoor
11a 11n 36
-
64
5180
-
5320
1000 mW Indoor + outdoor
149
-
165
5745
-
5825
1000 mW Indoor + outdoor
Mozambique 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
Oman 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 1000 mW Indoor + outdoor
- -
165 5825
Pakistan 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 149 5745 100 mW Indoor + outdoor
- -
165 5825
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
32
Country Mode CH MHz PWR
(EIRP)
Use
Russia 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 100 mW Indoor + outdoor
TPC - -
48 5240
11a 11n 52 5260 100 mW Indoor + outdoor
DFS + TPC - -
64 5320
132 5660 100 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 100 mW Indoor + outdoor
- -
165 5825
Saudi Arabia 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
33
Country Mode CH MHz PWR
(EIRP)
Use
Serbia 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC -
48
-
5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC
-
64
-
5320
100 5500 1000 mW Indoor + outdoor
-
-
116
5580
132 5660 1000 mW Indoor + outdoor
- -
140
5700
South Africa 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC -
48
-
5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC
-
64
-
5320
100 5500 1000 mW Indoor + outdoor
- -
116
5580
132 5660 1000 mW Indoor + outdoor
-
-
140 5700
Singapore 11g 11n 1 2412 100 mW Indoor + outdoor
Philippines - -
13 2472
11a 11n 36 5180 200 mW Indoor + outdoor
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116
5580
132 5660 1000 mW Indoor + outdoor
-
-
140 5700
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
34
Country Mode CH MHz PWR
(EIRP)
Use
11a 11n 149 5745 1000 mW Indoor + outdoor
- -
165 5825
Taiwan 11g 11n 1 2412 100 mW Indoor + outdoor
2 2417 200 mW Indoor + outdoor
- -
10 2457
11 2462 100 mW Indoor + outdoor
11a 11n 52 5260 400 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 400 mW Indoor + outdoor
-
-
116 5580
132 5660 400 mW Indoor + outdoor
- -
140
5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Thailand 11g 11n 1 2412 100 mW Indoor + outdoor
- -
11 2462
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 400 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 400 mW Indoor + outdoor
- -
116
5580
132 5660 400 mW Indoor + outdoor
-
-
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
35
Country Mode CH MHz PWR
(EIRP)
Use
Ukraine 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor + outdoor
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 200 mW Indoor + outdoor
- -
116 5580
132 5660 200 mW Indoor + outdoor
- -
136 5680
Uruguay 11g 11n 1 2412 100 mW Indoor + outdoor
2 2417 200 mW Indoor + outdoor
- -
10 2457
11 2462 100 mW Indoor + outdoor
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 400 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 400 mW Indoor + outdoor
-
-
116 5580
132 5660 400 mW Indoor + outdoor
- -
140
5700
11a 11n 149 5745 400 mW Indoor + outdoor
TC - -
165 5825
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
36
Country Mode CH MHz PWR
(EIRP)
Use
Venezuela 11g 11n 1 2412 1000 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 1000 mW Indoor only
DFS - -
64 5320
11a 11n 149 5745 4000 mW Indoor + outdoor
- -
165 5825
United Arab Emir- 11g 11n 1 2412 100 mW Indoor + outdoor
ates --
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor only
- -
116 5580
132 5660 1000 mW Indoor only
- -
140 5700
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
37
Country Mode CH MHz PWR
(EIRP)
Use
Bahamas 11g 11n 1 2412 100 mW Indoor + outdoor
Ecuador 22417 200 mW Indoor + outdoor
Canada - -
Peru 10 2457
Puerto Rico 11 2462 100 mW Indoor + outdoor
USA 11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 400 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 400 mW Indoor + outdoor
-
-
116 5580
132 5660 400 mW Indoor + outdoor
- -
140
5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Vietnam 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Approvals
for
SCALANCE
W780
/
W740
802.11n
1.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
38
Approvals SCALANCE W700
802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
39
Approvals for SCALANCE W788C / W786C 802.11n 2
Note
Issued approvals on the type plate of the device
The specified approvals apply only when the corresponding mark is printed on the product.
You can check which of the following approvals have been granted for your product by the
markings on the type plate.
Range of validity
The approvals listed in this section apply to the following products:
Article number
SCALANCE W786C-2 RJ-45 6GK5 786-2FC00-1AA0
SCALANCE W786C-2IA RJ-45 6GK5 786-2HC00-1AA0
SCALANCE W786C-2 SFP 6GK5 786-2FE00-1AA0
Article number
SCALANCE W788C-2 RJ-45 6GK5 788-2FC00-1AA0
SCALANCE W788C-2 M12 6GK5 788-2GD00-1AA0
SCALANCE W788C-2 M12 EEC 6GK5788-2GD00-1TA0
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
40
Approvals for SCALANCE W788C / W786C 802.11n
2.1 EC declaration of conformity
2.1
EC declaration of conformity
The EC Declaration of Conformity is available for all responsible authorities at:
Siemens Aktiengesellschaft
Process Industries and Drives Division,
Process Automation
DE-76181 Karlsruhe
Germany
You will find the current EC declaration of conformity for these products on the Internet
pages of Siemens Industry Online Support
(hhttps://support.industry.siemens.com/cs/ww/en/ps/15853/cert).
The SIMATIC NET products described in these Operating Instructions meet the
requirements of the following EC directives:
●
94/9/EC
Directive of the European Parliament and the Council of 23 March 1994 on the
approximation of the laws of the Member States concerning equipment and protective
systems intended for use in potentially explosive atmospheres (until 19.04.2016).
●
2014/34/EU
Directive 2014/34/EU of the European Parliament and of the Council of 26 February 2014
on the harmonization of the laws of the Member States relating to equipment and
protective systems intended for use in potentially explosive atmospheres official journal of
the EU L96, 29/03/2014, pages. 309–356 (as of 20.04.2016)
●
1999/5/EC
Directive of the European Parliament and of the Council of 1999 March 1999 on Radio
Equipment and Telecommunications Terminal Equipment and the mutual recognition of
their conformity (until 12.06.2016).
●
2014/53/EU
Directive of the European Parliament and of the Council of April 16, 2014 on the
harmonization of the laws of the member states relating to placing radio equipment on the
market.; official journal of the EU L153, 22/05/2014, pages. 62–106 (as of 13.06.2016)
●2011/65/EU (RoHS)
RoHS directive of the European Parliament and of the Council of 8 June 2011 on the
restriction of the use of certain hazardous substances in electrical and electronic
equipment.
●
1999/519/EC
Council recommendation on the limitation of exposure of the general public to
electromagnetic fields (0 Hz to 300 GHz)
Approvals for SCALANC
E W788C / W786C 802.11n
2.1 EC declaration of conformity
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
41
2.1.1
ATEX
ATEX directive (correct usage in potentially explosive atmospheres)
The SIMATIC NET product meets the requirements of the EC directive:94/9/EC (until
19.04.2016) and 2014/34/EU (as of 20.04.2016) "Equipment and Protective Devices for Use
in Potentially Explosive Atmospheres" according to the standards listed in the section
Products (Page 43):
Applied standard:
1 EN 60079-0 + A11
Hazardous areas - Part 0: Equipment - General requirements
2 EN 60079-15
Explosive atmospheres - Part 15: Equipment protection by type of protection "n"
2.1.2
RoHS
RoHS directive (restriction of the use of certain hazardous substances)
The SIMATIC NET products described in these operating instructions meet the requirements
of the EC directive 2011/65/EC for the restriction of the use of certain hazardous substances
in electrical and electronic equipment:
Applied standard:
3 EN 50581
Technical documentation for the assessment electrical and electronic products with
respect to restriction of hazardous substances
2.1.3
R&TTE / RED
2.1.3.1
Protection of health and safety
Article 3 (1) a) protection of health and safety
4 EN 60950-1+A1+A2+A11+A12
Information technology equipment - Safety - Part 1: General requirements
5 EN 62311
Assessment of electronic and electrical equipment related to human exposure re-
strictions for electromagnetic fields (0 Hz – 300 GHz)
Approvals for SCALANCE W788C / W786C 802.11n
2.1 EC declaration of conformity
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
42
2.1.3.2
Efficient use of the radio spectrum
Art. 3 (2) Efficient use of the radio spectrum
14
ETSI EN 301 328
Electromagnetic compatibility and radio spectrum matters (ERM) - wideband
transmission systems - data transmission equipment operating in the 2.4 GHz ISM
band and using wideband modulation techniques. Harmonized EN containing the
essential requirements according to Article 3.2 of the R&TTE directive.
15
ETSI EN 301 893
Broadband Radio Access Networks (BRAN) - 5 GHz high performance RLAN -
Harmonized EN covering essential requirements of article 3.2 of the R&TTE Di-
rective
2.1.3.3 EMC
Art. 3 (1) b - EMC
6 EN 50121-3-2+AC
Railway applications - Electromagnetic compatibility - part 3-2: Railway Vehicles -
Devices
7 EN 50121-4+AC
Railway applications - Electromagnetic compatibility - part 4: Interference emissions
and immunity of signal telecommunications equipment
8 ETSI EN 301 489-1
Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic
compatibility for radio equipment and services - Part 1 : Common technical re-
quirements
9 ETSI EN 301 489-17
Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic
compatibility for radio equipment and services - Part 17 :
10 EN 61000-6-1
Electromagnetic compatibility (EMC) - Part 6-1: Generic standards - Immunity for
residential, commercial and light-industrial environments
11 EN 61000-6-2+AC
Electromagnetic compatibility (EMC) - Part 6-2: Generic standards - Immunity for
industrial environments
12 EN 61000-6-3+A1+AC
Electromagnetic compatibility (EMC) - Part 6-3: Generic standards - Emission
standard for residential, commercial and light-industrial environments
13 EN 61000-6-4+A1
Electromagnetic compatibility (EMC) - Part 6-4: Generic standards - Emission
standard for industrial environments
Approvals for SCALANC
E W788C / W786C 802.11n
2.1 EC declaration of conformity
Approvals SCALANCE W700 802.
11n
Reference Manual, 01/2017, C79000-G8976-C392-05
43
2.1.4
Products
Product designation and standards
The standards that apply to the product are described in RoHS (Page 41), ATEX (Page 41)
and R&TTE / RED (Page 41).
Product name
Standards
W786C-2 RJ45
W786C-2IA RJ45
W786-2 SFP
W788C-2 RJ45
W788C-2 M12
1, 2 3, 4, 5, 8, 9, 10, 11, 12, 13, 14, 15, 16
W788C-2 M12 EEC 1, 2 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16
Certification ID
The following tables show the product names and the corresponding certification ID:
Type Number and type of
the Ethernet interfaces
Number of inter-
nal antennas
Number of R-SMA
sockets for external
antennas
Certification ID
Article number
Article number US variant
W786C-2 RJ-45 1 x RJ-45 - 6 EAPN-W2-RJ-E3
6GK5 786-2FC00-1AA0
W786C-2IA RJ-45 1 x RJ-45 2 - EAPN-W2-RJ-I3
6GK5 786-2HC00-1AA0
W786-2 SFP 2 x SFP - 6 EAPN-W2-SFP-E3
6GK5 786-2FE00-1AA0
Type
Certification ID
Article number:
W788C-2 RJ-45 RAPN-W2-RJ-E3
6GK 5788-2FC00-1AA0
W788C-2 M12 RAPN-W2-M12-E3
6GK5 788-2GD00-1AA0
W788C-2 M12 EEC RAPN-W2-M12-E3
6GK5788-2GD00-1TA0
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
44
Approvals for SCALANCE W788C / W786C 802.11n
2.2 General approvals
2.2
General approvals
ATEX (explosion protection directive)
The SIMATIC NET products meet the requirements of the EC directive 94/9/EC "Equipment
and Protective Devices for Use in Potentially Explosive Atmospheres”. and as of 20.04.2016
the EC directive 2014/34/EU.
ATEX classification:
II 3 G Ex nA IIC T4 Gc
KEMA 07ATEX0145 X
The products meet the requirements of the following standards:
●
EN 60079-15 (electrical apparatus for potentially explosive atmospheres; Type of
protection "n")
●
EN 60079-0 (Explosive atmospheres - Part 0: Equipment - General requirements)
You will find the current versions of the standards in the currently valid ATEX certificates.
WARNING
When using SIMATIC NET products in hazardous area zone 2, make absolutely sure that
the associated conditions in the following document are adhered to:
"SIMATIC NET Product Information Use of subasseblies/modules in a Zone 2 Hazardous
Area".
You will find this document
on the data medium that ships with some devices.
on the Internet pages of Siemens Industry Online Support
(http://support.automation.siemens.com/ww).
Enter the document identification number C234 as the search term.
Approvals SCALANCE W700 802.
11n
Reference Manual, 01/2017, C79000-G8976-C392-05
45
Approvals for SCALANCE W788C
/ W786C 802.11n
2.2 General approvals
IECEx
The SIMATIC NET products meet the requirements of explosion protection according to
IECEx.
IECEx classification:
Ex nA IIC T4 Gc
DEK 14.0025X
The products meet the requirements of the following standards:
●
IEC 60079-15 (Explosive atmospheres - Part 15: Equipment protection by type of
protection "n")
●
IEC 60079-0 (Explosive atmospheres - Part 0: Equipment - General requirements)
You will find the current versions of the standards in the currently valid IECEx certificates.
FM
The product meets the requirements of the standards:
●
Factory Mutual Approval Standard Class Number 3611
●
FM Hazardous (Classified) Location Electrical Equipment:
Non Incendive / Class I / Division 2 / Groups A,B,C,D / T4 and
Non Incendive / Class I / Zone 2 / Group IIC / T4
cULus Approval Hazardous Location
cULus Listed I. T. E. FOR HAZ. LOC.
Underwriters Laboratories Inc. complying with
●
UL 60950-1 (Information Technology Equipment)
●ANSI/ISA 12.12.01-2007
●CSA C22.2 No. 213-M1987
Approved for use in
Cl. 1, Div. 2, GP A, B, C, D T4
Cl. 1, Zone 2, GP IIC T4
Report no. E240480
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
46
Approvals for SCALANCE W788C / W786C 802.11n
2.2 General approvals
FCC approval
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1)
this device may not cause harmful interference, and
(2)
this device must accept any interference received, including interference that may cause
undesired operation.
Notice
Changes or modifications made to this equipment not expressly approved by SIEMENS may
void the FCC authorization to operate this equipment.
IEEE 802.11b or g operation of this product in the USA is firmware-limited to channels 1
through 11.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
●
Reorient or relocate the receiving antenna.
●
Increase the separation between the equipment and receiver.
●
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
●
Consult the dealer or an experienced radio/TV technician for help.
Notice
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20 cm
between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter. Professional Installation Notice:
To comply with FCC part 15 rules in the United States, the system must be professionally
installed to ensure compliance with the Part 15 certification. It is the responsibility of the
operator and professional installer to ensure that only certified systems are deployed in the
United States. The use of the system in any other combination (such as co-located antennas
transmitting the same information) is expressly forbidden.
Approvals SCALANCE W700 802.
11n
Reference Manual, 01/2017, C79000-G8976-C392-05
47
Approvals for SCALANCE W788C
/ W786C 802.11n
2.2 General approvals
Notice
For use of DFS channels
●
Use of the RCoax Cable Antenna 6XV1875-2D is not permitted in channels which
require dynamic frequency selection (DFS).
●
Any installation of either a master or a client device within 35 km of a TDWR (Terminal
Doppler Weather Radar) location shall be separated by at least 30 MHz (center-to-center)
from the TDWR operating frequency.
These devices shall be registered in the industry sponsored WISPA database,
http://udia.spectrumbridge.com/udia/home.aspx
(http://udia.spectrumbridge.com/udia/home.aspx)
When you open this link, you get the following choices:
–
"Search" opens a window with TDWR locations and frequencies.
–
"User Signup" allows you to register as user of the database.
–
After registering you can Logon and register your WLAN location. Please fill in all
required information.
For more information with respect to WISPA database and TWDR locations please consult
FCC publication KDB 443999 D01.
NEMA TS2
The product meets the requirements of the standard
NEMA TS2 (Traffic Controller Assemblies with NTCIP Requirements)
SCALANCE W788C-2 M12 EEC
6GK5788-2GD00-1TA0
RSS-247 of Industry Canada for SCALANCE W786-x
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
This radio transmitter (IC: 267AA-MPCIE1V1) has been approved by Industry Canada to
operate with the antenna types listed in section 6.8 with the maximum permissible gain and
required antenna impedance for each antenna type indicated. Antenna types not included in
this list, having a gain greater than the maximum gain indicated for that type, are strictly
prohibited for use with this device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna
of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To
reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
necessary for successful communication.
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
48
Approvals for SCALANCE W788C / W786C 802.11n
2.2 General approvals
To reduce potential radio interference to other users, the antenna type and its gain should be
so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
permitted for successful communication.
That the device for the band 5150-5250 MHz is only for indoor usage to reduce potential for
harmful interference to co-channel mobile satellite systems.
Users should also be cautioned to take note that high power radars are allocated as primary
users (meaning they have priority) of 5250-5350 MHz and 5650-5850 MHz and these radars
could cause interference and/or damage to LE-LAN devices.
This equipment complies with IC RSS-102 radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with minimum
distance 20cm between the radiator & your body.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
RSS-247 of Industry Canada for SCALANCE W7x8
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
This radio transmitter (IC: 267AA-MPCIE1V1) has been approved by Industry Canada to
operate with the antenna types listed in section 5.4 with the maximum permissible gain and
required antenna impedance for each antenna type indicated. Antenna types not included in
this list, having a gain greater than the maximum gain indicated for that type, are strictly
prohibited for use with this device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna
of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To
reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
necessary for successful communication.
To reduce potential radio interference to other users, the antenna type and its gain should be
so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
permitted for successful communication.
That the device for the band 5150-5250 MHz is only for indoor usage to reduce potential for
harmful interference to co-channel mobile satellite systems.
Users should also be cautioned to take note that high power radars are allocated as primary
users (meaning they have priority) of 5250-5350 MHz and 5650-5850 MHz and these radars
could cause interference and/or damage to LE-LAN devices.
This equipment complies with IC RSS-102 radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with minimum
distance 20cm between the radiator & your body.
Approvals SCALANCE W700 802.
11n
Reference Manual, 01/2017, C79000-G8976-C392-05
49
Approvals for SCALANCE W788C
/ W786C 802.11n
2.2 General approvals
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
Note for USA, Canada, Puerto Rico, Peru, Bahamas, Ecuador and Columbia
When operating the SCALANCE W700 with DFS (Dynamic Frequence Selection), the
IWLAN RCoax Cable 5 GHz (order number 6XV1875-2D) may not be used in the countries
listed above.
Approvals in Argentina
Devices of the SCALANCE W786-x series are approved in Argentina under the following
certification numbers:
Certification ID Certification number
EAPN-W1-RJ-E3 CNC: C-11549
EAPN-W2-RJ-E3 CNC: C-11536
EAPN-W2-RJ-I3 CNC: C-11564
EAPN-W2-SFP-E3 CNC: C-11547
Devices of the SCALANCE W788-x series are approved in Argentina under the following
certification numbers:
Certification ID Certification number
RAPN-W1-RJ-E3 CNC: C-11541
RAPN-W2-RJ-E3 CNC: C-11502
RAPN-W1-M12-E3 CNC: C-11546
RAPN-W2-M12-E3 CNC: C-11548
Approval in Brazil
From the SCALANCE W786-x series, the following devices are approved for Brazil:
Type
Order number EAPN number
W786-1 RJ-45 6GK5 786-1FC00-0AA0 EAPN-W1-RJ-E3
W786-2 RJ-45 6GK5 786-2FC00-0AA0 EAPN-W2-RJ-E3
W786C-2 RJ-45 6GK5 786-2FC00-1AA0 EAPN-W2-RJ-E3
W786-2IA RJ-45 6GK5 786-2HC00-0AA0 EAPN-W2-RJ-I3
W786C-2IA RJ-45 6GK5 786-2HC00-1AA0 EAPN-W2-RJ-I3
W786-2 SFP 6GK5 786-2FE00-0AA0 EAPN-W2-SFP-E3
The listed devices are approved in Brazil under the following certification numbers:
Approvals for SCALANCE W788C / W786C 802.11n
2.2 General approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
50
Este equipamento opera em caráter secundário, isto, ist é, não tem direito à proteção contra
interferência prejudicial, mesmo de estações do mesmo tipo e não pode causar interferência
a sistemas operando em caráter primário.
From the SCALANCE W7x8 series, the following devices are approved for Brazil:
Type
Order number RAPN number
W788-1 RJ-45 6GK 5788-1FC00-0AA0 RAPN-W1-RJ-E3
W788-2 RJ-45 6GK5 788-2FC00-0AA0 RAPN-W2-RJ-E3
W788-1 M12 6GK5 788-1GD00-0AA0 RAPN-W1-M12-E3
W788-2 M12 6GK5 788-2GD00-0AA0 RAPN-W2-M12-E3
W788-2 M12 EEC 6GK5 788-2GD00-0TA0 RAPN-W2-M12-E3
W748-1 RJ-45 6GK5 748-1FC00-0AA0 RAPN-W1-RJ-E3
W748-1 M12 6GK5 748-1GD00-0AA0 RAPN-W1-M12-E3
W788C-2 RJ-45 6GK 5788-2FC00-1AA0 RAPN-W2-RJ-E3
W788C-2 M12 6GK5 788-2GD00-1AA0 RAPN-W2-M12-E3
W788C-2 M12 EEC 6GK5788-2GD00-1TA0 RAPN-W2-M12-E3
The listed devices are approved in Brazil under the following certification numbers:
Este equipamento opera em caráter secundário, isto, ist é, não tem direito à proteção contra
interferência prejudicial, mesmo de estações do mesmo tipo e não pode causar interferência
a sistemas operando em caráter primário.
Approval for Mexico
The WLAN modules included in the devices have the following certification number:
RCPSIMP12-0751
Approvals for SCALANCE W788C
/ W786C 802.11n
2.2 General approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
51
Approval for Oman
Devices of the SCALANCE W786-x series are approved in Oman under the following
certification numbers:
OMAN-TRA
R/1773/14
D090258
Devices of the SCALANCE W788-x series are approved in Oman under the following
certification numbers:
OMAN-TRA
R/1772/14
D090258
Marking for the customs union
EAC (Eurasian Conformity)
Customs union of Russia, Belarus and Kazakhstan
Declaration of the conformity according to the technical regulations of the customs union
(TR CU)
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
52
2.3
National approvals
The national approval of the controller-based access points depends on the controller on
which they are operated. The controllers are available in the following country-specific
versions:
●
Version for the USA and Canada (NAM)
Article no. 6GK5 711-0XC00-1AB0
These countries are indicated in the table (NAM).
●
Version for the Japan (JP)
Article no. 6GK5 711-0XC00-1AD0
●
Version for countries outside Japan and NAM (RoW)
Article no. 6GK5 711-0XC00-1AA0
The diamond symbol (♦) identifies all countries for which there was no approval at the time
these operating instructions were written.
The current status of the approvals can be found on the Internet at the following address:
http://www.siemens.com/funkzulassungen
Column Meaning
Country Country
Mode IEEE 802.11 standard and the TPC and / or DFS functionality, where required
CH Channel
MHz Frequency
PWR (EIRP) Maximum permitted effective isotropic radiated power
Use Permitted use indoors and / or outdoors
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
53
Country Mode CH MHz PWR
(EIRP)
Use
Andorra 11g 11n 1 2412 100 mW Indoor + outdoor
Belgi
um
-
-
Bulgaria 13 2472
Denmark
Germany
Estonia
Finland
France
Greece
Great Britain
11a 11n
TPC
36
-
48
5180
-
5240
200 mW Indoor only
11h 11n
DFS + TPC
52
-
64
5260
-
5320
200 mW Indoor only
Ireland
100
5500
1000 mW
Indoor + outdoor
Iceland
-
-
Italy
116
5580
Croatia
Latvia
Liechtenstein
Lithuania
132
-
140
5660
-
5700
1000 mW Indoor + outdoor
Luxembourg
Malta
Macedonia
Monaco
Montenegro
Netherlands
Norway
Austria
Poland
Portugal
Romania
San Marino
Sweden
Switzerland
Serbia
Slovakia
Slovenia
Spain
Czech Republic
Turkey
Hungary
Vatican
Cyprus
Egypt 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
64 5320
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
54
Country Mode CH MHz PWR
(EIRP)
Use
Angola 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11h 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
Argentina 11g 11n 1 2412 1000 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 50 mW Indoor + outdoor
TPC - -
48 5240
52 5260 250 mW Indoor + outdoor
- -
64 5320
100 5500 250 mW Indoor + outdoor
- -
120 5600
132 5660 250 mW Indoor + outdoor
- -
140 5700
149 5745 1000 mW Indoor + outdoor
- -
165 5825
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
55
Country Mode CH MHz PWR
(EIRP)
Use
Australia 11g 11n 1 2412 100 mW Indoor + outdoor
New Zealand - -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11h 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 400 mW Indoor + outdoor
TPC - -
165 5825
Bahrain 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11h 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 2000 mW Indoor + outdoor
TPC - -
165 5825
Belarus 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 100 mW Indoor + outdoor
TCP - -
48 5240
11a 11n 52 5260 100 mW Indoor + outdoor
TCP + DFS - -
64 5320
132 5660 100 mW Indoor + outdoor
- -
140 5700
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
56
Country Mode CH MHz PWR
(EIRP)
Use
Brazil 11g 11n 1 2412 4000 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
140 5700
149 5745 4000 mW Indoor + outdoor
- -
165 5825
Chile 11g 11n 1 2412 100 mW Indoor only
- -
13 2472
11a 11n 36 5180 100 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 100 mW Indoor only
DFS + TPC - -
64 5320
149 5745 100 mW Indoor only
- -
165 5825
China 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 149 5745 2000 mW Indoor + outdoor
TPC - -
165 5825
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
57
Country Mode CH MHz PWR
(EIRP)
Use
Ivory Coast 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
Guatemala 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
11 2462
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 400 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 400 mW Indoor + outdoor
- -
116 5580
132 5660 400 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
TPC -
165
-
5825
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
58
Country Mode CH MHz PWR
(EIRP)
Use
Hong Kong 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
India 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11h 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 200 mW Indoor + outdoor
- -
165 5825
Indonesia ♦11g 11n 1 2412 100 mW Indoor + outdoor
2 2417 200 mW Indoor + outdoor
- -
10 2457
11 2462 100 mW Indoor + outdoor
- -
13 2472
11a 11n 149 5745 400 mW Indoor + outdoor
TPC - -
161 5805
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
59
Country Mode CH MHz PWR
(EIRP)
Use
Japan 11g 11n 1 2412 200 mW Indoor + outdoor
- -
13 2472
11a
TPC
85040 200 mW Indoor + outdoor
12 5060
16 5080
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11h 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 200 mW Indoor + outdoor
- -
140 5799
11a 184 4920 200 mW Indoor + outdoor
TPC - -
196 4980
Qatar 11g 11n 1 2412 100 mW Indoor only
- -
13 2472
11a 11n 149 5745 100 mW Indoor only
- -
165
5825
Kazakhstan 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 100 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 100 mW Indoor only
DFS + TPC - -
64 5320
132 5660 100 mW Indoor + outdoor
- -
140 5700
Colombia (NAM) 11g 11n 1 2412 100 mW Indoor + outdoor
2 2417 200 mW Indoor + outdoor
- -
10 2457
11 2462 100 mW Indoor + outdoor
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
60
Country Mode CH MHz PWR
(EIRP)
Use
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
149 5745 400 mW Indoor + outdoor
- -
165 5825
Korea 11g 11n 1 2412 400 mW Indoor + outdoor
- -
13 2472
11a 11n 149 5745 400 mW Indoor + outdoor
TPC - -
161 5805
Kuwait 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor + outdoor
TPC - -
48 5240
11h 11n 52 5260 200 mW Indoor + outdoor
DFS + TPC - -
64 5320
Macau 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13 2472
11a 11n 149 5745 100 mW Indoor + outdoor
TPC -
161
-
5805
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
61
Country Mode CH MHz PWR
(EIRP)
Use
Madagascar 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC -
48
-
5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC
-
64
-
5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
TPC - -
165 5825
Malaysia 11g 11n 1 2412 200 mW Indoor + outdoor
- -
13 2472
11h 11n 56 5280 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 1000 mW Indoor + outdoor
TPC - -
165 5825
Mexico (NAM) 11g 11n 1 2412 500 mW Indoor + outdoor
- -
11 2462
11a 11n 52 5180 1000 mW Indoor + outdoor
DFS + TPC - -
64 5320
11a 11n 149 5745 1000 mW Indoor + outdoor
TPC - -
165 5825
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
62
Country Mode CH MHz PWR
(EIRP)
Use
Mozambique 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11h 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
Oman 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 1000 mW Indoor + outdoor
TPC - -
165 5825
Pakistan 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 149 5745 100 mW Indoor + outdoor
TPC - -
165 5825
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
63
Country Mode CH MHz PWR
(EIRP)
Use
Russia 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 100 mW Indoor + outdoor
TPC - -
48 5240
11a 11n 52 5260 100 mW Indoor + outdoor
DFS + TPC - -
64 5320
132 5660 100 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 100 mW Indoor + outdoor
TPC - -
165 5825
Saudi Arabia 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11h 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
Singapore 11b 11g 11n 1 2412 100 mW Indoor + outdoor
Philippines ♦- -
13 2472
11a 11n 36 5180 200 mW Indoor + outdoor
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116
5580
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
64
Country Mode CH MHz PWR
(EIRP)
Use
132
-
140
5660
-
5700
1000 mW Indoor + outdoor
11a 11n
TPC
149
-
165
5745
-
5825
1000 mW Indoor + outdoor
South Africa 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC
-
48
-
5240
11h 11n 52 5260 200 mW Indoor only
DFS + TPC -
64
-
5320
100 5500 1000 mW Indoor + outdoor
-
-
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140
5700
Taiwan ♦11g 11n 1 2412 100 mW Indoor + outdoor
2 2417 200 mW Indoor + outdoor
- -
10
2457
11 2462 100 mW Indoor + outdoor
11a 11n 52 5260 400 mW Indoor + outdoor
TPC - -
64 5320
100 5500
- -
165 5825
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
65
Country Mode CH MHz PWR
(EIRP)
Use
Thailand 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
11 2462
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 400 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 400 mW Indoor + outdoor
-
-
116
5580
132 5660 400 mW Indoor + outdoor
- -
140
5700
11a 11n 149 5745 400 mW Indoor + outdoor
TPC - -
165 5825
Ukraine 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor + outdoor
TPC - -
48 5240
11h 11n 52 5260 200 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 200 mW Indoor + outdoor
- -
116 5580
132 5660 200 mW Indoor + outdoor
- -
136 5680
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
66
Country Mode CH MHz PWR
(EIRP)
Use
Uruguay 11g 1 2412 100 mW Indoor + outdoor
- - -
11 2462 200 mW
11a 36 5180 200 mW Indoor only
- -
48 5240
11a 149 5745 400 mW Indoor + outdoor
- -
165 5825
11n 11g 1 2412 100 mW Indoor + outdoor
- - -
11 2462 200 mW
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Venezuela 11g 11n 1 2412 1000 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 1000 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 4000 mW Indoor + outdoor
TPC - -
165 5825
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
67
Country Mode CH MHz PWR
(EIRP)
Use
United Arab Emir- 11g 11n 1 2412 100 mW Indoor + outdoor
ates
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11h 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor only
- -
116 5580
132 5660 1000 mW Indoor only
- -
140 5700
Bahamas (NAM) 11g 11n 1 2412 100 mW Indoor + outdoor
Ecuador 22417 200 mW Indoor + outdoor
Canada (NAM) - -
Peru 10 2457
Puerto Rico (NAM) 11 2462 100 mW Indoor + outdoor
USA (NAM) 11a 11n 52 5260 400 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 400 mW Indoor + outdoor
-
-
116 5580
132 5660 400 mW Indoor + outdoor
-
-
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
TPC - -
165 5825
Approvals for SCALANCE W788C / W786C 802.11n
2.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
68
Country Mode CH MHz PWR
(EIRP)
Use
Vietnam 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11h 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
TPC - -
165 5825
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
69
Approvals for SCALANCE W770/W730 802.11n 3
Note
Issued approvals on the type plate of the device
The specified approvals apply only when the corresponding mark is printed on the product.
You can check which of the following approvals have been granted for your product by the
markings on the type plate.
Range of validity
The approvals listed in this section apply to the following products:
Article number Article number of the US
version
Access points
SCALANCE W774-1 RJ-45 6GK5774-1FX00-0AA0 6GK5774-1FX00-0AB0
SCALANCE W774-1 M12 EEC 6GK5774-1FY00-0TA0 6GK5774-1FY00-0TB0
SCALANCE W778-1 M12 6GK5778-1GY00-0AA0 6GK5778-1GY00-0AB0
Client module
SCALANCE W734-1 RJ-45 6GK5734-1FX00-0AA0 6GK5734-1FX00-0AB0
SCALANCE W738-1 M12 6GK5738-1GY00-0AA0 6GK5738-1GY00-0AB0
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
70
Approvals for SCALANCE W770/W730 802.11n
3.1 EC declaration of conformity
3.1
EC declaration of conformity
The EC Declaration of Conformity is available for all responsible authorities at:
Siemens Aktiengesellschaft
Process Industries and Drives Division,
Process Automation
DE-76181 Karlsruhe
Germany
You will find the current EC declaration of conformity for these products on the Internet
pages of Siemens Industry Online Support
(hhttps://support.industry.siemens.com/cs/ww/en/ps/15853/cert).
The SIMATIC NET products described in these Operating Instructions meet the
requirements of the following EC directives:
●
94/9/EC
Directive of the European Parliament and the Council of 23 March 1994 on the
approximation of the laws of the Member States concerning equipment and protective
systems intended for use in potentially explosive atmospheres (until 19.04.2016).
●
2014/34/EU
Directive 2014/34/EU of the European Parliament and of the Council of 26 February 2014
on the harmonization of the laws of the Member States relating to equipment and
protective systems intended for use in potentially explosive atmospheres official journal of
the EU L96, 29/03/2014, pages. 309–356 (as of 20.04.2016)
●
1999/5/EC
Directive of the European Parliament and of the Council of 1999 March 1999 on Radio
Equipment and Telecommunications Terminal Equipment and the mutual recognition of
their conformity (until 12.06.2016).
●
2014/53/EU
Directive of the European Parliament and of the Council of April 16, 2014 on the
harmonization of the laws of the member states relating to placing radio equipment on the
market.; official journal of the EU L153, 22/05/2014, pages. 62–106 (as of 13.06.2016)
●2011/65/EU (RoHS)
RoHS directive of the European Parliament and of the Council of 8 June 2011 on the
restriction of the use of certain hazardous substances in electrical and electronic
equipment.
●
1999/519/EC
Council recommendation on the limitation of exposure of the general public to
electromagnetic fields (0 Hz to 300 GHz)
Approvals for SCALANCE W770/W730 802.11n
3.1 EC declaration of conformity
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
71
3.1.1
ATEX
ATEX directive (correct usage in potentially explosive atmospheres)
The SIMATIC NET product meets the requirements of the EC directive:94/9/EC (until
19.04.2016) and 2014/34/EU (as of 20.04.2016) "Equipment and Protective Devices for Use
in Potentially Explosive Atmospheres" according to the standards listed in the section
Products W770/W730 (Page 73):
Applied standard:
1 EN 60079-0 + A11
Hazardous areas - Part 0: Equipment - General requirements
2 EN 60079-15
Explosive atmospheres - Part 15: Equipment protection by type of protection "n"
3.1.2
RoHS
RoHS directive (restriction of the use of certain hazardous substances)
The SIMATIC NET products described in these operating instructions meet the requirements
of the EC directive 2011/65/EC for the restriction of the use of certain hazardous substances
in electrical and electronic equipment:
Applied standard:
3 EN 50581
Technical documentation for the assessment electrical and electronic products with
respect to restriction of hazardous substances
3.1.3
R&TTE / RED
3.1.3.1
Protection of health and safety
Article 3 (1) a) protection of health and safety
4 EN 60950-1+A1+A2+A11+A12
Information technology equipment - Safety - Part 1: General requirements
5 EN 62311
Assessment of electronic and electrical equipment related to human exposure re-
strictions for electromagnetic fields (0 Hz – 300 GHz)
Approvals for SCALANCE W770/W730 802.11n
3.1 EC declaration of conformity
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
72
3.1.3.2 EMC
Art. 3 (1) b - EMC
6 EN 50121-3-2+AC
Railway applications - Electromagnetic compatibility - part 3-2: Railway Vehicles -
Devices
7 EN 50121-4+AC
Railway applications - Electromagnetic compatibility - part 4: Interference emissions
and immunity of signal telecommunications equipment
8 ETSI EN 301 489-1
Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic
compatibility for radio equipment and services - Part 1 : Common technical re-
quirements
9 ETSI EN 301 489-17
Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic
compatibility for radio equipment and services - Part 17 :
10 EN 61000-6-1
Electromagnetic compatibility (EMC) - Part 6-1: Generic standards - Immunity for
residential, commercial and light-industrial environments
11 EN 61000-6-2+AC
Electromagnetic compatibility (EMC) - Part 6-2: Generic standards - Immunity for
industrial environments
12 EN 61000-6-3+A1+AC
Electromagnetic compatibility (EMC) - Part 6-3: Generic standards - Emission
standard for residential, commercial and light-industrial environments
13 EN 61000-6-4+A1
Electromagnetic compatibility (EMC) - Part 6-4: Generic standards - Emission
standard for industrial environments
3.1.3.3
Efficient use of the radio spectrum
Art. 3 (2) Efficient use of the radio spectrum
14
ETSI EN 301 328
Electromagnetic compatibility and radio spectrum matters (ERM) - wideband
transmission systems - data transmission equipment operating in the 2.4 GHz ISM
band and using wideband modulation techniques. Harmonized EN containing the
essential requirements according to Article 3.2 of the R&TTE directive.
15
ETSI EN 301 893
Broadband Radio Access Networks (BRAN) - 5 GHz high performance RLAN -
Harmonized EN covering essential requirements of article 3.2 of the R&TTE Di-
rective
Approvals for SCALANCE W770/W730 802.11n
3.1 EC declaration of conformity
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
73
3.1.4 Products W770/W730
CE conformity
The standards that apply to the product are described in ATEX (Page 71), RoHS (Page 71)
and R&TTE / RED (Page 71)
Product name
Standards
W774-1 RJ45
W734-1 RJ45
1, 2 ,3, 4, 5, 8, 9, 10, 11, 12, 13, 14, 15
W774-1 M12 EEC 1, 2 ,3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15
W778-1 M12
W738-1 M12
3, 4, 5, 8, 9, 10, 11, 12, 13, 14, 15
Certification ID
The following table shows the product names and the corresponding certification ID:
Type
Certification ID
Article number
Article number US variant
W774-1 RJ-45 MSN-W1-RJ-E2
6GK5774-1FX00-0AA0
6GK5774-1FX00-0AB0
W774-1 M12 EEC MSN-W1-M12-E2
6GK5774-1FY00-0TA0
6GK5774-1FY00-0TB0
W734-1 RJ-45 MSN-W1-RJ-E2
6GK5734-1FX00-0AA0
6GK5734-1FX00-0AB0
W778-1 M12 MSN65-W1-M12-E2
6GK5778-1GY00-0AA0
6GK5778-1GY00-0AB0
W738-1 M12 MSN65-W1-M12-E2
6GK5738-1GY00-0AA0
6GK5738-1GY00-0AB0
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
74
Approvals for SCALANCE W770/W730 802.11n
3.2 General approvals
3.2
General approvals
ATEX (explosion protection directive)
The SIMATIC NET products meet the requirements of the EC directive 94/9/EC "Equipment
and Protective Devices for Use in Potentially Explosive Atmospheres”. and as of 20.04.2016
the EC directive 2014/34/EU.
ATEX classification:
II 3 G Ex nA IIC T4 Gc
KEMA 07ATEX0145 X
The products meet the requirements of the following standards:
●
EN 60079-15 (electrical apparatus for potentially explosive atmospheres; Type of
protection "n")
●
EN 60079-0 (Explosive atmospheres - Part 0: Equipment - General requirements)
You will find the current versions of the standards in the currently valid ATEX certificates.
WARNING
When using SIMATIC NET products in hazardous area zone 2, make absolutely sure that
the associated conditions in the following document are adhered to:
"SIMATIC NET Product Information Use of subasseblies/modules in a Zone 2 Hazardous
Area".
You will find this document
on the data medium that ships with some devices.
on the Internet pages of Siemens Industry Online Support
(http://support.automation.siemens.com/ww).
Enter the document identification number C234 as the search term.
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
75
Approvals for SCALANCE W770/W730 802.11n
3.2 General approvals
IECEx
The SIMATIC NET products meet the requirements of explosion protection according to
IECEx.
IECEx classification:
Ex nA IIC T4 Gc
DEK 14.0025X
The products meet the requirements of the following standards:
●
IEC 60079-15 (Explosive atmospheres - Part 15: Equipment protection by type of
protection "n")
●
IEC 60079-0 (Explosive atmospheres - Part 0: Equipment - General requirements)
You will find the current versions of the standards in the currently valid IECEx certificates.
FM
The product meets the requirements of the standards:
●
Factory Mutual Approval Standard Class Number 3611
●
FM Hazardous (Classified) Location Electrical Equipment:
Non Incendive / Class I / Division 2 / Groups A,B,C,D / T4 and
Non Incendive / Class I / Zone 2 / Group IIC / T4
cULus Approval Hazardous Location
cULus Listed I. T. E. FOR HAZ. LOC.
Underwriters Laboratories Inc. complying with
●
UL 60950-1 (Information Technology Equipment)
●ANSI/ISA 12.12.01-2007
●CSA C22.2 No. 213-M1987
Approved for use in
Cl. 1, Div. 2, GP A, B, C, D T4
Cl. 1, Zone 2, GP IIC T4
Report no. E240480
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
76
Approvals for SCALANCE W770/W730 802.11n
3.2 General approvals
FCC approval
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1)
this device may not cause harmful interference, and
(2)
this device must accept any interference received, including interference that may cause
undesired operation.
Notice
Changes or modifications made to this equipment not expressly approved by SIEMENS may
void the FCC authorization to operate this equipment.
IEEE 802.11b or g operation of this product in the USA is firmware-limited to channels 1
through 11.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
●
Reorient or relocate the receiving antenna.
●
Increase the separation between the equipment and receiver.
●
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
●
Consult the dealer or an experienced radio/TV technician for help.
Notice
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20 cm
between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter. Professional Installation Notice:
To comply with FCC part 15 rules in the United States, the system must be professionally
installed to ensure compliance with the Part 15 certification. It is the responsibility of the
operator and professional installer to ensure that only certified systems are deployed in the
United States. The use of the system in any other combination (such as co-located antennas
transmitting the same information) is expressly forbidden.
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
77
Approvals for SCALANCE W770/W730 802.11n
3.2 General approvals
Notice
For use of DFS channels
●
Use of the RCoax Cable Antenna 6XV1875-2D is not permitted in channels which
require dynamic frequency selection (DFS).
●
Any installation of either a master or a client device within 35 km of a TDWR (Terminal
Doppler Weather Radar) location shall be separated by at least 30 MHz (center-to-center)
from the TDWR operating frequency.
These devices shall be registered in the industry sponsored WISPA database,
http://udia.spectrumbridge.com/udia/home.aspx
(http://udia.spectrumbridge.com/udia/home.aspx)
When you open this link, you get the following choices:
–
"Search" opens a window with TDWR locations and frequencies.
–
"User Signup" allows you to register as user of the database.
–
After registering you can Logon and register your WLAN location. Please fill in all
required information.
For more information with respect to WISPA database and TWDR locations please consult
FCC publication KDB 443999 D01.
Notice
In order to comply with FCC/ISED/MIC RF Exposure requirements, this device must be
installed to provide at least 20 cm separation from the human body at all times.
CSA Information Technology Equipment
CSA Certification Mark
Canadian Standard Association CSA C22.2 No. 60950-1-03
RSS-247 of Industry Canada
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
This radio transmitter (IC: 267AA-ELN1V1 for W760/W720 802.11n and IC: 267AA-MSN1V1
for W774/W734 802.11n) has been approved by Industry Canada to operate with the
antenna types listed in section 5.6 with the maximum permissible gain and required antenna
impedance for each antenna type indicated. Antenna types not included in this list, having a
gain greater than the maximum gain indicated for that type, are strictly prohibited for use with
this device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna
of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To
reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
necessary for successful communication.
To reduce potential radio interference to other users, the antenna type and its gain should be
so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
permitted for successful communication.
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
78
Approvals for SCALANCE W770/W730 802.11n
3.2 General approvals
That the device for the band 5150-5250 MHz is only for indoor usage to reduce potential for
harmful interference to co-channel mobile satellite systems.
Users should also be cautioned to take note that high power radars are allocated as primary
users (meaning they have priority) of 5250-5350 MHz and 5650-5850 MHz and these radars
could cause interference and/or damage to LE-LAN devices.
This equipment complies with IC RSS-102 radiation exposure limits set forth for an
uncontrolled environment.
In order to comply with FCC/ISED/MIC RF Exposure requirements, this device must be
installed to provide at least 20 cm separation from the human body at all times.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
Afin de se conformer aux exigences d'exposition RF MIC / FCC / ISED, cet appareil doit
être installé pour fournir au moins 20 cm de séparation du corps humain en tout temps
RCM
The product meets the requirements of the AS/NZS 2064 standard (Class A).
Approvals for Argentina
Devices of the SCALANCE W760/W720 series are approved in Argentina under the
following certification number:
Certification ID Certification number
ELN-W1-RJ-E1 CNC: C-13172
Devices of the SCALANCE W770/W730 series are approved in Argentina under the
following certification numbers:
Certification ID Certification number
MSN-W1-RJ-E2 CNC: C-13164
MSN-W1-M12-E2 CNC: C-13163
Approval for Brazil
Devices of the SCALANCE W760/W720 series are approved in Brazil under the following
certification numbers:
Este equipamento opera em caráter secundário, isto, ist é, não tem direito à proteção contra
interferência prejudicial, mesmo de estações do mesmo tipo e não pode causar interferência
a sistemas operando em caráter primário.
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
79
Approvals for SCALANCE W770/W730 802.11n
3.2 General approvals
Devices of the SCALANCE W770/W730 series are approved in Brazil under the following
certification numbers:
Este equipamento opera em caráter secundário, isto, ist é, não tem direito à proteção contra
interferência prejudicial, mesmo de estações do mesmo tipo e não pode causar interferência
a sistemas operando em caráter primário.
KCC Statement (Republic of Korea)
사용자안내문(제5조제1항제1호관련)
기 종 별 사 용 자 안 내 문
A급 기기급 기기 이 기기는 업무용(A 급)으로 전자파적합등록을 한(A 급)으로
(업무용 방송통신기기)
전자파적합등록을
한
기기이오니
판매자
또는
사용자는
이
점을
주의하시기 바라며,가정외의 지역에서 사용하는
것을 목적으로 합니다.
"당해 무선설비는 전파혼신 가능성이 있으므로 인명안전과 관련된 서비스는 할 수 없음"
Marking for the customs union
EAC (Eurasian Conformity)
Customs union of Russia, Belarus and Kazakhstan
Declaration of the conformity according to the technical regulations of the customs union
(TR CU)
Railway approval for the SCALANCE W774-1 M12 EEC
The SCALANCE W774-1 M12 EEC device meets the requirements of the railway standard
EN 50155:2007 "Railway Applications - Electronic equipment used on rolling stock".
Approvals for SCALANCE W770/W730 802.11n
3.3 SCALANCE W774/734 national approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
80
3.3
SCALANCE W774/734 national approvals
The following table lists the countries in which the SCALANCE W700 product is approved.
The diamond symbol (♦) identifies all countries for which there was no approval at the time
these operating instructions were written.
The current status of the approvals can be found on the Internet at the following address:
http://www.siemens.com/funkzulassungen
Column Meaning
Country Country
Mode IEEE 802.11 standard and the TPC and / or DFS functionality, where required
CH Channel
MHz Frequency
PWR (EIRP) Maximum permitted effective isotropic radiated power
Use Permitted use indoors and / or outdoors
Approvals for SCALANCE W770/W730 802.11n
3.3 SCALANCE W774/734 national approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
81
Country Mode CH MHz PWR
(EIRP)
Use
Andorra 11g 11n 1 2412 100 mW Indoor + outdoor
Belgium
-
-
Bosnia and Her- 13 2472
zegovina
Bulgaria
Denmark
Germany
Estonia
Finland
France
11a 11n
TPC
36
-
48
5180
-
5240
200 mW Indoor only
11a 11n
DFS + TPC
52
-
64
5260
-
5320
200 mW Indoor only
Greece
100
5500
1000 mW
Indoor + outdoor
Great Britain
-
-
Ireland
116
5580
Iceland
Italy
Croatia
Latvia
Liechtenstein
Lithuania
Luxembourg
132
-
140
5660
-
5700
1000 mW Indoor + outdoor
11a 11n 149
-
165
5745
-
5825
25 mW Indoor + outdoor
Malta
Macedonia
Monaco
Montenegro
Netherlands
Norway
Austria
Poland
Portugal
Romania
San Marino
Sweden
Switzerland
Slovakia
Slovenia
Spain
Czech Republic
Turkey
Hungary
Vatican
Cyprus
Egypt 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
64 5320
Approvals for SCALANCE W770/W730 802.11n
3.3 SCALANCE W774/734 national approvals
App
rovals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
82
Country Mode CH MHz PWR
(EIRP)
Use
Angola 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
Argentina 11g 11n 1 2412 1000 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 50 mW Indoor + outdoor
- -
48 5240
11a 11n 52 5260 250 mW Indoor + outdoor
TPC - -
64 5320
100 5500 250 mW Indoor + outdoor
- -
120 5600
132 5660 250 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 1000 mW Indoor + outdoor
- -
165 5825
Approvals for SCALANCE W770/W730 802.11n
3.3 SCALANCE W774/734 national approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
83
Country Mode CH MHz PWR
(EIRP)
Use
Australia 11g 11n 1 2412 100 mW Indoor + outdoor
New Zealand - -
13 2472
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Bahrain 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 2000 mW Indoor + outdoor
- -
165 5825
Belarus 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 100 mW Indoor + outdoor
TCP - -
48 5240
11a 11n 52 5260 100 mW Indoor + outdoor
TCP + DFS - -
64 5320
132 5660 100 mW Indoor + outdoor
- -
140 5700
Approvals for SCALANCE W770/W730 802.11n
3.3 SCALANCE W774/734 national approvals
App
rovals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
84
Country Mode CH MHz PWR
(EIRP)
Use
Brazil 11g 11n 1 2412 4000 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 200 mW Indoor only
TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 4000 mW Indoor + outdoor
- -
165 5825
Chile 11g 11n 1 2412 100 mW Indoor only
- -
13 2472
11a 11n 36 5180 100 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 100 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 100 mW Indoor only
DFS - -
165 5825
China 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 2000 mW Indoor + outdoor
- -
165 5825
Approvals for SCALANCE W770/W730 802.11n
3.3 SCALANCE W774/734 national approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
85
Country Mode CH MHz PWR
(EIRP)
Use
Ivory Coast 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
Guatemala 11g 11n 1 2412 100 mW Indoor + outdoor
2 2417 200 mW Indoor + outdoor
- -
10 2457
11 2462 100 mW Indoor + outdoor
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 400 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 400 mW Indoor + outdoor
- -
116 5580
132 5660 400 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
-
-
165 5825
Hong Kong 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
Approvals for SCALANCE W770/W730 802.11n
3.3 SCALANCE W774/734 national approvals
App
rovals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
86
Country Mode CH MHz PWR
(EIRP)
Use
11a 11n
DFS + TPC
52
-
64
5260
-
5320
200 mW Indoor only
100
-
116
5500
-
5580
1000 mW Indoor + outdoor
132
-
140
5660
-
5700
1000 mW Indoor + outdoor
India 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 200 mW Indoor + outdoor
- -
165 5825
Indonesia 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 149 5745 400 mW Indoor + outdoor
- -
161 5805
Approvals for SCALANCE W770/W730 802.11n
3.3 SCALANCE W774/734 national approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
87
Country Mode CH MHz PWR
(EIRP)
Use
Japan 11g 11n 1 2412 200 mW Indoor + outdoor
- -
13 2472
11a 8 5040 200 mW Indoor + outdoor
- -
16
5080
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 200 mW Indoor + outdoor
- -
140 5700
11a 184 4920 200 mW Indoor + outdoor
-
-
196 4980
Kazakhstan 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 100 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 100 mW Indoor only
DFS + TPC - -
64 5320
132 5660 100 mW Indoor + outdoor
- -
140 5700
Qatar 11g 11n 1 2412 100 mW Indoor only
- -
13 2472
11a 11n 149 5745 100 mW Indoor only
-
-
165 5825
Colombia 11g 11n 1 2412 100 mW Indoor + outdoor
- -
11 2462
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
Approvals for SCALANCE W770/W730 802.11n
3.3 SCALANCE W774/734 national approvals
App
rovals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
88
Country Mode CH MHz PWR
(EIRP)
Use
11a 11n 52 5260 400 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 400 mW Indoor + outdoor
- -
116 5580
132 5660 400 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Korea 11g 11n 1 2412 400 mW Indoor + outdoor
- -
13 2472
11a 11n 149 5745 400 mW Indoor + outdoor
TPC - -
161 5805
Kuwait 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor + outdoor
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor + outdoor
DFS + TPC - -
64 5320
Macau 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13 2472
11a 11n 149 5745 100 mW Indoor + outdoor
- -
161
5805
Madagascar 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC
-
48
-
5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC -
64
-
5320
Approvals for SCALANCE W770/W730 802.11n
3.3 SCALANCE W774/734 national approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
89
Country Mode CH MHz PWR
(EIRP)
Use
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Malaysia 11g 11n 1 2412 200 mW Indoor + outdoor
- -
13 2472
11a 11n 56 5280 200 mW Indoor only
DFS - -
64 5320
11a 11n 149 5745 1000 mW Indoor + outdoor
- -
165 5825
Mexico 11g 11n 1 2412 500 mW Indoor + outdoor
- -
11 2462
11a 11n 36 5180 1000 mW Indoor + outdoor
- -
64 5320
149 5745 1000 mW Indoor + outdoor
- -
165 5825
Pakistan 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 149 5745 100 mW Indoor + outdoor
- -
165 5825
Approvals for SCALANCE W770/W730 802.11n
3.3 SCALANCE W774/734 national approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
90
Country Mode CH MHz PWR
(EIRP)
Use
Russia 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 100 mW Indoor + outdoor
TPC - -
48 5240
11a 11n 52 5260 100 mW Indoor + outdoor
DFS + TPC - -
64 5320
132 5660 100 mW Indoor + outdoor
- -
140 5700
Saudi Arabia 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
Serbia 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC -
48
-
5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC
-
64
-
5320
100 5500 1000 mW Indoor + outdoor
-
-
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140
5700
Approvals for SCALANCE W770/W730 802.11n
3.3 SCALANCE W774/734 national approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
91
Country Mode CH MHz PWR
(EIRP)
Use
South Africa 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC -
48
-
5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC
-
64
-
5320
100 5500 1000 mW Indoor + outdoor
-
-
116
5580
132 5660 1000 mW Indoor + outdoor
- -
140
5700
Singapore 11g 11n 1 2412 100 mW Indoor + outdoor
Philippines - -
13 2472
11a 11n 36 5180 200 mW Indoor + outdoor
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116
5580
132 5660 1000 mW Indoor + outdoor
-
-
140 5700
11a 11n 149 5745 1000 mW Indoor + outdoor
- -
165 5825
Approvals for SCALANCE W770/W730 802.11n
3.3 SCALANCE W774/734 national approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
92
Country Mode CH MHz PWR
(EIRP)
Use
Taiwan 11g 11n 1 2412 100 mW Indoor + outdoor
2 2417 200 mW Indoor + outdoor
- -
10
2457
11 2462 100 mW Indoor + outdoor
11a 11n 52 5260 400 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 400 mW Indoor + outdoor
- -
116
5580
132 5660 400 mW Indoor + outdoor
-
-
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Venezuela 11g 11n 1 2412 1000 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 1000 mW Indoor only
DFS - -
64 5320
11a 11n 149 5745 4000 mW Indoor + outdoor
- -
165 5825
Approvals for SCALANCE W770/W730 802.11n
3.3 SCALANCE W774/734 national approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
93
Country Mode CH MHz PWR
(EIRP)
Use
United Arab Emir- 11g 11n 1 2412 100 mW Indoor + outdoor
ates
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor only
- -
116 5580
132 5660 1000 mW Indoor only
- -
140 5700
Bahamas 11g 11n 1 2412 100 mW Indoor + outdoor
Canada - -
Colombia 11 2462
Peru 11a 11n 36 5180 200 mW Indoor only
Puerto Rico --
Thailand 48 5240
USA 11a 11n 52 5260 400 mW Indoor + outdoor
Uruguay DFS + TPC - -
64 5320
100 5500 400 mW Indoor + outdoor
- -
116
5580
132 5660 400 mW Indoor + outdoor
-
-
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Approvals for SCALANCE W770/W730 802.11n
3.3 SCALANCE W774/734 national approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
94
Country Mode CH MHz PWR
(EIRP)
Use
Vietnam 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
95
Approvals for SCALANCE W770/W730 802.11n
3.4 SCALANCE W778/738 national approvals
3.4
SCALANCE W778/738 national approvals
The following table lists the countries in which the SCALANCE W700 product is approved.
The diamond symbol (♦) identifies all countries for which there was no approval at the time
these operating instructions were written.
The current status of the approvals can be found on the Internet at the following address:
http://www.siemens.com/funkzulassungen
Column Meaning
Country Country
Mode IEEE 802.11 standard and the TPC and / or DFS functionality, where required
CH Channel
MHz Frequency
PWR (EIRP) Maximum permitted effective isotropic radiated power
Use Permitted use indoors and / or outdoors
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
96
Approvals for SCALANCE W770/W730 802.11n
3.4 SCALANCE W778/738 national approvals
Country Mode CH MHz PWR
(EIRP)
Use
Andorra 11g 11n 1 2412 100 mW Indoor + outdoor
Belgium
-
-
Bosnia and Her- 13 2472
zegovina
Bulgaria
Denmark
Germany
Estonia
Finland
France
11a 11n
TPC
36
-
48
5180
-
5240
200 mW Indoor only
11a 11n
DFS + TPC
52
-
64
5260
-
5320
200 mW Indoor only
Greece
100
5500
1000 mW
Indoor + outdoor
Great Britain
-
-
Ireland
116
5580
Iceland
Italy
Croatia
Latvia
Liechtenstein
Lithuania
Luxembourg
132
-
140
5660
-
5700
1000 mW Indoor + outdoor
11a 11n 149
-
165
5745
-
5825
25 mW Indoor + outdoor
Malta
Macedonia
Monaco
Montenegro
Netherlands
Norway
Austria
Poland
Portugal
Romania
San Marino
Sweden
Switzerland
Serbia
♦
Slovakia
Slovenia
Spain
Cz
ech Republic
Turkey
Hungary
Vatican
Cyprus
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
97
Approvals for SCALANCE W770/W730 802.11n
3.4 SCALANCE W778/738 national approvals
Country Mode CH MHz PWR
(EIRP)
Use
Egypt ♦11g 11n 1
-
13
2412
-
2472
100 mW Indoor + outdoor
11a 11n
TPC
36
-
64
5180
-
5320
200 mW Indoor only
Australia ♦11g 11n 1 2412 100 mW Indoor + outdoor
New Zealand ♦- -
13 2472
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Bahrain ♦11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 2000 mW Indoor + outdoor
- -
165 5825
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
98
Approvals for SCALANCE W770/W730 802.11n
3.4 SCALANCE W778/738 national approvals
Country Mode CH MHz PWR
(EIRP)
Use
Brazil ♦11g 11n 1 2412 4000 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 200 mW Indoor only
TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 4000 mW Indoor + outdoor
- -
165 5825
Chile ♦11g 11n 1 2412 100 mW Indoor only
- -
13 2472
11a 11n 36 5180 100 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 100 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 100 mW Indoor only
DFS - -
165 5825
China ♦11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 2000 mW Indoor + outdoor
- -
165 5825
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
99
Approvals for SCALANCE W770/W730 802.11n
3.4 SCALANCE W778/738 national approvals
Country Mode CH MHz PWR
(EIRP)
Use
India ♦11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 200 mW Indoor + outdoor
- -
165 5825
Indonesia ♦11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 149 5745 400 mW Indoor + outdoor
- -
161 5805
Japan ♦11g 11n 1 2412 200 mW Indoor + outdoor
- -
13 2472
11a 8 5040 200 mW Indoor + outdoor
-
-
16 5080
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 200 mW Indoor + outdoor
- -
140 5700
11a 184 4920 200 mW Indoor + outdoor
-
-
196 4980
Korea ♦11g 11n 1 2412 400 mW Indoor + outdoor
- -
13 2472
11a 11n 149 5745 400 mW Indoor + outdoor
TPC - -
161 5805
Approvals for SCALANCE W770/W730 802.11n
3.4 SCALANCE W778/738 national approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
100
Country Mode CH MHz PWR
(EIRP)
Use
Kuwait ♦11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor + outdoor
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor + outdoor
DFS + TPC - -
64 5320
Mexico ♦11g 11n 1 2412 500 mW Indoor + outdoor
- -
11 2462
11a 11n 36 5180 1000 mW Indoor + outdoor
- -
64 5320
149 5745 1000 mW Indoor + outdoor
- -
165 5825
South Africa ♦11g 11n 1 2412 100 mW Indoor + outdoor
- -
13
2472
11a 11n 36 5180 200 mW Indoor only
TPC
-
48
-
5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC -
64
-
5320
100 5500 1000 mW Indoor + outdoor
-
-
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140
5700
Approvals for SCALANCE W770/W730 802.11n
3.4 SCALANCE W778/738 national approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
101
Country Mode CH MHz PWR
(EIRP)
Use
Singapore ♦11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor + outdoor
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
-
-
116
5580
132 5660 1000 mW Indoor + outdoor
- -
140
5700
11a 11n 149 5745 1000 mW Indoor + outdoor
- -
165 5825
Taiwan ♦11g 11n 1 2412 100 mW Indoor + outdoor
2 2417 200 mW Indoor + outdoor
- -
10 2457
11 2462 100 mW Indoor + outdoor
11a 11n 52 5260 400 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 400 mW Indoor + outdoor
-
-
116 5580
132 5660 400 mW Indoor + outdoor
- -
140
5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Canada ♦11g 11n 1 2412 100 mW Indoor + outdoor
Peru ♦- -
Thailand ♦11 2462
USA ♦11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 400 mW Indoor + outdoor
DFS + TPC - -
64 5320
Approvals for SCALANCE W770/W730 802.11n
3.4 SCALANCE W778/738 national approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
102
Country Mode CH MHz PWR
(EIRP)
Use
100 5500 400 mW Indoor + outdoor
-
-
116 5580
132 5660 400 mW Indoor + outdoor
- -
140
5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
103
Approvals for SCALANCE W760/W720 802.11n 4
Note
Issued approvals on the type plate of the device
The specified approvals apply only when the corresponding mark is printed on the product.
You can check which of the following approvals have been granted for your product by the
markings on the type plate.
Range of validity
The approvals listed in this section apply to the following products:
Article number Article number of the
US version
Article number of
the Israel version
Access point
SCALANCE W761-1 RJ-
45
6GK5761-1FC00-
0AA0
6GK5761-1FC00-
0AB0
-
Ethernet client modules
SCALANCE W722-1 RJ-
45
(iFeatures)
6GK5722-1FC00-
0AA0
6GK5722-1FC00-
0AB0
6GK5722-1FC00-0AC0
SCALANCE W721-1 RJ-
45
6GK5721-1FC00-
0AA0
6GK5721-1FC00-
0AB0
-
Approvals for SCALANCE W760/W720 802.11n
4.1 EC declaration of conformity
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
104
4.1
EC declaration of conformity
The EC Declaration of Conformity is available for all responsible authorities at:
Siemens Aktiengesellschaft
Process Industries and Drives Division,
Process Automation
DE-76181 Karlsruhe
Germany
You will find the current EC declaration of conformity for these products on the Internet
pages of Siemens Industry Online Support
(hhttps://support.industry.siemens.com/cs/ww/en/ps/15853/cert).
The SIMATIC NET products described in these Operating Instructions meet the
requirements of the following EC directives:
●
94/9/EC
Directive of the European Parliament and the Council of 23 March 1994 on the
approximation of the laws of the Member States concerning equipment and protective
systems intended for use in potentially explosive atmospheres (until 19.04.2016).
●
2014/34/EU
Directive 2014/34/EU of the European Parliament and of the Council of 26 February 2014
on the harmonization of the laws of the Member States relating to equipment and
protective systems intended for use in potentially explosive atmospheres official journal of
the EU L96, 29/03/2014, pages. 309–356 (as of 20.04.2016)
●
1999/5/EC
Directive of the European Parliament and of the Council of 1999 March 1999 on Radio
Equipment and Telecommunications Terminal Equipment and the mutual recognition of
their conformity (until 12.06.2016).
●
2014/53/EU
Directive of the European Parliament and of the Council of April 16, 2014 on the
harmonization of the laws of the member states relating to placing radio equipment on the
market.; official journal of the EU L153, 22/05/2014, pages. 62–106 (as of 13.06.2016)
●2011/65/EU (RoHS)
RoHS directive of the European Parliament and of the Council of 8 June 2011 on the
restriction of the use of certain hazardous substances in electrical and electronic
equipment.
●
1999/519/EC
Council recommendation on the limitation of exposure of the general public to
electromagnetic fields (0 Hz to 300 GHz)
Approvals for SCALANCE W760/W720 802.11n
4.1 EC declaration of conformity
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
105
4.1.1
ATEX
ATEX directive (correct usage in potentially explosive atmospheres)
The SIMATIC NET product meets the requirements of the EC directive:94/9/EC (until
19.04.2016) and 2014/34/EU (as of 20.04.2016) "Equipment and Protective Devices for Use
in Potentially Explosive Atmospheres" according to the standards listed in the section
AUTOHOTSPOT:
Applied standard:
1 EN 60079-0 + A11
Hazardous areas - Part 0: Equipment - General requirements
2 EN 60079-15
Explosive atmospheres - Part 15: Equipment protection by type of protection "n"
4.1.2
RoHS
RoHS directive (restriction of the use of certain hazardous substances)
The SIMATIC NET products described in these operating instructions meet the requirements
of the EC directive 2011/65/EC for the restriction of the use of certain hazardous substances
in electrical and electronic equipment:
Applied standard:
3 EN 50581
Technical documentation for the assessment electrical and electronic products with
respect to restriction of hazardous substances
4.1.3
R&TTE / RED
4.1.3.1
Protection of health and safety
Article 3 (1) a) protection of health and safety
4 EN 60950-1+A1+A2+A11+A12
Information technology equipment - Safety - Part 1: General requirements
5 EN 62311
Assessment of electronic and electrical equipment related to human exposure re-
strictions for electromagnetic fields (0 Hz – 300 GHz)
Approvals for SCALANCE W760/W720 802.11n
4.1 EC declaration of conformity
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
106
4.1.3.2 EMC
Art. 3 (1) b - EMC
6 EN 50121-3-2+AC
Railway applications - Electromagnetic compatibility - part 3-2: Railway Vehicles -
Devices
7 EN 50121-4+AC
Railway applications - Electromagnetic compatibility - part 4: Interference emissions
and immunity of signal telecommunications equipment
8 ETSI EN 301 489-1
Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic
compatibility for radio equipment and services - Part 1 : Common technical re-
quirements
9 ETSI EN 301 489-17
Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic
compatibility for radio equipment and services - Part 17 :
10 EN 61000-6-1
Electromagnetic compatibility (EMC) - Part 6-1: Generic standards - Immunity for
residential, commercial and light-industrial environments
11 EN 61000-6-2+AC
Electromagnetic compatibility (EMC) - Part 6-2: Generic standards - Immunity for
industrial environments
12 EN 61000-6-3+A1+AC
Electromagnetic compatibility (EMC) - Part 6-3: Generic standards - Emission
standard for residential, commercial and light-industrial environments
13 EN 61000-6-4+A1
Electromagnetic compatibility (EMC) - Part 6-4: Generic standards - Emission
standard for industrial environments
4.1.3.3
Efficient use of the radio spectrum
Art. 3 (2) Efficient use of the radio spectrum
14
ETSI EN 301 328
Electromagnetic compatibility and radio spectrum matters (ERM) - wideband
transmission systems - data transmission equipment operating in the 2.4 GHz ISM
band and using wideband modulation techniques. Harmonized EN containing the
essential requirements according to Article 3.2 of the R&TTE directive.
15
ETSI EN 301 893
Broadband Radio Access Networks (BRAN) - 5 GHz high performance RLAN -
Harmonized EN covering essential requirements of article 3.2 of the R&TTE Di-
rective
Approvals for SCALANCE W760/W720 802.11n
4.1 EC declaration of conformity
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
107
4.1.4
Products
CE conformity
The standards that apply to the product are described in RoHS (Page 105), ATEX
(Page 105) and R&TTE / RED (Page 105).
Product name
Standards
W761-1 RJ45
W722-1 RJ45
W721-1 RJ45
W774-1 RJ45
W734-1 RJ45
1, 2 3, 4, 5, 8, 9, 10, 11, 12, 13, 14, 15
W774-1 M12 EEC 1, 2 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15
Certification ID
The following table shows the product names and the corresponding certification ID:
Type
Certification ID
Order number
Order number US variant
W761-1 RJ-45 ELN-W1-RJ-E1
6GK5761-1FC00-0AA0
6GK5761-1FC00-0AB0
W722-1 RJ-45 ELN-W1-RJ-E1
6GK5722-1FC00-0AA0
6GK5722-1FC00-0AB0
W721-1 RJ-45 ELN-W1-RJ-E1
6GK5721-1FC00-0AA0
6GK5721-1FC00-0AB0
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
108
Approvals for SCALANCE W760/W720 802.11n
4.2 General approvals
4.2
General approvals
ATEX (explosion protection directive)
The SIMATIC NET products meet the requirements of the EC directive 94/9/EC "Equipment
and Protective Devices for Use in Potentially Explosive Atmospheres”. and as of 20.04.2016
the EC directive 2014/34/EU.
ATEX classification:
II 3 G Ex nA IIC T4 Gc
KEMA 07ATEX0145 X
The products meet the requirements of the following standards:
●
EN 60079-15 (electrical apparatus for potentially explosive atmospheres; Type of
protection "n")
●
EN 60079-0 (Explosive atmospheres - Part 0: Equipment - General requirements)
You will find the current versions of the standards in the currently valid ATEX certificates.
IECEx
The SIMATIC NET products meet the requirements of explosion protection according to
IECEx.
IECEx classification:
Ex nA IIC T4 Gc
DEK 14.0025X
The products meet the requirements of the following standards:
●
IEC 60079-15 (Explosive atmospheres - Part 15: Equipment protection by type of
protection "n")
●
IEC 60079-0 (Explosive atmospheres - Part 0: Equipment - General requirements)
You will find the current versions of the standards in the currently valid IECEx certificates.
WARNING
When using SIMATIC NET products in hazardous area zone 2, make absolutely sure that
the associated conditions in the following document are adhered to:
"SIMATIC NET Product Information Use of subasseblies/modules in a Zone 2 Hazardous
Area".
You will find this document
on the data medium that ships with some devices.
on the Internet pages of Siemens Industry Online Support
(http://support.automation.siemens.com/ww).
Enter the document identification number C234 as the search term.
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
109
Approvals for SCALANCE W760/W720 802.11n
4.2 General approvals
FM
The product meets the requirements of the standards:
●
Factory Mutual Approval Standard Class Number 3611
●
FM Hazardous (Classified) Location Electrical Equipment:
Non Incendive / Class I / Division 2 / Groups A,B,C,D / T4 and
Non Incendive / Class I / Zone 2 / Group IIC / T4
cULus Approval Hazardous Location
cULus Listed I. T. E. FOR HAZ. LOC.
Underwriters Laboratories Inc. complying with
●
UL 60950-1 (Information Technology Equipment)
●ANSI/ISA 12.12.01-2007
●CSA C22.2 No. 213-M1987
Approved for use in
Cl. 1, Div. 2, GP A, B, C, D T4
Cl. 1, Zone 2, GP IIC T4
Report no. E240480
Approvals for SCALANCE W760/W720 802.11n
4.2 General approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
110
FCC approval
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1)
this device may not cause harmful interference, and
(2)
this device must accept any interference received, including interference that may cause
undesired operation.
Notice
Changes or modifications made to this equipment not expressly approved by SIEMENS may
void the FCC authorization to operate this equipment.
IEEE 802.11b or g operation of this product in the USA is firmware-limited to channels 1
through 11.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
●
Reorient or relocate the receiving antenna.
●
Increase the separation between the equipment and receiver.
●
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
●
Consult the dealer or an experienced radio/TV technician for help.
Notice
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20 cm
between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter. Professional Installation Notice:
To comply with FCC part 15 rules in the United States, the system must be professionally
installed to ensure compliance with the Part 15 certification. It is the responsibility of the
operator and professional installer to ensure that only certified systems are deployed in the
United States. The use of the system in any other combination (such as co-located antennas
transmitting the same information) is expressly forbidden.
Approvals for SCALANCE W760/W720 802.11n
4.2 General approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
111
Notice
For use of DFS channels
●
Use of the RCoax Cable Antenna 6XV1875-2D is not permitted in channels which
require dynamic frequency selection (DFS).
●
Any installation of either a master or a client device within 35 km of a TDWR (Terminal
Doppler Weather Radar) location shall be separated by at least 30 MHz (center-to-center)
from the TDWR operating frequency.
These devices shall be registered in the industry sponsored WISPA database,
http://udia.spectrumbridge.com/udia/home.aspx
(http://udia.spectrumbridge.com/udia/home.aspx)
When you open this link, you get the following choices:
–
"Search" opens a window with TDWR locations and frequencies.
–
"User Signup" allows you to register as user of the database.
–
After registering you can Logon and register your WLAN location. Please fill in all
required information.
For more information with respect to WISPA database and TWDR locations please consult
FCC publication KDB 443999 D01.
CSA Information Technology Equipment
CSA Certification Mark
Canadian Standard Association CSA C22.2 No. 60950-1-03
RSS-247 of Industry Canada
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
This radio transmitter (IC: 267AA-ELN1V1 for W760/W720 802.11n and IC: 267AA-MSN1V1
for W774/W734 802.11n) has been approved by Industry Canada to operate with the
antenna types listed in section 5.6 with the maximum permissible gain and required antenna
impedance for each antenna type indicated. Antenna types not included in this list, having a
gain greater than the maximum gain indicated for that type, are strictly prohibited for use with
this device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna
of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To
reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
necessary for successful communication.
To reduce potential radio interference to other users, the antenna type and its gain should be
so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
permitted for successful communication.
Approvals for SCALANCE W760/W720 802.11n
4.2 General approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
112
That the device for the band 5150-5250 MHz is only for indoor usage to reduce potential for
harmful interference to co-channel mobile satellite systems.
Users should also be cautioned to take note that high power radars are allocated as primary
users (meaning they have priority) of 5250-5350 MHz and 5650-5850 MHz and these radars
could cause interference and/or damage to LE-LAN devices.
This equipment complies with IC RSS-102 radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with minimum
distance 20cm between the radiator & your body.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
RCM
The product meets the requirements of the AS/NZS 2064 standard (Class A).
Approvals for Argentina
Devices of the SCALANCE W760/W720 series are approved in Argentina under the
following certification number:
Certification ID Certification number
ELN-W1-RJ-E1 CNC: C-13172
Devices of the SCALANCE W770/W730 series are approved in Argentina under the
following certification numbers:
Certification ID Certification number
MSN-W1-RJ-E2 CNC: C-13164
MSN-W1-M12-E2 CNC: C-13163
Approval for Brazil
Devices of the SCALANCE W760/W720 series are approved in Brazil under the following
certification numbers:
Este equipamento opera em caráter secundário, isto, ist é, não tem direito à proteção contra
interferência prejudicial, mesmo de estações do mesmo tipo e não pode causar interferência
a sistemas operando em caráter primário.
Approvals for SCALANCE W760/W720 802.11n
4.2 General approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
113
Devices of the SCALANCE W770/W730 series are approved in Brazil under the following
certification numbers:
Este equipamento opera em caráter secundário, isto, ist é, não tem direito à proteção contra
interferência prejudicial, mesmo de estações do mesmo tipo e não pode causar interferência
a sistemas operando em caráter primário.
KCC Statement (Republic of Korea)
사용자안내문(제5조제1항제1호관련)
기 종 별 사 용 자 안 내 문
A급 기기급 기기 이 기기는 업무용(A 급)으로 전자파적합등록을 한(A 급)으로
(업무용 방송통신기기)
전자파적합등록을
한
기기이오니
판매자
또는
사용자는
이
점을
주의하시기 바라며,가정외의 지역에서 사용하는
것을 목적으로 합니다.
"당해 무선설비는 전파혼신 가능성이 있으므로 인명안전과 관련된 서비스는 할 수 없음"
Marking for the customs union
EAC (Eurasian Conformity)
Customs union of Russia, Belarus and Kazakhstan
Declaration of the conformity according to the technical regulations of the customs union
(TR CU)
Railway approval for the SCALANCE W774-1 M12 EEC
The SCALANCE W774-1 M12 EEC device meets the requirements of the railway standard
EN 50155:2007 "Railway Applications - Electronic equipment used on rolling stock".
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
114
Approvals for SCALANCE W760/W720 802.11n
4.3 National approvals
4.3
National approvals
The following table lists the countries in which the SCALANCE W700 product is approved.
The diamond symbol (♦) identifies all countries for which there was no approval at the time
these operating instructions were written.
The current status of the approvals can be found on the Internet at the following address:
http://www.siemens.com/funkzulassungen
Column Meaning
Country Country
Mode IEEE 802.11 standard and the TPC and / or DFS functionality, where required
CH Channel
MHz Frequency
PWR (EIRP) Maximum permitted effective isotropic radiated power
Use Permitted use indoors and / or outdoors
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
115
Approvals for SCALANCE W760/W720 802.11n
4.3 National approvals
Country Mode CH MHz PWR
(EIRP)
Use
Andorra 11g 11n 1 2412 100 mW Indoor + outdoor
Belgium
-
-
Bosnia and Her- 13 2472
zegovina
Bulgaria
Denmark
Germany
Estonia
Finland
France
11a 11n
TPC
36
-
48
5180
-
5240
200 mW Indoor only
11a 11n
DFS + TPC
52
-
64
5260
-
5320
200 mW Indoor only
Greece
100
5500
1000 mW
Indoor + outdoor
Great Britain
-
-
Ireland
116
5580
Iceland
Italy
Croatia
Latvia
132
-
140
5660
-
5700
1000 mW Indoor + outdoor
Liechtenstein
Lithuania
Luxembourg
Malta
Macedonia
Monaco
Montenegro
Netherlands
Norway
Austria
Poland
Portugal
Romania
San Marino
Sweden
Switzerland
Serbia
Slovakia
Slovenia
Spain
Czech Republic
Turkey
Hungary
Vatican
Cyprus
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
116
Approvals for SCALANCE W760/W720 802.11n
4.3 National approvals
Country Mode CH MHz PWR
(EIRP)
Use
Egypt 11g 11n 1
-
13
2412
-
2472
100 mW Indoor + outdoor
11a 11n
TPC
36
-
64
5180
-
5320
200 mW Indoor only
Angola 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
Argentina 11g 11n 1 2412 1000 mW Indoor + outdoor
-
-
13 2472
11a 11n 36 5180 50 mW Indoor + outdoor
- -
48
5240
11a 11n 52 5260 250 mW Indoor + outdoor
TPC
-
64
-
5320
100 5500 250 mW Indoor + outdoor
- -
120
5600
132 5660 250 mW Indoor + outdoor
-
-
140 5700
11a 11n 149 5745 1000 mW Indoor + outdoor
-
-
165 5825
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
117
Approvals for SCALANCE W760/W720 802.11n
4.3 National approvals
Country Mode CH MHz PWR
(EIRP)
Use
Australia 11g 11n 1 2412 100 mW Indoor + outdoor
New Zealand
-
13
-
2472
11a 11n 36 5180 200 mW Indoor only
- -
48
5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC
-
64
-
5320
11a 11n 149 5745 400 mW Indoor + outdoor
-
-
165
5825
Bahrain 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13
2472
11a 11n 36 5180 200 mW Indoor only
-
-
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC -
64
-
5320
11a 11n 149 5745 2000 mW Indoor + outdoor
-
-
165 5825
Belarus 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 100 mW Indoor + outdoor
TCP - -
48 5240
11a 11n 52 5260 100 mW Indoor + outdoor
TCP + DFS - -
64 5320
132 5660 100 mW Indoor + outdoor
- -
140 5700
Brazil 11g 11n 1 2412 4000 mW Indoor + outdoor
-
-
13 2472
11a 11n 36 5180 200 mW Indoor only
- -
48
5240
11a 11n 52 5260 200 mW Indoor only
TPC
-
64
-
5320
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
118
Approvals for SCALANCE W760/W720 802.11n
4.3 National approvals
Country Mode CH MHz PWR
(EIRP)
Use
100 5500 1000 mW Indoor + outdoor
-
-
140 5700
11a 11n 149 5745 4000 mW Indoor + outdoor
- -
165
5825
Chile 11g 11n 1 2412 100 mW Indoor only
-
-
13 2472
11a 11n 36 5180 100 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 100 mW Indoor only
DFS+TPC - -
64 5320
11a 11n 149 5745 100 mW Indoor only
DFS
-
165
-
5825
China 11g 11n 1 2412 100 mW Indoor + outdoor
-
13 -
2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS+TPC - -
64 5320
11a 11n 149 5745 2000 mW Indoor + outdoor
-
-
165 5825
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
119
Approvals for SCALANCE W760/W720 802.11n
4.3 National approvals
Country Mode CH MHz PWR
(EIRP)
Use
Ivory Coast 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
Guatemala 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
11 2462
11a 11n 36 5180 200 mW Indoor only
- -
48 5240
11a 11n 52 5260 400 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 400 mW Indoor + outdoor
- -
116 5580
132 5660 400 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165
5825
Approvals for SCALANCE W760/W720 802.11n
4.3 National approvals
Approvals SCALANC
E W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
120
Country Mode CH MHz PWR
(EIRP)
Use
Hong Kong 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
India 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC - -
64 5320
11a 11n 149 5745 200 mW Indoor + outdoor
- -
165 5825
Indonesia ♦11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13 2472
11a 11n 149 5745 400 mW Indoor + outdoor
- -
161
5805
Israel 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC -
64
-
5320
Approvals for SCALANCE W760/W720 802.11n
4.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
121
Country Mode CH MHz PWR
(EIRP)
Use
Japan 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13 2472
11a 8 5040 200 mW Indoor + outdoor
- -
16
5080
11a 11n 36 5180 200 mW Indoor only
-
-
48 5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC
-
64
-
5320
100 5500 200 mW Indoor + outdoor
- -
140
5700
11a 184 4920 200 mW Indoor + outdoor
-
-
196 4980
Kazakhstan 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 36 5180 100 mW Indoor + outdoor
TPC - -
48 5240
11a 11n 52 5260 100 mW Indoor + outdoor
DFS + TPC - -
64 5320
132 5660 100 mW Indoor + outdoor
- -
140 5700
Qatar 11g 11n 1 2412 100 mW Indoor only
- -
13 2472
11a 11n 149 5745 100 mW Indoor only
-
-
165 5825
Korea 11g 11n 1 2412 400 mW Indoor + outdoor
-
-
13 2472
11a 11n 149 5745 400 mW Indoor + outdoor
TPC -
161
-
5805
Approvals for SCALANCE W760/W720 802.11n
4.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
122
Country Mode CH MHz PWR
(EIRP)
Use
Kuwait 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13 2472
11a 11n 36 5180 100 mW Indoor + outdoor
TPC -
48
-
5240
11a 11n 52 5260 100 mW Indoor + outdoor
DFS + TPC
-
64
-
5320
Macau 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13
2472
11a 11n 149 5745 100 mW Indoor + outdoor
- -
161
5805
Madagascar 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC -
48
-
5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC
-
64
-
5320
100 5500 1000 mW Indoor + outdoor
- -
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Malaysia 11g 11n 1 2412 200 mW Indoor + outdoor
- -
13 2472
11a 11n 56 5280 200 mW Indoor only
DFS - -
64 5320
11a 11n 149 5745 1000 mW Indoor + outdoor
- -
165 5825
Approvals for SCALANCE W760/W720 802.11n
4.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
123
Country Mode CH MHz PWR
(EIRP)
Use
Mexico 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
11 2462
11a 11n 36 5180 1000 mW Indoor only
-
-
64 5320
149 5745 1000 mW Indoor + outdoor
- -
165
5825
Pakistan 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13 2472
11a 11n 149 5745 100 mW Indoor + outdoor
- -
165 5825
Russia 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13
2472
11a 11n 36 5180 100 mW Indoor + outdoor
TPC
-
48
-
5240
11a 11n 52 5260 100 mW Indoor + outdoor
DFS + TPC -
64
-
5320
132 5660 100 mW Indoor + outdoor
-
-
140 5700
Saudi Arabia 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13
2472
11a 11n 36 5180 200 mW Indoor only
TPC
-
48
-
5240
11a 11n 52 5260 200 mW Indoor only
DFS + TPC -
64
-
5320
100 5500 200 mW Indoor + outdoor
- -
112
5560
116 5580 200 mW Indoor + outdoor
-
-
140 5700
Approvals for SCALANCE W760/W720 802.11n
4.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
124
Country Mode CH MHz PWR
(EIRP)
Use
Singapore 11b 11g 11n 1 2412 100 mW Indoor + outdoor
Philippines - -
13 2472
11a 11n 36 5180 200 mW Indoor + outdoor
TPC - -
48 5240
11a 11n 52 5260 200 mW Indoor + outdoor
DFS + TPC - -
64 5320
100 5500 1000 mW Indoor + outdoor
-
-
116
5580
132 5660 1000 mW Indoor + outdoor
- -
140
5700
11a 11n 149 5745 1000 mW Indoor + outdoor
- -
165 5825
South Africa 11g 11n 1 2412 100 mW Indoor + outdoor
- -
13
2472
11a 11n 36 5180 200 mW Indoor only
TPC
-
48
-
5240
11a 11n 52 5260 200 mW Indoor only
DFS+TPC -
64
-
5320
100 5500 1000 mW Indoor + outdoor
-
-
116 5580
132 5660 1000 mW Indoor + outdoor
- -
140
5700
Approvals for SCALANCE W760/W720 802.11n
4.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
125
Country Mode CH MHz PWR
(EIRP)
Use
Taiwan ♦11g 11n 1 2412 100 mW Indoor + outdoor
2 2417 200 mW Indoor + outdoor
-
10
-
2457
11 2462 100 mW Indoor + outdoor
11a 11n 52 5260 400 mW Indoor only
DFS+TPC
-
64
-
5320
100 5500 400 mW Indoor + outdoor
- -
116
5580
132 5660 400 mW Indoor + outdoor
-
-
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165
5825
Venezuela 11g 11n 1 2412 1000 mW Indoor + outdoor
-
-
13 2472
11a 11n 36 5180 200 mW Indoor only
- -
48
5240
11a 11n 52 5260 1000 mW Indoor only
DFS
-
64
-
5320
11a 11n 149 5745 4000 mW Indoor + outdoor
-
-
165 5825
United Arab Emir- 11g 11n 1 2412 100 mW Indoor + outdoor
ates - -
13
2472
11a 11n 36 5180 200 mW Indoor only
TPC
-
48
-
5240
11a 11n 52 5260 200 mW Indoor only
DFS+TPC -
64
-
5320
100 5500 1000 mW Indoor only
-
-
116 5580
132 5660 1000 mW Indoor only
- -
140
5700
Bahamas 11g 11n 1 2412 100 mW Indoor + outdoor
Canada
-
11
-
2462
Approvals for SCALANCE W760/W720 802.11n
4.3 National approvals
Approvals SCALANCE W700 802.11n
Reference Manual, 01/2017, C79000-G8976-C392-05
126
Country Mode CH MHz PWR
(EIRP)
Use
Colombia 11a 11n 36 5180 200 mW Indoor only
Peru - -
Puerto Rico 48 5240
Thailand 11a 11n 52 5260 400 mW Indoor + outdoor
USA DFS + TPC - -
Uruguay 64 5320
100 5500 400 mW Indoor + outdoor
-
-
116 5580
132 5660 400 mW Indoor + outdoor
-
-
140
5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165 5825
Vietnam 11g 11n 1 2412 100 mW Indoor + outdoor
-
-
13 2472
11a 11n 36 5180 200 mW Indoor only
TPC -
48
-
5240
11a 11n 52 5260 200 mW Indoor only
DFS+TPC
-
64
-
5320
100 5500 1000 mW Indoor + outdoor
- -
116
5580
132 5660 1000 mW Indoor + outdoor
-
-
140 5700
11a 11n 149 5745 400 mW Indoor + outdoor
- -
165
5825
