Tornado Ez Floorkeeper Walk Behind Floor Scrubber Brochure Specifications

: Sweepscrub Tornado-Ez-Floorkeeper-Walk-Behind-Floor-Scrubber-Brochure-Specifications tornado-ez-floorkeeper-walk-behind-floor-scrubber-brochure-specifications 2117 file product_file

Open the PDF directly: View PDF .
Page Count: 2

Quiet Operation

Each of the units in the EZ Floorkeeper® Series of automatic

scrubbers is perfect for a wide range of flooring services from tile,

linoleum and rubberized surfaces to marble and concrete.Ruggedly

constructed of rotationally-molded plastic, these machines are a

fundamental component in a hard-floor maintenance program.In a

single pass,an EZ Floorkeeper lays solution,scrubs,and recovers dirty

water, leaving a clean, dry floor behind. Tornado® EZs are in use

worldwide in retail store chains, grocery stores,and discount stores.

Thanks to their quiet operation, compact size, and front-mounted

warning light, they can be used in retail settings while customers

are shopping.

Versatility

Tornado’s® EZ Floorkeeper®’s provide easy operation, versatility,

innovative features and durable design for use in many different

environments including:

• Hospitals and Healthcare Facilities

• Schools and Universities

• Hotels and Resorts

• Industrial Facilities

Rugged Construction

EZ Floorkeepers are available in a 20" brush-assisted model, a

20" traction drive unit,and a 24" traction drive unit.All units feature

200 rpm brush speed, 3-stage vac motor, speed control, 13-gallon

solution and recovery tank. All models come standard with swing

squeegee,pad holder,batteries,and charger.

A better way to clean.

The EZ Floorkeeper® Series

of Automatic Scrubbers

Value,performance,and one

of the industry’s most popular

walk-behind scrubbers

The EZ Floorkeeper® Series.

Value,performance,and one of the industry’s most popular walk-behind scrubbers

Key Features

• Convenient recovery tank drain hose

located above the brush deck

• 13 gallon solution tank is easily filled

through a side filler door

• See-through lid on the recovery tank

allows the operator to monitor recovery

tank level

• The 20”EZ-TD and the 24”EZ-TD feature

a traction drive system

• Battery well is easily accessible for

maintenance and service

• The EZ Floorkeeper®’s come standard

with pad holder,batteries and charger

©2008 Tornado Industries. All rights reserved.

Form#:F2730-4/08-10M.Printed in USA

www.tornadovac.com • Toll free:1-800-VACUUMS

Phone:(708) 867-5100 • Fax: (708) 867-6968

20" EZ BRUSH DRIVE

PRODUCT SPECIFICATIONS

MODEL 20" EZ BRUSH DRIVE 20" EZ TRACTION

DRIVE 24" EZ TRACTION

DRIVE

CATALOG NUMBER 99105A & 99105B 99125A & 99125B 99130

CLEANING PATH 20" 20" 24"

SWING SQUEEGEE 28" 28" 32"

BRUSH/PAD SIZE 20" 20" 24"

BRUSH/PAD SPEED 200 rpm 200 rpm 200 rpm

BRUSH/PAD PRESSURE 67 LBS 65-85 LBS 72 LBS

3-STAGE VAC MOTOR .75 HP .75 HP .75 HP

CFM 65 65 65

WATERLIFT 71" 71" 71"

BRUSH MOTOR 1.0 HP 1.0 HP 1.0 HP

DRIVE Brush Assist Traction Drive Traction Drive

FORWARD SPEED 0 to 150 fpm 0 to 200 fpm 0 to 200 fpm

REVERSE SPEED N/A 150 fpm 150 fpm

SOLUTION TANK 13 GAL 13 GAL 13 GAL

RECOVERY TANK 13 GAL 13 GAL 13 GAL

DIMENSIONS (L X W X H) 49" X 22" X 37" 49" X 22" X 37" 53" X 28" X 37"

WEIGHT W/OUT BATTERIES 151 LBS 166 LBS 172 LBS

STANDARD ACCESSORIES AND REPLACEMENT ITEMS

PAD HOLDER

(1 INCLUDED W/ UNIT) 99262 99262 99272

SQUEEGEE REPLACEMENT

KIT 18709 18709 18710

24V/20 AMP CHARGER 99510 99510 99510

BATTERIES 98799,12V,2 Req.

for 99105A

99506,6V,4 Req.

for 99105B

98799,12V,2 Req.

for 99125A

99506,6V,4 Req.

for 99125B 99506,6V,4 Req.

OPTIONAL ACCESSORIES AND ATTACHMENTS

POLY SCRUB BRUSH (1 REQ.) 99260 99260 99270

GRIT BRUSH (1 REQUIRED) 99263 99263 N/A

1.5" WET ATTACHMENT SET 90676 90676 90676

EZ Traction Drive: Quiet,

powerful,reliable operation

The 20" EZ-TD and the 24" EZ-TD fea-

ture a traction drive system for the

unit’s forward motion.The traction drive

is a sealed gear unit,a significant reduc-

tion in part number compared to com-

petitive units.The traction drive

requires no maintenance,has no lube

points,and is extremely quiet.

Value

The EZ Series offers some of

the industry’s most competitive auto-

matic scrubbing packages available

today.

Service made simple

The battery compartment is

easily accessible for maintenance

and service operations by

qualified personnel.

Common sense features

A see-through lid on the recovery

tank allows the operator to

monitor recovery tank level for

optimal machine performance.

Professional Performance

The EZs leave behind a clean,dry

floor.Easy-to-use controls make

the unit an operator favorite the

world over.
