TCL Communication H071 LTE / UMTS / GSM mobile phone User Manual VFD 610 FCC 01

TCL Communication Ltd. LTE / UMTS / GSM mobile phone VFD 610 FCC 01

Contents

VFD 610_FCC user manual_01

© Vodafone Group 2017. Vodafone, Vodacom and the
Vodafone logos are trade marks of Vodafone Group.
Any product or company names mentioned herein
may be the trade marks of their respective owners. VFD 610
Smart N8
Safety and
warranty
information
1 2
Product safety information
Pictograms and graphic symbols
Read the Safety & warranty information guide
Do not use while re-fuelling
Do not use hand-held while driving
This device may produce a bright or flashing light
When using the phone, make sure it is kept at least
10 mm away from your head or body
Do not dispose of in a fire
Small parts may cause a choking hazard
Avoid contact with magnetic media
This device may produce a loud sound
Avoid extreme temperatures
Keep away from pacemakers and other personal
medical devices
Avoid contact with liquid, keep dry
Switch off when instructed in hospitals and
medical facilities
Do not try to disassemble
Switch off when instructed in aircraft and airports
Do not rely on this device for emergency
communications
Switch off in explosive environments
Only use approved accessories
Safety and use
We recommend that you read this chapter carefully before
using your mobile phone. The manufacturer disclaims any
liability for damage, which may result as a consequence of
improper use or use contrary to the instructions contained
herein.
TRAFFIC SAFETY:
Given that studies show that using a mobile phone while
driving a vehicle constitutes a real risk, even when the
hands-free kit is used (car kit, headset...), drivers are
requested to refrain from using their mobile phone when
the vehicle is not parked. Check the laws and regulations
on the use of wireless mobile phones and their accessories
in the areas where you drive. Always obey them. The use
of these devices may be prohibited or restricted in certain
areas.
When driving, do not use your mobile phone and headset
to listen to music or to the radio. Using a headset can be
dangerous and forbidden in some areas.
When switched on, your mobile phone emits
electromagnetic waves that can interfere with the vehicle’s
electronic systems such as ABS anti-lock brakes or airbags.
To ensure that there is no problem:
- do not place your mobile phone on top of the dashboard or
within an airbag deployment area,
- check with your car dealer or the car manufacturer to make
sure that the car’s electronic devices are shielded from
mobile phone RF energy.
CONDITIONS OF USE:
You are advised to switch off the mobile phone from time to
time to optimize its performance.
Remember to abide by local authority rules of mobile phone
use on aircrafts.
Operational Warnings: Obey all posted signs when using
mobile devices in public areas.
Follow Instructions to Avoid Interference Problems: Turn off
your mobile device in any location where posted notices
instruct you to do so. In an aircraft, turn off your mobile
device whenever instructed to do so by airline staff. If your
mobile device offers an airplane mode or similar feature,
consult airline staff about using it in flight.
3 4
Switch the mobile phone off when you are in health care
facilities, except in designated areas. As with many other
types of equipment now in regular use, mobile phones
can interfere with other electrical or electronic devices, or
equipment using radio frequency.
Switch the mobile phone off when you are near gas or
flammable liquids. Strictly obey all signs and instructions
posted in a fuel depot, gas station, or chemical plant, or in
any potentially explosive atmosphere.
When the mobile phone is switched on, it should be kept at
least 15 cm from any medical device such as a pacemaker,
a hearing aid or insulin pump. In particular when using the
mobile phone you should hold it against the ear on the
opposite side to the device, if any.
Read and follow the directions from the manufacturer of
your implantable medical device. If you have any questions
about using your mobile device with your implantable
medical device, consult your healthcare provider.
To avoid hearing impairment, answer the call before holding
your mobile phone to your ear. Also move the handset away
from your ear while using the “hands-free” option because
the amplified volume might cause hearing damage.
It is recommended to have proper supervision while small
children use your mobile phone.
Please note the battery of your phone is not removable. If
you disassemble your phone the warranty will not apply.
Disassembling the phone may damage the battery, and
may cause leakage of substances that could create an
allergic reaction.
Always handle your mobile phone with care and keep it in a
clean and dust-free place.
Do not allow your mobile phone to be exposed to
adverse weather or environmental conditions (moisture,
humidity, rain, infiltration of liquids, dust, sea air, etc.).
The manufacturer’s recommended operating temperature
range is -10°C (14°F) to +55°C (131°F) (the max value
depends on device, materials and housing paint/texture).
Over 55°C (131°F) the legibility of the mobile phone’s
display may be impaired, though this is temporary and not
serious.
Do not open or attempt to repair your mobile phone
yourself.
Do not drop, throw, or try to bend your mobile phone.
Do not use the mobile phone if the glass made screen, is
damaged, cracked, or broken to avoid any injury.
Do not paint it.
Use only batteries, battery chargers, and accessories which
are recommended by TCL Communication Ltd. and its
affiliates and are compatible with your mobile phone model.
TCL Communication Ltd. and its affiliates disclaim any
liability for damage caused by the use of other chargers
or batteries.
Your mobile phone should not be disposed of in a municipal
waste. Please check local regulations for disposal of
electronic products.
Remember to make back-up copies or keep a written record
of all important information stored in your mobile phone.
Some people may suffer epileptic seizures or blackouts
when exposed to flashing lights, or when playing video
games. These seizures or blackouts may occur even if a
person never had a previous seizure or blackout. If you
have experienced seizures or blackouts, or if you have a
family history of such occurrences, please consult your
doctor before playing video games on your mobile phone
or enabling a flashing-lights feature on your mobile phone.
Parents should monitor their children’s use of video games
or other features that incorporate flashing lights on the
mobile phones. All persons should discontinue use and
consult a doctor if any of the following symptoms occur:
convulsion, eye or muscle twitching, loss of awareness,
involuntary movements, or disorientation. To limit the
likelihood of such symptoms, please take the following
safety precautions:
- Play at the farthest distance possible from the screen.
When you play games on your mobile phone, you may
experience occasional discomfort in your hands, arms,
shoulders, neck, or other parts of your body. Follow these
instructions to avoid problems such as tendinitis, carpal
tunnel syndrome, or other musculoskeletal disorders:
- Take a minimum of a 15-minute break every hour of game
playing.
- If your hands, wrists, or arms become tired or sore while
playing, stop and rest for several hours before playing
again.
5 6
- If you continue to have sore hands, wrists, or arms during or
after playing, stop the game and see a doctor.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen
at high volume levels for long periods. Exercise
caution when holding your device near your ear
while the loudspeaker is in use.
PRIVACY:
Please note that you must respect the laws and regulations
in force in your jurisdiction or other jurisdiction(s) where you
will use your mobile phone regarding taking photographs
and recording sounds with your mobile phone. Pursuant
to such laws and regulations, it may be strictly forbidden
to take photographs and/or to record the voices of other
people or any of their personal attributes, and reproduce or
distribute them, as this may be considered to be an invasion
of privacy.
It is the user’s sole responsibility to ensure that prior
authorization be obtained, if necessary, in order to record
private or confidential conversations or take a photograph
of another person; the manufacturer, the seller or vendor
of your mobile phone (including the operator) disclaim
any liability which may result from the improper use of the
mobile phone.
BATTERY AND ACCESSORIES:
Following new air regulation, the battery of your product is
not charged. Please charge it first.
For non-unibody device:
Before removing the battery from your mobile phone,
please make sure that the mobile phone is switched off.
Observe the following precautions for battery use:
- Do not attempt to open the battery (due to the risk of toxic
fumes and burns).
- Do not puncture, disassemble, or cause a short-circuit in
the battery,
- Do not burn or dispose of a used battery in the garbage or
store it at temperatures above 60°C (140°F).
Batteries must be disposed of in accordance with locally
applicable environmental regulations. Only use the battery
for the purpose for which it was designed. Never use
damaged batteries or those not recommended by TCL
Communication Ltd. and/or its affiliates.
For unibody device:
Please note your phone is a unibody device, the back cover
and battery are not removable. Observe the following
precautions:
- Do not attempt to open the back cover,
- Do not attempt to eject, replace and open battery,
- Do not punctuate the back cover of your phone,
- Do not burn or dispose of your phone in household rubbish
or store it at temperature above 60°C.
Phone and battery as a unibody device must be disposed
of in accordance with locally applicable environmental
regulations.
This symbol on your mobile phone, the battery,
and the accessories means that these products
must be taken to collection points at the end of
their life:
- Municipal waste disposal centers with specific bins for
these items of equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances being
disposed of in the environment, so that their components
can be reused.
In European Union countries:
These collection points are accessible free of charge. All
products with this sign must be brought to these collection
points.
In non European Union jurisdictions:
Items of equipment with this symbol are not be thrown into
ordinary bins if your jurisdiction or your region has suitable
recycling and collection facilities; instead they are to be
taken to collection points for them to be recycled.
In the United States you may learn more about CTIA’s
Recycling Program at http://www.gowirelessgogreen.org/
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES
ACCORDING TO THE INSTRUCTIONS
CHARGERS:
Home A.C./ Travel chargers will operate within the
temperature range of: 0°C (32°F) to 40°C (104°F).
7 8
The chargers designed for your mobile phone meet with the
standard for safety of information technology equipment
and office equipment use. Due to different applicable
electrical specifications, a charger you purchased in one
jurisdiction may not work in another jurisdiction. They
should be used for this purpose only.
Characteristics of power supply (depending on the country):
Travel charger: Input: 100-240 V, 50/60 Hz, 0.2A
Output: 5V, 1A
Battery: Lithium 2400mAh
Radio Waves
THIS MOBILE PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your mobile phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the emission
limits for exposure to radio-frequency (RF) energy. These
limits are part of comprehensive guidelines and establish
permitted levels of RF energy for the general population.
The guidelines are based on standards that were developed
by independent scientific organizations through periodic
and thorough evaluation of scientific studies. These
guidelines include a substantial safety margin designed
to ensure the safety of all persons, regardless of age and
health.
The exposure standard for mobile phones employs a
unit of measurement known as the Specific Absorption
Rate, or SAR. The SAR limit set by public authorities such
as the Federal Communications Commission of the US
Government (FCC), or by Industry Canada, is 1.6 W/kg
averaged over 1 gram of body tissue. Tests for SAR are
conducted using standard operating positions with the
mobile phone transmitting at its highest certified power
level in all tested frequency bands.
Although the SAR is determined at the highest certified
power level, the actual SAR level of the mobile phone
while operating can be well below the maximum value.
This is because the mobile phone is designed to operate at
multiple power levels so as to use only the power required
to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output of
the mobile phone. Before a mobile phone model is available
for sale to the public, compliance with national regulations
and standards must be shown.
The highest SAR value for this model mobile phone when
tested is 1.29 W/kg for use at the ear and 1.02W/kg for use
close to the body.
While there may be differences between the SAR levels
of various mobile phones and at various positions, they
all meet the government requirement for RF exposure.
For body-worn operation, the mobile phone meets FCC
RF exposure guidelines provided that it is used with a
non-metallic accessory with the handset at least 10 mm
from the body. Use of other accessories may not ensure
compliance with FCC RF exposure guidelines.
Additional information on SAR can be found on the Cellular
Telecommunications & Internet Association (CTIA) Web site:
http://www.ctia.org/
The World Health Organization (WHO) considers that
present scientific information does not indicate the need
for any special precautions for use of mobile phones. If
individuals are concerned, they might choose to limit their
own or their children’s RF exposure by limiting the length of
calls, or using “hands-free” devices to keep mobile phones
away from the head and body. (fact sheet n°193). Additional
WHO information about electromagnetic fields and public
health are available on the following website: http://www.
who.int/peh-emf.
9 10
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician
for help.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
For the receiver devices associated with the operation of
a licensed radio service (e.g. FM broadcast), they bear the
following statement:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the condition that this device does
not cause harmful interference.
For other devices, they bear the following statement:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Your mobile phone is equipped with a built-in antenna.
For optimal operation, you should avoid touching it or
degrading it.
As mobile devices offer a range of functions, they can
be used in positions other than against your ear. In such
circumstances the device will be compliant with the
guidelines when used with headset or usb data cable. If you
are using another accessory ensure that whatever product
is used is free of any metal and that it positions the mobile
phone at least 10 mm away from the body.
Please note by using the device some of your personal
data may be shared with the main device. It is under
your own responsibility to protect your own personal data,
not to share with it with any unauthorized devices or
third party devices connected to yours. For products with
Wi-Fi features, only connect to trusted Wi-Fi networks. Also
when using your product as a hotspot (where available),
use network security. These precautions will help prevent
unauthorized access to your device. Your product can store
personal information in various locations including a SIM
card, memory card, and built-in memory. Be sure to remove
or clear all personal information before you recycle, return,
or give away your product. Choose your apps and updates
carefully, and install from trusted sources only. Some apps
can impact your product’s performance and/or have access
to private information including account details, call data,
location details and network resources.
Note that any data shared with TCL Communication Ltd.
is stored in accordance with applicable data protection
legislation. For these purposes TCL Communication Ltd.
implements and maintains appropriate technical and
organizational measures to protect all personal data, for
example against unauthorized or unlawful processing
and accidental loss or destruction of or damage to such
personal data whereby the measures shall provide a level of
security that is appropriate having regard to
(i) the technical possibilities available,
(ii) the costs for implementing the measures,
(iii) the risks involved with the processing of the personal
data, and
(iv) the sensitivity of the personal data processed.
You can access, review and edit your personal information
at any time by logging into your user account, visiting your
user profile or by contacting us directly. Should you require
us to edit or delete your personal data, we may ask you to
provide us with evidence of your identity before we can act
on your request.
11 12
LICENCES:
microSD Logo is a trademark.
The Bluetooth word mark and logos are
owned by the Bluetooth SIG, Inc. and any
use of such marks by TCL Communication
Ltd. and its affiliates is under license. Other
trademarks and trade names are those of their
respective owners.
VFD 610 Bluetooth
Declaration ID D032716
The Wi-Fi Logo is a certification mark of the
Wi-Fi Alliance.
Google, the Google logo, Android, the Android
logo, Google Search TM, Google Maps TM,
Gmail TM, YouTube, Google Play Store and
Duo TM are trademarks of Google Inc.
The Android robot is reproduced or modified from work
created and shared by Google and used according to terms
described in the Creative Commons 3.0 Attribution License
(the text will show when you touch and hold Google legal
in Settings > About phone > Legal information) (1).
General information
You have purchased a product which uses the open source
(http://opensource.org/) programs mtd, msdosfs, netfilter/
iptables and initrd in object code and other open source
programs licensed under the GNU General Public License
and Apache License.
We will provide you with a complete copy of the
corresponding source codes upon request within a period
of three years from the distribution of the product from the
below mentioned TCL address in chapter Notice.
(1) This may not be available depending on your country.
You may download the source codes from http://
sourceforge.net/projects/alcatel/files/vodafone/vfd610.
The provision of the source code is free of charge from
internet.
Your telephone is a transceiver that operates on GSM in
quad-band (850/900/1800/1900 MHz) or UMTS in quad
band (850/900/1900/2100 MHz) or LTE in Six-band with
B1/3/7/8/20/28.
FCC ID: 2ACCJH071
Notice
The information in this manual is subject to change without
notice.
Every effort has been made in the preparation of this manual
to ensure accuracy of the contents, but all statements,
information, and recommendations in this manual do not
constitute a warranty of any kind, expressed or implied. Read
the safety precautions and safety information carefully to
ensure that you use this wireless device in a correct and
safe manner.
TCL Communication Ltd. Address:
5/F, Building 22E, 22 Science Park East Avenue, Hong Kong
Science Park, Shatin, NT, Hong Kong
13 14
Warranty information
WARRANTY TERMS AND CONDITIONS
1. Vodafone undertakes the warranty of this mobile phone
for a period of two (2) years from the date of purchase by
the original owner (not transferable) under normal use.
2. The battery has a limited warranty for twelve (12)
months, and charger for twenty-four (24) months
against manufacturing defects. Other accessories have
a limited warranty for twenty-four (24) months against
manufacturing defects.
3. This warranty does not cover damage resulting from:
a) Normal wear & tear of the equipment;
b) Defects and damages due to the equipment being
used other than its normal and customary manner;
c) An unauthorised disassembly, repair, alteration or
modification being carried out;
d) Misuse, abuse, negligence or accident howsoever
caused;
e) Defects or damage arising from improper testing,
operation, maintenance, installation, or any alteration
or modification;
f) Defects or damage due to spillage of food or liquids,
corrosion, rust or the use of wrong voltage;
g) Scratches or damage to plastic surfaces and all
other externally exposed parts that are due to normal
customer use;
4. If this phone needs service or repair, it must be delivered
at the user's cost.
5. This warranty will be null and void in any of the following
events:
a) If the serial number or warranty seal on the equipment
has been defaced or removed.
b) If any term contained in this warranty has been altered
or modified in any way without prior written consent
of Vodafone.
6. This limited warranty extends only to customers who
purchase the product and is only valid in Vodafone’s
intended country (or area) of sale of the product.
7. If the product is returned to Vodafone after the expiration
of the warranty period, Vodafone’s normal service
policies shall apply and the consumer will be charged
accordingly.
a) Vodafone neither assumes for it any other obligation
or liability beyond that which is expressly provided for
in this limited warranty.
b) All warranty information, product features and
specifications are subject to change without notice.
8. THIS WARRANTY IS IN LIEU OF ANY AND OTHER
WARRANTIES EXPRESSED OR IMPLIED, SPECIFICALLY
INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILlTY OR FITNESS FOR A PARTICULAR
PURPOSE. VODAFONE ASSUMES NO LIABILITY FOR THE
BREACH OF THE WARRANTY BEYOND CORRECTING
THE BREACH IN THE MANNER DESCRIBED ABOVE.
IN NO EVENT SHALL VODAFONE BE LIABLE FOR
CONSEQUENCES.

Navigation menu
