Tinno Mobile Technology T300A MOBILE PHONE User Manual
SHENZHEN TINNO MOBILE TECHNOLOGY CO., LTD. MOBILE PHONE Users Manual
Users Manual
Table of Contents
1.For your Safety ..............................................................2
2.Mobile Phone Profile.....................................................3
3.Preparation before Use..................................................4
4.General Instructions for Mobile Phone .......................8
5.Basic operation ............................................................12
6.Use Menu Functions....................................................15
7.English Editor Operation............................................42
8.Use USB........................................................................42
9.Appendix 1 ...................................................................43
10.Appendix 2 .................................................................45
11. Appendix 3.................................................................45
2
1.For your Safety
For your safety and for proper use of the mobile phone, please
read the following guidelines carefully:
¾ Do not switch the mobile phone on when close to chemicals,
gas stations or other explosive materials.
¾ During driving, please use the headset for safety purpose;
otherwise in cases of emergency, always stop the car by the
roadside to have a call conversation.
¾ Because the use of the mobile phone can cause interference in
the aircraft, never use the mobile phone in aircraft. The use of
the mobile phone is dangerous and illegal; do switch off the
mobile phone before boarding.
¾ Pay special attention to the use of the mobile phone near heart
pacemakers, deaf-aids and other medical equipments, because
the mobile phone can cause interference with them.
¾ Use of uncertified accessories and parts will void the guaranty.
¾ Do not dismantle the mobile phone without permission. In
case of failure, please contact the supplier as soon as possible.
¾ Do not plug the charger into the mobile phone and charge
without battery. Always power off the mobile phone when
taking out the battery; otherwise the memory of the phone
may be damaged.
¾ When charging the mobile phone, always keep it in the place
with good ventilation, heat sink and away from flammable and
explosive objects.
¾ In order to avoid demagnetization, always keep the mobile
phone away from magnetic objects such as CDs, credit cards
etc.
¾ Ensure that the mobile phone does not come in contact with
any liquid; if it does occur, remove the battery and contact the
supplier immediately.
¾ Do not use the mobile phone in the environments with
3
extreme temperatures, never expose the mobile phone to strong
sunlight or a wet environment. The suitable temperature for the
phone and accessories is 0℃-40℃. The height to use the phone
shall be less than 2,000m.
¾ Do not use liquid or wet cloth with strong cleanser to clean the
mobile phone.
¾ This mobile phone has Bluetooth, Image viewer, Audio player,
radio, Schedule radio record and Melody composer functions,
which shall be used as per the related laws and regulations.
¾ Always keep the mobile phone out of children’s reach. Do not
throw or vibrate the mobile phone because violent treatment to
the mobile phone may damage the inner circuits and precise
structures.
¾ Please do not discard the waste battery into general household
garbage. Please deal with the waste battery according to
provisions where they are definitely made.
Warning: We will not be bear any responsibility for any incompliance
with the above guidelines or improper use of the mobile
phone.
Our company keeps the right to make modifications to any
of the content here in this user guide without public
announcement in advance.
The content of this manual may vary from the actual content
displayed in the mobile phone. In such case, the latter shall
govern.
2.Mobile Phone Profile
The mobile phone has 17 keys on the keypad. In addition, it is
inbuilt with one vibration motor, one charger/data common
transmission port.
(Below is the front of the mobile phone)
4
(Below is the side of the mobile phone)
(Below is the back of the mobile phone)
Screen
Receiver
Send/Dail key
Number key
Switch on/off/end key
Left soft key
Right soft key
Navigation key
Headset/charger/data cable
5
3.Preparation before Use
Install SIM Card
When registering mobile phone number, you can apply for phone
numbers, mobile phone network service providers and thus obtain SIM
(Subscriber Identification Module) card.
With SIM card, you can use all functions of your mobile phone.
The SIM card save the parameters needed for communications and
personal data, including PIN (Personal Identification Number) code,
phonebook, short message and other extra system services.
Warning: Do not distort or scratch the SIM card nor let it contact static,
dust or moisture. If it is lost, please contact immediately with your
network operator for help.
Before SIM card installation, please switch off the mobile phone.
Battery Cover
Speaker
Camera
FM quick key
FM quick key
FM quick key
6
The SIM card is installed on the back of the mobile phone.
Follow the following diagram to install the SIM card.
Note: As the SIM card is small object, keep it out of children’s touch or
prevent children gulping it!
Install Memory card
As the mobile phone does not have enough storage space, to use
some functions, you need to install a memory card (This mobile phone
use T-FLASH card.)
Install T-FLASH card: Open the back cover to take off the battery,
insert the T-Flash card into its slot, and then put back the battery
restarting the mobile phone. The LCD will give the note that the T-flash
card has been detected.
SIM card
Memory card
7
Note: As the T-FLASH card is small object, keep it out of children’s
touch or prevent children gulping it!
Install Battery
The mobile phone is suitable for original battery and accessories.
When the battery is idle, it is recommended to put it into the
protection box.
Follow the following diagram to install the battery.
Note: Do install the battery as per the diagram so as prevent the battery
contact patch being damaged.
Charge Battery
The new battery cannot reach the optimal efficiency unless it has
undergone several continuous complete charges and discharges.
When the battery is used up, charge it in time. Over-discharge can
damage the battery.
After the battery is charged full, cut off the connection of charger
with the AC power supply and then the connection with the mobile
8
phone.
Follow the following diagram to connect the charger.
During charging, the battery capacity icon on the screen flickers
from the right to the left. After the battery is charged full, the icon is
full of bars. Slight heat during charging is normal.
Warning: When a travel charger and its accessories are used to charge
the battery, please firstly check if they are original or recognized by the
original manufacturer. The use of other accessories may damage your
mobile phone and cause risks! Always use them indoor and in dry
places.
Notices on using the battery
The performance of the battery is affected by many factors,
including radio barrier network settings, signal strength, work
temperature, chosen and used functions or settings as well as phone
accessories, tone, data or other applications.
For optimal performances, please follow the rules below:
¾ New battery or the battery having been idle for long need
charging for long. The standard voltage scope for the battery is
3.6V-4.2V.
¾ During charging, keep the battery at room temperature or similar
temperature.
¾ With time passing by, the battery will gradually be worn and
Headset/Charger Interface
9
thus need longer time to charge. This is normal. However, after
normal charging, if call duration decreases but charging time
increases, you need to buy another battery from the original
manufacturer or authorized by the original manufacturer. The
battery of interior quality can damage your mobile phone and
cause danger!
¾ If the phone is overused at low battery when charging, there
might need a longer time for the charge indicator to be shown on
the screen.
Note: Please dispose the battery according to the local regulations. Try
to recycle the battery as possible. Do not treat the waste battery as
common waste.
Warning: Do not throw the battery into fire so as to prevent fire. The
broken battery may cause explosion.
Warning
Charging the mobile phone by improper means can cause to
explosion. Always refer to the related regulations for the disposal
of the battery.
PIN Code:It is the personal identification number used to enter SIM card
and able to prevent others using SIM card without permission. If the
mobile phone has activated the PIN code protection, when the mobile
phone is switched on, the screen will display “Input PIN”. In the process
of inputting PIN code, the screen will use “*” to represent the input
content.
PUK Code (8-digit)
To change the locked PIN code, you need to use PUK (Personal
Unblocking Key) code. If PUK code is not provided together with the
SIM card, ask the local service provider for them.
Warning: If the PIN code is input wrongly for successively three times,
the SIM card will be locked. Please contact the network operator
immediately for help. Attempting to unlock the code may make the
10
SIM card ineffective forever!
4.General Instructions for Mobile Phone
Dial key
It is used to have call (when the phone number is input or in
phonebook state) and receive incoming call. In standby state, press this
key to display the latest calls (all received calls, missed calls, and
dialed calls, at most 60 phone numbers). In standby state, press this key
twice successively to dial out the latest call number.
Switch-on/off key /End key
In call state, it is used to interrupt a call; in call conversation state,
it is used to end a call or exit from the current menu and back to the
standby state. Hold this key for 4~5s to switch on/off the mobile phone.
Left/Right soft key
Press the left/right soft key to have the functions indicated in the
bottom row of the main screen of the mobile phone.
Navigation key
This mobile phone has four navigation keys, with the left, right, up
and down control functions. These four navigation keys can be set with
shortcut functions, in default state: press the up key to Messages, the
down key to enter SIM service, the left key to Phonebook and the right
key to enter Games. Shortcut keys can be active only in standby state
and their function definitions can be set by yourself with the procedures
as: enter the phone settings menu, choose dedicated key function to
reedit the navigation keys.
Standard keypad
On the keypad, you can see 0-9 number keys, * key and # key,
totally 12 keys.
Press these keys to input phone number, password, English letters,
11
symbols etc, or choose menus.
Note: In standby state, hold “1” key long to call the voice inbox
service center. The number for the voice inbox should be preset.
In different states or different functional menus, * key and # key
have different functions:
Press “#” key long to start or exit from the silence mode.
Continuously press shortly or press long * key to input “P”, "＋"
or "W" , among which, “P” and “W” are used for extension calls
while “+” for international calls.
In music player state, * and # are used to adjust volume.
Tip: The difference between “W” and “P” is that “P” will directly send
DTMF after 3s pause while “W” will eject a window asking whether
the user to send DTMF.
Keypad lock
When in standby interface, if the mobile phone is idle for certain
time, it will be locked automatically. Press the right soft key to release
and press * key again to unlock. After the mobile phone is locked, the
keypad cannot be activated easily; in case of incoming call, likewise,
press the answer key to receive it; after that, the keypad will be locked
automatically.
Icons in Standby State
Antenna;
Activate the alarm clock.
SMS
Battery power capacity indication
Vib. then ring
Ring only
Vib. only
Vib. and ring
Missed Calls
Keypad Lock
MMS
12
PUSH Inbox
GPRS
All calls diverted
Language and Input Mode
The mobile phone has defaulted English and Spanish input mode.
Services
Services are provided with SIM kit. The mobile phone support
service function. The detailed menu items depend on SIM card and the
network. When the network provides such function and your SIM card
supports such function, the service menu will automatically be posted
in the services of the mobile phone.
Caller groups
The callers group in the mobile phone includes Friends, Family,
VIP, Business and Others etc. You can set different call tone and photo
for different caller group.
Term Description
Dial domestic calls
The simplest method to dial a domestic call is to input phone
number via the number keypad, then press dial key to dial call.
To change phone number, press “Clear” key. During dialing, the
screen will display a cartoon. When the other party is connected,
the screen will display the corresponding information.
Press end key to end the call.
To dial a domestic call, input area code + phone number and
then press the dial key.
Dial international calls
If you want to make an international call, you can press * key
continuously until the international dialing prefix “+” is seen on
the screen. This will allow you make an international call from
any country without knowing the dialing prefix (for example, +1
represents America).
After inputting the prefix, you need to input the Country number
13
and complete telephone number. You can input the Country
number according to the common practice, such as, 49 for
Germany, 44 for British, 46 for Sweden, etc.
Dial international telephone number as following: “+” Country
number +Complete telephone number + Dial key.
Dial fixed-line telephone extension
Some fixed-line telephone extension may not directly get
through, so you need to connect to the switchboard at first then
put through extension number. The mobile phone can
automatically dial extension number if you input “P” between
the switchboard and extension number. Method for input “P” as
following: hold press or continually short press three times “*”
key (“P” will be shown on the display).
Dial fixed-line telephone extension as following: phone number
+ “P” + extension number + dialing key
Emergency calls
If your phone is under the network coverage (you can know this
by checking the signal bar at the up left corner on the screen), you can
make emergency calls. If your network supplier does not provide
roaming service in this area, Emergency will be shown on the screen.
That means you can only make this kind of calls. If your phone is under
the network coverage, you can even make emergency calls without the
SIM card.
* In some areas, 112 (emergency call) service is provided by the
network operator. In case of failure, consult the network operator.
IMEI
International Mobile Equipment Identity number. Switch off the
mobile phone and take off the battery, then you will see the label with
such number on the back of the mobile phone. Also, this number is
saved in the mobile phone. After switch on, in standby state, input
“*#06#” to display it.
14
5.Basic operation
Switch on
Press the switch-on/off key to start the mobile phone, then the
screen will display switch-on image.
After insert SIM card, the mobile phone will automatically check
the SIM card availability, and then it will be shown information as
following on the display by sequence:
1. “Input phone lock code”——If you have set the password.
2. “Input PIN” —— If you set SIM card password.
3. “No service”—Indicates fail to make register and cannot make any
calls.
4. “Emergency calls only”—indicates has registered to other network
and only can make call to 112.
5. “Searching”—the mobile phone is searching network until find
appropriate network.
6. “Operator name”—Indicates network successfully registered.
Note: If you do not know PIN code, please contact the network
service provider.
The defaulted phone password “1122”
Switch off
To switch off the mobile phone, press the end key. When the
screen displays switch-off cartoon.Do not take out the battery to switch
off the mobile phone. If so, the SIM card can be damaged easily and
some data will be lost.
Dial a Call
With the number keypad, you can enter phone numbers (if
wrong characters are input, press the clear key to delete them).
Press the dial key to dial the phone number. To end a call, press
the end key; or to cancel a dial, press the Cancel key or the
switch-on/off key. After the call is connected, you can see the
15
call timer on the screen.
Dial a call via phonebook: Enter the phonebook and search the
desired name/phone number, and then press dial key to dial call.
Redial latest dialed number: In standby state, press dial key to
view the list of the latest dialed phone numbers or names. Roll
to the desired phone number or name and press dial key to dial
call.
Adjust Receiver Volume
In call conversation, press the up navigation key or down
navigation key to adjust the volume of the receiver.
Answer a Call
When there is a call, as per the settings of the mobile phone, you
will be alerted with ring only, vibration only, vibration and ring,
vibration then ring.
To receive a call, press Dial/Call Key.
To refuse a call, press Switch-on/off key or the end key directly.
If the CLI (Call Line Identity) is opened, the phone number of the
caller will occur on the screen. If this number has been saved in the
phonebook, the name corresponding to this number will be displayed
on the screen.
Send DTMF Signal
When this function is set, in call conversation, press the desired
number key and * key and # key to send DTMF signals to the other
party. If such function is inactive, then extension call will become
impossible.
Dial Hold
If you have applied for dial hold, in the call conversation process,
press “Options” to have the following function menus:
Hold single call: Pause the current call but with the line keeping
connected.
End single call: End the current call conversation.
16
New Call: Enter the dial interface, dial another call.
Phonebook: Enter the directory of the phonebook.
Call history: Enter the directory of the call history.
Messages: Enter the directory of SMS.
Sound recorder: While having call conversation, you can record
the call.
Mute: You can activate/inactivate the speaker.
DTMF: You can set whether to send DTMF signals.
Note: Some menu items need the support of the local network or can
occur in special cases, such as Conference and New Call. Consult the
local network operator for details.
Fast Read SMS
When the user receives unread SMS, the screen will display an
icon of unread SMS. Press Read to enter and read the SMS.
Missed Calls
When there have a missed call incoming, the screen will display a
missed call icon. And press Read to enter and read missed call.
Connect to Voice mail
The mobile phone allows connecting the incoming call into the
voice mail and then you can receive a notice about voice message. (The
voice mail number must be preset).
6.Use Menu Functions
[Games]
This phone provides four kinds of games: Copter,Puzzle,Robot,
concrete operations could see the Game Help of these games.
Games settings:
BGM: Set the background sound effect of the game On/Off.
Sound Effect: Set the sound effect On/Off.
17
Vibration: Set the vibration effect On/Off
[Messages]
SMS
SMS is a kind of network service that cannot be used to send and
receive short messages until you apply to the network operator.
The SMS is sent to the SMS center of the network and then sent
by the network to the target user (GSM user). If the user does not
switch on the mobile phone or the mobile phone cannot receive the
SMS (the memory is full), the network will save the SMS temporarily.
The duration of storage depends on sender’s settings and network
service provider.
With this function, the mobile phone can send and receive chain
text messages, which may affect the message fees. For more
information, please consult the service provider.
When the SMS capacity is full, there will be an SMS icon
flickering on the standby interface. The full capacity can affect SMS
reception. Delete some SMS to solve the problem.
If the other party has received SMS, you will hear the alert sound
from the mobile phone (if such alert function is set as ON).
Note: When sending SMS via the SMS network, the mobile phone may
display “Message sent”. It indicates that the SMS has been sent to the
SMS center inbox set in the mobile phone but does not mean the
receiver has received the SMS. For more information, please consult
the service provider.
Inbox
You can see the SMS in the inbox.
Reply: You can reply to the received SMS.
Delete: Delete the current SMS.
Edit: You can edit the current SMS or send it after editing.
Forward: You can directly forward this SMS to others.
18
Call sender:Send a call to she sender.
Move to phone: You can move the entries in SIM card onto the
phone.
Copy to phone: You can copy the entries in SIM card onto the
phone.
Chat: You can chat with the sender after set a chat room.
Delete all: You can delete all SMS in inbox.
Copy all: You can have two options, i.e. copy all entries on the
SIM card in the inbox onto the phone.
Move all: You can have two options, i.e. move all entries on the
SIM card in the inbox onto the phone.
Use number: You can extract the number in the SMS and save it or
dial a call.
Use URL: You can link to the website contained in the received
SMS.
Use Email address:You can extract the Email address in the SMS .
Outbox
While sending SMS, if choosing “Save and send”, you can save
the SMS into the Outbox. You can directly save the edited SMS into the
Outbox, in such case, the Outbox will display “No number”, i.e. no
target number. If you fail to send the SMS, it will be saved in the
Outbox. Also, you can have such operations as Send, Edit, Delete,
Copy to phone ,Move to phone, Delete all, Copy all, Move all, Use
number, Use URL, Use Email address.
Write Message
You can write message in this menu.
Every SMS can contain 160 word length English characters. To
write SMS, press “#” key to switch input modes, “*” key to select
Symbol; press “Clear” key to clear one character before the cursor, long
press “Clear” key to delete all characters; press the end key to back to
the standby interface, press the upper and down direction key to choose
characters.
19
The mobile phone can send the chain SMS more than 160
characters (limit for common text messages). If the SMS contains more
than 160 characters, then the SMS will be split into 2pcs or more. You
can insert Picture, My picture, Predefined animation, My animation,
Melody, My melody, Predefined sound into SMS. However, the SMS
will not be received and displayed unless the network and the receiving
mobile phone support.
You can enter the phone number or choose a number from the
phonebook to send the SMS.
Templates
With it, you can pre-edit some common phrases, which is
convenient for quick SMS editing.
SMS settings
You can set some parameters of the SMS in the menu.
Profile settings:The SMS center number is provided by the
network operator.
Common settings
Delivery report: The network will inform you whether the
other party has received the SMS and what the time is.
Reply path: You can send the reply path to the network
terminal. This function needs the support from the SMS
center.
Memory status: You can view the capacity of the SIM card
and the phone.
Preferred storage: You can set the storage position (SIM or
phone) for SMS.
Prefered connection:You can set the preferred connection
(Prefer GPRS,Prefer GSM,GSM only) for SMS.
MMS
MMS can contain words, sound and photos. If the MMS is out of
the limit, the mobile phone will be unable to receive the MMS. If the
20
SMS contains photos, the mobile phone will adjust photos so as to
display them on the screen completely.
The display effect of MMS depends on reception devices.
Note: You cannot use photo messages unless the network operator or
service provider supports to do so. You cannot receive and display
MMS unless the mobile phone has the compatible MMS or e-mail
function.
Write message
To/ Cc/ Bcc
Add Number-- Input the number of the receiver.
Add Email-- Input the e-mail of the receiver.
Subject: You can edit the subject of the MMS.
Edit content
Press Edit key to have the following options:
Add picture: You can insert you desired picture.
Add audio: You can insert your desired audio.
Add video: You can insert your desired video.
Add attachment: You can insert your desired attachment.
Add bookmark text:You can add your desired bookmark.
Add slide before: You can add a slide before the current
page.
Add slide after: You can add a slide after the current
page.
Preview: You can preview the editing effect of the
current MMS.
Slid timing: You can set the play time of every slide.
After editing, you can press “Done” key to finish the MMS, in this
option you can send the MMS as following methods: send only, save
and send, save to drafts or save as template, you can also set functions
including : Validity period, Delivery report, Read report, Priority.
Inbox
You can see the MMS in the inbox and have the following
21
operations:
View: You can view the MMS and save photos, audio and annex.
Reply: Reply the sender with MMS Reply by SMS: Reply the
sender with SMS.
Reply all: If the MMS you received has been sent to many
receivers by the sender, with such function, you can send a reply
MMS to the same receivers.
Forward: You can directly forward this MMS to others.
Delete: Delete the current MMS.
Delete all: You can delete all MMS in inbox.
Save as template: You can save the MMS as template.
Properties: View the detailed information of the current message.
Use details: You can extract the number in the MMS and save it or
dial a call. You can also use the URL in the MMS.
Outbox
You can view the MMS send and saved in the Outbox and failed
and have such operations as View, Send, Delete and Delete all, Save as
template, Properties and Use details.
Drafts
You can save the edited MMS into the drafts, and also you can
have such operations as View, Send, Edit, Delete and Delete all, Save
as template, Properties and Use details on the MMS in the drafts.
Template
There will be the templates which user defined.
MMS settings: You can set some parameters of the MMS in the menu.
Compose:
Creation mode-- "Free" and “Restricted ".
Picture resizing-- You can reduce the size of the inserted
photo, including: 160*120,320*240 and Off.
Best slide duration-- You can set On or Off to activate
such function.
Auto Signature-- You can set On or Off to activate such
22
function.
Signature-- You can edit the content of the automatic
signature.
Send:
Validity period-- You can set the time to save in the MMS
service center and send, including Maximum,1hour,
6hours, 12hours, 1day, 1week.
Delivery report--You can On or Off to activate such
function.
Read report-- You can On or Off to activate such
function.
Priority-- Including Medium, High, Low.
Slide timing-- You can set the interval of the receiver to
see the MMS, defaulted as 5s
Delivery time --Immediate, 1hour later, 12 hours later
and 24 hours later.
Retrieve:
Home network—Immediate and Rejected, Delayed.
Roaming -- The same as to the main network, including
and As home, Delayed and Rejected,.
Read report—On request, Send, Never send
Delivery report—You can set On or Off to activate such
function.
Filter:
Anonymous -- Allow and Reject.
Advertisement-- Allow and Reject.
Server profile:
After choosing Settings, you can have the following settings:
Activate account.
Edit account: You will edit the Account name, MMSC
address, Data account, Connection type, User name
and Password of the account.
23
Delete account
Memory Status:
You can see the utilization rate of the mobile phone, including
the used space and the usable space. The sub menu should show SMS
capacity in Numbers .
Chat
You can have a chat in the chat room which you had selected or
preset its information such as my nickname, destination num.
Email
由于目前软件版本中功能混乱，无法对其编写说明
Voice mail server
This is a kind of network service, which cannot be used until you
apply to the network operator or open it. Please consult the local
service provider for more details and voice mail number.
¾ Call voice mail: You can dial the voice mail number saved in the
voice mail number function list. If you have two phone numbers,
they will have their own voice mail number.
¾ Edit: You can edit the voice mail name and the voice mail
number. Press the OK key to save the number.
Tip: In standby state, after the voice mail number is set, press 1 key to
call the voice mail.
Broadcast Message
Cell broadcast is a kind of information service such as weather
report, traffic etc that the network operator sends to the GSM users
within certain area.
¾ Receive mode: You can ON/OFF to activate such function.
¾ Read message: You cannot read the received information until
you open such function.
¾ Languages: You can set the language for the received
information. The defined is All languages.
¾ Channel settings: You can Select, Add and Edit and Delete
channel number.
24
[STK]
The mobile phone support service function. The detailed
menu items depend on SIM card and the network. When the
network provides such function and your SIM card supports such
function, the service menu will automatically be posted in the
services of the mobile phone.
[Phonebook]
The mobile phone is provided with the business card folder type
phonebook. The information of every contact saved on the mobile
phone include three phone numbers (mobile phone, home phone and
office phone), company name, e-mail address, office number, fax
number, birthday, associate picture, associate sound, caller group (Five
types: none, family, VIP, business and others). Every contact saved into
SIM card include name and number. The mobile phone supports 500
numbers.
Quick search
Input the first several letters to be searched, all the records related
will be display on the screen.
Search contact
Input the name to be searched, press “Search” in the phonebook,
then you can find the matching name.
Add new contact
You can save phone numbers to SIM card or phone. On SIM card,
one entry has only name and phone number. On the phone, one contact
can include Name, Number, Home Number, Company Name, E-mail
Address, Office Number, Fax Number, Birthday, Associate Picture,
Associate Sound and Caller Group.
Tip: If one contact is set with photo link, tone link and callers group at
the same time, then the caller group function will be inactive.
Multi operation
目前多笔操作功能混乱无法对其进行说明
25
Caller Groups
You can set call tone, photo and members for five caller groups.
Caller groups’ member can only come from the number saved on the
phone.
Extra numbers
You can set owner number.And the default SOS number are
060,911, 112.
Settings
Memory Status: You can view the current use status of the
phonebook, including SIM card and phone memory. The display
format is “Used/Total”.
Preferred Storage: You can choose the storage path for the
current number.
Fields: You can choose the display items in the phonebook and
the display items in the Add Contact interface.
Name list filter:
My vCard: You can edit and send my business card.
vCard version: You can choose the vCard version: vCard 2.1 or
vCard 3.0.
Caller picture
目前功能混乱无法对其进行说明
Caller ringtone
[Browser]
Bluetooth
The mobile phone supports the Bluetooth function. You can use
Bluetooth wireless technology to set wireless connection with other
compatible devices, including mobile phone, computer, headset etc.
With Bluetooth function, you can send photo, video segment, audio
segment, personal business card and memo. You can also establish
wireless connection with the compatible PC to transmit files.
26
As the device supporting Bluetooth wireless technology performs
communications via wireless wave, you don’t need keeping the device
opposite to other devices but keep the distance between them not more
than 10m (about 33). However, Bluetooth connection can be affected
by wall or other electronic equipments etc. To ensure mutual operation
between this device and other devices supporting Bluetooth wireless
technology, consult the manufacturer to confirm whether the device by
it is compatible with this device. Do not use Bluetooth function in
hospital and aircraft etc.
Bluetooth Menu
Power: Before using Bluetooth function, you need to activate this
option. When Bluetooth function or other functions are being used,
allowing this function to operate in the back desk will consume more
power. It is recommended to close this function when it is idle.
Inquiry audio device: With this function, you can inquiry audio device.
For other devices, enter My Devices to search.
My device: After entering this option, you will see the Bluetooth
devices compatible with the mobile phone.
Active devices: With this function, you can see all devices connected
with the mobile phone and their link service type. You can interrupt the
specified link service.
Settings: Before using Bluetooth function, enter this menu to have
corresponding settings. If your mobile phone’s Bluetooth function is
not activated, you can have activation confirmation.
Visibility: After this option is activated, other peripheral devices
supporting Bluetooth wireless technology can see your device
and its name via search. After the step audio play service is
activated, this device will be unable to be searched.
Change device name: You can edit my device name.
Authentication: After this option is activated, matching is
needed when peripheral device accesses my device via
Bluetooth (for matched devices as well). After closing the option,
27
no matching is needed for the matched devices.
Audio path: You can leave the audio in phone or forward to
other hand-free devices via Bluetooth. If using Bluetooth to have
a call, set this path as head-set devices.
Block list: You can view the block list if you set.
Storage: Select Phone or Memory card as default storage place.
BIP Settings: You can set the file directory shared by my device.
About:
Here, you can see the name of my device, device address and the
Bluetooth services supported by my device.
Tip: When searching Bluetooth devices, make sure that the peripheral
Bluetooth devices are within the signal cover range and can be searched.
To match the searched devices, you need to discuss with the user of this
device about a pair of matching passwords. To match the hand-free
device, you must input its matching password. After matching, this
device will be saved in my device .
Use Bluetooth to Receive/Send Data:
1. Open the applications needed to save the content to be sent. For
example, to send photos to another compatible device, you should enter
the album or file management.
2. Choose the content to be sent, and then choose Options->Send->To
Bluetooth. The screen will display the device supporting Bluetooth
wireless technology and within the signal coverage. To disconnect
search, choose “Cancel”.
3. Choose the device to be connected with.
4. If another device requires matching before data transmission, the
device will send hint and require inputting matching password.
5. After the connection is established, the mobile phone will display
data transmission speed.
6. When other Bluetooth devices send data to my service, the mobile
phone will hint and ask whether to receive the data. The received data
will be stored in the initially set received folder.
28
Tip: You can set the storage position to receive files as other folders
or the folders on T-flash card. After setting, the file received via
Bluetooth will be automatically saved to the specified folder.
Tip:
Before using Bluetooth headset for calls, please go to the menu
settings to confirm that the audio path has been set as hand-free
device.
Use the following methods to disconnect:
Close the activated Bluetooth to disconnect all devices.
Enter online devices and disconnect the specified online service.
Enter my devices and delete the matched devices to disconnect
other devices with my device.
The connection with the devices out of the signal coverage will
be ineffective.
WAP
Homepage-- Start the website chosen in the connection settings file.
Bookmarks--Ideas Telcel,Correo iTelcel,Buscador Ideas,Ideas Music
Store,Ideas Musica,Ideas juegos,Ideas Imagenes.
¾ Go to: Log into the chosen website.
¾ Edit: Edit the chosen bookmark name and website.
¾ Send: Send the bookmark as text message or multimedia
message.
¾ Delete: Delete the chosen bookmark.
¾ Delete all: Delete all bookmarks.
¾ Add bookmark: Add new bookmarks.
Recent pages: Record the latest 10 web pages browsed.
Offline pages: You can view these pages when you offline.
Input address: Input the website to be logged in.
Service Inbox: The mobile phone can receive the service information
(“Recommended” information) sent by the service provider. For
example, the service information can be the notice of related news
headlines, which can include one piece of news or a service website.
29
Settings:
¾ Edit account:
Ideas Telcel
Activate account
Edit account: You will edit the Account name,
Homepage, Data account, Connection type,
User name and Password of the account.
Note: The setting method of other WAP settings files is the same as
that of Ideas Telcel.
¾ Browser options-- You set whether to display images during
waiting time and when browsing webpages.
¾ Service message settings-- You can choose ON or OFF to enable
the push or not and you can choose the disable or always in the
Trust settings. Set SL settings functions as follow: Never,
confirm, without confirm. Add new trust list including:
number, IP address, Domain name.
¾ Clear cache-- You can clear cache. When the data of the cache
are excessive, network surfing speed can be affected.
¾ Clear cookies-- You can clear personal data.
¾ Trusted certificates--Entrust.net WAP CA (c)1999 Limited
liability. See www.entrust.net/wapcps; US VeriSign, Inc. Class 3
Public, primary certification authority.
Data account
GSM Data:You can edit the Account name,Number,user name,pass
-word,Line type,Speed,DNS by each account.
GPRS-- The Account Name, APN, User Name , Password, Auth
type .of GPRS data will be provided.
Note: For related charging standard and detailed settings, please consult
the local network service operator. Different network service
providers provide different services. Consult the local network
operator.
Connection manager: View the connection status.
30
[Multimedia]（由于多媒体菜单目前存在严重的功能混乱，以下说
明是根据其他项目的说明书修改的）
Camera
With this function, you can use the inbuilt camera to take photos.
The lens of the camera is located on the back of the slide and the screen
is used as the viewing window. All photos taken are in JPG form. After
downloading the photos onto PC, you need some software to view
them.
If the storage space of the mobile phone is insufficient to store the
taken photos, it is necessary to delete some old photos or other files in
“File Management” function list to release more space.
Description of Mobile Phone Options:
Options Description
Photos To view the saved photos.
Banding: 60Hz(default), 50Hz
Delay Time: 5s, 10s, 15s or Off.
Camera
setting Cont Shot: Oneor Off.
Size: 128*96,352*288. Image
Settings Image quality: Normal, High, Low
Scene
Mode Auto, Night
Storage Phone ,Memory Card
Restore
Default You can restore the recorder to factory settings.
Image viewer: All photos taken are saved in the album.
Options Description
View You can view the selected photos.
Browse Style There are two browse styles, i.e. list and matrix.
send You can send photo to MMS and Bluetooth.
Rename You can rename the selected photo.
Delete You can delete the selected photo.
Delete All files You can delete all photos in the album.
Storage You can choose photos storage path (to phone or
31
memory card).
Video recorder:
Press the OK key to start video recording. The duration of
recording depends on the time limit set and file management capacity.
Entering the options, you can have the following settings:
Options Description
Night Mode: On, Off
Camcorder
settings Banding: 50Hz ,60Hz
Storage You can store the video in Phone or Memory card.
Restore default You can restore the recorder to factory settings.
Video player:
It supports the videos in AVI .In such mode, you can have the
following operations to the specified file in AVI.
Options of the player
Options Description
Play You can view the selected video.
send You can send video to MMS and Bluetooth.
Rename You can rename the selected video.
Delete You can delete the selected video.
Delete All files You can delete all videos in the video folder
Storage You can store the video in Phone or Memory card.
Audio player:
If the operation system is Windows 2000 above, no driver needs
installing. To download music, you must insert the T-Flash card into the
mobile phone, switch off the mobile phone, connect the mobile phone
and PC with USB cable, then the PC will detect the new hardware and
create a new mobile HD. Download the chosen MP3 file to under "My
Music" of the mobile disk rather than in such folders as Audio, Images
and Photos; otherwise, the file cannot be played. (Only the music in
MP3, AMR and MIDI supportable).
Description of audio player options:
Options Description
Play Play the current chosen music.
32
Details View file name, Channel, Quality, Size, Time,
etc.
Add to
ringtones
Add the chosen music into the ring base.
Refresh
list
Enter the track list and update it (e.g. the deleted
music in the file management will not disappear
until update is conducted.
Settings Play Settings: Track list path, automatic track
list, repeat, shuffle and background play.
Radio: To use this function, you need to insert headset. It supports
radio played out via phone speaker.
(1)Function key introduction
OK key: enter the options of radio.
Up direction key: turn on radio record.
Down direction key: switch on/off the radio.
Left/Right direction key: when in the research mode, Press the left
direction key once forward by 0.05MHz(FM state)and the right
direction key backward by 0.05MHz(FM state) to search the desired
channel.
1-9 number key: when you preset auto search, the channel which are
searched will be list, then you can press the 1-9 number key to listen
the radio channel saved in the list one by one.
Short press: you can roll to choose the desired channel or press any of
number keys 1-9 to choose the corresponding channel.
Long press: save current channel to this key.
*,# key: Adjust volume.
(2)Option menu
Channel list: according current FM channel to show corresponding
channel list.
Manual input: You can edit the specified radio frequency band. The
frequency of the radio is between 87.5mHz and 108.0mHz.
Preset Auto Search: You can have automatic search and save the
33
searched channels into the list.
Settings: You can set background play, loud speaker，Record format，
Audio quality and Record storage.
Record: You can record current radio sounds through this function.
Append: Select a radio record file to keep going to record radio
program, all programs will add into the original file.
File list: Show all voice files.
Schedule Radio Recorder:
Set the start time and end time etc for the recording, thus when
the start time is reached, the radio recording will start automatically.
You can also set the repeat as: once,everyday, days, weekly,
monthly and set the channel list then select it.
Channel settings: You can select the channel on the list directly
or manual input the channel.
Record settings: functions as following: record format
(AMR/WAV), Audio quality (High/Low), storage (Phone/ Memory
card), Record file(New file/Append file).
Melody compose:
The mobile phone provides custom ring tones of different
musical instruments, and add them into profiles or SMS ring base.
When compose a music, you can play it with different speed and
musical instruments, then save it.
File Manager
You can manage photos, MP3 and folders in phone and memory
card.
Memory Card
¾ Open: You can open the files in the memory card.
¾ New folder: Under the root directory, you can create a new
folder to save more detailed files.
¾ Format: You can format all files in the memory card.
34
[Settings]
User profiles
Your mobile phone is provided with multiple profiles so that you
can customize some settings in different cases for different events.
Firstly, as per your personal hobby, have individualized settings on
profile and then activate it. You can have such profiles as General,
Meeting, Outdoor, Indoor, Headset and Bluetooth.
The content can be edited at every profiles mode as following:
¾ Tone setup: Include Incoming Call, Power on, Power off,
Message tone and Keypad tone.
¾ Volume: Set the volume of Ringtone and Key tone.
¾ Alert type: You can choose any one from Ring only, Vibration
only, Vibration and ring, Vibration then ring as the current ring
mode.
¾ Ring type: You can choose any one from Single, Repeat,
Ascending as the current ring type.
¾ Extra tone: You can have Select/Cancel settings on Warning,
Error, Camp on and Connect so as to have corresponding tone
tips.
¾ Answer mode: You can choose whether to use any key to
answer.
After individualized settings, choose “Activate” in “Select” to
start profiles.
Note: After the headset is inserted into the mobile phone, the mobile
phone will automatically change into headset profile. Unplug the
headset to return to the previous profile.
After the Bluetooth is connected with the mobile phone and used
as headset or handsfree, the mobile phone will automatically change
into Bluetooth profile. Disconnect with Bluetooth to return to the
previous profile.
In standby state, press # key for several seconds to switch to
silence profile and again to the previous profile.
35
Phone Setup
In such menu, you can set phone language, standby wallpaper,
time etc.
¾ Time and date: With this function, you can set home city, time
and date format and the time of specific place.
Set Home City: You can set different cities.
Note: This option must be used together with auto update of
time and date. Auto update of time and data cannot be
conducted unless the network supports.
Set Time and Date: You can set the current time and
date.
Set Format: You can set the display format for time
and date.
Note: If the battery is taken from the mobile phone or the battery is
used up for long time, when switching on the mobile phone after
reinstalling the battery or charging the battery, you need to reset the
time and date.
¾ Schedule power on/off: You can set the time for schedule power
on/off.
¾ Language: You can choose the desired language for phone
display.
¾ Display characteristics: You can set standby menu display as
wallpaper, screen saver, power on display, power off display,
whether to show date and time and owner number (if set in the
phonebook).
¾ Greeting text: You can set the greeting text displayed on the
main screen.
¾ Shortcuts: You can set the shortcuts menu and then this option
must be used together with Navigation key.
¾ Navigation key: You can have corresponding settings on the up,
down, left and right keys.
¾ Auto update of date and time: To set the mobile phone to
36
automatically update time and date according to the current time
zone, choose “Activate”. Auto update of time and date will not
affect the alarm clock, calendar or alarm clock memo setting
time, which will be subject to the time and date when created.
However, auto update of time and date may make some set
alarm clocks out of date.
¾ Flight mode:
¾ Misc. Settings: You can adjust the brightness and time of LCD
backlight.
Call Setup
¾ Call setting:
■ Caller ID: Including Set by network, Hide ID and Send ID.
Set by network: While having a call conversation, you
can send my caller ID in the form preset by the system.
Hide ID: While having a call conversation, you will not
send my caller ID. If the system does not support such
function, call may fail.
Send ID: While having a call conversation, you can send
my caller ID to the system.
Note: This function needs network support.
■ Call waiting: You can set this function Activate ,Deactivate or
Query status. The call hold and multi-party call cannot be active
unless this function is activated. This needs network support.
■ Call divert: This is a kind of network function, which cannot be
used unless you apply to the network operator for it. With this
function, you can divert calls meeting the conditions to another
number.
■ Call barring:
Outgoing calls:
1. All calls: You can bar all outgoing calls.
2. International calls: You can bar international calls.
3. International calls except to home PLMN: When
37
abroad, you can dial the calls of the current country
and the original country (the service providers
allows to do so).
Incoming calls:
1. All calls: You can bar all incoming calls.
2. When roaming: You can bar all calls except the calls
of the local service area.
Cancel all: You can cancel call barring settings and
dial/receive calls normally by putting the password.
Change barring password: You can apply to the
network to change the password for call barring.
¾ Black list: You can set it as On or Off. You can use the menu to
reject the number you do not want to receive.
¾ Auto redial: You can set it as On or Off. After the first
automatic redial fails, at most ten times can be available to
connect a phone number.
¾ Speed Dial: You can set whether to activate this function and
edit the related speed dialing numbers. If this function is
“Active”, then you dial any of the corresponding individual keys
(2-9) on the standby interface to dial the number specified for
this key.
¾ More:
■ Call time display: You can set whether to display call duration
during call conversation.
■ Call time reminder: You can set one alert tone or periodic alert
tone for several round minutes during call conversation so that you can
understand call time. You can also turn off the alert tone.
■ Auto quick end: You can set call duration. After the set time
expires, the mobile phone will automatically end the call.
Line switching: You can chose line1 or line 2 for your phone.
Closed user group: You can closed the user group which you
selected.
38
Note: Some settings need network support. For example, call barring
can not be used unless the local network and SIM card open it.
Network Setup
¾ Network selection: You can search the network again. Select
your favorite network and choose to register the network
automatically or manually.
¾ Preferred network: You can set the preferred registered network
for SIM card.
¾ GPRS connection:You can set the status of GPRS connecti-
on(when need or always)by this function.
Security Setup
¾ Security setup: By this function, you can set the SIM lock,
Phone lock,Auto keypad lock,Fixed dial, Barred dial and
Change password.
SIM Lock: You can set SIM lock (PIN code) as on/off. When
this option is chosen, it is necessary to input PIN code when you
power on the phone.
Phone Lock: You can set it as On or Off. It is a password of 4-8
digits and the defaulted one is 1122. You can change it.
Auto keypad lock: You can set it as On or Off. The mobile
phone has keypad lock function. When it lasts certain time, the
keypad will be locked, including such options as Off, 5s, 30s,
60s and 5min.
Fixed dial: This function needs the support of the SIM card and
the network operator. When it is activated, you can only dial the
phone numbers saved in host fixed dial list. To activate it, you
need to input PIN2 code.
Change Password: You can change the defaulted PIN, PIN2,
Phone password.
Restore Factory Settings
You can restore the factory settings of the mobile phone. The
restore factory setting password is 1122.
39
[Organizer]
Calendar
With this function, you can set the alarm clock to remind you of
your schedule and record your schedule. Roll the rectangle block to the
desired date. If the date is set with memo function, then this date will
be highlighted in yellow. To view all memos of one day, press OK to
see the schedule. You can have the following operations:
View tasks: You can view the task of the date where the cursor is
on and set the time, date, content and whether to activate alarm
on this schedule. When editing the task, you can choose the
alarm defaulted time with the left and right direction keys. In
addition, you can have such operations as Add, Delete, Delete
all and Send vCalendar.
Add task: You can select task type and then edit it. The task
types are as following: Reminder, Meeting, Course, Date, Call,
Anniversary.
Jump to date: You can move to the calendar of the specified
date.
Go to weekly view: You can view the whole tasks in one week.
The next time you can view the whole tasks in one month by
choosing Go to monthly view.
To Do
You can have such operations as View, Add, Edit, Delete, Delete
all and Send vCalendar.
If you have set alarm for the memo, when the set time is reached,
the mobile phone will ring and display the memo content.
Alarm
The time format for the alarm clock is identical to that of clock.
When the mobile phone is off, the alarm clock can still work provided
the battery is sufficient. The system has set 5 alarm clock options and
the defaulted is off. You can activate one option or all options
according to the actual demand. Every alarm clock option can set
40
independent time and date. When the time is reached, the mobile phone
will give out alert tone and flicker the current time and date on the
screen. Press Stop to stop alarm clock; press Sleep, then the mobile
phone will pause ringing and continue after 4min.
If alarm time is reached but the mobile phone is switched off, then
the mobile phone will be switch on automatically and ring. If Stop is
pressed, then the mobile phone will ask you whether to switch on the
mobile phone. Press “No” to switch off the mobile phone and “Yes” to
register at the network and switch on the mobile phone.
You can edit alarm as following functions: On/Off, Time,
repeat(once, everyday, days),alarm tone(tone,radio),snooze(default,
1-10mins),alert type(ring only, vibration only, vib and ring).
Calculator
The up navigation key for “+” and the down navigation key for
“－”, the left navigation key for "×" and the right navigation
key for "÷";
Press the clear key to clear the latest inputs or results digit by
digit; press the clear key long to clear all content or result;
Press “OK” key to obtain the result.
Note: The precision of this calculator is limited and can be used for
simple calculation.
Currence converter
First input the rate and local,press OK，then get the result.
World Clock
Press the left and right direction keys to view the current time of
every country corresponding to every time zone. If you set up the
daylight saving time for foreign city, the current time of the city except
the defaulted city will be ahead a hour.
Stopwatch
It include typical watch,nway watch.
E-book reader
You can read the words which you saved in the phone or in the
41
memory card.
[Call center]
Call history includes missed calls, dialed calls, received calls,
Delete call logs, call timers, call cost, SMS counter and GPRS counter.
In missed calls, received calls and dialed calls function list, you
can see the date and time of the call, edit or delete the phone number in
the list, save the number to phonebook or send SMS and MMS to the
number, or redial this number etc.
Note: The missed calls, received calls and dialed calls contains
respectively 20 entries. Choose any entry from missed calls, received
calls and dialed calls, press the Send key to dial the number directly.
Call timers
Last Call: With this function, you can view the last call time.
Dialed calls: With function, you can view the duration of all dialed
calls.
Received calls: With the function, you can view the duration of all
received calls.
Reset all time: With this function, you can clear all duration
records of calls after inputting the password which is supported
by Intex.
Note: The actual call duration and service time in the bill of the service
provider may be different from them, which depends on the network
functions, accounting rounding and tax etc.
Call cost
This needs the support of the network service provider.
Last call cost: With this function, you can view the fees of the last
call.
Total cost: With this function, you can view the fees of all calls.
Reset cost: With this function, you can clear all fee records. PIN2
code must be input to set call cost.
42
Max cost: With this function, you can limit call fees in the
specified pricing unit or currency unit. PIN2 code must be input
to set call cost.
Price per unit: This function needs network support. For more
details, please consult the network operator.
SMS counter
With this function, you can see and reset the number of sent
messages and received messages .
GPRS counter
Last sent: You can view the sending traffic of last link.
Last received: You can view the reception traffic of last link.
All sent: You can view the sending traffic of all links.
All received: You can view the reception traffic of all links.
Reset counter: You can clear all link traffic.
7.English Editor Operation
The mobile phone provides multiple convenient input modes,
which can support the use of other functions.
Basic letter input
After “Smart ABC /Smart abc/Multitap ABC/Multitap abc is
chosen, input your desired letters with the standard keypad.
Number input
This mode is mainly used to input phone numbers etc. After
“number” is chosen, you can input digit into the place where the cursor
is flickering.
Symbol input
In any of the above input modes, you are provided with symbol
input. If you can’t see symbols, press “*” key to see them. If you want
one symbol, press the up/down/left/right key to choose.
43
8.Use USB
Notices before use
¾ Always connect and stop USB device correctly.
¾ Never use Windows formatting command to format the mobile
disk of the mobile phone; otherwise, it will be damaged
severely.
¾ USB work environment:
Windows2000 / XP.
For other operation systems, the connection between PC
and the mobile phone cannot be conducted unless USB
driver is installed.
9.Appendix 1
Troubleshooting
Phenomena Possible Causes
Unable to switch on 1. Does the battery have power?
2. Is the battery placed correctly?
SIM failed
1. The SIM card is dirty. Clean it.
2. Reinstall the SIM card.
3. The SIM card is damaged.
Replace it.
Poor signals
Check the signal strength icon on the
screen. If the icon contains 3 bars, it
indicates the signal is the strongest; if
below 1 bars, it indicates the signal is
very poor.
44
Unable to dial out
1. Maybe you have set Hide My
Caller ID but your network
operator does not provide this
service for you.
2. Strong interference exists
around you.
3. Maybe you have activated the
call restriction function.
4. Maybe you have activated
Line 2 but your network
operator does not provide this
service for you.
Unable to charge the
battery
1. The battery may discharge too
much; so it cannot be charged
until it is connected for certain
time.
2. Its performance has
worsened.
Unable to register to
the network
1. Too weak signals or strong
interference.
2. SIM card installed properly?
Bad contact or SIM card
damaged? If the SIM card is
broken, please contact the
network operator to replace it.
Photos taken are too
dark
1. Check if the too low photo
brightness is set.
2. Check if ambient ray is too
dark.
45
Photos taken are too
unclear
1. Check if the object taken is
moving.
2. Check if the mobile phone
shivers slightly while you press
shutter.
Photos taken is
distorted
The object taken may be too close to
camera lens.
Unable to access
service menus.
Maybe the SIM card does not support
service function.
Only part of the
photo set as standby
photo can be seen.
The size of the photo may be too big.
The recommended size is 128*160.
10.Appendix 2
Abbreviations and Definitions
SMS Short Message Service
SIM Subscriber Identity Module
GSM Global System for Mobile Communication
PIN Personal Identity Number
PUK PIN Unblocking Key
IMEI International Mobile Equipment Identity
CB Cell Broadcast
GPRS General Packet Radio Service
MMS Multimedia Message service
46
11. Appendix 3
Notices for the use of accessories
Battery
More than 12h charging is needed for the new battery or
that idle for long.
Other batteries other than the original one can damage
your mobile phone and cause risk! The short in any form
can lead to explosion, fire or personal injury!
For your security and environment protection, do not
throw the battery freely but put it into the specified
recovery place.
Charger
Do not plug the charger into the mobile phone and charge
without battery so as to prevent the phone being
damaged.
Always use the charger in dry place indoor; never let the
charger touch any liquid during use so as to prevent
damaging the phone or even causing explosion, fire or
personal injury!
Always use the charger by the original manufacturer so
as to prevent damaging the phone or even causing fire or
personal injury etc!
USB
Please insert USB in switch-off status or choose the first option
“Memory unit” in switch-on status, then the mobile phone can
be used as a memory body.
Never insert the USB reversely, because doing so can make the
I/O port short.
Never use any other USB except that from the original
manufacturer; otherwise, the mobile phone and the USB port
47
may be damaged.
T-Flash card
It is recommended to use eligible T-Flash card, because the use
of ineligible products may damage the T-Flash memory card
slot.
12. Appendix 4
FCC RF Exposure Information and Statement
The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of
tissue. Device types T300A (FCC ID: XD6T300A) has also been tested
against this SAR limit. The highest SAR value reported under this
standard during product certification for use at the ear is 1.117W/kg
and when properly worn on the body is 1.196W/kg. This device was
tested for typical body-worn operations with the back of the handset
kept 1.5cm from the body. To maintain compliance with FCC RF
exposure requirements, use accessories that maintain a 1.5cm
separation distance between the user's body and the back of the handset.
The use of belt clips, holsters and similar accessories should not
contain metallic components in its assembly. The use of accessories
that do not satisfy these requirements may not comply with FCC RF
exposure requirements, and should be avoided.
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
48
NOTE: The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modifications could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
