MediaAccess C2100T for CenturyLink
Wireless .11ac
Smart Ultra-Broadband Gateway
with Integrated Video Bridge and HPNA
Features at a Glance
■Integrated VDSL2 modem, supporting
Bonded ADSL2+
Bonded VDSL2 (up to 17a profile)
■1 GE WAN port
■AutoWAN sensing™
■4 GE LAN ports
■Dual-band concurrent Wi-Fi interfaces:
IEEE802.11n 2.4GHz (2x2) with high power
IEEE802.11ac 5GHz (4x4)
■HomePNA™
■2 FXS ports for phone or fax
■1 USB 2.0 master port
■Non-service-aecting platform software upgrades
(dual bank memory)
■Extensive remote management
■IPv4 & IPv6 enabled
■Designed according to the latest ECO standards
Seamless Video over Next-Gen Wi-Fi
With its support of dual band concurrent Wi-Fi (IEEE802.11n 2.4GHz and
the next-generation IEEE802.11ac wireless standard for the 5GHz band),
the C2100T is a powerful and future-proof smart gateway enabling high-
speed wireless HD video streaming inside the home. Thanks to its integrated
wireless video bridge featuring a robust chipset and 4x4 antennas, it can
support multiple HD TV channels over the clean 5GHz radio. Furthermore,
its advanced architecture guarantees a very low packet error rate on the
wireless link, resulting in a 100% smooth and flicker-free wire-quality viewing
experience.
Simultaneously, it guarantees uninterrupted transmission of data services
over IEEE802.11n using the 2.4GHz band.
RoHS
COMPLIANT
Optimizing your WAN Bandwidth
In this bandwidth-hungry era of IPTV, real-time HD video streaming and
VoIP - to name but a few - operators need to stay competitive and keep
costs down, among others by taking advantage of existing facilities as much
as possible.
Our C2100T innovation helps you get the most out of your network by
letting you re-use existing copper wiring and giving higher coverage from
one DSLAM. Moreover, it is a powerful future-proof triple-play service
gateway allowing VDSL2 connectivity while providing Voice over IP
functions for residential users.
DRAFT
MediaAccess C2100T for CenturyLink
Wireless .11ac
Smart Ultra-Broadband Gateway
with Integrated Video Bridge and HPNA
IPv6 Enabled
With the approaching IPv4 address pool depletion, our products need to be
ready for IPv6. Technicolor is a frontrunner in the introduction of IPv6 on its
devices, with the C2100T being enabled for multiple IPv6 field scenarios.
Internet Protocol version 6 is the next generation of Internet technologies
aiming to eectively support the ever-expanding Internet usage and
functionality, and also to address security concerns that exist in an IPv4
environment.
Technicolor aims to introduce IPv6 as smoothly as possible in customer
networks. By providing in-depth knowledge of the networking stack, we
guide our customers in their transition from IPv4 to IPv6.
The Ultimate in Ultra Broadband
The accelerating growth of WAN and LAN trac is pushing operators
to look to ultra-high-speed network technologies to solve the bandwidth
crunch. VDSL2 combined with Gigabit Ethernet enables extremely high
bandwidth and guarantees superior quality in voice, data and video.
Some of the latest performance-enhancing technologies have been added
on top, to get the utmost out of existing infrastructures:
■Bonding: works by combining multiple wire pairs to increase available
capacity, or extend the copper network’s reach. It typically combines two
regular VDSL2 lines into a single, virtual “big pipe”.
■G.vector: eectively cancels the crosstalk noise inherently present in
VDSL2 bands. With vectoring, every line in a binder can operate at peak
performance, as if there were no other VDSL2 lines in that binder.
■G.inp (“Impulse Noise Protection”): makes sure that no errors occur on
the DSL connection, even under extreme conditions, so that high-quality
video transmission is guaranteed at all times. It is based on the principle
of retransmission.
Furthermore, the latest wireless technologies ensures robust in-home wireless
distribution which reduces wiring complexity and provides true mobility
without sacrificing Quality of Service (QoS) and Quality of Experience
(QoE) or transfer speeds.
HomePNA for Premium In-Home
Networking
The C2100T features a built-in HPNA 3.1 adapter that allows to distribute
high-quality data and video inside the home over existing coax wires. Hence,
it is ideal for IPTV deployments with minimal impact on subscribers’ homes:
set-top boxes can be directly connected to the gateway over the present
network infrastructure. Furthermore, the HPNA adapter enables HD
streaming speeds of up to 256 Mbps and an advanced QoS.
ECO
Technicolor is committed to oer its customers sustainable products
and implements a set of ECO features to reach the best possible
environmental performance. In addition to carefully selected plastics and
packaging to minimize the ecological footprint, the C2100T benefits from
a unique combination of hardware and software features that reduce power
consumption substantially.
Professional Services
To reinforce our extensive portfolio of digital home solutions, Technicolor has
a dedicated Professional Services team to make sure that every deployment
is a success, from initial provisioning and integration to operations, upgrades,
ongoing support and beyond.
Our wide array of services spans the entire customer project lifecycle,
encompassing:
■Expert consulting
■Seamless system integration
■Warranty on all our products
■Qualified technical support and maintenance
■Ecient repair, refurbishment and recycling
Easy to Use
Like all Technicolor modems and gateways, the C2100T is an easy to use,
easy to install gateway.
For convenience of the end user, the easy-to-access LEDs provide a clear
indication of start-up sequence, operational status, and connectivity status.
Multiple integrated web pages also allow direct access to the status and
settings, including privacy and security information.
Voice over IP
The C2100T oers VoIP functions for residential and business users. POTS
phone connectors are provided to accommodate regular phones and faxes.
Once the gateway is registered with a VoIP service, regular phone calls can
be conducted over the Internet with all the benefits of IP telephony.
Easy to Manage
The C2100T is compliant with the TR-069 data model through which the
device can be configured remotely by the operator without interrupting the
end user’s experience.
DRAFT
Technical Specifications
MediaAccess C2100T for CenturyLink
Wireless .11ac
Smart Ultra-Broadband Gateway
with Integrated Video Bridge and HPNA
Hardware Specifications
■Interfaces WAN 2 RJ-11 DSL line ports
1 Ethernet WAN 10/100/1000 Base-T port
■Interfaces LAN 4-port autosensing 10/100/1000 Base-T
auto-MDI/MDI-X Ethernet LAN switch
HPNA 3.1 interface
2 FXS POTS ports
1 USB 2.0 master port
IEEE802.11n 2.4GHz on-board
IEEE 802.11ac 5GHz on-board
■Interfaces other WPSbutton
Resetbutton
■Dimensions 255 x 154 x 35mm (10.0 x 6.0 x 1.3in.)
■AC Voltage 100 - 240VAC (switched mode power supply)
■Temperature 0° - 40°C (32° - 104°F)
■Humidity 20% to 80%
DSL Modem Specifications
■Supports multi mode standards
■ADSL compliance ITU-T G.992.1 Annex A (G.dmt)
ITU-T G.992.2 Annex A (G.lite)
ITU-T G.994.1 (G.hs)
Maximum rate: 8Mbps for downstream
and 1Mbps for upstream
■ADSL2 compliance ITU-T G.992.3 Annex A, L (G.dmt.bis)
ITU-T G.992.4 Annex A, L (G.lite.bis)
ITU-T G.998.4 (G.inp)
Maximum rate: 12Mbps for downstream
and 1Mbps for upstream
■ADSL2+ compliance ITU-T G.992.5 Annex A, M
ITU-T G.998.4 (G.inp)
ITU-T G.998.1 ATM Bonding
ITU-T G.998.2 Ethernet Bonding
Maximum rate: 24Mbps for downstream
and 3Mbps for upstream (per DSL line)
■VDSL2 compliance ITU G.993.2
SOS
SRA
INM
Up to 17aMHz profiles (on bonded interface)
ITU-T G.993.5 (G.vector)
ITU-T G.998.4 (G.inp)
ITU-T G.998.1 ATM Bonding
ITU-T G.998.2 Ethernet Bonding
Management
■User-friendly GUI via HTTP and HTTPS
■Web services API for remote access
(portal, management, diagnostics, applications, ...)
■Web-browsing intercept (install/diagnostics/captive portal)
■AutoWAN sensing™: automatic selection and configuration of WAN interfaces
■TR-069 CPE WAN Management Protocol
TR-098 Internet Gateway Device Management
TR-111 home network device management
TR-143 network throughput performance tests
and statistical monitoring
TR-104 voice service provisioning and configuration
■TR-064 LAN side configuration
■Zero-touch autoprovisioning
Wireless Specifications
■Full dual band concurrent Wi-Fi access points, Wi-Fi certified®
2.4GHz(2x2) IEEE802.11n AP
5.0GHz(4x4) IEEE802.11ac AP
with IEEE802.11ac compliant transmit
beamforming
■Wi-Fi 2.4 GHz power High Power, up to 23 dBm (200 mW EIRP)
■Wi-Fi Protected Setup (WPS™)
■Wi-Fi security levels WPA2™-Enterprise / WPA™-Enterprise
WPA2™-Personal / WPA™-Personal
WEP™
■Wi-Fi Multimedia (WMM®)
■Up to 4 BSSIDs (virtual AP) support per radio interface
■RX/TX switched diversity
■2x2 MIMO 2.4GHz Wi-Fi features
SGi
STBC
20/40MHz coexistence
■4x4 MIMO 5.0GHz Wi-Fi features
SGi
STBC
LDPC (FEC)
20/40/80MHz mode
■Dynamic rate switching for optimal wireless performance
■Manual/auto radio channel selection
Security
■Stateful Packet Inspection Firewall (SPIF)
■Customizable firewall security levels
■Intrusion detection and prevention
■DeMilitarized Zone (DMZ)
■Multilevel access policy
■Security and service segregation per SSID
Networking
■Symmetrical NAT with application helpers (ALGs)
■Game and application sharing NAT port maps
■DHCP conditional serving & relay, DNS server & relay
■IGMPv3 proxy (Fastleave)
■IGMP snooping (full routed)
■DHCP spoofing
■IEEE802.1q VLAN bridging, multiple bridge instances
■Multicast to unicast translation on Wi-Fi interfaces
IPv6 Networking
■IPv4 / IPv6 dual IP stack
■Supported models PPP(oE)(oA)
IPoE(oA)
■Transitioning 6rd/6to4/6in4
DS-Lite
■Stateful connection tracking / stateful inspection firewall
■DHCPv6 Stateful/stateless DHCPv6 client
Stateless DHCPv6 server
Relay
Prefix Delegation
■DNS v4/v6 Proxy
■ULA
■ICMPv6
■IPv6 Quality of Service
■MLDv1/v2
DRAFT
TECHNICOLOR WORLDWIDE HEADQUARTERS
1-5, rue Jeanne d’Arc
92130 Issy-les-Moulineaux, France
Tel: +33 (0)1 41 86 50 00 - Fax: +33 (0)1 41 86 58 59
www.technicolor.com
SALES CONTACT
For more information please get in touch with your usual
sales representative or use the following email:
EMEASalescontact@technicolor.com
APACSalescontact@technicolor.com
NAMSalescontact@technicolor.com
LATAMSalescontact@technicolor.com
© Copyright 2015 Technicolor. All rights reserved.
Photos and specifications are subject to change without
notice. All trade names referenced are service marks,
trademarks, or registered trademarks of their respective
companies.
DMS-DAT-20140221-0000 vA.0.2
Technical Specifications
MediaAccess C2100T for CenturyLink
Wireless .11ac
Smart Ultra-Broadband Gateway
with Integrated Video Bridge and HPNA
Quality of Service
■ATM QoS UBR, VBR-nrt, VBR-rt, CBRshaping,
queuing and scheduling
CLPtagging
■IP QoS Flexible classification (ALG aided)
IPrate limiting (two-rate remarking/dropping)
DSCP (re)marking
TCPACK optimization
Dynamic link fragmentation
Per service class connection/resource reservation
■Ethernet QoS Priority or C-VLAN/S-VLAN tagging
Switch port queuing and scheduling
■Wireless QoS WMM (BE, BK, VI, VO access categories)
queuing and scheduling
Voice over IP Specifications
■Voice technologies Voice over IP (VoIP)
■Voice signalling SIP
■Voice codecs G.711
Wideband G.722.2
T.38
■Echo cancellation G.168 compliant
■Comfort Noise Generator (CNG)
■Voice Activity Detection (VAD)
■Flexible telephone number per FXS handset, including common numbers
■Supplementary and advanced services
Caller ID
Call waiting (on call basis)
Call forwarding (no answer/busy/unconditional)
Call transferring
Call hold, call return
3-way conference
Message Waiting Indicator (MWI)
■Interoperable with main market softswitches
Content of the Box
■MediaAccess C2100T for CenturyLink
■DSL cable(s) (RJ-11)
■Ethernet cable (RJ-45)
■Power supply unit
■Quick Setup leaflet(s) (optional)
■Safety Instructions & Regulatory Information booklet (optional)
■Filter(s) or splitter(s) (optional)
C2100T front panel C2100T back panel
DRAFT

Navigation menu
