VALEO Telematik und Akustik CSM3-MM-US Car Sharing Main module User Manual Statements

Peiker acustic GmbH & Co. KG Car Sharing Main module Statements

Contents

User Manual

page 1
peiker acustic GmbH & Co. KG, Max-Planck-Straße 28-32, D-61381 Friedrichsdorf, Amtsgericht Bad Homburg HRA 1897
phG: peiker Verwaltungs GmbH, Amtsgericht Bad Homburg HRB 1369
Vorsitzender der Geschäftsführung: Andreas Peiker, Geschäftsführer: Reinhard Kromer-von Baerle, Mathias Köhler
Vorsitzender des Aufsichtsrates: Dr. Helmut Rothenberger Ein Unternehmen der peiker Firmengruppe
Statement for User Manual
CSM 3.0
Car Sharing Module 3.0
Rev. 1.1
Release
PEIKER acustic Confidential and Proprietary
Name of model:
Description
Internal peiker product ID
BMW CSM 3.0 ECE
main unit, EU variant
2515-057-001-51
BMW CSM 3.0 US
main unit, US variant
2515-057-101-51
BMW CSM 3.0 AE
external unit
2708-041-001-00
Trademark
peiker acustic GmbH & Co. KG
Brand
BMW
Status:
Release
Revision:
1.1
Date:
16.01.2015
page 2
The copyright protection of this original document remains with Peiker acustic GmbH & Co. KG. Without prior written authorization it shall not be copied or otherwise
reproduced by a third party and shall not be disclosed to competitors. The infringement shall be strictly enforced by applicable civil and criminal legal proceedings.
1 Change documentation
Date
Revision
Name
Changes / Comment
11.11.2014
Rev 1.0
M. Fleckenstein
Initial version
16.01.2015
Rev 1.1
M. Fleckenstein
Updated 4.2, removed reference to 15.105(a)
page 3
The copyright protection of this original document remains with Peiker acustic GmbH & Co. KG. Without prior written authorization it shall not be copied or otherwise
reproduced by a third party and shall not be disclosed to competitors. The infringement shall be strictly enforced by applicable civil and criminal legal proceedings.
1 Change documentation ..................................................................................................... 2
2 Introduction ..................................................................................................................... 4
2.1. Scope ............................................................................................................................... 4
2.1.1. Purpose of the document ............................................................................................. 4
2.1.2. General information ..................................................................................................... 4
2.1.3. Contact information ..................................................................................................... 4
3 Antenna installation ......................................................................................................... 5
4 Warning Statements ......................................................................................................... 6
4.1. Europe .............................................................................................................................. 6
4.2. US /Canada ....................................................................................................................... 6
page 4
The copyright protection of this original document remains with Peiker acustic GmbH & Co. KG. Without prior written authorization it shall not be copied or otherwise
reproduced by a third party and shall not be disclosed to competitors. The infringement shall be strictly enforced by applicable civil and criminal legal proceedings.
2 Introduction
2.1. Scope
2.1.1. Purpose of the document
The Car Sharing Module (CSM) 3.0 is manufactured by peiker acustic GmbH & Co. KG (grantee) and sold
as an OEM product.
According to the US Code of Federal Regulations (47 CFR 2.909, 2.927, 2.931, 2.1033, 15.15(b) etc.),
the grantee must ensure the end-user has the applicable and appropriate operating instructions for the
device. In the case of this product the grantee must notify the OEM to notify the end-user.
peiker acustic GmbH & Co. KG will supply this document to the reseller or distributor to inform him what
must be included in the end user’s manual for the commercial product and which installations guidelines
for the antenna are applicable.
2.1.2. General information
The CSM is assembled in the car after production by specially trained engineers. There are no other
distribution channels except spare part replacement within car service. Please be advised that this
product will need special trained professionals in configuring and installing the product. The product will
be distributed through controlled distribution channel which has special trained professionals to install
this product and will not be sold directly to the general public through retail stores.
The software application using the installed CSM module is up to the car sharing provider. It is also the
responsibility of the car sharing provider to create an end user manual for the installed application.
2.1.3. Contact information
peiker acustic GmbH & Co. KG
Max-Planck-Strasse 32
D-61381 Friedrichsdorf
Germany
http://www.peiker.de
info@peiker.de
page 5
The copyright protection of this original document remains with Peiker acustic GmbH & Co. KG. Without prior written authorization it shall not be copied or otherwise
reproduced by a third party and shall not be disclosed to competitors. The infringement shall be strictly enforced by applicable civil and criminal legal proceedings.
3 Antenna installation
To comply with the RF exposure requirements for 2G/3G cellular radio of the FCC following requirements
have to be fulfilled:
The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20
cm from all persons and must not be co-located or operated in conjunction with any antenna or
transmitter, except in accordance with FCC multi-transmitter product procedures. This device is to be
used in mobile or fixed applications only.
For mobile and fixed operating configurations the antenna gain, including cable loss, must not exceed
4.91 dBi
at 850 MHz & 900 MHz
9.58 dBi
at 1800 MHz to 2100 MH
for satisfying RF exposure compliance.
It must be ensured by the OEM that the end user has no manual or instructions to remove or install the
RF unit of the device.
page 6
The copyright protection of this original document remains with Peiker acustic GmbH & Co. KG. Without prior written authorization it shall not be copied or otherwise
reproduced by a third party and shall not be disclosed to competitors. The infringement shall be strictly enforced by applicable civil and criminal legal proceedings.
4 Warning Statements
The following certification markings and hints should be printed in the end user’s manual:
4.1. Europe
This device must be supplied by a limited power source according to EN 60950-1. The clearance and
protected creepage distances required by the end product must be withheld when the module is
installed. The cooling of the end product shall not negatively be influenced by the installation of the
module.
4.2. US /Canada
This device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS
standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts
de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
Modifications
The FCC requires the user to be notified that any changes or modifications made to this device that are
not expressly approved by peiker acustic GmbH & Co. KG could void the user's authority to operate the
equipment.
