Wavetrend Technologies TGA-A Active Duo RFID Tag TGA-A User Manual TGA A 1 5 Datasheetx

Wavetrend Technologies Limited Active Duo RFID Tag TGA-A TGA A 1 5 Datasheetx

Contents

Datasheet

Europe, Australasia and Middle East –
Corporate Office
+44 (0)20 8334 8400
KEY FEATURES
Tag can be configured to
hold standard
26-bit Wiegand numbering
Configurable settings include:
Site/vendor ID
Tag ID
Tag Age Counter
Various transmission re
petition intervals
Tamper Alarm
Collision avoidance algorithm
Ultra low power consumption
The TGA-
A ActivDuo Asset Tag is a long life active tag that continuously transmits a unique ID number, which can be detected
by Wavetrend
®
reader. An internal battery powers the tag and Wavetrend’s patented ultra
longer battery life at higher rates of transmission than any other brand of active RFID tag. Various preset transmission
intervals are available.
The TGA-A tag is available in both L-
Series and L
© 2011 Wavetrend Europe
Limited | All Rights Reserved | All specifications are subject to change without notice.
Corporate Office
USA, Canada and South America
+1 (703) 539 8502 +27 (0)11 792
BUSINESS BENEFITS
hold standard
Allows tag to be used with existing access control
systems separately or together
with the active RFID
system.
petition intervals
A unique code that can be allocated by Wavetrend to
each customer on request.
Readers can be set to
ignore tags with incorrect site codes.
4.2 billion tag ID’s are available per site code.
The Age Counter allows for advance notification of
the end of battery life
and for the unique identification
for each transmission made by the tag.
Different status transmission intervals allow tags to be
used in diverse applications while offering the best
battery life spans in the market.
Provides instant notification of un
authorized attempts
to remove a tag from an asset.
Reduces loss of data caused by simultaneous
transmissions from multiple tags.
Typical lifespan of 5
years when transmitting at the
standard or greater interval.
Beacon tag transmitting a unique ID & data at pre
Ultra long-range transmitter
Anti-tamper alert option
Motion sensor option
Ruggedised IP68 Industrial Housing
A ActivDuo Asset Tag is a long life active tag that continuously transmits a unique ID number, which can be detected
reader. An internal battery powers the tag and Wavetrend’s patented ultra
low power use design ensures
longer battery life at higher rates of transmission than any other brand of active RFID tag. Various preset transmission
Series and L
-Series plus formats
Limited | All Rights Reserved | All specifications are subject to change without notice.
South Africa
+1 (703) 539 8502 +27 (0)11 792
6066
Asset
Tag
TGA-
A
Personnel
IP68 Waterproof
Allows tag to be used with existing access control
with the active RFID
A unique code that can be allocated by Wavetrend to
Readers can be set to
4.2 billion tag ID’s are available per site code.
The Age Counter allows for advance notification of
and for the unique identification
Different status transmission intervals allow tags to be
used in diverse applications while offering the best
authorized attempts
years when transmitting at the
Best Usage
Guide
Beacon tag transmitting a unique ID & data at pre
-set intervals
A ActivDuo Asset Tag is a long life active tag that continuously transmits a unique ID number, which can be detected
low power use design ensures
longer battery life at higher rates of transmission than any other brand of active RFID tag. Various preset transmission
Europe, Australasia and Middle East –
Corporate Office
+44 (0)20 8334 8400
The TGA-A Asset Tag has a unique omni
directional antenna design allowing the tag
to be read from all directions and to be
deployed equally well on metallic and non
metallic assets.
Optimum read range is achieved on metal
with a 10% reduction on Non metals.
The tag is sealed to IP68 providing the
highest level of water ingress protection.
Model Range
The tags can be ordered using the part
numbers listed below:
L-Series
TG
A
-
A
Air Interface Protocols
L-Series’ and L-Series+ refers to a
proprietary communication protocol used
between Wavetrend
®
tags and readers.
L-Series tags provide ultra long read range
and are ideal for use in low tag density (< 30
tags per reader) operations such as
personnel tracking, small asset
management applications and access
control systems.
L-Series+ offers a wide range of extra
features including:
Increased levels of security,
Encrypted air
interface and secure concealed site code
options
Multiple classes,
allowing the user to
select shorter messaging packets for high
speed or high density application
User definable data fields,
allowing up to
200 characters of user data to be stored on
the tag
Ordering & Further Information
For more information on purchasing
the TGA-A Tag please email
Wavetrend’s Sales team:
sales@wavetrend.net
For more information on Wavetrend
®
visit our website.
Typical Applications
© 2011 Wavetrend Europe
Limited | All Rights Reserved | All specifications are subject to change without notice.
Corporate Office
USA, Canada and South America
+1 (703) 539 8502 +27 (0)11 792
Specifications
Smart telemetry tag,
that alert and log the
user if out of bounds conditions in either
temperature or humidity occur
Greater selection of tag beacon rates
offering greater tag of
the reduction in
spurious transmissions.
L-Series+ tags can only be read by L-Series+
readers. L-Series readers can read both L-Series
and L-Series+ tags.
FCC Statement of Conformity
Wavetrend , TGA-A Active Duo ,
FCC ID: 06XTGA-A
This device complies with Part 15 of the FCC ru
les subject to the following three
1) This device may not cause harmful interference.
2)
This device must accept all interference received, including interference that may cause
undesired operation.
3)
This device is for commercial use only and intended for use in a confined area with an
appropriate system receiver
Changes
or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
Environmental
Operating temperature
Storage temperature
Humidity
: -30°C to +60°C
: -40°C to +70°C
: 5% to 90% (non
-
condensing)
Physical
Size
Weight
Colour
Material
:68 x 36 x 16mm
:25g
:Grey
:Nylon
Radio Frequency
Transmit Frequency
Range
: 433.92 MHz
: 1 to 100+ meters (actual range is determined by the
choice of reader & antenna used to detect the tag and
the environment it is used in)
Electrical
Power
:
Internally powered by lithium battery
Accessories
TA-TGA
TA-TGA-AT
(All sold in packs of 10)
: Tag attachment kit
: Tamper alerting tag attachment kit
Limited | All Rights Reserved | All specifications are subject to change without notice.
South Africa
+1 (703) 539 8502 +27 (0)11 792
6066
Asset
Tag
TGA-
A
* (from front page) Battery life calculations
assume operation at room temperature with
the default status transmission interval of 1.5
seconds, without the anti-tamper circuit
armed and without a motion sensor fitted.
IMPORTANT NOTICE: Wavetrend ACTIV
tags do not comply with the FCC Part 15
rules or hold IC approval, so are not
available for sale into the United States of
America or Canada.
les subject to the following three
conditions:
This device must accept all interference received, including interference that may cause
This device is for commercial use only and intended for use in a confined area with an
or modifications not expressly approved by the party responsible for compliance could
condensing)
: 1 to 100+ meters (actual range is determined by the
choice of reader & antenna used to detect the tag and
the environment it is used in)
Internally powered by lithium battery
(All sold in packs of 10)
: Tamper alerting tag attachment kit
