16E09-101

Superior Temperature Control and Accuracy for Both

Refrigeration and Heating Applications...and It’s Universal, Too!

Features

Multiple Input Voltages

(24/120/208/240 Volts)

No Common Wire Required (Electrical load

must be greater than 2.5 amps and

uninterrupted)

Optional Multiple Sensor (4) Averaging

Electronic Temperature Accuracy

Alarm Output (with selectable delay – up to

99 minutes)

Adjustable Anti-Short Cycle Delay

Setpoint Locking Function

Applications

Convenience Store Freezer Control

Reach-In Coolers

Supermarket Display Cases (meat/produce)

Boiler Control

Restaurant/Convenience Store

Walk-In Coolers

Condenser Fan Cycling

Pump Control

Space and Return-Air Temperature

Includes

NTC Sensor with 7.5-Ft. Leads

Cross-Reference Replacement Guide

Universal

• Refrigeration or Heating Applications

• Alarm Output with Selectable Delay

Prevents false alarms

• No Common Wire Required*

Saves 30-60 minutes installation time

when upgrading a mechanical control

*Electrical load must be greater than 2.5 amps and uninterrupted

Electronic

Temperature Control

Multiple Input Voltage

(24/120/208/240 Volts AC)

Save

30-60 Minutes

Installation

Time

• 16E09-101 replaces most mechanical and electronic single stage controls using an SPDT output relay

• Offers the widest multiple voltage operating range: 24/120/208/240 VAC for truly universal replacement

• Does not require a common wire when electrical load is greater than 2.5 amps — saving 30 to 60 minutes

installation time when upgrading a mechanical control

• Offers a wider than industry standard setpoint temperature range (-40°F to 220°F) and adjustable differential settings

• Reduces inventory — 16E09-101 replaces most competitive mechanical and electronic refrigeration controls

Size: 8.5" x 11"

Job #: WRDG_130516

File Name:

130516_16E09_101_ETempCntrl_SS.ai

Printing & Finishing: 4/C Offset

Colors: CMYK DIE

Printout Size

100%

Updates: jd07.15.10, jd07.19.10,

jd07.28.10, BBpff8.13.10

This printout is for indicating

color breaks only.

Do not use for color matching.

Do not measure for accuracy.

Revision: 04

Time: 10a

*Note: Alarm connection contacts close when sensor fails or temperature range is exceeded.

NTC - Negative Temperature Coefficient

PTC - Positive Temperature Coefficient

Note: Sensor type (PTC or NTC) must meet temperature specifications. If averaging, 4 sensors of the same type must be used.

Line Voltage Application

(Non-Power Stealing)

Binary Input

(Gold-Plated

Contacts)

NTC*

Temperature

Sensor

PTC*

Temperature

Sensor

120 VAC

Hot

Neutral

L1

L2

208/240

VAC

Voltage Input

Load

SW2

PTC

BIN

GND

ALARM

NTC

PS

NC

NEUT

LINE

LOAD

24 VAC

TH TR

NON

PS

Alarm Output

For optional connection to

customer alarm equipment

24 VAC

TH - Thermostat Hot

TR - Thermostat Return

Line Voltage Application

(Power Stealing)

VAC Applications

(Non-Power Stealing)

Typical Wiring

Binary Input

(Gold-Plated

Contacts)

NTC*

Temperature

Sensor

PTC*

Temperature

Sensor

120 VAC

Hot

Neutral

L1

L2

208/240

VAC

Voltage Input

Load

Alarm Output

For optional connection to

customer alarm equipment

24 VAC

TH - Thermostat Hot

TR - Thermostat Return

SW2

PTC

BIN

GND

ALARM

NTC

PS

NC

NEUT

LINE

LOAD

24 VAC

TH TR

NON

PS

Binary Input

(Gold-Plated

Contacts)

NTC*

Temperature

Sensor

PTC*

Temperature

Sensor

Load

Alarm Output

For optional connection to

customer alarm equipment

24 VAC

TH - Thermostat Hot

TR - Thermostat Return

SW2

PTC

BIN

GND

ALARM

NTC

PS

NC

NEUT

LINE

LOAD

24 VAC

TH TR

NON

PS

Note: Do not use

Output Relay to control

Line Voltage when

using 24 VAC Power

24 VAC

Class 2

Transformer

Applied voltage: 120 VAC 208 VAC 240 VAC

Full load amps: 16 Amps 9.2 Amps 8 Amps

Locked rotor amps: 96 Amps 55.2 Amps 48 Amps

Non-inductive amps: 16 Amps 16 Amps 16 Amps

Horsepower: 1 hp 1 hp 1 hp

24 VAC: 100 VA, 30 VAC Max. (Class 2)

Pilot duty: 125 VA, 24 to 240 VAC

Minimum load: 1 Amp @ 24 VAC

Load Relay Electrical Ratings

N.C. and Load Contacts (Maximum Load Current)

16E09-101* Replaces the Following Models

Danfoss

UT72

Honeywell

T4031A1073

T4031C1004

T4031C1012

T6031A1029

T6054A1005

T6054A1054

T675A1045

T675A1136

T675A1425

T675A1441

T675A1458

T675A1508

T675A1516

T675A1524

T675A1540

T675A1565

T675A1706

T675A1722

T675A1771

T675A1854

T675F1032

T678C1005

T7079A1004

T7079A1012

T7079A1046

T7079A1053

Ranco ETC Commercial

Temperature Controls

060-100†

060-101†

060-109†

060-200†

ETC-111000

ETC-112000

Johnson Controls

A19ABA-40C†

A19ABC-24C†

A19BAB-3C†

A19BAC-1C†

A19BAF-1C

A19BBC-2C†

A319ABC-12-01

A319ABC-24-01

A320ABC-1C

A419ABC-1C

White-Rodgers

1609-33†

1609-100†

1609-101†

1609-102†

1609-103†

1609-104†

1609-105†

1687-9†

201-8†

201-20†

230-22†

241-2†

2A37-1†

*16E09-101 is not rated as a limit control †16E09-101 is a replacement on non-inductive applications up to 16 amps

N.O. contacts: 1 Amp (5 to 24 volts AC or DC)

Alarm Relay Electrical Ratings

16E09-101

WR-4975-2

16E09-101

Universal

24/120/208/240 Volts

Universal Replacement

Electronic Refrigeration

or Heating Control

Specifications

Setpoint Range:

-40° to 220°F (-40° to 104°C)

Differential Range: 1° to 30°F (1° to 30°C)

Supply Voltage:

24/120/208/240 VAC, 60Hz

Sensor: Negative Temperature Coefficient

with 7.5-Ft. Leads (Maximum length for

remote temperature sensing – 400 feet)

Control Enclosure Ambient Temperatures

Operating: -29° to 140°F (-34° to 60°C)

Storage: -40° to 185°F (-40° to 85°C)

Control Material

Cover and Case: NEMA 1 high-impact plastic

Thermoplastic: Non-flammable UL94V0

Switch Action: SPDT

Ambient Humidity: 0 to 95% RH, non-condensing

Dimensions

6 3/4" L x 3" W x 2 9/16" D

16E09-101 Optional Accessories/Service Items

Immersion Well: F89-0286

Replacement 7.5-Ft. NTC Remote Sensor: F136-0114

Well Heat Transfer Compound: F145-0650

For Additional Information

Visit www.white-rodgers.com

• Alarm Output with Selectable Delay

Prevents false alarms

• No Common Wire Required

(Electrical load must be greater than 2.5 amps and uninterrupted)

Saves 30-60 minutes installation time when upgrading a mechanical control
