OUTDOOR HEATING
2021

2 | Outdoor Heating Range 2021

CONTENTS

Stellar Black Gas Fire Pit

4

Stellar Black Pyramid Flame Heater

6

Stellar Black Deluxe Area Heater

8

Stainless Steel Deluxe Area Heater

10

Stellar Black Deluxe Patio Heater

12

Solaris Freestanding Ceramic Radiant Heater

14

Solaris Wall Mount Ceramic Radiant Heaters

16

Fletcher Cast Iron Fire Bowl

18

Furnace Cast Iron Chimenea

19

Tuscan 72cm Cast Iron Fire Pit

20

Humidor Cast Iron Chimenea & BBQ

22

ALL OUR PRODUCTS COME WITH A 12 MONTH DOMESTIC WARRANTY PERIOD AND WE HAVE A DEDICATED CUSTOMER SERVICE TEAM TO ANSWER ALL YOUR QUESTIONS.
Gasmate & Charmate | 3

The enchanting flame of this stylish, Decorative Gas Fire Pit provides a gentle warmth and complements any outdoor entertaining area.
4 | Outdoor Heating Range 2021

STELLAR BLACK GAS FIRE PIT
GF2001BLK Features include:
Flame Failure System This safety feature instantly ceases gas supply if the flame goes out.
Approximate Run Time Runs for approximately 17hrs on a full 9kg LPG cylinder.
For Outdoor Use Only Designed and approved for outdoor use only - ideal for alfresco areas and patios.
Flame Guard Glass flame guard provides added protection against naked flame.
Gas Connection Type Includes hose & POL regulator.
Easy Assembly
12 Month Domestic Warranty 3 Month Commercial Warranty
Gas Certified to Australian Standards

Model Number: Gas Consumption: Dimensions (mm): Gas Type: Ignition Type: Burner Type: Minimum Clearance: To combustible materials - with heat deflector fitted Weight:

GF2001BLK 29 MJ/h 500 W x 500 D x 1120 H Propane Electronic Piezo Stainless Steel Side: 500mm Above: 1000mm
18kg

Area Heater Cover
GMAHC 400 x 500 x 600mm Black polyester with PVC lining plus rope and ball anchor for secure fit. ALL ACCESSORIES ARE SOLD SEPARATELY.
Gasmate & Charmate | 5

Decorative Flame Heaters

Entertain in style with the gentle, glowing warmth of the sophisticated Decorative Flame Heater.
6 | Outdoor Heating Range 2021

STELLAR BLACK PYRAMID FLAME HEATER
FH200ODS Features include:
Oxygen Depletion System ODS safety device automatically switches off the heater when low oxygen levels are detected.
Safety Tip-Over Switch This safety feature instantly ceases gas supply if the heater is knocked over.
Flame Failure System This safety feature instantly ceases gas supply if the flame goes out.
Approximate Run Time Runs for approximately 14hrs on a full 9kg LPG cylinder.
For Outdoor Use Only Designed and approved for outdoor use only - ideal for alfresco areas and patios.
Flame Guard Grill flame guard provides added protection against naked flame.
Gas Connection Type Includes hose & POL regulator.
Easy Assembly
12 Month Domestic Warranty 3 Month Commercial Warranty
Gas Certified to Australian Standards

Model Number: Gas Consumption: Dimensions (mm): Gas Type: Ignition Type: Burner Type: Approx. Heat Coverage: Minimum Clearance: To combustible materials - with heat deflector fitted Weight:

FH200ODS 33 MJ/h 500 W x 500 D x 1930 H Propane Electronic Piezo Ceramic 10m2 Side: 500mm Above: 500mm
22 kg

Gasmate & Charmate | 7

Decorative Flame Heaters

STELLAR BLACK DELUXE AREA HEATER
AH2066 Features include:
Oxygen Depletion System ODS safety device automatically switches off the heater when low oxygen levels are detected.
Safety Tip-Over Switch This safety feature instantly ceases gas supply if the heater is knocked over.
Flame Failure System This safety feature instantly ceases gas supply if the flame goes out.
Approximate Run Time Runs for approximately 9hrs on a full 9kg LPG cylinder.
For Outdoor Use Only Designed and approved for outdoor use only ideal for alfresco areas and patios.
Flame Guard Grill flame guard provides added protection against naked flame.
Gas Connection Type Includes hose & POL regulator.
Easy Assembly
12 Month Domestic Warranty 3 Month Commercial Warranty
Gas Certified to Australian Standards

Model Number: Gas Consumption: Dimensions (mm): Gas Type: Ignition Type: Burner Type: Approx. Heat Coverage: Minimum Clearance: To combustible materials - with heat deflector fitted Weight:
8 | Outdoor Heating Range 2021

AH2066 40 MJ/h 500 W x 500 D x 1350 H Propane Rotary Direct Stainless Steel 15m2 Side: 500mm Above: 1000mm
17kg

Area Heater Cover
GMAHC 400 x 500 x 600mm Black polyester with PVC lining plus rope and ball anchor for secure fit. ALL ACCESSORIES ARE SOLD SEPARATELY.

Freestanding Gas Heaters

A great heating alternative in areas where ceiling clearances may prohibit the use of a mounted radiant heater.
Gasmate & Charmate | 9

Ideal for commercial use, this Deluxe Area Heater is equipped with the following features;
� 1mm emitter for greater durability and heat performance
� Stainless steel body for greater resistance to external elements and a stylish, clean finish that is easy to maintain when properly cared for
� Electronic piezo ignition for easy start-up, with adjustable heat output
� 12 month commercial warranty
10 | Outdoor Heating Range 2021

STAINLESS STEEL DELUXE AREA HEATER
AH2069CS Features include:
Oxygen Depletion System ODS safety device automatically switches off the heater when low oxygen levels are detected
Safety Tip-Over Switch This safety feature instantly ceases gas supply if the heater is knocked over.
Flame Failure System This safety feature instantly ceases gas supply if the flame goes out.
Approximate Run Time Runs for approximately 9hrs on a full 9kg LPG cylinder.
For Outdoor Use Only Designed and approved for outdoor use only - ideal for alfresco areas and patios.
Flame Guard Grill flame guard provides added protection against naked flame.
Gas Connection Type Includes hose & POL regulator.
Easy Assembly
24 Month Domestic Warranty 12 Month Commercial Warranty
Gas Certified to Australian Standards

Model Number: Gas Consumption: Dimensions (mm): Gas Type: Ignition Type: Burner Type: Approx. Heat Coverage: Minimum Clearance: To combustible materials - with heat deflector fitted Weight:

AH2069CS 40 MJ/h 500 W x 500 D x 1350 H Propane Electronic Piezo Stainless Steel 15m2 Side: 500mm Above: 1000mm
17kg

Area Heater Cover
GMAHC 400 x 500 x 600mm Black polyester with PVC lining plus rope and ball anchor for secure fit. ALL ACCESSORIES ARE SOLD SEPARATELY.
Gasmate & Charmate | 11

Freestanding Gas Heaters

STELLAR BLACK DELUXE PATIO HEATER
PH7056 Features include:
Safety Tip-Over Switch This safety feature instantly ceases gas supply if the heater is knocked over.
Flame Failure System This safety feature instantly ceases gas supply if the flame goes out.
Approximate Run Time Runs for approximately 9hrs on a full 9kg LPG cylinder.
For Outdoor Use Only Designed and approved for outdoor use only - ideal for alfresco areas and patios.
Gas Connection Type Includes hose & POL regulator.
Easy Assembly
12 Month Domestic Warranty 3 Month Commercial Warranty
Gas Certified to Australian Standards

Model Number: Gas Consumption: Dimensions (mm): Gas Type: Ignition Type: Burner Type: Approx. Heat Coverage: Minimum Clearance: To combustible materials - with heat deflector fitted Weight:

PH7056 40 MJ/h 820 W x 820 D x 2130 H Propane Rotary Direct Stainless Steel 28m2 Side: 500mm Above: 500mm
17kg

12 | Outdoor Heating Range 2021

Patio Heater Cover
CPHD 940 x 240 x 650mm Deluxe vinyl with felt lining plus zipper and two rods for easy fitting, secure with hook and loop fastening ALL ACCESSORIES ARE SOLD SEPARATELY.

Freestanding Gas Heaters

Providing a strong radiant heat with easy-to-use features, the Deluxe Patio Heater is the perfect addition to any outdoor entertainment area, especially in the colder months.
Gasmate & Charmate | 13

The Solaris Ceramic Freestanding LPG Heater combines a stylish, modern look with strong, radiant heat output for entertaining all year round.
14 | Outdoor Heating Range 2021

SOLARIS CERAMIC RADIANT HEATER & STAND
RH210 Features include:
For Outdoor Use Only Designed and approved for outdoor use only - ideal for alfresco areas and patios.
Gas Connection Type Includes hose & POL regulator.
Easy Assembly
12 Month Domestic Warranty 3 Month Commercial Warranty
Gas Certified to Australian Standards

Ceramic Radiant Heaters

Model Number: Gas Consumption: Dimensions (mm): Gas Type: Ignition Type: Burner Type: Approx. Heat Coverage: Minimum Clearance: To combustible materials - with heat deflector fitted Weight:

RH210
35 MJ/h
684 W x 655 D x 2075 H
Propane
Pull Cord
5 x Ceramic Tiles
20m2
Side: 1000mm Above: 400mm Below: 2000mm
Heater: 14kg Stand: 31kg Total: 45kg

Gasmate & Charmate | 15

Gasmate Ceramic Radiant Heaters emit strong, comfortable directional warmth so you can enjoy the outdoors all year round.
16 | Outdoor Heating Range 2021

SOLARIS CERAMIC RADIANT HEATER
RH205
Features include: For Outdoor Use Only Designed and approved for outdoor use only - ideal for alfresco areas and patios.
Gas Connection Type Includes natural gas regulator.
Assembly Wall mount bracket included. Requires professional installation by a qualified trades-person.
12 Month Domestic Warranty 3 Month Commercial Warranty
Gas Certified to Australian Standards

SOLARIS DELUXE CERAMIC RADIANT HEATER

RH200

Minimum Clearance

Heating Coverage

CEILING

400mm

409mm

4m

1m 2m

FLOOR

5m

Ceramic Radiant Heaters

Model Number: Gas Consumption: Dimensions (mm): Gas Type: Ignition Type: Burner Type: Approx. Heat Coverage: Minimum Clearance: To combustible materials - with heat deflector fitted Weight:

RH205 35 MJ/h 684 W x 494 D x 409 H Natural Gas Only Pull Cord 5 x Ceramic Tiles 20m2 Side: 1000mm Above: 400mm Below: 2000mm 14kg

RH200 35 MJ/h 684 W x 494 D x 409 H Natural Gas Only Electric Wall Switch 5 x Ceramic Tiles 20m2 Side: 1000mm Above: 400mm Below: 2000mm 15kg

Gasmate & Charmate | 17

FLETCHER CAST IRON FIRE BOWL
CM140-036
Features include: � Large, durable cast iron bowl � Robust, modern design to suit any outdoor area � Burns wood or charcoal � Enjoy the crackle and glow of a natural wood fire

Model Number: Finish: Dimensions (mm): Weight:

CM140-036 Cast Iron 900 W x 900 D x 270mm H 16kg

18 | Outdoor Heating Range 2021

FURNACE CAST IRON CHIMENEA
CM140-051
Features include: � Hard-wearing cast iron with antique finish � Chimney funnels smoke away and allows for a slower burn � Removable mesh doors offer protection from embers and sparks � Create an inviting warm atmosphere in your backyard

Model Number: Finish: Dimensions (mm): Weight:

CM140-051 Cast Iron 540 W x 540 D x 1120 H 30kg

Solid Fuel Heaters

Gasmate & Charmate | 19

Huddle around the natural warmth of the Charmate Tuscan Fire Pit and enjoy the ambience of natural flames.
20 | Outdoor Heating Range 2021

TUSCAN 72CM CAST IRON FIRE PIT
CMFP72
Features include: Enjoy the Ambience Relax with the crackle and glow of a natural wood fire Deep Bowl Durable, deep cast iron bowl for a generous fire
Cast Iron Construction Ensures effective heat distribution and unparalleled durablity
Sturdy & Stable Square cast iron base for stability
Burns Wood
Burns Charcoal

Solid Fuel Heaters

Model Number: Finish: Dimensions (mm): Weight:

CMFP72 Cast Iron 720 D x 290 H 22kg

Gasmate & Charmate | 21

Easily transform the Charmate Humidor from Chimenea to Firepit to BBQ by adding or removing the cast iron grill and tabletop and flipping the top over.
22 | Outdoor Heating Range 2021

HUMIDOR CAST IRON CHIMENEA & BBQ
CM140-093

Features include:

CHIMENEA FIREPIT BBQ

Use as Chimenea, Firepit or BBQ By adding or removing the cast iron grill and tabletop and flipping the top over
Cast Iron Construction Constructed in heavy-duty cast iron for durability and performance

45cm Cast Iron Grill Cook over wood or charcoal on the 45cm cast iron grill

Bamboo Tabletop Adds functionality and extra preparation space

Enjoy the Ambience Relax with the crackle and glow of a natural wood fire
Easy Clean Up With the removable fuel grate and ash guard

Burns Wood

Burns Charcoal

Model Number: Finish: Grill: Tabletop: Dimensions (mm): Weight:

CM140-093 Cast Iron Cast Iron Bamboo 500 D x 960 H 58kg

Gasmate & Charmate | 23

Solid Fuel Heaters

Customer Service
1300 174 876
Monday to Friday 8am - 5pm AEST
www.gasmate.com.au
Follow us on Facebook and Instagram @gasmate_aus

Available From:
All images are for reference only. Due to product development, product and images may differ. Gasmate� and Charmate� are registered trademarks of Sitro Group Australia Pty. Ltd. www.gasmate.com.au www.charmate.com.au
04268 02/21
