WinCC RT Professinal V16 Architectures
File info: application/pdf · 54 pages · 2.60MB
WinCC RT Professinal V16 Architectures
• Manual input values • Reporting with Microsoft Excel • Automatic report generation • Add-in for Microsoft Excel 2007, 2010, 2013, 2016 • Access to all process value and summarization archives • Access to calculated va…
Dec 20, 2019 · • Manual input values • Reporting with Microsoft Excel • Automatic report generation • Add-in for Microsoft Excel 2007, 2010, 2013, 2016 • Access to all process value and summarization archives • Access t…
WinCC RT Professinal V16 Architectures - Digital Asset ...
... implementation. WinCC RT Professional V16. Basic functionality. Page 3. 2/3/ 2020 ... Manual input values. • Reporting with Microsoft Excel.
Extracted Text
WinCC RT Professional V16 Architectures The SCADA system inside TIA Portal � Efficiency and transparency for your plant Unrestricted � Siemens 2019 Unrestricted � Siemens 2019 siemens.com/wincc WinCC RT Professional V16 architectures Legend � WinCC Runtime Professional V16 Base Packages = Base Package � SIMATIC Information Server 2014 SP3 upd4 = IS2014 � SIMATIC Process Historian 2014 SP3 upd4 = PH2014 Unrestricted � Siemens 2019 Page 2 2/3/2020 WinCC RT Professional V16 Basic functionality Basic functionality Description WinCC / OPC-Server � The WinCC OPC servers provide customer-specific OPC clients with data from the WinCC data warehouse, e.g. process values or messages. � The WinCC OPC UA server is installed as Windows service and started automatically. The WinCC OPC UA server supports only the communication profile "UA-TCP UA-SC UA Binary". The used port number is adjustable. � WinCC OPC HDA Server The WinCC OPC HDA Server enables an OPC HDA Client to access the archived process values in the WinCC archive system. Runtime API Unrestricted � Siemens 2019 Page 3 2/3/2020 � Runtime API describes the open programming interface of WinCC. � Via the API functions, you use the internal functions of WinCC in your own applications and access HMI tag data or data in the archives Application � API functions are used in the following places: � Within WinCC: In user-defined C -functions and local C-scripts. � Outside of WinCC: In Windows applications created in the C/C++ programming language. To use Runtime API in the C# or VB.Net programming languages, you must program a corresponding implementation. WinCC RT Professional V16 Runtime options Runtime Options WinCC Server / WinCC Client WinCC Recipes SIMATIC WinCC Redundancy Description Server/client systems Organization of data records for associated machines / production data Server Lizenz: 6AV2107-0EB00-0BB0 Client-Lizenz: 6AV2107-0DB06-0AH0 6AV2107-0JB00-0BB0 WinCC Redundancy provides a considerable increase in the availability of WinCC and the system as a whole by operating two servers at the same time linked together. 6AV2107-0FB00-0BB0 WinCC Logging (1500/5000 Tags) WinCC WebNavigator WebUX Archiving of process data (including 500 archive tags) Control and monitoring via the web (MS Internet Explorer) Platform and browser-independent operator control and monitoring via the web (HTML5) WinCC DataMonitor SIMATIC Information Server 2014 SP3 upd4 SIMATIC Process Historian 2014 SP3 upd4 Industrial Data Bridge1) SIMATIC ProDiag Monitoring and analyzing of current and historical process data via the web (MS IE) For new systems, the information server is recommended Web-based analysis and historical process data reports (browser dependent) Plant-wide archive for messages and process data Configurable connections to databases and IT systems SIMATIC ProDiag allows selective and fast machine and plant diagnostics for SIMATIC S7-1500 and SIMATIC HMI: Unrestricted � Siemens 2019 Page 4 2/3/2020 1) WinCC RT Prof: as Consumer/Provider as sep. application 6AV2107-0GB00-0BB0 See WebNavigator slides See WebUX slides 6AV2107-0UB00-0BB0 WinCC RT Professional V16 Engineering Options Engineering Options SIMATIC EnergySuite (incl. 10 Energy Objects) SIMATIC Visualization Architect Description Transparency of energy consumption � SIMATIC Energy Suite Engineering � SIMATIC Energy Suite S7-1500, 5-100 Energy Objects SIMATIC Visualization Architect (SiVArc) enables simple, fast, and flexible automated creation of HMI contents based on the STEP 7 user program. 6AV2108-0AA06-0AA5 6AV2107-0PX06-0AA5 MultiUser TIA Portal Multiuser Engineering allows several users to work on the same project simultaneously. 6ES7823-1AA06-0YA5 The TIA Portal Teamcenter Gateway permits storage and management of TIA Portal projects and global TIA Portal Teamcenter Gateway libraries in Teamcenter. 6ES7823-1EA06-0YA5 TIA Portal Cloud Connector The TIA Portal Cloud Connector enables access to local PC interfaces and connected SIMATIC hardware in the TIA Portal Engineering even though the engineering itself takes place via remote desktop in a private cloud. 6ES7823-1CA00-0YA0 SIMATIC ODK 1500S SIMATIC Target 1500S TM for Simulink� The SIMATIC ODK 1500S allows the development of function libraries with the high-level languages C/C++ for ODK-capable SIMATIC S7-1500 PLCs. 6AV2108-0AA06-0AA5 The SIMATIC Target 1500S TM for Simulink� is an add-on for Simulink from MathWorks. It allows the integration of Simulink models directly into the program cycle of an ODK-capable S7-1500 PLC. 6AV2107-0PX06-0AA5 Unrestricted � Siemens 2019 Page 5 2/3/2020 1) WinCC RT Prof: as Consumer/Provider as sep. application SIMATIC WinCC Professional WinCC Premium Add-ons for Process Management Efficient data management PM-CONTROL PM-QUALITY Data consistency over the entire production process Flexible parameter managemnt and job control Batch-based archiving and reporting Diagnostic management PM-MAINT PM-ANALYZE Higher availability of machines and production plants Intelligent maintenance management system Efficient identification of weak points in the process + reporting Open-mindedness PM-OPEN-EXPORT PM-OPEN-IMPORT PM-LOGON Consolidation of automation and IT world Automatic export of process data Automatic import of messages and archive values Automatic registration, e.g.: via RFID siemens.com/process-management \\ww004.siemens.net\bu01$\NbgM\PROJ\PROMOTOREN_VM\VM_WARE_WORLD_WITHOUT_UCL\Inst_SW\2019_01_Install_PM_AddOn Unrestricted � Siemens 2019 Page 6 2/3/2020 Analysis + Reporting with PM-ANALYZE Archiving, Display and analysis of alarms from several different systems in chronological order � SIMATIC WinCCV7 � PCS7 � WinCC Comfort / RT Professional � WinCC Advanced � WinCC flexible � Event log of the operating system � Database and archiving � Manual input values � Reporting with Microsoft Excel � Automatic report generation � Add-in for Microsoft Excel 2007, 2010, 2013, 2016 � Access to all process value and summarization archives � Access to calculated values and key figures � Access to messages and operating actions Unrestricted � Siemens 2019 Page 7 2/3/2020 WinCC RT Professional V16 Explanation of symbols WinCC Single-User System S7 System Components WinCC Server WinCC Standard Client PC without WinCC Unrestricted � Siemens 2019 Page 8 2/3/2020 External Database e.g.: SQL, Oracle, Access Ext 1 2 3... Software to be installed on the computer WinCC RT Professional V16 System requirements for supported Operating Systems � Windows 10 64bit Pro � Version 1809 (OS Build 17763) � Version 1903 (OS Build 18362) � Windows 10 64bit Enterprise � Version 1809 (OS Build 17763) � Version 1903 � Windows 10 64bit IoT Enterprise LTSB � 2015 LTSP (OS Build 10240) (Test for IPC) � 2016 LTSP (OS Build 14393) (Test for IPC) � 2019 LTSP (OS Build 17763) (Test for IPC) � Windows Server 2012 R2 64bit StdE � Windows Server 2016 64Bit Standard � Windows Server 2019 64Bit Standard Office � Excel 2016 � Build 16.0.6769 (32 or 64 Bit) � Access to Online Office 365 Unrestricted � Siemens 2019 Page 9 2/3/2020 Operating Systems 1) The Windows operating system is only released together with a SIMATIC IPC. WinCC RT Professional V16 Browser Microsoft Browser: � Google Chrome* � Microsoft Edge � Mozilla Firefox, Mozilla Firefox ESR Android Browser: � Google Chrome* � Firefox � Edge iOS & Mac Browser: � Safari* � Google Chrome � Firefox � Edge * Browser with the main focus for this operating system Unrestricted � Siemens 2019 Page 10 2/3/2020 WinCC RT Professional V16 Supported virtualization software WinCC Engineering and Runtime � WinCC Professional V16 & WinCC Runtime Professional V16 are released for the following virtualization platforms Virtualization platforms VMware vSphere Hypervisor (ESXi) ab, 6.5 or higher VMware Workstation 12.5.5 / 15.0.2 VMware Player 12.5.5/ 15.0.2 Microsoft Windows Hyper-V Server 2016 or 2019 Engineering Runtime Advanced/ Professional All of the released operating systems can be used as host operating systems in a virtualization platform. Unrestricted � Siemens 2019 Page 11 2/3/2020 WinCC RT Professional V16 Compatibility and general information (continued) Side-by-side installation with all SIMATIC products Parallel installation von WinCC Runtime Professional V16 and other SIMATIC HMI Products The parallel installation of WinCC V16 with versions of WinCC flexible before WinCC flexible 2008 SP5 is not permitted. The parallel installation of WinCC V16 with WinCC V7 is not permitted for: � WinCC V16 Professional � WinCC V16 Runtime Professional Parallel Use If the software or license key after the installation is named with the affix "Combo", the use of the following products/versions is permitted: � With license "STEP 7 Professional Combo": older versions of STEP 7 (STEP 7 Professional 2006 � STEP 7 Professional V16) � With license "WinCC V16 Comfort Combo": WinCC flexible 2008 Standard � With license "WinCC V16 Advanced Combo": WinCC flexible 2008 Advanced Unrestricted � Siemens 2019 Page 12 2/3/2020 WinCC RT Professional V16 Compatibility and general information (continued) Remote-Software Link The following options are available for remote access to WinCC stations: � NC (Real VNC) Enterprise Edition V5.0.1. � RDP (Remote Desktop Protocol) The RealVNC software must be used for remote access to the other computers of a distributed WinCC system (e.g. WinCC Server). The Remote Desktop Protocol (RDP) may only be used for remote maintenance of WinCC clients. Furthermore, no server services (e.g. WebNavigator server, DataMonitor server, OPC server) may be active on these computers. The reason for this is the handling of the remote desktop sessions by the Microsoft operating system. WinCC running in service mode The service mode allows you to run WinCC Runtime Professional as a service. WinCC Runtime Professional can also be active as a service if no interactive user is logged on to the computer. Unrestricted � Siemens 2019 Seite 13 2/3/2020 WinCC RT Professional V16 Compatibility and general information (continued) Remote Software: Using RealVNC Link The following scenarios were tested: � WinCC as a single-user system � WinCC as a distributed system � WinCC in redundant operation � WinCC/WebUX Server You can also use communication via OPC in the released scenarios. Start Remote Desktop Access to WinCC systems with a Remote Desktop Client is only possible via a console session. Access via the Remote Desktop Protocol may only take place via console transfer with the same user or initial logon. Unrestricted � Siemens 2019 Seite 14 2/3/2020 SIMATIC WinCC RT Professional Upgrade for Power Tags at WinCC in TIA Portal (to V16) ... WinCC RT Professional V11... �> V16 WinCC RT Professional RT Client WinCC RT Professional 128 WinCC RT Professional 512 WinCC RT Professional 2k WinCC RT Professional 4k WinCC RT Professional 8k WinCC RT Professional 64k-250k 6AV2105-3BB06-0AE0 6AV2105-3DD06-0AE0 6AV2105-3FF06-0AE0 6AV2105-3HH06-0AE0 6AV2105-3KK06-0AE0 6AV2105-3MM06-0AE0 RT SUS (V16) 6AV2107-0DB00-0AL0 6AV2105-0XA00-0AL0 The information in SIOS is available: https://support.industry.siemens.com/cs/ww/en/view/109751896 Unrestricted � Siemens 2019 Page 15 2/3/2020 SIMATIC WinCC Professional Powertags Server The number of WinCC Runtime Professional PowerTags for the server is selectable. Power Packs extend the number of available tags. The total price remains constant. Client The Client is being deployed for � WinCC RT Professional Client Or � WinCC RT Professional 128 128 512 2k 4k 8k 64k 100k 150k 256k Unrestricted � Siemens 2019 Page 16 2/3/2020 SIMATIC WinCC Professional Engineering Upgrade WinCC in TIA Portal (V13.SPx to V16) WinCC Prof. V11 - V16 WinCC Prof. V16 ... WinCC Professional V11 to V16 � WinCC Professional V16 512 � WinCC Professional V16 4096 � WinCC Professional V16 max. � WinCC Prof.V16 512 Powertags SUS DL � WinCC Prof.V16 4096 Powertags SUS DL � WinCC Prof.V16 max. Powertags SUS DL Online Software Delivery 6AV2103-3DA06-0AE5 6AV2103-3DA06-0AK5 6AV2103-3HA06-0AE5 6AV2103-3HA06-0AK5 6AV2103-3XA06-0AE5 6AV2103-3XA06-0AK5 SUS 6AV21030DA000AY0 6AV21030HA000AY0 6AV21030XA000AY0 Unrestricted � Siemens 2019 Page 17 2/3/2020 SIMATIC WinCC Professional Migration from WinCC V7 RC/RT WinCC V7.2 WinCC Professional. V13 SP1 WinCC V7.3 WinCC Professional V14 WinCC V7.4 WinCC Professional V14 SP1 WinCC V7.4 SP1 WinCC V7.5 WinCC RC/RT V7.0...V7.5 WinCC V16 V7 RT Client WinCC RT Professional Client V7 RC/RT 128 RT Prof. 128 V7 RC/RT 512 RT Prof. 512 V7 RC/RT 2k RT Prof. 2k V7 RC/RT 8k RT Prof. 8k V7 RC/RT 64k RT Prof. >= 64k WinCC RT Professional V15.1 WinCC RT Professional V16 OSD 6AV2107-4DB06-0AE0 6AV2105-4BB06-0AE0 6AV2107-4DB06-0AK0 6AV2105-4BB06-0AK0 6AV2105-4DD06-0AE0 6AV2105-4DD06-0AK0 6AV2105-4FF06-0AE0 6AV2105-4FF06-0AK0 6AV2105-4KK06-0AE0 6AV2105-4KK06-0AK0 6AV2105-4MM06-0AE0 6AV2105-4MM06-0AK0 When upgrading from V7 RC/RT, ONLY the RT Professional license will be delivered with immediate effect. The WinCC Professional Engineering software must be ordered separately if required. Unrestricted � Siemens 2019 Page 18 2/3/2020 Engineering: WinCC RT Professional V16 The following security programs were tested: � Trend Micro "Office Scan" 12.0 � Symantec Endpoint Protection V14.0 � McAfee Endpoint Security (ENS) 10.5 � Kaspersky Endpoint Security 11.1 � Windows Defender (version contained in the operating system) � Qihoo 360 "Safe Guard 11.5" + "Virus Scanner" Unrestricted � Siemens 2019 Page 19 2/3/2020 WinCC RT Professional V16 Licenses Runtime � WinCC differentiates between RT licenses (Runtime) and ES licenses (Configuration) as well as the number of tags. � RT licenses permit the operation of WinCC in runtime for an unlimited period of time. With this license you can use up to 262 144 external tags and up to 500 archive tags (WinCC Logging) in Runtime. Engineering is not possible. � New :... the license for sporadic use:50h of actual use � where the usage can be interrupted as often as required Activation 50 h Valid License Key Expired License Key Engineering A license key is required for: � WinCC Engineering System, e.g. WinCC Professional � Options for WinCC Engineering System Web options � The license type of the web options (WEBNAVIGATOR, DATAMONITOR and WebUX ) becomes consistently countable. Unrestricted � Siemens 2019 Page 20 2/3/2020 SIMATIC WinCC Professional V16 Order data Logging ... Runtime Professional V16 Logging*) � 1500 Logging Tags � 5000 Logging Tags 6AV2107-0GB00-0BB0 6AV2107-0GD00-0BB0 Online Software Delivery 6AV2107-0GB00-0BH0 6AV2107-0GD00-0BH0 � 1500 -> 5000 Logging Tag Not applicable due to conversion to additive licenses! � WinCC Professional contains 500 Archive Tags in the base system � WinCC Logging Tags are expandable by:1500 and 5000. � Archive licenses can be combined/ pooled (countable licenses). � WinCC Professional supports up to 80k Archive Tags +5000 Archive Tags +1500 Archive Tags 500 Archive Tags 27000000 *) Number of tags are additive, i.e. total archive tags = sum of individual licenses Unrestricted � Siemens 2019 Page 21 2/3/2020 WinCC RT Professional V16 basic station Article numbers SIMATIC WinCC Professional xx PowerTags V16 Engineering Description 512 PowerTags 4096 PowerTags Max PowerTags NEW: SIMATIC 50h Engineering with STEP 7 Professional V14 SP1 Combo, SIMATIC 50h Engineering with STEP 7 Professional Combo, WinCC Professional (incl. WinCC flexible 2008) and STEP 7 Safety Advanced (incl. Distributed Safety) Order number EU DVD Online Software Download 6AV2103-0DA06-0AA5 6AV2103-0HA06-0AA5 6AV2103-0XA06-0AA5 6AV2103-0DA06-0AH5 6AV2103-0HA06-0AH5 6AV2103-0XA06-0AH5 6ES7823-1GE06-0YA5 Order number ASIA DVD - - SIMATIC WinCC Runtime Professional ... PowerTags V16 Basis Package (RT incl. 500 Archive Variables) (RT incl. 500 Archive Variables and one WebUX Monitor Client) 128 PowerTags 6AV2105-0BA06-0AA0 6AV2105-0BA06-0AH0 512 PowerTags 6AV2105-0DA06-0AA0 6AV2105-0DA06-0AH0 2048 PowerTags 6AV2105-0FA06-0AA0 6AV2105-0FA06-0AH0 4096 PowerTags 6AV2105-0HA06-0AA0 6AV2105-0HA06-0AH0 8192 PowerTags 6AV2105-0KA06-0AA0 6AV2105-0KA06-0AH0 65536 PowerTags AV2105-0MA06-0AA0 6AV2105-0MA06-0AH0 102400 PowerTags 6AV2105-0PA06-0AA0 6AV2105-0PA06-0AH0 153600 PowerTags 6AV2105-0RA06-0AA0 6AV2105-0RA06-0AH0 262144 PowerTags 6AV2105-0TA06-0AA0 6AV2105-0TA06-0AH0 WinCC Client for RT Prof V15 6AV2107-0DB06-0AA0 6AV2107-0DB06-0AH0 Please note the price advantage for Online Software Delivery! Unrestricted � Siemens 2019 Page 22 2/3/2020 Note: WinCC Professional V16 can also be configured with a WinCC Unified Engineering (max license). 6AV2105-0BA16-0AA0 6AV2105-0DA16-0AA0 6AV2105-0FA16-0AA0 6AV2105-0HA16-0AA0 6AV2105-0KA16-0AA0 6AV2105-0MA16-0AA0 6AV2105-0PA16-0AA0 6AV2105-0RA16-0AA0 6AV2105-0TA16-0AA0 6AV2107-0DB16-0AA0 SIMATIC WinCC Professional Order Data Engineering / Trial Link to compatibility list: Compatibility List ... Trial Software � Engineering Trial Software V16 WinCC Basic / Comfort / Advanced � SIMATIC WinCC Professional V16, � Trial License 6AV2102-0AA06-0AA7 6AV2103-0AA06-0AA7 Online Software Delivery Download in Customer Support Portal Unrestricted � Siemens 2019 Page 23 2/3/2020 Integrated licensing concept NEW as of WinCC V7.4 / RT Professional V14 Web solutions with WebNavigator and WebUX In the future, these SCADA options will have standardized MLFBs as of V7.4 or V14 and therefore there will no longer be any in-house MLFBs for WinCC RT Professional V15 Separate Web licenses Combined Web licenses WebNavigator WebUX Operate WebNavigator WebUX Operate Scalable web access Switching between two license models: � Separate or combined Web-licenses WebUX Monitor Client (read only) WebUX Operate Client (read-write) Web Navigator Client (read-write) Web Licenses are additive: all WebClients = sum of the individual licenses (countable) � (1, 3, 10, 30, 100 clients) � Reserving licenses for users Monitor Monitor � IIS on Windows 10 supports a maximum of ten connections or instances. WebUX requires more than one connection for a client. Therefore, a maximum of three WebUX clients can connect to the WebUX server.If the limit is exceeded, you can no longer operate the instances already connected No update costs, because version-independent licenses (existing licenses remain valid after upgrade) 1x WinCC WebUX Monitor Client FREE! Unrestricted � Siemens 2019 Page 24 2/3/2020 Integrated licenses NEW as of WinCC V7.4 SP1 / WinCC RT Professional V14 WinCC WebNavigator (countable) Description WinCC WebNavigator - 1 Client WinCC WebNavigator - 3 Clients WinCC WebNavigator - 10 Clients WinCC WebNavigator - 30 Clients WinCC WebNavigator - 100 Clients WinCC WebNavigator Diagnostic Client WinCC DataMonitor (countable) Description WinCC DataMonitor - 1 Client WinCC DataMonitor - 3 Clients WinCC DataMonitor - 10 Clients WinCC DataMonitor - 30 Clients Unrestricted � Siemens 2019 Page 25 2/3/2020 Order number: DVD EU 6AV6362-1AB00-0BB0 6AV6362-1AD00-0BB0 6AV6362-1AF00-0BB0 6AV6362-1AJ00-0BB0 6AV6362-1AM00-0BB0 6AV6362-1BA00-0BB0 Order number Online Software Download EU 6AV6362-1AB00-0AH0 6AV6362-1AD00-0AH0 6AV6362-1AF00-0AH0 6AV6362-1AJ00-0AH0 6AV6362-1AM00-0AH0 6AV6362-1BA00-0AH0 Order number: DVD ASIA 6AV6362-1AB00-0BB0 6AV6362-1AD00-0BB0 6AV6362-1AF00-0BB0 6AV6362-1AJ00-0BB0 6AV6362-1AM00-0BB0 6AV6362-1BA00-0BB0 Order number: DVD EU 6AV6362-3AB00-0BB0 6AV6362-3AD00-0BB0 6AV6362-3AF00-0BB0 6AV6362-3AJ00-0BB0 Order number : Online Software Download EU 6AV6362-3AB00-0AH0 6AV6362-3AD00-0AH0 6AV6362-3AF00-0AH0 6AV6362-3AJ00-0AH0 Order number: DVD ASIA 6AV6362-3AB00-0BB0 6AV6362-3AD00-0BB0 6AV6362-3AF00-0BB0 6AV6362-3AJ00-0BB0 Integrated licenses NEW from WinCC V7.4 / WinCC RT Professional V14 WinCC WebUX (Monitor countable) Description WinCC WebUX Monitor 1 Client WinCC WebUX Monitor 3 Clients WinCC WebUX Monitor 10 Clients WinCC WebUX Monitor 30 Clients WinCC WebUX Monitor 100 Clients WinCC WebUX (Operate countable) Description WinCC WebUX Operate 1 Client WinCC WebUX Operate 3 Clients WinCC WebUX Operate 10 Clients WinCC WebUX Operate 30 Clients WinCC WebUX Operate 100 Clients Unrestricted � Siemens 2019 Page 26 2/3/2020 Order number: DVD EU 6AV6362-2AB00-0BB0 6AV6362-2AD00-0BB0 6AV6362-2AF00-0BB0 6AV6362-2AJ00-0BB0 6AV6362-2AM00-0BB0 Order number: DVD EU 6AV6362-2BB00-0BB0 6AV6362-2BD00-0BB0 6AV6362-2BF00-0BB0 6AV6362-2BJ00-0BB0 6AV6362-2BM00-0BB0 Order number Online Software Download EU 6AV6362-2AB00-0AH0 6AV6362-2AD00-0AH0 6AV6362-2AF00-0AH0 6AV6362-2AJ00-0AH0 6AV6362-2AM00-0AH0 Order number: DVD ASIA 6AV6362-2AB00-0BB0 6AV6362-2AD00-0BB0 6AV6362-2AF00-0BB0 6AV6362-2AJ00-0BB0 6AV6362-2AM00-0BB0 Order number Online Software Download EU 6AV6362-2BB00-0AH0 6AV6362-2BD00-0AH0 6AV6362-2BF00-0AH0 6AV6362-2BJ00-0AH0 6AV6362-2BM00-0AH0 Order number: DVD ASIA 6AV6362-2BB00-0BB0 6AV6362-2BD00-0BB0 6AV6362-2BF00-0BB0 6AV6362-2BJ00-0BB0 6AV6362-2BM00-0BB0 WinCC RT Professional V16 ? In which case WinCC RT Advanced / WinCC V7 ? WinCC RT Advanced WinCC V7 � Single user system with max 16 384 PowerTags � No clients � Support of bit messages and analog messages as well as the event-controlled alarm procedure Alarm-S / D for SIMATIC S7 � Recipes: Creation of data sets for machine data or production data � WinCC Logging For archiving variables and messages Unrestricted � Siemens 2019 Page 27 2/3/2020 � 18 servers � 64 clients or � 50 multi-clients � 150 web clients � 2 Server (redundant) � Possibility to connect to SAP Hana/SAP R3 via PM Add ons � KPI evaluation (see V7 Performance Monitor) � Connection of telecontrol stations (WinCC V7 TeleControl ) � Generierung from Tags, Messages, pictures, Trend with VBA � WinCC RT Professional V16 In which case WinCC RT Professional V16? Project TIA Portal for SPS / SCADA System Architecture � Perfect integration into the TIA Portal => customer has been using and is familiar with the TIA Portal for a long time � WinCC integrated � System diagnosis, time stamping at source � Process diagnosis � SIMATIC Energy Suite � Generierung from pictures with SiVArc � Intelligentes Lastmanagement good SCADA solution for small to medium solutions 1 server (optional redundant) maximum 32 clients Unrestricted � Siemens 2019 Seite 28 2/3/2020 WinCC RT Professional V16 Communication with the process WinCC RT Prof PROFIBUS Network Ethernet Network Ethernet Card of the PC: � SOFTNET-IE S7 max. 64 connections (6GK1704-1CW16-0AA0) � SOFTNET-IE S7 Extended max. 128 connections (6GK1704-1BW16-0AA0) With CP � CP 1623 PCIe: (6GK1162-3AA00 ) CP 5621 PCIe Softnet Module � S7 MPI/PROFIBUS protocols included in WinCCCP 5613 A2 PCI Hardnet Module � S7 MPI/PROFIBUS protocols � A license is required WinCC RT Professional V16 supports max 128 S7 connections of which: -max. 128 x S7-1200 / S7-1500 Connections -max. 64 x S7-300/400 Connections Ethernet Card of the PC � Protocols 1200/1500, S7 TCP/IP, Ind. Eth � Licenses for � SOFTNET-IE S7 Lean max. 8 connections (included in the WinCC package) � With > 8 connections => license required for Softnet-IE S7 CP 1623 PCIe Hardnet Assembly (license for Hardnet-IE S7 (S7 1613) required) � It is recommended that you use separate network cards for reducing the load on the PC- CPU � max. 128 x S7-1500/1200 Connections Example: � max. 64 x S7-1500/1200 Connections - LAN Card 1: 64 x 1200/1500 � max. 64 x S7-300/400 Connections + LAN Card 2: 64 x 300/400 Unrestricted � Siemens 2019 Page 29 2/3/2020 Single-user system Operator control and monitoring with a single PC Single-user system Engineering Station+ WinCC RT Prof 1 2 Additional information � Quantity Structure: � Process tags: up to 262 144 (depending on license selected) � Archive tags: max. 80 000 (depending on WinCC Logging option) (Note: WinCC Pro 500 archive tags are included in the basic version.) Unrestricted � Siemens 2019 Page 30 2/3/2020 1 Basis Paket = SIMATIC WinCC Runtime Professional PowerTags V16 WinCC RT Prof n e. g.: � 512 PowerTags � 2048 PowerTags � 4096 PowerTags � 8192 PowerTags � 65 536 PowerTags � 102 400 PowerTags � 153 600 PowerTags � 262 144 PowerTags SIMATIC Net V16 2 SIMATIC WinCC Engineering System Base Package V16 � 512 PowerTags � 4096 PowerTags � Max. PowerTags Redundant single-user systems - 2 operator control and monitoring stations with a high degree of availability Engineering Station 3 1 2 1 Redundant WinCC Single-user systems 1 Base Package WinCC RT Prof n SIMATIC Net V16 2 WinCC Redundancy MLFB: 6AV2107-0FB00-0BB0 3 WinCC Engineering � 512 PowerTags � 4096 PowerTags � max PowerTags Additional information � The two stations run in parallel (both are connected to the process). In the event of a fault � in one of the two WinCC stations, the other takes over the archiving of messages, and the process/user data (recipe). Automatic synchronization of all archives � after restoration of the normal operating state. Unrestricted � Siemens 2019 Page 31 2/3/2020 Redundant Single-User Systems Engineering station Engineering Station 3 1 2 1 Redundant WinCC single-user systems IMPORTANT Changes can be made in the two WinCC servers via the engineering station. The requirement for this is that the engineering station must be configured, for example, with: � WinCC Prof V16 or � WinCC Prof V16 + STEP 7 Basic V16 (S7-1200) or STEP 7 Prof V16 (S7-1500) Unrestricted � Siemens 2019 Page 32 2/3/2020 1 Base Package WinCC RT Prof n SIMATIC Net V16 2 WinCC Redundancy MLFB: 6AV2107-0FB00-0BB0 3 WinCC Engineering � 512 PowerTags � 4096 PowerTags � max PowerTags WinCC Recipes Recipe management WinCC 2 WinCC Clients WinCC 2 ... WinCC 2 13 4 RT Pro Server With WinCC Recipes, the user can manage his archives in tabular form, E. g.: Recipe management � managing the batch parameters, ... The recipe license is located on the server. Unrestricted � Siemens 2019 Page 33 2/3/2020 1 Base Package WinCC RT Prof SIMATIC Net V16 2 WinCC Client MLFB: 6AV2107-0DB06-0AA0 3 WinCC Server MLFB: 6AV2107-0EB00-0BB0 4 WinCC Recipes MLFB: 6AV2107-0JB00-0BH0 WinCC Logging Archive tags WinCC 2 WinCC Clients WinCC 2 ... WinCC 2 13 4 RT Pro Server The number of the archive tags can be increased with WinCC Logging. (countable licenses) � The license for 500 archive tags is included in the basic package. � The logging license is located on the server. � With a license for 1500 archive tags and the basic license for 500 archive tags, you then have 2000 archive tags at your disposal Unrestricted � Siemens 2019 Page 34 2/3/2020 1 Base Package WinCC RT Prof SIMATIC Net V16 2 WinCC Client MLFB: 6AV2107-0DB06-0AA0 3 WinCC Server MLFB: 6AV2107-0EB00-0BB0 4 WinCC Logging e. g.: 1500 archive tags MLFB: 6AV2107-0GB00-0BB0 e. g.: 5000 archive tags MLFB: 6AV2107-0GD00-0BB0 Multi-user systems � central server with operating and monitoring stations: Only standard client 2 WinCC WinCC Clients 2 WinCC 2 WinCC ... 13 1 � 32 WinCC Clients WinCC RT Prof Server 1 Base Package WinCC RT Prof n SIMATIC Net V16 2 WinCC Client MLFB: 6AV2107-0DB06-0AA0 3 WinCC Server MLFB: 6AV2107-0EB00-0BB0 Please note A standard client does not have a WinCC project. It is connected to a specific server from which it receives data and views. Unrestricted � Siemens 2019 Page 35 2/3/2020 Multi-user systems with standard clients � Engineering Scenario 1 � Development on the server Case 1: The engineering license is located on the server. Changes to the project are made directly on the server. Standard 2 WinCC Clients 2 WinCC 2 WinCC ... 13 4 1 � 32 WinCC Clients WinCC RT Prof Server + Engineering To be observed � Differences compared to the preceding scenario: An engineering license is also required on the server. TIA is possible (i.e. STEP 7 can be installed on the server.) In the event of changes, it may be necessary to shut down the server. 1 Base Package WinCC RT Prof n SIMATIC Net V16 2 WinCC Client MLFB: 6AV2107-0DB06-0AA0 3 WinCC Server MLFB: 6AV2107-0EB00-0BB0 4 WinCC Engineering � 512 PowerTags � 4096 PowerTags � max PowerTags Unrestricted � Siemens 2019 Page 36 2/3/2020 Multi-user systems with standard clients � Engineering Scenario 2 � Engineering station Case 2: Changes are made on an in-house engineering station (e.g.: work station of a system integrator who is not constantly connected) Standard 2 WinCC Clients 2 WinCC 4 2 WinCC Engineering Station ... 13 1 � 32 WinCC Clients WinCC RT Prof Server IMPORTANT Changes can be made on the WinCC server via the engineering station. The requirement for this is that the engineering station must be configured. 1 Base Package WinCC RT Prof n SIMATIC Net V16 2 WinCC Client MLFB: 6AV2107-0DB06-0AA0 3 WinCC Server MLFB: 6AV2107-0EB00-0BB0 4 WinCC Engineering � 512 PowerTags � 4096 PowerTags � max PowerTags Unrestricted � Siemens 2019 Page 37 2/3/2020 Multi-user systems with standard clients � Engineering Scenario 3 � Engineering station on a client Case 3: Changes are made on an engineering station that is running on a client (e.g.: work station of a maintenance employee) 4 Standard 2 WinCC Clients 2 WinCC ... WinCC 2 Engineering Station 13 1 � 32 WinCC Clients WinCC RT Prof Server IMPORTANT Changes can be made on the WinCC server via the engineering station. The requirement for this is that the engineering station must be configured. 1 Base Package WinCC RT Prof n SIMATIC Net V16 2 WinCC Client MLFB: 6AV2107-0DB06-0AA0 3 WinCC Server MLFB: 6AV2107-0EB00-0BB0 4 WinCC Engineering WinCC Prof (512 / 4096 / max ) Unrestricted � Siemens 2019 Page 38 2/3/2020 Analysis + Reporting with PM-ANALYZE Installation Variants PM-ANALYZE Client (With/Without WinCC Client) *Installation on a separate server requires a Microsoft SQL Server 2008, 2014,2016 (32/64). PM-ANALYZE Server (Without WinCC) Unrestricted � Siemens 2019 Page 39 2/3/2020 WinCC Server PM-AGENT Distributed System WinCC Comfort Panels OPC UA SIMATIC Information Server � Reporting System in the web PC with reporting with dashboards on HTML5-capable browser or via Office (Microsoft Excel, Word, PowerPoint) Internet LAN 1 WinCC single-user 2 system with IS2014 SP3 upd4 Additional Information Standard and user-specific reports (via Report Builder of MS SQL Reporting Services) Transparent access to WinCC-Archive in Excel and Word (2007, 2010, 2013 and 2016). Unrestricted � Siemens 2019 Page 40 2/3/2020 1 Base Package WinCC RT Prof n SIMATIC Net V16 2 WinCC IS 2014 SP3 upd4 Base Package MLFB: 6AV6361-2AA01-4AA0 The base package contains: � 1 x data source access (connection with a WinCC database) � 3 x client access (three simultaneous client accesses) Note: Information Server 2014 SP3 upd4 is compatible with -WinCC RT Prof V13 SP1 or higher -WinCC 7.0 SP3 or higher -WinCC OA 3.14 or higher -SIMATIC Process Historian 2014 SP2 SIMATIC Information Server � Reporting system in the web WinCC 2 WinCC Clients WinCC 2 WinCC 2 WinCC 2 13 Redundant WinCC Server 4 13 5 67 PH + Information Server Additional Information PH and Information Server can be installed on the same computer. If IS is connected to PH, no "IS DataSource Access" license is needed. Unrestricted � Siemens 2019 Page 41 2/3/2020 1 Base Package WinCC RT Prof n SIMATIC Net V16 2 WinCC Client MLFB: 6AV2107-0DB06-0AA0 3 WinCC Server MLFB: 6AV2107-0EB00-0BB0 4 WinCC Redundancy MLFB: 6AV2107-0FB00-0BB0 5 Process Historian 2014 SP3 upd4 MLFB: 6AV6361-1AA01-4AA0 6 WinCC IS 2014SP3 Base Package MLFB: 6AV6361-2AA01-4AA0 7 WinCC IS Client Access (1) MLFB: 6AV6361-2BD00-0AD0 Single-User Web Server Remote web client on the Internet/intranet With Internet Explorer or WinCC ViewerRT Internet/intranet 1 � 100 Web Clients 1 LAN RT Prof Web 2 Server Single-User System 1 Base Package WinCC RT Prof n SIMATIC Net V16 2 WinCC WebNavigator z. B.: for three clients MLFB: 6AV6362-1AD00-0BB0 Additional Information WinCC/WebNavigator allows operator control and monitoring from a remote operator station via a local intranet or the Internet. In each case, a web license for n clients allows a simultaneous connection with the WinCC web server for these n clients Unrestricted � Siemens 2019 Page 42 2/3/2020 Single-user web server with HTML5 web clients: WebUX allows remote web client on the internet/intranet via tablets/smartphones 1 Base Package Interne/Intranet WinCC RT Prof n SIMATIC Net V16 Any 3 web HTML5 clients 1 Web server single-user system 2 2 WinCC WebUX e.g.: for 3 clients LAN MLFB: 6AV6362-2BD00-0BB0 Additional information In this case, three clients HTML5 can access to the WebUX server without any installation from the client side. WebUX is based on a secure connection and needs a certificate. Note: The security certificate must be renewed after one year. Because of some limitations in comparison to WebNavigator, please verify that WebUX is suitable for the required operations. Unrestricted � Siemens 2019 Page 43 2/3/2020 Remote diagnostics of WinCC systems in connection with WebNavigator / WebUX - Combined licenses for WebNavigator / WebUX and Diagnostic Client Remote diagnostics of WinCC systems in connection with WebNavigator 4 Internet 1 Base Package WinCC RT Prof n SIMATIC Net V16 2 WinCC WebNavigator Any 3 Web Clients e. g.: for three Clients 1 MLFB: 6AV6362-1AD00-0BB0 Webserver Single-User System 2 3 WinCC WebUX e. g.: WebUX Operate 3 Clients MLFB: 6AV6362-2BD00-0BB0 Additional Information The WebNavigator license can allow the access even from WebUX HTML5 clients combined to WebNavigator desktop clients. In this case, a WebNavigator license for three clients allows connection from any three WebNavigator/WebUX clients, depending on the configuration. As example, a fourth stand-alone client with the Diagnostics License can access to the server anytime! Unrestricted � Siemens 2019 Page 44 2/3/2020 4 WinCC WebDiagnostics Client MLFB: 6AV6362-1BA00-0BB0 Web server single-user system � Special case with only one web connection (WebNavigator Diagnostics) Internet WebDiagnostics Client 2 1 Webserver- Single-User System 1 Base Package WinCC RT Prof n SIMATIC Net V16 2 WinCC WebDiagnostics Client MLFB: 6AV6362-1BA00-0BB0 Additional Information In contrast to the preceding case, the license is installed on a web client. Thus, no license is necessary on the server(s) for this client. Several diagnostic clients can be connected to a diagnostics server Unrestricted � Siemens 2019 Page 45 2/3/2020 Web-Solution 1: Web Solution based on (RDP-Clients) on Industrial Thin Client V3 3 1 � 25 Thin Clients (RDP-Clients) 1 Base Package Web Clients Internet WinCC RT Prof n SIMATIC Net V16 2 WinCC WebNavigator 12 RT Prof Webserver Single-User System e. g.: for 10 Clients MLFB: 6AV6362-1AF00-0BB0 With the services of the Windows Terminal Server, the functionalities of the WebNavigator can be used for thin clients (limited resources and operating system not supported by WinCC) Example: SIMATIC Thin Client The ITC V3 supports the protocols RDP, VNC and Sm@rtserver https://support.industry.siemens.com/cs/ww/en/view/109758315 Unrestricted � Siemens 2019 Page 46 2/3/2020 3 Thin Client V3 / Thin Client V3 PRO 6AV6646-1BA15-0AA0 SIMATIC ITC1500 V3 6AV6646-1BA15-0NA0 SIMATIC ITC1500 V3 6AV6646-1BA18-0AA0 SIMATIC ITC1900 V3 6AV6646-1BA18-0NA0 SIMATIC ITC1900 V3 6AV6646-1BA22-1AA0 SIMATIC ITC2200 V3 6AV6646-1BA22-1NA0 SIMATIC ITC2200 V3 Web Solution 2: Operator control and monitoring of WinCC systems with HTML 5 browser (Tablet / PC / WebPanel) 1 Base Package WinCC RT Prof n SIMATIC Net V16 Internet 2 WinCC WebUX 12 RT Prof Webserver Single-User System 3 any WebUX-Clients e. g.: for 10 Clients MLFB: 6AV6362-1AF00-0BB0 Additional Information WebPanel (Linux based software ) Integrated current Chromium Browser v66 (perfect for WebUX) The IWP software supports different hardware architect (Basic Panels / ITC /IPC 3 WebPanel Attention: Standard ThinClient V3 uses a Mozilla Firefox browser that is not optimal for WebUX Please order the new WebPanel based on Thin Client V3 with the new Google Chrome browser Unrestricted � Siemens 2019 Page 47 2/3/2020 Virtualization for WinCC clients and/or server Example: Virtual WinCC clients on Hypervisor 2 Thin clients via remote access to the 2 WinCC clients of the host computer 2 13 RT Prof Server 1 Base Package WinCC RT Prof n SIMATIC Net V16 2 WinCC Client MLFB: 6AV2107-0DB06-0AA0 3 WinCC Server MLFB: 6AV2107-0EB00-0BB0 WinCC clients run with the Hypervisor system. WinCC servers can also be operated using the Hypervisor system. The maximum number of clients that the virtualization server can host depends on the physical resources of the host computer � RAM, SSD � CPU, Number of Core Unrestricted � Siemens 2019 Page 48 2/3/2020 Functional differences between WinCC RT Professional V16 and WinCC 7.5 SP1 Functions WinCC RT Professional V16 PowerTags Screens / screen objects Alarms Server/client Logging *) 500/ 512 archive tags incl. Recipes **) WebNavigator WebUX PLC Connections *) V7.x: Archive tags **) V7.x: UserArchives Unrestricted � Siemens 2019 Page 49 2/3/2020 ES: 512, 4k, max. RT: 128, 512, 2k, 4k, 8k, 64k, 100K, 150K, 265k No limit / no limit 150,000 256 alarm classes, 32 types in groups, 17 alarm priorities 1 server / 32 clients Archive tags add. 1,500, 5,000 max. 80,000 (server) Recipes: 500 / Elements per recipe: 10 000 1, 3, 10, 30, 100 clients Up to 128 connections, -max. 128 x S7-1200 / S7-1500 Connections -max. 64 x S7-300 / 400 Connections WinCC V7.5 SP1 RC: 128, 512, 2k, 8k, 64k, 100K, 150K, 256k RT: 128, 512, 2k, 8k, 64k, 100K, 150K, 265k No limit / no limit 150,000 256 alarm classes 17 alarm priorities (0 to 16) 18 servers / 64 clients 50 multi-clients Archive tags add. 1,500, 5,000, 10k, 30k, 80k max. 80,000 (server) Recipes: No limit / Elements per recipe: 100,000 1, 3, 10, 30, 100 clients ( in WinCC V7.3 max.150 clients) 128 x S7-1500/ 32 x S7-1200 / 64 x S7-300/400 Functional differences between WinCC RT Professional V16 and WinCC 7.5 SP1 Communication MPI/PROFIBUS OPC UA SIMOTION SINUMERIK Allen Bradley Modicon Mitsubishi IEC Client DNP3 MQTT Unrestricted � Siemens 2019 Page 50 2/3/2020 WinCC Professional V16 Yes OPC UA Server : DA, HA, A&C (Alarm & Condition) OPC UA Client: DA OPC UA NO Ethernet/IP Modbus (TCP) MC TCP/IP NO NO NO WinCC V7.5 SP1 Yes UA Server: DA, HA, A&C (Alarm & Condition) UA Client: DA, A&C Yes Add-on Ethernet/IP Modbus (TCP) i-QR PLCs IEC 61850 (Add-on) Option Telecontrol WinCC Cloud Connect SIMATIC WinCC Professional Hardware and software from a single source - Order Packages Package Runtime Licenses Available SIMATIC IPC WinCC RT Professional Client 6AV2117-2DB06-0AA0 WinCC RT Professional 128 PT WinCC RT Professional 512 PT WinCC RT Professional 2048 PT 6AV2115-2BA06-0AA0 6AV2115-2DA06-0AA0 6AV2115-2FA06-0AA0 All SIMATIC IPC Box, Panel, Rack PCs WinCC RT Professional 4096 PT 6AV2115-2HA06-0AA0 WinCC RT Professional 8192 PT WinCC RT Professional 65536 PT 6AV2115-2KA06-0AA0 6AV2115-2MA06-0AA0 IPC227D and IPC277D Up to 30% price advantage (vs. regular WinCC list price) Available packages for SIMATIC IPC SIOS - IPC Packages Only if ordered simultaneously with the SIMATIC IPC. Please always observe the operating system requirements of the WinCC system. Unrestricted � Siemens 2019 Page 51 2/3/2020 Promoter selection help � Software packages for SIMATIC IPCs Additional information 2x7D/E WinCC flexible RT WinCC RT Advanced WinCC RT Professional client WinCC V7.x client 4x7D 6x7 / 8x7 C/E 647 / 847 C/D 547E/G 347E Unrestricted � Siemens 2019 Page 52 2/3/2020 Promoter selection help � Software packages for SIMATIC IPCs Additional information 2x7E WinCC flexible RT WinCC RT Advanced WinCC RT Professional WinCC V7.x 377E ITP1000 647 / 847C/D/E 127E client client ? (Worked, but not system tested) Unrestricted � Siemens 2019 Page 53 2/3/2020 Unrestricted � Siemens 2019 Page 54 2/3/2020 Subject to changes and errors. The information given in this document only contains general descriptions and/or performance features which may not always specifically reflect those described, or which may undergo modification in the course of further development of the products. The requested performance features are binding only when they are expressly agreed upon in the concluded contract. All product designations, product names, etc. may contain trademarks or other rights of Siemens AG, its affiliated companies or third parties. Their unauthorized use may infringe the rights of the respective owner.
