3 Media (USB). A110. 3BSE091823R1. 1042. AH. Compact HMI 6.0.3.2 installation media on a write protected. USB drive. Manuals as PDFs. Media can ...
Cambia Automation Limited ABB AI801 3BSE020512R1 Datasheet Contact Email: sales@cambia.cn Cambia Group 2018/12/11 ABB Control Technologies - Produktförsäljning Sverige Price Book Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-07-01 Valid to: 2018-12-31 1.1 Compact HMI 800 6.0.3 3BSE091845/A - SVE-CHP List Price, SEK 2018-10-31 Page 1 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-07-01 Item Description Valid to: 2018-12-31 Max Qty Article No 1.1 Compact HMI 800 6.0.3 3BSE091845/A - SVE-CHP List Price, SEK LP DC 0 Control System Lifecycle Management Program Automation Sentinel is the ABB control system lifecycle management program for the Extended Automation, Freelance, Compact Product Suite, Symphony Plus and OCS product lines. ABB recommends its customers to use Automation Sentinel for all its installed control systems. With this program, customers can keep control software up-to-date and maintain a flexible path forward to new system software technology. It provides services to maintain and continually advance and enhance your ABB control system installation. You may choose the level of maintenance and upgrade support that works best for your immediate needs and long-term production targets. Read more about our Automation Sentinel Program and its many valuable services here: http://new.abb.com/control-systems/service/offerings/service-agreements Please contact your local sales representative for detailed information on the program and on how order Automation Sentinel subscriptions. 1 Compact HMI Base System A110 Compact HMI 6.0.3 Media (USB) Compact HMI 6.0.3.2 installation media on a write protected USB drive. Manuals as PDFs. Media can also be downloaded from ABB Library or My ABB/My Control System No license is included. A120 Compact HMI 6.0.3 Base License Base License for one combined HMI Operator and Engineering Workplace Server. Plant Explorer, Aspect Server and Softpoint Server, Scheduler, Primary History Logs, PLC Connect, PLC Connect Dial-Up, Compact HMI Alarm Operations, SMS & Email Messaging, Audit trail, Advanced Access Control, Digital Signature, Graphics Builder & Symbol factory. No media is included. 3BSE091823R1 1 3BSE091827R1 1042 AH 1957 AH 1.1 Signal Additions B110 Compact HMI Base System signals, 50 50 Signals for Compact HMI 6.0.3 Base System. B120 Compact HMI Base System signals, 500 500 Signals for Compact HMI 6.0.3 Base System. B130 Compact HMI Base System signals, 2500 2500 Signals for Compact HMI 6.0.3 Base System. 9 3BSE091828R1 4 3BSE091829R1 4 3BSE091830R1 4822 AH 23503 AH 56840 AH 1.2 Snapshot Reports C110 Compact HMI 6.0.3 Snapshot Reports Makes it possible to create aspects that automatically executes a query and produces a report consisting of properties of objects in the system. 1 3BSE091831R1 25151 AH 2 HMI Clients 2.1 HMI Operator Workplace Clients D110 Operator Workplace Client, 200 signals 9 3BSE091833R1 10366 AH 2018-10-31 Page 2 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-07-01 Item Description Valid to: 2018-12-31 One additional Compact HMI 6.0.3 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. D120 Operator Workplace Client, 500 signals One additional Compact HMI 6.0.3 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. D130 Operator Workplace Client, 1000 signals One additional Compact HMI 6.0.3 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. D140 Operator Workplace Client, 2000 signals One additional Compact HMI 6.0.3 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. D150 Operator Workplace Client, 5000 signals One additional Compact HMI 6.0.3 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. D160 Operator Workplace Client, 10000 signals One additional Compact HMI 6.0.3 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. Max Qty Article No 9 3BSE091834R1 9 3BSE091835R1 9 3BSE091836R1 9 3BSE091837R1 9 3BSE091838R1 2.3 Office Workplaces D510 C HMI Smart Client Workplace Compact HMI 6.0.3 Smart Client Workplace. Includes access to system information from the office network. Possibility to view Process Graphics 2 displays, trend displays, build/view business graphics, historic data. 10 3BSE091839R1 3 Dongles H200 License dongle for USB Port For use in 800xA or Compact HMI systems. 5 3BSE064644R1 *** End of price list *** 1.1 Compact HMI 800 6.0.3 3BSE091845/A - SVE-CHP List Price, SEK LP DC 15948 AH 26314 AH 35882 AH 41392 AH 55527 AH 6524 AH 2639 A1 2018-10-31 Page 3 of 47 This page is intentionally blank ABB Control Technologies - Produktförsäljning Sverige Price Book Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-07-01 Valid to: 2018-12-31 1.2 Compact HMI 800 6.0.3 Expansion 3BSE091846/A - SVE-CHP List Price, SEK 2018-10-31 Page 5 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-07-01 Item Description Valid to: 2018-12-31 1.2 Compact HMI 800 6.0.3 Expansion 3BSE091846/A - SVE-CHP List Price, SEK Max Qty Article No LP DC 1 Compact HMI 800 Base System 1.1 Signal Additions B110 Compact HMI Base System signals, 50 50 Signals for Compact HMI 6.0.3 Base System. B120 Compact HMI Base System signals, 500 500 Signals for Compact HMI 6.0.3 Base System. B130 Compact HMI Base System signals, 2500 2500 Signals for Compact HMI 6.0.3 Base System. 1.2 Snapshot Reports and Symbol Factory for PG2 C110 Compact HMI 6.0.3 Snapshot Reports Makes it possible to create aspects that automatically executes a query and produces a report consisting of properties of objects in the system. C120 Compact HMI 6.0.3 Symbol Factory for PG2 Support for Symbol Factory process graphics 2 items in graphics displays. Symbol factory is included in new Compact HMI 6.0.3 base systems. This is only available for systems which has been upgraded to Compact HMI 6.0.3 and does not have a license for Symbol Factory. 2 HMI Clients 2.1 HMI Operator Workplace Clients D110 Operator Workplace Client, 200 signals One additional Compact HMI 6.0.3 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. D120 Operator Workplace Client, 500 signals One additional Compact HMI 6.0.3 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. D130 Operator Workplace Client, 1000 signals One additional Compact HMI 6.0.3 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. D140 Operator Workplace Client, 2000 signals One additional Compact HMI 6.0.3 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. D150 Operator Workplace Client, 5000 signals 9 3BSE091828R1 4 3BSE091829R1 4 3BSE091830R1 1 3BSE091831R1 1 3BSE091832R1 9 3BSE091833R1 9 3BSE091834R1 9 3BSE091835R1 9 3BSE091836R1 9 3BSE091837R1 4822 AH 23503 AH 56840 AH 25151 AH 11240 AH 10366 AH 15948 AH 26314 AH 35882 AH 41392 AH 2018-10-31 Page 6 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-07-01 Item Description Valid to: 2018-12-31 One additional Compact HMI 6.0.3 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. D160 Operator Workplace Client, 10000 signals One additional Compact HMI 6.0.3 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. 1.2 Compact HMI 800 6.0.3 Expansion 3BSE091846/A - SVE-CHP List Price, SEK Max Qty Article No LP DC 9 3BSE091838R1 55527 AH 2.2 Office Workplaces D510 C HMI Smart Client Workplace Compact HMI 6.0.3 Smart Client Workplace. Includes access to system information from the office network. Possibility to view Process Graphics 2 displays, trend displays, build/view business graphics, historic data. 10 3BSE091839R1 6524 AH 3 Client Signal Expansions F110 Client Signal Expansion, 200 to 500 Compact HMI 6.0.3. Operator Workplace Client Signal Expansion from 200 to 500 signals. 9 3BSE091840R1 F120 Client Signal Expansion, 500 to 1000 Compact HMI 6.0.3. Operator Workplace Client Signal Expansion from 500 to 1000 signals. 9 3BSE091841R1 F130 Client Signal Expansion, 1000 to 2000 Compact HMI 6.0.3. Operator Workplace Client Signal Expansion from 1000 to 2000 signals. 9 3BSE091842R1 F140 Client Signal Expansion, 2000 to 5000 Compact HMI 6.0.3. Operator Workplace Client Signal Expansion from 2000 to 5000 signals. 9 3BSE091843R1 F150 Client Signal Expansion, 5000 to 10000 Compact HMI 6.0.3. Operator Workplace Client Signal Expansion from 5000 to 10000 signals. *** End of price list *** 9 3BSE091844R1 5582 AH 10364 AH 9570 AH 5582 AH 14062 AH 2018-10-31 Page 7 of 47 This page is intentionally blank ABB Control Technologies - Produktförsäljning Sverige Price Book Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-07-01 Valid to: 2018-12-31 2.2 Compact HMI 800 6.0.1 Expansion 3BSE086015/D - SVE-CHP List Price, SEK 2018-10-31 Page 9 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-07-01 Item Description Valid to: 2018-12-31 1 Compact HMI 800 Base System 1.1 Signal Additions B110 Compact HMI Base System signals, 50 50 Signals for Compact HMI 6.0.1 Base System. B120 Compact HMI Base System signals, 500 500 Signals for Compact HMI 6.0.1 Base System. B130 Compact HMI Base System signals, 2500 2500 Signals for Compact HMI 6.0.1 Base System. 2 HMI Clients 2.1 HMI Operator Workplace Clients D110 Operator Workplace Client, 200 signals One additional Compact HMI 6.0.1 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. D120 Operator Workplace Client, 500 signals One additional Compact HMI 6.0.1 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. D130 Operator Workplace Client, 1000 signals One additional Compact HMI 6.0.1 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. D140 Operator Workplace Client, 2000 signals One additional Compact HMI 6.0.1 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. D150 Operator Workplace Client, 5000 signals One additional Compact HMI 6.0.1 Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. D160 Operator Workplace Client, 10000 signals One additional Compact HMI Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have an equal number of signals as the base system use. 2.2 Office Workplaces D510 C HMI Smart Client Workplace 2.2 Compact HMI 800 6.0.1 Expansion 3BSE086015/D - SVE-CHP List Price, SEK Max Qty Article No LP DC 9 3BSE084257R50 4 3BSE084257R500 4 3BSE084257R2500 4822 A1 23503 A1 56840 A1 9 3BSE084259R200 10366 A1 9 3BSE084259R500 15948 A1 9 3BSE084259R1000 26314 A1 9 3BSE084259R2000 35882 A1 9 3BSE084259R5000 41392 A1 9 3BSE084259R5001 55527 A1 10 3BSE084261R1 6524 A1 2018-10-31 Page 10 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-07-01 Item Description Valid to: 2018-12-31 Compact HMI 6.0.1 Smart Client Workplace. Includes access to system information from the office network. Possibility to view Process Graphics 2 displays, trend displays, build/view business graphics, historic data. 2.2 Compact HMI 800 6.0.1 Expansion 3BSE086015/D - SVE-CHP List Price, SEK Max Qty Article No LP DC 3 Client Signal Expansions F110 Client Signal Expansion, 200 to 500 Compact HMI 6.0.1 Operator Workplace Client Signal Expansion from 200 to 500 Signals 9 3BSE084258R200 F120 Client Signal Expansion, 500 to 1000 Compact HMI 6.0.1 Operator Workplace Client Signal Expansion from 500 to 1000 Signals 9 3BSE084258R500 F130 Client Signal Expansion, 1000 to 2000 Compact HMI 6.0.1 Operator Workplace Client Signal Expansion from 1000 to 2000 Signals 9 3BSE084258R1000 F140 Client Signal Expansion, 2000 to 5000 Compact HMI 6.0.1 Operator Workplace Client Signal Expansion from 2000 to 5000 Signals 9 3BSE084258R2000 F150 Client Signal Expansion, 5000 to 10000 Compact HMI 6.0.1 Operator Workplace Client Signal Expansion from 5000 to 10000 Signals *** End of price list *** 9 3BSE084258R5000 5582 A1 10366 A1 9569 A1 5582 A1 14063 A1 2018-10-31 Page 11 of 47 This page is intentionally blank ABB Control Technologies - Produktförsäljning Sverige Price Book Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Valid to: 2018-12-31 3 Compact HMI 800 5.1 Expansion 3BSE064097/G - SVE-CHP List Price, SEK 2018-10-31 Page 13 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Item Description Valid to: 2018-12-31 Max Qty Article No 3 Compact HMI 800 5.1 Expansion 3BSE064097/G - SVE-CHP List Price, SEK LP DC 1 Compact HMI 800 Base System 1.1 Signal Additions (Total max 10.000) B110 Compact HMI Base System signals, 50 50 Signals for Compact HMI 5.1 Base System. B120 Compact HMI Base System signals, 500 500 Signals for Compact HMI 5.1 Base System. B130 Compact HMI Base System signals, 2500 2500 Signals for Compact HMI 5.1 Base System. 2 HMI System Options C100 Compact HMI Alarm Management Alarm Analysis and Alarm Shelving. 3 HMI Clients 3.1 HMI Operator Workplace Clients Note: It is possible to have up to 10 workplaces of any type in total. D110 Operator Workplace Client, 200 signals One additional Compact HMI Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have a equal number of signals as the base system use. D120 Operator Workplace Client, 500 signals One additional Compact HMI Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have a equal number of signals as the base system use. D130 Operator Workplace Client, 1000 signals One additional Compact HMI Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have a equal number of signals as the base system use. D140 Operator Workplace Client, 2000 signals One additional Compact HMI Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have a equal number of signals as the base system use. D150 Operator Workplace Client, 5000 signals One additional Compact HMI Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have a equal number of signals as the base system use. D160 Operator Workplace Client, 10000 signals 9 3BSE064066R50 4 3BSE064066R500 4 3BSE064066R2500 1 3BSE064069R1 9 3BSE064068R200 9 3BSE064068R500 9 3BSE064068R1000 9 3BSE064068R2000 9 3BSE064068R5000 9 3BSE064068R5001 4782 A1 23124 A1 54946 A1 39796 A1 10368 A1 15948 A1 26315 A1 35885 A1 41392 A1 55525 A1 2018-10-31 Page 14 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Item Description Valid to: 2018-12-31 One additional Compact HMI Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have a equal number of signals as the base system use. Max Qty Article No 3 Compact HMI 800 5.1 Expansion 3BSE064097/G - SVE-CHP List Price, SEK LP DC 3.2 HMI Operator Workplace Remote Clients Note: It is possible to have up to 10 workplaces of any type in total. D310 Remote Operator Workplace, 200 signals One additional Remote Compact HMI Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have a equal number of signals as the base system use. D320 Remote Operator Workplace, 500 signals One additional Remote Compact HMI Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have a equal number of signals as the base system use. D330 Remote Operator Workplace, 1000 signals One additional Remote Compact HMI Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have a equal number of signals as the base system use. D340 Remote Operator Workplace, 2000 signals One additional Remote Compact HMI Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have a equal number of signals as the base system use. D350 Remote Operator Workplace, 5000 signals One additional Remote Compact HMI Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have a equal number of signals as the base system use. D360 Remote Operator Workplace, 10000 signals One additional Remote Compact HMI Operator Workplace Client. Process Graphics, Alarm and events, Trends, Reports. Additional clients to a Compact HMI base system need to have a equal number of signals as the base system use. 9 3BSE064070R200 9 3BSE064070R500 9 3BSE064070R1000 9 3BSE064070R2000 9 3BSE064070R5000 9 3BSE064070R5001 10368 A1 15948 A1 26315 A1 35885 A1 41392 A1 55525 A1 3.3 Office Workplaces D510 C HMI Smart Client Workplace Compact HMI Smart Client Workplace. Includes access to system information from the office network. Possability to view Process Graphics 2 displays, trend displays, build/view business graphics, historic data. 10 3BSE079194R10 6524 A1 5 Client Signal Expansions F110 Client Signal Expansion, 200 to 500 9 3BSE064067R200 5580 A1 Page 15 of 47 2018-10-31 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Item Description Valid to: 2018-12-31 Max Qty Article No 3 Compact HMI 800 5.1 Expansion 3BSE064097/G - SVE-CHP List Price, SEK LP DC Compact HMI Operator Workplace Client Signal Expansion from 200 to 500Signals F120 Client Signal Expansion, 500 to 1000 Compact HMI Operator Workplace Client Signal Expansion from 500 to 1000 Signals 9 3BSE064067R500 F130 Client Signal Expansion, 1000 to 2000 Compact HMI Operator Workplace Client Signal Expansion from 1000 to 2000 Signals 9 3BSE064067R1000 F140 Client Signal Expansion, 2000 to 5000 Compact HMI Operator Workplace Client Signal Expansion from 2000 to 5000 Signals 9 3BSE064067R2000 F150 Client Signal Expansion, 5000 to 10000 Compact HMI Operator Workplace Client Signal Expansion from 5000 to 10000 Signals *** End of price list *** 9 3BSE064067R5000 10368 A1 9570 A1 5580 A1 14065 A1 2018-10-31 Page 16 of 47 ABB Control Technologies - Produktförsäljning Sverige Price Book Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-03-01 Valid to: 2018-12-31 4 Panel 800 Version 6 3BSE070940/J - SVE-CHP List Price, SEK 2018-10-31 Page 17 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-03-01 Item Description Valid to: 2018-12-31 Max Qty Article No 4 Panel 800 Version 6 3BSE070940/J - SVE-CHP List Price, SEK LP DC 0 Software Management Program Automation Sentinel is the ABB control system lifecycle support program. An introductory trial period to the Automation Sentinel program will be included, at no additional cost, with each new ABB control system software delivery. Please contact your designated Automation Sentinel responsible for any questions or please refer to the Automation Sentinel product guide for detailed information on the program and on how to calculate and order Automation Sentinel subscriptions. 0.1 Upgrade Orders A040 Panel Builder 800 Version 6, upgrade Media folder with Panel Builder 800 Version 6 containing the latest version of: - Panel Builder 800 Version 6 - Panel 800 Runtime - Firmware for panels - Manuals as pdf-files - Release Notes - Mouse Pad - Renewed License This item can be ordered by users with a valid Automation Sentinel agreement for Panel Builder 800 version 5. 1 3BSE069301R1 1 Panel Builder 800 A110 Panel Builder 800 Version 6 Media folder with Panel Builder 800 Version 6 containing the latest version of: - Panel Builder 800 Version 6 - Panel 800 Runtime - Firmware for panels - Manuals as pdf-files - Release Notes - Mouse Pad - License for one Panel Builder 800 Version 6 1 3BSE069300R1 2 Panel 800 2.1 Operator Panels 2.1.1 Standard Touch Panels A410 PP871 Touch Panel 4.3" TFT 480x272 (16:9). Requires Panel Builder 800 Version 6 for configuration. To protect the front, it's recommended to use the RX871 Touch cover. A420 PP874 Touch Panel 7" TFT 800x480 widescreen (16:9). Requires Panel Builder 800 Version 6 for configuration. To protect the front, it's recommended to use the RX874 Touch cover. A430 PP877 Touch Panel 10.4" TFT 640x480 (4:3). Requires Panel Builder 800 Version 6 for configuration. To protect the front, it's recommended to use the RX877 Touch cover. 3BSE069270R2 3BSE069271R2 3BSE069272R2 2.1.2 Standard Key Panels 2018-10-31 1844 A1 5477 AK 6583 AK 14572 AK 23112 AK Page 18 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-03-01 Item Description Valid to: 2018-12-31 A470 PP874K Key Panel 7" TFT 800x480 widescreen (16:9). Requires Panel Builder 800 Version 6 for configuration. To protect the front, it's recommended to use the RX874K Key cover. A480 PP877K Key Panel 10.4" TFT 640x480 (4:3). Requires Panel Builder 800 Version 6 for configuration. To protect the front, it's recommended to use the RX877K Key cover. 2.1.3 High Performance Touch Panels A510 PP882 High Performance Touch Panel 12" TFT 1280x800 widescreen (16:10). Requires Panel Builder 800 Version 6 for configuration. To protect the front, it's recommended to use the RX882 Touch cover. A520 PP885 High Performance Touch Panel 15" TFT 1280x800 widescreen (16:10). Requires Panel Builder 800 Version 6 for configuration. To protect the front, it's recommended to use the RX885 Touch cover. 2.1.4 Black Touch Panels A545 PP874M Black Touch Panel 7" TFT 800x480 widescreen (16:9). Requires Panel Builder 800 Version 6 for configuration. To protect the front, it's recommended to use the RX874 Touch cover. A550 PP885M Black Touch Panel 15" TFT 1280x800 widescreen (16:10). Requires Panel Builder 800 Version 6 for configuration. To protect the front, it's recommended to use the RX885 Touch cover. A555 PP885H Black Touch Panel 15" High Brightness 1000 cd/m? TFT 1280x800 widescreen (16:10). Requires Panel Builder 800 Version 6 for configuration. To protect the front, it's recommended to use the RX885 Touch cover. 2.1.5 Rugged Touch Panels A565 PP880R Rugged Touch Panel 7" TFT 800x480 widescreen (16:9). Requires Panel Builder 800 Version 6 for configuration. To protect the front, it's recommended to use the RX885 Touch cover. A570 PP885R Rugged Touch Panel 15" Max Qty Article No 3BSE069273R1 4 Panel 800 Version 6 3BSE070940/J - SVE-CHP List Price, SEK LP DC 20741 AK 3BSE069274R1 31305 AK 3BSE069275R1 3BSE069276R1 36689 AK 44101 AK 3BSE069279R1 3BSE069280R1 3BSE069281R1 20202 AK 59958 AK 74948 AK 3BSE069295R1 3BSE069296R1 44428 AK 59958 AK 2018-10-31 Page 19 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-03-01 Item Description Valid to: 2018-12-31 TFT 1280x800 widescreen (16:10). Requires Panel Builder 800 Version 6 for configuration. To protect the front, it's recommended to use the RX885 Touch cover. A575 PP886H Rugged Touch Panel 15" High Brightness 1000 cd/m2 TFT 1280x800 widescreen (16:10). Requires Panel Builder 800 Version 6 for configuration. To protect the front, it's recommended to use the RX885 Touch cover. Max Qty Article No 4 Panel 800 Version 6 3BSE070940/J - SVE-CHP List Price, SEK LP DC 3BSE069297R1 74948 AK 2.1.6 Dongles Requires Panel 800 Runtime Version 6 to be installed on the PC, The USB dongle enables the runtime and the amount of signals. A610 Panel 800 Version 6 dongle 250 tags USB dongle for 250 signals (tags). 3BSE069282R1 9658 AK Enables the possibility to run Panel 800 version 6 applications in a PC, using Panel 800 runtime. A620 Panel 800 Version 6 dongle 2000 tags USB dongle for 2000 signals (tags). 3BSE069283R1 15453 AK Enables the possibility to run Panel 800 version 6 applications in a PC, using Panel 800 runtime. A630 Panel 800 Version 6 dongle 4000 tags USB dongle for 4000 signals (tags). 3BSE069284R1 23180 AK Enables the possibility to run Panel 800 version 6 applications in a PC, using Panel 800 runtime. 2.2 Accessories 2.2.1 Communication Interface for Panel 800 A710 CB802 Profibus DP Interface PROFIBUS DP slave expansion module for Panel 800 Version 6 panels. Not possible to use for PP885M, PP885H, PP880R, PP885R nor PP886H. Not marine certified. A720 CB810 USB to Ethernet adapter for progr. USB to Ethernet adapter with software. Cross over Ethernet patch cable included. 3BSE069285R1 3BSE042255R1 8394 AK 1425 AK 2.2.2 Connection Cables for Panel 800 A810 TK858V002 Adapter cable (CAB 107) Adapter cable RS232 - RS485 0.2 m 9 pin D-Sub to 25 pin D-Sub. For using 5.1 RS422/485 cables on Version 6 panels. A820 TK859V000 Gender changer (TK859V000) Gender changer 9 pin D-Sub male/male. A830 TK860V001 Splitter cable (CAB 109) Splitter cable Version 6 panel. Y-split cable to utilize more than two COM ports on Version 6 panels. 3BSE069474R1 3BSE069475R1 3BSE069476R1 951 AK 217 AK 1495 AK 2018-10-31 Page 20 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-03-01 Item Description Valid to: 2018-12-31 Max Qty Article No 2.2.3 Front Protections A910 RX871 Touch cover for PP871 Plastic cover to protect Process Panel PP871. A915 RX874 Touch cover for PP874 Plastic cover to protect Process Panel PP874. Also possible to use for PP874M and PP880R A920 RX877 Touch cover for PP877 Plastic cover to protect Process Panel PP877. A925 RX874K Key cover for PP874K Plastic cover to protect Process Panel PP874K. A930 RX877K Key cover for PP877K Plastic cover to protect Process Panel PP877K. A935 RX882 Touch cover for PP882 Plastic cover to protect Process Panel PP882. A940 RX885 Touch cover for PP885 Plastic cover to protect Process Panel PP885. Also possible to use for PP885R, PP885M, PP885H and PP886H 3BSE069286R1 3BSE069287R1 3BSE069288R1 3BSE069289R1 3BSE069290R1 3BSE069291R1 3BSE069292R1 2.2.4 Miscellaneous A995 MB802V2 SD card 2GB Secure Digital memory card 2GB Industrial grade for Version 6 panels. *** End of price list *** 3BSE069477R1 4 Panel 800 Version 6 3BSE070940/J - SVE-CHP List Price, SEK LP DC 190 AK 299 AK 381 AK 513 AK 541 AK 435 AK 516 AK 680 AK 2018-10-31 Page 21 of 47 This page is intentionally blank ABB Control Technologies - Produktförsäljning Sverige Price Book Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-03-15 Valid to: 2018-12-31 6 AC 800M used for Compact Control 6.0 3BSE087427/D - SVE-CHP List Price, SEK 2018-10-31 Page 23 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-03-15 Item Description Valid to: 2018-12-31 6 AC 800M used for Compact Control 6.0 3BSE087427/D - SVE-CHP List Price, SEK Max Qty Article No LP DC 1 System Units The Tool Cable TK212A is most useful when working with AC 800M. Please order a cable (Item A315) together with your first order of PM851AK01, PM856AK01, PM858K01, PM858K02, PM860AK01, PM861AK01, PM861AK02, PM862K01, PM862K02, PM864AK01, PM864AK02, PM866K01, PM866K02, PM866AK01, PM866AK02, PM891K01 or PM891K02. 1.1 AC 800M Processor Units A110 PM851AK01 Processor Unit 24MHz and 12 MB Package including: - PM851A, CPU - TP830, Baseplate - TB850, CEX-bus terminator - TB807, ModuleBus terminator - Battery for memory backup (4943013-6) - No license included A111 PM856AK01 Processor Unit 24MHz and 16MB Package including: - PM856A, CPU - TP830, Baseplate - TB850, CEX-bus terminator - TB807, ModuleBus terminator - Battery for memory backup (4943013-6) - No license included A113 PM858K01 Processor Unit 33MHz and 16MB. Package including: - PM858, CPU - TP830, Baseplate - TB850, CEX-bus terminator - TB807, ModuleBus terminator - TB852, RCU-Link terminator - Battery for memory backup (4943013-6) - No license included 3BSE066485R1 3BSE066490R1 3BSE082895R1 Only compatible with 800xA 6.0.2, Compact Control Builder 6.0.0-1 and onwards. Please see Product Update for more information. A114 PM858K02 Redundant Processor Unit 33MHz and 16MB. Package including: - 2 pcs PM858, CPU - 2 pcs TP830, Baseplate - 2 pcs TB807, ModuleBus terminator - TK850, CEX-bus expansion cable - TK851, RCU-Link cable - 2 pcs Battery for memory backup (4943013-6) - No license included. 3BSE082896R1 Only compatible with 800xA 6.0.2, Compact Control Builder 6.0.0-1 and onwards. Please see Product Update for more information. A115 PM860AK01 Processor Unit 48MHz and 16MB Package including: - PM860A, CPU - TP830, Baseplate - TB850, CEX-bus terminator - TB807, ModuleBus terminator - Battery for memory backup (4943013-6) - No license included 3BSE066495R1 2018-10-31 14673 XH 27513 XH 35100 XH 65313 XH 47022 XH Page 24 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-03-15 Item Description Valid to: 2018-12-31 6 AC 800M used for Compact Control 6.0 3BSE087427/D - SVE-CHP List Price, SEK Max Qty Article No LP DC A129 PM862K01 Processor Unit 67MHz and 32MB. Package including: - PM862, CPU - TP830, Baseplate - TB850, CEX-bus terminator - TB807, ModuleBus terminator - TB852, RCU-Link terminator - Battery for memory backup (4943013-6) - No license included. Only compatible with 800xA 6.0.2, Compact Control Builder 6.0.0-1 and onwards. Please see Product Update for more information. A130 PM862K02 Redundant Processor Unit 67MHz and 32MB. Package including: - 2 pcs PM862, CPU - 2 pcs TP830, Baseplate - 2 pcs TB807, ModuleBus terminator - 1 pcs TK850, CEX-bus expansion cable - 1 pcs TB851, RCU-Link cable - 2 pcs Battery for memory backup (4943013-6) - No license included. Only compatible with 800xA 6.0.2, Compact Control Builder 6.0.0-1 and onwards. Please see Product Update for more information. A146 PM866AK01 Processor Unit 133MHz and 64MB. Package including: - PM866A, CPU - TP830, Baseplate - TB850, CEX-bus terminator - TB807, ModuleBus terminator - TB852, RCU-Link terminator - Battery for memory backup (4943013-6) - No license included. A147 PM866AK02 Redundant Processor Unit 133MHz and 64MB. Package including: - 2 pcs PM866A, CPU - 2 pcs TP830, Baseplate - 2 pcs TB807, ModuleBus terminator - 1 pcs TK850, CEX-bus expansion cable - 1 pcs TB851, RCU-Link cable - 2 pcs Battery for memory backup (4943013-6) - No license included. A150 PM891K01 Processor Unit 450MHZ and 256MB. Package including: - PM891 CPU Module - TB850, CEX-bus terminator - TB853, RCU Control Link Terminator - No license included A160 PM891K02 Redundant Processor Unit 450MHZ and 256MB. Package including: - 2 pcs PM891K01 Processor Unit - TK850V007 CEX-bus Extension Cable - TK855 RCU Data Link Cable - TK856 RCU Control Link Cable - No license included A175 SB822 Rechargeable Battery Unit 3BSE076940R1 110842 XH 3BSE081636R1 202563 XH 3BSE076939R1 169339 XH 3BSE081637R1 308411 XH 3BSE053241R1 284079 XH 3BSE053242R1 530634 XH 3BSE018172R1 4362 AH Page 25 of 47 2018-10-31 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-03-15 Item Description Valid to: 2018-12-31 External DIN-rail mounted rechargeable battery unit including lithium-ion battery, 24V DC connector and connection cable TK821V020. Equivalent amount of Lithium metal is 0.8g (0.03oz) A180 MB801V512 Compact Flash card Expansion Compact Flash memory for Panel 800 Version 5. 512 MB 6 AC 800M used for Compact Control 6.0 3BSE087427/D - SVE-CHP List Price, SEK Max Qty Article No LP DC 3BSE042257R1 1495 AK 1.3 Extra Batteries For extra Lithium batteries (4943013-6), please refer to ABB Parts Online 2 Communication 2.1 Control Network No articles, such as cables, hubs, switches etc, for Control Network are included in this price list. Please refer to Product Guide AC 800M, for recommended articles. 2.2 Serial Interfaces on TP830 RS232-C interfaces for protocols COMLI, MODBUS, Siemens 3964R, the free-programmable serial protocol etc. Also for connection of engineering tool. A315 TK212A Tool cable RJ45 8P8C plug RJ45 (male) to Dsub-9 (female), length 3 m. RJ45 8P8C plug (with shell). Cable : UL2464 26 AWG x 8C. 3BSC630197R1 355 AK A320 TC562 Short Distance Modem length < 10 km. Point-to-point up to 1 km at 19200 bps. G1 compliant. Power 24V d.c. To be used with CI531, CI532Vxx, CI534Vxx, CI853. 3BSC630049R1 6483 AH A325 TK853V020 Modem Cable, 2m Modem cable for serial interfaces on TP830. 3BSC950201R1 483 AH Cable for connection between modem TC562 and TP830 2.3 Serial Communication Interface RS232-C interfaces for protocols COMLI, MODBUS, Siemens 3964R, the free-programmable serial protocol etc. A405 CI853K01 Dual RS232-C Interface Package including: - CI853, Communication Interface - TP853, Baseplate 3BSE018103R1 15467 XH 2.4 MODBUS TCP A485 CI867K01 Modbus TCP Interface Package including: - CI867, Communication Interface - TP867 , Baseplate 3BSE043660R1 31596 XH 2.5 PROFIBUS DP The required PROFIBUS network components (Linking devices, etc) must be ordered from price list 3BDD 013 232, PROFIBUS Network Components. A510 CI854BK01 PROFIBUS-DP/V1 interface 3BSE069449R1 20447 XH 2018-10-31 Page 26 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-03-15 Item Description Valid to: 2018-12-31 Package including: - CI854, Communication Interface - TP854, Baseplate Only compatible with 800xA 6.0.3.2, Compact Control Builder 6.0.0-2 and onwards. Please see Product Update for more information. A515 CI854AK01 PROFIBUS-DP/V1 interface Package including: - CI854, Communication Interface - TP854, Baseplate Note! This part is not RoHS 2 2011/65/EU compliant. This is a spare part for systems placed on the market before July 22, 2017 and may only be ordered for repair, reuse, updating of functionalities or upgrading of capacity. 2.6 PROFINET IO A555 CI871K01 Profinet IO Interface Package including: - CI871, Communication Interface - TP867, Baseplate 2.7 IEC 61850 A625 CI868K01 IEC61850 Interface Package including: - CI868, Communication Interface - TP867 , Baseplate 2.8 Ethernet IP A635 CI873K01 Ethernet/IP Interface Packaging including: - CI873, Communication Interface - TP867, Baseplate A636 LD 800DN Linking Device EtherNet/IP to DeviceNetPackage including: 1 pcs LD 800DN, 1 pcs Installation Guide, 2 pcs Termination resistors for DeviceNet, 1/4 W, 121 Ohm. Only to be used with CI873 Communication Interface. G1 compliant. 2.9 Advant Fieldbus 100 A645 CI869K01 AF 100 Interface Package including: - CI869, Communication Interface - TP869 , Baseplate Note! This part is exempted from the scope of 2011/65/EU (RoHS) as provided in Article 2(4)(c), (e), (f) and (j) therein (Ref.: 3BSE088609 EU DECLARATION OF CONFORMITY ABB Advant Master Process Control System). 2.10 MasterBus 300 A655 CI855K01 MB 300 Interface Package including: - CI855, MB300 Interface Module - TP853, Base plate 2.11 S100 I/O Bus 6 AC 800M used for Compact Control 6.0 3BSE087427/D - SVE-CHP List Price, SEK Max Qty Article No LP DC 3BSE030220R1 18401 XH 3BSE056767R1 3BSE048845R1 3BSE056899R1 3BSC690164R1 28423 XH 52614 XH 35875 XH 30534 AH 3BSE049110R1 58105 AH 3BSE018106R1 66578 AH Page 27 of 47 2018-10-31 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-03-15 Item Description Valid to: 2018-12-31 6 AC 800M used for Compact Control 6.0 3BSE087427/D - SVE-CHP List Price, SEK Max Qty Article No LP DC A675 CI856K01 S100 I/O Interface Communication between AC800M and S100 system. Including: - CI856, Communication Interface - TP856, Baseplate 3BSE026055R1 2.12 Satt I/O For SATT 19'' rack I/O and S200 I/O via ControlNet. For additional SATT 19" rack I/O components, see price list 3BSE014353 (Interface) in price book 3BSE014360 (SattLine/SattCon). A688 CI865K01 SATT I/O Interface Package including: - CI865, Communication Interface - TP865, Baseplate 3BSE040795R1 2.13 INSUM A695 CI857K01 INSUM Ethernet Interface Package including: - CI857, Communication Interface - TP853, Baseplate 3BSE018144R1 2.14 DriveBus A698 CI858K01 DriveBus Interface Package including: - CI858, Communication Interface - TP858, Baseplate 3BSE018135R1 2.16 Bus Accessories A705 TK850V007 CEX-Bus Extension Cable Length 0,7 m Use of TK850V007 needs TK851 as CEX-bus terminator. A710 TB850 CEX-Bus Terminator With 25-pin DB25P male connector. With screw fixing. A TB850 CEX-Bus terminator must always be installed on the last unit on the CEX bus. A715 TB851 CEX-Bus Terminator With 25-pin DB25S female connector. With screw fixing. When Communication Interface units are mounted on adjacent DIN rails, they are connected by means of a CEX-Bus extension cable (TK850) and terminated using a TB851 CEX-Bus terminator. A716 BC810K02 CEX-bus Interconnection Unit Including: - 2 pcs BC810, Interconnection Unit - 2 pcs TP857, Baseplate - TK851, Interconnection Cable - 2 pcs TB850, CEX-Bus Terminator A717 BC820K02 CEX-Bus Interconnection Unit Allows AC 800M redundant PM858, PM862 or PM866(A) pair to be up to 200 m apart, cables not included. Including: - 2pcs BC820 CEX-Bus Interconnection Unit - 2 pcs TP850 Baseplate - 2 pcs TK857 RCU-Link Cable - 2 pcs TB850, CEX-Bus Terminator 3BSC950192R1 3BSC950193R1 3BSC950194R1 3BSE031155R1 3BSE071500R1 50219 AH 23810 XH 33648 XH 40692 XH 1317 AH 264 AH 307 AH 18217 XH 38795 XH Page 28 of 47 2018-10-31 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-03-15 Item Description Valid to: 2018-12-31 A720 TK851V010 Connection Cable, 1m Used as: - RCU Link Cable - BC810 Interconnection Cable A725 TB852 RCU Link Terminator Terminator for RCU link. A730 TB853 RCU Control Link Terminator Terminator for RCU Control link. A740 TK855 RCU Data Link Cable, 1m Used as RCU Data Link Cable with PM891. A750 TK856 RCU Control Link Cable, 1m Used as RCU Control Link Cable. A760 TK857V003 RCU Link Cable Used with BC820. 3 Power Supply D015 SD822Z Power Supply, 5A Input 115/230V a.c. switch selectable, output 24V d.c., 5A. If redundant power application is required connect to SS822Z Voting Unit. DIN rail mounted. D021 SD831 Power Supply, 3A Input a.c. 100-240 V or d.c. 110-300 V. Output d.c. 24 V 3A. If redundant power application is required connect to SS8XX voting unit. DIN rail mounted. G2 compliant. D022 SD832 Power Supply, 5A Input a.c. 100-120/200-240 V. Output d.c. 24 V 5A, auto-select input. If redundant power application is required connect to SD8XX voting unit. DIN rail mounted. G2 compliant. D023 SD833 Power Supply, 10A Input a.c. 100-120/200-240 V, auto-select input. Output d.c. 24 V 10A. If redundant power application is required connect to SD8XX voting unit. DIN rail mounted. G2 compliant. D024 SD834 Power Supply, 20A Input a.c. 100-240 V or d.c. 110-300 V. Output d.c. 24 V 20A. If redundant power application is required connect to SS8XX voting unit. DIN rail mounted. G2 compliant. D025 SS822Z Power Voting Unit With dual 24V d.c 20A inputs, single 24V d.c. 20A output. Each power input supervised. Used if redundant power supply is required. For use with power supply SD822Z. DIN rail mounted. D027 SS832 Power Voting Unit 6 AC 800M used for Compact Control 6.0 3BSE087427/D - SVE-CHP List Price, SEK Max Qty Article No LP DC 3BSC950262R1 2906 AH 3BSC950263R1 3BSE057022R1 3BSC950356R1 3BSE057021R1 3BSC950375R1 1557 AH 1061 AH 4712 AH 2367 AH 2906 AH 3BSC610054R1 3395 AK 3BSC610064R1 1912 AK 3BSC610065R1 2712 AK 3BSC610066R1 3445 AK 3BSC610067R1 3BSC610055R1 3BSC610068R1 4913 AK 3757 AK 2723 AK 2018-10-31 Page 29 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-03-15 Item Description Valid to: 2018-12-31 Input d.c. 24 V. Dual 24 V to single 24 V, 2x10A. DIN rail mounted. G2 compliant. D030 Mains Breaker Kit for DIN Rail 115/230V 115/230V a.c. with input terminals, breaker and 3 fused (6.3A). Double output terminals. 6 AC 800M used for Compact Control 6.0 3BSE087427/D - SVE-CHP List Price, SEK Max Qty Article No LP DC 3BSE022262R1 3126 AH 4 Mounting Rails D305 Al-profile with DIN Rail, C. Duct, 28,3" Mounting 719mm (28,3") DIN rail length 683mm (26,9") For RE820. D310 Al-profile with DIN Rail, C. Duct, 24" Mounting 592mm (24") DIN rail length 556mm (21,9") D320 Al-profile with DIN Rail, C. Duct, 19" Mounting 465mm (19") DIN rail length 429mm (16,9") 3BSE022257R1 3BSE022256R1 3BSE022255R1 2436 AH 2248 AH 1967 AH 5 User Documentation H210 AC 800M 6.0 Communication Protocols User documentation. H220 AC 800M 6.0 OPC Server User documentation. H230 AC 800M 6.0 Library Object Style Guide User documentation. H240 AC 800M 6.0 PROFIBUS DP Installation User documentation. H250 AC 800M 6.0 PROFIBUS DP Configuration User documentation. H260 AC 800M 6.0 AC 800M DriveBus User documentation. H270 AC 800M 6.0 Controller Hardware User documentation. H280 AC 800M 6.0 IEC 61850 Configuration AC 800M 6.0 IEC 61850 Configuration for CI868 H290 AC 800M 6.0 ProfiNet IO Configuration User documentation. H310 AC 800M 6.0 Ethernet/IP DN Configuration AC 800M 6.0 Ethernet/IP DeviceNet Configuration H320 AC 800M 6.0 Ethernet/IP DN Installation AC 800M 6.0 Ethernet/IP DeviceNet Installation H330 Advant Fieldbus 100 User Manual User documentation. *** End of price list *** 3BSE035982-600 3BSE035983-600 3BSE042835-600 3BDS009029-600 3BDS009030-600 2PAA113566-600 3BSE036351-600 9ARD171385-600 3BDS021515-600 9ARD000014-600 9ARD000015-600 3BSE000506-600 1229 A1 660 A1 660 A1 1229 A1 660 A1 660 A1 1798 A1 1229 A1 1229 A1 660 A1 660 A1 3618 A1 2018-10-31 Page 30 of 47 ABB Control Technologies - Produktförsäljning Sverige Price Book Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-03-15 Valid to: 2018-12-31 7 Compact Control Builder AC 800M 6.0 3BSE078498/D - SVE-CHP List Price, SEK 2018-10-31 Page 31 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-03-15 Item Description Valid to: 2018-12-31 7 Compact Control Builder AC 800M 6.0 3BSE078498/D - SVE-CHP List Price, SEK Max Qty Article No LP DC 0 Control System Lifecycle Support Program Automation Sentinel is the ABB control system lifecycle management program. An introductory trial period to the Automation Sentinel program will be included, at no additional cost, with each new ABB control system software delivery. Please contact your designated Automation Sentinel responsible for any questions or please refer to the Automation Sentinel 3.0 product guide for detailed information on the program and on how to calculate and order Automation Sentinel subscriptions. 0.1 Upgrade Orders A040 Compact Control Builder AC800M 6.0 Media This item can be ordered by users with a valid Automation Sentinel agreement for Compact Control Builder AC 800M or OPC Server for A C 800M. It includes media and documentation for Compact Control Builder AC 800M and OPC server for AC 800M. Product revision is 6.0.0-2 No license is included. 1 3BSE046066R60 1594 A1 1 Compact Control Builder AC 800M A110 Compact Control Builder AC 800M 6.0 Product Box including: - Licenses for one Compact Control Builder AC 800M, one OPC Server for AC 800M, and one SoftController. - DVD with software for Compact Control Builder AC 800M, OPC Server for AC 800M, and SoftController. - Firmware for AC 800M and its communication units. - Manuals as pdf-files - A Getting Started manual Product revision is 6.0.0-2 A120 OPC Server for AC 800M 6.0 License for one OPC Server for AC 800M. 1 3BSE040360R60 17105 A1 1 3BSE039915R60 6670 A1 2 User Documentation H130 CCB AC 800M 6.0 Getting Started Compact Control Builder AC 800M 6.0 Getting Started H140 CCB AC 800M 6.0 Configuration Compact Control Builder AC 800M 6.0 Configuration H150 CCB AC 800M 6.0 Planning Compact Control Builder AC 800M 6.0 Planning H160 CCB AC 800M 6.0 Binary/Analog Handeling Compact Control Builder AC 800M 6.0 Binary and Analog Handeling *** End of price list *** 3BSE041584-600 3BSE040935-600 3BSE044222-600 3BSE041488-600 1229 A1 1798 A1 1229 A1 1798 A1 2018-10-31 Page 32 of 47 ABB Control Technologies - Produktförsäljning Sverige Price Book Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Valid to: 2018-12-31 8 S800 I/O used for Compact Control 6.0 3BSE087428/C - SVE-CHP List Price, SEK 2018-10-31 Page 33 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Item Description Valid to: 2018-12-31 8 S800 I/O used for Compact Control 6.0 3BSE087428/C - SVE-CHP List Price, SEK Max Qty Article No LP DC 0 Extended warranty for S800 I/O Hardware We can offer an extended warranty for one, two, or three years in addition to normal warranty conditions for S800 I/O Hardware. See price list Extended Warranty 3BSE049908. 0.5 ISA-S71.04 level G3 Compliance Modules are compliant to ISA-S71.04 level G3, unless explicitly stated differently. 1 COMMUNICATION 1.1 Field Communication Interface A015 CI801 PROFIBUS FCI S800 Interface Including: - 1 pcs Power Supply Connector - 1 pcs TB807 Modulebus Terminator The basic system software loaded in CI801 does not support the following I/O modules: DI825, DI830, DI831, DI885, AI880A, DI880 and DO880. A018 CI801 Engineering kit SW1.3 Including: - CD with GSD file, Memory Maps and Release Note. - Reference Manual Memory Maps for CI801. A040 CI840A PROFIBUS DP-V1 Interface For redundant communication interface two CI840A, and one TU847 or one TU846 must be ordered. A045 CI840 Engineering kit SW 4.0 Including: - CD with GSD file, Memory Maps and Release Notes. - Reference Manual Memory Maps for CI840. A074 TU846 MTU for CI840 For 1+1 CI840 Supporting redundant I/O. Vertical mounting of modules. Including: - 1 pcs Power Supply Connector - 2 pcs TB807 Modulebus Terminator A075 TU847 MTU for CI840 For 1+1 CI840 Supporting non-redundant I/O. Vertical mounting of modules. Supporting non-redundant I/O. Including: - 1 pcs Power Supply Connector - 1 pcs TB807 Modulebus Terminator A080 Extra, Front label set FCI Sheet with 12 labels For TB820 A090 Extra, Label set, item design. FCI Sheet with 40 labels For TB820 A095 Mounting kit, vertical CI801/CI840/TB840 For vertical mounting of CI801, CI840, and TB840 on a vertical DIN rail. A100 Mounting profile kit DIN rails and duct DIN rail length : 1650mm + 210mm (65" + 8.3") 3BSE022366R1 3BSE038540R1300 3BSE041882R1 3BSE031694R4000 3BSE022460R1 3BSE022462R1 3BSC970089R1 3BSC970091R1 3BSE040749R1 3BSE049768R1 2018-10-31 5396 XK 1385 AK 11005 XK 1625 AK 4230 AK 3126 AK 216 AK 216 AK 1713 AK 4110 AH Page 34 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Item Description Valid to: 2018-12-31 8 S800 I/O used for Compact Control 6.0 3BSE087428/C - SVE-CHP List Price, SEK Max Qty Article No LP DC A110 Al-profile with DIN Rail, C. Duct, 19" Mounting 465mm (19") DIN rail length 429mm (16,9") A120 Al-profile with DIN Rail, C. Duct, 24" Mounting 592mm (24") DIN rail length 556mm (21,9") 3BSE022255R1 3BSE022256R1 1967 AH 2248 AH 1.2 Upgrade Kit and Tool Cables Upgrading of CI801, CI840A to latest software version are available for download from ABB Library/Solutions Bank. Item A195 is cable connecting a PC to CI840 for download of software. CI801 requires items A195 and A197 for download of software A195 TK212A Tool cable RJ45 8P8C plug RJ45 (male) to Dsub-9 (female), length 3 m. RJ45 8P8C plug (with shell). Cable : UL2464 26 AWG x 8C. 3BSC630197R1 355 AK A197 FS801K01 Service adapter kit Including: - 1 pcs Service adapter FS801 - 1 pcs cable TK802 3BSE038407R1 2274 AK For connection of CI801 to PC. A cable TK212A is also needed. 2 S800 I/O and S800L I/O 2.1 S800 I/O Modules 2.1.1 Analog Input Modules B020 AI810 Analog Input 8 ch 0(4)..20mA, 0..10V, 12Bit, single ended. Use Module Termination Unit TU810, TU812, TU814, TU818, TU830, TU833, TU835, TU838, TU850. B025 AI815 Analog Input HART 8 ch 0(4)..20mA, 0(1)..5V, 12bit, single ended. Current limited transmitter power distribution. Use Module Termination Unit TU810, TU812, TU814, TU818, TU830, TU833, TU835, TU838. B030 AI820 Analog Input 4 ch +-20mA, 0(4)...20mA, +-10V, +-5V, 0(1)...5V, diff., 50V CMV,. Rin(curr)250 Ohms, 14bit + sign. Individually galvanic isolated channels. Use Module Termination Unit TU810, TU812, TU814, TU830, TU833. B035 AI825 Analog Input 4 ch -20..20mA, -10..10V, 14bit + sign. Individually galvanic isolated channels. Use Module Termination Unit TU811, TU813, TU831. B040 AI830A Analog input RTD 8 ch Pt100, Ni100/120, Cu10, R. Use Module Termination Unit TU810, TU812, TU814, TU830, TU833. B050 AI835A Thermocouple/mV Input 8 ch Use Module Termination Unit TU810, TU812, TU814, TU818, TU830, TU833. B053 AI843 Thermocouple/mV Input S/R 8 ch 3BSE008516R1 3BSE052604R1 3BSE008544R1 3BSE036456R1 3BSE040662R1 3BSE051306R1 3BSE028925R1 8032 XK 9908 XK 10536 XK 11806 XK 10495 XK 10543 XK 17036 XK 2018-10-31 Page 35 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Item Description Valid to: 2018-12-31 Single or redundant. 16bit. Use Module Termination Unit TU818, TU830, TU833, TU842, TU843, TU852. B055 AI845 Analog Input S/R HART 8 ch 0(4)..20mA, 0(1)..5V, 12bit, single ended. Current limited transmitter power distribution. Advanced on-board diagnostics. HART support. Use Module Termination Unit TU810, TU812, TU814, TU818, TU830, TU833, TU835, TU838, TU844, TU845, TU854 B060 AI890 Analog Input IS 8 ch 0(4)...20mA single ended. Intrinsic Safety Interface. Use Module Termination Unit TU890 or TU891. B065 AI893 Analog Input TC/RTD IS 8 ch For TC and RTD sensors. Intrinsic Safety Interface. Use Module Termination Unit TU890 or TU891. B070 AI895 Analog Input IS HART 8 ch 4...20mA single ended. Intrinsic Safety Interface and HART. Use Module Termination Unit TU890 or TU891 2.1.2 Analog Output Modules B110 AO810V2 Analog Output 8 ch 0(4)..20mA, 14bit RLmax 500/850 Ohms. Use module Termination Unit TU810, TU812, TU814, TU830 or TU833. B115 AO815 Analog Output HART 8 ch 1x8 ch. 4..20mA, 12bit, RLmax 750 ohm. Use Module Termination Unit TU810, TU812, TU814, TU830 or TU833. B120 AO820 Analog Output 4 ch +-20mA, 0(4)...20mA, +-10V, 12bit+sign. Individually galvanic isolated channels. RL max 500 Ohms. Use Module Termination Unit TU810, TU812, TU814, TU830, TU833. B125 AO845A Analog Output S/R HART 8 ch (0) 4..20mA, 12bit, RLmax 750 ohm. Single or redundant. Loop supervised DI function. Use Module Termination Unit TU810, TU812, TU814, TU830, TU833, TU842, TU843, TU852. B130 AO890 Analog Output IS 8 ch 0(4)...20mA. RL max 750 ohm. Intrinsic Safety Interface. Use Module Termination Unit TU890 or TU891. B140 AO895 Analog Output IS HART 8 ch 0(4)...20mA. RL max 750 ohm. Intrinsic Safety Interface and HART. Use Module Termination Unit TU890 or TU891. 2.1.3 Digital Input Modules B210 DI810 Digital Input 24V 16 ch Isolated in two groups of 8 channels. Use Module Termination Unit TU810, TU812, TU814, TU818, TU830, TU833, TU838, TU850. B220 DI811 Digital Input 48V 16 ch Isolated in two groups of 8 channels. Use Module Termination Unit TU810, TU812, TU814, TU818, TU830, TU833, TU838, TU850. 8 S800 I/O used for Compact Control 6.0 3BSE087428/C - SVE-CHP List Price, SEK Max Qty Article No LP DC 3BSE023675R1 12379 XK 3BSC690071R1 3BSC690141R1 3BSC690086R1 11302 XK 14469 XK 13020 XK 3BSE038415R1 3BSE052605R1 3BSE008546R1 3BSE045584R1 3BSC690072R1 3BSC690087R1 11302 XK 12703 XK 14856 XK 14800 XK 13310 XK 15132 XK 3BSE008508R1 3BSE008552R1 2843 XK 3436 XK Page 36 of 47 2018-10-31 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Item Description Valid to: 2018-12-31 B230 DI814 Digital Input 24V Current 16 ch Isolated in two groups of 8 channels. Current sourcing. Use Module Termination Unit TU810, TU812, TU814, TU830, TU833, TU838. B235 DI818 Digital Input 24V 32 ch Isolated in two groups of 16 channels. Use Module Termination Unit TU818, TU819, TU830. B240 DI820 Digital Input 120V a.c. 8 ch Individually galvanic isolated channels. Use Module Termination Unit TU811, TU813, TU831, TU839, TU851. B250 DI821 Digital Input 230V 8 ch Individually galvanic isolated channels. Use Module Termination Unit TU811, TU813, TU831, TU839, TU851. B255 DI825 Digital Input 125V SOE 8 ch Individually galvanic isolated channels. Use Module Termination Unit TU811, TU813, TU831. B258 DI828 Digital Input 120V 16 ch Individually galvanic isolated channels. Use Module Termination Unit TU851. B260 DI830 Digital Input 24V SOE 16 ch Isolated in two groups of 8 channels. Use Module Termination Unit TU810, TU812, TU814, TU818, TU830, TU833, TU838, TU850. B270 DI831 Digital Input 48V SOE 16 ch Isolated in two groups of 8 channels. Use Module Termination Unit TU810, TU812, TU814, TU818, TU830, TU833, TU838, TU850. B275 DI840 Digital Input 24V S/R 16 ch Single or redundant. Advanced On-Board diagnostics. Use Module Termination Unit TU810, TU812, TU814, TU818, TU830, TU833, TU838, TU842, TU843, TU852. B285 DI890 Digital Input IS 8 ch Intrinsic Safety Interface. Individually galvanic isolated channels. Use Module Termination Unit TU890 or TU891. 2.1.4 Digital Output Modules B310 DO810 Digital Output 24V 16 ch Isolated in two groups of 8 channels. 0.5A, Short circuit proof. Use Module Termination Unit TU810, TU812, TU814, TU830, TU833. B320 DO814 Digital Output Current 16 ch Isolated in two groups of 8 channels. 0,5A , shortcut circuit proof. Current sinking. Use Module Termination Unit TU810, TU812, TU814, TU830, TU833, TU838. B330 DO815 Digital Output 24V 8 ch 8 S800 I/O used for Compact Control 6.0 3BSE087428/C - SVE-CHP List Price, SEK Max Qty Article No LP DC 3BUR001454R1 3112 XK 3BSE069052R1 3BSE008512R1 3BSE008550R1 3BSE036373R1 3BSE069054R1 3BSE013210R1 3BSE013212R1 3BSE020836R1 5686 XK 2567 XK 2767 XK 7107 XK 5092 XK 8025 XK 8273 XK 9142 XK 3BSC690073R1 4892 XK 3BSE008510R1 3BUR001455R1 3BSE013258R1 3388 XK 3767 XK 3650 XK 2018-10-31 Page 37 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Item Description Valid to: 2018-12-31 Isolated in two groups of 4 channels. 2.0A short circuit proof. Use Module Termination Unit TU810, TU812, TU814, TU830, TU833. B335 DO818 Digital Output 24V 32 ch Isolated in two groups of 16 channels. 0.5A, Short circuit proof. Use Module Termination Unit TU818, TU819, TU830. B340 DO820 Digital Output Relay 8 ch 24-230V a.c../d.c. 3A, cos phi>0.4, d.c. 42W. Individually galvanic isolated channels. Use Module Termination Unit TU811, TU813, TU831, TU836, TU837, TU851. B350 DO821 Digital Output Relay 8 ch 24-230V a.c./d.c.. 3A, cos phi>0.4, d.c. 42W, normal closed. Individually galvanic isolated channels. Use Module Termination Unit TU811, TU813, TU831, TU836, TU837, TU851. B351 DO828 Digital Output, Relay 16 ch Individually galvanic isolated channels. 5-250V a.c and 5-125V d.c, max 2A. Use Module Termination Unit TU851. B353 DO840 Digital Output 24V S/R 16 ch Isolated in two groups of 8 channels. Single or redundant. 0.5A. Advanced On-board diagnostics. Use Module Termination Unit TU810, TU812, TU814, TU830, TU833, TU842, TU843, TU852. B355 DO890 Digital Output IS 4 ch Intrinsic Safety Interface. Individually galvanic isolated channels. Use Module Termination Unit TU890 or TU891. 2.1.5 Pulse Counting Modules B360 DP820 Pulse Counter RS-422 2 ch bidirectional pulse counters and frequency measurement, current, 5V, (12v), 24V. 1,5MHz Rated isol 50V Use Module Termination Unit TU810, TU812, TU814, TU830, TU833. B365 DP840 Pulse Counter S/R 8 ch Pulse Counter or Frequency Measurement Module. Redundant or single. 0.5Hz - 20kHz. Use Module Termination Unit TU810, TU812, TU814, TU818, TU830, TU833, TU842, TU843, TU844, TU845, TU852, TU854. 2.1.6 Label sets for I/O Modules B410 Transparent film fronts Set of 12 transparent plastic film fronts. To be used with ordinary paper quality. B420 White colored plastic coated paper One sheet of size A4. Original paper quality. No need to use transparent films. 2.2 Module Termination Units C005 TU805K01 Termination Units 2- or 3-wire 8 S800 I/O used for Compact Control 6.0 3BSE087428/C - SVE-CHP List Price, SEK Max Qty Article No LP DC 3BSE069053R1 3BSE008514R1 3BSE013250R1 3BSE069055R1 3BSE020838R1 6783 XK 3188 XK 3402 XK 6376 XK 11047 XK 3BSC690074R1 5651 XK 3BSE013228R1 3BSE028926R1 22080 XK 18975 XK 3BSE072159R1 3BSE072160R1 3BSE035990R1 225 AK 224 AK 6141 AK 2018-10-31 Page 38 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Item Description Valid to: 2018-12-31 Includes 10 pcs of Termination Unit TU805 for DI801 and DO801. C010 TU810V1 Compact MTU, 50V Compact Module Termination Unit 2x8 signal terminals. C020 TU811V1 Compact MTU, 250V Compact Module Termination Unit 1x8 signal terminals. C030 TU812V1 Compact MTU, 50V, D-sub Compact Module Termination Unit with 25 pin D-sub connector, rated isol. 50V. D-sub (female) connector is not enclosed. C035 TU813 Compact MTU, 250V Crimped snap-in connectors. C040 TU814V1 Compact MTU, 50V, snap-in con. Compact Module Termination Unit 2x8 Signal terminals for crimped snap-in connectors. Detachable (pluggable) connectors are enclosed. C045 TU818 Compact MTU, 50V Compact Module Terminatin Unit with 1x32 (and 2x16) signal terminals. C046 TU819 Compact MTU, 50V Compact Module Termination Unit with 2x25 pin D-sub connector, D-sub (female) connector is not enclosed. C050 TU830V1 Extended MTU, 50V Extended Module Termination Unit 2x16 signal terminals. C060 TU831V1 Extended MTU, 250V Extended Module Termination Unit 2x8 signal terminals. C065 TU833 Extended MTU, 50V 2x16 signal terminals, Spring-cage terminals. C070 TU835V1 Extended MTU, 50V, Fused Extended Module Termination Unit 8 fused power outlets, 8 signal terminals. C080 TU836V1 Extended MTU, 250V, Fused Extended Module Termination Unit 2x4 fused signals, 2x4 return terminals, 2x2 L 2x2N terminals. C090 TU837V1 Extended MTU, 250V, Fused Extended Module Termination Unit 8x1 fused isol. signals, 8x1 L terminals, 2x6 N terminals. C100 TU838 Extended MTU, 50V Extended Module Termination Unit 2x4 fused transducer power outlets, 16 signal terminals, 2x4 return terminals, 2x2 L+, 2x2 L- terminals. Module is mounted horizontally. C101 TU839 Extended MTU, 250V Extended Module Termination Unit, 2x8 signal terminals 2x4 fused sensor power. C102 TU842 Redundant MTU, 50V Used with redundant I/O. Horizontal DIN rail mounting. C104 TU843 Redundant MTU, 50V Used with redundant I/O. Vertical DIN rail mounting. 8 S800 I/O used for Compact Control 6.0 3BSE087428/C - SVE-CHP List Price, SEK Max Qty Article No LP DC 3BSE013230R1 3BSE013231R1 3BSE013232R1 3BSE036714R1 3BSE013233R1 1104 AK 1104 AK 1435 AK 1463 AK 1463 AK 3BSE069209R1 3BSE068891R1 3BSE013234R1 3BSE013235R1 3BSE038726R1 3BSE013236R1 3BSE013237R1 3BSE013238R1 3BSE008572R1 1559 AK 1746 AK 1373 AK 1104 AK 1511 AK 1987 AK 1987 AK 1980 AK 1987 AK 3BSE046966R1 3BSE020850R1 3BSE021443R1 1421 AK 2456 AK 2456 AK Page 39 of 47 2018-10-31 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Item Description Valid to: 2018-12-31 C106 TU844 Redundant MTU, 50V Used with redundant I/O. Horizontal DIN rail mounting. Shunt Stick not included. C108 TU845 Redundant MTU, 50V Used with redundant I/O. Vertical DIN rail mounting. Shunt Stick not included. C109 TU850 Extended MTU, 50V 2x8 signal terminals and 2x8 disconnetable current limited sensor/transmitter outlet power terminals. C115 TU851 Extended MTU, 250V Extended Module Termination Unit with 2x16 signal terminals. C120 TU852 MTU, Redundant , 50V Used with redundant I/O. Horizontal DIN rail mounting. With 2x25 pin D-sub connector. C130 TU854 MTU, Redundant, 50V Used with redundant I/O. Horizontal DIN rail mounting. With 1x25 pin D-sub connector. Shunt Stick not included. C170 TU890 IS MTU Module Termination Unit with Intrinsic Safety Interface, 3x9 signal terminals. 8 S800 I/O used for Compact Control 6.0 3BSE087428/C - SVE-CHP List Price, SEK Max Qty Article No LP DC 3BSE021445R1 2912 AK 3BSE021447R1 2912 AK 3BSE050930R1 3BSE068782R1 3BSE069964R1 1987 AK 1470 AK 2719 AK 3BSE069966R1 3264 AK 3BSC690075R1 1456 AK Including wiring separator. C180 TU891 non-IS MTU Module Termination Unit for 3x9 signal terminals. For non Intrinsic Safety. C190 TY801K01 8pcs Shunt Stick 125 + 125 ohms shunt. Used for AI845 and AI880A on TU834, TU844, TU845, TU854. C193 TY804K01 8pcs Shunt Stick 1000 ohms shunt. Used for DP840 on TU844, TU845, TU854. C194 TY805K01 8pcs Shunt Stick 125 + 125 ohms shunt with current limitation on transmitter power. Used for AI845 and AI880A on TU834, TU844, TU845, TU854. C195 TY820K01 10pcs Temperature Sensor TY820 is a temperature sensor with a PT 100 element. Used with AI835/AI835A and AI843 to measure cold junction Temperature. 2.3 S800L I/O Modules 2.3.1 Analog Input Modules C210 AI801 Analog Input 8 ch 0(4)..20mA, 12bit, single ended. 2.3.2 Analog Output Modules 2018-10-31 3BSC840157R1 3BSE023607R1 3BSE033670R1 3BSE081160R1 3BSE056980R1 3BSE020512R1 1628 AK 1380 AK 1387 AK 2587 AK 7624 AK 5071 XK Page 40 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Item Description Valid to: 2018-12-31 8 S800 I/O used for Compact Control 6.0 3BSE087428/C - SVE-CHP List Price, SEK Max Qty Article No LP DC C255 AO801 Analog output 8 ch 0(4)...20mA, 12 bit, RLmax 850 Ohm. 2.3.3 Digital Input Modules C265 DI801 Digital Input 24V 16 ch Current sink. C266 DI802 Digital Input 120V 8 ch Individually galvanic isolated channels. C267 DI803 Digital Input 230V 8 ch Individually galvanic isolated channels. 2.3.4 Digital Output Modules C285 DO801 Digital Output 24V 16 ch 0.5A C286 DO802 Digital Output Relay 8 ch 24-230V, a.c./d.c. Individually galvanic isolated channels. 2.3.5 Label sets for S800L I/O Modules C310 Label Set S800L, 16ch Text colour: Black , Text style: Helv. reg., Text height: 2mm, Material: Polyesterfilm Xeroperm t=0,12 Sheet with 12 labels for 16 channels I/O modules. C320 Label Set S800L, 8ch Text colour: Black , Text style: Helv. reg., Text height: 2mm, Material: Polyesterfilm Xeroperm t=0,12 Sheet with 12 labels for 8 channels I/O modules. 2.4 ModuleBus Communication Parts D010 TB805 Bus Outlet Modulebus extension cable adaptor D-sub 25, female One requried per extension cable TK801. D015 TB845 Dual Modulebus outlet Modulebus extension cable adaptor two D-sub, female. Two TK801 cables for redundancy. D020 TB806 Bus Inlet Modulebus extension cable adaptor D-sub 25, male One requried per extension cable TK801. D025 TB846 Dual Modulebus inlet Modulebus extension cable adaptor two D-sub, male. Two TK801 cables for redundancy. D030 TK801V003 Cable, 0.3m Modulebus Extension Shielded Cable 0.3m D-sub 25, male-female D040 TK801V006 Cable, 0.6m Modulebus Extension Shielded Cable 0.6m D-sub 25, male-female D050 TK801V012 Cable, 1.2m Modulebus Extension Shielded Cable 1.2m D-sub 25, male-female 3BSE020514R1 3BSE020508R1 3BSE022360R1 3BSE022362R1 3BSE020510R1 3BSE022364R1 3BSE019419R1 3BSE019419R2 3BSE008534R1 3BSE021437R1 3BSE008536R1 3BSE021439R1 3BSC950089R1 3BSC950089R2 3BSC950089R3 6624 XK 1718 XK 2208 XK 2208 XK 2125 XK 2374 XK 216 AK 216 AK 1021 AK 1394 AK 1021 AK 1601 XK 1007 AK 1145 AK 1421 AK Page 41 of 47 2018-10-31 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Item Description Valid to: 2018-12-31 8 S800 I/O used for Compact Control 6.0 3BSE087428/C - SVE-CHP List Price, SEK Max Qty Article No LP DC D060 TB807 Modulebus terminator Terminator for Modulebus. D070 TB820V2 Modulebus Cluster Modem Optical cluster modem for non redundant operation. Including: 1 pcs Power Supply Connector 1 pcs TB807 Modulebus Terminator D073 TB825 Optical Media Converter Multi Mode Short to long distance optical fiber conversion. For modulebus communication up to 1000m. D074 TB826 Optical Media Converter SingleMode Short to long distance optical fiber conversion. For modulebus communication up to 5000m, for S800 I/O HI up to 20,000m. D075 TB840A Modulebus Cluster Modem Optical cluster modem for 1+1 redundant operation. D093 TB842 Modulebus Optical Port Used together with CI801 and CI840, connected via TB806 or TB846. D095 TU807 Termination Unit for TB840/TB840A For single modulebus I/O. Including: TB807 D096 TU840 Termination Unit for 1+1 TB840 Support for redundant I/O. Including: - 1 pcs Power Supply Connector - 2 pcs TB807 Modulebus Terminator D097 TU841 Termination unit for 1+1 TB840 Support for non-redundant I/O. Including: - 1 pcs Power Supply Connector - 1 pcs TB807 Modulebus Terminator D098 TU848 Termination Unit for 1+1 TB840 MTU with individual power supply. Support for redundant I/O. Including: - 1 pcs Power Supply Connector - 2 pcs TB807 Modulebus Terminator D099 TU849 Termination Unit for 1+1 TB840 MTU with individual power supply. Support for non-redundant I/O. Including: - 1 pcs Power Supply Connector - 1 pcs TB807 Modulebus Terminator D100 TK811V015 POF Cable, 1.5m, Duplex 1.5m latching duplex connector Duplex plastic fibre. D110 TK811V050 POF Cable, 5m, Duplex 5m latching duplex connector Duplex plastic fibre. D120 TK811V150 POF Cable, 15m, Duplex 15m latching duplex connector Duplex plastic fibre. D130 TK812V015 POF Cable, 1.5m, Simplex 1.5m latching connector Simplex plastic fibre. D140 TK812V050 POF Cable, 5m, Simplex 5m latching connector Simplex plastic fibre. 3BSE008538R1 3BSE013208R1 3BSE036634R1 3BSE061637R1 3BSE037760R1 3BSE022464R1 3BSE039025R1 3BSE020846R1 3BSE020848R1 3BSE042558R1 3BSE042560R1 3BSC950107R1 3BSC950107R2 3BSC950107R3 3BSC950118R1 3BSC950118R2 304 AK 3602 XK 6320 XK 11909 XK 7673 XK 1815 XK 1656 AK 3312 AK 2663 AK 3595 AK 3036 AK 455 AK 759 AK 1615 AK 380 AK 573 AK Page 42 of 47 2018-10-31 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Item Description Valid to: 2018-12-31 8 S800 I/O used for Compact Control 6.0 3BSE087428/C - SVE-CHP List Price, SEK Max Qty Article No LP DC D150 TK812V150 POF Cable, 15m, Simplex 15m latching connector Simplex plastic fibre. 3 POWER SUPPLY E020 SD822Z Power Supply, 5A Input 115/230V a.c. switch selectable, output 24V d.c., 5A. If redundant power application is required connect to SS822Z Voting Unit. DIN rail mounted. E030 SS822Z Power Voting Unit With dual 24V d.c 20A inputs, single 24V d.c. 20A output. Each power input supervised. Used if redundant power supply is required. For use with power supply SD822Z. DIN rail mounted. E050 SD831 Power Supply, 3A Input a.c. 100-240 V or d.c. 110-300 V. Output d.c. 24 V 3A. If redundant power application is required connect to SS8XX voting unit. DIN rail mounted. G2 compliant. E060 SD832 Power Supply, 5A Input a.c. 100-120/200-240 V. Output d.c. 24 V 5A, auto-select input. If redundant power application is required connect to SD8XX voting unit. DIN rail mounted. G2 compliant. E070 SD833 Power Supply, 10A Input a.c. 100-120/200-240 V, auto-select input. Output d.c. 24 V 10A. If redundant power application is required connect to SD8XX voting unit. DIN rail mounted. G2 compliant. E080 SD834 Power Supply, 20A Input a.c. 100-240 V or d.c. 110-300 V. Output d.c. 24 V 20A. If redundant power application is required connect to SS8XX voting unit. DIN rail mounted. G2 compliant. E090 SS832 Power Voting Unit Input d.c. 24 V. Dual 24 V to single 24 V, 2x10A. DIN rail mounted. G2 compliant. 5 User Documentation H310 S800 I/O Getting Started User documentation. H320 S800 I/O Modules and Termination Units User documentation. H330 S800 I/O FCI for PROFIBUS DP/DPV1 S800 I/O Fieldbus Communication Interface for PROFIBUS DP/DPV1 H340 S800 I/O Modules & TUs with IS Interface S800 I/O Modules and Termination Units with Intrinsic Safety Interface 3BSC950118R3 3BSC610054R1 3BSC610055R1 3BSC610064R1 3BSC610065R1 3BSC610066R1 3BSC610067R1 3BSC610068R1 3BSE020923-600 3BSE020924-600 3BSE020926-600 3BSE020927-600 1332 AK 3395 AK 3757 AK 1912 AK 2712 AK 3445 AK 4913 AK 2723 AK 3027 A1 3969 A1 3934 A1 1700 A1 Page 43 of 47 2018-10-31 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Item Description Valid to: 2018-12-31 8 S800 I/O used for Compact Control 6.0 3BSE087428/C - SVE-CHP List Price, SEK Max Qty Article No LP DC H350 S200 I/O Hardware User documentation. H370 AC 800M 6.0 Interfacing SATT I/O User documentation. 3BSE021356-600 3BSE042821-600 *** End of price list *** 1798 A1 1229 A1 2018-10-31 Page 44 of 47 ABB Control Technologies - Produktförsäljning Sverige Price Book Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Valid to: 2018-12-31 9 Extended Warranty - AC 800M, S800 & S900 3BSE049908/I - SVE-CHP List Price, SEK 2018-10-31 Page 45 of 47 Compact Products V6 3BSE087426/E - SVE-CHP Effective Date: 2018-01-01 Item Description Valid to: 2018-12-31 9 Extended Warranty - AC 800M, S800 & S900 3BSE049908/I - SVE-CHP List Price, SEK Max Qty Article No LP DC 1 Extended warranty time on hardware for S800 I/O, S900 I/O, Fieldbus and AC 800M Terms and conditions for the supply of products from Local Division Process Automation, LBU Control Technologies within ABB AB in Sweden is valid. Note that the price for the Extended Warranty Time order will be calculated as a percentage of the affected S800 I/O, S900 I/O, Fieldbus and AC 800M articles in the accompanying order. Item A100 => 3% of the affected HW articles within the whole order Item A110 => 6% of the affected HW articles within the whole order Item A120 => 9% of the affected HW articles within the whole order A100 Extended Warranty, 12 additional months S800 I/O, S900 I/O, Fieldbus and AC 800M 3BSE049878R1 A110 Extended Warranty, 24 additional months S800 I/O, S900 I/O, Fieldbus and AC 800M 3BSE049878R2 A120 Extended Warranty, 36 additional months S800 I/O, S900 I/O, Fieldbus and AC 800M 3BSE049878R3 *** End of price list *** 7 N 7 N 7 N 2018-10-31 Page 46 of 47 ABB AB Control Technologies, Automation Products 205 22 Malmö Tel 021-32 50 00 - Begär Styrsystem Kundservcie E-mail: kundservice.styrsystem@se.abb.com 2018-10-31 Page 47 of 47
