Drill/Tap Chart

Solid Wall Threaded Inserts for Metal Carbon Steel

Part

Internal

Drive

Number Thread Drill

Tap

Tool

Thin Wall - Inch

319-3...............10-24...................I.................. 5/16-18............ 500-2

319-332............10-32...................I.................. 5/16-18............ 500-2

319-4..............1/4-20.................Q...................3/8-16............. 500-3

319-428...........1/4-28.................Q...................3/8-16............. 500-3

319-5............ 5/16-18............... X................. 7/16-14............ 500-4

319-524......... 5/16-24............... X................. 7/16-14............ 500-4

319-6..............3/8-16............29/64..............1/2-13............. 500-5

319-624...........3/8-24............29/64..............1/2-13............. 500-5

319-7............ 7/16-14..........33/64............ 9/16-12............ 500-6

319-720......... 7/16-20..........33/64............ 9/16-12............ 500-6

319-8..............1/2-13............37/64..............5/8-11............. 500-7

319-820...........1/2-20............37/64..............5/8-11............. 500-7

Thin Wall - Metric 319-M4............M4-0.7..................I.................. 5/16-18............ 500-1 319-M5............M5-0.8..................I.................. 5/16-18............ 500-2 319-M6............M6-1.0.................Q...................3/8-16............. 500-3 319-M8.......... M8-1.25............... X................. 7/16-14............ 500-4 319-M10........ M10-1.5..........29/64..............1/2-13............. 500-5 319-M12....... M12-1.75.........37/64..............5/8-11............. 500-7

Standard Wall - Inch 329-004............. 4-40............... 5/32................ 10-32............ 500-004 329-006............. 6-32................... 7...................1/4-20.......... 500-006 329-008............. 8-32................... F................. 5/16-18............ 500-1 329-3...............10-24.............. 5/16...............3/8-16............. 500-2 329-332............10-32.............. 5/16...............3/8-16............. 500-2 329-332IC..........10-32.............. 5/16...............3/8-16............. 500-2 329-3IC.............10-24.............. 5/16...............3/8-16............. 500-2 329-4..............1/4-20................. U................. 7/16-14............ 500-3 329-401...........1/4-20................. U................. 7/16-14............ 500-3 329-428...........1/4-28................. U................. 7/16-14............ 500-3 329-4IC............1/4-20................. U................. 7/16-14............ 500-3 329-5............ 5/16-18..........27/64..............1/2-13............. 500-4 329-501......... 5/16-18..........27/64..............1/2-13............. 500-4 329-524......... 5/16-24..........27/64..............1/2-13............. 500-4 329-5IC.......... 5/16-18..........27/64..............1/2-13............. 500-4 329-6..............3/8-16............31/64............ 9/16-12............ 500-5 329-601...........3/8-16............31/64............ 9/16-12............ 500-5 329-624...........3/8-24............31/64............ 9/16-12............ 500-5 329-6IC............3/8-16............31/64............ 9/16-12............ 500-5 329-7............ 7/16-14..........17/32..............5/8-11............. 500-6 329-720......... 7/16-20..........17/32..............5/8-11............. 500-6 329-8..............1/2-13............21/32..............3/4-10............. 500-7 329-801...........1/2-13............21/32..............3/4-10............. 500-7 329-820...........1/2-20............21/32..............3/4-10............. 500-7 329-8IC............1/2-13............21/32..............3/4-10............. 500-7 329-9............ 9/16-12..........21/32..............3/4-10............. 500-7 329-918......... 9/16-18..........21/32..............3/4-10............. 500-7

Part

Internal

Drive

Number Thread Drill

Tap

Tool

Standard Wall - Inch

329-10............5/8-11............49/64............... 7/8-9............... 500-8

329-1018..........5/8-11............49/64............... 7/8-9............... 500-8

329-10F...........5/8-18............49/64............... 7/8-9............... 500-8

329-12............3/4-10...............7/8.....................1-8................. 500-9

329-1216..........3/4-16...............7/8.....................1-8................. 500-9

329-14............. 7/8-9............ 1-7/64............1-1/4-7............500-10

329-1414..........7/8-14........... 1-7/64............1-1/4-7............500-10

329-16................1-8.............. 1-9/32...........1-3/8-12..........500-11

329-1614............ 1-14............. 1-9/32...........1-3/8-12..........500-11

Heavy Wall - Inch 335-4..............1/4-20............27/64..............1/2-13............. 500-3 335-5............ 5/16-18..........31/64............ 9/16-12............ 500-4 335-6..............3/8-16............17/32..............5/8-11............. 500-5 335-8..............1/2-13............49/64............... 7/8-9.................. NA 335-10............5/8-11...............7/8.....................1-8.................... NA

Standard Wall - Metric 450-3..............M3-0.5........... 5.1mm.............M6-1.0.......... 500-004 450-4..............M4-0.7........... 6.9mm............M8-1.25............ 500-1 450-5..............M5-0.8........... 6.9mm............M8-1.25............ 500-1 450-6..............M6-1.0........... 8.6mm............M10-1.5............ 500-3 450-8............ M8-1.25........10.4mm......... M12-1.75........... 500-4 450-10.......... M10-1.5..........14mm.............M16-2.0............ 500-5 450-12......... M12-1.75.........14mm.............M16-2.0............ 500-6 450-16.......... M16-2.0..........21mm.............M24-3.0............ 500-8 450-20.......... M20-2.5..........33mm.............M36-4.0...........500-12 450-24.......... M24-3.0..........33mm.............M36-4.0...........500-12

Standard Wall - Inch/Metric 550-006............. 6-32................. 5.1.................M6-1.0.......... 500-006 550-008............. 8-32................. 6.9................M8-1.25............ 500-1 550-1024...........10-24................ 6.9................M8-1.25............ 500-2 550-1032...........10-32................ 6.9................M8-1.25............ 500-2 550-1420..........1/4-20............... 8.6................M10-1.5............ 500-3 550-5............ 5/16-18............ 10.4............. M12-1.75........... 500-4 550-6..............3/8-16................14.................M16-2.0............ 500-5 550-8..............1/2-13................14.................M16-2.0............ 500-6

Standard Wall - Metric/Inch 650-6..............M6-1.0............. 5/16...............3/8-16............. 500-3 650-8............ M8-1.25..........27/64..............1/2-13............. 500-4 650-10.......... M10-1.5..........31/64............ 9/16-12............ 500-5
650-10F........ M10-1.25.........31/64............ 9/16-12............ 500-5 650-12......... M12-1.75.........21/32..............3/4-10............. 500-6 650-14.......... M14-2.0..........49/64............... 7/8-9............... 500-7 650-16.......... M16-2.0.............7/8.....................1-8................. 500-8
