FMC640
Professional LTE/GNSS
terminal

Quick Manual v1.8

Table of Contents
Know your device .......................................................................... 3 Pinout ................................................................................................. 4
Wiring scheme ............................................................................... 5 Set up your device ......................................................................... 6
How to insert Micro-SIM card and connect the battery................ 6 PC Connection (Windows) ................................................................ 7 How to install USB drivers (Windows)............................................. 7 Configuration (Windows) ................................................................. 7 Quick SMS configuration .................................................................. 9 Mounting recommendations ..................................................... 10 LED indications ............................................................................ 11 Characteristics............................................................................. 11 Basic characteristics ....................................................................... 11 Electrical characteristics ................................................................. 13 Safety information ...................................................................... 14 Certification and Approvals ....................................................... 15

Warranty ...................................................................................... 16 Warranty Disclaimer........................................................................16

FMC640| Wiki

Know your device

Figure 1 FMC640 device view
3

FMC640| Wiki

Pinout

Pin number
1 2 3 4 5 6
7
8 9
10
11 12 13 14
15
16
17
18
19
20

Pin name
GND (-) CAN 1L 1WIRE POWER DIN4 DIN2 CAN 2L
AIN2
DOUT3 DOUT2
AIN3
VCC (+) CAN 1H 1WIRE DATA DIN3
IGN (DIN1)
CAN 2H
AIN1
DOUT4/AIN4
DOUT1
K-Line

Description
Ground SAE J1939 CAN interface Low channel 1 Power supply pin for Dallas 1-Wire� devices Digital input, channel 1 Digital input, channel 2 SAE J1939 CAN interface Low channel 2 Analog input, channel 2. Input range: 0-30V/010V DC Digital output. Open collector output Digital output. Open collector output Analog input, channel 3. Input range: 0-30V/010V DC Power supply (+10-30 V DC) SAE J1939 CAN interface High channel 1 Data channel for Dallas 1-Wire� devices Digital input, channel 3 Digital input, channel 1. DEDICATED FOR IGNITION INPUT SAE J1939 CAN interface High channel 2 Analog input, channel 1. Input range: 0-30V/010V DC Digital output. Open collector output OR Analog input, channel 4. Input range: 0-30V/0-10V DC Digital output. Open collector output K-LINE interface for online Tachograph Vehicle Data transfer

Figure 2 FMC640 pinout
FMC640| Wiki

Wiring scheme
1

1 Automotive relay

Figure 3 FMC640 Wiring scheme
5

FMC640| Wiki

Set up your device
How to insert SIM card and connect the battery
1. Unscrew 4 screws counterclockwise that are located on the bottom of the device.
2. Remove the cover. 3. Insert SIM card as shown with PIN request disabled or read
Security info how to enter it later in Teltonika Configurator. Make sure that SIM card cut-off corner is pointing forward to slot. SIM slot 1 is closer to PCB, SIM slot 2 is the upper one. 4. Connect battery as shown to device. 5. After configuration, see "PC Connection (Windows)", attach device cover back. 6. Screw in all screws. Device is ready to be mounted.

Figure 4 Unscrew screws Figure 6 SIM card insert

Figure 5 Cover removal Figure 7 Battery connection

Figure 8 Attaching cover back
6

Figure 9 Device is ready
FMC640| Wiki

PC Connection (Windows)
1. Power-up FMC640 with DC voltage (10 � 30 V) power supply using power wires. LED's should start blinking, see "LED indications".
2. Connect device to computer using Micro-USB cable: You will need to install USB drivers, see "How to install USB drivers (Windows)"
3. You are now ready to use the device on your computer.
How to install USB drivers (Windows)
1. Please download COM port drivers from here. 2. Extract and run TeltonikaCOMDriver.exe. 3. Click Next in driver installation window. 4. In the following window click Install button. Setup will continue installing the driver and eventually the confirmation window will appear. Click Finish to complete the setup.

Configuration (Windows)

At first FMC640 device will have default factory settings set. These settings should be changed according to the user's needs. Main configuration can be performed via Teltonika Configurator software. Get the latest Configurator version from here. Configurator operates on Microsoft Windows OS and uses prerequisite MS .NET Framework. Make sure you have the correct version installed.

Table 1 MS .NET requirements

MS .NET requirements

Operating system

MS .NET Framework version

Windows Vista Windows 7 Windows 8.1 Windows 10

MS .NET Framework 4.6.2

Version 32 and 64 bit

Links www.microsoft.com

Downloaded Configurator will be in compressed archive. Extract it and launch Configurator.exe. After launch software language can be changed by clicking in the right bottom corner (Figure 10 Language selection).

FMC640| Wiki

Figure 10 Language selection
Configuration process begins by pressing on connected device (Figure 11 Device connected via USB).
Figure 11 Device connected via USB
After connection to Configurator Status window will be displayed (Figure 12 Configurator Status window).

Various Status window tabs display information about GNSS, GSM, I/O, Maintenance and etc. FMC640 has one user editable profile, which can be loaded and saved to the device. After any modification of configuration the changes need to be saved to device using Save to device button. Main buttons offer following functionality:

Load from device � loads configuration from device.

Save to device � saves configuration to device.

Load from file � loads configuration from file.

Save to file � saves configuration to file.

Update firmware � updates firmware on device.

Read records � reads records from the device.

Reboot device � restarts device.

Reset configuration � sets device configuration to

default.

Most important configurator section is GPRS � where all your server and GPRS settings can be configured and Data Acquisition � where data acquiring parameters can be configured. More details about FMC640 configuration using Configurator can be found in our Wiki.

Figure 12 Configurator Status window
8

FMC640| Wiki

Quick SMS configuration
Default configuration has optimal parameters present to ensure best performance of track quality and data usage. Quickly set up your device by sending this SMS command to it:
" setparam 2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0;"
Note: Before SMS text, two space symbols should be inserted.
GPRS settings: � 2001 � APN � 2002 � APN username (if there
are no APN username, empty field should be left) � 2003 � APN password (if there are no APN password, empty field should be left) Server settings: � 2004 � Domain � 2005 � Port � 2006 � Data sending protocol (0 � TCP, 1 � UDP)

Default configuration settings

Movement and ignition detection:

Vehicle movement will be detected by accelerometer

Ignition will be detected by vehicle power voltage between 13,2 � 30 V

Device makes a record On Moving if one of these events happen:

300 seconds passes

Vehicle turns 10 degrees

Vehicle drives 100 meters
Device makes a record On Stop if: 1 hour passes while vehicle is stationary and ignition is off
Records sending to server: If device has made a record it is sent to the server every 120 seconds

Speed difference between last coordinate and current position is greater than 10 km/h

After successful SMS configuration, FMC640 device will synchronize time and update records to configured server. Time intervals and default I/O elements can be changed by using Teltonika Configurator or SMS parameters.

FMC640| Wiki

Mounting recommendations
� Connecting Wires Wires should be connected while module is not plugged in. Wires should be fastened to the other wires or non-moving parts. Try to avoid heat emitting and moving objects near the wires. The connections should not be seen very clearly. If factory isolation was removed while connecting wires, it should be applied again. If the wires are placed in the exterior or in places where they can be damaged or exposed to heat, humidity, dirt, etc., additional isolation should be applied. Wires cannot be connected to the board computers or control units.
� Connecting power source Be sure that after the car computer falls asleep, power is still available on chosen wire. Depending on car, this may happen in 5 to 30 minutes period. When module is connected, be sure to measure voltage again if it did not decrease. It is recommended to connect to the main power cable in the fuse box. Use 3A, 125V external fuse.

� Connecting ignition wire Be sure to check if it is a real ignition wire � power does not disappear while starting the engine. Check if this is not an ACC wire (when key is in the first position, most electronics of the vehicle are available). Check if power is still available when you turn off any of vehicles devices. Ignition is connected to the ignition relay output. As alternative, any other relay, which has power output, when ignition is on, may be chosen.
� Connecting ground wire Ground wire is connected to the vehicle frame or metal parts that are fixed to the frame. If the wire is fixed with the bolt, the loop must be connected to the end of the wire. For better contact scrub paint from the place where loop is connected.
PAY ATTENTION! Connecting the power supply must be carried out in a very low impedance point of on-board vehicle network. Connecting the GND at an arbitrary point to the mass of the car is unacceptable, as static and dynamic potentials on the line GND will be unpredictable, which can lead to unstable FMC640 operation and even its failure.

FMC640| Wiki

LED indications

Characteristics

Table 2 Navigation LED indications

Behaviour
Permanently switched on Blinking every second
Off
Blinking fast constantly

Meaning
GNSS signal is not received
Normal mode, GNSS is working
GNSS is turned off because: Device is not working or Device is in sleep mode
Device firmware is being flashed

Table 3 Status LED indications

Behaviour
Blinking every second Blinking every two seconds Blinking fast for a short time
Off

Meaning
Normal mode Sleep mode Modem activity Device is not working or Device is in boot mode

Basic characteristics

Table 4 Basic characteristics

Module
Name Technology
GNSS
GNSS Receiver Tracking sensitivity Accuracy Hot start Warm start Cold start
Cellular
Technology 2G bands 3G bands 4G bands
Data transfer
Data support

Quectel EG91-EX LTE Cat 1, UMTS, GSM
GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS 33/99 channel -165 dBM < 3 m < 1 s < 25 s < 35 s
LTE(CaT1)/3G(UMTS/HSPA)/2G(GSM/GPRS)/GNSS EG91-EX: GSM: B3/B8 EC91-EX: WCDMA: B1/B8 EC91-EX: LTE FDD: B1/B3/B7/B8/B20/B28 LTE: LTE FDD: Max 10Mbps (DL)/Max 5Mbps (UL) UMTS: WCDMA: Max 384Kbps (DL)/Max 384Kbps (UL) GSM: GPRS: Max 107Kbps (DL)/Max 85.6Kbps (UL) SMS (text/data)

FMC640| Wiki

Power
Input voltage range Back-up battery Internal fuse
Power consumption
Bluetooth
Specification
Supported peripherals
Interface
Digital Inputs Digital Outputs Analog Inputs 1-Wire temperature sensors 1-Wire iButton RS232 RS485 CAN J1939 J1708 K-Line LVCAN/ALLCAN GNSS antenna GSM antenna USB LED indication SIM SIM
Memory

10 - 30 V DC with overvoltage protection 550 mAh 8,4V Ni-MH battery 3 A, 125 V At 12V < 7 mA (Deep Sleep) At 12V < 12 mA (Online Deep Sleep) At 12V < 28 mA (GPS Sleep) At 12V < 120 mA (GPRS) At 12V < 65 mA (nominal with no load) At 12V < 2.5 A Max. (with full Load/Peak)
5.0 + LE Temperature and Humidity sensor, Universal BLE sensors support
4 4 4 6 1 2 1 2 1 1 1 External High Gain External High Gain 2.0 Mini-USB 2 status LED lights Micro-SIM 2x SIM Card (Dual-SIM) 2MB internal flash memory and external SD card up to 32 GB.

Features

Sensors
Scenarios
Functionalities Sleep modes Configuration and firmware update SMS

Accelerometer Green Driving, Over Speeding detection, Jamming detection, Excessive Idling detection, Towing detection, Crash detection, Immobilizer, iButton Read Notification Crash detection, Auto Geofence, Manual Geofence, Trip Detection, Odometer, DDD download and Tacho Online Data GPS Sleep, Online Deep Sleep, Deep Sleep
FOTA Web, FOTA, Teltonika Configurator (USB)
Configuration, Events, DOUT Control, Debug

GPRS commands

Configuration, Debug, DOUT Control

Time Synchronization Fuel monitoring Ignition detection

GPS, NITZ, NTP LLS (Analog), LV-CAN, ALL-CAN, CAN FMS, RS232/RS485 Fuel Sensor, Ultrasonic level sensor Digital Input , Accelerometer, External Power Voltage

Physical specification
Dimensions Weight

104,1 x 76,8 x 31,5 mm (L x W x H) 197 g

Operating environment
Operating temperature (without battery) Storage temperature (without battery) Battery Charging temperature Battery Discharge temperature Battery storage temperature Operating humidity

-40 �C to +85 �C
-40 �C to +85 �C
Ta = 20 � 5 (Ambient Temp.) Ta = 20 � 5 (Ambient Temp.) -20 �C to +45� C 5% to 95% non-condensing

Ingress Protection Rating

IP41

FMC640| Wiki

Electrical characteristics
Table 5 Electrical characteristics

Characteristic description
Supply Voltage
Supply Voltage (Recommended Operating Conditions)
Digital output (Open drain grade)
Drain current (Digital Output OFF) Drain current (Digital Output ON, Recommended Operating Conditions) Static Drain-Source resistance (Digital Output ON)
Digital Input
Input resistance (DIN1) Input resistance (DIN2) Input resistance (DIN3) Input resistance (DIN4) Input voltage (Recommended Operating Conditions) Input Voltage threshold (DIN1, DIN2, DIN3, DIN4)

Value Min. Typ. Max. Unit

+10

+30

120

�A

0.5

400 300

Supply voltage

7.5

Analog input
Input Voltage (Recommended Operating Conditions), Range 1 Input resistance Input Voltage (Recommended Operating Conditions), Range 2 Input resistance
1-WIRE
Supply voltage Output inner resistance Output current (UOUT> 3.0 V) Short circuit current (UOUT> 0 V)
CAN interface
Internal terminal resistors CAN bus Differential input resistance Recessive output voltage Differential output voltage
Common mode input voltage

+10

120

+30

147

+3.3

+3.9

120

19 30 52

2.5 3

0.5 0.7 0.9

-30

FMC640| Wiki

Safety information
This message contains information on how to operate FMC640 safely. By following these requirements and recommendations, you will avoid dangerous situations. You must read these instructions carefully and follow them strictly before operating the device!
� The device uses SELV limited power source. The nominal voltage is +12 V DC. The allowed voltage range is +10...+30 V DC.
� To avoid mechanical damage, it is advised to transport the device in an impact-proof package. Before usage, the device should be placed so that its LED indicators are visible. They show the status of device operation.
� When connecting the 2x10 connector cables to the vehicle, the appropriate jumpers of the power supply of the vehicle should be disconnected.
� Before dismounting the device from the vehicle, the 2x10 connector must be disconnected.
� The device is designed to be mounted in a zone of limited access, which is inaccessible to the operator. All related devices must meet the requirements of EN 62368-1 standard.
� The device FMC640 is not designed as a navigational device for boats.
14

Do not disassemble the device. If the device is damaged, the power supply cables are not isolated or the isolation is damaged, DO NOT touch the device before unplugging the power supply. All wireless data transferring devices produce interference that may affect other devices which are placed nearby. The device must be connected only by qualified personnel.
The device must be firmly fastened in a predefined location.
The programming must be performed using a PC with autonomic power supply.
Installation and/or handling during a lightning storm is prohibited.
The device is susceptible to water and humidity.
FMC640| Wiki

Certification and Approvals
� FMC640 CE / RED � FMC640 E-Mark � FMC640 REACH � FMC640 Declaration of IMEI assignment � FMC640 Declaration of device operation temperature
This sign on the package means that it is necessary to read the User`s Manual before your start using the device. Full User`s Manual version can be found in our Wiki.
This sign on the package means that all used electronic and electric equipment should not be mixed with general household waste.
Hereby, Teltonika declare under our sole responsibility that the above described product is in conformity with the relevant Community harmonization: European Directive 2014/53/EU (RED).
15

FMC640| Wiki

Warranty
TELTONIKA guarantees its products to be free of any manufacturing defects for a period of 24 months. With additional agreement we can agree on a different warranty period, for more detailed information please contact our sales manager.
Contact us teltonika-iot-group.com/about-us/contacts/
All batteries carry a reduced 6 month warranty period.
If a product should fail within this specific warranty time, the product can be:
� Repaired � Replaced with a new product � Replaced with an equivalent repaired product fulfilling the same
functionality � TELTONIKA can also repair products that are out of warranty at
an agreed cost.

Warranty Disclaimer
TELTONIKA PRODUCTS ARE INTENDED TO BE USED BY PERSONS WITH TRAINING AND EXPERIENCE. ANY OTHER USE RENDERS THE LIMITED WARRANTIES EXPRESSED HEREIN AND ALL IMPLIED WARRANTIES NULL AND VOID AND SAME ARE HEREBY EXCLUDED. ALSO EXCLUDED FROM THIS LIMITED WARRANTY ARE ANY AND ALL INCIDENTAL OR CONSEQUENTIAL DAMAGES INCLUDING BUT NOT LIMITED TO, LOSS OF USE OR REVENUE, LOSS OF TIME, INCONVENIENCE OR ANY OTHER ECONOMIC LOSS.
More information can be found at teltonika-iotgroup.com/warranty-repair/
