THE CABERO EVAPORATOR RANGE
Universal Features of Cabero
· Blue fins provide corrosion protection
· Fans and defrost heaters are fully wired to junction box/s (IP54) with cable glands
· High efficiency external rotor fan/s 300mm and 350mm diameter are IP44 500mm diameter are IP54
· Air bypass panel increases efficiency by eliminating air leakage around coil
· Separate fan compartments in all multi fan models
· Reduced dehumidification (moisture removal) and ice formation is achieved through the inline tube configuration
· Unit casings are manufactured from high grade aluminium and powder coated white for greater corrosion and hygiene protection
· Fold down drip trays make maintenance quick and easy
· Drip tray is powder coated internally for easy cleaning and is thermally decoupled and detachable from the heat exchanger casing for increased defrosting efficiency
THE CABERO ADVANTAGE
The German designed evaporator range from Cabero incorporates innovative design features that offer customers both good performance and longevity.
The professional inline tube pattern reduces dehumidification enhancing the shelf life of perishable foods such as meat, fruit and vegetables. Blue fin coating and powder coated high grade aluminium cases provide corrosion protection and improved hygiene. Standard design features make Cabero a great choice for coolrooms and freezers in applications such as convenience stores, supermarkets, pubs and clubs,
butchers, groceries, deli's, food processors, distribution centres, ice cream stores and any other walk in application.
Cabero evaporators are a key component for an efficient refrigeration system. Stable temperature and humidity ensures that sensitive products like vegetables, meat, cheese or fish will maintain optimum weight, quality and storage life.
The Cabero difference
Cabero (Parallel)
Others (Staggered)
Advantages of Parallel Inline Pipe
· Reduced moisture removal
· Reduced air side pressure drop
· Reduced defrost frequency
Technical Features of Cabero
· Specially designed 12mm smooth bore thick walled copper tubes are less sensitive to pressure drop changes
· Multi refrigerant venturi type distributor suits all commonly used refrigerants
· Inline tube design of 35 x 35mm
· Refrigerant line connections are on the left hand end, when viewed from the fan side.
· Flush mounting to ceiling standard on all models
· Low noise levels due to fans design and increased depth between fan/s and coil face
· Pressure tested according to the PED 97/23/EC and EN327:2000 at 27.5 bar
· Powder coated aluminium in RAL 9010
CABERO EVAPORATORS 01
CABERO CH SERIES
Cabero CH series evaporators are typically used in walk-in cool and freezer rooms with ceiling heights of 2 metres or more and 500mm fan models with ceiling heights of 3 metres or more. CH evaporators are commonly used in in fast food outlets, butchers shops, fruit and vegetable shops and general purpose coolrooms and freezers.
Plentiful air movement is provided by the quiet and efficient 300, 350 and 500mm external rotor fan motors to reach all the products in the refrigerated space. The design combination of induced draft air flow, larger distance between the fan and coil face and the air bypass panel provides very good air throw to reach all corners of the room. CH evaporators are fully wired to reduce installation time and the easy to fold down drip tray
allows for quick and easy internal cleaning and on the low temperature models for maintenance of the drip tray defrost heater/s.
All Cabero CH evaporators use blue fin coating and 12mm smooth bore thick walled copper tubes to extend the efficient life of the evaporator. CH series evaporators are a good choice to clients wanting to maximize product quality and storage life.
Standard Features
·Walk-In profile suits cool and freezer rooms ·Powder coated smooth aluminium case · Low energy fan/s ·Venturi distributor for multiple refrigerants ·Separate fan compartments · 12mm smooth bore copper tubing · Stainless steel fixings
· Fins protected with epoxy blue-fin coating · Flush mount ceiling brackets · Fan/s pre-wired to IP54 junction box ·Air bypass sheet with special drainage system · Professional in-line tube configuration · Fold down drip tray with central drain connection
02 CABERO EVAPORATORS
CABERO CH PRO SERIES
Cabero PRO CH series evaporators have all the features of the CH models plus a fully fitted and wired electronic expansion controller and valve. The controller is IP65 rated which allows it to be fitted inside the evaporator.
The Carel EVD Ice control and expansion valve provide improved refrigeration performance and energy savings at the same time. Electronic expansion valves close 100% so a liquid line solenoid is not required. Where power failures are expected to occur an Ultracap can be added as an accessory to drive the valve closed in the event of a power failure. The Ultracap is simply mounted with the controller and plugs into the existing IP65 rated plug.
Commissioning time is significantly reduced as the controller requires only two digital input from the user. Simply select the refrigerant type and the required
superheat and the setup is complete. Mechanical TX valves which require the system to be close to design temperature before the superheat can be set, electronic expansion valves do not. Controller includes a digital display of the superheat and of any faults to make maintenance and fault find quick and easy.
Energy savings of more than 15% can be achieved by allowing the condensing pressure / temperature to float down with the ambient temperature as electronic expansion valves are not dependant on pressure drop like mechanical TX valves.
Standard Features
· Fast clips securing access panels · Fully fitted and wired electronic expansion valve ·Fully fitted and wired electronic expansion
valve controller ·Expansion valve controller pre-configured for
many refrigerants · Digital display of superheat and fault codes · Simple control via 240V input ·RS485 connections to suit Carel Ultracella
refrigeration system controller
· Walk in profile suits cool and freezer rooms · Powder coated smooth aluminium case · External rotor fan/s · Venturi distributor for multiple refrigerants · Professional 12mm In-line tube configuration · Blue fin protective coating on aluminium fins · Pre-wired fans to IP54 junction box · Air by-pass sheet with special drainage system · Fold down drip tray with central drain connection
CABERO EVAPORATORS 03
CABERO LPC SERIES
LPC series evaporators are suited for use in smaller coolrooms and freezers, rooms with low ceiling heights or refrigerated cabinets.
The forced draft air flow and reduced cabinet height of the LPC series allows the room loading space to be maximised. LPC evaporators are commonly used in multi door reach in cool and freezer rooms in convenience stores where the air flow is often directed towards the rear of the room. The combination of blue fin coating and 12mm smooth bore copper thick walled copper tubes provide reliable refrigeration performance and the 300mm external rotor forced draft fan motors are energy efficient, quiet and move generous air volumes to reach all corners of the refrigerated space. Installing an LPC is
made easy with fully wired fans and defrost heaters. The side panels are removable providing clear access to all internal components and for easier fitting of the TX valve and the multi refrigerant distributors require no adjustment. The internally painted drip tray folds down quickly and easily for cleaning of the drip tray and accessing the drip tray defrost heater/s. LPC evaporators are a good choice for all small rooms and cabinets where maximising stock capacity and even temperature of product is important.
Standard Features
· Low profile suits small rooms and reach in cabinets · Professional in-line tube configuration · Forced draft provides even air distribution · Low energy fan/s · Powder coated smooth aluminium case · Separate fan compartments · Venturi distributor for multiple refrigerants
· Stainless steel fixings · 12mm smooth bore copper tubing · Flush mount ceiling brackets · Fan/s pre-wired to IP54 junction box · Fold down drip tray with central drain conn. · Fins protected with epoxy blue-fin coating · Air bypass sheet with special drainage system
04 CABERO EVAPORATORS
CABERO DH SERIES EVAPORATORS
DH series dual air discharge evaporators are designed for process and packaging rooms and for sensitive products where reduced air flow is optimal.
The DH evaporators are mounted centrally to the ceiling and use a forced draft air flow design to distribute low velocity air into the refrigerated space. Both drip trays fold down for easy access and are powder coated internally for easy cleaning.
The fans are fully wired and the panels are easily removed for installation and maintenance. Plenty of room is provided for mounting the TX valve.
The combination of 12mm smooth bore thick walled copper tubes and return bends with blue fin protected fins protect the heat transfer surface.
Standard Features
· Low profile dual air discharge design · Professional in-line tube configuration · Forced draft provides even air distribution · Low energy fans · Powder coated smooth aluminium case · Venturi distributor for multiple refrigerants · Stainless steel fixings
· Flush mount ceiling brackets · Fans pre-wired to IP54 junction box · Fold down drip trays with threaded central
drain connections · Blue Fin protection · Air by-pass sheets with special drainage system
CABERO EVAPORATORS 05
CH SERIES - MEDIUM TEMPERATURE SELECTION DATA
Cat. No.
Part No.
Capacity @ -8°C SST & 8 KTD : Watts
Capacity @ -4°C SST & 6 KTD : Watts
R404A (EN 328
SC2)
R134a (EN 328 SC2)
R404A (EN 328)
R134a (EN 328)
Air Flow
l/s
Air No. & Throw Dia. of
m Fans
Total Watts
Fan Motors
Total Amps
Heat/24 Hrs Total
Watts
Connections Liq." Suct."
300mm and 350mm Diameter Fan Model - 4mm Fin Spacing
2710355 2710356 2710357 2710358 2710359 2710360
2710361 2710362 2710363 2710364 2710365 2710366 2710367 2710368 2710369 2710370
CH4B1/30-1 CH4C1/30-1 CH4B1/35-1 CH4C1/35-1 CH4B2/30-1 CH4D1/35-1 CH4E1/35-1 CH4C2/30-1 CH4B2/35-1 CH4C2/35-1 CH4D2/35-1 CH4E2/35-1 CH4C3/35-1 CH4D3/35-1 CH4E3/35-1 CH4D4/35-1 CH4E4/35-1
2120 2590 3060 3980 4240 4530 4850 5170 6480 7970 9000 9890 11910 13850 14940 18470 20800
1929 2357 2785 3622 3858 4122 4414 4705 5897 7253 8190 9000 10838 12604 13595 16808 18928
1611 1968 2326 3025 3222 3443 3686 3929 4925 6057 6840 7516 9052 10526 11354 14037 15808
1466
439
6 1 x 300 62 0.28
1791
428
2116
689
1 x 350 130 0.58
2753 664 7
2932 878
2 x 300 124 0.56
3133
622
6 1 x 350 130 0.58
3354 586
3576 856 7 2 x 300 124 0.56
4482 1383 9
5512 1322 2 x 350 260 1.16
6224 1230 8
6840 1183
8237 1936 10
9579 1839
3 x 350 390 1.74
10333 1761 9
12774 2439 4 x 350 520 2.32
14385 2358
500mm Diameter Fan Model - 4mm Fin Spacing
2710371
2710372 2710373 2710374 2710375 2710376 2710377 2710378 2710379 3509085 3509086 3509087
CH4C1/50-1 CH4D1/50-1 CH4E1/50-1 CH4G1/50-1 CH4C2/50-1 CH4D2/50-1 CH4E2/50-1 CH4G2/50-1 CH4D3/50-1 CH4E3/50-1 CH4G3/50-1 CH4D4/50-1 CH4E4/50-1 CH4G4/50-1
11460 13740 15190 17450 23220 27690 30720 35400 41490 46640 51680 52900 58850 67070
10429 12503 13823 15880 21130 25198 27955 32214 37756 42442 47029 48139 53554 61034
8710 10442 11544 13262 17647 21044 23347 26904 31532 35446 39277 40204 44726 50973
7926 2033 26 9503 1975 25
1 x 500 730 1.35 10505 1922 24 12068 1808 22 16059 4067 27 19150 3950 26
2 x 500 1460 2.70 21246 3844 25 24483 3617 23 28694 5925 26 32256 5767 25 3 x 500 2190 4.05 35742 5425 23 36586 7900 26 40701 7689 25 4 x 500 2920 5.4 46386 7233 23
Refrigerant Correction Multiplier
Refrigerant Capacity Multiplier
R404A 1.0
R507 1.0
*Internally equalised expansion valve required.
R134a 0.91
1488
3120 2976 3120 2976
1/2 1/2 1/2 3/4
6240
7/8
9360
5/8
1 1/8
12480
7/8
1 3/8
17520 35040
5/8
1 1/8
1 3/8
7/8
1 5/8
52560
1 1/8
2 1/8
70080
1 3/8
2 5/8
R22 0.95
06 CABERO EVAPORATORS
CH SERIES - MEDIUM TEMPERATURE DIMENSION DATA
Cat. No.
Part No.
Drain
Weight
Overall Dim: mm
BSP"
kg
L
D
H
E
E1
F
A
300mm and 350mm Diameter Fan Model - 4mm Fin Spacing
2710355 2710356 2710357 2710358 2710359 2710360
2710361 2710362 2710363 2710364 2710365 2710366 2710367 2710368 2710369 2710370
CH4B1/30-1
1
19
780
470
470
490
NA
415
400
CH4C1/30-1
1
22
780
470
470
490
NA
415
400
CH4B1/35-1
1
26
980
530
470
690
NA
415
400
CH4C1/35-1
1
28
980
530
470
690
NA
415
400
CH4B2/30-1
1
34
1230
470
470
940
NA
415
400
CH4D1/35-1
1
30
980
530
470
690
NA
415
400
CH4E1/35-1
1
32
980
530
470
690
NA
415
400
CH4C2/30-1
1
38
1230
470
470
940
NA
415
400
CH4B2/35-1
1
43
1630
530
470
1340
NA
415
400
CH4C2/35-1
1
47
1630
530
470
1340
NA
415
400
CH4D2/35-1
1
53
1630
530
470
1340
NA
415
400
CH4E2/35-1
1
58
1630
530
470
1340
NA
415
400
CH4C3/35-1
1
69
2360
530
470
1990
NA
415
400
CH4D3/35-1
1
75
2360
530
470
1990
NA
415
400
CH4E3/35-1
1
82
2360
530
470
1990
NA
415
400
CH4D4/35-1
1
98
3010
530
470
1340
1300
415
400
CH4E4/35-1
1
107
3010
530
470
1340
1300
415
400
500mm Diameter Fan Model - 4mm Fin Spacing
2710371
2710372 2710373 2710374 2710375 2710376 2710377 2710378 2710379 3509085 3509086 3509087
CH4C1/50-1
1 1/4
96
1494
720
750
1120
NA
510
550
CH4D1/50-1
1 1/4
103
1494
720
720
1120
NA
510
550
CH4E1/50-1
1 1/4
110
1494
720
720
1120
NA
510
550
CH4G1/50-1
1 1/4
128
1494
790
790
1120
NA
580
550
CH4C2/50-1
1 1/4
164
2574
720
720
1120
1080
510
550
CH4D2/50-1
1 1/4
178
2574
720
720
1120
1080
510
550
CH4E2/50-1
1 1/4
191
2574
720
720
1120
1080
510
550
CH4G2/50-1
1 1/4
222
2574
790
790
1120
1080
580
550
CH4D3/50-1
1 1/4
250
3654
720
720
1120
1080
510
550
CH4E3/50-1
1 1/4
271
3654
720
720
1120
1080
510
550
CH4G3/50-1
1 1/4
318
3654
790
790
1120
1080
580
550
CH4D4/50-1
2
321
4014
720
880
940
900
510
550
CH4E4/50-1
2
351
4014
720
880
940
900
510
550
CH4G4/50-1
2
414
4014
790
880
940
900
580
550
E
E
E1
E1
suspension point
Ø 14 mm
F
E
E
E1
E1
suspension point
Ø 14 mm
F
A
A
HH
HH
L L
E
E1
E
E1
L
L
D
D
E
E1
E1
E1
E
E1
E1
E1
HH
HH
L
L
L
L
FOR ALL WIRING DIAGRAMS AND INSTALLATION INSTRUCTIONS VISIT WWW.ACTROL.COM.AU
CABERO EVAPORATORS 07
CH E SERIES - LOW TEMPERATURE SELECTION DATA
Cat. No.
Part No.
Capacity @ Capacity @
-25°C SST -24°C SST
& 7 KTD : & 6 KTD :
Watts
Watts
"R404A (EN 328
SC3)"
"R404A (EN 328)"
Air Flow
l/s
Air Throw
m
No. & Diam.
of Fans
Fan Motors
Defrost Heaters 240 Volt
Total Watts
Total Amps
Heat/ 24 Hrs Total
Watts
Coil No. & Watts
Drip Tray No. & Watts
Total Amps
Connections Liq." Suct."
300mm and 350mm Diameter Fan Model - 4mm Fin Spacing
2710381 2710382 2710383 2710384 2710385
2710386 2710387 2710388 2710389 2710390 2710391 2710392
2710393 2710394 2710395
CH4B1/30E-1 CH4C1/30E-1 CH4B1/35E-1 CH4C1/35E-1 CH4B2/30E-1 CH4D1/35E-1 CH4E1/35E-1 CH4C2/30E-1 CH4B2/35E-1 CH4C2/35E-1 CH4D2/35E-1 CH4E2/35E-1 CH4C3/35E-1 CH4D3/35E-1 CH4E3/35E-1 CH4D4/35E-1 CH4E4/35E-1
1590 1820 2310 2950 3180 3310 3450 3650 5040 6100 6890 7210 9080 10290 10790 13760 14900
1363 1560 1980 2529 2726 2837 2957 3129 4320 5229 5906 6180 7783 8820 9249 11794 12771
439 428 689 664 878 622 586 856 1383 1322 1230 1183 1936 1839 1761 2439 2358
6 1 x 300 62 0.28
1 x 350 130 0.58 7
2 x 300 124 0.56
6 1 x 350 130 0.58
7
124 0.56
9 2 x 350 260 1.16
8
10 3 x 350 390 1.74
9 4 x 350 520 2.32
1488 2 x 450 1 x 450 5.6
3120 2 x 650 1 x 650 8.1
2976 2 x 850 1 x 850 10.6
3120 4 x 650 1 x 650 13.5
2976 6240
2 x 850 1 x 850 10.6
15.0 2 x 1200
15.0 1 x 1200
4 x 1200
25.0
9360
2 x 1750
21.8
1 x 1750
4 x 1750
36.4
12480 4 x 2300 1 x 2300 47.9
1/2 1/2 5/8 1/2 3/4
7/8
5/8
1 1/8
7/8 1 3/8
500mm Diameter Fan Model - 4mm Fin Spacing
2710396
2710397
2710398
2710399 2710400 2710401
2710403 3509088 3509089 3509090
CH4C1/50E-1 CH4D1/50E-1 CH4E1/50E-1 CH4G1/50E-1 CH4C2/50E-1 CH4D2/50E-1 CH4E2/50E-1 CH4G2/50E-1 CH4D3/50E-1 CH4E3/50E-1 CH4G3/50E-1 CH4D4/50E-1 CH4E4/50E-1 CH4G4/50E-1
8310 10300 10990 12570 17000 20950 22420 26120 30770 34820 36800 39070 42920 48260
7123 8829 9420 10774 14571 17957 19217 22389 26374 29846 31543 33489 36789 41366
2033 1975 1922 1808 4067 3950 3844 3617 5925 5767 5425 7900 7689 7233
26 25
1 x 500 730 1.35 24 22 27 26
2 x 500 1460 2.70 25 23 26 25 3 x 500 2190 4.05 23 26 25 4 x 500 2920 5.4 23
17520 35040 52560 70080
3 x 850
17.7
5 x 850
24.8
2 x 850
6 x 850
28.3
3 x 1650
34.4
5 x 1650
48.1
2 x 1650
6 x 1650
55.0
5 x 2450
71.5
2 x 2450
6 x 2450
81.7
7 x 2600 2 x 2600 97.5
5/8 1 1/8
1 3/8
7/8
1 5/8
1 1/8 2 1/8 1 3/8 2 5/8
Refrigerant Correction Multiplier
Refrigerant
R404A
R507
R134a
R22
Capacity Multiplier
1.0
1.0
0.85
0.95
*Internally equalised expansion valve required.
08 CABERO EVAPORATORS
CH E SERIES - LOW TEMPERATURE DIMENSION DATA
Cat. No.
Part No.
Drain
Weight
Overall Dim: mm
BSP"
kg
L
D
H
E
E1
F
A
300mm and 350mm Diameter Fan Model - 4mm Fin Spacing
2710381 2710382 2710383 2710384 2710385
2710386 2710387 2710388 2710389 2710390 2710391 2710392
2710393 2710394 2710395
CH4B1/30E-1
1
CH4C1/30E-1
1
CH4B1/35E-1
1
CH4C1/35E-1
1
CH4B2/30E-1
1
CH4D1/35E-1
1
CH4E1/35E-1
1
CH4C2/30E-1
1
CH4B2/35E-1
1
CH4C2/35E-1
1
CH4D2/35E-1
1
CH4E2/35E-1
1
CH4C3/35E-1
1
CH4D3/35E-1
1
CH4E3/35E-1
1
CH4D4/35E-1
1
CH4E4/35E-1
1
19
780
470
470
490
NA
415
400
22
780
470
470
490
NA
415
400
26
980
530
470
690
NA
415
400
28
980
530
470
690
NA
415
400
34
1230
470
470
940
NA
415
400
30
980
530
470
690
NA
415
400
32
980
530
470
690
NA
415
400
38
1230
470
470
940
NA
415
400
43
1630
530
470
1340
NA
415
400
47
1630
530
470
1340
NA
415
400
53
1630
530
470
1340
NA
415
400
58
1630
530
470
1340
NA
415
400
69
2360
530
470
1990
NA
415
400
75
2360
530
470
1990
NA
415
400
82
2360
530
470
1990
NA
415
400
98
3010
530
470
1340
1300
415
400
107
3010
530
470
1340
1300
415
400
500mm Diameter Fan Model - 4mm Fin Spacing
2710396
2710397
2710398
2710399 2710400 2710401
2710403 3509088 3509089 3509090
CH4C1/50E-1
1 1/4
CH4D1/50E-1
1 1/4
CH4E1/50E-1
1 1/4
CH4G1/50E-1
1 1/4
CH4C2/50E-1
1 1/4
CH4D2/50E-1
1 1/4
CH4E2/50E-1
1 1/4
CH4G2/50E-1
1 1/4
CH4D3/50E-1
1 1/4
CH4E3/50E-1
1 1/4
CH4G3/50E-1
1 1/4
CH4D4/50E-1
2
CH4E4/50E-1
2
CH4G4/50E-1
2
98
1494
720
750
1120
NA
510
550
105
1494
720
720
1120
NA
510
550
112
1494
720
720
1120
NA
510
550
130
1494
790
790
1120
NA
580
550
167
2574
720
720
1120
1080
510
550
181
2574
720
720
1120
1080
510
550
194
2574
720
720
1120
1080
510
550
225
2574
790
790
1120
1080
580
550
254
3654
720
720
1120
1080
510
550
275
3654
720
720
1120
1080
510
550
322
3654
790
790
1120
1080
580
550
330
4014
720
880
940
900
510
550
360
4014
720
880
940
900
510
550
423
4014
790
880
940
900
580
550
E
E
E1
E1
suspension point
Ø 14 mm
F
E
E
E1
E1
suspension point
Ø 14 mm
F
A
A
HH
HH
L L
E
E1
E
E1
L
L
D
D
E
E1
E1
E1
E
E1
E1
E1
HH
HH
L
L
L
L
FOR ALL WIRING DIAGRAMS AND INSTALLATION INSTRUCTIONS VISIT WWW.ACTROL.COM.AU
CABERO EVAPORATORS 09
CH SERIES - WATER DEFROST EVAPORATORS SELECTION DATA
Cat. No.
Part No.
Capacity @ -8°C SST & 8 KTD : Watts
R404A (EN 328 SC2)
R134a (EN 328 SC2)
Capacity @ -4°C SST & 6 KTD : Watts
R404A (EN 328)
R134a (EN 328)
Air Flow
l/s
Air Throw
m
No. & Dia. of Fans
Total Watts
Fan Motors
Total Amps
Heat/24 Hrs Total
Watts
Water Defrost Evaporators
3509010 3509011 3509012 3509013 3509014 3509015 3509016 3509017 3509018 3509019
CH4C2/50W-1 CH4D2/50W-1 CH4E2/50W-1 CH4G2/50W-1 CH4D3/50W-1 CH4E3/50W-1 CH4G3/50W-1 CH4D4/50W-1 CH4E4/50W-1 CH4G4/50W-1
23220 27690 30720 35400 14490 46640 51680 52900 58850 67070
21130 25198 27955 32214 37756 42442 47029 48139 53554 61034
17647 21044 23347 26904 31532 35446 39277 40204 44726 50973
16059
4067 27
19150
3950 26
2 x 500 1460 2.7
21246
3844 25
24483
3617 23
28694 5925 26
32256
5767 25 3 x 500 2190
4.1
35742 5425 23
36586 7900 26
40701
7689 25 4 x 500 2920 5.4
46386 7233 23
35040 52560 70080
Cat. No.
Part No.
3509010 3509011 3509012 3509013 3509014 3509015 3509016 3509017 3509018 3509019
CH4C2/50W-1 CH4D2/50W-1 CH4E2/50W-1 CH4G2/50W-1 CH4D3/50W-1 CH4E3/50W-1 CH4G3/50W-1 CH4D4/50W-1 CH4E4/50W-1 CH4G4/50W-1
Water Defrost
Inlet BSP "
1 1/2 1 1/2 1 1/2 2 2 2 2 2 2 2
Outlet BSP "
3 3 3 3 4 4 4 4 4 4
Flow Rate l/s
1.8 2.0 2.3 2.9 3.0 3.4 4.3 3.3 3.8 4.7
Connections
Liq. "
7/8 7/8 7/8 7/8 7/8 1 1/8 1 1/8 1 11/8 1 3/8 1 3/8
Suct."
1 3/8 1 5/8 1 5/8 1 5/8 2 1/8 2 1/8 2 1/8 2 1/8 2 1/8 2 5/8
Refrigerant Correction Multiplier
Refrigerant
R404A
R507
R134a
R22
Capacity Multiplier
1.0
1.0
0.91
0.95
*Internally equalised expansion valve required.
10 CABERO EVAPORATORS
CH SERIES - WATER DEFROST EVAPORATORS DIMENSION DATA
Cat. No.
Part No.
Weight
Overall Dim: mm
kg
L
D
H
E
E1
F
A
500mm Diameter Fan Model - 4mm Fin Spacing
3509010 3509011 3509012 3509013 3509014 3509015 3509016 3509017 3509018 3509019
CH4C2/50W-1 CH4D2/50W-1 CH4E2/50W-1 CH4G2/50W-1 CH4D3/50W-1 CH4E3/50W-1 CH4G3/50W-1 CH4D4/50W-1 CH4E4/50W-1 CH4G4/50W-1
190
2570
793
840
1120
1080
514
550
205
2570
793
840
1120
1080
514
550
220
2570
793
840
1120
1080
514
550
254
2570
863
840
1120
1080
584
550
290
3650
793
840
1120 2 x 1080 514
550
311
3650
793
840
1120 2 x 1080 514
550
359
3650
863
840
1120 2 x 1080 584
550
370
4040
793
982
940
3 x 900
514
550
397
4040
793
982
940
3 x 900
514
550
464
4040
863
982
940 3 x 900 584
550
E
E1
L
E
E1
H
suspension point
Ø 14 mm
F
Air Flow
D E1
L
E
E1
E1
E1
H H
L
FOR ALL WIRING DIAGRAMS AND INSTALLATION INSTRUCTIONS VISIT WWW.ACTROL.COM.AU
CABERO EVAPORATORS 11
CH PRO SERIES - MEDIUM TEMPERATURE SELECTION DATA
Cat. No.
Part No.
Capacity @ -8°C SST & 8 KTD : Watts
Capacity @ -4°C SST & 6 KTD : Watts
R404A (EN R134a (EN R404A R134a 328 SC2) 328 SC2) (EN 328) (EN 328)
Air Flow
l/s
Air Throw
m
No. & Dia. of Fans
Total Watts
Fan Motors
Total Heat/24 Hrs Amps Total Watts
Connections Liq." Suct."
300mm and 350mm Diameter Fan Model - 4mm Fin Spacing
3511000 3511001 3511002 3511003 3511004 3511005
3511006 3511007 3511008 3511009 3511010 3511011 3511012 3511013 3511014 3511015
CH4B1/30-1 EVD CH4C1/30-1 EVD CH4B1/35-1 EVD CH4C1/35-1 EVD CH4B2/30-1 EVD CH4D1/35-1 EVD CH4E1/35-1 EVD CH4C2/30-1 EVD CH4B2/35-1 EVD CH4C2/35-1 EVD CH4D2/35-1 EVD CH4E2/35-1 EVD CH4C3/35-1 EVD CH4D3/35-1 EVD CH4E3/35-1 EVD CH4D4/35-1 EVD CH4E4/35-1 EVD
2120 2590 3060 3980 4240 4530 4850 5170 6480 7970 9000 9890 11910 13850 14940 18470 20800
1929 2357 2785 3622 3858 4122 4414 4705 5897 7253 8190 9000 10838 12604 13595 16808 18928
1611 1968 2326 3025 3222 3443 3686 3929 4925 6057 6840 7516 9052 10526 11354 14037 15808
1466 1791 2116 2753 2932 3133 3354 3576 4482 5512 6224 6840 8237 9579 10333 12774 14385
439 428 689 664 878 622 586 856 1383 1322 1230 1183 1936 1839 1761 2439 2358
6 1 x 300 62 0.28
1 x 350 130 0.58 7
2 x 300 124 0.56 6 1 x 350 130 0.58 7 2 x 300 124 0.56 9
2 x 350 260 1.16 8 10
3 x 350 390 1.74 9
4 x 350 520 2.32
1488 3120 2976 3120 2976 6240
9360 12480
1/2 1/2 5/8 1/2 3/4
7/8
5/8
1 1/8
7/8 1 3/8
500mm Diameter Fan Model - 4mm Fin Spacing
3511017
3511018 3511019 3511016 3511020 3509076 3509077 3509078 3509079
CH4C1/50-1 EVD CH4D1/50-1 EVD CH4E1/50-1 EVD CH4G1/50-1 EVD CH4C2/50-1 EVD CH4D2/50-1 EVD CH4E2/50-1 EVD CH4G2/50-1 EVD CH4D3/50-1 EVD CH4E3/50-1 EVD CH4G3/50-1 EVD
11460 13740 15190 17450 23220 27690 30720 35400 41490 46640 51680
10429 12503 13823 15880 21130 25198 27955 32214 37756 42442 47029
8710 10442 11544 13262 17647 21044 23347 26904 31532 35446 39277
7926 9503 10505 12068 16059 19150 21246 24483 28694 32256 35742
2033 1975 1922 1808 4067 3950 3844 3617 5925 5767 5425
26 25
1 x 500 730 1.35 24 22 27 26
2 x 500 1460 2.70 25 23 26 25 3 x 500 2190 4.05 23
17520 35040 52560
5/8 1 1/8
1 3/8
7/8
1 5/8
1 1/8
2 1/8
Refrigerant Correction Multiplier
Refrigerant
R404A
R507
R134a
R22
Capacity Multiplier
1.0
1.0
0.91
0.95
*Internally equalised expansion valve required.
12 CABERO EVAPORATORS
CH PRO SERIES - MEDIUM TEMPERATURE DIMENSION DATA
Cat. No.
Part No.
Drain
Weight
Overall Dim: mm
BSP"
kg
L
D
H
E
E1
F
A
300mm and 350mm Diameter Fan Model - 4mm Fin Spacing
3511000
CH4B1/30-1 EVD
1
19
780
470
470
490
NA
415
400
3511001
CH4C1/30-1 EVD
1
22
780
470
470
490
NA
415
400
3511002
CH4B1/35-1 EVD
1
26
980
530
470
690
NA
415
400
3511003
CH4C1/35-1 EVD
1
28
980
530
470
690
NA
415
400
3511004
CH4B2/30-1 EVD
1
34
1230
470
470
940
NA
415
400
3511005
CH4D1/35-1 EVD
1
30
980
530
470
690
NA
415
400
CH4E1/35-1 EVD
1
32
980
530
470
690
NA
415
400
3511006
CH4C2/30-1 EVD
1
38
1230
470
470
940
NA
415
400
3511007
CH4B2/35-1 EVD
1
43
1630
530
470
1340
NA
415
400
3511008
CH4C2/35-1 EVD
1
47
1630
530
470
1340
NA
415
400
3511009
CH4D2/35-1 EVD
1
53
1630
530
470
1340
NA
415
400
3511010
CH4E2/35-1 EVD
1
58
1630
530
470
1340
NA
415
400
3511011
CH4C3/35-1 EVD
1
69
2360
530
470
1990
NA
415
400
3511012
CH4D3/35-1 EVD
1
75
2360
530
470
1990
NA
415
400
3511013
CH4E3/35-1 EVD
1
82
2360
530
470
1990
NA
415
400
3511014
CH4D4/35-1 EVD
1
98
3010
530
470
1340
1300
415
400
3511015
CH4E4/35-1 EVD
1
107
3010
530
470
1340
1300
415
400
500mm Diameter Fan Model - 4mm Fin Spacing
CH4C1/50-1 EVD
1 1/4
96
1560
720
750
1120
NA
510
550
3511017
CH4D1/50-1 EVD
1 1/4
103
1560
720
720
1120
NA
510
550
CH4E1/50-1 EVD
1 1/4
110
1560
720
720
1120
NA
510
550
3511018
CH4G1/50-1 EVD
1 1/4
128
1560
790
790
1120
NA
580
550
3511019
CH4C2/50-1 EVD
1 1/4
164
2640
720
720
1120
1080
510
550
3511016
CH4D2/50-1 EVD
1 1/4
178
2640
720
720
1120
1080
510
550
3511020
CH4E2/50-1 EVD
1 1/4
191
2640
720
720
1120
1080
510
550
3509076
CH4G2/50-1 EVD
1 1/4
222
3720
790
790
1120
1080
580
550
3509077
CH4D3/50-1 EVD
1 1/4
250
3720
720
720
1120
1080
510
550
3509078
CH4E3/50-1 EVD
1 1/4
271
3720
720
720
1120
1080
510
550
3509079
CH4G3/50-1 EVD
1 1/4
318
3720
790
790
1120
1080
580
550
E E
L L
E
E1
E
E1
HH
E
E1
E1
E
E1
E1
L L
E
E1
E1
E1
E
E1
E1
E1
HH
suspension point
sØus1p4emnsmion point
F
Ø 14 mm
F
A A
D D
HH
HH
L
L
L
L
FOR ALL WIRING DIAGRAMS AND INSTALLATION INSTRUCTIONS VISIT WWW.ACTROL.COM.AU
CABERO EVAPORATORS 13
CH PRO E SERIES - LOW TEMPERATURE SELECTION DATA
Cat. No.
Part No.
Capacity @ Capacity @ -25°C SST & 7 -24°C SST & 6 KTD : Watts KTD : Watts
"R404A (EN 328
SC3)"
"R404A (EN 328)"
Air Flow
l/s
Air Throw No. & Dia. m of Fans
Total Watts
Fan Motors
Total Heat/24 Hrs Amps Total Watts
Connections Liq." Suct."
300mm and 350mm Diameter Fan Model - 4mm Fin Spacing
3511021 3511022 3511023 3511024 3511025
3511026 3511027 3511028 3511029 3511030 3511031 3511032
3511033 3511034 3511035
CH4B1/30E-1 EVD CH4C1/30E-1 EVD CH4B1/35E-1 EVD CH4C1/35E-1 EVD CH4B2/30E-1 EVD CH4D1/35E-1 EVD CH4E1/35E-1 EVD CH4C2/30E-1 EVD CH4B2/35E-1 EVD CH4C2/35E-1 EVD CH4D2/35E-1 EVD CH4E2/35E-1 EVD CH4C3/35E-1 EVD CH4D3/35E-1 EVD CH4E3/35E-1 EVD CH4D4/35E-1 EVD CH4E4/35E-1 EVD
1590 1820 2310 2950 3180 3310 3450 3650 5040 6100 6890 7210 9080 10290 10790 13760 14900
1363 1560 1980 2529 2726 2837 2957 3129 4320 5229 5906 6180 7783 8820 9249 11794 12771
439 428 689 664 878 622 586 856 1383 1322 1230 1183 1936 1839 1761 2439 2358
6
1 x 300 62
0.28
1 x 350 130 0.58 7
2 x 300 124
0.56
6
1 x 350 130 0.58
7
2 x 300 124
0.56
9
2 x 350 260
1.16
8
10
3 x 350 390
1.74
9 4 x 350 520 2.32
500mm Diameter Fan Model - 4mm Fin Spacing
3511036
3511037
3511038
3511039 3509080 3509081
3509082
CH4C1/50E-1 EVD CH4D1/50E-1 EVD CH4E1/50E-1 EVD CH4G1/50E-1 EVD CH4C2/50E-1 EVD CH4D2/50E-1 EVD CH4E2/50E-1 EVD CH4G2/50E-1 EVD CH4D3/50E-1 EVD CH4E3/50E-1 EVD CH4G3/50E-1 EVD
8310 10300 10990 12570 17000 20950 22420 26120 30770 34820 36800
7123
2033
26
8829
1975
25
9420
1922
24
10774
1808
22
14571
4067
27
17957
3950
26
19217
3844
25
22389
3617
23
26374
5925
26
29846
5767
25
31543
5425
23
Refrigerant Correction Multiplier
Refrigerant Capacity Multiplier
R404A 1.0
R507 1.0
*Internally equalised expansion valve required.
1 x 500 730
1.35
2 x 500 1460 2.70 3 x 500 2190 4.05
R134a 0.85
1488
3120 2976 3120 2976
1/2 1/2 5/8 1/2 3/4
6240
7/8
9360
5/8
1 1/8
12480
7/8
1 3/8
17520 35040
5/8
1 1/8
1 3/8
7/8
1 5/8
52560
1 1/8
2 1/8
R22 0.95
14 CABERO EVAPORATORS
CH PRO E SERIES - LOW TEMPERATURE DIMENSION DATA
Cat. No.
Part No.
Drain
Weight
Overall Dim: mm
BSP"
kg
L
D
H
E
E1
F
A
300mm and 350mm Diameter Fan Model - 4mm Fin Spacing
3511021
CH4B1/30E-1 EVD
1
3511022
CH4C1/30E-1 EVD
1
3511023
CH4B1/35E-1 EVD
1
3511024
CH4C1/35E-1 EVD
1
3511025
CH4B2/30E-1 EVD
1
CH4D1/35E-1 EVD
1
3511026
CH4E1/35E-1 EVD
1
3511027
CH4C2/30E-1 EVD
1
3511028
CH4B2/35E-1 EVD
1
3511029
CH4C2/35E-1 EVD
1
3511030
CH4D2/35E-1 EVD
1
3511031
CH4E2/35E-1 EVD
1
3511032
CH4C3/35E-1 EVD
1
CH4D3/35E-1 EVD
1
3511033
CH4E3/35E-1 EVD
1
3511034
CH4D4/35E-1 EVD
1
3511035
CH4E4/35E-1 EVD
1
19
780
470
470
490
NA
415
400
22
780
470
470
490
NA
415
400
26
980
530
470
690
NA
415
400
28
980
530
470
690
NA
415
400
34
1230
470
470
940
NA
415
400
30
980
530
470
690
NA
415
400
32
980
530
470
690
NA
415
400
38
1230
470
470
940
NA
415
400
43
1630
530
470
1340
NA
415
400
47
1630
530
470
1340
NA
415
400
53
1630
530
470
1340
NA
415
400
58
1630
530
470
1340
NA
415
400
69
2360
530
470
1990
NA
415
400
75
2360
530
470
1990
NA
415
400
82
2360
530
470
1990
NA
415
400
98
3010
530
470
1340
1300
415
400
107
3010
530
470
1340
1300
415
400
500mm Diameter Fan Model - 4mm Fin Spacing
3511036
CH4C1/50E-1 EVD
1 1/4
CH4D1/50E-1 EVD
1 1/4
3511037
CH4E1/50E-1 EVD
1 1/4
CH4G1/50E-1 EVD
1 1/4
3511038
CH4C2/50E-1 EVD
1 1/4
CH4D2/50E-1 EVD
1 1/4
3511039
CH4E2/50E-1 EVD
1 1/4
3509080
CH4G2/50E-1 EVD
1 1/4
3509081
CH4D3/50E-1 EVD
1 1/4
CH4E3/50E-1 EVD
1 1/4
3509082
CH4G3/50E-1 EVD
1 1/4
98
1560
720
750
1120
NA
510
550
105
1560
720
720
1120
NA
510
550
112
1560
720
720
1120
NA
510
550
130
1560
790
790
1120
NA
580
550
167
2640
720
720
1120
1080
510
550
181
2640
720
720
1120
1080
510
550
194
2640
720
720
1120
1080
510
550
225
3720
790
790
1120
1080
580
550
254
3720
720
720
1120
1080
510
550
275
3720
720
720
1120
1080
510
550
322
3720
790
790
1120
1080
580
550
E E
L L
E
E1
E
E1
HH
E
E1
E1
E
E1
E1
L L
E
E1
E1
E1
E
E1
E1
E1
HH
suspension point
sØus1p4emnsmion point
F
Ø 14 mm
F
A
A
D D
HH
HH
L
L
L
L
FOR ALL WIRING DIAGRAMS AND INSTALLATION INSTRUCTIONS VISIT WWW.ACTROL.COM.AU
CABERO EVAPORATORS 15
LPC SERIES - MEDIUM TEMPERATURE SELECTION DATA
Cat. No.
Part No.
Capacity @ -8°C SST & 8 KTD : Watts
"R404A (EN 328
SC2)"
"R134a (EN 328
SC2)"
Capacity @ -4°C SST & 6 KTD : Watts
"R404A "R134a (EN 328)" (EN 328)"
Air Flow
l/s
Air Throw
m
No. & Dia. of Fans
Fan Motors 230V/50Hz
Total Total Heat/24 Hrs Watts Amps Total Watts
Connections Liq." Suct."
300mm Diameter Fan Model - 4mm Fin Spacing
2710337 2710338 2710339 2710340 2710341 2710342 2710343
2710344
LPC4A1/30-1* LPC4B1/30-1* LPC4C1/30-1* LPC4D1/30-1 LPC4E1/30-1 LPC4B2/30-1 LPC4C2/30-1 LPC4D2/30-1 LPC4E2/30-1 LPC4C3/30-1 LPC4D3/30-1 LPC4E3/30-1 LPC4C4/30-1 LPC4D4/30-1 LPC4E4/30-1
1155 1617 1991 2178 2442 3289 4048 4510 4961 6061 6930 7469 8140 9262 10032
1051 1471 1812 1982 2222 2993 3684 4104 4515 5516 6306 6797 7407 8428 9129
866 1213 1493 1634 1832 2467 3036 3383 3721 4546 5198 5602 6105 6947 7524
788
375
1104
336
1359
311
1486 294
1667 278
2245 672
2763 622
3078 589
3386 556
4137
933
4730 883
5098 833
5556 1244
6321 1178
6847
1111
Refrigerant Correction Multiplier
Refrigerant Capacity Multiplier
R404A 1.0
R507 1.0
*Internally equalised expansion valve required.
7 1 x 300 72 0.32
6 5 7 6 2 x 300 144 0.64 5 6
3 x 300 216 0.96 5 6
4 x 300 288 1.28 5
R134a 0.91
1728
1/2
1/2 5/8
3456 5184 6912
7/8 5/8
1 1/8
R22 0.95
16 CABERO EVAPORATORS
LPC SERIES - MEDIUM TEMPERATURE DIMENSION DATA
Cat. No.
Part No.
Overall Dim: mm
Drain
Weight
BSP"
kg
L
D
H
E
F
300mm Diameter Fan Model - 4mm Fin Spacing
2710337 2710338 2710339 2710340 2710341 2710342 2710343
2710344
LPC4A1/30-1* LPC4B1/30-1* LPC4C1/30-1* LPC4D1/30-1 LPC4E1/30-1 LPC4B2/30-1 LPC4C2/30-1 LPC4D2/30-1 LPC4E2/30-1 LPC4C3/30-1 LPC4D3/30-1 LPC4E3/30-1 LPC4C4/30-1 LPC4D4/30-1 LPC4E4/30-1
1
18
820
670
351
590
600
1
19
820
670
351
590
600
1
21
820
670
351
590
600
1
22
820
670
351
590
600
1
23
820
670
351
590
600
1
32
1370
670
351
1140
600
1
35
1370
670
351
1140
600
1
38
1370
670
351
1140
600
1
40
1370
670
351
1140
600
1
48
1920
670
351
1690
600
1
52
1920
670
351
1690
600
1
56
1920
670
351
1690
600
1
62
2470
670
351
1120
600
1
67
2470
670
351
1120
600
1
72
2470
670
351
1120
600
313
318 313 318 313
L
E
110
50
L
E
110
50
L E
E
suspension point
110
12 mm
B F
250 50 L
E
AIR 110
50
313
318 H
318
FOR ALL WIRING DIAGRAMS AND INSTALLATION INSTRUCTIONS VISIT WWW.ACTROL.COM.AU
CABERO EVAPORATORS 17
LPC E SERIES - LOW TEMPERATURE SELECTION DATA
Cat. No.
Part No.
Capacity @ Capacity @
-25°C SST -24°C SST
& 7 KTD : & 6 KTD :
Watts
Watts
"R404A (EN 328
SC3)"
"R404A (EN 328)"
Air Flow
l/s
Air Throw
m
No. & Dia. of Fans
Fan Motors
Total Total Watts Amps
Heat/ 24 Hrs Total
Watts
Defrost Heaters 240 Volts
Connections
Coil No. & Watts
Drip Tray No. & Liq." Suct." Watts
300mm Diameter Fan Model - 4mm Fin Spacing
2710345 2710346
2710347 2710348 2710349
2710350 2710351
2710352
2710353
LPC4A1/30E.1* LPC4B1/30E.1* LPC4C1/30E.1* LPC4D1/30E.1 LPC4E1/30E.1 LPC4B2/30E.1 LPC4C2/30E.1 LPC4D2/30E.1 LPC4E2/30E.1 LPC4C3/30E.1 LPC4D3/30E.1 LPC4E3/30E.1 LPC4C4/30E.1 LPC4D4/30E.1 LPC4E4/30E.1
880 1190 1370 1580 1730 2350 2800 3160 3470 4280 4870 5230 5650 6290 6980
754
375
7
1020 336
1174
311
1 x 300 72 0.32
6
1354
294
1483
278 5
2014
672
7
2400 622 6 2 x 300 144 0.64
2709 589
2974 556 5
3669 933
6
4174
883
3 x 300 216 0.96
4483 833 5
4843 1244
6
5391
1178
4 x 300 288 1.28
5983
1111
5
1728
3456 5184 6912
2 x 600 1 x 600
1/2
1/2 5/8
2 x 1100 1 x 1100
7/8
5/8 2 x 1600 1 x 1600
1 1/8 2 x 2100 1 x 2100
Refrigerant Correction Multiplier
Refrigerant Capacity Multiplier
R404A 1.0
R507 1.0
R134a 0.85
R22 0.95
*Internally equalised expansion valve required.
18 CABERO EVAPORATORS
LPC E SERIES - LOW TEMPERATURE DIMENSION DATA
Cat. No.
Part No.
Overall Dim: mm
Drain
Weight
BSP"
kg
L
D
H
E
F
300mm Diameter Fan Model - 4mm Fin Spacing
2710345 2710346
2710347 2710348 2710349
2710350 2710351
2710352
2710353
LPC4A1/30E.1* LPC4B1/30E.1* LPC4C1/30E.1* LPC4D1/30E.1 LPC4E1/30E.1 LPC4B2/30E.1 LPC4C2/30E.1 LPC4D2/30E.1 LPC4E2/30E.1 LPC4C3/30E.1 LPC4D3/30E.1 LPC4E3/30E.1 LPC4C4/30E.1 LPC4D4/30E.1 LPC4E4/30E.1
1
18
820
670
351
590
600
1
19
820
670
351
590
600
1
21
820
670
351
590
600
1
22
820
670
351
590
600
1
23
820
670
351
590
600
1
32
1370
670
351
1140
600
1
35
1370
670
351
1140
600
1
38
1370
670
351
1140
600
1
40
1370
670
351
1140
600
1
48
1920
670
351
1690
600
1
52
1920
670
351
1690
600
1
56
1920
670
351
1690
600
1
62
2470
670
351
1120
600
1
67
2470
670
351
1120
600
1
72
2470
670
351
1120
600
313
318 313 318 313
L
E
110
50
L
E
110
50
L E
E
suspension point
110
12 mm
B F
250 50 L
E
AIR 110
50
313
318 H
318
FOR ALL WIRING DIAGRAMS AND INSTALLATION INSTRUCTIONS VISIT WWW.ACTROL.COM.AU
CABERO EVAPORATORS 19
DH SERIES - MEDIUM TEMPERATURE SELECTION DATA
Cat. No.
Part No.
Capacity @ 0C SST & 10 KTD : Watts
"R404A (EN 328
SC1)"
"R134a (EN 328
SC1)"
Air Flow Air Throw
l/s
m
No. & Dia. of Fans
Total Watts
Fan Motors
Connections
Total Amps
Heat/ 24 Hrs Liq."
Total Watts
Suct."
300mm and 350mm Diameter Fan Models - 4mm Fin Spacing
3509049 3509050
3509051 3509052
3509053 3509054 3509055 3509056 3509057 3509058 3509059 3509060 3509061
DH4B1/30 DH4C1/30 DH4B1/35 DH4C1/35 DH4D1/35 DH4E1/35 DH4B2/30 DH4C2/30 DH4B2/35 DH4C2/35 DH4D2/35 DH4E2/35 DH4C3/35 DH4D3/35 DH4E3/35 DH4D4/35 DH4E4/35
3180 3820 4600 5720 6440 6880 6470 7740 8750 11550 12730 14160 17380 19690 21160 26130 28410
2894 3476 4186 5205 5860 6261 5888 7743 7963 10511 11584 12886 15816 17918 19256 23778 25853
433 422 653 606 569 544 867 844 1306 1211 1139 1089 1817 1708 1633 2278 2178
1 x 300 72
0.32
6
1 x 350 140
0.60
5
7
2 x 300 144
0.64
8
2 x 350 280
1.20
7
9
3 x 350 420
1.80
8
4 x 350 560
2.40
500mm Diameter Fan Models - 4mm Fin Spacing
3509062 3509063 3509064 3509065 3509066 3509067 3509068 3509069 3509070 3509071 3509072
DH4C1/50 DH4D1/50 DH4E1/50 DH4G1/50 DH4C2/50 DH4D2/50 DH4E2/50 DH4G2/50 DH4D3/50 DH4E3/50 DH4G3/50
17240 20300 22400 25630 34990 40950 45340 52000 61410 68870 75860
15688 18473 20384 23323 31841 37265 41259 47320 55883 62672 69033
2033 1975 1922 1808 4067 3950 3844 3617 5925 5767 5425
22
21
1 x 500 770
1.70
20
18
22
21
2 x 500 1540
3.40
20
18
21
20 3 x 500 2310
5.10
18
Refrigerant Correction Multiplier
Refrigerant Capacity Multiplier
R404A 1.0
R507 1.0
*Internally equalised expansion valve required.
R134a 0.91
1728
1/2
3360
1/2
5/8
3456
3/4
6720
7/8
5/8
1 1/8 10080
13440
7/8
1 3/8
5/8
1 1/8
18480
1 3/8
36960
7/8
1 5/8
55440
1 1/8
2 1/8
R22 0.95
20 CABERO EVAPORATORS
DH SERIES - MEDIUM TEMPERATURE DIMENSION DATA
Cat. No.
Part No.
Drain
Weight
BSP"
kg
L
Overall Dim: mm
D
H
E
E1
F
A
300mm and 350mm Diameter Fan Models - 4mm Fin Spacing
3509049 3509050
3509051 3509052
3509053 3509054 3509055 3509056 3509057 3509058 3509059 3509060 3509061
DH4B1/30 DH4C1/30 DH4B1/35 DH4C1/35 DH4D1/35 DH4E1/35 DH4B2/30 DH4C2/30 DH4B2/35 DH4C2/35 DH4D2/35 DH4E2/35 DH4C3/35 DH4D3/35 DH4E3/35 DH4D4/35 DH4E4/35
1
27
750
1028
308
490
NA
978
323
1
29
750
1028
308
490
NA
978
323
1
32
950
1028
308
690
NA
978
323
1
35
950
1028
308
690
NA
978
323
1
38
950
1028
308
690
NA
978
323
1
41
950
1028
308
690
NA
978
323
1
43
1200
1028
308
940
NA
978
323
1
47
1200
1028
308
940
NA
978
323
1
55
1600
1028
308
1340
NA
978
323
1
61
1600
1028
308
1340
NA
978
323
1
67
1600
1028
308
1340
NA
978
323
1
72
1600
1028
308
1340
NA
978
323
1
84
2250
1028
308
1990
NA
978
323
1
92
2250
1028
308
1990
NA
978
323
1
100
2250
1028
308
1990
NA
978
323
1
120
2900
1028
308
1340
1300
978
323
1
130
2900
1028
308
1340
1300
978
323
500mm Diameter Fan Models - 4mm Fin Spacing
3509062 3509063 3509064 3509065 3509066 3509067 3509068 3509069 3509070 3509071 3509072
DH4C1/50 DH4D1/50 DH4E1/50 DH4G1/50 DH4C2/50 DH4D2/50 DH4E2/50 DH4G2/50 DH4D3/50 DH4E3/50 DH4G3/50
1 1/4
103
1420
1110
480
1120
NA
1060
475
1 1/4
110
1420
1110
480
1120
NA
1060
475
1 1/4
116
1420
1110
480
1120
NA
1060
475
1 1/4
138
1420
1250
480
1120
NA
1200
475
1 1/4
183
2500
1110
480
1120
1080
1060
475
1 1/4
197
2500
1110
480
1120
1080
1060
475
1 1/4
213
2500
1110
480
1120
1080
1060
475
1 1/4
250
2500
1250
480
1120
1080
1200
475
1 1/4
275
3580
1110
480
1120
1080
1060
475
1 1/4
297
3580
1110
480
1120
1080
1060
475
1 1/4
363
3580
1250
480
1120
1080
1200
475
80
L
E
E1
80
L
E
A
80
L
D
E
E1
E1
F
H A
A
80 E
L
E1
E1
E1
A
FOR ALL WIRING DIAGRAMS AND INSTALLATION INSTRUCTIONS VISIT WWW.ACTROL.COM.AU
CABERO EVAPORATORS 21
Actrol reserves the right to make changes to the information and specifications of products described in this literature without notice or obligation. Images are representative only. For specific detail on any product please contact your local Actrol branch
V2 [BROCHURE CODE 2126020]
Adobe PDF Library 15.0 Adobe InDesign CC 13.0 (Windows)
