AX1500 SMART ROUTER R15

Preface

D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes.

Hardware A1 A1

Revision v1.02 v1.03

Manual Revisions

Date 2021/10/20 2021/11/15

Description Wording changes New cover, removal of Parental Control notice

Trademarks

D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies.

Apple�, Apple logo�, Safari�, iPhone�, and Macintosh� are trademarks of Apple Inc., registered in the U.S. and other countries. App StoreSM is a service mark of Apple Inc.

ChromeTM browser, Google PlayTM and AndroidTM are trademarks of Google Inc.

Internet Explorer�, Windows� and the Windows logo are trademarks of the Microsoft group of companies.

D-Link R15 User Manual

ErP Power Usage

This device is an Energy Related Product (ErP) with High Network Availability (HiNA), and automatically switches to a powersaving Network Standby mode within 1 minute of no packets being transmitted.

R15

Network Standby: 3.89W

D-Link R15 User Manual

Table of Contents

Product Overview.............................................................. 1 Package Contents......................................................................... 1 System Requirements ................................................................. 2 Introduction ................................................................................... 3 Features.................................................................................... 3 Hardware Overview..................................................................... 4 LED Indicators ........................................................................ 4 Back Panel ............................................................................... 5
Installation ......................................................................... 6 Before you Begin........................................................................... 6 Wireless Installation Considerations...................................... 7 Setup................................................................................................. 8 EAGLE PRO AI Setup ............................................................ 9 Hardware Setup ..................................................................10 Setup Wizard ........................................................................13
Configuration ................................................................... 20 Home ..............................................................................................21 Internet ...................................................................................22 R15 ...........................................................................................23 Connected Clients ..............................................................24 Settings ..........................................................................................26 Wizard .....................................................................................26 Internet - IPv4.......................................................................27 IPv4 - Dynamic IP (DHCP)............................................28 IPv4 - Static IP..................................................................29 IPv4 - PPPoE .....................................................................30

IPv4 - PPTP........................................................................32 IPv4 - L2TP ........................................................................34 IPv4 - DS-Lite ...................................................................36 Internet - IPv6.......................................................................37 IPv6 - Auto Detection ...................................................38 IPv6 - Static IPv6 .............................................................40 IPv6 - Auto Configuration (SLAAC/DHCPv6)........42 IPv6 - PPPoE .....................................................................45 IPv6 - 6rd ...........................................................................49 IPv6 - Local Connectivity Only ..................................51 Internet - VLAN ....................................................................52 Wireless ..................................................................................54 Guest Zone.......................................................................60 Network..................................................................................62 D-Link Cloud.........................................................................64 Operation Mode..................................................................65 Features ..................................................................................66 Parental Control ..................................................................66 QoS Engine............................................................................69 Firewall ...................................................................................71 Firewall Settings - IPv4/IPv6 Rules................................73 Port Forwarding ..................................................................75 Port Forwarding - Virtual Server....................................77 Static Routes - IPv4.............................................................79 Static Routes - IPv6.............................................................80 Dynamic DNS .......................................................................81 Quick VPN ..............................................................................83

D-Link R15 User Manual

iii

Table of Contents
Management................................................................................84 Time & Schedule - Time ....................................................84 Time & Schedule - Schedule ...........................................85 System Log............................................................................86 System Admin - Admin.....................................................88 System Admin - System....................................................89 User ..........................................................................................90 Upgrade .................................................................................91 Statistics .................................................................................92
EAGLE PRO AI ...................................................................93
Voice Control....................................................................97 Link D-Link Cloud Service to Other Services ....................98 Google Home Setup ..........................................................98 Amazon Alexa Setup ...................................................... 103 Amazon Alexa Voice Commands ............................... 106 The Google Assistant Setup......................................... 107 Google Assistant Voice Commands .......................... 109
Quick VPN.......................................................................110 Important Information .......................................................... 111 iOS Devices ................................................................................ 112 VPN Setup Instructions.................................................. 112 Connect or Disconnect.................................................. 114 Mac OS X..................................................................................... 115 VPN Setup Instructions.................................................. 115 Connect or Disconnect.................................................. 117 Windows 7.................................................................................. 118 VPN Setup Instructions.................................................. 118 Connect or Disconnect.................................................. 121
D-Link R15 User Manual

Windows 8.1/8.......................................................................... 122 VPN Setup Instructions.................................................. 122 Connect or Disconnect.................................................. 127
Windows 10 ............................................................................... 128 VPN Setup Instructions.................................................. 128 Connect or Disconnect.................................................. 130
Android ....................................................................................... 131 VPN Setup Instructions.................................................. 131 Connect or Disconnect.................................................. 133
Connect a Wireless Client to your Router ....................134 WPS Button................................................................................ 134 Windows� 10 ............................................................................. 135 Windows� 8................................................................................ 136 Windows� 7................................................................................ 138
Troubleshooting ............................................................140 Wireless Basics ...............................................................142 Networking Basics .........................................................146 Wireless Security ...........................................................148 Technical Specifications ................................................149 Wall Mounting ...............................................................150 Regulatory Statements .................................................151
iv

Section 1 - Product Overview

Product Overview
Package Contents

R15 AX1500 Smart Router Power Adapter (12V, 1A) Ethernet Cable ( RJ45, 1m) Quick Installation Guide

If any of the above items are missing or damaged, please contact your local reseller. Note: Using a power supply with a different voltage rating than the one included with the router will cause damage and void the warranty for this product.

D-Link R15 User Manual

Section 1 - Product Overview

System Requirements

Network Requirements
Web-based Configuration Utility
Requirements
EAGLE PRO AI APP Requirements

� An Ethernet-based cable, DSL or fiber modem � IEEE 802.11ax/ac/n/g/b/a wireless clients � 10/100/1000 Ethernet
Computer with the following: � Windows�, Macintosh, or Linux-based operating system � An installed Ethernet adapter
Browser Requirements: � Internet Explorer 11 or later � Firefox 28 or later � Safari 6 or later � Chrome 28 or later
� iOS� or AndroidTM device (Please refer to the description of the app's page to check whether your device is compatible.)

D-Link R15 User Manual

Section 1 - Product Overview
Introduction
With a powerful network processor, the AX1500 Smart Router packs in strong processing power to help you manage your home or office network. It's a powerful, intelligent home router with AI-assisted traffic control, Wi-Fi utilization and mesh optimization, and parental controls. It also has integrated voice assistant compatibility for Amazon Alexa and Google Assistant so you can control your network with voice commands.
Features
Smooth Wireless Connectivity with Maximized Bandwidth The innovative AI Traffic Optimizer provides weekly usage report to inform administrators about the consumption of network bandwidth along with heavy users. It also rates the overall condition of the wireless network and states the number of times the engine has optimized the network automatically based on the network conditions and usage data.
Handle More with a High-Power Processor With the R15, you're not only enjoying buffer-free gaming and lightning-fast surfing, but also features such as optimized QoS, controlled Internet access with website filtering, and compatibility with voice assistants. All this is possible with the router's 1.4 GHz dual-core high-power processor, 128 MB of flash memory and 256 MB of RAM.
Intelligent Quality of Service Features The Quality of Service (QoS) allows you to prioritize important traffic to ensure that real-time applications are receiving optimal bandwidth. Moreover, the inbuilt AI engine collects and analyzes traffic data and notifies administrators of clients that consume high bandwidth so that they can take prompt action.
Always Up-to-Date with the Latest Features The R15 will automatically check daily for updates to make sure that the device always has the latest security upgrades and new features, which will install silently in the background. For extra peace of mind, in the event of failure during the firmware update, the router will store a backup system image in the memory before proceeding with the update.
Easy Setup and Flexible Management Managing your Internet utilization has never been easier; just download the free EAGLE PRO AI for your mobile device and follow the on-screen step-by-step instructions to add your device. You also have the option to use a web browser to access the setup wizard for basic configuration and advanced features. Support for industry-standard Wi-Fi Protected Setup (WPS) lets you create encrypted connections to new devices by pressing a button.

D-Link R15 User Manual

Section 1 - Product Overview

Hardware Overview
LED Indicators

1 234

Power

Internet

3 Wireless (2.4 GHz) 4 Wireless (5 GHz)
D-Link R15 User Manual

Solid White The device is on and the system is healthy.

Solid Orange The device is booting up or performing the factory reset process.

Blinking Orange The device is under recovery mode.

Solid White The Internet connection is established.

Solid Orange The device cannot connect to the Internet.

Blinking Orange & White Alternately

The device is undergoing the firmware upgrade process.

Blinking Orange Internet access has been paused.

Solid White Blinking White
Solid White Blinking White

The 2.4 GHz wireless band is enabled. The device is transmitting data. It is processing WPS if the below 5 GHz LED is blinking at the same time. The 5 GHz wireless band is enabled. The device is transmitting data. It is processing WPS if the above 2.4 GHz LED is blinking at the same time.

Section 1 - Product Overview

Back Panel
4

2 35

Gigabit LAN Ports Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game

(1- 3)

consoles.

2 Gigabit WAN Port Use an Ethernet cable to connect your broadband modem to this port.

Reset Button

Insert a paperclip in the hole, wait for the power LED turns orange (all other LEDs should be off ), then release to reset the router to default settings.

WPS Button

Press to start the WPS process and automatically create an encrypted connection to a WPS client.

5 Power Connector Connector for the supplied power adapter.

D-Link R15 User Manual

Section 2 - Installation
Installation
This section will walk you through the installation of your R15.
Before you Begin
� Placement of the router is very important. Do not place the router in an enclosed area such as a closet, cabinet, attic, or garage.
� Configure the router with the computer that was last connected directly to your Internet connection. Verify that it is connected to the Internet before connecting additional devices.
� If your ISP provides you with a modem/router combo, you will need to set it to bridge or router mode depending on your usage requirements. Please contact your ISP or refer to the user manual for your modem/router device.
� You can only use the Ethernet port on your modem. If you were using the USB connection before using the router, then you must turn off your modem, disconnect the USB cable and connect an Ethernet cable to the Internet port on the router, then turn the modem back on. In some cases, you may need to call your Internet Service Provider (ISP) to change connection types (USB to Ethernet).
� If connecting to a DSL modem, make sure to have your DSL service information provided by your Internet Service Provider handy. This information is likely to include your DSL account's username and password. Your ISP may also supply you with additional WAN configuration settings which might be necessary to establish a connection.
� If you are connecting a considerable amount of networking equipment, it may be a good idea to take the time to label each cable or take a picture of your existing setup before making any changes.
� If you have DSL and are connecting via PPPoE, make sure you disable or uninstall any PPPoE software such as WinPoET, BroadJump, or EnterNet 300 from your computer or you will not be able to connect to the Internet.

D-Link R15 User Manual

Section 2 - Installation
Wireless Installation Considerations
The D-Link wireless router lets you access your network using a wireless connection from virtually anywhere within the operating range of your wireless network. Keep in mind that the number, thickness and location of walls, ceilings, or other objects that the wireless signals must pass through may limit the range. Typical ranges vary depending on the types of materials and background RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to follow these basic guidelines:
1. Keep the number of walls and ceilings between the D-Link router and other network devices to a minimum - each wall or ceiling can reduce your adapter's range from 3-90 feet (1-30 meters.) Position your devices so that the number of walls or ceilings is minimized.
2. Be aware of the direct line between network devices. A wall that is 1.5 feet thick (0.5 meters), at a 45-degree angle appears to be almost 3 feet (1 meter) thick. At a 2-degree angle it looks over 42 feet (14 meters) thick. Position devices so that the signal will travel straight through a wall or ceiling (instead of at an angle) for better reception.
3. Building materials make a difference. A solid metal door or aluminum studs may have a negative effect on range. Try to position access points, wireless routers, and computers so that the signal passes through drywall or open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (fish tanks), mirrors, file cabinets, brick, and concrete will degrade your wireless signal.
4. Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that generate RF noise.
5. If you are using 2.4 GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and home security systems), your wireless connection may degrade dramatically or drop completely. Make sure your 2.4 GHz phone base is as far away from your wireless devices as possible. The base transmits a signal even if the phone is not in use.

D-Link R15 User Manual

Section 2 - Installation
Setup
There are several ways you can configure your router to connect to the Internet
� EAGLE PRO AI - Use your compatible iOS or Android device to install and configure your router. Refer to EAGLE PRO AI Setup on page 9.
� Hardware Setup - This section explains how to set up your R15. Refer to Hardware Setup on page 10. � D-Link Setup Wizard - This wizard will launch when you log in to the router using your browser for the first time. Refer to
Setup Wizard on page 13. � Manual Setup - Log in to the router to manually configure your router. Refer to Configuration on page 20

D-Link R15 User Manual

Section 2 - Installation
EAGLE PRO AI Setup
The EAGLE PRO AI allows you to install and configure your R15 from your compatible Android or iOS device. Note: The screenshots may be different depending on your mobile device's OS version. However, the process is the same.
Step 1 Search and install the free EAGLE PRO AI available on the App Store or on Google Play.
Step 2 Launch the EAGLE PRO AI from the home screen of your device.
Step 3 Tap Install New Device. Scan the setup code on the device label on the bottom of the router. Follow the on-screen instructions to complete the setup.

D-Link R15 User Manual

Modem

Section 2 - Installation
Hardware Setup
Step 1 Position your R15 near your Internet-connected modem. Place it in an open area for better wireless coverage.
Step 2 Turn off and unplug the power to your cable or DSL broadband modem. This is required. In some cases, you may need to turn it off for up to five minutes.

Modem

Step 3 Use the Ethernet cable to connect your modem to the port labelled INTERNET on the router.

Modem

D-Link R15 User Manual

Section 2 - Installation
Step 4 Plug in the power and turn your modem back on and wait approximately one minute before proceeding with the procedure.

Modem

Step 5 Connect the supplied power adapter to the router and a power outlet, and wait approximately one minute until the LED indicator on the front of the device changes from orange to solid white.

Step 6 If you are configuring the router wirelessly from a PC, connect to the Wi-Fi network name printed on the label attached to the bottom of your router. Note: The Wi-Fi name (SSID), Wi-Fi password, and device password are printed on the device label on the bottom of the device.
SSID: Password:

Modem

D-Link R15 User Manual

Section 2 - Installation
If you are configuring the router from a PC with a wired Ethernet connection, plug one end of an Ethernet cable into the port labelled 1 on the back of the router, and the other end into the Ethernet port on your computer.
Step 7 If you are connecting to a broadband service that uses a dynamic connection (not PPPoE), you may be online already. Try opening a web browser and connecting to a website. If the website does not load, proceed to Setup Wizard on page 13.

Modem

D-Link R15 User Manual

Section 2 - Installation

Setup Wizard
The setup wizard is designed to guide you through a step-by-step process of configuring your new R15 for Internet connection.

If this is your first time installing the router, open your web browser and enter http://XXXX.devicesetup.net/ into the browser (XXXX represents the last 4 digits of the MAC address). Enter the Admin Password and click Log In
to start the configuration process. The web address and device password are
printed on the device label on the bottom of the device.

http://xxxx.devicesetup.net/

Agree to the Terms of Use and Privacy Policy before proceeding.

D-Link R15 User Manual

Section 2 - Installation
Follow the on-screen instructions to configure your new D-Link router and connect to the Internet. Click Next to continue.
Connect the router and the modem with an Ethernet cable.

D-Link R15 User Manual

Section 2 - Installation
If the router does not detect a valid Internet connection, a list of connection types will be displayed. Select your Internet connection type (this information can be obtained from your Internet Service Provider). Click Next to continue.

If the router detects or you select PPPoE, enter your PPPoE username and password. If you do not have this information, please contact your ISP.
Click Next to continue.
Note: Be sure to remove all other existing PPPoE software from your computer. The software is no longer needed and will not work through a router.

D-Link R15 User Manual

Section 2 - Installation
If the router detects or you select Static, enter the IP and DNS settings supplied by your ISP. If you do not have this information, please contact your ISP. Click Next to continue.

Type in a Wi-Fi Network Name and Wi-Fi Password to set up your Wi-Fi network. Your wireless clients will need this network password to be able to connect to your wireless network.
Click Next to continue.
Note: The router's Smart Connect feature presents a single wireless network. When connecting clients to an extended network, they will be automatically added to the best band, either 2.4 GHz or 5 GHz. To disable the Smart Connect feature and individually configure 2.4 GHz and 5 GHz networks, refer to Wireless on page 54.

D-Link R15 User Manual

Section 2 - Installation
In order to better protect the router's configuration page, please enter a password. You will be prompted for this password every time you log in to the router's web configuration utility. Password must be 8-15 characters and contains both numbers and letters. Note: It is strongly recommended that you change the default device password for accessing the router's configuration page. Click Next to continue.
Select your time zone from the drop-down menu. Click Next to continue.

D-Link R15 User Manual

Section 2 - Installation
Keeping your router's firmware up-to-date provides you with the latest security upgrades and new features over the air. Choose whether to keep your device up-to-date automatically or to manage the device updates by yourself. Click Next to continue.
You will be presented with a summary of your settings. Click Next to apply the settings or Back to make changes.

D-Link R15 User Manual

Section 2 - Installation
Please wait while the device settings are saved. Do not turn off or unplug your router during this time.

Your new settings have been saved and your router is now configured. Click OK to close the Setup Wizard. Congratulations, your device has been successfully configured! You can log in to the web configuration interface with the Admin Password.

D-Link R15 User Manual

Section 3 - Configuration
Configuration
If this is your first time installing the router, open your web browser and enter the default management address at http://XXXX.devicesetup.net/. (where XXXX represents the last 4 digits of the MAC address).

http://xxxx.devicesetup.net/

Note: If you cannot remember your password for login, use a paperclip to press the recessed Reset button on the back of the device to restore the router to its default settings.
The router's home page will open displaying its current connection status.
The left pane has quick access to Settings, Features, and Management functions. You can access AI Assistant (an AI-assisted message center for reports on Wi-Fi conditions and bandwidth utilization at the top right). Note that you need to turn on AI-assisted functions to receive messages.
Note: The system will automatically log out after a period (180 seconds) of inactivity.

D-Link R15 User Manual

Section 3 - Configuration

Home

The Home page displays the status of the router in the form of an interactive diagram. You can click each icon to display information about the components of the network at the bottom of the screen. The left pane allows you to quickly navigate to other pages.
The Home page displays whether the router is currently connected to the Internet.

If it is disconnected, click Click to repair to bring up the setup wizard, refer to the Setup Wizard on page 13 for more information.

D-Link R15 User Manual

Section 3 - Configuration
Internet
To bring up more details about your Internet connection, click on the Internet icon.
Click IPv4 or IPv6 to see details of the IPv4 connection and IPv6 connection respectively. Click Release IP Address to disconnect from the Internet. To reconnect, click Renew IP Address. To reconfigure the Internet settings, refer to Internet - IPv4 on page 27.

D-Link R15 User Manual

Section 3 - Configuration
R15
Click on the R15 icon to view details about the router and its wireless settings.
Here you can see the router's current Wi-Fi network name and password, as well as the router's MAC address, IPv4 address, and IPv6 address.
To reconfigure network settings, either click Go to settings at the bottom of the page, or click Settings > Network (in the left pane). Refer to Network on page 62 for more information.
To reconfigure wireless settings, either click Go to settings, on the lower right, or click Settings > Wireless menu (in the left pane). Refer to Wireless on page 54 for more information.

D-Link R15 User Manual

Section 3 - Configuration
Connected Clients
Click on the Connected Clients icon to obtain information about the connected clients of the router. On this page you can see all the clients currently connected to the router along with their IP addresses and device manufacturers.
To view more information about a client or edit a client's settings such as IP reservation and parental control, click on the client you want to edit.

D-Link R15 User Manual

Section 3 - Configuration

Edit Rule
Name Enter a custom name for this client.

Vendor Displays the vendor of the client.

MAC Address Displays the MAC address of the client.

IP Address Displays the current IP address of the client.

Reserve IP Click Enable to reserve an IP address for the client.

IP Address (Reserved) Specify an IP address for the router's DHCP server to assign.

Parental Control Enable Parental Control and select a profile to control the client's Internet access. Make sure that this device is also on the device list of the selected profile.

Profile

Use the drop-down menu to select a profile to be used for Parental Control. The profile can be set to Always Block to have this client blocked from accessing the Internet, or you can create your own profiles to specify the times that the client can access the network. You can also block access to unwanted websites. Refer to Features > Parental Control on page 66 for more information.

Click Save when you are done.

D-Link R15 User Manual

Section 3 - Configuration

Settings
Wizard

Go to Settings > Wizard to open the setup wizard. This is the same wizard that appears when you start the router for the first time. Refer to Setup Wizard on page 13 for details.
Note: When the Wizard is opened, the router will disconnect from the Internet.

D-Link R15 User Manual

Section 3 - Configuration
Internet - IPv4
Go to Settings > Internet to see the Internet configuration options for IPv4 connection. To configure IPv6 Internet and network connection details, click the IPv6 tab. Refer to Internet - IPv6 on page 37. To configure VLAN connection details, click the VLAN link. Refer to Internet - VLAN on page 52. Click Save at any time to save the changes you have made on this page.
My Internet Choose your Internet connection type from the drop-down menu. Connection is You will be presented with more options for your connection type.
For IPv4 - Dynamic IP (DHCP) refer to page 28 For IPv4 - Static IP refer to page 29 For IPv4 - PPPoE refer to page 30 For IPv4 - PPTP refer to page 32 For IPv4 - L2TP refer to page 34 For IPv4 - DS-Lite refer to page 36

D-Link R15 User Manual

Section 3 - Configuration
IPv4 - Dynamic IP (DHCP)
Select Dynamic IP (DHCP) to obtain IP address information automatically from your Internet Service Provider (ISP). Select this option if your ISP does not specify an IP address to use. Click Save at any time to save the changes you have made on this page.

Host Name Primary DNS Server Secondary DNS Server
MTU MAC Address Clone
Secure DNS DNS over HTTP Provider
Allow Fall-back

Advanced Settings...
The host name is optional but may be required by some ISPs. Leave it blank if you are not sure.
Enter the primary DNS server IP address assigned by your ISP. This address is usually filled in automatically.
Enter the secondary DNS server IP address assigned by your ISP. This address is usually filled in automatically.
Maximum Transmission Unit - you may need to change the MTU for optimal performance with your ISP. The default is 1500.
The default MAC address is set to the Internet port's physical interface MAC address on the router. You can replace the Internet port's MAC address with the MAC address of a connected client.
Enable this option to use public DNS with encryption via DNSover-HTTPS (DoH).
Select the public DNS service provider: Google or Cloudflare.
Use your primary or secondary DNS server as an alternative if the configured provider is not working.

D-Link R15 User Manual

Section 3 - Configuration

IPv4 - Static IP

Select Static IP if your IP information is provided by your Internet Service Provider (ISP). Click Save at any time to save the changes you have made on this page.

IP Address Subnet Mask Default Gateway Primary DNS Server

Enter the IP address provided by your ISP. Enter the subnet mask provided by your ISP. Enter the default gateway address provided by your ISP. Enter the primary DNS server IP address provided by your ISP.

Secondary DNS Server MTU
MAC Address Clone
Secure DNS DNS over HTTP Provider
Allow Fall-back

Advanced Settings...
Enter the secondary DNS server IP address assigned by your ISP.
Maximum Transmission Unit - you may need to change the MTU for optimal performance with your ISP.
The default MAC address is set to the Internet port's physical interface MAC address on the router. You can replace the Internet port's MAC address with the MAC address of a connected client.
Enable this option to use public DNS with encryption via DNSover-HTTPS (DoH).
Select the DNS-over-HTTPS (DoH) service provider: Google or Cloudflare.
Use your primary or secondary DNS server as an alternative if the configured provider is not working.

D-Link R15 User Manual

Section 3 - Configuration
IPv4 - PPPoE
Select PPPoE (Point-to-Point Protocol over Ethernet) if your ISP requires you to enter a PPPoE username and password in order to connect to the Internet. Click Save at any time to save the changes you have made on this page.

Username Password Reconnect Mode Maximum Idle Time

Enter the username provided by your ISP.
Enter the password provided by your ISP.
Select either Always on, On Demand, or Manual.
Configurable when On Demand is selected. Enter a maximum idle time during which the Internet connection is maintained during inactivity. To disable this feature, select Always on or Manual as the reconnect mode. The default is 5 minutes.

Address Mode

Advanced Settings...
Select Static IP if the following information has been provided by your ISP: IP address, MTU, and DNS server addresses. In most cases, select Dynamic IP.

Advanced Settings... - Dynamic IP
Address Mode Shows your chosen address mode. Service Name Enter the ISP service name (optional) Primary DNS Server Enter the primary DNS server IP address assigned by your ISP.

D-Link R15 User Manual

Section 3 - Configuration

Secondary DNS Server Enter the secondary DNS server IP address assigned by your ISP.

MTU

Maximum Transmission Unit (1280~1500)- you may need to change the MTU for optimal performance with your ISP. The default is 1500.

MAC Address Clone

The default MAC address is set to the Internet port's physical interface MAC address on the router. You can replace the Internet port's MAC address with the MAC address of a connected client.

Advanced Settings... - Static IP
Address Mode Displays your chosen address mode.

IP Address Enter the IP address provided by your ISP.

Service Name Enter the ISP service name (optional)

Primary DNS Server Enter the primary DNS server IP address assigned by your ISP.

Secondary DNS Server Enter the secondary DNS server IP address assigned by your ISP.

MTU

Maximum Transmission Unit (1280~1492)- you may need to change the MTU for optimal performance with your ISP. The default is 1492.

MAC Address Clone

The default MAC address is set to the Internet port's physical interface MAC address on the router. You can replace the Internet port's MAC address with the MAC address of a connected client.

Secure DNS Enable this option to use public DNS with encryption via DNSover-HTTPS (DoH).

DNS over HTTP Provider Select the DNS-over-HTTPS (DoH) service provider: Google or Cloudflare.

Allow Fall-back Use your primary or secondary DNS server as an alternative if the configured provider is not working.

D-Link R15 User Manual

Section 3 - Configuration
IPv4 - PPTP
Choose PPTP (Point-to-Point-Tunneling Protocol) if your Internet Service Provider (ISP) uses a PPTP connection. Your ISP will provide you with a username and password. Click Save at any time to save the changes you have made on this page.

PPTP Server
Username Password Reconnect Mode Maximum Idle Time

Enter the PPTP server's IP address or name provided by your ISP.
Enter the username provided by your ISP.
Enter the password provided by your ISP.
Select Always on, On Demand, or Manual.
Configurable when On Demand is selected. Enter a maximum idle time during which the Internet connection is maintained during inactivity. To disable this feature, select Always on as the reconnect mode.

Address Mode

Advanced Settings...
Select Static IP if the following information is given by your ISP: IP address, subnet mask, gateway, and DNS server addresses. In most cases, select Dynamic IP.

Advanced Settings... - Dynamic IP
Address Mode Shows your chosen address mode. Primary DNS Server Enter the primary DNS server IP address assigned by your ISP.

D-Link R15 User Manual

Section 3 - Configuration

Secondary DNS Server MTU

Enter the secondary DNS server IP address assigned by your ISP.
Maximum Transmission Unit (1280~1460) - you may need to change the MTU for optimal performance with your ISP. The default is 1400.

Advanced Settings... - Static IP

Address Mode Displays your chosen address mode.

PPTP IP Address Enter the IP address provided by your ISP.

PPTP Subnet Mask Enter the subnet mask provided by your ISP.

PPTP Gateway IP Address Enter the gateway IP address provided by your ISP.

Primary DNS Server Enter the primary DNS server IP address assigned by your ISP.

Secondary DNS Server Enter the secondary DNS server IP address assigned by your ISP.

MTU

Maximum Transmission Unit (1280~1460) - you may need to change the MTU for optimal performance with your ISP. The default is 1400.

Secure DNS DNS over HTTP Provider
Allow Fall-back

Enable this option to use public DNS with encryption via DNSover-HTTPS (DoH).
Select the DNS-over-HTTPS (DoH) service provider: Google or Cloudflare.
Use your primary or secondary DNS server as an alternative if the configured provider is not working.

D-Link R15 User Manual

Section 3 - Configuration
IPv4 - L2TP
Choose L2TP (Layer 2 Tunneling Protocol) if your Internet Service Provider (ISP) uses an L2TP connection. Your ISP will provide you with a username and password. Click Save at any time to save the changes you have made on this page.

L2TP Server Username Password
Reconnect Mode Maximum Idle Time

Enter the L2TP server IP address provided by your ISP.
Enter the username provided by your ISP.
Enter the password provided by your ISP.
Select Always on, On Demand, or Manual.
Configurable when On Demand is selected. Enter a maximum idle time during which the Internet connection is maintained during inactivity. To disable this feature, select Always on or Manual as the reconnect mode. The default is 5 minutes.

Address Mode

Advanced Settings...
Select Static IP if the following information is given by your ISP: IP address, subnet mask, gateway, and DNS server addresses. In most cases, select Dynamic IP.

Advanced Settings... - Dynamic IP
Address Mode Shows your chosen address mode.
Primary DNS Server Enter the primary DNS server IP address assigned by your ISP.
Secondary DNS Server Enter the secondary DNS server IP address assigned by your ISP.

D-Link R15 User Manual

Section 3 - Configuration

MTU

Maximum Transmission Unit (1280~1460) - you may need to change the MTU for optimal performance with your ISP. The default is 1400

Advanced Settings... - Static IP

Address Mode Shows your chosen address mode.

L2TP IP Address Enter the IP address provided by your ISP.

L2TP Subnet Mask Enter the subnet mask provided by your ISP.

L2TP Gateway IP Address Enter the gateway IP address provided by your ISP.

Primary DNS Server Enter the primary DNS server IP address assigned by your ISP.

Secondary DNS Server Enter the secondary DNS server IP address assigned by your ISP.

MTU

Maximum Transmission Unit (1280~1460) - you may need to change the MTU for optimal performance with your ISP. The default is 1400.

Secure DNS DNS over HTTP Provider
Allow Fall-back

D-Link R15 User Manual

Section 3 - Configuration

IPv4 - DS-Lite

DS-Lite allows local IPv4 packets to travel through an IPv6 network. After selecting DS-Lite, the following parameters will be available for configuration. Click Save at any time to save the changes you have made on this page.

Advanced Settings...

DS-Lite Configuration

Select DS-Lite DHCPv6 Option to let the router allocate the AFTR IPv6 (Address Family Transition Router) address automatically. Select Manual Configuration to enter the AFTR IPv6 address manually.

Advanced Settings... - DS-Lite DHCPv6 Option

B4 IPv4 Address
WAN IPv6 Address IPv6 WAN Default
Gateway

Enter the B4 (Basic Bridging Broadband) IPv4 address that will be encapsulated into IPv6 packets to transmit over an IPv6 network.
Once connected, the WAN IPv6 address will be displayed here.
Once connected, the IPv6 WAN default gateway address will be displayed here.

Advanced Settings... - Manual Configuration Option

AFTR IPv6 Address Enter the Address FamilyTransition Router (AFTR) IPv6 address. This is where an IPv6 packet will be decapsulated.

B4 IPv4 Address Enter the B4 IPv4 address.

WAN IPv6 Address Once connected, the WAN IPv6 address will be displayed here.

IPv6 WAN Default Once connected, the IPv6 WAN default gateway address will Gateway be displayed here.

Secure DNS DNS over HTTP Provider
Allow Fall-back

D-Link R15 User Manual

Section 3 - Configuration
Internet - IPv6
Go to Settings > Internet to see the Internet configuration options for IPv4 , then click the IPv6 tab to access the configuration options for IPv6.
To configure the IPv4 Internet and network connection details, click the IPv4 tab. Refer to Internet - IPv4 on page 27 To configure the VLAN connection details, click the VLAN tab. Refer to Internet - VLAN on page 52
Click Save at any time to save the changes you have made on this page.

My Internet Connection is

Choose your Internet connection type from the drop-down menu. You will be presented with the appropriate options for your connection type.

For IPv6 - Auto Detection refer to page 38 For IPv6 - Static IPv6 refer to page 40 For IPv6 - Auto Configuration (SLAAC/DHCPv6) refer to page 42 For IPv6 - PPPoE refer to page 45 For IPv6 - 6rd refer to page 49 For IPv6 - Local Connectivity Only refer to page 51

D-Link R15 User Manual

Section 3 - Configuration
IPv6 - Auto Detection
Select Auto Detection to automatically detect the IPv6 connection method used by your Internet Service Provider (ISP). If Auto Detection fails, you can manually select another IPv6 connection type. Click Save at any time to save the changes you have made on this page.

DNS Type Primary DNS Server Secondary DNS Server

IPv6 DNS Settings
Select either Obtain DNS server address automatically or Use the following DNS address.
If you select Use the following DNS address, enter the primary DNS server address.
Enter the secondary DNS server address as a backup.

LAN IPv6 Address Settings
Enable DHCP-PD Enable or disable DHCP prefix delegation.
LAN IPv6 Link-Local Displays the router's LAN link-local address, which is used only Address within the local network.
If Enable DHCP-PD is disabled, enter the following: LAN IPv6 Address Enter a valid LAN IPv6 address.
LAN IPv6 Link-Local Displays the router's LAN link-local address. Address

D-Link R15 User Manual

Section 3 - Configuration

Advanced Settings... - Address Autoconfiguration Settings

Enable Automatic IPv6 Address Assignment

Enable or disable the Automatic IPv6 Address Assignment feature.

Enable Automatic Enable or disable DHCP-PD for other IPv6 routers connected DHCP-PD in LAN to the LAN interface.

Autoconfiguration Select SLAAC+RDNSS, SLAAC+Stateless DHCP, or Stateful Type DHCPv6.

If you select SLAAC+RDNSS or SLAAC+Stateless DHCP as the Autoconfiguration Type:

Router Advertisement
Lifetime

Enter the router advertisement lifetime (in minutes). The default is 30 minutes.

If you select Stateful DHCPv6 as the Autoconfiguration Type:
IPv6 Address Enter the start IPv6 address for the DHCP server's IPv6 Range (Start) assignment.

IPv6 Address Range (End)
IPv6 Address Lifetime

Enter the end IPv6 address for the DHCP server's IPv6 assignment.
Enter the dynamic IP's retention time. The default is 10080 minutes.

D-Link R15 User Manual

Section 3 - Configuration
IPv6 - Static IPv6
Select Static IP if your IPv6 information is provided by your Internet Service Provider (ISP). Click Save at any time to save the changes you have made on this page.

Use Link-Local Address IPv6 Address
Subnet Prefix Length
Default Gateway Primary DNS Server Secondary DNS Server

Enable or disable link-local address.
Configurable when Use Link-Local Address is disabled. Enter the address supplied by your ISP.
Configurable when Use Link-Local Address is disabled. Enter the subnet prefix length (1~128) supplied by your ISP.
Enter the default gateway for your IPv6 connection.
Enter the primary DNS server address.
Enter the secondary DNS server address.

LAN IPv6 Address
LAN IPv6 Link-Local Address

LAN IPv6 Address Settings
Enter the LAN (local) IPv6 address for the router. Displays the router's LAN link-local address.

D-Link R15 User Manual

Section 3 - Configuration

Advanced Settings... - Address Autoconfiguration Settings

Enable Automatic IPv6 Address Assignment

Enable or disable the Automatic IPv6 Address Assignment feature.

Autoconfiguration Select SLAAC+RDNSS, SLAAC+Stateless DHCP, or Stateful Type DHCPv6.

If you select SLAAC+RDNSS or SLAAC+Stateless DHCP as the Autoconfiguration Type:

Router Advertisement
Lifetime

Enter the router advertisement lifetime (in minutes). The default is 30 minutes.

If you select Stateful DHCPv6 as the Autoconfiguration Type:
IPv6 Address Enter the start IPv6 address for the DHCP server's IPv6 Range (Start) assignment.
IPv6 Address Enter the end IPv6 address for the DHCP server's IPv6 Range (End) assignment.
IPv6 Address Lifetime Enter the dynamic IP's retention time. The default is 10080 minutes.

D-Link R15 User Manual

Section 3 - Configuration
IPv6 - Auto Configuration (SLAAC/DHCPv6)
Select Auto Configuration if your ISP assigns an IPv6 address when your router requests one from the ISP's server. Some ISPs require you to configure relevant settings in advance before your router can connect to the IPv6 Internet. Click Save at any time to save the changes you have made on this page.

DNS Type Primary DNS Server Secondary DNS Server

IPv6 DNS Settings
Select either Obtain DNS server address automatically or Use the following DNS address.
If you select Use the following DNS address, enter the primary DNS server address.
If you select Use the following DNS address, enter the secondary DNS server address.

LAN IPv6 Address Settings
Enable DHCP-PD Enable or disable prefix delegation.
LAN IPv6 Link-Local Displays the router's LAN link-local address. Address
If Enable DHCP-PD is disabled, configure the following: LAN IPv6 Address Enter a valid LAN IPv6 address.
LAN IPv6 Link-Local Displays the router's LAN link-local address for the local Address network only.

D-Link R15 User Manual

Section 3 - Configuration

Advanced Settings... - Address Autoconfiguration Settings

Enable Automatic IPv6 Address Assignment

Enable or disable the Automatic IPv6 Address Assignment feature.

If Enable DHCP-PD is enabled in the previous LAN IPv6 Address Settings:
Enable Automatic Enable or disable DHCP-PD for other IPv6 routers connected DHCP-PD in LAN to the LAN interface.

Autoconfiguration Select SLAAC+RDNSS, SLAAC+Stateless DHCP, or Stateful Type DHCPv6.

If you select SLAAC+RDNSS or SLAAC+Stateless DHCP as the Autoconfiguration Type:

Router Advertisement
Lifetime

Enter the router advertisement lifetime (in minutes). The default is 30 minutes.

D-Link R15 User Manual

Section 3 - Configuration

Advanced Settings... - Address Autoconfiguration Settings

Enable Automatic IPv6 Address Assignment

Enable or disable the Automatic IPv6 Address Assignment feature.

If Enable DHCP-PD is disabled in the previous LAN IPv6 Address Settings:

Autoconfiguration Select SLAAC+RDNSS, SLAAC+Stateless DHCP, or Stateful Type DHCPv6.

If you select SLAAC+RDNSS or SLAAC+Stateless DHCP as the Autoconfiguration Type:

Router Advertisement
Lifetime

Enter the router advertisement lifetime (in minutes). The default is 30 minutes.

If you select Stateful DHCPv6 as the Autoconfiguration Type:
IPv6 Address Enter the start IPv6 address for the DHCP server's IPv6 Range (Start) assignment.
IPv6 Address Enter the end IPv6 address for the DHCP server's IPv6 Range (End) assignment.
IPv6 Address Lifetime Enter the IP address retention period in minutes. The default is 10080 minutes.

D-Link R15 User Manual

Section 3 - Configuration
IPv6 - PPPoE
Select PPPoE if your ISP requires you to enter a PPPoE username and password to connect to the Internet. Click Save at any time to save the changes you have made on this page.

PPPoE Session Username Password
Address Mode IP Address
Service Name Reconnect Mode
MTU

Create a new PPPoE session.
Enter the username provided by your ISP.
Enter the password provided by your ISP.
Select either Dynamic IP or Static IP.
Configurable if Static IP is chosen. Enter the IP address provided by your ISP.
Enter the ISP service name (optional).
Select either Always On or Manual.
Maximum Transmission Unit - you may need to change the MTU for optimal performance with your ISP. The default is 1492 bytes.

D-Link R15 User Manual

Section 3 - Configuration

DNS Type Primary DNS Server Secondary DNS Server

IPv6 DNS Settings
Select either Obtain DNS server address automatically or Use the following DNS address.
If you select Use the following DNS address, enter the primary DNS server address.
If you select Use the following DNS address, enter the secondary DNS server address as a backup.

Enable DHCP-PD LAN IPv6 Address
LAN IPv6 Link-Local Address

LAN IPv6 Address Settings
Enable or disable prefix delegation.
Configurable if the above DHCP-PD is disabled. Enter the IP address provided by your ISP.
Displays the router's LAN link-local address for the local network only.

D-Link R15 User Manual

Section 3 - Configuration

Advanced Settings... - Address Autoconfiguration Settings

Enable Automatic IPv6 Address Assignment

Enable or disable the Automatic IPv6 Address Assignment.

If Enable DHCP-PD is enabled in the previous LAN IPv6 Address Settings:
Enable Automatic Enable or disable DHCP-PD for other IPv6 routers connected DHCP-PD in LAN to the LAN interface.

Autoconfiguration Select SLAAC+RDNSS, SLAAC+Stateless DHCP, or Stateful Type DHCPv6.

If you select SLAAC+RDNSS or SLAAC+Stateless DHCP as the Autoconfiguration Type:

Router Advertisement
Lifetime

Enter the router advertisement lifetime (in minutes).

D-Link R15 User Manual

Section 3 - Configuration

Advanced Settings... - Address Autoconfiguration Settings

Enable Automatic IPv6 Address Assignment

Enable or disable the Automatic IPv6 Address Assignment feature.

If Enable DHCP-PD is disabled in the previous LAN IPv6 Address Settings:

Autoconfiguration Select SLAAC+RDNSS, SLAAC+Stateless DHCP, or Stateful Type DHCPv6.

If you select SLAAC+RDNSS or SLAAC+Stateless DHCP as the Autoconfiguration Type:

Router Advertisement
Lifetime

Enter the router advertisement lifetime (in minutes). The default is 30 minutes.

If you select Stateful DHCPv6 as the Autoconfiguration Type:
IPv6 Address Enter the start IPv6 address for the DHCP server's IPv6 Range (Start) assignment.
IPv6 Address Enter the end IPv6 address for the DHCP server's IPv6 Range (End) assignment.
IPv6 Address Lifetime Enter the IPv6 address lifetime (in minutes). The default is 10080 minutes.

D-Link R15 User Manual

Section 3 - Configuration
IPv6 - 6rd
IPv6 6rd (rapid deployment) allows IPv6 packets to be transmitted over an IPv4 network. Click Save at any time to save the changes you have made on this page.

Assign IPv6 Prefix Primary DNS Server Secondary DNS Server

Currently unsupported. Enter the primary DNS server address. Enter the secondary DNS server address as a backup.

Enable Hub and Spoke Mode

6rd Manual Configuration
Enable this option if you want to minimize the number of routes to the destination by using a hub and spoke method of networking.

6rd Configuration

Choose the 6rd DHCPv4 Option to automatically discover and populate the data values, or Manual Configuration to enter the settings yourself.

If you select Manual Configuration as the 6rd Configuration:
6rd IPv6 Prefix Enter the 6rd IPv6 network address and prefix length (1~128) supplied by your ISP.

WAN IPv4 Address Enter the IPv4 network prefix.

6rd Border Relay IPv4 Enter the 6rd border relay IPv4 address settings supplied by Address your ISP.

D-Link R15 User Manual

Section 3 - Configuration

LAN IPv6 Address
LAN IPv6 Link-Local Address

LAN IPv6 Address Settings
Displays the router's LAN IPv6 address. Displays the router's LAN link-local address.

Advanced Settings... - Address Autoconfiguration Settings

Enable Automatic IPv6 Address Assignment

Enable or disable the Automatic IPv6 Address Assignment feature.

Autoconfiguration Select SLAAC+RDNSS, SLAAC+Stateless DHCP, or Stateful Type DHCPv6.

If you select SLAAC+RDNSS or SLAAC+Stateless DHCP as the Autoconfiguration Type:

Router Advertisement
Lifetime

Enter the router advertisement lifetime (in minutes). The default is 30 minutes.

If you select Stateful DHCPv6 as the Autoconfiguration Type:
IPv6 Address Enter the start IPv6 address for the DHCP server's IPv6 Range (Start) assignment.
IPv6 Address Enter the end IPv6 address for the DHCP server's IPv6 Range (End) assignment.
IPv6 Address Lifetime Enter the IPv6 address lifetime (in minutes). The default is 10080 minutes.

D-Link R15 User Manual

Section 3 - Configuration
IPv6 - Local Connectivity Only
Local Connectivity Only allows you to set up an IPv6 connection that will not connect to the Internet. Click Save at any time to save the changes you have made on this page.
Advanced Settings... - IPv6 ULA Settings
Enable ULA Click here to enable Unique Local IPv6 Unicast Addresses settings.
Use Default ULA Prefix Enable this option to use the default ULA prefix. ULA Prefix If you disable Use Default ULA Prefix, enter your own ULA prefix.
Advanced Settings... - Current IPv6 ULA Settings
Current ULA Prefix Displays the current ULA prefix. LAN IPv6 ULA Displays the LAN's IPv6 ULA.

D-Link R15 User Manual

Section 3 - Configuration
Internet - VLAN
Go to Settings > Internet, then click the VLAN link to access the configuration options for the VLAN. VLAN allows Triple-Play services to be differentiated by dividing a network into segments and allowing access to these services by devices only in the assigned segment. To configure the IPv4 Internet and network connection details, click the IPv4 link. Refer to Internet - IPv4 on page 27 To configure the IPv6 Internet and network connection details, click the IPv6 link. Refer to Internet - IPv6 on page 37 Click Save at any time to save the changes you have made on this page.
Status Click to enable or disable the Triple-Play VLAN feature. More configuration options will be available if the Status is enabled.

D-Link R15 User Manual

Section 3 - Configuration

If Triple-Play is Enabled: VLAN TAG
Internet VLAN ID
IPTV VLAN ID VOIP VLAN ID
Priority ID

Enable VLAN TAG to enter VLAN ID, as provided by your ISP
Enter the VLAN ID for your Internet connection, as provided by your ISP.
Enter the VLAN ID for your IPTV service, as provided by your ISP.
Enter the VLAN ID for your VoIP network, as provided by your ISP.
Enable or disable traffic priority ID for the Internet, IPTV, and VoIP VLANs. Select a priority ID from the drop-down menus to assign to the corresponding VLAN (0-7). Higher priority ID traffic takes precedence over traffic with a low priority ID tag.

LAN Port 1-3

Interface Traffic Type Setting
Select the type of connection (Internet, IPTV, or Voice over IP) coming from the WAN connection to each interface on the router.

D-Link R15 User Manual

Section 3 - Configuration

Wireless

Go to Settings > Wireless to see your wireless network settings for your router.

Click Save at any time to save the changes you have made on this page.

Status

Wi-Fi Mesh
Enable or disable Wi-Fi mesh if you plan to build a mesh network in your environment. The mesh network is able to find the shortest and fasted path to your gateway/router in a mesh network topology. Hence, it enhances efficiency and reliability.

Status

Smart Connect
Enable or disable the Smart Connect Feature. The Smart Connect feature presents a single wireless network. When connecting clients to the extended network, the clients will be automatically added to the best band, either 2.4 GHz or 5 GHz.

If Smart Connect is Enabled:
Wireless
Wi-Fi Name (SSID) Create a name for your wireless network. Up to 32 characters are allowed.

Password Create a Wi-Fi password. Wireless clients will need to enter this password to successfully connect to the network.

D-Link R15 User Manual

Section 3 - Configuration

Wireless - Advanced Settings...

Security Mode

Choose None, WPA/WPA2-Personal, WPA2-Personal, WPA2/ WPA3-Personal, or WPA3-Personal. WPA3 provides the highest level of encryption among these. Note that WPS will be disabled if WPA3 is used.

Transmission Power Select the desired wireless transmission power: High, Medium, or Low.

Schedule

Select the time during which the wireless network will be available. The schedule may be set to Always Enable or you can add your own schedule.

To add a schedule: Each box represents half an hour, with the clock time (0~23) at the top of each column. To add a time period to the schedule, simply click on the start time and drag to the end time. You can add multiple days and multiple periods per day to the schedule.

D-Link R15 User Manual

Section 3 - Configuration

Status

Smart Connect
Enable or disable the Smart Connect Feature. When disabled, 2.4GHz and 5GHz configuration options become available.

If Smart Connect is Disabled:
2.4GHz / 5GHz
Status Enable or disable the 2.4GHz / 5GHz wireless network.

Wi-Fi Name (SSID) Create a name for your wireless network. Up to 32 characters are allowed.

Password Create a Wi-Fi password. Wireless clients will need to enter this password to connect to the network.

D-Link R15 User Manual

Section 3 - Configuration

Security Mode

2.4GHz - Advanced Settings...
Choose None, WPA/WPA2-Personal, WPA2-Personal, WPA2/ WPA3-Personal, or WPA3-Personal. WPA3 provides the highest level of encryption among these. Note that WPS will be disabled if WPA3 is used.

802.11 Mode (2.4GHz) Wi-Fi Channel

Select the desired wireless networking standards to use in your environment. The available options for the 2.4 GHz wireless network are Mixed 802.11b/g/n, Mixed 802.11b/g, Mixed 802.11g/n, 802.11b only, 802.11g only, and 802.11n only.
Select the desired channel:1-11. The default is Auto (recommended).

Transmission Power
Channel Width (2.4GHz)

Select the desired wireless transmission power: High, Medium, or Low. Select Auto 20/40 MHz if you are using both 802.11n and non-802.11n (802.11b/g) devices, or select 20 MHz if you are using a mix of 802.11b/g devices.

HT20/40 Coexistence (2.4GHz)

Enable or disable the existence of both 20 MHz and 40 MHz channel width. Keep it enabled to achieve the maximum operability of wireless products using different standards in your environment. However, it might prevent your 802.11n devices from reaching the maximum performance.

Visibility Status The default setting is Visible. Select Invisible if you do not want to broadcast the SSID of your wireless network.

Schedule

Select the time during which the wireless network will be available. The schedule may be set to Always Enable or you can add your own schedule.

D-Link R15 User Manual

Section 3 - Configuration

Security Mode
802.11 Mode (5GHz)
Wi-Fi Channel Transmission Power Channel Width (5GHz)
Visibility Status Schedule

5GHz - Advanced Settings...
Choose None, WPA/WPA2-Personal, WPA2-Personal, WPA2/ WPA3-Personal, or WPA3-Personal. WPA3 provides the highest level of encryption among these. Note that WPS will be disabled if WPA3 is used.
Select the desired wireless networking standards to use. The available options for the 5 GHz wireless network are Mixed 802.11a/n/ac/ax, Mixed 802.11a/n/ac, Mixed 802.11a/n, 802.11ac only, 802.11a only, and 802.11n only.
Select the desired channel: 36, 40, 44, 48, 149, 153, 157, 161, or 165. The default is Auto (recommended).
Select the desired wireless transmission power: High, Medium, or Low.
Select Auto 20/40/80 MHz if you are using 802.11ax, 802.11ac, 802.11n, and 802.11a devices, select Auto 20/40 if you are using 802.11n and 802.11a devices, or select 20 MHz if you are using 802.11a devices.
The default setting is Visible. Select Invisible if you do not want to broadcast the SSID of your wireless network.
Select the time during which the wireless network will be available. The schedule may be set to Always Enable or you can add your own schedule.

D-Link R15 User Manual

Section 3 - Configuration

AI Wi-Fi Optimizer
AI-assisted Wi-Fi Optimizer intelligently assists in bandwidth optimization in your home or office network. It automatically adopts the "cleanest" channel and utilizes beamforming technology to improve signal efficiency and reduce interference. It also provides push notifications about weekly network bandwidth utilization and network management advice on prioritizing clients to maintain the overall Internet quality. Refer to EAGLE PRO AI on page 93 for more information.
AI Wi-Fi Optimizer Enable or disable AI Wi-Fi Optimizer functionality.
Choose Optimization Enable or disable scheduled optimization. Select the time at Time which the AI Wi-Fi Optimizer will start.
Once this is turned on, you will start receiving weekly reports on Wi-Fi conditions through AI Assistant.

Wi-Fi Protected Setup

The easiest way to connect your wireless devices to the router is with Wi-Fi Protected Setup (WPS).

WPS-PBC Status

Enable or disable WPS-PBC (Push Button Configuration) functionality. Press to establish a connection with another WPS compatible device.

D-Link R15 User Manual

Section 3 - Configuration
Guest Zone
Go to Settings > Wireless, then click the Guest Zone tab to configure your guest Wi-Fi.
The Guest Zone feature will allow you to create temporary zones that can be used by guests to access the Internet. These zones will be separate from your main wireless network. You may configure different zones for the 2.4 GHz and 5 GHz wireless bands. Click Save at any time to save the changes you have made on this page.

If Smart Connect is Enabled in the previous Wireless settings, configure the following for both radio frequencies. If it is Disabled, configure the following for 2.4GHz and 5GHz individually.
Wireless

Status Enable or disable the Guest Zone feature. The status is disabled by default.

Wireless Name (SSID) Create a name for your wireless network using up to 32 characters.

Password Create a Wi-Fi password. Your password must be between 8-63 characters in length.

Schedule

Select the time during which the wireless network will be available. The schedule may be set to Always Enable or you can add your own schedule.
To add a schedule: Each box represents half an hour, with the clock time (0~23) at the top of each column. To add a time period to the schedule, simply click on the start time and drag to the end time. You can add multiple days and multiple periods per day to the schedule.

D-Link R15 User Manual

Section 3 - Configuration

Security Mode

Advanced Settings
Choose None, WPA/WPA2-Personal, WPA2-Personal, WPA2/ WPA3-Personal, or WPA3-Personal. WPA3 provides the highest level of encryption among these. Note that WPS will be disabled if WPA3 is used.

Internet Access Only

Home Network Access
Enabling this option will confine connectivity to the Internet and prevent guests from accessing other local network devices.

D-Link R15 User Manual

Section 3 - Configuration
Network
Go to Settings > Network to change the local network settings of the router and configure the DHCP settings. Click Save at any time to save the changes you have made on this page.

LAN IP Address
Subnet Mask Management Link
Local Domain Name Enable DNS Relay

Network Settings
Enter the IP address of the router. The default IP address is 192.168.0.1. If you change the IP address, you will need to enter the new IP address in your browser to log in to the web configuration.
Enter the subnet mask of the router. The default subnet mask is 255.255.255.0.
The default address to access the router's configuration is http://R15-XXXX.local./ (where XXXX represents the last 4 digits of your router's MAC address). You can replace R15-XXXX with a name of your choice.
Enter the domain name (optional).
Disable this option to transfer the DNS server information from your ISP to network clients for setting DNS server. If enabled, network clients will instead set the router's IP address as the DNS server.

D-Link R15 User Manual

Section 3 - Configuration

Status DHCP IP Address
Range
DHCP Lease Time Always Broadcast
WAN Port Speed UPnP
IPv4 Multicast Streams IPv6 Multicast Streams

DHCP Server
Enable or disable the DHCP server.
Enter the start and end IP addresses for the DHCP server's IP assignment. Note: If you statically assign IP addresses to your computers or devices, make sure the IP addresses are outside of this range or you may have an IP conflict.
Enter the length of time for the IP address lease in minutes. The default is 10080 minutes.
Enable this feature to broadcast your network's DHCP server to LAN/WLAN clients.
Advanced Settings...
You may set the link speed of the Internet port to 10 Mbps, 100 Mbps, 1000 Mbps, or Auto (recommended).
Enable or disable Universal Plug and Play (UPnP). UPnP provides compatibility with networking equipment, software, and peripherals. This is enabled by default.
Allow or disallow IPv4 multicast traffic to pass through the router from the Internet. This is enabled by default.
Allow or disallow IPv6 multicast traffic to pass through the router from the Internet. This is enabled by default.

D-Link R15 User Manual

Section 3 - Configuration
D-Link Cloud
Go to Settings > D-Link Cloud to see your D-Link Cloud Service details. This page lists whether you are registered with D-Link Cloud Service and email address associated with the account. It enables you to manage your device anytime, anywhere and check the status of your router. Use the EAGLE PRO AI to find out more about D-Link Cloud's features.

D-Link R15 User Manual

Section 3 - Configuration

Operation Mode

Go to Settings > Operation Mode to select your operation mode. Depending on your network architecture, you can configure the router to function as one of the following types of network device: router, extender, or bridge.
Router Mode: In this mode, the R15 directly connects to the Internet provided by your ISP (Internet Service Provider). All client devices from a network group are connected and managed under this router. This is the default mode.
Bridge Mode: In this Mode, the R15 extends your existing network and improves overall Wi-Fi coverage, meaning that you already have a router on the premises. Under this mode, the DHCP Server, Parental Control, QoS, and Firewall settings rely on the existing router.
Extender Mode: In this mode, this device acts as an extender to connect your wireless devices, expanding Wi-Fi coverage. It provides connectivity between various wireless devices. This can be useful if you already have an existing wireless router. You can then manage the extender through the main router under this mode.

D-Link R15 User Manual

Section 3 - Configuration
Features
Parental Control
Go to Features > Parental Control to configure parental control policies. You can configure schedules that set time limits for Internet access and prevent access to certain websites.
Click Save at any time to save the changes you have made on this page. This page displays a list of profiles with the following information:
Profile Name The name describes this profile. Device Count The number of devices that this policy will be applied to.
State Displays the current status of Internet accessibility, i.e. Normal, Schedule Paused, or Paused on Demand.
Edit Edit this access profile. Delete Remove this access profile. A maximum of 12 profiles can be defined.
To add a profile, configure the following:

Schedule

Profile Name Enter a name for this profile.

Allow Internet Access Click Enabled and define the schedule to allow Internet access. Time Select the time during which the Internet will be available.

D-Link R15 User Manual

Section 3 - Configuration

Block Internet Access During Bedtime
Allow Slow Internet Access

Click Enabled and define the schedule to block Internet access during bedtime. To add a bedtime schedule: Select the time during which bedtime schedule will be active. Select the days of the week, then select the pause time and the resume time for the period during which Internet access will be blocked. To specify different time periods for days of the week, click Add another Bedtime schedule... A maximum of 2 schedules can be defined.
Enable this option to allow slow Internet access with reduced speed during restricted hours set above.

You can also modify an existing schedule by clicking Edit.

Website Filter

Click Add Rule to add a new website to be blocked:

Website Name

Enter the name for the website. This blocks access to websites based on a website's address. For example, enter "ABC.com" or "www.ABC.com."

URL Keyword

This blocks access to websites based on the keywords with matching URLs. For example, use "ABC" to block "www.ABC. com" and "xxx.ABC.com" and other URLs containing ABC. Enter the same website name as the above in this field to block only the specific URL.

You can also modify or delete an existing rule by clicking Edit or Delete respectively.

Device

Click Add Device to add devices to be in the defined profile. Select the devices from the list of connected devices to which the access policy should be applied, then click Apply to close the screen. Click Save to save your profile settings and the new profile will be added to the profile list. You can also modify or delete an existing profile by clicking Edit or Delete

respectively.On the Edit page for a selected profile, you can click Internet access to specified devices of the profile immediately.

to pause

D-Link R15 User Manual

Section 3 - Configuration

Click Settings to view the messages displayed to the device users whose Internet access has been restricted.

Blocked Webpage Message

For these access controls: Manual Pause Control, Website Filter, Custom Schedule, and Bedtime Schedule, you can view and customize the messages as well as the titles:

Title Enter the title of the message in the text box.

Description State the message to inform the user about the restricted access.

Reset this message Preview this message

Click this button to reset the modified message to its factory default.
Display the presentation of the message on a new webpage.

D-Link R15 User Manual

Section 3 - Configuration
QoS Engine
Go to Features > QoS Engine to configure clients' Internet access priorities. It aims to optimize Internet traffic to enhance the overall user experience.
Click Save at any time to save the changes you have made on this page.

Click Check Speed to run a speed check to determine how to distribute WiFi bandwidth to prioritized devices. The speed test helps the QoS engine to distribute Wi-Fi bandwidth to prioritized devices (configured in the device cards below).

AI Traffic Optimizer
Upload Speed Download Speed

The intelligent QoS Engine lists devices consuming comparatively large resources and will intelligently adjust bandwidth to these devices by assigning a low priority. It will also allocate appropriate bandwidth to connected devices based on their priorities to maintain quality online experience.
Once this is turned on, you will start receiving weekly reports on bandwidth usage through AI Assistant.
The rate at which the content is being transferred to the Internet.
The rate at which the content is being transferred to the router.
Click Apply to QoS after the Speed Test to automatically fill in the above information.

D-Link R15 User Manual

Section 3 - Configuration
This Quality of Service (QoS) Engine allows you to prioritize particular clients over others, so that these clients receive higher bandwidth. For example, if one client is streaming a movie and another is downloading a bulk of files, you might want to assign the former device a higher priority than the latter so that the movie streaming is not disrupted.
Under Connected Clients, you will see device cards representing each connected client. Click All to see all connected devices and Heavy Consumer to see clients that are particularly active on the Internet.
To assign a priority level to a device, enable AI Traffic Optimizer first. Then click the client to open its information page. It shows the following information:
Device Name: The name that describes the client device MAC Address: The MAC address of the client device IPv4/IP v6 Address: The IP address in IPv4 and IPv6 addressing mechanism of the client device. Priority: Select the priority for the client device with the following categories:
Normal; High: Always Enable, for 1 Day, for 4 Hours, for 2 Hours, or for 1 Hour; Low: Always Enable, for 1 Day, for 4 Hours, for 2 Hours, or for 1 Hour.
Traffic Statistics
It shows traffic statistics for these activities: TCP flow, UDP flow, and Download and Upload speeds in megabit per second.
Real-Time & Weekly Traffic
Two graphs: Real-time Traffic represents real-time data speeds in megabyte per second or kilobyte per second. Weekly Traffic represents daily download and upload data volume for the past week in kilobyte or megabyte.
If no devices are explicitly assigned a priority, they will all be treated with equal priority.

D-Link R15 User Manual

Section 3 - Configuration
Firewall
Go to Features > Firewall to configure the router's firewall settings. The firewall feature helps protect your network from malicious attacks over the Internet.
To configure the IPv4 firewall rules, click the IPv4 Rules tab. Refer to Firewall Settings - IPv4/IPv6 Rules on page 73 To configure the IPv6 firewall rules, click the IPv6 Rules tab. Refer to Firewall Settings - IPv4/IPv6 Rules on page 73
Click Save at any time to save the changes you have made on this page.

Enable DMZ
DMZ IP Address Enable SPI IPv4
Enable Anti-spoof Checking
IPv6 Simple Security IPv6 Ingress Filtering

Enable or disable Demilitarized Zone (DMZ). Devices in this zone are completely exposed to threats over the Internet. This is not recommended unless they are servers that must be exposed to the WAN.
If you enable DMZ, enter the IP address of the client to be placed in this zone, or use the drop-down menu to quickly select one of the clients.
Enabling Stateful Packet Inspection (SPI) or dynamic packet filtering helps prevent cyber attacks by tracking more states per session to validate that the traffic passing through the session conforms to the protocol.
Enable this feature to help protect your network from certain kinds of "spoofing" attacks.
Enable or disable IPv6 simple security. A simple firewall configuration that denies access directly to computers behind the router.
Enable or disable IPv6 ingress filtering for incoming packets to prevent suspicious senders.

D-Link R15 User Manual

Section 3 - Configuration

Advanced Settings... - Application Level Gateway (ALG) Configuration

Different ALGs provide special handling for specific protocols or applications. A number of ALGs for common applications are enabled by default as stated below.

PPTP Allows multiple machines on the LAN to connect to their corporate network using the PPTP protocol.

IPSec (VPN)

Allows multiple VPN clients to connect to their corporate network using IPSec. Some VPN clients support traversal of IPSec through NAT. This Application Level Gateway (ALG) may interfere with the operation of such VPN clients. If you are having trouble connecting with your corporate network, try turning this ALG off. Please check with the system administrator of your corporate network whether your VPN client supports NAT traversal.

RTSP Allows applications that uses Real Time Streaming Protocol (RTSP) to receive streaming media from the Internet.

SIP Allows devices and applications using VoIP (Voice over IP) to communicate across NAT. Some VoIP applications and devices have the ability to discover NAT devices and work around them. This ALG may interfere with the operation of such devices. If you are having trouble making VoIP calls, try turning this ALG off.

D-Link R15 User Manual

Section 3 - Configuration
Firewall Settings - IPv4/IPv6 Rules
Go to Features > Firewall, then click the IPv4 Rules tab or the IPv6 Rules tab to configure rules for traffic filtering. To configure the Firewall Advanced settings, click the Advanced link. Refer to Firewall on page 71 Click Save at any time to save the changes you have made on this page.
To begin, use the drop-down menu to select whether it is an ALLOW or DENY rule. You can also choose to turn filtering OFF. If you want to remove a rule, click in the Delete column. If you wish to edit a rule, click
in the Edit column. If you wish to create a new rule, click the Add Rule button.

D-Link R15 User Manual

Section 3 - Configuration

If you click Edit or Add Rule, the following options will appear: Name Enter a name for the rule.

Source IP Address Range

Enter the source IP address range (e.g. 1.1.1.1-1.1.1.2 for IPv4 or 2001::1-2001::2 for IPv6) that the rule will apply to. Using the drop-down menu, specify whether it is a WAN or LAN IP address. Both a single IP address and a range of IP addresses can be entered.

Destination IP Address Range

Enter the destination IP address range (e.g. 1.1.1.1-1.1.1.2 for IPv4 or 2001::1-2001::2 for IPv6) that the rule will apply to. Using the drop-down menu, specify whether it is a WAN or LAN IP address. Both a single IP address and a range of IP addresses can be entered.

Protocol & Port Range

Select the protocol of the traffic to allow or deny (Any, TCP, or UDP) and then enter the range of ports (e.g. 21-23) that the rule will apply to. Select Any to allow/deny all types of traffic regardless of the port number.

Schedule

Use the drop-down menu to select the time schedule for the rule. The schedule may be set to Always Enable, or you can create your own schedules in the Schedules section. Refer to Management > Time & Schedule - Schedule on page 85 for more information.

A maximum of 24 rules can be defined.

D-Link R15 User Manual

Section 3 - Configuration
Port Forwarding
Go to Features > Port Forwarding to specify a port or range of ports to open for specific devices on the network. This might be necessary for certain applications to connect through the router. For example, access from the Internet can be redirected to a DMZ host using Port Forwarding.
To configure the Virtual Server settings, click the Virtual Server link. Refer to Port Forwarding - Virtual Server on page 77.
Click Save at any time to save the changes you have made on this page.
If you want to remove a rule, click in the Delete column. If you want to edit a rule, click in the Edit column. If you want to create a new rule, click the Add Rule button.

D-Link R15 User Manual

Section 3 - Configuration

If you click Edit or Add Rule, the following options will appear: Name Enter a name for the rule.

Local IP

Enter the IP address of the computer on your local network to which you want to direct the incoming service. Alternatively, select the device from the drop-down menu.

TCP Port

Enter the TCP ports that you want to open. You can enter a single port or a range of ports. Separate ports with a comma (for example: 24,1009,3000-4000).

UDP Port

Enter the UDP ports that you want to open. You can enter a single port or a range of ports. Separate ports with a comma (for example: 24,1009,3000-4000).

Schedule

D-Link R15 User Manual

Section 3 - Configuration

Port Forwarding - Virtual Server

Go to Features > Port Forwarding then click the Virtual Server tab to configure its settings and specify a public port on your router for redirection to an internal LAN IP with the mapped port. This might be necessary if you are hosting services behind the router.
To configure the Port Forwarding settings, click the Port Forwarding link. Refer to Port Forwarding on page 75
Click Save at any time to save the changes you have made on this page.

If you wish to remove a rule, click in the Delete column. If you wish to edit a rule, click in the Edit column. If you wish to create a new rule, click the Add Rule button.

D-Link R15 User Manual

Section 3 - Configuration

If you click on Edit or Add Rule, the following options will appear:

Name

Enter a name for the rule. Alternatively, select the protocol/ Application Name from the drop-down menu. Depending on the requested service, the router redirects the external service request to the appropriate internal host.

Local IP

Enter the IP address of the computer on your local network that you want to direct the incoming service to. Alternatively, select the device from the drop-down menu.

Protocol Select the protocol of the traffic to allow or deny (TCP, UDP, Both, or Other).

Protocol Number

If you entered Other above, enter the protocol number. Refer to https://www.iana.org/assignments/protocol-numbers/ protocol-numbers.xhtml for Assigned Internet Protocol Numbers.

External Port Enter the public port you want to open.

Internal Port Enter the private port you want to open.

Schedule

Use the drop-down menu to select the time schedule for the rule. The schedule may be set to Always Enable, or you can create your own schedules in the Schedules section. Refer to Time & Schedule - Schedule on page 85 for more information.

D-Link R15 User Manual

Section 3 - Configuration
Static Routes - IPv4
Go to Features > Static Routes to define custom routes to control how traffic moves around your network. To configure the Static Route IPv6 settings, click the IPv6 tab. Refer to Static Routes - IPv6 on page 80 Click Save at any time to save the changes you have made on this page.
If you wish to remove a rule, click in the Delete column. If you wish to edit a rule, click in the Edit column. If you wish to create a new rule, click the Add Rule button.

If you click on Edit or Add Route, the following options will appear: Name Enter a name for the route.
Destination Network Enter the destination IP address of the subnetwork.
Mask Enter the subnet mask of the destination address.
Gateway Enter the IP address of the next hop, which is the gateway to the remote network.
Metric Enter a route metric value between 1 and 16. This value indicates the cost of using this route.
Interface Select the interface that the IP packet will use to transit out of the router when this route is used.

D-Link R15 User Manual

Section 3 - Configuration

Static Routes - IPv6

Go to Features > Static Routes, then click IPv6 to configure the IPv6 Static Routes. To configure the Static Route IPv4 settings, click the IPv4 tab. Refer to Static Routes - IPv4 on page 79. Click Save at any time to save the changes you have made on this page.

If you wish to remove a rule, click in the Delete column. If you wish to edit a rule, click in the Edit column. If you wish to create a new rule, click the Add Rule button.

If you click on Edit or Add Route, the following options will appear: Name Enter a name for the route.

DestNetwork Enter the destination IPv6 address of the subnetwork or the prefix, for example, 2010:db9:abcd:1234::

PrefixLen Enter the prefix length, which is the number of prefix bits of the IPv6 address. Enter a value between 64 and 128.

Gateway Enter the IP address of the next hop, which is the gateway to the remote network.

Metric Enter a route metric value between 1 between 128. This value indicates the cost of using this route.

Interface Select the interface that the IP packet will use to transit out of the router when this route is used.

D-Link R15 User Manual

Section 3 - Configuration
Dynamic DNS
Go to Features > Dynamic DNS. This page allows your router to associate an easy-to-remember domain name such as [YourDomainName].com with a regularly changing IP address assigned by your Internet Service provider. This feature is helpful when running a virtual server. Click Save at any time to save the changes you have made on this page.

Enable Dynamic DNS
Status Server Address
Host Name
User Name Password Time Out

Enable or disable dynamic DNS. Enable this feature to display more configuration options.
Displays the current dynamic DNS connection status.
Select the DDNS service provider from the drop-down menu.
Enter the host name that you registered with your dynamic DNS service provider.
Enter your dynamic DNS account name.
Enter your dynamic DNS account password.
Enter a time-out value (in hours) to indicate how often the router should update its Dynamic DNS settings.

D-Link R15 User Manual

Section 3 - Configuration

At the bottom of the page are the IPv6 host settings. If you wish to remove a record, click in the Delete column. If you wish to edit a record, click in the Edit column. If you wish to create a new record, click the Add Record button.

Host Name Enter the host name that you registered with your dynamic DNS service provider.

IPv6 Address

Enter the IPv6 address of your host or server for DDNS configuration. Alternatively, select the network interface for DDNS configuration.

A maximum of 10 records can be defined.

D-Link R15 User Manual

Section 3 - Configuration
Quick VPN
Go to Features > Quick VPN. This page will help you configure the Quick VPN feature of your router. For more information, refer to Quick VPN on page 110. Before proceeding, ensure that your Internet connection is working properly. We recommend configuring Dynamic DNS before proceeding with Quick VPN setup. If your router is assigned an IP address from your ISP using DHCP, it may frequently change, requiring connection parameters to be set accordingly and a DDNS address can avoid this hassle.
To configure the User settings and grant users with VPN permission, go to Management > User. Refer to User on page 90.
Click Save at any time to save the changes you have made on this page.

L2TP over IPSec
Username Password
PSK VPN Profile for iOS Device and MAC OS X
Authentication Protocol MPPE

Enable or disable the Quick VPN server. Quick VPN uses L2TP protocol.
Enter a username.
Enter a password containing both numbers and letters with 8 to 64 characters in length.
Enter a Pre-shared Key between 6 and 64 characters.
Click Export to save the VPN profile settings file for iOS devices and Mac OS X.
Advanced Settings...
Choose the authentication protocol type: MSCHAPv2, PAP, or CHAP. MSCHAPv2 is the default.
Select the encryption cipher strength for Microsoft Point-toPoint (MPPE) Encryption: None, RC4-40, or RC4-128. None is the default.

D-Link R15 User Manual

Section 3 - Configuration

Management
Time & Schedule - Time

Go to Management > Time & Schedule. The Time page allows you to configure, update, and maintain the correct time on the internal system clock. From here you can set the time zone and the Network Time Protocol (NTP) server.
To configure the Schedule settings, click the Schedule tab. Refer to Time & Schedule - Schedule on page 85
Click Save at any time to save the changes you have made on this page.

Time Zone Time

Time Configuration
Select your time zone from the drop-down menu. Displays the current date and time of the router.

Automatic Time Configuration

NTP Server

Select from the drop-down menu to use one of the following servers to synchronize the time and date for your router: D-Link NTP Server or Google NTP Server. Choose Manual to set the NTP server's IP address or server name.

D-Link R15 User Manual

Section 3 - Configuration
Time & Schedule - Schedule
Go to Management > Time & Schedule, then click the Schedule tab. The Schedule page allows you to control some of the functions based on a pre-configured schedule, for example, Port Forwarding in Features > Port Forwarding and Firewall Settings in Features > Firewall as well as sending Syslog via email in Management > System Log. To configure the Time settings, click the Time tab. Refer to Time & Schedule - Time on page 84 Click Save at any time to save the changes you have made on this page.
If you wish to remove a schedule, click in the Delete column. If you wish to edit a schedule, click in the Edit column. If you wish to create a new schedule, click the Add a Schedule button.
On the Schedule creation page, enter the name of your schedule in the Name field. Each box represents half an hour, with the clock time (0~23) at the top of each column. To add a time period to the schedule, simply click on the start time and drag to the end time. You can add multiple days and multiple periods per day to the schedule. To remove a time period from the schedule, click on the cross icon. Click Apply to save and close the page. Then click Save when you are done creating schedules.

D-Link R15 User Manual

Section 3 - Configuration
System Log
Go to Management > System Log. The router keeps a running log of events. This log can be sent to a Syslog server or to your email address.
Click Save at any time to save the changes you have made on this page.

System Log

Log Settings
Click the Check System Log button to download a text file containing the system log. You can view the log entries by opening with any text editing applications such as WordPad on Windows.

Enable Logging to Syslog Server
SysLog Server IP Address

SysLog Settings
Check this box to send the router logs to a SysLog Server.
Configurable if Enable Logging to Syslog Server is enabled. Enter the IP address of the Syslog server. If the Syslog server is connected to the router, select it from the drop-down menu to automatically populate the field.

D-Link R15 User Manual

Section 3 - Configuration

Enable E-mail Notification

Email Settings
Enable this option if you want the logs to be automatically sent to an email address.

If you enable Enable E-mail Notification, configure the following: From E-mail Address Enter the sender's email address of the SysLog messages.

To E-mail Address Enter the recipient's email address.

SMTP Server Address Enter the SMTP server address.

SMTP Server Port Enter the SMTP server port. The default is 25.

Enable Authentication Enable this if your SMTP server requires authentication.

Account Name Enter your SMTP account name.

Password Enter your SMTP account's password.

E-mail Log When Full or On Schedule

Send When Log Full

If enabled, this option will set the router to send the log when the log buffer is full. The email account for sending logs is configured in the above section.

Send on Schedule

If enabled, this option will set the router to send the log according to a set schedule periodically, so the administrator is always up to date on the operation of the router. The email account for sending logs is configured in the above section.

Schedule

If you enable Send On Schedule, use the drop-down menu to select a schedule to apply. The schedule may be set to Always Enable, or you can create your own schedules in the Schedules section. Refer to Time & Schedule - Schedule on page 85 for more information.

D-Link R15 User Manual

Section 3 - Configuration
System Admin - Admin
Go to Management > System Admin. The Admin page will allow you to change the administrator (Admin) password. To configure the System settings, click the System tab. Refer to System Admin - System on page 89 Click Save at any time to save the changes you have made on this page.

Admin Password

Password

Enter a new password for the administrator account. You will need to enter this password whenever you configure the router using a web browser or add the router to EAGLE PRO AI. It is recommended that you change the default device password printed on the device label on the bottom of the device.

Advanced Settings... - Administration

Enable HTTPS Management
Enable HTTPS Remote Management

Enable router management using an encrypted HTTP connection.
Enable remote management over the Internet using an encrypted HTTP connection.

Remote Admin Port Status LED

Specify the port number for accessing the web configuration interface. The default is 8081.
LED Control
Turn the LED status lights on or off.

D-Link R15 User Manual

Section 3 - Configuration
System Admin - System
Go to Management > System Admin, then click System. This page allows you to save the router's current configuration, load a previously saved configuration, reset the router to its factory default settings, or reboot the router.
To configure the Admin settings, click the Admin tab. Refer to System Admin - Admin on page 88
Click Save at any time to save the changes you have made on this page.

Save Settings to Local Hard Drive
Load Settings from Local Hard Drive
Restore to Factory Default Settings

System
This option will save the current router configuration settings to a file (bin type) on your computer.
This option will load a previously saved router configuration file. This will overwrite the router's current configuration.
This option will restore the router back to the default configurations stored in the firmware. Any settings that have not been saved will be lost, including any rules that you have created. If you want to back up the current router configuration settings before restoring to factory defaults, use the Save Settings to Local Hard Drive function above.

Reboot the Device Auto Reboot

Auto Reboot Configuration
Click this button to reboot the router immediately.
You may set the router to automatically reboot at a set time. The options are Never, Daily, or Weekly. You may set the day, and hour and minute of the day for automatic reboot.

D-Link R15 User Manual

Section 3 - Configuration
User
Go to Management > User. The User page is used to create, manage, and delete user accounts with VPN connection permission. Click Save at any time to save the changes you have made on this page.
If you wish to remove a user, click in the Delete column. If you wish to edit a user, click in the Edit column. If you wish to create a new user, click the Create User button.

To create a user, click Create User and configure the following: User Name Enter a username for the new user account. Maximum length: 20 characters.
Password Enter a password for the new user account. Maximum length: 32 characters.
VPN
Status Enable or disable Virtual Private Network (VPN) functionality for this user.
A maximum of 9 users (not including the Admin) can be created. Click OK to close the screen.

D-Link R15 User Manual

Section 3 - Configuration
Upgrade
Go to Management > Upgrade. This page allows you to upgrade the router's firmware, either automatically or manually. To manually upgrade the firmware, you must first download the firmware file from http://support.dlink.com.
Click Save at any time to save the changes you have made on this page.

Current Firmware Version

Firmware Information
Displays the current firmware version for both the main router as well as the extenders.

Check for New Firmware

Click this button to prompt the router to automatically check for a new firmware version. If a newer version is found, it will prompt you to install it.

Advanced Settings...Upgrade Manually Device Name Select the device in the mesh network for manual update.

Select File

If you wish to upgrade manually, first download the firmware file. Then, click the Select File button and locate the file to install the new firmware.

Automatic Upgrade

Automatic Firmware Upgrade
If enabled, the router will automatically upgrade to the newest firmware. The system will automatically upgrade to the latest firmware every day at 3:30-4:00 AM.

Choose Upgrade Time Enable this function to set the router to automatically upgrade its firmware at a set time every day.

Upgrade Time Configurable if Choose UpgradeTime is enabled. Set the hour and minute to automatically upgrade the router.

D-Link R15 User Manual

Section 3 - Configuration
Statistics
Go to Management > Statistics. On the Statistics page you can view the amount of traffic that passes through the router on the Internet and LAN interfaces as well as the traffic from Wi-Fi 2.4 GHz and Wi-Fi 5GHz networks.
Router You can view the Internet, LAN, Wi-Fi 2.4 GHz, or Wi-Fi 5 GHz by clicking the respective tab at the top. The real-time graph of network traffic in kilobyte per second will be shown. To clear the information on the graph, click Clear. The table below for each interface and radio frequency shows the total number of packets and data that are sent and received through the interface. The traffic counter will reset if the device is rebooted.
Extender Click the Extender tab to view the above information about the extender.

D-Link R15 User Manual

Section 3 - Configuration
EAGLE PRO AI
With the EAGLE PRO AI on your smart devices, you can get the R15 up and running quickly. Just plug in the router, open the app and build your home network by following the easy instructions on the screen. The new EAGLE PRO AI is especially designed to ease your management work with the following features:
AI Wi-Fi Optimizer: Enable this feature to always connect to the cleanest Wi-Fi Channel using the breakthrough beamforming technology and receive information about automatic optimization for continuous improvement in the Wi-Fi environment. AI Traffic Optimizer: The QoS engine controls the traffic flow intelligently by automatically assigning heavy traffic with a low priority to improve the overall user experience. It also generates information about bandwidth usage of individual devices and aggregate utilization data. AI Assistant: The message center reports Internet traffic volume and provides usage notifications when clients are transmitting a large amount of data or overly active at night in the weekly bandwidth report. It also enables you to prioritize connected devices to reduce traffic congestion along with the report. Moreover, every improvement made by the Wi-Fi Optimizer will also be recorded to inform administrators about conditions of the wireless environment. AI Parental Control: The Parental Control provides the highest flexibility of Internet accessibility control and website filtering. It allows administrators to control the availability of Internet access and speed on individual devices during the designated time periods.
AI Wi-Fi Optimizer:
To enable this function, open the app. From the Home screen, tap Wi-Fi and tap . Then tap the slider for AI Wi-Fi Optimizer. Turn on Wi-Fi Optimizer to have your wireless connection adopting an interference-free channel automatically and receive weekly Wi-Fi environment report every Monday at 8 AM local time.

D-Link R15 User Manual

Section 3 - Configuration
AI Traffic Optimizer:
To enable this function, open the app. From the Home screen, tap the main router, scroll down the Device Info screen to Settings, and tap QoS. Then tap the slider for AI Traffic Optimizer. Before you start the AI Traffic Optimizer, run Speed Test from the Home screen (go to Home> Internet Speed) to set the download and upload speeds to assist the QoS engine in distributing the bandwidth to prioritized clients.
To prioritize clients, tap Client Priority from the Home screen. Tap a client device and assign a priority level with effective duration to this device. High priority devices running online games, video conferences, or other real-time programs will have the best access. The Red bar on the left indicates heavy users.

AI Parental Control:

To enable this function, open the app. From the Home screen, tap Parental Control.

Then use the following procedure to add a new control profile:
1. Tap Start. 2. Name this profile. Then tap Next to continue. 3. Select client devices to which the profile will be applied. 4. Tap Done to proceed. 5. The profile summary will be displayed. On this page you can tap Pause to pause Internet
immediately to the devices specified in the profile.
You can set schedules to restrict Internet access.
Use Block Bedtime Internet Access to block Internet access during the specified days with time periods. Up to two schedules can be defined. Use Allow Scheduled Internet Access to allow Internet access only during the specified days and times. Users cannot access the Internet except during the hours that you specify. Note that bedtime restriction takes precedence over the allowed schedules here.

D-Link R15 User Manual

Section 3 - Configuration
You can also block specific websites on this page to prevent the specified devices from accessing certain websites. To do this, tap Website Filter, tap Add Website, then enter the website name and the domain keyword, for example, enter violent.com to block all access to this site and violent to block domain names that contain this keyword. Then tap Add at the top right.

AI Assistant:
Tap AI Assistant to display the weekly reports on bandwidth consumption with
information about heavy users. Weekly reports also give information on the number of times the system performs traffic management automatically when congestion occurs and provides qualitative rating on your Wi-Fi environment. Furthermore, the Nighttime Internet Activity informs you about the overly active Internet access during nighttime.
This app enables you to proactively improve sleep quality by restricting Internet access during nighttime. Tap Health Mode to set the bedtime during which Internet access will be blocked on all devices within the network.
Note: The Bedtime scheduling also restricts local access by disabling Wi-Fi connectivity. However, remote management through the Internet is allowed.

D-Link R15 User Manual

Section 3 - Configuration
Other Features
Advanced Mode
The advanced mode provides links to the web configuration interface of the device. Note that this feature is only available with local access (i.e. connected within the same Wi-Fi network). To access, go to Home > Advanced Mode.
Device Information and Settings
From Home, tap the device (main router) of the mesh network topology to view its information and settings: name, IP and MAC address, hardware and firmware version, time zone, and model number. You can also configure the Internet connection method and change the device password on this page. It also provides basic device maintenance functions: reboot, LED indicator on/off, firmware update, and device identification with flashing LED.
Client Information and Statistics
From Home, tap the device (Clients) of the mesh network topology to view the clients currently online and blocked. Tap a device to obtain its information: name, IP and MAC address, and parental control profile. It also displays real-time traffic statistics as well as weekly traffic for the past days in a week for both download and upload data transmissions. The Priority function allows you to assign a High/Low priority for this device with effective duration: Always, 1 Day, 4 Hours, 2 Hours, or 1 Hour.
Extender Information
From Home, tap the device (Extenders) of the mesh network topology to view the extenders currently connected with the following information: name, IP and MAC address, and hardware and firmware version. Tap Clients to view its currently connected clients. You can also identify the device by flashing an LED indicator and restart the device on this screen.

D-Link R15 User Manual

Section 4 - Third Party Services
Voice Control
With the R15, you can command your router's functionality with your voice through Amazon Alexa and the Google Assistant, enabling you to control your network with voice commands. Features include enabling and disabling your Wi-Fi guest zone without logging in to the web interface, rebooting the router, and checking your router for firmware upgrades. In order to use third-party services to control and manage your device, please register your device with D-Link Cloud Service first.

D-Link R15 User Manual

Section 4 - Third Party Services
Link D-Link Cloud Service to Other Services
Google Home Setup
In order to use third-party apps to control and manage your device, you will first need to link your D-Link account with apps such as Google Assistant or Amazon Alexa. Step 1 Launch EAGLE PRO AI and go to the Home screen.
Step 2 Tap Voice Control from the Home screen.

D-Link R15 User Manual

Section 4 - Third Party Services
Step 3 Choose the cloud service (e.g. Google Assistant).

Step 4 Link with the Google Assistant.

D-Link R15 User Manual

Section 4 - Third Party Services
Step 5 The Google Home app will be launched.

Step 6 Link your registered account with Google. Depending on your system, note that if the account link page does not display, please tap "+" on the top left from the above step to add the device manually: Tap + Set up device, choose Works with Google, and search for EAGLE PRO AI. Then sign in using your registered D-Link account.

D-Link R15 User Manual

100

Section 4 - Third Party Services
Step 7 Choose your device.

Step 8 Choose a home.

D-Link R15 User Manual

101

Section 4 - Third Party Services
Step 9 Choose a location for your device.

Step 10 Device is now successfully set up with the Google Home.

D-Link R15 User Manual

102

Section 4 - Third Party Services
Amazon Alexa Setup
You will need the Amazon Alexa app, an Amazon account, and a D-Link account to use this feature.
Note: The screenshots may be different depending on your mobile device's OS version. However, the process is the same.

Step 1 Launch the Amazon Alexa app.
Step 2 Tap Browse Skills.

Amazon Alexa

D-Link R15 User Manual

103

Section 4 - Third Party Services
Step 3 Search EAGLE PRO AI for Skills & Games.

Step 4 The EAGLE PRO AI page.

D-Link R15 User Manual

104

Section 4 - Third Party Services
Step 5 Tap LAUNCH to link the skill.

Step 6 Congratulations! EAGLE PRO AI has been successfully linked as a skill for your Amazon device. Refer to Amazon Alexa Voice Commands on the next page for tasks that you can ask your Amazon Alexa to perform.

D-Link R15 User Manual

105

Section 4 - Third Party Services

Amazon Alexa Voice Commands
With EAGLE PRO AI enabled as a skill for Alexa, you can ask Alexa to do any of the following tasks. Before commanding Alexa, say "Open EAGLE PRO AI" and respond to Alexa's offering by saying "Help."

Task Enable the guest Wi-Fi Disable the guest Wi-Fi Find out your Wi-Fi SSID Find out the guest Wi-Fi name and password Reboot the router Upgrade the router Obtain weekly report messages Note: Network can be substituted for Wi-Fi.

Command "Enable my guest Wi-Fi." "Disable my guest Wi-Fi." "What is my Wi-Fi SSID? "What are my guest Wi-Fi credentials?" "Reboot my router." "Upgrade my router." "Read messages."

If using an Alexa speaker, start your command with one of the following:
1. "Alex, ask EAGLE PRO AI to." For example, command Alexa by saying, " Alexa, ask EAGLE PRO AI to enable my guest Wi-Fi." 2. "Alex, talk to EAGLE PRO AI" and wait for Alexa to respond. Then say your command.

D-Link R15 User Manual

106

Section 4 - Third Party Services
The Google Assistant Setup
You will need the Google Assistant app, a Google account, and a D-Link Cloud Service account to use this feature. Note: The screenshots may be different depending on your mobile device's OS version. However, the process is the same. Step 1 We will set up the pin code first for controls such as reboot and enable or disable guest Wi-Fi. Tap Voice Control from the Home screen of the EAGLE PRO AI app.
Step 2 Tap Edit to customize the pin code or use the randomly generated number.

D-Link R15 User Manual

107

Section 4 - Third Party Services
Step 3 Launch the Google Assistant app.

Assistant

Step 4 Say or Type in your command and provide the pin code when being asked. Refer to Google Assistant Voice Commands on the next page for tasks that you can ask your Google Assistant to perform.

D-Link R15 User Manual

108

Section 4 - Third Party Services

Google Assistant Voice Commands
With EAGLE PRO AI linked with the Google Assistant, you can ask your Google Assistant to do any of these tasks:

Task Check guest Wi-Fi status Check Wi-Fi status Check guest Wi-Fi SSID Check Wi-Fi SSID Enable the guest Wi-Fi Disable the guest Wi-Fi Find out the guest Wi-Fi password Reboot the router Update the router Notes: 1. Only supported on Nest Hub with screen display. 2. Network can be substituted for Wi-Fi.

Command "Is my guest Wi-Fi enabled?" "Is my Wi-Fi enabled?" "What is my guest Wi-Fi SSID?" "What is my Wi-Fi SSID?" "Enable my guest Wi-Fi." "Disable my guest Wi-Fi." "What is my guest Wi-Fi password?"1 "Reboot my router." "Software update my router."

If using a Google Home speaker, start your command by saying "Hey Google."

D-Link R15 User Manual

109

Section 5 - Quick VPN
Quick VPN
This router is equipped with D-Link's Quick VPN technology. Virtual Private Networking (VPN) creates a connection between devices across the Internet. Using Quick VPN allows you to connect your computer or mobile device to places with free, untrusted Wi-Fi hotspots in places like coffee shops and hotels by encrypting and relaying it through your home Internet connection. This extra 'hop' reduces the chances of hackers stealing your information, such as logins, passwords, and credit card numbers. When traveling, Quick VPN lets you watch sports and use video streaming services without experiencing blackouts or filtering. You can surf the whole Internet just as you would at home.
Without Quick VPN

Your Laptop

Potential Hacker Public Unsecured

Stealing Data

Wi-Fi Hotspot

With Quick VPN

Internet

Your Laptop

Public Unsecured Wi-Fi
Hotspot

Internet

Unencrypted Data

Your Network with Quick VPN Server
Encrypted Data

D-Link R15 User Manual

110

Section 5 - Quick VPN

Important Information

The following instructions explain and help you to configure your D-Link Quick VPN enabled router and devices to create a Virtual Private Network (VPN). This feature is provided for advanced users who wish to connect remotely and use their router's Internet connection to add a layer of security while using untrusted networks. Configure the Quick VPN Server on your router first and then set up client devices to connect through your router's WAN connection.
� Quick VPN only provides an added layer of security against specific types of snooping attacks and does not guarantee complete data integrity or protection. Only traffic in the tunnel between your router and device will be encrypted, WAN traffic will leave your D-Link Quick VPN enabled router unencrypted.
� Keep your Quick VPN Username, Password, and Passkey safe. Keep your Quick VPN Username, Password, and Passkey safe. It is recommended that you change these credentials periodically.
� A device connected via Quick VPN tunnel may experience lower data throughput and higher latency due to a number of factors including: Internet conditions, local and remote network Wi-Fi and WAN bandwidth limitations, and increased latency. This may negatively impact real time voice and video communication.
� Quick VPN supports up to five concurrent VPN client sessions using the same login and password are supported. Quick VPN uses L2TP/IPsec with MSCHAPv2, PAP, or CHAP authentication.
� You device may warn you that your information may be intercepted, since you control the Quick VPN server, you may ignore this.
� UDP Ports 500, 4500, 1701 and IP Port 50 must be open in order for Quick VPN to work.
� L2TP/IPsec VPN usage may be restricted in some countries and on some networks. If you have trouble using Quick VPN on some networks, but not others and are not violating network access rules, try contacting your ISP or network administrator.
� Devices connected via Quick VPN are assigned addresses on a separate subnet (ex. 192.168.1.x). Some network resources may be unavailable when connecting via Quick VPN.
� If your Internet connection uses DHCP, it is strongly recommended that you first set up Dynamic DNS (DDNS), such as D-Link DDNS, to eliminate the need to reconfigure client devices in the event your ISP assigns you a new WAN IP address.

D-Link R15 User Manual

111

Section 5 - Quick VPN

iOS Devices
VPN Setup Instructions

This section provides Quick VPN setup instructions for iOS devices. Refer to Quick VPN on page 83 for your router setup instructions.

Go into Settings on your compatible iOS device. Scroll down and tap General. Scroll down and tap VPN.

Tap Add VPN Configuration...

D-Link R15 User Manual

112

Section 5 - Quick VPN
You should see a pop-up window asking you to fill out the details of your VPN connection. Type: Choose IPSec. Tap Back to return to the Add Configuration page. Description: For reference purposes only, used to differentiate between multiple VPN connections. Server: Enter the IP/DDNS address of your Quick VPN server. Account: Enter the Username used to authenticate login to VPN server Password: Enter Password used to authenticate login to VPN server Secret: Enter your Pre-Shared Key (PSK).
Tap Done to close the configuration window. Your iOS device is now configured to connect to your Quick VPN server.

D-Link R15 User Manual

113

Section 5 - Quick VPN

Connect or Disconnect

To connect or disconnect from to your Quick VPN server, go to Settings > VPN and tap the button next to VPN Status.

The VPN icon will appear in the notification area at the top of your screen indicating that your device is currently connected to the Quick VPN server.

D-Link R15 User Manual

114

Section 5 - Quick VPN

Mac OS X
VPN Setup Instructions

This section provides Quick VPN setup instructions for OS X using the Export Profile function. Refer to Quick VPN on page 83 for your router setup instructions.

Open the exported profile. The Install Profile dialogue will appear; click Continue and Install.
Enter your user account password when prompted. Close the Profiles dialogue.
Go to > System Preferences... > Network and select the Quick VPN
connection and click Authentication Settings.

D-Link R15 User Manual

115

Section 5 - Quick VPN
Enter your Passkey in the Shared Secret text box and click OK, Apply, then OK.
Your Mac is now configured to connect to your Quick VPN server.

D-Link R15 User Manual

116

Section 5 - Quick VPN
Connect or Disconnect
To connect to or disconnect from your Quick VPN server, go to > System
Preferences... > Network. Select the Quick VPN connection and click on the Connect or Disconnect button.

D-Link R15 User Manual

117

Section 5 - Quick VPN

Windows 7
VPN Setup Instructions

This section provides Quick VPN setup instructions for Windows 7. Refer to Quick VPN on page 83 for your router setup instructions.

Click the Start button and type vpn into the Search programs and files box.
Select Set up a virtual private network (VPN) connection.

Enter the IP/DDNS address of your Quick VPN server in the Internet address box, create a name for your connection in the Destination Name, check Don't Connect now; just set it up so I can connect later, and click Next.

D-Link R15 User Manual

118

Section 5 - Quick VPN
Enter your Username. If you would like windows to save your password, enter your Password and check Remember this password. Click Create to continue.
Do not click Connect Now. Click Close. Click the Start button and type view network connections into the Search programs and files text box. Select View network connections.

D-Link R15 User Manual

119

Section 5 - Quick VPN
Click Advanced settings. Enter your Passkey in the Key text box under Use preshared key for authentication. Click OK to close Advanced Properties and click OK to close Quick VPN Connection Properties.
Your Windows 7 system is now configured to connect to your Quick VPN server.

D-Link R15 User Manual

120

Section 5 - Quick VPN

Connect or Disconnect

To connect to or disconnect from your Quick VPN server, click on the Network Settings icon in the notification area of the Windows taskbar and from the Dial Up and VPN section click on your Quick VPN connection and click on the Connect or Disconnect button.

D-Link R15 User Manual

121

Section 5 - Quick VPN

Windows 8.1/8
VPN Setup Instructions

This section provides Quick VPN setup instructions for Windows 8.1/8. Refer to Quick VPN on page 83 for your router setup instructions.

This section provides Quick VPN setup instructions for Windows 8.1/8. Click the Start button and type vpn. Select Manage virtual private networks.

From the Network Settings page, click Add a VPN Connection.

D-Link R15 User Manual

122

Section 5 - Quick VPN

1 Select Microsoft from VPN Provider.

2 Create a name for your VPN connection.

3 Enter your IP/DDNS address of your Quick VPN server.

4 Select User name and password from Type of sign-in info.

If you would like windows to remember your sign-in information, enter your User name, Password, and select Remember my sign-in info

6 Choose Save.

D-Link R15 User Manual

123

Section 5 - Quick VPN
Right-click on the Quick VPN Connection you just created and left-click on Properties.
Select the Security tab. For the Type of VPN, select Layer 2 Tunneling with IPsec (L2TP/IPSec).

D-Link R15 User Manual

124

Section 5 - Quick VPN
Click the Start button and type view network connections. Select View network connections.
Right-click your Quick VPN Connection and left-click Properties. Select the Security tab. For the Type of VPN, select Layer 2 Tunneling with IPsec (L2TP/IPSec).

D-Link R15 User Manual

125

Section 5 - Quick VPN
Click Advanced settings. Enter your Passkey in the Key text box under Use preshared key for authentication. Click OK to close Advanced Properties and click OK to close Quick VPN Properties.
Your Windows 8.1/8 system is now configured to connect to your Quick VPN server.

D-Link R15 User Manual

126

Section 5 - Quick VPN

Connect or Disconnect

To connect to or disconnect from your Quick VPN server, click on the Network Settings icon in the notification area of the Windows taskbar. Click on your Quick VPN connection and click on the Connect or Disconnect button.

D-Link R15 User Manual

127

Section 5 - Quick VPN

Windows 10
VPN Setup Instructions

This section provides Quick VPN setup instructions for Windows 10. Refer to Quick VPN on page 83 for your router setup instructions.

This section provides Quick VPN setup instructions for Windows 10.
Click Start > Settings > Network & Internet > VPN > Add a VPN Connection.

D-Link R15 User Manual

128

Section 5 - Quick VPN
On the Add a VPN connection screen, do the following:
1 Select Windows (built-in) from the VPN Provider menu. 2 Create a name for your VPN connection. 3 Enter your IP/DDNS address of your Quick VPN server. 4 Select L2TP/IPSec with pre-shared key for VPN type. 5 Enter the Passkey. 6 Select User name and password from Type of sign-in info.
If you would like windows to remember your sign-in information, enter your User name, Password, and select Remember my sign-in info 7 Choose Save. Your Windows 10 system is now configured to connect to your Quick VPN server.

D-Link R15 User Manual

129

Section 5 - Quick VPN

Connect or Disconnect

To connect to or disconnect from your Quick VPN server, click on the
Network Settings icon (either or ) in the notification area of the Windows taskbar and click on your Quick VPN connection. The section of VPN in Network & Internet Settings page will open, select your Quick VPN, then select Connect. Or if the Connect button shows under the VPN connection, select Connect. If connected, the VPN connection name will display Connected underneath it. You can click Disconnect to stop the connection.

D-Link R15 User Manual

130

Section 5 - Quick VPN
Android
VPN Setup Instructions
This section provides Quick VPN setup instructions for Android devices. Your device's screens may vary. Refer to Quick VPN on page 83 for your router setup instructions.
Go to Settings > Network & Internet > VPN

D-Link R15 User Manual

131

Section 5 - Quick VPN
Tap + to create or VPN Settings to edit a VPN connection profile 1 Enter a name for your VPN connection. 2 Select L2TP/IPSec PSK for Type. 3 Enter the IP/DDNS address of your Quick VPN server. 4 Enter your Passkey in IPSec pre-shared key field. 5 Choose Save. Your Android device is now configured to connect to your Quick VPN server.

D-Link R15 User Manual

132

Section 5 - Quick VPN

Connect or Disconnect

Tap the Quick VPN connection you created.

To connect, enter your Username and Password, then tap CONNECT.

To disconnect, tap DISCONNECT.

D-Link R15 User Manual

133

Section 6 - Connect a Wireless Client to your Router
Connect a Wireless Client to your Router
WPS Button
The easiest way to connect your wireless devices to the router is with WPS (Wi-Fi Protected Setup). Most wireless devices such as wireless adapters, media players, Blu-ray DVD players, wireless printers and cameras will have a WPS button (or a software utility with WPS) that you can press to connect to the router. Please refer to your user manual for the wireless device you want to connect to make sure you understand how to enable WPS. Once you know, follow the steps below:
Step 1 - Press the WPS button on the router for about 1 second. The wireless LEDs will start to blink.
WPS Button

Step 2 - Within 2 minutes, press the WPS button on your wireless device (or launch the software utility and start the WPS process).
Step 3 - Allow up to 1 minute for your connection to be configured. Once the LEDs stop blinking, you will be connected using WPA2 encryption.

D-Link R15 User Manual

134

Section 6 - Connect a Wireless Client to your Router

Windows� 10
WPA/WPA2/WPA3
Note: To enjoy the benefits offered by Wi-Fi 6 and WPA3, please make sure that your operating system and wireless network adapter support Wi-Fi 6.
To join an existing network, locate the wireless network icon in the taskbar, next to the time display and click on it.

Clicking on this icon will display a list of wireless networks which are within range of your computer. Select the desired network by clicking on the SSID.

Wireless Icon

To connect to the SSID, click Connect.
To automatically connect with the router when your device next detects the SSID, check the Connect Automatically check box.
You will then be prompted to enter the Wi-Fi password (network security key) for the wireless network. Enter the password into the box and click Next to connect to the network. Your computer will now automatically connect to this wireless network when it is detected.

D-Link R15 User Manual

135

Section 6 - Connect a Wireless Client to your Router
Windows� 8
WPA/WPA2
To join an existing network, locate the wireless network icon in the taskbar, next to the time display.
Clicking on this icon will display a list of wireless networks which are within connecting proximity of your computer. Select the extender's network by clicking on the network name.
You will then be prompted to enter the network security key (Wi-Fi password) for the wireless network. Enter the password into the box and click Next. If you wish to use Wi-Fi Protected Setup (WPS) to connect to the router, you can also press the WPS button on your router at this point to enable the WPS function.

Wireless Icon dlink dlink

D-Link R15 User Manual

136

Section 6 - Connect a Wireless Client to your Router
When you have established a successful connection with a wireless network, the word Connected will appear next to the name of the network to which you are connected.
dlink

D-Link R15 User Manual

137

Section 6 - Connect a Wireless Client to your Router

Windows� 7
WPA/WPA2

It is recommended that you enable wireless encryption (WPA/WPA2) on your wireless router or access point before configuring your wireless adapter. If you are joining an existing network, you will need to know the security key or passphrase (Wi-Fi password) being used.

Click on the wireless icon in your system tray (lower-right corner).

The utility will display any available wireless networks in your area.
Highlight the wireless connection with Wi-Fi name (SSID) you would like to connect to and click the Connect button.
If you get a good signal but cannot access the Internet, check your TCP/IP settings for your wireless adapter. Refer to Networking Basics on page 146 for more information.

Wireless Icon

D-Link R15 User Manual

138

Section 6 - Connect a Wireless Client to your Router
The following window appears while your computer tries to connect to the router.
Enter the same security key or passphrase (Wi-Fi password) that is on your router and click OK. You can also connect by pushing the WPS button on the router. It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the security settings are correct. The key or passphrase must be exactly the same as the one on the wireless router.

D-Link R15 User Manual

139

Section 7 - Troubleshooting

Troubleshooting

This chapter provides solutions to problems that can occur during the installation and operation of the router. Read the following descriptions if you are having problems.

1. Why can't I access the web-based configuration utility?
When entering the IP address of the D-Link router (192.168.0.1 for example), you are not connecting to a website, nor do you have to be connected to the Internet. The device has the utility built-in to a ROM chip in the device itself. Your computer must be on the same IP subnet to connect to the web-based utility.
� Make sure you have an updated Java-enabled web browser. We recommend the following:
- Microsoft Internet Explorer� 11 or higher - Mozilla Firefox 28 or higher - GoogleTM Chrome 28 or higher - Apple Safari 6 or higher
� Verify physical connectivity by checking for solid link lights on the device. If you do not get a solid link light, try using a different cable, or connect to a different port on the device if possible. If the computer is turned off, the link light may not be on.
� Disable any Internet security software running on the computer. Software firewalls such as ZoneAlarm, BlackICE, Sygate and Norton Personal Firewall may block access to the configuration pages. Check the help files included with your firewall software for more information on disabling or configuring it.

D-Link R15 User Manual

140

Section 7 - Troubleshooting
� Access the web configuration. Open your web browser and enter the IP address of your D-Link router in the address bar. This should open the login page for your web configuration.
� If you still cannot access the configuration, unplug the power to the router for 10 seconds and plug back in. Wait about 30 seconds and try accessing the configuration. If you have multiple computers, try connecting using a different computer.
2. What can I do if I forgot my password?
If you forgot your password, you must reset your router. This process will change all your settings back to the factory defaults.
To reset the router, locate the reset button (hole) on the rear panel of the unit. With the router powered on, use a paperclip to hold the recessed button down until the power LED turns orange. Release the button and the router will go through its reboot process. Wait about 30 seconds to access the router. The address of the web configuration is printed on the device label on the bottom of the device. You may also enter the default IP address: 192.168.0.1. When logging in, enter the default device password printed on the device label too.

D-Link R15 User Manual

141

Appendix A - Wireless Basics
Wireless Basics
D-Link wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business, or public access wireless networks. Strictly adhering to the IEEE standard, the D-Link wireless family of products allows you to access the data you want, when, and where you want it. You will be able to enjoy the freedom that wireless networking delivers.
A wireless local area network (WLAN) is a cellular computer network that transmits and receives data with radio signals instead of wires. Wireless LANs are used increasingly in both home and office environments, and public areas such as airports, coffee shops and universities. Innovative ways to utilize WLAN technology are helping people work and communicate more efficiently. Increased mobility and the absence of cabling and other fixed infrastructure have proven to be beneficial for many users.
Wireless users can use the same applications they use on a wired network. Wireless adapter cards used on laptop and desktop systems support the same protocols as Ethernet adapter cards.
Under many circumstances, it may be desirable for mobile network devices to link to a conventional Ethernet LAN in order to use servers, printers or an Internet connection supplied through the wired LAN. A wireless router is a device used to provide this link.
What is Wireless?
Wireless or Wi-Fi technology is another way of connecting your computer to the network without using wires. Wi-Fi uses radio frequency to connect wirelessly so you have the freedom to connect computers anywhere in your home or office network.

D-Link R15 User Manual

142

Appendix A - Wireless Basics

How does wireless work?
Wireless works similarly to how cordless phones work, through radio signals that transmit data from one point A to point B. But wireless technology has restrictions as to how you can access the network. You must be within the wireless network range area to be able to connect your computer. There are two different types of wireless networks: Wireless Local Area Network (WLAN), and Wireless Personal Area Network (WPAN).
Wireless Local Area Network (WLAN)
In a wireless local area network, a device called an Access Point (AP) connects computers to the network. The access point has a small antenna attached to it, which allows it to transmit data back and forth over radio signals. With an indoor access point the signal can travel up to 300 feet. With an outdoor access point the signal can reach out up to 30 miles to serve places like manufacturing plants, industrial locations, university and high school campuses, airports, golf courses, and many other outdoor venues.
Wireless Personal Area Network (WPAN)
Bluetooth is the industry standard wireless technology used for WPAN. Bluetooth devices in WPAN operate in a range up to 30 feet away. Compared to WLAN the speed and wireless operation range are both less than WLAN, but in return it doesn't use nearly as much power. This makes it ideal for personal devices, such as mobile phones, PDAs, headphones, laptops, speakers, and other devices that operate on batteries.
Who uses wireless?
Wireless technology has become so popular in recent years that almost everyone is using it, whether it's for home, office, business, D-Link has a wireless solution for it.

D-Link R15 User Manual

143

Appendix A - Wireless Basics
Home Uses/Benefits � Gives everyone at home broadband access � Surf the web, check email, instant message, etc. � Gets rid of the cables around the house � Simple and easy to use
Small Office and Home Office Uses/Benefits � Stay on top of everything at home as you would at office � Remotely access your office network from home � Share Internet connection and printer with multiple computers � No need to dedicate office space
Where is wireless used?
Wireless technology is expanding everywhere, not just at home or office. People like the freedom of mobility and it's becoming so popular that more and more public facilities now provide wireless access to attract people. The wireless connection in public places is usually called "hotspots".
Using a D-Link USB adapter with your laptop, you can access the hotspot to connect to the Internet from remote locations like: airports, hotels, coffee shops, libraries, restaurants, and convention centers.
Wireless network is easy to setup, but if you're installing it for the first time it could be quite a task not knowing where to start. That's why we've put together a few setup steps and tips to help you through the process of setting up a wireless network.

D-Link R15 User Manual

144

Appendix A - Wireless Basics

Tips
Here are a few things to keep in mind, when you install a wireless network.
Centralize your router or access point
Make sure you place the router/access point in a centralized location within your network for the best performance. Try to place the router/access point as high as possible in the room, so the signal gets dispersed throughout your home. If you have a two-story home, you may need a repeater or an extender to boost the signal to extend the range.
Extend and Strengthen Your Wireless Network with Wi-Fi Mesh
D-Link's Wi-Fi Mesh is a scalable solution that allows you to easily increase the coverage and eliminate weak spots of your wireless AX network. Setup is effortless; configuration of multiple routers and extenders can be done in minutes as settings can be passed on to other devices once the first is configured. And routing is more efficient and reliable since mesh network intelligently finds the shortest path and reroutes data traffic through working mesh points in the event of link or device failures.
Eliminate Interference
Place home appliances such as cordless telephones, microwaves, and televisions as far away as possible from the router/ access point. This would significantly reduce any interference that the appliances might cause since they operate on same frequency.
Wireless Encryption
Don't let your next-door neighbors or intruders connect to your wireless network. Encrypt your wireless network with the latest WPA3 security protocol. Refer to the product manual for detail information on how to set it up.

D-Link R15 User Manual

145

Appendix C - Networking Basics
Networking Basics
Check your IP address
After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below.
Click on Start and type cmd in the Search box.
At the prompt, type ipconfig and press Enter.
This will display the IP address, subnet mask, and the default gateway of your adapter.
If the IP address is 0.0.0.0 or empty, check your adapter installation, security settings, and the settings on your router. Some firewall software programs may block a DHCP request on newly installed adapters.

D-Link R15 User Manual

146

Appendix C - Networking Basics
Statically Assign an IP address

1. If you are not using a DHCP capable gateway/router, or you need to assign a static IP address, please follow the steps below:

Windows� 10 Windows� 7 /8 Windows� XP

Start> Settings > Network & Internet. Start > Control Panel > Network and Internet > Network and Sharing Center Start > Control Panel > Network Connections

2. Select Wi-Fi > Manage known networks. For Windows 7/8/XP, click Change adapter settings. Choose the network you want to modify, right-click on it, then select Properties.

3. Under IP assignment, select Edit. For Windows 7/8/XP, select Internet Protocol Version 4 (TCP/IPv4) Properties or Internet Protocol Version 6 Properties (TCP/IPv6). Then select Use the Following IP Address.

4. Under Edit IP settings, select Manual. If IPv4 is selected, type the IP address settings in IP address, Subnet prefix length (subnet mask), and Gateway fields. If IPv6 is selected, type the IP address settings in IP address, Subnet prefix length, and Gateway fields.

Example: Enter x.x.x.x for IPv4 addressing scheme (where x is between 0 and 255) and xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx for IPv6 addressing scheme (where x is a hexadecimal digit).

Set Preferred DNS the same as the LAN IP address of your router. The Alternate DNS is only optional or you may enter a DNS server from your ISP.

5. When you're done, click Save.

D-Link R15 User Manual

147

Appendix D - Wireless Security

Wireless Security
This section will show you the different levels of encryption you can use to protect your data from intruders. The router offers the following types of security protocols:

� WPA3 (Wi-Fi Protected Access 3) � WPA2-PSK (Pre-Shared Key) � WPA-PSK (Pre-Shared Key)

� WPA2 (Wi-Fi Protected Access 2) � WPA (Wi-Fi Protected Access)
What is WPA?

WPA (Wi-Fi Protected Access), is a Wi-Fi standard that was designed to improve the security features of WEP (Wired Equivalent Privacy).

The 2 major improvements over WEP:

� Improved data encryption through the Temporal Key Integrity Protocol (TKIP). TKIP scrambles the keys using a hashing algorithm and by adding an integrity-checking feature, ensures that the keys haven't been tampered with. WPA2 is based on 802.11i and uses Advanced Encryption Standard (AES) instead of TKIP.
� User authentication, which is generally missing in WEP, through the extensible authentication protocol (EAP). WEP regulates access to a wireless network based on a computer's hardware-specific MAC address, which is relatively simple to be sniffed out and stolen. EAP is built on a more secure public-key encryption system to ensure that only authorized network users can access the network.

WPA-PSK/WPA2-PSK/WPA3-SAE uses a passphrase or key to authenticate your wireless connection. The key is an alphanumeric password between 8 and 63 characters long. The password can include symbols (!?*&_) and spaces. This key must be the exact same key entered on your wireless router or access point. Further, The Simultaneous Authentication of Equals (SAE) of WPA3 enhances the protection against dictionary attacks.

WPA/WPA2 incorporates user authentication through the Extensible Authentication Protocol (EAP). EAP is built on a more secure public key encryption system to ensure that only authorized network users can access the network.

WPA3 has the strongest encryption among these with the increased cryptographic capability and the requirements of the Protected Management Frames (PMFs) to help prevent snooping attacks.

D-Link R15 User Manual

148

Appendix E - Technical Specifications

Technical Specifications

Device Interfaces � Wireless Interface (2.4 GHz): IEEE 802.11n/g/b � Wireless Interface (5 GHz): IEEE 802.11ax/ac/n/a � One 10/100/1000 Mbps WAN port � Three 10/100/1000 Mbps LAN port
Standards
� IEEE 802.11ax1,2,3 � IEEE 802.11ac1,2,3 � IEEE 802.3u � IEEE 802.3ab � IEEE 802.1p/q (WAN) � IEEE802.3x � IEEE 802.11h � IEEE 802.11k/v � IEEE 802.11n/g/b/a
Antenna Types � Four external antennas
Security � WPA3/WPA2/WPA-Personal � Wi-Fi Protected Setup (WPS)
WAN Connection Type � Static IP � Dynamic IP � PPPoE � PPTP � L2TP � DS-Lite

Power � Input: 100 to 240 V AC, 50 / 60 Hz � Output: 12 V, 1 A
Temperature � Operating: 0 to 40 �C (32 to 104 �F) � Storage: -20 to 65 �C (-4 to 149 �F)
Humidity � Operating: 10% to 90% maximum, non-condensing � Storage: 5% to 95% maximum, non-condensing
Certifications � IC � FCC � CE � RCM � VCCI � KCC � Anatel � BSMI
Dimensions � L x W x H: 195 x 139 x 55 mm (7.68 x 5.47 x 2.17 in)
Weight � 300 g

The marking information is located at the bottom of the apparatus. 1 Maximum wireless signal rate derived from IEEE Standard 802.11a, 802.11g, 802.11n, 802.11ac and 802.11ax specifications. Actual data throughput will vary. Network conditions and environmental factors - including volume of network traffic, building materials and construction, and network overhead - lower actual data throughput rate. Environmental factors will adversely affect wireless signal range. 2 Frequency Range varies depending on country's regulation. 3 The router does not include 5.25-5.35 GHz & 5.47-5.725 GHz in some regions.

D-Link R15 User Manual

149

Appendix H - Wall Mounting Information
Wall Mounting
To mount the unit directly onto a wall, use 2 screws (not included) with the dimensions shown below. Install the screws 85 mm (3.35 in) apart and slide the mounting holes into the base of the router over them.
The screw head should project out from the wall at 7 mm (0.28 in) as shown below.

D-Link R15 User Manual

150

Appendix G - Regulatory Information
Regulatory Statements
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help.
Non-modifications Statement:
Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Caution:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible.
Note
The country code selection is for non-USA models only and is not available to all USA models. Per FCC regulations, all WiFi product marketed in the USA must be fixed to USA operational channels only.

D-Link R15 User Manual

151

Appendix G - Regulatory Information
IMPORTANT NOTICE: FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body.
Innovation, Science and Economic Development Canada (ISED) Statement:
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil num�rique de la classe B est conforme � la norme NMB-003 du Canada.
Innovation, Science and Economic Development Canada (ISED) Statement:
This device complies with ISED licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of the device.
Le pr�sent appareil est conforme aux CNR d'ISED applicables aux appareils radio exempts de licence. L'exploitation est autoris�e aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radio�lectrique subi, m�me si le brouillage est susceptible d'en compromettre le fonctionnement.

D-Link R15 User Manual

152

Appendix G - Regulatory Information
Caution : (i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; (ii) the maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the equipment still complies with the e.i.r.p. limits specified for point-to-point and non-point-to-point operation as appropriate; and (iii) Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices. Avertissement: (i) les dispositifs fonctionnant dans la bande 5150-5250 MHz sont r�serv�s uniquement pour une utilisation � l'int�rieur afin de r�duire les risques de brouillage pr�judiciable aux syst�mes de satellites mobiles utilisant les m�mes canaux; (ii) le gain maximal d'antenne permis (pour les dispositifs utilisant la bande de 5725 � 5 850 MHz) doit �tre conforme � la limite de la p.i.r.e. sp�cifi�e pour l'exploitation point � point et l'exploitation non point � point, selon le cas; (iii) De plus, les utilisateurs devraient aussi �tre avis�s que les utilisateurs de radars de haute puissance sont d�sign�s utilisateurs principaux (c.�-d., qu'ils ont la priorit�) pour les bandes 5650-5850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.
Radiation Exposure Statement
This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body.
D�claration d'exposition aux radiations
Cet �quipement est conforme aux limites d'exposition aux rayonnements ISED �tablies pour un environnement non contr�l�. Cet �quipement doit �tre install� et utilis� avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps.

D-Link R15 User Manual

153

Appendix G - Regulatory Information

5 G 2.4 G

Frequency Band(s) Frequenzband Fr�quence bande(s) Bandas de Frecuencia Frequenza/e Frequentie(s)
5.15 � 5.25 GHz
5.25 � 5.35 GHz
5.47 � 5.725 GHz
2.4 � 2.4835 GHz

Max. Output Power (EIRP) Max. Output Power Consommation d'�nergie max. Potencia m�xima de Salida Potenza max. Output Max. Output Power
200 mW
200 mW
1 W
100 mW

D-Link R15 User Manual

154

Appendix G - Regulatory Information
European Community Declaration of Conformity:

Cesky [Czech] Dansk [Danish] Deutsch [German] Eesti [Estonian] English Espa�ol [Spanish] [Greek] Fran�ais [French] Italiano [Italian]

T�mto D-Link Corporation prohlasuje, ze tento produkt, jeho p�slusenstv� a software jsou v souladu se smrnic� 2014/53/EU. Cel� text ES prohl�sen� o shod vydan�ho EU a o firmwaru produktu lze st�hnout na str�nk�ch k produktu www.dlink.com.
D-Link Corporation erkl�rer herved, at dette produkt, tilbeh�r og software er i overensstemmelse med direktiv 2014/53/EU. Den fulde tekst i EU-overensstemmelseserkl�ringen og produktfirmware kan wnloades fra produktsiden hos www.dlink.com.
Hiermit erkl�rt die D-Link Corporation, dass dieses Produkt, das Zubeh�r und die Software der Richtlinie 2014/53/ EU entsprechen. Der vollst�ndige Text der Konformit�tserkl�rung der Europ�ischen Gemeinschaft sowie die Firmware zum Produkt stehen Ihnen zum Herunterladen von der Produktseite im Internet auf www.dlink.com zur Verf�gung.
K�esolevaga kinnitab D-Link Corporation, et see toode, tarvikud ja tarkvara on koosk�las direktiiviga 2014/53/EL. Euroopa Liidu vastavusdeklaratsiooni t�istekst ja toote p�sivara on allalaadimiseks saadaval tootelehel www.dlink. com.
Hereby, D-Link Corporation, declares that this product, accessories, and software are in compliance with directive 2014/53/EU. The full text of the EU Declaration of Conformity and product firmware are available for download from the product page at www.dlink.com
Por la presente, D-Link Corporation declara que este producto, accesorios y software cumplen con las directivas 2014/53/UE. El texto completo de la declaraci�n de conformidad de la UE y el firmware del producto est�n disponibles y se pueden descargar desde la p�gina del producto en www.dlink.com.
, D-Link Corporation , 2014/53/. www.dlink. com.
Par les pr�sentes, D-Link Corporation d�clare que ce produit, ces accessoires et ce logiciel sont conformes aux directives 2014/53/UE.Le texte complet de la d�claration de conformit� de l'UE et le icroprogramme du produit sont disponibles au t�l�chargement sur la page des produits � www.dlink.com.
Con la presente, D-Link Corporation dichiara che questo prodotto, i relativi accessori e il software sono conformi alla direttiva 2014/53/UE. Il testo completo della dichiarazione di conformit� UE e il firmware del prodotto sono disponibili per il download dalla pagina del prodotto su www.dlink.com.

D-Link R15 User Manual

155

Appendix G - Regulatory Information

Latviski [Latvian] Lietuvi [Lithuanian] Nederlands [Dutch] Malti [Maltese] Magyar [Hungarian] Polski [Polish] Portugu�s [Portuguese] Slovensko[Slovenian] Slovensky [Slovak] Suomi [Finnish] Svenska[Swedish] D-Link R15 User Manual

Ar so uzmums D-Link Corporation apliecina, ka sis produkts, piederumi un programmatra atbilst direktvai 2014/53/ES. ES atbilstbas deklarcijas pilno tekstu un produkta apartprogrammatru var lejupieldt attiecg produkta lap vietn www.dlink.com.
Siuo dokumentu ,,D-Link Corporation" pareiskia, kad sis gaminys, priedai ir programin ranga atitinka direktyv 2014/53/ES. Vis ES atitikties deklaracijos tekst ir gaminio programin aparatin rang galima atsisisti is gaminio puslapio adresu www.dlink.com.
Hierbij verklaart D-Link Corporation dat dit product, accessoires en software voldoen aan de richtlijnen 2014/53/ EU. De volledige tekst van de EU conformiteitsverklaring en productfirmware is beschikbaar voor download van de productpagina op www.dlink.com.
Bil-preenti, D-Link Corporation tiddikjara li dan il-prodott, l-aessorji, u s-software huma konformi mad-Direttiva 2014/53/UE. Tista' tniel it-test si tad-dikjarazzjoni ta' konformit� tal-UE u l-firmware tal-prodott mill-pana talprodott fuq www.dlink.com.
Ezennel a D-Link Corporation kijelenti, hogy a jelen term�k, annak tartoz�kai �s szoftvere megfelelnek a 2014/53/ EU sz. rendeletek rendelkez�seinek. Az EU Megfelels�gi nyilatkozat teljes sz�vege �s a term�k firmware a term�k oldal�r�l t�lthet le a www.dlink.com c�men.
D-Link Corporation niniejszym owiadcza, e ten produkt, akcesoria oraz oprogramowanie s zgodne z dyrektywami 2014/53/EU. Pelen tekst deklaracji zgodnoci UE oraz oprogramowanie sprztowe do produktu mona pobra na stronie produktu w witrynie www.dlink.com.
Desta forma, a D-Link Corporation declara que este produto, os acess�rios e o software est�o em conformidade com a diretiva 2014/53/UE. O texto completo da declara��o de conformidade da UE e do firmware
Podjetje D-Link Corporation s tem izjavlja, da so ta izdelek, dodatna oprema in programnska oprema skladni z direktivami 2014/53/EU. Celotno besedilo izjave o skladnosti EU in vdelana programska oprema sta na voljo za prenos na strani izdelka na www.dlink.com.
Spolocnos D-Link t�mto vyhlasuje, ze tento produkt, pr�slusenstvo a softv�r s� v s�lade so smernicou 214/53/ E�. �pln� znenie vyhl�senia E� o zhode a firmv�ri produktu s� k dispoz�cii na prevzatie zo str�nky produktu www. dlink.com.
D-Link Corporation t�ten vakuuttaa, ett� t�m� tuote, lis�varusteet ja ohjelmisto ovat direktiivin 2014/53/EU vaatimusten mukaisia. T�ydellinen EU-vaatimustenmukaisuusvakuutus samoin kuin tuotteen laiteohjelmisto ovat ladattavissa osoitteesta www.dlink.com.
D-Link Corporation f�rs�krar h�rmed att denna produkt, tillbeh�r och programvara �verensst�mmer med direktiv 2014/53/EU. Hela texten med EU-f�rs�kran om �verensst�mmelse och produkt-firmware kan h�mtas fr�n produktsidan p� www.dlink.com.
156

Appendix G - Regulatory Information

�slenska [Icelandic] Norsk [Norwegian]

H�r me� l�sir D-Link Corporation �v� yfir a� �essi vara, fylgihlutir og hugb�na�ur eru � samr�mi vi� tilskipun 2014/53/EB. S�kja m� ESB-samr�misyfirl�singuna � heild sinni og fastb�na� v�runnar af vefs��u v�runnar � www. dlink.com.
Herved erkl�rer D-Link Corporation at dette produktet, tilbeh�ret og programvaren er i samsvar med direktivet 2014/53/EU. Den fullstendige teksten i EU-erkl�ring om samsvar og produktets fastvare er tilgjengelig for nedlasting fra produktsiden p� www.dlink.com.

Warning Statement:
The equipment supplied by an approved external power adapter which is considered to be Pluggable Equipment Type A. The socket outlets shall be installed near the equipment and be easily accessible.

D-Link R15 User Manual

157

Appendix G - Regulatory Information
NOTICE OF WIRELESS RADIO LAN USAGE IN THE EUROPEAN COMMUNITY (FOR WIRELESS PRODUCT ONLY):
� This device is restricted to indoor use when operated in the European Community using channels in the 5.15-5.35 GHz band to reduce the potential for interference.
� This device is a 2.4 GHz wideband transmission system (transceiver), intended for use in all EU member states and EFTA countries. This equipment may be operated in AL, AD, BE, BG, DK, DE, FI, FR, GR, GW, IS, IT, HR, LI, LU, MT, MK, MD, MC, NL, NO, AT, PL, PT, RO, SM, SE, RS, SK, ES, CI, HU, and CY.
Usage Notes:
� To remain in conformance with European National spectrum usage regulations, frequency and channel limitations will be applied on the products according to the country where the equipment will be deployed.
� This device is restricted from functioning in Ad-hoc mode while operating in 5 GHz. Ad-hoc mode is direct peer-to-peer communication between two client devices without an Access Point.
� Access points will support DFS (Dynamic Frequency Selection) and TPC (Transmit Power Control) functionality as required when operating in 5 GHz band within the EU.
� Please refer to the product manual or datasheet to check whether your product uses 2.4 GHz and/or 5 GHz wireless.
HINWEIS ZUR VERWENDUNG VON DRAHTLOS-NETZWERK (WLAN) IN DER EUROP�ISCHEN GEMEINSCHAFT ( NUR F�R EIN DRAHTLOSES PRODUKT )
� Der Betrieb dieses Ger�ts in der Europ�ischen Gemeinschaft bei Nutzung von Kan�len im 5,15-5,35 GHz Frequenzband ist ausschlie�lich auf Innenr�ume beschr�nkt, um das Interferenzpotential zu reduzieren.
� Bei diesem Ger�t handelt es sich um ein zum Einsatz in allen EU-Mitgliedsstaaten und in EFTA-L�ndern - ausgenommen Frankreich. Der Betrieb dieses Ger�ts ist in den folgenden L�ndern erlaubt: AL, AD, BE, BG, DK, DE, FI, FR, GR, GW, IS, IT, HR, LI, LU, MT, MK, MD, MC, NL, NO, AT, PL, PT, RO, SM, SE, RS, SK, ES, CI, HU, CY
Gebrauchshinweise:
� Um den in Europa geltenden nationalen Vorschriften zum Nutzen des Funkspektrums weiterhin zu entsprechen, werden Frequenz und Kanalbeschr�nkungen, dem jeweiligen Land, in dem das Ger�t zum Einsatz kommt, entsprechend, auf die Produkte angewandt.
� Die Funktionalit�t im Ad-hoc-Modus bei Betrieb auf 5 GHz ist f�r dieses Ger�t eingeschr�nkt. Bei dem Ad-hoc-Modus handelt es sich um eine Peer-to-Peer-Kommunikation zwischen zwei Client-Ger�ten ohneeinen Access Point.
� Access Points unterst�tzen die Funktionen DFS (Dynamic Frequency Selection) und TPC (Transmit Power Control) wie erforderlich bei Betrieb auf 5 GHz innerhalb der EU.
� Bitte schlagen Sie im Handbuch oder Datenblatt nach nach, ob Ihr Ger�t eine 2,4 GHz und / oder 5 GHz Verbindung nutzt.

D-Link R15 User Manual

158

Appendix G - Regulatory Information
AVIS CONCERNANT L'UTILISATION DE LA RADIO SANS FIL LAN DANS LA COMMUNAUT� EUROP�ENNE (UNIQUEMENT POUR LES PRODUITS SANS FIL)
� Cet appareil est limit� � un usage int�rieur lorsqu'il est utilis� dans la Communaut� europ�enne sur les canaux de la bande de 5,15 � 5,35 GHz afin de r�duire les risques d'interf�rences.
� Cet appareil est un syst�me de transmission � large bande (�metteur-r�cepteur) de 2,4 GHz, destin� � �tre utilis� dans tous les �tatsmembres de l'UE et les pays de l'AELE. Cet �quipement peut �tre utilis� dans les pays suivants : AL, AD, BE , BG, DK, DE, FI, FR, GR, GW, IS, IT, HR, LI, LU, MT , MK, MD, MC, NL, NO, AT, PL, PT, RO, SM, SE, RS, SK, ES, CI, HU, CY
Notes d'utilisation:
� Pour rester en conformit� avec la r�glementation nationale europ�enne en mati�re d'utilisation du spectre, des limites de fr�quence et de canal seront appliqu�es aux produits selon le pays o� l'�quipement sera d�ploy�.
� Cet appareil ne peut pas utiliser le mode Ad-hoc lorsqu'il fonctionne dans la bande de 5 GHz. Le mode Adhoc fournit une communication directe pair � pair entre deux p�riph�riques clients sans point d'acc�s.
� Les points d'acc�s prendront en charge les fonctionnalit�s DFS (Dynamic Frequency Selection) et TPC (Transmit Power Control) au besoin lors du fonctionnement dans la bande de 5 GHz au sein de l'UE.
� Merci de vous r�f�rer au guide d'utilisation ou de la fiche technique afin de v�rifier si votre produit utilise 2.4 GHz et/ou 5 GHz sans fil.
AVISO DE USO DE LA LAN DE RADIO INAL�MBRICA EN LA COMUNIDAD EUROPEA (SOLO PARA EL PRODUCTO INAL�MBRICO)
� El uso de este dispositivo est� restringido a interiores cuando funciona en la Comunidad Europea utilizando canales en la banda de 5,15-5,35 GHz, para reducir la posibilidad de interferencias.
� Este dispositivo es un sistema de transmisi�n (transceptor) de banda ancha de 2,4 GHz, pensado para su uso en todos los estados miembros de la UE y en los pa�ses de la AELC. Este equipo se puede utilizar en AL, AD, BE, BG, DK, DE, FI, FR, GR, GW, IS, IT, HR, LI, LU, MT, MK, MD, MC, NL, NO, AT, PL, PT, RO, SM, SE, RS, SK, ES, CI, HU, CY
Notas de uso:
� Para seguir cumpliendo las normas europeas de uso del espectro nacional, se aplicar�n limitaciones de frecuencia y canal en los productos en funci�n del pa�s en el que se pondr� en funcionamiento el equipo.
� Este dispositivo tiene restringido el funcionamiento en modo Ad-hoc mientras funcione a 5 Ghz. El modo Ad-hoc es la comunicaci�n directa de igual a igual entre dos dispositivos cliente sin un punto de acceso.
� Los puntos de acceso admitir�n la funcionalidad DFS (Selecci�n de frecuencia din�mica) y TPC (Control de la potencia de transmisi�n) si es necesario cuando funcionan a 5 Ghz dentro de la UE.
� Por favor compruebe el manual o la ficha de producto para comprobar si el producto utiliza las bandas inal�mbricas de 2.4 GHz y/o la de 5 GHz.

D-Link R15 User Manual

159

Appendix G - Regulatory Information
AVVISO PER L'USO DI LAN RADIO WIRELESS NELLA COMUNIT� EUROPEA (SOLO PER PRODOTTI WIRELESS)
� Nella Comunit� europea, l'uso di questo dispositivo � limitato esclusivamente agli ambienti interni sui canali compresi nella banda da 5,15 a 5,35 GHz al fine di ridurre potenziali interferenze. Questo dispositivo � un sistema di trasmissione a banda larga a 2,4 GHz (ricetrasmittente), destinato all'uso in tutti gli stati membri dell'Unione europea e nei paesi EFTA.
� Questo dispositivo pu� essere utilizzato in AL, AD, BE, BG, DK, DE, FI, FR, GR, GW, IS, IT, HR, LI, LU, MT, MK, MD, MC, NL, NO, AT, PL, PT, RO, SM, SE, RS, SK, ES, CI, HU, CY
Note per l'uso
� Al fine di mantenere la conformit� alle normative nazionali europee per l'uso dello spettro di frequenze, saranno applicate limitazioni sulle frequenze e sui canali per il prodotto in conformit� alle normative del paese in cui il dispositivo viene utilizzato.
� Questo dispositivo non pu� essere attivato in modalit� Ad-hoc durante il funzionamento a 5 Ghz. La modalit� Ad-hoc � una comunicazione diretta peer-to-peer fra due dispositivi client senza un punto di accesso.
� I punti di accesso supportano le funzionalit� DFS (Dynamic Frequency Selection) e TPC (Transmit Power Control) richieste per operare a 5 Ghz nell'Unione europea.
� Ti invitiamo a fare riferimento al manuale del prodotto o alla scheda tecnica per verificare se il tuo prodotto utilizza le frequenze 2,4 GHz e/o 5 GHz.
KENNISGEVING VAN DRAADLOOS RADIO LAN-GEBRUIK IN DE EUROPESE GEMEENSCHAP (ALLEEN VOOR DRAADLOOS PRODUCT)
� Dit toestel is beperkt tot gebruik binnenshuis wanneer het wordt gebruikt in de Europese Gemeenschap gebruik makend van kanalen in de 5.15-5.35 GHz band om de kans op interferentie te beperken.
� Dit toestel is een 2.4 GHz breedband transmissiesysteem (transceiver) dat bedoeld is voor gebruik in alle EU lidstaten en EFTA landen. Deze uitrusting mag gebruikt worden in AL, AD, BE, BG, DK, DE, FI, FR, GR, GW, IS, IT, HR, LI, LU, MT, MK, MD, MC, NL, NO, AT, PL, PT, RO, SM, SE, RS, SK, ES, CI, HU, CY
Gebruiksaanwijzingen:
� Om de gebruiksvoorschriften van het Europese Nationale spectrum na te leven, zullen frequentie- en kanaalbeperkingen worden toegepast op de producten volgens het land waar de uitrusting gebruikt zal worden.
� Dit toestel kan niet functioneren in Ad-hoc mode wanneer het gebruikt wordt in 5 GHz. Ad-hoc mode is directe peer-to-peer communicatie tussen twee klantenapparaten zonder een toegangspunt.
� Toegangspunten ondersteunen DFS (Dynamic Frequency Selection) en TPC (Transmit Power Control) functionaliteit zoals vereist bij gebruik in 5 GHz binnen de EU.
� Raadpleeg de handleiding of de datasheet om te controleren of uw product gebruik maakt van 2.4 GHz en/of 5 GHz.

D-Link R15 User Manual

160

Appendix G - Regulatory Information
SAFETY INSTRUCTIONS
The following general safety guidelines are provided to help ensure your own personal safety and protect your product from potential damage. Remember to consult the product user instructions for more details. � Static electricity can be harmful to electronic components. Discharge static electricity from your body (i.e. touching grounded bare metal)
before touching the product. � Do not attempt to service the product and never disassemble the product. For some products with a user replaceable battery, please read
and follow the instructions in the user manual. � Do not spill food or liquid on your product and never push any objects into the openings of your product. � Do not use this product near water, areas with high humidity, or condensation unless the product is specifically rated for outdoor application. � Keep the product away from radiators and other heat sources. � Always unplug the product from mains power before cleaning and use a dry lint free cloth only.
SICHERHEITSVORSCHRIFTEN
Die folgenden allgemeinen Sicherheitsvorschriften dienen als Hilfe zur Gew�hrleistung Ihrer eigenen Sicherheit und zum Schutz Ihres Produkts. Weitere Details finden Sie in den Benutzeranleitungen zum Produkt. � Statische Elektrizit�t kann elektronischen Komponenten schaden. Um Sch�den durch statische Aufladung zu vermeiden, leiten Sie
elektrostatische Ladungen von Ihrem K�rper ab, (z. B. durch Ber�hren eines geerdeten blanken Metallteils), bevor Sie das Produkt ber�hren. � Unterlassen Sie jeden Versuch, das Produkt zu warten, und versuchen Sie nicht, es in seine Bestandteile zu zerlegen. F�r einige Produkte mit austauschbaren Akkus lesen Sie bitte das Benutzerhandbuch und befolgen Sie die dort beschriebenen Anleitungen. � Vermeiden Sie, dass Speisen oder Fl�ssigkeiten auf Ihr Produkt gelangen, und stecken Sie keine Gegenst�nde in die Geh�useschlitze oder -�ffnungen Ihres Produkts. � Verwenden Sie dieses Produkt nicht in unmittelbarer N�he von Wasser und nicht in Bereichen mit hoher Luftfeuchtigkeit oder Kondensation, es sei denn, es ist speziell zur Nutzung in Au�enbereichen vorgesehen und eingestuft. � Halten Sie das Produkt von Heizk�rpern und anderen Quellen fern, die W�rme erzeugen. � Trennen Sie das Produkt immer von der Stromzufuhr, bevor Sie es reinigen und verwenden Sie dazu ausschlie�lich ein trockenes fusselfreies Tuch.

D-Link R15 User Manual

161

Appendix G - Regulatory Information
CONSIGNES DE S�CURIT�
Les consignes g�n�rales de s�curit� ci-apr�s sont fournies afin d'assurer votre s�curit� personnelle et de prot�ger le produit d'�ventuels dommages. Veuillez consulter les consignes d'utilisation du produit pour plus de d�tails. � L'�lectricit� statique peut endommager les composants �lectroniques. D�chargez l'�lectricit� statique de votre corps (en touchant un objet
en m�tal reli� � la terre par exemple) avant de toucher le produit. � N'essayez pas d'intervenir sur le produit et ne le d�montez jamais. Pour certains produits contenant une batterie rempla�able par l'utilisateur,
veuillez lire et suivre les consignes contenues dans le manuel d'utilisation. � Ne renversez pas d'aliments ou de liquide sur le produit et n'ins�rez jamais d'objets dans les orifices. � N'utilisez pas ce produit � proximit� d'un point d'eau, de zones tr�s humides ou de condensation sauf si le produit a �t� sp�cifiquement
con�u pour une application ext�rieure. � �loignez le produit des radiateurs et autres sources de chaleur. � D�branchez toujours le produit de l'alimentation avant de le nettoyer et utilisez uniquement un chiffon sec non pelucheux.
INSTRUCCIONES DE SEGURIDAD
Las siguientes directrices de seguridad general se facilitan para ayudarle a garantizar su propia seguridad personal y para proteger el producto frente a posibles da�os. No olvide consultar las instrucciones del usuario del producto para obtener m�s informaci�n. � La electricidad est�tica puede resultar nociva para los componentes electr�nicos. Descargue la electricidad est�tica de su cuerpo (p. ej.,
tocando alg�n metal sin revestimiento conectado a tierra) antes de tocar el producto. � No intente realizar el mantenimiento del producto ni lo desmonte nunca. Para algunos productos con bater�a reemplazable por el usuario,
lea y siga las instrucciones del manual de usuario. � No derrame comida o l�quidos sobre el producto y nunca deje que caigan objetos en las aberturas del mismo. � No utilice este producto cerca del agua, en zonas con humedad o condensaci�n elevadas a menos que el producto est� clasificado
espec�ficamente para aplicaci�n en exteriores. � Mantenga el producto alejado de los radiadores y de otras fuentes de calor. � Desenchufe siempre el producto de la alimentaci�n de red antes de limpiarlo y utilice solo un pa�o seco sin pelusa.

D-Link R15 User Manual

162

Appendix G - Regulatory Information
ISTRUZIONI PER LA SICUREZZA
Le seguenti linee guida sulla sicurezza sono fornite per contribuire a garantire la sicurezza personale degli utenti e a proteggere il prodotto da potenziali danni. Per maggiori dettagli, consultare le istruzioni per l'utente del prodotto. � L'elettricit� statica pu� essere pericolosa per i componenti elettronici. Scaricare l'elettricit� statica dal corpo (ad esempio toccando una parte
metallica collegata a terra) prima di toccare il prodotto. � Non cercare di riparare il prodotto e non smontarlo mai. Per alcuni prodotti dotati di batteria sostituibile dall'utente, leggere e seguire le
istruzioni riportate nel manuale dell'utente. � Non versare cibi o liquidi sul prodotto e non spingere mai alcun oggetto nelle aperture del prodotto. � Non usare questo prodotto vicino all'acqua, in aree con elevato grado di umidit� o soggette a condensa a meno che il prodotto non sia
specificatamente approvato per uso in ambienti esterni. � Tenere il prodotto lontano da caloriferi e altre fonti di calore. � Scollegare sempre il prodotto dalla presa elettrica prima di pulirlo e usare solo un panno asciutto che non lasci filacce.
VEILIGHEIDSINFORMATIE
De volgende algemene veiligheidsinformatie werd verstrekt om uw eigen persoonlijke veiligheid te waarborgen en uw product te beschermen tegen mogelijke schade. Denk eraan om de gebruikersinstructies van het product te raadplegen voor meer informatie. � Statische elektriciteit kan schadelijk zijn voor elektronische componenten. Ontlaad de statische elektriciteit van uw lichaam (d.w.z. het
aanraken van geaard bloot metaal) voordat uhet product aanraakt. � U mag nooit proberen het product te onderhouden en u mag het product nooit demonteren. Voor sommige producten met door de
gebruiker te vervangen batterij, dient u de instructies in de gebruikershandleiding te lezen en te volgen. � Mors geen voedsel of vloeistof op uw product en u mag nooit voorwerpen in de openingen van uw product duwen. � Gebruik dit product niet in de buurt van water, gebieden met hoge vochtigheid of condensatie, tenzij het product specifiek geclassificeerd is
voor gebruik buitenshuis. � Houd het product uit de buurt van radiators en andere warmtebronnen. � U dient het product steeds los te koppelen van de stroom voordat u het reinigt en gebruik uitsluitend een droge pluisvrije doek.

D-Link R15 User Manual

163

Appendix G - Regulatory Information

Disposing and Recycling Your Product

ENGLISH

This symbol on the product or packaging means that according to local laws and regulations this product should be not be disposed of in household waste but sent for recycling. Please take it to a collection point designated by your local authorities once it has reached the end of its life, some will accept products for free. By recycling the product and its packaging in this manner you help to conserve the environment and protect human health.

D-Link and the Environment

At D-Link, we understand and are committed to reducing any impact our operations and products may have on the environment. To minimise this impact D-Link designs and builds its products to be as environmentally friendly as possible, by using recyclable, low toxic materials in both products and packaging.

D-Link recommends that you always switch off or unplug your D-Link products when they are not in use. By doing so you will help to save energy and reduce CO2 emissions.

To learn more about our environmentally responsible products and packaging please visit www.dlinkgreen.com.

DEUTSCH

Dieses Symbol auf dem Produkt oder der Verpackung weist darauf hin, dass dieses Produkt gem�� bestehender �rtlicher Gesetze und Vorschriften nicht �ber den normalen Hausm�ll entsorgt werden sollte, sondern einer Wiederverwertung zuzuf�hren ist. Bringen Sie es bitte zu einer von Ihrer Kommunalbeh�rde entsprechend amtlich ausgewiesenen Sammelstelle, sobald das Produkt das Ende seiner Nutzungsdauer erreicht hat. F�r die Annahme solcher Produkte erheben einige dieser Stellen keine Geb�hren. Durch ein auf diese Weise durchgef�hrtes Recycling des Produkts und seiner Verpackung helfen Sie, die Umwelt zu schonen und die menschliche Gesundheit zu sch�tzen.

D-Link und die Umwelt

D-Link ist sich den m�glichen Auswirkungen seiner Gesch�ftst�tigkeiten und seiner Produkte auf die Umwelt bewusst und f�hlt sich verpflichtet, diese entsprechend zu mindern. Zu diesem Zweck entwickelt und stellt D-Link seine Produkte mit dem Ziel gr��tm�glicher Umweltfreundlichkeit her und verwendet wiederverwertbare, schadstoffarme Materialien bei Produktherstellung und Verpackung.

D-Link empfiehlt, Ihre Produkte von D-Link, wenn nicht in Gebrauch, immer auszuschalten oder vom Netz zu nehmen. Auf diese Weise helfen Sie, Energie zu sparen und CO2-Emissionen zu reduzieren.

Wenn Sie mehr �ber unsere umweltgerechten Produkte und Verpackungen wissen m�chten, finden Sie entsprechende Informationen im Internet unter www.dlinkgreen.com.

D-Link R15 User Manual

164

Appendix G - Regulatory Information

FRAN�AIS

Ce symbole appos� sur le produit ou son emballage signifie que, conform�ment aux lois et r�glementations locales, ce produit ne doit pas �tre �limin� avec les d�chets domestiques mais recycl�. Veuillez le rapporter � un point de collecte pr�vu � cet effet par les autorit�s locales; certains accepteront vos produits gratuitement. En recyclant le produit et son emballage de cette mani�re, vous aidez � pr�server l'environnement et � prot�ger la sant� de l'homme.

D-Link et l'environnement

Chez D-Link, nous sommes conscients de l'impact de nos op�rations et produits sur l'environnement et nous engageons � le r�duire. Pour limiter cet impact, D-Link con�oit et fabrique ses produits de mani�re aussi �cologique que possible, en utilisant des mat�riaux recyclables et faiblement toxiques, tant dans ses produits que ses emballages.

D-Link recommande de toujours �teindre ou d�brancher vos produits D-Link lorsque vous ne les utilisez pas. Vous r�aliserez ainsi des �conomies d'�nergie et r�duirez vos �missions de CO2.

Pour en savoir plus sur les produits et emballages respectueux de l'environnement, veuillez consulter le www.dlinkgreen.com.

ESPA�OL

Este s�mbolo en el producto o el embalaje significa que, de acuerdo con la legislaci�n y la normativa local, este producto no se debe desechar en la basura dom�stica sino que se debe reciclar. Ll�velo a un punto de recogida designado por las autoridades locales una vez que ha llegado al fin de su vida �til; algunos de ellos aceptan recogerlos de forma gratuita. Al reciclar el producto y su embalaje de esta forma, contribuye a preservar el medio ambiente y a proteger la salud de los seres humanos.
D-Link y el medio ambiente
En D-Link, comprendemos y estamos comprometidos con la reducci�n del impacto que puedan tener nuestras actividades y nuestros productos en el medio ambiente. Para reducir este impacto, D-Link dise�a y fabrica sus productos para que sean lo m�s ecol�gicos posible, utilizando materiales reciclables y de baja toxicidad tanto en los productos como en el embalaje.
D-Link recomienda apagar o desenchufar los productos D-Link cuando no se est�n utilizando. Al hacerlo, contribuir� a ahorrar energ�a y a reducir las emisiones de CO2.
Para obtener m�s informaci�n acerca de nuestros productos y embalajes ecol�gicos, visite el sitio www.dlinkgreen.com.

D-Link R15 User Manual

165

Appendix G - Regulatory Information

ITALIANO

La presenza di questo simbolo sul prodotto o sulla confezione del prodotto indica che, in conformit� alle leggi e alle normative locali, questo prodotto non deve essere smaltito nei rifiuti domestici, ma avviato al riciclo. Una volta terminato il ciclo di vita utile, portare il prodotto presso un punto di raccolta indicato dalle autorit� locali. Alcuni questi punti di raccolta accettano gratuitamente i prodotti da riciclare. Scegliendo di riciclare il prodotto e il relativo imballaggio, si contribuir� a preservare l'ambiente e a salvaguardare la salute umana.

D-Link e l'ambiente

D-Link cerca da sempre di ridurre l'impatto ambientale dei propri stabilimenti e dei propri prodotti. Allo scopo di ridurre al minimo tale impatto, D-Link progetta e realizza i propri prodotti in modo che rispettino il pi� possibile l'ambiente, utilizzando materiali riciclabili a basso tasso di tossicit� sia per i prodotti che per gli imballaggi.

D-Link raccomanda di spegnere sempre i prodotti D-Link o di scollegarne la spina quando non vengono utilizzati. In questo modo si contribuir� a risparmiare energia e a ridurre le emissioni di anidride carbonica.

Per ulteriori informazioni sui prodotti e sugli imballaggi D-Link a ridotto impatto ambientale, visitate il sito all'indirizzo www.dlinkgreen.com.

NEDERLANDS

Dit symbool op het product of de verpakking betekent dat dit product volgens de plaatselijke wetgeving niet mag worden weggegooid met het huishoudelijk afval, maar voor recyclage moeten worden ingeleverd. Zodra het product het einde van de levensduur heeft bereikt, dient u het naar een inzamelpunt te brengen dat hiertoe werd aangeduid door uw plaatselijke autoriteiten, sommige autoriteiten accepteren producten zonder dat u hiervoor dient te betalen. Door het product en de verpakking op deze manier te recyclen helpt u het milieu en de gezondheid van de mens te beschermen.

D-Link en het milieu
Bij D-Link spannen we ons in om de impact van onze handelingen en producten op het milieu te beperken. Om deze impact te beperken, ontwerpt en bouwt D-Link zijn producten zo milieuvriendelijk mogelijk, door het gebruik van recycleerbare producten met lage toxiciteit in product en verpakking.
D-Link raadt aan om steeds uw D-Link producten uit te schakelen of uit de stekker te halen wanneer u ze niet gebruikt. Door dit te doen bespaart u energie en beperkt u de CO2-emissies.
Breng een bezoek aan www.dlinkgreen.com voor meer informatie over onze milieuverantwoorde producten en verpakkingen.

D-Link R15 User Manual

166

Appendix G - Regulatory Information

POLSKI

Ten symbol umieszczony na produkcie lub opakowaniu oznacza, e zgodnie z miejscowym prawem i lokalnymi przepisami niniejszego produktu nie wolno wyrzuca jak odpady czy mieci z gospodarstwa domowego, lecz naley go podda procesowi recyklingu. Po zakoczeniu uytkowania produktu, niekt�re odpowiednie do tego celu podmioty przyjm takie produkty nieodplatnie, dlatego prosimy dostarczy go do punktu zbi�rki wskazanego przez lokalne wladze. Poprzez proces recyklingu i dziki takiemu postpowaniu z produktem oraz jego opakowaniem, pomog Pastwo chroni rodowisko naturalne i dba o ludzkie zdrowie.

D-Link i rodowisko

D-Link podchodzimy w spos�b wiadomy do ochrony otoczenia oraz jestemy zaangaowani w zmniejszanie wplywu naszych dziala i produkt�w na rodowisko naturalne. W celu zminimalizowania takiego wplywu firma D-Link konstruuje i wytwarza swoje produkty w taki spos�b, aby byly one jak najbardziej przyjazne rodowisku, stosujc do tych cel�w materialy nadajce si do powt�rnego wykorzystania, charakteryzujce si mal toksycznoci zar�wno w przypadku samych produkt�w jak i opakowa.

Firma D-Link zaleca, aby Pastwo zawsze prawidlowo wylczali z uytku swoje produkty D-Link, gdy nie s one wykorzystywane. Postpujc w ten spos�b pozwalaj Pastwo oszczdza energi i zmniejsza emisje CO2.

Aby dowiedzie si wicej na temat produkt�w i opakowa majcych wplyw na rodowisko prosimy zapozna si ze stron Internetow www. dlinkgreen.com.

CESKY

Tento symbol na v�robku nebo jeho obalu znamen�, ze podle m�stn platn�ch pedpis se v�robek nesm� vyhazovat do komun�ln�ho odpadu, ale odeslat k recyklaci. Az v�robek doslouz�, odneste jej pros�m na sbrn� m�sto urcen� m�stn�mi �ady k tomuto �celu. Nkter� sbrn� m�sta pij�maj� v�robky zdarma. Recyklac� v�robku i obalu pom�h�te chr�nit zivotn� prosted� i lidsk� zdrav�.

D-Link a zivotn� prosted�
Ve spolecnosti D-Link jsme si vdomi vlivu nasich provoz a v�robk na zivotn� prosted� a snaz�me se o minimalizaci tchto vliv. Proto sv� v�robky navrhujeme a vyr�b�me tak, aby byly co nejekologictjs�, a ve v�robc�ch i obalech pouz�v�me recyklovateln� a n�zkotoxick� materi�ly.
Spolecnost D-Link doporucuje, abyste sv� v�robky znacky D-Link vypnuli nebo vyt�hli ze z�suvky vzdy, kdyz je nepouz�v�te. Pomzete tak setit energii a sn�zit emise CO2.
V�ce informac� o nasich ekologick�ch v�robc�ch a obalech najdete na adrese www.dlinkgreen.com.

D-Link R15 User Manual

167

Appendix G - Regulatory Information

MAGYAR

Ez a szimb�lum a term�ken vagy a csomagol�son azt jelenti, hogy a helyi t�rv�nyeknek �s szab�lyoknak megfelelen ez a term�k nem semmis�thet meg a h�ztart�si hullad�kkal egy�tt, hanem �jrahasznos�t�sra kell k�ldeni. K�rj�k, hogy a term�k �lettartam�nak eltelt�t k�veten vigye azt a helyi hat�s�g �ltal kijel�lt gyjthelyre. A term�kek egyes helyeken ingyen elhelyezhetk. A term�k �s a csomagol�s �jrahasznos�t�s�val seg�ti v�deni a k�rnyezetet �s az emberek eg�szs�g�t.

A D-Link �s a k�rnyezet

A D-Linkn�l meg�rtj�k �s elk�telezettek vagyunk a mveleteink �s term�keink k�rnyezetre gyakorolt hat�sainak cs�kkent�s�re. Az ezen hat�s cs�kkent�se �rdek�ben a D-Link a lehet legink�bb k�rnyezetbar�t term�keket tervez �s gy�rt az�ltal, hogy �jrahasznos�that�, alacsony k�rosanyagtartalm� term�keket gy�rt �s csomagol�sokat alkalmaz.

A D-Link azt javasolja, hogy mindig kapcsolja ki vagy h�zza ki a D-Link term�keket a t�pforr�sb�l, ha nem haszn�lja azokat. Ezzel seg�t az energia megtakar�t�s�ban �s a sz�ndioxid kibocs�t�s�nak cs�kkent�s�ben.

K�rnyezetbar�t term�keinkrl �s csomagol�sainkr�l tov�bbi inform�ci�kat a www.dlinkgreen.com weboldalon tudhat meg.

NORSK

Dette symbolet p� produktet eller forpakningen betyr at dette produktet if�lge lokale lover og forskrifter ikke skal kastes sammen med husholdningsavfall, men leveres inn til gjenvinning. Vennligst ta det til et innsamlingssted anvist av lokale myndigheter n�r det er kommet til slutten av levetiden. Noen steder aksepteres produkter uten avgift. Ved p� denne m�ten � gjenvinne produktet og forpakningen hjelper du � verne milj�et og beskytte folks helse.
D-Link og milj�et
Hos D-Link forst�r vi oss p� og er forpliktet til � minske innvirkningen som v�r drift og v�re produkter kan ha p� milj�et. For � minimalisere denne innvirkningen designer og lager D-Link produkter som er s� milj�vennlig som mulig, ved � bruke resirkulerbare, lav-toksiske materialer b�de i produktene og forpakningen.
D-Link anbefaler at du alltid sl�r av eller frakobler D-Link-produkter n�r de ikke er i bruk. Ved � gj�re dette hjelper du � spare energi og � redusere CO2-utslipp.
For mer informasjon ang�ende v�re milj�ansvarlige produkter og forpakninger kan du g� til www.dlinkgreen.com.

D-Link R15 User Manual

168

Appendix G - Regulatory Information

DANSK

Dette symbol p� produktet eller emballagen betyder, at dette produkt i henhold til lokale love og regler ikke m� bortskaffes som husholdningsaffald, mens skal sendes til genbrug. Indlever produktet til et indsamlingssted som angivet af de lokale myndigheder, n�r det er n�et til slutningen af dets levetid. I nogle tilf�lde vil produktet blive modtaget gratis. Ved at indlevere produktet og dets emballage til genbrug p� denne m�de bidrager du til at beskytte milj�et og den menneskelige sundhed.

D-Link og milj�et

Hos D-Link forst�r vi og bestr�ber os p� at reducere enhver indvirkning, som vores aktiviteter og produkter kan have p� milj�et. For at minimere denne indvirkning designer og producerer D-Link sine produkter, s� de er s� milj�venlige som muligt, ved at bruge genanvendelige materialer med lavt giftighedsniveau i b�de produkter og emballage.

D-Link anbefaler, at du altid slukker eller frakobler dine D-Link-produkter, n�r de ikke er i brug. Ved at g�re det bidrager du til at spare energi og reducere CO2-udledningerne.

Du kan finde flere oplysninger om vores milj�m�ssigt ansvarlige produkter og emballage p� www.dlinkgreen.com.

SUOMI

T�m� symboli tuotteen pakkauksessa tarkoittaa, ett� paikallisten lakien ja s��nn�sten mukaisesti t�t� tuotetta ei pid� h�vitt�� yleisen kotitalousj�tteen seassa vaan se tulee toimittaa kierr�tett�v�ksi. Kun tuote on elinkaarensa p��ss�, toimita se l�himp��n viranomaisten hyv�ksym��n kierr�tyspisteeseen. Kierr�tt�m�ll� k�ytetyn tuotteen ja sen pakkauksen autat tukemaan sek� ymp�rist�n ett� ihmisten terveytt� ja hyvinvointia.
D-Link ja ymp�rist�
D-Link ymm�rt�� ymp�rist�nsuojelun t�rkeyden ja on sitoutunut v�hent�m��n tuotteistaan ja niiden valmistuksesta ymp�rist�lle mahdollisesti aiheutuvia haittavaikutuksia. N�m� negatiiviset vaikutukset minimoidakseen D-Link suunnittelee ja valmistaa tuotteensa mahdollisimman ymp�rist�yst�v�llisiksi k�ytt�m�ll� kierr�tett�vi�, alhaisia pitoisuuksia haitallisia aineita sis�lt�vi� materiaaleja sek� tuotteissaan ett� niiden pakkauksissa.
Suosittelemme, ett� irrotat D-Link-tuotteesi virtal�hteest� tai sammutat ne aina, kun ne eiv�t ole k�yt�ss�. Toimimalla n�in autat s��st�m��n energiaa ja v�hent�m��n hiilidioksiidip��st�j�.
Lue lis�� ymp�rist�yst�v�llisist� D-Link-tuotteista ja pakkauksistamme osoitteesta www.dlinkgreen.com.

D-Link R15 User Manual

169

Appendix G - Regulatory Information

SVENSKA

Den h�r symbolen p� produkten eller f�rpackningen betyder att produkten enligt lokala lagar och f�reskrifter inte skall kastas i hush�llssoporna utan i st�llet �tervinnas. Ta den vid slutet av dess livsl�ngd till en av din lokala myndighet utsedd uppsamlingsplats, vissa accepterar produkter utan kostnad. Genom att p� detta s�tt �tervinna produkten och f�rpackningen hj�lper du till att bevara milj�n och skydda m�nniskors h�lsa.

D-Link och milj�n

P� D-Link f�rst�r vi och �r fast beslutna att minska den p�verkan v�ra verksamheter och produkter kan ha p� milj�n. F�r att minska denna p�verkan utformar och bygger D-Link sina produkter f�r att de ska vara s� milj�v�nliga som m�jligt, genom att anv�nda �tervinningsbara material med l�g gifthalt i b�de produkter och f�rpackningar.

D-Link rekommenderar att du alltid st�nger av eller kopplar ur dina D-Link produkter n�r du inte anv�nder dem. Genom att g�ra detta hj�lper du till att spara energi och minska utsl�pp av koldioxid.

F�r mer information om v�ra milj�ansvariga produkter och f�rpackningar www.dlinkgreen.com.

PORTUGU�S

Este s�mbolo no produto ou embalagem significa que, de acordo com as leis e regulamenta�es locais, este produto n�o dever� ser eliminado juntamente com o lixo dom�stico mas enviado para a reciclagem. Transporte-o para um ponto de recolha designado pelas suas autoridades locais quando este tiver atingido o fim da sua vida �til, alguns destes pontos aceitam produtos gratuitamente. Ao reciclar o produto e respectiva embalagem desta forma, ajuda a preservar o ambiente e protege a sa�de humana.
A D-Link e o ambiente
Na D-Link compreendemos e comprometemo-nos com a redu��o do impacto que as nossas opera�es e produtos possam ter no ambiente. Para minimizar este impacto a D-Link concebe e constr�i os seus produtos para que estes sejam o mais inofensivos para o ambiente poss�vel, utilizando meteriais recicl�veis e n�o t�xicos tanto nos produtos como nas embalagens.
A D-Link recomenda que desligue os seus produtos D-Link quando estes n�o se encontrarem em utiliza��o. Com esta ac��o ajudar� a poupar energia e reduzir as emiss�es de CO2.
Para saber mais sobre os nossos produtos e embalagens respons�veis a n�vel ambiental visite www.dlinkgreen.com.

D-Link R15 User Manual

170
