Verifone, Inc. 1-800-Verifone www.verifone.com

Electrical

Separate Power Sources

Before you connect the terminal power pack to an electrical outlet, check that the on/off power switch on the terminal is off. If the terminal does not have an on/off switch, check that the power cable connector is removed from the terminal's power port. Or, when connecting the terminal to a power pack, always connect the plug of the power pack to an electrical wall outlet first. Then connect the power cable to the terminal's power port. The reference input power rating are as follows:
� Input Voltage: 100-240V AC, 50/60 Hz � Output Voltage: 5V DC, 2A Model CM5/CM5P/CM5W/CM5PW is intended to be provided with appropriately certified power module suitable for the destination country with an output rating of 5V DC, 2A, Tma 50�C and evaluated as a Limited Power Source, output rated SELV and non-energy hazardous. Suitability of power module is subject to auditing agency's discretion.
AC Adapter

The AC adapter is designed to ensure your personal safety and to be compatible with this equipment. Please follow these guidelines: � Do not use the adapter in a high moisture environment. Never touch the adapter when your hands or feet are wet. � Allow adequate ventilation around the adapter. Avoid locations with restricted air flow. � Connect the adapter to a proper power source. The voltage and grounding requirements are found on the product case and/or packaging. � Do not use the adapter if the cord becomes damaged. � Do not attempt to service the adapter. There are no serviceable parts inside. Replace the unit if it is damaged or exposed to excess moisture.
Disconnecting Power

Disconnecting power during a transaction may cause transaction data files that are not yet stored in terminal memory to be lost.
Location � Electrical Considerations

WARNING!

This device contains sensitive electronic components that can be permanently damaged if exposed to excessive shock, electrical interference or vibration.

AVERTISSEMENT! Cet appareil contient des composants �lectroniques sensibles qui peuvent �tre endommag�s defa�on permanente si elle est expos�e � des chocs excessifs, des interf�rences �lectriques ou

CAUTION:

des vibrations. Due to the risk of electric shock or damage to the terminal, do not use this equipment near a water source, for example near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool. Likewise, avoid using this product during thunderstorms causing power cuts. Avoid placing the terminal near electrical devices or other units that could cause large voltage fluctuations or electrical interference, such as air conditioners, neon signs, high frequency safety devices or electrical equipment.

ATTENTION:

Du fait d'un risqu� d'�lectgrocution ou d'une deterioration du terminal, ne pas utiliser cet �quipement pr�s d'une source d'eau, par example pr�s d'une baignoire, d'un lavabo, d'un �vier de

cuisine ou d'un bac de lavage, dans un sous-sol humide ou � proximit� d'une piscine. De m�me, �viter d'utiliser ce produit lors des orages provaquant des coupures �lectriques. �viter de

placer le terminal � proximit� d'appareils �lectriques ou autres unit�s pouvant entra�ner des fluctuations de tension importantes ou des interf�rences �lectriques, tells que les climatiseurs,

enseignes au n�on, dispositifs de s�curit� � haute fr�quence ou �quipments �lectriques.

Equipment

Damage

Carefully inspect the shipping carton and its contents for any damage. If the unit or any product component appears damaged or to have been tampered with, immediately notify the shipping company and your Verifone distributor or service provider. Do not use a Verifone Carbon Mobile 5 unit that has been tampered.
Repairs

Do not, under any circumstances, attempt any service, adjustments, or repairs on this equipment. Instead, contact your local Verifone distributor or service provider for assistance. Failure to comply may void the product warranty.
Location � Environmental Considerations

Do not plug the power pack into an outdoor outlet. The terminal is not waterproof or dustproof and should not be used outside the normal operating temperature range. Any damage to the unit from exposure to water or dust may void your warranty. Do not use the terminal where there is high heat, dust, humidity, moisture, or caustic chemicals or oils. Keep the terminal away from direct sunlight and anything that radiates heat, such as a stove or a motor.

WARNING!

Your POS Terminal contains sensitive electronic components that can be permanently damaged if exposed to excessive shock or vibration. To minimize the risk of damage to your Terminal,

avoid dropping your Terminal and operating it in high-shock and high-vibration environments. Do not store the Terminal where prolonged exposure to extreme temperature can occur,

because it can cause permanent damage. Do not expose the Terminal to water. Contact with water can cause this unit to malfunction.

AVERTISSEMENT! Votre terminal de point de vente contient des composants �lectroniques sensibles, susceptibles de subir des dommages d�finitifs en cas d'exposition � des chocs ou � des vibrations

excessives. Pour minimiser le risque de dommages pour votre terminal, �viter de le faire tomber ou de l'exposer � des environnements pouvant provoquer des chocs et des vibrations

excessives. Ne pas stocker le terminal dans des lieux susceptibles d'entra�ner une exposition prolong�e � des temp�ratures extr�mes, du fait des dommages d�finitifs que cette situation

peut provoquer. Ne pas exposer le terminal � l'eau. Un contact avec de l'eau peut provoquer un dysfonctionnement de l'unit�.

Cleaners and Solvents

Never use thinner, trichloroethylene or ketone-based solvents to clean the Verifone Carbon Mobile 5, these may deteriorate plastic or rubber parts. Do not spray cleaners or other solutions directly onto the keypad or display. For best results, use a clean cloth damped with water and mild soap. To remove stubborn stains, use alcohol or an alcohol-based cleaner.
Battery Pack Instruction for Portable Product

Dispose of the battery pack in accordance with all national, state, and local laws and regulations as regionally required. Some batteries may be recycled and may be accepted for disposal at local recycling centers.

CAUTION:

There is risk of explosion if the battery is replaced by an incorrect type.

ATTENTION:

Il y a risque d'explosion si la batterie est remplac�e par un type incorrect.

The highest specified charging temperature of battery pack is 55 +/- 3�C.

The lowest specified charging temperature of battery pack is -5 +/- 3�C.

Operating Temperature

The product is designed to work in maximum ambient temperature 0�C and 45�C.
Notice for Label Location

The label of our device will be affixed under battery compartment for your reference.
Notice for ISED WLAN 5G

(i) The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems. (ii) Where applicable, antenna type(s), antenna models(s), and worst-case tilt angle(s) necessary to remain compliant with the e.i.r.p. elevation mask requirement set forth in section 6.2.2.3 shall be clearly indicated.
Avertissement: (i)Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont r�serv�s uniquement pour une utilisation � l'int�rieur afin de r�duire les risques de brouillage pr�judiciable aux syst�mes de satellites mobiles utilisant les m�mes canaux. (ii)Lorsqu'il y a lieu, les types d'antennes (s'il y en a plusieurs), les num�ros de mod�le de l'antenne et les pires angles d'inclinaison n�cessaires pour rester conforme � l'exigence de la p.i.r.e. applicable au masque d'�l�vation, �nonc�e � la section 6.2.2.3, doivent �tre clairement indiqu�s.
ISED Exposure

Radiation Exposure Statement: The product complies with the Canada portable RF exposure limit set forth for an uncontrolled environment and is safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available. D�claration d'exposition aux radiations: Le produit est conforme aux limites d'exposition pour les appareils portables RF pour les Etats-Unis et le Canada �tablies pour un environnement non contr�l�. Le produit est s�r pour un fonctionnement tel que d�crit dans ce manuel. La r�duction aux expositions RF peut �tre augment�e si l'appareil peut �tre conserv� aussi loin que possible du corps de l'utilisateur ou que le dispositif est r�gl� sur la puissance de sortie la plus faible si une telle fonction est disponible.
Verifone Carbon Mobile 5 Certifications and Regulations

Verifone Part Number: DOC278-001-EN-F, Revision F01

*DOC278-001-EN-F*

Verifone Carbon Mobile 5 Certifications and Regulations FCC/ISED Compliance
The following product has been tested and certified as compliant with the regulations and guidelines detailed below: Manufacturer: Verifone, Inc. Brand: Verifone Model: CM5, CM5P, CM5W, CM5PW
Part 15 of FCC and ISED Rules
This device complies with the limits for a Class B digital device as specified in Part 15 of FCC and Innovation, Science and Economic Development Canada license-exempt RSS standard(s) Rules which provide reasonable protection against harmful interference in a residential installation. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. Le pr�sent appareil est conforme aux CNR d'Innovation, Science and Economic Development Canada applicables aux appareils radio exempts de licence. L'exploitation est autoris�e aux deux conditions suivantes: (1) Cet appareil ne doit pas provoquer d'interf�rences nuisibles. (2) Cet appareil doit accepter toutes les interf�rences re�ues, y compris les interf�rences susceptibles de provoquer un fonctionnement ind�sirable. This equipment generates, uses and can radiate radio frequency energy. If not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. In the unlikely event that there is interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: � Reorient or relocate the receiving antenna. � Increase the separation between the equipment and receiver. � Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. � Consult the dealer or an experienced radio/TV technician for help. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. Use of a shielded interface cable is required to comply with the Class B limits of Part 15 of FCC Rules. Cet appareil et son antenne ne doivent pas �tre situ�s ou fonctionner en conjonction avec une autre antenne ou un autre �metteur, exception faites des radios int�gr�es qui ont �t� test�es. Any changes or modifications to this equipment not expressly approved by Verifone could void the user's authority to operate this equipment. NOTE: The County Code Selection feature is disabled for products marketed in USA/Canada.
La fonction de s�lection de l'indicatif du pays est d�sactiv�e pour les produits commercialis�s aux �tats-Unis et au USA/Canada. Per FCC/ISED regulation, all Wi-Fi products marketed in USA/Canada must be fixed to USA/Canada operational channels only. This Class B digital apparatus complies with CAN ICES-003(B). Cet appareil num�rique de la classe B est conforme � la norme NMB-003(B) du Canada.
RF Exposure
USA The CM5W/CM5 meets the government's requirements for exposure to radio waves. The CM5W/CM5 is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. The exposure standard for wireless device employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg for body SAR and 4W/kg for extremity SAR. *Tests for SAR are conducted using standard operating positions accepted by the FCC with the device transmitting at its highest certified power level in all tested frequency bands. The body worn SAR and extremity SAR are tested for CM5W and the body-worn accessory SAR and extremity SAR are tested for CM5. For CM5, to maintain compliance with FCC RF exposure guidelines, if you wear this device on your body when transmitting, always place the device in a Verifone supplied or approved clip, holder, holster, case or body harness for this product. Use of nonVerifone approved accessories may not maintain compliance with FCC RF exposure guidelines. If you do not use one of the Verifone supplied or approved body-worn accessories and are not using the device held in the normal use position, ensure that the device is at least 15 mm from your body when transmitting. For any concern or inquiry, please contact Verifone distributor or Verifone service on how to purchase the approved holster. The extremity SAR is tested with CM5P/CM5PW. This device complies with SAR for general population/uncontrolled exposure limits in ANSI/IEEE C95.1-1999 and has been tested in accordance with the measurement methods and procedures specified in OET Bulletin 65 Supplement C. CE The CM5W/CM5PW/CM5P complies with the Radio Equipment Directive (2014/53/EU) issued by the Commission of the European Community. A minimum separation distance of 0 cm must be maintained between the user's body and the device, including the antenna during body-worn operation to comply with the RF exposure requirements in Europe for CM5W. A minimum separation distance of 0 mm is tested for Limbs SAR-10g/4.0W/kg criteria for CM5P/CM5PW/CM5W.
Notice for Operating Frequency and Output Power

Feature NFC (dB �A/m at 10m) 2.4G WLAN: 802.11b/g/n-HT20 (EIRP dBm)
5G WLAN: 802.11a/n-HT20/n-HT40 (EIRP dBm)
BT- EDR/LE (EIRP dBm) 2G: GSM900/GSM1800 (dBm) 3G Band I/Band V/Band VIII (dBm) 4G Band 1/3/5/8/7/20/38/40/41 (dBm)

CM5W 6.59
11b:16.75 11g:15.61 11n:15.05 11a:12.28 11n-HT20:13.80 11m-HT40:13.03 EDR:9.99 LE:1.02 NA
NA
NA

CM5PW Type A:7.76 Type B:7.32 11b:17.17 11g:16.27 11n:15.50 11a:13.31 11n-HT20:14.21 11m-HT40:14.11 EDR:9.50 LE:1.72 NA
NA
NA

CM5P
Type A:7.31 Type B:7.32
11b:16.86 11g:16 11n:15.17
11a:13.31 11n-HT20:14.83 11m-HT40:14.25
EDR:9.98 LE:1.48
EGSM:33.8 DCS:30.7
Band I:23.7 Band V/VIII:23.8
Band 1/20:23.9 Band 3:23.6 Band 5/8:24 Band 7:23 Band 38/40/41:23.8

Notice for WLAN

For CE WLAN: 5150-5350 MHz This device is restricted for indoor use only when operating in the 5150 to 5350 MHz frequency range.

This equipment may be operated in:

UK(NI)

For IC (i) The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems. (ii) Where applicable, antenna type(s), antenna models(s), and worst-case tilt angle(s) necessary to remain compliant with the e.i.r.p. elevation mask requirement set forth in section 6.2.2.3 shall be clearly indicated. Avertissement: (i) Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont r�serv�s uniquement pour une utilisation � l'int�rieur afin de r�duire les risques de brouillage pr�judiciable aux syst�mes de satellites mobiles utilisant les m�mes canaux. (ii) Lorsqu'il y a lieu, les types d'antennes (s'il y en a plusieurs), les num�ros de mod�le de l'antenne et les pires angles d'inclinaison n�cessaires pour rester conforme � l'exigence de la p.i.r.e. applicable au masque d'�l�vation, �nonc�e � la section 6.2.2.3, doivent �tre clairement indiqu�s.

Legal Terms and Conditions Regarding PCI SSC Approvals

PCI SSC's approval only applies to PEDs that are identical to the PED tested by a PCI Security Standards Council recognized laboratory. If any aspect of the PED is different from that which was tested by the laboratory - even if the PED conforms to the basic product description contained in the letter, then the PED model should not be considered approved, nor prompted as approved. For example, if a PED contains firmware, software, or physical construction that has the same name or model number as those tested by the laboratory, but in fact are not identical to those PED samples tested by the laboratory, then the PED should not be considered or prompted as approved. No vendor or other third party may refer to a PED as "PCI Approved," nor otherwise state or imply that PCI SSC has, in whole or part, approved any aspect of a vendor or its PEDs, except to the extent and subject to the terms and restrictions expressly set forth in a written agreement with PCI SSC, or in an approval letter. All other references to PCI SSC's approval are strictly and actively prohibited by PCI SSC. When granted, an approval is provided by PCI SSC to ensure certain security and operational characteristics important to the achievement of PCI SSC's goals, but the approval does not under any circumstances include any endorsement or warranty any products or services provided by third parties. Approval does not, under any circumstances, include or imply any product warranties from PCI SSC, including, without limitation, any implied warranties of merchantability, fitness for purpose or noninfringement, all of which are expressly disclaimed by PCI SSC. All rights and remedies regarding products and services, which have received an approval, shall be provided by the party providing such products or services, and not by PCI SSC or the payment brand participants.

Recycling: DO NOT DISCARD!
UFoNrITprMopUeSr TdiBspEoRsaEl CinYsCtruLcEtDionOsR, gDoIStoPhOttSpE://DreOcyFclPeR.vOerPifEonReL.Yc.om continued on rear cover
Recyclage: NE PAS JETER!
L'unit� doit �tre recycl�e ou mise au rebut dans les endroits pr�vus � cet effet. Pour conna�tre les proc�dures de mise au rebut, consultez le site http://recycle.verifone.com suite au verso

Please retain this sheet for future reference. � conserver pour r�f�rence ult�rieure.

Verifone Carbon Mobile 5 Declaration of Conformity
DECLARATION OF CONFORMITY according to ISO/IEC 17050-1 and 17050-2 This declaration of conformity is issued under the sole responsibility of the manufacturer ______________________________________________________________________

Manufacturer's Name: Manufacturer's Address:

Declares, that the product
Product Name: Model Name: Part Number: Brand: Product Options: SW Version: NB Company Name: NB Company Number: Certificate Number:

Conforms to the following Product Specifications:

Regulatory Requirement

Standards

Verifone, Inc. Verifone, Inc. 1400 West Stanford Ranch Road Suite 200 Rocklin, CA 95765
Carbon Mobile 5 CM5P, CM5W, CM5PW
M278-xxx-xx-x
Verifone All CM5-N-0.0.46 Timco 1177 TCF-871TC19

CM5PW CM5P CM5W

Safety

IEC 62368-1:2014 EN 62368-1:2014 + A11:2017

EMC

EN 55032:2012 + AC:2013 EN 55032:2015/A11:2020, Class B EN 61000-3-2:2014, Class A EN 61000-3-3:2013 EN 55035:2017 EN 55024:2010 EN 55024:2010 + A1:2015

RF (WIFI/BT)

EN 301 489-1 V2.1.1 Draft EN 301 489-1 V2.2.0 EN 301 489-17 V3.1.1 Draft EN 301 489-17 V3.2.0 EN 300 328 V2.2.2 EN 301 893 V2.1.1

RF (RFID)

EN 301 489-1 V2.1.1 Draft EN 301 489-1 V2.2.0 EN 301 489-3 V2.1.1 EN 300 330 V2.1.1

EN 301 489-1 V2.1.1

Draft EN 301 489-1 V2.2.0

Draft EN 301 489-52 V1.1.0

RF (2G/3G/4G)

EN 301 511 V12.5.1.

EN 301 908-1 V13.1.1

EN 301 908-2 V13.1.1

EN 301 908-13 V13.1.1

EN 301 489-1 V2.1.1

RF (GPS)

Draft EN 301 489-1 V2.2.0 EN 301 489-19 V2.1.1

EN 303 413 V1.1.1

SAR

EN 62209-2:2010/IEC 62209-2:2010 EN 50663:2017 EN 62479:2010 EN 50566:2017

Supplementary Information:
We hereby declare that these devices comply with the requirements of the Radio Equipment Directive 2014/53/EU. These products carry the CE Mark Directive 93/68/ EEC, and conform to RoHS Directive 2011/65/EU and delegated Directive (annex II)2015/863/EU, as well as Technical Documentation: EN IEC 63000:2018 and DIN EN IEC63000:2018.

CE Approval Date: June 22, 2021

European contact for regulatory topics only:

Thomas Weikart EVP, Global Operations, 2744 North University Drive, Coral Springs, FL 33065
Verifone Holding GmbH Seilerweg, 2F, Bad Hersfeld 36251, Germany Tel: +49 6621 84-500
