FTTH SOLUTIONS

DIGISOL XPON ONU 300Mbps Wireless Router with 1 PON, 1 GE + 1 FE LAN Port & 1 FXS Port
DG-GR1321
Key Features:-
� Plug and play, features auto-detecting, auto-configuration, and auto firmware upgrade, etc.
� Integrated OAM/OMCI remote configuration and maintenance function.
� Support IGMP Snooping. � Support 802.11n WiFi(2T2R) function. � Support NAT, Firewall function. � Support IPv4 and IPv6 dual stack. � Integrated line testing compliant with GR-909 on POTS.

Introduction:-
DIGISOL DG-GR1321 terminal devices are designed for fulfilling FTTH and triple play service demand of fixed network operators or cable operators. These boxes are based on the mature Gigabit EPON/GPON technology, which have high ratio of performance to price, and the technology of 802.11n WiFi (2T2R), Layer 2/3 and high quality VoIP as well. They are highly reliable and easy to maintain, with guaranteed QoS for different service. And they are fully compliant with technical regulations such as IEEE802.3ah. It works on both GEPON/GPON technology.

Technical Specifications:HARDWARE PARAMETER:
PON Interface � SC single-mode/ single-fiber,
Upstream 1.25Gbps, Downstream 2.5Gbps
Wavelength � Tx 1310nm, Rx 1490nm
Rx Sensitivity � -8dBm to -27dBm
Optical Type � SC/PC
Interface Type � 1*10/100/1000Mbps +
1*10/100Mbps + � Auto adaptive Ethernet interfaces,
Full/Half Duplex, RJ45 Connector � 1 FXS Port
Datasheet Updated: 16th August 2021

Wireless � Compliant with IEEE802.11b/g/n,
300Mbps, 2T2R with Two external antenna
Indicators � 8, For PWR, PON, LOS, LAN2, LAN1,
TEL, PAIR, Wi-Fi
SOFTWARE PARAMETER: LAN � Support Port rate limiting � Support Loop detection � Support Flow control � Support Storm control
VLAN � Support VLAN tag mode � Support VLAN trunk mode � Support VLAN translation mode

Multicast � Support IGMPv1/v2/v3 � Support IGMP Proxy and MLD Proxy � Support IGMP Snooping and MLD
Snooping
QoS � Support 4 queues � Support SP and WRR � Support 802.1P � Support DSCP
L3 � Support IPv4, IPv6 and IPv4/ Ipv6
dual stack � Support DHCP/ PPPOE/ Static � Support Static route � Support NAT � Support Virtual Server

FTTH SOLUTIONS

DIGISOL XPON ONU 300Mbps Wireless Router with 1 PON, 1 GE + 1 FE LAN Port & 1 FXS Port

Technical Specifications:-
DHCP � Support DHCP server
VoIP � Support SIP protocol � Support Voice coding: ITU-T G.711/
G.723/ G.726/G.729 � Support Echo cancellation exceeding
ITU-T G.165/G.168-2002, up to 128ms tail length � Support high/low speed fax/Modem, bypass fax, and T38 fax � Support InBand / RFC2833/SIP INFO, Md5 authentication, call forward, call waiting, hot-line call, and all kinds of value-added voice service. Multi-party conferencing � Support Line testing according to GR-909
