refresh, manual refresh, Advanced health status and diagnostics • Smart Partition™ solution with configurable SLC and MLC/TLC partitions • Extended operating temperature range from –25˚C to 95˚C • e.MMC 5.1 interface with HS400 Interface USB USB XB513 & XB313 Built and tested to cost-effectively meet a wide variety of program-erase ...
Capacities from 8GB to 256GB. • Advanced power protection, Auto refresh, manual refresh, Advanced health status and diagnostics. • Smart Partition™ solution ...
Connected Home and Edge Computing Storage Extreme High Endurance & Reliability Storage Solutions for Connected Home and Edge Computing Western Digital delivers a full range of Connected Home and Edge Computing storage solutions to help you reduce TCO and optimize performance. Connected Home and Edge Computing Storage 1 High Endurance & Reliable Storage in a Connected World from Endpoints to Edge With the advent of the cord-cutting, 5G-adopting world of cable and telecommunications, and the Mobile Virtual Network Operator (MVNO) business model, many service providers are expanding their touchpoints to create stickiness and retain customers and their businesses. In Connected Home applications, service providers are extending their infrastructure to provide not only broadcast TV and streaming video content on-demand, but also IoT-related services such as home gateway and security, smart appliances, HVAC systems, and irrigation systems. The conventional cloud-based DVR architecture (cDVR) that is used to store all the content and make decisions in the cloud is no longer adequate for service providers that seek to provide "anytime, anywhere, always-on" experiences to their customers. Enter "Edge Computing" -- the hybrid solution where computing power and data storage are brought closer to the location where they are needed -- to help address the latency challenge, especially during the peak hour, due to network bandwidth, and prepare the service providers for the immediate and distant future where 4K, 8K contents are made more complicated with AR/VR/MR applications. Storage at the Edge and Endpoints must meet specific requirements to help service providers achieve cost-effective DVR implementations and reduce TCO for their system and network architecture. Western Digital provides a full portfolio of storage solutions including small form factors, a wide capacity option, broad operating temperature range, and most importantly, its high endurance for the anticipated 24/7 operations and workload. Western Digital's High Endurance portfolio for Edge Computing and Connected Home is specifically designed to optimize the overall performance of the applications that require constant and continuous writes to the storage. They are engineered and tested to meet the service provider's demanding reliability, endurance, and quality requirements. Furthermore, the additional features of our storage, such as Card Health Status Monitor and Remote Maintenance, will help service providers reduce TCO in both customer retention and system deployment. Connected Home and Edge Computing Storage 2 Advanced Features Product Highlights · Custom-designed embedded flash drive, SDTM, microSDTM, USB, SSD and HDD for Connected Home · A broad range of capacities: 4GB to 4TB1 · Extreme durability supporting the toughest time shift buffer (TSB) specification requirements · Supports wide operational temperature range Applications · Smart TV · Home entertainment -- Pause live TV (PLTV), trick play, rewind, Lite DVR, nDVR, Push VOD, STB and content prepositioning · Home networking -- Routers and modems with embedded form factors · Home automation -- Security cameras, IoT gateway and energy management Business Benefits · Quickly deploy cost-effective DVR · Enable ad-insertion at the Edge · Drives faster time-to-market for new and advanced services · Offloads network traffic during peak times · Reduces network latencies · Reduces TCO for system/network architecture · Advanced OS and application solutions enable high reliability and longevity Connected Home and Edge Computing Storage Special Features · Health Status Monitor for Cards & e.MMC -- Remotely monitor usage and identify when upgrades or replacements are needed · Host Lock for Cards & e.MMC -- Prevent usage by unauthorized devices · Programmable String for Cards & e.MMC -- Program a unique identifier for inventory control · Secure Firmware Update for Cards & e.MMC · Remote Maintenance for Cards & e.MMC · High bandwidth support for multi-stream of 4K/UHD content 3 High Endurance & Reliable Storage in a Connected World from Endpoints to Edge e.MMC Embedded Flash Drive Edge+ SDTM Cards Solid State Drives iNAND® CH EM133 & EM123 e.MMC embedded flash drives optimized for high endurance applicationss Features · Capacities from 8GB to 256GB · Advanced power protection, Auto refresh, manual refresh, Advanced health status and diagnostics · Smart PartitionTM solution with configurable SLC and MLC/TLC partitions · Extended operating temperature range from 25°C to 95°C · e.MMC 5.1 interface with HS400 Interface USB LD313 & LD513 Designed to enable fast deployment of revenue-generating servicess Features · Capacities from 4GB to 128GB1 · Up to 896 TBW3 endurance · Host lock, secure firmware update, health status monitor · Wide operating temperature range from 25°C to 85°C Edge+ microSDTM Cards CL SN720 & CL SN520, PC SA530 Optimized for audio-video applications including PVRs, DVRs, and STBs Features · PCIe Gen3x4 NVMeTM, PCIe Gen3x2 NVMe and SATA III interfaces · M.2 2242, M.2 2280 and 2.5"/7mm form factors · High capacities up to 2TB1 Up to 1600 TBW3 endurance Hard Disk Drives USB XB513 & XB313 Built and tested to cost-effectively meet a wide variety of program-erase cycles and empower new user experiences Features · Capacities from 16GB (for video buffer) and 32GB to 128GB (for DVR Lite)1 · Up to 192 TBW3 endurance · Host lock, health status monitor · Operating temperature range from 0°C to 55°C fits STB environments Connected Home and Edge Computing Storage QD313 and QD513 Custom-designed to meet the needs of high endurance applications such as pause live TV (PLTV) Features · Capacities from 4GB to 64GB1 · Host lock, secure firmware update, health status monitor · Up to 640 TBW3 endurance · Enables entry-level lite DVR AV-25 and AV-GP 1000 Engineered to offer cool, quiet, and reliable operation optimized for audiovideo applications Features · Capacities from 320GB to 4TB1 · 2.5" and 3.5" form factors · SATA 6 Gb/s interface · Low power consumption * TBW (terabytes written) values calculated using JEDEC client workload (JESD219) and vary by capacity. 4 Embedded Flash Drives Product iNAND® CH EM133 iNAND® CH EM123 Interface e.MMC 5.1 Capacity1 16GB to 256GB 8GB to 64GB Operating Temp 25°C to 95°C Endurance3 Up to 1117 TBW (UDA) (For EUDA to be added) Up to 448 TBW (UDA) and 1440 TBW (EUDA) Dimensions 11.5x13x0.8mm 11.5x13x1.2mm Ordering Information SDINBDA6-###G-H SDINBDG4-###G-H SD & microSD Cards Product Form Factor Capacity1 Operating Temp Endurance3 Sequential R/W (MB/s)2 Ordering Information CH LD313 SD 8GB to 128GB Up to 896 TBW Up to 50/30 SDSDEB-###G CH LD513 CH QD313 SD microSD 4GB to 32GB 8GB to 64GB 25°C to 85°C Up to 450 TBW Up to 640 TBW Up to 50/50 Up to 50/30 SDSDEC-###G SDSDQEB-###G CH QD513 microSD 4GB to 8GB Up to 400 TBW Up to 50/50 SDSDQEC-###G USB Product Capacity1 Operating Temp Endurance3 Sequential R/W (MB/s)2 Ordering Information CH XB 513 16GB Up to 160 TBW 7/5 SDUFDEC-###G 0°C to 55°C CH XB 313 32GB to 128GB Up to 192 TBW Up to 20/10 SDUFDEA-###G Connected Home and Edge Computing Storage 5 Hard Drives Product Interface Form Factor Capacity1 Operating Temp Technology Ordering Information 320GB1 500GB1 1TB1 2TB1 3TB1 4TB1 WD AV-25 2.5" 320GB to 1TB 0°C to 60°C CMR WD3200LUCT WD5000LUCT WD10JUCT, WD10JUCX -- -- -- SATA 6 Gb/s WD AV-GP 1000 3.5" 500GB to 4TB 0°C to 70°C CMR -- WD5000AURX WD10EURX WD20EURX WD30EURX WD40EURX Solid State Drives Product Interface Form Factor Capacity1 Operating Temp Technology Ordering Information 128GB1 256GB1 512GB1 1TB1 2TB1 CL SN720 PCIe Gen 3x4 NVMe 1.3 M.2 2280 256GB to 2TB -- M.2 2280 256GB to 2TB M.2 2280 256GB to 2TB CL SN520 CL SN520 PCIe Gen 3x2 NVMe 1.3 M.2 2242 M.2 2280 128GB to 512GB 128GB to 512GB 0°C to 85°C 3D TLC PC SA530 SATA 6 Gb/s 2.5"/7 mm and M.2 2280 256GB to 1TB 0°C to 70°C SDAPNUW-128G-1022 M.2 2242 M.2 2280 128GB to 512GB 128GB to 512GB M.2 2242 128GB to 512GB M.2 2280 128GB to 512GB -- SDASB8Y-256G (2.5", non-SED) SDASN8Y-256G (M.2 2280, non-SED) SDATB8Y-256G (2.5", SED) SDATN8Y-256G (M.2 2280, SED) SDASB8Y-512G (2.5", non-SED) SDASN8Y-512G (M.2 2280, non-SED) SDATB8Y-512G (2.5", SED) SDATN8Y-512G (M.2 2280, SED) SDASB8Y-1T00 (2.5", non-SED) SDASN8Y-1T00 (M.2 2280, non-SED) SDATB8Y-1T00 (2.5", SED) SDATN8Y-1T00 (M.2 2280, SED) -- 1 1GB=1,000,000,000 bytes. 1TB=1,000,000,000,000 bytes. Actual user storage may be less depending on operating environment. 2 Based on internal testing; performance may vary depending on host device, usage conditions, drive capacity and other factors. 1MB=1,000,000 bytes. 3 Approximations based on internal metrics that quantify how much data can be written to a card during its lifespan, expressed in Terabytes Writes (TBW), with write application of 1. TBW (terabytes written) values calculated using JEDEC client workload (JESD219) and vary by capacity. Connected Home and Edge Computing Storage 6 5601 Great Oaks Parkway San Jose, CA 95119, USA www.westerndigital.com/support For all inquiries, please email: OEMProducts@wdc.com ©2020 Western Digital Corporation or its affiliates. All rights reserved. Western Digital, the Western Digital logo, and iNAND are registered trademarks or trademarks of Western Digital Corporation or its affiliates in the U.S. and/or other countries. The SD, microSD, microSDHC and microSDXC marks and logos are trademarks of SD-3C, LLC. Reference to a product does not meant it will be available in all countries. Images may differ from actual product. All other marks are the property of their respective owners. Western Digital Technologies, Inc. is the seller of record and licensee in the Americas of SanDisk® products. October 2020Adobe PDF Library 15.0
