CY9A340NB Series
32-bit ARM� Cortex�-M3 FM3 Microcontroller
The CY9A340NB Series are highly integrated 32-bit microcontrollers dedicated for embedded controllers with low-power consumption mode and competitive cost.
These series are based on the ARM� Cortex�-M3 Processor with on-chip Flash memory and SRAM, and have peripheral functions such as various timers, ADCs, and Communication Interfaces (USB, UART, CSIO, I2C).
The products which are described in this data sheet are placed into TYPE6 product categories in FM3 Family Peripheral Manual.
Features
32-bit ARM� Cortex�-M3 Core
Processor version: r2p1
Up to 40 MHz Frequency Operation
Integrated Nested Vectored Interrupt Controller (NVIC): 1
NMI (non-maskable interrupt) and 48 peripheral interrupts and 16 priority levels
24-bit System timer (Sys Tick): System timer for OS task
management
On-chip Memories
[Flash memory]
Dual operation Flash memory
Dual Operation Flash memory has the upper bank and the lower bank. So, this series could implement erase, write and read operations for each bank simultaneously.
Main area: Up to 256 Kbytes (Up to 240 Kbytes upper bank + 16 Kbytes lower bank)
Work area: 32 Kbytes (lower bank)
Read cycle: 0 wait-cycle
Security function for code protection
[SRAM]
This Series on-chip SRAM is composed of two independent SRAM (SRAM0, SRAM1). SRAM0 is connected to I-code bus and D-code bus of Cortex-M3 core. SRAM1 is connected to System bus.
SRAM0: Up to 16 Kbytes
SRAM1: Up to 16 Kbytes
External Bus Interface*
Supports SRAM, NOR Flash memory device
Up to 8 chip selects
8-/16-bit Data width
Up to 25-bit Address bit
Maximum area size: Up to 256 Mbytes
Supports Address/Data multiplex
Supports external RDY function
*: CY9AF341LB, F342LB and F344LB do not support External Bus Interface.
USB Interface
The USB interface is composed of Device and Host. PLL for USB is built-in, USB clock can be generated by multiplication of Main clock.
[USB device]
USB2.0 Full-Speed supported
Max 6 EndPoint supported
EndPoint 0 is control transfer EndPoint 1, 2 can select Bulk-transfer, Interrupt-transfer or
Isochronous-transfer EndPoint 3 to 5 can select Bulk-transfer or
Interrupt-transfer EndPoint 1 to 5 is comprised of Double Buffers. The size of each endpoint is according to the follows.
- Endpoint 0, 2 to 5: 64 bytes - Endpoint 1: 256 bytes
[USB host]
USB2.0 Full/Low-speed supported
Bulk-transfer, interrupt-transfer and Isochronous-transfer
support
Automatic detection of connected/disconnected USB Device
Automatic processing of the IN/OUT token handshake
packet
Max 256-byte packet-length supported
Wake-up function supported
Cypress Semiconductor Corporation � Document Number: 002-05635 Rev. *C
198 Champion Court � San Jose, CA 95134-1709 �
408-943-2600 Revised May 16, 2019
CY9A340NB Series
Multi-function Serial Interface (Max 8 channels)
4 channels with 16steps�9-bit FIFO (ch.4 to ch.7), 4
channels without FIFO (ch.0 to ch.3)
Operation mode is selectable from the followings for each
channel. UART CSIO I2C
[UART]
Full-duplex double buffer Selection with or without parity supported Built-in dedicated baud rate generator External clock available as a serial clock Hardware Flow control* : Automatically control the
transmission by CTS/RTS (only ch.4)
Various error detection functions available (parity errors,
framing errors, and overrun errors)
*: CY9AF341LB, F342LB and F344LB do not support Hardware Flow control.
[CSIO]
Full-duplex double buffer Built-in dedicated baud rate generator Overrun error detection function available
[I2C]
Standard-mode (Max 100 kbps) / Fast-mode (Max 400 kbps) supported
DMA Controller (8 channels)
The DMA Controller has an independent bus from the CPU, so CPU and DMA Controller can process simultaneously.
8 independently configured and operated channels Transfer can be started by software or request from the
built-in peripherals
Transfer address area: 32-bit (4 Gbytes) Transfer mode: Block transfer/Burst transfer/Demand
transfer
Transfer data type: byte/half-word/word Transfer block count: 1 to 16 Number of transfers: 1 to 65536
A/D Converter (Max 24 channels)
[12-bit A/D Converter] Successive Approximation type Built-in 2 units Conversion time: 2.0 s @ 2.7 V to 3.6 V Priority conversion available (priority at 2 levels) Scanning conversion mode Built-in FIFO for conversion data storage (for SCAN
conversion: 16steps, for Priority conversion: 4steps)
Base Timer (Max 8 channels)
Operation mode is selectable from the followings for each channel.
16-bit PWM timer 16-bit PPG timer 16-/32-bit reload timer 16-/32-bit PWC timer
General-Purpose I/O Port
This series can use its pins as general-purpose I/O ports when they are not used for external bus or peripherals. Moreover, the port relocate function is built in. It can set which I/O port the peripheral function can be allocated to.
Capable of pull-up control per pin Capable of reading pin level directly Built-in the port relocate function Up to 83 fast general-purpose I/O Ports@100 pin Package Some ports are 5V tolerant I/O.
See Pin Description to confirm the corresponding pins.
Dual Timer (32-/16-bit Down Counter)
The Dual Timer consists of two programmable 32-/16-bit down counters. Operation mode is selectable from the followings for each channel.
Free-running Periodic (=Reload) One-shot
Document Number: 002-05635 Rev. *C
Page 2 of 126
CY9A340NB Series
HDMI-CEC/Remote Control Receiver (Up to 2 channels)
HDMI-CEC transmitter
Header block automatic transmission by judging Signal free
Generating status interrupt by detecting Arbitration lost Generating START, EOM, ACK automatically to output
CEC transmission by setting 1 byte data Generating transmission status interrupt when transmitting
1 block (1 byte data and EOM/ACK)
HDMI-CEC receiver
Automatic ACK reply function available Line error detection function available
Remote control receiver
4 bytes reception buffer Repeat code detection function available
Real-time clock (RTC)
The Real-time clock can count Year/Month/Day/Hour/Minute/Second/A day of the week from 00 to 99.
The interrupt function with specifying date and time
(Year/Month/Day/Hour/Minute) is available. This function is also available by specifying only Year, Month, Day, Hour or Minute.
Timer interrupt function after set time or each set time.
Capable of rewriting the time with continuing the time count.
Leap year automatic count is available.
Watch Counter
The Watch counter is used for wake up from sleep and timer mode.
Interval timer: up to 64 s (Max) @ Sub Clock: 32.768 kHz
External Interrupt Controller Unit
Up to 16 external interrupt input pins
Include one non-maskable interrupt (NMI) input pin
Watchdog Timer (2 channels)
A watchdog timer can generate interrupts or a reset when a time-out value is reached.
This series consists of two different watchdogs, a Hardware watchdog and a Software watchdog.
The Hardware watchdog timer is clocked by the built-in low-speed CR oscillator. Therefore, the Hardware watchdog is active in any low-power consumption modes except RTC, Stop, Deep Standby RTC, Deep Standby Stop modes.
CRC (Cyclic Redundancy Check) Accelerator
The CRC accelerator calculates the CRC which has a heavy software processing load, and achieves a reduction of the integrity check processing load for reception data and storage.
CCITT CRC16 and IEEE-802.3 CRC32 are supported.
CCITT CRC16 Generator Polynomial: 0x1021
IEEE-802.3 CRC32 Generator Polynomial: 0x04C11DB7
Clock and Reset
[Clocks]
Selectable from five clock sources (2 external oscillators, 2 built-in CR oscillators, and Main PLL).
Main Clock:
4 MHz to 48 MHz
Sub Clock:
32.768 kHz
Built-in high-speed CR Clock:4 MHz
Built-in low-speed CR Clock: 100 kHz
Main PLL Clock
[Resets] Reset requests from INITX pin Power-on reset Software reset Watchdog timers reset Low-voltage detection reset Clock Super Visor reset
Clock Super Visor (CSV)
Clocks generated by built-in CR oscillators are used to supervise abnormality of the external clocks.
External clock failure (clock stop) is detected, reset is
asserted.
External frequency anomaly is detected, interrupt or reset is
asserted.
Low-Voltage Detector (LVD)
This Series includes 2-stage monitoring of voltage on the VCC pins. When the voltage falls below the voltage that has been set, Low-Voltage Detector generates an interrupt or reset.
LVD1: error reporting via interrupt
LVD2: auto-reset operation
Document Number: 002-05635 Rev. *C
Page 3 of 126
CY9A340NB Series
Low-Power Consumption Mode
Six low-power consumption modes supported.
Sleep
Timer
RTC
Stop
Deep Standby RTC (selectable between keeping the value of
RAM and not)
Deep Standby Stop (selectable between keeping the value of
RAM and not)
Debug Serial Wire JTAG Debug Port (SWJ-DP) Embedded Trace Macrocells (ETM).*
*: CY9AF341LB/MB, F342LB/MB and F344LB/MB support only SWJ-DP.
Unique ID
Unique value of the device (41-bit) is set.
Power Supply
Wide range voltage: VCC = 1.65 V to 3.6 V VCC = 3.0 V to 3.6 V (when USB is used)
Document Number: 002-05635 Rev. *C
Page 4 of 126
CY9A340NB Series
Contents
1. Product Lineup.................................................................................................................................................................. 7 2. Packages ........................................................................................................................................................................... 8 3. Pin Assignment ................................................................................................................................................................. 9 4. List of Pin Functions....................................................................................................................................................... 16 5. I/O Circuit Type ............................................................................................................................................................... 40 6. Handling Precautions ..................................................................................................................................................... 44 7. Handling Devices ............................................................................................................................................................ 47 8. Block Diagram ................................................................................................................................................................. 49 9. Memory Size .................................................................................................................................................................... 50 10. Memory Map .................................................................................................................................................................... 50 11. Pin Status in Each CPU State ........................................................................................................................................ 53 12. Electrical Characteristics ............................................................................................................................................... 61 12.1 Absolute Maximum Ratings ......................................................................................................................................... 61 12.2 Recommended Operating Conditions ......................................................................................................................... 62 12.3 DC Characteristics ...................................................................................................................................................... 63 12.3.1 Current rating ............................................................................................................................................................... 63 12.3.2 Pin Characteristics ....................................................................................................................................................... 66 12.4 AC Characteristics....................................................................................................................................................... 67 12.4.1 Main Clock Input Characteristics.................................................................................................................................. 67 12.4.2 Sub Clock Input Characteristics ................................................................................................................................... 68 12.4.3 Built-in CR Oscillation Characteristics .......................................................................................................................... 68 12.4.4 Operating Conditions of Main and USB PLL (In the case of using main clock for input of PLL)................................... 69 12.4.5 Operating Conditions of Main PLL (In the case of using the built-in High-speed CR for the input clock
of the Main PLL)........................................................................................................................................................... 69 12.4.6 Reset Input Characteristics .......................................................................................................................................... 71 12.4.7 Power-on Reset Timing................................................................................................................................................ 71 12.4.8 External Bus Timing ..................................................................................................................................................... 72 12.4.9 Base Timer Input Timing .............................................................................................................................................. 79 12.4.10 CSIO/UART Timing .................................................................................................................................................. 80 12.4.11 External Input Timing................................................................................................................................................ 89 12.4.12 I2C Timing ................................................................................................................................................................. 90 12.4.13 ETM Timing .............................................................................................................................................................. 91 12.4.14 JTAG Timing............................................................................................................................................................. 92 12.5 12-bit A/D Converter.................................................................................................................................................... 93 12.6 USB Characteristics .................................................................................................................................................... 96 12.7 Low-Voltage Detection Characteristics...................................................................................................................... 100 12.7.1 Low-Voltage Detection Reset..................................................................................................................................... 100 12.7.2 Interrupt of Low-Voltage Detection............................................................................................................................. 101 12.8 Flash Memory Write/Erase Characteristics ............................................................................................................... 102 12.8.1 Write / Erase time....................................................................................................................................................... 102 12.8.2 Write cycles and data hold time ................................................................................................................................. 102 12.9 Return Time from Low-Power Consumption Mode.................................................................................................... 103 12.9.1 Return Factor: Interrupt/WKUP .................................................................................................................................. 103 12.9.2 Return Factor: Reset .................................................................................................................................................. 105 13. Ordering Information .................................................................................................................................................... 107 14. Package Dimensions .................................................................................................................................................... 109 15. Errata.............................................................................................................................................................................. 118
Document Number: 002-05635 Rev. *C
Page 5 of 126
CY9A340NB Series
16. Major Changes .............................................................................................................................................................. 122 Document History............................................................................................................................................................... 125 Sales, Solutions, and Legal Information........................................................................................................................... 126
Document Number: 002-05635 Rev. *C
Page 6 of 126
CY9A340NB Series
1. Product Lineup
Memory size
Product name
CY9AF341LB/MB/NB CY9AF342LB/MB/NB CY9AF344LB/MB/NB
On-chip Flash memory
On-chip SRAM
Main area
Work area SRAM0 SRAM1 Total
64 Kbytes
32 Kbytes 8 Kbytes 8 Kbytes 16 Kbytes
128 Kbytes
32 Kbytes 8 Kbytes 8 Kbytes 16 Kbytes
256 Kbytes
32 Kbytes 16 Kbytes 16 Kbytes 32 Kbytes
Function
Product name
CY9AF341LB CY9AF342LB CY9AF344LB
CY9AF341MB CY9AF342MB CY9AF344MB
CY9AF341NB CY9AF342NB CY9AF344NB
Pin count
64
80/96
100/112
CPU
Freq.
Cortex-M3 40 MHz
Power supply voltage range
1.65 V to 3.6 V
USB2.0 (Device/Host)
1 ch.
DMAC
8 ch.
External Bus Interface
Addr: 21-bit (Max)
Addr: 25-bit (Max)
R/W Data: 8-bit (Max) R/W Data: 8-/16-bit (Max)
-
CS: 4 (Max)
CS: 8 (Max)
Support: SRAM, NOR
Support: SRAM,
Flash memory
NOR Flash memory
Multi-function Serial Interface (UART/CSIO/I2C)
8 ch. (Max) ch.4 to ch.7: FIFO (16steps � 9-bit)
ch.0 to ch.3: No FIFO
Base Timer (PWC/Reload timer/PWM/PPG)
8 ch. (Max)
Dual Timer
1 unit
HDMI-CEC/ Remote Control Receiver
2 ch. (Max)
Real-Time Clock
1 unit
Watch Counter
1 unit
CRC Accelerator
Yes
Watchdog timer
1ch. (SW) + 1ch. (HW)
External Interrupts
8 pins (Max) + NMI � 1
11 pins (Max) + NMI � 1
16 pins (Max) + NMI � 1
I/O ports
51 pins (Max)
66 pins (Max)
83 pins (Max)
12-bit A/D converter
12 ch. (2 units)
17 ch. (2 units)
24 ch. (2 units)
CSV (Clock Super Visor)
Yes
LVD (Low-Voltage Detector)
2 ch.
High-speed Built-in CR
Low-speed
4 MHz 100 kHz
Debug Function
SWJ-DP
SWJ-DP/ETM
Unique ID
Yes
Note:
- All signals of the peripheral function in each product cannot be allocated by limiting the pins of package.
It is necessary to use the port relocate function of the I/O port according to your function use. See Electrical Characteristics 12.4 AC Characteristics (12.4.3)Built-in CR Oscillation Characteristics for accuracy of built-in CR.
Document Number: 002-05635 Rev. *C
Page 7 of 126
CY9A340NB Series
2. Packages
Package
Product name
LQFP: LQD064 (0.5 mm pitch) LQFP: LQG064 (0.65 mm pitch) QFN: VNC064 (0.5 mm pitch) LQFP: LQH080 (0.5 mm pitch) LQFP: LQJ080 (0.65 mm pitch) BGA: FDG096 (0.5 mm pitch) LQFP: LQI100 (0.5 mm pitch) QFP: PQH100 (0.65 mm pitch) BGA: LBC112 (0.8 mm pitch)
: Supported
CY9AF341LB CY9AF342LB CY9AF344LB
-
- - - -
CY9AF341MB CY9AF342MB CY9AF344MB
-
-
-
Note:
- See Package Dimensions for detailed information on each package.
CY9AF341NB CY9AF342NB CY9AF344NB
-
-
-
-
Document Number: 002-05635 Rev. *C
Page 8 of 126
3. Pin Assignment
LQI100
(TOP VIEW)
CY9A340NB Series
100 VSS 99 P81/UDP0 98 P80/UDM0 97 VCC 96 P60/SIN5_0/TIOA2_2/INT15_1/WKUP3/CEC1/MRDY_1 95 P61/SOT5_0/TIOB2_2/UHCONX 94 P62/SCK5_0/ADTG_3/MOEX_1 93 P63/INT03_0/MWEX_1 92 P0F/NMIX/CROUT_1/RTCCO_0/SUBOUT_0/WKUP0 91 P0E/CTS4_0/TIOB3_2/MDQM1_1 90 P0D/RTS4_0/TIOA3_2/MDQM0_1 89 P0C/SCK4_0/TIOA6_1/MALE_1 88 P0B/SOT4_0/TIOB6_1/MCSX0_1 87 P0A/SIN4_0/INT00_2/MCSX1_1 86 P09/TRACECLK/TIOB0_2/RTS4_2/MCSX2_1 85 P08/AN23/TRACED3/TIOA0_2/CTS4_2/MCSX3_1 84 P07/AN22/TRACED2/ADTG_0/SCK4_2/MCLKOUT_1 83 P06/AN21/TRACED1/TIOB5_2/SOT4_2/INT01_1/MCSX4_1 82 P05/AN20/TRACED0/TIOA5_2/SIN4_2/INT00_1/MCSX5_1 81 P04/TDO/SWO 80 P03/TMS/SWDIO 79 P02/TDI/MCSX6_1 78 P01/TCK/SWCLK 77 P00/TRSTX/MCSX7_1 76 VCC
VCC 1 P50/INT00_0/SIN3_1/MADATA00_1 2 P51/INT01_0/SOT3_1/MADATA01_1 3 P52/INT02_0/SCK3_1/MADATA02_1 4 P53/SIN6_0/TIOA1_2/INT07_2/MADATA03_1 5 P54/SOT6_0/TIOB1_2/MADATA04_1 6 P55/SCK6_0/ADTG_1/MADATA05_1 7
P56/INT08_2/MADATA06_1 8 P30/TIOB0_1/INT03_2/MADATA07_1 9 P31/TIOB1_1/SCK6_1/INT04_2/MADATA08_1 10 P32/TIOB2_1/SOT6_1/INT05_2/MADATA09_1 11 P33/INT04_0/TIOB3_1/SIN6_1/ADTG_6/MADATA10_1 12
P34/TIOB4_1/MADATA11_1 13 P35/TIOB5_1/INT08_1/MADATA12_1 14
P36/SIN5_2/INT09_1/MADATA13_1 15 P37/SOT5_2/INT10_1/MADATA14_1 16 P38/SCK5_2/INT11_1/MADATA15_1 17
P39/ADTG_2 18 P3A/TIOA0_1/RTCCO_2/SUBOUT_2 19
P3B/TIOA1_1 20 P3C/TIOA2_1 21 P3D/TIOA3_1 22 P3E/TIOA4_1 23 P3F/TIOA5_1 24
VSS 25
LQFP - 100
75 VSS 74 P20/AN19/INT05_0/CROUT_0/MAD24_1 73 P21/AN18/SIN0_0/INT06_1/WKUP2 72 P22/AN17/SOT0_0/TIOB7_1 71 P23/AN16/SCK0_0/TIOA7_1 70 P1F/AN15/ADTG_5/MAD23_1 69 P1E/AN14/RTS4_1/MAD22_1 68 P1D/AN13/CTS4_1/MAD21_1 67 P1C/AN12/SCK4_1/MAD20_1 66 P1B/AN11/SOT4_1/MAD19_1 65 P1A/AN10/SIN4_1/INT05_1/MAD18_1 64 P19/AN09/SCK2_2/MAD17_1 63 P18/AN08/SOT2_2/MAD16_1 62 AVSS 61 AVRH 60 AVCC 59 P17/AN07/SIN2_2/INT04_1/MAD15_1 58 P16/AN06/SCK0_1/MAD14_1 57 P15/AN05/SOT0_1/MAD13_1 56 P14/AN04/SIN0_1/INT03_1/MAD12_1 55 P13/AN03/SCK1_1/RTCCO_1/SUBOUT_1/MAD11_1 54 P12/AN02/SOT1_1/MAD10_1 53 P11/AN01/SIN1_1/INT02_1/WKUP1/MAD09_1 52 P10/AN00 51 VCC
VCC 26 P40/TIOA0_0/INT12_1 27 P41/TIOA1_0/INT13_1 28
P42/TIOA2_0 29 P43/TIOA3_0/ADTG_7 30 P44/TIOA4_0/MAD00_1 31 P45/TIOA5_0/MAD01_1 32
C 33 VSS 34 VCC 35 P46/X0A 36 P47/X1A 37 INITX 38 P48/INT14_1/SIN3_2/MAD02_1 39 P49/TIOB0_0/SOT3_2/MAD03_1 40 P4A/TIOB1_0/SCK3_2/MAD04_1 41 P4B/TIOB2_0/MAD05_1 42 P4C/TIOB3_0/SCK7_1/CEC0/MAD06_1 43 P4D/TIOB4_0/SOT7_1/MAD07_1 44 P4E/TIOB5_0/INT06_2/SIN7_1/MAD08_1 45 PE0/MD1 46 MD0 47 PE2/X0 48 PE3/X1 49 VSS 50
Note:
- The number after the underscore ("_") in pin names such as XXX_1 and XXX_2 indicates the relocated port number. For these
pins, there are multiple pins that provide the same function for the same channel. Use the extended port function register (EPFR) to select the pin.
Document Number: 002-05635 Rev. *C
Page 9 of 126
PQH100
(TOP VIEW)
CY9A340NB Series
80 P50/INT00_0/SIN3_1/MADATA00_1 79 VCC 78 VSS 77 P81/UDP0 76 P80/UDM0 75 VCC 74 P60/SIN5_0/TIOA2_2/INT15_1/WKUP3/CEC1/MRDY_1 73 P61/SOT5_0/TIOB2_2/UHCONX 72 P62/SCK5_0/ADTG_3/MOEX_1 71 P63/INT03_0/MWEX_1 70 P0F/NMIX/CROUT_1/RTCCO_0/SUBOUT_0/WKUP0 69 P0E/CTS4_0/TIOB3_2/MDQM1_1 68 P0D/RTS4_0/TIOA3_2/MDQM0_1 67 P0C/SCK4_0/TIOA6_1/MALE_1 66 P0B/SOT4_0/TIOB6_1/MCSX0_1 65 P0A/SIN4_0/INT00_2/MCSX1_1 64 P09/TRACECLK/TIOB0_2/RTS4_2/MCSX2_1 63 P08/AN23/TRACED3/TIOA0_2/CTS4_2/MCSX3_1 62 P07/AN22/TRACED2/ADTG_0/SCK4_2/MCLKOUT_1 61 P06/AN21/TRACED1/TIOB5_2/SOT4_2/INT01_1/MCSX4_1 60 P05/AN20/TRACED0/TIOA5_2/SIN4_2/INT00_1/MCSX5_1 59 P04/TDO/SWO 58 P03/TMS/SWDIO 57 P02/TDI/MCSX6_1 56 P01/TCK/SWCLK 55 P00/TRSTX/MCSX7_1 54 VCC 53 VSS 52 P20/AN19/INT05_0/CROUT_0/MAD24_1 51 P21/AN18/SIN0_0/INT06_1/WKUP2
P51/INT01_0/SOT3_1/MADATA01_1 81 P52/INT02_0/SCK3_1/MADATA02_1 82 P53/SIN6_0/TIOA1_2/INT07_2/MADATA03_1 83 P54/SOT6_0/TIOB1_2/MADATA04_1 84 P55/SCK6_0/ADTG_1/MADATA05_1 85
P56/INT08_2/MADATA06_1 86 P30/TIOB0_1/INT03_2/MADATA07_1 87 P31/TIOB1_1/SCK6_1/INT04_2/MADATA08_1 88 P32/TIOB2_1/SOT6_1/INT05_2/MADATA09_1 89 P33/INT04_0/TIOB3_1/SIN6_1/ADTG_6/MADATA10_1 90
P34/TIOB4_1/MADATA11_1 91 P35/TIOB5_1/INT08_1/MADATA12_1 92
P36/SIN5_2/INT09_1/MADATA13_1 93 P37/SOT5_2/INT10_1/MADATA14_1 94 P38/SCK5_2/INT11_1/MADATA15_1 95
P39/ADTG_2 96 P3A/TIOA0_1/RTCCO_2/SUBOUT_2 97
P3B/TIOA1_1 98 P3C/TIOA2_1 99 P3D/TIOA3_1 100
QFP - 100
50 P22/AN17/SOT0_0/TIOB7_1 49 P23/AN16/SCK0_0/TIOA7_1 48 P1F/AN15/ADTG_5/MAD23_1 47 P1E/AN14/RTS4_1/MAD22_1 46 P1D/AN13/CTS4_1/MAD21_1 45 P1C/AN12/SCK4_1/MAD20_1 44 P1B/AN11/SOT4_1/MAD19_1 43 P1A/AN10/SIN4_1/INT05_1/MAD18_1 42 P19/AN09/SCK2_2/MAD17_1 41 P18/AN08/SOT2_2/MAD16_1 40 AVSS 39 AVRH 38 AVCC 37 P17/AN07/SIN2_2/INT04_1/MAD15_1 36 P16/AN06/SCK0_1/MAD14_1 35 P15/AN05/SOT0_1/MAD13_1 34 P14/AN04/SIN0_1/INT03_1/MAD12_1 33 P13/AN03/SCK1_1/RTCCO_1/SUBOUT_1/MAD11_1 32 P12/AN02/SOT1_1/MAD10_1 31 P11/AN01/SIN1_1/INT02_1/WKUP1/MAD09_1
P3E/TIOA4_1 1 P3F/TIOA5_1 2
VSS 3 VCC 4 P40/TIOA0_0/INT12_1 5 P41/TIOA1_0/INT13_1 6 P42/TIOA2_0 7 P43/TIOA3_0/ADTG_7 8 P44/TIOA4_0/MAD00_1 9 P45/TIOA5_0/MAD01_1 10
C 11 VSS 12 VCC 13 P46/X0A 14 P47/X1A 15 INITX 16 P48/INT14_1/SIN3_2/MAD02_1 17 P49/TIOB0_0/SOT3_2/MAD03_1 18 P4A/TIOB1_0/SCK3_2/MAD04_1 19 P4B/TIOB2_0/MAD05_1 20 P4C/TIOB3_0/SCK7_1/CEC0/MAD06_1 21 P4D/TIOB4_0/SOT7_1/MAD07_1 22 P4E/TIOB5_0/INT06_2/SIN7_1/MAD08_1 23 PE0/MD1 24 MD0 25 PE2/X0 26 PE3/X1 27 VSS 28 VCC 29 P10/AN00 30
Note:
- The number after the underscore ("_") in pin names such as XXX_1 and XXX_2 indicates the relocated port number. For these
pins, there are multiple pins that provide the same function for the same channel. Use the extended port function register (EPFR) to select the pin.
Document Number: 002-05635 Rev. *C
Page 10 of 126
LQH080/ LQJ080
(TOP VIEW)
CY9A340NB Series
80 VSS 79 P81/UDP0 78 P80/UDM0 77 VCC 76 P60/SIN5_0/TIOA2_2/INT15_1/WKUP3/CEC1/MRDY_1 75 P61/SOT5_0/TIOB2_2/UHCONX 74 P62/SCK5_0/ADTG_3/MOEX_1 73 P63/INT03_0/MWEX_1 72 P0F/NMIX/CROUT_1/RTCCO_0/SUBOUT_0/WKUP0 71 P0E/CTS4_0/TIOB3_2/MDQM1_1 70 P0D/RTS4_0/TIOA3_2/MDQM0_1 69 P0C/SCK4_0/TIOA6_1/MALE_1 68 P0B/SOT4_0/TIOB6_1/MCSX0_1 67 P0A/SIN4_0/INT00_2/MCSX1_1 66 P07/AN22/ADTG_0/MCLKOUT_1 65 P04/TDO/SWO 64 P03/TMS/SWDIO 63 P02/TDI/MCSX6_1 62 P01/TCK/SWCLK 61 P00/TRSTX/MCSX7_1
VCC 1 P50/INT00_0/SIN3_1/MADATA00_1 2 P51/INT01_0/SOT3_1/MADATA01_1 3 P52/INT02_0/SCK3_1/MADATA02_1 4 P53/SIN6_0/TIOA1_2/INT07_2/MADATA03_1 5 P54/SOT6_0/TIOB1_2/MADATA04_1 6 P55/SCK6_0/ADTG_1/MADATA05_1 7
P56/INT08_2/MADATA06_1 8 P30/TIOB0_1/INT03_2/MADATA07_1 9 P31/TIOB1_1/SCK6_1/INT04_2/MADATA08_1 10 P32/TIOB2_1/SOT6_1/INT05_2/MADATA09_1 11 P33/INT04_0/TIOB3_1/SIN6_1/ADTG_6/MADATA10_1 12
P39/ADTG_2 13 P3A/TIOA0_1/RTCCO_2/SUBOUT_2 14
P3B/TIOA1_1 15 P3C/TIOA2_1 16 P3D/TIOA3_1 17 P3E/TIOA4_1 18 P3F/TIOA5_1 19
VSS 20
LQFP - 80
60 P20/AN19/INT05_0/CROUT_0/MAD24_1 59 P21/AN18/SIN0_0/INT06_1/WKUP2 58 P22/AN17/SOT0_0/TIOB7_1 57 P23/AN16/SCK0_0/TIOA7_1 56 P1B/AN11/SOT4_1/MAD19_1 55 P1A/AN10/SIN4_1/INT05_1/MAD18_1 54 P19/AN09/SCK2_2/MAD17_1 53 P18/AN08/SOT2_2/MAD16_1 52 AVSS 51 AVRH 50 AVCC 49 P17/AN07/SIN2_2/INT04_1/MAD15_1 48 P16/AN06/SCK0_1/MAD14_1 47 P15/AN05/SOT0_1/MAD13_1 46 P14/AN04/SIN0_1/INT03_1/MAD12_1 45 P13/AN03/SCK1_1/RTCCO_1/SUBOUT_1/MAD11_1 44 P12/AN02/SOT1_1/MAD10_1 43 P11/AN01/SIN1_1/INT02_1/WKUP1/MAD09_1 42 P10/AN00 41 VCC
P44/TIOA4_0/MAD00_1 21 P45/TIOA5_0/MAD01_1 22
C 23 VSS 24 VCC 25 P46/X0A 26 P47/X1A 27 INITX 28 P48/INT14_1/SIN3_2/MAD02_1 29 P49/TIOB0_0/SOT3_2/MAD03_1 30 P4A/TIOB1_0/SCK3_2/MAD04_1 31 P4B/TIOB2_0/MAD05_1 32 P4C/TIOB3_0/SCK7_1/CEC0/MAD06_1 33 P4D/TIOB4_0/SOT7_1/MAD07_1 34 P4E/TIOB5_0/INT06_2/SIN7_1/MAD08_1 35 PE0/MD1 36 MD0 37 PE2/X0 38 PE3/X1 39 VSS 40
Note:
- The number after the underscore ("_") in pin names such as XXX_1 and XXX_2 indicates the relocated port number. For these
pins, there are multiple pins that provide the same function for the same channel. Use the extended port function register (EPFR) to select the pin.
Document Number: 002-05635 Rev. *C
Page 11 of 126
LQD064/ LQG064
(TOP VIEW)
CY9A340NB Series
64 VSS 63 P81/UDP0 62 P80/UDM0 61 VCC 60 P60/SIN5_0/TIOA2_2/INT15_1/WKUP3/CEC1 59 P61/SOT5_0/TIOB2_2/UHCONX 58 P62/SCK5_0/ADTG_3 57 P0F/NMIX/CROUT_1/RTCCO_0/SUBOUT_0/WKUP0 56 P0C/SCK4_0/TIOA6_1 55 P0B/SOT4_0/TIOB6_1 54 P0A/SIN4_0/INT00_2 53 P04/TDO/SWO 52 P03/TMS/SWDIO 51 P02/TDI 50 P01/TCK/SWCLK 49 P00/TRSTX
VCC 1 P50/INT00_0/SIN3_1 2 P51/INT01_0/SOT3_1 3 P52/INT02_0/SCK3_1 4 P30/TIOB0_1/INT03_2 5 P31/TIOB1_1/SCK6_1/INT04_2 6 P32/TIOB2_1/SOT6_1/INT05_2 7 P33/INT04_0/TIOB3_1/SIN6_1/ADTG_6 8
P39/ADTG_2 9 P3A/TIOA0_1/RTCCO_2/SUBOUT_2 10
P3B/TIOA1_1 11 P3C/TIOA2_1 12 P3D/TIOA3_1 13 P3E/TIOA4_1 14 P3F/TIOA5_1 15
VSS 16
LQFP - 64
48 P21/AN18/SIN0_0/INT06_1/WKUP2 47 P22/AN17/SOT0_0/TIOB7_1 46 P23/AN16/SCK0_0/TIOA7_1 45 P19/AN09/SCK2_2 44 P18/AN08/SOT2_2 43 AVSS 42 AVRH 41 AVCC 40 P17/AN07/SIN2_2/INT04_1 39 P15/AN05 38 P14/AN04/INT03_1 37 P13/AN03/SCK1_1/RTCCO_1/SUBOUT_1 36 P12/AN02/SOT1_1 35 P11/AN01/SIN1_1/INT02_1/WKUP1 34 P10/AN00 33 VCC
C 17 VCC 18 P46/X0A 19 P47/X1A 20 INITX 21 P49/TIOB0_0 22 P4A/TIOB1_0 23 P4B/TIOB2_0 24 P4C/TIOB3_0/SCK7_1/CEC0 25 P4D/TIOB4_0/SOT7_1 26 P4E/TIOB5_0/INT06_2/SIN7_1 27 PE0/MD1 28 MD0 29 PE2/X0 30 PE3/X1 31 VSS 32
Note:
- The number after the underscore ("_") in pin names such as XXX_1 and XXX_2 indicates the relocated port number. For these
pins, there are multiple pins that provide the same function for the same channel. Use the extended port function register (EPFR) to select the pin.
Document Number: 002-05635 Rev. *C
Page 12 of 126
VNC064
(TOP VIEW)
CY9A340NB Series
64 VSS 63 P81/UDP0 62 P80/UDM0 61 VCC 60 P60/SIN5_0/TIOA2_2/INT15_1/WKUP3/CEC1 59 P61/SOT5_0/TIOB2_2/UHCONX 58 P62/SCK5_0/ADTG_3 57 P0F/NMIX/CROUT_1/RTCCO_0/SUBOUT_0/WKUP0 56 P0C/SCK4_0/TIOA6_1 55 P0B/SOT4_0/TIOB6_1 54 P0A/SIN4_0/INT00_2 53 P04/TDO/SWO 52 P03/TMS/SWDIO 51 P02/TDI 50 P01/TCK/SWCLK 49 P00/TRSTX
VCC 1 P50/INT00_0/SIN3_1 2 P51/INT01_0/SOT3_1 3 P52/INT02_0/SCK3_1 4 P30/TIOB0_1/INT03_2 5 P31/TIOB1_1/SCK6_1/INT04_2 6 P32/TIOB2_1/SOT6_1/INT05_2 7 P33/INT04_0/TIOB3_1/SIN6_1/ADTG_6 8
P39/ADTG_2 9 P3A/TIOA0_1/RTCCO_2/SUBOUT_2 10
P3B/TIOA1_1 11 P3C/TIOA2_1 12 P3D/TIOA3_1 13 P3E/TIOA4_1 14 P3F/TIOA5_1 15
VSS 16
QFN - 64
48 P21/AN18/SIN0_0/INT06_1/WKUP2 47 P22/AN17/SOT0_0/TIOB7_1 46 P23/AN16/SCK0_0/TIOA7_1 45 P19/AN09/SCK2_2 44 P18/AN08/SOT2_2 43 AVSS 42 AVRH 41 AVCC 40 P17/AN07/SIN2_2/INT04_1 39 P15/AN05 38 P14/AN04/INT03_1 37 P13/AN03/SCK1_1/RTCCO_1/SUBOUT_1 36 P12/AN02/SOT1_1 35 P11/AN01/SIN1_1/INT02_1/WKUP1 34 P10/AN00 33 VCC
C 17 VCC 18 P46/X0A 19 P47/X1A 20 INITX 21 P49/TIOB0_0 22 P4A/TIOB1_0 23 P4B/TIOB2_0 24 P4C/TIOB3_0/SCK7_1/CEC0 25 P4D/TIOB4_0/SOT7_1 26 P4E/TIOB5_0/INT06_2/SIN7_1 27 PE0/MD1 28 MD0 29 PE2/X0 30 PE3/X1 31 VSS 32
Note:
- The number after the underscore ("_") in pin names such as XXX_1 and XXX_2 indicates the relocated port number. For these
pins, there are multiple pins that provide the same function for the same channel. Use the extended port function register (EPFR) to select the pin.
Document Number: 002-05635 Rev. *C
Page 13 of 126
CY9A340NB Series
LBC112
(TOP VIEW)
1
2
3
4
5
6
7
8
9
10
11
A
VSS UDP0 UDM0 VCC
P0E
P0B
TMS/
AN22 SWDIO TRSTX VCC
VSS
B
VCC VSS
P52
P61
P0F
P0C
AN23
TDO/ SWO
TCK/ SWCLK
VSS
TDI
C
P50
P51
VSS
P60
P62
P0D
P09 AN20 VSS AN19 AN18
D
P53
P54
P55
VSS
P56
P63
P0A VSS AN21 AN16 AN15
E
P30
P31
P32
P33 Index
AN17 AN14 AN12 AN11
F
P34
P35
P36
P39
AN13 AN10 AN09 AVRH
G
P37
P38
P3A
P3D
AN08 AN07 AN06 AVSS
H
P3B
P3C
P3E
VSS
P44
P4C AN05 VSS AN04 AN03 AVCC
J
VCC
P3F
VSS
P40
P43
P49
P4D AN02 VSS AN01 AN00
K
VCC VSS
X1A
INITX P42
P48
P4B
P4E
MD1 VSS VCC
L
VSS
C
X0A
VSS
P41
P45
P4A MD0
X0
X1
VSS
PFBGA - 112
Note:
- The number after the underscore ("_") in pin names such as XXX_1 and XXX_2 indicates the relocated port number. For these
pins, there are multiple pins that provide the same function for the same channel. Use the extended port function register (EPFR) to select the pin.
Document Number: 002-05635 Rev. *C
Page 14 of 126
CY9A340NB Series
FDG096
(TOP VIEW)
1
2
3
4
5
6
7
8
9
10
11
A
TMS/
VSS UDP0 UDM0 VCC VSS
P0F
VSS AN22 SWDIO TRSTX VSS
B
VCC VSS
P52
P61
P63
P0D
P0C
TDO/ SWO
TCK/ SWCLK
VSS
TDI
C
P50
P51
VSS
P60
P62
P0E
P0B
P0A
VSS AN19 AN18
D
P53
P54
P55 Index
AN17 AN16 VSS
E
P56
P30
P31
AN11 AN10 AN09
F
VSS VSS VSS
AN08 AN07 AVRH
G
P32
P33
P39
AN06 AN05 AVSS
H
P3A P3B P3C
AN04 AN03 AVCC
J
P3D
P3E
VSS
P3F
P48
P4A
P4D AN02 VSS AN01 AN00
K
VCC VSS
X1A
INITX P45
P49
P4C
P4E
MD1 VSS VCC
L
VSS
C
X0A VSS P44 VSS P4B MD0
X0
X1
VSS
Note:
PFBGA - 96
- The number after the underscore ("_") in pin names such as XXX_1 and XXX_2 indicates the relocated port number. For these
pins, there are multiple pins that provide the same function for the same channel. Use the extended port function register
(EPFR) to select the pin.
Document Number: 002-05635 Rev. *C
Page 15 of 126
CY9A340NB Series
4. List of Pin Functions
List of Pin Numbers
The number after the underscore ("_") in pin names such as XXX_1 and XXX_2 indicates the relocated port number. For these pins, there are multiple pins that provide the same function for the same channel. Use the extended port function register (EPFR) to select the pin.
Pin No
LQFP-100 QFP-100 BGA-112 LQFP-80 BGA-96
LQFP-64 QFN-64
Pin Name
I/O Circuit Type
Pin State Type
1
79
B1
1
B1
1
VCC
-
P50
2
INT00_0
2
80
C1
2
C1
E
L
SIN3_1
-
MADATA00_1
P51
3
INT01_0
3
81
C2
3
C2
SOT3_1
E
L
(SDA3_1)
-
MADATA01_1
P52
4
INT02_0
4
82
B3
4
B3
SCK3_1
E
L
(SCL3_1)
-
MADATA02_1
P53
SIN6_0
5
83
D1
5
D1
-
TIOA1_2
E
L
INT07_2
MADATA03_1
P54
6
84
D2
6
D2
-
SOT6_0
(SDA6_0)
E
K
TIOB1_2
MADATA04_1
Document Number: 002-05635 Rev. *C
Page 16 of 126
CY9A340NB Series
Pin No LQFP-100 QFP-100 BGA-112 LQFP-80 BGA-96
7
85
D3
7
D3
8
86
D5
8
E1
9
87
E1
9
E2
10
88
E2
10
E3
11
89
E3
11
G1
12
90
E4
12
G2
13
91
F1
-
-
14
92
F2
-
-
LQFP-64 QFN-64 -
5 6 7 8 -
-
Pin Name
P55 SCK6_0 (SCL6_0) ADTG_1 MADATA05_1 P56 INT08_2 MADATA06_1 P30 TIOB0_1 INT03_2 MADATA07_1 P31 TIOB1_1 SCK6_1 (SCL6_1) INT04_2 MADATA08_1 P32 TIOB2_1 SOT6_1 (SDA6_1) INT05_2 MADATA09_1 P33 INT04_0 TIOB3_1 SIN6_1 ADTG_6 MADATA10_1 P34 TIOB4_1 MADATA11_1 P35 TIOB5_1 INT08_1 MADATA12_1
I/O Circuit Type
Pin State Type
E
K
E
L
E
L
E
L
E
L
E
L
E
K
E
L
Document Number: 002-05635 Rev. *C
Page 17 of 126
CY9A340NB Series
LQFP-100
15 -
16
17
18
19
20 21 22 23 24 25 26
QFP-100
93 -
94
95
96
97
98 99 100 1 2 3 4
Pin No BGA-112 LQFP-80
F3
-
-
-
-
-
-
-
G1
-
G2
-
F4
13
G3
14
H1
15
H2
16
G4
17
B2
-
H3
18
J2
19
L1
20
J1
-
BGA-96
F1 F2 F3
-
-
G3
H1
H2 H3 J1 B2 J2 J4 L1 -
LQFP-64 QFN-64 -
-
-
9
10
11 12 13 14 15 16 -
Pin Name
P36 SIN5_2 INT09_1 MADATA13_1 VSS VSS VSS P37 SOT5_2 (SDA5_2) INT10_1 MADATA14_1 P38 SCK5_2 (SCL5_2) INT11_1 MADATA15_1 P39 ADTG_2 P3A TIOA0_1 RTCCO_2 SUBOUT_2 P3B TIOA1_1 P3C TIOA2_1 P3D TIOA3_1 VSS P3E TIOA4_1 P3F TIOA5_1 VSS VCC
I/O Circuit Type
E -
E
E
E
E
E E E E E -
Pin State Type
L
L
L K K K K K K K
Document Number: 002-05635 Rev. *C
Page 18 of 126
CY9A340NB Series
LQFP-100 27
28
29
30
31
32 33 34 35 36 37 38
39
40
QFP-100 5
6
7
8
9
10 11 12 13 14 15 16
17
18
Pin No BGA-112 LQFP-80 BGA-96
J4
-
-
L5
-
-
K5
-
-
J5
-
-
H5
21
L5
L6
22
K5
K2
-
K2
J3
-
J3
H4
-
-
-
-
L6
L2
23
L2
L4
24
L4
K1
25
K1
L3
26
L3
K3
27
K3
K4
28
K4
K6
29
J5
J6
30
K6
LQFP-64 QFN-64 -
-
-
-
-
17 18 19 20 21
-
22
-
Pin Name
P40 TIOA0_0 INT12_1 P41 TIOA1_0 INT13_1 P42 TIOA2_0 P43 TIOA3_0 ADTG_7 P44 TIOA4_0 MAD00_1 P45 TIOA5_0 MAD01_1 VSS VSS VSS VSS C VSS VCC P46 X0A P47 X1A INITX P48 INT14_1 SIN3_2 MAD02_1 P49 TIOB0_0 SOT3_2 (SDA3_2) MAD03_1
I/O Circuit Type
E
E
E
E
E
E D D B
E
E
Pin State Type
L L K K K K
F G C L
K
Document Number: 002-05635 Rev. *C
Page 19 of 126
CY9A340NB Series
Pin No LQFP-100 QFP-100 BGA-112 LQFP-80 BGA-96
41
19
L7
31
J6
42
20
K7
32
L7
43
21
H6
33
K7
44
22
J7
34
J7
45
23
K8
35
K8
46
24
K9
36
K9
47
25
L8
37
L8
48
26
L9
38
L9
49
27
L10
39
L10
50
28
L11
40
L11
51
29
K11
41
K11
52
30
J11
42
J11
53
31
J10
43
J10
LQFP-64 QFN-64 23 24 -
25
26 -
27
28 29 30 31 32 33 34
35
-
Pin Name
P4A TIOB1_0 SCK3_2 (SCL3_2) MAD04_1 P4B TIOB2_0 MAD05_1 P4C TIOB3_0 SCK7_1 (SCL7_1) CEC0 MAD06_1 P4D TIOB4_0 SOT7_1 (SDA7_1) MAD07_1 P4E TIOB5_0 INT06_2 SIN7_1 MAD08_1 MD1 PE0 MD0 X0 PE2 X1 PE3 VSS VCC P10 AN00 P11 AN01 SIN1_1 INT02_1 WKUP1 MAD09_1
I/O Circuit Type
E
E
I
I
I
C G A A F
F
Pin State Type
K K
S
K
L E D A B
M
R
Document Number: 002-05635 Rev. *C
Page 20 of 126
CY9A340NB Series
LQFP-100 54 55
56
57
58
59 60 61 62
QFP-100 32 33
34
35
36
37 38 39 40
Pin No BGA-112 LQFP-80 BGA-96
J8
44
J8
K10
-
K10
J9
-
J9
H10
45
H10
H9
46
H9
H7
47
G10
G10
48
G9
G9
49
F10
H11
50
H11
F11
51
F11
G11
52
G11
LQFP-64 QFN-64 36 -
37
38 39 -
-
40 41 42 43
Pin Name
P12 AN02 SOT1_1 (SDA1_1) MAD10_1 VSS VSS P13 AN03 SCK1_1 (SCL1_1) RTCCO_1 SUBOUT_1 MAD11_1 P14 AN04 INT03_1 SIN0_1 MAD12_1 P15 AN05 SOT0_1 (SDA0_1) MAD13_1 P16 AN06 SCK0_1 (SCL0_1) MAD14_1 P17 AN07 SIN2_2 INT04_1 MAD15_1 AVCC AVRH AVSS
I/O Circuit Type
F -
F
F
F
F
F -
Pin State Type
M
M
N M M N
Document Number: 002-05635 Rev. *C
Page 21 of 126
CY9A340NB Series
LQFP-100 63 64 65
66 67 68 69 70
Pin No QFP-100 BGA-112 LQFP-80 BGA-96
41
G8
53
F9
42
F10
54
E11
-
H8
-
-
43
F9
55
E10
44
E11
56
E9
45
E10
-
-
46
F8
-
-
47
E9
-
-
48
D11
-
-
LQFP-64 QFN-64 44 45 -
-
-
-
-
-
Pin Name
P18 AN08 SOT2_2 (SDA2_2) MAD16_1 P19 AN09 SCK2_2 (SCL2_2) MAD17_1 VSS P1A AN10 SIN4_1 INT05_1 MAD18_1 P1B AN11 SOT4_1 (SDA4_1) MAD19_1 P1C AN12 SCK4_1 (SCL4_1) MAD20_1 P1D AN13 CTS4_1 MAD21_1 P1E AN14 RTS4_1 MAD22_1 P1F AN15 ADTG_5 MAD23_1
I/O Circuit Type
F
F F
F
F F F F
Pin State Type
M M
N M M M M M
Document Number: 002-05635 Rev. *C
Page 22 of 126
CY9A340NB Series
LQFP-100 71
72
73
74 75 76 77 78 79 80 81
Pin No QFP-100 BGA-112 LQFP-80 BGA-96
-
B10
-
B10
-
C9
-
C9
-
-
-
D11
49
D10
57
D10
50
E8
58
D9
51
C11
59
C11
52
C10
60
C10
53
A11
-
A11
54
A10
-
-
55
A9
61
A10
56
B9
62
B9
57
B11
63
B11
58
A8
64
A9
59
B8
65
B8
LQFP-64 QFN-64 -
46
47
48
-
49 50 51 52
53
Pin Name
VSS VSS VSS P23 AN16 SCK0_0 (SCL0_0) TIOA7_1 P22 AN17 SOT0_0 (SDA0_0) TIOB7_1 P21 AN18 SIN0_0 INT06_1 WKUP2 P20 AN19 INT05_0 CROUT_0 MAD24_1 VSS VCC P00 TRSTX MCSX7_1 P01 TCK SWCLK P02 TDI MCSX6_1 P03 TMS SWDIO P04 TDO SWO
I/O Circuit Type
F
F
F
F E E E E E
Pin State Type
M M
R
N
J J J J J
Document Number: 002-05635 Rev. *C
Page 23 of 126
CY9A340NB Series
LQFP-100 82 83
84 85 86 87
QFP-100 60 61
62 63 64 65
Pin No BGA-112 LQFP-80
C8
-
D8
-
D9
-
66 A7
-
-
-
B7
-
C7
-
D7
67
BGA-96 -
A8 A7 -
C8
LQFP-64 QFN-64 -
-
54 -
Pin Name
P05 AN20 TRACED0 TIOA5_2 SIN4_2 INT00_1 MCSX5_1 VSS P06 AN21 TRACED1 TIOB5_2 SOT4_2 (SDA4_2) INT01_1 MCSX4_1 P07 AN22 ADTG_0 MCLKOUT_ 1 TRACED2 SCK4_2 (SCL4_2) VSS P08 AN23 TRACED3 TIOA0_2 CTS4_2 MCSX3_1 P09 TRACECLK TIOB0_2 RTS4_2 MCSX2_1 P0A SIN4_0 INT00_2 MCSX1_1
I/O Circuit Type
F F
F F
E I
Pin State Type
Q
Q
P
P O L
Document Number: 002-05635 Rev. *C
Page 24 of 126
CY9A340NB Series
Pin No LQFP-100 QFP-100 BGA-112 LQFP-80
88
66
A6
68
89
67
B6
69
-
-
D4
-
-
-
C3
-
90
68
C6
70
91
69
A5
71
-
-
-
-
92
70
B5
72
93
71
D6
73
94
72
C5
74
95
73
B4
75
BGA-96
LQFP-64 QFN-64
55 C7
-
56 B7
-
-
-
C3
-
B6
-
C6
-
A5
-
A6
57
B5
-
58 C5
-
B4
59
Pin Name
P0B SOT4_0 (SDA4_0) TIOB6_1 MCSX0_1
P0C SCK4_0 (SCL4_0) TIOA6_1 MALE_1
VSS VSS P0D RTS4_0 TIOA3_2 MDQM0_1 P0E CTS4_0 TIOB3_2 MDQM1_1 VSS P0F NMIX CROUT_1 RTCCO_0 SUBOUT_0 WKUP0 P63 INT03_0 MWEX_1 P62 SCK5_0 (SCL5_0) ADTG_3 MOEX_1 P61 SOT5_0 (SDA5_0) TIOB2_2 UHCONX
I/O Circuit Type
Pin State Type
I
K
I
K
-
E
K
E
K
-
E
I
E
L
E
K
E
K
Document Number: 002-05635 Rev. *C
Page 25 of 126
CY9A340NB Series
LQFP-100
96
97 98 99 100
Pin No QFP-100 BGA-112 LQFP-80 BGA-96
74
C4
76
C4
75
A4
77
A4
76
A3
78
A3
77
A2
79
A2
78
A1
80
A1
LQFP-64 QFN-64
60
61 62 63 64
Pin Name
P60 SIN5_0 TIOA2_2 INT15_1 WKUP3 CEC1 MRDY_1 VCC P80 UDM0 P81 UDP0 VSS
I/O Circuit Type
Pin State Type
I
T
-
H
H
H
H
-
Document Number: 002-05635 Rev. *C
Page 26 of 126
CY9A340NB Series
List of pin functions
The number after the underscore ("_") in pin names such as XXX_1 and XXX_2 indicates the relocated port number. For these pins, there are multiple pins that provide the same function for the same channel. Use the extended port function register (EPFR) to select the pin.
Pin Function
Pin Name
ADC
ADTG_0 ADTG_1
Function Description
LQFP100
84 7
QFP100
62 85
Pin No
BGA- LQFP- BGA-
112
80
96
A7
66
A8
D3
7
D3
LQFP/ QFN-
64
-
-
ADTG_2
18
96
F4
13
G3
9
ADTG_3
94
72
C5
74
C5
58
ADTG_4
A/D converter external trigger input pin
-
-
-
-
-
-
ADTG_5
70
48
D11
-
-
-
ADTG_6 ADTG_7 ADTG_8 AN00 AN01
12
90
E4
12
G2
8
30
8
J5
-
-
-
-
-
-
-
-
-
52
30
J11
42
J11
34
53
31
J10
43
J10
35
AN02 AN03 AN04 AN05 AN06 AN07 AN08 AN09 AN10
54
32
J8
44
J8
36
55
33
H10
45
H10
37
56
34
H9
46
H9
38
57
35
H7
47
G10
39
58
36
G10
48
G9
-
59
37
G9
49
F10
40
63
41
G8
53
F9
44
64
42
F10
54
E11
45
65
43
F9
55
E10
-
AN11 AN12 AN13 AN14 AN15
A/D converter analog input pin. 66
44
E11
56
E9
-
ANxx describes ADC ch.xx.
67
45
E10
-
-
-
68
46
F8
-
-
-
69
47
E9
-
-
-
70
48
D11
-
-
-
AN16 AN17 AN18 AN19
71
49
D10
57
D10
46
72
50
E8
58
D9
47
73
51
C11
59
C11
48
74
52
C10
60
C10
-
AN20 AN21 AN22 AN23
82
60
C8
-
-
-
83
61
D9
-
-
-
84
62
A7
66
A8
-
85
63
B7
-
-
-
Document Number: 002-05635 Rev. *C
Page 27 of 126
CY9A340NB Series
Pin Function
Pin Name
Function Description
Base Timer 0
Base Timer 1
Base Timer 2
Base Timer 3
Base Timer 4
Base Timer 5
Base Timer 6 Base Timer 7
TIOA0_0 TIOA0_1 TIOA0_2 TIOB0_0 TIOB0_1 TIOB0_2 TIOA1_0 TIOA1_1 TIOA1_2 TIOB1_0 TIOB1_1 TIOB1_2 TIOA2_0 TIOA2_1 TIOA2_2 TIOB2_0 TIOB2_1 TIOB2_2 TIOA3_0 TIOA3_1 TIOA3_2 TIOB3_0 TIOB3_1 TIOB3_2 TIOA4_0 TIOA4_1 TIOA4_2 TIOB4_0 TIOB4_1 TIOB4_2 TIOA5_0 TIOA5_1 TIOA5_2 TIOB5_0 TIOB5_1 TIOB5_2 TIOA6_1 TIOB6_1 TIOA7_0 TIOA7_1 TIOA7_2 TIOB7_0 TIOB7_1 TIOB7_2
Base timer ch.0 TIOA pin Base timer ch.0 TIOB pin Base timer ch.1 TIOA pin Base timer ch.1 TIOB pin Base timer ch.2 TIOA pin Base timer ch.2 TIOB pin Base timer ch.3 TIOA pin Base timer ch.3 TIOB pin Base timer ch.4 TIOA pin Base timer ch.4 TIOB pin Base timer ch.5 TIOA pin Base timer ch.5 TIOB pin Base timer ch.6 TIOA pin Base timer ch.6 TIOB pin Base timer ch.7 TIOA pin Base timer ch.7 TIOB pin
Document Number: 002-05635 Rev. *C
LQFP100
27 19 85 40 9 86 28 20 5 41 10 6 29 21 96 42 11 95 30 22 90 43 12 91 31 23 44 13 32 24 82 45 14 83 89 88 71 72 -
QFP100
5 97 63 18 87 64 6 98 83 19 88 84 7 99 74 20 89 73 8 100 68 21 90 69 9 1 22 91 10 2 60 23 92 61 67 66 49 50 -
Pin No
BGA- LQFP-
112
80
J4
-
G3
14
B7
-
J6
30
E1
9
C7
-
L5
-
H1
15
D1
5
L7
31
E2
10
D2
6
K5
-
H2
16
C4
76
K7
32
E3
11
B4
75
J5
-
G4
17
C6
70
H6
33
E4
12
A5
71
H5
21
H3
18
-
-
J7
34
F1
-
-
-
L6
22
J2
19
C8
-
K8
35
F2
-
D9
-
B6
69
A6
68
-
-
D10
57
-
-
-
-
E8
58
-
-
BGA96
H1 K6 E2 H2 D1 J6 E3 D2 H3 C4 L7 G1 B4 J1 B6 K7 G2 C6 L5 J2 J7 K5 J4 K8 B7 C7 D10 D9 -
LQFP/ QFN-
64 10 22 5 11 23 6 12 60 24 7 59 13 25 8 14 26 15 27 56 55 46 47 -
Page 28 of 126
CY9A340NB Series
Pin Function Debugger
External Bus
Pin Name
SWCLK
SWDIO
SWO TCK TDI TDO
TMS
TRACECLK TRACED0 TRACED1 TRACED2 TRACED3 TRSTX MAD00_1 MAD01_1 MAD02_1 MAD03_1 MAD04_1 MAD05_1 MAD06_1 MAD07_1 MAD08_1 MAD09_1 MAD10_1 MAD11_1 MAD12_1 MAD13_1 MAD14_1 MAD15_1 MAD16_1 MAD17_1 MAD18_1 MAD19_1 MAD20_1 MAD21_1 MAD22_1 MAD23_1 MAD24_1
Function Description Serial wire debug interface clock input pin Serial wire debug interface data input / output pin Serial wire viewer output pin JTAG test clock input pin JTAG test data input pin JTAG debug data output pin JTAG test mode state input/output pin Trace CLK output pin of ETM
Trace data output pins of ETM
JTAG test reset input pin
External bus interface address bus
LQFP100
78
80
81 78 79 81
80
86 82 83 84 85 77 31 32 39 40 41 42 43 44 45 53 54 55 56 57 58 59 63 64 65 66 67 68 69 70 74
QFP100
56
58
59 56 57 59
58
64 60 61 62 63 55 9 10 17 18 19 20 21 22 23 31 32 33 34 35 36 37 41 42 43 44 45 46 47 48 52
Pin No
BGA- LQFP-
112
80
BGA96
B9
62
B9
A8
64
A9
B8
65
B8
B9
62
B9
B11
63
B11
B8
65
B8
A8
64
A9
C7
-
-
C8
-
-
D9
-
-
A7
-
-
B7
-
-
A9
61
A10
H5
21
L5
L6
22
K5
K6
29
J5
J6
30
K6
L7
31
J6
K7
32
L7
H6
33
K7
J7
34
J7
K8
35
K8
J10
43
J10
J8
44
J8
H10
45
H10
H9
46
H9
H7
47
G10
G10
48
G9
G9
49
F10
G8
53
F9
F10
54
E11
F9
55
E10
E11
56
E9
E10
-
-
F8
-
-
E9
-
-
D11
-
-
C10
60
C10
LQFP/ QFN-
64
50
52
53 50 51 53
52
49 -
Document Number: 002-05635 Rev. *C
Page 29 of 126
CY9A340NB Series
Pin Function
Pin Name
External Bus
MCSX0_1 MCSX1_1 MCSX2_1 MCSX3_1 MCSX4_1 MCSX5_1 MCSX6_1 MCSX7_1 MDQM0_1 MDQM1_1
MOEX_1
MWEX_1
MADATA00_1 MADATA01_1 MADATA02_1 MADATA03_1 MADATA04_1 MADATA05_1 MADATA06_1 MADATA07_1 MADATA08_1 MADATA09_1 MADATA10_1 MADATA11_1 MADATA12_1 MADATA13_1 MADATA14_1 MADATA15_1
MALE_1
MRDY_1
MCLKOUT_1
Function Description
External bus interface chip select output pin
External bus interface byte mask signal output pin External bus interface read enable signal for SRAM External bus interface write enable signal for SRAM
External bus interface data bus
Address Latch enable signal for multiplex External RDY input signal External bus clock output pin
LQFP100
88 87 86 85 83 82 79 77 90 91
94
93
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
89
96
84
QFP100
66 65 64 63 61 60 57 55 68 69
72
71
80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95
67
74
62
Pin No
BGA- LQFP-
112
80
BGA96
A6
68
C7
D7
67
C8
C7
-
-
B7
-
-
D9
-
-
C8
-
-
B11
63
B11
A9
61
A10
C6
70
B6
A5
71
C6
C5
74
C5
D6
73
B5
C1
2
C1
C2
3
C2
B3
4
B3
D1
5
D1
D2
6
D2
D3
7
D3
D5
8
E1
E1
9
E2
E2
10
E3
E3
11
G1
E4
12
G2
F1
-
-
F2
-
-
F3
-
-
G1
-
-
G2
-
-
B6
69
B7
C4
76
C4
A7
66
A8
LQFP/ QFN-
64 -
-
-
-
-
-
-
Document Number: 002-05635 Rev. *C
Page 30 of 126
CY9A340NB Series
Pin Function
Pin Name
Function Description
External Interrupt
INT00_0 INT00_1 INT00_2 INT01_0 INT01_1 INT02_0 INT02_1 INT03_0 INT03_1 INT03_2 INT04_0 INT04_1 INT04_2 INT05_0 INT05_1 INT05_2 INT06_1 INT06_2
INT07_2
INT08_1 INT08_2
INT09_1
INT10_1
INT11_1
INT12_1
INT13_1
INT14_1
INT15_1
NMIX
External interrupt request 00 input pin
External interrupt request 01 input pin
External interrupt request 02 input pin
External interrupt request 03 input pin
External interrupt request 04 input pin
External interrupt request 05 input pin
External interrupt request 06 input pin
External interrupt request 07 input pin External interrupt request 08 input pin
External interrupt request 09 input pin External interrupt request 10 input pin External interrupt request 11 input pin External interrupt request 12 input pin External interrupt request 13 input pin External interrupt request 14 input pin External interrupt request 15 input pin Non-Maskable Interrupt input pin
LQFP100
2 82 87 3 83 4 53 93 56 9 12 59 10 74 65 11 73 45
QFP100
80 60 65 81 61 82 31 71 34 87 90 37 88 52 43 89 51 23
5
83
14
92
8
86
15
93
Pin No
BGA- LQFP-
112
80
C1
2
C8
-
D7
67
C2
3
D9
-
B3
4
J10
43
D6
73
H9
46
E1
9
E4
12
G9
49
E2
10
C10
60
F9
55
E3
11
C11
59
K8
35
BGA96
C1 C8 C2 B3 J10 B5 H9 E2 G2 F10 E3 C10 E10 G1 C11 K8
D1
5
D1
F2
-
-
D5
8
E1
F3
-
-
LQFP/ QFN-
64 2 54 3 4 35 38 5 8 40 6 7 48 27
-
-
-
16
94
G1
-
-
-
17
95
G2
-
-
-
27
5
J4
-
-
-
28
6
L5
-
-
-
39
17
K6
29
J5
-
96
74
C4
76
C4
60
92
70
B5
72
A6
57
Document Number: 002-05635 Rev. *C
Page 31 of 126
CY9A340NB Series
Pin Function
Pin Name
Function Description
GPIO
P00
P01
P02
P03
P04
P05
P06
P07
P08
P09
P0A
P0B
P0C
P0D
P0E
P0F
P10
P11
P12
P13
P14
P15
P16
P17
P18
P19
P1A
P1B
P1C
P1D
P1E
P1F
P20
P21
P22
P23
General-purpose I/O port 0 General-purpose I/O port 1 General-purpose I/O port 2
LQFP100
77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 52 53 54 55 56 57 58 59 63 64 65 66 67 68 69 70 74 73 72 71
QFP100
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 30 31 32 33 34 35 36 37 41 42 43 44 45 46 47 48 52 51 50 49
Pin No
BGA- LQFP-
112
80
A9
61
B9
62
B11
63
A8
64
B8
65
C8
-
D9
-
A7
66
B7
-
C7
-
D7
67
A6
68
B6
69
C6
70
A5
71
B5
72
J11
42
J10
43
J8
44
H10
45
H9
46
H7
47
G10
48
G9
49
G8
53
F10
54
F9
55
E11
56
E10
-
F8
-
E9
-
D11
-
C10
60
C11
59
E8
58
D10
57
BGA96
A10 B9 B11 A9 B8 A8 C8 C7 B7 B6 C6 A6 J11 J10 J8 H10 H9 G10 G9 F10 F9 E11 E10 E9 C10 C11 D9 D10
LQFP/ QFN-
64 49 50 51 52 53 54 55 56 57 34 35 36 37 38 39 40 44 45 48 47 46
Document Number: 002-05635 Rev. *C
Page 32 of 126
CY9A340NB Series
Pin Function
Pin Name
Function Description
GPIO
P30
P31
P32
P33
P34
P35
P36
P37
P38
P39
P3A
P3B
P3C
P3D
P3E
P3F
P40
P41
P42
P43
P44
P45
P46
P47
P48
P49
P4A
P4B
P4C
P4D
P4E
P50
P51
P52
P53
P54
P55
P56
P60
P61
P62
P63
P80
P81
PE0
PE2
PE3
General-purpose I/O port 3
General-purpose I/O port 4
General-purpose I/O port 5 General-purpose I/O port 6 General-purpose I/O port 8 General-purpose I/O port E
LQFP100
9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 27 28 29 30 31 32 36 37 39 40 41 42 43 44 45 2 3 4 5 6 7 8 96 95 94 93 98 99 46 48 49
QFP100
87 88 89 90 91 92 93 94 95 96 97 98 99 100 1 2 5 6 7 8 9 10 14 15 17 18 19 20 21 22 23 80 81 82 83 84 85 86 74 73 72 71 76 77 24 26 27
Pin No
BGA- LQFP-
112
80
E1
9
E2
10
E3
11
E4
12
F1
-
F2
-
F3
-
G1
-
G2
-
F4
13
G3
14
H1
15
H2
16
G4
17
H3
18
J2
19
J4
-
L5
-
K5
-
J5
-
H5
21
L6
22
L3
26
K3
27
K6
29
J6
30
L7
31
K7
32
H6
33
J7
34
K8
35
C1
2
C2
3
B3
4
D1
5
D2
6
D3
7
D5
8
C4
76
B4
75
C5
74
D6
73
A3
78
A2
79
K9
36
L9
38
L10
39
BGA96
E2 E3 G1 G2 G3 H1 H2 H3 J1 J2 J4 L5 K5 L3 K3 J5 K6 J6 L7 K7 J7 K8 C1 C2 B3 D1 D2 D3 E1 C4 B4 C5 B5 A3 A2 K9 L9 L10
LQFP/ QFN-
64 5 6 7 8 9 10 11 12 13 14 15 19 20 22 23 24 25 26 27 2 3 4 60 59 58 62 63 28 30 31
Document Number: 002-05635 Rev. *C
Page 33 of 126
CY9A340NB Series
Pin Function
Pin Name
Multifunction Serial 0
SIN0_0 SIN0_1
SOT0_0 (SDA0_0)
SOT0_1 (SDA0_1)
SCK0_0 (SCL0_0)
Multifunction Serial 1
SCK0_1 (SCL0_1) SIN1_1
SOT1_1 (SDA1_1)
SCK1_1 (SCL1_1)
Function Description
LQFP100
Multi-function serial interface 73
ch.0 input pin
56
Multi-function serial interface
ch.0 output pin.
This pin operates as SOT0
72
when it is used in a
UART/CSIO (operation modes
0 to 2) and as SDA0 when it is used in an I2C (operation mode 57
4).
Multi-function serial interface
ch.0 clock I/O pin.
71
This pin operates as SCK0
when it is used in a
UART/CSIO (operation modes
0 to 2) and as SCL0 when it is used in an I2C (operation mode
58
4).
Multi-function serial interface ch.1 input pin
53
Multi-function serial interface
ch.1 output pin.
This pin operates as SOT1
when it is used in a UART/CSIO (operation modes
54
0 to 2) and as SDA1 when it is used in an I2C (operation mode
4).
Multi-function serial interface
ch.1 clock I/O pin.
This pin operates as SCK1
when it is used in a UART/
55
CSIO (operation modes 0 to 2)
and as SCL1 when it is used in an I2C (operation mode 4).
QFP100 51 34 50 35 49 36 31
32
33
Pin No
BGA- LQFP-
112
80
C11
59
H9
46
BGA96
C11 H9
E8
58
D9
H7
47
G10
D10
57
D10
G10
48
G9
J10
43
J10
J8
44
J8
H10
45
H10
LQFP/ QFN-
64 48 47
-
46
35
36
37
Document Number: 002-05635 Rev. *C
Page 34 of 126
CY9A340NB Series
Pin Function
Pin Name
Multifunction Serial 2
SIN2_2
SOT2_2 (SDA2_2)
SCK2_2 (SCL2_2)
Multifunction Serial 3
SIN3_1 SIN3_2
SOT3_1 (SDA3_1)
SOT3_2 (SDA3_2)
Function Description
LQFP100
Multi-function serial interface ch.2 input pin
59
Multi-function serial interface ch.2 output pin.
This pin operates as SOT2
when it is used in a UART/CSIO (operation modes
63
0 to 2) and as SDA2 when it is
used in an I2C (operation mode
4).
Multi-function serial interface
ch.2 clock I/O pin.
This pin operates as SCK2
when it is used in a UART/
64
CSIO (operation modes 0 to 2)
and as SCL2 when it is used in
an I2C (operation mode 4).
Multi-function serial interface 2
ch.3 input pin
39
QFP100 37
41
42 80 17
Multi-function serial interface
ch.3 output pin.
3
81
This pin operates as SOT3
when it is used in a
UART/CSIO (operation modes
0 to 2) and as SDA3 when it is
used in an I2C (operation mode 40
18
4).
Pin No
BGA- LQFP-
112
80
BGA96
G9
49
F10
G8
53
F9
F10
54
E11
C1
2
C1
K6
29
J5
C2
3
C2
J6
30
K6
LQFP/ QFN-
64 40
44
45
2 3
-
SCK3_1 (SCL3_1)
Multi-function serial interface ch.3 clock I/O pin. This pin operates as SCK3
4
82
B3
4
B3
4
when it is used in a UART/
SCK3_2 (SCL3_2)
CSIO (operation modes 0 to 2)
and as SCL3 when it is used in 41 an I2C (operation mode 4).
19
L7
31
J6
-
Document Number: 002-05635 Rev. *C
Page 35 of 126
CY9A340NB Series
Pin Function
Pin Name
Multifunction Serial 4
SIN4_0 SIN4_1 SIN4_2
SOT4_0 (SDA4_0)
SOT4_1 (SDA4_1)
Multifunction Serial 5
SOT4_2 (SDA4_2)
SCK4_0 (SCL4_0)
SCK4_1 (SCL4_1)
SCK4_2 (SCL4_2) RTS4_0 RTS4_1 RTS4_2 CTS4_0 CTS4_1 CTS4_2 SIN5_0 SIN5_2
SOT5_0 (SDA5_0)
SOT5_2 (SDA5_2)
Function Description
Multi-function serial interface ch.4 input pin
LQFP100
87 65 82
QFP100
65 43 60
Multi-function serial interface 88
66
ch.4 output pin.
This pin operates as SOT4
when it is used in a UART/CSIO (operation modes
66
44
0 to 2) and as SDA4 when it is
used in an I2C (operation mode
4).
83
61
Multi-function serial interface 89
67
ch.4 clock I/O pin.
This pin operates as SCK4
when it is used in a UART/
67
45
CSIO (operation modes 0 to 2)
and as SCL4 when it is used in
an I2C (operation mode 4).
84
62
90
68
Multi-function serial interface ch.4 RTS output pin
69
47
86
64
91
69
Multi-function serial interface ch.4 CTS input pin
68
46
85
63
Multi-function serial interface 96
74
ch.5 input pin
15
93
Multi-function serial interface
ch.5 output pin.
95
73
This pin operates as SOT5
when it is used in a
UART/CSIO (operation modes
0 to 2) and as SDA5 when it is
used in an I2C (operation mode 16
94
4).
Pin No
BGA- LQFP-
112
80
D7
67
F9
55
C8
-
BGA96
C8 E10 -
A6
68
C7
E11
56
E9
D9
-
-
B6
69
B7
E10
-
-
A7
-
-
C6
70
B6
E9
-
-
C7
-
-
A5
71
C6
F8
-
-
B7
-
-
C4
76
C4
F3
-
-
B4
75
B4
G1
-
-
LQFP/ QFN-
64 54 55
-
-
56
-
60 -
59
-
SCK5_0 (SCL5_0)
Multi-function serial interface ch.5 clock I/O pin. This pin operates as SCK5
94
72
C5
74
C5
58
when it is used in a UART/
SCK5_2 (SCL5_2)
CSIO (operation modes 0 to 2)
and as SCL5 when it is used in 17 an I2C (operation mode 4).
95
G2
-
-
-
Document Number: 002-05635 Rev. *C
Page 36 of 126
CY9A340NB Series
Pin Function
Pin Name
Multifunction Serial 6
SIN6_0 SIN6_1
SOT6_0 (SDA6_0)
SOT6_1 (SDA6_1)
Function Description
Multi-function serial interface ch.6 input pin
LQFP100
5 12
QFP100
83 90
Multi-function serial interface
ch.6 output pin.
6
84
This pin operates as SOT6
when it is used in a
UART/CSIO (operation modes
0 to 2) and as SDA6 when it is
used in an I2C (operation mode 11
89
4).
Pin No
BGA- LQFP-
112
80
D1
5
E4
12
BGA96
D1 G2
D2
6
D2
E3
11
G1
LQFP/ QFN-
64 8
-
7
SCK6_0 (SCL6_0)
Multi-function serial interface ch.6 clock I/O pin. This pin operates as SCK6
7
85
D3
7
D3
-
when it is used in a UART/
SCK6_1 (SCL6_1)
CSIO (operation modes 0 to 2)
and as SCL6 when it is used in 10 an I2C (operation mode 4).
88
E2
10
E3
6
Multifunction
SIN7_1
Multi-function serial interface ch.7 input pin
45
23
K8
35
K8
27
Serial 7
Multi-function serial interface ch.7 output pin.
This pin operates as SOT7
SOT7_1 (SDA7_1)
when it is used in a UART/CSIO (operation modes
44
22
J7
34
J7
26
0 to 2) and as SDA7 when it is
used in an I2C (operation mode
4).
Multi-function serial interface
ch.7 clock I/O pin.
SCK7_1 (SCL7_1)
This pin operates as SCK7
when it is used in a UART/
43
CSIO (operation modes 0 to 2)
21
H6
33
K7
25
and as SCL7 when it is used in
an I2C (operation mode 4).
Document Number: 002-05635 Rev. *C
Page 37 of 126
CY9A340NB Series
Pin Function
Pin Name
USB
UDM0 UDP0
UHCONX
Real-time clock
RTCCO_0 RTCCO_1
RTCCO_2
SUBOUT_0
SUBOUT_1
SUBOUT_2
Low-Power Consumption
WKUP0
Mode
WKUP1
WKUP2
HDMICEC/ Remote Control Reception Reset
Mode
WKUP3 CEC0 CEC1 INITX
MD0
Power
MD1 VCC
Function Description
LQFP100
USB device/host D � pin
98
USB device/host D + pin
99
USB external pull-up control pin
95
92
0.5 seconds pulse output pin of Real-time clock
55
19
92
Sub clock output pin
55
19
Deep standby mode return signal input pin 0
92
Deep standby mode return signal input pin 1
53
Deep standby mode return signal input pin 2
73
Deep standby mode return signal input pin 3
96
HDMI-CEC/Remote Control Reception ch.0 input/output pin
43
HDMI-CEC/Remote Control Reception ch.1 input/output pin
96
External Reset Input pin. A reset is valid when INITX=L.
38
Mode 0 pin.
During normal operation,
MD0=L must be input. During serial programming to Flash
47
memory, MD0=H must be
input.
Mode 1 pin.
During serial programming to Flash memory, MD1=L must
46
be input.
1
26
35 Power supply Pin
51
76
97
QFP100 76 77 73 70 33 97 70 33 97 70
31
51
74
21
74
16
25
24
79 4 13 29 54 75
Pin No
BGA- LQFP-
112
80
A3
78
A2
79
BGA96
A3 A2
B4
75
B4
B5
72
A6
H10
45
H10
G3
14
H1
B5
72
A6
H10
45
H10
G3
14
H1
B5
72
A6
J10
43
J10
C11
59
C11
C4
76
C4
H6
33
K7
C4
76
C4
K4
28
K4
L8
37
L8
K9
36
K9
B1
1
B1
J1
-
-
K1
25
K1
K11
41
K11
A10
-
-
A4
77
A4
LQFP/ QFN-
64 62 63 59 57 37 10 57 37 10 57
35
48
60
25
60
21
29
28
1 18 33 61
Document Number: 002-05635 Rev. *C
Page 38 of 126
CY9A340NB Series
Pin Function
GND
Pin Name
Function Description
LQFP100
-
QFP100
-
Pin No
BGA- LQFP-
112
80
-
-
BGA96
F1
LQFP/ QFN-
64
-
-
-
-
-
F2
-
-
-
-
-
F3
-
-
-
B2
-
B2
-
25
3
L1
20
L1
16
-
-
K2
-
K2
-
-
-
J3
-
J3
-
-
-
H4
-
-
-
-
-
-
-
L6
-
34
12
L4
24
L4
-
50
28
L11
40
L11
32
VSS
GND Pin
-
-
K10
-
K10
-
-
-
J9
-
J9
-
-
-
H8
-
-
-
-
-
B10
-
B10
-
-
-
C9
-
C9
-
-
-
-
-
D11
-
75
53
A11
-
A11
-
-
-
D8
-
-
-
-
-
-
-
A7
-
-
-
D4
-
-
-
-
-
C3
-
C3
-
-
-
-
-
A5
-
100
78
A1
80
A1
64
Clock
X0
Main clock (oscillation) input pin
48
26
L9
38
L9
30
X0A
Sub clock (oscillation) input pin 36
14
L3
26
L3
19
X1
Main clock (oscillation) I/O pin 49
27
L10
39
L10
31
X1A
Sub clock (oscillation) I/O pin 37
15
K3
27
K3
20
CROUT_0 Built-in high-speed CR-osc
74
52
C10
60
C10
-
CROUT_1 clock output port
92
70
B5
72
A6
57
ADC power
AVCC
A/D converter analog power supply pin
60
38
H11
50
H11
41
AVRH
A/D converter analog reference voltage input pin
61
39
F11
51
F11
42
ADC GND
AVSS
A/D converter GND pin
62
40
G11
52
G11
43
C pin
C
Power supply stabilization capacity pin
33
11
L2
23
L2
17
Note:
- While this device contains a Test Access Port (TAP) based on the IEEE 1149.1-2001 JTAG standard, it is not fully compliant to
all requirements of that standard. This device may contain a 32-bit device ID that is the same as the 32-bit device ID in other devices with different functionality. The TAP pins may also be configurable for purposes other than access to the TAP controller.
Document Number: 002-05635 Rev. *C
Page 39 of 126
CY9A340NB Series
5. I/O Circuit Type
Type A
X1
R
Circuit
Pull-up resistor
P-ch
P-ch
N-ch
Feedback resistor
Digital output
Remarks It is possible to select the main oscillation / GPIO function
When the main oscillation is selected.
- Oscillation feedback resistor : Approximately 1M
- With Standby mode control
Digital output
- When the GPIO is selected. - CMOS level output.
- CMOS level hysteresis input
- With pull-up resistor control
Pull-up resistor control - With standby mode control
Digital input
- Pull-up resistor : Approximately 33 k
Standby mode control
-
IOH= -4 mA, IOL= 4 mA
Clock input
Pull-up
resistor R
P-ch
P-ch
X0
Standby mode control Digital input Standby mode control
Digital output
N-ch
Digital output
B
Pull-up resistor
Pull-up resistor control
- CMOS level hysteresis input - Pull-up resistor
: Approximately 33 k
Digital input
Document Number: 002-05635 Rev. *C
Page 40 of 126
Type C
N-ch
Circuit
CY9A340NB Series
Digital input Digital output
Remarks
- Open drain output - CMOS level hysteresis input
D X1A
X0A
Pull-up resistor
P-ch
P-ch
Digital output
It is possible to select the sub oscillation / GPIO function
When the sub oscillation is selected.
- Oscillation feedback resistor : Approximately 5 M
- With Standby mode control
- When the GPIO is selected.
N-ch
Digital output
- CMOS level output.
R
- CMOS level hysteresis input
- With pull-up resistor control
- With Standby mode control
Pull-up resistor control - Digital input
-
Pull-up resistor : Approximately 33 k IOH= -4 mA, IOL= 4 mA
Standby mode control
Feedback resistor
Clock input
Pull-up
resistor R
P-ch
P-ch
Standby mode control Digital input Standby mode control
Digital output
N-ch
Digital output
Pull-up resistor control
Document Number: 002-05635 Rev. *C
Page 41 of 126
Type E
F
CY9A340NB Series
Circuit
P-ch
P-ch
Digital output
N-ch
Digital output
R
Remarks
- CMOS level output
- CMOS level hysteresis input
- With pull-up resistor control
- With Standby mode control
- Pull-up resistor
: Approximately 33 k
-
IOH= -4 mA, IOL= 4 mA
- When this pin is used as an I2C pin, the
digital output P-ch transistor is always off
P-ch
Pull-up resistor control Digital input Standby mode control
P-ch
Digital output
N-ch
Digital output
- CMOS level output
- CMOS level hysteresis input
- With input control
- Analog input
- With pull-up resistor control
- With Standby mode control
- Pull-up resistor
: Approximately 33 k
-
IOH= -4 mA, IOL= 4 mA
- When this pin is used as an I2C pin, the
digital output P-ch transistor is always off
R
Pull-up resistor control
Digital input
Standby mode control
Analog input Input control
Document Number: 002-05635 Rev. *C
Page 42 of 126
Type G
Circuit
Mode input
CY9A340NB Series
Remarks CMOS level hysteresis input
H
UDP0/P81 Differential
UDM0/P80
I
P-ch R
GPIO Digital output
GPIO Digital input/output direction GPIO Digital input GPIO Digital input circuit control
It is possible to select the USB I/O / GPIO function.
When the USB I/O is selected.
- Full-speed, Low-speed control
UDP output
USB Full-speed/Low-speed control UDP input
When the GPIO is selected.
- CMOS level output - CMOS level hysteresis input - With Standby mode control
Differential input USB/GPIO select UDM input
UDM output
USB Digital input/output direction GPIO Digital output
GPIO Digital input/output direction GPIO Digital input
GPIO Digital input circuit control
P-ch
Digital output
N-ch
Digital output
- CMOS level output
- CMOS level hysteresis input
- 5 V tolerant
- With pull-up resistor control
- With Standby mode control
- Pull-up resistor
: Approximately 33 k
-
IOH= -4 mA, IOL= 4 mA
- Available to control PZR registers.
- When this pin is used as an I2C pin, the
digital output P-ch transistor is always off
Pull-up resistor control Digital input Standby mode control
Document Number: 002-05635 Rev. *C
Page 43 of 126
CY9A340NB Series
6. Handling Precautions
Any semiconductor devices have inherently a certain rate of failure. The possibility of failure is greatly affected by the conditions in which they are used (circuit conditions, environmental conditions, etc.). This page describes precautions that must be observed to minimize the chance of failure and to obtain higher reliability from your Cypress semiconductor devices.
6.1 Precautions for Product Design
This section describes precautions when designing electronic equipment using semiconductor devices.
Absolute Maximum Ratings
Semiconductor devices can be permanently damaged by application of stress (voltage, current, temperature, etc.) in excess of certain established limits, called absolute maximum ratings. Do not exceed these ratings.
Recommended Operating Conditions
Recommended operating conditions are normal operating ranges for the semiconductor device. All the device's electrical characteristics are warranted when operated within these ranges. Always use semiconductor devices within the recommended operating conditions. Operation outside these ranges may adversely affect reliability and could result in device failure. No warranty is made with respect to uses, operating conditions, or combinations not represented on the data sheet. Users considering application outside the listed conditions are advised to contact their sales representative beforehand.
Processing and Protection of Pins
These precautions must be followed when handling the pins which connect semiconductor devices to power supply and input/output functions. 1. Preventing Over-Voltage and Over-Current Conditions
Exposure to voltage or current levels in excess of maximum ratings at any pin is likely to cause deterioration within the device, and in extreme cases leads to permanent damage of the device. Try to prevent such overvoltage or over-current conditions at the design stage. 2. Protection of Output Pins Shorting of output pins to supply pins or other output pins, or connection to large capacitance can cause large current flows. Such conditions if present for extended periods of time can damage the device. Therefore, avoid this type of connection. 3. Handling of Unused Input Pins Unconnected input pins with very high impedance levels can adversely affect stability of operation. Such pins should be connected through an appropriate resistance to a power supply pin or ground pin.
Latch-up
Semiconductor devices are constructed by the formation of P-type and N-type areas on a substrate. When subjected to abnormally high voltages, internal parasitic PNPN junctions (called thyristor structures) may be formed, causing large current levels in excess of several hundred mA to flow continuously at the power supply pin. This condition is called latch-up. CAUTION: The occurrence of latch-up not only causes loss of reliability in the semiconductor device, but can cause injury or damage from high heat, smoke or flame. To prevent this from happening, do the following: 1. Be sure that voltages applied to pins do not exceed the absolute maximum ratings. This should include attention to abnormal
noise, surge levels, etc. 2. Be sure that abnormal current flows do not occur during the power-on sequence.
Observance of Safety Regulations and Standards
Most countries in the world have established standards and regulations regarding safety, protection from electromagnetic interference, etc. Customers are requested to observe applicable regulations and standards in the design of products.
Fail-Safe Design
Any semiconductor devices have inherently a certain rate of failure. You must protect against injury, damage or loss from such failures by incorporating safety design measures into your facility and equipment such as redundancy, fire protection, and prevention of over-current levels and other abnormal operating conditions.
Document Number: 002-05635 Rev. *C
Page 44 of 126
CY9A340NB Series
Precautions Related to Usage of Devices
Cypress semiconductor devices are intended for use in standard applications (computers, office automation and other office equipment, industrial, communications, and measurement equipment, personal or household devices, etc.). CAUTION: Customers considering the use of our products in special applications where failure or abnormal operation may directly affect human lives or cause physical injury or property damage, or where extremely high levels of reliability are demanded (such as aerospace systems, atomic energy controls, sea floor repeaters, vehicle operating controls, medical devices for life support, etc.) are requested to consult with sales representatives before such use. The company will not be responsible for damages arising from such use without prior approval.
6.2 Precautions for Package Mounting
Package mounting may be either lead insertion type or surface mount type. In either case, for heat resistance during soldering, you should only mount under Cypress' recommended conditions. For detailed information about mount conditions, contact your sales representative.
Lead Insertion Type
Mounting of lead insertion type packages onto printed circuit boards may be done by two methods: direct soldering on the board, or mounting by using a socket.
Direct mounting onto boards normally involves processes for inserting leads into through-holes on the board and using the flow soldering (wave soldering) method of applying liquid solder. In this case, the soldering process usually causes leads to be subjected to thermal stress in excess of the absolute ratings for storage temperature. Mounting processes should conform to Cypress recommended mounting conditions.
If socket mounting is used, differences in surface treatment of the socket contacts and IC lead surfaces can lead to contact deterioration after long periods. For this reason it is recommended that the surface treatment of socket contacts and IC leads be verified before mounting.
Surface Mount Type
Surface mount packaging has longer and thinner leads than lead-insertion packaging, and therefore leads are more easily deformed or bent. The use of packages with higher pin counts and narrower pin pitch results in increased susceptibility to open connections caused by deformed pins, or shorting due to solder bridges.
You must use appropriate mounting techniques. Cypress Inc. recommends the solder reflow method, and has established a ranking of mounting conditions for each product. Users are advised to mount packages in accordance with Cypress ranking of recommended conditions.
Lead-Free Packaging
CAUTION: When ball grid array (BGA) packages with Sn-Ag-Cu balls are mounted using Sn-Pb eutectic soldering, junction strength may be reduced under some conditions of use.
Storage of Semiconductor Devices
Because plastic chip packages are formed from plastic resins, exposure to natural environmental conditions will cause absorption of moisture. During mounting, the application of heat to a package that has absorbed moisture can cause surfaces to peel, reducing moisture resistance and causing packages to crack. To prevent, do the following: 1. Avoid exposure to rapid temperature changes, which cause moisture to condense inside the product. Store products in
locations where temperature changes are slight. 2. Use dry boxes for product storage. Products should be stored below 70% relative humidity, and at temperatures between 5�C
and 30�C. When you open Dry Package that recommends humidity 40% to 70% relative humidity. 3. When necessary, Cypress Inc. packages semiconductor devices in highly moisture-resistant aluminum laminate bags, with a silica gel desiccant. Devices should be sealed in their aluminum laminate bags for storage. 4. Avoid storing packages where they are exposed to corrosive gases or high levels of dust.
Baking
Packages that have absorbed moisture may be de-moisturized by baking (heat drying). Follow the Cypress recommended conditions for baking. Condition: 125�C/24 h
Document Number: 002-05635 Rev. *C
Page 45 of 126
CY9A340NB Series
Static Electricity
Because semiconductor devices are particularly susceptible to damage by static electricity, you must take the following precautions: 1. Maintain relative humidity in the working environment between 40% and 70%. Use of an apparatus for ion generation may be
needed to remove electricity. 2. Electrically ground all conveyors, solder vessels, soldering irons and peripheral equipment. 3. Eliminate static body electricity by the use of rings or bracelets connected to ground through high resistance (on the level of 1
M). Wearing of conductive clothing and shoes, use of conductive floor mats and other measures to minimize shock loads is recommended. 4. Ground all fixtures and instruments, or protect with anti-static measures. 5. Avoid the use of styrofoam or other highly static-prone materials for storage of completed board assemblies.
6.3 Precautions for Use Environment
Reliability of semiconductor devices depends on ambient temperature and other conditions as described above. For reliable performance, do the following: 1. Humidity
Prolonged use in high humidity can lead to leakage in devices as well as printed circuit boards. If high humidity levels are anticipated, consider anti-humidity processing. 2. Discharge of Static Electricity When high-voltage charges exist close to semiconductor devices, discharges can cause abnormal operation. In such cases, use anti-static measures or processing to prevent discharges. 3. Corrosive Gases, Dust, or Oil Exposure to corrosive gases or contact with dust or oil may lead to chemical reactions that will adversely affect the device. If you use devices in such conditions, consider ways to prevent such exposure or to protect the devices. 4. Radiation, Including Cosmic Radiation Most devices are not designed for environments involving exposure to radiation or cosmic radiation. Users should provide shielding as appropriate. 5. Smoke, Flame CAUTION: Plastic molded devices are flammable, and therefore should not be used near combustible substances. If devices begin to smoke or burn, there is danger of the release of toxic gases.
Customers considering the use of Cypress products in other special environmental conditions should consult with sales representatives.
Document Number: 002-05635 Rev. *C
Page 46 of 126
CY9A340NB Series
7. Handling Devices
Power supply pins
In products with multiple VCC and VSS pins, respective pins at the same potential are interconnected within the device in order to prevent malfunctions such as latch-up. However, all of these pins should be connected externally to the power supply or ground lines in order to reduce electromagnetic emission levels, to prevent abnormal operation of strobe signals caused by the rise in the ground level, and to conform to the total output current rating.
Moreover, connect the current supply source with each Power supply pin and GND pin of this device at low impedance. It is also advisable that a ceramic capacitor of approximately 0.1 �F be connected as a bypass capacitor between each Power supply pin and GND pin, between AVCC pin and AVSS pin near this device.
Stabilizing supply voltage
A malfunction may occur when the power supply voltage fluctuates rapidly even though the fluctuation is within the recommended operating conditions of the VCC power supply voltage. As a rule, with voltage stabilization, suppress the voltage fluctuation so that the fluctuation in VCC ripple (peak-to-peak value) at the commercial frequency (50 Hz/60 Hz) does not exceed 10% of the VCC value in the recommended operating conditions, and the transient fluctuation rate does not exceed 0.1 V/s when there is a momentary fluctuation on switching the power supply.
Crystal oscillator circuit
Noise near the X0/X1 and X0A/X1A pins may cause the device to malfunction. Design the printed circuit board so that X0/X1, X0A/X1A pins, the crystal oscillator, and the bypass capacitor to ground are located as close to the device as possible.
It is strongly recommended that the PC board artwork be designed such that the X0/X1 and X0A/X1A pins are surrounded by ground plane as this is expected to produce stable operation.
Evaluate oscillation of your using crystal oscillator by your mount board.
Sub crystal oscillator
This series sub oscillator circuit is low gain to keep the low current consumption. The crystal oscillator to fill the following conditions is recommended for sub crystal oscillator to stabilize the oscillation.
Surface mount type
Size:
More than 3.2 mm � 1.5 mm
Load capacitance: Approximately 6 pF to 7 pF
Lead type
Load capacitance: Approximately 6 pF to 7 pF
Using an external clock
When using an external clock as an input of the main clock, set X0/X1 to the external clock input, and input the clock to X0. X1(PE3) can be used as a general-purpose I/O port. Similarly, when using an external clock as an input of the sub clock, set X0A/X1A to the external clock input, and input the clock to X0A. X1A (P47) can be used as a general-purpose I/O port.
Example of Using an External Clock
Device
Can be used as general-purpose I/O ports.
X0(X0A)
X1(PE3), X1A (P47)
Set as External clock input
Document Number: 002-05635 Rev. *C
Page 47 of 126
CY9A340NB Series
Handling when using Multi-function serial pin as I2C pin
If it is using the multi-function serial pin as I2C pins, P-ch transistor of digital output is always disabled. However, I2C pins need to keep the electrical characteristic like other pins and not to connect to the external I2C bus system with power OFF.
C Pin
This series contains the regulator. Be sure to connect a smoothing capacitor (CS) for the regulator between the C pin and the GND pin. Please use a ceramic capacitor or a capacitor of equivalent frequency characteristics as a smoothing capacitor. However, some laminated ceramic capacitors have the characteristics of capacitance variation due to thermal fluctuation (F characteristics and Y5V characteristics). Please select the capacitor that meets the specifications in the operating conditions to use by evaluating the temperature characteristics of a capacitor. A smoothing capacitor of about 4.7F would be recommended for this series.
Device
C CS
VSS
GND
Mode pins (MD0)
Connect the MD pin (MD0) directly to VCC or VSS pins. Design the printed circuit board such that the pull-up/down resistance stays low, as well as the distance between the mode pins and VCC pins or VSS pins is as short as possible and the connection impedance is low, when the pins are pulled-up/down such as for switching the pin level and rewriting the Flash memory data. It is because of preventing the device erroneously switching to test mode due to noise.
Notes on power-on
Turn power on/off in the following order or at the same time. If not using the A/D converter, connect AVCC = VCC and AVSS = VSS.
Turning on : VCC AVCC AVRH
Turning off : AVRH AVCC VCC
Serial Communication
There is a possibility to receive wrong data due to the noise or other causes on the serial communication. Therefore, design a printed circuit board so as to avoid noise. Consider the case of receiving wrong data due to noise, perform error detection such as by applying a checksum of data at the end. If an error is detected, retransmit the data.
Differences in features among the products with different memory sizes and between Flash memory products and MASK products
The electric characteristics including power consumption, ESD, latch-up, noise characteristics, and oscillation characteristics among the products with different memory sizes and between Flash memory products and MASK products are different because chip layout and memory structures are different.
If you are switching to use a different product of the same series, please make sure to evaluate the electric characteristics.
Pull-Up function of 5 V tolerant I/O
Please do not input the signal more than VCC voltage at the time of Pull-Up function use of 5 V tolerant I/O.
Document Number: 002-05635 Rev. *C
Page 48 of 126
8. Block Diagram
CY9A340NB Series
TRSTX,TCK, TDI,TMS TDO
TRACEDx, TRACECLK
INITX
X0 X1 X0A X1A CROUT
AVCC, AVSS, AVRH ANxx ADTGx
TIOAx TIOBx
SWJ-DP ETM*1
TPIU*1
ROM Table
Cortex-M3Core I
@40 MHz(Max)
D
NVIC
Sys
Dual-Timer
WatchDog Timer (Software)
Clock Reset Generator
WatchDog Timer (Hardware)
CSV
CLK
Main Osc Sub Osc
PLL
CR 4 MHz
Source Clock
CR 100 kHz
12-bit A/D Converter Unit 0 Unit 1
Base Timer 16-bit 8ch./ 32-bit 4ch.
CEC0,CEC1
RTCCO, SUBOUT
WKUPx
HDMI-CEC/ Remote Reciver Control
Real-Time Clock
Deep Standby Ctrl
AHB-APB Bridge : APB1 (Max 40 MHz) AHB-APB Bridge : APB2 (Max 40 MHz)
AHB-APB Bridge: APB0(Max 40 MHz)
Multi-layer AHB (Max 40 MHz)
Flash I/F Security
SRAM0 8/16 Kbyte
SRAM1 8/16 Kbyte
On-Chip Flash 64+32 Kbyte/ 128+32 Kbyte/ 256+32 Kbyte
USB2.0 (Host/
PHY
Device)
DMAC 8ch.
UDP0/UDM0 UHCONX
AHB-AHB Bridge
External Bus I/F*2
USB Clock Ctrl
PLL
LVD Ctrl
IRQ-Monitor
CRC Accelerator
Watch Counter
External Interrupt Controller
16-pin + NMI
MODE-Ctrl
Power-On Reset LVD
Regulator
GPIO
PIN-Function-Ctrl
Multi-Function Serial I/F 8ch.
(with FIFO ch.4 to ch.7) HW flow control(ch.4)*2
MADx MADATAx MCSXx, MOEX, MWEX, MALE, MRDY, MCLKOUT, MDQMx
C
INTx NMIX
MD0, MD1 P0x, P1x,
. . .
PEx SCKx SINx SOTx CTS4 RTS4
*1: For the CY9AF341LB/MB, CY9AF342LB/MB, and CY9AF344LB/MB, ETM is not available.
*2: For the CY9AF341LB, CY9AF342LB and CY9AF344LB, the External Bus Interface is not available. And the Multi-function Serial Interface does not support hardware flow control in these products.
Document Number: 002-05635 Rev. *C
Page 49 of 126
9. Memory Size
See Memory size in Product Lineup to confirm the memory size.
10. Memory Map
Memory Map (1)
0xFFFF_FFFF 0xE010_0000 0xE000_0000
Reserved
Cortex-M3 Private Peripherals
See the next page "lMemory Map (2)" for the memory size details.
Reserved
0x7000_0000 0x6000_0000
0x4400_0000 0x4200_0000 0x4000_0000
0x2400_0000 0x2200_0000
0x2008_0000 0x2000_0000 0x1FFF_0000 0x0020_8000 0x0020_0000 0x0010_4000 0x0010_0000
External Device Area
Reserved
32Mbytes Bit band alias
Peripherals
Reserved
32Mbytes Bit band alias
Reserved
SRAM1 SRAM0 Reserved Flash(Work area) Reserved Security/CR Trim
Flash(Main area) 0x0000_0000
Document Number: 002-05635 Rev. *C
CY9A340NB Series
0x41FF_FFFF
Peripherals Area
Reserved
0x4006_1000 0x4006_0000 0x4005_0000 0x4004_0000 0x4003_F000 0x4003_C000 0x4003_B000 0x4003_A000 0x4003_9000 0x4003_8000 0x4003_7000 0x4003_6000 0x4003_5000
0x4003_4000 0x4003_3000 0x4003_2000 0x4003_1000 0x4003_0000 0x4002_F000 0x4002_E000
DMAC Reserved USB ch.0 EXT-bus I/F Reserved
RTC Watch Counter
CRC MFS Reserved USB Clock Ctrl LVD/DS mode HDMI-CEC/ Remote Control Receiver GPIO Reserved Int-Req.Read EXTI Reserved CR Trim
0x4002_8000 0x4002_7000
0x4002_6000 0x4002_5000
Reserved
A/DC Reserved Base Timer
Reserved
0x4001_6000 0x4001_5000
0x4001_3000 0x4001_2000 0x4001_1000 0x4001_0000
0x4000_1000 0x4000_0000
Dual Timer Reserved
SW WDT HW WDT Clock/Reset
Reserved
Flash I/F
Page 50 of 126
Memory Map (2)
CY9A340NB Series
Refer to the programming manual for the detail of Flash main area. CY9AB40N/A40N/340N/140N/150R, CY9B520M/320M/120M Series Flash Programming Manual
Document Number: 002-05635 Rev. *C
Page 51 of 126
CY9A340NB Series
Peripheral Address Map
Start address
End address
0x4000_0000 0x4000_1000 0x4001_0000 0x4001_1000 0x4001_2000 0x4001_3000 0x4001_5000 0x4001_6000 0x4002_0000 0x4002_5000 0x4002_6000 0x4002_7000 0x4002_8000 0x4002_E000 0x4002_F000 0x4003_0000 0x4003_1000 0x4003_2000 0x4003_3000 0x4003_4000 0x4003_5000 0x4003_5800 0x4003_6000 0x4003_7000 0x4003_8000 0x4003_9000 0x4003_A000 0x4003_B000 0x4003_C000 0x4003_F000 0x4004_0000 0x4005_0000 0x4006_0000 0x4006_1000
0x4000_0FFF 0x4000_FFFF 0x4001_0FFF 0x4001_1FFF 0x4001_2FFF 0x4001_4FFF 0x4001_5FFF 0x4001_FFFF 0x4002_4FFF 0x4002_5FFF 0x4002_6FFF 0x4002_7FFF 0x4002_DFFF 0x4002_EFFF 0x4002_FFFF 0x4003_0FFF 0x4003_1FFF 0x4003_2FFF 0x4003_3FFF 0x4003_4FFF 0x4003_57FF 0x4003_5FFF 0x4003_6FFF 0x4003_7FFF 0x4003_8FFF 0x4003_9FFF 0x4003_AFFF 0x4003_BFFF 0x4003_EFFF 0x4003_FFFF 0x4004_FFFF 0x4005_FFFF 0x4006_0FFF 0x41FF_FFFF
Bus AHB APB0 APB1
APB2
AHB
Peripherals
Flash memory I/F register Reserved Clock/Reset Control Hardware Watchdog timer Software Watchdog timer Reserved Dual Timer Reserved Reserved Base Timer Reserved A/D Converter Reserved Built-in CR trimming Reserved External Interrupt Interrupt Source Check Register Reserved GPIO HDMI-CEC/Remote control Receiver Low-Voltage Detector Deep standby mode Controller USB clock generator Reserved Multi-function serial CRC Watch Counter Real-time clock Reserved External Bus interface USB ch.0 Reserved DMAC register Reserved
Document Number: 002-05635 Rev. *C
Page 52 of 126
CY9A340NB Series
11. Pin Status in Each CPU State
The terms used for pin status have the following meanings.
INITX=0
This is the period when the INITX pin is the L level.
INITX=1
This is the period when the INITX pin is the H level.
SPL=0
This is the status that the standby pin level setting bit (SPL) in the standby mode control register (STB_CTL) is set to 0.
SPL=1
This is the status that the standby pin level setting bit (SPL) in the standby mode control register (STB_CTL) is set to 1.
Input enabled
Indicates that the input function can be used.
Internal input fixed at 0
This is the status that the input function cannot be used. Internal input is fixed at L.
Hi-Z
Indicates that the pin drive transistor is disabled and the pin is put in the Hi-Z state.
Setting disabled
Indicates that the setting is disabled.
Maintain previous state
Maintains the state that was immediately prior to entering the current mode. If a built-in peripheral function is operating, the output follows the peripheral function. If the pin is being used as a port, that output is maintained.
Analog input is enabled
Indicates that the analog input is enabled.
Trace output
Indicates that the trace function can be used.
GPIO selected
In Deep standby mode, pins switch to the general-purpose I/O port.
Document Number: 002-05635 Rev. *C
Page 53 of 126
CY9A340NB Series
List of Pin Status
Pin status type
Function group
Power-on reset or low-volta
ge detection
state
INITX input state
Device internal reset state
Run mode or
Sleep mode state
Timer mode, RTC mode, or Stop mode state
Deep standby RTC mode or Deep standby Stop mode
state
Return from Deep
standby mode state
GPIO selected
Power supply unstable
-
Setting disabled
Power supply stable
INITX = 0 INITX = 1
-
-
Setting disabled
Setting disabled
Power supply stable INITX = 1
-
Maintain previous state
Power supply stable
INITX = 1
SPL = 0
SPL = 1
Maintain previous state
Hi-Z / Internal input fixed at 0
A Main crystal
oscillator input pin/ External main clock input
Input enabled
selected
Input enabled
Input enabled
Input enabled
Input enabled
Input enabled
Power supply stable
INITX = 1
SPL = 0 SPL = 1
GPIO selected Internal input fixed at 0
Hi-Z / Internal input fixed at 0
Power supply stable INITX = 1
-
GPIO selected
Input enabled
Input enabled
Input enabled
GPIO selected
External main clock input selected B
Main crystal oscillator output pin
C
INITX input pin
Setting disabled
Setting disabled
Hi-Z / Internal input fixed at 0/ or Input enabled
Setting disabled
Setting disabled
Hi-Z / Internal input fixed at 0
Setting disabled
Setting disabled
Hi-Z / Internal input fixed at 0
Maintain previous state
Maintain previous state
Maintain previous state
Maintain previous state
Maintain previous state/Wh en oscillatio n stops*1, Hi-Z / Internal input fixed at 0
Maintain previous state/Whe n oscillation stops*1, Hi-Z / Internal input fixed at 0
Hi-Z / Internal input fixed at 0
Hi-Z / Internal input fixed at 0
Maintain previous state/When oscillation stops*1, Hi-Z / Internal input fixed at 0
GPIO selected Internal input fixed at 0
Maintain previous state
Maintain previous state/Wh en oscillatio n stops*1, Hi-Z / Internal input fixed at 0
Hi-Z / Internal input fixed at 0
Hi-Z / Internal input fixed at 0
Maintain previous state/Wh en oscillatio n stops*1, Hi-Z / Internal input fixed at 0
GPIO selected
Maintain previous state
Maintain previous state/Wh en oscillatio n stops*1, Hi-Z / Internal input fixed at 0
Pull-up / Input enabled
Pull-up / Input enabled
Pull-up / Input enabled
Pull-up / Input enabled
Pull-up / Input enabled
Pull-up / Input enabled
Pull-up / Input enabled
Pull-up / Input enabled
Pull-up / Input enabled
D
Mode input pin
Mode input pin
E GPIO selected
Input enabled
Input enabled
Input enabled
Input enabled
Input enabled
Input enabled
Input enabled
Input enabled
Input enabled
Input enabled
Input enabled
Input enabled
Input enabled
Input enabled
Input enabled
Input enabled
Input enabled
Input enabled
Setting disabled
Setting disabled
Setting disabled
Maintain previous state
Maintain previous state
Hi-Z / Input enabled
GPIO selected
Hi-Z / Input enabled
GPIO selected
Document Number: 002-05635 Rev. *C
Page 54 of 126
CY9A340NB Series
Pin status type
Function group
Power-on reset or low-volta
ge detection
state
INITX input state
Device internal reset state
Run mode or
Sleep mode state
Timer mode, RTC mode, or Stop mode state
Deep standby RTC mode or Deep standby Stop mode
state
Return from Deep
standby mode state
GPIO selected
Power supply unstable
-
Setting disabled
Power supply stable
INITX = 0 INITX = 1
-
-
Setting disabled
Setting disabled
Power supply stable INITX = 1
-
Power supply stable
INITX = 1
SPL = 0
SPL = 1
Maintain previous state
Maintain previous state
Hi-Z / Internal input fixed at 0
F
Sub crystal oscillator input pin / Input External sub clock enabled input selected
Input enabled
Input enabled
Input enabled
Input enabled
Input enabled
Power supply stable
INITX = 1 SPL = 0 SPL = 1
GPIO selected
Internal input fixed at 0
Hi-Z / Internal input fixed at 0
Power supply stable INITX = 1
-
GPIO selected
Input enabled
Input enabled
Input enabled
GPIO selected
Setting disabled
Setting disabled
Setting disabled
Maintain previous state
Maintain previous state
Hi-Z / Internal input fixed at 0
GPIO selected Internal input fixed at 0
Hi-Z / Internal input fixed at 0
GPIO selected
External sub clock Setting
input selected
disabled
G
Setting disabled
Setting disabled
Maintain previous state
Maintain previous state
Hi-Z / Internal input fixed at 0
Maintain previous state
Hi-Z/ Internal input fixed at 0
Maintain previous state
Sub crystal oscillator output pin
Hi-Z / Internal input fixed at 0/ or Input enable
Hi-Z / Internal input fixed at 0
Hi-Z / Internal input fixed at 0
Maintain previous state
Maintain previous state/Whe n oscillation stops*2, Hi-Z / Internal input fixed at 0
Maintain previous state/When oscillation stops*2, Hi-Z / Internal input fixed at 0
Maintain previous state/Wh en oscillatio n stops*2, Hi-Z/ Internal input fixed at 0
Maintain previous state/Wh en oscillatio n stops*2, Hi-Z/ Internal input fixed at 0
Maintain previous state/Wh en oscillatio n stops*2, Hi-Z/ Internal input fixed at 0
Document Number: 002-05635 Rev. *C
Page 55 of 126
CY9A340NB Series
Pin status type
Function group
Power-on reset or low-volta
ge detection
state
INITX input state
Device internal reset state
Run mode or
Sleep mode state
Timer mode, RTC mode, or Stop mode state
Power supply unstable
-
Power supply stable
INITX = 0 INITX = 1
-
-
Power supply stable INITX = 1
-
Power supply stable
INITX = 1
SPL = 0
SPL = 1
Deep standby RTC mode or Deep standby Stop mode
state
Return from Deep
standby mode state
Power supply stable
INITX = 1 SPL = 0 SPL = 1
Power supply stable INITX = 1
-
GPIO selected
GPIO
Hi-Z
Hi-Z / Input enabled
Hi-Z / Input enabled
Maintain previous state
Maintain previous state
Hi-Z / Internal input fixed at 0
selected Internal input fixed at 0
Hi-Z / Internal input fixed at 0
GPIO selected
H USB I/O pin
Setting disabled
NMIX selected
I
Resource other than above
selected
GPIO selected
JTAG selected
J
GPIO selected
Setting disabled
Hi-Z
Hi-Z
Setting disabled
Resource selected
Setting disabled
Setting disabled
Hi-Z / Input enabled
Pull-up / Input enabled
Setting disabled
Setting disabled
Setting disabled
Hi-Z / Input enabled
Pull-up / Input enabled
Setting disabled
Maintain previous state
Maintain previous state
Hi-Z at transmission/ Input enabled/ Internal input fixed at 0 at reception
Maintain previous state
Hi-Z at transmission/ Input enabled/ Internal input fixed at 0 at reception
Maintain previous state
Hi-Z / Internal input fixed at 0
Hi-Z / Input enabled
WKUP input enabled
Hi-Z / Input enabled
Hi-Z / WKUP input enabled
Hi-Z / Input enabled
GPIO selected
Maintain previous state
Maintain previous state
Maintain previous state
Hi-Z / Internal input fixed at 0
Maintain previous state
GPIO selected Internal input fixed at 0
Maintain previous state
Hi-Z / Internal input fixed at 0
Maintain previous state
GPIO selected
GPIO selected
K
GPIO selected
GPIO
Hi-Z
Hi-Z / Input enabled
Hi-Z / Input enabled
Maintain previous state
Maintain previous state
Hi-Z / Internal input fixed at 0
selected Internal input
Hi-Z / Internal input fixed at 0
fixed at 0
Document Number: 002-05635 Rev. *C
Page 56 of 126
CY9A340NB Series
Pin status type
Function group
Power-on reset or low-volta
ge detection
state
INITX input state
Device internal reset state
Run mode or
Sleep mode state
Timer mode, RTC mode, or Stop mode state
Deep standby RTC mode or Deep standby Stop mode
state
Return from Deep
standby mode state
External interrupt enabled selected
Resource other L than above
selected GPIO selected
Analog input selected
M Resource other than above selected GPIO selected
Power supply unstable
-
Setting disabled
Hi-Z
Power supply stable
INITX = 0 INITX = 1
-
-
Setting disabled
Setting disabled
Hi-Z / Input enabled
Hi-Z / Input enabled
Power supply stable INITX = 1
-
Maintain previous state
Power supply stable
INITX = 1
SPL = 0
SPL = 1
Maintain previous state
Maintain previous state
Hi-Z / Internal input fixed at 0
Hi-Z
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Setting disabled
Setting disabled
Setting disabled
Maintain previous state
Maintain previous state
Hi-Z / Internal input fixed at 0
Power supply stable
INITX = 1 SPL = 0 SPL = 1
Power supply stable INITX = 1
-
GPIO selected
Internal input fixed at 0
Hi-Z / Internal input fixed at 0
GPIO selected
Hi-Z / Internal input fixed at 0 / Analog input enabled
GPIO selected Internal input fixed at 0
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0
Hi-Z / Internal input fixed at 0 / Analog input enabled
GPIO selected
Analog input selected
Hi-Z
N External interrupt enabled selected
Resource other than above selected
Setting disabled
GPIO selected
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog
input enabled
Setting disabled
Setting disabled
Maintain previous state
Maintain previous state
Maintain previous state
Hi-Z / Internal input fixed at 0
GPIO selected
GPIO selected
Internal input fixed at 0
Hi-Z / Internal input fixed at 0
Document Number: 002-05635 Rev. *C
Page 57 of 126
CY9A340NB Series
Pin status type
Function group
Power-on reset or low-volta
ge detection
state
INITX input state
Device internal reset state
Run mode or
Sleep mode state
Timer mode, RTC mode, or Stop mode state
Deep standby RTC mode or Deep standby Stop mode
state
Return from Deep
standby mode state
Power supply unstable
-
Power supply stable
INITX = 0 INITX = 1
-
-
Power supply stable INITX = 1
-
Power supply stable
INITX = 1
SPL = 0
SPL = 1
Power supply stable
INITX = 1 SPL = 0 SPL = 1
Power supply stable INITX = 1
-
Trace selected
O Resource other than above selected GPIO selected
Setting disabled
Hi-Z
Setting disabled
Hi-Z / Input enabled
Setting disabled
Hi-Z / Input enabled
Maintain previous state
Maintain previous state
Trace output
Hi-Z / Internal input fixed at 0
GPIO selected Internal input fixed at 0
Hi-Z / Internal input fixed at 0
GPIO selected
Analog input selected
P Trace selected
Resource other than above selected GPIO selected
Hi-Z
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Setting disabled
Setting disabled
Setting disabled
Maintain previous state
Maintain previous state
Trace output
Hi-Z / Internal input fixed at 0
GPIO selected Internal input fixed at 0
Hi-Z / Internal input fixed at 0
GPIO selected
Analog input selected
Q Trace selected
External interrupt enabled selected Resource other than above selected GPIO selected
Hi-Z
Setting disabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Trace output
Setting disabled
Setting disabled
Maintain previous state
Maintain previous state
Maintain previous state
Hi-Z / Internal input fixed at 0
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
GPIO selected Internal input fixed at 0
Hi-Z / Internal input fixed at 0
GPIO selected
Document Number: 002-05635 Rev. *C
Page 58 of 126
CY9A340NB Series
Pin status type
Function group
Power-on reset or low-volta
ge detection
state
INITX input state
Device internal reset state
Run mode or
Sleep mode state
Timer mode, RTC mode, or Stop mode state
Deep standby RTC mode or Deep standby Stop mode
state
Return from Deep
standby mode state
Analog input selected
WKUP R enabled
External interrupt enabled selected
Resource other than above selected GPIO selected
CEC enabled Resource other than above S selected
GPIO selected
Power supply unstable
-
Hi-Z
Power supply stable
INITX = 0 INITX = 1
-
-
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Power supply stable INITX = 1
-
Hi-Z / Internal input fixed at 0 / Analog input enabled
Power supply stable
INITX = 1
SPL = 0
SPL = 1
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
Setting disabled
Setting disabled
Setting disabled
Setting disabled
Setting disabled
Setting disabled
Maintain previous state
Maintain previous state
Maintain previous state
Maintain previous state
Maintain previous state
Hi-Z / Internal input fixed at 0
Maintain previous state
Hi-Z
Hi-Z / Input enabled
Hi-Z / Input enabled
Maintain previous state
Maintain previous state
Hi-Z / Internal input fixed at 0
Power supply stable
INITX = 1 SPL = 0 SPL = 1
Hi-Z / Internal input fixed at 0 / Analog input enabled
Hi-Z / Internal input fixed at 0 / Analog input enabled
WKUP input enabled
Hi-Z / WKUP input enabled
Power supply stable INITX = 1
-
Hi-Z / Internal input fixed at 0 / Analog
input enabled
GPIO selected
Internal input fixed at 0
Hi-Z / Internal input fixed at 0
GPIO selected
Maintain previous state
Maintain previous state
Maintain previous state
GPIO selected
Internal input fixed at 0
Hi-Z / Internal input fixed at 0
GPIO selected
Document Number: 002-05635 Rev. *C
Page 59 of 126
CY9A340NB Series
Pin status type
Function group
Power-on reset or low-volta
ge detection
state
INITX input state
Device internal reset state
Run mode or
Sleep mode state
Timer mode, RTC mode, or Stop mode state
Deep standby RTC mode or Deep standby Stop mode
state
Return from Deep
standby mode state
CEC enabled
WKUP enabled
T External interrupt enabled selected
Resource other than above selected
GPIO selected
Power supply unstable
-
Setting disabled
Power supply stable
INITX = 0 -
Setting disabled
INITX = 1 -
Setting disabled
Power supply stable INITX = 1
-
Maintain previous state
Power supply stable
INITX = 1
SPL = 0
SPL = 1
Maintain Maintain
previous previous
state
state
Setting disabled
Hi-Z
Setting disabled
Hi-Z / Input enabled
Setting disabled
Hi-Z / Input enabled
Maintain previous state
Maintain previous state
Maintain previous state
Hi-Z / Internal input fixed at 0
Power supply stable
INITX = 1 SPL = 0 SPL = 1
Maintain previous state
Maintain previous state
WKUP input enabled
Hi-Z / WKUP input enabled
Power supply stable INITX = 1
-
Maintain previous state
GPIO selected
Internal input fixed at 0
Hi-Z / Internal input fixed at 0
GPIO selected
*1: Oscillation is stopped at Sub Timer mode, Low-speed CR Timer mode, RTC mode, Stop mode, Deep Standby RTC mode, and Deep Standby Stop mode.
*2: Oscillation is stopped at Stop mode and Deep Standby Stop mode.
Document Number: 002-05635 Rev. *C
Page 60 of 126
CY9A340NB Series
12. Electrical Characteristics
12.1 Absolute Maximum Ratings
Parameter Power supply voltage*1, *2 Analog power supply voltage*1, *3 Analog reference voltage*1, *3 Input voltage*1
Analog pin input voltage*1 Output voltage*1
L level maximum output current*4
L level average output current*5
L level total maximum output current L level total average output current*6 H level maximum output current*4
H level average output current*5
H level total maximum output current H level total average output current*6 Power consumption Storage temperature
Symbol VCC AVCC AVRH VI
VIA VO
IOL
Min VSS - 0.5 VSS - 0.5 VSS - 0.5 VSS - 0.5 VSS - 0.5 VSS - 0.5
VSS - 0.5
-
Rating Max
VSS + 4.6 VSS + 4.6 VSS + 4.6 VCC + 0.5 ( 4.6 V) VSS + 6.5 AVCC + 0.5 ( 4.6 V) VCC + 0.5 ( 4.6 V) 10
39
IOLAV
-
IOL
-
IOLAV
-
IOH
-
4 10.5 27 100 50 - 10
39
IOHAV
-
IOH IOHAV PD TSTG
- 55
- 4 12 27 - 100 - 50 300 + 150
Unit
V V V
V
V
V
V
mA
mA
mA mA mA mA mA mA
mA
mA mA mA mA mA mW �C
Remarks
5 V tolerant
P81/UDP0 , P80/UDM0 pins *7 *8
P81/UDP0 , P80/UDM0 pins *7 *8
*1: These parameters are based on the condition that VSS = AVSS = 0 V.
*2: VCC must not drop below VSS - 0.5 V. *3: Ensure that the voltage does not to exceed VCC + 0.5 V, for example, when the power is turned on.
*4: The maximum output current is defined as the value of the peak current flowing through any one of the corresponding pins. *5: The average output current is defined as the average current value flowing through any one of the corresponding pins
for a 100 ms period. *6: The total average output current is defined as the average current value flowing through all of corresponding pins for a 100 ms.
*7: When P81/UDP0 and P80/UDM0 pins are used as GPIO (P81, P80). *8: When P81/UDP0 and P80/UDM0 pins are used as USB (UDP0, UDM0).
WARNING:
- Semiconductor devices may be permanently damaged by application of stress (including, without limitation, voltage, current or
temperature) in excess of absolute maximum ratings. Do not exceed any of these ratings.
Document Number: 002-05635 Rev. *C
Page 61 of 126
CY9A340NB Series
12.2 Recommended Operating Conditions
Parameter
Power supply voltage Analog power supply voltage
Analog reference voltage
Smoothing capacitor Operating temperature
Symbol Conditions
VCC
-
AVCC
-
AVRH
-
AVRL
-
CS
--
TA
-
Value
Min
Max
1.65*4 3.6
3.0*4
3.6
1.65
3.6
2.7 AVCC AVSS 1 - 40
AVCC AVCC AVSS 10 + 85
Unit
V
V V V V �F �C
(VSS = AVSS = 0.0V)
Remarks
*1 *2 AVCC = VCC AVCC 2.7 V AVCC< 2.7 V
For Regulator*3
*1: When P81/UDP0 and P80/UDM0 pins are used as GPIO (P81, P80).
*2: When P81/UDP0 and P80/UDM0 pins are used as USB (UDP0, UDM0).
*3: See C Pin in Handling Devices for the connection of the smoothing capacitor.
*4: In between less than the minimum power supply voltage and low voltage reset/interrupt detection voltage or more, instruction execution and low voltage detection function by built-in High-speed CR(including Main PLL is used) or built-in Low-speed CR is possible to operate only.
WARNING:
- The recommended operating conditions are required in order to ensure the normal operation of the semiconductor device. All
of the device's electrical characteristics are warranted when the device is operated under these conditions. Any use of semiconductor devices will be under their recommended operating condition. Operation under any conditions other than these conditions may adversely affect reliability of device and could result in device failure. No warranty is made with respect to any use, operating conditions or combinations not represented on this data sheet. If you are considering application under any conditions other than listed herein, please contact sales representatives beforehand.
Document Number: 002-05635 Rev. *C
Page 62 of 126
CY9A340NB Series
12.3 DC Characteristics
12.3.1 Current rating
Parameter Symbol
Pin name
PLL Run mode
High-speed
ICC
CR
Run mode
Power supply current
VCC
Sub Run mode
Low-speed CR Run mode
PLL Sleep mode
High-speed
CR
Sleep mode
ICCS
Sub
Sleep mode
Low-speed CR Sleep mode
(VCC = AVCC = 1.65V to 3.6V, VSS = AVSS = 0V, TA = - 40�C to + 85�C)
Conditions
CPU: 40 MHz, Peripheral: 40 MHz CPU: 40 MHz, Peripheral: the clock stops NOP operation
Value Typ*3 Max*4
15.5 21
8.7
12
Unit mA mA
Remarks *1, *5 *1, *5
CPU/ Peripheral: 4 MHz*2 1.8
2.9
mA
*1
CPU/ Peripheral: 32 kHz 110
CPU/ Peripheral: 100 kHz 125
Peripheral: 40 MHz
9
Peripheral: 4 MHz*2
0.8
Peripheral: 32 kHz
96
Peripheral: 100 kHz
110
680
A
700
A
12.5 mA
1.6
mA
670
A
680
A
*1, *6 *1 *1, *5 *1 *1, *6 *1
*1: When all ports are fixed. *2: When setting it to 4 MHz by trimming. *3: TA=+25�C, VCC=3.6 V *4: TA=+85�C, VCC=3.6 V *5: When using the crystal oscillator of 4 MHz(Including the current consumption of the oscillation circuit) *6: When using the crystal oscillator of 32 kHz(Including the current consumption of the oscillation circuit)
Document Number: 002-05635 Rev. *C
Page 63 of 126
CY9A340NB Series
Parameter
Symbol
Pin name
Conditions
ICCT ICCR ICCH Power supply current ICCHD
ICCRD
Main Timer mode
Sub Timer mode
RTC mode
Stop mode
VCC
Deep Standby Stop mode
Deep Standby RTC mode
TA = + 25�C, When LVD is off
TA = + 85�C, When LVD is off TA = + 25�C, When LVD is off TA = + 85�C, When LVD is off
TA = + 25�C, When LVD is off TA = + 85�C, When LVD is off TA = + 25�C, When LVD is off
TA = + 85�C, When LVD is off
TA = + 25�C, When LVD is off, When RAM is off
TA = + 25�C, When LVD is off, When RAM is on
TA = + 85�C, When LVD is off, When RAM is off
TA = + 85�C, When LVD is off, When RAM is on TA = + 25�C, When LVD is off, When RAM is off
TA = + 25�C, When LVD is off, When RAM is on
TA = + 85�C, When LVD is off, When RAM is off TA = + 85�C, When LVD is off, When RAM is on
Value Typ*2 Max*2
Unit Remarks
mA *1, *3
-
mA *1, *3
12
35
A *1, *4
-
330
A *1, *4
9.8
29
A *1, *4
-
280
A *1, *4
9
28
A *1
-
270
A *1
1.25 7
A *1, *4, *5
5.3
18
A *1, *4, *5
70 -
100
1.9
9
A *1, *4, *5 A *1, *4, *5 A *1, *5
5.9
20
A *1, *5
75
A *1, *5
-
105
A *1, *5
*1: When all ports are fixed. *2: VCC=3.6 V *3: When using the crystal oscillator of 4 MHz(Including the current consumption of the oscillation circuit) *4: When using the crystal oscillator of 32 kHz(Including the current consumption of the oscillation circuit) *5: RAM on/off setting is on-chip SRAM only.
Document Number: 002-05635 Rev. *C
Page 64 of 126
CY9A340NB Series
Low-Voltage Detection Current
Parameter
Symbol
Pin name
(VCC = 1.65V to 3.6V, VDDI = 1.1V to 1.3V, VSS = 0V, TA = - 40�C to + 85�C)
Conditions
Value
Unit
Typ
Max
Remarks
At operation
for reset
0.13
0.3
Low-voltage
VCC = 3.6 V
detection circuit (LVD) power
ICCLVD
VCC
supply current
At operation
for interrupt
0.13
0.3
VCC = 3.6 V
A At not detect A At not detect
Flash Memory Current
Parameter
Symbol
Pin name
(VCC = 1.65V to 3.6V, VDDI = 1.1V to 1.3V, VSS = 0V, TA = - 40�C to + 85�C)
Conditions
Value
Unit
Typ
Max
Remarks
Flash memory write/erase current
ICCFLASH
VCC
At Write/Erase 9.5
11.2
mA *
*: The current at which to write or erase Flash memory, ICCFLASH is added to ICC.
A/D Converter Current
Parameter
Power supply current
Symbol ICCAD
(VCC = VCC28 = AVCC = 1.65V to 3.6V, VDDI = 1.1V to 1.3V, VSS = AVSS = 0V, TA = - 40�C to +85�C)
Pin name
Conditions
Value
Typ
Max Unit
Remarks
AVCC
At 1unit operation
At stop
0.27
0.42
mA
0.03
10
A
At 1unit
operation
0.72
1.29
mA
Reference power supply current
ICCAVRH
AVRH AVRH=3.6 V
At stop
0.02
2.6
A
Document Number: 002-05635 Rev. *C
Page 65 of 126
CY9A340NB Series
12.3.2 Pin Characteristics
Parameter
H level input voltage (hysteresis input)
Symbol Pin name
Conditions
CMOS hysteresis VCC 2.7 V
input pin, MD0, MD1 VCC < 2.7 V
VIHS VCC 2.7 V
5V tolerant
input pin
VCC < 2.7 V
(VCC = AVCC = 1.65V to 3.6V, VSS = AVSS = 0V, TA = - 40�C to + 85�C)
Value
Min
Typ
Unit Max
Remarks
VCC � 0.8 -
VCC � 0.7
VCC + 0.3 V
VCC � 0.8 -
VCC � 0.7
VSS + 5.5 V
L level input
voltage (hysteresis
VILS
input)
CMOS hysteresis input pin, MD0, MD1
VCC 2.7 V VCC < 2.7 V
5V tolerant input pin
VCC 2.7 V VCC < 2.7 V
VSS - 0.3
-
VSS - 0.3
-
VCC � 0.2 V
VCC � 0.3
VCC � 0.2 V
VCC � 0.3
4 mA type
VCC 2.7 V, IOH = - 4 mA
VCC - 0.5 -
VCC
V
H level output voltage
VOH
VCC < 2.7 V, IOH = - 2 mA
VCC 2.7 V,
VCC - 0.45
The pin
IOH = - 12 mA
doubled as
VCC - 0.4
-
VCC
V
USB I/O
VCC < 2.7 V,
IOH = - 6.5 mA
L level output voltage
VOL
Input leak current
IIL
VCC 2.7 V,
IOL = 4 mA
4 mA type
VSS
VCC < 2.7 V,
IOL = 2 mA
VCC 2.7 V,
The pin
IOL = 10.5 mA
doubled as
VSS
USB I/O
VCC < 2.7 V,
IOL = 5 mA
-
CEC0, CEC1
-
- 5
VCC = AVCC = AVRH = VSS = AVSS = 0.0 V
-
0.4
V
-
0.4
V
-
+ 5
A
-
+1.8
A
VCC 2.7 V
21
Pull-up resistor value
RPU
Pull-up pin
VCC < 2.7 V
-
33
66
k
-
134
Input capacitance
CIN
Other than
VCC,
VSS, AVCC,
-
AVSS,
AVRH
-
5
15
pF
Document Number: 002-05635 Rev. *C
Page 66 of 126
CY9A340NB Series
12.4 AC Characteristics
12.4.1 Main Clock Input Characteristics
Parameter
Input frequency
Input clock cycle Input clock pulse width Input clock rising time and falling time
Internal operating clock*1 frequency
Internal operating clock*1 cycle time
Symbol
Pin name
fCH
tCYLH
X0,
X1
-
tCF, tCR
fCM
-
fCC
-
fCP0
-
fCP1
-
fCP2
-
tCYCC
-
tCYCP0
-
tCYCP1
-
tCYCP2
-
Conditions
VCC 2.7 V VCC < 2.7 V
-
-
PWH/tCYLH, PWL/tCYLH
-
-
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value
Unit
Min
Max
Remarks
4
48
4
20
4
48
MHz MHz
When crystal oscillator is connected
When using external clock
20.83 250
ns
When using external clock
45
55
%
When using external clock
-
5
ns
When using external clock
-
40
-
40
-
40
-
40
-
40
25
-
25
-
25
-
25
-
MHz MHz MHz MHz MHz ns ns ns ns
Master clock Base clock (HCLK/FCLK) APB0 bus clock*2 APB1 bus clock*2 APB2 bus clock*2 Base clock (HCLK/FCLK) APB0 bus clock*2 APB1 bus clock*2 APB2 bus clock*2
*1: For more information about each internal operating clock, see Chapter 2-1: Clock in FM3 Family Peripheral Manual. *2: For about each APB bus which each peripheral is connected to, see Block Diagram in this data sheet.
X0
Document Number: 002-05635 Rev. *C
Page 67 of 126
CY9A340NB Series
12.4.2 Sub Clock Input Characteristics
Parameter
Input frequency
Input clock cycle Input clock pulse width
Symbol
Pin name
Conditions
fCL tCYLL -
X0A, X1A
-
PWH/tCYLL, PWL/tCYLL
Min 32 10 45
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value
Unit
Typ
Max
Remarks
32.768 -
-
100
kHz
When crystal oscillator is connected
kHz When using external clock
-
31.25 s When using external clock
-
55
% When using external clock
X0A
12.4.3 Built-in CR Oscillation Characteristics
Built-in High-speed CR
Parameter
Clock frequency
Frequency stabilization time
Symbol
Conditions
TA = + 25�C VCC 2.7 V
TA = + 25�C
fCRH
VCC < 2.7 V
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value Unit
Min Typ Max
Remarks
3.96 4
4.04
3.9 4
4.1
When trimming*1
MHz
TA = - 40�C to + 85�C 3.84 4
4.16
TA = - 40�C to + 85�C 2.8
-
tCRWT
-
-
-
5.2
When not trimming
30
s
*2
*1: In the case of using the values in CR trimming area of Flash memory at shipment for frequency/temperature trimming.
*2: This is the time to stabilize the frequency of High-speed CR clock after setting trimming value. This period is able to use High-speed CR clock as source clock.
Built-in Low-speed CR
Parameter
Symbol
Conditions
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value Unit
Min Typ Max
Remarks
Clock frequency fCRL
-
50
100 150
kHz
Document Number: 002-05635 Rev. *C
Page 68 of 126
CY9A340NB Series
12.4.4 Operating Conditions of Main and USB PLL (In the case of using main clock for input of PLL)
Parameter
PLL oscillation stabilization wait time*1 (LOCK UP time) PLL input clock frequency
PLL multiple rate
PLL macro oscillation clock frequency Main PLL clock frequency*2 USB clock frequency*3
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value
Symbol
Unit
Min Typ Max
Remarks
tLOCK
100 -
fPLLI
4
-
-
5
-
fPLLO
75
-
fCLKPLL
-
-
fCLKSPLL
-
-
-
s
16
MHz
37
multip
le
150 MHz
40
MHz
48
MHz After the M frequency division
*1: Time from when the PLL starts operating until the oscillation stabilizes.
*2: For more information about Main PLL clock (CLKPLL), see Chapter 2-1: Clock in FM3 Family Peripheral Manual.
*3: For more information about USB clock, see Chapter 2-2: USB Clock Generation in FM3 Family Peripheral Manual Communication Macro Part.
12.4.5 Operating Conditions of Main PLL (In the case of using the built-in High-speed CR for the input clock of the Main PLL)
Parameter
PLL oscillation stabilization wait time*1 (LOCK UP time) PLL input clock frequency PLL multiple rate PLL macro oscillation clock frequency Main PLL clock frequency*2
Symbol Min
Value Typ
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Unit Max
Remarks
tLOCK
100 -
-
fPLLI
3.8
4
4.2
-
19
-
35
fPLLO
72
-
150
fCLKPLL
-
-
40
s
MHz multiple MHz MHz
*1: Time from when the PLL starts operating until the oscillation stabilizes.
*2: For more information about Main PLL clock (CLKPLL), see Chapter 2-1: Clock in FM3 Family Peripheral Manual.
Note:
- Make sure to input to the Main PLL source clock, the High-speed CR clock (CLKHC) that the frequency/temperature has been
trimmed. When setting PLL multiple rate, please take the accuracy of the built-in High-speed CR clock into account and prevent the master clock from exceeding the maximum frequency.
Document Number: 002-05635 Rev. *C
Page 69 of 126
CY9A340NB Series
Main PLL connection Main clock (CLKMO) High-speed CR clock (CLKHC)
PLL input K clock divider
Main PLL
PLL macro oscillation clock M
divider
Main PLL clock (CLKPLL)
N divider
USB PLL connection Main clock (CLKMO)
PLL input K clock divider
USB PLL
PLL macro oscillation clock M
divider
USB clock
N divider
Document Number: 002-05635 Rev. *C
Page 70 of 126
CY9A340NB Series
12.4.6 Reset Input Characteristics
Parameter Reset input time
Symbol
Pin name
tINITX
INITX
Conditions -
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value Unit
Min
Max
Remarks
500
-
ns
12.4.7 Power-on Reset Timing
Parameter
Symbol Pin name
(VSS = 0V, TA = - 40�C to + 85�C)
Conditions
Value Min Typ Max
Unit Remarks
Power supply shut down time
Power ramp rate Time until releasing Power-on reset
tOFF dV/dt tPRT
VCC
-
1
Vcc:0.2 V to 1.65 V 0.2
-
1.34
-
-
ms *1
- 1000 mV/s *2
- 16.09 ms
*1: VCC must be held below 0.2 V for minimum period of tOFF. Improper initialization may occur if this condition is not met. *2: This dV/dt characteristic is applied at the power-on of cold start (tOFF>1 ms).
Note:
- If tOFF cannot be satisfied designs must assert external reset(INITX) at power-up and at any brownout event per "12. 4. 6.Reset
Input Characteristics".
VCC
Internal RST CPU Operation
1.65V VDH
0.2V
dV/dt
0.2V
0.2V
tPRT
tOFF
RST Active
release start
Glossary: VDH: detection voltage of Low Voltage detection reset. See "12.7 Low-Voltage Detection Characteristics"
Document Number: 002-05635 Rev. *C
Page 71 of 126
CY9A340NB Series
12.4.8 External Bus Timing
External bus clock output characteristics
Parameter Output frequency
Symbol
Pin name
tCYCLE
MCLKOUT*
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value
Conditions
Unit
Min
Max
VCC 2.7 V
-
VCC < 2.7 V
-
40
MHz
20
MHz
*: The external bus clock output (MCLKOUT) is a divided clock of HCLK. For more information about setting of clock divider, see Chapter 12: External Bus Interface in FM3 Family Peripheral Manual. When external bus clock is not output, this characteristic does not give any effect on external bus operation.
MCLKOUT
External bus signal input/output characteristics
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Parameter
Symbol
Conditions
Value
Unit
Remarks
VIH Signal input characteristics
VIL
VOH
Signal output characteristics VOL
0.8 � VCC
V
0.2 � VCC
V
0.8 � VCC
V
0.2 � VCC
V
Input signal Output signal
VIH VIL
VOH VOL
VIH VIL
VOH VOL
Document Number: 002-05635 Rev. *C
Page 72 of 126
CY9A340NB Series
Separate Bus Access Asynchronous SRAM Mode
Parameter
MOEX Min pulse width
MCSX Address output delay time
MOEX Address hold time
MCSX MOEX delay time
MOEX MCSX time
MCSX MDQM delay time
Data set up MOEX time
MOEX Data hold time MWEX Min pulse width
MWEX Address output delay time
MCSX MWEX delay time
MWEX MCSX delay time
MCSX MDQM delay time
MWEX Data output time
MWEX Data hold time
Symbol
Pin name
tOEW
MOEX
tCSL � AV tOEH - AX
MCSX[7:0], MAD[24:0]
MOEX, MAD[24:0]
tCSL - OEL tOEH - CSH
MOEX, MCSX[7:0]
tCSL - RDQML
MCSX, MDQM[1:0]
tDS - OE
MOEX, MADATA[15:0]
tDH - OE
MOEX, MADATA[15:0]
tWEW
MWEX
tWEH - AX
MWEX, MAD[24:0]
tCSL - WEL tWEH - CSH
MWEX, MCSX[7:0]
tCSL-WDQML tCSL - DV tWEH - DX
MCSX, MDQM[1:0]
MCSX, MADATA[15:0]
MWEX, MADATA[15:0]
Conditions
VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value
Min
Max
Unit
MCLK�n-3
-
ns
-9 -12
0
MCLK�m-9 MCLK�m-12
0
MCLK�m-9 MCLK�m-12 30 38
+9 ns
+12 MCLK�m+9
ns MCLK�m+12 MCLK�m+9
ns MCLK�m+12 MCLK�m+9
ns MCLK�m+12 MCLK�m+9
ns MCLK�m+12 -
ns -
0
-
ns
MCLK�n-3
0
MCLK�n-9 MCLK�n-12
0
MCLK�n-9 MCLK�n-12 MCLK-9 MCLK-12
0
-
ns
MCLK�m+9 ns
MCLK�m+12 MCLK�n+9
ns MCLK�n+12 MCLK�m+9
ns MCLK�m+12 MCLK�n+9
ns MCLK�n+12 MCLK+9
ns MCLK+12 MCLK�m+9
ns MCLK�m+12
Note:
- When the external load capacitance CL = 30 pF (m = 0 to 15, n = 1 to 16).
Document Number: 002-05635 Rev. *C
Page 73 of 126
MCLK
MCSX[7:0] MAD[24:0]
MOEX MDQM[1:0]
MWEX MADATA[15:0]
CY9A340NB Series
Document Number: 002-05635 Rev. *C
Page 74 of 126
CY9A340NB Series
Separate Bus Access Synchronous SRAM Mode
Parameter Address delay time
MCSX delay time
Symbol
Pin name
tAV
MCLK, MAD[24:0]
tCSL
MCLK,
tCSH
MCSX[7:0]
tREL MOEX delay time
tREH
Data set up MCLK time
tDS
MCLK Data hold time
tDH
MWEX delay time
tWEL tWEH
MCLK, MOEX
MCLK, MADATA[15:0] MCLK, MADATA[15:0]
MCLK, MWEX
MDQM[1:0] delay time
tDQML tDQMH
MCLK, MDQM[1:0]
MCLK Data output time
tODS
MCLK, MADATA[15:0]
MCLK Data hold time
tOD
MCLK, MADATA[15:0]
Note:
- When the external load capacitance CL = 30 pF.
Conditions
VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC <2.7 V VCC 2.7 V
VCC <2.7 V
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value
Min
Max
Unit
1
12 13
ns
1
12
ns
1 1 1 24 37 0 1 1 1 1 MCLK + 1 1
12
ns
9 12
ns
9 12
ns
-
ns
-
ns
9 12
ns
9 12
ns
9 12
ns
9 12
ns
MCLK + 18 MCLK + 24
ns
18
24
ns
MCLK MCSX[7:0] MAD[24:0]
MOEX
MDQM[1:0] MWEX
MADATA[15:0]
Document Number: 002-05635 Rev. *C
Page 75 of 126
CY9A340NB Series
Multiplexed Bus Access Asynchronous SRAM Mode
Parameter
Multiplexed address delay time Multiplexed address hold time
Symbol
Pin name
tALE-CHMADV tCHMADH
MALE, MADATA[15:0]
Conditions
VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value
Min
Max
Unit
+10
-2
ns
+20
MCLK�n+0 MCLK�n+0
MCLK�n+10 ns
MCLK�n+20
Note:
- When the external load capacitance CL = 30 pF (m = 0 to 15, n = 1 to 16).
MCLK MCSX[7:0]
MALE MAD [24:0]
MOEX MDQM [1:0]
MWEX MADATA[15:0]
Document Number: 002-05635 Rev. *C
Page 76 of 126
CY9A340NB Series
Multiplexed Bus Access Synchronous SRAM Mode
Parameter
MALE delay time
MCLK Multiplexed Address delay time MCLK Multiplexed Data output time
Symbol
Pin name
tCHAL tCHAH
MCLK, ALE
tCHMADV tCHMADX
MCLK, MADATA[15:0]
Conditions
VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value
Min
Max
Unit
Remarks
9
ns
1
12
ns
9
ns
1
12
ns
VCC 2.7 V 1
VCC < 2.7 V
tOD
ns
VCC 2.7 V 1
VCC < 2.7 V
tOD
ns
Note:
- When the external load capacitance CL = 30 pF.
MCLK MCSX[7:0]
MALE MAD [24:0]
MOEX MDQM [1:0]
MWEX
MADATA[15:0]
Document Number: 002-05635 Rev. *C
Page 77 of 126
CY9A340NB Series
External Ready Input Timing
Parameter
MCLK MRDY input setup time
Symbol tRDYI
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value
Pin name Conditions
Unit
Min
Max
Remarks
MCLK, MRDY
VCC 2.7 V 23 VCC < 2.7 V 37
-
ns
When RDY is input
MCLK
���
Original MOEX MWEX
Over 2cycles tRDYI
MRDY
When RDY is released
MCLK
Extended MOEX MWEX
MRDY
��� ���
2 cycles
tRDYI 0.5�VCC
Document Number: 002-05635 Rev. *C
Page 78 of 126
CY9A340NB Series
12.4.9 Base Timer Input Timing
Timer input timing
Parameter Input pulse width
Symbol
Pin name
tTIWH, tTIWL
TIOAn/TIOBn (when using as ECK, TIN)
Conditions
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value
Unit
Min
Max
Remarks
-
2tCYCP
-
ns
ECK TIN
tTIWH
tTIWL
VIHS
VIHS
VILS
VILS
Trigger input timing
Parameter Input pulse width
Symbol Pin name
tTRGH, tTRGL
TIOAn/TIOBn (when using as TGIN)
Conditions
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value
Unit
Min
Max
Remarks
-
2tCYCP
-
ns
TGIN
tTRGH
tTRGL
VIHS
VIHS
VILS
VILS
Note:
- tCYCP indicates the APB bus clock cycle time.
About the APB bus number which the Base Timer is connected to, see Block Diagram in this data sheet.
Document Number: 002-05635 Rev. *C
Page 79 of 126
CY9A340NB Series
12.4.10 CSIO/UART Timing
CSIO (SPI = 0, SCINV = 0)
Parameter Baud rate Serial clock cycle time SCK SOT delay time
SIN SCK setup time
SCK SIN hold time Serial clock L pulse width Serial clock H pulse width SCK SOT delay time
SIN SCK setup time
SCK SIN hold time SCK falling time SCK rising time
Symbol tSCYC tSLOVI
tIVSHI
tSHIXI tSLSH tSHSL tSLOVE
tIVSHE
tSHIXE tF tR
Pin name
SCKx SCKx, SOTx SCKx, SINx SCKx, SINx SCKx SCKx SCKx, SOTx SCKx, SINx SCKx, SINx SCKx SCKx
Conditions Master mode
Slave mode
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
VCC < 2.7 V
Min
Max
VCC 2.7 V
Min
Max
Unit
-
8
-
8
Mbps
4tCYCP
-
4tCYCP
-
ns
- 30
+ 30
- 20
+ 20 ns
50
-
36
-
ns
0
-
2tCYCP - 10
-
tCYCP + 10
-
-
50
0
-
ns
2tCYCP - 10 -
ns
tCYCP + 10 -
ns
-
33
ns
10
-
10
-
ns
20
-
20
-
ns
-
5
-
5
ns
-
5
-
5
ns
Notes:
- The above characteristics apply to clock synchronous mode.
- tCYCP indicates the APB bus clock cycle time.
About the APB bus number which Multi-function serial is connected to, see Block Diagram in this data sheet.
- These characteristics only guarantee the same relocate port number.
For example, the combination of SCKx_0 and SOTx_1 is not guaranteed.
- When the external load capacitance CL = 30 pF.
Document Number: 002-05635 Rev. *C
Page 80 of 126
CY9A340NB Series
SCK SOT SIN
VOH
tSHOVI
VOH VOL
tSCYC VOL
tIVSLI VIH VIL
tSLIXI VIH VIL
Master mode
VOH
tSHSL
tSLSH
SCK
VIH
VIH
VIL
tF
VIL
VIL
tR
tSHOVE
SOT
VOH VOL
SIN
tIVSLE
VIH VIL
tSLIXE
VIH VIL
Slave mode
Document Number: 002-05635 Rev. *C
Page 81 of 126
CY9A340NB Series
CSIO (SPI = 0, SCINV = 1)
Parameter Baud rate Serial clock cycle time SCK SOT delay time
SIN SCK setup time
SCK SIN hold time Serial clock L pulse width Serial clock H pulse width SCK SOT delay time
SIN SCK setup time
SCK SIN hold time SCK falling time SCK rising time
Symbol tSCYC tSHOVI
tIVSLI
tSLIXI tSLSH tSHSL tSHOVE
tIVSLE
tSLIXE tF tR
Pin name
SCKx SCKx, SOTx SCKx, SINx SCKx, SINx SCKx SCKx SCKx, SOTx SCKx, SINx SCKx, SINx SCKx SCKx
Conditions -
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
VCC < 2.7 V
Min
Max
VCC 2.7 V
Min
Max
Unit
-
8
-
8
Mbps
4tCYCP
-
4tCYCP
-
ns
- 30
Master
mode
50
+ 30
- 20
-
36
+ 20
ns
-
ns
0
-
0
-
ns
2tCYCP - 10
-
2tCYCP - 10
-
ns
tCYCP + 10
-
tCYCP + 10
-
ns
-
50
-
33
ns
Slave mode 10
-
10
-
ns
20
-
20
-
ns
-
5
-
5
ns
-
5
-
5
ns
Notes:
- The above characteristics apply to clock synchronous mode.
- tCYCP indicates the APB bus clock cycle time.
- About the APB bus number which Multi-function serial is connected to, see Block Diagram in this data sheet.
- These characteristics only guarantee the same relocate port number.
For example, the combination of SCKx_0 and SOTx_1 is not guaranteed.
- When the external load capacitance CL = 30 pF.
Document Number: 002-05635 Rev. *C
Page 82 of 126
CY9A340NB Series
SCK SOT SIN
VOH
tSHOVI
VOH VOL
tSCYC VOL
tIVSLI VIH VIL
tSLIXI VIH VIL
Master mode
VOH
tSHSL
tSLSH
SCK
VIH
VIH
VIL
tF
VIL
VIL
tR
tSHOVE
SOT
VOH VOL
SIN
tIVSLE
VIH VIL
tSLIXE
VIH VIL
Slave mode
Document Number: 002-05635 Rev. *C
Page 83 of 126
CY9A340NB Series
CSIO (SPI = 1, SCINV = 0)
Parameter Baud rate Serial clock cycle time SCK SOT delay time
SIN SCK setup time
SCK SIN hold time
SOT SCK delay time Serial clock L pulse width Serial clock H pulse width SCK SOT delay time
SIN SCK setup time
SCK SIN hold time SCK falling time SCK rising time
Symbol
Pin name
tSCYC tSHOVI
tIVSLI
tSLIXI
tSOVLI tSLSH tSHSL tSHOVE
tIVSLE
tSLIXE tF tR
SCKx SCKx, SOTx SCKx, SINx SCKx, SINx SCKx, SOTx SCKx SCKx SCKx, SOTx SCKx, SINx SCKx, SINx SCKx SCKx
Conditions -
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
VCC < 2.7 V
Min
Max
VCC 2.7 V
Min
Max
Unit
-
8
-
8
Mbps
4tCYCP
-
4tCYCP
-
ns
- 30
+ 30
- 20
+ 20
ns
Master
50
mode
0
-
36
-
ns
-
0
-
ns
2tCYCP - 34
-
2tCYCP - 10
-
tCYCP + 10
-
-
50
2tCYCP - 34 -
ns
2tCYCP - 10 -
ns
tCYCP + 10 -
ns
-
33
ns
Slave mode 10
-
10
-
ns
20
-
20
-
ns
-
5
-
5
ns
-
5
-
5
ns
Notes:
- The above characteristics apply to clock synchronous mode.
- tCYCP indicates the APB bus clock cycle time.
- About the APB bus number which Multi-function serial is connected to, see Block Diagram in this data sheet.
- These characteristics only guarantee the same relocate port number.
For example, the combination of SCKx_0 and SOTx_1 is not guaranteed.
- When the external load capacitance CL = 30 pF.
Document Number: 002-05635 Rev. *C
Page 84 of 126
CY9A340NB Series
SCK SOT SIN
tSOVLI
VOH VOL
VIH VIL
tIVSLI
VOL
tSCYC
VOH
tSHOVI
tSLIXI
VOH VOL
VIH VIL
VOL
Master mode
SCK SOT SIN
tSLSH
tSHSL
VIH VIL
*
tF
VOH VOL
tIVSLE
VIH VIL
VIL
VIH
VIH
tR tSLIXE
tSHOVE VOH VOL
VIH VIL
*: Changes when writing to TDR register
Slave mode
Document Number: 002-05635 Rev. *C
Page 85 of 126
CY9A340NB Series
CSIO (SPI = 1, SCINV = 1)
Parameter
Baud rate Serial clock cycle time SCK SOT delay time
SIN SCK setup time
SCK SIN hold time
SOT SCK delay time Serial clock L pulse width Serial clock H pulse width SCK SOT delay time
SIN SCK setup time
SCK SIN hold time SCK falling time SCK rising time
Symbol
tSCYC tSLOVI
tIVSHI
tSHIXI
tSOVHI tSLSH tSHSL tSLOVE
tIVSHE
tSHIXE tF tR
Pin name
SCKx
SCKx, SOTx
SCKx, SINx SCKx, SINx SCKx, SOTx SCKx SCKx SCKx, SOTx SCKx, SINx SCKx, SINx SCKx SCKx
Conditions -
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
VCC < 2.7 V
Min
Max
VCC 2.7 V
Min
Max
Unit
-
8
4tCYCP
-
-
8
Mbps
4tCYCP
-
ns
- 30
+ 30
- 20
+ 20 ns
Master mode 50
-
0
-
2tCYCP - 34
-
2tCYCP - 10
-
tCYCP + 10
-
-
50
Slave mode 10
-
20
-
-
5
-
5
36
-
ns
0
-
ns
2tCYCP - 34 -
ns
2tCYCP - 10 -
ns
tCYCP + 10 -
ns
-
33
ns
10
-
ns
20
-
ns
-
5
ns
-
5
ns
Notes:
- The above characteristics apply to clock synchronous mode.
- tCYCP indicates the APB bus clock cycle time.
- About the APB bus number which Multi-function serial is connected to, see Block Diagram in this data sheet.
- These characteristics only guarantee the same relocate port number.
For example, the combination of SCKx_0 and SOTx_1 is not guaranteed.
- When the external load capacitance CL = 30 pF.
Document Number: 002-05635 Rev. *C
Page 86 of 126
SCK SOT SIN
SCK SOT SIN
CY9A340NB Series
VOH VOL
tSOVHI
tIVSHI
VIH VIL
VOH
tSCYC
tSLOVI tSHIXI
VOL
VOH VOL
VIH VIL
Master mode
VOH
tR
VIL
VIH
VOH VOL
VIH VIL
tIVSHE
tF tSHSL
VIH
VIL
tSLSH VIL
tSLOVE tSHIXE
VOH VOL
VIH VIL
Slave mode
Document Number: 002-05635 Rev. *C
Page 87 of 126
CY9A340NB Series
UART external clock input (EXT = 1)
Parameter
Serial clock L pulse width Serial clock H pulse width SCK falling time SCK rising time
Symbol
tSLSH tSHSL tF tR
Conditions CL = 30 pF
Min tCYCP + 10 tCYCP + 10 -
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value Unit
Max
Remarks
-
ns
-
ns
5
ns
5
ns
SCK
tR
t SHSL
tF t SLSH
V
V IL
IH
V
IH
V IL
V
V I L
IH
Document Number: 002-05635 Rev. *C
Page 88 of 126
CY9A340NB Series
12.4.11 External Input Timing
Parameter
Symbol Pin name Conditions
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value
Unit
Min
Max
Remarks
Input pulse width
tINH, tINL
ADTG
-
INTxx,
*2
NMIX
*3
WKUPx
*4
2tCYCP*1
-
2tCYCP + 100*1 -
500
-
600
-
ns
A/D converter trigger input
ns
External interrupt
ns
NMI
ns
Deep standby wake up
*1: tCYCP indicates the APB bus clock cycle time. About the APB bus number which the Multi-function Timer is connected to, see Block Diagram in this data sheet.
*2: When in Run mode, in Sleep mode. *3: When in Timer mode, in RTC mode, in Stop mode. *4: When in Deep Standby RTC mode, in Deep Standby Stop mode.
Document Number: 002-05635 Rev. *C
Page 89 of 126
CY9A340NB Series
12.4.12 I2C Timing
Parameter
Symbol
Conditions
SCL clock frequency (Repeated) START condition hold time SDA SCL
SCL clock L width
SCL clock H width
(Repeated) START condition setup time SCL SDA
Data hold time SCL SDA
Data setup time SDA SCL
STOP condition setup time SCL SDA
Bus free time between STOP condition and START condition
Noise filter
FSCL tHDSTA tLOW tHIGH tSUSTA
tHDDAT tSUDAT tSUSTO
tBUF tSP
CL = 30 pF, R = (Vp/IOL)*1
-
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Standard-mode
Min
Max
Fast-mode
Min
Max
Unit Remarks
0
100
0
400
kHz
4.0
-
0.6
-
s
4.7
-
1.3
-
s
4.0
-
0.6
-
s
4.7
-
0.6
-
s
0
3.45*2 0
0.9*3
s
250
-
100
-
ns
4.0
-
0.6
-
s
4.7
-
1.3
-
s
2 tCYCP*4 -
2 tCYCP*4 -
ns
*1: R and C represent the pull-up resistor and load capacitance of the SCL and SDA lines, respectively. Vp indicates the power supply voltage of the pull-up resistor and IOL indicates VOL guaranteed current.
*2: The maximum tHDDAT must satisfy that it does not extend at least L period (tLOW) of device's SCL signal.
*3: A Fast-mode I2C bus device can be used on a Standard-mode I2C bus system as long as the device satisfies the requirement of tSUDAT 250 ns.
*4: tCYCP is the APB bus clock cycle time. About the APB bus number that I2C is connected to, see Block Diagram in this data sheet. To use Standard-mode, set the APB bus clock at 2 MHz or more. To use Fast-mode, set the APB bus clock at 8 MHz or more.
SDA SCL
Document Number: 002-05635 Rev. *C
Page 90 of 126
CY9A340NB Series
12.4.13 ETM Timing
Parameter
Data hold
TRACECLK frequency TRACECLK clock cycle
Symbol
Pin name
tETMH
TRACECLK, TRACED[3:0]
1/ tTRACE tTRACE
TRACECLK
Conditions
VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value
Unit
Min
Max
Remarks
2
11
ns
2
15
-
40
MHz
-
20
MHz
25
-
ns
50
-
ns
Note:
- When the external load capacitance CL = 30 pF.
HCLK
TRACECLK
TRACED[3:0]
Document Number: 002-05635 Rev. *C
Page 91 of 126
CY9A340NB Series
12.4.14 JTAG Timing
Parameter
Symbol Pin name
TMS, TDI setup time tJTAGS TMS, TDI hold time tJTAGH
TCK, TMS, TDI
TCK, TMS, TDI
TDO delay time
tJTAGD
TCK, TDO
Conditions
VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V VCC 2.7 V VCC < 2.7 V
(VCC = 1.65V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Value
Min
Max
Unit
Remarks
15
-
ns
15
-
ns
-
25
ns
-
45
Note:
- When the external load capacitance CL = 30 pF.
TCK
TMS/TDI
TDO
Document Number: 002-05635 Rev. *C
Page 92 of 126
CY9A340NB Series
12.5 12-bit A/D Converter
Electrical Characteristics for the A/D Converter
(VCC = AVCC = 1.65V to 3.6V, VSS = AVSS = 0V, TA = - 40�C to + 85�C)
Value
Parameter
Symbol Pin name Min
Typ
Max
Unit
Remarks
Resolution
-
-
-
-
12
bit
Integral Nonlinearity -
-
Differential Nonlinearity
-
-
-
� 2
� 4.5
LSB
-
� 2.2
� 2.5
LSB
Zero transition voltage VZT
ANxx
-
� 6
� 15
mV
Full-scale transition voltage
VFST
ANxx
-
AVRH � 6 AVRH � 15 mV
2.0*1
-
-
Conversion time
-
-
4.0*1
-
-
s
10*1
-
-
0.6
-
Sampling time*2
tS
-
1.2
-
10
us
3.0
-
Compare clock cycle*3
tCCK
-
100
200
-
500
1000
ns
State transition time
to operation
tSTT
-
-
-
1.0
s
permission
Power supply current (analog + digital)
-
AVCC
-
0.27
0.42
0.03
10
mA A
Reference power
supply current (between AVRH to
-
AVSS)
AVRH
-
0.72
1.29
0.02
2.6
mA A
Analog input capacity CAIN
-
-
-
9.4
pF
2.2
Analog input resistor RAIN
-
-
-
5.5
k
10.5
Interchannel disparity -
-
-
-
4
LSB
Analog port input leak current
-
ANxx
-
-
5
A
Analog input voltage -
ANxx
AVSS
-
AVRH
V
Reference voltage
2.7
AVRH
-
AVCC
AVCC
V
-
AVRL
AVSS
-
AVSS
V
*1: The conversion time is the value of sampling time (tS) + compare time (tC).
AVCC 2.7 V 1.8 V< AVCC < 2.7 V 1.65 V< AVCC < 1.8 V AVCC 2.7 V 1.8 V< AVCC < 2.7 V 1.65 V< AVCC < 1.8 V AVCC 2.7 V 1.8 V< AVCC < 2.7 V 1.65 V< AVCC < 1.8 V
A/D 1unit operation When A/D stops A/D 1unit operation AVRH=3.6 V When A/D stops
AVCC 2.7 V 1.8 V< AVCC < 2.7 V 1.65 V< AVCC < 1.8 V
AVCC 2.7 V AVCC < 2.7 V
The condition of the minimum conversion time is the following.
AVCC 2.7 V, HCLK=40 MHz
sampling time: 0.6 s, compare time: 1.4 s
1.8 V < AVCC < 2.7 V, HCLK=40 MHz sampling time: 1.2 s, compare time: 2.8 s
1.65 V < AVCC < 1.8 V, HCLK=40 MHz sampling time: 3 s, compare time: 7 s
Ensure that it satisfies the value of the sampling time (tS) and compare clock cycle (tCCK).
For setting of the sampling time and the compare clock cycle, see Chapter 1-1: A/D Converter in FM3 Family Peripheral Manual
Analog Macro Port.
The register setting of the A/D Converter are reflected in the operation according to the APB bus clock timing.
The sampling clock and compare clock is generated from the Base clock (HCLK).
About the APB bus number which the A/D Converter is connected to, see Block Diagram in this data sheet.
*2: A necessary sampling time changes by external impedance.
Ensure that it set the sampling time to satisfy (Equation 1).
Document Number: 002-05635 Rev. *C
Page 93 of 126
*3: The compare time (tC) is the value of (Equation 2).
Analog signal source
REXT
ANxx
Analog input pin
RAIN
CY9A340NB Series
Comparator CAIN
(Equation 1) tS ( RAIN + REXT ) � CAIN � 9
tS: RAIN:
CAIN: REXT:
Sampling time[ns] Input resistor of A/D[k] = 2.2 k at 2.7 V < AVCC < 3.6 V Input resistor of A/D[k] = 5.5 k at 1.8 V < AVCC < 2.7 V Input resistor of A/D[k] = 10.5 k at 1.65 V < AVCC < 1.8 V Input capacity of A/D[pF] = 9.4 pF at 1.65 V < AVCC < 3.6 V Output impedance of external circuit[k]
(Equation 2) tC = tCCK � 14
tC:
Compare time
tCCK:
Compare clock cycle
Document Number: 002-05635 Rev. *C
Page 94 of 126
CY9A340NB Series
Definition of 12-bit A/D Converter Terms
� Resolution: � Integral Nonlinearity:
� Differential Nonlinearity:
Analog variation that is recognized by an A/D converter.
Deviation of the line between the zero-transition point (0b000000000000 0b000000000001) and the full-scale transition point (0b111111111110 0b111111111111) from the actual conversion characteristics.
Deviation from the ideal value of the input voltage that is required to change the output code by 1 LSB.
Digital output Digital output
Integral Nonlinearity
0xFFF
Actual conversion
0xFFE characteristics
{1 LSB(N-1) + VZT} 0xFFD
VFST
(Actually-
measured
0x004
value)
VNT
(Actually-measured
0x003
value)
Actual conversion
0x002
characteristics
Ideal characteristics
0x001
VZT (Actually-measured value)
Differential Nonlinearity
0x(N+1) Actual conversion characteristics
Ideal characteristics 0xN
0x(N-1) 0x(N-2)
V(N+1)T
(Actually-measured value)
VNT
(Actually-measured value)
Actual conversion characteristics
AVSS
Analog input
AVRH
AVSS
Analog input
AVRH
Linearity error of digital output N =
VNT - {1LSB � (N - 1) + VZT} 1LSB
[LSB]
Differential linearity error of digital output N =
V(N + 1) T - VNT 1LSB
- 1 [LSB]
1LSB =
VFST - VZT 4094
N: VZT: VFST: VNT:
A/D converter digital output value. Voltage at which the digital output changes from 0x000 to 0x001. Voltage at which the digital output changes from 0xFFE to 0xFFF. Voltage at which the digital output changes from 0x(N - 1) to 0xN.
Document Number: 002-05635 Rev. *C
Page 95 of 126
CY9A340NB Series
12.6 USB Characteristics
Parameter
Input characteristics
Input H level voltage
Input L level voltage
Differential input sensitivity Different common mode range
Output H level voltage
Output L level voltage
Output characteristics
Crossover voltage Rising time Falling time Rising/falling time matching Output impedance Rising time Falling time Rising/falling time matching
Symbol
VIH VIL
Pin name
(VCC = 3.0V to 3.6V, VSS = 0V, TA = - 40�C to + 85�C)
Conditions
Value
Min
Max
Unit
Remarks
-
2.0
VCC + 0.3
V
*1
-
VSS - 0.3 0.8
V
*1
VDI
-
0.2
-
V
*2
VCM
VOH
VOL
VCRS tFR tFF tFRFM ZDRV tLR tLF tLRFM
-
0.8
UDP0, UDM0
External
pull-down resistor = 15
2.8
k
External
pull-up resistor = 1.5
0
k
-
1.3
Full-Speed 4
Full-Speed 4
Full-Speed 90
Full-Speed 28 Low-Speed 75 Low-Speed 75
Low-Speed 80
2.5
3.6
0.3
2.0 20 20 111.11 44 300 300 125
V
*2
V
*3
V
*3
V
*4
ns *5
ns *5
%
*5
*6
ns *7
ns *7
%
*7
*1: The switching threshold voltage of Single-End-Receiver of USB I/O buffer is set as within VIL (Max) = 0.8 V, VIH (Min) = 2.0 V (TTL input standard). There are some hysteresis to lower noise sensitivity.
*2: Use the differential-Receiver to receive the USB differential data signal. The Differential-Receiver has 200 mV of differential input sensitivity when the differential data input is within 0.8 V to 2.5 V to the local ground reference level. Above voltage range is the common mode input voltage range.
Minimum differential input sensitivity [V]
Common mode input voltage [V]
Document Number: 002-05635 Rev. *C
Page 96 of 126
CY9A340NB Series
*3: The output drive capability of the driver is below 0.3 V at Low-State (VOL) (to 3.6 V and 1.5 k load), and 2.8 V or above (to ground and 15 k load) at High-State (VOH).
*4: The cross voltage of the external differential output signal (D + /D -) of USB I/O buffer is within 1.3 V to 2.0 V.
VCRS specified range
*5: They indicate the rising time (Trise) and falling time (Tfall) of the full-speed differential data signal. They are defined by the time between 10% and 90% of the output signal voltage. For full-speed buffer, Tr/Tf ratio is regulated as within � 10% to minimize RFI emission.
Rising time
Falling time
Document Number: 002-05635 Rev. *C
Page 97 of 126
CY9A340NB Series
*6: USB Full-speed connection is performed via twist pair cable shield with 90 � 15% characteristic impedance (Differential Mode). USB standard defines that output impedance of USB driver must be in range from 28 to 44 . So, discrete series resistor (Rs) addition is defined in order to satisfy the above definition and keep balance. When using this USB I/O, use it with 25 to 30 (recommendation value 27 ) Series resistor Rs.
28 to 44 Equiv. Imped.
28 to 44 Equiv. Imped. Mount it as external resistor.
Rs series resistor 25 to 30 Series resistor of 27 (recommendation value) must be added. And, use resistance with an uncertainty of 5% by E24 sequence.
*7: They indicate the rising time (Trise) and falling time (Tfall) of the low-speed differential data signal. They are defined by the time between 10% and 90% of the output signal voltage.
Rising time
Falling time
See Figure Low-Speed Load (Compliance Load) for conditions of the external load.
Document Number: 002-05635 Rev. *C
Page 98 of 126
Low-Speed Load (Upstream Port Load) - Reference 1 Low-Speed Load (Downstream Port Load) - Reference 2
CY9A340NB Series
CL = 50pF to 150pF CL = 50pF to 150pF
Low-Speed Load (Compliance Load)
CL = 200pF to 600pF
CL = 200pF to 600pF
CL = 200pF to 450pF CL = 200pF to 450pF
Document Number: 002-05635 Rev. *C
Page 99 of 126
CY9A340NB Series
12.7 Low-Voltage Detection Characteristics
12.7.1 Low-Voltage Detection Reset
Parameter
Symbol
Conditions
Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage
Detected voltage
Released voltage
Detected voltage
Released voltage
Detected voltage
Released voltage
Detected voltage
Released voltage
LVD stabilization wait time
LVD detection delay time
VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH
VDL
VDH
VDL
VDH
VDL
VDH
VDL
VDH
tLVDW
tLVDDL
SVHR*1 = 00000 SVHR*1 = 00001 SVHR*1 = 00010 SVHR*1 = 00011 SVHR*1 = 00100 SVHR*1 = 00101 SVHR*1 = 00110 SVHR*1 = 00111 SVHR*1 = 01000 SVHR*1 = 01001 SVHR*1 = 01010 SVHR*1 = 01011 SVHR*1 = 01100 SVHR*1 = 01101 SVHR*1 = 01110 SVHR*1 = 01111 SVHR*1 = 10000 SVHR*1 = 10001 SVHR*1 = 10010 SVHR*1 = 10011 -
(TA = - 40�C to + 85�C)
Value
Min
Typ
Max
1.38
1.50
1.60
1.43
1.55
1.65
1.43
1.55
1.65
Same as SVHR = 00000 value
1.47
1.60
1.73
Same as SVHR = 00000 value
1.52
1.65
1.78
Same as SVHR = 00000 value
1.56
1.70
1.84
Same as SVHR = 00000 value
1.61
1.75
1.89
Same as SVHR = 00000 value
1.66
1.80
1.94
Same as SVHR = 00000 value
1.70
1.85
2.00
Same as SVHR = 00000 value
1.75
1.90
2.05
Same as SVHR = 00000 value
1.79
1.95
2.11
Same as SVHR = 00000 value
1.84
2.00
2.16
Same as SVHR = 00000 value
1.89
2.05
2.21
Same as SVHR = 00000 value
2.30
2.50
2.70
Same as SVHR = 00000 value
2.39
2.60
2.81
Same as SVHR = 00000 value
2.48
2.70
2.92
Same as SVHR = 00000 value
2.58
2.80
3.02
Same as SVHR = 00000 value
2.67
2.90
3.13
Same as SVHR = 00000 value
2.76
3.00
3.24
Same as SVHR = 00000 value
2.85
3.10
3.35
Same as SVHR = 00000 value
2.94
3.20
3.46
Same as SVHR = 00000 value
Unit
Remarks
V When voltage drops V When voltage rises V When voltage drops V When voltage rises V When voltage drops V When voltage rises V When voltage drops V When voltage rises V When voltage drops V When voltage rises V When voltage drops V When voltage rises V When voltage drops V When voltage rises V When voltage drops V When voltage rises V When voltage drops V When voltage rises V When voltage drops V When voltage rises V When voltage drops V When voltage rises V When voltage drops V When voltage rises V When voltage drops V When voltage rises V When voltage drops V When voltage rises V When voltage drops V When voltage rises V When voltage drops V When voltage rises
V When voltage drops
V When voltage rises
V When voltage drops
V When voltage rises
V When voltage drops
V When voltage rises
V When voltage drops
V When voltage rises
-
-
5200 � tCYCP*2 s
-
-
200
s
*1: The SVHR bit of Low-Voltage Detection Voltage Control Register (LVD_CTL) is initialized to 00000 by Low-Voltage Detection Reset.
*2: tCYCP indicates the APB2 bus clock cycle time.
Document Number: 002-05635 Rev. *C
Page 100 of 126
CY9A340NB Series
12.7.2 Interrupt of Low-Voltage Detection
Parameter
Symbol Conditions
Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage Detected voltage Released voltage LVD stabilization wait time
LVD detection delay time
VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH VDL VDH
tLVDW
tLVDDL
SVHI = 00100 SVHI = 00101 SVHI = 00110 SVHI = 00111 SVHI = 01000 SVHI = 01001 SVHI = 01010 SVHI = 01011 SVHI = 01100 SVHI = 01101 SVHI = 01110 SVHI = 01111 SVHI = 10000 SVHI = 10001 SVHI = 10010 SVHI = 10011 -
*: tCYCP indicates the APB2 bus clock cycle time.
Min
1.56 1.61 1.61 1.66 1.66 1.70 1.70 1.75 1.75 1.79 1.79 1.84 1.84 1.89 1.89 1.93 2.30 2.39 2.39 2.48 2.48 2.58 2.58 2.67 2.67 2.76 2.76 2.85 2.85 2.94 2.94 3.04
-
Value
Typ
Max
1.70 1.84 1.75 1.89 1.75 1.89 1.80 1.94 1.80 1.94 1.85 2.00 1.85 2.00 1.90 2.05 1.90 2.05 1.95 2.11 1.95 2.11 2.00 2.16 2.00 2.16 2.05 2.21 2.05 2.21 2.10 2.27 2.50 2.70 2.60 2.81 2.60 2.81 2.70 2.92 2.70 2.92 2.80 3.02 2.80 3.02 2.90 3.13 2.90 3.13 3.00 3.24 3.00 3.24 3.10 3.35 3.10 3.35 3.20 3.46 3.20 3.46 3.30 3.56
-
5200 � tCYCP*
(TA = - 40�C to + 85�C)
Unit
Remarks
V
When voltage drops
V
When voltage rises
V
When voltage drops
V
When voltage rises
V
When voltage drops
V
When voltage rises
V
When voltage drops
V
When voltage rises
V
When voltage drops
V
When voltage rises
V
When voltage drops
V
When voltage rises
V
When voltage drops
V
When voltage rises
V
When voltage drops
V
When voltage rises
V
When voltage drops
V
When voltage rises
V
When voltage drops
V
When voltage rises
V
When voltage drops
V
When voltage rises
V
When voltage drops
V
When voltage rises
V
When voltage drops
V
When voltage rises
V
When voltage drops
V
When voltage rises
V
When voltage drops
V
When voltage rises
V
When voltage drops
V
When voltage rises
s
-
-
200
s
Document Number: 002-05635 Rev. *C
Page 101 of 126
CY9A340NB Series
12.8 Flash Memory Write/Erase Characteristics
12.8.1 Write / Erase time
Parameter
Sector erase time
Large Sector Small Sector
Half word (16-bit) write time
Chip erase time
Value
Typ*
Max*
1.1
2.7
0.3
0.9
30
528
6.8
18
(VCC = 1.65V to 3.6V, TA = - 40�C to + 85�C)
Unit
Remarks
s
Includes write time prior to internal erase
s
Not including system-level overhead time
s
Includes write time prior to internal erase
*: The typical value is immediately after shipment, the maximum value is guarantee value under 10,000 cycle of erase/write.
12.8.2 Write cycles and data hold time
Erase/write cycles (cycle)
Data hold time (year)
1,000
20*
10,000
10*
*: At average + 85C
Remarks
Document Number: 002-05635 Rev. *C
Page 102 of 126
CY9A340NB Series
12.9 Return Time from Low-Power Consumption Mode
12.9.1 Return Factor: Interrupt/WKUP
The return time from Low-Power consumption mode is indicated as follows. It is from receiving the return factor to starting the program operation.
Return Count Time
Parameter
Sleep mode High-speed CR Timer mode, Main Timer mode, PLL Timer mode Low-speed CR Timer mode
Sub Timer mode RTC mode, Stop mode Deep Standby RTC mode Deep Standby Stop mode
Symbol
(VCC = 1.65V to 3.6V, VDDI = 1.1V to 1.3V, VSS = 0V, TA = - 40�C to + 85�C)
Value
Typ
Max*
Unit
Remarks
tCYCC
s
40
80
s
350
tICNT
690
278
318
278
700
s
880
s
523
s
603
s
When RAM is off
523
s
When RAM is on
*: The maximum value depends on the accuracy of built-in CR.
Operation example of return from Low-Power consumption mode (by external interrupt*)
External interrupt
Interrupt factor accept
Active tICNT
CPU Operation
*: External interrupt is set to detecting fall edge.
Interrupt factor clear by CPU
Start
Document Number: 002-05635 Rev. *C
Page 103 of 126
CY9A340NB Series
Operation example of return from Low-Power consumption mode (by internal resource interrupt*)
Internal resource interrupt
Interrupt factor accept
Active tICNT
Interrupt factor clear by CPU
CPU Operation
Start
*: Internal resource interrupt is not included in return factor by the kind of Low-Power consumption mode.
Notes:
- The return factor is different in each Low-Power consumption modes.
See Chapter 6: Low Power Consumption Mode and Operations of Standby Modes in FM3 Family Peripheral Manual.
- When interrupt recoveries, the operation mode that CPU recoveries depend on the state before the Low-Power
consumption mode transition. See Chapter 6: Low Power Consumption Mode in FM3 Family Peripheral Manual.
Document Number: 002-05635 Rev. *C
Page 104 of 126
CY9A340NB Series
12.9.2 Return Factor: Reset The return time from Low-Power consumption mode is indicated as follows. It is from releasing reset to starting the program operation.
Return Count Time
Parameter
Sleep mode High-speed CR Timer mode, Main Timer mode, PLL Timer mode Low-speed CR Timer mode
Sub Timer mode
RTC/Stop mode Deep Standby RTC mode Deep Standby Stop mode
Symbol
(VCC = 1.65V to 3.6V, VDDI = 1.1V to 1.3V, VSS = 0V, TA = - 40�C to + 85�C)
Value
Typ
Max*
Unit
Remarks
148
263
s
148
263
s
258
483
s
tRCNT
322
516
s
278
523
s
318
603
s
When RAM is off
278
523
s
When RAM is on
*: The maximum value depends on the accuracy of built-in CR.
Operation example of return from Low-Power consumption mode (by INITX)
INITX Internal reset
Reset active
tRCNT
Release
CPU Operation
Start
Document Number: 002-05635 Rev. *C
Page 105 of 126
CY9A340NB Series
Operation example of return from low power consumption mode (by internal resource reset*)
Internal resource
reset
Internal reset
Reset active tRCNT
Release
CPU Operation
Start
*: Internal resource reset is not included in return factor by the kind of Low-Power consumption mode.
Notes:
- The return factor is different in each Low-Power consumption modes.
See Chapter 6: Low Power Consumption Mode and Operations of Standby Modes in FM3 Family Peripheral Manual.
- When interrupt recoveries, the operation mode that CPU recoveries depend on the state before the Low-Power
consumption mode transition. See Chapter 6: Low Power Consumption Mode in FM3 Family Peripheral Manual.
- The time during the power-on reset/low-voltage detection reset is excluded. See (6) Power-on Reset Timing in 4.
AC Characteristics in Electrical Characteristics for the detail on the time during the power-on reset/low-voltage detection reset.
- When in recovery from reset, CPU changes to the High-speed CR Run mode. When using the main clock or the
PLL clock, it is necessary to add the main clock oscillation stabilization wait time or the Main PLL clock stabilization wait time.
- The internal resource reset means the watchdog reset and the CSV reset.
Document Number: 002-05635 Rev. *C
Page 106 of 126
CY9A340NB Series
13. Ordering Information
Part number
On-chip Flash
memory
CY9AF341LBPMC1-G-JNE2
Main: 64 Kbyte Work: 32 Kbyte
CY9AF342LBPMC1-G-JNE2
Main: 128 Kbyte Work: 32 Kbyte
Main: 256 Kbyte CY9AF344LBPMC1-G-JNE2 Work: 32 Kbyte
CY9AF341LBPMC-G-JNE2
Main: 64 Kbyte Work: 32 Kbyte
CY9AF342LBPMC-G-JNE2
Main: 128 Kbyte Work: 32 Kbyte
CY9AF344LBPMC-G-JNE2
Main: 256 Kbyte Work: 32 Kbyte
CY9AF341LBQN-G-AVE2
Main: 64 Kbyte Work: 32 Kbyte
CY9AF342LBQN-G-AVE2
Main: 128 Kbyte Work: 32 Kbyte
CY9AF344LBQN-G-AVE2
Main: 256 Kbyte Work: 32 Kbyte
CY9AF341MBPMC-G-JNE2
Main: 64 Kbyte Work: 32 Kbyte
CY9AF342MBPMC-G-JNE2
Main: 128 Kbyte Work: 32 Kbyte
Main: 256 Kbyte CY9AF344MBPMC-G-JNE2 Work: 32 Kbyte
CY9AF341MBPMC1-G-JNE2 Main: 64 Kbyte Work: 32 Kbyte
CY9AF342MBPMC1-G-JNE2
Main: 128 Kbyte Work: 32 Kbyte
CY9AF344MBPMC1-G-JNE2
Main: 256 Kbyte Work: 32 Kbyte
CY9AF341MBBGL-GE1
Main: 64 Kbyte Work: 32 Kbyte
CY9AF342MBBGL-GE1
Main: 128 Kbyte Work: 32 Kbyte
CY9AF344MBBGL-GE1
Main: 256 Kbyte Work: 32 Kbyte
CY9AF341NBPMC-G-JNE2
Main: 64 Kbyte Work: 32 Kbyte
CY9AF342NBPMC-G-JNE2
Main: 128 Kbyte Work: 32 Kbyte
Main: 256 Kbyte CY9AF344NBPMC-G-JNE2 Work: 32 Kbyte
On-chip SRAM 16 Kbyte 16 Kbyte 32 Kbyte 16 Kbyte 16 Kbyte 32 Kbyte 16 Kbyte 16 Kbyte 32 Kbyte 16 Kbyte 16 Kbyte 32 Kbyte 16 Kbyte 16 Kbyte 32 Kbyte 16 Kbyte 16 Kbyte 32 Kbyte 16 Kbyte 16 Kbyte 32 Kbyte
Package
Plastic LQFP 64-pin
(0.5mm pitch), (LQD064)
Plastic LQFP 64-pin
(0.65mm pitch), (LQG064)
Plastic QFN 64-pin
(0.5mm pitch), (VNC064)
Plastic LQFP 80-pin
(0.5mm pitch), (LQH080)
Plastic LQFP 80-pin
(0.65mm pitch), (LQJ080)
Plastic PFBGA 96-pin
(0.5mm pitch), (FDG096)
Plastic LQFP 100-pin
(0.5mm pitch), (LQI100)
Packing Tray
Document Number: 002-05635 Rev. *C
Page 107 of 126
CY9A340NB Series
Part number CY9AF341NBPQC-G-JNE2 CY9AF342NBPQC-G-JNE2 CY9AF344NBPQC-G-JNE2 CY9AF341NBBGL-GE1 CY9AF342NBBGL-GE1 CY9AF344NBBGL-GE1
On-chip Flash
memory
Main: 64 Kbyte Work: 32 Kbyte
Main: 128 Kbyte Work: 32 Kbyte
Main: 256 Kbyte Work: 32 Kbyte
Main: 64 Kbyte Work: 32 Kbyte
Main: 128 Kbyte Work: 32 Kbyte
Main: 256 Kbyte Work: 32 Kbyte
On-chip SRAM 16 Kbyte 16 Kbyte 32 Kbyte 16 Kbyte 16 Kbyte 32 Kbyte
Package
Packing
Plastic QFP 100-pin
(0.65mm pitch), (PQH100)
Tray
Plastic PFBGA 112-pin
(0.8mm pitch), (LBC112)
Document Number: 002-05635 Rev. *C
Page 108 of 126
14. Package Dimensions
Package Type LQFP 100
Package Code LQI100
75 76
D4 57
D1
51 50
CY9A340NB Series
51 50
D4 57
D1
75 76
3
6
100
1
e 3
0.2 0 C A-B D
TOP VIEW
2
E1 E
54 7
26
25
257
0.1 0 C A-B D
b
8
0.0 8 C A-B D
0.0 8 C
SIDE VIEW
A SEATIN G
A'
PLA N E
E1 E
54 7
26 25
100
1
BOTTOM VIEW
A
L1
0.25
A1 10
L
DETAIL A
9
c b
SECTIO N A-A '
SYM BOL
A A1 b c D D1 e E E1 L L1
DIM ENSIONS
M IN. NOM . M AX.
1.70
0.05
0.15
0.15
0.27
0.09
0.20
16.00 BSC
14.00 BSC
0.50 BSC
16.00 BSC
14.00 BSC
0.45 0.60 0.75
0.30 0.50 0.70
NOTES :
1. ALL DIM ENSIONS ARE IN M ILLIM ETERS.
2. DATUM PLANE H IS LOCATED AT THE BOTTOM OF THE M OLD PARTING LINE COINCIDENT W ITH W HERE THE LEAD EXITS THE BODY.
3. DATUM S A-B AND D TO BE DETERM INED AT DATUM PLANE H.
4. TO BE DETERM INED AT SEATING PLANE C.
5. DIM ENSIONS D1 AND E1 DO NOT INCLUDE M OLD PROTRUSION. ALLOW ABLEPROTRUSION IS 0.25m m PRE SIDE. DIM ENSIONS D1 AND E1 INCLUDE M OLD M ISM ATCH AND ARE DETERM INED AT DATUM PLANE H.
6. DETAILS OF PIN 1 IDENTIFIER ARE OPTIONAL BUT M UST BE LOCATED W ITHIN THE ZONE INDICATED.
7. REGARDLESS OF THE RELATIVE SIZE OF THE UPPER AND LOW ER BODY SECTIONS. DIM ENSIONS D1 AND E1 ARE DETERM INED AT THE LARGEST FEATURE OF THE BODY EXCLUSIVE OF M OLD FLASH AND GATE BURRS. BUT INCLUDING ANY M ISM ATCH BETW EEN THE UPPER AND LOW ER SECTIONS OF THE M OLDER BODY.
8. DIM ENSION b DOES NOT INCLUDE DAM BAR PROTRUSION. THE DAM BAR PROTRUSION (S) SHALL NOT CAUSE THE LEAD W IDTH TO EXCEED b M AXIM UM BY M ORE THAN 0.08m m . DAM BAR CANNOT BE LOCATED ON THE LOW ER RADIUS OR THE LEAD FOOT.
9. THESE DIM ENSIONS APPLY TO THE FLAT SECTION OF THE LEAD BETW EEN 0.10m m AND 0.25m m FROM THE LEAD TIP.
10. A1 IS DEFINED AS THE DISTANCE FROM THE SEATING PLANE TO THE LOW EST POINT OF THE PACKAGE BODY.
002-11500 *A
PACKAGE OUTLINE, 100 LEAD LQFP 14.0X14.0X1.7 M M LQI100 REV*A
Document Number: 002-05635 Rev. *C
Page 109 of 126
CY9A340NB Series
Package Type QFP 100
80 81
Package Code PQH100
D 4
D1 57
51 50
51 50
80 81
6 3
100
1
e
3
0.40 C A-B D
TOP VIEW
E1 E 54 7
31
30
b
0.13
257 0.20 C A-B D
C A-B D 8
31 30
BOTTOM VIEW
2
SID E VIEW
0.10 C
A SEATING A' PLANE
L2
10
D ETAIL A
100 1
9c b
SECTION A-A'
SYM BOL
A A1 b c D D1 e E E1 L L1 L2
DIM ENSIONS
M IN. NOM . M AX.
3.35
0.05
0.45
0.27 0.32 0.37
0.11
0.23
23.90 BSC
20.00 BSC
0.65 BSC
17.90 BSC
14.00 BSC
0�
8�
0.73 0.88 1.03
1.95 REF
0.2 5 BSC
Document Number: 002-05635 Rev. *C
PACKAGE OUTLINE, 100 LEAD QFP 20.00X14.00X3 .35 M M PQH100 REV**
002-15156 **
Page 110 of 126
CY9A340NB Series
Package Type LQFP 80
Package Code LQH080
D4
60
D1 5 7
41
41
60
61
40
40
61
5 7
E1 E
4
3
6
80
21
21
80
1
D
e
3
0.20 C A-B D
TOP VIEW
20
257
0.10 C A-B D
b
0.08 C A-B D
8
20
1
BOTTOM VIEW
2
A
SIDE VIEW
0.08 C
A SEATIN G
9c
A'
PLAN E
L1
L
0.25 A1
10
b
SECTION A-A'
SYM BOL
A A1 b c D D1 e E E1 L L1
DIM ENSIONS
M IN. NOM . M AX.
1.70
0.05
0.15
0.15
0.27
0.09
0.20
14.00 BSC.
12.00 BSC.
0.50 BSC
14.00 BSC.
12.00 BSC.
0.45 0.60 0.75
0.30 0.50 0.70
Document Number: 002-05635 Rev. *C
PACKAGE OUTLINE, 80 LEAD LQFP 12.0X12.0X1.7 M M LQH080 Rev **
002-11501 **
Page 111 of 126
CY9A340NB Series
Package Type LQFP 80
Package Code LQJ080
60 61
D4 57
D1
41 40
41 40
60 61
3 6
80
1 e
0.2 0 C A-B D
E1 E 54 7
21
20
257
3
0.1 0 C A-B D
b
d d d C A-B D
8
2
0.1 0 C
A
SEA TIN G
A'
PLAN E
21 20
A
L1
0.2 5
L
80 1
A1 10
9
c b
SECTION A-A'
SYM BOL
A A1 b c D D1 e E E1 L L1
DIM ENSIONS
M IN. NOM . M AX.
1.70
0.00
0.20
0.16 0.32 0.38
0.09
0.20
16.00 BSC
14.00 BSC
0.65 BSC
16.00 BSC
14.00 BSC
0.45 0.60 0.75
0.30 0.50 0.70
0�
8�
Document Number: 002-05635 Rev. *C
PACKAGE OUTLINE, 80 LEAD LQFP 14.0X14.0X1.7 M M LQJ080 REV**
002-14043 **
Page 112 of 126
CY9A340NB Series
Package Type LQFP 64
Package Code LQD064
D4
D1 5 7
48
33
49
3 6
64
32
5 7
E1 E
4
17
33 32
17
48 49
64
1
e
3
0.2 0 C A-B D
TOP VIEW
16
b
257
0.1 0 C A-B D
0.0 8 C A-B D
8
16
1
BOTTOM VIEW
2
A
9c
A
SEA TIN G
0.0 8 C
A'
PLAN E
L1
SIDE VIEW
0.25 A1
L
10
b
SECTION A-A'
SYM BOL
A A1 b c D D1 e E E1 L L1
DIM ENSIONS
M IN. NOM . M AX.
1.70
0.00
0.20
0.15
0.2
0.09
0.20
12.00 BSC.
10.00 BSC.
0.50 BSC
12.00 BSC.
10.00 BSC.
0.45 0.60 0.75
0.30 0.50 0.70
Document Number: 002-05635 Rev. *C
PACKAGE OUTLINE, 64 LEAD LQFP 10.0X10.0X1.7 M M LQD064 Rev**
002-11499 **
Page 113 of 126
CY9A340NB Series
Package Type LQFP 64
Package Code LQG064
48 49
4 D
57 D1
33
32
33 32
48 49
E1 E
54 7 3
64
17
17
64
1
e
3
0.20 C A-B D
TOP VIEW
16
b
257
0.10 C A-B D
0.13
C A-B D
8
16
1
BOTTOM VIEW
2
A
A
SEATI N G
A'
PLA N E
L1
0.10 C
SIDE VIEW
0.2 5 L
A1 10
9
c b
SECTION A -A'
SYM BOL
A A1 b c D D1 e E E1 L L1
DIM ENSION
M IN. NOM . M AX.
1.70
0.00
0.20
0.27 0.32 0.37
0.09
0.20
14.00 BSC
12.00 BSC
0.65 BSC
14.00 BSC
12.00 BSC
0.45 0.60 0.75
0.30 0.50 0.70
0�
8�
Document Number: 002-05635 Rev. *C
PACKAGE OUTLINE, 64 LEAD LQFP 12.0X12.0X1.7 M M LQG064 REV**
002-13881 **
Page 114 of 126
Package Type QFN 64
48 0.10 C
49 2X
Package Code VNC064
D
A
33
32
33 32
5
E
(ND-1)� e
CY9A340NB Series
0.10 C A B
D2
48 49 0.10 C A B
E2
64 1
IN D EX M ARK 8
TOP VIEW
A
A1
SIDE VIEW
17 16
B 0.10 C 2X
17
16
9e
L
BOTTOM VIEW
64
1
b4
0.10 0.05
CAB C
0.10 C 0.05 C SEATINGPLANE
C
DIM ENSIONS SYMBOL
M IN. NOM . M AX.
A
0.90
A1
0.00
0.05
D
9.00 BSC
E
9.00 BSC
b
0.20 0.25 0.30
D2
6.00 BSC
E2
6.00 BSC
e
0.50 BSC
R
0.20 REF
L
0.35 0.40 0.45
N
64
ND
16
NOTES:
1. ALL DIM ENSIONS ARE IN M ILLIM ETERS. 2. DIM ENSIONING AND TOLERANCING CONFORM S TO ASM E Y14.5M -1994. 3. N IS THE TOTAL NUM BER OF TERM INALS. 4 DIM ENSION "b "APPLIES TO M ETALLIZED TERM INAL AND IS M EASURED
BETW EEN 0.15 AND 0.30m m FROM TERM INAL TIP. IF THE TERM INAL HAS THE OPTIONAL RADIUS ON THE OTHER END OF THE TERM INAL, THE DIM ENSION "b "SHOULD NOT BE M EASURED IN THAT RADIUS AREA. 5 ND REFERS TO THE NUM BER OF TERM INALS ON D SIDE OR E SIDE. 6. M AX. PACKAGE W ARPAGE IS 0.05m m . 7. M AXIM UM ALLOW ABLE BURR IS 0.076m m IN ALL DIRECTIONS. 8 PIN #1 ID ON TOP W ILL BE LOCATED W ITHIN THE INDICATED ZONE. 9 BILATERAL COPLANARITY ZONE APPLIES TO THE EXPOSED HEAT SINK SLUG AS W ELL AS THE TERM INALS.
Document Number: 002-05635 Rev. *C
PACKAGE OUTLINE, 64 LEAD QFN 9.0X9.0X0.9 M M VNC064 6.0X6.0 M M EPAD (SAW N) Rev*.*
002-13234 **
Page 115 of 126
CY9A340NB Series
Package Type FBGA 112
Package Code LBC112
0.20 C 2X
PIN A1 CO RN E R
IN D EX M A RK 7
TOP VIEW
A
B 0.20 C 2X
11 10 9
6
8 7 6 5 4 3 2 1
LK JHGF EDCBA
6
BOTTOM VIEW
DETAIL A
0.10 C
C D ETAIL A
5 11 2xb
0.08
CAB
SID E VIEW
SYM BOL
A A1 D E D1 E1 MD ME N
b eD eE SD SE
M IN. -
0.25
0.35
DIM ENSIONS NOM . 0.35
10.00 BSC 10.00 BSC
8.00 BSC 8.00 BSC
11 11 112 0.45 0.80 BSC 0.80 BSC
0.00 0.00
M AX. 1.45 0.45
0.55
N OTES: 1. ALL DIM ENSIONS ARE IN M ILLIM ETERS. 2. SOLDER BALL POSITION DESIGNATIO N PER JEP95, SECTION 3, SPP-020. 3. "e"REPRESENTSTHE SOLDER BALL GRID PITCH. 4. SYM BOL "M D"IS THE BALL M ATRIX SIZE IN THE "D"DIRECTION.
SYM BOL "M E"IS THE BALL M ATRIX SIZE IN THE "E"DIRECTION. N IS THE NUM BER OF POPULATED SOLDER BALL POSITIONS FOR M ATRIX SIZE M D X M E.
5. DIM ENSION "b"IS M EASURED AT THE MAXIM UM BALL DIAM ETER IN A PLANE PARALLEL TO DATUM C.
6. "SD"AND "SE"ARE M EASURED W ITH RESPECT TO DATUM S A AND B AND DEFINE THE POSITION OF THE CENTER SOLDER BALL IN THE OUTER ROW . W HEN THERE IS AN ODD NUM BEROF SOLDER BALLS IN THE OUTER ROW , "SD"OR "SE"= 0. W HEN THERE IS AN EVEN NUM BEROF SOLDER BALLS IN THE OUTER ROW , "SD"= eD/2 AND "SE"= eE/2.
7. A1 CORNER TO BE IDENTIFIED BY CHAM FER, LASER OR INK M ARK M ETALIZED M ARK, INDENTATION OR OTHER M EANS.
8. "+ " INDICATESTHE THEORETICAL CENTER OF DEPOPULATED SOLDER
BALLS.
Document Number: 002-05635 Rev. *C
PACKAGE OUTLINE, 112 BALL FBGA 10.00X10.00X1.45 M M LBC112 REV**
002-13225 **
Page 116 of 126
CY9A340NB Series
Package Type FBGA 96
Package Code FDG096
A
0.20 C 2X
PIN A1 CO RN ER
INDEX M ARK 7
TOP VIEW
0.08 C
C DETAIL A
B
0.20 C 2X
0.20 C
5 96xb
0.0 5
CAB
11 10 9
6
8 7 6 5 4 3 2 1
LK JHGF EDCBA
6
BOTTOM VIEW
DETAIL A
SIDE VIEW
SYM BOL
A A1 D E D1 E1 MD ME N
b eD eE SD SE
M IN. -
0.15
0.20
DIM ENSIONS NOM . 0.25
6.00 BSC 6.00 BSC 5.00 BSC 5.00 BSC
11 11 96 0.30 0.50 BSC 0.50 BSC
0.00 0.00
M AX. 1.30 0.35
0.40
N OTES: 1. ALL DIM ENSIONS ARE IN M ILLIM ETERS. 2. SOLDER BALL POSITION DESIGNATIO N PER JEP95, SECTION 3, SPP-020. 3. "e"REPRESENTSTHE SOLDER BALL GRID PITCH. 4. SYM BOL "M D"IS THE BALL M ATRIX SIZE IN THE "D"DIRECTION.
SYM BOL "M E"IS THE BALL M ATRIX SIZE IN THE "E"DIRECTION. N IS THE NUM BER OF POPULATED SOLDER BALL POSITIONS FOR M ATRIX SIZE M D X M E.
5. DIM ENSION "b"IS MEASURED AT THE M AXIM UM BALL DIAMETER IN A PLANE PARALLEL TO DATUM C.
6. "SD"AND "SE"ARE M EASURED W ITH RESPECT TO DATUM S A AND B AND DEFINE THE POSITION OF THE CENTER SOLDER BALL IN THE OUTER ROW . W HEN THERE IS AN ODD NUM BEROF SOLDER BALLS IN THE OUTER ROW , "SD"OR "SE"= 0. W HEN THERE IS AN EVEN NUM BEROF SOLDER BALLS IN THE OUTER ROW , "SD"= eD/2 AND "SE"= eE/2.
7. A1 CORNER TO BE IDENTIFIED BY CHAM FER, LASER OR INK M ARK M ETALIZED M ARK, INDENTATION OR OTHER M EANS.
8. "+ " INDICATESTHE THEORETICAL CENTER OF DEPOPULATED SOLDER
BALLS.
PACKAGE OUTLINE, 96 BALL FBGA 6.0X6.0X1.3 M M FDG096 REV**
002-13224 **
Document Number: 002-05635 Rev. *C
Page 117 of 126
CY9A340NB Series
15. Errata
This chapter describes the errata for CY9A340N, CY9A340NA and CY9A340MB series. Details include errata trigger conditions, scope of impact, available workaround, and silicon revision applicability. Contact your local Cypress Sales Representative if you have questions.
15.1 Part Numbers Affected
Part Number Initial Revision CY9AF341NPMC-G-JNE2, CY9AF342NPMC-G-JNE2, CY9AF344NPMC-G-JNE2, CY9AF341NPQC-G-JNE2, CY9AF342NPQC-G-JNE2, CY9AF344NPQC-G-JNE2, CY9AF341NBGL-GE1, CY9AF342NBGL-GE1, CY9AF344NBGL-GE1, CY9AF341MPMC-G-JNE2, CY9AF342MPMC-G-JNE2, CY9AF344MPMC-G-JNE2, CY9AF341MPMC1-G-JNE2, CY9AF342MPMC1-G-JNE2, CY9AF344MPMC1-G-JNE2, CY9AF341MBGL-GE1, CY9AF342MBGL-GE1, CY9AF344MBGL-GE1, CY9AF341LPMC1-G-JNE2, CY9AF342LPMC1-G-JNE2, CY9AF344LPMC1-G-JNE2, CY9AF341LPMC-G-JNE2, CY9AF342LPMC-G-JNE2, CY9AF344LPMC-G-JNE2, CY9AF341LQN-G-AVE2, CY9AF342LQN-G-AVE2, CY9AF344LQN-G-AVE2
Rev. A
CY9AF341NAPMC-G-JNE2, CY9AF342NAPMC-G-JNE2, CY9AF344NAPMC-G-JNE2, CY9AF341NAPQC-G-JNE2, CY9AF342NAPQC-G-JNE2, CY9AF344NAPQC-G-JNE2,
CY9AF341NABGL-GE1, CY9AF342NABGL-GE1, CY9AF344NABGL-GE1, CY9AF341MAPMC-G-JNE2, CY9AF342MAPMC-G-JNE2, CY9AF344MAPMC-G-JNE2, CY9AF341MAPMC1-G-JNE2, CY9AF342MAPMC1-G-JNE2, CY9AF344MAPMC1-G-JNE2,
CY9AF341MABGL-GE1, CY9AF342MABGL-GE1, CY9AF344MABGL-GE1, CY9AF341LAPMC1-G-JNE2, CY9AF342LAPMC1-G-JNE2, CY9AF344LAPMC1-G-JNE2,
CY9AF341LAPMC-G-JNE2, CY9AF342LAPMC-G-JNE2, CY9AF344LAPMC-G-JNE2, CY9AF341LAQN-G-AVE2, CY9AF342LAQN-G-AVE2, CY9AF344LAQN-G-AVE2
Rev. B
CY9AF341NBPMC-G-JNE2, CY9AF342NBPMC-G-JNE2, CY9AF344NBPMC-G-JNE2, CY9AF341NBPQC-G-JNE2, CY9AF342NBPQC-G-JNE2, CY9AF344NBPQC-G-JNE2,
CY9AF341NBBGL-GE1, CY9AF342NBBGL-GE1, CY9AF344NBBGL-GE1, CY9AF341MBPMC-G-JNE2, CY9AF342MBPMC-G-JNE2, CY9AF344MBPMC-G-JNE2, CY9AF341MBPMC1-G-JNE2, CY9AF342MBPMC1-G-JNE2, CY9AF344MBPMC1-G-JNE2,
CY9AF341MBBGL-GE1, CY9AF342MBBGL-GE1, CY9AF344MBBGL-GE1, CY9AF341LBPMC1-G-JNE2, CY9AF342LBPMC1-G-JNE2, CY9AF344LBPMC1-G-JNE2,
CY9AF341LBPMC-G-JNE2, CY9AF342LBPMC-G-JNE2, CY9AF344LBPMC-G-JNE2, CY9AF341LBQN-G-AVE2, CY9AF342LBQN-G-AVE2, CY9AF344LBQN-G-AVE2
15.2 Qualification Status
Product Status: In Production - Qual.
Document Number: 002-05635 Rev. *C
Page 118 of 126
CY9A340NB Series
15.3 Errata Summary This table defines the errata applicability to available devices.
Items [1] FLASH lower bank read during write [2] FLASH read during write & erase suspend
[3] Regulator issue [4] HDMI-CEC arbitration lost issue [5] HDMI-CEC polling message issue
Part Number Refer to 15.1 Refer to 15.1 Refer to 15.1 Refer to 15.1 Refer to 15.1
Silicon Revision Initial rev. Initial rev.
Initial rev., Rev. A Initial rev., Rev. A Initial rev., Rev. A , Rev. B
Fix Status Fixed in Rev. A Fixed in Rev. A Fixed in Rev. B Fixed in Rev. B Next silicon is not planned
1. FLASH lower bank read during write
PROBLEM DEFINITION
During writing (programming) to FLASH memory of an upper bank, FLASH memory of a lower bank could not be read at a specific timing in some operation combinations.
PARAMETERS AFFECTED
N/A
TRIGGER CONDITION(S)
This issue may happen when read data or fetch instruction from the FLASH memory lower bank (smaller sector), while a write (program) operation to the FLASH memory upper bank (larger sector) is in progress.
SCOPE OF IMPACT
Instructions could not be fetched (read) correctly from the lower bank, and then execution of the (corrupted) instructions may cause a hard fault or run-away. If an instruction in RAM reads a data from the lower bank while writing to the upper bank, an incorrect value might be read.
WORKAROUND
To rewrite the upper bank of FLASH memory, put the write instruction in RAM instead of the lower bank and execute it from the RAM. Do not access the lower bank until the write operation is completed (RDY=1). Especially to avoid a vector fetch from the lower bank of the FLASH memory by an interrupt occurred, the interrupt should be prohibited or the vector address should be set to RAM by the vector table offset register.
FIX STATUS
This issue was fixed in Rev. A.
2. FLASH Read during Write & Sector Erase Suspend
PROBLEM DEFINITION
When writing is executed during sector erase suspend, FLASH memory could not be read correctly at a specific timing.
PARAMETERS AFFECTED
N/A
TRIGGER CONDITION(S)
This issue may happen when read data or fetch instruction from the FLASH memory bank (higher or lower), while a write (program) operation is in progress to the opposite bank which has a sector erase suspended. The following flow could not be executed correctly.
(a) Erase a sector of a bank
(b) Suspend the sector erase operation
(c) Write to a different sector of the bank
(d) Execute an instruction or read data in the opposite bank
SCOPE OF IMPACT
Document Number: 002-05635 Rev. *C
Page 119 of 126
CY9A340NB Series
Instructions could not be fetched (read) correctly, and then execution of the (corrupted) instructions may cause a hard fault or run-away. If an instruction in RAM reads a data from the bank, an incorrect value might be read.
WORKAROUND
Do not execute the write operation to a different sector in the same bank at sector erase suspend.
FIX STATUS
This issue was fixed in Rev. A.
3. Regulator issue
PROBLEM DEFINITION
The regulator does not get initialized while internal power-up sequence.
PARAMETERS AFFECTED
N/A
TRIGGER CONDITION(S)
This issue rarely happens depending on states of internal circuits which the user cannot control.
SCOPE OF IMPACT
MCU does not start operation if this issue occurs.
WORKAROUND
This error cannot be avoided by any software.
FIX STATUS
This issue was fixed in Rev. B.
4. HDMI-CEC arbitration lost issue
PROBLEM DEFINITION
Large external load on CEC bus may cause arbitration lost.
PARAMETERS AFFECTED
N/A
TRIGGER CONDITION(S)
The arbitration lost detection mechanism samples outputting signals and determines that arbitration lost occurs if sampled signals do not match the outputting signals. The large external load on the CEC bus increases slew rate of the signals. The increased slew rate makes the mismatch between outputting signals and sampled signals and the mismatch misleads MCU that arbitration lost occurs.
SCOPE OF IMPACT
Once the arbitration lost is detected, the CEC aborts the transmission. Any transmission cannot be completed.
WORKAROUND
This error cannot be avoided by any software. Reduce the external load.
FIX STATUS
This issue was fixed in Rev. B.
5. HDMI-CEC polling message issue
PROBLEM DEFINITION
Error#1) While MCU sends a Polling Message, it always returns a NACK to a message coming to the MCU from another node.
Error#2) MCU always waits for 7-bit signal free on CEC line before it drives the line even when the last line initiator was another node.
PARAMETERS AFFECTED
N/A
TRIGGER CONDITION(S)
This error always happens.
SCOPE OF IMPACT
MCU does not reply properly to another node.
Document Number: 002-05635 Rev. *C
Page 120 of 126
CY9A340NB Series
WORKAROUND
The software workaround is applied to Error #1. 1. Store 0x0 to SFREE register. 2. Monitor CEC line with GPIO and wait until 1 lasts for the signal free time. 3. Store frame data to TXDATA register and store 0x0F to RCADR1 or RCADR2 register.
It sends a message after 3~4 clocks of 32.768 kHz clock when TXDATA is stored 0x0F. If the device receives a frame from another node within 2~3 clocks after storing TXDATA, the bus error occurs and if the device receives a frame from another node within 3~4 clocks after storing TXDATA, the arbitration lost occurs. In these cases:
4-A-1. Set RCADR1 or RCADR2 to former value from 0x0F to reply ACK 4-A-2. Return back to step 2 above If the device receives a frame from another node within 1~2 clocks after storing TXDATA, take these steps. 4-B-1. Monitor CEC line with GPIO after 50us from storing TXDATA 4-B-2. Set TXEN to 1 -> 0 -> 1 immediately when GPIO finds state low on the CEC line 4-B-3. Set RCADR1 or RCADR2 to former value from 0x0F to reply ACK 4-B-4. Return back to step 2 above For Error #2, there is no software workaround, but signal free time of fixed 7-bit does not violate HDMI-CEC specification. The specification says signal free time must be more than and equals to 5-bit.
FIX STATUS
The user uses the workaround to avoid the issue. The next silicon fixing the issue is not planned.
Document Number: 002-05635 Rev. *C
Page 121 of 126
CY9A340NB Series
16. Major Changes
Spansion Publication Number: DS706-00039
Page
Section
Revision 2.0
FEATURE
2
� On-chip Memories
� USB Interface
6
� Unique ID
7
PRODUCT LINEUP � Function
48 HANDLING DEVICES
53
MEMORY MAP � Memory Map (2)
58
PIN STATUS IN EACH CPU STATE � List of Pin Status
ELECTRICAL CHARACTERISTICS 65 3.DC Characteristics
(1) Current rating
4.AC Characteristics
68
(3) Built-in CR Oscillation Characteristics
� Built-in high-speed CR
72, 73
(7) External Bus Timing � Separate Bus Access Asynchronous SRAM Mode
74
� Separate Bus Access Synchronous SRAM Mode
79, 81, 83, 85
88
(9) CSIO Timing (11) I2C Timing
5. 12-bit A/D Converter 91 � Electrical characteristics for the A/D
converter (Preliminary value)
93
� Definition of 12-bit A/D Converter Terms
7. Low-Voltage Detection 98 Characteristics
(1) Low-Voltage Detection Reset
99 (2) Interrupt of Low-Voltage Detection
Revision 2.1
-
-
Revision 3.0
-
-
-
-
2
FEATURES �External Bus Interface
3
�Multi-function Serial Interface
Change Results
Revised the descriptions of [Flash memory].
Revised the descriptions of [USB function]. Added the descriptions of "Unique ID".
Added the descriptions.
Revised the Pin status type of "I".
Revised the descriptions of Power supply current. Added the "Flash memory write/erase current". Added the footnote. Revised the table and the footnote.
Revised the table and the figure.
Revised the title to "CSIO Timing". Revised the note. Revised the footnote. � Revised the parameter. � Revised the symbol. � Corrected the value. � Revised the parameter. � Revised the symbol. � Corrected "Conditions" and "Value" in the table. � Added the Item. � Added the footnote. Added the Item.
Company name and layout design change
Corrected the Series name. MB9A340NA Series MB9A340NB Series Corrected the Product name as follows. MB9AF344LB, MB9AF342LB, MB9AF341LB MB9AF344MB, MB9AF342MB, MB9AF341MB MB9AF344NB, MB9AF342NB, MB9AF341NB Added the Item. � Maximum area size : Up to 256 Mbytes Corrected the description of "I2C"
Document Number: 002-05635 Rev. *C
Page 122 of 126
CY9A340NB Series
Page
Section
Change Results
7 51 52 63
64,65
PRODUCT LINEUP �Function BLOCK DIAGRAM MEMORY MAP �Memory Map (1) ELECTRICAL CHARACTERISTICS 2.Recommended Operating Conditions
3.DC Characteristics (1)Current rating
(9)CSIO Timing �Synchronous serial (SPI=1, SCINV=1) 86 (9) CSIO Timing � External clock(EXT=1): asynchronous only (12)I2C Timing 88
5.12-bit A/D Converter �Electrical Characteristics for
the A/D Converter 91
101 ORDERING INFORMATON
Revision 4.0
2
Features USB Interface
53
Memory Map � Memory map(2)
Electrical Characteristics 64 - 66 3. DC Characteristics
(1) Current rating
Electrical Characteristics 67 3. DC Characteristics
(2) Pin Characteristics
Electrical Characteristics 4. AC Characteristics 70 (4-1) Operating Conditions of Main and USB PLL (4-2) Operating Conditions of Main PLL
Electrical Characteristics 71 4. AC Characteristics
(6) Power-on Reset Timing
Electrical Characteristics 80 - 87 4. AC Characteristics
(9) CSIO/UART Timing
Added the footnote Corrected the figure Corrected the address "External Device Area"
Add the footnote �Corrected the Condition �Delete the minimum value �Corrected the remarks �Add the footnote Corrected the figure of "MS bit=1"
Corrected the figure
Corrected the description as follows. �Typical mode Standard-mode �High-speed mode Fast-mode �Corrected the terminal name
AN00 ~ AN23 ANxx �Corrected the minimum value of "Sampling time" �Corrected the max and min value of "State transition time to operation permission" �Corrected the footnote Corrected the "Part number"
Added the description of PLL for USB
Added the summary of Flash memory sector and the note � Changed the table format � Added Main Timer mode current � Moved A/D Converter Current
Added input leak current of CEC pin at power off.
Added the figure of Main PLL connection and USB PLL connection
� Added Time until releasing Power-on reset � Changed the figure of timing � Modified from UART Timing to CSIO/UART Timing � Changed from Internal shift clock operation to Master mode � Changed from External shift clock operation to Slave mode
Document Number: 002-05635 Rev. *C
Page 123 of 126
CY9A340NB Series
Page
Section
Change Results
92
Electrical Characteristics 5. 12bit A/D Converter
102 105
106, 107
Electrical Characteristics 9. Return Time from Low-Power Consumption Mode
Ordering Information
� Added the typical value of Integral Nonlinearity, Differential Nonlinearity, Zero transition voltage and Full-scale transition voltage
� Added Conversion time at AVcc < 2.7V
Added Return Time from Low-Power Consumption Mode
Changed notation of part number
NOTE: Please see "Document History" about later revised information.
Document Number: 002-05635 Rev. *C
Page 124 of 126
CY9A340NB Series
Document History
Document Title: CY9A340NB Series 32-bit ARM� Cortex�-M3 FM3 Microcontroller Document Number: 002-05635
Revision
ECN
Orig. of Change
Submission Date
Description of Change
**
-
AKIH
06/10/2015 Migrated to Cypress and assigned document number 002-05635.
No change to document contents.
*A
5199288
AKIH
04/01/2016 Updated to Cypress template.
*B
5534251
YSKA
07/26/2017 Updated "12.4.7 Power-On Reset Timing". Changed parameter from "Power Supply
rise time(Tr)[ms]" to "Power ramp rate(dV/dt)[mV/s]" and added some comments
(Page 71)
Modified RTC description in "Features, Real-Time Clock(RTC)" as below
Changed starting count value from 01 to 00. Deleted "second , or day of the week" in the Interrupt function (Page 3)
Added Notes for JTAG (Page 39), Changed "J-TAG" to" JTAG" in "4 List of Pin Functions" (Page 29)
Updated Package code and dimensions as follows (Page 8-15, 107-117)
FPT-64P-M38 -> LQD064, FPT-64P-M39 -> LQG064,
LCC-64P-M24 -> VNC064, FPT-80P-M37 -> LQH080,
FPT-80P-M40 -> LQJ080, BGA-96P-M07 -> FDG096,
FPT-100P-M23 -> LQI100, FPT-100P-M36 -> PQH100
BGA-112P-M04 -> LBC112
Added "15. Errata" (Page 118)
Change the name from "USB Function" to "USB Device" (Page 1, 7, 38)
Add "Analog reference voltage(AVRL)" in "12.2 Recommended Operating Conditions" and "12.6 12-bit A/D Converter"(Page 62, 93) Corrected the following statement
Analog port input current Analog port input leak current in chapter 12.6. 12-bit A/D Converter (Page 93) Added the Baud rate spec in "12.5.10 CSIO/UART Timing"(Page 80, 82, 84, 86)
*C
6574940
HUAL
05/16/2019 Updated Document Title to read as "CY9A340NB Series 32-bit ARM� Cortex�-M3
FM3 Microcontroller".
Replaced "MB9A340NB Series" with "CY9A340NB Series" in all instances across the
document.
Updated Ordering Information:
Updated part numbers.
Updated to new template.
Completing Sunset Review.
Document Number: 002-05635 Rev. *C
Page 125 of 126
CY9A340NB Series
Sales, Solutions, and Legal Information
Worldwide Sales and Design Support
Cypress maintains a worldwide network of offices, solution centers, manufacturer's representatives, and distributors. To find the office closest to you, visit us at Cypress Locations.
Products
ARM� Cortex� Microcontrollers Automotive Clocks & Buffers Interface Internet of Things Memory Microcontrollers PSoC Power Management ICs Touch Sensing USB Controllers Wireless/RF
cypress.com/arm cypress.com/automotive
cypress.com/clocks cypress.com/interface
cypress.com/iot cypress.com/memory
cypress.com/mcu cypress.com/psoc cypress.com/pmic cypress.com/touch cypress.com/usb cypress.com/wireless
PSoC� Solutions
PSoC 1 | PSoC 3 | PSoC 4 | PSoC 5LP | PSoC 6 MCU
Cypress Developer Community
Forums | WICED IOT Forums | Projects | Video | Blogs | Training | Components
Technical Support
cypress.com/support
ARM and Cortex are the registered trademarks of ARM Limited in the EU and other countries. All other trademarks or registered trademarks referenced herein are the property of their respective owners.
� Cypress Semiconductor Corporation, 2012-2019. This document is the property of Cypress Semiconductor Corporation and its subsidiaries ("Cypress"). This document, including any software or firmware included or referenced in this document ("Software"), is owned by Cypress under the intellectual property laws and treaties of the United States and other countries worldwide. Cypress reserves all rights under such laws and treaties and does not, except as specifically stated in this paragraph, grant any license under its patents, copyrights, trademarks, or other intellectual property rights. If the Software is not accompanied by a license agreement and you do not otherwise have a written agreement with Cypress governing the use of the Software, then Cypress hereby grants you a personal, non-exclusive, nontransferable license (without the right to sublicense) (1) under its copyright rights in the Software (a) for Software provided in source code form, to modify and reproduce the Software solely for use with Cypress hardware products, only internally within your organization, and (b) to distribute the Software in binary code form externally to end users (either directly or indirectly through resellers and distributors), solely for use on Cypress hardware product units, and (2) under those claims of Cypress's patents that are infringed by the Software (as provided by Cypress, unmodified) to make, use, distribute, and import the Software solely for use with Cypress hardware products. Any other use, reproduction, modification, translation, or compilation of the Software is prohibited.
TO THE EXTENT PERMITTED BY APPLICABLE LAW, CYPRESS MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARD TO THIS DOCUMENT OR ANY SOFTWARE OR ACCOMPANYING HARDWARE, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. No computing device can be absolutely secure. Therefore, despite security measures implemented in Cypress hardware or software products, Cypress shall have no liability arising out of any security breach, such as unauthorized access to or use of a Cypress product. CYPRESS DOES NOT REPRESENT, WARRANT, OR GUARANTEE THAT CYPRESS PRODUCTS, OR SYSTEMS CREATED USING CYPRESS PRODUCTS, WILL BE FREE FROM CORRUPTION, ATTACK, VIRUSES, INTERFERENCE, HACKING, DATA LOSS OR THEFT, OR OTHER SECURITY INTRUSION (collectively, "Security Breach"). Cypress disclaims any liability relating to any Security Breach, and you shall and hereby do release Cypress from any claim, damage, or other liability arising from any Security Breach. In addition, the products described in these materials may contain design defects or errors known as errata which may cause the product to deviate from published specifications. To the extent permitted by applicable law, Cypress reserves the right to make changes to this document without further notice. Cypress does not assume any liability arising out of the application or use of any product or circuit described in this document. Any information provided in this document, including any sample design information or programming code, is provided only for reference purposes. It is the responsibility of the user of this document to properly design, program, and test the functionality and safety of any application made of this information and any resulting product. "High-Risk Device" means any device or system whose failure could cause personal injury, death, or property damage. Examples of High-Risk Devices are weapons, nuclear installations, surgical implants, and other medical devices. "Critical Component" means any component of a High-Risk Device whose failure to perform can be reasonably expected to cause, directly or indirectly, the failure of the High-Risk Device, or to affect its safety or effectiveness. Cypress is not liable, in whole or in part, and you shall and hereby do release Cypress from any claim, damage, or other liability arising from any use of a Cypress product as a Critical Component in a High-Risk Device. You shall indemnify and hold Cypress, its directors, officers, employees, agents, affiliates, distributors, and assigns harmless from and against all claims, costs, damages, and expenses, arising out of any claim, including claims for product liability, personal injury or death, or property damage arising from any use of a Cypress product as a Critical Component in a High-Risk Device. Cypress products are not intended or authorized for use as a Critical Component in any High-Risk Device except to the limited extent that (i) Cypress's published data sheet for the product explicitly states Cypress has qualified the product for use in a specific High-Risk Device, or (ii) Cypress has given you advance written authorization to use the product as a Critical Component in the specific High-Risk Device and you have signed a separate indemnification agreement.
Cypress, the Cypress logo, Spansion, the Spansion logo, and combinations thereof, WICED, PSoC, CapSense, EZ-USB, F-RAM, and Traveo are trademarks or registered trademarks of Cypress in the United States and other countries. For a more complete list of Cypress trademarks, visit cypress.com. Other names and brands may be claimed as property of their respective owners.
Document Number: 002-05635 Rev. *C
May 16, 2019
Page 126 of 126
