KIVIK

Important Safety and Handling Information

• ❌? Do not handle improperly.
• ?? Two people are recommended for lifting and moving.
• ❌? Do not assemble on rough or uneven surfaces.
• ? Assemble on a soft surface like a rug.
• ?❓ If unsure about assembly, refer to instructions or contact support.
• ? Contact IKEA for assistance if needed.

Parts List and Unpacking

? When unpacking the sofa cover, handle it carefully. Do not use sharp objects like scissors ✂️ ❌ to open the packaging. Dispose of packaging responsibly ?️.

Step 1: Assemble Sofa Frame Base

Attach the main sofa frame components. Insert four bolts ? (Part #110019) through the designated holes in the frame. Use the assembly tool ?️ (Part #120202) with nuts ⚙️ (Part #100712) and washers ⭕ (Part #100854) to secure the frame parts.

Product Care and Warnings

? Clean surfaces with a damp cloth.

? Ironing instructions: The cover can be ironed at a low temperature ♨️ (indicated by one dot on the care label). Refer to the IKEA care label for details.

⚠️ Do not apply excessive force or pressure to the armrests ❌.

Step 2: Apply Main Sofa Cover

Unfold the main sofa cover. Carefully place it over the sofa frame, aligning the top edges. Pull the cover down evenly over the sides and back of the sofa frame.

Step 2 Continued: Secure Main Sofa Cover

Ensure the cover is correctly positioned and smooth. Secure the cover using the integrated straps or fasteners, typically found along the bottom edges and corners. ? Be careful not to pinch your fingers ❌ when securing.

Step 3: Apply Additional Covers

For sofas with separate seat/back cushions or modular sections, apply their respective covers. Drape the cover over the cushion or section and pull it into place. ? Ensure correct alignment and avoid pinching fingers ❌.

Step 4: Attach Side Panels

Attach the side panels to the main sofa base. Use the long threaded rods ? (Part #117175) to connect the panels securely.

Step 5: Insert Main Sofa Frame

Carefully slide the main sofa frame into the assembled base structure. Ensure it is properly seated. Use the assembly tool ?️ (Part #120202), nuts ⚙️ (Part #100712), and washers ⭕ (Part #100854) to secure the frame to the base.

Step 6: Attach Sofa Legs

Turn the assembled sofa upside down or tilt it carefully. Attach the four leg bases ? (Part #121236) to the designated points on the underside of the sofa frame.

A separate component, possibly a storage unit or drawer, is shown with a strap. Its specific assembly step is not detailed here but may be part of a modular configuration.

Step 7: Apply Seat Cushion Covers

Take the covers for the seat cushions. Carefully slide them onto the cushions, aligning the seams. Pull the cover taut and smooth it out.

Step 8: Place Back Cushions

Place the back cushions onto the sofa frame. Ensure they are oriented correctly. The diagram shows a zipper ? detail for securing the cushion cover. ? Ensure the cushion is placed correctly and the cover is aligned.

Step 9: Apply Back Cushion Covers

Take the covers for the back cushions. Carefully slide them onto the cushions, aligning the seams. Pull the cover taut and smooth it out. Use the zipper ? to close the cover securely.

Step 10: Final Cushion Placement

Place the back cushions onto the sofa. The diagram shows the back cushions being lowered into position, with a zipper ? detail visible.

Final Adjustments

Adjust the seat and back cushions to ensure they are properly settled and aligned for comfort and appearance. The diagram shows hands pushing the cushions into place.

The final assembled sofa is shown.

Product Information and Configurations

The KIVIK sofa can be configured in various ways, including as a 2-seat sofa, a 3-seat sofa, or with a chaise longue attachment.

Document Information:

© Inter IKEA Systems B.V. 2009

Date: 2020-12-02

Document Number: AA-448712-4
