Studio 5000 Architect Getting Results Guide

Getting Results Guide

Original Instructions

Studio 5000 Architect Getting Results Guide
Important User Information
Read this document and the documents listed in the additional resources section about installation, configuration, and operation of this equipment before you install, configure, operate, or maintain this product. Users are required to familiarize themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws, and standards. Activities including installation, adjustments, putting into service, use, assembly, disassembly, and maintenance are required to be carried out by suitably trained personnel in accordance with applicable code of practice. If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment. The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many variables and requirements associated with any particular installation, Rockwell Automation, Inc. cannot assume responsibility or liability for actual use based on the examples and diagrams. No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits, equipment, or software described in this manual. Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell Automation, Inc., is prohibited. Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
WARNING: Identifies information about practices or circumstances that can cause an explosion in a hazardous environment, which may lead to personal injury or death, property damage, or economic loss.
ATTENTION: Identifies information about practices or circumstances that can lead to personal injury or death, property damage, or economic loss. Attentions help you identify a hazard, avoid a hazard, and recognize the consequence.
IMPORTANT Identifies information that is critical for successful application and understanding of the product. Labels may also be on or inside the equipment to provide specific precautions.
SHOCK HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that dangerous voltage may be present.
BURN HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that surfaces may reach dangerous temperatures.
ARC FLASH HAZARD: Labels may be on or inside the equipment, for example, a motor control center, to alert people to potential Arc Flash. Arc Flash will cause severe injury or death. Wear proper Personal Protective Equipment (PPE). Follow ALL Regulatory requirements for safe work practices and for Personal Protective Equipment (PPE).

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Studio 5000 Architect Getting Results Guide
Summary of changes
This manual includes new and updated information. Use these reference tables to locate changed information. Grammatical and editorial style changes are not included in this summary.

New or enhanced features

This table contains a list of topics changed in this version, the reason for the change, and a link to the topic that contains the changed information.

Topic Name

Reason

New Controller Graphic on page 35
Common module configuration errors on page 88 Errors during commit and update on page 106

Added rule changes of 1768/1769 CompactLogix controller multiple bank slots. Added error message and solution for module configuration failure.
Added error message and solution for commit operation failure.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Table of Contents

About Studio 5000 Architect software

Chapter 1
Hardware Diagram....................................................................................12 Project Explorer .........................................................................................12 Toolbox ....................................................................................................... 13 Add, import, and remove components ..................................................... 15

Chapter 2

Install and activate Studio 5000 System requirements ................................................................................ 17

Architect software

Install Studio 5000 Architect software.....................................................18 Activate Studio 5000 Architect software..................................................19

Create, open, save, and close projects

Chapter 3
Studio 5000 Architect projects..................................................................21 Create a project ......................................................................................... 22 Open a project ............................................................................................23 Save a project ............................................................................................. 24 Close a project............................................................................................ 24 Project Update ........................................................................................... 24

Add hardware diagrams

Chapter 4
Optimize Network Layout........................................................................ 27 Add a hardware diagram .......................................................................... 28 Open a hardware diagram ........................................................................ 28 Navigate a hardware diagram .................................................................. 28 Show or hide the grid ................................................................................ 29 Enable or disable snap to grid .................................................................. 29 Close a hardware diagram ........................................................................ 29 Remove a hardware diagram.................................................................... 30 Diagram Overview .................................................................................... 30 Hardware Diagram ................................................................................... 30

Add new components

Chapter 5
Add 1756 ControlLogix hardware..............................................................33 Add a 1756 ControlLogix chassis .........................................................33 Add a 1756-L6x or L7x ControlLogix controller ..................................34 Add a 1756-L8x ControlLogix controller .............................................35 New Controller Graphic.......................................................................35
Add 176x/5069 CompactLogix hardware...................................................37 Add a 1768-L4x CompactLogix controller ...........................................37 Add a 1769-L1x CompactLogix controller........................................... 38

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Table of Contents 6

Add a 1769-L23x CompactLogix controller ........................................ 38 Add a 1769-L24x or L27x CompactLogix controller ............................39 Add a 1769-L3x CompactLogix controller .......................................... 40 Add a 5069-L3x CompactLogix controller .......................................... 41 Add a 5069-AEN2TR communication module ................................... 41 Add an expansion slot ......................................................................... 42 New Controller Graphic...................................................................... 42 New 5069-AEN2TR Graphic ................................................................43 Add modules ...............................................................................................44 Add a module........................................................................................44 About unsupported modules...............................................................45 Add Kinetix servo drives ............................................................................45 Add a Kinetix servo drive.................................................................... 46 New Servo Drive Graphic ................................................................... 46 Add PowerFlex drives.................................................................................47 Add a PowerFlex drive .........................................................................47 New PowerFlex Graphic ..................................................................... 48 Add PanelView Plus and MobileView graphic terminals ....................... 48 Add a PanelView Plus graphic terminal ............................................ 48 Add a MobileView graphic terminal .................................................. 49 New PanelView Plus Graphic ............................................................. 50 New PanelView Plus Project............................................................... 50 New MobileView Graphic.................................................................... 51 New MobileView Project ..................................................................... 51 PanelView Plus Properties settings .................................................... 51 MobileView Properties settings ......................................................... 52 Add computers........................................................................................... 52 Add a computer ................................................................................... 52 New Computer Graphic.......................................................................53 Add visualization stations and servers .....................................................53 Add a FactoryTalk View Site Edition Station.....................................53 Add a FactoryTalk View Machine Edition Station.............................54 Add a FactoryTalk View Site Edition Server Project..........................55 Add a FactoryTalk Linx Server Project................................................56 Add a Tag Alarm and Event Server project ........................................57 New Site Edition Project .................................................................... 58 New Machine Edition Station Project ................................................59 New Tag Alarm and Event Server Project ..........................................59 New FactoryTalk Linx Server Project .................................................59 FactoryTalk View Site Edition Project settings ................................ 60 FactoryTalk View Machine Edition Project settings ......................... 61 Tag Alarm and Event Server General settings ................................... 61
Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Table of Contents
Tag Alarm and Event Server Priorities settings ............................... 62 FactoryTalk Linx Server General settings ......................................... 62 FactoryTalk Linx Server Alarms and Events settings........................63

Import existing components

Chapter 6
Import a controller project from a file .....................................................65 Import a controller project from an online controller ........................... 66 Import a FactoryTalk View application from a file..................................67 Select Online Controller to Import ...........................................................67 Choose Matching Controller Configuration File .................................... 68 Confirm Update Changes ......................................................................... 68 Add Existing FactoryTalk View Project ................................................... 69

Add networks

Chapter 7
Add a managed Ethernet switch............................................................... 71 Add an unmanaged Ethernet switch....................................................... 72 Add a Generic switch................................................................................. 72 Add a network trunk ..................................................................................73 Connect Ethernet components .................................................................73 Connect components to a network trunk ................................................74 Add an Ethernet Tap ..................................................................................74 New Generic Switch Graphic ....................................................................74 Switch Configuration.................................................................................75

Add relationships and tags

Chapter 8
About ownership relationships.................................................................77 About producer/consumer relationships.................................................79 About shortcuts ..........................................................................................81 Add an ownership relationship ................................................................ 83 Add a producer/consumer relationship................................................... 83 Add a shortcut............................................................................................ 84 Add a produced and consumed tag.......................................................... 85 Add a point tag........................................................................................... 86 Add an axis tag........................................................................................... 86 Edit a produced and consumed tag ......................................................... 87 Edit a shortcut ........................................................................................... 87 Common module configuration errors ................................................... 88 Ethernet node limitations ........................................................................ 88 Configure Module ..................................................................................... 89 Produce/Consume Tags ............................................................................ 90 Consumer Tag ............................................................................................ 91 Producer Tag...............................................................................................91

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Table of Contents

I/O Aliases .................................................................................................. 92 Communications ........................................................................................ 93 Add New or Modify Existing Shortcut......................................................93

Customize a hardware diagram

Chapter 9
Add a graphic..............................................................................................95 Add a file .....................................................................................................95 Add a text box ............................................................................................ 96 Add a shape ................................................................................................ 96 Add a link ....................................................................................................97 Text Box Properties ....................................................................................97 Supported graphic formats .......................................................................97 Element Properties.................................................................................... 98

Commit and update hardware diagrams

Chapter 10
Commit a hardware diagram................................................................... 99 Update a hardware diagram .................................................................. 100 Update a hardware diagram with an online controller ........................ 101 Commit a single project...........................................................................102 Update a single project ............................................................................103 Output ....................................................................................................... 103 Select Online Controller to Update.........................................................104 Auto Find Matching Controller ...............................................................105 Choose Matching Controller Configuration File ...................................105 Errors during commit and update..........................................................106 FactoryTalk View commit validation rules.............................................107 Shortcut commit validation rules ...........................................................107

Create and use libraries
8

Chapter 11
Create a new library.................................................................................109 Rename a library ...................................................................................... 110 Import a library ........................................................................................ 110 Delete a library...........................................................................................111 Export a library..........................................................................................111 Export part of a library............................................................................. 112 Create a new folder .................................................................................. 112 Rename a folder.........................................................................................113 Delete a folder............................................................................................113 Add a component to a library .................................................................. 114 Import a component to a library ............................................................. 115 Copy library components from Studio 5000 Architect software to Logix Designer software .................................................................................... 115
Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Table of Contents
Copy library components from Studio 5000 Architect software to FactoryTalk View Studio software .......................................................... 116 Rename a component .............................................................................. 116 Delete a component ..................................................................................117 View component properties .....................................................................117 Replace an AOI in the current project .....................................................117 Show references to AOIs and UDTs ........................................................ 118 Toolbox ...................................................................................................... 119 Create New Library ..................................................................................120

Search and print project information

Chapter 12
View relationships ................................................................................... 121 Print a hardware diagram .......................................................................122 Search a project........................................................................................122 Print search results...................................................................................122 Filter the Toolbox...................................................................................... 123 Find............................................................................................................ 123 Find Results .............................................................................................. 123 Print Preview ............................................................................................ 124

Set Studio 5000 Architect options

Chapter 13
Project Settings ........................................................................................ 127 Hardware Diagram..................................................................................128 User Prompts............................................................................................ 129 Libraries ....................................................................................................130

Appendix A

Log on, log off, and set security Studio 5000 Architect software and FactoryTalk Security Single Sign-

policies

On ............................................................................................................... 131

Log on to FactoryTalk .............................................................................. 132

Change the logged on user account ........................................................ 132

Change a password .................................................................................. 133

Log off Studio 5000 Architect software .................................................. 133

Set FactoryTalk Directory permissions .................................................. 134

Set Studio 5000 Architect permissions .................................................. 134

Set Logix Designer permissions.............................................................. 135

Set FactoryTalk View SE permissions..................................................... 136

Set FactoryTalk View ME permissions ................................................... 136

Studio 5000 Architect Feature Security policies .................................... 137

Required Studio 5000 Architect permissions ........................................ 137

Required Logix Designer policies and permissions for Studio 5000

Architect software .................................................................................... 138

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Table of Contents
Legal Notices Index

Required FactoryTalk View SE permissions for Studio 5000 Architect software..................................................................................................... 139 Required FactoryTalk View ME permissions for Studio 5000 Architect software..................................................................................................... 139 Log on to FactoryTalk...............................................................................140 Legal Notices ............................................................................................ 141

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 1
About Studio 5000 Architect software

Studio 5000 Architect� software is a tool for creating the basic I/O and communication configurations for automation systems. Use the visual editing system in Studio 5000 Architect software to rapidly assemble and connect control hardware, I/O modules, and visualization devices.
Use Studio 5000 Architect software to create and import ControlLogix�, CompactLogixTM, Compact I/OTM, FLEXTM I/O, FLEX ExTM, POINT I/OTM, GuardLogix�, Kinetix�, and PowerFlex� controllers, modules, and drives. Edit chassis positions, firmware settings, I/O aliases, and network configurations in Studio 5000 Architect software. Launch Studio 5000� Logix Designer software to edit program logic and advanced configurations.
Studio 5000 Architect can also create and import FactoryTalk� View Site Edition and FactoryTalk View ME visualization projects, including PanelViewTM Plus graphic terminals, MobileViewTM graphic terminals, FactoryTalk� LinxTM and FactoryTalk Alarms and Events servers. Edit screen resolution, areas, shortcuts, and network configuration in Studio 5000 Architect. Launch FactoryTalk� View Studio to edit application screens and program logic.
Connect components using ControlNetTM network trunks or EtherNet/IPTM networks using generic or StratixTM switches. Once connected, configure ownership relationships, producer/consumer relationships, and shortcuts so that devices share tags across the network.
Studio 5000 Architect can import components from EPLAN� or Integrated Architecture� Builder and export components to EPLAN. Custom components such as Add-On Instructions (AOI), User-Defined Types (UDT), Displays, Global Objects, and Images can be exchanged between Logix Designer software, FactoryTalk View Studio software, and the Rockwell Automation Process Library.
Import automation system data into Studio 5000 Architect and export out of Studio 5000 Architect using OWL (.rdf), AML (.aml), XML (.xml) files.

See also
Install and activate Studio 5000 Architect software on page 17 Create, open, save, and close projects on page 21

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 1

About Studio 5000 Architect software

Add hardware diagrams on page 27

Add new components on page 33

Add relationships and tags on page 77

Hardware Diagram

How do I open Hardware Diagram?
� In Project Explorer, expand the Devices folder, then select a hardware diagram.

Use Hardware Diagram to view and organize components that are added to a Studio 5000 Architect project. If multiple hardware diagrams are open simultaneously, switch between them using the tabs at the top of Hardware Diagram.

A large hardware diagram can exceed the display area in Hardware Diagram. Use the scroll bars or Diagram Overview to navigate to a section of a hardware diagram.

Project Explorer

See also
Add a hardware diagram on page 28 Open a hardware diagram on page 28 Diagram Overview on page 30 How do I open Project Explorer? � From the View menu, select Project Explorer.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 1

About Studio 5000 Architect software

Use Project Explorer to view or edit the contents of a Studio 5000 Architect project.

Item

Name

Description

FactoryTalk View applications Logix Designer projects Devices

An alphabetical list of FactoryTalk View applications associated with this Studio 5000 Architect project. If Arrange Projects by Hardware Diagram is enabled, projects are grouped by hardware diagram (shown). An alphabetical list of Logix Designer projects associated with this Studio 5000 Architect project, grouped by hardware diagram. An alphabetical list of devices in this Studio 5000 Architect project, grouped by hardware diagram.

Components

An alphabetical list of hardware components added to a hardware diagram, such as chassis, controllers, modules, computers, PanelView Plus and MobileView terminals.

Toolbox

See also

Add, import, and remove components on page 15
How do I open Toolbox?
� From the View menu, select Toolbox. Use Toolbox to view default hardware components or add, remove, and manage custom libraries. Drag components from the Toolbox to a Hardware Diagram to add components to a project.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 1

About Studio 5000 Architect software
Components shown in gray are either unsupported in Studio 5000 Architect software or require a version of Logix Designer software that is not installed on the system.

Item

Name

Filter

Product Catalog Libraries

The Toolbox sections are:
Description
Enter a catalog number or name to show matching Logix Designer, FactoryTalk View Studio, and library components. A list of Logix Designer and FactoryTalk View Studio components that can be added to a hardware diagram. A list of libraries containing components that can be added to a hardware diagram or a Logix Designer or FactoryTalk View Studio project.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Add, import, and remove components

See also

Chapter 1

About Studio 5000 Architect software

Filter the Toolbox on page 123
Add, import, and remove components on page 15
Create a new library on page 109
Import a library on page 110
A Studio 5000 Architect project contains one or more components. Each component represents a hardware device, software project, visualization server, or document. Components appear in Hardware Diagram and Project Explorer.
Add components from a library or import from a file or online controller. Once part of a project, connect components to networks and configure relationships to share tags and control an automation system.
Components that are no longer in use can be removed from a project.

See also
Add 1756 ControlLogix hardware on page 33 Add modules on page 44 Add PanelView Plus and MobileView graphic terminals on page 48 Add visualization stations and servers on page 53

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 2
Install and activate Studio 5000 Architect software

Install and activate Studio 5000 Architect software on a computer that meets the system requirements to begin designing automation systems.

System requirements

See also
System requirements on page 17
Install Studio 5000 Architect software on page 18
Activate Studio 5000 Architect software on page 19
To run Studio 5000 Architect software version 5.00.00, the host computer must meet the hardware, software, and firmware requirements. For the latest compatibility information, refer to the Product Compatibility and Download Center.

Hardware requirements
Studio 5000 Architect software requires the following hardware:
� Intel� Core 2 Duo, 2.8 Ghz processor � 1 GB of memory � 16 GB free hard disk space � 1024x768, True color graphics device

Software requirements
Studio 5000 Architect software requires the following operating systems:
� Windows� 10 Professional (64-bit) � Windows 10 Enterprise (64-bit) � Windows Server� 2019 Standard � Windows Server� 2019 Datacenter � Windows Server 2016 Standard � Windows Server 2016 Datacenter � Windows Server 2012 Standard � Windows Server 2012 Datacenter

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 2

Install and activate Studio 5000 Architect software
� Windows Server 2012 R2 Standard � Windows Server 2012 R2 Datacenter
* See Studio 5000 Architect Release Notes for anomalies.
Studio 5000 Architect software is compatible with these Rockwell Automation products:
� FactoryTalk� Services Platform version 3.00.00 and 6.20.00 � FactoryTalk� Activation Manager version 4.04 � RSLogix 5000� version 20.00.00 � Logix Designer versions 21.03.01, 23.00.00, and 24.00 through 33.00.00 � FactoryTalk View versions 8.10.00 through 12.00.00 � FactoryTalk� Alarms and Events versions 2.74.00 through 6.20.00 � RSLinx� Enterprise version 5.74.00 through 5.90.00 � RSLinx� Classic version 4.12.00 � FactoryTalk� LinxTM version 6.20.00

Firmware requirements
Studio 5000 Architect software does not have any firmware requirements. Hardware and software products used in Studio 5000 Architect projects might place limits on firmware versions. Read the release notes for each product in the FactoryTalk system to determine firmware limitations.

Install Studio 5000 Architect software
18

See also
Product Compatibility and Download Center Install Studio 5000 Architect software on a computer that meets the system requirements to begin designing automation systems.
To install Studio 5000 Architect software:
1. Log on to the computer as a user with administrative privileges. 2. Run Setup.exe to start the Studio 5000 Architect installation program. 3. In Setup, select an installation option:
� Install now: Installs Studio 5000 Architect components using the recommended settings.
� Customize: Select which Studio 5000 Architect components to install, then select Install.
4. In End User License Agreements, read the license agreements, then select an option: � Accept all: Accept terms of all license agreements and continue installation.
Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Activate Studio 5000 Architect software

Chapter 2

Install and activate Studio 5000 Architect software

� Decline: Decline terms of all license agreements and cancel installation.

5. When installation is complete, select Finish.

See also
System requirements on page 17
Activate Studio 5000 Architect software on page 19
Studio 5000 Architect software is copy protected and must be activated using FactoryTalk Activation Manager software. When starting Studio 5000 Architect software, FactoryTalk Activation Manager software verifies its activation is valid. If Studio 5000 Architect software was not yet activated, use the software for a seven-day grace period with full functionality. If the grace period ends and Studio 5000 Architect software was not successfully activated, Studio 5000 Architect software does not start and an error is logged to FactoryTalk� Diagnostics.
If unable to complete the activation process from the computer where Studio 5000 Architect software is installed, obtain an activation from the Rockwell Automation Activation web site.

See also
Rockwell Automation Activation web site Legal Notices on page 141

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 3
Create, open, save, and close projects

Use the Studio 5000� Launcher to create or open a Studio 5000 Architect project. After designing an automation system, save and close the project.

Studio 5000 Architect projects

See also
About projects on page 21 Create a project on page 22 Open a project on page 23 Studio 5000 Architect projects are saved as a project file (.ADL) and a project folder containing related files. Studio 5000 Architect projects are composed of Hardware Diagrams and Components.

Hardware Diagrams
A hardware diagram is a collection of hardware, software, and reference components that represent an automation system. Creating a new Studio 5000 Architect project adds a hardware diagram automatically.
Hardware diagrams are displayed in Hardware Diagram and under the Projects and Devices folders in Project Explorer. As hardware diagrams are added, removed, and renamed, the corresponding folders in Project Explorer are added, removed, and renamed.

Components
Components are added to a hardware diagram to represent part of an automation system.
There are three types of components: hardware components, software components, and reference components.
Hardware components represent physical hardware, such as controllers, modules, computers, visualization devices, and networks. Hardware components are displayed in Hardware Diagram and in Project Explorer under Devices. Hardware components are stored as part of the Studio 5000 Architect project file.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 3

Create, open, save, and close projects
Software components represent Logix Designer and FactoryTalk View applications that run on hardware components. Software components are only shown in the Project Explorer tree under the Projects folder. Software components are stored as Logix Designer (.ACD) files and FactoryTalk View Studio project folders under the Studio 5000 Architect project folder. Edit the project files and folders using Logix Designer and FactoryTalk View Studio.
Changes made to software components in Studio 5000 Architect projects do not automatically show in Logix Designer projects or FactoryTalk View applications. Similarly, changes made to Logix Designer projects or FactoryTalk View applications do not automatically show in Studio 5000 Architect projects. To push changes from Studio 5000 Architect projects, commit the Studio 5000 Architect project. To pull changes from Logix Designer projects or FactoryTalk View applications, update the Studio 5000 Architect project.
Graphics, files, text boxes, shapes, and links are reference components that describe other components. Reference components are only shown in Hardware Diagram. Reference components are stored as part of the Studio 5000 Architect project file.

Create a project

See also
Create a project on page 22 Open a project on page 23 Add a hardware diagram on page 28 Add, import, and remove components on page 15 To design a new automation system, create a Studio 5000 Architect project. Studio 5000 Architect projects are stored in the logged in user's directory at Documents\Studio 5000\Projects by default.

To create a new project

1. Open Studio 5000. 2. Select New Project. 3. In the Project Types column, select Architect. 4. Select an Architect project template.
� Blank Project creates a new project with no components. � Distributed Architecture - Connected Enterprise creates a new
project with one engineering workstation, one operator workstation, one FactoryTalk View Site Edition server, and five FactoryTalk View Machine Edition stations. The FactoryTalk View server and stations control one 1756 ControlLogix controller and four 1769 CompactLogix controllers.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Open a project

Chapter 3

Create, open, save, and close projects

� Distributed Architecture - Multiple Process Servers creates a new project with one operator workstation and two Process Automation System Servers (PASS) servers. Each PASS server controls five 1756 ControlLogix controllers.
� Distributed Architecture - Single Process Server creates a new project with one operator workstation and one Process Automation System Server. The PASS server controls five 1756 ControlLogix controllers.
� Process Skid with Logix Batch Sequence Manager creates a new project with one PanelView Plus 7 graphic terminal that controls three 1769 CompactLogix controllers.

5. In Name, enter a name for the new project. 6. (optional) In Location, type or browse to a location to store the project
file. 7. Select Finish.

See also
Studio 5000 Architect projects on page 21
Add, import, and remove components on page 15
To edit an existing Studio 5000 Architect project, open it using Studio 5000. Studio 5000 Architect projects are stored in the current user's directory at Documents\Studio 5000\Projects by default. Each instance of Studio 5000 Architect software can have a single open project.
If the Studio 5000 Architect project contains Logix Designer or FactoryTalk View applications and those projects changed, Studio 5000 Architect software displays Project Update to update the hardware diagram.

To open a project
1. Open Studio 5000 software. 2. Select Existing Project. 3. From the list of file types, select Architect (.adl). 4. Navigate to the folder that contains the Studio 5000 Architect project
file. 5. Select the project from the list. 6. Select Open.

See also
Studio 5000 Architect projects on page 21 Close a project on page 24

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 3

Create, open, save, and close projects

Save a project on page 24

Project Update on page 24

Save a project

Saving a project records the locations, properties, relationships, and tags of all components in the Studio 5000 Architect project file. By default, Studio 5000 Architect projects are stored in the directory of the logged in user at Documents\Studio 5000\Projects.

Saving a project does not commit changes to Logix Designer projects or FactoryTalk View applications.

To save a project
1. From the File menu, select Save As. 2. (optional) In Save Project As, enter a name for the new project. 3. (optional) In Save Project As, select a location to store the project file. 4. Select Save.

Close a project

See also
Studio 5000 Architect projects on page 21 Commit a hardware diagram on page 99 Close a project on page 24 Each instance of Studio 5000 Architect software can have a single open project. To open a project in the same Studio 5000 Architect instance, first close the current project.

To close a project
� From the File menu, select Close.

Project Update
24

See also
Studio 5000 Architect projects on page 21 Save a project on page 24 Open a project on page 23 How do I open Project Update? � Project Update only appears when opening a Studio 5000 Architect project that contains Logix Designer or FactoryTalk View projects. If the Logix Designer or FactoryTalk View project has changed since the
Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 3

Create, open, save, and close projects

last time the Studio 5000 Architect project was opened, Studio 5000 Architect displays Project Update.

Use Project Update to select which controllers and project files overwrite components in the Studio 5000 Architect project. The Selected controller validation results table lists all the changes to be made to the Studio 5000 Architect project.

See also
Studio 5000 Architect projects on page 21 Update a hardware diagram on page 100

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Add hardware diagrams

Chapter 4

A hardware diagram is a grid that contains components representing an automation system. A Studio 5000 Architect project can contain many hardware diagrams, which can be open simultaneously as tabs in Hardware Diagram. Components must be on the same hardware diagram to communicate with each other.
If adding or moving components past the right or bottom edge of a hardware diagram, Studio 5000 Architect automatically expands the hardware diagram to a new page. Page breaks appear as dashed gray lines and do not print. When closing and reopening a hardware diagram, Studio 5000 Architect automatically shrinks the hardware diagram to the number of pages necessary to show the components in the hardware diagram.
Hardware diagrams are displayed in Hardware Diagram and under the Projects and Devices folders in Project Explorer.

Optimize Network Layout

See also
Add a hardware diagram on page 28
Open a hardware diagram on page 28
When manually configuring a hardware diagram, or adding or importing devices from a library or file, devices may appear in a random order and network cables may appear crossed. Optimize Network Layout repositions the devices and refines the network layout.
When importing data files into Studio 5000 Architect, the hardware diagram is optimized upon import.

To Optimize Network Layout
� Right-click in the hardware diagram and select Optimize Network Layout.

See also

Add, edit and remove hardware diagrams Open a hardware diagram on page 28

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 4

Add hardware diagrams

Add a hardware diagram

Import a controller project from an online controller on page 66
Add a hardware diagram to group a new set of components within the same Studio 5000 Architect project.

To add a hardware diagram
1. In Project Explorer, right-click on the Devices folder, then select New Hardware Diagram.
2. (optional) In Enter New Hardware Diagram Name, type a name for the new hardware diagram.
3. Select OK. The new hardware diagram appears in the Hardware Diagram and under the Project and Devices folders in Project Explorer.

Open a hardware diagram

See also
Add, import, and remove components on page 15 Remove a hardware diagram on page 30 Open a hardware diagram to view or edit its components.

To open a hardware diagram
� In Project Explorer, expand the Project or Devices folders, then select the hardware diagram to open.

Navigate a hardware diagram

See also
Add, import, and remove components on page 15 Print a hardware diagram on page 122 Close a hardware diagram on page 29 A large hardware diagram can exceed the display area in Hardware Diagram. Use Diagram Overview to quickly navigate to a section of a hardware diagram.

To navigate a hardware diagram
1. (optional) If Diagram Overview is not visible, select View > Diagram Overview.
2. In Diagram Overview, select to center Hardware Diagram at the selected location.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Show or hide the grid

See also

Chapter 4

Add hardware diagrams

Diagram Overview on page 30
Hardware Diagram on page 12
Snap to Grid aligns components vertically or horizontally on a hardware diagram according to grid lines. Show grid displays the alignment grid in the hardware diagram, Hide grid removes the grid lines from the hardware diagram display, so that only components are shown.
Components placed on the hardware diagram use the Snap to Grid setting even when the grid is hidden.

To show or hide the grid
� Below Hardware Diagram, select Hide grid or Show grid.

Enable or disable snap to grid

See also
Enable or disable Snap to Grid on page 29
When Snap to Grid is enabled, components dropped on the Hardware Diagram pane automatically align horizontally and vertically to the grid lines, even if the grid lines are hidden. When Snap to Grid is disabled, components are placed on the Hardware Diagram pane where they are dropped.

To enable or disable Snap to Grid
� Below Hardware Diagram, select Snap to grid or Turn off snap to grid.

See also

Close a hardware diagram

Show or hide the grid on page 29
Close a hardware diagram to hide a hardware diagram from view without closing the Studio 5000 Architect project.

To close a hardware diagram
� At the top of Hardware Diagram, right-click the name of the hardware diagram, then select Close.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 4

Add hardware diagrams

Remove a hardware diagram

See also
Open a hardware diagram on page 28
Remove a hardware diagram on page 30
Remove a hardware diagram to delete it and all associated hardware components and software projects from a Studio 5000 Architect project. The remove operation cannot be undone.

To remove a hardware diagram
1. In Project Explorer, expand the Devices folder, right-click on a hardware diagram, then select Delete.
2. In the confirmation prompt, select Yes.

Diagram Overview

See also
Add a hardware diagram on page 28
Close a hardware diagram on page 29
How do I open Diagram Overview?
� From the View menu, select Diagram Overview. Use Diagram Overview to quickly navigate large hardware diagrams. Diagram Overview shows the full contents of the active hardware diagram, including all devices, networks, and images.
The red rectangle in Diagram Overview represents the current view in Hardware Diagram. Clicking in Diagram Overview centers both the red rectangle and Hardware Diagram at the selected location.

Hardware Diagram

See also
Navigate a hardware diagram on page 28
Hardware Diagram on page 12
How do I open Hardware Diagram?
� In Project Explorer, expand the Devices folder, then select a hardware diagram.
Use Hardware Diagram to view and organize components that are added to a Studio 5000 Architect project. If multiple hardware diagrams are open simultaneously, switch between them using the tabs at the top of Hardware Diagram.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 4

Add hardware diagrams

A large hardware diagram can exceed the display area in Hardware Diagram. Use the scroll bars or Diagram Overview to navigate to a section of a hardware diagram.

See also
Add a hardware diagram on page 28 Open a hardware diagram on page 28 Diagram Overview on page 30

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Add new components

Chapter 5

A Studio 5000 Architect project contains one or more components. Each component represents a hardware device, software project, visualization server, or document. Components appear in Hardware Diagram and Project Explorer.
Add components to your project from the Toolbox, using the predefined components or an imported library. Once added, connect components to networks and configure relationships to share tags and control an automation system.
For a list of supported Logix Designer controllers, see Studio 5000 Architect Help.

Add 1756 ControlLogix hardware
Add a 1756 ControlLogix chassis

See also
Add 1756 ControlLogix hardware on page 33 Add modules on page 44 Add motion controls on page 45 Add PanelView Plus and MobileView graphic terminals on page 48 Add visualization stations and servers on page 53 Add a variety of 1756 ControlLogix hardware, including chassis, controllers, and modules to a Studio 5000 Architect project. Chassis, controllers, and modules appear in Hardware Diagram and Project Explorer. See also Add a 1756 ControlLogix chassis on page 33 Add a 1756-L6x or L7x ControlLogix controller on page 34 Add a 1756-L8x ControlLogix controller on page 35 Import a controller project from a file on page 65 Import a controller project from an online controller on page 66 Automation systems driven by 1756 ControlLogix controllers require one or more chassis to connect controllers and I/O modules.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

To add a 1756 ControlLogix chassis
1. In Toolbox, expand Product Catalog, Programmable Control Systems, 1756 ControlLogix/GuardLogix Systems, and Chassis.
2. Drag a chassis from Toolbox to Hardware Diagram. 3. (optional) In New Chassis Graphic, enter a unique name for the
chassis. 4. Select OK. The chassis appears in Hardware Diagram and Project
Explorer.

Add a 1756-L6x or L7x ControlLogix controller

See also
Add a 1756-L6x or L7x ControlLogix controller on page 34
Automation systems driven by 1756-L6x or L7x ControlLogix controllers require one or more controllers to manage inputs, outputs, and run applications.

Prerequisites
� Add a 1756 ControlLogix chassis

To add a 1756-L6x or L7x ControlLogix controller
1. In Toolbox, expand Programmable Control Systems and 1756 ControlLogix/GuardLogix Systems.
2. Expand either Controllers, Standard or Controllers, Safety. 3. Drag a 1756-L6x or L7x controller from Toolbox to an unused slot on a
chassis in Hardware Diagram. 4. (optional) In New Controller Graphic, configure the controller
settings:
� Name: Enter a unique name. � Controller Firmware Version: Select a firmware version. The
default value is the most recent firmware version. � ACD File Name: Enter a name for the Logix Designer project. The
default value is the controller name.
5. Select OK. In Hardware Diagram, the controller snaps into its slot in the chassis. Project Explorer shows the controller in Devices.

See also
Add a 1756 ControlLogix chassis on page 33 Add a module on page 44

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

New Controller Graphic on page 35

Add a 1756-L8x ControlLogix Automation systems driven by 1756-L8x ControlLogix controllers require one
or more controllers to manage inputs, outputs, and run applications.
controller

Prerequisites
� Add a 1756 ControlLogix chassis.

To add a 1756-L8x controller
1. In Toolbox, expand Programmable Control Systems and 1756 ControlLogix/GuardLogix Systems.
2. Expand Controllers, Standard. 3. Drag a 1756-L8x controller from Toolbox to an unused slot on a chassis
in Hardware Diagram. 4. (optional) In New Controller Graphic, configure the controller
settings:
� Name: Enter a unique name. � Controller Firmware Version: Select a firmware version. The
default value is the most recent firmware version. � ACD File Name: Enter a name for the Logix Designer project. The
default value is the controller name. � Address / Host Name: Select a network type, then enter an IP
address or host name.
5. Select OK. In Hardware Diagram, the controller snaps into its slot in the chassis. Project Explorer shows the controller in Devices.

New Controller Graphic

See also
Add a 1756 ControlLogix chassis on page 33 Add a module on page 44 New Controller Graphic on page 35 How do I open New Controller Graphic?

When adding a controller to a project
1. In Toolbox, expand the Programmable Control Systems, controller family and Controllers folders.
2. Drag the desired controller from Toolbox to the Hardware Diagram. 3. (optional) In Enter Name, type a unique name for the controller, then
click OK.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

When editing an existing 1769/68 CompactLogix controller

1. In the Hardware Diagram, right-click on a 1769/68 CompactLogix controller, then click Configure CompactLogix Chassis.

Use New Controller Graphic to set firmware, project, and hardware settings for a new controller. Edit these settings after the controller is added to the project.

Settings that do not apply to the controller are hidden.

Setting
Controller Firmware Version ACD File Name Bank 1

Description

Controllers

Sets the controller firmware version. Sets the name of the controller project (.acd) file. Contains the information of the first bank, for example, slot number, power supply, and cable type. Bank 1 is the parent chassis of the controller. If the system contains expansion banks, configure them in Bank 2 and Bank 3.

All All L3x and L4x

Bank 2 Bank 3 Slots Left
Slots Right
Power Supply Cable Type

Contains the information of the expansion bank, for example, slot number, power supply, and cable type. Contains the information of the expansion bank, for example, slot number, and power supply. Specifies the number of 1769 slots to the left of the power supply in the bank. The total number of slots to the left and slots to the right must be greater than zero. Specifies the number of 1769 slots to the right of the power supply in the bank. The total number of slots to the left and slots to the right must be greater than zero. Specifies the power supply catalog number. Specifies the cable type between banks. After selecting a cable type, the banks are connected automatically. There are three cable types, 1769-CRLx, 1769-CRRx, and 1769-CLLx, where x means the length of the cable (1 or 3): � 1769-CRLx: connection from the right side of one bank to the left side of the
next bank. � 1769-CRRx: connection from the right side of one bank to the right side of the
next bank. � 1769-CLLx: connection from the left side of one bank to the left side of the
next bank. This cable can be used only to connect banks 2 and 3.

L3x and L4x L3x and L4x L3x and L4x
L3x and L4x
L3x and L4x L3x and L4x

See also
Add a 1756-L6x or L7x ControlLogix controller on page 34 Add a 1756-L8x ControlLogix controller on page 35 Add a 1769-L3x CompactLogix controller on page 40 Add a 5069-L3x CompactLogix controller on page 41

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Add 176x/5069 CompactLogix hardware

Chapter 5

Add new components

Add a variety of 1768, 1769, and 5069 CompactLogix controllers, banks, expansion slots, and modules to a Studio 5000 Architect project. Controllers, banks, slots, and modules appear in Hardware Diagram and Project Explorer.

Add a 1768-L4x CompactLogix controller

See also
Add a 1769-L1x CompactLogix controller on page 38
Add a 1769-L23x CompactLogix controller on page 38
Add a 1769-L24x or L27x CompactLogix controller on page 39
Add a 1769-L3x CompactLogix controller on page 40
Add a 1768-L4x CompactLogix controller on page 37
Automation systems driven by 1768-L4x CompactLogix controllers require one or more controllers to manage inputs, outputs, and run applications.
To add a 1768-L4 CompactLogix controller
1. In Toolbox, expand Programmable Control Systems, 176x/5069 CompactLogix Systems, 1768 CompactLogix System, and either Controllers, Standard or Controllers, Safety.
2. Drag a controller from Toolbox to Hardware Diagram. 3. (optional) In New Controller Graphic, type a unique name for the
controller and then OK. 4. In New Controller Graphic, configure the controller settings, and
select OK: � (optional) Name: Enter a unique name. � (optional) Description: Enter a description. Cannot be longer than
128 characters. � Controller Firmware Version: Select a firmware version. The
default value is the most recent firmware version. � ACD File Name: Enter a name for the Logix Designer project. The
default value is the controller name. � Address / Host Name: Select a network type, then enter an IP
address or host name. 5. (optional) In New Bank Graphic, configure the controller settings:
� Slot Left: Enter the number of left slots for each bank. � Power Supply: Select the power supply for each bank. � Slot Right: Enter the number of right slots for each bank. � Cable Type: Select a type of cable to connect banks 1 and 2 or banks
2 and 3.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

6. Select OK. The CompactLogix controller, banks, slots, power supplies, and cables appear in Hardware Diagram. Project Explorer shows the CompactLogix controller, banks, slots, and power supplies in Hardware Diagrams.

Add a 1769-L1x CompactLogix controller

See also
Add an expansion slot on page 42
Add a module on page 44
Automation systems driven by 1769-L1x CompactLogix controllers require one or more controllers to manage inputs, outputs, and run applications.
To add a 1769-L1x CompactLogix controller
1. In Toolbox, expand Programmable Control Systems, 176x/5069 CompactLogix Systems, 1769 CompactLogix System, and Controllers, Standard.
2. Drag a controller from Toolbox to Hardware Diagram. 3. In New Controller Graphic, configure the controller settings:
� (optional) Name: Enter a unique name. � (optional) Description: Enter a description. Cannot be longer than
128 characters. � Controller Firmware Version: Select a firmware version. The
default value is the most recent firmware version. � ACD File Name: Enter a name for the Logix Designer project. The
default value is the controller name. � Address / Host Name: Select a network type, then enter an IP
address or host name. � Number of Expansion I/O Slots: Enter the number of expansion
slots. 4. Select OK. The CompactLogix controller, banks, and expansion slots
appear in Hardware Diagram. Project Explorer shows the CompactLogix controller, banks, and expansion slots in Devices.

Add a 1769-L23x CompactLogix controller

See also
Add an expansion slot on page 42 Add a module on page 44 Automation systems driven by 1769-L23x CompactLogix controllers require one or more controllers to manage inputs, outputs, and run applications.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

To add a 1769-L23x CompactLogix controller

1. In Toolbox, expand Programmable Control Systems, 176x/5069 CompactLogix Systems, 1769 CompactLogix System, and Controllers, Standard.
2. Drag a controller from Toolbox to Hardware Diagram. 3. In New Controller Graphic, configure the controller settings:
� (optional) Name: Enter a unique name. � (optional) Description: Enter a description. Cannot be longer than
128 characters. � Controller Firmware Version: Select a firmware version. The
default value is the most recent firmware version. � ACD File Name: Enter a name for the Logix Designer project. The
default value is the controller name. � Address / Host Name: Select a network type, then enter an IP
address or host name. � Number of Expansion I/O Slots: Enter the number of expansion
slots.
4. Select OK. The CompactLogix controller, banks, and expansion slots appear in Hardware Diagram. Project Explorer shows the CompactLogix controller, banks, and expansion slots in Devices.

Add a 1769-L24x or L27x CompactLogix controller

See also
Add an expansion slot on page 42
Add a module on page 44
Automation systems driven by 1769-L24x or L27x CompactLogix controllers require one or more controllers to manage inputs, outputs, and run applications.

To add a 1769-L24x or L27x CompactLogix controller
1. In Toolbox, expand Programmable Control Systems, 176x/5069 CompactLogix Systems, 1769 CompactLogix System, and Controllers, Standard.
2. Drag a controller from Toolbox to Hardware Diagram. 3. In New Controller Graphic, configure the controller settings:
� (optional) Name: Enter a unique name. � (optional) Description: Enter a description. Cannot be longer than
128 characters. � Controller Firmware Version: Select a firmware version. The
default value is the most recent firmware version.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

� ACD File Name: Enter a name for the Logix Designer project. The default value is the controller name.
� Address / Host Name: Select a network type, then enter an IP address or host name.
� Number of Expansion I/O Slots: Enter the number of expansion slots.
4. Select OK. The CompactLogix controller, banks, and expansion slots appear in Hardware Diagram. Project Explorer shows the CompactLogix controller, banks, and expansion slots in Devices.

Add a 1769-L3x CompactLogix controller

See also
Add an expansion slot on page 42
Add a module on page 44
Automation systems driven by 1769-L3x CompactLogix controllers require one or more controllers to manage inputs, outputs, and run applications.
To add a 1769-L3x CompactLogix controller
1. In Toolbox, expand Programmable Control Systems, 176x/5069 CompactLogix Systems, 1769 CompactLogix System, and either Controllers, Standard or Controllers, Safety.
2. Drag a controller from Toolbox to Hardware Diagram. 3. In New Controller Graphic, configure the controller settings, then
click OK: � (optional) Name: Enter a unique name. � (optional) Description: Enter a description. Cannot be longer than
128 characters. � Controller Firmware Version: Select a firmware version. The
default value is the most recent firmware version. � ACD File Name: Enter a name for the Logix Designer project. The
default value is the controller name. � Address / Host Name: Select a network type, then enter an IP
address or host name. 4. (optional) In New Bank Graphic, configure the bank settings:
� Slot Left: Enter the number of left slots for each bank. � Power Supply: Select the power supply for each bank. � Slot Right: Enter the number of right slots for each bank. � Cable Type: Select a type of cable to connect banks 1 and 2 or banks
2 and 3.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

5. Select OK. The CompactLogix controller, banks, slots, power supplies, and cables appear in Hardware Diagram. Project Explorer shows the CompactLogix controller, banks, slots, and power supplies in Devices.

Add a 5069-L3x CompactLogix controller

See also
Add an expansion slot on page 42
Add a module on page 44
Automation systems driven by 5069-L3x CompactLogix controllers require one or more controllers to manage inputs, outputs, and run applications.
To add a 5069-L3x CompactLogix bank
1. In Toolbox, expand Programmable Control Systems, 176x/5069 CompactLogix Systems, 5069 CompactLogix System, and Controllers.
2. Drag a controller from Toolbox to Hardware Diagram. 3. In New Controller Graphic, configure the controller settings, then
select OK: � (optional) Name: Enter a unique name. � (optional) Description: Enter a description. Cannot be longer than
128 characters. � Controller Firmware Version: Select a firmware version. The
default value is the most recent firmware version. � ACD File Name: Enter a name for the Logix Designer project. The
default value is the controller name. � Address / Host Name: Select a network type, then enter an IP
address or host name. � Number of Expansion I/O Slots: Enter the number of expansion
slots. 4. Select OK. The CompactLogix controller, banks, and slots, appear in
Hardware Diagram. Project Explorer shows the CompactLogix controller, banks, and slots in Devices.

Add a 5069-AEN2TR communication module

See also
Add an expansion slot on page 42 Add a module on page 44 Add a 5069-AEN2TR communication module to connect remote modules to a 5069 controller.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

To add a 5069-AEN2TR communication module
1. In Toolbox, expand Programmable Control Systems, 176x/5069 CompactLogix Systems, 5069 CompactLogix System, and Communication Modules.
2. Drag the 5069-AEN2TR communication module from Toolbox to Hardware Diagram.
3. In New 5069-AEN2TR Graphic, configure the module settings, then select OK:
� (optional) Name: Enter a unique name. � Number of Expansion I/O Slots: Enter the number of expansion
slots.
4. Select OK. The 5069-AEN2TR, 5069 CompactLogix bank and slots appear in Hardware Diagram. Project Explorer shows the CompactLogix controller, banks, and slots in Devices.

Add an expansion slot

See also
New 5069-AEN2TR Graphic on page 43
Before adding a module to a 1769/68 CompactLogix bank or POINT I/OTM communication module, the controller must have an available expansion slot. Each controller has a certain number of expansion slots. Once a controller has reached its limit of expansion slots no further expansion slots can be added.

To add an expansion slot
� In Hardware Diagram, right-click the controller or an existing expansion slot, then select Insert Empty Slot After. A new expansion slot appears.

New Controller Graphic

See also
Add 176x/5069 CompactLogix hardware on page 37 How do I open New Controller Graphic?

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Setting Controller Firmware Version ACD File Name Bank 1
Bank 2 Bank 3 Slots Left
Slots Right
Power Supply Cable Type

Chapter 5

Add new components

When editing an existing 1769/68 CompactLogix controller

1. In the Hardware Diagram, right-click on a 1769/68 CompactLogix controller, then click Configure CompactLogix Chassis.

Use New Controller Graphic to set firmware, project, and hardware settings for a new controller. Edit these settings after the controller is added to the project.

Settings that do not apply to the controller are hidden.

Description

Controllers

All All L3x and L4x

L3x and L4x L3x and L4x L3x and L4x
L3x and L4x
L3x and L4x L3x and L4x

See also

New 5069-AEN2TR Graphic

Add a 1756-L6x or L7x ControlLogix controller on page 34 Add a 1756-L8x ControlLogix controller on page 35 Add a 1769-L3x CompactLogix controller on page 40 Add a 5069-L3x CompactLogix controller on page 41 How do I open New 5069-AEN2TR Graphic?

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

1. In Toolbox, expand Programmable Control Systems, 176x/5069 CompactLogix Systems, 5069 CompactLogix System, and Communication Modules.
2. Drag the 5069-AEN2TR communication module from Toolbox to Hardware Diagram.
Use New 5069-AEN2TR Graphic to set a name and number of expansion slots for a new 5069-AEN2TR communication module.

Add modules Add a module

See also
Add a 5069-AEN2TR communication module on page 41
Add or remove modules for 1756 ControlLogix, 1769/68 CompactLogix, 1794/97 FLEX I/O, and 1734 POINT I/O hardware. Although modules can be added to a project without a related chassis or controller, most modules require a controller to operate properly. Modules appear in Hardware Diagram and Project Explorer.
See also
Add a module on page 44
About unsupported modules on page 45
Automation systems require one or more modules to drive inputs, outputs, or handle communications.

Prerequisites
� Add 1756 ControlLogix, 1769/68 CompactLogix, 1794/97 FLEX I/O, or 1734 POINT I/O hardware to the project.

To add a module
1. In Toolbox, expand the product family and module type. 2. Drag the module from Toolbox to an unused slot on a chassis, bank, or
DIN rail in Hardware Diagram.
Tip: The unused slot turns green if it is compatible or red if it is not compatible.
3. (optional) In New Module Graphic, enter a unique name for the module, then select OK. In Hardware Diagram, the module snaps into its slot in the chassis. Project Explorer shows the module in Projects and Devices.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

See also

Chapter 5

Add new components

About unsupported modules on page 45

About unsupported modules Modules updated or imported from a controller or Logix Designer project
may not be supported in Studio 5000 Architect. When a module is not supported, Studio 5000 Architect displays an unsupported module image in the appropriate chassis, DIN rail, or expansion slot.

Unsupported modules have these limitations:

� Cannot change the properties of unsupported modules.

� Cannot move unsupported modules to another chassis, DIN rail, or

expansion slot.

� Cannot cut, copy, or paste unsupported modules. However, cutting or

copying its chassis or DIN rail copies the unsupported module.

For this family of devices:

Studio 5000 Architect displays this image:

1756 ControlLogix

1768/69 CompactLogix

1794/97 FLEX I/O

Add Kinetix servo drives

See also
Add a module on page 44 Import a controller project from a file on page 65 Import a controller project from an online controller on page 66 Update a hardware diagram on page 100 Add Kinetix servo drives to operate multi-axis motion controls using a Logix Designer project. Servo drives appear in Hardware Diagram and Project Explorer.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

Important:

Using Kinetix drives in Studio 5000 Architect software requires Logix Designer 24.x through 33.x.

Add a Kinetix servo drive

See also

Add a Kinetix servo drive on page 46

Add a Kinetix servo drive to run multi-axis motion controls from a Logix Designer project.

Important:

Using Kinetix drives in Studio 5000 Architect software requires Logix Designer 24.x through 33.x.

To add a Kinetix servo drive:
1. In Toolbox, expand Motion Control and Servo Drives. 2. Expand the drive type and Kinetix product family. 3. Drag a servo drive from Toolbox to Hardware Diagram. 4. In New Servo Drive Graphic, configure the drive settings:
� (optional) Name: Enter a unique name. � (optional) Description: Enter a description. Cannot be longer than
128 characters. � Address / Host Name: Select a network type, then enter an IP
address or host name. � (optional) Change DC BUS Supply/Line Filter: Select either Single
or Multiple supply/line filters, then select a power supply.
5. Select OK. The servo drive appears in Hardware Diagram. Project Explorer shows the servo drive in Devices.

New Servo Drive Graphic

See also

New Servo Drive Graphic on page 46

How do I open New Servo Drive Graphic?

1. In Toolbox, expand Motion Control and Servo Drives. 2. Expand the drive type and Kinetix product family. 3. Drag a servo drive from Toolbox to Hardware Diagram.

Use New Servo Drive Graphic to set description, and network settings for a new servo drive.

Important:

Using Kinetix drives in Studio 5000 Architect software requires Logix Designer 24.x through 33.x.

The Kinetix Servo Drives Configuration settings are:

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Setting Type Vendor Name Description Change DC BUS Supply/Line Filter Address/Host Name
Add PowerFlex drives
Add a PowerFlex drive

Chapter 5

Add new components

Description

Sets the type of the servo drive. Shows the vendor information of the servo drive. Sets the name of the servo drive.

Sets the description of the servo drive. Cannot be longer than 128 characters. Sets the number and type of power supply/line filters for the servo drive. Only shown for Kinetix 5700 devices. Sets the network configuration of the servo drive. � Private Network: Select the value from the list, from 1 to 254. � IP Address: Enter a unique IP address to identify the servo drive on the IP network. � Host Name: Enter a fully qualified domain name, such as
servodrive.yourcompany.com.

See also

Add a Kinetix servo drive on page 46

Add a PowerFlex drive to connect and control it in a FactoryTalk system.

Important:

Using PowerFlex drives in Studio 5000 Architect software requires Logix Designer 24.x through 33.x.

See also

Add a PowerFlex drive on page 47

New PowerFlex Graphic on page 48

Add a PowerFlex drive to control it from a Logix Designer project.

Important:

Using PowerFlex drives in Studio 5000 Architect software requires Logix Designer 24.x through 33.x.

To add a PowerFlex drive
1. In Toolbox, expand Drives and Drives, AC Low Voltage. 2. Expand either Architecture Drives or Compact Drives, then expand
the product family folder. 3. Drag the drive from Toolbox to Hardware Diagram. 4. In New PowerFlex Graphic, configure the PowerFlex settings:
� (optional) Name: Enter a unique name. � (optional) Description: Enter a description. Cannot be longer than
128 characters. � Address / Host Name, set the IP address or host name for the drive.
5. Select OK. The drive appears in the Hardware Diagram pane. Project Explorer shows the drive in Devices.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

See also

New PowerFlex Graphic
Field Name Description Address / Host Name Always show this dialog

New PowerFlex Graphic on page 48

How do I open New PowerFlex Graphic?

1. In Toolbox, expand Drives and Drives, AC Low Voltage. 2. Expand either Architecture Drives or Compact Drives, then expand
the product family folder. 3. Drag the drive from Toolbox to Hardware Diagram.

Use New PowerFlex Graphic to add PowerFlex drives to a hardware diagram.

Important:

Using PowerFlex drives in Studio 5000 Architect software requires Logix Designer 24.x through 33.x.

The New PowerFlex Graphic settings are:

Description
Sets a unique name for the drive. Sets the description for the drive. Cannot be longer than 128 characters. Sets the IP address or host name for the drive. If unchecked, New PowerFlex Graphic does not open the next time a drive is added to the Hardware Diagram. New drives use the default settings.

Add PanelView Plus and MobileView graphic terminals
Add a PanelView Plus graphic terminal

See also
Add a PowerFlex drive on page 47 Add or remove PanelView Plus and MobileView graphic terminals to the project. Adding a PanelView Plus or MobileView terminal creates a new FactoryTalk View ME application.
See also
Add a PanelView Plus graphic terminal on page 48 Add a MobileView graphic terminal on page 49 Add a variety of PanelView Plus graphic terminals to a Studio 5000 Architect project. Adding a PanelView Plus terminal creates a new FactoryTalk View ME application.

To add a PanelView Plus graphic terminal

1. In Toolbox, expand Visualization and Graphic Terminals. 2. Expand the PanelView Plus model family and size items. 3. Drag a PanelView Plus model from Toolbox to Hardware Diagram. 4. In New PanelView Plus Graphic, configure settings for the PanelView
Plus terminal:

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

� (optional) Name: Enter a unique name for the terminal. � (optional) Description: Enter a description of the terminal. Cannot
be longer than 128 characters. � IP Address: Enter a static IP address for the terminal. � (optional) Catalog Number: Select a catalog number from the list.

5. Click OK. 6. In New PanelView Plus Project, configure settings for the new
FactoryTalk View ME application:

� Name: Enter a unique name for the application. Studio 5000 Architect creates a new FactoryTalk View ME application.
� (optional) Description: Enter a description of the application. Cannot be longer than 128 characters.
� (optional) Scale Replace Displays: Select to scale objects in Replace displays to the resolution of the panel.
� (optional) Scale OnTop Displays: Select to scale objects in OnTop displays to the resolution of the panel.
� (optional) Language: Select a language for the application.

7. Select OK. The PanelView Plus graphic terminal appears in Hardware Diagram and in Project Explorer under Devices. The FactoryTalk View ME application appears in Project Explorer under Projects.

Add a MobileView graphic terminal

See also
New PanelView Plus Graphic on page 50
New PanelView Plus Project on page 50
Add a variety of MobileView graphic terminals to the Studio 5000 Architect project. Adding a MobileView terminal creates a new FactoryTalk View ME application.

To add a MobileView graphic terminal
1. In Toolbox, expand Visualization and Mobile Terminals. 2. Expand the MobileView model family and size items. 3. Drag a MobileView model from Toolbox to Hardware Diagram. 4. In New MobileView Graphic, configure settings for the MobileView
terminal:
� Name: Enter a unique name for the terminal. � (optional) Description: Enter a description of the terminal. Cannot
be longer than 128 characters. � IP Address: Enter a static IP address for the terminal. � (optional) Catalog Number: Select a catalog number from the list.
5. Select OK.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

6. In New MobileView Project, configure settings for the new FactoryTalk View ME application:
� Name: Enter a unique name for the application. Studio 5000 Architect creates a new FactoryTalk View ME application.
� (optional) Description: Enter a description of the application. Cannot be longer than 128 characters.
� (optional) Scale Replace Displays: Select to scale objects in Replace displays to the resolution of the panel.
� (optional) Scale OnTop Displays: Select to scale objects in OnTop displays to the resolution of the panel.
� (optional) Language: Select a language for the application.
7. Select OK. The MobileView graphic terminal appears in Hardware Diagram and in Project Explorer under Devices. The FactoryTalk View ME application appears in Project Explorer under Projects.

New PanelView Plus Graphic

See also
New MobileView Graphic on page 51
New MobileView Project on page 51
How do I open New PanelView Plus Graphic?
1. In Toolbox, expand Visualization and Graphic Terminals. 2. Expand the PanelView Plus model family and size items. 3. Drag a PanelView Plus model from Toolbox to Hardware Diagram. Use New PanelView Plus Graphic to set name, description, and IP address settings for a new PanelView Plus graphic terminal. These settings are editable after the project contains the PanelView Plus terminal.

See also
Add a PanelView Plus graphic terminal on page 48
PanelView Plus Properties settings on page 51
New PanelView Plus Project How do I open New PanelView Plus Project?
1. In Toolbox, expand Visualization and Graphic Terminals. 2. Expand the PanelView Plus model family and size items. 3. Drag a PanelView Plus model from Toolbox to Hardware Diagram. 4. Configure the settings in New PanelView Plus Graphic, then click OK.
Use New PanelView Plus Project to set the name and description for a new PanelView Plus project. The name and description are editable after the project is part of the Studio 5000 Architect project.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

New MobileView Graphic

See also

Chapter 5

Add new components

Add a PanelView Plus graphic terminal on page 48
FactoryTalk View Machine Edition Project settings on page 61
How do I open New MobileView Graphic?
1. In Toolbox, expand Visualization and Mobile Terminals. 2. Expand the MobileView model family and size items. 3. Drag a MobileView model from Toolbox to Hardware Diagram.
Use New MobileView Graphic to set name, description, and IP address settings for a new MobileView graphic terminal. These settings are editable after the MobileView terminal is in the project.

New MobileView Project

See also
Add a MobileView graphic terminal on page 49
MobileView Properties settings on page 52
How do I open New MobileView Project?
1. In Toolbox, expand Visualization and Graphic Terminals. 2. Expand the MobileView model family and size items. 3. Drag a MobileView model from Toolbox to Hardware Diagram. 4. Configure the settings in New MobileView Graphic, then click OK.
Use New MobileView Project to set the name and description for a new MobileView project. The name and description are editable after the project is part of the Studio 5000 Architect project.

See also

Add a MobileView graphic terminal on page 49

FactoryTalk View Machine Edition Project settings on page 61

PanelView Plus Properties settings

The PanelView Plus Properties settings define name, description, and network settings for PanelView Plus graphic terminals. Set these settings from New PanelView Plus Graphic when adding a PanelView Plus terminal or from the Properties General tab when editing a PanelView Plus terminal.

The PanelView Plus Properties settings are:

Setting
Name Description IP Address Catalog Number

Description
Sets the PanelView Plus terminal name. Sets the PanelView Plus terminal description. 255 character maximum. Sets the unique address that identifies the PanelView Plus terminal on the IP network. Sets a PanelView Plus terminal catalog number.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

See also

MobileView Properties settings
Setting Name Description IP Address Catalog Number

New PanelView Plus Graphic on page 50
The MobileView Properties settings define name, description, and network settings for MobileView components. Set these settings in New MobileView Graphic when adding a MobileView terminal or from the Properties General tab when editing a MobileView terminal.
The MobileView Properties settings are:
Description Sets the MobileView name. Sets the MobileView description. 128 character maximum. Sets the unique address that identifies the MobileView on the IP network. Sets a MobileView catalog number.

Add computers Add a computer

See also
New MobileView Graphic on page 51
Add or remove computers from your project. Computers represent the hardware that serve FactoryTalk View SE and FactoryTalk View ME applications to visualization devices. Computers appear in Hardware Diagram and Project Explorer.
See also
Add a computer on page 52
Add visualization stations and servers on page 53
Add a computer to a Studio 5000 Architect project to represent a host machine for FactoryTalk View SE and FactoryTalk View ME servers.

To add a computer
1. In Toolbox, expand the Computers and Generic Computer folders. 2. Drag a computer from Toolbox to Hardware Diagram. 3. In New Computer Graphic, configure these settings:
� Name: Type a unique name for the computer. � (optional) Description: Type a description for the computer. Cannot
be longer than 128 characters. � Computer Name: Enter or select the computer's hostname.
4. Select OK. The computer appears in the Hardware Diagram and in Project Explorer under Devices.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

See also

Chapter 5

Add new components

New Computer Graphic on page 53

New Computer Graphic

How do I open New Computer Graphic?
1. In Toolbox, expand the Computers and Generic Computer folders. 2. Drag a computer from Toolbox to the Hardware Diagram.

Use New Computer Graphic to set the name, description, and host name for a new computer. Edit these settings after adding the computer to the project.

The computer properties are:

Field
Name Description Computer Name

Description
Sets the name for the computer. Sets the description for the computer. Cannot be longer than 128 characters. Sets the unique name that identifies the computer on the network.

Add visualization stations and servers

See also
Add a computer on page 52
Visualization stations and servers represent software applications that provide visual, communication, alarm, and event data to FactoryTalk View SE and FactoryTalk View ME components. Visualization stations and servers display in Project Explorer.

See also

Add a FactoryTalk View SE Station on page 53

Add a FactoryTalk View ME Station on page 54

Add a FactoryTalk View SE Server Project on page 55

Add a FactoryTalk Linx Server Project on page 56

Add a Tag Alarm and Event Server Project on page 57

Add a FactoryTalk View Site If integrating an automation system with FactoryTalk View Site Edition

visualization devices, add a FactoryTalk View Site Edition station to the

Edition Station

Studio 5000 Architect project.

Prerequisites
� Add a computer

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

To add a FactoryTalk View Site Edition Station
1. In Toolbox, expand Visualization and Stations. 2. Drag a FactoryTalk View SE Local or FactoryTalk View SE Network
station from Toolbox to a computer in Hardware Diagram. 3. In New View SE Station Project, configure settings for the application:
� Name: Enter a unique name for the application. The Studio 5000 Architect software creates a new FactoryTalk View Site Edition application.
� (optional) Description: Enter a description of the application. Cannot be longer than 255 characters.
� (optional) Language: Select a language for the application.
4. In New View SE Station Project, configure settings for the HMI server:
� (optional) Area: Enter a View SE area to assign the HMI server to the area.
� Name: Enter a unique name for the HMI server. � (optional) Description: Enter a description of the HMI server.
Cannot be longer than 255 characters.
5. (optional) In New View SE Station Project, select additional server functions:
� New FactoryTalk Linx Server: Select if this computer is also a FactoryTalk Linx server. The Studio 5000 Architect software creates a new FactoryTalk Linx Server and displays New FactoryTalk Linx Server Project.
� New Tag Alarm and Event Server: Select if this computer is also a Tag Alarm & Events server. Studio 5000 Architect creates a new Tag Alarm and Event server and displays New Tag Alarm and Event Server Project.
6. Select OK.
Project Explorer shows the View SE Station project in Projects.

Add a FactoryTalk View Machine Edition Station

See also
Add a computer on page 52 New Site Edition Project on page 58 New FactoryTalk Linx Server Project on page 59 New Tag Alarm and Event Server Project on page 59 If integrating an automation system with View Machine Edition (ME) Visualization devices, add a View ME Station to the Studio 5000 Architect project.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5
Tip: RSLinx Enterprise is renamed to FactoryTalk Linx. Some software applications may refer to RSLinx Enterprise. FactoryTalk Linx is compatible with all software applications that used RSLinx Enterprise.

Add new components

Prerequisites
� Add a computer

To add a FactoryTalk View Machine Edition Station
1. In Toolbox, expand Visualization and Stations. 2. Drag FactoryTalk View Machine Edition from Toolbox to a computer
in Hardware Diagram. 3. In New View ME Station Project, configure the station settings:
� Name: Enter a unique name. � (optional) Description: Enter a description. Cannot be longer than
255 characters. � (optional) Language: Select a project language. � (optional) Resolution: Select a project resolution. � (optional) Scale Replace Displays: Select to scale objects in Replace
displays to the resolution of the panel. � (optional) Scale OnTop Displays: Select to scale objects in OnTop
displays to the resolution of the panel.
4. Select OK.
In Hardware Diagram, Studio 5000 Architect software displays a new computer. Project Explorer shows the View ME Station project in Projects.

See also

Add a computer on page 52

New Machine Edition Station Project on page 59

Add a FactoryTalk View Site If integrating an automation system with FactoryTalk View SE Visualization

devices, add a FactoryTalk View SE Server project to the Studio 5000 Architect

Edition Server Project

project.

Prerequisites
� Add a computer

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

To add a FactoryTalk View SE Server Project
1. In Toolbox, expand Visualization and Servers. 2. Drag FactoryTalk View SE Server from Toolbox to a computer in
Hardware Diagram. 3. In New FactoryTalk View SE Server Project, configure the Application
settings:
� Name: Enter a unique name. � (optional) Description: Enter a description. Cannot be longer than
255 characters. � (optional) Language: Select a project language.
4. In New FactoryTalk View SE Server Project, configure settings for the HMI server:
� (optional) Area: Enter a View SE area to assign the HMI server to the area.
� Name: Enter a unique name for the HMI server. � (optional) Description: Enter a description of the HMI server.
Cannot be longer than 255 characters.
5. (optional) In New FactoryTalk View SE Server Project, select additional server functions:
� New FactoryTalk Linx Server: Select if this computer is also a FactoryTalk Linx server. The Studio 5000 Architect software creates a new FactoryTalk Linx Server and displays New FactoryTalk Linx Server Project.
� New Tag Alarm and Event Server: Select if this computer is also a Tag Alarm & Events server. The Studio 5000 Architect software creates a new Tag Alarm and Event server and displays New Tag Alarm and Event Server Project.
6. Select OK. Project Explorer shows the View SE Server project in Projects.

Add a FactoryTalk Linx Server Project

See also
Add a computer on page 52 New Site Edition Project on page 58 If an automation system has a dedicated FactoryTalk Linx server, add a FactoryTalk Linx server project to the Studio 5000 Architect project.
Prerequisites
� Add a computer

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

To add a FactoryTalk Linx Server Project

1. In Toolbox, expand Visualization and Servers. 2. Drag FactoryTalk Linx Server from Toolbox to a computer in
Hardware Diagram. 3. In New FactoryTalk Linx Server Project, on the General tab, enter the
Application settings.
� Type: Select a View SE application type. � Name: Enter a unique name for the application. The Studio 5000
Architect software creates a new FactoryTalk View SE application. � (optional) Description: Enter a description of the application.
Cannot be longer than 255 characters. � (optional) Language: Select a language for the application.
4. On the same tab, enter the FactoryTalk Linx Server settings.
� (optional) Area: Enter a View SE area to assign the FactoryTalk Linx server to the area. If the area does not exist, the Studio 5000 Architect software creates a new area.
� Name: Enter a unique name for the server. � (optional) Description: Enter a description of the server. Cannot be
longer than 255 characters. � (optional) Create HMI Server: Select to create an associated HMI
server.
5. (optional) To select alarm and event options, select the Alarms and Events tab:
� Enable alarm and event support: Select if this server monitors alarm and event tags.
� Enable server-assigned priorities: Select and assign severity ranges if this server has custom warning levels for alarms and events.
6. Select OK.
Project Explorer shows the FactoryTalk Linx server project in Projects.

See also

Add a Tag Alarm and Event Server project

Add a computer on page 52
New FactoryTalk Linx Server Project on page 59
If the automation system has a dedicated FactoryTalk Alarms and Events server, add a Tag Alarm and Event server project to the Studio 5000 Architect project.

Prerequisites
� Add a computer

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

To add a Tag Alarm and Event Server Project
1. In Toolbox, expand Visualization and Servers. 2. Drag Tag Alarm and Event Server from Toolbox to a computer in
Hardware Diagram. 3. In New Tag Alarm and Event Server Project, enter the Application
settings:
� Type: Select a View SE application type. � Name: Enter a unique name for the application. If entering a
unique name, the Studio 5000 Architect software creates a new FactoryTalk View SE application. � (optional) Description: Enter a description of the application. Cannot be longer than 255 characters. � (optional) Language: Select a language for the application.
4. In New Tag Alarm and Event Server Project, enter the Tag Alarm and Event Server settings:
� (optional) Area: Enter a View SE area to assign the tag server to the area. If entering a unique area, the Studio 5000 Architect software creates a new area.
� Name: Enter a unique name for the server. � (optional) Description: Enter a description of the server. Cannot be
longer than 255 characters. � (optional) Create HMI Server: Select to create an associated HMI
server.
5. (optional) In the Priorities tab of New Tag Alarm and Event Server Project, enter the Priority settings.
� Enable server-assigned priorities: Select to change default event ranges.
� Urgent: Set the low threshold for Urgent level events. � High: Set the low threshold for High level events. � Medium: Set the low threshold for Medium level events.
6. Select OK. Project Explorer shows the Tag Alarm and Event server project in Projects.

New Site Edition Project

See also
Add a computer on page 52 New Tag Alarm and Event Server Project on page 59 New Site Edition Project on page 58 How do I open New Site Edition Project? 1. In Toolbox, expand the Visualization and Stations folders.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

2. Drag FactoryTalk View Site Edition Station from Toolbox to a computer in the Hardware Diagram.

Use New Site Edition Project to set application and HMI server settings for a new local or network distributed Site Edition project. Edit these settings after the Site Edition project is added to the Studio 5000 Architect project.

New Machine Edition Station Project

See also
Add a FactoryTalk View Site Edition Station on page 53
FactoryTalk View Site Edition Project settings on page 60
How do I open New Machine Edition Station Project?
1. In Toolbox, expand the Visualization and Stations folders. 2. Drag FactoryTalk View ME Station from Toolbox to a computer in the
Hardware Diagram.
Use New Machine Edition Station Project to set name, description, resolution, scaling options, and language for a new FactoryTalk View Machine Edition project. Edit these settings after the FactoryTalk View Machine Edition project is added to the Studio 5000 Architect project.

New Tag Alarm and Event Server Project

See also
Add a FactoryTalk View Machine Edition Station on page 54
FactoryTalk View Machine Edition Project settings on page 61
How do I open New Tag Alarm and Event Server Project?
1. In Toolbox, expand the Visualization and Servers folders. 2. Drag the Tag Alarm and Event Server from Toolbox to a computer in
the Hardware Diagram. Use New Tag Alarm and Event Server Project to set server and alarm properties for a new Tag Alarm and Event Server.

New FactoryTalk Linx Server Project

See also
Add a Tag Alarm and Event Server Project on page 57 FactoryTalk Alarms and Event Server General settings on page 61 FactoryTalk Alarms and Event Server Priorities settings on page 62 How do I open New FactoryTalk Linx Server Project? 1. In Toolbox, expand the Visualization and Servers folders.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

2. Drag the RSLinx Enterprise Server from Toolbox to a computer in the Hardware Diagram.
Use New FactoryTalk Linx Server Project to set application, server, and alarm and event settings for a new FactoryTalk Linx server

FactoryTalk View Site Edition Project settings
Application Field Type Name Description Language HMI Server Field Area
Name Description

See also
Add a FactoryTalk Linx Server Project on page 56
FactoryTalk Linx Server General settings on page 62
FactoryTalk Linx Server Alarms and Events settings on page 63
The FactoryTalk View Site Edition Project settings define application and HMI server settings for a Site Edition project. Set these settings from New Site Edition Project when adding a local or network server or from the Properties General tab when editing a Site Edition project.
The FactoryTalk View Site Edition Project application and HMI server settings are:
Description
Specifies the project type for the FactoryTalk View Site Edition project. Can only be set when adding an HMI, FactoryTalk Linx, or Tag Alarm and Event server without a station. Specifies the name for the FactoryTalk View Site Edition project. The project name must not be empty. Specifies the description for the FactoryTalk View Site Edition project. Cannot be longer than 255 characters. Specifies the display language for the FactoryTalk View Site Edition project.
The FactoryTalk View Site Edition Project HMI server settings are:
Description
Specifies the area for the project's HMI server. � If the area name is unique, a new area is created as a child of the
FactoryTalk View Site Edition project. The HMI server is added as a child of the new area. � If the area name already exists, the HMI server is added as a child of the specified area. � If the area name is blank, the HMI server is added as a child of the FactoryTalk View Site Edition project. Cannot be set when adding or editing a FactoryTalk View Site Edition Local Station. Specifies the name for the project's HMI server. The HMI server name must not be empty. Cannot be set when adding or editing a FactoryTalk View Site Edition Local Station. Specifies the description for the project's HMI server.
The FactoryTalk View Site Edition Project server settings are:

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Server Setting

Description

New FactoryTalk Linx Server New Tag Alarm and Event Server

If checked, opens New FactoryTalk Linx Server. This check box is only available when adding a new project. If checked, opens New Tag Alarm and Event Server. This check box is only available when adding a new project.

Chapter 5

Add new components

See also

New Site Edition Project on page 58

New FactoryTalk Linx Server Project on page 59

New FactoryTalk Alarm and Event Server dialog box on page 59

FactoryTalk View Machine Edition Project settings

The FactoryTalk View Machine Edition Project settings define name, description, language, resolution, and scaling options for a FactoryTalk View ME application. Set when adding a FactoryTalk View ME application from New ME Station Project or when editing a FactoryTalk View ME application from the Properties General tab.

The FactoryTalk View ME Project settings are:

Setting
Name Description Language Resolution Scale Replace Displays Scale OnTop Displays Ensure runtime application can execute on PanelView Plus 7 Standard

Description
Sets the FactoryTalk View ME application name. The project name must not be empty. Sets the FactoryTalk View ME application description. 255 character maximum. Sets the FactoryTalk View ME application display language. Sets the FactoryTalk View ME application target resolution. Set if objects in Replace displays should be scaled to the resolution of the panel. Set if objects in OnTop displays should be scaled to the resolution of the panel. Set if an application should be compatible with both PanelView Plus 7 Performance and PanelView Plus 7 Standard graphic terminals.

See also

New Machine Edition Station Project on page 59

Tag Alarm and Event Server The Tag Alarm and Event Server General settings define server settings for a

Tag Alarm and Event server. Set from the General tab of New Tag Alarm and

General settings

Event Server when adding a new Tag Alarm and Event server or from the

Properties - General tab when editing a Tag Alarm and Event server.

The General settings are:

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

Tag Alarm and Event Server Field

Area

Name Description
Server Setting Create HMI Server

Description
Specifies the area for the Tag Alarm and Event server. � If the area name is unique, creates a new area as a child of the
FactoryTalk View Site Edition project. Adds the Tag Alarm and Event server as a child of the new area. � If the area name already exists, adds the Tag Alarm and Event server as a child of the specified area. � If the area name is blank, adds the Alarm and Event server as a child of the FactoryTalk View Site Edition project. Cannot set when the project type is a FactoryTalk View Site Edition Local Station. Specifies the name for the Tag Alarm and Event server. The server name cannot be empty. Specifies the description for the server. 255 character maximum.
The server settings are:
Description
If checked, opens New HMI Server. This check box is only available when adding a new project.

See also

New Tag Alarm and Event Server Project on page 59

Tag Alarm and Event Server Priorities settings on page 62

Tag Alarm and Event Server The Tag Alarm and Event Server Priorities settings define settings for a Tag

Alarm and Events server. Set from the Priorities tab of New Tag Alarm and

Priorities settings

Event Server Project when adding a new Tag Alarm and Events server or

from the Priorities tab when editing a Tag Alarm and Events server.

The Tag Alarm and Event Server Priorities settings are:

Setting
Enable server-assigned priorities Urgent High Medium

Description
If selected, can set custom priority values for Urgent, High, and Medium priority events. Specifies the priority at which an Urgent priority alarm or event are created. Specifies the priority at which a High priority alarm or event are created. Specifies the priority at which a Medium priority alarm or event are created.

FactoryTalk Linx Server General settings

See also
New Tag Alarm and Event Server Project on page 59
The FactoryTalk Linx Server General settings define options for a FactoryTalk Linx server. Configure these settings from the General tab of New FactoryTalk Linx Server when adding a FactoryTalk Linx server or from the Properties > General tab when editing a FactoryTalk Linx server.
The general settings of a FactoryTalk Linx Server are:

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 5

Add new components

FactoryTalk Linx Server setting Area
Name Description

Description
Specifies the area for the FactoryTalk Linx server. � If the area name is unique, a new area is created as a child of the FactoryTalk View SE project. The FactoryTalk Linx
server is added as a child of the new area. � If the area name already exists, the FactoryTalk Linx server is added as a child of the specified area. � If the area name is blank, the FactoryTalk Linx server is added as a child of the FactoryTalk View SE project. Cannot set when the project type is a FactoryTalk View SE Local Station. Specifies the name for the FactoryTalk Linx server. The FactoryTalk Linx server name must not be empty. Specifies the description for the FactoryTalk Linx server. 255 character maximum.

The server settings are:

Server Setting Create HMI Server

Description
If checked, opens New HMI Server. This check box is only available when adding a new project.

See also

New FactoryTalk Linx Server Project on page 59

FactoryTalk Linx Server Alarms and Events settings

The FactoryTalk Linx Server Alarms and Events settings define alarm and event settings for a FactoryTalk Linx server. Set from the Alarms and Events tab of New FactoryTalk Linx Server when adding a new FactoryTalk Linx server or from the Properties Alarms and Events tab when editing a FactoryTalk Linx server.

The FactoryTalk Linx Server Alarms and Events settings are:

Setting Enable alarm and event support
Enable server-assigned priorities
Urgent High Medium

Description
If selected, sets the FactoryTalk Linx Data Server to act as an Alarm and Event server. If selected, enables custom priority values for Urgent, High, and Medium priority events. Sets the priority at which an Urgent priority alarm or event is created. Sets the priority at which a High priority alarm or event is created. Sets the priority at which a Medium priority alarm or event is created.

See also
New FactoryTalk Linx Server Project on page 59 FactoryTalk Linx Server General settings on page 62

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Import existing components

Chapter 6

A Studio 5000 Architect project contains one or more components. Each component represents a hardware device, software project, visualization server, or document. Components appear in Hardware Diagram and Project Explorer.
Import existing components from a project file or online controller to add them to a Studio 5000 Architect project. Once added, connect components to networks and configure relationships to share tags and control an automation system.

See also

Import a controller project from a file on page 65

Import a controller project from an online controller on page 66

Import a FactoryTalk View application from a file on page 67

Import a controller project from a file

Import Logix Designer project files (.acd) to a Studio 5000 Architect project. Studio 5000 Architect software adds the controller, chassis or DIN rail, and all associated modules, tags, and aliases to the project.

If the imported project contains unknown or unsupported modules, Studio 5000 Architect stops the import operation.

If the imported project contains produced or consumed tags using user defined data types, define the user defined data type in the producer controller before committing the hardware diagram.

To import a controller project from a file:
1. In Hardware Diagram, right-click on a blank area of the hardware diagram, then select Add Controller Project.
2. In Open, locate and select the project file to add, then select Open. 3. If importing a 1769 controller, in Bank Configuration, change the
configuration to match your physical controller, then select OK. 4. In Confirm Update Changes, select OK. The controller, chassis or DIN
rail, and all associated modules appear in Hardware Diagram.
Note: Select Cancel if the project contains unknown or unsupported modules. Remove unsupported modules in Logix Designer and try again.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 6

Import existing components
See also

About unsupported modules on page 45

Import a controller project from an online controller on page 66

Confirm Update Changes on page 68

Import a controller project from an online controller

Import a controller project to the Studio 5000 Architect project from an online controller using either RSLinx Classic or FactoryTalk Linx. Studio 5000 Architect software adds the controller, chassis or DIN rail, and all associated modules, tags, and aliases to the project.

The Import option is only available for the modules supported by Studio 5000 Architect software. Locate the children node when choosing modules to make sure that the selected modules are supported by Studio 5000 Architect.

If the imported project contains produced or consumed tags using user defined data types, define the user defined data type in the producer controller before committing the hardware diagram.

To import a controller project from an online controller:
1. In Hardware Diagram, right-click on a blank area of the hardware diagram, then select Import from Online Controller....
2. In Import from Online Controller, in Communication Software select either RSLinx Classic or FactoryTalk Linx.
3. Browse the network tree to select the controller to import into your project, then select Import.
4. In Choose Matching Controller Configuration File, perform one of these steps:
� To create a new project file, select Create New. � To use controller settings from a project file in the list, select the file,
then select Select. � To use controller settings from a different project file, select
Browse, then add the file to the list. Once Studio 5000 Architect software verifies the validity of the file, select Select.
5. If importing a 1769 controller, in Bank Configuration, modify the configuration to match the physical controller, then select OK.
6. In Confirm Update Changes, select OK.

See also
Import a controller project from a file on page 65 Update a hardware diagram with an online controller on page 101 Select Online Controller to Import on page 67

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Import a FactoryTalk View application from a file

Chapter 6

Import existing components

Choose Matching Controller Configuration File on page 68

Confirm Update Changes on page 68

Import a FactoryTalk View application to the Studio 5000 Architect project. Studio 5000 Architect software adds the associated PanelView Plus or MobileView terminal, tags, displays, global objects, images, macros, and servers to the project.

To import a FactoryTalk View application from a file:
1. In Hardware Diagram, right-click on a blank area of the hardware diagram, then select Add Existing FactoryTalk View Project.
2. In Add Existing FactoryTalk View Project, select an application and its settings:
� Application Type: Select a type of FactoryTalk View application. � Applications: Select the application to import. � Language: Select a language for the application. � Diagram to add discovered hardware to: Select a hardware diagram
where Studio 5000 Architect software imports the components.
3. Select OK. 4. In Update Summary, review the changes, then select OK.
The FactoryTalk View application displays in Project Explorer. If importing a FactoryTalk View ME application, a PanelView Plus or MobileView terminal is added to the hardware diagram and its catalog number is set based on the station resolution of the project.

Select Online Controller to Import

See also
Add Existing FactoryTalk View Project on page 69
How do I open Select Online Controller to Import?
� From the Hardware Diagrams menu, select Import from Online Controller...
Select Online Controller to Import lists controllers connected to the network. Select a controller to import settings from the online controller to settings in the Studio 5000 Architect project.

See also
Import a controller project from an online controller on page 66

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 6

Import existing components

Choose Matching Controller How do I open Choose Matching Controller Configuration File?

Configuration File

If you are importing a controller from an online controller

1. Select Hardware Diagrams > Import from Online Controller... 2. In Select Online Controller to Import, browse the network, select the
controller to import into the project, then click Select.

If you are updating a hardware diagram with an online controller
� Select Use external controller configuration file in Select Online Controller to Update.
Choose Matching Controller Configuration lists existing project files that are compatible with the controller you are importing. The selected controller project and its documentation are added to the Studio 5000 Architect project.
� To import or update to a new project file, select Create New. � To import or update to a project file in the list, select the file, then
select Select. � To import or update to a different project file, select Browse, then
add the file to the list. Once Studio 5000 Architect software verifies the validity of the file, select Select.

Confirm Update Changes

See also
Import a controller project from an online controller on page 66 Update a hardware diagram with an online controller on page 101 Select Online Controller to Import on page 67 How do I open Confirm Update Changes?

If you are importing a controller from a file
1. In Hardware Diagram, right-click on a blank area of the hardware diagram, then click Add Controller Project.
2. In Open, locate and select the project file you wish to add, then click Open.
3. If you are importing a 1769 controller, in Bank Configuration, modify the configuration to match your physical controller, then click OK.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 6

Import existing components

If you are importing a controller from an online controller

1. In Hardware Diagram, right-click on a blank area of the hardware diagram, then click Import From Online.
2. In Select Online Controller to Import, browse the network and click the controller you want to import into your project, then click Select.
3. In Choose Matching Controller Configuration File, perform one of following steps:
� To create a new project file, click Create New. � To use controller settings from a project file in the list, click the file,
then click Select. � To use controller settings from a different project file, click Browse,
then add the file to the list. Once Studio 5000 Architect verifies the validity of the file, click Select.
4. If you are importing a 1769 controller, in Bank Configuration, modify the configuration to match your physical controller, then click OK.

Confirm Update Changes lists pending changes to a Studio 5000 Architect project. This message appears before a project import changes a Studio 5000 Architect project. Review the changes, then continue or cancel the update.

Add Existing FactoryTalk View Project

See also
Import a controller project from a file on page 65
Import a controller project from an online controller on page 66
Update a hardware diagram on page 100
Update a hardware diagram with an online controller on page 101
How do I open Add Existing FactoryTalk View Project? � In Hardware Diagram, right-click on a blank area of the hardware diagram, then click Add Existing FactoryTalk View Project.
Use Add Existing FactoryTalk View Project to import a FactoryTalk View application into a Studio 5000 Architect project. Studio 5000 Architect software updates the project after import.
When importing a FactoryTalk View ME application, a PanelView Plus or MobileView terminal is added to the hardware diagram and its catalog number is set based on the project's station resolution.

See also
Import a FactoryTalk View application from a file on page 67

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Add networks

Chapter 7

Networks in Studio 5000 Architect represent the hardware and cables that allow components to communicate. After connecting components to the same network, create ownership relationships, tags, and I/O aliases.
In ControlNet and other non-Ethernet networks, must connect components that communicate with each other to the same network trunk. ControlNet and other network trunks are only shown in Hardware Diagram.
In Ethernet networks, connect components that communicate with each other to each other, either directly or through Ethernet switches. Ethernet switches display in Hardware Diagram. Managed switches owned by a controller also appear in Project Explorer.

Add a managed Ethernet switch

See also
Add a managed Ethernet switch on page 71
Add an unmanaged Ethernet switch on page 72
Add a Generic switch on page 72
Add a network trunk on page 73
Add a managed Ethernet switch to build or expand an Ethernet network using Stratix devices. Studio 5000 Architect software supports managed Stratix switches ranging from 3 to 20 ports in their default configuration. Some switches support expansions up to a total of 26 ports.

To add a managed Ethernet Switch
1. In Toolbox, expand Network Infrastructure and Ethernet Switches. 2. Expand Managed Switches, then expand the list by switch port size. 3. Drag a switch from Toolbox to Hardware Diagram. 4. (optional) In New Switch Graphic, enter the switch properties:
a. (optional) Name: Enter a unique name for the switch.
b. (optional) Description: Enter a description for the switch. Cannot be longer than 128 characters.
c. Address / Host Name: Set the IP address or host name for the switch.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 7

Add networks

5. Select OK. The Stratix switch appears in the Hardware Diagram and in Project Explorer under Devices.

See also

Switch Configuration on page 75

Add an unmanaged Ethernet Add an unmanaged Ethernet switch to build or expand an Ethernet network

using Stratix devices. Studio 5000 Architect software supports unmanaged

switch

Stratix switches ranging from 4 to 8 ports.

To add an unmanaged Ethernet switch
1. In Toolbox, expand Network Infrastructure and Ethernet Switches. 2. Expand Unmanaged Switches, then expand the list by switch port size. 3. Drag a switch from Toolbox to Hardware Diagram. 4. In New Switch Graphic, enter a unique name for the switch, then
select OK. The switch appears in Hardware Diagram and in Project Explorer under Devices.

Add a Generic switch

See also
Switch Configuration on page 75
Add a generic switch to the Studio 5000 Architect project. Use generic switches to connect mainstream Ethernet hardware to the automation system.

To add a Generic Switch
1. In Toolbox, expand Network Infrastructure and Generic Switch. 2. Drag a Generic Switch from Toolbox to Hardware Diagram. 3. (optional) In New Generic Switch Graphic, configure the switch
properties:
� Name: Enter a unique name for the switch. � Description: Enter a description for the switch. Cannot be longer
than 255 characters. � Type: Select whether the switch is Managed or Unmanaged. � Number of Ports: Select the number of ports on the switch. � Address / Host Name: If the switch is managed, set the IP address
or host name for the switch.
4. Select OK. The generic switch appears in Hardware Diagram and in Project Explorer under Devices.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Add a network trunk

See also

Chapter 7

Add networks

New Generic Switch Graphic on page 74
ControlNet and other network trunks represent the cabling that connects non-Ethernet components. Using multiple controllers or modules to communicate across a ControlNet or other non-Ethernet network requires a network trunk.
ControlNet trunks are blue, other network trunks are black.

To add a network trunk
1. From the Network Trunk list, select a network trunk type, then select Network Trunk Tool.
2. In Hardware Diagram, either: � Select the location to set the trunk position. � Drag over a location to set both the trunk position and size.
Studio 5000 Architect software displays the network trunk in Hardware Diagram.

Connect Ethernet components

See also
Connect components to a network trunk on page 74
Add, import, and remove components on page 15
For Ethernet components to communicate with each other, connect them to the same Ethernet network. In most cases, components connect to an Ethernet switch. Components with multiple Ethernet ports support Device Level Ring (DLR) connections and can connect components without a switch.
Ethernet connections and ports are green.

To connect Ethernet components
1. In Hardware Diagram, drag the component or component port to an unused port on an Ethernet switch or other Ethernet component.
2. (optional) If the new connection links two previously unconnected networks, Studio 5000 Architect software combines them into a single network. In Select Network Name, enter a network name for the combined network, then select OK.

See also

Add a managed Ethernet switch on page 71

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 7

Add networks

Connect components to a network trunk

Add an unmanaged Ethernet switch on page 72 Add a Generic switch on page 72 Connect components to a network trunk on page 74 In order for ControlNet and other non-Ethernet components to communicate with each other, connect the components to the same network trunk. Components can only connect to one network trunk at a time. ControlNet connections are blue, other network connections are black.

To connect a device to a network trunk
� In Hardware Diagram, drag the component or component port to the ControlNet or other network trunk.

Add an Ethernet Tap

See also
Add a network trunk on page 73
Connect Ethernet components on page 73
Add an Ethernet tap to monitor messages on an Ethernet network.
To add an Ethernet tap
1. In Toolbox, expand Network Infrastructure, Ethernet Switches, Managed Switches, and 3-Port Switches.
2. Drag an Ethernet tap from Toolbox to Hardware Diagram. 3. In New Switch Graphic, configure the switch properties, then select
OK: � (optional) Name: Enter a unique name for the Ethernet tap. � (optional) Description: Enter a description for the Ethernet tap. � Address / Host Name: Select a network type and set the IP address
or host name for the Ethernet tap. 4. Select OK. The Ethernet tap appears in Hardware Diagram and in
Project Explorer under Devices.

See also
Connect Ethernet components on page 73 Switch Configuration on page 75
New Generic Switch Graphic How do I open New Generic Switch Graphic?

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Settings Name Description Type
Number of Ports Address/Host Name
Switch Configuration
Setting Type Vendor Name Description Expansions

Chapter 7

Add networks

1. In Toolbox, expand the Network Infrastructure and Generic Switch folders.
2. Drag a Generic Switch from Toolbox to the Hardware Diagram.

Use New Generic Switch Graphic to set switch settings for a new Ethernet switch. Edit these settings after the switch is added to the project.

Description
Specifies the name of the generic switch. Specifies the description of the generic switch. Cannot be longer than 255 characters. Specifies the type of switch: � Unmanaged: Unmanaged switches provide a basic network connection. No additional network
configuration is required with this option. � Managed: Managed switches allow taking control of communication over an Ethernet network.
Configure the address or host name if choosing this option. Specifies the number of ports to create connections between communication modules. The value range is 2 to 26. Specifies the IP configuration for a managed switch. Three options are: � Private Network: Select the value from the list, from 1 to 254. � IP Address: Enter a unique IP address to identify each node on the IP network. � Host Name: Enter a fully qualified domain name, such as switch.yourcompany.com.

See also
Add a Generic switch on page 72
How do I open Switch Configuration?
1. In Toolbox, expand the Network Infrastructure, Ethernet Switches, Managed Switches or Unmanaged Switches, and number of port folders.
2. Drag the desired switch from Toolbox to the Hardware Diagram.
Use Switch Configuration to set the name, description, and network settings for a new Stratix switch or Ethernet tap. Edit these settings after the switch or tap is added to the project.
Settings that do not apply to the switch or tap are hidden.
Description
Specifies the type of the switch. Shows the vendor information of the switch. Shows the switch name specified in New Switch Graphic. Specifies the description for the switch. Cannot be longer than 128 characters. Specifies the port expansion information. Three available options are: � (0) - None � (1) - 8 port expansion � (2) - 8 port expansion (16 ports total)

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 7

Add networks

Setting

Address / Host Name

Description Specifies the configuration for the switch. The setting is available if the switch type is Managed. Three options are: � Private Network: Select the value from the list, from 1 to 254.
The Private Network setting is not available for Stratix 6000 switches. � IP Address: Enter a unique IP address to identify each node on the IP network. � Host Name: Enter a fully qualified domain name, such as switch.yourcompany.com.
See also
Add a managed Ethernet switch on page 71 Add an unmanaged Ethernet switch on page 72 Add an Ethernet Tap on page 74

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Add relationships and tags

Chapter 8

Relationship
Ownership relationship Producer/consumer relationship Shortcut

For components to communicate with each other in production, they must have one of three relationships:
Description
Connects one module to one controller or FactoryTalk Linx server. Connects one controller to another controller. Connects one controller to a FactoryTalk Linx server for use in a FactoryTalk View application.
Once two components have a relationship, they can communicate with each other using one or more tags. Add tags for producer/consumer relationships, point tags, and axis tags using Studio 5000 Architect or Logix Designer.

About ownership relationships

See also
Add an ownership relationship on page 83
Add a producer/consumer relationship on page 83
Add a shortcut on page 84
Add a produced and consumed tag on page 85
Add a point tag on page 86
An ownership relationship connects one module to one controller or FactoryTalk Linx server. Once the relationship is added, the controller or server "owns" the module and can read from or write to its tags. A controller or server can own multiple modules. Modules can have multiple owners. In large automation systems, ownership relationships can be very complex with many modules owned by many controllers across multiple chassis.
Ethernet devices owned by or added to the I/O configuration of a controller are counted toward the node limits of the controller.
Studio 5000 Architect software displays the owned modules for each controller in Project Explorer under the controller project's I/O Configuration folder. Studio 5000 Architect displays owned modules for each FactoryTalk Linx server in Communications.
To add an ownership relationship, one of these conditions must be true:
� Either the controller and the target module must be on the same chassis

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 8

Add relationships and tags

� Or the controller or FactoryTalk Linx server must own all communication modules along the path to the target module's chassis

Example
A controller in Chassis A needs to read tags from an input module across the factory floor in Chassis B. The two chassis are physically connected using an Ethernet network. Adding an ownership relationship between the controller and the input module is a four step process:
1. In Studio 5000 Architect software, connect the two chassis together using communication modules and an Ethernet switch.
2. Add an ownership relationship between the communication module in Chassis A and the controller.
3. Add an ownership relationship between the communication module in Chassis B and the controller.
4. Add an ownership relationship between the input module in Chassis B and the controller.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 8

Add relationships and tags

Project Explorer shows the path of owned modules in the controller project's I/O Configuration folder.

See also

Add networks on page 71

Add an ownership relationship on page 83

Common module configuration errors on page 88

Ethernet node limitations on page 88

Project Explorer on page 12

About producer/consumer relationships

A producer/consumer relationship connects one controller to another controller. Once the relationship is added, the consumer controller can read from or write to specific tags provided by the producer controller. A consumer controller can consume tags from many producer controllers. Similarly, a producer controller can produce tags for many consumer controllers. In large automation systems, producer/consumer relationships can be very complex with many controllers producing and consuming tags from multiple controllers.

Studio 5000 Architect software displays the producer controllers for each consumer controller in Project Explorer under the controller project's I/O Configuration folder.

To add a producer/consumer relationship, one of these conditions must be true:

� Either the consuming controller and the producing controller must be on the same chassis

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 8

Add relationships and tags

� Or the consuming controller must own all communication modules along the path to the producer controller's chassis

Example
A controller in Chassis A needs to consume tags from a controller across the factory floor in Chassis B. The two chassis are physically connected using an Ethernet network. Adding a producer/consumer relationship between the consuming controller and the producing controller is a four step process:
1. In Studio 5000 Architect software, connect the two chassis together using communication modules and an Ethernet switch.
2. Add an ownership relationship between the communication module in Chassis A and the consuming controller in chassis A.
3. Add an ownership relationship between the communication module in Chassis B and the consuming controller in chassis A.
4. Add a producer/consumer relationship between the producing module in Chassis B and the consuming controller in Chassis A.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 8

Add relationships and tags

Project Explorer shows the path of owned modules and producer controllers in the consumer controller project's I/O Configuration folder.

About shortcuts

See also
Add networks on page 71 Add an ownership relationship on page 83 Add a producer/consumer relationship on page 83 Project Explorer on page 12 A shortcut connects one controller to a FactoryTalk Linx server for use in a FactoryTalk View project. Once the relationship is added, the FactoryTalk Linx server can read from or write to the controller's tags. This allows a FactoryTalk View application to communicate with a controller. Studio 5000 Architect software displays the shortcuts for each FactoryTalk Linx server in Communications. To add a shortcut, the FactoryTalk Linx server must own all communication modules along the path to the target module's chassis.
Example
A FactoryTalk View application with a FactoryTalk Linx server (right) needs to read tags from a controller across the factory floor in Chassis A. The chassis and the computer are physically connected using an Ethernet network. Adding a shortcut between the FactoryTalk Linx server and the controller is a three step process:

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 8

Add relationships and tags

1. In Studio 5000 Architect software, connect the computer hosting the FactoryTalk Linx server to Chassis A using communication modules and an Ethernet switch.
2. Add an ownership relationship between the communication module in Chassis A and the FactoryTalk Linx server.
3. Add a shortcut between the controller in Chassis A and the FactoryTalk Linx server.

Communications shows the path of each shortcut from the FactoryTalk Linx server to the controller.

See also
Add networks on page 71 Add an ownership relationship on page 83

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Add an ownership relationship

Chapter 8

Add relationships and tags

Add a shortcut on page 84

Communications on page 93

An ownership relationship connects one module to one controller or FactoryTalk Linx server. Once the relationship is added, the controller or server owns the module and can read from or write to its tags.

FactoryTalk Linx servers can only own controllers or communication modules and can only read tags from controllers.

Prerequisites
� Either place the controller and the target module on the same chassis, or make the FactoryTalk Linx server the owner of all communication modules along the path to the target module.

To add an ownership relationship
1. In Hardware Diagram, locate the module to be owned by the controller or FactoryTalk Linx server.
2. Drag the module on top of the controller or FactoryTalk Linx server. 3. In Configure Module, set the keying, and network settings, then select
OK. 4. Commit the hardware diagram to save the module configurations to
the Logix Designer project or FactoryTalk View application.
Project Explorer displays the owned modules for each controller and Communications displays owned modules for each FactoryTalk Linx server.

See also

Add a producer/consumer relationship

About ownership relationships on page 77
Configure Module on page 89
A producer/consumer relationship connects one controller to another controller. Once the relationship is added, the consumer controller can read from or write to specific tags provided by the producer controller.

Prerequisites
� Either place the consumer controller and producer controller on the same chassis, or make the consumer controller the owner of all communication modules along the path to the producer controller

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 8

Add relationships and tags
To add a producer/consumer relationship
1. In Hardware Diagram, locate the controller to produce tags for the consumer controller.
2. Drag the producer controller on top of the consumer controller. 3. In Configure Module, set the keying settings, then select OK. 4. Commit the hardware diagram to save the controller configurations to
the Logix Designer projects.
Project Explorer shows the path of owned modules and producer controllers in the I/O Configuration folder of the consumer controller project.

Add a shortcut

See also
About producer/consumer relationships on page 79
Configure Module on page 89
A shortcut connects one controller to a FactoryTalk Linx server for use in a FactoryTalk View application. Using the shortcut, the FactoryTalk Linx server reads from or writes to the controller's tags. This allows a FactoryTalk View application to communicate with a controller.

Prerequisites
� The FactoryTalk Linx server must own all communication modules along the path to the target controller.

To add a shortcut
1. In Hardware Diagram, locate the controller to use in the FactoryTalk View application.
2. Drag the controller on top of the computer that hosts the FactoryTalk Linx server.
3. In Add New or Modify Existing Shortcut, set the shortcut settings, then select OK:
� Shortcut name: Enter a new shortcut name or select an existing shortcut from the list. Selecting an existing shortcut overwrites it.
� Offline tag file: Enter a path to an offline tag file � Enable Alarms and Events: Enable or disable Alarms and Events
support on the shortcut. Only enable if alarms and events are defined in the controller and the FactoryTalk View application responds to those alarms or events.
4. Commit the hardware diagram to save the controller configurations to the FactoryTalk View applications.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 8

Add relationships and tags

Communications shows the path of each shortcut from the FactoryTalk Linx server to the controller.

Add a produced and consumed tag

See also
About shortcuts on page 81 Add New or Modify Existing Shortcut on page 93 Communications on page 93 Add an RSLinx Enterprise Server Project on page 56 Add produced and consumed tags to allow a consumer controller to read and write values in a producer controller.
Prerequisites
� Add a producer/consumer relationship between two controllers. � In the View menu, verify Produce/Consume Tags is checked.

To add a produced and consumed tag
1. In Produce/Consume Tags, select Add. 2. In Consumer Tag, select a consumer controller and a name for the tag. 3. Select Connection. 4. In Producer Tag, select a producer controller. 5. (optional) In Producer Tag, configure the tag options:
� External Access: Select the type of access for external controllers: Read/Write, Read Only, or None.
� RPI: Enter a requested packet interval in milliseconds. The producer controller updates the tag once per interval.
� Allow Unicast Consumer Connection: Select whether the tag is broadcast using a one-to-one consumer connection.
6. Select OK. 7. In Consumer Tag, configure the remaining tag options:
� Data Type: Select a data type for the tags. � External Access: Select the type of access for external controllers:
Read/Write, Read Only, or None. � Array Dimensions: Select the number of dimensions. Only available
for array-like data types. � Use Unicast Connection over EtherNet/IP: Select whether the tag is
consumed using a one-to-one consumer connection.
8. Select OK.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 8

Add relationships and tags

9. Commit the hardware diagram to save the tags to the Logix Designer projects.

Add a point tag

See also
Produce/Consume Tags on page 90
Consumer Tag on page 91
Producer Tag on page 91
A point tag, also known as an I/O alias, allows referencing the point tag instead of the I/O point in your controller programs. This is useful shorthand for controllers with many inputs and outputs.
If the Create alias tags automatically when Point Tag is defined setting in Studio 5000 Architect options is enabled, adding a point tag automatically adds controller scope alias tags in each owning controller's project. If the setting is disabled, corresponding alias tags are not added.

Prerequisites
� Verify the I/O module is owned by at least one controller. � In the View menu, verify I/O Aliases is checked.

To add a point tag
1. In Hardware Diagram, select an I/O module. 2. In I/O Aliases, click in the Point Tag column for an I/O point. 3. Enter a name for the point tag, then select Enter. 4. Commit the hardware diagram to save the tags to the Logix Designer
projects.

Add an axis tag

See also
I/O Aliases on page 92
An axis tag allows a controller project to reference a specific axis of motion on a Kinetix 5500 servo drive. Create the tag in either Studio 5000 Architect or Logix Designer software. The tag is committed and updated as part of a Logix Designer project.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 8

Add relationships and tags

To add an axis tag

1. Drag the Kinetix 5500 servo drive on top of a controller to create an ownership relationship.
2. In Kinetix 5500 Servo Drives Configuration, set the keying settings. 3. Select the Associated Axes tab. 4. In Axis Name, enter the name for the axis tag. 5. (optional) In Motion Group, enter or select a motion group to contain
the axis tag. 6. Select OK. 7. Commit the hardware diagram to save the tag to the Logix Designer
project.
Studio 5000 Architect displays the new axis tag and motion group in Project Explorer under the controller project's Motion Groups folder.

Edit a produced and consumed tag
Edit a shortcut

See also
Add an ownership relationship on page 83 Kinetix 5500 Servo Drives Configuration on page 46 Edit a produced and consumed tag to change its name, description, data type, access options, or RPI.
To edit a produced and consumed tag
1. In Produce/Consume Tags, locate and select the tag to edit. 2. Select Edit. 3. In Consumer Tag, edit the name, description, data type, or access
options. 4. (optional) Select Connection to open Producer Tag to edit the RPI,
then select OK. 5. Select OK.
See also
Produce/Consume Tags on page 90 Consumer Tag on page 91 Producer Tag on page 91 Edit a shortcut to change its name or offline tag file.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 8

Add relationships and tags
To edit a shortcut
1. In Project Explorer, expand the Projects folder and hardware diagram containing the FactoryTalk View application.
2. Expand the FactoryTalk View project containing the FactoryTalk Linx server to modify.
3. Right-click the FactoryTalk Linx server, then select Properties. 4. In Properties, select Shortcuts. 5. Select the arrows next to the shortcut to edit. 6. Change the name or controller tag file. 7. Select OK.

See also

About shortcuts on page 81

Common module configuration errors

When adding an ownership relationship between an Add-On Profile (AOP) module and a controller, Studio 5000 Architect software checks the validity of the relationship against Logix Designer relationship rules. If the relationship is invalid, Studio 5000 Architect software displays an error message.

Common error messages include:

Error Message
Child module incompatible with parent module. Network size exceeds the allowable size for a network. Child will not work under the specified parent port.
Catalog Services could not be found. This could indicate the Catalog Services is not installed. The maximum number of Ethernet nodes for this controller type has been exceeded. The module does not allow disabled electronic keying when safety connections are present. Module is not initialized. Likely cause is the module identity (CIP Key) or the module parent is not set.

Resolution
Verify module properties in Logix Designer. Remove EtherNet devices from the network. Add the ownership relationship with the controller using a compatible port. Verify Logix Designer and Catalog Services are installed properly.
Remove Ethernet devices from the I/O configuration of the controller. Enable Electronic Keying in module properties or remove the safety connections. Remove Powerflex 523 or 525 AC drive devices from the drive configuration of the controller.

Ethernet node limitations

See also
About ownership relationships on page 77
Add an ownership relationship on page 83
Any Ethernet/IP device that is owned by or added to the I/O configuration of a controller is counted towards the node limits of the controller. ControlLogix and CompactLogix controllers count all devices connected to local and remote Ethernet ports.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 8

Add relationships and tags

The maximum number of connected Ethernet nodes varies by controller. Use the Capacity tab in the Logix Designer software to determine limits for a controller.

Examples of devices counted as Ethernet nodes when added to the I/O Configuration tree are:

� Remote communication adapter � I/O modules connected to the EtherNet/IP network � Motion devices, such as drives � Remote controllers � HMI devices that are included in the I/O Configuration tree, for
example, PanelView Plus terminals � Linking devices, such as the 1788-EN2DNR � Third-party devices that are directly connected to the EtherNet/IP
network

The local Ethernet modules and embedded Ethernet ports are not included in the count.

Configure Module

See also
Add an ownership relationship on page 83 How do I open Configure Module?
If adding an ownership relationship:
1. In Hardware Diagram, locate the module that will be owned by the controller or RSLinx server.
2. Drag the module on top of the controller or RSLinx server that will own it.

Setting Type

If adding a producer/consumer relationship
1. In Hardware Diagram, locate the controller that will produce tags for the consumer controller.
2. Drag the producer controller on top of the consumer controller.
Use Configure Module to set keying and connection settings for a module or producer controller. Use these settings to create an ownership relationship or a producer/consumer relationship. Edit these settings using the Edit Device Properties Module Configuration tab.
Settings that do not apply to a module or controller are hidden.
Description Specifies the type of the module.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 8

Add relationships and tags

Setting Vendor Parent Name Description Comm Format Slot
Electronic Keying
Revision Node
Address / Host Name

Description Shows the vendor information of the module. Shows the name of the parent module. If the module is in the local chassis, displays Local. Shows the name of the module. Specifies the description for the module. Specifies the format of the module (input or output). Shows the slot in the chassis where the module exists. Specifies the electronic keying protection mode to prevent a module from being inserted in the wrong slot. � Exact Match. Requires all attributes of the physical module and the module created in the software to match. � Compatible Module Keying. Accepts or rejects the connection based on firmware compatibility. � Disable Keying. Requires no attributes of the physical module and the module configured in the software to match. Modifying the Electronic Keying option may cause the module connection to break or result in a loss of data, or both. If used incorrectly, this option can lead to personal injury or death, property damage or economic loss. Specifies the major (primary) and minor (secondary) firmware version of the module. Specifies the node on the module trunk where the module exists. This option is only available for ControlNet modules that you are associating with a controller. Specifies the configuration for the switch. These settings are available for managed Ethernet switches. There are three options: � Private Network: Select the value from the list, from 1 to 254. � IP Address: Enter a unique IP address to identify each node on the IP network. � Host Name: Enter a fully qualified domain name, such as switch.yourcompany.com.

Produce/Consume Tags

See also
Add an ownership relationship on page 83 Add a producer/consumer relationship on page 83 How do I open Produce/Consume Tags? � From the View menu, check Produce/Consume Tags. Use Produce/Consume Tags to add, edit, and remove produced and consumed tags from controller projects.

Column Consumer Controller Consumer Tag Data Type Producer Controller Producer Tag
90

The columns in Produce/Consume Tags are:
Description The name of the consumer controller. The name of the consumed tag in the consumer controller project. The data type of the tag, such as BOOL or DINT. The name of the producer controller. The name of the produced tag in the producer controller project.
Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Column RPI
Class

Chapter 8

Add relationships and tags

Description

The requested packet interval (RPI) of the tag. The producing controller updates the tag once per interval. The default interval is 20ms. The class of the tag, either Standard or Safety. Only available for safety controllers, such as a 1756-L61S.

See also

Add a produced and consumed tag on page 85

Edit a produced and consumed tag on page 87

Consumer Tag

How do I open Consumer Tag? � In Produce/Consume Tags, click Add or Edit.

Use Consumer Tag to add or edit a consumer tag.

The Consumer Tag settings are:

Setting Controller Tag Name Description Data Type
Class External Access

Description
The controller that consumes the tag. The tag name used in both the producer and consumer controller. The description of the tag. Cannot be longer than 120 characters. The data type of the tag, such as BOOL or DINT. For safety class producer/consumer tags, the user defined data type must be defined in Logix Designer and the data type of the first element must be CONNECTION STATUS. The class of the tag, either Safety or Standard. Only available for safety controllers, such as a 1756-L61S. The level of access that external applications and devices have to the tag. � Read/Write: External applications and devices can both read and change the tag's value. � Read Only: External applications and devices can only read the value of the tag. � None: External applications and devices cannot read or change the tag's value.

Array Dimensions

Sets the number of dimensions for the tag. The default is 0

Use Unicast Connection over EtherNet/IP Sets whether or not the tag is consumed using a unicast connection. This setting is only available if the connection

between the producer and the consumer is over EtherNet/IP.

Producer Tag

See also
Add a produced and consumed tag on page 85 Edit a produced and consumed tag on page 87 Producer Tag on page 91 How do I open Producer Tag? 1. In Produce/Consume Tags, click Add or Edit. 2. In Consumer Tag, click Connection. Use Producer Tag to add or edit a producer tag. The Producer Tag settings are:

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 8

Add relationships and tags

Setting

Controller Tag Name Description Class

External Access

RPI Allow Unicast Consumer Connections

Description
The controller that produces the tag. The tag name used in both the producer and consumer controller. The description of the tag. 120 character maximum. The class of the tag, either Safety or Standard. Only available for safety controllers, such as a 1756-L61S. The level of access that external applications and devices have to the tag. � Read/Write: External applications and devices can both read and
change the tag's value. � Read Only: External applications and devices can only read the value
of the tag. � None: External applications and devices cannot read or change the
tag's value. The requested packet interval (RPI) of the tag. The producing controller updates the tag once per interval. The default interval is 20ms. Sets whether or not the tag is provided using a unicast connection to the consumer controller. This setting is only available if the connection between the producer and the consumer is over EtherNet/IP.

I/O Aliases

See also
Add a produced and consumed tag on page 85
Edit a produced and consumed tag on page 87
Consumer Tag on page 91
How do I open I/O Aliases? � From the View menu, check I/O Aliases.
Use I/O Aliases to add, edit, and remove point tags. I/O Aliases shows each I/O module owned by a selected controller and lists the I/O points, direction, and created point tags of the module. Cannot create or edit tags for an I/O module unless the module is owned by at least one controller.

Column Name Catalog Number Description
92

The I/O Aliases columns are:
Description The name of the module. The catalog number of the module. The description of the module.
Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Column
Point Type/Direction Point Tag InputController

Chapter 8

Add relationships and tags

Description

The number of the physical input or output point on the module. The type of input or output, as defined by the module. The point tag as defined for the module. Shows the alias tag as defined in each owner controller's project. If multiple controllers own the module, multiple columns are shown.

Communications

See also
Add a point tag on page 86 Add an ownership relationship on page 83 How do I open Communications? � From the View menu, check Communications. Use Communications to view and edit shortcut paths for FactoryTalk View applications that have FactoryTalk Linx servers.

See also

Add a shortcut on page 84

Add New or Modify Existing Shortcut

How do I open Add New or Modify Existing Shortcut?
1. In Hardware Diagram, locate the controller that will be used in the FactoryTalk View project.
2. Drag the controller on top of the computer that hosts the RSLinx server.

Use Add New or Modify Existing Shortcut to set a name and offline tag file for a new or existing shortcut. Change these settings after the shortcut is created using the Properties Shortcuts tab when editing a FactoryTalk Linx server.

See also
Add a shortcut on page 84 Edit a shortcut on page 87

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Add a graphic Add a file

Customize a hardware diagram

Chapter 9

Add graphics, files, text boxes, shapes, and links to display additional information or reference material about the project. Graphics, files, text boxes, shapes and links appear in Hardware Diagram.
See also
Add a graphic on page 95 Add a file on page 95 Add a text box on page 96 Add a shape on page 96 Add a link on page 97 Add a graphic in Hardware Diagram to display information related to the network design. Studio 5000 Architect software provides a set of sample device images, located at C:\Users\Public\Documents\Studio 5000\Samples\Architect\Graphics.
To add a graphic:
1. Select Edit > Add Graphic. 2. In Add Graphic, type the path to the file or select Browse to select an
image file, then select OK.
See also
Supported graphic formats on page 97 Add a file on page 95 Add any file to Hardware Diagram to accompany the project. Add any file type. Commonly added files are configuration and documentation. Added files are copied into the project folder and appear in Hardware Diagram as images.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 9

Customize a hardware diagram
To add a file:
1. Select Edit > Add File. 2. In Add File, configure the image and file settings:
� Image file name: Enter the path to the file or select Browse to select an image file.
� File name: Enter the path to the file or select browse to select the file.
3. Select OK. Studio 5000 Architect software adds the file to the project and the file appears in Hardware Diagram as the selected image.

Add a text box

See also
Add a graphic on page 95
Supported graphic formats on page 97
Add text boxes in Hardware Diagram to label components.
To add text:
1. From the Drawing toolbar, select the Text Tool. 2. Click in Hardware Diagram to set the position or select and drag to set
both the position and size. 3. In Text Box Properties, configure the text settings:
� In the space provided, type the text. � (optional) Select the text properties, such as bold, italic, underline,
strikeout, color, font � (optional) Choose a border for the text box and specify the options
for the border style. 4. Select OK. The text appears in Hardware Diagram.

Add a shape
96

See also
Text Box Properties on page 97 Add shapes in Hardware Diagram to label and group components.
To add shapes:
1. From the Drawing toolbar, select the appropriate tool: � Line Tool � Rectangle Tool � Circle Tool
Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 9

Customize a hardware diagram

2. Drag in Hardware Diagram to set the position and size.

Add a link

See also
Element Properties on page 98
Add a web link in Hardware Diagram to refer to a web page or document containing more information about the network design. Web links are represented in Hardware Diagram using text and an optional image.

To add a link:
1. Select Edit > Add Web Link. 2. In Add Web Link, configure these settings:
� Text: Enter the text to display in the hardware diagram. � (optional) Image: Enter the path to the file or select Browse to select
an image file. � URL: Enter the URL to the content.
3. Select OK. Studio 5000 Architect software displays the link in Hardware Diagram.

Text Box Properties

See also

Supported graphic formats on page 97 How do I open Text Box Properties?

� If you are adding a text box, click the

Text Tool, then click in

Hardware Diagram to set the position or drag across the hardware

diagram to set both the position and size.

� If you are editing a text box, right-click the text box and select

Properties.

Use Text Box Properties to add or edit a text box in a Studio 5000 Architect project. Change the text, font, size, color, effects, and borders of a text box.

See also

Add a text box on page 96

Supported graphic formats

Studio 5000 Architect software supports these graphic formats:
� Bitmap (BMP) � Device-independent bitmap (DIB) � Graphics interchange format (GIF) � Joint Photographic Experts Group (JPEG)

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 9

Customize a hardware diagram
� Portable Network Graphics (PNG) � Icon (ICO)

Element Properties

See also
Add a graphic on page 95 Add a file on page 95 Add a link on page 97 How do I open Element Properties? � In Hardware Diagram, right-click on a rectangle, circle, or line, then click Properties. Use Element Properties to set border and fill options for a rectangle, circle, or line.

See also

Update a hardware diagram on page 100

Select Online Controller to Update on page 104

Choose Matching Controller Configuration File on page 68

Errors during commit and update on page 106

Commit a single project to apply all changes made in the Studio 5000 Architect project to the associated Logix Designer project or FactoryTalk View application file. Any differences in the project file are overwritten. Studio 5000 Architect creates a new project file if one does not exist.

To avoid accidentally overwriting project and application changes, commit changes from Studio 5000 Architect software before editing in Logix Designer or FactoryTalk View Studio software.

Important:

If a FactoryTalk View application has a shortcut that is not in the Studio 5000 Architect project, the commit does not remove the shortcut from the FactoryTalk View application.

To commit a single project
1. In Project Explorer, expand the Projects folder 2. (optional) If Arrange Projects by Hardware Diagram is enabled,
expand the hardware diagram containing the project. 3. In Project Explorer, select a project. 4. From the Sync menu, select Commit Project Changes. 5. In Commit Summary, review the changes to the Logix Designer
project or FactoryTalk View application, then select OK. 6. When Studio 5000 Architect software finishes committing the project,
in Committing Projects select Close. The results display in Output.

102

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Update a single project

See also

Chapter 10 Commit and update hardware diagrams

Output on page 103
Errors during commit and update on page 106
Update a project to apply all changes made in its associated Logix Designer project or FactoryTalk View application file to the Studio 5000 Architect project. Any differences in the Studio 5000 Architect project are overwritten.
If a Logix Designer project or FactoryTalk View application contains a module that is not supported, Studio 5000 Architect software adds an unsupported module image in the appropriate chassis, DIN rail, or slot. If a module is unnamed, Studio 5000 Architect software automatically generates a module name based on the module's catalog number.
To avoid accidentally overwriting project and application changes, update changes from Logix Designer or FactoryTalk View Studio software before editing in Studio 5000 Architect software.

To update a single project
1. In Project Explorer, expand the Projects folder. 2. (optional) If Arrange Projects by Hardware Diagram is enabled,
expand the hardware diagram containing the project. 3. In Project Explorer, select a project. 4. From the Sync menu, select Update Project Changes. 5. (optional) If Ethernet Configuration appears, configure the Ethernet
connections, then select OK. 6. In Update Summary, review the changes to the hardware diagram,
then select OK. 7. (optional) If Validate Results for PointTag update appears, review
changes to point tags, then select OK.
The results of the update show in Output.

Output

See also
Output on page 103 About unsupported modules on page 45 Errors during commit and update on page 106 How do I open Output? � From the View menu, click Output. Use Output to view error, warning, and informational messages about a Studio 5000 Architect project. By default, messages are sorted by time, with

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

103

Chapter 10

Commit and update hardware diagrams
the newest message at the bottom of the list. Messages are cleared when the project is closed.

Column Severity
Time Hardware Diagram Project Type Message

Description
The type of message, including: � Error: An operation was canceled or could not continue. Resolve the error condition and repeat the operation to continue. � Warning: An operation completed, but may have significantly changed one or more components in the project. Review these
components to ensure they function as expected. � Info: An operation completed successfully. The time the message occurred. Hidden by default. The hardware diagram associated with the message. Hidden by default. The Logix Designer project or FactoryTalk View application associated with the message. The model number of the hardware component associated with the message. The message description, explaining the operation status and severity.

Select Online Controller to Update

See also
Commit a hardware diagram on page 99
Update a hardware diagram on page 100
How do I open Select Online Controller to Update?
� In Hardware Diagram, right-click a controller, then click Update With Online.
Select Online Controller to Update lists controllers connected to the network. Select a controller to update settings from the online controller to settings in the Studio 5000 Architect project. Select Auto Find to automatically scan the network for a matching controller.

See also
Update a hardware diagram with an online controller on page 101 Auto Find Matching Controller on page 105

104

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Auto Find Matching Controller

Chapter 10 Commit and update hardware diagrams
How do I open Auto Find Matching Controller?
1. In Hardware Diagram, right-click a controller, then click Update With Online.
2. In Select Online Controller to Update, click Auto Find...
Use Auto Find Matching Controller when importing or updating a project to scan the network for a matching controller.

See also
Update a hardware diagram with an online controller on page 101
Select Online Controller to Update on page 104
Choose Matching Controller How do I open Choose Matching Controller Configuration File? Configuration File
If you are importing a controller from an online controller
1. Select Hardware Diagrams > Import from Online Controller... 2. In Select Online Controller to Import, browse the network, select the
controller to import into the project, then click Select.

See also
Import a controller project from an online controller on page 66 Update a hardware diagram with an online controller on page 101 Select Online Controller to Import on page 67

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

105

Chapter 10 Commit and update hardware diagrams

Errors during commit and update

Duplication, configuration, permission, communication, and license errors may occur when committing or updating a Studio 5000 Architect project. These errors either cancel the action or continue with limited functionality. They are not displayed in Commit Summary or Update Summary.

Error Message Unable to commit a duplicated node <object> with name <name>.

Resolution Remove the duplicated node from the target project.

HMI <name> is unable to be created for it already exists. Project <name> contains invalid configuration data. Verify the project properties, then try again. User does not have permissions <permission> for <scope>.
User does not have permission to read or list children for <scope>.
User does not have permission to read/write or list children for <scope>.
User does not have permission to delete <object>
User does not have permission to create <object>
User does not have permission to read <object>
User does not have permission to write <object>, all children under it will not be created. <Scope> scope is in Read-only mode, for the FactoryTalk Directory server is not available. Component added event could not be fired properly, for it could not connect to FactoryTalk Event subsystem. Failed to open HMI <name>.
The HMI server is offline. Unable to add the display to the application. The application already contains the PanelView Plus 7 Standard or Compact Machine Edition maximum displays. Unable to add the display to the application. The application already contains the maximum displays the license allowed. Unable to commit or upload HMI server. The maximum number of HMI servers allowed to load on a single computer has been reached. Unable to set the application to compact version because the PanelView Plus 7 Standard or Compact Machine Edition display limits have been exceeded. HMI <name> is not licensed to allow remote connections. HMI <name> is not licensed and could not be opened.
Unknown error. Controller <name> requires a different Logix Designer version 21 to be installed.
Controller project requires RSLogix 5000 version 0 to be installed.

Remove the duplicated HMI server from the target project. Remove the invalid device configuration from the target project.
Verify the permissions of the user are set correctly in FactoryTalk Security. Verify the permissions of the user are set correctly in FactoryTalk Security. Verify the permissions of the user are set correctly in FactoryTalk Security. Verify the permissions of the user are set correctly in FactoryTalk Security. Verify the permissions of the user are set correctly in FactoryTalk Security. Verify the permissions of the user are set correctly in FactoryTalk Security. Verify the permissions of the user are set correctly in FactoryTalk Security. Verify the FactoryTalk Directory is configured properly. If it is remotely hosted, ensure the server is online and can be reached on the network. Verify FactoryTalk View is installed and configured correctly.
Verify the path to the FactoryTalk View application is correct and the file is not corrupt. Verify the <HMI> server is online can be reached on the network. Reduce the number of displays in the FactoryTalk View application.
Reduce the number of displays in the FactoryTalk View application.
Reduce the number of HMI servers configured to run on the computer.
Reduce the number of displays in the FactoryTalk View application.
Remove remote connections in the FactoryTalk View application. Change the FactoryTalk View license or remove the HMI server from the application. This occurs when you attempt to configure, commit, update, or open a project in Logix Designer. Update Logix Designer to at least version 21.03. This occurs when you attempt to add a controller project. Update Logix Designer to at least version 21.03

106

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

See also

Chapter 10 Commit and update hardware diagrams

Commit a hardware diagram on page 99

Update a hardware diagram on page 100

FactoryTalk View commit validation rules on page 107

Shortcut commit validation rules on page 107

FactoryTalk View commit validation rules

Studio 5000 Architect software validates each component of FactoryTalk View applications before committing to ensure compatibility with FactoryTalk View.

Scenario
Display or global object has a higher version than the FactoryTalk View application. Display or global object has a lower version than the FactoryTalk View application.

FactoryTalk View Compatibility Incompatible
Compatible

FactoryTalk View ME display or global object added to FactoryTalk View SE application.

Compatible

FactoryTalk View SE display or global object added to FactoryTalk View ME application. FactoryTalk View ME macro added to FactoryTalk View SE application. FactoryTalk View SE macro added to FactoryTalk View ME application.

Incompatible Incompatible Incompatible

Result Commit cancels. Error appears in Commit Summary.
Commit succeeds. FactoryTalk View upgrades the display or global object when opened in FactoryTalk View Studio software. Commit succeeds. FactoryTalk View converts the display or global object when opened in FactoryTalk View Studio software. Commit cancels. Error appears in Commit Summary.
Commit cancels. Error appears in Commit Summary.
Commit cancels. Error appears in Commit Summary.

See also

Errors during commit and update on page 106

Shortcut commit validation Studio 5000 Architect software validates shortcuts before committing to
ensure compatibility with the FactoryTalk Linx server.
rules

Scenario

FactoryTalk Linx Compatibility

Shortcut in Studio 5000 Architect software points to

Compatible

communication module and controller that match

FactoryTalk Linx server device tree.

Shortcut in Studio 5000 Architect software points to IP

Compatible

address not used by any device in FactoryTalk Linx server device tree.

Shortcut in Studio 5000 Architect software points to a

Incompatible

controller with a different catalog number than the controller in the FactoryTalk Linx server device tree.

Result Commit succeeds.
Commit succeeds. Communication module and controller added to FactoryTalk Linx server device tree.
Commit succeeds. The path is removed from the shortcut. Studio 5000 Architect software displays a warning in Commit Summary.

See also

Errors during commit and update on page 106

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

107

Chapter 10 Commit and update hardware diagrams

108

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Create and use libraries

Chapter 11

Create a new library

A library is a list of components from Logix Designer, FactoryTalk View, and other Rockwell Automation� products. Libraries are independent from Studio 5000 Architect and configured separately. Use libraries to add components to a Studio 5000 Architect project or export and import libraries to transfer groups of components to another computer.

Library components are add-on instruction (AOI), user defined tag (UDT), FactoryTalk View components, or hardware definitions exported from Logix Designer as .l5x XML files. Libraries have a .lal file extension and are an archive of the individual .l5x files, each containing the definitions of each component and any referenced AOIs and UDTs. The .lal file name matches the name defined for the library.

This table identifies the types of supported library components:

Logix Designer
AOI UDT

FactoryTalk View SE
Displays Global Objects Macros Images

FactoryTalk View ME
Displays Global Objects Macros Images Tag list

Other PDF

See also
Create a new library on page 109 Import a library on page 110 Delete a library on page 111 Libraries contain the components used in designing an automation system. Create custom libraries for organizing groups of components. Libraries are not specific to Studio 5000 Architect projects.

To create a new library
1. From the Studio 5000 Architect menu, select Library Management > New Library.
2. In Name, type a unique library name.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

109

Chapter 11 Create and use libraries

3. (optional) In Description, type a phrase to describe the library contents.
4. (optional) In Revision, use the arrows to establish major and minor revisions for the library to support manual tracking of libraries over time.
5. (optional) In Revision Note, type a phrase that provides a revision specific description for the library.
6. Select OK to create new Studio 5000 Architect Library (.lal) file in the libraries directory (by default C:\Users\Public\Documents\Studio 5000\Libraries\Architect).

Rename a library

See also
Add a component to a library on page 114
Toolbox on page 13
Libraries contain the components used to design an automation system. Components refer to other components by component name and type only, not library location. Renaming a library does not require changes to the components in that library.

To rename a library
1. In Toolbox, right-click a library, then select Rename. 2. Type in a new name for the library, then select Enter.

Import a library

See also
Import a library on page 110
Toolbox on page 13
Libraries contain the components used to design an automation system. Libraries are not specific to Studio 5000 Architect projects and can be imported from Logix Designer, FactoryTalk View, PlantPAx�, and other Rockwell Automation products.

To import a library
1. From the Studio 5000 Architect menu select Library Management > Import Library.
2. In Import Library, navigate to and select one or more library files, then select Open.

110

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Delete a library Export a library

Chapter 11 Create and use libraries
The library (or libraries) are automatically shown in Toolbox. If a library of the same name already exists in Toolbox, Studio 5000 Architect software prompts to select a different library or import the library under a new name.

See also
Add a component to a library on page 114
Toolbox on page 13
Libraries contain the components used to design an automation system. If a custom library is no longer useful, it can be deleted. The Default Hardware Libraries cannot be deleted.

To delete a library
1. In Toolbox, right-click a library (or libraries), then select Delete. 2. In Deletion Confirmation in Library Manager select OK. The library
archive file for each selected library, and all of its contents, is deleted from the libraries directory.

See also
Create a new library on page 109
Import a library on page 110
Toolbox on page 13
Libraries contain the components used to design an automation system. Libraries are not specific to Studio 5000 Architect software and can be exported from Studio 5000 Architect for use in Logix Designer software, FactoryTalk View software, and other Rockwell Automation software products.

To export a library
1. From the Studio 5000 Architect menu select Library Management > Export Library.
2. In Export Library, navigate to and select the location to export the library file.
3. In File Name type the name for the library file. 4. Select Save to export the library.
If a library file of the same name already exists in the directory, Studio 5000 Architect software prompts to replace the file.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

111

Chapter 11 Create and use libraries
Export part of a library

See also
Add a component to a library on page 114
Libraries contain the components used to design an automation system. To export a subset of a library, such as a single folder of components, create a new library that contains just that subset and then export that library.

To export part of a library
1. From the Studio 5000 Architect menu select Library Management > New Library.
2. In Name, type a unique library name. 3. (optional) In Description, type a phrase to describe the contents of the
library. 4. (optional) In Revision, use the arrows to establish major and minor
revisions for the library. 5. (optional) In Revision Note, type a phrase that provides a revision
specific description for the library. 6. Select OK to create the new Studio 5000 Architect Library file in the
libraries directory (by default C:\Users\Public\Documents\Studio 5000\Libraries\Architect). 7. In Toolbox, right-click a component (or components), then select Copy. 8. In Toolbox, right-click on the target library or folder, then select Paste. Studio 5000 Architect verifies that components with the same name and type do not exist in the target folder or library. 9. Select OK. Studio 5000 Architect displays the component (or components) in the target library or folder. Repeat the copy and paste process as needed to copy the entire subset of components. 10. From the Studio 5000 Architect menu, select Library Management > Export Library. 11. In Export Library, navigate to and select the location to export the library file. 12. In File Name, type a unique name for the library file. 13. Select Save to export the library.

Create a new folder

See also
Create a new folder on page 112 Toolbox on page 13 Use folders to organize the components in a custom library. Folder names must not include \ / ? : * " > < or |.

112

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Rename a folder Delete a folder

Chapter 11 Create and use libraries
Once created, copy, paste, and move the folders. Components can be imported directly into a folder.

To create a new folder
1. In Toolbox, right-click a custom library, then select New Folder. A folder is added to the tree with the default name New Folder_1 selected.
2. Type in a name for the folder, then select Enter.

See also
Rename a folder on page 113 Delete a folder on page 113 Import a component to a library on page 115 Toolbox on page 13 Use folders to organize the components in a custom library.

To rename a folder
1. In Toolbox, right-click a folder, then select Rename. 2. Type in a new name for the folder, then select Enter.

See also
Create a new folder on page 112
Delete a folder on page 113
Toolbox on page 13
Use folders to organize the components in a custom library. If a folder is no longer useful, it can be deleted. To delete a folder that contains components, delete each component from the folder first. After all components are deleted from the folder, delete the folder from the library.

To delete a folder
1. In Toolbox, right-click a folder then select Delete. 2. In Delete Confirmation in Library Manager, select Yes. The folder (or
folders) are deleted from the Toolbox.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

113

Chapter 11 Create and use libraries
Add a component to a library

See also
Delete a component on page 117
Rename a folder on page 113
Create a new folder on page 112
Toolbox on page 13
A library component is a Logix Designer add-on instruction (AOI) or user defined tag (UDT), or a FactoryTalk View Studio display, graphic object, or image. When a component is added to the library, the export file is added to the archive file in the libraries directory.
Components with the same name but different types (for example, AOI or UDT) can exist in the same library or folder in the library. Components with the same name and type (for example, AOI) cannot exist in the same library.
Once a component is added to a library, the component can be copied or moved into another library.

To add a component to a library from Logix Designer or FactoryTalk
View Studio
1. Start Logix Designer or FactoryTalk View Studio and open a project. 2. In the Controller Organizer, drag the selected component from Logix
Designer or FactoryTalk View Studio software to a folder in the Toolbox in Studio 5000 Architect software. Studio 5000 Architect software adds the component to the selected library.

To add a component to a library from a project
1. Save the project in Logix Designer. 2. Start Studio 5000 Architect software and open a project. 3. From the main menu, select Library Management > Add Component
to Library. 4. In Add component to Library, click to locate the component, then
select OK. Studio 5000 Architect software displays the component in the selected library.

See also
Rename a component on page 116 Delete a component on page 117

114

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Import a component to a library

Chapter 11 Create and use libraries
Import previously exported components from Logix Designer into a selected library or folder. Multiple components can be imported in a single operation.
To import a component from a file
1. In Toolbox, right-click the folder or library, then select Import Component.
2. In Import Component, select one or more .l5x files to import, then select Open. The Toolbox displays the imported component or components.

See also

Copy library components from Studio 5000 Architect software to Logix Designer software on page 115

Copy library components from Studio 5000 Architect software to FactoryTalk View Studio software on page 116

Add a component to a library on page 114

Toolbox on page 13

Copy library components from Studio 5000 Architect software to Logix Designer software

Add-on instruction (AOI) and user defined tag (UDT) objects in Studio 5000 Architect libraries are items that can be copied into Logix Designer projects. Any references within the AOI and UDT objects are automatically copied into the Logix Designer project.
When updating a Logix Designer project, if a reference in an AOI or UDT is missing from the Logix Designer project, the referenced objects must be copied to the project.

To copy library components from Studio 5000 Architect software to
Logix Designer software
1. Open Studio 5000 Architect software. 2. Open the Logix Designer project. 3. In Studio 5000 Architect select View > Toolbox. 4. In Toolbox, drag an AOI to the Add-On Instructions folder or a UDT to
the Data Types > User-Defined folder in the Logix Designer Controller Organizer.

See also

Chapter 12 Search and print project information

Find Results on page 123
Print Preview on page 124
Use Filter to limit which products or library components appear in the Toolbox.

To filter the Toolbox
� At the top of Toolbox, select Filter, then enter a filter term. Matching Logix Designer, FactoryTalk View Studio, and library components appear.

See also
Toolbox on page 13
How do I open Find?
� From the Edit menu, click Find.
Use Find to search for terms in custom libraries and Logix Designer projects included in a Studio 5000 Architect project. Find does not search FactoryTalk View applications.
Description Enter search term. Determines if the search term is case sensitive. Determines if the search must find an exact match, including spaces. Determines the controller projects to search. Determines the custom libraries to search. Determines object types to search. Determines if the Find closes once the search has completed.

See also
Search a project on page 122 How do I open Find Results?
� From the View menu, click Find Results.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

123

Chapter 12

Search and print project information
Use Find Results to view the results of a search. Double-click an item in Find Results to open the item in Logix Designer. By default, items are sorted alphabetically by name. Results are cleared when the project closes.

Item Name Kind Type Container Location Description
Print Preview

Description The name of the search result, such as AB:1756_AO6_Struct:C:0. The kind of the search result, such as DataTypes. The data type of the search result, such as DINT or IO. The component in the project or library that contains the search result, such as Controller. The name of the project or library that contains the search result, such as Hardware Diagram 01:L75. The description of the search result, if available.
See also
Search a project on page 122 Print search results on page 122 Find on page 123 How do I open Print Preview? 1. Perform a search using Find. 2. In Find Results, right-click on a row, then click Print Preview.

124

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 12 Search and print project information
Use Print Preview to review and print search results and hardware diagrams.

Icon

Description

Print. Print the project search results or hardware diagram. Hand Tool. Select and scroll through the contents of the search results or hardware diagram. Snapshot Tool. Select or drag the search results or hardware diagram to copy the page or selection to the clipboard.

Dynamic Zoom Tool. Drag up to increase the zoom level and drag down to decrease the zoom level.

Zoom Out Tool. Drag a rectangle to decrease the zoom level or select to incrementally decrease zoom level.

Zoom In Tool. Drag a rectangle to increase the zoom level or select to incrementally increase zoom level.

Page Width. Display the search results or hardware diagram, including page margins, in the display area.

Margin Width. Display only the search results or hardware diagram that appears within the margins in the display area.

Whole Page. Display the search results or hardware diagram page in the display area.

Zoom Out. Decrease the zoom level.

Zoom. Change the zoom level.

Zoom In. Increase the zoom level.
Continuous. Successively scroll between multiple pages, displaying a continuous flow of project search results or hardware diagrams without any page breaks. Layout. Configure the display area to show multiple pages simultaneously.

Close. Close Print Preview. First Page. Display the first page in Print Preview. Previous Page. Display the previous page in Print Preview. Current Page. Display the desired page in Print Preview.

Next Page. Go to the next page in Print Preview. Last Page. Go to the last page in Print Preview. Previous View. Display the last selected view in Print Preview.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

125

Chapter 12 Icon

Search and print project information Description Next View. Display the next selected view in Print Preview.

See also
Print search results on page 122 Print a hardware diagram on page 122 Find Results on page 123

126

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 13
Set Studio 5000 Architect options

Set a variety of options to customize how Studio 5000 Architect software operates. In most cases, changes to the project settings take effect immediately. However, if the changed behavior does not occur, close and restart Studio 5000 Architect software.
Specify options settings by configuring the Options properties tabs.

See also

Project Settings on page 127

Hardware Diagram on page 128

User Prompts on page 129

Libraries on page 130

Project Settings

How do I open Project Settings? � From the Tools menu, select Options.

Use Project Settings to set basic project options.

Option Workspace Directory Create project subdirectory under the main project directory Launch new instance of Studio 5000 Architect if a project is already open
Create alias tags automatically when Point Tag is defined

Description
Specifies the directory used for project backups and projects imported from online controllers. By default, creates a subdirectory named for the project under the default project directory. Clearing this checkbox stores all project files in the default project directory. Specifies how Studio 5000 Architect software opens projects. � When selected, Studio 5000 Architect software automatically starts a
new Studio 5000 Architect instance when a project is open and choosing to open or create a new project. � When cleared, Studio 5000 Architect software closes the currently open project and prompts to save changes before opening or creating a new project Specifies whether alias tags are created automatically when the point tag is defined. � When selected, Studio 5000 Architect software automatically unifies alias tag names across Studio 5000 Architect, Logix Designer, and third party software packages (for example, EPLAN Electric P8 software). � When cleared, Studio 5000 Architect software permits unique alias tag names across Studio 5000 Architect, Logix Designer, and third party software packages.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

127

Chapter 13 Set Studio 5000 Architect options Option Update alias tags automatically when Point Tag is updated
Arrange projects in the Project Explorer by the hardware diagram they support
Restore Defaults

Description
Specifies whether existing alias tags are replaced upon import. � When selected, Studio 5000 Architect software automatically updates
alias tags when importing a file from a third party software package (for example, EPLAN Electric P8 software). � When cleared, Studio 5000 Architect software maintains existing alias tags when importing an XML file from a third party software package. Specifies whether Project Explorer sorts projects and applications: � When Arrange Projects by Hardware Diagram is enabled, Project Explorer lists Logix Designer projects and FactoryTalk View applications by the hardware diagram that contains the project or application hardware. � When Arrange Projects by Hardware Diagram is disabled, Project Explorer lists all Logix Designer projects and FactoryTalk View applications in a single list. Restore to the default settings.

Hardware Diagram
Option Size
Orientation Using Logix Designer Show Sheet Boundaries

See also
Hardware Diagram on page 128
User Prompts on page 129
Libraries on page 130
How do I open Hardware Diagram?
� From the Tools menu, select Options, then select Hardware Diagram.
Use Hardware Diagram to set the size, orientation, and language options for hardware diagrams.
Description Specifies the desired page size for hardware diagrams. To ensure that hardware diagrams print correctly, set the hardware diagram size to match the page size for the printer.
Specifies how hardware diagrams display and print, either Portrait for a vertical alignment or Landscape for a horizontal alignment. Specifies language the Logix Designer application should use when started from within Studio 5000 Architect software. This setting has no impact on the language display of Studio 5000 Architect software. Select to display the boundaries of the printable area in the hardware diagram.

See also
Project Settings on page 127 User Prompts on page 129 Libraries on page 130

128

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Chapter 13 Set Studio 5000 Architect options

User Prompts

How do I open User Prompts? � From the Tools menu, select Options, then select User Prompts.

Use User Prompts to set the options for displaying prompts. Items selected on this tab result in a prompt. Clearing the check box stops the prompt from occurring and Studio 5000 Architect software performs the default action.

Option Prompt for configuration changes Prompt for ACD filename change Prompt for module names Prompt for overwrite configuration Prompt for commit pending changes Prompt for change to recommended Flex terminal base Show docking indicators when dragging views
Auto scroll upon selection
Prompt for confirmation before updating from a project Prompt for confirmation before committing changes to a project Prompt for update when opening a project file
Prompt for confirmation when deleting a controller (and associated controller project file) Show duplicate library name dialog box Prompt for deletion of referenced component in the Toolbox pane Show duplicate component name dialog box Set replace (no backup) as the default when duplicate component names are found Prompt for Ethernet configuration after updating from a project

Description
When attempting to close a project, prompt to save and commit to implement the configuration changes. When the .acd file name for a controller changes, prompt to commit the hardware diagram. When a module is created, prompt with a default module name and the opportunity to rename the module. Before importing or updating with an online controller, prompt that the process overwrites the current controller configuration. Before updating with an online controller, prompt to commit any pending changes to a hardware diagram. When an alternate Flex wiring base is specified, prompt to change back to the recommended Flex wiring base. When a view is rearranged in the hardware diagram, display indicators (top, bottom, left, right, or as a tab of another view group) to show where it can dock. When a device is selected either in Project Explorer or Hardware Diagram, automatically locate the device in the Project Explorer or Hardware Diagram. Prompt to confirm changes and update the Studio 5000 Architect project prior to updating changes from a controller project. Prompt to confirm changes and update the Studio 5000 Architect project prior to a commit operation. Prompt to update changes to the associated .acd file made in the Logix Designer application since the last time the Studio 5000 Architect project was open. Prompt to delete the controller from the hardware diagram, as well as the controller project file (*.acd) associated with that controller. Prompt when specifying a library name that already exists. Prompt to delete components exclusively referenced by a component currently selected for deletion in Toolbox. Prompt when specifying a library component name that already exists. Prompt to replace a component (without backing up the original with a '_bk' extension) when duplicate component names are found (default). Prompt to change Ethernet switches and connection settings after updating a project

See also
Project Settings on page 127 Hardware Diagram on page 128 Libraries on page 130

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

129

Chapter 13 Set Studio 5000 Architect options

Libraries

How do I open Libraries? � From the Tools menu, select Options, then select Libraries.

Use Libraries to set the default location for libraries. If changing the directory location, manually move any existing libraries to this new directory location.

Option Default Library Directory
Browse button

Description
The default location is C:\Users\Public\Documents\Studio 5000\Libraries\Architect. Library paths can include mapped network drives and UNC paths. All libraries are stored in the same directory. Libraries are not moved or copied when the directory changes. To use existing libraries after the directory changes, copy the .lal files to the new directory location. Use to browse a directory structure to provide the path to the library directory.

See also
Project Settings on page 127 Hardware Diagram on page 128 User Prompts on page 129

130

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Appendix A
Log on, log off, and set security policies

By default, FactoryTalk Security single sign-on is enabled. In most cases, FactoryTalk Security handles log on and log off automatically.
If single sign-on is disabled, users must log on and log off of the FactoryTalk Directory Network and Local Directory before using Studio 5000 Architect.
FactoryTalk Security policies set permissions that determine if a user or group can perform an action in Studio 5000 Architect or other FactoryTalk products. If the user or group does not have the required permissions, Studio 5000 Architect actions either displays an error message or has limited functionality.

Studio 5000 Architect software and FactoryTalk Security Single Sign-On

See also
About Studio 5000 Architect and FactoryTalk Security Single Sign-On on page 131
Log on to Factory Talk on page 132
Required Studio 5000 Architect permissions on page 137
FactoryTalk Security policy setting "Use single sign-on" (SSO) is enabled by default. When enabled, log on once per directory, on a given computer using SSO. After logging on, all participating FactoryTalk products that run in that directory on that computer automatically use the security credentials of the logged-on user. Work with multiple Rockwell Automation products simultaneously, without having to log on to each software product separately.
When SSO is enabled, no additional operations are necessary unless an alternate FactoryTalk user wants to use Studio 5000 Architect software. Use Log On to Factory Talk to log on that user account.
Keep these items in mind concerning how SSO policy settings are used with Studio 5000 Architect software:
� The Tools > Security > Log On To FactoryTalk menu selection is available unless the Studio 5000 Architect product policies are installed. Use this men to change the user credentials that Studio 5000 Architect software is currently running under, or to change from the SSO user if SSO is enabled.
� If SSO is disabled, Studio 5000 Architect software removes all ties with the computer-wide SSO at startup. When you start Studio 5000 Architect software a prompt to log on to FactoryTalk appears.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

131

Appendix A

Log on, log off, and set security policies
� When SSO is enabled, selecting Tools > Security > Log Off does not result in a logged off situation as Studio 5000 Architect software automatically logs on the SSO user again.

Log on to FactoryTalk

See also
Change the logged on user account on page 132
When single sign on is disabled, logging on to FactoryTalk Security from the Start menu does not automatically log into Studio 5000 Architect software. Instead, when starting Studio 5000 Architect software you are prompted to log on to FactoryTalk before editing a project.

To log on to FactoryTalk
� In Log On to FactoryTalk, type the User name and password, and then select OK. The Change Password prompt displays if the password to the account is expired or if the administrator requires a password change at log on.

See also

Change the logged on user account

Log on to FactoryTalk on page 140
Change a password on page 133
If a different user account needs to open or edit a Studio 5000 Architect project, use Log On to Factory Talk to change to that user account. Change the logon for the network directory, the local directory, or both.

To change the logged on user account
1. From the Studio 5000 Architect menu select Tools > Security > Log On to FactoryTalk
2. In Log On to FactoryTalk, select Change Logon. 3. Type the User name and Password, and then select OK.
The Change Password prompt displays if the account password expired or the administrator requires a password change at log on.

See also

Appendix A Log on, log off, and set security policies

Required FactoryTalk View ME permissions for Studio 5000 Architect software on page 139
Set FactoryTalk Directory permissions on page 134
Set Studio 5000 Architect permissions on page 134
Set Logix Designer permissions on page 135
Studio 5000 Architect Feature Security policies control user permissions, which determine whether a user or group can perform a specific action in Studio 5000 Architect software.
Description Specifies whether a user is allowed to create a new Studio 5000 Architect project. Specifies whether a user is allowed to open an existing Studio 5000 Architect project. Specifies whether a user is allowed to save a Studio 5000 Architect project.

See also

Set Studio 5000 Architect permissions on page 134

Required Studio 5000 Architect permissions on page 137

Required Studio 5000 Architect permissions

Permissions set in FactoryTalk Security policies determine if a user or group can perform actions in Studio 5000 Architect projects. If the user or group does not have the required permissions, Studio 5000 Architect actions either displays an error message or has limited functionality.

Action Create a new Studio 5000 Architect project
Open an existing Studio 5000 Architect project Save an existing Studio 5000 Architect project

Required Studio 5000 Architect permissions
Create: Allow Save: Allow Open: Allow Open: Allow Save: Allow

See also
Set Studio 5000 Architect permissions on page 134 Studio 5000 Architect Feature Security policies on page 137

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

137

Appendix A Log on, log off, and set security policies

Required Logix Designer policies and permissions for Studio 5000 Architect software

Logix Designer Feature Security policies and permissions set in FactoryTalk Security determine if a user or group can perform actions on Studio 5000 Architect projects that contain Logix Designer projects. If the user or group does not have the required permissions, Studio 5000 Architect actions either displays an error message or has limited functionality.

Action Add a Logix Designer project Import a Logix Designer project from an online controller

Required RSLogix 5000 Feature Security policies Controller: Secure Project: New Controller: Secure Project: New (new project file only)

Add a module
Edit module properties Move a module in a hardware diagram

Controller: Secure
Controller: Secure Controller: Secure

Remove a module
Open a Logix Designer project in Logix Designer Go online with a controller
Commit a Logix Designer project

Controller: Secure
Controller: Secure Controller: Secure
Controller: Secure Project: New (first commit only)

Update a Logix Designer project Update a Logix Designer project with an online controller

Controller: Secure Controller Secure: Project: New (first update only)

Browse tags in the controller

Controller: Secure

Create aliases for I/O tags

Controller: Secure

Use current tags in a controller to create a produce/consume tag relationship

Controller: Secure

Add a new tag, and then create a produce/consume tag relationship

Controller: Secure

Add a new AOI

Controller: Secure

Overwrite an AOI that already exists (properties are modified) Controller: Secure

Delete an AOI

Controller: Secure

Add a new UDT

Controller: Secure

Overwrite an UDT that already exists (properties are modified)

Controller: Secure

Delete an UDT

Controller: Secure

Search a Logix Designer project

Controller: Secure

Required FactoryTalk Directory > RSLogix 5000 permissions Project: Open
Project: Go Online Project: Open Project: Save Project: Upload Module: Create Properties Module: Modify Properties Module: Modify Properties Module: Create Module: Delete Module: Modify Properties Module: Delete Module: Modify Properties Project: Open Project: Go Online Project: Open Controller: Modify Properties Controller: Unsecure Module: Modify Properties Project: Open Project: Save Tag: Modify Properties Project: Open Project: Go Online Project: Open Project: Save Project: Upload Project: Open Tag: Modify Properties Tag: Create Tag: Delete Tag: Create
Add-On Instruction: Create Add-On Instruction: Modify Add-On Instruction: Delete User Defined Type: Create User Defined Type: Modify
User Defined Type: Delete Project: Open

138

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

See also

Appendix A Log on, log off, and set security policies

Set FactoryTalk Directory permissions on page 134

Set Logix Designer permissions on page 135

Required FactoryTalk View SE permissions for Studio 5000 Architect software

FactoryTalk View SE permissions set in FactoryTalk Security determine if a user or group can perform actions on Studio 5000 Architect projects that contain FactoryTalk View SE applications. If the user or group does not have the required permissions, Studio 5000 Architect actions either displays an error message or has limited functionality.

Action Add existing FactoryTalk View SE application Open FactoryTalk View SE application in FactoryTalk View Studio Commit new FactoryTalk View SE application
Commit existing FactoryTalk View SE application
Update existing FactoryTalk View SE application

Required FactoryTalk Directory permissions List Children: Allow Read: Allow List Children: Allow Read: Allow Create Children: Allow List Children: Allow Read: Allow Write: Allow Create Children: Allow Delete: Allow List Children: Allow Read: Allow Write: Allow List Children: Allow Read: Allow

Required Application permissions List Children: Allow Read: Allow List Children: Allow Read: Allow Not applicable.
Create Children: Allow Delete: Allow List Children: Allow Read: Allow Write: Allow List Children: Allow Read: Allow

Required Area permissions
List Children: Allow Read: Allow List Children: Allow Read: Allow Not applicable.
Create Children: Allow Delete: Allow List Children: Allow Read: Allow Write: Allow List Children: Allow Read: Allow

See also

Set FactoryTalk Directory permissions on page 134

Set FactoryTalk View SE permissions on page 136

Required FactoryTalk View ME permissions for Studio 5000 Architect software

FactoryTalk View ME permissions set in FactoryTalk Security determine if a user or group can perform actions on Studio 5000 Architect projects that contain FactoryTalk View ME applications. If the user or group does not have the required permissions, Studio 5000 Architect actions either displays an error message or has limited functionality.

Action Add existing FactoryTalk View ME application Open FactoryTalk View ME application in FactoryTalk View Studio

Required FactoryTalk Directory permissions
List Children: Allow Read: Allow List Children: Allow Read: Allow

Required Application permissions
List Children: Allow Read: Allow List Children: Allow Read: Allow

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

139

Appendix A Action

Log on, log off, and set security policies

Commit existing FactoryTalk View ME application

Update existing FactoryTalk View ME application

Required FactoryTalk Directory permissions
Create Children: Allow Delete: Allow List Children: Allow Read: Allow Write: Allow List Children: Allow Read: Allow

Required Application permissions
Create Children: Allow Delete: Allow List Children: Allow Read: Allow Write: Allow List Children: Allow Read: Allow

Log on to FactoryTalk

See also
Set FactoryTalk Directory permissions on page 134
Set FactoryTalk View ME permissions on page 136
How do I open Log On to FactoryTalk?
� From the Tools menu, select Security > Log On to FactoryTalk. Use Log On to FactoryTalk to choose the logon credentials used to authenticate Studio 5000 Architect software.
� Use a Network log on to access Network (distributed) applications on the Network Directory Server.
� Use a Local log on to access Local (stand-alone) applications on the Local Directory. If you cannot log on to a particular directory on this computer, verify that the user account has permissions to that directory.

See also
Log on to FactoryTalk on page 132 Change the logged on user account on page 132

140

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

Legal Notices

Legal Notices
Rockwell Automation publishes legal notices, such as privacy policies, license agreements, trademark disclosures, and other terms and conditions on the Legal Notices page of the Rockwell Automation website.
End User License Agreement (EULA)
You can view the Rockwell Automation End User License Agreement (EULA) by opening the license.rtf file located in your product's install folder on your hard drive. The default location of this file is:
C:\Program Files (x86)\Common Files\Rockwell\license.rtf.
Open Source Software Licenses
The software included in this product contains copyrighted software that is licensed under one or more open source licenses. You can view a full list of all open source software used in this product and their corresponding licenses by opening the index.html file located your product's OPENSOURCE folder on your hard drive. The default location of this file is:
C:\Program Files (x86)\Common Files\Rockwell\Help\Architect Release Notes\OPENSOURCE\index.htm You may obtain Corresponding Source code for open source packages included in this product from their respective project web site(s). Alternatively, you may obtain complete Corresponding Source code by contacting Rockwell Automation via the Contact form on the Rockwell Automation website: http://www.rockwellautomation.com/global/aboutus/contact/contact.page. Please include "Open Source" as part of the request text.

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

141

Index
A
add 1756-L8x ControlLogix controller 33 5069-AEN2TR communication module 39 5069-L3x CompactLogix controller 38 ownership relationship 78 PowerFlex drive 45 producer/consumer relationship 79 shortcut 79 switch unmanaged 68 tag axis 82 point 81
axis tag add 82
C
commit validation rules 100, 101
F
find matching controller 98
G
graphic supported formats 91
I
I/O Aliases 87 image
supported formats 91 install 18
M
managed switch add 68

Index
O
ownership relationship add 78
P
point tag add 81
PowerFlex drive add 45
producer/consumer relationship add 79
Project Explorer 12
S
shortcut add 79 edit 83
system requirements 17
T
Toolbox 13
U
unmanaged switch add 68

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020

143

Rockwell Automation support

Use these resources to access support information.

Technical Support Center
Knowledgebase Local Technical Support Phone Numbers

Find help with how-to videos, FAQs, chat, user forums, and product notification updates. Access Knowledgebase articles. Locate the telephone number for your country.

rok.auto/support
rok.auto/knowledgebase rok.auto/phonesupport

Literature Library Product Compatibility and Download Center (PCDC)

Find installation instructions, manuals, brochures, and technical data publications. rok.auto/literature Get help determining how products interact, check features and capabilities, and rok.auto/pcdc find associated firmware.

Documentation feedback
Your comments help us serve your documentation needs better. If you have any suggestions on how to improve our content, complete the form at rok.auto/docfeedback.
Waste Electrical and Electronic Equipment (WEEE)
At the end of life, this equipment should be collected separately from any unsorted municipal waste.
Rockwell Automation maintains current product environmental information on its website at rok.auto/pec.

Allen-Bradley, expanding human possibility, Logix, Rockwell Automation, and Rockwell Software are trademarks of Rockwell Automation, Inc. EtherNet/IP is a trademark of ODVA, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies. Rockwell Otomayson Ticaret A.. Kar Plaza Merkezi E Blok Kat:6 34752, �erenk�y, stanbul, Tel: +90 (216) 5698400 EEE Y�netmeliine Uygundur

Rockwell Automation Publication ARCH-GR001J-EN-E - October 2020
Rockwell Automation Publication ARCH-GR001I-EN-E - December 2018
