4900-HCR Collapse-Resistant-Subsea-Hose Parflex HCR Hose
High Collapse Resistant Subsea Hose for the Oil & Gas Market
Parker Parflex HCR hose is specifically designed to serve the oil & gas market in subsea hydraulic applications. Its state of the art construction provides a minimum crush resistance of 6,600 psi external pressure. The stainless steel inner carcass provides industry leading collapse strength needed in deep water applications. The seamless, extruded Polyamide core tube has a wide range of media compatibility and the high tensile strength aramid reinforcement provides a full 5000 psi working pressure at 4:1 design factor. The seawater resistant perforated Polyurethane cover provides durable protection in demanding environments and the industry leading bend radius allows for tight routing. These features combine to offer a solution to withstand the rigors of the oil & gas industry.
Contact Information:
Parker Hannifin Corporation Parflex Division 11151 Cash Road Houston, TX 77477 phone (281) 566 4500 fax (281) 582 5271 www.parker.com/parflex epdquotes@parker.com
Product Features:
· Validated to ISO13628-5:2009 / API 17E · Collapse resistant to 10,000 ft seawater at 1.5 design factor
per API 17E (Contact the Parflex Division for installation depths greater than 10,000 ft.) · 5,000 psi working pressure at 4:1 design factor · Seawater-resistant perforated polyurethane jacket
HCR High Collapse Resistant Hose
Features
Collapse resistant to 10,000 ft seawater at 1.5 design factor per API 17E
Flexible 316L stainless steel interlocking carcass Available in long continuous lengths Seamless polyamide core tube Abrasion and seawater resistant perforated
polyurethane cover Compact bend radius
Applications/Markets
Subsea Hydraulics BOP Stack Well Stimulation Hydraulic Flying Leads
Part Number
Nominal I.D.
Maximum O.D.
Maximum Working Pressure
Minimum Bend Radius
Weight
Minimum Collapse Pressure
lbs
HCRV-8 HCRV-16
inch mm inch mm psi MPa inch mm lbs./ft. kg./mtr. psi MPa 1/2 13 1.04 26.4 5,000 34.5 4.0 102 0.45 0.67 6600 45.6 1 25 1.83 46.4 5,000 34.5 11.8 300 1.44 2.15 6600 45.6
Construction
Carcass: 316L SS Core tube: Polyamide Reinforcement: Aramid Fiber Braid Cover: Perforated Polyurethane
Fittings
HV Series - constructed of 316L stainless steel
106HV - JIC 37° Female Flare 19GHV - Straight Dual Seal 1GXHV - Grayloc Hub Connection
Operating Parameters
Temperature Range: -40°F to +131°F (-40°C to +55°C) Min. Burst Pressure is 4x Max. Working Pressure
Colors
Standard Yellow (-YEL)
Non-Standard Black (-BLK)
Blue (-BLU) Green (-GRN)
Notes
1.5 design factor for collapse pressure per API 17E
Contact the Parflex Division for installation depths greater than 10,000 ft.
© 2018-2020 Parker Hannifin Corporation, All Rights Reserved
4900-HCR 0 4/20
