Turbowheel Dart: Dashboard Settings
Enable the Settings Mode: Pressing the Power + Mode simultaneously will enter the Dashboard setting mode.

Toggling through Short pressing the power button will toggle through the 10

the Settings

available settings for the scooter

Changing the P Value

Once you have the P setting you wish to change, press the mode button will increase value, the power button to decrease it

Setting the Change

Holding the mode button will set the value & return you to the P menu. Also, after 5 seconds the Dash will return to the main screen.

P01: Backlight. Range 1-3, 3 = Brightest

P08: Power Output. Default = 100

P02: Units. 1 = MPH, 2= KPH
P03: Battery Voltage. 24, 36, 48, 52, 60. Default = 52V P04: Dash Timeout. Range 1-60 minutes Default = 10 minutes P06: Tire Diameter. Default = 10

P09: Kick-off Start. Default = 0 1 = Push to start P11: Regenerative braking. Range 0-5 Default = 0 off, 5 = strongest P12: Acceleration Power. Range 1-5 Default = 3 P15: Low voltage cut. Default = 41

P07: Motor Poles. Default = 28

P17: Cruise Control. Default = 0, Off 1 = Enabled

2

Turbowheel Dart: Technical Specifications
Turbowheel Lightning, T10-DDM Sincpower 18.2Ah / 52V (nominal) 10 x 2.5" air tire Dual disc + regenerative ~40 Miles ~35-40 MPH 77 lb Front & rear spring + hydraulic suspension Twin front & rear, with braking mode 2x 25A control2x 1000W Hub 330 lb
3

Turbowheel Dart: Unfolding
4

Turbowheel Dart: Folding
5

9 6

7

9

partially

partially

180

8

may

up to one year

9
