Aug 22, 2019 — Supports manual configuration of LAN IP addresses. ○. Supports Address Resolution Protocol (ARP). DHCP server. ○. The DHCP server can ...
Notice. The purchased products, services and features are stipulated by the contract made between Huawei and the customer.
HUAWEI H112-372 5G CPE Pro V100R001 Product Description Issue Date 03 2019-08-22 HUAWEI TECHNOLOGIES CO., LTD. Copyright © Huawei Technologies Co., Ltd. 2019. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. Trademarks and Permissions and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd. All other trademarks and trade names mentioned in this document are the property of their respective holders. LTE is a trademark of ETSI. Wi-Fi®, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are trademarks of Wi-Fi Alliance. Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS" without warranties, guarantees or representations of any kind, either express or implied. The information in this document is subject to change without notice. Every effort has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information, and recommendations in this document do not constitute a warranty of any kind, express or implied. Huawei Technologies Co., Ltd. Address: Website: Email: Huawei Industrial Base Bantian, Longgang Shenzhen 518129 People's Republic of China http://consumer.huawei.com/en/ mobile@huawei.com Issue 03 (2019-08-22) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. i HUAWEI H112-372 5G CPE Pro Product Description About This Document About This Document Summary This document provides information regarding the features, main functions and services, technical specifications, and technical references of the product. This document includes: Chapter Details 1 Product Overview Provides an overview of the product. 2 Technical Specifications Describes the specifications of the product hardware, software, and user interface. 3 Services and Applications Describes the main functions and applications of the product. 4 System Structure and Scenario Describes the product system structure. Constraints 5 Technical References Describes the standards and communication protocols of the product. 6 Packing List Describes the devices and accessories that comprise the product package The document is an invitation to offer but not an offer. It is intended to describe the general features and functions of a product. The features and functions of certain products may vary with the requirements of customers. History Issue 01 02 03 Date 2019-06-12 2019-07-12 2019-08-22 Details Initial official release. Refresh antenna gain. Add the LTE CA combination and EN_DC combination. Issue 03 (2019-08-22) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. ii HUAWEI H112-372 5G CPE Pro Product Description About This Document Acronyms and Abbreviations Acronym or Abbreviation 3GPP ACS AES ALG AMR-NB AMR-WB AP APN ARP CLAT CPE CS CSFB DBDC DL DMZ DNS DTMF E-UTRA FDD HOTA IEEE IP IPSec IPv4 IPv6 ICMP L2TP LAN Full Spelling 3rd Generation Partnership Project Auto Configuration Server Advanced Encryption Standard Application Layer Gateway Adaptive Multi-Rate compression - Narrowband Adaptive Multi-Rate compression - Wideband Access Point Access Point Name Address Resolution Protocol Customer-side Translator Customer Premises Equipment Circuit Switched Circuit Switched Fallback Dual Band Dual Concurrent Downlink Demilitarized Zone Domain Name Server Dual-Tone Multi-Frequency Evolved Universal Terrestrial Radio Access Network Frequency Division Duplex Huawei Firmware Over the Air Institute of Electrical and Electronics Engineers Internet Protocol Internet Protocol Security Internet Protocol version 4 Internet Protocol version 6 Internet Control Message Protocol Layer Two Tunneling Protocol Local Area Network Issue 03 (2019-08-22) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. iii HUAWEI H112-372 5G CPE Pro Product Description Acronym or Abbreviation LED LTE MAC MDI MDIX MIMO MME NAT NAPT PC PCC PGW PIN PLAT PPTP QAM QR RFC RTCP RTP SAMBA SCC SCP SDRAM SDP SGW SIP SMA SMS SOHO SSID About This Document Full Spelling Light Emitting Diode Long Term Evolution Media Access Control Medium Dependent Interface Medium Dependent Interface Crossover Multi-input Multi-output Mobility Management Entity Network Address Translation Network Address and Port Translation Personal Computer Primary Component Carrier PDN Gateway Personal Identification Number Provider-side Translator Point-to-Point Tunneling Protocol Quadrature Amplitude Modulation Quick Response Request For Comments Real-time Transport Control Protocol Real-time Transport Protocol System for Advanced Mobile Broadband Applications Secondary Component Carrier Service Control Point Synchronous Dynamic Random Access Memory Session Description Protocol Serving Gateway Session Initiation Protocol Sub-Miniature-A Short Message Small Office Home Office Service Set Identifier Issue 03 (2019-08-22) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. iv HUAWEI H112-372 5G CPE Pro Product Description Acronym or Abbreviation TDD TKIP UE UL UMTS UPnP USB USIM VPN WAN WEP Wi-Fi® WMM WPA/WPA2-PSK WPA2-PSK WPS About This Document Full Spelling Time Division Duplex Temporal Key Integrity Protocol User Equipment Uplink Universal Mobile Telecommunications System Universal Plug and Play Universal Serial Bus UMTS Subscriber Identity Module Virtual Private Network Wide Area Network Wireless Encryption Protocol Wireless Fidelity Wi-Fi Multimedia Wi-Fi Protected Access/Wi-Fi Protected Access II Pre-Shared Key Wi-Fi Protected Access II - Pre-Shared Key Wi-Fi Protected Setup Issue 03 (2019-08-22) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. v HUAWEI H112-372 5G CPE Pro Product Description Contents Contents About This Document.................................................................................................................... ii 1 Product Overview ......................................................................................................................... 1 2 Technical Specifications .............................................................................................................. 3 2.1 Hardware Specifications ............................................................................................................................................... 3 2.2 Antenna Specifications ................................................................................................................................................. 6 2.2.1 Build-in LTE Antenna................................................................................................................................................ 6 2.2.2 Build-in Wi-Fi Antenna ............................................................................................................................................. 9 2.2.3 LTE CA combination ............................................................................................................................................... 10 2.2.4 EN_DC combination ............................................................................................................................................... 13 2.3 Software Specifications .............................................................................................................................................. 16 3 Services and Applications ......................................................................................................... 19 3.1 Data Services .............................................................................................................................................................. 19 3.1.1 Accessing the Internet through a Mobile Network (5G/LTE) .................................................................................. 19 3.1.2 Accessing the Internet through an Ethernet Network .............................................................................................. 20 3.2 SMS ............................................................................................................................................................................ 20 3.3 Security Service .......................................................................................................................................................... 20 3.3.1 Firewall Service ....................................................................................................................................................... 20 3.3.2 MAC Filtering ......................................................................................................................................................... 21 3.3.3 Wi-Fi Authentication................................................................................................................................................ 21 3.4 VPN Function ............................................................................................................................................................. 21 3.4.1 VPN Client............................................................................................................................................................... 21 3.4.2 VPN Pass-Through .................................................................................................................................................. 21 3.5 IP Pass-Through.......................................................................................................................................................... 22 3.6 IPv6 Only and IPv4v6 Dual Stack .............................................................................................................................. 22 3.6.1 IPv4v6 Dual Stack ................................................................................................................................................... 22 3.6.2 IPv6 Only (CLAT) ................................................................................................................................................... 22 3.7 Multi-APN .................................................................................................................................................................. 23 3.8 5GHz Preferred........................................................................................................................................................... 23 3.9 HiLink......................................................................................................................................................................... 23 3.10 Customer management ............................................................................................................................................. 23 3.10.1 WebUI .................................................................................................................................................................... 23 3.10.2 HUAWEI SmartHome APP ................................................................................................................................... 23 Issue 03 (2019-08-22) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. vi HUAWEI H112-372 5G CPE Pro Product Description Contents 3.11 Operator maintenance ............................................................................................................................................... 24 3.12 HOTA ....................................................................................................................................................................... 24 4 System Structure and Scenario Constraints...........................................................................25 4.1 System Architecture .................................................................................................................................................... 25 4.2 Scenario Constraints ................................................................................................................................................... 26 5 Technical References .................................................................................................................. 27 5.1 Standards and Communication Protocols ................................................................................................................... 27 5.1.1 Standards and Communication Protocols of the Product ......................................................................................... 27 5.1.2 Standards and Communication Protocols of the Wireless Uu Interface................................................................... 27 6 Packing List .................................................................................................................................. 28 Issue 03 (2019-08-22) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. vii HUAWEI H112-372 5G CPE Pro Product Description 1 Product Overview 1 Product Overview The HUAWEI 5G CPE H112-372 is a 5G wireless gateway for multiple users in household or small office environments. It enables users to access the Internet. The H112-372 supports 3GPP Release 15 with UE downlink category 19 and uplink category 13. The supported service functions are as follows: Data service: SA (Supported only in China): 5G: Downlink 1CC (100M), 4x4 MIMO, 256 QAM, peak rate: 1.65Gbps (DL/UL subframe configuration 8:2). Uplink 1CC (100M) 2x2 MIMO, 256 QAM, peak rate: 250Mbps (DL/UL subframe configuration 8:2) NSA: 5G: Downlink 1CC (100M), 4x4 MIMO, 256 QAM, peak rate: 2.33Gbps (Total downlink subframe configuration) Uplink 1CC (100M), 1T256 QAMpeak rate: 650Mbps (Total uplink subframe configuration) LTE Downlink 5CC, 4x4 MIMO (Different frequency bands support different MIMO modes), 256QAM, peak rate: 1.6Gbps (FDD frequency bands, 20+20+20+20MHz, 4x4MIMO). Uplink 2CC, 1T, 64 QAM, peak rate: 150Mbps (FDD frequency bands, 20MHz+20MHz) The actual data rate varies with network configuration. Working band: 5G: n41/77(3300MHz~3800MHz)/78/79(4800MHz~4900MHz, Supported only in China), LTE: B1/3/5/7/8/18/19/20/28/32/34/38/39/40/41/42/43 Wi-Fi: 802.11 b/g/n/a/ac. 2.4GHz Wi-Fi 2x2 MIMO up to 300Mbps, 5GHz Wi-Fi 2x2 MIMO up to 867Mbps. Maximum Users: 32+32 1 GE port for LAN/WAN, 1 GE port for LAN. Multi APN function (Optional) for Data, TR-069 services(Optional) Routing mode: NAT enable (Default) / IP pass-through (Optional) Issue03 (2019-08-22) Huawei Proprietary and Confidential 1 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 1 Product Overview VPN client service (L2TP, PPTP) Customer management via WebUI or HUAWEI SmartHome APP (iOS or Android) Operator maintenance via TR-069 (Optional) and TR-143 (Optional) Huawei Firmware Over the Air (HOTA) 5GHz Wi-Fi preferred HUAWEI HiLink Figure 1-1 H112-372 appearance Issue03 (2019-08-22) Huawei Proprietary and Confidential 2 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 2 Technical Specifications 2 Technical Specifications 2.1 Hardware Specifications Table 2-1 Technical specifications of the H112-372 main unit Item Description Technical standard WAN LAN 3GPP Release 15 IEEE 802.3/802.3u Wi-Fi IEEE 802.11b/g/n/a/ac Working 5G band/frequency LTE n41/77/78/79(n79 is supported only in China) B1/3/5/7/8/18/19/20/28/32/34/38/39/40/41/42/43 Wi-Fi 2.422 GHz2.482 GHz (5-13ch), 5.170 GHz5.330 GHz, 5.490 GHz5.710 GHz, 5.735 GHz5.835 GHz, (W52,W53,W56,W58) (W58 is supported only in China) DL MIMO 5G 4x4n41/77/78/79 LTE 4x4B1/3/7/38/39/40/41/42/43 LTE 2x2B5/8/18/19/20/28/32/34 UL MIMO n41/77/78/79 (UL MIMO is supported only in SA mode, and SA mode is supported only in China.) External port One power adapter port One LAN/WAN port (RJ45), One LAN port (RJ45) two external 5G antenna ports (TS-9) One SIM card slot (Nano-SIM) Antennas Built-in 5G/LTE primary antenna Built-in 5G/LTE secondary antenna Built-in Wi-Fi 2.4 GHz and 5 GHz antennas Issue03 (2019-08-22) Huawei Proprietary and Confidential 3 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 2 Technical Specifications Item LED Indicators Buttons Maximum transmit power Description One 5G indicator One 4G indicator One Wi-Fi indicator One ambient light strip One Power ON/OFF switch One Hi button One Reset button 5G n77/78/79: 23 dBm+2.7/-3.7 dB n41: 23 dBm+2.7/-2.7 dB LTE B1/3/5/7/8/18/19/20/28/32/34/38/39/40/41/42/43: 23 dBm+2.7/-2.7 dB Wi-Fi 2.4GHz 802.11b Ant0/Ant1 13 dBm±2dB@11 Mbps 802.11g 15 dBm±2dB@6 Mbps 15 dBm±2dB@54 Mbps 802.11n 15 dBm±2dB@2.4G MCS0 15 dBm±2dB@2.4G MCS7 5GHz Formats and Ant0 Ant1 channels 11a 6M 15 14.5 11a 54M 15 14.5 11n 20 MCS0 15 14.5 11n 20 MCS7 15 14.5 11n 40 MCS0 17 16.5 11n 40 MCS7 16 15.5 W52/W53 11ac 20 MCS0 15 14.5 11ac 20 MCS8 15 14.5 11ac 40 MCS0 17 16.5 11ac 40 MCS9 15 14.5 11ac 80 MCS0 15 14.5 11ac 80 MCS9 15 14.5 11a 6M 19 18.5 11a 54M 16 15.5 W56 11n 20 MCS0 19 18.5 11n 20 MCS7 16 15.5 Issue03 (2019-08-22) Huawei Proprietary and Confidential 4 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description Item Receiving sensitivity Power consumption AC/DC power supply Dimensions (Maximum) Weight Temperature Humidity 2 Technical Specifications Description 11n 40 MCS0 19 18.5 11n 40 MCS7 16 15.5 11ac 20 MCS0 19 18.5 11ac 20 MCS8 15 14.5 11ac 40 MCS0 19 18.5 11ac 40 MCS9 15 14.5 11ac 80 MCS0 18 17.5 11ac 80 MCS9 15 14.5 11a 6M 19 18.5 11a 54M 16 15.5 11n 20 MCS0 18.5 18 11n 20 MCS7 16 15.5 11n 40 MCS0 19 18.5 11n 40 MCS7 16 15.5 W58 11ac 20 MCS0 18.5 18 11ac 20 MCS8 15 14.5 11ac 40 MCS0 19 18.5 11ac 40 MCS9 15 14.5 11ac 80 MCS0 18 17.5 11ac 80 MCS9 15 14.5 Note: Some edge frequency point power will have a fallback 5G Conform to 3GPP Definition LTE Conform to 3GPP Definition Wi-Fi Conform to IEEE P802.11 Definition < 24 W AC (input): 100V-240V 50Hz/60Hz DC (output): 12V/2A 99 mm (Top edge length) x 107 mm (Bottom edge length) x 215 mm (Height) About 756 g (excluding the power adapter) Working temperature: 0°C to 40°C Storage temperature: -20°C to +70°C 5% 95% (non-condensing) Issue03 (2019-08-22) Huawei Proprietary and Confidential 5 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 2 Technical Specifications Item Description Certification/Co Overseas: CE certification /RoHS/REACH/WEEE/Wi-Fi certification /ErP/GCF mpliance China : CCC/ SSRC Type Approval/ China Type Approval 2.2 Antenna Specifications 2.2.1 Build-in LTE Antenna Table 2-2 LTE antenna specifications Item Description Frequency 5G n41: UL 24962690 MHz DL 24962690 MHz n77: UL 33003800 MHz DL 33003800 MHz n78: UL 33003800 MHz DL 33003800 MHz n79: UL 48004900 MHz DL 48004900 MHz LTE B1: UL 19201980 MHz DL 21102170 MHz B3: UL 17101785 MHz DL 18051880 MHz B5: UL 824849 MHz DL 869894 MHz B7: UL 25002570 MHz DL 26202690 MHz B8: UL 880915 MHz DL 925960 MHz B18: UL 815830 MHz DL 860875 MHz B19: UL 830845 MHz DL 875890 MHz B20: UL 832862 MHz DL 791821 MHz B28: UL 703748 MHz DL 758803 MHz B32: / DL 14521496 MHz B38: UL 25702620MHz DL 25702620 MHz B40: UL 23002400 MHz DL 23002400 MHz B41: UL 24962690 MHz DL 24962690 MHz B42: UL 34003600 MHz DL 34003600 MHz B43: UL 36003800 MHz DL 36003800 MHz Input impedance 50 Standing wave ratio < 2.5 Main antenna efficiency 5G n41: -1.9 dB n77: -1.8 dB n78: -1.9 dB Issue03 (2019-08-22) Huawei Proprietary and Confidential 6 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description Item Diversity antenna efficiency Description n79: -2.9 dB LTE B1: -2.0 dB B3: -1.6 dB B5: -2.2 dB B7: -2.0 dB B8: -2.7 dB B18: -2.3 dB B19: -2.2 dB B20: -2.4 dB B28: -3.0 dB B32: / B34: -2.1 dB B38: -1.8 dB B39: -1.8 dB B40: -2.4 dB B41: -1.9 dB B42: -2.0 dB B43: -1.8 dB 5G n41: -1.4 dB n77: -1.1 dB n78: -1.3 dB n79: -2.5 dB LTE B1: -1.7 dB B3: -1.5 dB B5: -2.8 dB B7: -1.4 dB B8: -3.3 dB B18: -2.7 dB B19: -2.8 dB B20: -2.3 dB B28: -2.5 dB B32: / B34: -1.7 dB B38: -1.3 dB B39: -1.5 dB B40: -1.9 dB B41: -1.4 dB Issue03 (2019-08-22) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 2 Technical Specifications 7 HUAWEI H112-372 5G CPE Pro Product Description Item Description B42: -1.3 dB B43: -1.2 dB Main antenna gain 5G n41: 5.6 dBi n77: 5.6 dBi n78: 6 dBi n79: 4.6 dBi LTE B1: 3.9 dBi B3: 3 dBi B5: 3.3 dBi B7: 4.7 dBi B8: 2.5 dBi B18: 3.3 dBi B19: 3.3 dBi B20: 3.3 dBi B28: 2.3 dBi B32: / B34: 3.6 dBi B38: 5.5 dBi B39: 3.2 dBi B40: 3.9 dBi B41: 5.5 dBi B42: 4.1 dBi B43: 4.8 dBi Diversity antenna gain 5G n41: 5.5 dBi n77: 4.8 dBi n78: 4.1 dBi n79: 4.4 dBi LTE B1: 3.7 dBi B3: 3.8 dBi B5: 2.6 dBi B7: 5.6 dBi B8: 1.9 dBi B18: 2.7 dBi B19: 2.7 dBi B20: 2.2 dBi 2 Technical Specifications Issue03 (2019-08-22) Huawei Proprietary and Confidential 8 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 2 Technical Specifications Item TX/RX Polarization Description B28: 3.0 dBi B32: / B34: 3.4 dBi B38: 5.5 dBi B39: 2.6 dBi B40: 3.8 dBi B41: 5.5 dBi B42: 4.0 dBi B43: 4.3 dBi 2T4R Linear polarization 2.2.2 Build-in Wi-Fi Antenna Table 2-3 Wi-Fi 2.4 GHz antenna specifications Item Description Frequency 2.422 GHz-2.482 GHz (Channel 5 Channel 13) Input impedance 50 Standing wave ratio < 2 Efficiency -2.2 dB Gain 3 dBi Polarization Linear polarization Table 2-4 Wi-Fi 5 GHz antenna specifications Item Description Frequency 5.170 GHz-5.330 GHz,5.490 GHz-5.710 GHz,5.735 GHz5.835 GHz Input impedance 50 Standing wave ratio < 2 Efficiency -3 dB Gain 3.7 dBi Polarization Linear polarization Issue03 (2019-08-22) Huawei Proprietary and Confidential 9 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 2.2.3 LTE CA combination Table 2-5 LTE CA combination Item Description Band combination LTE DL CA_1C CA_3C CA_7C CA_39C CA_40C CA_41C CA_42C CA_7A-7A CA_1A-3A CA_1A-7A CA_1A-8A CA_20A-32A CA_20A-38A CA_3A-19A CA_19A-42A CA_1A-19A CA_1A-20A CA_1A-28A CA_1A-38A CA_1A-42A CA_3A-3A CA_3A-7A CA_3A-8A CA_3A-20A CA_3A-28A CA_3A_32A CA_41A-42A CA_7A-32A CA_3A-40A CA_1A-32A CA_3A-38A CA_3A-41A CA_3A-42A CA_7A-8A CA_7A-20A CA_7A-28A CA_8A-39A CA_8A-41A CA_38C CA_39A-41A CA_1A-18A CA_1A-41A CA_1A-40A DL 2 Technical Specifications 2CC(DL) 3CC(DL) MIMO 4+4 4+4 4+4 4+4 4+4 4+4 4+4 4+2 4+4 4+4 4+2 2+2 2+4 4+2 2+4 4+2 4+2 4+2 4+4 2+4 4+4 4+4 4+2 4+2 4+2 4+2 4+4 4+2 4+4 2+2 4+4 4+4 4+4 4+2 4+2 4+2 2+4 2+4 4+4 4+4 4+2 4+4 4+4 MIMO Issue03 (2019-08-22) Huawei Proprietary and Confidential 10 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description CA_40D CA_41D CA_1A-7C CA_1A-3C CA_1A-41C CA_1A-42C CA_1A-40C CA_3A-7C CA_3A-40C CA_3A-41C CA_3A-41A-42A CA_3C-5A CA_3C-7A CA_3C-8A CA_3C-20A CA_3C-28A CA_3C-32A CA_7A-40C CA_7C-20A CA_7C-28A CA_28A-40C CA_1A-3A-7A CA_1A-3A-8A CA_1A-3A-20A CA_1A-3A-28A CA_1A-3A-32A CA_1A-3A-38A CA_1A-7A-7A CA_1A-8A-38A CA_1A-20A-32A CA_1A-7A-20A CA_1A-7A-28A CA_1A-7A-32A CA_3A-3A-20A CA_3A-3A-7A CA_3A-7A-7A CA_3A-7A-20A CA_3A-7A-28A CA_3A-7A-32A CA_3A-7A-38A (B3 PCC) CA_7A-20A-32A CA_7A-20A-38A B20 PCC) CA_41A-42C CA_41C-42A CA_39A-41C CA_39C-41A CA_1A-3A-19A CA_1A-3A-42A CA_1A-19A-42A CA_1A-42C CA_3A-19A-42A CA_3A-42C 2 Technical Specifications 4+4+4 4+4+4 4+4+4 4+4+4 4+4+4 4+4+4 4+4+4 4+4+4 4+4+4 4+4+4 2+4+4 4+4+2 4+4+4 4+4+2 4+4+2 4+4+2 4+4+2 4+4+4 4+4+2 4+4+2 2+4+4 4+4+4 4+4+2 4+4+2 4+4+2 2+4+2 4+4+4 4+2+4 4+2+4 2+2+2 4+4+2 4+4+2 2+4+2 4+4+2 4+4+4 4+2+4 4+4+2 4+4+2 4+4+2 4+4+2 4+2+2 2+2+4 4+4+4 4+4+4 4+4+4 4+4+4 2+4+2 2+4+4 2+2+4 2+4+4 4+2+4 4+4+4 Issue03 (2019-08-22) Huawei Proprietary and Confidential 11 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 2 Technical Specifications CA_19A-42C CA_8A-41C CA_3A-28A-40A CA_1A-28A-40A CA_1A-3A-40A CA_1A-7A-8A CA_3A-7A-8A DL CA_40E CA_3A-40D CA_3C-7C CA_1A-3A-7C CA_1A-3A-40C CA_1A-3C-5A CA_1A-3C-7A CA_1A-3C-8A CA_1A-3C-28A CA_1A-7C-28A CA_1A-7A-40C CA_3C-8A-38A CA_3A-7A-20A-32A CA_3A-7A-40C CA_3A-7C-20A CA_3A-7C-28A CA_3C-7A-20A CA_3C-7A-28A CA_3C-7A-32A CA_3A-28A-40C CA_1A-3A-7A-7A CA_1A-3A-7A-8A CA_1A-3A-7A-20A CA_1A-3A-7A-28A CA_1A-3A-7A-32A CA_1A-7A-20A-32A CA_1A-3A-8A-38A CA_7A-40D CA_7A-28A-40C CA_41C-42C CA_3A-41A-42C CA_3A-41C-42A CA_39C-41C CA_39A-41D CA_1A-3A-19A-42A CA_1A-3A-42C CA_1A-19A-42C CA_1A-42D CA_3A-19A-42C CA_3A-42D CA_1A-3A-20A-32A CA_1A-28A-40C CA_1A-3A-28A-40A 4CC(DL) 5CC(DL) 2+4+4 2+4+4 4+2+4 4+2+2 4+4+4 2+4+2 4+4+2 MIMO 4+4+4+4 4+4+4+4 4+4+4+4 4+4+4+4 4+4+4+4 2+4+4+2 2+4+4+4 4+4+4+2 4+4+4+2 4+4+4+2 4+2+2+2 4+4+2+2 4+4+2+2 4+4+4+4 4+4+4+2 4+4+4+2 4+4+4+2 4+4+4+2 4+4+4+2 4+2+4+4 4+2+2+2 2+4+4+2 2+4+4+2 2+4+4+2 2+4+4+2 2+4+2+2 2+4+2+4 4+4+4+4 4+2+4+4 4+4+4+4 2+4+4+4 2+4+4+4 4+4+4+4 4+4+4+4 2+4+2+4 2+4+4+4 2+2+4+4 2+4+4+4 4+2+4+4 4+4+4+4 2+4+2+2 4+2+2+2 4+4+2+2 Issue03 (2019-08-22) Huawei Proprietary and Confidential 12 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 2 Technical Specifications DL CA_1A-3A-3A-8A-38A CA_1A-3A-7C-28A CA_1A-3A-7A-20A-32A CA_3C-7C-28A CA_1A-41C-42C CA_1A-3C-7C CA_3A-7A-28A-40C CA_1A-3A-28A-40C CA_3A-28A-40D CA_7A-40E CA_3A-40E CA_1A-3A-7A-40C CA_1A-7A-28A-40C CA_1A-3A-19A-42C CA_3A-41C-42C CA_1A-42E CA_3A-42E CA_1A-3A-18A-42C UL UL CA_3C CA_7C CA_39C CA_40C CA_41C CA_42C CA_1A-3A CA_1A-7A CA_1A-20A CA_3A-7A CA_3A-8A CA_3A-28A CA_3A-20A CA_3A-38A MIMO 2+2+2+2+2 2+4+4+4+2 2+4+2+2+2 2+2+4+4+2 4+2+2+4+4 4+4+4+2+2 4+4+2+2+2 4+4+2+2+2 2+2+4+4+4 4+2+2+2+2 4+2+2+2+2 2+2+2+2+2 4+2+2+2+2 2+4+2+4+4 2+2+2+4+4 2+2+2+2+2 4+2+2+2+2 2+4+2+4+4 MIMO / / / / / / / / / / / / / / (1)All the preceding LTE CA combinations can only represent product capabilities. For details about the carrier's support, see the product configuration. (2)B32 supports only SCC. All downlink CA combinations with B32 do not support uplink inter-band CA. 2.2.4 EN_DC combination Item Band combination Description 5G EN_DC DC_1A_n78A DC_3A_n78A DC_5A_n78A DC_7A_n78A DC_8A_n78A 2CC MIMO 4+4 4+4 2+4 4+4 2+4 Issue03 (2019-08-22) Huawei Proprietary and Confidential 13 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 2 Technical Specifications DC_20A_n78A DC_28A_n78A DC_38A_n78A DC_40A_n78A DC_41A_n78A DC_1A_n77A DC_3A_n77A DC_28A_n77A DC_1A_n41A DC_3A_n41A DC_20A_n41A DC_39A_n41A DC_39A_n79A DC_3A_n79A 3CC EN_DC DC_1A-3A_n78A DC_1A-7A_n78A DC_1A-8A_n78A DC_1A-20A_n78A DC_3A-7A_n78A DC_3A-8A_n78A DC_3A-20A_n78A DC_3A-38A_n78A(B38 SCC) DC_7A-20A_n78A DC_20A-38A_n78A(B38 SCC) DC_1C_n78A DC_3C_n78A DC_1C_n78A DC_3A-3A_n78A DC_7C_n78A DC_40C_n78A DC_41C_n78A DC_1A-3A_n77A DC_1A-28A_n78A DC_3A-28A_n78A DC_3A-41A_n78A DC_3A-42A_n78A(B42 SCC) DC_7A-28A_n78A DC_7C_n78A DC_3A-32A_n78A DC_3A-40A_n78A DC_1A-40A_n78A DC_1A-32A_n78A DC_7A-32A_n78A DC_20A-32A_n78A DC_1A-41A_n78A DC_1A-28A_n77A DC_3A-28A_n77A DC_7A-8A_n78A 4CC EN_DC DC_1A-3C_n78A DC_1A-7C_n78A DC_1A-3A-7A_n78A DC_1A-3A-8A_n78A DC_1A-3A-20A_n78A 2+4 2+4 4+4 4+4 4+4 4+4 4+4 2+4 4+4 4+4 2+4 4+4 4+4 4+4 MIMO 4+4+4 4+4+4 4+2+4 4+2+4 4+4+4 4+2+4 4+2+4 4+4+4 4+2+4 2+4+4 4+4+4 4+4+4 4+4+4 4+2+4 4+4+4 4+4+4 4+4+4 4+4+4 4+2+4 4+2+4 4+4+4 4+4+4 4+2+4 4+4+4 2+2+4 2+2+4 2+2+4 2+2+4 2+2+4 2+2+4 4+4+4 2+2+4 4+2+4 2+2+4 MIMO 4+4+4+4 4+4+4+4 2+2+4+4 2+4+2+4 2+4+2+4 Issue03 (2019-08-22) Huawei Proprietary and Confidential 14 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 2 Technical Specifications DC_1A-7A-20A_n78A DC_3A-7A-20A_n78A DC_3A-7C_n78A DC_3C-7A_n78A DC_3C-20A_n78A DC_3A-42C_n78A(B42 SCC) DC_7C-28A_n78A DC_1A-41C_n78A DC_1A-3A-28A_n77A DC_1A-3A-28A_n78A DC_3A-7A-28A_n78A DC_3C-32A_n78A DC_3C-28A_n78A DC_3A-40C_n78A DC_1A-40C_n78A DC_1A-3A-40A_n78A DC_1A-7A-28A_n78A DC_1A-7A-32A_n78A DC_1A-20A-32A_n78A DC_7A-20A-32A_n78A DC_3A-20A-32A_n78A DC_1A-7A-8A_n78A DC_3A-7A-8A_n78A 5CC EN_DC DC_1A-3A-7A-20A_n78A DC_1A-3C-7A_n78A DC_1A-3A-7C_n78A DC_3C-7C_n78A DC_3C-7A-20A_n78A DC_1A-3C-28A_n78A DC_3A-7C-28A_n78A DC_3A-7A-20A-32A_n78A DC_1A-3A-7A-28A_n78A DC_1A-3A-7A-8A_n78A DC_1A-7A-20A-32A_n78A DC_3A-28A-40C_n78A DC_1A-3A-40C_n78A DC_1A-7C-28A_n78A 6CC EN_DC DC_1A-3A-28A-40C_n78A DC_1A-3A-7C-28A_n78A DC_3C-7C-28A_n78A 2+4+2+4 2+4+2+4 4+4+4+4 4+4+4+4 4+4+2+4 4+4+4+4 4+4+2+4 4+4+4+4 2+4+2+4 2+4+2+4 2+4+2+4 2+2+2+4 2+2+2+4 2+2+2+4 2+2+2+4 2+2+2+4 2+2+2+4 2+2+2+4 2+2+2+4 2+2+2+4 2+2+2+4 2+2+2+4 2+2+2+4 MIMO 2+2+2+2+4 2+2+2+4+4 4+2+2+2+4 4+4+4+4+4 2+2+4+2+4 4+2+2+2+4 4+2+2+2+4 2+2+2+2+4 2+2+2+2+4 2+2+2+2+4 2+2+2+2+4 2+2+2+2+4 2+2+2+2+4 2+2+2+2+4 MIMO 2+2+2+2+2+4 2+2+2+2+2+4 2+2+4+4+2+4 (1)All the preceding EN_DC combinations can only represent product capabilities. For details about the carrier's support, see the product configuration. (2)B32 supports only SCC. All downlink EN_DC combinations with B32 do not support uplink inter-band CA. Issue03 (2019-08-22) Huawei Proprietary and Confidential 15 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 2.3 Software Specifications 2 Technical Specifications Table 2-6 Software specifications Item Description 5G features DL 4x4 MIMO DL 256 QAM, UL 256QAM LTE features DL 4x4 MIMO+5 CC DL 256 QAMUL 64 QAM Mobile network APN management APN auto adapter Gateway Router Supports the default route Supports manual configuration of LAN IP addresses Supports Address Resolution Protocol (ARP) DHCP server The DHCP server can be enabled or disabled The address pool of the DHCP server can be configured The lease can be configured NAT Supports NAT and NAPT (compliant with RFC2663, RFC3022, and RFC3027) Supports cone NAT ARP ICMP IPv4v6 dual stack IPv4 only IPv6 only (Optional , CLAT for LAN side IPv4 device access Internet) VPN client SMS When the CLAT function is enabled, the IPv4 device Internet access service cannot reach the maximum throughput. Under IPv6 only, NAT-base service (such as port forwarding and port triggering) is not available VPN pass-through Support L2TP VPN client Support PPTP VPN client Writing/sending/receiving Writing/sending/receiving extra-long messages Issue03 (2019-08-22) Huawei Proprietary and Confidential 16 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 2 Technical Specifications Item Data service Description 5G Downlink single CC (100M), 4x4 MIMO, 256 QAM Uplink single CC (100M), 2x2 MIMO, 256 QAM LTE Downlink 5CC, 4x4 MIMO, 256 QAM Uplink 2CC, single-shot, 64 QAM Wi-Fi 802.11b/g/n/a/ac Supports multi APNs (Optional, one for data and one for TR-069) Firewall setup Firewall enable/disable MAC Address Filter IP Filter Virtual server Special Applications DMZ settings SIP ALG settings UPnP settings NAT settings Domain Filter LAN 10/100/1000 Mbps auto-negotiation MDI/MDIX auto-sensing IEEE 802.3/802.3u-compatible Wi-Fi Broadcasts and hides service set identifiers (SSIDs) Complies with IEEE 802.11b/g/n/a/ac WPS WMM Encryption WEP, AES, and TKIP + AES Security mode Open WPA2-PSK WPA/WPA2-PSK WEP MAC address authentication Supports the MAC address authentication whitelist Supports the MAC address authentication blacklist Supports a maximum of 10 MAC address entries STA Supports inquiry of STA status Supports a maximum of 64 connected stations Issue03 (2019-08-22) Huawei Proprietary and Confidential 17 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 2 Technical Specifications Item Operator maintenance (Optional) USIM NTP HUAWEI SmartHome APP System requirements Description Supports TR-069 Amendment III Supports TR-098 Amendment II Supports TR-143 Amendment I PIN management and USIM card authentication Supports daylight saving time (DST) (Optional) View data traffic usage and SMS Manage connected devices Change CPE's SSID and password Operating system Windows 7, Windows 8.1, Windows 10 (Not support Windows RT), MAC OS X 10.12, 10.13 and 10.14 with latest updates Web browser Microsoft Internet Explorer 9.0 and Microsoft Edge with latest updates FireFox 49.0 with latest updates All major versions of Chrome in the last year (53.0 with latest updates) Safari 10.0 with latest updates (MACOS) Your computer's hardware system should meet or exceed the recommended system requirements for the installed OS version Issue03 (2019-08-22) Huawei Proprietary and Confidential 18 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 3 Services and Applications 3 Services and Applications 3.1 Data Services The H112-372 can access the Internet through mobile networks and Ethernet networks. By connecting to the H112-372 using Wi-Fi or a network cable, users can obtain access to high-speed Internet services and establish a local area network (LAN). 3.1.1 Accessing the Internet through a Mobile Network (5G/LTE) The H112-372 can access the Internet through mobile networks. Figure 3-1 Accessing the Internet through a mobile network Issue03 (2019-08-22) Huawei Proprietary and Confidential 19 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 3 Services and Applications 3.1.2 Accessing the Internet through an Ethernet Network The H112-372's LAN/WAN port can be connected to a wall-mounted Ethernet port using a network cable. Figure 3-2 Accessing the Internet through an Ethernet network 3.2 SMS The H112-372 supports message writing/sending/receiving and group sending (up to 50 -contacts at a time). 3.3 Security Service The H112-372 supports comprehensive and robust security services. It provides a firewall function and PIN protection mechanisms. These features allow users to connect their computers to the Internet and simultaneously protect their computers against security threats from the Internet. 3.3.1 Firewall Service The H112-372 supports the enabling or disabling of a firewall on the network connection, which protects the device and network from attacks by hackers on the Internet and controls access to the Internet. Issue03 (2019-08-22) Huawei Proprietary and Confidential 20 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 3 Services and Applications 3.3.2 MAC Filtering The H112-372 supports configuration of the Media Access Control (MAC) address to restrict network access. 3.3.3 Wi-Fi Authentication The gateway supports the following user authentication protocols for Wi-Fi: No encryption WEP, WPA2-PSK (AES), WPA/WPA2-PSK (TKIP/AES). 3.4 VPN Function 3.4.1 VPN Client VPN tunneling involves establishing and maintaining a logical network connection (that may contain intermediate hops). On this connection, packets constructed in a specific VPN protocol format are first encapsulated within some other base or carrier protocol, then transmitted between the VPN client and server, and finally decapsulated on the receiving side. The H112-372 supports L2TP and PPTP tunneling protocols. 3.4.2 VPN Pass-Through The H112-372 supports L2TP/PPTP VPN pass-through for the LAN side device. The LAN side device can create a VPN tunnel to the VPN server. Issue03 (2019-08-22) Huawei Proprietary and Confidential 21 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 3 Services and Applications 3.5 IP Pass-Through The LTE CPE obtains the WAN IP address and passes it through to the PC (Case 1) or Router (Case 2), and then the PC (Case 1) or Router (Case 2) can directly use the WAP IP address. 3.6 IPv6 Only and IPv4v6 Dual Stack 3.6.1 IPv4v6 Dual Stack CPE provides dual stack function. 3.6.2 IPv6 Only (CLAT) The LTE CPE supports IPv6 only with the transition solution CLAT for IPv4 device. When the IPv6 only (CLAT) function is enabled, NAT-based functions (like DMZ/Port Forwarding/Port tigger) cannot be used. When an IPv4 device accesses the Internet, the performance is degraded because packets need to be packetized and unpacked. However, IPv6 devices are not affected. Issue03 (2019-08-22) Huawei Proprietary and Confidential 22 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 3 Services and Applications 3.7 Multi-APN The H112-372 supports the establishment and maintenance of two APNs. These two APN connections isolate data and remote management services on an operator's network. The H112-372 supports an independent APN for CPE internal/TR-069. 3.8 5GHz Preferred Priority usage of 5 GHz Wi-Fi band over 2.4 GHz band when signal strength is equal to increase connection speeds. 3.9 HiLink Supports HiLink routers to connect to H112-372 through the Hi button to create an expanded network. Supports quick connection between a HiLink device (such as Honor set-up boxes, Honor handsets and HUAWEI handsets running on EMUI 5.0 and later) and H112-372 through the Hi button. 3.10 Customer management 3.10.1 WebUI The H112-372 supports local configuration through the Web UI. You can perform device management and network configuration to ensure normal and stable performance. 3.10.2 HUAWEI SmartHome APP Scan the QR code (can be found in the Quick Start Guide and Web UI) to download the HUAWEI SmartHome APP and configure the router from your phone. Issue03 (2019-08-22) Huawei Proprietary and Confidential 23 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 3 Services and Applications 3.11 Operator maintenance The H112-372 supports Operator maintenance through the TR-069. Operator remote manages the CPE software update/parameters configuration via TR-069. 3.12 HOTA The H112-372 supports the HOTA feature, which allows users to remotely update the device firmware through the HOTA server. Issue03 (2019-08-22) Huawei Proprietary and Confidential 24 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 4 System Structure and Scenario Constraints 4 System Structure and Scenario Constraints 4.1 System Architecture Figure 4-1 shows the interfaces for the H112-372. Figure 4-1 System structure The following describes the modules shown in Figure 4-1. 5G/LTE access function: The H112-372 adopts the 5G/LTE access technology at the WAN side. LAN access function: One 10/100/1000 Mbps high-speed Ethernet ports are provided at the LAN side. The H112-372 provides the switching function for local networking and sharing of the broadband network when it is connected to terminal devices. AP function: An 802.11b/g/n/a/ac-compliant Wi-Fi AP interface is provided for wireless networking at home. The interface is compliant with the IEEE 802.11b/g/n/a/ac standard and the WEP, WPA/WPA2-PSK, WPA2-PSK security authentication mechanisms. DHCP/DNS: The DHCP server dynamically allocates IP addresses to PCs. Issue03 (2019-08-22) Huawei Proprietary and Confidential 25 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 4 System Structure and Scenario Constraints Web-based management: You can configure the H112-372 and modify and view the configuration of the H112-372. IP routing protocol and NAT: The H112-372 has high-speed routing capability. With the built-in NAT, the H112-372, together with LTE terminals, can provide flexible broadband access solutions and networking schemes. 4.2 Scenario Constraints The H112-372 is a household wireless broadband access product designed for use in scenarios with relatively few network access devices and relatively low network reliability requirements, such as homes or small office and home offices (SOHOs). The H112-372 is not an enterprise-grade product. It cannot be used by medium- or large-sized enterprises or in scenarios with high network reliability requirements, such as banks, securities agencies, traffic control, and communications device backhaul. The H112-372 has the following constraints: When the IP Pass-Through mode is enabled, the HOTA function cannot be used. When the L2TP/PPTP VPN client function is enabled, the throughput performance will slow down. A maximum of 64 devices can be connected to the Wi-Fi in theory; the actual number of devices that can be connected and served depends on actual conditions. Issue03 (2019-08-22) Huawei Proprietary and Confidential 26 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 5 Technical References 5 Technical References 5.1 Standards and Communication Protocols 5.1.1 Standards and Communication Protocols of the Product Table 5-1 Standards and communication protocols of the product Item Description Physical layer RFC894 ARP RFC826 IP RFC791, RFC1122, RFC1071, RFC1141, RFC1624, RFC792, RFC950, RFC1256 ICMP RFC792, RFC950, RFC1256 TCP RFC793 UDP RFC768 NAT RFC1631, RFC2663, RFC3022, RFC3027 DHCP RFC1531, RFC1533 5.1.2 Standards and Communication Protocols of the Wireless Uu Interface This device supports 3GPP Release 15. Issue03 (2019-08-22) Huawei Proprietary and Confidential 27 Copyright © Huawei Technologies Co., Ltd. HUAWEI H112-372 5G CPE Pro Product Description 6 Packing List 6 Packing List Table 6-1 Packing list Description Wireless Gateway Power supply adapter Quick Start Ethernet cable Warranty card Quantity 1 1 1 1 1 Remarks Standard Standard Standard Standard Optional The HUAWEI H112-372 wireless gateway has an optional external antenna. Issue03 (2019-08-22) Huawei Proprietary and Confidential 28 Copyright © Huawei Technologies Co., Ltd.Microsoft Word 2013
