1. Night Vision Sensor 2. Main Camera Lenses 3. Microphone 4. Power ON/OFF 5. Indicator Light 6. Antenna 7. The Temperature Sensor 8. Micro USB Port
Oct 12, 2018 — MANUAL. DT50 Baby Monitor. Page 2. Warning. Packing List. Overview. Getting Started. 1. Charge the Camera. 2. Camera Pairing. 3. View. 4. ·
MANUAL DT50 Baby Monitor. Warning Packing List Overview Getting Started 1. Charge the Camera 2. Camera Pairing 3. View 4. Lullabies 5. Feeding Timer 6. Auto Tracking ...
USER MANUAL DT50 Baby Monitor CONTENTS Warning 1 Packing List 2 Overview 2 Getting Started 5 1. Charge the Camera 5 2. Camera Pairing 5 3. View 7 4. Lullabies 9 5. Feeding Timer 10 6. Auto Tracking 11 7. Setting 12 FQA 22 Contact US 22 WARNING 1. Strangulation Hazard - Children have strangled in cords. Keep this cord out of the reach of children (more than 3 feet (1m) away). 2. Never Place the Camera of Cord in or Near Crib or Playpen. Secure the cord at least three feet away from crib or playpen. 3. Caution - Only insert a battery pack, Never use the transmitter or receiver near water, including near a bathtub, sink, laundry tub, wet basement, etc. 4. Use only the AC adapters provided. 5. Adult assembly is required. Keep small parts away from children when assembling. 6. This product is not a toy. Do not allow children to play with it. 7. This product is not intended to replace proper adult supervision of children. 8. You must check your child's activity regularly, as this product will not alert parents to silent activities of a child. 9. Before using this product, read and follow all instructions and warnings contained in this booklet. 10. This product is intended for indoor use only. 11. This product is not intended for use as a medical monitor and its use should not replace adult supervision. 12. Test monitor before use and after changing camera location. Check reception regularly. Obstacles, such as concrete walls, may shorten the wireless signal transfer range. 13. Always unplug AC adapters from wall outlets and power sources during periods of non-use. 14. Do not touch the plug contacts with sharp or metal objects. 15. Do not allow water damage to the monitor unit, charging port, or charging cable which cause overheat of the charging components. 16. Do not use unofficial third party charging cables and adapters to charge he device. This may result in overheat of the charging port. Only use the charging cables and adapters provided in the box. 01 PACKING LIST DT50 Camera DT50 Monitor QUICK REFERENCE GUIDE DT50 Baby Monitor Camera Power Adapter Monitor Power Adapter Quick Reference Guide OVERVIEW 1. Baby Unit 1 2 6 3 3 7 4 8 5 9 02 1. Night Vision Sensor 2. Main Camera Lenses 3. Microphone 4. Power ON/OFF 5. Indicator Light 2. Parent Unit 10 6. Antenna 7. The Temperature Sensor 8. Micro USB Port 9. Pair Button 12 MENU OK 3 VOL+ 4 VOL- 5 6 1. Menu Button: Press to access different menu options or exit the menu. 2. OK / : Short press to confirm the option. Long press to digital zoom. 3. : Short Press to adjust monitor's voice. Long press to tilt the camera upward. 4. : Press to pan the camera right 5. : Short Press to adjust monitor's voice. Long press to tilt the camera downward. 6. : Press to pan the camera left. 7. MIC 8. : Long press to turn On / Off the camera, short press to turn On / Off the screen. 9. : In monitor interface, long press to talk to your baby. In other setting interface, short press back to monitor interface.0 10. Volume Level LED. 11. Speaker. 12. Reset Hole: The monitor will force a shutdown when you take this peration. Please note othat when you turn on the monitor, it does not restore factory settings. 13. Stand. 14. Micro USB Charging Port. 7 89 13 11 14 12 Reset 03 04 GETTING STARTED 1. Charge the Camera æConnect the camera power adapter to the camera unit. çPress to turn On / Off the camera. èPosition your camera unit no less than 3 feet away from your baby's crib. Ensure the power cord is not within reach of your baby. 2. Camera Pairing æPress Menu button to enter to the interface, choose "Camera". 1 1 22°C Camera View Lullabies Feeding Timer Auto Tracking Setting MENU OK VOL+ VOL- 05 ç Press "OK" button to enter to the interface. 1 1 Add Camera Camera 1 Camera 2 Camera 3 Camera 4 22°C Delete Camera Camera 5 Camera 6 Camera 7 Camera 8 MENU OK VOL+ VOL- è The monitor will show "Camera Pairing". 1 1 22°C Camera Pairing 30 MENU OK VOL+ VOL- 06 é Press camera's PAIR key, then connect successfully. PAIR (On The Bottom Of Camera) ç Press "OK" to scan camera 1. X 22°C 14 : 52 : 03 Camera 1 Camera 2 Camera 3 Camera 4 Scan MENU OK VOL+ VOL- 3. View æPress Menu button to enter to the function interface , choose "View". 1 1 22°C Camera View Lullabies Feeding Timer Auto Tracking Setting MENU OK VOL+ VOL- 07 è Press and to scan camera 2/3/4.. X 22°C 14 : 52 : 03 Camera 1 Camera 2 Camera 3 Camera 4 Scan MENU OK VOL+ VOL- 08 4. Lullabies æ Press Menu button to enter to the function interface, choose "Lullabies". 1 1 22°C Camera View Lullabies Feeding Timer Auto Tracking Setting MENU OK VOL+ VOL- çChoose the internal lullaby to Soothe your baby. 1 1 Mochart Baha All 22°C Vrtoven Brahms Stop MENU OK VOL+ VOL- 09 5.Feeding Timer æ Press Menu button to enter to the function interface, choose "Feeding Timer". 1 1 22°C Camera View Lullabies Feeding Timer Auto Tracking Setting MENU OK VOL+ VOL- ç Press "OK" button to choose the time to remind for feeding kids. è After selected, count down bar will appear in video view interface, when up to predefined time, monitor will alarm for 5 seconds. 1 1 2. hours 4. hours Cancel 22°C 3. hours 5. hours Setting MENU OK VOL+ VOL- 10 6. Auto Tracking æ Press Menu button to enter to the function interface, choose "Auto Tracking". 7. Setting Press Menu button to enter to the function interface, choose "Setting". 1 1 22°C Camera View Lullabies Feeding Timer Auto Tracking Setting MENU OK VOL+ VOL- 1 1 22°C Camera View Lullabies Feeding Timer Auto Tracking Setting ç Press "ON / OFF'" to enable / disable this function. 1 1 22°C ON OFF MENU OK VOL+ VOL- èAfter selected ON, camera will automatically move following with the people or object in the range of lens. Please Note: When the camera detects movement, there will be a delay in following the auto tracking function. 11 7.1. Language Setting Select the language to display 22°C Language Setting Date & Time Temp.°C/°F Motion Detecting Power Saving 15 : 11 : 06 Brightness Setting Temp Setting Frequency VOX Default Setting MENU OK VOL+ VOL- 12 7.2. Brightness Setting æ Choose "Brightness Setting" and press "OK" to confirm the option. 22°C Language Setting Date & Time Temp.°C/°F Motion Detecting Power Saving 15 : 11 : 06 Brightness Setting Temp Setting Frequency VOX Default Setting MENU OK VOL+ VOL- ç Press and to adjust brightness on monitor screen. 22°C Language Setting Date & Time Temp.°C/°F Motion Detecting Power Saving 15 : 11 : 06 Brightness Setting Temp Setting Frequency VOX Default Setting MENU OK VOL+ VOL- 13 7.3. Date & Time æ Choose "Date & Time" and press "OK" to confirm the option. 22°C Language Setting Date & Time Temp.°C/°F Motion Detecting Power Saving 15 : 11 : 06 Brightness Setting Temp Setting Frequency VOX Default Setting MENU OK VOL+ VOL- ç Adjust the Date via pressing . 22°C 15 : 11 : 06 2018 / 10 / 12 15 : 11 : 06 MENU OK VOL+ VOL- 14 7.4. Temperature Setting æ Choose "Temp Setting" and press "OK" to confirm the option. 22°C Language Setting Date & Time Temp.°C/°F Motion Detecting Power Saving 15 : 11 : 06 Brightness Setting Temp Setting Frequency VOX Default Setting MENU OK VOL+ VOL- 7.5. Temperature °F/°C switch Switch °C & °F easily by this function. 22°C Language Setting Date & Time Temp.°C/°F Motion Detecting Power Saving 15 : 11 : 06 Brightness Setting Temp Setting Frequency VOX Default Setting MENU OK VOL+ VOL- ç Adjust the highest and lowest temperature limitation data, when room temp reach or beyond the limitation, monitor will alarm automatically. 22°C 15 : 11 : 06 Low Temperature 55 °F High Temperature 77 °F OFF ON MENU OK VOL+ VOL- 22°C °C °F 15 : 11 : 06 MENU OK VOL+ VOL- 15 16 7.6. Frequency Switch 60Hz & 50Hz easily by this function. 22°C Language Setting Date & Time Temp.°C/°F Motion Detecting Power Saving 15 : 11 : 06 Brightness Setting Temp Setting Frequency VOX Default Setting MENU OK VOL+ VOL- 1 1 60Hz 22°C 50Hz MENU OK VOL+ VOL- 7.7. Motion Detecting æChoose "Motion Detection" and press "OK" to confirm the option. 22°C Language Setting Date & Time Temp.°C/°F Motion Detecting Power Saving 15 : 11 : 06 Brightness Setting Temp Setting Frequency VOX Default Setting MENU OK VOL+ VOL- çChoose "ON", when the camera detect the movement, the monitor will alert you with alarm sound. 22°C ON OFF 15 : 11 : 06 MENU OK VOL+ VOL- 17 18 7.8. VOX æChoose "VOX" and press "OK" to confirm the option. 22°C Language Setting Date & Time Temp.°C/°F Motion Detecting Power Saving 15 : 11 : 06 Brightness Setting Temp Setting Frequency VOX Default Setting MENU OK VOL+ VOL- 7.9. Power Saving æChoose "Power Saving" and press "OK" to confirm the option. 22°C Language Setting Date & Time Temp.°C/°F Motion Detecting Power Saving 15 : 11 : 06 Brightness Setting Temp Setting Frequency VOX Default Setting MENU OK VOL+ VOL- çChoose "High, Middle, Low"to open the VOX function, you will hear alarm once any abnormal sound or noise reached the corresponding decibel level. 22°C High Middle Low OFF 15 : 11 : 06 MENU OK VOL+ VOL- 1 1 ON 22°C OFF MENU OK VOL+ VOL- 19 20 7.9. Default Setting æChoose "Default Setting" and press "OK" to confirm the option. 22°C Language Setting Date & Time Temp.°C/°F Motion Detecting Power Saving 15 : 11 : 06 Brightness Setting Temp Setting Frequency VOX Default Setting MENU OK VOL+ VOL- çDelete all cameras and settings history by selecting this function. 22°C 15 : 11 : 06 Caution: After default setting, you have to re-pair the camera before next use. YES NO MENU OK VOL+ VOL- 21 FQA Q: Cannot to connect to camera. A: 1. Please ensure the camera keep charging. 2. Please ensure the camera and monitor within 900 feet (at open area). Q: The video changed to unclear. A: 1. Please try to remove the camera near to monitor. 2. Please clear the obstacle between camera and monitor. Q: The baby monitor has some noise. A: The camera and tablet may be too close. Move them further apart. Q: Can I use the 220V? A: The working voltage of this baby monitor is 110-240V Q: How long this monitor can standby? A: After charged full, the monitor can standby about 4 hours. Q: Can I hear my baby's voice when turn off the screen? A: Yes, please turn on the "VOX" function and press to turn off the screen, then you will hear your baby's voice and alarm once any abnormal sound or noise happened. Q: What is the auto tracking? A: This function means camera will automatically move following with the people or object in the range of lens. If you don't like this function, you can choose to turn off it. CONTACT US For any inquires, issue or comments concerning our products, please send E-mail to the address below, and we will respond as soon as possible. E-mail: cs@tabletexpress.com 22Adobe PDF library 15.00 Adobe Illustrator CC 2017 (Windows)
