SonicWall SonicOS API 6.5.4 Reference About SonicOS API 7 Enabling through the CLI Starting at the config# prompt: config(<serial number>)# administration (config-administration)# sonicos-api
SonicWall® SonicOS API 6.5.4
Reference
Contents
1
About SonicOS API . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 SonicOS API Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Enabling through the Management Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Enabling through the CLI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Supported Request Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Supported HTTP Headers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Supported HTTP MIME Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Status and Error Representation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Client Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Example - Commit Pending Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Example - Address Object API Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
API Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Authentication Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Two-Factor Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 RFC-2617 HTTP Basic Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 RFC-7616 HTTP Digest Access Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
MD5 Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 SHA-512/256 Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Integrity Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Session Variant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Public Key Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Public Key Challenge/Response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 RSA Padding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Password Size Limits and RSA Key Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Challenge-Handshake Authentication (CHAP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Pros and Cons of the Different Schemes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Session Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Challenge-Free and Challenge/Response Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Password and Password-Hash Saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Operation After Non-Digest Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Nonce Resetting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
API: Config - Pending . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 About Modifying Configuration API . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
GET Pending Changes (Unchanged) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 GET Pending Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
SonicWall® SonicOS API 6.5.4 Reference Contents
2
POST Pending Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
API: Restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 About Restarting API . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
API: Address Objects IPv4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Object: Address Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Collection: Address Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
API: Address Objects IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Object: Address Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Collection: Address Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
API: Address Objects MAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Object: Address Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 Collection: Address Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
API: Address Objects FQDN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Object: Address Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 Collection: Address Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
API: Address Groups -- IPv4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Object: Address Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Collection: Address Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
API: Address Groups -- IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Object: Address Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 Collection: Address Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
SonicWall® SonicOS API 6.5.4 Reference Contents
3
Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
API: Schedule Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Object: Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 Collection: Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
API: Service Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Object: Service Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 Collection: Service Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
API: Service Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Object: Service Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 Collection: Service Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
API: Zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Object: Zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74 Collection: Zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
API: DNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Object: DNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
API: Interfaces IPv4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Object: Interface IPv4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103 Collection: Interface IPv4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
API: NAT Policies IPv4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Object: NAT Policies IPv4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114 Collection: NAT Policies IPv4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
SonicWall® SonicOS API 6.5.4 Reference Contents
4
API: NAT Policies IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Object: NAT Policies IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
API: NAT Policies NAT64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Object: NAT Policies NAT64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132 Collection: NAT Policies NAT64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
API: Access Rules IPv4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Object: Access Rules IPv4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138 Collection: Access Rules IPv4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
API: Access Rules IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Object: Access Rules IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152 Collection: Access Rules IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
API: Route Policies IPv4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
Object: Route Policies IPv4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166 Collection: Route Policies IPv4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
API: Route Policies IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173 Endpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173 Schema Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Object: Route Policies IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173 Collection: Route Policies IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174 Schema Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
SonicWall Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179 About This Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180
SonicWall® SonicOS API 6.5.4 Reference Contents
5
1
About SonicOS API
· SonicOS API Function on page 6 · Enabling through the Management Interface on page 6 · Enabling through the CLI on page 7
· Supported Request Methods on page 7 · Supported HTTP Headers on page 8 · HTTP Status Codes on page 10 · Status and Error Representation on page 10
· Client Authentication on page 12 · Examples on page 13
SonicOS API Function
SonicOS API provides an alternative to the SonicOS Command Line Interface (CLI) for configuring selected functions. SonicOS API is disabled by default in SonicOS. Any attempt to access SonicOS API while it is disabled results in an HTTP 403 Forbidden error. To use the SonicOS API, you must enable it, either through the SonicOS Management Interface or from the CLI. SonicOS API is supported on all platforms running SonicOS 6.5.4 and higher.
Topics: · Enabling through the Management Interface on page 6 · Enabling through the CLI on page 7
Enabling through the Management Interface
To enable SonicOS API through the management interface:
1 Navigate to MANAGE | System Setup | Appliance > Base Settings. 2 Scroll down to the SonicOS API section. 3 Select Enable SonicOS API. 4 Click Accept.
SonicWall® SonicOS API 6.5.4 Reference About SonicOS API
6
Enabling through the CLI
Starting at the config# prompt:
config(<serial number>)# administration (config-administration)# sonicos-api (config-administration)# commit
Supported Request Methods
SonicOS API utilizes four of the methods defined in the HTTP protocol (RFC 7231 and RFC 5789) to create, read, update and delete (CRUD) resources. Supported HTTP request methods describes the supported HTTP methods for management operations after authentication. Refer to Client Authentication on page 12 for the methods supported during authentication.
Supported HTTP request methods
HTTP method GET
POST
PUT DELETE
Description
Retrieves the specified resource or collection of resources. GET is a read-only operation that does not alter appliance state or configuration. A GET operation should not contain a request-body.
Submits data to be processed by the specified resource or collection of resources. In most cases, the POST verb is used by SonicOS APIs to create and add a resource to a collection of resources (for example, add a new MAC address-object to collection of objects).
Updates the specified resource. The data included in the PUT request-body replaces the previous configuration.
Deletes the specified resource or collection of resources.
Supported HTTP header request and response formats
Type Text/plain
Application/JSON
Example
GET /api/sonicos/address-objects/mac Accept: text/plain
POST /api/sonicos/address-objects/mac Content-type: application/json Accept: application/json {
"address_object": { "mac": { "name": "001122334455" ,"address": "001122334455" ,"multi_homed": true ,"zone": "LAN" }
} }
To configure all other parameters:
config(C0EAE483FB86)# administration (config-administration)# sonicos-api (config-sonicos-api)# exit (config-administration)# commit
SonicWall® SonicOS API 6.5.4 Reference About SonicOS API
7
SonicOS API Commands basic digest integrity-protection md5-digest rsa-key-size session-security two-factor-bearer-token
chap hold-password max-nonce public-key rsa-padding-type sha256-digest
Supported HTTP Headers
Content-type Accept
Specifies the format (MIME type) of the request body (input). Specifies the format of the response body (output).
Supported HTTP MIME Types
SonicOS supports these HTTP MIME types: · Text/plain · Application/JSON
These HTTP headers define the request and response format: · Content-type Specifies the format (MIME type) of the request body (input) · Accept Specifies the format of the response body (output) NOTE: The headers can be used to obtain mixed input/output. See examples below for reference.
Examples
Topics:
· Application/JSON on page 8 · Text/Plain on page 9
Application/JSON
When specified, the request and/or response body is expected to be in SonicOS API JSON format.
Request
POST /api/sonicos/address-objects/mac Content-type: application/json Accept: application/json
{
SonicWall® SonicOS API 6.5.4 Reference About SonicOS API
8
"address_object": { "mac": { "name": "001122334455" ,"address": "001122334455" ,"multi_homed": true ,"zone": "LAN" }
} }
Response
HTTP/1.0 200 OK Server: SonicWALL Content-type: application/json; charset=UTF-8
{ "status": { "success": true ,"cli": { "depth": 1 ,"mode": "config_mode" ,"configuring": true ,"pending_config": true ,"restart_required": "NONE" } ,"info": [ { "level": "info", "code": "E_OK", "message": "Success." } ]
} }
Text/Plain
When specified, the request and/or response body is expected to be in SonicOS CLI plain-text command format.
Topics:
· Request 1 on page 9 · Request 2 on page 9
Request 1
GET /api/sonicos/address-objects/mac Accept: text/plain
Response
HTTP/1.0 200 OK Server: SonicWALL Content-type: text/plain; charset=UTF-8
address-object mac example address 001122334455 zone LAN multi-homed exit
Request 2
POST /api/sonicos/direct/cli Content-type: text/plain Accept: application/json
SonicWall® SonicOS API 6.5.4 Reference About SonicOS API
9
address-object mac example address 001122334455 zone LAN multi-homed exit
Response
HTTP/1.0 200 OK Server: SonicWALL Content-type: application/json; charset=UTF-8
{ "status": { "success": true ,"cli": { "depth": 1 ,"mode": "config_mode" ,"configuring": true ,"pending_config": true ,"restart_required": "NONE" } ,"info": [ { "level": "info", "code": "E_OK", "message": "Success." } ]
} }
Status and Error Representation
All plain text output from the last backend CLI command executed is captured and returned to the client. If the command executed was not a show command and the requested operation succeeded, then the response body is empty. This is consistent with the CLI when executing a command via SSH or the serial console in that status is only rendered to the console upon error.
A JSON status object is guaranteed to be returned in the response body when performing a POST, PUT, or DELETE operation or upon error(s) encountered when processing a request.
Topics:
· HTTP Status Codes on page 10
· Application/JSON on page 11
HTTP Status Codes
SonicOS API uses standard HTTP status codes to report success or failure when servicing a request.
HTTP Status Codes
Code 200 400 401
403
Status Text
Description
OK
The request succeeded.
Bad Request
An invalid request was submitted. Verify that the request URI is correct and that the request body is as expected.
Not Authorized The user is unauthenticated or lacks the required privileges for the requested operation. This may be accompanied by headers for initiating authentication, depending on the scheme(s) enabled for that.
Forbidden
The request was understood by the server but denied. The response body notes the reason why the request was denied.
SonicWall® SonicOS API 6.5.4 Reference About SonicOS API
10
HTTP Status Codes
Code 404 405 406 413 414 500 503
Status Text
Description
Not Found
The resource specified was not found.
Method Not Allowed
The HTTP verb specified is not allowed or supported by the resource specified.
Not Acceptable The MIME type specified in the HTTP Content-type and/or Accept header is not supported.
Request body Maximum size of the request body was exceeded. too large
Request URL too long
The request URL exceeded the maximum size allowed or contains extra/unknown parameters (directories).
Internal Server The request failed due to an internal server error. The response body should note
Error
the reason why the request failed.
No resources Maximum number of sessions was exceeded.
Application/JSON
A JSON status object is guaranteed to be returned in the response body when performing a POST, PUT, or DELETE operation or upon error(s) encountered when processing a request.
Topics:
· Schema Structure on page 11
· Schema Attributes on page 12
Schema Structure
{ "status": { "success": {boolean} ,"cli": { "depth": {number} ,"mode": "{string}" ,"command": "{string}" ,"configuring": {boolean} ,"pending_config": {boolean} ,"restart_required": "{string}" } ,"info": [ { "level": "{string}", "code": "{string}", "message": "{string}" } ... ] }
}
SonicWall® SonicOS API 6.5.4 Reference About SonicOS API
11
Schema Attributes
Schema attributes Attribute
status status.success status.cli
status.cli.depth
status.cli.mode status.cli.command
status.cli.configuring status.cli.pending_config
status.cli.restart_required
status.info status.info.level status.info.code status.info.message
Type
Description
object
Status object.
boolean Boolean success flag. Refer to the status.info array for (true|false) more detailed information as to what caused the error if
the success flag is false.
object
CLI status.
NOTE: This attribute is included only when an API sent one or more commands to the CLI backend.
number (uint8)
Current mode depth of the CLI:
· 0 = top-level mode · >= 1 config mode
string
Name of the current mode.
string
Command last executed.
NOTE: This attribute is only included upon command error(s).
boolean Boolean configuring flag. Should always be true upon one (true|false) or more consecutive POST, PUT or DELETE API calls that
modify the configuration.
boolean Boolean pending-config flag. Should always be true upon (true|false) one or more consecutive POST, PUT or DELETE API calls
that modify the configuration. This flag should be cleared once any/all pending changes are committed (saved).
string
Appliance restart status. To take effect, some configuration changes require an appliance restart. These values indicate the type of restart needed:
· NONE · APPLIANCE · CHASSIS · CHASSIS_SHUTDOWN · ALL_BLADES
array
Informational message(s).
string
Status level: info, warning, error.
string
Status code. If success, E_OK is returned, else E_{XXX} where XXX = error code.
string
Status message.
Client Authentication
SonicOS API currently offers the following mechanisms for initial client authentication: · HTTP Basic Authentication (RFC 2617) · HTTP Digest Access Authentication (RFC-7616) · Public Key Authentication · Challenge-Handshake Authentication (CHAP)
SonicWall® SonicOS API 6.5.4 Reference About SonicOS API
12
· Time-Based One-Time Password (TOTP)/Bearer Token Authentication Regardless of the authentication mechanism used, only:
· A single administrator can manage (modify configuration) at any given time. This remains true regardless of where an admin logged in (web management UI, CLI, GMS, or SonicOS API).
· Users with full admin privileges are allowed to access SonicOS API. · A single SonicOS API session is currently allowed. For more information refer to API Authentication on page 17.
Examples
Topics:
· Example - Commit Pending Configuration on page 13 · Example - Address Object API Calls on page 15
Example - Commit Pending Configuration
All SonicOS APIs that modify configuration (POST, PUT, DELETE) do not take effect immediately. Rather, configuration is staged and is not pushed to run-time config and saved to flash/permanent storage until API clients explicitly execute a POST request to /api/sonicos/config/pending. This is the same behavior as in the SonicOS CLI and equivalent to invoking the commit command from the top-level config mode.
Pending configuration can be canceled (deleted) at any time by executing a DELETE request to /api/sonicos/config/pending. Any/all pending configuration is canceled upon client session termination, whether due to idle-timeout or explicit logout. In this case, all unsaved changes are lost. It is the client's responsibility to either commit pending configuration after each POST/PUT/DELETE API call or maintain pending changes on the client side to be restored in a later session.
Endpoint
Endpoint
HTTP method and body
GET
POST
PUT
URI: /api/sonicos/config/pending
Empty
Empty
--
Schema: N/A
DELETE Empty
Topics:
· Schema on page 13 · Examples on page 14
Schema
Schema Structure
A schema is not really applicable here as POST, PUT, and DELETE HTTP body is expected to be empty. However, GET returns any/all pending (unsaved) configuration.
SonicWall® SonicOS API 6.5.4 Reference About SonicOS API
13
Schema Attributes
Not applicable.
Examples
Topics:
· # GET Pending Changes (unchanged) on page 14 · # GET Pending Changes on page 14 · # POST Pending Changes on page 15
# GET Pending Changes (unchanged)
Request:
GET /api/sonicos/config/pending Accept: application/json
Response:
HTTP/1.0 200 OK Server: SonicWALL Content-type: application/json; charset=UTF-8 { }
# GET Pending Changes
Request:
GET /api/sonicos/config/pending Accept: application/json
Response:
HTTP/1.0 200 OK Server: SonicWALL Content-type: application/json; charset=UTF-8 {
"address_objects": [ { "pending": "ADD" ,"ipv4": { "name": "B" ,"host": { "ip": "2.2.2.2" } ,"zone": "WAN" } }
] }
SonicWall® SonicOS API 6.5.4 Reference About SonicOS API
14
# POST Pending Changes
Request:
POST /api/sonicos/config/pending Accept: application/json
Response:
HTTP/1.0 200 OK Server: SonicWALL Content-type: application/json; charset=UTF-8 {
"status": { "success": true ,"cli": { "depth": 1 ,"mode": "config_mode" ,"configuring": true ,"pending_config": false ,"restart_required": "NONE" } ,"info": [ { "level": "info", "code": "E_OK", "message": "Success." } ]
} }
Example - Address Object API Calls
Topics:
· # Create a new IPv4 Address Object named Web Server on page 15 · # Modify the Web Server Address Object host IP on page 15 · # Delete the Web Server Address Object on page 16
# Create a new IPv4 Address Object named Web Server
POST /api/sonicos/address-objects/ipv4 Content-type: application/json
{ "address_object": { "ipv4": { "name": "Web Server", "zone": "DMZ", "host": { "ip": "192.168.168.168" } } }
}
# Modify the Web Server Address Object host IP
PUT /api/sonicos/address-objects/ipv4/name/Web%20Server Content-type: application/json
{
SonicWall® SonicOS API 6.5.4 Reference About SonicOS API
15
"address_object": { "ipv4": { "host": { "ip": "192.168.168.1" } }
} }
# Delete the Web Server Address Object
DELETE /api/sonicos/address-objects/ipv4/name/Web%20Server
SonicWall® SonicOS API 6.5.4 Reference About SonicOS API
16
2
API Authentication
Topics:
· Authentication Methods on page 17 · Two-Factor Authentication on page 18 · RFC-2617 HTTP Basic Authentication on page 23 · RFC-7616 HTTP Digest Access Authentication on page 24 · Public Key Authentication on page 25 · Challenge-Handshake Authentication (CHAP) on page 27 · Session Security on page 29
Authentication Methods
SonicOS API supports four authentication mechanisms that share the same endpoint for client login and logout.
Endpoint GET
URI: /api/sonicos/auth Empty
HTTP Method & Body
POST
PUT
Empty
--
DELETE Empty
1 Navigate to MANAGE | System Setup | Appliance > Base Settings. 2 Scroll down to the SonicOS API section. 3 Select from the choices under Enable SonicOS API.
· Enable RFC-7616 HTTP Digest Access Authentication · Enable digest algorithms: SHA256 or MD5 · Integrity protection: Disabled, Allowed, or Enforced. · Use session variant (password hashes in place of passwords): Disabled, Allowed, or Enforced.
· Enable CHAP authentication · Enable RFC-2617 HTTP Basic Access authentication · Enable Public Key Authentication
· RSA modulus (key/cipher size in bits): 2014 is the default. · RSA padding type: PKCS#1 v1.5 or PKCS#1 v2.0 OAEP
· OAEP hash method: SHA-1, SHA-256, or Other · OAEP mask (MGF1) method: SHA1, SHA-256, or Other · Enable Two-Factor and Bearer Token Authentication
SonicWall® SonicOS API 6.5.4 Reference API Authentication
17
· Enable session security using RFC-7616 Digest Access Authentication · Can hold user passwords received from the client. · Maximum nonce use: 10 by default
NOTE: It is highly recommended to call delete api/sonicos/auth to log out of the API session, with bearer token or user name/password. Otherwise, the session is closed after a time of inactivity.
NOTE: The settings for RFC-7616 Digest Authentication also apply to session security. If the settings are disabled for RFC-7616, they are enabled for session security.
Two-Factor Authentication
SonicOS API supports Two Factor Authentication (TFA) for administrators and users who want to enable the security feature from the Graphical User Interface (GUI) and API. This is an alternative to the other authentication mechanisms described here and cannot be used along with those. Bearer Token Authentication is an alternative method of securing the management requests sent after authentication, as per the Open API Specification, and as used by Swagger. When two-factor authentication is used to log in on the API, then Bearer Token Authentication must be used in all the requests that follow it.
To log in with TFA and use Bearer Token Authentication through the firewall:
1 Enter your Username and Password in the SonicWall LOG IN page.
2 Navigate to MANAGE | System Setup | Appliance > Base Settings.
3 Under the Administrator Name & Password section, scroll down to One-time Passwords Method:
4 Choose TOTP from the drop-down menu.
SonicWall® SonicOS API 6.5.4 Reference API Authentication
18
5 Scroll down to the SonicOS API section. 6 Select Enable Two-Factor and Bearer Token Authentication (applies to built-in admin and local user with
TOTP only, post sonicos/tfa directly instead of sonicos/auth).
7 Click ACCEPT. A message displays under the ACCEPT and CANCEL buttons next to Status indicating the configuration has been updated.
To use TFA and Bearer Token Authentication:
1 Enter your Username and Password in the SonicWall LOG IN page. 1 The SonicWall-proprietary bar code screen displays. 2 Install either the Google Authenticator or Duo apps on your phone to implement two-step verification
using TOTP for your appliance. 3 Using the apps, scan the SonicWall bar code by positioning your phone lens window in front of the bar
code. 4 The apps then generate a security code that you enter into the text field next to 2FA Code:
IMPORTANT: Remember to write down your eight-digit emergency scratch code somewhere for later access as it is the only way to log in if you lose your mobile phone. 5 Click OK.
SonicWall® SonicOS API 6.5.4 Reference API Authentication
19
6 Click the Click here to continue ... link in the next SonicWall bar code screen after you have succeeded to UNBIND the TOTP KEY.
7 Enter the code from the app in the 2FA Code field and click OK.
SonicWall® SonicOS API 6.5.4 Reference API Authentication
20
8 After your password has been verified you successfully land in the appliance's Base Settings page.
NOTE: Administrators and users can also enforce the TFA and Bearer Token Authentication feature by going to System Setup | Users > Settings page.
To log in with TFA and use Bearer Token Authentication through the API:
1 Navigate to MANAGE | Logs & Reporting | API. 2 Click on the HTTPS://SONICOS-API.SONICWALL.COM link under the SonicWall SonicOS API Agreement
section. 3 Click Logout to log out of the firewall. 4 The browser automatically links to the SWAGGER API open-source software user interface, which
displays. You can also use other API tools such as Postman and Linux Command cURL.
NOTE: The Swagger tool works slowly sometimes so it may take a few seconds for the UI to appear. Also, not all browsers have the same speed of connection to Swagger and the other API apps.
5 Post "tfa" with user name, password, and two-factor code to the firewall.
SonicWall® SonicOS API 6.5.4 Reference API Authentication
21
6 Click Execute. 7 Click Authorize when done. 8 The bearer token is returned in the "tfa" response message.
9 Click Authorize.
10 Click Authorize again under Available authorizations.
SonicWall® SonicOS API 6.5.4 Reference API Authentication
22
RFC-2617 HTTP Basic Authentication
RFC-2617 HTTP Basic Authentication is the simplest method for client authentication. HTTP Basic Authentication uses the standard Authentication HTTP headers to pass user credentials between the client and the server. Because HTTP Basic Authentication provides no means for protecting the confidentiality of a user's credentials, SonicOS API requires user credentials to be transmitted over HTTPS when this is enabled. For SonicOS API HTTP Basic Authentication, use the Linux command-line curl command with the -u option:
· Login:
curl -k -i -u admin:password -X POST https://a.b.c.d/api/sonicos/auth
· Logout:
curl -k -i -X DELETE https://a.b.c.d/api/sonicos/auth
RFC-7616 HTTP Digest Access Authentication
SonicOS API supports the RFC-7616 HTTP Digest Access Authentication scheme as its most secure. It includes: · Secure authentication using SHA-256, extensible for other algorithms in the future. · Replay prevention utilizing a counter that is incremented in each request and can be reset to any value at any time in replies from the firewall. · An option for a "rolling nonce," where an HTTP reply can optionally pass back a new nonce (random number) to be used for the next request. · Optional "integrity protection" where requests with entity body content can include that in the digest calculation. · An optional "session" variant that uses a SHA hash of the password instead of the password itself so that the SonicWall/client do not need to store the actual password.
For SonicOS API HTTP Digest Access Authentication, use the Linux command-line curl command with the -u option:
· Login:
curl -k -i -u admin:password -digest -X HEAD https://a.b.c.d/api/sonicos/auth
SonicWall® SonicOS API 6.5.4 Reference API Authentication
23
MD5 Support
MD5 is supported with HTTP Digest Access Authentication to allow inter-operation with older software that does not support SHA-256, but it is disabled by default and use of SHA-256 instead is highly recommended.
SHA-512/256 Support
Although RFC-7616 specifies the hashing scheme named "SHA-512/256," which is an efficient hybrid between SHA-512 and SHA-256 (see FIPS 180-4), as an alternative to SHA-256, SonicOS does not currently support it.
Integrity Protection
Integrity protection is an optional feature specified in RFC-7616 where the body content of a request is included in the digest hash, hence providing protection against malware trying to change or replace that. This is not useful in the authentication request since no sensitive data is sent, but it is supported for session security and, if enabled, can be used there too.
NOTE: curl's latest digest authentication does not support integrity protection for requests with data content. Setting integrity protection on the SonicWall to Allow, rather than to Enforce, allows initial authentication without integrity protection. Custom scripts can then use integrity protection to safeguard the content of the API management requests.
SonicWall® SonicOS API 6.5.4 Reference API Authentication
24
Session Variant
RFC-7616 specifies a mode of operation referred to as the session variant. A hash of the password, and some other fixed values, is used instead of the actual password. This allows the operation without needing to store the password in any retrievable way. This can be useful to enhance security on the client side when using local user accounts, including the built-in admin. The client can then store the hash of the admin password, rather than storing the actual password.
This can also be helpful on the SonicWall side during session security. Refer to Password and Password-Hash Saving on page 29.
Public Key Authentication
The SonicWall proprietary Public Key Authentication is an alternative secure scheme that, unlike digest authentication, allows the password to be securely encrypted and sent from the client to the firewall. This is necessary if session security is to be performed with accounts that are authenticated remotely via LDAP/RADIUS/TACACS+.
Public Key Challenge/Response
The public key exchange utilizes the WWW-Authenticate and Authorization HTTP headers, compliant with the access authentication framework specified in RFC-7235 section 2, and with their auth-scheme specifying SNWL-PK-AUTH.
A client must first invoke a challenge from the firewall by making a request to /api/sonicos/auth. Any method can be used for this, but it is suggested that a POST be used if the override parameter is to be set, or otherwise a HEAD request since no request data content is involved. This solicits a response as follows:
HTTP/1.0 401 Unauthorized
Server: SonicWall
WWW-Authenticate: SNWL-PK-AUTH type=RSA, key="..."
An exception for authentication is with CHAP authenticated via RADIUS, but it is not compatible with then doing session security.
The client will then need to resend the request to /api/sonicos/auth with an Authorization header as follows:
Authorization: SNWL-PK-AUTH user="admin", data="..."
The content of the key field in the challenge is the RSA public key, in ASN.1 type RSAPublicKey format (see RFC-3447 section A.1.1) and base64-encoded. This is what comes between the BEGIN and END markers in an RSA key in a .pem file, concatenated into a single line (with the BEGIN/END markers not included). For example with this RSA key:
-----BEGIN PUBLIC KEY-----
MIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQCdzKnaH+K2kfpHE2U7SDsbZMpd
Qu8vEYIdDlqrQx7BzQpfBGVy5CbTsJn+RiGPNYjtFAL+7Qux4wqc6aOnpWJoY/
BiBmoEKRumBOd2VJBr599yllfqQbXPwQEd9euWTlvaD7G+OhIWFMCnPRIOFkZxwc
1v+Aqq8FY/A/nMYPYwIDAQAB
-----END PUBLIC KEY-----
It would be the string "MIGfMA0G...YwIDAQAB". The client can take this string and save it as a .pem file, enclosed in ----- BEGIN PUBLIC KEY----- / -----END PUBLIC KEY----- header/footer. That can then be used with openssl's command-line RSA utility to encrypt a password using openssl by either of:
SonicWall® SonicOS API 6.5.4 Reference API Authentication
25
echo -n password | openssl rsautl -encrypt -pubin -inkey key-file.pem | base64 -w 0
echo -n password | openssl pkeyutl -encrypt -pkeyopt rsa_padding_mode:pkcs1 -pubin \
-inkey key-file.pem | base64 -w 0
Or if PKCS#1 v2.0 OAEP padding is selected (see below) by any one of:
echo -n password | openssl rsautl -encrypt -oaep -pubin -inkey key-file.pem | base64 -w 0
echo -n password | openssl pkeyutl -encrypt -pkeyopt rsa_padding_mode:oaep -pubin \
-inkey key-file.pem | base64 -w 0
echo -n password | openssI pkeyutI -encrypt -pkeyopt rsa_padding_mode:oaep -pkeyopt \
rsa_oaep_md:sha256 -pkeyopt rsa_mgf1_md:sha256 -pubin _inkey key-file.pem | base64 -w 0
The "openssl rsautl" is now deprecated and using "openssl pkeyutl" is preferred. In the case of OAEP, the first two forms above both use SHA-1 for the hashes in the OAEP padding, and the third form needs to be used for other hashing methods (such as SHA-256, as in the above example). Note that the latter is not supported in all SonicOS version.
The data field in the response holds the cipher data (encrypted password), base64-encoded (as output by the above commands).
The string could be piped through "fold -w 64" to break it into 64-character lines, as in the example above, but that is not necessary and a .pem file with a single long line between the header/footer lines works fine.
The following is an example bash script to send a public key authentication request to the firewall, extract the public key from the WWW-Authenticate challenge in the reply, use that to encrypt the password (with OAEP padding using SHA-256) and then send the response back to the firewall:
curl -k -i -s -X POST https://$ADDR/api/sonicos/auth | grep 'WWW-Authenticate: SNWL-PK-AUTH' \ | sed -e 's/^.*key="/-----BEGIN PUBLIC KEY-----\n/' \ -e 's/"/\n-----END PUBLIC KEY-----/' >pk.pem
CIPHER=$(echo -n "$PASSWORD" | openssl pkeyutl -encrypt -pkeyopt rsa_padding_mode:oaep \ -pkeyopt rsa_oaep_md:sha256 -pkeyopt rsa_mgf1_md:sha256 -pubin -inkey pk.pem \ | base64 -w 0)
curl -k -i -s -H 'Authorization: SNWL-PK-AUTH user="'$USERNAME'", data="'$CIPHER'"' \ -X POST https://192.168.168.32/api/sonicos/auth
RSA Padding
RSA defines two types of padding, the original one specified in PKCS#1 v1.5, and a more recent OAEP padding specified in PKCS#1 v2.0.
PKCS#1 v2.0 utilizes SHA hashing and is more secure and preferred, but gives more size overhead, hence resulting in a smaller maximum password size for a given key size. Refer to Password Size Limits and RSA Key Sizes.
The type of padding to use is configurable, defaulting to OAEP. The client and firewall must be using the same type of padding, and for security it is highly recommended that OAEP padding be used.
OAEP padding uses two hashes (its primary hash and that for its MGF1 mask generation function) and in some versions of SonicOS these too are configurable. In both cases any hashing method that is supported by OpenSSL (the version used in SonicOS) can be used. The two do not need to be the same, but what the client uses in the encryption must match what is configured on the firewall.
SonicWall® SonicOS API 6.5.4 Reference API Authentication
26
Password Size Limits and RSA Key Sizes
The maximum length of the password that can be encrypted depends on the chosen RSA key size (modulus) and padding type, as follows:
Key Bits 512 512 512 512 512 512 1024 1024 1024 1024 1024 1024 2048 2048 2048 2048 2048 2048
Cipher Size 64 bytes 64 bytes 64 bytes 64 bytes 64 bytes 64 bytes 128 bytes 128 bytes 128 bytes 128 bytes 128 bytes 128 bytes 256 bytes 256 bytes 256 bytes 256 bytes 256 bytes 256 bytes
Padding Type
Pad Bytes
PKCS#1 v1.5
11
OAEP with SHA-1 42
OAEP with SHA-224 58
OAEP with SHA-256 66
OAEP with SHA-384 98
OAEP with SHA-512 130
PKCS#1 v1.5
11
OAEP with SHA-1 42
OAEP with SHA-224 58
OAEP with SHA-256 66
OAEP with SHA-384 98
OAEP with SHA-512 130
PKCS#1 v1.5
11
OAEP with SHA-1 42
OAEP with SHA-224 58
OAEP with SHA-256 66
OAEP with SHA-384 98
OAEP with SHA-512 130
Maximum Password Length 53 characters 22 characters 6 characters Not possible Not possible Not possible 117 characters 86 characters 70 characters 62 characters 30 characters Not possible 245 characters 214 characters 198 characters 190 characters 158 characters 126 characters
Challenge-Handshake Authentication (CHAP)
SonicOS API supports a CHAP authentication scheme, which is generally less secure than the more modern RFC-7616 HTTP Digest scheme, but could be useful, particularly if using RADIUS for the back-end authentication with remote user accounts
Clients must first perform a CHAP challenge initiate request by invoking a call to GET /api/sonicos/auth:
HTTP/1.0 200 OK Server: SonicWALL Content-type: application/json; charset=UTF-8
{ "id": "{string}", "challenge": "{string}"
}
id:
Type:
string (hexadecimal number)
Description: CHAP ID
Example:
0b
SonicWall® SonicOS API 6.5.4 Reference API Authentication
27
challenge:
Type: Description: Example:
string (hexadecimal #) Hexadecimal-formatted, randomly generated number EA7F57F37595B6891C222EF284C05D84
Clients must then generate a one-way hash (CHAP digest) using the user's credentials and the parameters returned via the initiate request. For information on how to calculate the digest see RFC-1994.
When the CHAP digest is generated, it is packaged up via a JSON-formatted request to
POST /api/sonicos/auth:
{ "override": {boolean}, "id": "{string}", "user": "{string}", "digest": "{string}"
}
override:
id: user: digest:
Type: Description:
Default: Example: Type: Description: Example: Type: Description: Example: Type: Description: Example:
boolean Boolean flag that if true will allow the API session to override an admin currently logged in. false true string (hexadecimal number) CHAP ID. 0b string Username. admin string CHAP digest. D96E46E27497B6891C222EF284C05D84
Pros and Cons of the Different Schemes
Each of the four authentication schemes supported by SonicOS 6.5.4 API has pros and cons, and not all of them are usable in all situations.
Generally, the recommendation is to use Public Key Authentication if administrative user accounts are used that need to be authenticated remotely via RADIUS, LDAP or TACACS+, and use HTTP Digest Authentication otherwise.
Refer to the overview table below for a comparison:
Situations
HTTP Basic
Level of security:
Low
Supported in 3rd party utilities (curl, etc.): Yes
Client complexity:
Low
Remote authentication:
Compatible with all
Efficiency/performance:
High
HTTP Digest Very High Yes Low Not possible
Medium
Public Key High No Medium-High Compatible with all Low
CHAP Medium No Medium RADIUS only Medium
SonicWall® SonicOS API 6.5.4 Reference API Authentication
28
Session Security
Session Security means validating every request that is sent throughout the session after the initial authentication (i.e. those sent to a management, rather than authentication, endpoint). This is to avoid vulnerability to attacks such as injection of malicious requests from malware that can spoof the client's IP address (e.g. cross-site request forgery - CSRF) or a man-in-the-middle attack that could try to alter the content of a request. SonicOS API supports this enforcement which is enabled by default.
For this the RFC-7617 HTTP Digest Access Authentication mechanism is used, which provides for very good session security, including source authentication, replay detection and optional content integrity validation. If session security is enabled on the API then every subsequent management request sent after authentication will need to include an Authorization header generated as per RFC-7617, with an incrementing nc (nonce-count) field.
Session security will be possible after initial authentication by any of the supported schemes, with the one exception that it will not be supported after CHAP authentication with a remote user account authenticated by RADIUS.
Challenge-Free and Challenge/Response Operation
If the client saves the nonce and opaque values from the authentication stage and uses those with a sequential nonce count to generate Authorization headers in its requests then, so long as those are valid, no challenge is needed, allowing for efficient operation with a single HTTP request/response for each API management operation. It is recommended that this should be the normal method of operation for most clients.
On the other hand, the client can choose to not do this, sending its requests initially without an Authorization header, in which case each request solicits a 401 Unauthorized response with an HTTP digest challenge to which the client can respond. Operating in this way is less efficient, with two request/response exchanges needed for every API management operation, but it means that a utility like curl, which does not support tracking nonces etc. across multiple requests, can be used without needing additional scripting.
Password and Password-Hash Saving
To perform session security with user accounts that are remotely authenticated via LDAP/RADIUS/TACACS+, the initial authentication must use one of the HTTP Basic Access or Public Key authentication schemes. With these, the client sends the user's password to the SonicWall, and it can then save it for the lifetime of the session and use it for session security validation. If RFC-7617's Session Variant is used then, rather than storing the actual password in its internal memory, the SonicWall stores a more secure irreversible hash of it. The client must then calculate its digest hash accordingly, as per the RFC.
Operation After Non-Digest Authentication
The API client needs to know the values (realm, nonce, opaque and qop) for session security. After initial user authentication by the digest scheme, it already has those and can immediately start sending API requests with digests calculated from them. But if a different mechanism is used for that, the client has two choices:
· The client can send the first request after authentication with no Authorization header, which provokes a digest challenge giving all the relevant data.
SonicWall® SonicOS API 6.5.4 Reference API Authentication
29
· On success of any authentication mechanism, other than HTTP digest authentication, if session security is enabled on the API then the "200 OK" response includes an Authentication-Info header giving the data as follows:
HTTP/1.0 200 OK
Server: SonicWALL
Authentication-Info: Digest algorithm=SHA-256, realm="admin-users@a.b.c.d",
qop="auth", nonce="...", opaque="..."
This follows the model of the Authentication-Info header specified in RFC-7616, but it is a proprietary use of it. Clients can ignore this header (proceeding as per the first bullet option above) but utilizing the data returned in it to avoid the need for the challenge/response handshake when the first post-authentication API management request is sent.
Nonce Resetting
RFC-7617 allows for multiple requests to use the same nonce (with a sequentially updating nonce count) through session, but it also provides a mechanism for the server to periodically (or whenever it chooses) generate a new random nonce, returning it to the client via a nextnonce field in an Authentication-Info header in the response to a request. After receiving a response with that, the client must then use it for the next request (resetting the nonce count to 1 for that request).
There is a Maximum nonce use configuration option to set the number of requests after which a new nonce is generated. Setting this to zero causes the same nonce to be used through the entire session.
SonicWall® SonicOS API 6.5.4 Reference API Authentication
30
3
API: Config - Pending
· About Modifying Configuration API on page 31 · Endpoint on page 31 ·
· Schema Attributes on page 32 · Examples on page 32Schema Structure on page 31
· GET Pending Changes (Unchanged) on page 32 · GET Pending Changes on page 32 · POST Pending Changes on page 33
About Modifying Configuration API
All SonicOS API that modify configuration (POST, PUT, DELETE) do not take effect immediately. Rather, configuration is staged and is not pushed to run-time config or saved to flash/permanent storage until API clients explicitly execute a POST request to /api/sonicos/config/pending. This is the same behavior as SonicOS CLI and equivalent to invoking the commit command from the top-level config mode.
Pending configuration can be canceled (deleted) at any time by executing a DELETE request to /api/sonicos/config/pending. It should be noted that any/all pending configuration is canceled (deleted) upon client session termination, whether due to idle-timeout or explicit logout. In this case, all unsaved changes are lost so it is the client's responsibility to either commit pending configuration after each POST/PUT/DELETE API call or maintain pending changes on the client side to be restored in a later session.
Endpoint
Endpoint
URI: /api/sonicos/config/pending Schema: N/A
GET Empty
HTTP method and body
POST
PUT
Empty
--
DELETE Empty
Schema Structure
A schema is not really applicable here as POST, PUT and DELETE HTTP body is expected to be empty. However, GET returns any/all pending (unsaved) configuration so see all schemas in the following chapters.
SonicWall® SonicOS API 6.5.4 Reference API: Config - Pending
31
Schema Attributes
Not applicable.
Examples
Topics:
· GET Pending Changes (Unchanged) on page 32 · GET Pending Changes on page 32 · POST Pending Changes on page 33
GET Pending Changes (Unchanged)
Request:
GET /api/sonicos/config/pending Accept: application/json
Response:
HTTP/1.0 200 OK Server: SonicWALL Content-type: application/json; charset=UTF-8
{
}
GET Pending Changes
Request:
GET /api/sonicos/config/pending Accept: application/json
Response:
HTTP/1.0 200 OK Server: SonicWALL Content-type: application/json; charset=UTF-8
{ "address_objects": [ { "pending": "ADD" ,"ipv4": { "name": "B" ,"host": { "ip": "2.2.2.2" } ,"zone": "WAN" } }
SonicWall® SonicOS API 6.5.4 Reference API: Config - Pending
32
] }
POST Pending Changes
Request:
POST /api/sonicos/config/pending Accept: application/json
Response:
HTTP/1.0 200 OK Server: SonicWALL Content-type: application/json; charset=UTF-8
{ "status": { "success": true
,"cli": { "depth": 1
,"mode": "config_mode" ,"configuring": true ,"pending_config": false ,"restart_required": "NONE" }
,"info": [ { "level": "info", "code": "E_OK", "message": "Success." }
] } }
SonicWall® SonicOS API 6.5.4 Reference API: Config - Pending
33
4
API: Restart
· About Restarting API on page 34 · Endpoint on page 34 · Schema Structure on page 34
· Schema Attributes on page 34 · Example on page 35
About Restarting API
Restarts SonicOS (and chassis) immediately or after an interval of time.
Endpoint
Endpoint GET
URI: /api/sonicos/restart
--
[ / chassis ]
[
/at/{YYYYMMDDHHMMSS}
| /in/{UINT32} { /minutes | /hours | /days }
| /now
]
HTTP method and body
POST PUT DELETE
Empty --
--
Schema: N/A
Schema Structure
Not applicable.
Schema Attributes
Not applicable.
SonicWall® SonicOS API 6.5.4 Reference API: Restart
34
Example
POST /api/sonicos/restart POST /api/sonicos/restart/now POST /api/sonicos/restart/chassis/now POST /api/sonicos/restart/in/3/days
SonicWall® SonicOS API 6.5.4 Reference API: Restart
35
5
API: Address Objects IPv4
· Endpoint on page 36 · Schema Structure on page 36
· Object: Address Object on page 36 · Collection: Address Object on page 37 · Schema Attributes on page 37
Endpoint
Endpoint GET
URI: /api/sonicos/address-objects/ipv4
Empty
Schema: collection#address-object-ipv4-config
URI: /api/sonicos/address-objects/ipv4/name/{NAME} Empty
Schema: object#address-object-ipv4-config
URI: /api/sonicos/address-objects/ipv4/uuid/{UUID} Empty
Schema: object#address-object-ipv4-config
HTTP method and body
POST PUT
DELETE
Required Required Required
--
Required Ignored
--
Required Ignored
Schema Structure
Topics:
· Object: Address Object on page 36 · Collection: Address Object on page 37 · Schema Attributes on page 37
Object: Address Object
{ "address_object": { "ipv4": { "name": "{string}", "uuid": "{string}",
"host": { "ip": "{string}"
},
SonicWall® SonicOS API 6.5.4 Reference API: Address Objects IPv4
36
| "range": { "begin": "{string}", "end": "{string}"
}, | "network": {
"subnet": "{string}", "mask": "{string}" }
"zone": "{string}" } } }
Collection: Address Object
{ "address_objects": [ object#address-object-ipv4-config, ... ]
}
Schema Attributes
Topics:
· address_object: on page 37 · address_objects: on page 38 · address_object.ipv4: on page 38 · address_object.ipv4.name: on page 38 · address_object.ipv4.uuid: on page 38 · address_object.ipv4.host: on page 38 · address_object.ipv4.host.ip: on page 38 · address_object.ipv4.range: on page 38 · address_object.ipv4.range.begin: on page 38 · address_object.ipv4.range.end: on page 38 · address_object.ipv4.network: on page 39 · address_object.ipv4.network.subnet: on page 39 · address_object.ipv4.network.mask: on page 39 · address_object.ipv4.zone: on page 39
address_object:
Type: object Flags: -noneDescription: Add/edit address object.
SonicWall® SonicOS API 6.5.4 Reference API: Address Objects IPv4
37
address_objects:
Type: array Flags: -noneDescription: Address object collection.
address_object.ipv4:
Type: object Flags: key Description: IPV4 address object.
address_object.ipv4.name:
Type: string Flags: key Description: Host/network/range address object name.
address_object.ipv4.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
address_object.ipv4.host:
Type: object Flags: -noneDescription: Address object host.
address_object.ipv4.host.ip:
Type: string (ip) Flags: -noneDescription: IPv4 host address in the form: D.D.D.D.
address_object.ipv4.range:
Type: object Flags: -noneDescription: Address object range.
address_object.ipv4.range.begin:
Type: string (ip) Flags: -noneDescription: IPv4 starting range in the form: D.D.D.D.
address_object.ipv4.range.end:
Type: string (ip) Flags: -noneDescription: IIPv4 ending range in the form: D.D.D.D.
SonicWall® SonicOS API 6.5.4 Reference API: Address Objects IPv4
38
address_object.ipv4.network:
Type: object Flags: -noneDescription: Address object network.
address_object.ipv4.network.subnet:
Type: string (ip) Flags: -noneDescription: IPv4 network in the form: D.D.D.D.
address_object.ipv4.network.mask:
Type: string (subnet) Flags: -noneDescription: IPv4 netmask in decimal dotted or CIDR form: D.D.D.D OR /D
address_object.ipv4.zone:
Type: string Flags: -noneDescription: Zone object name.
SonicWall® SonicOS API 6.5.4 Reference API: Address Objects IPv4
39
6
API: Address Objects IPv6
· Endpoint on page 40 · Schema Structure on page 40
· Object: Address Object on page 40 · Collection: Address Objects on page 41 · Schema Attributes on page 41
Endpoint
Endpoint GET
URI: /api/sonicos/address-objects/ipv6
Empty
Schema: collection#address-object-ipv6-config
URI: /api/sonicos/address-objects/ipv6/name/{NAME} Empty
Schema: object#address-object-ipv6-config
URI: /api/sonicos/address-objects/ipv6/uuid/{UUID} Empty
Schema: object#address-object-ipv6-config
HTTP method and body
POST PUT
DELETE
Required Required Required
--
Required Ignored
--
Required Ignored
Schema Structure
Topics:
· Object: Address Object on page 40 · Collection: Address Objects on page 41 · Schema Attributes on page 41
Object: Address Object
{ "address_object": { "ipv6": { "name": "{string}", "uuid": "{string}",
"host": { "ip": "{string}"
},
SonicWall® SonicOS API 6.5.4 Reference API: Address Objects IPv6
40
| "range": { "begin": "{string}", "end": "{string}"
}, | "network": {
"subnet": "{string}", "mask": "{string}" }
"zone": "{string}" } } }
Collection: Address Objects
{ "address_objects": [ object#address-object-ipv6-config, ... ]
}
Schema Attributes
Topics:
· address_object: on page 41 · address_objects: on page 42 · address_object.ipv6: on page 42 · address_object.ipv6.name: on page 42 · address_object.ipv6.uuid: on page 42 · address_object.ipv6.host: on page 42 · address_object.ipv6.host.ip: on page 42 · address_object.ipv6.range: on page 42 · address_object.ipv6.range.begin: on page 42 · address_object.ipv6.range.end: on page 42 · address_object.ipv6.network: on page 43 · address_object.ipv6.network.subnet: on page 43 · address_object.ipv6.network.mask: on page 43 · address_object.ipv6.zone: on page 43
address_object:
Type: object Flags: -noneDescription: Add/edit address object.
SonicWall® SonicOS API 6.5.4 Reference API: Address Objects IPv6
41
address_objects:
Type: array Flags: -noneDescription: Address object collection.
address_object.ipv6:
Type: object Flags: key Description: IPV6 address object.
address_object.ipv6.name:
Type: string Flags: key Description: Host/network/range address object name.
address_object.ipv6.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
address_object.ipv6.host:
Type: object Flags: -noneDescription: Address object host.
address_object.ipv6.host.ip:
Type: string (ip) Flags: -noneDescription: IPv6 host address in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH
address_object.ipv6.range:
Type: object Flags: -noneDescription: Address object range.
address_object.ipv6.range.begin:
Type: string (ip) Flags: -noneDescription: IPv6 starting range in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH
address_object.ipv6.range.end:
Type: string (ip) Flags: -noneDescription: IIPv6 ending range in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH
SonicWall® SonicOS API 6.5.4 Reference API: Address Objects IPv6
42
address_object.ipv6.network:
Type: object Flags: -noneDescription: Address object network.
address_object.ipv6.network.subnet:
Type: string (ip) Flags: -noneDescription: IPv6 network in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH
address_object.ipv6.network.mask:
Type: string (v6 prefix) Flags: -noneDescription: Network prefix.
address_object.ipv6.zone:
Type: string Flags: -noneDescription: Zone object name.
SonicWall® SonicOS API 6.5.4 Reference API: Address Objects IPv6
43
7
API: Address Objects MAC
· Endpoint on page 44 · Schema Structure on page 44
· Object: Address Object on page 44 · Collection: Address Object on page 45 · Schema Attributes on page 45
Endpoint
Endpoint
URI: /api/sonicos/address-objects/mac Schema: collection#address-object-mac-config URI: /api/sonicos/address-objects/mac/name/{NAME} Schema: object#address-object-mac-config URI: /api/sonicos/address-objects/mac/uuid/{UUID} Schema: object#address-object-mac-config
GET Empty
Empty
Empty
HTTP method and body
POST PUT
DELETE
Required Required Required
--
Required Ignored
--
Required Ignored
Schema Structure
Topics:
· Object: Address Object on page 44
· Collection: Address Object on page 45
· Schema Attributes on page 45
Object: Address Object
{ "address_object": { "mac": { "name": "{string}", "uuid": "{string}", "address": "{string}", "zone": "{string}", "multi_homed": {boolean} }
SonicWall® SonicOS API 6.5.4 Reference API: Address Objects MAC
44
} }
Collection: Address Object
{ "address_objects": [ object#address-object-mac-config, ... ]
}
Schema Attributes
Topics:
· address_object: on page 45 · address_objects: on page 45 · address_object.mac: on page 45 · address_object.mac.name: on page 45 · address_object.mac.uuid: on page 46 · address_object.mac.address on page 46 · address_object.mac.zone: on page 46 · address_object.mac.multi_homed: on page 46
address_object:
Type: object Flags: -noneDescription: address object.
address_objects:
Type: array Flags: -noneDescription: Address object collection.
address_object.mac:
Type: object Flags: key Description: MAC address object.
address_object.mac.name:
Type: string Flags: key Description: MAC address object name.
SonicWall® SonicOS API 6.5.4 Reference API: Address Objects MAC
45
address_object.mac.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
address_object.mac.address
Type: string (mac) Flags: -noneDescription: Address object MAC address in the form: HH:HH:HH:HH:HH:HH or HHHHHHHHHHHH or HH-HH-HH-HH-HH-HH.
address_object.mac.zone:
Type: string Flags: -noneDescription: Zone object name.
address_object.mac.multi_homed:
Type: boolean (true|false) Flags: -noneDescription: Enable multi-homed host.
SonicWall® SonicOS API 6.5.4 Reference API: Address Objects MAC
46
8
API: Address Objects FQDN
· Endpoint on page 47 · Schema Structure on page 47
· Object: Address Object on page 47 · Collection: Address Object on page 48 · Schema Attributes on page 48
Endpoint
Endpoint GET
URI: /api/sonicos/address-objects/fqdn
Empty
Schema: collection#address-object-fqdn-config
URI: /api/sonicos/address-objects/fqdn/name/{NAME} Empty
Schema: object#address-object-fqdn-config
URI: /api/sonicos/address-objects/fqdn/uuid/{UUID} Empty
Schema: object#address-object-fqdn-config
HTTP method and body
POST PUT
DELETE
Required Required Required
--
Required Ignored
--
Required Ignored
Schema Structure
Topics:
· Object: Address Object on page 47
· Collection: Address Object on page 48
· Schema Attributes on page 48
Object: Address Object
{ "address_object": { "fqdn": { "name": "{string}", "uuid": "{string}", "domain": "{string}", "zone": "{string}", "dns_ttl": {number} }
SonicWall® SonicOS API 6.5.4 Reference API: Address Objects FQDN
47
} }
Collection: Address Object
{ "address_objects": [ object#address-object-fqdn-config, ... ]
}
Schema Attributes
Topics:
· address_object: on page 48 · address_objects: on page 48 · address_object.fqdn: on page 48 · address_object.fqdn.name: on page 48 · address_object.fqdn.uuid: on page 49 · address_object.fqdn.domain on page 49 · address_object.fqdn.zone: on page 49 · address_object.fqdn.dns_ttl on page 49
address_object:
Type: object Flags: -noneDescription: address object.
address_objects:
Type: array Flags: -noneDescription: Address object collection.
address_object.fqdn:
Type: object Flags: key Description: fqdn address object.
address_object.fqdn.name:
Type: string Flags: key Description: FQDN address object name.
SonicWall® SonicOS API 6.5.4 Reference API: Address Objects FQDN
48
address_object.fqdn.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
address_object.fqdn.domain
Type: string (fqdn) Flags: -noneDescription: FQDN in the form: example.com or *.example.com.
address_object.fqdn.zone:
Type: string Flags: -noneDescription: Zone object name.
address_object.fqdn.dns_ttl
Type: number (uint16)) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
SonicWall® SonicOS API 6.5.4 Reference API: Address Objects FQDN
49
9
API: Address Groups -- IPv4
· Endpoint on page 50 · Schema Structure on page 50
· Object: Address Group on page 50 · Collection: Address Group on page 51 · Schema Attributes on page 51
Endpoint
Endpoint GET
URI: /api/sonicos/address-groups/ipv4
Empty
Schema: collection#address-group-ipv4-config
URI: /api/sonicos/address-groups/ipv4/name/{NAME} Empty
Schema: object#address-group-ipv4-config
URI: /api/sonicos/address-groups/ipv4/uuid/{UUID} Empty
Schema: object#address-group-ipv4-config
HTTP method and body
POST PUT
DELETE
Required Required Required
--
Required If deleting
member(s)
--
Required If deleting
member(s)
Schema Structure
Topics:
· Object: Address Group on page 50 · Collection: Address Group on page 51 · Schema Attributes on page 51
Object: Address Group
{ "address_group": { "ipv4": { "name": "{string}", "uuid": "{string}",
"address_group": { "ipv4": [ { "name": "{string}"
SonicWall® SonicOS API 6.5.4 Reference API: Address Groups -- IPv4
50
},
... ] },
"address_object": { "ipv4": [ { "name": "{string}" },
... ],
"mac": [ { "name": "{string}" },
... ],
"fqdn": [ { "name": "{string}" },
... ] } } } }
Collection: Address Group
{ "address_objects": [ object#address-group-ipv4-config, ... ]
}
Schema Attributes
Topics:
· address_group: on page 52 · address_groups: on page 52 · address_group.ipv4: on page 52 · address_group.ipv4.name: on page 52 · address_group.ipv4.uuid: on page 52 · address_group.ipv4.address_group: on page 52 · address_group.ipv4.address_group.ipv4: on page 52 · address_group.ipv4.address_object.ipv4.name: on page 53
SonicWall® SonicOS API 6.5.4 Reference API: Address Groups -- IPv4
51
· address_group.ipv4.address_object.mac: on page 53 · address_group.ipv4.address_object.mac.name: on page 53 · address_group.ipv4.address_object.fqdn: on page 53 · address_group.ipv4.address_object.fqdn.name: on page 53
address_group:
Type: object Flags: -noneDescription: Address group.
address_groups:
Type: array Flags: -noneDescription: Address group collection.
address_group.ipv4:
Type: object Flags: key Description: ipv4 address group.
address_group.ipv4.name:
Type: string Flags: key Description: IPv4 address group name.
address_group.ipv4.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
address_group.ipv4.address_group:
Type: object Flags: -noneDescription: Assign address group to group.
address_group.ipv4.address_group.ipv4:
Type: array Flags: -noneDescription: IPV4 address group.
address_group.ipv4.address_group.ipv4.name:
Type: string Flags: -noneDescription: Group address object name.
SonicWall® SonicOS API 6.5.4 Reference API: Address Groups -- IPv4
52
address_group.ipv4.address_object:
Type: object Flags: -noneDescription: Assign an FQDN address object to group.
address_group.ipv4.address_object.ipv4:
Type: array Flags: -noneDescription: IPV4 address object.
address_group.ipv4.address_object.ipv4.name:
Type: string Flags: -noneDescription: Host/network/range address object name.
address_group.ipv4.address_object.mac:
Type: array Flags: -noneDescription: MAC address object.
address_group.ipv4.address_object.mac.name:
Type: string Flags: -noneDescription: MAC address object name.
address_group.ipv4.address_object.fqdn:
Type: array Flags: -noneDescription: FQDN address object.
address_group.ipv4.address_object.fqdn.name:
Type: string Flags: -noneDescription: FQDN address object name.
SonicWall® SonicOS API 6.5.4 Reference API: Address Groups -- IPv4
53
10
API: Address Groups -- IPv6
· Endpoint on page 54 · Schema Structure on page 54
· Object: Address Group on page 54 · Collection: Address Group on page 55 · Schema Attributes on page 56
Endpoint
Endpoint GET
URI: /api/sonicos/address-groups/ipv6
Empty
Schema: collection#address-group-ipv6-config
URI: /api/sonicos/address-groups/ipv6/name/{NAME} Empty
Schema: object#address-group-ipv6-config
URI: /api/sonicos/address-groups/ipv6/uuid/{UUID} Empty
Schema: object#address-group-ipv6-config
HTTP method and body
POST PUT
DELETE
Required Required Required
--
Required If deleting
member(s)
--
Required If deleting
member(s)
Schema Structure
Topics:
· Object: Address Group on page 54 · Collection: Address Group on page 55 · Schema Attributes on page 56
Object: Address Group
{ "ipv6": {
"name": "{string}", "uuid": "{string}",
"address_group": { "ipv4": [ { "name": "{string}" },
SonicWall® SonicOS API 6.5.4 Reference API: Address Groups -- IPv6
54
... ],
"ipv6": [ { "name": "{string}" },
... ] },
"address_object": { "ipv4": [ { "name": "{string}" },
... ],
"ipv6": [ { "name": "{string}" },
... ],
"mac": [ { "name": "{string}" },
... ],
"fqdn": [ { "name": "{string}" },
... ] } } } }
Collection: Address Group
{ "address_objects": [ object#address-group-ipv6-config, ... ]
}
SonicWall® SonicOS API 6.5.4 Reference API: Address Groups -- IPv6
55
Schema Attributes
Topics:
· address_group: on page 56 · address_groups: on page 56 · address_group.ipv6: on page 56 · address_group.ipv6.name: on page 56 · address_group.ipv6.uuid: on page 56 · address_group.ipv6.address_group: on page 57 · address_group.ipv6.address_group.ipv4: on page 57 · address_group.ipv6.address_group.ipv4.name: on page 57 · address_group.ipv6.address_object.ipv6: on page 57 · address_group.ipv6.address_object.ipv6.name: on page 58 · address_group.ipv6.address_object.mac: on page 58 · address_group.ipv6.address_object.mac.name: on page 58 · address_group.ipv6.address_object.fqdn: on page 58 · address_group.ipv6.address_object.fqdn.name: on page 58
address_group:
Type: object Flags: -noneDescription: Address group.
address_groups:
Type: array Flags: -noneDescription: Address group collection.
address_group.ipv6:
Type: object Flags: key Description: IPV6 address group.
address_group.ipv6.name:
Type: string Flags: key Description: Group address object name.
address_group.ipv6.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
SonicWall® SonicOS API 6.5.4 Reference API: Address Groups -- IPv6
56
address_group.ipv6.address_group:
Type: object Flags: -noneDescription: Assign address group to group.
address_group.ipv6.address_group.ipv4:
Type: array Flags: -noneDescription: IPV4 address group.
address_group.ipv6.address_group.ipv4.name:
Type: string Flags: -noneDescription: Group address object name.
address_group.ipv6.address_group.ipv6:
Type: array Flags: -noneDescription: IPV6 address group.
address_group.ipv6.address_group.ipv6.name:
Type: string Flags: -noneDescription: Group address object name.
address_group.ipv6.address_object:
Type: object Flags: -noneDescription: Assign an IPV6 address object to group.
address_group.ipv6.address_object.ipv4:
Type: array Flags: -noneDescription: IPV4 address object.
address_group.ipv6.address_object.ipv4.name:
Type: string Flags: -noneDescription: Host/network/range address object name.
address_group.ipv6.address_object.ipv6:
Type: array Flags: -noneDescription: IPV6 address object.
SonicWall® SonicOS API 6.5.4 Reference API: Address Groups -- IPv6
57
address_group.ipv6.address_object.ipv6.name:
Type: string Flags: -noneDescription: Address object name.
address_group.ipv6.address_object.mac:
Type: array Flags: -noneDescription: MAC address object.
address_group.ipv6.address_object.mac.name:
Type: string Flags: -noneDescription: MAC address object name.
address_group.ipv6.address_object.fqdn:
Type: array Flags: -noneDescription: FQDN address object.
address_group.ipv6.address_object.fqdn.name:
Type: string Flags: -noneDescription: FQDN address object name.
SonicWall® SonicOS API 6.5.4 Reference API: Address Groups -- IPv6
58
11
API: Schedule Objects
· Endpoint on page 59 · Schema Structure on page 59
· Object: Schedule on page 59 · Collection: Schedule on page 60 · Schema Attributes on page 60
Endpoint
Endpoint
URI: /api/sonicos/schedules Schema: collection#schedule-config URI: /api/sonicos/schedules/name/{NAME} Schema: object#schedule-config URI: /api/sonicos/schedules/uuid/{UUID} Schema: object#schedule-config
Schema Structure
Topics:
· Object: Schedule on page 59 · Collection: Schedule on page 60 · Schema Attributes on page 60
Object: Schedule
{ "schedule": {
"name": "{string}", "uuid": "{string}",
"occurs": { "once": { "event": { "start": "{string}", "end": "{string}"
GET Empty
HTTP method and body
POST PUT
DELETE
Required Required Required
Empty --
Required Ignored
Empty --
Required Ignored
SonicWall® SonicOS API 6.5.4 Reference API: Schedule Objects
59
} }, | "recurring": {
"recurring": [ { "start": "{string}", "end": "{string}", "sun": {boolean}, "mon": {boolean}, "tue": {boolean}, "wed": {boolean}, "thu": {boolean}, "fri": {boolean}, "sat": {boolean} },
... ] }, | "mixed": { "event": {
"start": "{string}", "end": "{string}" },
"recurring": [ { "start": "{string}", "end": "{string}", "sun": {boolean}, "mon": {boolean}, "tue": {boolean}, "wed": {boolean}, "thu": {boolean}, "fri": {boolean}, "sat": {boolean} },
... ] } } } }
Collection: Schedule
{ "schedules": [ object#schedule-config, ... ]
}
Schema Attributes
Topics:
· schedule: on page 61
· schedules: on page 61
· schedule.name: on page 61
SonicWall® SonicOS API 6.5.4 Reference API: Schedule Objects
60
· schedule.uuid: on page 62 · schedule.occurs: on page 62 · schedule.occurs.once: on page 62 · schedule.occurs.once.event: on page 62 · schedule.occurs.once.event.start: on page 62 · schedule.occurs.recurring.recurring.end: on page 63 · schedule.occurs.recurring.recurring.mon: on page 63 · schedule.occurs.recurring.recurring.tue: on page 63 · schedule.occurs.recurring.recurring.wed: on page 63 · schedule.occurs.recurring.recurring.thu: on page 63 · schedule.occurs.recurring.recurring.fri: on page 63 · schedule.occurs.recurring.recurring.sat: on page 63 · schedule.occurs.mixed: on page 63 · schedule.occurs.mixed.event: on page 64 · schedule.occurs.mixed.event.start: on page 64 · schedule.occurs.mixed.event.end: on page 64 · schedule.occurs.mixed.recurring: on page 64 · schedule.occurs.mixed.recurring.start: on page 64 · schedule.occurs.mixed.recurring.end: on page 64 · schedule.occurs.mixed.recurring.sun: on page 64 · schedule.occurs.mixed.recurring.mon: on page 64 · schedule.occurs.mixed.recurring.tue: on page 64 · schedule.occurs.mixed.recurring.wed: on page 65 · schedule.occurs.mixed.recurring.thu: on page 65 · schedule.occurs.mixed.recurring.fri: on page 65 · schedule.occurs.mixed.recurring.sat: on page 65
schedule:
Type: object Flags: -noneDescription: Schedule object.
schedules:
Type: array Flags: -noneDescription: Schedule object collection.
schedule.name:
Type: string Flags: key Description:
SonicWall® SonicOS API 6.5.4 Reference API: Schedule Objects
61
schedule.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
schedule.occurs:
Type: object Flags: -noneDescription: Set schedule type.
schedule.occurs.once:
Type: object Flags: -noneDescription: Set for single occurrence.
schedule.occurs.once.event:
Type: object Flags: -noneDescription: Enter the start and end date and time of a one time event.
schedule.occurs.once.event.start:
Type: string (time yyyymmddhhmm) Flags: -noneDescription: Timestamp in the form: YYYY:MM:DD:HH:MM
schedule.occurs.once.event.end:
Type: string (time yyyymmddhhmm) Flags: -noneDescription: Timestamp in the form: YYYY:MM:DD:HH:MM
schedule.occurs.recurring:
Type: object Flags: -noneDescription: Set for recurring schedule.
schedule.occurs.recurring.recurring:
Type: array Flags: -noneDescription: Add to the list of applicable days and start and stop time of the schedule.
schedule.occurs.recurring.recurring.start:
Type: string (time hhmm) Flags: -noneDescription: Time in the form: DD:DD
SonicWall® SonicOS API 6.5.4 Reference API: Schedule Objects
62
schedule.occurs.recurring.recurring.end:
Type: string (time hhmm) Flags: -noneDescription: Time in the form: DD:DD
schedule.occurs.recurring.recurring.sun:
Type: boolean (true|false) Flags: -noneDescription: Day of the week.
schedule.occurs.recurring.recurring.mon:
Type: boolean (true|false) Flags: -noneDescription: Day of the week.
schedule.occurs.recurring.recurring.tue:
Type: boolean (true|false) Flags: -noneDescription: Day of the week.
schedule.occurs.recurring.recurring.wed:
Type: boolean (true|false) Flags: -noneDescription: Day of the week.
schedule.occurs.recurring.recurring.thu:
Type: boolean (true|false) Flags: -noneDescription: Day of the week.
schedule.occurs.recurring.recurring.fri:
Type: boolean (true|false) Flags: -noneDescription: Day of the week.
schedule.occurs.recurring.recurring.sat:
Type: boolean (true|false) Flags: -noneDescription: Day of the week.
schedule.occurs.mixed:
Type: object Flags: -noneDescription: Set for both recurring schedule and single occurrence.
SonicWall® SonicOS API 6.5.4 Reference API: Schedule Objects
63
schedule.occurs.mixed.event:
Type: object Flags: -noneDescription: Enter the start and end date and time of a one time event.
schedule.occurs.mixed.event.start:
Type: string (time yyyymmddhhmm) Flags: -noneDescription: Timestamp in the form: YYYY:MM:DD:HH:MM
schedule.occurs.mixed.event.end:
Type: string (time yyyymmddhhmm) Flags: -noneDescription: Timestamp in the form: YYYY:MM:DD:HH:MM
schedule.occurs.mixed.recurring:
Type: array Flags: -noneDescription: Add to the list of applicable days and start and stop time of the schedule.
schedule.occurs.mixed.recurring.start:
Type: string (time hhmm) Flags: -noneDescription: Time in the form: DD:DD
schedule.occurs.mixed.recurring.end:
Type: string (time hhmm) Flags: -noneDescription: Time in the form: DD:DD
schedule.occurs.mixed.recurring.sun:
Type: boolean (true|false) Flags: -noneDescription: Day of the week.
schedule.occurs.mixed.recurring.mon:
Type: boolean (true|false) Flags: -noneDescription: Day of the week.
schedule.occurs.mixed.recurring.tue:
Type: boolean (true|false) Flags: -noneDescription: Day of the week.
SonicWall® SonicOS API 6.5.4 Reference API: Schedule Objects
64
schedule.occurs.mixed.recurring.wed:
Type: boolean (true|false) Flags: -noneDescription: Day of the week.
schedule.occurs.mixed.recurring.thu:
Type: boolean (true|false) Flags: -noneDescription: Day of the week.
schedule.occurs.mixed.recurring.fri:
Type: boolean (true|false) Flags: -noneDescription: Day of the week.
schedule.occurs.mixed.recurring.sat:
Type: boolean (true|false) Flags: -noneDescription: Day of the week.
SonicWall® SonicOS API 6.5.4 Reference API: Schedule Objects
65
12
API: Service Objects
· Endpoint on page 66 · Schema Structure on page 66
· Object: Service Object on page 66 · Collection: Service Object on page 67 · Schema Attributes on page 67
Endpoint
Endpoint
URI: /api/sonicos/service-objects Schema: collection#service-object-config URI: /api/sonicos/service-objects/name/{NAME} Schema: object#service-object-config URI: /api/sonicos/service-objects/uuid/{UUID} Schema: object#service-object-config
GET Empty
HTTP method and body
POST PUT
DELETE
Required Required Required
Empty --
Required Ignored
Empty --
Required Ignored
Schema Structure
Topics:
· Object: Service Object on page 66 · Collection: Service Object on page 67 · Schema Attributes on page 67
Object: Service Object
{ "service_object": { "name": "{string}", "uuid": "{string}",
"custom": {number}, | "icmp": "{string}", | "igmp": "{string}", | "tcp": {
SonicWall® SonicOS API 6.5.4 Reference API: Service Objects
66
"begin": {number}, "end": {number} }, | "udp": { "begin": {number}, "end": {number} }, | "gre": {true}, | "esp": {true}, | "6over4": {true}, | "ah": {true}, | "icmpv6": "{string}", | "eigrp": {true}, | "ospf": "{string}", | "pim": "{string}", | "l2tp": {true}, | "ipcomp": {true} } }
collection#service-object-config {
"service_objects": [ object#service-object-config, ...
] }
Collection: Service Object
{ "service-objects": [ object#service-object-config, ... ]
}
Schema Attributes
Topics:
· service_object: on page 68
· service_objects: on page 68
· service_object.name: on page 68
· service_object.uuid: on page 68
· service_object.custom: on page 68
· service_object.icmp: on page 68
· service_object.igmp: on page 69
· service_object.tcp: on page 69
· service_object.tcp.begin: on page 69
· service_object.tcp.end: on page 69
· service_object.udp: on page 69
· service_object.udp.begin: on page 69
SonicWall® SonicOS API 6.5.4 Reference API: Service Objects
67
· service_object.udp.end: on page 69 · service_object.gre: on page 69 · service_object.esp: on page 69 · service_object.6over4: on page 70 · service_object.ah: on page 70 · service_object.icmpv6: on page 70 · service_object.eigrp: on page 70 · service_object.ospf: on page 70 · service_object.pim: on page 70 · service_object.l2tp: on page 70 · service_object.ipcomp: on page 70
service_object:
Type: object Flags: -noneDescription: Service object.
service_objects:
Type: array Flags: -noneDescription: Service object collection.
service_object.name:
Type: string Flags: key Description: Service object name.
service_object.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
service_object.custom:
Type: number (uint8) Flags: -noneDescription: Integer in the form: D OR 0xHH
service_object.icmp:
Type: string Flags: -noneDescription: Service object ICMP.
SonicWall® SonicOS API 6.5.4 Reference API: Service Objects
68
service_object.igmp:
Type: string Flags: -noneDescription: Service object IGMP.
service_object.tcp:
Type: object Flags: -noneDescription: Service object TCP.
service_object.tcp.begin:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
service_object.tcp.end:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
service_object.udp:
Type: object Flags: -noneDescription: Service object UDP.
service_object.udp.begin:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
service_object.udp.end:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
service_object.gre:
Type: boolean (true) Flags: -noneDescription: Service object GRE.
service_object.esp:
Type: boolean (true) Flags: -noneDescription: Service object ESP.
SonicWall® SonicOS API 6.5.4 Reference API: Service Objects
69
service_object.6over4:
Type: boolean (true) Flags: -noneDescription: Service object 6over4.
service_object.ah:
Type: boolean (true) Flags: -noneDescription: Service object AH.
service_object.icmpv6:
Type: string Flags: -noneDescription: Service object ICMPV6
service_object.eigrp:
Type: boolean (true) Flags: -noneDescription: Service object EIGRP.
service_object.ospf:
Type: string Flags: -noneDescription: Service object OSPF.
service_object.pim:
Type: string Flags: -noneDescription: Service object PIM.
service_object.l2tp:
Type: boolean (true) Flags: -noneDescription: Service object l2tp.
service_object.ipcomp:
Type: boolean (true) Flags: -noneDescription: Service object ipcomp.
SonicWall® SonicOS API 6.5.4 Reference API: Service Objects
70
13
API: Service Groups
· Endpoint on page 71 · Schema Structure on page 71
· Object: Service Group on page 71 · Collection: Service Group on page 72 · Schema Attributes on page 72
Endpoint
Endpoint
URI: /api/sonicos/service-groups Schema: collection#service-group-config URI: /api/sonicos/service-groups/name/{NAME} Schema: object#service-group-config URI: /api/sonicos/service-groups/uuid/{UUID} Schema: object#service-group-config
Schema Structure
Topics:
· Object: Service Group on page 71 · Collection: Service Group on page 72 · Schema Attributes on page 72
Object: Service Group
{ "service_group": { "name": "{string}", "uuid": "{string}",
"service_object": [ { "name": "{string}" },
GET Empty
HTTP method and body
POST PUT
DELETE
Required Required Required
Empty -- Empty --
Required If deleting member(s)
Required If deleting member(s)
SonicWall® SonicOS API 6.5.4 Reference API: Service Groups
71
... ],
"service_group": [ { "name": "{string}" },
... ] } }
Collection: Service Group
{ "service-groups": [ object#service-group-config, ... ]
}
Schema Attributes
Topics:
· service_group: on page 72 · service_groups: on page 72 · service_group.name: on page 72 · service_group.uuid: on page 73 · service_group.service_object: on page 73 · service_group.service_object.name: on page 73 · service_group.service_group: on page 73 · service_group.service_group.name: on page 73
service_group:
Type: object Flags: -noneDescription: Service group.
service_groups:
Type: array Flags: -noneDescription: Service group collection.
service_group.name:
Type: string Flags: key Description: Service object group name.
SonicWall® SonicOS API 6.5.4 Reference API: Service Groups
72
service_group.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
service_group.service_object:
Type: array Flags: -noneDescription: Assign service object to group.
service_group.service_object.name:
Type: string Flags: -noneDescription: Service object name.
service_group.service_group:
Type: array Flags: -noneDescription: Assign service group to group.
service_group.service_group.name:
Type: string Flags: -noneDescription: Service object group name.
SonicWall® SonicOS API 6.5.4 Reference API: Service Groups
73
· Endpoint on page 74 · Schema Structure on page 74
· Object: Zone on page 74 · Collection: Zone on page 76 · Schema Attributes on page 76
Endpoint
Endpoint
URI: /api/sonicos/zones Schema: collection#zone-config URI: /api/sonicos/zones/name/{NAME} Schema: object#zone-config URI: /api/sonicos/zones/uuid/{UUID} Schema: object#zone-config
Schema Structure
Topics:
· Object: Zone on page 74 · Collection: Zone on page 76 · Schema Attributes on page 76
Object: Zone
{ "zone": { "name": "{string}", "uuid": "{string}",
"security_type": "{string}", "interface_trust": {boolean},
"auto_generate_access_rules": { "allow_from_to_equal": {boolean},
14
API: Zones
GET Empty
HTTP method and body
POST PUT
DELETE
Required Required Required
Empty --
Required Ignored
Empty --
Required Ignored
SonicWall® SonicOS API 6.5.4 Reference API: Zones
74
"allow_from_higher": {boolean}, "allow_to_lower": {boolean}, "deny_from_lower": {boolean} },
"websense_content_filtering": {boolean},
"client": { "anti_virus": {boolean}, "content_filtering": {boolean}
},
"gateway_anti_virus": {boolean}, "intrusion_prevention": {boolean}, "app_control": {boolean}, "anti_spyware": {boolean}, "create_group_vpn": {boolean}, "ssl_control": {boolean}, "sslvpn_access": {boolean},
"wireless": { "sslvpn_enforcement": { "server": { "name": "{string}", | "host": "{string}" },
"service": { "name": "{string}",
| "protocol": { "name": "{string}", "begin": {number}, "end": {number}
} } },
"wifi_sec_enforcement": { "exception_service": { "name": "{string}",
| "protocol": { "name": "{string}", "begin": {number}, "end": {number}
} } },
"wifi_sec_for_site_to_site_vpn": {boolean}, "trust_wpa_traffic_as_wifi_sec": {boolean}, "only_sonicpoint_traffic": {boolean} },
"guest_services": { "inter_guest": {boolean},
"bypass": { "client": { "anti_virus": {boolean}, "content_filtering": {boolean} }
},
"external_auth": { "client_redirect": "{string}",
SonicWall® SonicOS API 6.5.4 Reference API: Zones
75
"web_server": { "protocol": "{string}", "name": "{string}", "port": {number}, "timeout": {number}
},
"message_auth": { "method": "{string}", "shared_secret": "{string}", "confirm_secret": "{string}"
},
"social_network": { "facebook": {boolean}, "google": {boolean}, "twitter": {boolean}
},
"auth_pages": { "login": "{string}", "expiration": "{string}", "timeout": "{string}", "max_sessions": "{string}", "traffic_exceeded": "{string}"
},
"web_content": { "redirect": { "use_default": {true}, | "custom": "{string}" },
"server_down": { "use_default": {true},
| "custom": "{string}" } }
Collection: Zone
{ "zones": [ object#zone-config, ... ]
}
Schema Attributes
Topics:
· zone: on page 80
· zones: on page 80
· zone.name: on page 81
· zone.uuid: on page 81
· zone.security_type: on page 81
SonicWall® SonicOS API 6.5.4 Reference API: Zones
76
· zone.interface_trust: on page 81 · zone.auto_generate_access_rules: on page 81 · zone.auto_generate_access_rules.allow_from_to_equal: on page 81 · zone.auto_generate_access_rules.allow_from_higher: on page 81 · zone.auto_generate_access_rules.allow_to_lower: on page 81 · zone.auto_generate_access_rules.deny_from_lower: on page 81 · zone.websense_content_filtering: on page 82 · zone.client: on page 82 · zone.client.anti_virus: on page 82 · zone.client.content_filtering: on page 82 · zone.gateway_anti_virus: on page 82 · zone.intrusion_prevention: on page 82 · zone.app_control: on page 82 · zone.anti_spyware: on page 82 · zone.create_group_vpn: on page 82 · zone.ssl_control: on page 83 · zone.sslvpn_access: on page 83 · zone.wireless: on page 83 · zone.wireless.sslvpn_enforcement: on page 83 · zone.wireless.sslvpn_enforcement.server: on page 83 · zone.wireless.sslvpn_enforcement.server.name: on page 83 · zone.wireless.sslvpn_enforcement.server.host: on page 83 · zone.wireless.sslvpn_enforcement.service: on page 83 · zone.wireless.sslvpn_enforcement.service.name: on page 83 · zone.wireless.sslvpn_enforcement.service.protocol: on page 84 · zone.wireless.sslvpn_enforcement.service.protocol.name: on page 84 · zone.wireless.sslvpn_enforcement.service.protocol.begin: on page 84 · zone.wireless.sslvpn_enforcement.service.protocol.end: on page 84 · zone.wireless.wifi_sec_enforcement: on page 84 · zone.wireless.wifi_sec_enforcement.exception_service: on page 84 · zone.wireless.wifi_sec_enforcement.exception_service.name: on page 84 · zone.wireless.wifi_sec_enforcement.exception_service.protocol: on page 84 · zone.wireless.wifi_sec_enforcement.exception_service.protocol.name: on page 84 · zone.wireless.wifi_sec_enforcement.exception_service.protocol.begin: on page 85 · zone.wireless.wifi_sec_enforcement.exception_service.protocol.end: on page 85 · zone.wireless.wifi_sec_for_site_to_site_vpn: on page 85 · zone.wireless.trust_wpa_traffic_as_wifi_sec: on page 85
SonicWall® SonicOS API 6.5.4 Reference API: Zones
77
· zone.wireless.only_sonicpoint_traffic: on page 85 · zone.guest_services: on page 85 · zone.guest_services.inter_guest: on page 85 · zone.guest_services.bypass: on page 85 · zone.guest_services.bypass.client: on page 85 · zone.guest_services.bypass.client.anti_virus: on page 86 · zone.guest_services.bypass.client.content_filtering: on page 86 · zone.guest_services.external_auth: on page 86 · zone.guest_services.external_auth.client_redirect: on page 86 · zone.guest_services.external_auth.web_server: on page 86 · zone.guest_services.external_auth.web_server.protocol: on page 86 · zone.guest_services.external_auth.web_server.name: on page 86 · zone.guest_services.external_auth.web_server.port: on page 86 · zone.guest_services.external_auth.web_server.timeout: on page 86 · zone.guest_services.external_auth.message_auth: on page 87 · zone.guest_services.external_auth.message_auth.method: on page 87 · zone.guest_services.external_auth.message_auth.shared_secret: on page 87 · zone.guest_services.external_auth.message_auth.confirm_secret: on page 87 · zone.guest_services.external_auth.social_network: on page 87 · zone.guest_services.external_auth.social_network.facebook: on page 87 · zone.guest_services.external_auth.social_network.google: on page 87 · zone.guest_services.external_auth.social_network.twitter: on page 87 · zone.guest_services.external_auth.auth_pages: on page 88 · zone.guest_services.external_auth.auth_pages.login: on page 88 · zone.guest_services.external_auth.auth_pages.expiration: on page 88 · zone.guest_services.external_auth.auth_pages.timeout: on page 88 · zone.guest_services.external_auth.auth_pages.max_sessions: on page 88 · zone.guest_services.external_auth.auth_pages.traffic_exceeded: on page 88 · zone.guest_services.external_auth.web_content: on page 88 · zone.guest_services.external_auth.web_content.redirect: on page 88 · zone.guest_services.external_auth.web_content.redirect.use_default: on page 88 · zone.guest_services.external_auth.web_content.redirect.custom: on page 89 · zone.guest_services.external_auth.web_content.server_down: on page 89 · zone.guest_services.external_auth.web_content.server_down.use_default: on page 89 · zone.guest_services.external_auth.web_content.server_down.custom: on page 89 · zone.guest_services.external_auth.logout_expired: on page 89 · zone.guest_services.external_auth.logout_expired.every: on page 89
SonicWall® SonicOS API 6.5.4 Reference API: Zones
78
· zone.guest_services.external_auth.logout_expired.cgi: on page 89 · zone.guest_services.external_auth.status_check: on page 89 · zone.guest_services.external_auth.status_check.every: on page 89 · zone.guest_services.external_auth.status_check.cgi: on page 90 · zone.guest_services.external_auth.session_sync: on page 90 · zone.guest_services.external_auth.session_sync.every: on page 90 · zone.guest_services.external_auth.session_sync.cgi: on page 90 · zone.guest_services.policy_page_non_authentication: on page 90 · zone.guest_services.policy_page_non_authentication.guest_usage_policy: on page 90 · zone.guest_services.custom_auth_page: on page 90 · zone.guest_services.custom_auth_page.header: on page 90 · zone.guest_services.custom_auth_page.header.text: on page 90 · zone.guest_services.custom_auth_page.header.url: on page 91 · zone.guest_services.custom_auth_page.footer: on page 91 · zone.guest_services.custom_auth_page.footer.text: on page 91 · zone.guest_services.custom_auth_page.footer.url: on page 91 · zone.guest_services.post_auth: on page 91 · zone.guest_services.bypass_guest_auth: on page 91 · zone.guest_services.bypass_guest_auth.all: on page 91 · zone.guest_services.bypass_guest_auth.name: on page 91 · zone.guest_services.bypass_guest_auth.group: on page 91 · zone.guest_services.bypass_guest_auth.mac: on page 92 · zone.guest_services.smtp_redirect: on page 92 · zone.guest_services.smtp_redirect.name: on page 92 · zone.guest_services.smtp_redirect.host: on page 92 · zone.guest_services.deny_networks: on page 92 · zone.guest_services.deny_networks.name: on page 92 · zone.guest_services.deny_networks.group: on page 92 · zone.guest_services.deny_networks.mac: on page 92 · zone.guest_services.deny_networks.fqdn: on page 92 · zone.guest_services.deny_networks.host: on page 93 · zone.guest_services.deny_networks.range: on page 93 · zone.guest_services.deny_networks.range.begin: on page 93 · zone.guest_services.deny_networks.range.end: on page 93 · zone.guest_services.deny_networks.network: on page 93 · zone.guest_services.deny_networks.network.subnet: on page 93 · zone.guest_services.deny_networks.network.mask: on page 93
SonicWall® SonicOS API 6.5.4 Reference API: Zones
79
· zone.guest_services.deny_networks.ipv6: on page 93 · zone.guest_services.deny_networks.ipv6.host: on page 93 · zone.guest_services.deny_networks.ipv6.range: on page 94 · zone.guest_services.deny_networks.ipv6.range.begin: on page 94 · zone.guest_services.deny_networks.ipv6.range.end: on page 94 · zone.guest_services.deny_networks.ipv6.network: on page 94 · zone.guest_services.deny_networks.ipv6.network.subnet: on page 94 · zone.guest_services.deny_networks.ipv6.network.mask: on page 94 · zone.guest_services.pass_networks: on page 94 · zone.guest_services.pass_networks.name: on page 94 · zone.guest_services.pass_networks.group: on page 94 · zone.guest_services.pass_networks.mac: on page 95 · zone.guest_services.pass_networks.fqdn: on page 95 · zone.guest_services.pass_networks.host: on page 95 · zone.guest_services.pass_networks.range: on page 95 · zone.guest_services.pass_networks.range.begin: on page 95 · zone.guest_services.pass_networks.range.end: on page 95 · zone.guest_services.pass_networks.network: on page 95 · zone.guest_services.pass_networks.network.subnet: on page 95 · zone.guest_services.pass_networks.network.mask: on page 95 · zone.guest_services.pass_networks.ipv6: on page 96 · zone.guest_services.pass_networks.ipv6.host: on page 96 · zone.guest_services.pass_networks.ipv6.range: on page 96 · zone.guest_services.pass_networks.ipv6.range.begin: on page 96 · zone.guest_services.pass_networks.ipv6.range.end: on page 96 · zone.guest_services.pass_networks.ipv6.network: on page 96 · zone.guest_services.pass_networks.ipv6.network.subnet: on page 96 · zone.guest_services.pass_networks.ipv6.network.mask: on page 96 · zone.guest_services.max_guests: on page 96 · zone.guest_services.dynamic_address_translation: on page 97
zone:
Type: object Flags: -noneDescription: Zone object.
zones:
Type: array Flags: -noneDescription: Zone object collection.
SonicWall® SonicOS API 6.5.4 Reference API: Zones
80
zone.name:
Type: string Flags: key Description: Zone object name.
zone.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
zone.security_type:
Type: string Flags: -noneDescription: Set zone security type.
zone.interface_trust:
Type: boolean (true|false) Flags: -noneDescription: Enable allow interface trust.
zone.auto_generate_access_rules:
Type: object Flags: -noneDescription: Enable auto generate access rules.
zone.auto_generate_access_rules.allow_from_to_equal:
Type: boolean (true|false) Flags: -noneDescription: Allow traffic between zones with the same trust level.
zone.auto_generate_access_rules.allow_from_higher:
Type: boolean (true|false) Flags: -noneDescription: Allow traffic from zones with higher trust level.
zone.auto_generate_access_rules.allow_to_lower:
Type: boolean (true|false) Flags: -noneDescription: Allow traffic to zones with lower trust level.
zone.auto_generate_access_rules.deny_from_lower:
Type: boolean (true|false) Flags: -noneDescription: Deny traffic from zones with lower trust level.
SonicWall® SonicOS API 6.5.4 Reference API: Zones
81
zone.websense_content_filtering:
Type: boolean (true|false) Flags: -noneDescription: Enable enforce websense enterprise content filtering service.
zone.client:
Type: object Flags: -noneDescription: Client settings
zone.client.anti_virus:
Type: boolean (true|false) Flags: -noneDescription: Enable client anti-virus enforcement service.
zone.client.content_filtering:
Type: boolean (true|false) Flags: -noneDescription: Enable client content filtering services enforcement service.
zone.gateway_anti_virus:
Type: boolean (true|false) Flags: -noneDescription: Enable gateway anti-virus service.
zone.intrusion_prevention:
Type: boolean (true|false) Flags: -noneDescription: Enable intrusion prevention service.
zone.app_control:
Type: boolean (true|false) Flags: -noneDescription: Enable app control service.
zone.anti_spyware:
Type: boolean (true|false) Flags: -noneDescription: Enable anti-spyware service.
zone.create_group_vpn:
Type: boolean (true|false) Flags: -noneDescription: Enable automatic creation of group VPN for this zone.
SonicWall® SonicOS API 6.5.4 Reference API: Zones
82
zone.ssl_control:
Type: boolean (true|false) Flags: -noneDescription: Enable SSL-Control on this zone.
zone.sslvpn_access:
Type: boolean (true|false) Flags: -noneDescription: Enable SSL-VPN access this zone.
zone.wireless:
Type: object Flags: -noneDescription: Enter wireless zone configuration mode.
zone.wireless.sslvpn_enforcement:
Type: object Flags: -noneDescription: Enable SSLVPN enforcement. Set to null or {} if disabled/unconfigured.
zone.wireless.sslvpn_enforcement.server:
Type: object Flags: -noneDescription: Set the SSLVPN server as a named address object.
zone.wireless.sslvpn_enforcement.server.name:
Type: string Flags: -noneDescription: Host address object name.
zone.wireless.sslvpn_enforcement.server.host:
Type: string (ip) Flags: -noneDescription: IPv4 host address in the form: D.D.D.D. IPv6 host address in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.wireless.sslvpn_enforcement.service:
Type: object Flags: -noneDescription: Set the SSLVPN service as a named service object.
zone.wireless.sslvpn_enforcement.service.name:
Type: string Flags: -noneDescription: Service object name.
SonicWall® SonicOS API 6.5.4 Reference API: Zones
83
zone.wireless.sslvpn_enforcement.service.protocol:
Type: object Flags: -noneDescription: Set the SSLVPN service as a protocol.
zone.wireless.sslvpn_enforcement.service.protocol.name:
Type: string Flags: -noneDescription: Service protocol.
zone.wireless.sslvpn_enforcement.service.protocol.begin:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
zone.wireless.sslvpn_enforcement.service.protocol.end:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
zone.wireless.wifi_sec_enforcement:
Type: object Flags: -noneDescription: Enable WiFiSec enforcement.
zone.wireless.wifi_sec_enforcement.exception_service:
Type: object Flags: -noneDescription: Specify services that are allowed to bypass wifisec enforcement.
zone.wireless.wifi_sec_enforcement.exception_service.na me:
Type: string Flags: -noneDescription: Service object name.
zone.wireless.wifi_sec_enforcement.exception_service.pr otocol:
Type: object Flags: -noneDescription: Set the WiFiSec exception service as a protocol.
zone.wireless.wifi_sec_enforcement.exception_service.pr otocol.name:
Type: string Flags: -noneDescription: Service protocol.
SonicWall® SonicOS API 6.5.4 Reference API: Zones
84
zone.wireless.wifi_sec_enforcement.exception_service.pr otocol.begin:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
zone.wireless.wifi_sec_enforcement.exception_service.pr otocol.end:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
zone.wireless.wifi_sec_for_site_to_site_vpn:
Type: boolean (true|false) Flags: -noneDescription: Enable WiFiSec for site-to-site VPN tunnel traversal.
zone.wireless.trust_wpa_traffic_as_wifi_sec:
Type: boolean (true|false) Flags: -noneDescription: Trust WPA / WPA2 traffic as WiFiSec.
zone.wireless.only_sonicpoint_traffic:
Type: boolean (true|false) Flags: -noneDescription: Enable only allow traffic generated by a SonicPoint/SonicPointN.
zone.guest_services:
Type: object Flags: -noneDescription: Enable zone guest services and enter configuration mode. Set to null or {} if disabled/unconfigured.
zone.guest_services.inter_guest:
Type: boolean (true|false) Flags: -noneDescription: Enable inter-guest communication.
zone.guest_services.bypass:
Type: object Flags: -noneDescription: Enable bypass check for guest clients.
zone.guest_services.bypass.client:
Type: object Flags: -noneDescription: Enable bypass check for guest clients.
SonicWall® SonicOS API 6.5.4 Reference API: Zones
85
zone.guest_services.bypass.client.anti_virus:
Type: boolean (true|false) Flags: -noneDescription: Enable bypass anti-virus check for guests.
zone.guest_services.bypass.client.content_filtering:
Type: boolean (true|false) Flags: -noneDescription: Enable bypass client content filtering check for guests.
zone.guest_services.external_auth:
Type: object Flags: -noneDescription: Enable external guest authentication and enter its configuration mode. Set to null or {} if disabled/unconfigured.
zone.guest_services.external_auth.client_redirect:
Type: string Flags: -noneDescription: Set local web server settings for client redirect.
zone.guest_services.external_auth.web_server:
Type: object Flags: -noneDescription: Configure the external web server settings.
zone.guest_services.external_auth.web_server.protocol:
Type: string Flags: -noneDescription: Configure the external web server protocol.
zone.guest_services.external_auth.web_server.name:
Type: string Flags: -noneDescription: FQDN/host address object name.
zone.guest_services.external_auth.web_server.port:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
zone.guest_services.external_auth.web_server.timeout:
Type: number (uint8) Flags: -noneDescription: Integer in the form: D OR 0xHH
SonicWall® SonicOS API 6.5.4 Reference API: Zones
86
zone.guest_services.external_auth.message_auth:
Type: object Flags: -noneDescription: Enable external message authentication.
zone.guest_services.external_auth.message_auth.method :
Type: string Flags: -noneDescription: Set external message authentication method.
zone.guest_services.external_auth.message_auth.shared_ secret:
Type: string Flags: -noneDescription:
zone.guest_services.external_auth.message_auth.confirm _secret:
Type: string Flags: -noneDescription:
zone.guest_services.external_auth.social_network:
Type: object Flags: -noneDescription: Enable social network login.
zone.guest_services.external_auth.social_network.facebo ok:
Type: boolean (true|false) Flags: -noneDescription: Enable Facebook social network login.
zone.guest_services.external_auth.social_network.google :
Type: boolean (true|false) Flags: -noneDescription: Enable Google social network login.
zone.guest_services.external_auth.social_network.twitter :
Type: boolean (true|false) Flags: -noneDescription: Enable Twitter social network login.
SonicWall® SonicOS API 6.5.4 Reference API: Zones
87
zone.guest_services.external_auth.auth_pages:
Type: object Flags: -noneDescription: Configure the external authentication pages.
zone.guest_services.external_auth.auth_pages.login:
Type: string Flags: -noneDescription:
zone.guest_services.external_auth.auth_pages.expiration:
Type: string Flags: -noneDescription:
zone.guest_services.external_auth.auth_pages.timeout:
Type: string Flags: -noneDescription:
zone.guest_services.external_auth.auth_pages.max_sessi ons:
Type: string Flags: -noneDescription:
zone.guest_services.external_auth.auth_pages.traffic_exc eeded:
Type: string Flags: -noneDescription:
zone.guest_services.external_auth.web_content:
Type: object Flags: -noneDescription: Configure the Web content messages.
zone.guest_services.external_auth.web_content.redirect:
Type: object Flags: -noneDescription: Configure the Web content redirect message.
zone.guest_services.external_auth.web_content.redirect. use_default:
Type: boolean (true) Flags: -noneDescription: Use the default Web content redirect message.
SonicWall® SonicOS API 6.5.4 Reference API: Zones
88
zone.guest_services.external_auth.web_content.redirect.c ustom:
Type: string Flags: -noneDescription:
zone.guest_services.external_auth.web_content.server_d own:
Type: object Flags: -noneDescription: Configure the Web content server down message.
zone.guest_services.external_auth.web_content.server_d own.use_default:
Type: boolean (true) Flags: -noneDescription: Use the default Web content server down message.
zone.guest_services.external_auth.web_content.server_d own.custom:
Type: string Flags: -noneDescription:
zone.guest_services.external_auth.logout_expired:
Type: object Flags: -noneDescription: Enable auto-session logout.
zone.guest_services.external_auth.logout_expired.every:
Type: number (uint8) Flags: -noneDescription: Integer in the form: D OR 0xHH
zone.guest_services.external_auth.logout_expired.cgi:
Type: string Flags: -noneDescription:
zone.guest_services.external_auth.status_check:
Type: object Flags: -noneDescription: Enable server status check.
zone.guest_services.external_auth.status_check.every:
Type: number (uint8)
SonicWall® SonicOS API 6.5.4 Reference API: Zones
89
Flags: -noneDescription: Integer in the form: D OR 0xHH
zone.guest_services.external_auth.status_check.cgi:
Type: string Flags: -noneDescription:
zone.guest_services.external_auth.session_sync:
Type: object Flags: -noneDescription: Enable session synchronization.
zone.guest_services.external_auth.session_sync.every:
Type: number (uint8) Flags: -noneDescription: Integer in the form: D OR 0xHH
zone.guest_services.external_auth.session_sync.cgi:
Type: string Flags: -noneDescription:
zone.guest_services.policy_page_non_authentication:
Type: object Flags: -noneDescription: Enable policy page without authentication and enter its configuration mode. Set to null or {} if disabled/unconfigured.
zone.guest_services.policy_page_non_authentication.gue st_usage_policy:
Type: string Flags: -noneDescription:
zone.guest_services.custom_auth_page:
Type: object Flags: -noneDescription: Enable custom authentication page and enter its configuration mode. Set to null or {} if disabled/unconfigured.
zone.guest_services.custom_auth_page.header:
Type: object Flags: -noneDescription: Configure custom page header.
zone.guest_services.custom_auth_page.header.text:
Type: string
SonicWall® SonicOS API 6.5.4 Reference API: Zones
90
Flags: -noneDescription:
zone.guest_services.custom_auth_page.header.url:
Type: string (web url) Flags: -noneDescription: URL in the form: http://host/file
zone.guest_services.custom_auth_page.footer:
Type: object Flags: -noneDescription: Configure custom login page footer.
zone.guest_services.custom_auth_page.footer.text:
Type: string Flags: -noneDescription:
zone.guest_services.custom_auth_page.footer.url:
Type: string (web url) Flags: -noneDescription: URL in the form: http://host/file
zone.guest_services.post_auth:
Type: string (web url) Flags: -noneDescription: URL in the form: http://host/file
zone.guest_services.bypass_guest_auth:
Type: object Flags: -noneDescription: Enable bypass guest authentication. Set to null or {} if disabled/unconfigured.
zone.guest_services.bypass_guest_auth.all:
Type: boolean (true) Flags: -noneDescription: All MAC addresses.
zone.guest_services.bypass_guest_auth.name:
Type: string Flags: -noneDescription: MAC address object name.
zone.guest_services.bypass_guest_auth.group:
Type: string Flags: -noneDescription: MAC group address object name.
SonicWall® SonicOS API 6.5.4 Reference API: Zones
91
zone.guest_services.bypass_guest_auth.mac:
Type: string (mac) Flags: -noneDescription: Address object MAC address in the form: HH:HH:HH:HH:HH:HH or HHHHHHHHHHHH or HH-HH-HH-HH-HH-HH.
zone.guest_services.smtp_redirect:
Type: object Flags: -noneDescription: Redirect SMTP traffic to specified server. Set to null or {} if disabled/unconfigured.
zone.guest_services.smtp_redirect.name:
Type: string Flags: -noneDescription: Host address object name.
zone.guest_services.smtp_redirect.host:
Type: string (ip) Flags: -noneDescription: IPv4 host address in the form: D.D.D.D. IPv6 host address in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.guest_services.deny_networks:
Type: object Flags: -noneDescription: Enable blocking of traffic to the named network.
zone.guest_services.deny_networks.name:
Type: string Flags: -noneDescription: Address object name.
zone.guest_services.deny_networks.group:
Type: string Flags: -noneDescription: Group address object name.
zone.guest_services.deny_networks.mac:
Type: string (mac) Flags: -noneDescription: Address object MAC address in the form: HH:HH:HH:HH:HH:HH or HHHHHHHHHHHH or HH-HH-HH-HH-HH-HH.
zone.guest_services.deny_networks.fqdn:
Type: string (fqdn) Flags: -noneDescription: FQDN in the form: example.com or *.example.com.
SonicWall® SonicOS API 6.5.4 Reference API: Zones
92
zone.guest_services.deny_networks.host:
Type: string (ip) Flags: -noneDescription: IPv4 host address in the form: D.D.D.D. IPv6 host address in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.guest_services.deny_networks.range:
Type: object Flags: -noneDescription: Set the denied networks to range of addresses.
zone.guest_services.deny_networks.range.begin:
Type: string (ip) Flags: -noneDescription: IPv4 starting range in the form: D.D.D.D. IPv6 starting range in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.guest_services.deny_networks.range.end:
Type: string (ip) Flags: -noneDescription: IPv4 ending range in the form: D.D.D.D. IPv6 ending range in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.guest_services.deny_networks.network:
Type: object Flags: -noneDescription: Set the denied networks to network address.
zone.guest_services.deny_networks.network.subnet:
Type: string (ip) Flags: -noneDescription: IPv4 network in the form: D.D.D.D. IPv6 network in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.guest_services.deny_networks.network.mask:
Type: string (subnet) Flags: -noneDescription: IPv4 netmask in decimal dotted or CIDR form: D.D.D.D OR /D. IPv6 netmask in the form: /D.
zone.guest_services.deny_networks.ipv6:
Type: object Flags: -noneDescription: IPv6 address object.
zone.guest_services.deny_networks.ipv6.host:
Type: string (ip) Flags: -noneDescription: IPv4 host address in the form: D.D.D.D. IPv6 host address in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
SonicWall® SonicOS API 6.5.4 Reference API: Zones
93
zone.guest_services.deny_networks.ipv6.range:
Type: object Flags: -noneDescription: Set the denied networks to range of addresses.
zone.guest_services.deny_networks.ipv6.range.begin:
Type: string (ip) Flags: -noneDescription: IPv4 starting range in the form: D.D.D.D. IPv6 starting range in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.guest_services.deny_networks.ipv6.range.end:
Type: string (ip) Flags: -noneDescription: IPv4 ending range in the form: D.D.D.D. IPv6 ending range in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.guest_services.deny_networks.ipv6.network:
Type: object Flags: -noneDescription: Set the denied networks to network address.
zone.guest_services.deny_networks.ipv6.network.subnet:
Type: string (ip) Flags: -noneDescription: IPv4 network in the form: D.D.D.D. IPv6 network in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.guest_services.deny_networks.ipv6.network.mask:
Type: string (subnet) Flags: -noneDescription: IPv4 netmask in decimal dotted or CIDR form: D.D.D.D OR /D. IPv6 netmask in the form: /D.
zone.guest_services.pass_networks:
Type: object Flags: -noneDescription: Enable allowing of traffic to the named network.
zone.guest_services.pass_networks.name:
Type: string Flags: -noneDescription: Address object name.
zone.guest_services.pass_networks.group:
Type: string Flags: -noneDescription: Group address object name.
SonicWall® SonicOS API 6.5.4 Reference API: Zones
94
zone.guest_services.pass_networks.mac:
Type: string (mac) Flags: -noneDescription: Address object MAC address in the form: HH:HH:HH:HH:HH:HH or HHHHHHHHHHHH or HH-HH-HH-HH-HH-HH.
zone.guest_services.pass_networks.fqdn:
Type: string (fqdn) Flags: -noneDescription: FQDN in the form: example.com or *.example.com.
zone.guest_services.pass_networks.host:
Type: string (ip) Flags: -noneDescription: IPv4 host address in the form: D.D.D.D. IPv6 host address in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.guest_services.pass_networks.range:
Type: object Flags: -noneDescription: Set the pass networks to range of addresses.
zone.guest_services.pass_networks.range.begin:
Type: string (ip) Flags: -noneDescription: IPv4 starting range in the form: D.D.D.D. IPv6 starting range in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.guest_services.pass_networks.range.end:
Type: string (ip) Flags: -noneDescription: IPv4 ending range in the form: D.D.D.D. IPv6 ending range in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.guest_services.pass_networks.network:
Type: object Flags: -noneDescription: Set the pass networks to network address.
zone.guest_services.pass_networks.network.subnet:
Type: string (ip) Flags: -noneDescription: IPv4 network in the form: D.D.D.D. IPv6 network in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.guest_services.pass_networks.network.mask:
Type: string (subnet) Flags: -noneDescription: IPv4 netmask in decimal dotted or CIDR form: D.D.D.D OR /D. IPv6 netmask in the form: /D.
SonicWall® SonicOS API 6.5.4 Reference API: Zones
95
zone.guest_services.pass_networks.ipv6:
Type: object Flags: -noneDescription: IPv6 address object.
zone.guest_services.pass_networks.ipv6.host:
Type: string (ip) Flags: -noneDescription: IPv4 host address in the form: D.D.D.D. IPv6 host address in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.guest_services.pass_networks.ipv6.range:
Type: object Flags: -noneDescription: Set the pass networks to range of addresses.
zone.guest_services.pass_networks.ipv6.range.begin:
Type: string (ip) Flags: -noneDescription: IPv4 starting range in the form: D.D.D.D. IPv6 starting range in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.guest_services.pass_networks.ipv6.range.end:
Type: string (ip) Flags: -noneDescription: IPv4 ending range in the form: D.D.D.D. IPv6 ending range in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.guest_services.pass_networks.ipv6.network:
Type: object Flags: -noneDescription: Set the pass networks to network address.
zone.guest_services.pass_networks.ipv6.network.subnet:
Type: string (ip) Flags: -noneDescription: IPv4 network in the form: D.D.D.D. IPv6 network in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
zone.guest_services.pass_networks.ipv6.network.mask:
Type: string (subnet) Flags: -noneDescription: IPv4 netmask in decimal dotted or CIDR form: D.D.D.D OR /D. IPv6 netmask in the form: /D.
zone.guest_services.max_guests:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
SonicWall® SonicOS API 6.5.4 Reference API: Zones
96
zone.guest_services.dynamic_address_translation:
Type: boolean (true|false) Flags: -noneDescription: Enable dynamic address translation.
SonicWall® SonicOS API 6.5.4 Reference API: Zones
97
· Endpoint on page 98 · Schema Structure on page 98
· Object: DNS on page 98 · Schema Attributes on page 99
Endpoint
Endpoint
URI: /api/sonicos/dns Schema: collection#dns-config
Schema Structure
Topics:
· Object: DNS on page 98 · Schema Attributes on page 99
Object: DNS
{ "dns": { "server": { "inherit": {true}, | "static": { "primary": "{string}", "secondary": "{string}", "tertiary": "{string}" }
"ipv6": { "preferred": {boolean},
"inherit": {true}, | "static": {
"primary": "{string}", "secondary": "{string}", "tertiary": "{string}" }
15
API: DNS
GET Empty
HTTP method and body
POST PUT
DELETE
--
Required --
SonicWall® SonicOS API 6.5.4 Reference API: DNS
98
} },
"rebinding": { "action": "{string}",
"allowed_domains": { "name": "{string}",
| "group": "{string}" } },
"fqdn_binding": {boolean} } }
Schema Attributes
Topics:
· dns: on page 99 · dns.server: on page 100 · dns.server.inherit: on page 100 · dns.server.static: on page 100 · dns.server.static.primary: on page 100 · dns.server.static.secondary: on page 100 · dns.server.static.tertiary: on page 100 · dns.server.ipv6: on page 100 · dns.server.ipv6.preferred: on page 100 · dns.server.ipv6.inherit: on page 100 · dns.server.ipv6.static: on page 101 · dns.server.ipv6.static.primary: on page 101 · dns.server.ipv6.static.secondary: on page 101 · dns.server.ipv6.static.tertiary: on page 101 · dns.rebinding: on page 101 · dns.rebinding.action: on page 101 · dns.rebinding.allowed_domains: on page 101 · dns.rebinding.allowed_domains.name: on page 102 · dns.rebinding.allowed_domains.group: on page 102 · dns.fqdn_binding: on page 102
dns:
Type: object Flags: -noneDescription: DNS configuration.
SonicWall® SonicOS API 6.5.4 Reference API: DNS
99
dns.server:
Type: object Flags: -noneDescription: DNS server configuration.
dns.server.inherit:
Type: boolean (true) Flags: -noneDescription: Inherit DNS servers.
dns.server.static:
Type: object Flags: -noneDescription: Set static DNS server
dns.server.static.primary:
Type: string (ip) Flags: -noneDescription: IPv4 host address in the form: D.D.D.D
dns.server.static.secondary:
Type: string (ip) Flags: -noneDescription: IPv4 host address in the form: D.D.D.D
dns.server.static.tertiary:
Type: string (ip) Flags: -noneDescription: IPv4 host address in the form: D.D.D.D
dns.server.ipv6:
Type: object Flags: -noneDescription: Set IPv6 DNS server
dns.server.ipv6.preferred:
Type: boolean Flags: -noneDescription: Prefer IPv6 DNS servers.
dns.server.ipv6.inherit:
Type: boolean (true) Flags: -noneDescription: Inherit DNS servers.
SonicWall® SonicOS API 6.5.4 Reference API: DNS
100
dns.server.ipv6.static:
Type: object Flags: -noneDescription: Set static DNS server
dns.server.ipv6.static.primary:
Type: string (ip) Flags: -noneDescription: IIPv6 host address in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH
dns.server.ipv6.static.secondary:
Type: string (ip) Flags: -noneDescription: IPv6 host address in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH
dns.server.ipv6.static.tertiary:
Type: string (ip) Flags: -noneDescription: IPv6 host address in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH
dns.rebinding:
Type: object Flags: -noneDescription: Enable and configure DNS rebinding attack prevention. Set to null or {} if disabled/unconfigured.
Disabling rebinding example:
{ "dns": { "rebinding": { } }
}
dns.rebinding.action:
Type: string Flags: -noneDescription: Set action when experiencing attack. Must be one of the following values: log-attack-only | return-query-refused | drop-dns-reply
dns.rebinding.allowed_domains:
Type: object Flags: -noneDescription: Specify the domains for which checking is not done. Set to null or {} if disabled/unconfigured.
Disabling allowed_domains example:
{ "dns": { "rebinding": {
SonicWall® SonicOS API 6.5.4 Reference API: DNS
101
"allowed_domains": { } } } }
dns.rebinding.allowed_domains.name:
Type: string Flags: -noneDescription: FQDN address object name.
dns.rebinding.allowed_domains.group:
Type: string Flags: -noneDescription: Custom FQDN group address object name.
dns.fqdn_binding:
Type: boolean (true|false) Flags: -noneDescription: Enable FQDN object only cache DNS reply from sanctioned server.
SonicWall® SonicOS API 6.5.4 Reference API: DNS
102
16
API: Interfaces IPv4
· Endpoint on page 103 · Schema Structure on page 103
· Object: Interface IPv4 on page 103 · Collection: Interface IPv4 on page 105 · Schema Attributes on page 105
Endpoint
Endpoint
URI: /api/sonicos/interfaces/ipv4 Schema: collection#interface-ipv4-config URI: /api/sonicos/interfaces/ipv4 Schema: collection#interface-ipv4-config
Schema Structure
Topics:
· Object: Interface IPv4 on page 103 · Collection: Interface IPv4 on page 105 · Schema Attributes on page 105
Object: Interface IPv4
{ "interface": { "ipv4": { "name": "{string}", "comment": "{string}",
"ip_assignment": { "zone": "{string}",
"mode": { "static": { "ip": "{string}", "netmask": "{string}",
GET Empty
HTTP method and body
POST PUT
DELETE
--
Required --
Empty --
Required --
SonicWall® SonicOS API 6.5.4 Reference API: Interfaces IPv4
103
"gateway": "{string}",
"dns": { "primary": "{string}", "secondary": "{string}", "tertiary": "{string}"
},
"backup_ip": "{string}" },
| "dhcp": { "hostname": "{string}", "renew_on_startup": {boolean}, "renew_on_link_up": {boolean}, "initiate_renewals_with_discover": {boolean}, "force_discover_interval": {number}
} } },
"mtu": {number},
"mac": { "default": {true},
| "override": "{string}" },
"link_speed": { "auto_negotiate": {true},
| "half": "{string}", | "full": "{string}" },
"management": { "http": {boolean}, "https": {boolean}, "ping": {boolean}, "snmp": {boolean}, "ssh": {boolean}
},
"user_login": { "http": {boolean}, "https": {boolean}
},
"https_redirect": {boolean}, "send_icmp_fragmentation": {boolean}, "fragment_packets": {boolean}, "ignore_df_bit": {boolean}, "flow_reporting": {boolean}, "multicast": {boolean}, "cos_8021p": {boolean}, "exclude_route": {boolean}, "asymmetric_route": {boolean}, "shutdown_port": {boolean}, "default_8021p_cos": "{string}", "policy": "{string}",
"sonicpoint": { "limit": {number},
"reserve_address": { "dynamic": {true},
| "manual": "{string}" }
SonicWall® SonicOS API 6.5.4 Reference API: Interfaces IPv4
104
} } } }
Collection: Interface IPv4
{ "interfaces": [ object#interface-ipv4-config, ... ]
}
Schema Attributes
Topics:
· interface: on page 106 · interfaces: on page 107 · interface.ipv4: on page 107 · interface.ipv4.name: on page 107 · interface.ipv4.comment: on page 107 · interface.ipv4.ip_assignment: on page 107 · interface.ipv4.ip_assignment.zone: on page 107 · interface.ipv4.ip_assignment.mode: on page 107 · interface.ipv4.ip_assignment.mode.static: on page 107 · interface.ipv4.ip_assignment.mode.static.ip: on page 107 · interface.ipv4.ip_assignment.mode.static.netmask: on page 108 · interface.ipv4.ip_assignment.mode.static.gateway: on page 108 · interface.ipv4.ip_assignment.mode.static.dns: on page 108 · interface.ipv4.ip_assignment.mode.static.dns.primary: on page 108 · interface.ipv4.ip_assignment.mode.static.dns.secondary: on page 108 · interface.ipv4.ip_assignment.mode.static.dns.tertiary: on page 108 · interface.ipv4.ip_assignment.mode.static.backup_ip: on page 108 · interface.ipv4.ip_assignment.mode.dhcp: on page 108 · interface.ipv4.ip_assignment.mode.dhcp.hostname: on page 108 · interface.ipv4.ip_assignment.mode.dhcp.renew_on_startup: on page 109 · interface.ipv4.ip_assignment.mode.dhcp.renew_on_link_up: on page 109 · interface.ipv4.ip_assignment.mode.dhcp.initiate_renewals_with_discover: on page 109 · interface.ipv4.ip_assignment.mode.dhcp.force_discover_interval: on page 109 · interface.ipv4.mtu: on page 109 · interface.ipv4.mac: on page 109
SonicWall® SonicOS API 6.5.4 Reference API: Interfaces IPv4
105
· interface.ipv4.mac.default: on page 109 · interface.ipv4.mac.override: on page 109 · interface.ipv4.link_speed: on page 109 · interface.ipv4.link_speed.auto_negotiate: on page 110 · interface.ipv4.link_speed.half: on page 110 · interface.ipv4.link_speed.full: on page 110 · interface.ipv4.management: on page 110 · interface.ipv4.management.http: on page 110 · interface.ipv4.management.https: on page 110 · interface.ipv4.management.ping: on page 110 · interface.ipv4.management.snmp: on page 110 · interface.ipv4.management.ssh: on page 110 · interface.ipv4.user_login: on page 111 · interface.ipv4.user_login.http: on page 111 · interface.ipv4.user_login.https: on page 111 · interface.ipv4.https_redirect: on page 111 · interface.ipv4.send_icmp_fragmentation: on page 111 · interface.ipv4.fragment_packets: on page 111 · interface.ipv4.ignore_df_bit: on page 111 · interface.ipv4.flow_reporting: on page 111 · interface.ipv4.multicast: on page 111 · interface.ipv4.cos_8021p: on page 112 · interface.ipv4.exclude_route: on page 112 · interface.ipv4.asymmetric_route: on page 112 · interface.ipv4.shutdown_port: on page 112 · interface.ipv4.default_8021p_cos: on page 112 · interface.ipv4.policy: on page 112 · interface.ipv4.sonicpoint: on page 112 · interface.ipv4.sonicpoint.limit: on page 112 · interface.ipv4.sonicpoint.reserve_address: on page 112 · interface.ipv4.sonicpoint.reserve_address.dynamic: on page 113 · interface.ipv4.sonicpoint.reserve_address.manual: on page 113
interface:
Type: object Flags: -noneDescription: Interface.
SonicWall® SonicOS API 6.5.4 Reference API: Interfaces IPv4
106
interfaces:
Type: array Flags: -noneDescription: Interface collection.
interface.ipv4:
Type: object Flags: -noneDescription: IP version IPV4.
interface.ipv4.name:
Type: string Flags: key Description: Interface name.
interface.ipv4.comment:
Type: string Flags: -noneDescription:
interface.ipv4.ip_assignment:
Type: object Flags: -noneDescription: Set interface zone and IP assignment. Set to null or {} if disabled/unconfigured.
interface.ipv4.ip_assignment.zone:
Type: string Flags: -noneDescription: Zone object name.
interface.ipv4.ip_assignment.mode:
Type: object Flags: -noneDescription: Interface IP assignment mode.
interface.ipv4.ip_assignment.mode.static:
Type: object Flags: -noneDescription: Static IP address assignment.
interface.ipv4.ip_assignment.mode.static.ip:
Type: string (v4 ip) Flags: -noneDescription: IPV4 Address in the form: a.b.c.d
SonicWall® SonicOS API 6.5.4 Reference API: Interfaces IPv4
107
interface.ipv4.ip_assignment.mode.static.netmask:
Type: string (v4 subnet) Flags: -noneDescription: IPV4 netmask in decimal dotted or CIDR form: D.D.D.D OR /D
interface.ipv4.ip_assignment.mode.static.gateway:
Type: string (v4 ip) Flags: -noneDescription: IPV4 Address in the form: a.b.c.d
interface.ipv4.ip_assignment.mode.static.dns:
Type: object Flags: -noneDescription: Set the DNS server IP address.
interface.ipv4.ip_assignment.mode.static.dns.primary:
Type: string (v4 ip) Flags: -noneDescription: IPV4 Address in the form: a.b.c.d
interface.ipv4.ip_assignment.mode.static.dns.secondary:
Type: string (v4 ip) Flags: -noneDescription: IPV4 Address in the form: a.b.c.d
interface.ipv4.ip_assignment.mode.static.dns.tertiary:
Type: string (v4 ip) Flags: -noneDescription: IPV4 Address in the form: a.b.c.d
interface.ipv4.ip_assignment.mode.static.backup_ip:
Type: string (v4 ip) Flags: -noneDescription: IPV4 Address in the form: a.b.c.d
interface.ipv4.ip_assignment.mode.dhcp:
Type: object Flags: -noneDescription: IP address obtained by DHCP.
interface.ipv4.ip_assignment.mode.dhcp.hostname:
Type: string Flags: -noneDescription:
SonicWall® SonicOS API 6.5.4 Reference API: Interfaces IPv4
108
interface.ipv4.ip_assignment.mode.dhcp.renew_on_start up:
Type: boolean (true|false) Flags: -noneDescription: Enable request renew of previous IP on startup.
interface.ipv4.ip_assignment.mode.dhcp.renew_on_link_u p:
Type: boolean (true|false) Flags: -noneDescription: Enable renew DHCP lease on any link up occurrence.
interface.ipv4.ip_assignment.mode.dhcp.initiate_renewal s_with_discover:
Type: boolean (true|false) Flags: -noneDescription: Enable initiate renewals with a discover when using DHCP.
interface.ipv4.ip_assignment.mode.dhcp.force_discover_i nterval:
Type: number (uint32) Flags: -noneDescription: Integer in the form: D OR 0xHHHHHHHH
interface.ipv4.mtu:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
interface.ipv4.mac:
Type: object Flags: -noneDescription: Set MAC address used for this interface.
interface.ipv4.mac.default:
Type: boolean (true) Flags: -noneDescription: Factory configured MAC.
interface.ipv4.mac.override:
Type: string (mac) Flags: -noneDescription: MAC address in the form: HH:HH:HH:HH:HH:HH OR HHHHHHHHHHHH
interface.ipv4.link_speed:
Type: object
SonicWall® SonicOS API 6.5.4 Reference API: Interfaces IPv4
109
Flags: -noneDescription: Set interface link speed.
interface.ipv4.link_speed.auto_negotiate:
Type: boolean (true) Flags: -noneDescription: Set interface link speed to auto-negotiate.
interface.ipv4.link_speed.half:
Type: string Flags: -noneDescription: Half duplex.
interface.ipv4.link_speed.full:
Type: string Flags: -noneDescription: Full duplex.
interface.ipv4.management:
Type: object Flags: -noneDescription: Enable management for the specified protocols.
interface.ipv4.management.http:
Type: boolean (true|false) Flags: -noneDescription: HTTP.
interface.ipv4.management.https:
Type: boolean (true|false) Flags: -noneDescription: HTTPS.
interface.ipv4.management.ping:
Type: boolean (true|false) Flags: -noneDescription: Ping.
interface.ipv4.management.snmp:
Type: boolean (true|false) Flags: -noneDescription: SNMP.
interface.ipv4.management.ssh:
Type: boolean (true|false) Flags: -noneDescription: SSH.
SonicWall® SonicOS API 6.5.4 Reference API: Interfaces IPv4
110
interface.ipv4.user_login:
Type: object Flags: -noneDescription: Enable user login for the specified protocols.
interface.ipv4.user_login.http:
Type: boolean (true|false) Flags: -noneDescription: HTTP.
interface.ipv4.user_login.https:
Type: boolean (true|false) Flags: -noneDescription: HTTPS.
interface.ipv4.https_redirect:
Type: boolean (true|false) Flags: -noneDescription: Enable redirection from HTTP to HTTPS.
interface.ipv4.send_icmp_fragmentation:
Type: boolean (true|false) Flags: -noneDescription: Enable ICMP fragmentation needed message generation.
interface.ipv4.fragment_packets:
Type: boolean (true|false) Flags: -noneDescription: Enable fragment non-VPN outbound packets larger than this interface's MTU.
interface.ipv4.ignore_df_bit:
Type: boolean (true|false) Flags: -noneDescription: Enable ignore don't fragment (DF) bit.
interface.ipv4.flow_reporting:
Type: boolean (true|false) Flags: -noneDescription: Enable flow reporting on the interface.
interface.ipv4.multicast:
Type: boolean (true|false) Flags: -noneDescription: Enable multicast support.
SonicWall® SonicOS API 6.5.4 Reference API: Interfaces IPv4
111
interface.ipv4.cos_8021p:
Type: boolean (true|false) Flags: -noneDescription: Enable 802.1p support.
interface.ipv4.exclude_route:
Type: boolean (true|false) Flags: -noneDescription: Enable exclude from route advertisement (NSM, OSPF, BGP, RIP).
interface.ipv4.asymmetric_route:
Type: boolean (true|false) Flags: -noneDescription: Enable asymmetric route.
interface.ipv4.shutdown_port:
Type: boolean (true|false) Flags: -noneDescription: Enable shutdown port.
interface.ipv4.default_8021p_cos:
Type: string Flags: -noneDescription: Enable default 802.1p CoS.
interface.ipv4.policy:
Type: string Flags: -noneDescription: Tunnel interface VPN policy name.
interface.ipv4.sonicpoint:
Type: object Flags: -noneDescription: Set SonicPoint parameter.
interface.ipv4.sonicpoint.limit:
Type: number (uint32) Flags: -noneDescription: SonicPoint limit per interface.
interface.ipv4.sonicpoint.reserve_address:
Type: object Flags: -noneDescription: Set dynamically or manually reserve SonicPoint address.
SonicWall® SonicOS API 6.5.4 Reference API: Interfaces IPv4
112
interface.ipv4.sonicpoint.reserve_address.dynamic:
Type: boolean (true) Flags: -noneDescription: Dynamically reserve SonicPoint address.
interface.ipv4.sonicpoint.reserve_address.manual:
Type: string (v4 ip) Flags: -noneDescription: IPV4 Address in the form: a.b.c.d
SonicWall® SonicOS API 6.5.4 Reference API: Interfaces IPv4
113
17
API: NAT Policies IPv4
· Endpoint on page 114 · Schema Structure on page 114
· Object: NAT Policies IPv4 on page 114 · Collection: NAT Policies IPv4 on page 116 · Schema Attributes on page 116
Endpoint
Endpoint
URI: /api/sonicos/nat-policies/ipv4 Schema: collection#nat-policies-ipv4-config URI: /api/sonicos/nat-policies/ipv4 Schema: collection#nat-policies-ipv4-config
GET Empty
HTTP method and body
POST PUT
DELETE
Required Required Required
Empty --
Required Ignored
Schema Structure
Topics:
· Object: NAT Policies IPv4 on page 114 · Collection: NAT Policies IPv4 on page 116 · Schema Attributes on page 116
Object: NAT Policies IPv4
{ "nat_policy": { "ipv4": { "inbound": "{string}", "outbound": "{string}",
"source": { "any": {true},
| "name": "{string}", | "group": "{string}" },
"translated_source": {
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv4
114
"original": {true}, | "name": "{string}", | "group": "{string}" },
"destination": { "any": {true},
| "name": "{string}", | "group": "{string}" },
"translated_destination": { "original": {true},
| "name": "{string}", | "group": "{string}" },
"service": { "any": {true},
| "name": "{string}", | "group": "{string}" },
"translated_service": { "original": {true},
| "name": "{string}", | "group": "{string}" },
"uuid": "{string}", "name": "{string}", "enable": {boolean}, "comment": "{string}",
"priority": { "auto": {true},
| "manual": {number} },
"reflexive": {boolean},
"virtual_group": { "any": {true},
| "id": {number} },
"nat_method": "{string}", "source_port_remap": {boolean},
"high_availability": { "probing": { "probe_every": {number},
"probe_type": { "icmp_ping": {true},
| "tcp": {number} },
"reply_timeout": {number}, "deactivate_after": {number}, "reactivate_after": {number}, "rst_as_miss": {boolean}, "port_probing": {boolean} } } }
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv4
115
} }
Collection: NAT Policies IPv4
{ "nat_policies": [ object#nat-policy-ipv4-config, ... ]
}
Schema Attributes
Topics:
· nat_policy: on page 117 · nat_policies: on page 117 · nat_policy.ipv4: on page 118 · nat_policy.ipv4.inbound: on page 118 · nat_policy.ipv4.outbound: on page 118 · nat_policy.ipv4.source: on page 118 · nat_policy.ipv4.source.any: on page 118 · nat_policy.ipv4.source.name: on page 118 · nat_policy.ipv4.source.group: on page 118 · nat_policy.ipv4.translated_source: on page 118 · nat_policy.ipv4.translated_source.original: on page 118 · nat_policy.ipv4.translated_source.name: on page 119 · nat_policy.ipv4.translated_source.group: on page 119 · nat_policy.ipv4.destination: on page 119 · nat_policy.ipv4.destination.any: on page 119 · nat_policy.ipv4.destination.name: on page 119 · nat_policy.ipv4.destination.group: on page 119 · nat_policy.ipv4.translated_destination: on page 119 · nat_policy.ipv4.translated_destination.original: on page 119 · nat_policy.ipv4.translated_destination.name: on page 119 · nat_policy.ipv4.translated_destination.group: on page 120 · nat_policy.ipv4.service: on page 120 · nat_policy.ipv4.service.any: on page 120 · nat_policy.ipv4.service.name: on page 120 · nat_policy.ipv4.service.group: on page 120 · nat_policy.ipv4.translated_service: on page 120
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv4
116
· nat_policy.ipv4.translated_service.original: on page 120 · nat_policy.ipv4.translated_service.name: on page 120 · nat_policy.ipv4.translated_service.group: on page 120 · nat_policy.ipv4.uuid: on page 121 · nat_policy.ipv4.name: on page 121 · nat_policy.ipv4.enable: on page 121 · nat_policy.ipv4.comment: on page 121 · nat_policy.ipv4.priority: on page 121 · nat_policy.ipv4.priority.auto: on page 121 · nat_policy.ipv4.priority.manual: on page 121 · nat_policy.ipv4.reflexive: on page 121 · nat_policy.ipv4.virtual_group: on page 121 · nat_policy.ipv4.virtual_group.any: on page 122 · nat_policy.ipv4.virtual_group.id: on page 122 · nat_policy.ipv4.nat_method: on page 122 · nat_policy.ipv4.source_port_remap: on page 122 · nat_policy.ipv4.high_availability: on page 122 · nat_policy.ipv4.high_availability.probing: on page 122 · nat_policy.ipv4.high_availability.probing.probe_every: on page 122 · nat_policy.ipv4.high_availability.probing.probe_type: on page 122 · nat_policy.ipv4.high_availability.probing.probe_type.icmp_ping: on page 122 · nat_policy.ipv4.high_availability.probing.probe_type.tcp: on page 123 · nat_policy.ipv4.high_availability.probing.reply_timeout: on page 123 · nat_policy.ipv4.high_availability.probing.deactivate_after: on page 123 · nat_policy.ipv4.high_availability.probing.reactivate_after: on page 123 · nat_policy.ipv4.high_availability.probing.port_probing: on page 123 · nat_policy.ipv4.high_availability.probing.rst_as_miss: on page 123
nat_policy:
Type: object Flags: -noneDescription: NAT policy.
nat_policies:
Type: array Flags: -noneDescription: NAT policy collection.
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv4
117
nat_policy.ipv4:
Type: object Flags: -noneDescription: IPv4 NAT policy.
nat_policy.ipv4.inbound:
Type: string Flags: key Description: Interface name.
nat_policy.ipv4.outbound:
Type: string Flags: key Description: Interface name.
nat_policy.ipv4.source:
Type: object Flags: key Description: Specify the original source for the NAT policy.
nat_policy.ipv4.source.any:
Type: boolean (true) Flags: key Description: Any host.
nat_policy.ipv4.source.name:
Type: string Flags: key Description: Address object name.
nat_policy.ipv4.source.group:
Type: string Flags: key Description: Group address object name.
nat_policy.ipv4.translated_source:
Type: object Flags: key Description: Specify the translated source for the NAT policy.
nat_policy.ipv4.translated_source.original:
Type: boolean (true) Flags: key Description: Original source IP.
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv4
118
nat_policy.ipv4.translated_source.name:
Type: string Flags: key Description: Address object name.
nat_policy.ipv4.translated_source.group:
Type: string Flags: key Description: Group address object name.
nat_policy.ipv4.destination:
Type: object Flags: key Description: Specify the original destination for the NAT policy.
nat_policy.ipv4.destination.any:
Type: boolean (true) Flags: key Description: Any host.
nat_policy.ipv4.destination.name:
Type: string Flags: key Description: Address object name.
nat_policy.ipv4.destination.group:
Type: string Flags: key Description: Group address object name.
nat_policy.ipv4.translated_destination:
Type: object Flags: key Description: Specify the translated destination for the NAT policy.
nat_policy.ipv4.translated_destination.original:
Type: boolean (true) Flags: key Description: Original destination IP.
nat_policy.ipv4.translated_destination.name:
Type: string Flags: key Description: Address object name.
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv4
119
nat_policy.ipv4.translated_destination.group:
Type: string Flags: key Description: Group address object name.
nat_policy.ipv4.service:
Type: object Flags: key Description: Specify the original service for the NAT policy.
nat_policy.ipv4.service.any:
Type: boolean (true) Flags: key Description: Any service.
nat_policy.ipv4.service.name:
Type: string Flags: key Description: Service object name.
nat_policy.ipv4.service.group:
Type: string Flags: key Description: Service object group name.
nat_policy.ipv4.translated_service:
Type: object Flags: key Description: Specify the translated service for the NAT policy.
nat_policy.ipv4.translated_service.original:
Type: boolean (true) Flags: key Description: Original service.
nat_policy.ipv4.translated_service.name:
Type: string Flags: key Description: Service object name.
nat_policy.ipv4.translated_service.group:
Type: string Flags: key Description: Service object group name.
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv4
120
nat_policy.ipv4.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
nat_policy.ipv4.name:
Type: string Flags: required Description: Name.
nat_policy.ipv4.enable:
Type: boolean (true|false) Flags: -noneDescription: Enable NAT policy.
nat_policy.ipv4.comment:
Type: string Flags: -noneDescription:
nat_policy.ipv4.priority:
Type: object Flags: -noneDescription: Set NAT policy priority
nat_policy.ipv4.priority.auto:
Type: boolean (true) Flags: -noneDescription: Set auto priority(priority = 0) for NAT policy.
nat_policy.ipv4.priority.manual:
Type: number (uint32) Flags: -noneDescription: Integer in the form: D OR 0xHHHHHHHH
nat_policy.ipv4.reflexive:
Type: boolean (true|false) Flags: -noneDescription: Configure a reflexive rule.
nat_policy.ipv4.virtual_group:
Type: object Flags: -noneDescription: Specify virtual group for the NAT policy.
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv4
121
nat_policy.ipv4.virtual_group.any:
Type: boolean (true) Flags: -noneDescription: Any virtual group.
nat_policy.ipv4.virtual_group.id:
Type: number (uint8) Flags: -noneDescription: Integer in the form: D OR 0xHH
nat_policy.ipv4.nat_method:
Type: string Flags: -noneDescription: Set the NAT destination translation method.
nat_policy.ipv4.source_port_remap:
Type: boolean (true|false) Flags: -noneDescription: Enable source port remap.
nat_policy.ipv4.high_availability:
Type: object Flags: -noneDescription: NAT high availability and load balancing configuration mode.
nat_policy.ipv4.high_availability.probing:
Type: object Flags: -noneDescription: Enable HA probing and enter configuration mode.
nat_policy.ipv4.high_availability.probing.probe_every:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
nat_policy.ipv4.high_availability.probing.probe_type:
Type: object Flags: -noneDescription: Set probe IP type.
nat_policy.ipv4.high_availability.probing.probe_type.icmp _ping:
Type: boolean (true) Flags: -noneDescription: ICMP ping probe.
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv4
122
nat_policy.ipv4.high_availability.probing.probe_type.tcp:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
nat_policy.ipv4.high_availability.probing.reply_timeout:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
nat_policy.ipv4.high_availability.probing.deactivate_after:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
nat_policy.ipv4.high_availability.probing.reactivate_after:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
nat_policy.ipv4.high_availability.probing.rst_as_miss:
Type: boolean (true|false) Flags: -noneDescription: Enable count RST response as miss.
nat_policy.ipv4.high_availability.probing.port_probing:
Type: boolean (true|false) Flags: -noneDescription: Enable port probing.
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv4
123
18
API: NAT Policies IPv6
· Endpoint on page 124 · Schema Structure on page 124
· Object: NAT Policies IPv6 on page 124 · Schema Attributes on page 125
Endpoint
Endpoint URI: /api/sonicos/nat-policies/ipv6 Schema: collection#nat-policies-ipv6-config URI: /api/sonicos/nat-policies/ipv6 Schema: collection#nat-policies-ipv6-config
GET Empty
HTTP method and body
POST PUT
DELETE
Required Required Required
Empty --
Required Ignored
Schema Structure
Topics:
· Object: NAT Policies IPv6 on page 124
· Schema Attributes on page 125
Object: NAT Policies IPv6
{ "nat_policy": { "ipv6": { "inbound": "{string}", "outbound": "{string}",
"source": { "any": {true},
| "name": "{string}", | "group": "{string}" },
"translated_source": { "original": {true},
| "name": "{string}", | "group": "{string}"
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv6
124
},
"destination": { "any": {true},
| "name": "{string}", | "group": "{string}" },
"translated_destination": { "original": {true},
| "name": "{string}", | "group": "{string}" },
"service": { "any": {true},
| "name": "{string}", | "group": "{string}" },
"translated_service": { "original": {true},
| "name": "{string}", | "group": "{string}" },
"uuid": "{string}", "name": "{string}", "enable": {boolean}, "comment": "{string}",
"priority": { "auto": {true},
| "manual": {number} },
"reflexive": {boolean},
"virtual_group": { "any": {true},
| "id": {number} } } } }
Schema Attributes
Topics:
· nat_policy: on page 126 · nat_policies: on page 127 · nat_policy.ipv6: on page 127 · nat_policy.ipv6.inbound: on page 127 · nat_policy.ipv6.outbound: on page 127 · nat_policy.ipv6.source: on page 127 · nat_policy.ipv6.source.any: on page 127 · nat_policy.ipv6.source.name: on page 127
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv6
125
· nat_policy.ipv6.source.group: on page 127 · nat_policy.ipv6.translated_source: on page 127 · nat_policy.ipv6.translated_source.original: on page 128 · nat_policy.ipv6.translated_source.name: on page 128 · nat_policy.ipv6.translated_source.group: on page 128 · nat_policy.ipv6.destination: on page 128 · nat_policy.ipv6.destination.any: on page 128 · nat_policy.ipv6.destination.name: on page 128 · nat_policy.ipv6.destination.group: on page 128 · nat_policy.ipv6.translated_destination: on page 128 · nat_policy.ipv6.translated_destination.original: on page 128 · nat_policy.ipv6.translated_destination.name: on page 129 · nat_policy.ipv6.translated_destination.group: on page 129 · nat_policy.ipv6.service.any: on page 129 · nat_policy.ipv6.service.name: on page 129 · nat_policy.ipv6.service.group: on page 129 · nat_policy.ipv6.translated_service: on page 129 · nat_policy.ipv6.translated_service.original: on page 129 · nat_policy.ipv6.translated_service.name: on page 129 · nat_policy.ipv6.translated_service.group: on page 129 · nat_policy.ipv6.uuid: on page 130 · nat_policy.ipv6.name: on page 130 · nat_policy.ipv6.enable: on page 130 · nat_policy.ipv6.comment: on page 130 · nat_policy.ipv6.comment: on page 130 · nat_policy.ipv6.priority: on page 130 · nat_policy.ipv6.priority.auto: on page 130 · nat_policy.ipv6.priority.manual: on page 130 · nat_policy.ipv6.reflexive: on page 130 · nat_policy.ipv6.reflexive: on page 130 · nat_policy.ipv6.virtual_group: on page 130 · nat_policy.ipv6.virtual_group.any: on page 131 · nat_policy.ipv6.virtual_group.id: on page 131
nat_policy:
Type: object Flags: -noneDescription: NAT policy.
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv6
126
nat_policies:
Type: object Flags: -noneDescription: NAT policy collection.
nat_policy.ipv6:
Type: object Flags: key Description: IPv6 NAT policy.
nat_policy.ipv6.inbound:
Type: string Flags: key Description: Interface name.
nat_policy.ipv6.outbound:
Type: string Flags: key Description: Interface name.
nat_policy.ipv6.source:
Type: object Flags: key Description: Specify the original source for the NAT policy.
nat_policy.ipv6.source.any:
Type: boolean (true) Flags: key Description: Any host.
nat_policy.ipv6.source.name:
Type: string Flags: key Description: Address object name.
nat_policy.ipv6.source.group:
Type: string Flags: key Description: Group address object name.
nat_policy.ipv6.translated_source:
Type: object Flags: key Description: Specify the translated source for the NAT policy.
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv6
127
nat_policy.ipv6.translated_source.original:
Type: boolean (true) Flags: key Description: Original source IP.
nat_policy.ipv6.translated_source.name:
Type: string Flags: key Description: Address object name.
nat_policy.ipv6.translated_source.group:
Type: string Flags: key Description: Group address object name.
nat_policy.ipv6.destination:
Type: object Flags: key Description: Specify the original destination for the NAT policy.
nat_policy.ipv6.destination.any:
Type: boolean (true) Flags: key Description: Any host.
nat_policy.ipv6.destination.name:
Type: string Flags: key Description: Address object name.
nat_policy.ipv6.destination.group:
Type: string Flags: key Description: Group address object name.
nat_policy.ipv6.translated_destination:
Type: object Flags: key Description: Specify the translated destination for the NAT policy.
nat_policy.ipv6.translated_destination.original:
Type: boolean (true) Flags: key Description: Original destination IP.
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv6
128
nat_policy.ipv6.translated_destination.name:
Type: string Flags: key Description: Address object name.
nat_policy.ipv6.translated_destination.group:
Type: string Flags: key Description: Group address object name.
nat_policy.ipv6.service:
Type: object Flags: key Description: Specify the original service for the NAT policy.
nat_policy.ipv6.service.any:
Type: boolean (true) Flags: key Description: Any service.
nat_policy.ipv6.service.name:
Type: string Flags: key Description: Service object name.
nat_policy.ipv6.service.group:
Type: string Flags: key Description: Service object group name.
nat_policy.ipv6.translated_service:
Type: object Flags: key Description: Specify the translated service for the NAT policy.
nat_policy.ipv6.translated_service.original:
Type: boolean (true) Flags: key Description: Original service.
nat_policy.ipv6.translated_service.name:
Type: string Flags: key Description: Service object name.
nat_policy.ipv6.translated_service.group:
Type: string Flags: key
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv6
129
Description: Service object group name.
nat_policy.ipv6.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
nat_policy.ipv6.name:
Type: string Flags: required Description: Name.
nat_policy.ipv6.enable:
Type: boolean (true|false) Flags: -noneDescription: Enable NAT policy.
nat_policy.ipv6.comment:
Type: string Flags: -noneDescription: Policy comment.
nat_policy.ipv6.priority:
Type: object Flags: -noneDescription: Set NAT policy priority.
nat_policy.ipv6.priority.auto:
Type: boolean (true) Flags: -noneDescription: Set auto priority(priority = 0) for NAT policy.
nat_policy.ipv6.priority.manual:
Type: number (uint32) Flags: -noneDescription: Integer in the form: D OR 0xHHHHHHHH
nat_policy.ipv6.reflexive:
Type: boolean (true|false) Flags: -noneDescription: Configure a reflexive rule.
nat_policy.ipv6.virtual_group:
Type: object Flags: -noneDescription: Specify virtual group for the NAT policy.
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv6
130
nat_policy.ipv6.virtual_group.any:
Type: boolean (true) Flags: -noneDescription: Any virtual group.
nat_policy.ipv6.virtual_group.id:
Type: number (uint8) Flags: -noneDescription: Integer in the form: D OR 0xHH
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies IPv6
131
19
API: NAT Policies NAT64
· Endpoint on page 132 · Schema Structure on page 132
· Object: NAT Policies NAT64 on page 132 · Collection: NAT Policies NAT64 on page 133 · Schema Attributes on page 133
Endpoint
Endpoint
URI: /api/sonicos/nat-policies/nat64 Schema: collection#nat-policy-nat64-config URI: /api/sonicos/nat-policies/nat64 Schema: collection#nat-policy-nat64-config
GET Empty
HTTP method and body
POST PUT
DELETE
Required Required Required
Empty --
Required Ignored
Schema Structure
Topics:
· Object: NAT Policies NAT64 on page 132 · Collection: NAT Policies NAT64 on page 133 · Schema Attributes on page 133
Object: NAT Policies NAT64
{ "nat_policy": { "nat64": { "inbound": "{string}", "outbound": "{string}",
"source": { "any": {true},
| "name": "{string}", | "group": "{string}" },
"translated_source": {
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies NAT64
132
"original": {true}, | "name": "{string}", | "group": "{string}" },
"pref64": { "any": {true},
| "name": "{string}", | "group": "{string}" },
"translated_destination": { "embedded_ipv4_address": {true}
},
"service": { "icmp_udp_tcp": {true}
},
"translated_service": { "original": {true}
},
"uuid": "{string}", "name": "{string}", "enable": {boolean}, "comment": "{string}" } } }
Collection: NAT Policies NAT64
{ "nat_policies": [ object#nat-policy-nat64-config, ... ]
}
Schema Attributes
Topics:
· nat_policy: on page 134 · nat_policies: on page 134 · nat_policy.nat64: on page 134 · nat_policy.nat64.inbound: on page 134 · nat_policy.nat64.outbound: on page 134 · nat_policy.nat64.source: on page 135 · nat_policy.nat64.source.any: on page 135 · nat_policy.nat64.source.name: on page 135 · nat_policy.nat64.source.group: on page 135 · nat_policy.nat64.translated_source: on page 135
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies NAT64
133
· nat_policy.nat64.translated_source.original: on page 135 · nat_policy.nat64.translated_source.name: on page 135 · nat_policy.nat64.translated_source.group: on page 135 · nat_policy.nat64.pref64: on page 135 · nat_policy.nat64.pref64.any: on page 136 · nat_policy.nat64.pref64.name: on page 136 · nat_policy.nat64.pref64.group: on page 136 · nat_policy.nat64.translated_destination: on page 136 · nat_policy.nat64.translated_destination.embedded_ipv4_address: on page 136 · nat_policy.nat64.service: on page 136 · nat_policy.nat64.service.icmp_udp_tcp: on page 136 · nat_policy.nat64.service.icmp_udp_tcp: on page 136 · nat_policy.nat64.translated_service: on page 136 · nat_policy.nat64.translated_service.original: on page 136 · nat_policy.nat64.uuid: on page 137 · nat_policy.nat64.name: on page 137 · nat_policy.nat64.enable: on page 137 · nat_policy.nat64.comment: on page 137
nat_policy:
Type: object Flags: -noneDescription: NAT policy.
nat_policies:
Type: object Flags: -noneDescription: NAT policy collection.
nat_policy.nat64:
Type: object Flags: key Description: NAT64 NAT policy.
nat_policy.nat64.inbound:
Type: string Flags: key Description: Interface name.
nat_policy.nat64.outbound:
Type: string Flags: key Description: Interface name.
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies NAT64
134
nat_policy.nat64.source:
Type: object Flags: key Description: Specify the original source for the NAT64 policy.
nat_policy.nat64.source.any:
Type: boolean (true) Flags: key Description: Any host.
nat_policy.nat64.source.name:
Type: string Flags: key Description: Address object name.
nat_policy.nat64.source.group:
Type: string Flags: key Description: Group address object name.
nat_policy.nat64.translated_source:
Type: object Flags: key Description: Specify the translated source for the NAT64 policy.
nat_policy.nat64.translated_source.original:
Type: boolean (true) Flags: key Description: Original source IP.
nat_policy.nat64.translated_source.name:
Type: string Flags: key Description: Address object name.
nat_policy.nat64.translated_source.group:
Type: string Flags: key Description: Group address object name.
nat_policy.nat64.pref64:
Type: object Flags: key Description: Specify the prefix for the NAT64 policy.
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies NAT64
135
nat_policy.nat64.pref64.any:
Type: boolean (true) Flags: key Description: Any host.
nat_policy.nat64.pref64.name:
Type: string Flags: key Description: Address object name.
nat_policy.nat64.pref64.group:
Type: string Flags: key Description: Group address object name.
nat_policy.nat64.translated_destination:
Type: object Flags: key Description: Specify the translated destination for the NAT policy.
nat_policy.nat64.translated_destination.embedded_ipv4_ address:
Type: boolean (true) Flags: key Description: Embedded ipv4 address.
nat_policy.nat64.service:
Type: object Flags: key Description: Specify the original service for the NAT policy.
nat_policy.nat64.service.icmp_udp_tcp:
Type: boolean (true) Flags: key Description: ICMP UDP TCP service.
nat_policy.nat64.translated_service:
Type: object Flags: key Description: Specify the translated service for the NAT policy.
nat_policy.nat64.translated_service.original:
Type: boolean (true) Flags: key Description: Original service.
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies NAT64
136
nat_policy.nat64.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
nat_policy.nat64.name:
Type: string Flags: required Description: Name.
nat_policy.nat64.enable:
Type: boolean (true|false) Flags: -noneDescription: Enable NAT policy.
nat_policy.nat64.comment:
Type: string Flags: -noneDescription:
SonicWall® SonicOS API 6.5.4 Reference API: NAT Policies NAT64
137
20
API: Access Rules IPv4
· Endpoint on page 138 · Schema Structure on page 138
· Object: Access Rules IPv4 on page 138 · Collection: Access Rules IPv4 on page 140 · Schema Attributes on page 140
Endpoint
Endpoint
URI: /api/sonicos/access-rules/ipv4 Schema: collection#access-rule-ipv4-config URI: /api/sonicos/access-rules/ipv4/uuid/{UUID} Schema: collection#access-rule-ipv4-config
GET Empty
Empty
HTTP method and body
POST PUT
DELETE
Required Required Required
--
Required Ignored
Schema Structure
Topics:
· Object: Access Rules IPv4 on page 138
· Collection: Access Rules IPv4 on page 140
· Schema Attributes on page 140
Object: Access Rules IPv4
{ "access_rule": { "ipv4": { "from": "{string}", "to": "{string}", "action": "{string}",
"source": { "address": { "any": {true}, | "name": "{string}", | "group": "{string}" },
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv4
138
"port": { "any": {true},
| "name": "{string}", | "group": "{string}" } },
"service": { "any": {true},
| "name": "{string}", | "group": "{string}" },
"destination": { "address": { "any": {true}, | "name": "{string}", | "group": "{string}" }
},
"schedule": { "always_on": {true},
| "name": "{string}" },
"users": { "included": { "all": {true}, | "guests": {true}, | "administrator": {true}, | "name": "{string}", | "group": "{string}" },
"excluded": { "none": {true},
| "guests": {true}, | "administrator": {true}, | "name": "{string}", | "group": "{string}" } },
"uuid": "{string}", "name": "{string}", "comment": "{string}", "enable": {boolean}, "reflexive": {boolean}, "max_connections": {number}, "logging": {boolean}, "management": {boolean}, "packet_monitoring": {boolean},
"priority": { "auto": {true},
| "manual": {number} },
"tcp": { "timeout": {number}
},
"udp": { "timeout": {number}
},
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv4
139
"fragments": {boolean}, "botnet_filter": {boolean},
"connection_limit": { "destination": { "threshold": {number} },
"source": { "threshold": {number}
} },
"flow_reporting": {boolean}, "geo_ip_filter": {boolean}, "single_sign_on": {boolean}, "cos_override": {boolean},
"quality_of_service": { "class_of_service": { "explicit": "{string}", | "map": {true}, | "preserve": {true} },
"dscp": { "explicit": {number},
| "map": {true}, | "preserve": {true} } } } } }
Collection: Access Rules IPv4
{ "access_rules": [ object#access_rule-ipv4-config, ... ]
}
Schema Attributes
Topics:
· access_rule: on page 142 · access_rules: on page 143 · access_rule.ipv4: on page 143 · access_rule.ipv4.from: on page 143 · access_rule.ipv4.to: on page 143 · access_rule.ipv4.action: on page 143 · access_rule.ipv4.source: on page 143 · access_rule.ipv4.source.address: on page 143
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv4
140
· access_rule.ipv4.source.address.any: on page 143 · access_rule.ipv4.source.address.name: on page 143 · access_rule.ipv4.source.address.group: on page 144 · access_rule.ipv4.source.port: on page 144 · access_rule.ipv4.source.port.any: on page 144 · access_rule.ipv4.source.port.name: on page 144 · access_rule.ipv4.source.port.group: on page 144 · access_rule.ipv4.service: on page 144 · access_rule.ipv4.service.any: on page 144 · access_rule.ipv4.service.name: on page 144 · access_rule.ipv4.service.group: on page 144 · access_rule.ipv4.destination: on page 145 · access_rule.ipv4.destination.address: on page 145 · access_rule.ipv4.destination.address.any: on page 145 · access_rule.ipv4.destination.address.name: on page 145 · access_rule.ipv4.destination.address.group: on page 145 · access_rule.ipv4.schedule: on page 145 · access_rule.ipv4.schedule.always_on: on page 145 · access_rule.ipv4.schedule.name: on page 145 · access_rule.ipv4.users: on page 145 · access_rule.ipv4.users.included: on page 146 · access_rule.ipv4.users.included.all: on page 146 · access_rule.ipv4.users.included.guests: on page 146 · access_rule.ipv4.users.included.administrator: on page 146 · access_rule.ipv4.users.included.name: on page 146 · access_rule.ipv4.users.included.group: on page 146 · access_rule.ipv4.users.excluded: on page 146 · access_rule.ipv4.users.excluded.none: on page 146 · access_rule.ipv4.users.excluded.guests: on page 146 · access_rule.ipv4.users.excluded.administrator: on page 147 · access_rule.ipv4.users.excluded.name: on page 147 · access_rule.ipv4.users.excluded.group: on page 147 · access_rule.ipv4.uuid: on page 147 · access_rule.ipv4.name: on page 147 · access_rule.ipv4.name: on page 147 · access_rule.ipv4.comment: on page 147 · access_rule.ipv4.enable: on page 147
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv4
141
· access_rule.ipv4.reflexive: on page 147 · access_rule.ipv4.max_connections: on page 147 · access_rule.ipv4.logging: on page 148 · access_rule.ipv4.management: on page 148 · access_rule.ipv4.packet_monitoring: on page 148 · access_rule.ipv4.priority: on page 148 · access_rule.ipv4.priority.auto: on page 148 · access_rule.ipv4.priority.manual: on page 148 · access_rule.ipv4.tcp: on page 148 · access_rule.ipv4.tcp.timeout: on page 148 · access_rule.ipv4.udp: on page 148 · access_rule.ipv4.udp.timeout: on page 149 · access_rule.ipv4.fragments: on page 149 · access_rule.ipv4.botnet_filter: on page 149 · access_rule.ipv4.connection_limit: on page 149 · access_rule.ipv4.connection_limit.destination: on page 149 · access_rule.ipv4.connection_limit.destination.threshold: on page 149 · access_rule.ipv4.connection_limit.source: on page 149 · access_rule.ipv4.connection_limit.source.threshold: on page 149 · access_rule.ipv4.flow_reporting: on page 149 · access_rule.ipv4.geo_ip_filter: on page 150 · access_rule.ipv4.single_sign_on: on page 150 · access_rule.ipv4.single_sign_on: on page 150 · access_rule.ipv4.cos_override: on page 150 · access_rule.ipv4.quality_of_service: on page 150 · access_rule.ipv4.quality_of_service.class_of_service: on page 150 · access_rule.ipv4.quality_of_service.class_of_service.explicit: on page 150 · access_rule.ipv4.quality_of_service.class_of_service.map: on page 150 · access_rule.ipv4.quality_of_service.class_of_service.preserve: on page 150 · access_rule.ipv4.quality_of_service.dscp: on page 150 · access_rule.ipv4.quality_of_service.dscp.explicit: on page 151 · access_rule.ipv4.quality_of_service.dscp.map: on page 151 · access_rule.ipv4.quality_of_service.dscp.preserve: on page 151
access_rule:
Type: object Flags: -noneDescription: Access rule.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv4
142
access_rules:
Type: array Flags: -noneDescription: Access rule collection.
access_rule.ipv4:
Type: object Flags: -noneDescription: IPv4 access rule.
access_rule.ipv4.from:
Type: string Flags: key Description: Zone object name.
access_rule.ipv4.to:
Type: string Flags: key Description: Zone object name.
access_rule.ipv4.action:
Type: string Flags: key Description: Set the action for this access rule.
access_rule.ipv4.source:
Type: object Flags: key Description: Source.
access_rule.ipv4.source.address:
Type: object Flags: key Description: Source address.
access_rule.ipv4.source.address.any:
Type: boolean (true) Flags: key Description: Any address.
access_rule.ipv4.source.address.name:
Type: string Flags: key Description: Address object name.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv4
143
access_rule.ipv4.source.address.group:
Type: string Flags: key Description: Group address object name.
access_rule.ipv4.source.port:
Type: object Flags: key Description: Specify a source port for this Access Policy.
access_rule.ipv4.source.port.any:
Type: boolean (true) Flags: key Description: Any source service.
access_rule.ipv4.source.port.name:
Type: string Flags: key Description: Service object name.
access_rule.ipv4.source.port.group:
Type: string Flags: key Description: Service object group name.
access_rule.ipv4.service:
Type: object Flags: key Description: Specify a destination service for this Access Policy.
access_rule.ipv4.service.any:
Type: boolean (true) Flags: key Description: Any destination service.
access_rule.ipv4.service.name:
Type: string Flags: key Description: Service object name.
access_rule.ipv4.service.group:
Type: string Flags: key Description: Service object group name.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv4
144
access_rule.ipv4.destination:
Type: object Flags: key Description: Destination.
access_rule.ipv4.destination.address:
Type: object Flags: key Description: Destination a destination address for this Access Policy.
access_rule.ipv4.destination.address.any:
Type: boolean (true) Flags: key Description: Any address.
access_rule.ipv4.destination.address.name:
Type: string Flags: key Description: Address object name.
access_rule.ipv4.destination.address.group:
Type: string Flags: key Description: Group address object name.
access_rule.ipv4.schedule:
Type: object Flags: key Description: Specify a schedule for this access policy.
access_rule.ipv4.schedule.always_on:
Type: boolean (true) Flags: key Description: Always on.
access_rule.ipv4.schedule.name:
Type: string Flags: key Description: Schedule object name.
access_rule.ipv4.users:
Type: object Flags: key Description: Specify users that are excluded from this access policy.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv4
145
access_rule.ipv4.users.included:
Type: object Flags: key Description: Specify included users.
access_rule.ipv4.users.included.all:
Type: boolean (true) Flags: key Description: All users.
access_rule.ipv4.users.included.guests:
Type: boolean (true) Flags: key Description: Guest users.
access_rule.ipv4.users.included.administrator:
Type: boolean (true) Flags: key Description: Administrator.
access_rule.ipv4.users.included.name:
Type: string Flags: key Description: Local user object name.
access_rule.ipv4.users.included.group:
Type: string Flags: key Description: Local user group object name.
access_rule.ipv4.users.excluded:
Type: object Flags: key Description: Specify excluded users.
access_rule.ipv4.users.excluded.none:
Type: boolean (true) Flags: key Description: No users.
access_rule.ipv4.users.excluded.guests:
Type: boolean (true) Flags: key Description: Guest users.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv4
146
access_rule.ipv4.users.excluded.administrator:
Type: boolean (true) Flags: key Description: Administrator.
access_rule.ipv4.users.excluded.name:
Type: string Flags: key Description: Local user object name.
access_rule.ipv4.users.excluded.group:
Type: string Flags: key Description: Local user group object name.
access_rule.ipv4.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
access_rule.ipv4.name:
Type: string Flags: required Description: Name.
access_rule.ipv4.comment:
Type: string Flags: -noneDescription:
access_rule.ipv4.enable:
Type: boolean (true|false) Flags: -noneDescription: Enable this access rule.
access_rule.ipv4.reflexive:
Type: boolean (true|false) Flags: -noneDescription: Configure a reflexive rule.
access_rule.ipv4.max_connections:
Type: number (uint8) Flags: -noneDescription: Integer in the form: D OR 0xHH
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv4
147
access_rule.ipv4.logging:
Type: boolean (true|false) Flags: -noneDescription: Enable logging when this access rule is used.
access_rule.ipv4.management:
Type: boolean (true|false) Flags: -noneDescription: Allow management traffic.
access_rule.ipv4.packet_monitoring:
Type: boolean (true|false) Flags: -noneDescription: Enable packet monitoring.
access_rule.ipv4.priority:
Type: object Flags: -noneDescription: Set access rule priority
access_rule.ipv4.priority.auto:
Type: boolean (true) Flags: -noneDescription: Set auto priority(priority = 0) for access rule.
access_rule.ipv4.priority.manual:
Type: number (uint32) Flags: -noneDescription: Integer in the form: D OR 0xHHHHHHHH
access_rule.ipv4.tcp:
Type: object Flags: -noneDescription: TCP.
access_rule.ipv4.tcp.timeout:
Type: number (uint32) Flags: -noneDescription: Integer in the form: D OR 0xHHHHHHHH
access_rule.ipv4.udp:
Type: object Flags: -noneDescription: UDP.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv4
148
access_rule.ipv4.udp.timeout:
Type: number (uint32) Flags: -noneDescription: Integer in the form: D OR 0xHHHHHHHH
access_rule.ipv4.fragments:
Type: boolean (true|false) Flags: -noneDescription: Allow fragmented packets on this access rule.
access_rule.ipv4.botnet_filter:
Type: boolean (true|false) Flags: -noneDescription: Enable Botnet filter.
access_rule.ipv4.connection_limit:
Type: object Flags: -noneDescription: Configure connection limit.
access_rule.ipv4.connection_limit.destination:
Type: object Flags: -noneDescription: Enable connection limit for each destination IP address. Set to null or {} if disabled/unconfigured.
access_rule.ipv4.connection_limit.destination.threshold:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
access_rule.ipv4.connection_limit.source:
Type: object Flags: -noneDescription: Enable connection limit for each source IP address. Set to null or {} if disabled/unconfigured.
access_rule.ipv4.connection_limit.source.threshold:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
access_rule.ipv4.flow_reporting:
Type: boolean (true|false) Flags: -noneDescription: Enable flow reporting.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv4
149
access_rule.ipv4.geo_ip_filter:
Type: boolean (true|false) Flags: -noneDescription: Enable Geo-IP filter.
access_rule.ipv4.single_sign_on:
Type: boolean (true|false) Flags: -noneDescription: Invoke single sign on to authenticate users.
access_rule.ipv4.cos_override:
Type: boolean (true|false) Flags: -noneDescription: Allow 802.1p marking to override DSCP values.
access_rule.ipv4.quality_of_service:
Type: object Flags: -noneDescription: Configure quality of service for rule.
access_rule.ipv4.quality_of_service.class_of_service:
Type: object Flags: -noneDescription: Set 802.1p marking action. Set to null or {} if disabled/unconfigured.
access_rule.ipv4.quality_of_service.class_of_service.explic it:
Type: string Flags: -noneDescription: Set explicit marking.
access_rule.ipv4.quality_of_service.class_of_service.map:
Type: boolean (true) Flags: -noneDescription: Map marking.
access_rule.ipv4.quality_of_service.class_of_service.prese rve:
Type: boolean (true) Flags: -noneDescription: Preserve marking.
access_rule.ipv4.quality_of_service.dscp:
Type: object Flags: -noneDescription: Set DSCP marking action.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv4
150
access_rule.ipv4.quality_of_service.dscp.explicit:
Type: number (uint8) Flags: -noneDescription: Integer in the form: D OR 0xHH
access_rule.ipv4.quality_of_service.dscp.map:
Type: boolean (true) Flags: -noneDescription: Map marking.
access_rule.ipv4.quality_of_service.dscp.preserve:
Type: boolean (true) Flags: -noneDescription: Preserve marking.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv4
151
21
API: Access Rules IPv6
· Endpoint on page 152 · Schema Structure on page 152
· Object: Access Rules IPv6 on page 152 · Collection: Access Rules IPv6 on page 154 · Schema Attributes on page 154
Endpoint
Endpoint
URI: /api/sonicos/access-rules/ipv6 Schema: collection#access-rule-ipv6-config URI: /api/sonicos/access-rules/ipv6/uuid/{UUID} Schema: collection#access-rule-ipv6-config
GET Empty
Empty
HTTP method and body
POST PUT
DELETE
Required Required Required
--
Required Ignored
Schema Structure
Topics:
· Object: Access Rules IPv6 on page 152
· Collection: Access Rules IPv6 on page 154
· Schema Attributes on page 154
Object: Access Rules IPv6
{ "access_rule": { "ipv6": { "from": "{string}", "to": "{string}", "action": "{string}",
"source": { "address": { "any": {true}, | "name": "{string}", | "group": "{string}" },
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv6
152
"port": { "any": {true},
| "name": "{string}", | "group": "{string}" } },
"service": { "any": {true},
| "name": "{string}", | "group": "{string}" },
"destination": { "address": { "any": {true}, | "name": "{string}", | "group": "{string}" }
},
"schedule": { "always_on": {true},
| "name": "{string}" },
"users": { "included": { "all": {true}, | "guests": {true}, | "administrator": {true}, | "name": "{string}", | "group": "{string}" },
"excluded": { "none": {true},
| "guests": {true}, | "administrator": {true}, | "name": "{string}", | "group": "{string}" } },
"uuid": "{string}", "name": "{string}", "comment": "{string}", "enable": {boolean}, "reflexive": {boolean}, "max_connections": {number}, "logging": {boolean}, "management": {boolean}, "packet_monitoring": {boolean},
"priority": { "auto": {true},
| "manual": {number} },
"tcp": { "timeout": {number}
},
"udp": { "timeout": {number}
},
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv6
153
"fragments": {boolean}, "botnet_filter": {boolean},
"connection_limit": { "destination": { "threshold": {number} },
"source": { "threshold": {number}
} },
"flow_reporting": {boolean}, "geo_ip_filter": {boolean}, "single_sign_on": {boolean}, "cos_override": {boolean},
"quality_of_service": { "class_of_service": { "explicit": "{string}", | "map": {true}, | "preserve": {true} },
"dscp": { "explicit": {number},
| "map": {true}, | "preserve": {true} } } } } }
Collection: Access Rules IPv6
{ "access_rules": [ object#access_rule-ipv6-config, ... ]
}
Schema Attributes
Topics:
· access_rule: on page 156 · access_rules: on page 157 · access_rule.ipv6: on page 157 · access_rule.ipv6.from: on page 157 · access_rule.ipv6.to: on page 157 · access_rule.ipv6.action: on page 157 · access_rule.ipv6.source: on page 157 · access_rule.ipv6.source.address: on page 157
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv6
154
· access_rule.ipv6.source.address.any: on page 157 · access_rule.ipv6.source.address.name: on page 157 · access_rule.ipv6.source.address.group: on page 158 · access_rule.ipv6.source.port: on page 158 · access_rule.ipv6.source.port.any: on page 158 · access_rule.ipv6.source.port.name: on page 158 · access_rule.ipv6.source.port.group: on page 158 · access_rule.ipv6.service: on page 158 · access_rule.ipv6.service.any: on page 158 · access_rule.ipv6.service.name: on page 158 · access_rule.ipv6.destination: on page 158 · access_rule.ipv6.destination.address: on page 159 · access_rule.ipv6.destination.address.any: on page 159 · access_rule.ipv6.destination.address.name: on page 159 · access_rule.ipv6.destination.address.group: on page 159 · access_rule.ipv6.schedule: on page 159 · access_rule.ipv6.schedule.always_on: on page 159 · access_rule.ipv6.schedule.name: on page 159 · access_rule.ipv6.users: on page 159 · access_rule.ipv6.users.included: on page 159 · access_rule.ipv4.users.included.all: on page 160 · access_rule.ipv6.users.included.guests: on page 160 · access_rule.ipv6.users.included.administrator: on page 160 · access_rule.ipv6.users.included.name: on page 160 · access_rule.ipv6.users.included.group: on page 160 · access_rule.ipv6.users.excluded: on page 160 · access_rule.ipv6.users.excluded.none: on page 160 · access_rule.ipv6.users.excluded.guests: on page 160 · access_rule.ipv6.users.excluded.administrator: on page 160 · access_rule.ipv6.users.excluded.name: on page 161 · access_rule.ipv6.users.excluded.group: on page 161 · access_rule.ipv6.uuid: on page 161 · access_rule.ipv6.name: on page 161 · access_rule.ipv6.comment: on page 161 · access_rule.ipv6.enable: on page 161 · access_rule.ipv6.reflexive: on page 161 · access_rule.ipv6.reflexive: on page 161
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv6
155
· access_rule.ipv6.max_connections: on page 161 · access_rule.ipv6.logging: on page 161 · access_rule.ipv6.management: on page 162 · access_rule.ipv6.packet_monitoring: on page 162 · access_rule.ipv6.priority: on page 162 · access_rule.ipv6.priority.auto: on page 162 · access_rule.ipv6.priority.manual: on page 162 · access_rule.ipv6.tcp: on page 162 · access_rule.ipv6.tcp.timeout: on page 162 · access_rule.ipv6.udp: on page 162 · access_rule.ipv6.udp.timeout: on page 162 · access_rule.ipv6.fragments: on page 163 · access_rule.ipv6.botnet_filter: on page 163 · access_rule.ipv6.connection_limit: on page 163 · access_rule.ipv6.connection_limit.destination: on page 163 · access_rule.ipv6.connection_limit.destination.threshold: on page 163 · access_rule.ipv6.connection_limit.source: on page 163 · access_rule.ipv6.connection_limit.source.threshold: on page 163 · access_rule.ipv6.flow_reporting: on page 163 · access_rule.ipv6.geo_ip_filter: on page 163 · access_rule.ipv6.single_sign_on: on page 164 · access_rule.ipv6.cos_override: on page 164 · access_rule.ipv6.quality_of_service: on page 164 · access_rule.ipv6.quality_of_service.class_of_service: on page 164 · access_rule.ipv6.quality_of_service.class_of_service.explicit: on page 164 · access_rule.ipv6.quality_of_service.class_of_service.map: on page 164 · access_rule.ipv6.quality_of_service.class_of_service.preserve: on page 164 · access_rule.ipv6.quality_of_service.dscp: on page 164 · access_rule.ipv6.quality_of_service.dscp.explicit: on page 164 · access_rule.ipv6.quality_of_service.dscp.map: on page 165 · access_rule.ipv6.quality_of_service.dscp.preserve: on page 165
access_rule:
Type: object Flags: -noneDescription: Access rule.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv6
156
access_rules:
Type: array Flags: -noneDescription: Access rule collection.
access_rule.ipv6:
Type: object Flags: -noneDescription: IPv6 access rule.
access_rule.ipv6.from:
Type: string Flags: key Description: Zone object name.
access_rule.ipv6.to:
Type: string Flags: key Description: Zone object name.
access_rule.ipv6.action:
Type: string Flags: key Description: Set the action for this access rule.
access_rule.ipv6.source:
Type: object Flags: key Description: Source.
access_rule.ipv6.source.address:
Type: object Flags: key Description: Source address.
access_rule.ipv6.source.address.any:
Type: boolean (true) Flags: key Description: Any address.
access_rule.ipv6.source.address.name:
Type: string Flags: key Description: Address object name.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv6
157
access_rule.ipv6.source.address.group:
Type: string Flags: key Description: Group address object name.
access_rule.ipv6.source.port:
Type: object Flags: key Description: Specify a source port for this Access Policy.
access_rule.ipv6.source.port.any:
Type: boolean (true) Flags: key Description: Any source service.
access_rule.ipv6.source.port.name:
Type: string Flags: key Description: Service object name.
access_rule.ipv6.source.port.group:
Type: string Flags: key Description: Service object group name.
access_rule.ipv6.service:
Type: object Flags: key Description: Specify a destination service for this Access Policy.
access_rule.ipv6.service.any:
Type: boolean (true) Flags: key Description: Any destination service.
access_rule.ipv6.service.name:
Type: string Flags: key Description: Service object name.
access_rule.ipv6.service.group:
Type: string Flags: key Description: Service object group name.
access_rule.ipv6.destination:
Type: object Flags: key Description: Destination.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv6
158
access_rule.ipv6.destination.address:
Type: object Flags: key Description: Destination a destination address for this Access Policy.
access_rule.ipv6.destination.address.any:
Type: boolean (true) Flags: key Description: Any address.
access_rule.ipv6.destination.address.name:
Type: string Flags: key Description: Address object name.
access_rule.ipv6.destination.address.group:
Type: string Flags: key Description: Group address object name.
access_rule.ipv6.schedule:
Type: object Flags: key Description: Specify a schedule for this access policy.
access_rule.ipv6.schedule.always_on:
Type: boolean (true) Flags: key Description: Always on.
access_rule.ipv6.schedule.name:
Type: string Flags: key Description: Schedule object name.
access_rule.ipv6.users:
Type: object Flags: key Description: Specify users that are excluded from this access policy.
access_rule.ipv6.users.included:
Type: object Flags: key Description: Specify included users.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv6
159
access_rule.ipv4.users.included.all:
Type: boolean (true) Flags: key Description: All users.
access_rule.ipv6.users.included.guests:
Type: boolean (true) Flags: key Description: Guest users.
access_rule.ipv6.users.included.administrator:
Type: boolean (true) Flags: key Description: Administrator.
access_rule.ipv6.users.included.name:
Type: string Flags: key Description: Local user object name.
access_rule.ipv6.users.included.group:
Type: string Flags: key Description: Local user group object name.
access_rule.ipv6.users.excluded:
Type: object Flags: key Description: Specify excluded users.
access_rule.ipv6.users.excluded.none:
Type: boolean (true) Flags: key Description: No users.
access_rule.ipv6.users.excluded.guests:
Type: boolean (true) Flags: key Description: Guest users.
access_rule.ipv6.users.excluded.administrator:
Type: boolean (true) Flags: key Description: Administrator.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv6
160
access_rule.ipv6.users.excluded.name:
Type: string Flags: key Description: Local user object name.
access_rule.ipv6.users.excluded.group:
Type: string Flags: key Description: Local user group object name.
access_rule.ipv6.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
access_rule.ipv6.name:
Type: string Flags: required Description: Name.
access_rule.ipv6.comment:
Type: string Flags: -noneDescription:
access_rule.ipv6.enable:
Type: boolean (true|false) Flags: -noneDescription: Enable this access rule.
access_rule.ipv6.reflexive:
Type: boolean (true|false) Flags: -noneDescription: Configure a reflexive rule.
access_rule.ipv6.max_connections:
Type: number (uint8) Flags: -noneDescription: Integer in the form: D OR 0xHH
access_rule.ipv6.logging:
Type: boolean (true|false) Flags: -noneDescription: Enable logging when this access rule is used.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv6
161
access_rule.ipv6.management:
Type: boolean (true|false) Flags: -noneDescription: Allow management traffic.
access_rule.ipv6.packet_monitoring:
Type: boolean (true|false) Flags: -noneDescription: Enable packet monitoring.
access_rule.ipv6.priority:
Type: object Flags: -noneDescription: Set access rule priority
access_rule.ipv6.priority.auto:
Type: boolean (true) Flags: -noneDescription: Set auto priority(priority = 0) for access rule.
access_rule.ipv6.priority.manual:
Type: number (uint32) Flags: -noneDescription: Integer in the form: D OR 0xHHHHHHHH
access_rule.ipv6.tcp:
Type: object Flags: -noneDescription: TCP.
access_rule.ipv6.tcp.timeout:
Type: number (uint32) Flags: -noneDescription: Integer in the form: D OR 0xHHHHHHHH
access_rule.ipv6.udp:
Type: object Flags: -noneDescription: UDP.
access_rule.ipv6.udp.timeout:
Type: number (uint32) Flags: -noneDescription: Integer in the form: D OR 0xHHHHHHHH
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv6
162
access_rule.ipv6.fragments:
Type: boolean (true|false) Flags: -noneDescription: Allow fragmented packets on this access rule.
access_rule.ipv6.botnet_filter:
Type: boolean (true|false) Flags: -noneDescription: Enable Botnet filter.
access_rule.ipv6.connection_limit:
Type: object Flags: -noneDescription: Configure connection limit.
access_rule.ipv6.connection_limit.destination:
Type: object Flags: -noneDescription: Enable connection limit for each destination IP address. Set to null or {} if disabled/unconfigured.
access_rule.ipv6.connection_limit.destination.threshold:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
access_rule.ipv6.connection_limit.source:
Type: object Flags: -noneDescription: Enable connection limit for each source IP address. Set to null or {} if disabled/unconfigured.
access_rule.ipv6.connection_limit.source.threshold:
Type: number (uint16) Flags: -noneDescription: Integer in the form: D OR 0xHHHH
access_rule.ipv6.flow_reporting:
Type: boolean (true|false) Flags: -noneDescription: Enable flow reporting.
access_rule.ipv6.geo_ip_filter:
Type: boolean (true|false) Flags: -noneDescription: Enable Geo-IP filter.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv6
163
access_rule.ipv6.single_sign_on:
Type: boolean (true|false) Flags: -noneDescription: Invoke single sign on to authenticate users.
access_rule.ipv6.cos_override:
Type: boolean (true|false) Flags: -noneDescription: Allow 802.1p marking to override DSCP values.
access_rule.ipv6.quality_of_service:
Type: object Flags: -noneDescription: Configure quality of service for rule.
access_rule.ipv6.quality_of_service.class_of_service:
Type: object Flags: -noneDescription: Set 802.1p marking action. Set to null or {} if disabled/unconfigured.
access_rule.ipv6.quality_of_service.class_of_service.explic it:
Type: string Flags: -noneDescription: Set explicit marking.
access_rule.ipv6.quality_of_service.class_of_service.map:
Type: boolean (true) Flags: -noneDescription: Map marking.
access_rule.ipv6.quality_of_service.class_of_service.prese rve:
Type: boolean (true) Flags: -noneDescription: Preserve marking.
access_rule.ipv6.quality_of_service.dscp:
Type: object Flags: -noneDescription: Set DSCP marking action.
access_rule.ipv6.quality_of_service.dscp.explicit:
Type: number (uint8) Flags: -noneDescription: Integer in the form: D OR 0xHH
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv6
164
access_rule.ipv6.quality_of_service.dscp.map:
Type: boolean (true) Flags: -noneDescription: Map marking.
access_rule.ipv6.quality_of_service.dscp.preserve:
Type: boolean (true) Flags: -noneDescription: Preserve marking.
SonicWall® SonicOS API 6.5.4 Reference API: Access Rules IPv6
165
22
API: Route Policies IPv4
· Endpoint on page 166 · Schema Structure on page 166
· Object: Route Policies IPv4 on page 166 · Collection: Route Policies IPv4 on page 167 · Schema Attributes on page 167
Endpoint
Endpoint GET
URI: /api/sonicos/route-policies/ipv4
Empty
Schema: collection#route-policy-ipv4-config
URI: /api/sonicos/route-policies/ipv4/uuid/{UUID} Empty
Schema: collection#route-policy-ipv4-config
HTTP method and body
POST PUT
DELETE
Required Required Required
--
Required Ignored
Schema Structure
Topics:
· Object: Route Policies IPv4 on page 166 · Collection: Route Policies IPv4 on page 167 · Schema Attributes on page 167
Object: Route Policies IPv4
{ "route_policy": { "ipv4": { "interface": "{string}", "metric": {number},
"source": { "any": {true},
| "name": "{string}", | "group": "{string}" },
"destination": {
SonicWall® SonicOS API 6.5.4 Reference API: Route Policies IPv4
166
"any": {true}, | "name": "{string}", | "group": "{string}" },
"service": { "any": {true},
| "name": "{string}", | "group": "{string}" },
"gateway": { "default": {true},
| "name": "{string}", | "host": "{string}" },
"uuid": "{string}", "name": "{string}", "disable_on_interface_down": {boolean}, "vpn_precedence": {boolean}, "auto_add_access_rules": {boolean}, "probe": "{string}", "disable_when_probes_succeed": {boolean}, "default_probe_state_up": {boolean}, "comment": "{string}", "tcp_acceleration": {boolean}, "wxa_group": "{string}" } } }
Collection: Route Policies IPv4
{ "route_policies": [ object#route-policy-ipv4-config, ... ]
}
Schema Attributes
Topics:
· route_policy: on page 168 · route_policies: on page 168 · route_policy.ipv4: on page 168 · route_policy.ipv4.interface: on page 169 · route_policy.ipv4.metric: on page 169 · route_policy.ipv4.source: on page 169 · route_policy.ipv4.source.any: on page 169 · route_policy.ipv4.source.name: on page 169 · route_policy.ipv4.source.group: on page 169 · route_policy.ipv4.destination: on page 169
SonicWall® SonicOS API 6.5.4 Reference API: Route Policies IPv4
167
· route_policy.ipv4.destination.any: on page 169 · route_policy.ipv4.destination.name: on page 169 · route_policy.ipv4.destination.group: on page 170 · route_policy.ipv4.service: on page 170 · route_policy.ipv4.service.any: on page 170 · route_policy.ipv4.service.name: on page 170 · route_policy.ipv4.service.group: on page 170 · route_policy.ipv4.service: on page 170 · route_policy.ipv4.service.any: on page 170 · route_policy.ipv4.service.name: on page 170 · route_policy.ipv4.service.group: on page 170 · route_policy.ipv4.gateway: on page 170 · route_policy.ipv4.gateway.default: on page 170 · route_policy.ipv4.gateway.name: on page 170 · route_policy.ipv4.gateway.host: on page 170 · route_policy.ipv4.uuid: on page 171 · route_policy.ipv4.name: on page 171 · route_policy.ipv4.disable_on_interface_down: on page 171 · route_policy.ipv4.vpn_precedence: on page 171 · route_policy.ipv4.auto_add_access_rules: on page 171 · route_policy.ipv4.probe: on page 171 · route_policy.ipv4.disable_when_probes_succeed: on page 171 · route_policy.ipv4.default_probe_state_up: on page 171 · route_policy.ipv4.comment: on page 171 · route_policy.ipv4.tcp_acceleration: on page 172 · route_policy.ipv4.wxa_group: on page 172
route_policy:
Type: object Flags: -noneDescription: Route policy.
route_policies:
Type: array Flags: -noneDescription: Route policy collection.
route_policy.ipv4:
Type: object Flags: -noneDescription: IPv4 route policy.
SonicWall® SonicOS API 6.5.4 Reference API: Route Policies IPv4
168
route_policy.ipv4.interface:
Type: string Flags: key Description: Route interface name.
route_policy.ipv4.metric:
Type: number (uint8) Flags: key Description: Integer in the form: D OR 0xHH
route_policy.ipv4.source:
Type: object Flags: key Description: Set route policy source.
route_policy.ipv4.source.any:
Type: boolean (true) Flags: key Description: Any host.
route_policy.ipv4.source.name:
Type: string Flags: key Description: Host/network/range address object name.
route_policy.ipv4.source.group:
Type: string Flags: key Description: Group address object name.
route_policy.ipv4.destination:
Type: object Flags: key Description: Set route policy destination.
route_policy.ipv4.destination.any:
Type: boolean (true) Flags: key Description: Any host.
route_policy.ipv4.destination.name:
Type: string Flags: key Description: FQDN/host/network/range address object name.
SonicWall® SonicOS API 6.5.4 Reference API: Route Policies IPv4
169
route_policy.ipv4.destination.group:
Type: string Flags: key Description: Group address object name.
route_policy.ipv4.service:
Type: object Flags: key Description: Set route policy service.
route_policy.ipv4.service.any:
Type: boolean (true) Flags: key Description: Any service.
route_policy.ipv4.service.name:
Type: string Flags: key Description: Service object name.
route_policy.ipv4.service.group:
Type: string Flags: key Description: Service object group name.
route_policy.ipv4.gateway:
Type: object Flags: key Description: Set route policy gateway.
route_policy.ipv4.gateway.default:
Type: boolean (true) Flags: key Description: Default gateway 0.0.0.0
route_policy.ipv4.gateway.name:
Type: string Flags: key Description: Host address object name.
route_policy.ipv4.gateway.host:
Type: string (ip) Flags: key Description: IPv4 host address in the form: D.D.D.D
SonicWall® SonicOS API 6.5.4 Reference API: Route Policies IPv4
170
route_policy.ipv4.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
route_policy.ipv4.name:
Type: string Flags: required Description: Name.
route_policy.ipv4.disable_on_interface_down:
Type: boolean (true|false) Flags: -noneDescription: Disable route when the interface is disconnected.
route_policy.ipv4.vpn_precedence:
Type: boolean (true|false) Flags: -noneDescription: Allow VPN path to take precedence.
route_policy.ipv4.auto_add_access_rules:
Type: boolean (true|false) Flags: -noneDescription: Enable auto-add access rules.
route_policy.ipv4.probe:
Type: string Flags: -noneDescription: Atom Object name.
route_policy.ipv4.disable_when_probes_succeed:
Type: boolean (true|false) Flags: -noneDescription: Disable route when probe succeeds.
route_policy.ipv4.default_probe_state_up:
Type: boolean (true|false) Flags: -noneDescription: Set probe default state to up.
route_policy.ipv4.comment:
Type: string Flags: -noneDescription:
SonicWall® SonicOS API 6.5.4 Reference API: Route Policies IPv4
171
route_policy.ipv4.tcp_acceleration:
Type: boolean (true|false) Flags: -noneDescription: Enable permit TCP acceleration.
route_policy.ipv4.wxa_group:
Type: string Flags: -noneDescription: WXA group name.
SonicWall® SonicOS API 6.5.4 Reference API: Route Policies IPv4
172
23
API: Route Policies IPv6
· Endpoint on page 173 · Schema Structure on page 173
· Object: Route Policies IPv6 on page 173 · Collection: Route Policies IPv6 on page 174 · Schema Attributes on page 174
Endpoint
Endpoint GET
URI: /api/sonicos/route-policies/ipv6
Empty
Schema: collection#route-policy-ipv6-config
URI: /api/sonicos/route-policies/ipv6/uuid/{UUID} Empty
Schema: collection#route-policy-ipv6-config
HTTP method and body
POST PUT
DELETE
Required Required Required
--
Required Ignored
Schema Structure
Topics:
· Object: Route Policies IPv6 on page 173 · Collection: Route Policies IPv6 on page 174 · Schema Attributes on page 174
Object: Route Policies IPv6
{ "route_policy": { "ipv6": { "interface": "{string}", "metric": {number},
"source": { "any": {true},
| "name": "{string}", | "group": "{string}" },
"destination": {
SonicWall® SonicOS API 6.5.4 Reference API: Route Policies IPv6
173
"any": {true}, | "name": "{string}", | "group": "{string}" },
"service": { "any": {true},
| "name": "{string}", | "group": "{string}" },
"gateway": { "default": {true},
| "name": "{string}", | "host": "{string}" },
"uuid": "{string}", "name": "{string}", "disable_on_interface_down": {boolean}, "vpn_precedence": {boolean}, "auto_add_access_rules": {boolean}, "probe": "{string}", "disable_when_probes_succeed": {boolean}, "default_probe_state_up": {boolean}, "comment": "{string}" } } }
Collection: Route Policies IPv6
{ "route_policies": [ object#route-policy-ipv6-config, ... ]
}
Schema Attributes
Topics:
· route_policy: on page 175 · route_policies: on page 175 · route_policy.ipv6: on page 175 · route_policy.ipv6.interface: on page 175 · route_policy.ipv6.metric: on page 175 · route_policy.ipv6.source: on page 176 · route_policy.ipv6.source.any: on page 176 · route_policy.ipv6.destination.name: on page 176 · route_policy.ipv6.destination.group: on page 176 · route_policy.ipv6.service: on page 176
SonicWall® SonicOS API 6.5.4 Reference API: Route Policies IPv6
174
· route_policy.ipv6.service.any: on page 177 · route_policy.ipv6.service.name: on page 177 · route_policy.ipv6.service.group: on page 177 · route_policy.ipv6.gateway: on page 177 · route_policy.ipv6.gateway.default: on page 177 · route_policy.ipv6.gateway.name: on page 177 · route_policy.ipv6.gateway.host: on page 177 · route_policy.ipv6.uuid: on page 177 · route_policy.ipv6.name: on page 177 · route_policy.ipv6.disable_on_interface_down: on page 178 · route_policy.ipv6.vpn_precedence: on page 178 · route_policy.ipv6.auto_add_access_rules: on page 178 · route_policy.ipv6.probe: on page 178 · route_policy.ipv6.disable_when_probes_succeed: on page 178 · route_policy.ipv6.default_probe_state_up: on page 178
route_policy:
Type: object Flags: -noneDescription: Route policy.
route_policies:
Type: array Flags: -noneDescription: Route policy collection.
route_policy.ipv6:
Type: object Flags: key Description: IPv6 route policy.
route_policy.ipv6.interface:
Type: string Flags: key Description: Route interface name.
route_policy.ipv6.metric:
Type: number (uint8) Flags: key Description: Integer in the form: D OR 0xHH
SonicWall® SonicOS API 6.5.4 Reference API: Route Policies IPv6
175
route_policy.ipv6.source:
Type: object Flags: key Description: Set route policy source.
route_policy.ipv6.source.any:
Type: boolean (true) Flags: key Description: Any host.
route_policy.ipv6.source.name:
Type: string Flags: key Description: Host/network/range address object name.
route_policy.ipv6.source.group:
Type: string Flags: key Description: Group address object name.
route_policy.ipv6.destination:
Type: object Flags: key Description: Set route policy destination.
route_policy.ipv6.destination.any:
Type: boolean (true) Flags: key Description: Any host.
route_policy.ipv6.destination.name:
Type: string Flags: key Description: FQDN/host/network/range address object name.
route_policy.ipv6.destination.group:
Type: string Flags: key Description: Group address object name.
route_policy.ipv6.service:
Type: object Flags: key Description: Set route policy service.
SonicWall® SonicOS API 6.5.4 Reference API: Route Policies IPv6
176
route_policy.ipv6.service.any:
Type: boolean (true) Flags: key Description: Any service.
route_policy.ipv6.service.name:
Type: string Flags: key Description: Service object name.
route_policy.ipv6.service.group:
Type: string Flags: key Description: Service object group name.
route_policy.ipv6.gateway:
Type: object Flags: key Description: Set route policy gateway.
route_policy.ipv6.gateway.default:
Type: boolean (true) Flags: key Description: Default gateway 0.0.0.0/::
route_policy.ipv6.gateway.name:
Type: string Flags: key Description: Host address object name.
route_policy.ipv6.gateway.host:
Type: string (ip) Flags: key Description: IPv4 host address in the form: D.D.D.D IPv6 host address in the form: HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH:HHHH.
route_policy.ipv6.uuid:
Type: string Flags: key Description: UUID in the form: HHHHHHHH-HHHH-HHHH-HHHH-HHHHHHHHHHHH
route_policy.ipv6.name:
Type: string Flags: required Description: Name.
SonicWall® SonicOS API 6.5.4 Reference API: Route Policies IPv6
177
route_policy.ipv6.disable_on_interface_down:
Type: boolean (true|false) Flags: -noneDescription: Disable route when the interface is disconnected.
route_policy.ipv6.vpn_precedence:
Type: boolean (true|false) Flags: -noneDescription: Allow VPN path to take precedence.
route_policy.ipv6.auto_add_access_rules:
Type: boolean (true|false) Flags: -noneDescription: Enable auto-add access rules.
route_policy.ipv6.probe:
Type: string Flags: -noneDescription: Atom Object name.
route_policy.ipv6.disable_when_probes_succeed:
Type: boolean (true|false) Flags: -noneDescription: Disable route when probe succeeds.
route_policy.ipv6.default_probe_state_up:
Type: boolean (true|false) Flags: -noneDescription: Set probe default state to up.
route_policy.ipv6.comment:
Type: string Flags: -noneDescription:
SonicWall® SonicOS API 6.5.4 Reference API: Route Policies IPv6
178
24
SonicWall Support
Technical support is available to customers who have purchased SonicWall products with a valid maintenance contract and to customers who have trial versions. The Support Portal provides self-help tools you can use to solve problems quickly and independently, 24 hours a day, 365 days a year. To access the Support Portal, go to https://www.sonicwall.com/support. The Support Portal enables you to:
· View knowledge base articles and technical documentation · View video tutorials · Access MySonicWall · Learn about SonicWall professional services · Review SonicWall Support services and warranty information · Register for training and certification · Request technical support or customer service To contact SonicWall Support, visit https://www.sonicwall.com/support/contact-support.
SonicWall® SonicOS API 6.5.4 Reference SonicWall Support
179
About This Document
Legend
WARNING: A WARNING icon indicates a potential for property damage, personal injury, or death.
CAUTION: A CAUTION icon indicates potential damage to hardware or loss of data if instructions are not followed.
IMPORTANT, NOTE, TIP, MOBILE, or VIDEO: An information icon indicates supporting information.
SonicOS Reference Updated - May 2019 Software Version - 6.5.4 232-004282-04 Rev A
Copyright © 2019 SonicWall Inc. All rights reserved.
SonicWall is a trademark or registered trademark of SonicWall Inc. and/or its affiliates in the U.S.A. and/or other countries. All other trademarks and registered trademarks are property of their respective owners The information in this document is provided in connection with SonicWall Inc. and/or its affiliates' products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with the sale of SonicWall products. EXCEPT AS SET FORTH IN THE TERMS AND CONDITIONS AS SPECIFIED IN THE LICENSE AGREEMENT FOR THIS PRODUCT, SONICWALL AND/OR ITS AFFILIATES ASSUME NO LIABILITY WHATSOEVER AND DISCLAIMS ANY EXPRESS, IMPLIED OR STATUTORY WARRANTY RELATING TO ITS PRODUCTS INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NON- INFRINGEMENT. IN NO EVENT SHALL SONICWALL AND/OR ITS AFFILIATES BE LIABLE FOR ANY DIRECT, INDIRECT, CONSEQUENTIAL, PUNITIVE, SPECIAL OR INCIDENTAL DAMAGES (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS, BUSINESS INTERRUPTION OR LOSS OF INFORMATION) ARISING OUT OF THE USE OR INABILITY TO USE THIS DOCUMENT, EVEN IF SONICWALL AND/OR ITS AFFILIATES HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. SonicWall and/or its affiliates make no representations or warranties with respect to the accuracy or completeness of the contents of this document and reserves the right to make changes to specifications and product descriptions at any time without notice. SonicWall Inc. and/or its affiliates do not make any commitment to update the information contained in this document. For more information, visit https://www.sonicwall.com/legal. End User Product Agreement To view the SonicWall End User Product Agreement, go to: https://www.sonicwall.com/en-us/legal/license-agreements. Open Source Code SonicWall is able to provide a machine-readable copy of open source code with restrictive licenses such as GPL, LGPL, AGPL when applicable per license requirements. To obtain a complete machine-readable copy, send your written requests, along with certified check or money order in the amount of USD 25.00 payable to "SonicWall Inc.", to:
General Public License Source Code Request SonicWall Inc. Attn: Jennifer Anderson 1033 McCarthy Blvd Milpitas, CA 95035
SonicWall® SonicOS API 6.5.4 Reference SonicWall Support
180
Acrobat Elements 15.0 (Windows)
