Chapter 1 Introduction
The MCUXpresso Config Tools set is a suite of evaluation and configuration tools that help you from initial evaluation to production software development. Following tools are included:
Table 1. MCUXpresso Config Tools
Name
Description
Pins Tool
Enables you to configure the pins of a device. Pins tool enables you to create, inspect, change, and modify any aspect of the pin configuration and muxing of the device.
Clocks Tool
Enables you to configure initialization of the system clock (core, system, bus, and peripheral clocks) and generates the C code with clock initialization functions and configuration structures.
Peripherals Tool Enable you to configure the initialization for the MCUXpresso SDK drivers.
Device
Enables you to generate a Device Configuration Data (DCD) image using the format and constrains
Configuration Tool specified in the Boot ROM reference manual.
TEE Tool
Enables you to configure security policies of memory areas, bus masters, and peripherals, in order to isolate and safeguard sensitive areas of your application.
1.1 Versions
The suite of these tools is called MCUXpresso Config Tools. These tools are provided as an online Web application or as a desktop application or as integrated version in MCUXpresso IDE.
NOTE The desktop version of the tool contacts the NXP server and fetches the list of the available processors. Once used, the processors data is retrieved on demand.
TIP To use the desktop tool in the offline mode, create a configuration for the given processor while online. The tool will then store the processors locally in the user folder and enable faster access and offline use. Otherwise, it is possible to download and export the data using the Export menu.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
5 / 136
NXP Semiconductors Figure 1. Desktop version of Pins tool
Introduction
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
6 / 136
NXP Semiconductors
Chapter 2 User Interface
2.1 Creating, saving, and opening a configuration
In this context, configuration stands for common tools settings stored in an MEX (Microcontrollers Export Configuration) file. This file contains settings of all available toolsand can be used in both web and desktop versions.
The folder with the saved MEX file must contain exactly one project file to be able to parse the toolchain project. The file type depends on the toolchain of the project and can be one of the following:
Table 2. Supported toolchain project files
Toolchain
Project file
IAR EW
EWP
MDK Vision
UVPROJX
ARM GCC
CMakeLists.txt
2.1.1 Creating a new configuration
In Project Explorer, right-click the Eclipse project based on MCUXpresso SDK, and select MCUXpresso Config Tool > Open Pins. One of the following actions takes place:
� If the project contains an MEX file in the root folder, the file is opened. � If the project contains any source file with tool configuration (pin_mux.c, clock_config.c and/or peripheral.c), the tool
configuration is imported from this file. � Otherwise, an empty/default configuration for selected processor is created.
NOTE The same command can be invoked also from popup menu on the MEX file or from toolbar in Project Explorer view.
2.1.2 Saving a configuration
You can save your configuration by clicking the Save button on the toolbar or selecting File>Save from the Main Menu. The command is enabled only if the configuration is dirty (unsaved) and one of MCUXpresso Config Tool perspective is opened. The configuration is always saved into an MEX file stored in the project root folder. If file doesn't exist, new one is created using current project name.
NOTE Configuration is also saved when you select Update Code in the toolbar.
2.1.3 Importing sources
To import source code files, do the following: 1. In the Menu bar, select File > Import.... 2. From the list, select MCUXpresso Config Tools>Import Source.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
7 / 136
NXP Semiconductors
User Interface
Figure 2. Import Source wizard
3. Click Next. 4. On the next page, click Browse to specify the location of the source file. 5. Select the source file you wish to import and click Open. 6. On the next page, select which functional groups to import (based on tools) by selecting the checkbox in the left column. 7. Define how to import the functional groups by selecting one of the two available options in the dropdown menu in the
right column: � Rename � All files are merged into the current configuration. It imports all the functions only. If the imported function has the same name as an existing one, it is automatically renamed to the indexed one. For example, if BOARD_InitPins already exists in the configuration then the imported function is renamed to BOARD_InitPins1. � Overwrite � All files are merged into the current configuration. It imports all the functions only. If the imported function has the same name as an existing one, then the existing one is replaced with the imported one.
8. Click Finish.
NOTE Only C files with valid YAML configuration can be imported. It imports the configuration only, then the whole C file is re-created based on this setting. The rest of the C and DTSI files are ignored.
2.1.3.1 Importing configuration
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
8 / 136
NXP Semiconductors
2.1.3.2 Importing registers You can import register configuration from a processor memory dump.
NOTE Currently, register configuration can be imported into the Clocks tool only.
User Interface
NOTE A processor memory-dump file in the CSV or S19 format is required for importing register configuration.
Figure 3. Import Registers
To import register configuration, do the following:
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
9 / 136
NXP Semiconductors
User Interface
1. In the Menu bar, select File > Import.... Alternatively, click the Import Registers Configuration button in the Registers view, or drag-and-drop the memory dump file anywhere in the Registers view area.
Figure 4. Import Registers Configuration
2. In the Import wizard, select MCUXpresso Config Tools > Import Registers. 3. Click Next. 4. On the next page, click Browse to specify the location of the registers configuration. 5. Select the registers file you wish to import, and click OK. 6. By default, the imported register configuration will overwrite the existing functional group. If you want a new functional group
to be created instead, select the Create new functional group option button, and specify the functional group name. 7. Click Finish.
NOTE All registers are imported from the dump file regardless of their relevance to clock configuration, therefore, the list can contain registers not needed by the Clocks tool.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
10 / 136
NXP Semiconductors
User Interface
2.1.4 Restoring configuration from source code
The generated code contains information about the Clocks tool settings that are used in the tool (block within a comment in YAML format).
The following is an example of the settings information in the generated source code.
Figure 5. Setting Information in the source code If this information is not corrupted, it's possible to re-import the clock settings into the tool using the following steps.
1. In the Menu bar, select File > Import.... 2. From the list, select MCUXpresso Config Tools > Clocks Tool > Import Source Files. 3. Click Next. 4. Click Browse. 5. Navigate and select the clock_config.c file previously produced by the Clocks tool. 6. If the settings parse successfully, clock configurations are added into the current global configuration.
2.2 Toolbar
The toolbar is located on the top of the window and includes buttons/menus of frequently used actions common to all tools. See the following sections for more information.
Table 3. Toolbar
Item
Description
Config Tools Overview
Open the Overview dialog with information about currently-used tools.
Show Problems View
Open the Problems view.
Update Code
Open the update dialog allowing you to update generated peripheral initialization code directly within specified toolchain project.
Table continues on the next page...
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
11 / 136
NXP Semiconductors
User Interface
Table 3. Toolbar (continued) Item Functional group selection
Call from default initialization Functional group properties
Tool selection Undo/Redo
Description
Select functional group. Functional group in the Peripherals tool represents a group of peripherals that are initialized as a group. The tool generates a C function for each function group that contains the initialization code.
Set the current functional group to be initialized by the default initialization function.
Open the Functional group properties dialog to modify name and other properties of the function group.
Display icons of individual tools. Use them to switch between tools.
Undo/Redo last action.
In addition, the toolbar may contain additional items depending on the selected tool. See the chapters dedicated to individual tools for more information.
2.2.1 Eclipse project selection
You can use the Eclipse project drop-down menu to switch between projects.
2.2.2 Config Tools Overview
Click the Config Tools Overview button to open Config Tools Overview and inspect information about the configuration, hardware, and project. For more information, see the Config Tools Overview section.
2.2.3 Show Problems View
Click the Show Problems View to open/highlight the Problems view and inspect any errors in your configuration. See Problems view for more information.
Button color depends on issue type. Red indicates the presence of at least one error, yellow indicates the presence of at least one warning.
2.2.4 Update code
To update the generated code in the related toolchain project, click the Update Code button. In the window, select the tools or files you want to update. If the file is updated automatically, the button is filled with a black square. The reason is displayed in the tooltip.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
12 / 136
NXP Semiconductors
User Interface
Figure 6. Update Files window To inspect the code difference between the versions, click the change link.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
13 / 136
NXP Semiconductors
User Interface
Figure 7. Show differences
To update the project without opening the Update Files dialog, deselect the Always show details before Update Code checkbox. To access the Update Code dialog from the Update Code dropdown menu, select Open Update Code Dialog.
Figure 8. Update Code dropdown menu
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
14 / 136
NXP Semiconductors
NOTE The generated code is always overwritten.
User Interface
NOTE Previous version of the file can be retrieved from Eclipse local history.
The Update Code action is enabled under following conditions: � If the MEX configuration is saved in a toolchain project, the processor selected in the tool matches with processor selected in the toolchain project � Core is selected (for multicore processors)
2.2.5 Functional groups
Every Pins/Clocks/Peripherals configuration can contain several functional groups.
These groups represent functions which will be generated into source code. Use the dropdown menu to switch between functional groups and configure them.
Figure 9. Functional groups
You can use two additional buttons to further configure functional groups:
Table 4. Functional Groups Icon
Description
Toggle "Called from default initialization function" feature (in source code)
Opens the Functional group properties window
NOTE Red/orange background indicates errors/warnings in the configuration.
2.2.5.1 Functional group properties In the Functional Group Properties window, you can configure several options for functions and code generation. Each settings is applicable for the selected function. You can specify generated function name, select core (for multicore processors only) that is affecting the generated source code, or write function description (this description will be generated in the C file). You can also add, copy, and remove functional groups as needed. Aside from name and description, you can choose to set the following parameters for selected functional groups:
� Set custom #define prefix - Enable to use the specified prefix for the identifiers in the source code. You can also modify the functions order (on the left), the order is applied in the generated code.
NOTE Not all processors support this option.
� Called from default initialization function - Enable to call the function is called from the default initialization function. � Clock gate enable
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
15 / 136
NXP Semiconductors
User Interface
Figure 10. Functional group properties for the Pins tool
2.2.6 Undo/Redo actions
You can reverse your actions by using Undo/Redo buttons available in the Toolbar. You can also perform these actions from the Edit menu in the Menu bar.
Table 5. Undo/reto actions
Icon
Description
Cancels the previous action
Cancels the previous undo action
2.2.7 Selecting the tools
Buttons on the extreme right-hand side of the toolbar represent available tools. Click the icons to quickly navigate between .
2.3 Status bar
The status bar is visible at the bottom part of the GUI. Status bar indicates error and warning state of the currently selected functional group.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
16 / 136
NXP Semiconductors
User Interface
2.4 Preferences
To configure preferences in the Preferences dialog, select Window>Preferences>MCUXpresso Config Tools from the Menu bar.
NOTE You can restore settings to default by selecting Restore Defaults in the lower right corner of the dialog.
Figure 11. Preferences Several settings are available. Table 6. Preferences Item Line ending style
Generate files read-only
Description
Select between Windows (CR + LF), Linux/Mac (LF), or Default (based on host).
Prevent modifying the source files unintentionally. Generated source files are marked as read-only.
Table continues on the next page...
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
17 / 136
NXP Semiconductors
Table 6. Preferences (continued) Item Generate source folder
Create empty configuration if no yaml is available Always overwrite files without asking Always show details before Update Code Undo history size
Proxy connection
User Interface
Description At build time, automatically create a folder including source files. Generates a configuration even if no yaml is present. Update existing files automatically, without prompting. Review changes before the project is updated. Enter the maximum number of steps that can be undone. Enter 0 to disable.
� Direct � Connect directly and avoid a proxy connection. � Native � Use system proxy configuration for
network connection.
NOTE The proxy settings are copied from operating system settings. In case of error, you can specify proxy information in the tools.ini file, located in the <install_dir>/bin/ folder. Make sure the file contains the following lines:
-- Djava.net.useSystemProxies=true (already present by default)
-- Dhttp.proxyHost=<somecompany.proxy.net> -- Dhttp.proxyPort=80
NOTE Authentication is not supported.
Work Offline Processor data update
Show pin label & identifier table columns (Pins tool) Show Overview window on opening configuration for the first time Automatically load last configuration on startup
Disable both the connection to NXP cloud and the download of processor/board/kit data.
Select from the following options: � Auto Update � Update the processor data automatically. � Manual � Update processor data after confirmation. � Disabled � Disable processor data update.
Select to show the pin label and the label identifier in the relevant views.
Open the Overview dialog on opening configuration for the first time.
Avoid the startup window and load the last used configuration instead.
2.5 Configuration preferences
In the Configuration preferences window, you can set your preferences for to the configuration storage file (MEX).
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
18 / 136
NXP Semiconductors
User Interface
To configure the preferences related to the configuration, uses popup menu on the Eclipse project, select Properties and then MCUXpresso Config Tools in the left pane.
Figure 12. Configuration Preferences Several preferences are available. Ta�ble 7. Configuration Preferences Item Validate boot init only
Generate YAML Generate extended information into header file
Custom source file copyright header Generate code only for registers that are different from the after-reset state
Description
Validate tools' dependencies only against `boot init' function group.When selected, dependencies from all functional groups of all tools must be satisfied in the functional groups marked for default initialization. Clearing this option hides warnings in case the user is using complex scenarios with alternating functional groups within the application code.
Generate YAML into C sources files.
Generate extended information into the header file. For projects created in earlier MCUXpresso versions, this option is selected by default.
Add a custom copyright header to generated source files that don't already contain copyright.
Generate code only for registers that are different from the after-reset state. For projects created in earlier MCUXpresso versions, this option is selected by default.
WARNING When the source does not contain YAML code, it can't be imported.
2.6 Problems view
The Problems view displays issues in individual tools and in the inter-dependencies between the tools.
Figure 13. Problems view
To open the Problems view, click the Show Problems view button in the Toolbar, or select Views > Problems from the Menu bar. The Problems table contains the following information:
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
19 / 136
NXP Semiconductors
User Interface
Table 8. Problems view
Item
Description
Level
Severity of the problem: Information, Warning, or Error.
Resource
Resource related to the problem, such as signal name, the clock signal, and so on.
Issue
Description of the problem.
Origin
Information on the dependency source.
Target
Tool that handles the dependency and its resolution.
Type
Type of the problem. It's either the validation checking dependencies between tools, or a single tool issue.
Every issue comes with a context menu accessible by right-clicking the table row. Use this menu to access information about the problem or to apply a quick fix where applicable. You can also copy the rows for later use by right-clicking the row and selecting Copy or by using the Ctrl+C shortcut. You can use the Ctrl+left-click shortcut to add additional rows to the selection.
NOTE Quick fix is only available for problems highlighted with the "lightbulb" icon.
Filter buttons are available on the right side of the Problems view ribbon.
Table 9. Filter buttons
Button
Description
Enables the Validate boot init only preference. See Configuration preferences section for details.
Filters messages in the Problems view. If selected, only problems for the active tool are displayed. See Configuration preferences section for details.
2.7 Registers view
The Registers view lists the registers handled by the tool models. You can see the state of the processor registers that correspond to the current configuration settings and also the state that is in the registers by default after the reset. The values of the registers are displayed in the hexadecimal and binary form. If the value of the register (or bit) is not defined, an interrogation mark "?" is displayed instead of the value.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
20 / 136
NXP Semiconductors
User Interface
Figure 14. Registers view The Registers view contains several items. Table 10. Registers Item Peripheral filter drop-down list
Show modified registers only chekbox Text filter
Description List the registers only for the selected peripheral. Select all to list registers for all the peripherals. Hide the registers that are left in their after-reset state or are not configured. Filter content by text.
The following table lists the color highlighting styles used in the Registers view.
Table 11. Color codes
Color Yellow background Gray text color Black text
Description Indicates that the bit-field has been affected by the last change made in the tool.
Indicates the bit-field is not edited and the value is the after-reset value. Indicates the bit-fields that the tool modifies.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
21 / 136
NXP Semiconductors
User Interface
NOTE This view contains registers for the seleted tool. The view uses registers as internal parameters but it might not handle all the register writes needed in the code. The register writes are done inside the SDK functions that are called by the generated code. There might be additional registers accessed in the SDK code during the setup process, and such register writes are not known to the tool and are not displayed in the registers view.
2.8 Log view
The Log view shows user-specific information about MCUXpresso Config Tools operations. The Log view can show up to 100 records across all tools in chronological order.
Each log entry consists of a timestamp, the name of the tool responsible for the entry, severity level, and the actual message. If no tool name is specified, the entry was triggered by shared functionality.
You can filter the content of the Log view using the combo boxes to display only specific tool and/or severity level information. Filters in different tools can be set independently.
Buffered log records are cleared using the clear button. This affects Log views across all tools.
Figure 15. Log view
2.9 Config tools overview
The Config Tools Overview provides you with general information about your currently active configuration, hardware, and project. It also provides a quick overview of the used/active and unused/inactive tools, generated code, and functional groups. By default, the Config Tools Overview icon is located on the left side of the toolbar.
Config Tools Overview contains several items.
Table 12. Config Tools Overview
Item
Description
Configuration � General Info
Displays the name of and the path to the MEX file of the current configuration. Click the link to open the folder containing the MEX file. To import additional settings, click the Import additional settings into current configuration button.
Configuration � HW Info
Displays the processor, part number, core, and SDK-version information of the current configuration.
Project
Displays toolchain project information.
Pins/Clocks/Peripherals/TEE/Device Configuration
Displays basic information about the Pins, Clocks, Peripherals, TEE and Device Configuration tools.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
22 / 136
NXP Semiconductors
User Interface
NOTE If you have disabled a tool and want to reopen it, click the tool icon in the upper right corner or select it from the Main Menu. The Config Tools Overview opens automatically.
To enable/disable the tools, click the toggle button. You can navigate to the tools by clicking their icons. Following information about the tools is also available:
Table 13. Config Tools Overview
Item
Description
Generated code
Contains the list of source-code files. Click the links to open the files in the Code Preview view.
Functional groups
Contains the list of the currently active functional groups. To select the groups in the Functional groups tab in the toolbar, select the relevant links.
�
Figure 16. Config Tools Overview
NOTE Unsupported tools are not displayed in the overview.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
23 / 136
NXP Semiconductors
Chapter 3 Pins Tool
Pins tool is an easy-to-use tool for configuration of device pins. The Pins tool software helps create, inspect, change, and modify any element of pin configuration and device muxing.
Figure 17. Pins tool
3.1 Pins routing principle
The Pins tool is designed to configure routing peripheral signals either to pins or to internal signals. Internal signal is an interconnection node which peripheral signals can be connected to (without any pin interaction). Connecting two peripheral signals to internal signal makes an interconnection of these two peripheral signals. This routing configuration can be done in the following views:
� Pins � Peripheral Signals � Package � Routing Details Following two sections describe the two methods you can use to define the routing path.
3.1.1 Beginning with peripheral selection
You can select the peripheral in the Routing Details view and the Peripheral Signals view. 1. Select the Peripheral. 2. In Routing Details view, select one of the available Signals or expand the peripheral in Peripheral Signals view. 3. Selected the desired pin/internal signal.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
24 / 136
NXP Semiconductors
Pins Tool
Items (pins/internal signals) in the Routed pin/signal column in the Routing Details view have following decorators:
� Exclamation mark and default text color indicates that such item selection causes a register conflict or the item cannot be routed to the selected peripheral signal (some other peripheral signal can be).
� Exclamation mark and gray text color indicates that the item cannot be routed to any signal of the selected peripheral. The item is available for different peripheral using the same signal.
NOTE Route to field in Routing details view contains items that are connectable to the selected signal (without its channel if applicable). So when selected signal is "GPIO, 6" then the Routed pin/signal provides items connectable to "GPIO".
3.1.2 Beginning with pin/internal signal selection
You can select a pin or an internal signal in the Routing Details view. 1. Select the pin/internal signal (Routed pin/signal). 2. Select one of the available Peripherals. In the Pins view, see all available peripherals/signals by selecting the checkbox in the first column or scroll down to the required peripheral type. 3. For the selected peripheral, select one of the available Signals. Items in Peripheral column in Routing Details view have the following symbols: � Exclamation mark and default text color indicates that such item selection can cause a register conflict or the item does not support selected signal. � Exclamation mark and gray text color indicates that the item cannot be routed to the selected pin/internal signal. The item is available for different pin/internal signal using the same signal.
NOTE In the Pins view and the Package view you can configure only pins and not internal signals.
3.1.3 Routing of peripheral signals
Peripheral signals representing on-chip peripheral input or output can be connected to other on-chip peripherals or to a pin through an inter-peripheral crossbar. You can configure this connection in the Routing Details view. Three types of peripheral signal routing are available:
1. Routing the signal from the output of an internal peripheral (A) into the input of another internal peripheral (B) The signal leads from the output of one internal peripheral (A) to the input node of another internal peripheral (B). In other words, signal leads from A to B (A > B). To configure a signal in this way, perform the following steps (PWM triggering ADC (PWM > ADC) used as example): a. Add a new row in the Routing Details view. b. Select peripheral B from the drop-down list in the Peripheral column.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
25 / 136
NXP Semiconductors
Pins Tool
Figure 18. Selecting the peripheral (B) c. Select the input node of peripheral B from the drop-down list in the Signal column.
Figure 19. Selecting the input node (B) d. Select the output signal of peripheral A from the drop-down list in the Routed pin/signal column.
Figure 20. Selecting the output signal Once the configuration is done, the row will look like this:
Figure 21. Result
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
26 / 136
NXP Semiconductors
NOTE It's necessary to select the ADC peripheral where the signal leads to (input in ADC). It's a limitation of the Pins tool that the signal is not listed for the PWM peripheral (output). Notice the direction of the signal in the Arrow column.
Pins Tool
2. Routing the signal from a pin on the package to internal peripheral input signal through an inter-peripheral crossbar
NOTE Only if a crossbar switch is present.
The signal leads from a pin on the package (XB_IN) connected through an inter-peripheral crossbar, to an internal peripheral (B) input node. In other words, the signal leads from XB_IN to B (XB_IN > B). To configure a signal in this way, perform the following steps (routing pin 55 using XB_IN6 to EVTG0 input A (XB_IN6 > EVTG0) used as example):
a. Add a new row in the Routing Details view. b. Select peripheral B from the drop-down list in the Peripheral column.
Figure 22. Selecting the peripheral (B)> c. Select the input node of peripheral B from the drop-down list in the Signal column.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
27 / 136
NXP Semiconductors
Pins Tool
Figure 23. Selecting the input node (B) d. Select the XB_IN pin from the drop-down list in the Routed pin/signal column.
Figure 24. Selecting the pin Once the configuration is done, the row will look like this:
Figure 25. Result
NOTE In this example, GPIOF0 is multiplexed with XB_IN6, QTimerB channel 2 output/input and QSPI1 SCLK signal. In this case, the tool will automatically pick XB_IN6 for the pin as XB_IN6 is the only option to be routed to EVTG0 input A.
3. Routing the signal from internal peripheral (A) output to a pin via inter-peripheral crossbar
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
28 / 136
NXP Semiconductors
Pins Tool
NOTE Only if a crossbar switch is present.
The signal leads from internal peripheral (A) output to a pin connected through an inter-peripheral crossbar on the package (XB_OUT). In other words, the signal leads from A to XB_OUT (A > XB_OUT). To configure a signal in this way, perform the following steps (routing EVTG0 output to a pin 87 using XB_OUT4 used as an example):
a. Add a new row in the Routing Details view. b. Select peripheral A from the drop-down list in the Peripheral column.
Figure 26. Selecting the peripheral (A) c. Select the input node of peripheral A from the drop-down list in the Signal column.
Figure 27. Selecting the output signal (A) d. Select the XB_OUT pin from the drop-down list in the Route to column.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
29 / 136
NXP Semiconductors
Pins Tool
Figure 28. Selecting the pin Once the configuration is done, the row will look like this:
Figure 29. Result NOTE
In this example, GPIOC14 is multiplexed with XB_OUT4, SDA of I2C0 and fault4 of eFlexPWMA. In this case, the tool will automatically configure XB_OUT4 for the pin GPIOC14 (pin 87) as XB_OUT4 is the only option for EVTG0 output A.
3.2 Example workflow
This section lists the steps to create an example pin configuration, which can then be used in a project. In this example, three pins (UART3_RX, UART3_TX and PTB20) on a board are configured. You can use the generated files with the application code.
1. In the Pins view on the left, select the UART3_RX and TX signals. For this, you can click into the cells to make them `green'.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
30 / 136
NXP Semiconductors
Pins Tool
Figure 30. Configuring signals in the Pins view 2. In the Routing Details view, select the Output direction for the TX and PTB20 signals.
Figure 31. Selecting direction NOTE
For GPIO peripherals, you can set the Direction by clicking the cell and selecting from the drop-down menu. If you select Output you can also set GPIO initial state by clicking the cell in the GPIO initial state column. If you select Input you can also set GPIO interrupt by clicking the cell in the GPIO interrupt column. 3. The Pins tool automatically generates the source code for pin_mux.c and pin_mux.h on the right panel of Code Preview.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
31 / 136
NXP Semiconductors
Pins Tool
Figure 32. Generated code
4. You can now copy-paste the content of the source(s) to your application and IDE. Alternatively, you can export the generated files or update the code with the Update Code button in Toolbar. To export the files, select File > Export (in the desktop version) or select the menu Pins > Export menu (in the Web version). In the Export dialog expand the tree control for the tool you want to export sources for and select the Export Source Files option. Export, select the Export Source Files option.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
32 / 136
NXP Semiconductors
Pins Tool
Figure 33. Export
5. Click Next and specify the directory for each respective core (in multicore configuration) where you want to store the exported files for each individual core (in case of multicore configuration).
6. Click Finish to export the files. 7. Integrate and use the exported files in your application as source files.
3.3 User interface
The Pins tool consists of several views.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
33 / 136
NXP Semiconductors
Pins Tool
Figure 34. Pins tool user interface
Figure 35. Selecting power group
NOTE Power Groups are not supported for all processors.
3.3.1 Pins view
The Pins view shows all the pins in a table format.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
34 / 136
NXP Semiconductors
Pins Tool
Figure 36. Pins table view
This view shows the list of all the pins available on a given device. The Pin name column shows the default name of the pin, or if the pin is routed. The pin name is changed to show appropriate function for selected peripheral if routed. The next columns of the table shows peripherals and pin name(s) on given peripheral. Peripherals with few items are cumulated in the last column. To route/unroute a pin to the given peripheral, select the relevant cell in the Pin column. Routed pins are highlighted in green. If a conflict in routing exists, the pins are highlighted in red. Every routed pin appears in the Routed pins table. When multiple functions are specified in the configuration, the Pins view shows pins for selected function primarily. Pins for different functions are shown with light transparency and cannot be configured until switched to this function. Select a row to open a drop-down list that offers the following options:
� Route/Unroute the pin. � Highlight the pin in the Package view. � Set the label and identifier for the pin. � Add a comment to the pin. You can later inspect the comment in the Code Preview view.
TIP The option to route more signals to a single pin is indicated by an ellipsis (...). Select the cell to open a dialog to choose from multiple available signals. The dialog also displays which signals are routed by default.
3.3.2 Package view
The Package view displays the processor package. The processor package provides an overview of the package including resource allocation.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
35 / 136
NXP Semiconductors
Pins Tool
Figure 37. Processor package This view shows package overview with pins location. In the center are the peripherals. To highlight the pin/peripheral configuration in the Pins and Routing Details views, right-click the pin or peripheral and select Highlight. For BGA packages, use the Resources icon to see them.
� Green color indicates the routed pins/peripherals. � Gray color indicates that the pin/peripheral is not routed. � Dark Gray color indicates that the pin/peripheral is dedicated. It is routed by default and has no impact on generated code. The view also shows the package variant and the description (type and number of pins). The following icons are available in the toolbar:
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
36 / 136
NXP Semiconductors
Table 14. Toolbar options
Icon
Description
Zoom in package image.
Pins Tool
Zoom out package image.
Rotate package image.
Show pins as you can see it from the bottom. This option is available on BGA packages only.
Show pins as you can see it from the top. This option is available on BGA packages only.
Show resources. This option is available on BGA packages only.
Switch package. Package legend.
NOTE Depending on the processor package selected, not all views are available.
The Switch package for the Processor window shows list of available processor packages, showing package type and number of pins.
3.3.3 Peripheral Signals view
The Peripheral Signals view shows a list of peripherals and their signals. Only the Peripheral Signals and Pins view show the checkbox (allocated) with status. Table 15. Status codes Color code Status
Error
Configured
Not configured
Warning
Dedicated: Device is routed by default and has no impact on the generated code.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
37 / 136
NXP Semiconductors
Pins Tool
Figure 38. Peripheral Signals view
Use the checkbox to route/unroute the pins. To highlight the pin/routing configuration about the peripheral in the Package and Routing Details views, right-click the signal and select Highlight. To route/unroute multiple pins, click the peripheral and select the options in the Select signals dialog.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
38 / 136
NXP Semiconductors
Pins Tool
Figure 39. Select signals dialog
3.3.3.1 Filtering in the Pins and Peripheral Signals views
The following image illustrates the filtering controls in the Pins and Peripheral Signals views.
Show pins with input signals
Show pins with digital signals
Show pins with analog signals Show pins not routed
Show dedicated pins
Show routed pins
Show pins with output signals
Show pins with input/output signals
Show only pins with interrupt capability
Show pins with low leakage power mode wake-up capability
Figure 40. Filtering Controls
Type any text to search across the table/tree. It will search for the pins/peripheral signals containing the specified text. You can also use wildcards "*" and "?" to help you filter results you want. Use "space" to search for multiple strings at the same time.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
39 / 136
NXP Semiconductors
Pins Tool
3.3.4 Routing Details view
In the Routing Details view, you can inspect and configure routed pins and internal signals. You can also configure the electrical properties of pins and view them. It displays the pad configuration available in a configuration where each pin is associated with the signal name and the function.
NOTE The electrical features are configured only for pins in the table. For example, the routed pins.
The table is empty when a new configuration is created, which means no pin is configured. Each row represents configuration of a single pin and if there are no conflicts, then the code is immediately updated. For Boards/Kits the pins are routed already.
Figure 41. Routing Details
Add a new row with the Add new row button in the view toolbar. Configure the pin/signal by selecting the Peripheral first, then the required Signal, and finally, the pin to Route to. Use the columns in the right side of the table to configure the electrical features. You can also use the Pins and Peripheral Signals views to route pins and peripheral signals and view/modify the configuration in the Routing Details view. If the feature is not supported, n/a is displayed. To highlight peripheral/pin information in the Package and Pins views, right-click the row and select Highlight. To filter rows, type the text or the search phrase in the filter area in the view toolbar.
NOTE When you enter the search text, it also searches the text in the full pin names displays rows that contain the search text.
To display pins or signals only, use the Pins and Signals buttons in the view toolbar. To add a new row to the end of table, click on the Add new row button. To remove the selected row, click on the Delete the selected row button. To delete a specific row or insert a new row at a given position, right-click and use the dropdown list commands. To add a specific number of rows, enter the number in the field. To clear the table, type 0. To change the order of the rows, use the arrow icons to move one row up or down. To filter table entries by text, enter the text string in the type filter text field. To copy the row, right-click any cell in the row and select Copy. You can later paste the copied row into the Routing Details view of another functional group or configuration by right-clicking the table and choosing Paste. The gray background indicates read-only items. The italic value indicates that the value is not configured and it shows the after-reset value and no code is generated, so the configuration relies on the after reset value or the values configured from the different functions.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
40 / 136
NXP Semiconductors
TIP � The value shown using italic indicates the after-reset value. The real value may be different from the after reset
value, if configured in other functions. Use the drop-down menu to select the required value. � If you select the same value as the after-reset value, the tool will always generate code to set this feature. Use the drop-down "Reset" value to reset the value to its after-reset state. � If an item does not support reset to after reset value, the Reset menu is not available. � The first row shows pin number or coordinate on BGA package.
Pins Tool
3.3.4.1 Labels and identifiers
You can define the label of any pin that can be displayed in user interface for ease of identification.
Boards and kits have pre-defined labels. However, it's also possible to define a pin label listed in the Pins and Routing Details views.
To set\update the Labels and Identifier columns visibility, select Edit > Preferences from the Menu bar, and select the Show pin label & identifier table columns (Pins tool) checkbox.
The pin identifier is used to generate the #define in the pin_mux.h file. However, it's an optional parameter. If the parameter is not defined, the code for #define is not generated. Additionally, you can define multiple identifiers, using the ";" character as a separator. You can also set the identifier by typing it directly into the cell in the Identifier column in the Routing Details views.
Figure 42. Pin identifier In this case it's possible to select from values if the pin is routed. See Routing Details.
Figure 43. Identifier in Routing Details table
A check is implemented to ensure whether the generated defines are duplicated in the pin_mux.h file. These duplications are indicated in the identifier column as errors. See Identifier errors.
Figure 44. Identifier errors
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
41 / 136
NXP Semiconductors
Pins Tool
You can also select the pin to use in a given routing from the Routing Details view. However, the identifier must be a valid C identifier and should be used in the source code.
Figure 45. Pins macros prefix If multiple functions are used, each individual function can include a special prefix. Check the Pins > Functional Group Properties > Set custome #define prefix checkbox to enter prefix of macros in particular function used in the generated code of the pin_mux.h file. Entered prefix text must be a C identifier. If unchecked, the Function name is used as a default prefix.
3.3.5 Expansion Header
In the Expansion Header view, you can add and modify an expansion header configuration, map the connectors, and route the pin signals. You can also import and apply an expansion board to the header. Certain boards, such as LPCXpresso55S69, come with preconfigured expansion headers.
Figure 46. Expansion header
The expansion header is not automatically preset for every supported device. If the header is not preconfigured, follow these steps to create and modify an expansion header configuration:
1. Open the view by selecting Views>Expansion Header from the Toolbar.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
42 / 136
NXP Semiconductors
2. Add a new header by selecting the Add button in the view toolbar. 3. In the Add New Expansion Header window, select the Header type from the drop-down list.
Pins Tool
Figure 47. Adding new expansion header 4. Name the header and map the connectors.
Figure 48. Adding new expansion header
5. Select OK.
Expansion Header view now displays the connector layout. You can point your cursor over the pins to display additional information. Right-click the pin to display a shortcut menu of additional options.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
43 / 136
NXP Semiconductors
Pins Tool
Figure 49. Expansion header
6. To map the header pin to processor pin, right-click the header pin and select Connect. 7. In the Connector Pin dialog, select the processor pin/external signal from the list and click OK.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
44 / 136
NXP Semiconductors
Pins Tool
Figure 50. Connected pin 8. To route the pin, right-click the header pin and select Route. 9. In the Pin dialog, select the signal from the list and click OK.
The connector pin is now routed.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
45 / 136
NXP Semiconductors
Pins Tool
Figure 51. Routed pin
You can create more than one expansion header configuration. Switch between the configurations in the view's drop-down list. To highlight the pin/routing configuration in the Pins and Routing Details views, right-click the connector pin and select Highlight. Modify the configuration parameters at any time by selecting the Edit button. Information in the Pins view is updated automatically. Remove a configuration by selecting the Remove button. Use the Label drop-down list to switch between display information for header, board, and routing.
3.3.5.1 Expansion Board In the Expansion Header view, you can also apply an expansion board to an already created expansion header. The expansion board configuration can be imported into Pins tool in the form of an XML file. Based on the chosen processor, the tool will then recommend adequate routing.
NOTE Only a single expansion board can be configured per expansion header.
1. In the Expansion Header view, click the Apply expansion board to the selected header. Alternatively, select Pins>Apply expansion board from the Menu bar.
2. In the Apply expansion board dialog, click Browse to locate the XML file with expansion board information and click OK.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
46 / 136
NXP Semiconductors
Pins Tool
Figure 52. Apply expansion board
3. Click OK to apply the expansion board. 4. On the next page, choose if you want to create a new functional group for the expansion board, or modify an existing
functional group. In the latter case, use the dropdown list to select from available functional groups. 5. In the Expansion Board Routing table, inspect the suggested routing of expansion board pins. If you want to change the
route of a pin, click the pin cell in the Route column and select the signal in the Connector pin dialog and click Done.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
47 / 136
NXP Semiconductors
Pins Tool
Figure 53. Expansion board routing
6. Choose how you want to populate identifiers for code. Following options are available: � Expansion header names � Expansion board names � None
7. Click Apply to apply the settings. You can change the expansion board signal routing at any time by clicking the Configure routing for expansion board button in the Expansion Header view.
3.3.6 Highlighting and color coding
You can easily identify routed pins/peripherals in the package using highlighting. By default, the current selection (pin/peripheral) is highlighted in the Package view.
� The pin/peripheral is highlighted by yellow border around it in the Package view. If the highlighted pin/peripheral is selected then it has a blue border around it.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
48 / 136
NXP Semiconductors
Pins Tool
� Red indicates that the pin has an error. � Green indicates that the pin is muxed or used. � Light grey indicates that the pin is available for mux, but is not muxed or used. � Dark gray indicates that the pin/peripheral is dedicated. It is routed by default and has no impact on generated code.
Peripheral with error
Highlighted unrouted pin Highlighted peripheral
Dedicated peripheral Unrouted pin Dedicated pin Pin with error
Figure 54. Highlighting and color coding
Unallocated peripheral
Routed pin Allocated peripheral
Figure 55. Pins conflicts
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
49 / 136
NXP Semiconductors
Pins Tool
Figure 56. Warnings
� Package view -- Click on the peripheral or use the pop-up menu to highlight peripherals: and all allocated pins (to selected peripheral). or all available pins if nothing is allocated yet. -- Click on the pin or use the pop-up menu to highlight the pin and the peripherals. -- Click outside the package to cancel the highlight.
� Peripherals / Pins view -- The peripheral and pin behaves as described above image.
3.4 Errors and warnings
The Pins Tool checks for any conflict in the routing and also for errors in the configuration. Routing conflicts are checked only for the selected function. It is possible to configure different routing of one pin in different functions to allow dynamic pins routing re-configuration.
Figure 57. Error and warnings
If an error or warning is encountered, the conflict in the Routing Details view is represented in the first column of the row and the error/warning is indicated in the cell, where the conflict was created. The first two rows in the figure above show the peripheral/signal where the erroneous configuration occurs. The fourth row shows the warning on the unconfigured identifier while specifying a direction. The detailed error/warning message appears as a tooltip. For more information on error and warnings color, see the Highlighting and Color Coding section.
3.4.1 Incomplete routing
A cell with incomplete routing is indicated by a red background. To generate proper pin routing, click on the drop down arrow and select the suitable value. A red decorator on a cell indicates an error condition.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
50 / 136
NXP Semiconductors
Pins Tool
Figure 58. Incomplete routing The tooltip of the cell shows more details about the conflict or the error, typically it lists the lines where conflict occurs. You can also select Pins > Automatic Routing from the Main menu to resolve any routing issues.
NOTE Not all routing issues can be resolved automatically. In some cases, manual intervention is required.
3.5 Code generation
If the settings are correct and no error is reported, the code generation engine instantly re-generates the source code. You can view the resulting code the Code Preview view of the Pins tool. Code Preview automatically highlights differences between the current and immediately preceding iteration of the code. You can choose between two modes of highlighting by clicking the Set viewing style for source differences. You can also disable highlighting altogether from the same dropdown menu.
For multicores, the sources are generated for each core. Appropriate files are shown with @Core #{number} tag.
NOTE The tag name may be different depending on the selected multi-core processor family/type.
You can also copy and paste the generated code into the source files. The view generates code for each function. In addition to the function comments, the tool configuration is stored in a YAML format. This comment is not intended for direct editing and can be used later to restore the pins configuration.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
51 / 136
NXP Semiconductors
Pins Tool
Figure 59. Generated code YAML configuration contains configuration of each pin. It stores only non-default values.
TIP For multicore processors, it will generate source files for each core. If processor is supported by SDK, it can generate BOARD_InitBootPins function call from main by default. You can specify "Call from BOARD_InitBootPins" for each function, in order to generate appropriate function call.
3.6 Using pins definitions in code
The Pins tool generates definitions of named constants that can be leveraged in the application code. Using such constants based on user-specified identifiers allows you to write code which is independent of configured routing. In the case you change the pin where the signal is routed, the application will still refer to the proper pin. For example, when the LED_RED is specified an identifier of a pin routed to PTB22, the following defines are generated into the pin_mux.h:
#define BOARD_LED_RED_GPIO GPIOB /*!<@brief GPIO device name: GPIOB */ #define BOARD_LED_RED_PORT PORTB /*!<@brief PORT device name: PORTB *'/
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
52 / 136
NXP Semiconductors #define BOARD_LED_RED_PIN 22U /*!<@brief PORTB pin index: 22 */
Pins Tool
The name of the define is composed from function group prefix and pin identifier. For more details. see Functional groups and Labels and identifiers sections. To write to this GPIO pin in application using the SDK driver (fsl_gpio.h), you can for example use the following code referring to the generated defines for the pin with identifier LED_RED:
GPIO_PinWrite(BOARD_LED_RED_GPIO, BOARD_LED_RED_PIN, true);
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
53 / 136
NXP Semiconductors
Chapter 4 Clocks Tool
The Clocks Tool configures initialization of the system clock (core, system, bus, and peripheral clocks) and generates the C code with clock initialization functions and configuration structures.
4.1 Features
The Clocks tool allows you to perform various actions related to the Clock initialization, among them the following: � Inspect and modifies element configurations on the clock path from the clock source up to the core/peripherals. � Validate clock elements settings and calculates the resulting output clock frequencies. � Generate a configuration code using the SDK. � Modify the settings and provides output using the table view of the clock elements with their parameters. � Navigate, modify, and display important settings and frequencies easily in Diagram view. � Edit detailed settings in Details view. � Inspect the interconnections between peripherals and consuming clocks in Module Clocks view. � Find clock elements settings that fulfills given requirements for outputs. � Fully integrated in tools framework along with other tools. � Shows configuration problems in Problems view and guides the user for the resolution.
4.2 User interface
The Clocks tool is integrated and runs within the MCUXpresso Config Tools framework.
Figure 60. User interface
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
54 / 136
NXP Semiconductors
Clocks Tool
4.3 Clock configuration
Each clock configuration (functional group) lists the settings for the entire clock system and is a part of the global configuration stored in the MEX file. Initially, after the new clock configuration is created, it's set to reflect the default after-reset state of the processor.
There can be one or more clock configurations handled by the Clocks tool. The default clock configuration is created with the name "BOARD_BootClockRUN". Multiple configurations means multiple options are available for the processor initialization.
NOTE All clock settings are stored individually for each clock configuration so that each clock configuration is configured independently.
Clocks configurations (functional groups) are presented at the top of the view. You can switch between them by selecting them from the dropdown menu.
Figure 61. Default clock configuration
NOTE The code generation engine of the tool generates function with the name derived from the Clock configuration name.
4.4 Global settings
Global settings, such as Run Mode and MCG mode, influence the entire clock system. It's recommended to set them first. Global settings can be modified in Clock Table, Clock Diagram, and Details views.
NOTE Global settings can be changed at any time.
Figure 62. Global settings
4.5 Clock sources
The Clock Sources table is located in the Clocks Table view. You can also edit the clock sources directly from the Diagram view or from the Details view. You can configure the availability of external clock sources (check the checkbox) and set their frequencies. Some sources can have additional settings available when you unfold the node. If the external crystal or the system oscillator clock is available, check the checkbox in the clock source row and specify the frequency.
Figure 63. External clock source configuration
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
55 / 136
NXP Semiconductors
Clocks Tool
NOTE Some clock sources remain inactive even though the checkbox is checked. This is because the clock sources functionality depends on other settings like power mode or additional enable/disable setting options. You can hover the cursor on the setting to see a tooltip with information on the element and possible limitations/options.
4.6 Setting states and markers
The following states, styles, and markers reflect the information shown in the settings' rows in the settings tables (clock sources, output, details or individual).
Table 16. Setting states and markers
State/Style/
Icon
Marker
Description
Error marker
Indicates that there is an error in the settings or something related to it. See the tooltip of the setting for details.
Warning marker
Indicates that there is a warning in the settings or something related to it. See the tooltip of the setting for details.
Lock icon
Indicates that the settings (that may be automatically adjusted by the tool) are locked to prevent any automatic adjustment. If the setting can be locked, they are automatically locked when you change the value. To add/remove the lock manually, use the pop-up menu command Lock/Unlock.
NOTE The clock element settings that cannot be automatically adjusted by the tool keep their value as is and do not allow locking. These are: clock sources, clock selectors and configuration elements.
Yellow background
Gray text
Indicates that the field is directly or indirectly changed by the previous user action.
Indicates that the value of setting does not actively influence the clock. It is disabled or relates to an inactive clock element. For example, on the clock path following the unavailable clock source or disabled element. The frequency signal also show the text "inactive" instead of frequency. The value is also gray when the value is read-only. In such a state it is not possible to modify the value.
4.7 Frequency settings
The Clocks tool instantly re-calculates the state of the entire clock system after each change of settings from the clock source up to the clock outputs.
The current state of all clock outputs is listed in the Clock Outputs view located on the right side of the clock sources. The displayed value can be:
� Frequency � Indicates that a clock signal is active and the output is fed with the shown frequency. The tool automatically chooses the appropriate frequency units. In case the number is too long or has more than three decimal places, it's shortened and only two decimal places are shown, followed by an ellipsis (`...'), indicating that the number is longer.
� "Inactive" text � Indicates that no clock signal flows into the clock output or is disabled due to some setting.
If you have a specific requirement for an output clock, click on the frequency you would like to set, change it, and press Enter.
Figure 64. Setting the core clock frequency
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
56 / 136
NXP Semiconductors In case the tool has reached/attained the required frequency, it appears locked and is displayed as follows:
Clocks Tool
Figure 65. Tool attains the required frequency In case the tool is not able to reach/attain the required frequency or some other problem occurs, it's displayed as follows:
Figure 66. Tool encounters problem The frequency value in square brackets [ ] indicates the value that the tool is actually using in the calculations instead of the value that has been requested.
NOTE You can edit or set requirements only for the clock source and the output frequencies. The other values can be adjusted only when no error is reported.
4.7.1 Pop-up menu commands
� Lock/Unlock � Removes a lock on the frequency which enables the tool to change any valid value that satisfies all other requirements, limits, and constraints.
� Find Near Valid Value � Tries to find a valid frequency that lies near the specified value, in case the tool failed in reaching the requested frequency.
Figure 67. Pop-up menu commands
4.7.2 Frequency precision
For locked frequency settings (where user requests a specific value) the frequency precision value is also displayed. By default, the value is 0.1% but can be individually adjusted by clicking the value.
Figure 68. Frequency precision
4.8 Dependency arrows
In the Clocks Table view, the area between the clock sources and the clock output contains arrows directing the clock source to outputs. The arrows lead from the current clock source used for the selected output into all outputs that are using the signal from the same clock source. This identifies the dependencies and the influences when there is change in the clock source or elements on a shared clock path.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
57 / 136
NXP Semiconductors
Clocks Tool
Figure 69. Dependency arrows
4.9 Details view
The Details view displays and allows you to change clock-element settings information. The information is also updated in real-time based on any changes in the Clocks Diagram and Clocks Table.
Figure 70. Details view In the Details view, you can perform the following actions:
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
58 / 136
NXP Semiconductors
Clocks Tool
� Display clock-element information - Point the mouse cursor at the clock element to display general clock-element information.
� View the clock-element in Clocks Diagram or Clocks Table - Left-click on a clock element to highlight it in the Clocks Diagram or Clocks Table views, depending on which is currently active.
� View detailed clock-element information - Double-click on a clock element to display element details, as well as highlight the element in Clocks Diagram or Clocks Table, depending on which is currently active. You can also view element details by clicking the Open in new window button in the upper right corner of the Details view.
� Modify clock-element settings - Left-click in the Value column to change clock element value, such as frequency, or select an option from the dropdown menu.
� Lock/unlock clock elements - Right-click on a clock element to lock/unlock the element.
� Filter for active/locked/erroneous clock elements - Use the buttons in the upper-right corner of the Details view to filter for active/locked/erroneous clock elements, or to remove all current filters.
4.10 Clocks diagram
The clocks diagram shows the structure of the entire clock model, including the clock functionality handled by the tool. It visualizes the flow of the clock signal from clock sources to clock output. It's dynamically refreshed after every change and always reflects the current state of the clock model. At the same time it allows you to edit the settings of the clock elements.
Figure 71. Clocks diagram
4.10.1 Mouse actions in diagram
You can perform the following actions in the Clock diagram view. � Position the mouse cursor on the element to see the tooltip with the information on the clock element such as status, description, output frequency, constraints, and enable/disable conditions.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
59 / 136
NXP Semiconductors
Clocks Tool
� Single-click on output frequency or scale to change output frequency or scale. � Single-click on lock to remove the lock. � Double-click on the element to show its settings in the Details view (force to open the view if closed or not visible). � Single-click on the element to show its settings in the Details view. � Single-click on a selected Clock source to display a dropdown menu for enabling or disabling the source. � Single-click on a selected Clock selector to display selector input options.
Figure 72. Clocks mouse actions in diagram
� Right-click on the element, component, or clock output to see a pop-up menu with the following options. -- Edit settings of: {element} � Invokes the floating view with the settings for a single element. -- Edit all settings � Invokes the floating view with all the settings for an element. -- Edit settings on the path to: {clock output} � Invokes the floating view with the settings for all elements on the clock path leading to the selected clock output.
Figure 73. Floating view
4.10.2 Color and line styles
Different color and line styles indicate different information for the element and clock signal paths. The color and line styles can indicate:
� Active clock path for selected output � Clock signal path states - used/unused/error/unavailable � Element states � normal/disabled/error To inspect colors and style appearance, select Help > Show diagram legend from the main menu.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
60 / 136
NXP Semiconductors
Clocks Tool
4.10.3 Clock model structure
The clock model consists of interconnected clock elements. The clock signal flows from the clock sources through various clock elements to the clock outputs. The clock element can have specific enable conditions that can stop the signal from being passed to the successor. The clock element can also have specific constraints and limits that are watched by the Clocks Tool. To inspect these details, position the cursor on the element in the clock diagram to display the tooltip.
The following are the clock model elements.
� Clock source � Produces a clock signal of a specified frequency. If it's an external clock source, it can have one or more related pins.
Figure 74. Clock source � Clocks selector (multiplexer) � Selects one input from multiple inputs and passes the signal to the output.
Figure 75. Clocks selector � Prescaler � Divides or multiplies the frequency with a selectable or fixed ratio.
Figure 76. Prescaler � Frequency Locked Loop (FLL) � Multiplies an input frequency with given factor.
Figure 77. Frequency Locked Loop � Phase Locked Loop (PLL) � Contains pre-divider and thus is able to divide/multiply with a given value.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
61 / 136
NXP Semiconductors
Clocks Tool
Figure 78. Phase Locaked Loop � Clock gate � Stops the propagation of incoming signal. � Clock output � Marks the clock signal output that has some name and can be further used by the peripherals or other parts
of the processor. You can put a lock and/or frequency request.
Figure 79. Clock output � Clock component � Group of clock elements surrounded with a border. The clock component can have one or more outputs.
The clock component usually corresponds to the processor modules or peripherals. The component output may behave like clock gates, allowing or preventing the signal flow out of the component.
Figure 80. Clock component
� Configuration element � Additional setting of an element. Configuration elements do not have graphical representation in the diagram. They are shown in the setting table for the element or the clock path the element is on.
4.11 Clocks menu
Options related to the Clocks tool can be found in the Clocks menu in the Menu bar.
Table 17. Clocks menu
Menu item
Description
Functional groups
Open the Functional group properties dialog.
Refresh
Refresh each clocks configuration with explicit invocation of code generation.
Reset To Board Defaults
Reset the clock model to board defaults.
Reset To Processor Defaults
Resets the clock model ito processor defaults.
Unlock All Settings
Unlocks all locks in all settings.
Unlock Settings on the Active Path
Unlocks all locks in the settings that are on the active path.
4.12 Troubleshooting problems
It's possible that problems or conflicts occur while working with the Clocks Tool. Such problems and the overall status are indicated in red on the central status bar of the Clocks Tool. The status bar displays global information on the reported problem.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
62 / 136
NXP Semiconductors
Clocks Tool
You may encounter any of the following problems:
1. Requirement(s) not satisfiable: Indicates that there are one or more locked frequency or frequency constraints for which the tool is not able to find a valid settings and satisfy those requirements.
2. Invalid settings or requirements: [element list] � Indicates that the value of a settings is not valid. For example: The current state of settings is beyond the acceptable range.
The following are some tips to troubleshoot encountered problems.
1. Find the elements and settings with marked errors in the diagram or tables and see the details in the tooltip.
2. Start with only one locked frequency and let the tool find and calculate other ones. After you are successful you can add more.
3. Go through the locked outputs, if there are any, and verify the requirements (possible errors in the required frequency, wrong units, and so on).
4. If you are OK to have a near around of the requested value, right-click and from the pop-up menu select Clock output > Find near value.
5. If you cannot reach the values you need, see the clock paths leading to the clock output you want to adjust and check the selectors if it's possible to switch to another source of clock.
6. Try to remove locks by selecting Clocks > Unlock All Settings. In case many changes are required, you can simply reset the model to the default values and start from the beginning. To reset, select Clocks > Reset to processor defaults.
You can resolve most of the reported problems using the Problems view. Each problem is listed as a separate row. The following options appear when you right-click on a selected row in the Problems view.
� Show problem - Shows the problem in the Clocks Diagram view If one the solutions are possible then the pop up is extended by:
-- Remove lock - Removes the lock from erroneous element.
-- Find Near value - Finds the nearest value.
Figure 81. Find Near Value Dialog
Unlock settings active path and try again - unlocks all elements that lead to selected output and tries to recompute. Unlock settings and try again - unlocks all locked values and tries to recompute. If automatic value computation fails,
nothing will be changed. Cancel - cancels the modifications.
4.13 Code generation
If the settings are correct and no error is reported, the tool's code generation engine instantly re-generates the source code. The resulting code is found in the Code Preview view. Code Preview automatically highlights differences between the current and immediately preceding iteration of the code. You can choose between two modes of highlighting by clicking the Set viewing style for source differences. You can also disable highlighting altogether from the same dropdown menu.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
63 / 136
NXP Semiconductors
Clocks Tool
Figure 82. Code Preview
4.13.1 Working with the code
The generated code is aligned with the SDK. To use the code with the SDK project it's necessary to transfer the code into your project structure. To transfer the code into your project, do the following in the Code Preview:
� Copy the content using the COPY command, either by pressing the CTRL+C keys or the pop-up menu after the whole text is selected.
� Use export command. � Click the Export button in Code Preview view. � Click Update Code in the toolbar.
4.14 Clock Consumers view
The Clock Consumers view provides an overview of peripheral instances. It also provides information on clock-clock instance pairing. This view is not editable and is for information only.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
64 / 136
NXP Semiconductors
Clocks Tool
NOTE Information about which peripherals are consuming which output clock is available in the clock output tooltip.
Figure 83. Clock Consumers view
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
65 / 136
NXP Semiconductors
Chapter 5 Peripherals Tool
5.1 Features
The Peripherals tool features: � Configuration of initialization for SDK drivers � User friendly user interface allowing to inspect and modify settings � Smart configuration component selection along the SDK drivers used in toolchain project � Instant validation of basic constraints and problems in configuration � Generation of initialization source code using SDK function calls � Multiple functional-group support for initialization alternatives � Configuration problems are shown in the Problems view and marked with decorators in other views � Integration in MCUXpresso Config Tools framework along with other tools � Middleware configuration support (USB)
5.2 Basic terms and definitions
Table 18. Terms and definitions
Term Functional group
Peripheral instance
Configuration component Component instance Component mode
Definition
Represents a group of peripherals that are initialized as a group. The tool generates a C function for each functional group that contains the initialization code for the peripheral instances in this group. Only one functional group can be selected as default initialization, the others are treated as alternatives that are not initialized by default.
Occurrence of a peripheral (device) of specific type. For example, UART peripheral has three instances on the selected processor, so there are UART0, UART1 and UART2 devices.
Provides user interface for configuring SDK software component (for example, peripheral driver) and generates code for its initialization.
Configuration component can have multiple instances with different settings. (for example, for each peripheral instance like UART0, UART1).
Specific use-case of the component instance (for example, TRANSFER mode of DSPI, or interrupt-based mode of communication.
5.3 Workflow
The following steps briefly describe the basic workflow in the Peripherals tool.
1. In the Peripherals view, select the peripheral instance you would like to configure (use the checkbox).
2. In case more components are available for use by the peripheral, the Select component dialog appears. The dialog displays the list of suitable configuration components for the selected peripheral matching the SDK driver for the selected processor.
3. Select the component you want to use and click OK.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
66 / 136
NXP Semiconductors
Peripherals Tool
4. In the settings editor that automatically opens, select the Component mode that you would like to use and configure individual settings.
NOTE The selection of the component mode may impact appearance of some settings. Therefore, the selection of the mode should be always the first step.
5. Open the Code Preview and see the output source code.
NOTE Note: The source code preview is automatically generated after each change if no error is reported.
6. You can use the Update Code button from the toolbar. Alternatively, you can export the source code by selecting File>Export... from the Menu bar.
NOTE Note: To export the source code, you can also click the Export button in the Code Preview view.
7. Settings can be saved in a MEX format (used for all settings of all tools) by selecting File>Save from the Menu bar.
5.4 User interface
Figure 84. User interface
Figure 85. Peripheral view Figure 86. Components view
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
67 / 136
NXP Semiconductors
Peripherals Tool
5.4.1 Toolbar (Peripherals)
In addition to general items available to all tools, the Toolbar of the Peripherals tool contains additional items unique to it:
Table 19. Toolbar
Item
Description
Global settings
Open a tab aggregating global settings of all configuration sets.
Initialization order
Open a dialog for customization of peripheral initialization order.
NOTE For details on other items, refer to the Toolbar chapter.
5.4.1.1 Object Missing This object is not available in the repository.
5.4.2 Components view
The components view shows a list of configuration components, sorted by category into groups such as Middleware, Peripheral drivers and others.
The view highlights configuration components based on their status.
Table 20. Component status
Status
Color highlighting
Enabled
Light gray.
Enabled/with warning
Light gray with the alert symbol.
Table continues on the next page...
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
68 / 136
NXP Semiconductors
Table 20. Component status (continued)
Status
Color highlighting
Enabled/with error
Red with the error symbol.
Disabled
Dark gray.
Peripherals Tool
Figure 87. Components view In the Components view, you can perform several actions. Table 21. Components view actions Display configuration-component information
Open the Settings Editor of the configuration component
Add new configuration components
Point the mouse cursor at the configuration component to display general configuration-component information.
Left-click the configuration component to open its Settings Editor.
Left-click the + button and select from the list to add a new component. In the Select component dialog, you can filter the list to show only toolchain-project-relevant, or latest version components. You can also click the + buttons next to Middleware/Peripheral drivers/Other categories to add new components in them directly.
Table continues on the next page...
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
69 / 136
NXP Semiconductors Table 21. Components view actions (continued)
Peripherals Tool
Filter configuration components by name
Type a text string to filter configuration component names in the search bar.
Right-click the the configuration component to open a shortcut menu. Several options are available in the shortcut menu.
Table 22. Shortcut menu options
Option
Description
Open
Open the configuration component in the Settings Editor.
Open in another view
Duplicates the configuration component in the Settings Editor.
Edit comment
Create/Edit custom notes for the configuration component.
Lock/Unlock editing of component instance
Lock/Unlock the editing of the component instance.
Documentation
Display the documentation of the configuration component, if available.
Remove
Remove the component from configuration.
NOTE If the component has any global settings, a dialog appears prompting you to confirm the removal. If the component doesn't have any global settings, the component is deleted after removing the last instance.
Migrate Enable/Disable Move to Copy to
Migrate the component to a different component type or to a component with a newer driver version.
Enable/Disable the configuration component
Choose from available functional groups to move the configuration component to.
Choose from available functional groups to copy the configuration component to.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
70 / 136
NXP Semiconductors
Peripherals Tool
5.4.3 Peripherals view
The Peripherals view contains a table showing a list of available peripherals on the currently selected processor that can be configured by the Peripherals tool. In case of multicore processors, the displayed peripherals are also core-specific.
Each instance of a peripheral (for example, UART0) occupies one row. First column contains peripheral name and a checkbox indicating whether the peripheral is used by any component instance.
Second column contains a name of component instance handling the peripheral. This name is customizable in the settings editor and it is used in generated code. The name of the component instance can't contain spaces.
You can enable an instance by selecting the checkbox, or by clicking the switch in the settings editor of the component instance.
Disable a component instance by deselecting it.
Double-click on the second column to open the Settings Editor for the component instance.
Right-click the the peripheral to open a shortcut menu. Several options are available in the shortcut menu.
Table 23. Shortcut menu options
Option
Description
Open
Open the component instance in the Settings Editor.
Open in another view
Duplicate the component instance in the Settings Editor.
Add
Add a component instance to the peripheral.
Edit comment
Create/Edit custom notes for the component instance.
Lock/Unlock editing of component instance
Lock/Unlock the editing of the component instance.
Documentation
Display the documentation of the component instance, if available.
Remove
Remove the component instance from configuration. If more instances are in use, a confirmation window will allow you to select which instance you want to remove.
Migrate
Migrate the component to a different component type or to a component with a newer driver version.
Enable/Disable
Enable/Disable the component instance.
Move to
Choose from available functional groups to move the component instance to.
Copy to
Choose from available functional groups to copy the component instance to.
Initialized in user code
Mark the peripheral as configured by user code (available on not configured peripherals).
5.4.4 Settings Editor
You can edit peripheral component settings in the Settings Editor. Open editors are shown in the central area of the screen, each with its own tab. Multiple editors can be opened at the same time. Changes done in the editor are immediately applied and kept even if the settings editor is closed. Settings that are disabled are highlighted in gray. In case that a component instance is disabled, all settings are highlighted in gray. Tooltips are displayed for all enabled settings when the mouse cursor is placed at settings.
To open Settings Editor, do the following:
� Double-click the component instance in the Peripherals or Components view to display component instance settings.
� Left-click the component in the Components view to display global settings of the component.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
71 / 136
NXP Semiconductors
Peripherals Tool
5.4.4.1 Quick selections
Settings are grouped to larger groups (config sets) that may provide presets with typical values. You can use these presets to quickly set the desired typical combination of settings or return to the default state.
Figure 88. Quick selection example 5.4.4.2 Settings Following setting types are available in the Settings Editor
� Boolean � Two state setting (yes/no, true/false).
Figure 89. Boolean setting example � Integer, Float � Integer or float number.
Figure 90. Integer/Float setting example � String � Textual input. More than a single entry can be supported.
Figure 91. String setting example � Enumeration � Selection of one item from list of values.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
72 / 136
NXP Semiconductors
Figure 92. Enumeration setting example � Set � List of values, multiple of them can be selected.
Peripherals Tool
Figure 93. Set setting example � Structure � Group of multiple settings of different types, may contain settings of any type including nested structures.
Figure 94. Structure setting example � Array � Array of multiple settings of same type � you can add/remove items. The array of simple structures may also be
represented as a table grid, master-detail, and as radio buttons.
Figure 95. Array The `+' button adds a new item at the end of array. To rearrange the position or delete an item, right-click the item and select one of the following options: Move up, Move down, Move to top, Move to bottom, or Remove. You can also copy-paste an array from one instance to another by right-clicking the array label and choosing Copy. You can then navigate to another instance array, right-click the table and choose Paste to add it.
NOTE System clipboard is not used for this purpose.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
73 / 136
NXP Semiconductors
Peripherals Tool
Figure 96. Array setting example � Info � Read-only information for the user.
Figure 97. Array setting example � File setting - Link/import an external settings file. 5.4.4.3 Settings Editor header All components share the Settings Editor header. In the header, you can view and change component information, enable or disable the component, and view component documentation (where applicable).
Figure 98. Settings Editor header Table 24. Settings Editor header Header item Description Name
Mode
Peripheral Documentation
Description
Displays the configuration component title.
Displays the component instance name. This name is used in the generated code in constants and function identifiers and is derived from the peripheral name. You can change it at any time by clicking the Custom name button and editing the field.
Displays the required usage for the component instance and influences available settings. Use the dropdown menu to change the mode (where applicable).
Displays the name of the peripheral to be associated with the component instance. Use the dropdown menu to change it.
Click the button to view configuration component-specific documentation in the Documentation view. Note that not all configuration components are documented, therefore not all setting headers contain the Documentation icon.
Table continues on the next page...
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
74 / 136
NXP Semiconductors
Table 24. Settings Editor header (continued) Header item Lock editing Enable/disable component instance switch
Peripherals Tool
Description Click the button to lock/unlock component editing. Source code will still be generated. Use the switch to enable or disable selected component instance. Note that by disabling the instance, you don't remove it from the tools configuration, but prevent its inclusion in the generated code.
5.4.5 Documentation view
You can display component-specific documentation by opening the Documentation view.
NOTE Not all components might have this option enabled.
Figure 99. Documentation view
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
75 / 136
NXP Semiconductors
You can open the Documentation view in several ways: � In the Peripherals view, right-click the peripheral checkbox and choose Documentation from the list. � In the Components view, right-click the component and choose Documentation from the list. � In the Settings Editor, click the Documentation button next to component name. � In the Settings Editor, click the question mark next to the settings label.
Peripherals Tool
5.5 SEMC Validation tool
If you are developing hardware with external memory, you can validate the memory settings with the Memory Validation tool. The tool is available for all SEMC, FlexSPI/NOR, and FCB peripherals and can be used after selecting these peripheral from the list in the Peripherals view. Click the Validation button in the Settings Editor to open the Validation view and run validation scenarios for SEMC memory settings.
NOTE The Memory Validation tool requires Python 2.7 to run. You must manually install the latest Python 2.7 from https://www.python.org/downloads and make sure arm-none-eabi-gdb-py starts without error. It's possible that Windows requires that python27.dll is installed.
Should the settings prove valid, you can click the Sync with DCD button to synchronize the memory settings with the DCD tool. You need to manually update the existing sdram configuration from the DCD tool with the one generated by clicking Apply to DCD. Also, if a configuration is not defined in the DCD tool, the configuration generated by clicking Apply to DCD will not work as it is, and additional configuration will need to be added in the Clocks or Pins tools.
5.5.1 Validation view
Use the Validation view to run validation scenarios for your memory settings and analyse the results. You can choose scenarios, tests to run in these scenarios, and view the test results, logs, and summary. To run validation tests, do the following:
1. Select the correct connection type and COM port in the Connections area. Alternatively, scan for available COM ports by clicking the Scan for available COM ports button.
2. Choose a scenario you wish to test in the Scenarios sub-view. a. To test the Phy configuration: i. Select Firmware Init > Firmware Init test. b. To perform a basic memory check by running Write-Read-Compare/Walking Ones/Walking Zeros: i. Select Operational > Operational tests. ii. Select Choose Tests. iii. Select the tests to perform and set the test parameters. c. To run stress tests: i. Select Stress Tests > Stress tests. ii. Select Choose Tests and set the test parameters. d. To run diags tests: i. Select Diags and choose between Diags margin state/Diag Write Margin/Diag Read Margin. ii. Select Choose Tests and set the test parameters.
3. To start validation, click the Start Validation button. 4. Observe the results in real-time in the Results sub-view.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
76 / 136
NXP Semiconductors
Peripherals Tool
5. Inspect the results in the Summary and Logs sub-views.
6. View the U-boot-compatible code in Core Preview. You can export the generated code for importing into U-boot by selecting the Export button.
7. Download DDRV reports using the Configure and generate DDRV reports button.
5.6 Problems
The tool validates the settings and problems and errors are reported in the Problems view. If there is an error related to the setting or component an error decorator is shown next to the element containing an error.
Figure 100. Error decorators In the case of a dependency error, a quick-fix button is displayed.
Figure 101. Quick fix 1 Right-click the button to display a list of issues, then left-click the issue to display possible solutions.
Figure 102. Quick fix 2
5.7 Code generation
If the settings are correct and no error is reported, the tool's code generation engine instantly re-generates the source code. You can view the resulting code the Code Preview view of the Peripherals tool. Code Preview automatically highlights differences between the current and immediately preceding iteration of the code. You can choose between two modes of highlighting by clicking the Set viewing style for source differences. You can also disable highlighting altogether from the same dropdown menu. The Peripherals tool produces the following C files:
� peripherals.c � peripherals.h
NOTE For multicore processors the peripherals.c/.h are generated for each core, containing functional groups associated with that core. This can be configured in functional group properties.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
77 / 136
NXP Semiconductors
Peripherals Tool
NOTE Some components, such as the USB or FlexSPI, may generate additional output files.
These files contain initialization code for peripherals produced by selected configuration components including: � Constants and functions declaration in header file. � Initialized configuration structures variables (constants). � Global variables for the user application that are used in the initialization. For example, handles and buffers. � Initialization function for each configuration component. � Initialization function for each functional group. The name of the function is the same as the functional group name. These functions include execution of all assigned components' initialization functions. � Default initialization function containing call to the function initializing the selected functional group of peripherals.
NOTE The prefixes of the global definitions (defines, constants, variables and functions) can be configured in the Properties of the functional group.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
78 / 136
NXP Semiconductors
Peripherals Tool
Figure 103. Code Preview
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
79 / 136
NXP Semiconductors
Chapter 6 Device Configuration Tool
Device Configuration tool allows you to configure the initialization of memory interfaces of your hardware. Use the Device Configuration Data (DCD) view to create different types of commands and specify their sequence, define their address, values, sizes, and polls.
Figure 104. Device Configuration tool
6.1 Device Configuration Data (DCD) view
The Device Configuration Data (DCD) view displays memory initialization commands of your currently active configuration. Here, you can create new command groups and commands and specify their parameters. Commands in the Device Configuration Data (DCD) can be synchronised from the SEMC Validation tool in the Peripherals tool.
6.1.1 Device Configuration Data (DCD) view actions
The following is a list of command and command group-relevant actions you can perform in the Device Configuration Data (DCD) view:
� Create a new command group - Right-click the table and choose Add Group from the context menu. � Re/Name a command group - Left-click the command group cell and enter the required name. � Disable a command group - Right-click the command group row and choose Disable Group from the context menu. � Remove a command group - Right-click the command group row and choose Remove Group from the context menu. � Collapse all command groups - Right-click the the table and choose Collapse All Groups from the context menu. � Expand all command groups - Right-click the table and choose Expand All Groups from the context menu.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
80 / 136
NXP Semiconductors
Device Configuration Tool
� Add a command to a group - Right-click the table and choose Add Command from the context menu. Alternatively, click the Add Command button in the tool's toolbar.
� Specify command type - Left-click the row's Command cell and choose from the dropdown menu.
� Specify register address for a command - Left-click the row's Address cell and choose from the dropdown menu.
� Specify a value or a mask for a command - Left-click the row's Value(s) / Mask(s) cell to open the mask window. Enter the value into the field and select OK. Alternatively, select Cancel to cancel the operation, or Reset to reset the value.
Figure 105. Mask
� Specify the size of write/read data for a command - Left-click the row's Size cell and choose from the dropdown menu. � Specify the number of polls of a command - Left-click the row's Poll cell and enter the required value. � Add a comment to a command - Left-click the row's Comment cell. � Remove a command - Right-click the command row and choose Remove Command from the context menu. Alternatively,
click the Remove Command button in the tool's toolbar. � Cut a command - Right-click the command row and choose Cut from the context menu. � Copy a command - Right-click the command row and choose Copy from the context menu. � Paste a command - Right-click the command row and choose Paste from the context menu.
NOTE You can remove all commands by clicking Device Configuration in the Menu bar and choosing Clear All Commands from the dropdown menu.
Basic cell selection shortcuts are applicable. � Select additional commands - Ctrl+Left-click the command row.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
81 / 136
NXP Semiconductors
Device Configuration Tool
6.2 Code generation
If the settings are correct and no error is reported, the code generation engine instantly re-generates the source code. You can view the resulting code the Code Preview view of the Device Configuration tool. Code Preview automatically highlights differences between the current and immediately preceding iteration of the code. You can choose between two modes of highlighting by clicking the Set viewing style for source differences. You can also disable highlighting altogether from the same dropdown menu. Device Configuration source code can be generated in a C array (default) or binary format. The code in a C array format is generated in two files:
� dcd.c � dcd.h The code in a binary format is generated in a single file: � dcd.bin To change the code format, choose the required option from the dropdown menu in the Device Configuration Data (DCD) view.
Figure 106. Code Preview
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
82 / 136
NXP Semiconductors
Chapter 7 Trusted Execution Environment Tool
In the Trusted Execution Environment, or TEE tool, you can configure security policies of memory areas, bus masters, and peripherals, in order to isolate and safeguard sensitive areas of your application. You can set security policies of different parts of your application in the Security Access Configuration and its sub-views, and review these policies in the Memory Attribution Map, Access Overview. and Domains Overview views. Use the User Memory Regions view to create a convenient overview of memory regions and their security levels. You can also view registers handled by the TEE tool in the Registers view, and inspect the code in the Code Preview tool.
NOTE In order for your configuration to come into effect, make sure you have enabled the relevant enable secure check option in the Miscellaneous sub-view of the Security Access Configuration view.
Figure 107. TEE tool user interface (SAU+IDAU)
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
83 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 108. TEE tool user interface (RDC)
7.1 AHB with security extension-enabled devices
The features and appearance of the TEE tool are based on the security model of the loaded device. This section describes the features and appearance of the tool for devices with ARM TrustZone and AHB with security extension Currently, following devices of this type are supported:
� LPC55Sxx -- LPC55S69, LPC55S66 -- LPC55S16, LPC55S14 -- LPC55S06, LPC55S04
� RT6xx, RT5xx -- MIMXRT685S, MIMXRT633S -- MIMXRT595S, MIMXRT555S, MIMXRT533S
NOTE Pre-production only.
7.1.1 User Memory Regions view
In the User Memory Regions view, you can create and maintain a high-level configuration of memory regions and their security levels. You can create the regions, name them, specify their address, size, security level, and provide them with a description. You can then fix any errors in the settings with the help of the Problems view. Create a new memory region by clicking the Add new memory region button in the view's header. Enter/change the memory region's parameters by clicking the row's cells. In the Security Level column, you have these options to choose from:
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
84 / 136
NXP Semiconductors
Trusted Execution Environment Tool
� NS-User - Non-secure user � NS-Priv - Non-secure privileged � S-User - Secure user � S-Priv - Secure privileged � NSC-User - Non-secure callable user � NSC-Priv - Non-secure callable privileged � Any Errors in configuration are highlighted by a red icon in the relevant cell. In the case the issue is easily fixed, you can right-click the cell to display a dropdown list of offered solutions. Remove the memory region by selecting the table row and clicking the Remove selected memory region(s) button in the view's header.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
85 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 109. User Memory Regions
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
86 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 110. User Memory Regions
You can import memory region configuration from other IDE projects by clicking the Import memory regions configuration from the IDE project(s) button in the view toolbar. Select the project you want from the list to import its memory regions settings into your current project.
NOTE After the import, you might have to correct some of the security levels manually.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
87 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 111. Select Project
7.1.2 Security Access Configuration view
In the Security Access Configuration view, you can configure your application's security policies in a number of ways. See the following sections for more details.
7.1.2.1 SAU In the SAU sub-view, you can enable and configure SAU (Security attribution unit). When enabled, you can set up SAU memory regions, specify their start and size or end address, and specify their security level. SAU automatically sets the entire memory space to a secure severity level when disabled. It also sets the entire memory space to a secure security level when enabled but without set memory regions. You can choose between two security levels:
� NS - Non-secure � NSC - Non-secure callable Alternatively, you can set all the SAU memory regions to non-secure security level by selecting the All Non-Secure.
NOTE This option is only available when SAU is disabled.
You can also decide to generate code even for disabled memory regions by selecting the option Generate sources for disabled regions.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
88 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 112. SAU/IDAU
7.1.2.2 Interrupts In the Interrupts sub-view, you can set security designation for device's peripheral interrupts. In case that the processor contains more than a single core or processing unit, additional Handling by Core tables might appear. In these tables, you can specify if the interrupts coming from the peripheral can be handled by the core or processing unit. All interrupts are set to Secure by default. If you want to change the interrupt source's security designation, left-click the Secure cell of the interrupt and choose from the dropdown menu. Alternatively, right-click the interrupt's Name cell and choose the security designation from the context menu. To select multiple entries, use the Ctrl+Left-click shortcut, then right-click the selected area for the context menu.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
89 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 113. Interrupts
7.1.2.3 Secure/Non-secure MPU In the Secure MPU and Non-secure MPU sub-views, you can enable and configure MPU (Memory Protection Unit). You can create regions, specify their address, size, and other parameters. Use the Secure MPU sub-view for the configuration of the secure, and Non-secure MPU for the configuration of the non-secure security level.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
90 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 114. MPU
MPU is disabled by default and must be enabled by selecting the Enable MPU option.
NOTE Not every device supports MPU.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
91 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Use the MPU Memory Attributes table to name and configure MPU memory attribute sets. Click the cells of the Memory Type and Device Attributes columns to display the available choices. Use the MPU Memory Regions table to enable and configure MPU memory regions.
1. Enable the region. 2. Specify the Address. 3. Specify either the Size or the End Address. 4. Set the Exec option if you want the region to be able to run code. 5. Set the Permissions (Read Only or Read/Write). 6. Set the Privileges.
NOTE Privileged access can be set by default for all memory regions not handled by MPU by selecting the Enable privileged software access to the default memory map option.
7. Set the Shareability, or the caching options. 8. Allocate one of the sets from the MPU Memory Attributes table in Mem.Attr.. Sets can be allocated to more than one region.
7.1.2.4 MPC In the MPC (Memory Protection Checker) sub-view, you can set security policies on entire memory sectors as defined by physical addresses. Set the memory sector security level by left-clicking the relevant cell in the Security level column and choosing from the dropdown list. Alternatively, you can right-click the relevant cell in the Sector column and choose the security level from the context menu. To select multiple entries, use the Ctrl+Left-click shortcut, then right-click the selected area for the context menu. You have four security levels to choose from, in ascending order of security:
� NS-User - Non-secure user � NS-Priv - Non-secure privileged � S-User - Secure user � S-Priv - Secure privileged
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
92 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 115. MPC
7.1.2.5 Masters/Slaves
In the Masters/Slaves sub-view, you can configure security levels for bus masters and slaves.
Set the bus master/slave security level by left-clicking the relevant cell in the Security level column and choosing from the dropdown list. Alternatively, you can right-click the relevant cell in the Master and Slave column and choose from the security
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
93 / 136
NXP Semiconductors
Trusted Execution Environment Tool
level from the context menu. To select multiple entries, use the Ctrl+Left-click shortcut, then right-click the selected area for the context menu. You have four security levels to choose from, in ascending order of security:
� NS-User - Non-secure user � NS-Priv - Non-secure privileged � S-User - Secure user � S-Priv - Secure privileged You can further specify the interrelation between master and slave security levels by selecting the following options: � Simple Master in Strict Mode - Select to allow simple bus master to read and write on same level only. De-select to allow to
read and write on same and lower level. � Smart Master in Strict Mode - Select to allow smart bus master to execute, read, and write to memory at same level only.
De-select to allow to execute on same level only, read and write on same and lower level.
NOTE Instruction-type bus master security level must be equal to bus slave security level. Data and others security level must be equal or higher than bus slave security level.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
94 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 116. Masters/Slaves
7.1.2.6 Pins
In the Pins sub-view, you can specify if the reading GPIO state is allowed or denied.
All pins' reading GPIO state is set to Allow by default. If you want to change the pins reading GPIO state, left-click the Reading GPIO state cell of the pin and choose from the dropdown menu. Alternatively, right-click the pin's Name cell and choose the
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
95 / 136
NXP Semiconductors
Trusted Execution Environment Tool
reading GPIO state from the context menu. To select multiple entries, use the Ctrl+Left-click shortcut, then right-click the selected area for the context menu.
Figure 117. Pins
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
96 / 136
NXP Semiconductors
Trusted Execution Environment Tool
7.1.2.7 Miscellaneous
In the Miscellaneous sub-view, you can set various configuration options. The list of these options depends on processor data, and varies greatly. All the options influence your register settings, and can be inspected in the Register view. Only some of the options directly influence configuration you have made in the Security Access Configuration view. Point your cursor over individual options to display a tooltip explaining the function of each option.
Figure 118. Miscellanous (RDC)
7.1.3 Memory attribution map
In the Memory attribution map, you can view security levels set for memory regions. This view is read-only.
7.1.3.1 Core 0 In the Core 0 sub-view, you can review security levels set for Core 0 to the code, data, and peripherals memory regions. The table is read-only. The Access by Master table displays MSW or SAU+IDAU, MPC (Memory Protection Checker) security level, and Resulting Security Level status of listed code, data, and peripherals memory regions, alongside their physical addresses. To set the display options, do the following:
1. Click the Filter access for checkbox to enable filtering options. 2. Select the master security access you want to review by choosing from the Master dropdown menu. 3. Optionally, set the security level of the selected master by choosing from the Security mode dropdown menu. This setting
has no effect on the configuration. 4. Optionally, customize the output by de-selecting the Show details and Merged SAU+IDAU options. 5. Optionally, filter displayed memory regions in the Filter area. Point your cursor over the color-coded cells to display a tooltip with information about the security level combination. Double-click the cell to open the pertinent settings in Security Access Configuration.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
97 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 119. Core 0
7.1.3.2 Other masters
In the Other Masters sub-view, you can review security attributes of memory in relation to access rights by master other than Core 0. The table is read-only.
To set the display options, do the following:
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
98 / 136
NXP Semiconductors
Trusted Execution Environment Tool
1. Click the Filter access for checkbox to enable filtering options. 2. Select the master type security access you want to review by choosing from the Master dropdown menu. 3. Optionally, customize the output by de-selecting the Show Details, Show Code, Show Data, and Show Peripherals options. 4. Optionally, filter displayed memory regions in the Filter area. Point your cursor over the color-coded fields to display a tooltip with information about the security level combination. Double-click the cell to open the pertinent settings in Security Access Configuration.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
99 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 120. Other masters
7.1.4 Access Overview
In Access Overview, you can review security policies you have set in Security Access Configuration view. The vertical axis displays all masters, divided into color-coded groups by their security settings.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
100 / 136
NXP Semiconductors
Trusted Execution Environment Tool
The horizontal axis displays memory ranges and slave buses/peripherals. Point your cursor at an entry to display a tooltip with information about the entry. You can group the displayed information by security or by masters by using the button on the righ-hand side of the toolbar.
Figure 121. Access Overview
7.1.5 Code generation
If the settings are correct and no error is reported, the code generation engine instantly re-generates the source code. You can view the resulting code the Code Preview view of the Trusted Execution Environment tool.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
101 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Code Preview automatically highlights differences between the current and immediately preceding iteration of the code. You can choose between two modes of highlighting by clicking the Set viewing style for source differences. You can also disable highlighting altogether from the same dropdown menu.
Some AHB with security extension-enabled devices support ROM preset as well as C code. You can choose to have the code generated in the ROM preset by selecting the option in the Miscellaneous sub-view.
7.2 RDC-enabled devices
The features and appearance of the TEE tool are based on the security model of the loaded device. This section describes the features and appearance of the tool devices with enabled RDC (Resource Domain Controller) and XRDC2 (eXtended Resource Controller 2). Currently, following devices of this type are supported:
� RT1170 -- Dual core (Cortex-M7 + Cortex-M4): MIMXRT1176, MIMXRT1175, MIMXRT1173 -- Single core only (Cortex-M7): MIMXRT1172, MIMXRT1171
7.2.1 User Memory Regions view
In the User Memory Regions view, you can create and maintain a high-level configuration of memory regions and their access templates. You can create the regions, name them, specify their address, size, security level, and provide them with a description. You can then fix any errors in the settings with the help of the Problems view.
Figure 122. User Memory Regions
Create a new memory region by clicking the Add new memory region button in the view's header. Enter/change the memory region's parameters by clicking the row's cells. Modify the access policy of memory regions by clicking the cell in the Access column. This action opens the Access templates dialog. Errors in configuration are highlighted by a red icon in the relevant cell. In the case the issue is easily fixed, you can right-click the cell to display a dropdown list of offered solutions. Remove the memory region by selecting the table row and clicking the Remove selected memory region(s) button in the view's header.
7.2.1.1 Access templates In the Access templates dialog, you can modify access templates for device domains. The dialog displays the device RDC domains, as well as all user-created XRDC2 domains.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
102 / 136
NXP Semiconductors
Trusted Execution Environment Tool
NOTE Make sure to first specify the number of domains in the M4 Domain/M7 Domain > Domains.
Figure 123. Access template
Select access template by clicking the topmost cell of domain column to open a dropdown list containing all options. Once you have selected access templates for all domains, click OK to return to the User Memory Regions view.
7.2.2 Security Access Configuration view
In the Security Access Configuration view, you can configure your application's security policies in a number of ways. See the following sections for more details.
7.2.2.1 RDC In the RDC sub-view, you can assign masters to domains and specify access rules for slaves for each domain.
7.2.2.1.1 RDC Masters In the RDC Masters sub-view, you can view available bus masters, allocate them to available domains (cores), and lock/unlock the allocation.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
103 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 124. RDC Masters
Allocate a master to a domain by clicking the cell in the Domain column in the Masters table and selecting the domain from the dropdown list. Select the Lock checkbox to prevent further register modifications. Alternatively, you can select the options by right-clicking the master and using the dropdown list.
NOTE Some masters are allocated to specific domains by default and cannot be reallocated.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
104 / 136
NXP Semiconductors
Trusted Execution Environment Tool
7.2.2.1.2 Memory Regions
In the Memory Regions sub-view, you can view, enable/disable and configure the MRC (Memory Region Controller) bus slaves and their domain access.
Memory Region Controller implements the access controls for slave memories based on the pre-programmed Memory Region Descriptor registers.
Figure 125. Memory Regions
Use the Memory Regions Configuration table to enable and configure MRC slaves: 1. Enable the region. 2. Specify the Address. 3. Specify either the Size or the End Address. 4. Optional: Lock the settings to prevent further register modifications.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
105 / 136
NXP Semiconductors
Trusted Execution Environment Tool
5. Set the Access Template for available domains. Alternatively, you can select the options by right-clicking the master and using the dropdown list.
7.2.2.1.3 Peripherals In the Peripherals sub-view, you can view and configure the PDAP (Peripheral Domain Access Permissions) for peripherals.
Figure 126. Peripherals
Use the Peripherals Configuration table to enable and configure PDAP: 1. Optional: Lock the settings to prevent further register entries. 2. Select Use semaphore to enable the semaphore function for the peripheral.
NOTE When enabled, the master cannot access this peripheral until obtaining a semaphore. During the time that the domain has the semaphore in possession, its bus masters have exclusive access to the peripheral.
3. Set the Access Template for available domains.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
106 / 136
NXP Semiconductors
Trusted Execution Environment Tool
7.2.2.2 XRDC2 Domains view In the M7/M4 Domain sub-views, you can view and configure security policies of the XRDC2(eXtended Resource Domain Controller 2) domains. Each CPU can contain up to 16 domains.
7.2.2.2.1 MPU In the MPU sub-view, you can enable and configure MPU (Memory Protection Unit). You can create regions, specify their address, size, and other parameters. The MPU enforces privilege rules, separates processes, and enforces access rules to memory, and supports the standard ARMv7 Protected Memory System Architecture model. MPU is disabled by default and must be enabled by selecting the Enable MPU option.
NOTE Not every device supports MPU.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
107 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 127. MPU
Use the MPU Memory Attributes table to name and configure MPU memory attribute sets. Click the cells of the Memory Type and Inner/Outer Attributes columns to display the available options. Use the MPU Memory Regions table to enable and configure MPU memory regions.
1. Enable the region. 2. Specify the Address.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
108 / 136
NXP Semiconductors
3. Specify either the Size or the End Address. 4. Set the Exec option if you want the region to be able to run code. 5. Set the Permissions. 6. Set the SRD (Sub Region Disable) bits. 7. Set the Shareability, or the caching options.
Trusted Execution Environment Tool
7.2.2.2.2 Domains
In the Domains sub-view, you can view, add/remove, and rename XRDC2 domains. Each CPU supports up to 16 XRDC2 domains.
Figure 128. Domains
Add a new domain by clicking the Add new domain button. Rename the domain by entering a new name in the Name column. Remove a domain by clicking the Remove last domain button.
7.2.2.2.3 Masters In the Masters sub-view, you can add/remove, view, configure XRDC2 domain assignments to available RDC masters. Master Domain Assignment Controller (MDAC) is responsible for the generation of the DID, nonsecure and privileged attributes for every system bus transaction in the device based on pre-programmed Master Domain Assignment (MDA) registers.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
109 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 129. Masters
To add a new domain assignment: 1. Click the Add new domain assignment for the selected master button. 2. Select the Enable checkbox. 3. Enter the Match Input value.
NOTE The match field specifies the reference value for the comparison with the MDAC match input. The match field width varies by MDAC instance from 0 to 16 bits. Unimplemented bits are read as 0. A size of 0 bits generates a hit on all comparisons.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
110 / 136
NXP Semiconductors
Trusted Execution Environment Tool
4. Enter the Mask Input value.
NOTE The mask field specifies which bits are valid for the match comparison. Only bit positions in which the mask value is zero are compared. The mask field width is the same as the mask field which varies by MDAC instance from 0 to 16 bits. A mask value of all ones generates a hit on all comparisons.
5. Select the XRDC2 domain assignment from the dropdown list in the Domain column. 6. Select the security access type from the dropdown list in the Secure column. 7. Select the privileged access type from the dropdown list in the Privileged column. 8. Optional: select the Lock checkbox to prevent further register modifications.
7.2.2.2.4 Peripherals
In the Peripherals sub-view, you can view the access templates for PAC (Peripheral Access Controller) and configure access for all peripherals managed by PAC on the selected RDC domain.
The Peripheral Access Controller submodule performs access control for a set of peripherals connected to a peripheral bus bridge or integrated into a peripheral subsystem.
The Access Template table displays the ID and name of all access templates available for the PAC on the selected device. The information is data driven and display only.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
111 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 130. Peripherals
Use the Peripherals Configuration table to configure access for a peripheral: 1. Select the Enable checkbox. 2. Set the Lock to the desired state. 3. Set the Access Template for all listed domains.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
112 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Alternatively, you can select the options by right-clicking the master and using the dropdown list.
7.2.2.2.5 Memory Regions
In the Memory Regions sub-view, you can view the access templates for MRC (Memory Region Controller) and configure access for all non-peripheral memory spaces managed by MRC on the selected RDC domain.
The Memory Region Controller (MRC) provides domain-based, hardware access control for all system bus references targeted at non-peripheral memory spaces.
The Access Template table displays the ID and name of all access templates available for the MRC on the selected device. The information is data driven and display only.
Figure 131. Memory Regions
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
113 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Use the Memory Regions Configuration table to configure access for a non-peripheral memory space: 1. Select the Enable checkbox. 2. Specify the Start Address. 3. Specify either Size or End Adress. 4. Set the Lock to the desired state. 5. Set the Access Template for all listed domains.
Alternatively, you can select the options by right-clicking the master and using the dropdown list.
7.2.2.2.6 Memory Slots
In the Memory Slots sub-view, you can view the access templates for MSC (Memory Slot Controller) and configure access for all memory spaces managed by MSC on the selected RDC domain.
The Memory Slot Controller (MSC) performs access control for a peripheral or memory space with a fixed address range.
The Access Template table displays the ID and name of all access templates available for the MSC on the selected device. The information is data driven and display only.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
114 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 132. Memory Slots
Use the Memory Slots Configuration table to configure access for a memory space: 1. Select the Enable checkbox. 2. Set the Lock to the desired state. 3. Set the Access Template for all listed domains.
Alternatively, you can select the options by right-clicking the master and using the dropdown list.
7.2.2.3 Miscellaneous In the Miscellaneous sub-view, you can set various configuration options. The list of these options depends on processor data, and varies greatly. All the options influence your register settings, and can be inspected in the Register view. Only some of the options directly influence configuration you have made in the Security Access Configuration view. Point your cursor over individual options to display a tooltip explaining the function of each option.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
115 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 133. Miscellanous (RDC)
7.2.3 Memory Attribution Map
In the Memory Attribution Map view, you can review access levels set for all masters to the code, data, and peripherals memory regions on a domain level. The table is read-only.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
116 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 134. Memory Attribution Map
To set the display options, do the following: 1. Click the Filter access for checkbox to enable filtering options.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
117 / 136
NXP Semiconductors
Trusted Execution Environment Tool
2. Select the master you want to review by choosing from the Master dropdown menu. 3. Optionally, set the security level of the selected master by choosing from the Security mode dropdown menu. This setting
has no effect on the configuration. 4. Optionally, customize the output by de-selecting the Show Details, Show Code, Show Data, Show Peripherals, and Show
External options. 5. Optionally, filter displayed memory regions in the Filter area. Point your cursor over the cells to display a tooltip with information about the security level combination. Double-click the cell to open the pertinent settings in Security Access Configuration.
7.2.4 Access Overview
In Access Overview, you can review security policies you have set in Security Access Configuration view. The view is divided into subviews displaying access overview for specific XRDC2 domains. The vertical axis displays all masters, divided into color-coded groups by their security settings. The horizontal axis displays memory ranges and slave buses/peripherals.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
118 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 135. Access Overview
Point your cursor at an entry to display a tooltip with information about the entry. You can group the displayed information by security or by masters by using the button on the righ-hand side of the toolbar.
7.2.5 Domains Overview
In Domains Overview, you can review access policies of XRDC2 domains you have configured in the subviews of the Domain view. Point your cursor over the cells to display a tooltip with information about the security level combination.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
119 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Figure 136. Domain Overview
7.2.6 Code generation
If the settings are correct and no error is reported, the code generation engine instantly re-generates the source code. You can view the resulting code the Code Preview view of the Trusted Execution Environment tool.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
120 / 136
NXP Semiconductors
Trusted Execution Environment Tool
Code Preview automatically highlights differences between the current and immediately preceding iteration of the code. You can choose between two modes of highlighting by clicking the Set viewing style for source differences. You can also disable highlighting altogether from the same dropdown menu.
Some AHB with security extension-enabled devices support ROM preset as well as C code. You can choose to have the code generated in the ROM preset by selecting the option in the Miscellaneous sub-view.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
121 / 136
NXP Semiconductors
Chapter 8 Advanced Features
8.1 Switching the processor
You can switch the processor or the package of the current configuration to a different one. However, switching to a completely different processor may lead to various issues, such as inaccessible pin routing or unsatisfiable clock-output frequency. In that case, it's necessary to fix the problem manually. For example, go to the Routing Details view and re-configure all pins which report an error or conflict. Alternatively, you may need to change the required frequencies on clock output. To change the processor in the selected configuration, select File > Switch processor from the Menu bar.
Figure 137. Switch processor To change the package of the currently selected processor, select File > Switch processor from the Menu bar.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
122 / 136
NXP Semiconductors
Advanced Features
Figure 138. Switch package
8.2 Exporting the Pins table
To export the Pins table, do the following: 1. In the Menu bar, select File > Export. 2. In the Export wizard, select Export the Pins in CSV (Comma Separated Values) Format. 3. Click Next. 4. Select the folder and specify the file name to which you want to export. 5. The exported file contains content of the Pins view table, and lists the functions and the selected routed pins.
Figure 139. Exported file content
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
123 / 136
NXP Semiconductors
Advanced Features
The exported content can be used in other tools for further processing. For example, see it after aligning to blocks in the image below.
Figure 140. Aligning to block
8.3 Tools advanced configuration
Use the ide\mcuxpressoide.ini file to configure the processor data directory location. You can define the "com.nxp.mcudata.dir" property to set the data directory location. For example: -Dcom.nxp.mcudata.dir=C:/my/data/directory.
8.4 Generating HTML reports
You can generate an HTML report file displaying your configuration of Pins, Clocks, and Peripheral tool for future reference. To generate the HTML report, select Export > Pins/Clocks/Peripherals Tool > Export HTML Report .
8.5 Exporting sources
It's possible to export the generated source using the Export wizard. To launch the Export wizard:
1. Select File > Export from the Menu bar. 2. Select Export Source Files.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
124 / 136
NXP Semiconductors
Advanced Features
Figure 141. Export wizard
3. Click Next. 4. Select the target folder where you want to store the generated files.
Figure 142. Select target folder
5. In case of multicore processors, select the cores you want to export. 6. Click Finish.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
125 / 136
NXP Semiconductors
8.6 Exporting registers
You can export the content of tool-modified registers data using the Export wizard. To export registers, follow these steps:
1. Select File > Export from the main menu. 2. Select the Pins Tool > Export Registers option. 3. Click Next. 4. Select the target file path where you want to export modified registers content. 5. Click Finish.
Advanced Features
8.7 Command line execution
This section describes the Command Line Interface (CLI) commands supported by the desktop application. MCUXpresso Config tools can be executed on command line with these parameters: mcuxpressoide.exe -noSplash application com.nxp.swtools.framework.application [tools commands]. Notes regarding command line execution:
� Command -HeadlessTool is used as a separator of each command chain. � Each command chain works independently. � Every chain starts with -HeadlessTool command and continues to the next -HeadlessTool command, or end. (only exception
are commands from framework which doesn�t need the -HeadlessTool command). � Commands which don�t need the -HeadlessTool command, can be placed before the first -HeadlessTool if chained, or without
-HeadlessTool when not chained. � Commands from each tool are executed in given order. � Commands from framework are not executed in given order. � The following commands are not executed in given order:
-- ImportProject -- Export MEX -- ExportAll � The application can exit with following codes when unexpected behavior occurs: hen parameter is missing: -- When parameter is missing: 1 -- When tool error occurs: 2 Command example: -HeadlessTool Clocks -MCU MKL43Z256xxx4 -SDKVersion ksdk2_0 -ExportSrc C:/exports/src -HeadlessTool Pins -MCU MK65FN2M0xxx18 -SDKVersion ksdk2_0 -ExportSrc C:/exports/src -HeadlessTool Peripherals -MCU MK64FX512xxx12 -SDKVersion ksdk2_0 -ExportSrc C:/exports/src The following commands are supported in the framework:
Table 25. Commands supported in the framework
Command name
Definition and Description parameters
Restriction
Table continues on the next page...
Example
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
126 / 136
NXP Semiconductors
Advanced Features
Table 25. Commands supported in the framework (continued)
Force language
-nl {lang}
Force set language
{lang} is in ISO-639-1 standard
Removal of the '.nxp' folder -nl zh from home directory is recommended, as some text might be cached
Show console
Select MCU Select SDK version Select part number Configuration name
Select tool Load configuration Export Mex
Only 'zh' and 'en' are supported
-consoleLog
Log output is also sent to Java's System.out (typically back to the command shell if any)
None
-MCU
MCU to be selected by framework
Requires �SDKversion command
-SDKversion Version of the MCU to be Requires -MCU command selected by framework
-PartNum
Select specific package of Requires -MCU and -
the MCU
SDKversion commands
-ConfigName
Name of newly created configuration - used in export
Name is used when new configuration is created by -MCU and -SDKversion commands
-HeadlessTool Select a tool that should be None run in headless mode
-Load
Load existing configuration None from (*.mex) file
-ExportMEX
Export .mex configuration None file after tools run
Argument is expected as a folder name
-MCU MK64FX512xxx12 -SDKversion test_ksdk2_0 -PartNum MK64FX512VLL12 -ConfigName "MyConfig"
-HeadlessTool Clocks
-Load C:/conf/conf.mex
-MCU xxx SDKversion xxx ExportMEX C:/exports/ my_config_folder
Export all generated files
-ExportAll
Export generated files (with source code and so on. Code is regenerated before export
Requires -HeadlessTool command
-HeadlessTool Pins -ExportAll C:/exports/ generated
Includes -ExportSrc and in framework -ExportMEX
Argument is expected as a folder name
Create new configuration by importing toolchain project
-ImportProject Creates new
{path}
configuration by importing
toolchain project
Requires -HeadlessTool command
Parameter is path to the root of the toolchain project
-HeadlessTool Pins -ImportProject c:\test\myproject
Table continues on the next page...
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
127 / 136
NXP Semiconductors
Table 25. Commands supported in the framework (continued)
Specify SDK path
-SDKpath {path}
Specify absolute path to the root directory of the SDK package.
@since v3.0
Advanced Features
-SDKpath c:\nxp\SDK_2.0_MKL4 3Z256xxx4
8.7.1 Command line execution - Pins tool
This section describes the Command Line Interface (CLI) commands supported in the Pins tool.
Table 26. Commands supported in Pins
Command name Enable tool Import C files
Definition and Description parameters
Restriction
-Enable
Enable tool if it is disabled Requires -HeadlessTool in the current configuration Pins
-ImportC
Import .c files into configuration
Requires -HeadlessTool Pins
Importing is done after loading mex and before generating outputs
Import DTSI files
-ImportDTSI
Import .dtsi files into configuration
Importing is done after loading mex and before generating outputs
Requires -HeadlessTool Pins
Export all generated files
(to simplify all exports commands to one command)
-ExportAll
Export generated files (with Requires -HeadlessTool
source code etc.)
Pins
Code will be regenerated before export
Includes -ExportSrc,ExportCSV, -ExportHTML and in framework ExportMEX
Argument is expected as a folder name
Export Source files
-ExportSrc
Export generated source files.
Requires -HeadlessTool Pins
Code will be regenerated before export
Argument is expected as a folder name
Export CSV file
-ExportCSV
Export generated csv file. Requires -HeadlessTool Pins
Table continues on the next page...
Example -HeadlessTool Pins Enable -HeadlessTool Pins -ImportC C:/imports/ file1.c C:/imports/file2.c
-HeadlessTool Pins ImportDTSI C:/imports/ file1.dtsi C:/imports/ file2.dtsi
-HeadlessTool Pins -ExportAll C:/exports/ generated
-HeadlessTool Pins -ExportSrc C:/ exports/src
-HeadlessTool Pins -ExportSrc C:/ exports/src
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
128 / 136
NXP Semiconductors
Table 26. Commands supported in Pins (continued)
Code will be regenerated before export
Argument is expected as a folder name
Export HTML report file -ExportHTML
Export generated html report file.
Requires -HeadlessTool Pins
Code will be regenerated before export
Argument is expected as a folder name
Export registers
ExportRegiste rs
Export registers tab into folder.
Code will be regenerated before export
Requires -HeadlessTool Pins
Argument is expected as a folder name
Advanced Features
-HeadlessTool Pins -ExportHTML C:/ exports/html
-HeadlessTool Pins -ExportRegisters C:/ exports/regs
8.7.2 Command line execution - Clocks Tool
This section describes the Command Line Interface (CLI) commands supported by the Clocks tool.
Table 27. Commands supported in Clocks
Command name
Definition and parameters
Enable tool
-Enable
Import C files
-ImportC
Description
Restriction
Example
Enable tool if it is disabled in the current configuration
Requires HeadlessTool Clocks
Import .c files into configuration
Requires HeadlessTool Clocks
Importing is done after loading mex and before generating outputs
-HeadlessTool Clocks Enable
-ImportC C:/imports/ file1.c C:/imports/file2.c
Export all generated files
-ExportAll
Export generated files (with source code and so on. Code is regenerated before export
Requires -
-ExportAll C:/
HeadlessTool Clocks exports/generated
Includes -ExportSrc and in framework ExportMEX
Argument is expected as a folder name
Table continues on the next page...
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
129 / 136
NXP Semiconductors
Advanced Features
Table 27. Commands supported in Clocks (continued)
Export Source files
-ExportSrc
Export generated source files.
Code will be regenerated before export
Argument is expected as a folder name
Requires HeadlessTool Clocks
Export HTML report file -ExportHTML
Export generated html report file.
Code will be regenerated before export
Argument is expected as a folder name
Requires HeadlessTool Clocks
-ExportSrc C:/ exports/src
-ExportHTML C:/ exports/html
8.7.3 Command line execution - Peripherals tool
This section describes the Command Line Interface (CLI) commands supported by the Peripherals tool.
Table 28. Commands supported in Peripherals Tool
Command name
Definition and parameters
Description
Enable tool
-Enable
Enable tool if it is disabled in the current configuration
Restriction
Requires HeadlessTool Peripherals
Example
-HeadlessTool Peripherals -Enable
Import C files
-ImportC
Import .c files into configuration
Importing is done after
Requires HeadlessTool Peripherals
loading mex and before
generating outputs
-HeadlessTool Peripherals -ImportC C:/imports/file1.c C:/ imports/file2.c
Export all generated files
(to simplify all exports commands to one command)
-ExportAll
Export generated files (with source code etc.)
Code will be regenerated before export
Requires -HeadlessTool Peripherals
Includes -ExportSrc, ExportHTML and in framework -ExportMEX
Argument is expected to be a folder
-HeadlessTool Peripherals -ExportAll C:/exports/generated
Export Source files
-ExportSrc
Export generated source files
Requires -HeadlessTool Peripherals
-HeadlessTool Peripherals -ExportSrc C:/exports/src
Table continues on the next page...
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
130 / 136
NXP Semiconductors
Table 28. Commands supported in Peripherals Tool (continued)
Code will be regenerated before export
Argument is expected to be a folder
Export HTML report file -ExportHTML
Export generated html report file
Code will be regenerated before export
Argument is expected to be a folder
Requires HeadlessTool Peripherals
* for internal commands, internal plugin must be installed into production application
Advanced Features
-HeadlessTool Peripherals ExportHTML C:/ exports/html
8.7.4 Command line execution - Project Cloner
This section describes the Command Line Interface (CLI) commands supported by the Project Cloner.
Table 29. Commands supported in Project Cloner
Command name
Definition and parameters
Description
Restriction
Example
Specify SDK path
-SDKpath {path}
Specify absolute path to @since v3.0 the root directory of the SDK package
-SDKpath c:\nxp\SDK_2.0_MKL4 3Z256xxx4
Clone SDK example project
-PG_clone {board} {example} {toolchain} {wrkspc} {prjName}
Clones specified SDK Requires -
-HeadlessTool
example projecte under HeadlessTool PrjCloner PrjCloner -SDKpath
new name
and -SDKpath {path} c:\nxp\SDK_2.0_MKL4
3Z256xxx4 -PG_clone
1. {board} -
@since v3.0
twrk64f120m
subdirectory of
demo_apps/hello kds
the board in
c:\tmp exmpl
SDK package
2. {example} relative path from board sub-dir and name of the example, for example demo_apps/ hello_world; use '/' as a path separator
3. {toolchain} - id of the toolchain to create project
Table continues on the next page...
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
131 / 136
NXP Semiconductors
Table 29. Commands supported in Project Cloner (continued)
(see toolchains toolchain - id)
4. {wrkspc} absolute path where new project shall be created, e.g. projects workspace
5. {prjName} name of the new project
Advanced Features
8.8 Managing data and working offline
With the Data Manager, you can download, import, and export processor data. This feature is especially useful if you want to make the best out of the tools while staying offline.
Figure 143. Data Manager
8.8.1 Working offline
To work offline, you need to first download the processor-specific data. Once the configuration is created for the processor, the internet connection is not needed anymore.
8.8.2 Downloading data
You can download required processor data with Data Manager.
NOTE By default, the data is downloaded and cached automatically during the Creating a new standalone configuration for processor, board or kit process.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
132 / 136
NXP Semiconductors
Advanced Features
To download processor data, do the following:
NOTE Internet connection is required for data download.
1. In Menu bar, select Config Tools >Data Manager. 2. In Data Manager, select the processor/board/kit you want to work with from the list. 3. Click Update / Download and confirm.
The data is now downloaded on your local computer, as shown by the Cached status in Data Manager.
8.8.3 Exporting data
With Data Manager, you can export downloaded processor data in a ZIP format. To export data, do the following:
1. In Menu bar, select Config Tools >Data Manager. 2. In Data Manager, click Export. 3. In Export Processor Data window, select the processor data you want to export. 4. Click Browse to specify the location and name of the resulting ZIP file. 5. Click Finish,
Data is now saved on your local computer in a ZIP format. You can physically (for example, with an USB stick) move it to an offline computer.
NOTE You can also export downloaded data by selecting File > Export > Processor Data > Export Processor Data from the Menu bar.
8.8.4 Importing data
You can import processor data from another computer with Data Manager, provided this data is available locally. To import data, do the following:
1. In Menu bar, select Config Tools >Data Manager. 2. In Data Manager, select Import. 3. In Import Processor Data dialog, click Browse. 4. Specify the location of the ZIP file you want to import and click OK. 5. Choose the data to import by selecting the checkbox in the table. 6. Click Finish.
The data is now imported to your offline computer, as shown by the Cached status in Data Manager. You can now work with the data by selecting New...>Create new standalone configuration for processor, board or kit in the Start development wizard.
NOTE You can also import data by selecting File>Import>MCUXpresso Config Tools>Import Processor Data from the Menu bar.
8.8.5 Updating data
You can keep cached data up to date with the Data Manager.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
133 / 136
NXP Semiconductors
Advanced Features
NOTE If you select the relevant option in Window > Preferences > MXUXpresso Config Tools in the Menu bar, data will be updated automatically or after a prompt.
NOTE Internet connection is required for data update.
To update cached data, do the following: 1. In Menu bar, select Config Tools > Data Manager. 2. In Data Manager, filter outdated data by clicking Select outdated. 3. Click Update / Download and confirm. You can always check versions of your data by clicking Cached only and comparing version information in the Local Version and Remote Version columns. You can clean all cached data by selecting Clean cached. This will remove all processor, board, kit, and component data, as well as SDK info files from your computer.
NOTE Doesn't affect user templates.
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
134 / 136
NXP Semiconductors
Chapter 9 Support
If you have any questions or need additional help, perform a search on the forum or post a new question. Visit https:// community.nxp.com/community/mcuxpresso/mcuxpresso-config .
User's Guide
MCUXpresso Config Tools User's Guide (IDE), Rev. 0, 1/2021
135 / 136
How To Reach Us Home Page: nxp.com Web Support: nxp.com/support
Information in this document is provided solely to enable system and software implementers to use NXP products. There are no express or implied copyright licenses granted hereunder to design or fabricate any integrated circuits based on the information in this document. NXP reserves the right to make changes without further notice to any products herein.
NXP makes no warranty, representation, or guarantee regarding the suitability of its products for any particular purpose, nor does NXP assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation consequential or incidental damages. "Typical" parameters that may be provided in NXP data sheets and/or specifications can and do vary in different applications, and actual performance may vary over time. All operating parameters, including "typicals," must be validated for each customer application by customer's technical experts. NXP does not convey any license under its patent rights nor the rights of others. NXP sells products pursuant to standard terms and conditions of sale, which can be found at the following address: nxp.com/SalesTermsandConditions.
While NXP has implemented advanced security features, all products may be subject to unidentified vulnerabilities. Customers are responsible for the design and operation of their applications and products to reduce the effect of these vulnerabilities on customer's applications and products, and NXP accepts no liability for any vulnerability that is discovered. Customers should implement appropriate design and operating safeguards to minimize the risks associated with their applications and products.
NXP, the NXP logo, NXP SECURE CONNECTIONS FOR A SMARTER WORLD, COOLFLUX, EMBRACE, GREENCHIP, HITAG, I2C BUS, ICODE, JCOP, LIFE VIBES, MIFARE, MIFARE CLASSIC, MIFARE DESFire, MIFARE PLUS, MIFARE FLEX, MANTIS, MIFARE ULTRALIGHT, MIFARE4MOBILE, MIGLO, NTAG, ROADLINK, SMARTLX, SMARTMX, STARPLUG, TOPFET, TRENCHMOS, UCODE, Freescale, the Freescale logo, AltiVec, C5, CodeTEST, CodeWarrior, ColdFire, ColdFire+, CWare, the Energy Efficient Solutions logo, Kinetis, Layerscape, MagniV, mobileGT, PEG, PowerQUICC, Processor Expert, QorIQ, QorIQ Qonverge, Ready Play, SafeAssure, the SafeAssure logo, StarCore, Symphony, VortiQa, Vybrid, Airfast, BeeKit, BeeStack, CoreNet, Flexis, MXC, Platform in a Package, QUICC Engine, SMARTMOS, Tower, TurboLink, and UMEMS are trademarks of NXP B.V. All other product or service names are the property of their respective owners. AMBA, Arm, Arm7, Arm7TDMI, Arm9, Arm11, Artisan, big.LITTLE, Cordio, CoreLink, CoreSight, Cortex, DesignStart, DynamIQ, Jazelle, Keil, Mali, Mbed, Mbed Enabled, NEON, POP, RealView, SecurCore, Socrates, Thumb, TrustZone, ULINK, ULINK2, ULINK-ME, ULINK-PLUS, ULINKpro, �Vision, Versatile are trademarks or registered trademarks of Arm Limited (or its subsidiaries) in the US and/or elsewhere. The related technology may be protected by any or all of patents, copyrights, designs and trade secrets. All rights reserved. Oracle and Java are registered trademarks of Oracle and/or its affiliates. The Power Architecture and Power.org word marks and the Power and Power.org logos and related marks are trademarks and service marks licensed by Power.org.
� NXP B.V. 2016-2021.
All rights reserved.
For more information, please visit: http://www.nxp.com For sales office addresses, please send an email to: salesaddresses@nxp.com
Date of release: 1/2021 Document identifier: MCUXIDECTUG
