HD100 Series Product Data Sheet

Full PDF Document

If the inline viewer fails, it will open the original document in compatibility mode automatically. You can also open the file directly.

Extracted Text

HD100 Series
AC/DC Benchtop Hipot Testers

The HD100 Series of AC/DC Hipots are accurate, durable instruments designed for production testing on all types of electrical units, systems and components. This product is simple to operate and designed for use with minimal training.
The AC/DC output configuration eliminates the need to purchase separate AC and DC Hipots, while the output connected voltmeter ensures accurate voltage measurements regardless of output loading. This series is capable of testing to most industry specifications such as UL, CSA, VDE, IEC, and MIL for dielectric withstand testing.

FEATURES
Continuously adjustable test voltage Shielded output cable Adjustable overload from 10 to 110% of rated
current output Audible / visual alarms provide a clear
indication of overload situation Zero start interlock ensures voltage is at zero
before high voltage can be energized Shorting solenoid grounds output cable and
object under test
BENEFITS
Dual functionality eliminates the need to purchase separate AC and DC Hipots. Automatic grounding of power supply and test object when high voltage is turned OFF. Meets industry specifications for most UL, CSA, VDE, IEC, MIL dielectric withstand tests. Easily mountable into a 19-inch rack.
APPLICATIONS
Capacitors Transformers Wire and Cable Coils and Chokes Connectors Medical Devices Appliances

Hipotronics, Inc. 1650 Route 22. Brewster, NY 10509. United States tel: + 1 845 279 8091 | fax: + 1 845 279 2467 | email: sales@hipotronics.com
Hipotronics has a policy of continuous product improvement. We therefore reserve the right to change design and specification without notice.
1/2

TECHNICAL SPECIFICATIONS

Model Number

AC

System

Voltage

Output (V)

DC

Voltage

Polarity

Metering: Type, Accuracy

Voltage Meter

Current Meter

Dimensions (W x D x H)

Weight

Net Shipping

Input Voltage & Frequency

HD103-* 0-2.5kV

HD106-* 0-5kV

HD115-* 0-12.5kV

HD125-* 0-10kV

HD140-* 0-15.5kV

0-3kV

0-6kV

0-15kV

0-25kV

0-40kV

0-0.6/1.2/3kV

Negative Output, Positive Ground 4.5" analog meters, �2% full scale accuracy 0-1.2/3/6kV 0-3.75/7.5/15kV 0-5/10/25kV
0-50/500/5000�A DC, 0-5mA AC

0-8/16/40kV

21 x 20 x 11 in (53 x 51 x 28cm)

46lbs (21kg) 59lbs (27kg)

51lbs (23kg)
64lbs (29kg)

75lbs (34kg) 85lbs (39kg)

82lbs (37kg) 92lbs (47kg)

* In the model number, designate 'A' for 120V/60Hz input or 'B' for 230V/50Hz input

SYSTEM CONTROLS

OPTIONAL EQUIPMENT & ACCESSORIES

Part Number HHDA13-280 HTP-F TC-25 SPK1-HD100 SPK1-HD140 HTL-S HTL-140 EXT-WARN-1

Description Grounding Stick, 120kV Max Voltage Fixed Test Probe, 25kV Max Voltage
Test Cage, 25kV Max Voltage Spare Parts Kit for HD103, HD106, HD115 & HD125
Spare Parts Kit for HD140 Extra Test Lead for HD103, HD106, HD115 & HD125
Extra Test Lead for HD140 One year extended warranty

HHDA13-280 Grounding Stick (pictured above)

Hipotronics, Inc. 1650 Route 22. Brewster, NY 10509. United States tel: + 1 845 279 8091 | fax: + 1 845 279 2467 | email: sales@hipotronics.com
Hipotronics has a policy of continuous product improvement. We therefore reserve the right to change design and specification without notice.
2/2
