Smart Energy Socket
Manual - turns the device to ON or OFF, as described below Auto - allows setting two types of schedules for Home Energy Management, as described in the next sections
Installation Guide Smart Energy Socket
11. Configuration with Inverters with SetApp. 16. Modifying the Device Operation Mode and Schedules. 17. Verifying the Connection. 18. LED Indications. 18.
Installation Guide Smart Energy Socket - SolarEdge
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.
Extracted Text
Installation Guide Smart Energy Socket Version 1.3 1 Disclaimers Disclaimers Important Notice Copyright � SolarEdge Inc. All rights reserved. No part of this document may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photographic, magnetic or otherwise, without the prior written permission of SolarEdge Inc. The material furnished in this document is believed to be accurate and reliable. However, SolarEdge assumes no responsibility for the use of this material. SolarEdge reserves the right to make changes to the material at any time and without notice. You may refer to the SolarEdge web site (www.solaredge.com) for the most updated version. All company and brand products and service names are trademarks or registered trademarks of their respective holders. Patent marking notice: see http://www.solaredge.com/patent The general terms and conditions of delivery of SolarEdge shall apply. The content of these documents is continually reviewed and amended, where necessary. However, discrepancies cannot be excluded. No guarantee is made for the completeness of these documents. The images contained in this document are for illustrative purposes only and may vary depending on product models. Emission Compliance This equipment has been tested and found to comply with the limits applied by the local regulations. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, you are encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and the receiver. Smart Energy Socket Installation Guide Disclaimers 2 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance may void the user's authority to operate the equipment. Smart Energy Socket Installation Guide 3 Contents Disclaimers 1 Important Notice 1 Emission Compliance 1 HANDLING AND SAFETY INSTRUCTIONS 4 Safety Symbols Information 4 Revision History 5 Overview 6 Installation 10 Configuration 11 Configuration with Inverters with an LCD 11 Configuration with Inverters with SetApp 16 Modifying the Device Operation Mode and Schedules 17 Verifying the Connection 18 LED Indications 18 Button Functionality 20 Troubleshooting 21 Specifications 23 Smart Energy Socket Installation Guide 4 HANDLING AND SAFETY INSTRUCTIONS HANDLING AND SAFETY INSTRUCTIONS During installation, testing and inspection, adherence to all the handling and safety instructions is mandatory. Failure to do so may result in injury or loss of life and damage to the equipment. Safety Symbols Information The following safety symbols are used in this document. Familiarize yourself with the symbols and their meaning before installing or operating the system. WARNING! Denotes a hazard. It calls attention to a procedure that, if not correctly performed or adhered to, could result in injury or loss of life. Do not proceed beyond a warning note until the indicated conditions are fully understood and met. CAUTION! Denotes a hazard. It calls attention to a procedure that, if not correctly performed or adhered to, could result in damage or destruction of the product. Do not proceed beyond a caution sign until the indicated conditions are fully understood and met. NOTE Denotes additional information about the current subject. IMPORTANT SAFETY FEATURE Denotes information about safety issues. Disposal requirements under the Waste Electrical and Electronic Equipment (WEEE) regulations: NOTE Discard this product according to local regulations or send it back to SolarEdge. Smart Energy Socket Installation Guide Revision History Version 1.3 (December 2019) SetApp configuration updated Version 1.2 (August 2019) SetApp configuration added Version 1.1 (May 2018) Terminology and product name updated Revision History 5 Smart Energy Socket Installation Guide 6 Overview Overview The SolarEdge Smart Energy solutions allow increasing the self-consumption of a site. One method used for this purpose is controlling the usage (consumption) of loads using Smart Energy products. The Smart Energy devices divert power to an appliance (load) according to preconfigured schedules, using the following modes: Schedule - The device turns on and off at times set by the user for the user's convenience, regardless of available PV power. Smart Save - The device (typically a boiler or water pump) is controlled automatically to maximize self-consumption. Grid power is used only if PV power is insufficient to meet the user's "Ready by" time. For example, to heat water for 2 hours and have hot water by 18:00, set the Duration to 2 hours and Ready-by to 18:00. The boiler may work before 16:00 if there is available PV power, but in any case you are guaranteed to have hot water by 18:00. Refer to Figure 2 for examples of the device modes of operation. You can re-configure the schedules at any time and manually switch appliances on and off. You can configure the Smart Energy products locally through the inverter, or remotely via the monitoring platform (or monitoring smartphone app). The SolarEdge Smart Energy Socket (referred to as "the device") is a ZigBee wireless AC switch with a built-in energy and power-consumption meter that provides power measurements up to 2.5kW. Based on these measurements and on the system configuration it switches the loads on and off. Smart Energy Socket Installation Guide Overview 7 Figure 1: SolarEdge system with Device Control products The following figure illustrates a typical example of device operation with Smart Save and Schedule modes. Note that in Smart Save mode, the consumption is reduced by taking advantage of excess PV earlier in the day. Smart Energy Socket Installation Guide 8 Overview Figure 2: Examples of device operation To enable the Smart Energy Socket functionality, the following supporting devices must be installed: Smart Energy Socket Installation Guide Energy Meter: Energy Meter with Modbus Connection. Refer to: http://www.solaredge.com/files/pdfs/solaredge-meterinstallation-guide.pdf or http://www.solaredge.com/files/pdfs/solaredge-meterinstallation-guide-na.pdf Overview 9 Energy Meter with Cellular Connection. Refer to https://www.solaredge.com/sites/default/files/se_energy_ meter_cellular_na.pdf ZigBee Plug-in for Smart Energy. Refer to: https://www.solaredge.com/sites/default/files/se-device-controlzigbee-module-installation-guide.pdf https://www.solaredge.com/sites/default/files/se-zigbee-plug-infor-setapp-installation-guide.pdf Smart Energy Socket Installation Guide 10 Installation Installation Figure 3: The Smart Energy Socket CAUTION! This product must be operated under the specified operating specifications, as described in the latest technical specification datasheet. Configure the product so that the load connected is not switched on or off more frequently than specified by the load manufacturer. Do not connect loads that require a continuous current supply (e.g. fridge, freezer). Do not use the product if it is damaged or malfunctioning. Never connect loads that can cause injuries or fire if they are switched on unintentionally (e.g. an iron). Do not let the product come into contact with water or other liquids. The enclosed documentation is an integral part of this product. Keep the documentation in a convenient place for future reference and observe all instructions contained therein. Plug the device into a wall socket , at a maximum distance of 50 m from the inverter. Smart Energy Socket Installation Guide Configuration 11 Configuration Smart Energy devices are configured using the following inverter types: Inverters with an LCD - from firmware version 3.25xx. Inverters with SetApp configuration - from firmware version 4.7.xx. For detailed information about various use cases, refer to https://www.solaredge.com/sites/default/files/home_energy_ management_immersion_heater_controller_use_cases_app_note.pdf. NOTE Verify that the inverter has a ZigBee Plug-in installed and is connected to the monitoring platform (refer to the Inverter Installation Guide for details on setting up communication). Configuration with Inverters with an LCD Required inverter Firmware CPU version : v3.25xx and later. To associate the device with the inverter using the inverter LCD user buttons: 1. Enter the inverter Setup mode as described in the Inverter Installation Guide. 2. Select Communication � ZigBee Conf.. 3. Select: Device Type � HA (Home Automation) Protocol � HAM (Home Automation) When HA Device Type is selected, a Device Manager menu item will appear in the main configuration menu: Country <Italy> Language <Eng> Commu n i c ati on Power Control Display Maintenance Information 4. From the main menu select Device Manager. The Device Manager screen is displayed: Add Devices <0> Smart Energy Socket Installation Guide 12 Configuration with Inverters with an LCD 5. Select Add Devices to start the device association with the inverter. 6. Press the association button on the Smart Energy Socket. The Device Manager LCD screen should display a new line for each discovered device, including the 3 last digits of its serial number, operating mode and operating state. Discovery time may take up to 3 minutes. You can press the inverter LCD light button or the internal ESC button to exit the discovery process when all devices are discovered. Add Devices <3> SE-REG xxx <Auto,OFF> SE- REG- 36x x <A u to, OF F > SE-SW xxx <Man, OFF> SE-S-PLGxxx <Man OFF> Remove All Device types: SE-SW - Smart Energy Relay SE-S-PLG - Smart Energy Socket SE-S-SW - Smart Energy Switch 7. Select the device. The device configuration screen is displayed: Mode<Manual> State<OFF> Device Info Remove Device For the following device configuration steps, you can use either the inverter LCD buttons or the monitoring platform/ app. The steps herein show configuration using the inverter LCD. For configuring using the monitoring platform, refer to https://www.solaredge.com/sites/default/files/configuring_device_ control_with_the_monitoring_app.pdf 8. Select Mode. The mode configuration screen is displayed: Manual Auto Smart Energy Socket Installation Guide Configuration 13 Manual - turns the device to ON or OFF, as described below Auto - allows setting two types of schedules for Home Energy Management, as described in the next sections: Smart Save - set the device operation requirements (ReadyBy and Duration values). This mode is useful for maximizing self-consumption using excess PV power: the device operates autonomously based on configured settings. Schedule - set the device start and stop times regardless of available excess PV power. To set Manual mode: 1. Select Mode � Manual 2. Select ON or OFF to turn the device on or off. To set Auto mode: 1. Select Auto. The following screen is displayed, showing options for setting the device parameters: Mode <Auto> Use Excess PV <Y> Add Schedule Device Properties Device Info Remove Device 2. Select Device Properties and set the following properties: Load Rating <x.xKW> Export TH <xxxxW> Import TH <xxxxW> Min On Time <xxx> Load Rating - the rated power (in kW) of the appliance Export TH (threshold) - optional; the minimum power (in W) above which the excess PV power will be diverted to the appliance. This value can be lower than the load rating. The default value is 5% above the Load Rating. Import TH (threshold) - optional; the maximum power (in W) purchased from the grid and diverted to the appliance. The default value is 5% of the Load Rating. Smart Energy Socket Installation Guide 14 Configuration with Inverters with an LCD NOTE If changing the Export TH and Import TH default values, make sure they sum up to a value that equals or greater than the appliance Load Rating value. Otherwise, the device will turn off when there is insufficient power to divert to the appliance. Min ON Time - (optional); the minimum duration (in minutes) the appliance should remain ON once switched on, even when no excess PV power is available. The default value is 5 minutes. 3. Select Use Excess PV. The following screen is displayed: Set <Yes> Week Days <1234567> Set <Yes/ No> - automatically divert the excess PV to the device (default: Yes). Week Days <optional> - days to repeat the settings (default: every day). 4. Select Add Schedule. The following screen is displayed, showing schedule setting options. You can configure up to four different schedules. Smart Save Schedule Disable Remove Schedule Use Disable to deactivate a schedule or Remove Schedule to delete it. 5. Select and set one of the scheduling options: Smart Save: Set<Smart> Ready by <00:00> Duration <00> Ready by - requested energy must be diverted to the load by this time (default: 00:00; format: hours:minutes). Duration - minimum accumulated time the load must remain on (in minutes; default: 00). Schedule: Set <Schedule> Start Time <00:00> End Time <00:00> Week Days <1234567> Smart Energy Socket Installation Guide Configuration 15 Start/End Time - the time of day by which the Smart Energy Socket must start/ complete its task of delivering energy to the load (default: 00:00; format: hours:minutes). If these values are not set, only the excess PV power is used. Week Days (optional) - days to repeat the settings (default: every day). NOTE In Auto mode , if you configure overlapping time-frames between Schedule and Smart Save options, Schedule mode takes precedence over the Smart Save mode. Smart Energy Socket Installation Guide 16 Configuration with Inverters with SetApp Configuration with Inverters with SetApp Required inverter Firmware CPU version : v4.7xx and later. To associate the Smart Energy device with the inverter using SetApp: 1. Access SetApp as described in the Inverter Installation Guide. 2. Select Commissioning > Communication > ZigBee > Protocol > Home Automation. 3. Return to the Commissioning screen. 4. Select Device Manager. The Smart Energy Manager screen is displayed. 5. Select Add Devices to start device association with the inverter. A 3 minute countdown starts. 6. Within the 3-minute time, press and hold the association button for 2 seconds. SetApp indicates that the device has been associated. 7. After all required devices have been associated, tap Stop in the Smart Energy Manager to exit. To configure the Smart Energy device: 1. Go to the monitoring platform web-site on your computer, or open the monitoring platform application on your mobile device. 2. Click/tap the Smart Energy icon. 3. Select a device and go to Details and Settings. 4. Complete the following information: Rated power Min active time Device icon Device name 5. Return to the device screen and configure: Schedules Ready-by timers Excess Solar Power mode (requires a SolarEdge Energy Meter) Device state Smart Energy Socket Installation Guide Configuration 17 Modifying the Device Operation Mode and Schedules You can re-configure the device operation mode and schedules at any time, using the monitoring platform. To Manually turn the load on or off Do this Select the device from the Device Manager screen. Select Mode � Manual and set the device to either ON or OFF. Disconnect the device(s) from the network Modify the schedule configuration (only for inverters with an LCD) Select Remove Device or Remove All from the device screen. Select the device from the Device Manager screen. Select Mode � Auto and set the parameters of any menu: Smart Save/Schedule. Disable or delete a schedule (only for Select Disable or Remove Schedule from the inverters with an LCD) Schedule screen. Smart Energy Socket Installation Guide 18 Verifying the Connection Verifying the Connection 1. Check the status screens: HA devices status, showing the device name and state: ON, OFF, or an asterisk (*), which indicates no communication with the device: HA Devices State: SE-S-PLG 011 <ON> Communication status, showing the number of communicating HA devices (under Prot) and the number of detected devices (under ##): wwwww Dev Prot ## RS485-1 <---><--><> ZigBee <HA> < 1><1> 2. To check the device details, from the device configuration screen, select Device Info. The following screen is displayed: MAC: xxxxxxxxxxx Last seen:<DD:HH> MFG: SolarEdge Model: SE-S-PLG Power [W]: 0 MAC: the full MAC address of the device Last seen: The date and time when the device communicated with the inverter MFG: The device manufacturer Model: The device model type Power [W]: The energy delivered to the load LED Indications The device has a bi-color LED (red/ green) that provides information about its operation status: LED function Solid green (2 seconds), flashing green (2 seconds) Flashing red Flashing green Reset Indication No ZigBee association with the inverter ZigBee association in process Smart Energy Socket Installation Guide LED function Solid green Solid red Configuration 19 Indication ZigBee association completed and the relay is closed ZigBee association completed and the relay is open Smart Energy Socket Installation Guide 20 Button Functionality Button Functionality The following table describes the device button functions depending on the network association state: Network state Pressing duration Result No ZigBee association with the Any inverter Attempt to associate with the network ZigBee associated with the inverter Manually toggle ON/OFF state (manual Up to 3 seconds (short mode). To return to Auto/Scheduled states, press) configure the device using the mobile application or monitoring platform. More than 10 seconds Disconnect from the network (the LED turns (long press) red and the device resets). 3 - 10 seconds Start a discovery search for nearby devices. The discovery may take up to 3 minutes during which the device is not functional. Not required for normal operation. Smart Energy Socket Installation Guide Configuration 21 Troubleshooting Symptom / Error Possible cause Troubleshooting An asterisk (*) is displayed next to the Device type in the device manager screen indicating that the device is not communicating. In the Communication status screen, the number of detected The device is not associated with the inverter devices does not match the number of communicating devices. The device is powered on but the green LED is OFF Try to solve using these options. If problem is not solved, proceed with the next option: Turn the device OFF and ON. Recheck communication. Reset the device by pressing the button for more than 10 seconds and then repeat the association process. Reconfiguration is not required. From the Device Manager screen select Remove Device and repeat the discovery process. Reconfiguration is required in this case. Contact SolarEdge support. The device is powered on and the green LED is ON The device is Associated with the inverter but is not communicating. All the devices are not communicating No ZigBee error is displayed on the inverter LCD - The inverter has not detected the installed ZigBee Plug-in. Turn OFF the AC to the inverter. Check that the ZigBee Plug-in is inserted correctly inside the inverter. Turn ON the AC to the inverter. Smart Energy Socket Installation Guide 22 Troubleshooting Symptom / Error Possible cause Troubleshooting Try to solve using these options. If problem is not solved, proceed with the next option: Check the ZigBee status screen: Verify that PAN has been established and Channel is not 0: PAN : X X X X X C H : X X /X X X X R SSI: <L > MID:XXXX XX Network problems Turn the inverter OFF and ON (power cycle). Reset all the devices using the association button and begin the discovery process again for all devices. From the Device Manager screen select Remove All and repeat the discovery process for all the devices. Contact SolarEdge support. Error message Device You are attempting limit reached. Remove to associate more Remove an unused device from the devices from the than 10 devices to device list before attempting to add device list is displayed the load managemnt another device. in the LCD. network. Smart Energy Socket Installation Guide Configuration 23 Specifications ELECTRICAL SERVICE SEHAZB-SCKT-MTR-XX(1) Operating Voltage Range - Line to Neutral 90 - 250 AC Frequency 50/60 Maximum Active Power Measurement 2.5 Maximum Load Current 13 COMMUNICATION Supported Communication Protocol ZigBee Home Automation Nominal Transmit Power 3 Operating Frequency Range 2.4 - 2.5 Outdoor (LOS) Range 400 Indoor Range(2) 50 STANDARD COMPLIANCE Radio ETSI EN 300 328 V 1.8.1, ETSI EN 301 489-1, ETSI EN 301 489-17 Safety EN 60335-1, EN 60335-2-30, EN 50371 Immunity EN 55014-2 Emissions EN 55014-1, EN 61000-3-2, EN 61000-3-3 INSTALLATION SPECIFICATIONS Operating Temperature Range 0 to +50 Protection Rating IP30 Dimensions (H x W x D) 110 x 50 x 40 Vac Hz kW A dBm GHz m m �C mm (1)Multiple plug types for various sockets: XX = GB, DE, FR, IT (2)Approximate values. May differ depending on specific installation conditions. Smart Energy Socket Installation Guide
